dreamGEAR DGIPOD-798 RoadTalk Pro User Manual
dreamGEAR, LLC RoadTalk Pro
users manual
Features:
1. Frequency range:88.1-107.9MHZ
2. LCD display with blue backlight
3. Power off automatically when there is no input audio signal with 60 seconds
4. Voice display & LCD display caller ID
5. Power off if no music signal within 60 second.LCD display “OFF” with blue backlight
6. M1 M2 will display on screen when save frequency memory status.
7. After finished 1
st
pairily ,it will be autopairing.for next connection.
Description:
1& 2 --Memory button & sound volume
3 -- Frequency backward button
4 -- Frequency forward button
5 -- Multifunctional button(pairing, on/off)
6 –MIC
7 -- 3.5mm Audio jack
8 --LCD display
9—Caller ID display
10—Bluetooth signal
11—Frequency Memory display
12—OFF
13—iPod connector power charging port 5V 500 mAh
14—redial button
Operation manual:
1. Turn on : Plug DB015 into your car’s cigarette lighter and it will power on
automatically
2. Turn on radio and select a suitable frequency signal & press 3 or 4 to select same
frequency at DB015 to match radio as well.
3. FM Transmitter:
1) Press & hold 1 or 2 for three seconds for frequency memory.
2) Press 1 or 2 to recall FM frequency.
3) Insert provided 3.5 audio cable connecting to DB015 audio jack & Audio device at
the same time for music transmission .
4) Select idea song for your mobile phone & transfer music to car radio through
Bluetooth device .Make sure your mobile phone build in stereo A2DP function
FCC NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH
MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: 1. This device may not cause harmful
interference, and 2. This device must accept any interference received,
including interference that may cause undesired operation
