USER Manual
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
INDUSTRY CANADA STATEMENTS
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted
for successful communication.
This device has been designed to operate with the Johanson Technology ceramic chip
antenna, part number 2450AT43B100, and having a maximum gain of +1.3 dB. Antennas not
included in this list or having a gain greater than +1.3 dB are strictly prohibited for use with this
device. The required antenna impedance is 50 ohms.
Responsibilities to comply with FCC and Industry Canada Regulations
The 2.4GHz Module has been certified for integration into products only controlled by Computer
Security Systems, Inc d.b.a. Saflok under the following conditions:
1. The transmitter module must not be co-located or operating in conjunction with any other
antenna or transmitter.
2. The antenna approved for this device is the Johanson Technology ceramic chip
antenna, part number 2450AT43B100.
As long as the conditions above are met, further transmitter testing will not be required.
However, Computer Security Systems, Inc. d.b.a. Saflok is still responsible for testing their end-
product for any additional compliance requirements required with this module installed (for
example, digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions cannot be met (for certain
configurations or co-location with another transmitter), then the FCC and Industry Canada
authorizations are no longer considered valid and the FCC ID and IC Certification Number
cannot be used on the final product. In these circumstances, the integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a
separate FCC and Industry Canada authorization.
End Product Labeling
The 2.4GHz Module is labeled with its own FCC ID and IC Certification Number. If the FCC ID and IC
Certification Number are not visible when the module is installed inside another device, then the
outside of the device into which the module is installed must also display a label referring to the
enclosed module. In that case, the final end product must be labeled in a visible area with the
following:
“Contains Transmitter Module FCC ID: SAPMESSENGEREM”
“Contains Transmitter Module IC: 7078A-A28990”
or
“Contains FCC ID: SAPMESSENGEREM”
“Contains IC: 7078A-A28990”
The Computer Security Systems, Inc d.b.a. Saflok of the 2.4GHz Module must only use the approved
antenna(s) listed above, which have been certified with this module.
