i Tech Dynamic C51-A05054-XX Bluetooth Headset User Manual
i.Tech Dynamic Limited Bluetooth Headset Users Manual
Users Manual
2
13
2
13
15
Getting Started
To use your i.Tech Clip V (“the headset”), please follow
these simple steps:
Charge your headset
Pair your headset with a Bluetooth-enabled mobile handset
12
3
12
12
3
(fig.1)
Charger
(fig.2)
Charging
Socket
Charger Plug
Charging Your Headset
4
11
4
11
Bluetooth Specification: Version 1.2 Class 2
Bluetooth Profile Supported: Headset and Handsfree
Range of Frequency: 2.4GHz Spectrum
Talk Time*: up to 6 hours
Standby Time* : up to 120 hours
Nominal Charging Time: Within 3 hours
Dimensions: 46(L)x18(W)x22.5(H) mm
Weight: 16.7 grams
Product Specifications
Charging Your Headset
Connect the charger to an AC wall outlet (mains socket) and the
charger plug to the headset’s charging socket (fig.1). The LED will be
red while charging.
IMPORTANT Charging indication will be delayed for a few seconds if
the headset has not been used for a long time or the battery is
drained.
Charging Time
Charging the battery fully is normally within 3 hours. When the
battery is fully charged, the LED will turn blue and remain on.
Disconnect the charger from AC wall outlet (mains socket) and the
headset. Press and hold the MFB (fig.1) for 2 seconds to turn the
headset on, please refer to “Turning Your Headset On and Off” .
Talk & Standby Time
The fully charged battery offers up to 6 hours talk time and up to 120
hours standby time. When no calls are in progress, the headset
remains turned on in standby mode.
Low Battery
When the headset is on and the battery becomes low, the status
indicator flashes red and the headset emits a beep every 1 minute.
Please recharge the battery as described above.
10
5
10
5
Adjusting the Volume
Press the volume key repeatedly until you reach the desired volume
level. The listening volume may be affected by the volume setting of
the caller’s handset as well. Re-adjust the listening volume again
when necessary.
Resetting or Removing Pairing
You may reset the headset to its original settings anytime. To do this
you also clear all current pairing settings.
1. Ensure the headset is off.
2. Press and hold the volume key for 20 seconds until LED flashes Red
and Blue alternatively.
3. Release the volume key.
4. Press and hold the volume key again until you hear two beeps.
5. Recharge the headset for a few seconds.
The headset is then turned off and returned to its original settings. All
previous pairing settings are cleared.
Rejecting a Call (Handsfree Profile ONLY)
Press and hold the volume key then press and hold the MFB until the
incoming call is rejected.
Transferring a Call (Handsfree Profile ONLY)
Press and hold the volume then press and hold the MFB until the
audio is transferred from headset to your mobile handset during
conversation.
Turning On the Headset
Press and hold the MFB for two seconds until you hear a short beep.
The status indicator will then flash blue.
IMPORTANT: Press the MFB again each time when you want to turn on
the headset to re-activate pairing so as to resume the connection
between the headset and the mobile handset. For pairing, please
refer to the “Pairing Your Headset” section for details.
Turning Off the Headset
Press and hold the MFB for approximately 3 seconds until you hear a
long beep. The status indicator will stop flashing.
IMPORTANT To disconnect the Bluetooth connection, press the MFB
firmly to turn off your headset. If you will not be using the headset
for a while, you should consider turning off the Bluetooth function
on your mobile phone as well.
Turning Your Headset On and Off
6
9
6
9
Pairing Your Headset
Voice Dialling from Your Headset
If your mobile handset is equipped with a voice dialling function,
simply press the MFB on your headset, and when you hear a beep
say the voice tag.
IMPORTANT For voice dialling, you must record the voice tag (the
person’s name) into your mobile handset first before using the voice
dialling function. Please refer to your mobile handset’s user guide on
how to record the voice tags .
Last Number Redialling from Your Headset
Short press the MFB on your headset twice.
IMPORTANT The above functions are only applicable to mobile
handsets with Bluetooth Handsfree Profile. Functionality varies
depending on the mobile handset model you have. Please refer to
your mobile handset user guide for additional information.
Using Your Headset
8
7
8
7
1. Place the headset and the mobile handset no more then 1 meter
apart and ensure there is nothing in between.
2. Ensure the headset is OFF.
3. Press and hold the MFB approximately 8 seconds until the headset
status indicator alternately flashes blue and red.
