dreamGEAR DGPS3-3879 Orbiter Wireless Controller for PS3 User Manual
dreamGEAR, LLC Orbiter Wireless Controller for PS3 Users Manual
Manual
dreamGEAR, LLC
Orbiter Wireless Controller for PS3 USER MANUAL
DGSP3-3879(2.4G)
Product Application
This wireless controller is designed for Playstation3 (both slim and original fat console), PC.
Built in 2.4GHz technology. Very popular controller for racing, fighting and other highly active
games on popular consoles such as PS3. Compatible with Windows2000/XP/Vista/WIN7
systems and supports vibration function (with the installation of additional drivers)
Product Features
1)Bulit in 2.4Ghz technology; no signal delay
2)Automatic connect functionality between the controller and the receiver. The LED on the
controller and receiver will maintain the signal with its illumination.
3)Built in power saving system in will stop the signal when voltage is reduced ( The LED light in
the controller will continuously flash). The user can press ‘SELECT” and “R3” button
simultaneously to turn off the vibration function.
4) When the controller is connected with the receiver but no use takes place for 5minutes, it goes
into sleep mode. The controller also allows you to simultaneously press SELECT、START、L3、
R3 button to enable sleep mode. Pressing the PS button will reactivate the controller.
5)Compatible with both ANALOG and DIGITAL mode
6)Built in large capacity rechargeable battery; While the controller is being charged the LED will
remain flashing until the charge is completed. When the light is steady it indicates the battery is
full.
7)Built in dual motor and 256 level 3D analog stick.
8)Easy to navigate soft touch buttons, ideal for active game play.
9)Supports multi-loop signal functionality. No interference between controllers (Max
accommodating 20 sets controller. With the additional installation of memory chip in the controller,
it can support up to 128 controller sets at the same time)
dreamGEAR, LLC
··
Instructions
-Connect the receiver to usb PC outlet or PS3 console. LED will rapidly flash. This shows it
searching for the controller signal.
-Press PS button on controller,4 LED in controller slowly flash. Press PS button again. LED
rapidly flash for about 10 seconds later letting you know the controller has connected with
receiver.
-Receiver LED and controller LED will remain alight. This lets you know the controller and
receiver are connected and functioning properly.
*Remark: The controller LED go out when its connected to computer in digital mode; Pressing
the PS button again will put the controller in analog mode , illuminating the LED once again.
-To manually reset the controller, insert a very thin metal object (such as a paper clip or the tip of
a ball point pen) for 3 seconds into the tiny whole marked by the words “reset.”
Charging instructions
1:Connect controller with usb cable to DC5V outlet or a standard USB hub.
2: The LED in controller will flash acknowledging the charge progress.
BUTTON 6/8
BUTTON 3
BUTTON 1
BUTTON 2
BUTTON 4
RIGHT 3D ANALOG/R3
START
BUTTON UP/DOWN./LEFT/RIGHT
SELECT
LEFT 3D ANALOG/L3
BUTTON 5/7
4LED SIGNAL Instruction
MINI USB
LED IN RECEIVER
SLEEP MODE
USB PLUG
dreamGEAR, LLC
3:When controller and receiver disconnect, 4LED will flash simultaneously until charger progress
is completed.
4:The controller LED will remain illuminated while the battery is fully charged
5:The LED in controller will flash once the controller is no longer adequately charged for proper
functionality. In addition, the motor will stop working once the charge becomes weak enough.
REMARK:we have not built the controller motor inside, therefore we take no responsibility for
any problems arising from the customer opening the controller shell
FCC Caution
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other
antenna or transmitter.
REMARK
We have not built the controller motor inside, therefore we take no responsibility for any problems arising from
the customer opening the controller shell.
For more information, contact
dreamGEAR, LLC
20001 S. Western Avenue Torrance, CA,United States
Tel:0755-2997 0775
Fax:0755-2997 0785
Email:sales3@chtgame.com
