![](/img.php?id=2680679&img=bg1.png)
Proximity Card Readers
6005R/5395R/5355R
Introduction
This guide is a basic reference to ensure all connections are properly made. Installation and wiring of systems must be in accordance
with the National Electrical Code, ANSI/NFPA 70.
A proximity card reader is a key component of an electronic access control system based on RFID technology. In operation it is capable
of reading data stored on a proximity credential without physical contact and then passes the data obtained to the access control system.
Access control systems typically manage and record the movement of individuals through secure entry points into a building or area.
Mounting Provisions
Each reader may be installed either indoors or outdoors.
Installing on or near metal may cause a reduced read range.
6005R 5395R 5355R
Mullion Mount •
Single Gang Wall Mount* • •
*Plastic or metal
Specifications:
*Single Line LED:
This is the standard operating mode and does not make use of the orange conductor.
The LED is red when the reader is idle and flashes when a card is presented. The LED turns
green when the brown conductor is pulled low by the access control panel.
**Dual Line LED: This mode makes use of both the brown and orange conductors.
The brown conductor controls the red LED and the orange conductor controls the green LED.
LED states are determined by the access control system option and capability.
Cable Requirements
24 AWG minimum, multi-conductor stranded with an overall foil shield, for example Belden 9535 or similar. Per the SIA’s Wiegand speci-
fication, maximum cable length is 500 feet (152 m).
Output Formats
Wiegand (industry standard 26-bit Wiegand and custom Wiegand formats). 5355R is also 8-bit Burst
Grounding
Shield (drain) continuity must run from the reader to the access panel.
Shield (drain) and reader ground must be tied together at the access panel and connect to an earth ground at one point only.
Reader Wiring
Conductor Function
Red DC (5-16 VDC)
Black Ground
Green Data 0
White Data 1
Brown Red LED*
Orange Green LED**
Yellow Card Present
Blue Beeper
Violet fleaPower™
Drain Shield Ground
Proximity Card Readers
Installation
© 2015 RutheRfoRd ContRols Int’l | A doRMA GRoup CoMpAny
www.rutherfordcontrols.com • Phone: 1.800.265.6630 • fax: 1.800.482.9795 • e-mail: sales@rutherfordcontrols.com
isProxreader pCn15051
r07/15Gr-1
![](/img.php?id=2680679&img=bg2.png)
Power
Reader may be powered by the access panel Linear Power Supply
or switch mode (provided the switching frequency is not 125kHz).
Voltage
5 to 16VDC. 12VDC at the reader is recommended for best operation.
Model 6005R 5395R 5355R
Current Draw 30-75mA 35-75mA 70-110mA
fleaPower™ Control Line
To reduce the average current required by the reader, connect the
purple conductor to ground. This will turn the LED off when inactive.
Connection
Connection must be done in accordance with NFPA 70. Do not
connect to a receptacle controlled by a switch.
Listings & Certifications
FCC compliance Statement: This device complies with part 15 of
the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Product can be used without license conditions or restrictions in
all European Union countries, including Austria, Belgium, Den-
mark, Finland, France, Germany, Greece, Ireland, Luxembourg, the
Netherlands, Portugal, Spain, Sweden, and the United Kingdom,
as well as other non-EU countries, including Iceland, Norway, and
Switzerland.
This device complies with Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélec-
trique subi, même si le brouillage est susceptible d’en comprom-
ettre le fonctionnement.
IMPORTANT! Changes or modifications not expressly approved by
Rutherford Controls Int’l Inc. (A DORMA Group Company) could
void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
CAN ICES-3 (A)/NMB-3(A)
Troubleshooting
1. When the reader is first powered on it will beep 4-times and the
Red LED will be on.
2. Presenting a supported access credential will result in the reader
beeping and the LED flashing once.
NOTE: The access panel controls LED functionality, such as
switching the LED to Green.
If the reader does not recognize the card or fob (no beep, no LED
flash) or exhibits short read range, please see the table below for
possible causes and solutions.
Possible Cause Corrective Action
Incorrect cabling Verify gauge, connections and cabling
length
Not enough power 12VDC recommended, 5VDC at reader is
minimum
Incorrect card used Verify if card technology is supported
Reader/access
panel not properly
grounded
Earth ground needed-verify shield and
reader ground are tied at access panel and
connect to ground at one point
Supply generating
interference
Verify switching frequency of power supply
Should any of the corrective actions mentioned above not im-
prove performance, disconnect the reader from the access panel
and power it with a separate power supply or 9VDC battery and
re-test card functionality. By powering the readers separately, most
variables that may lead to reduced performance can be eliminated.
Should the problem persist, please contact RCI directly.
AWID is a trademark of Applied Wireless Identifications Group.
HID is a registered trademarks of HID Global Coporation, an ASSA
ABLOY company. Belden is a registered trademark of Belden
Technologies, Inc. All other trademarks are the property of their
respective owners. RCI reserves the right to change specifications
without notice.