4. Activate your mobile handset’s Bluetooth function by referring to
your mobile handset user guide for details.
5. Set the mobile handset to search for Bluetooth devices within 1
meter range as instructed in the mobile handset user guide and
select “i.Tech Clip V” from the list.
6. Enter the preprogrammed passkey “0000” and press “OK” to pair
your headset and mobile handset. When the pairing is complete,
the headset status indicator will flash blue rapidly 5 times followed
by a long beep.
7. Press “Return” to go back to your mobile handset’s main menu. For
certain mobile handset models, a headset icon will be shown on the
screen. You should now be able to make and receive calls using
your headset.
IMPORTANT If the pairing cannot be completed within 2 minutes while
the pairing mode is activated, the headset status indicator flashes
purple followed by 3 beeps and the headset is turned off. Please repeat
the above pairing procedures.
Pairing Your Headset Using Your Headset
Answering a Call
When there is an incoming call, you will hear ringing through the
earphone and the built-in buzzer. Press the MFB to accept the call or
answer the call via your mobile handset in the normal way.
IMPORTANT You can stop the buzzer alert by pressing the volume key
once. The buzzer will ring again when there is another incoming call.
Ending a Call
Press the MFB to end your call or end the call via your mobile handset
in the normal way.
Dialing from Your Mobile Handset
Simply make calls on your mobile handset in the normal way.
Muting the Built-in Buzzer
Press and hold the volume key for two seconds to mute the buzzer
while in standby mode. The status indicator will flash red. Press the
volume key for 3 seconds to deactivate the muting function while in
standby mode. The status indicator will flash blue.
IMPORTANT: If you do not wish to be disturbed at all, you may
consider resetting the mobile phone setting to restrict incoming calls.
Please refer to your mobile phone user guide for set up details.
Care and Maintenance
Headset
•
Consider turning your headset off before placing it in your pocket
or bag. If the MFB is accidentally depressed, your mobile handset
may place an unintended call.
•
Do not expose the headset to liquid, moisture or humidity as it is
not waterproof.
•
Do not use abrasive cleaning solvents to clean the headset.
•
Do not expose the headset to extremely high or low temperatures.
•
Do not dispose of the headset in a fire as it will result in explosion.
•
Do not expose your headset to contact with sharp objects as this
will cause scratches and damage.
•
Do not stick anything inside the headset as this may damage
internal components.
•
Do not attempt to disassemble the headset as it does not comtain
serviceable components.
•
If you do not use the headset for long periods, be sure to store it in
a dry place, free from extreme temperatures and dust.
Built-in Battery
•
Do not attempt to replace the headset’s battery yourself as it is
built into the headset and is not changeable.
•
Charge the battery in accordance with the instruction supplied
with this user guide.
•
Only use the manufacturer supplied charger when charging the
headset.
Charger
•
Only use the manufacturer supplied charger when charging the
headset.
•
Do not disassemble the charger as it may expose you to
dangerous voltages or other risks. Incorrect reassembly can cause
electric shock when the headset is subsequently used.
•
Do not use the charger outdoors or in damp areas.
•
Only charge the headset’s built-in battery in accordance with the
instructuins in this user guide.
•
Avoid charging the headset in extremely high or low tempera-
tures.
Safety Information
•
Check local laws regarding use of a mobile handset and headset
whilst driving. If you use the headset while driving, ensure your
attention and focus remain on the road and you drive in a
responsible and safe manner.
•
Never allow children to play with the headset – small parts may
be a choking hazard.
•
Observe all signs that require an electrical device or RF radio
product to be switched off in designated areas. These could
include hospitals, blasting areas, and potentially explosive
environments.
•
Turn off your headset prior to boarding an aircraft. Do not use
your headset in an aircraft.
•
Never mount or store your headset over any air bag deployment
area as serious injury may result when an air bag deploys.
•
Do not open or mutilate the built-in battery.
•
Dispose of batteries according to local regulations. Do not
dispose as household waste.
•
Dispose of the packaging and this product in accordance with the
latest provisions.
M
i.Tech Clip V Overview
14
15
Troubleshooting
If you are unable to connect your headset with your mobile handset or
Bluetooth enabled device, please try the following:
•
Ensure your headset is turned on and is properly charged.
•
Ensure the headset is paired with your mobile handset.
•
Ensure your mobile handset’s Bluetooth feature is activated.Please
refer to your mobile handset user guide for specific instruction.
•
Ensure the headset is within a maximum of 10 meters of your
mobile handset(s) and there are no obstructions, such as walls or
other electronic devices in between.
If the above suggestions do not solve your problem, please recharge
the headset and remove your mobile phone battery for a while. Then
start pairing again.
The i.Tech Clip V Headset is compliant with and adopts the Bluetooth
Specification 1.2. However, interoperability between the device and
other Bluetooth-enabled products is not guaranteed because it
depends on compatibility. For more information on the compatibility
between the device with other Bluetooth-enabled products, please
check with the manufacturer or browse:
http://www.itechdynamic.com
14
Table of Contents
i.Tech Clip V Overview ................................................................................................... 1
Getting Started .............................................................................................................. 2
Charging Your Headset ................................................................................................ 3-4
Charging Time ................................................................................................... 4
Talk and Stand-by Time .................................................................................. 4
Low Battery ....................................................................................................... 4
Turning your Headset On and off ............................................................................. 5
Pairing Your Headset ................................................................................................... 6-7
Using Your Headset ...................................................................................................... 8-10
Answering a Call ............................................................................................... 8
Ending a Call ...................................................................................................... 8
Dialing from Your Mobile Handset ............................................................... 8
Muting the Built-in Buzzer ……....................................................................... 8
Muting the Microphone ………........................................................................ 9
Voice Dialing from Your Headset .................................................................. 9
Last Number Redialing from Your Headset ................................................ 9
Rejecting a Call (Handsfree Profile ONLY) …………..................................... 10
Transferring a Call (Handsfree Profile ONLY) …………................................ 10
Adjusting the Volume .................................................................................................. 10
Resetting the Headset .................................................................................................. 10
Care and Maintenance ................................................................................................. 11-12
Headset .............................................................................................................. 11
Built-in Battery ................................................................................................. 12
Charger ............................................................................................................... 12
Safety Information ........................................................................................................ 13
Troubleshooting ............................................................................................................. 14
Product Specifications .................................................................................................. 15
Declaration of Conformity (DoC) ................................................................................ 16
We, i.Tech Dynamic Ltd., declare that the following product:
Product Name: i.Tech Clip V
Model No.: C51-A05054-XX
Is in conformity with the following essential requirements of Council
Directive 1999/5/EC ( referred to as R&TTE Directive ) : Article 3.1a, 3.1.b
and 3.2. and the product is manufactured in accordance with Annex II of
above directive.
A copy of the Declaration of Conformity can be found at:
http://www.itechdynamic.com
Declaration of Conformity ( DoC )
S3J-51A05054-01
01/2006
2005 Hutchison Harbour Ring Enterprises Limited
All rights in this publication are reserved and no part may
be reproduced without the prior written permission of
the publisher. The contents of this publication are
believed to be correct at the time of going to press, but
any information, specifications, products or services
mentioned may be modified, supplemented or
withdrawn without further notice.
The Stylized i.Tech logos are trademarks owned by
Hutchison Harbour Ring Enterprises Limited or its
affiliates.
Bluetooth
®
and the Bluetooth logos are trademarks
owned by Bluetooth SIG, Inc, USA and licensed to i.Tech
Dynamic Limited.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Caution: Changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate the equipment.
i.Tech declares under our sole responsibility that the
headset is in conformity with the provisions of the
following Council Directives: 1999/5/EC
16
Up to 1 metre
Muting the Microphone
You can put a call on hold by muting the microphone.
Press and hold the volume key for two seconds until status indicator
flashes Red to mute built in Microphone and press and hold the volume
key for 3 seconds to deactivate the muting function while conversation.
The headset only works with Bluetooth-enabled mobile phones. Prior
to using and pairing your headset for the first time, please check if your
mobile phone is Bluetooth-enabled.
The pairing instructions for a typical Bluetooth-enabled mobile phone
are explained on the next page. The headset pairing procedure may
vary depending on the model of your mobile phone. Please contact the
manufacturer of your mobile phone or its agent for further informa-
tion.
If you are setting up the headset and your mobile phone in a noisy
environment, we advise you to put on the earphone first so that the
beep will be more audible.
1. Microphone
2. Volume Key
3. Status Indicator
4. Charging Socket
5. Built-in Buzzer
6. Earphone
7. Multi-function Button (MFB)
8. Built-in Rechargeable Battery
1
2
3
4
5
6
7
8
The headset comes with a built-in rechargeable battery. Prior to
using the headset for the first time, it is recommended to fully
charge the battery first.
