i Tech Dynamic C51-A05101-XX i.Tech BlueCON nano User Manual
i.Tech Dynamic Limited i.Tech BlueCON nano
User Manual
i.Tech BlueCON nano
2x
3
(Back Cover)
Thank you for purchasing the i.Tech BlueCON Nano, a wireless
audio Bluetooth dongle that allows you to plug in your iPod
Nano and connect to your Bluetooth stereo headphones. The
BlueCON Nano offers you a novel wireless alternative for you
to enjoy quality hi-fi stereo music from your Mp3 player. The
protective cover can also be flipped over and acts as a docking
station so you can enjoy your music on the move or around
the home and in the office.
Read more about the features and functions in this user guide
and learn how the i.Tech BlueCON Nano lets you have a total
control of your Mp3 music.
Table of Content
i.Tech BlueCON nano Overview ………..…………………………... .…….. 2
Getting Started ………..…………………………... .………….........……... ..... 3
Charging Your Dongle ………..…………………………... .………..….......... 3
Normal Charging Time ………..…………………………......…...… 4
Music Play Time ………..…………………………....…………..... ..... 4
Battery Low Indication ………..………………………….......…… 4
Turning Your Dongle On and Off ………..…………………………... .….. 5
Charging Your Dongle and iPod® nano ………..…………………….... 5
Steps to Connect Your iPod® nano to the Dongle ……... .....……... 6
Pairing Your Dongle ………..…………………………....…………... ............ 7
Care and Maintenance ………..…………………………....…………........... 8
Built-in Battery ………..…………………………....……... .…………... ..... 9
Charger ………..…………………………....………... .…………....……......... 9
Safety Information ………..…………………………....…………... .……...... 10
Troubleshooting ………..…………………………....…………... .……........... 11
Declaration of Conformity (DoC) ………..…………………………... .…… 12
Product Specifications ………..…………………………....…………... .…… 13
2 1
i.Tech BlueCON nano Overview
1. Protective Cover Release Button
2. Multi-function Connector
3. Multi-function Button (MFB)
4. Status Indicator
5. Protective Cover
6. Charging Socket (mini USB)
Fig. 1
1
5
4 6
2
3
4
Getting Started
To use your i.Tech BlueCON nano (“the Dongle”), please commence
the following steps:
1. Charge your dongle (the normal charging time is approxi-
mately three hours)
2. Pair your dongle with a Bluetooth stereo headset that has the
A2DP profile and also works with AVRCP enabled-devices (for
best results we recommend you use with the Clip R35 or the
i.Tech range of Bluetooth stereo products.)
3. Connect your dongle with iPod® nano.
2 3
2 3
Charging Your Dongle
Charger
Charging Your Dongle
The dongle comes with a built-in rechargeable battery. Prior to using
the dongle for the first time, it is recommended that you fully charge
the battery.
Fig. 2
Charging
Socket
Charger Plug
Connect the charger plug to the dongle’s charging socket (refer to
Figure 2) and plug the charger to an AC wall outlet (the mains). The
status indicator will be red while charging.
IMPORTANT
1. If the dongle has not been used for a long time or the battery is
drained, the status indicator may delay the charging indication
for a few seconds.
2. You can listen to music as usual while your dongle and iPod®
nano are on charge.
Normal Charging Time
It normally takes about three hours to fully charge the battery.
When the battery is fully charged, the status indicator will turn
blue and remain blue. Disconnect the charger from the AC wall
outlet and the charger plug from the dongle. Press and hold the
MFB (refer to Figure 1) for two seconds to turn on the dongle.
Please refer to the section on “Turning Your Dongle On and Off” for
details.
Music Play Time
The fully charged battery can offer up to 10 hours of music play
time.
Battery Low Indication
When the dongle is on and the battery becomes low, the status
indicator will start flashing red. Please recharge the battery
according to the instructions described above.
4 5
4 5
Turning Your Dongle On and Off
Turning On
Press and hold the MFB for approximately two seconds until you
see the status indicator start flashing blue.
NOTE: Each time when you turn on the dongle by pressing and
holding the MFB, it will automatically reactivate the pairing to
resume the connection between the dongle and the headset. For
pairing procedure, please refer to the section on “Pairing Your
Dongle”.
Turning Off
Press and hold the MFB for approximately three seconds until you
see the status indicator stop flashing.
Charging Your Dongle and iPod® nano
You may charge your dongle and iPod® nano together. Connect
your iPod nano to the dongle (refer to the following section on
“Steps to Connect Your iPod nano to the Dongle”), and then charge
your dongle accordingly (refer to the section on “Charging Your
Dongle”). While charging, you can continue listening to the music
playing from your iPod® nano.
Steps to Connect Your iPod® nano to the Dongle
1. Slide the protective cover release button downward
2. Pull out the protective cover gently
3. Slide in your iPod® nano to connect with the multi-function
connector on the dongle in the direction indicated below.
4. Close the protective cover to protect your iPod® nano.
5. The iPod nano protective cover can also be also be used as a
music stand so you can prop your nano on your desk on work
top at home.
1
2
3
5
6 7
6 7
Pairing To Your Dongle
Prior to using your dongle for the first time, you must pair it with
a Bluetooth stereo headset. For best results we recommend you
pair it with the i.Tech Clip R35 which features remote control
functions or any of the Bluetooth Stereo headphone range e.g
BlueBAND, Clip IIs & IIIs or the Clip S35
The information in this section describes the pairing procedure
for the dongle with a typical Bluetooth headset. However, the
pairing procedure may vary with different models of Bluetooth
headset. Please refer to the user guide provided by the headset
manufacturer for pairing details.
1. Before pairing, ensure that the headset is off.
2. Press the MFB button on the dongle and hold it for eight
seconds until the status indicator starts flashing blue and red
alternately. The dongle is now in pairing mode.
3. Turn on your Bluetooth headset (A2DP profile enabled) and
start the pairing mode. Place the dongle and the headset
where they are no more than one metre apart, and ensure
that there are no obstructions in between or other Bluetooth
devices nearby.
Pairing Your Dongle
4. Continue to press and hold the MFB on both devices when
their status indicators are still flashing blue and red
alternately.
5. Once the pairing has been successfully completed, the status
indicators on both devices will change to flash blue only.
6. Now you can enjoy the music stored in your iPod nano with
the dongle.
Note :
• If the status indicator flashes purple instead of blue, or is off,
please repeat steps 1 to 6 above to start pairing again.
• If you have a Bluetooth mobile handset that you would like
to use together with the dongle and the headset, please pair
your mobile phone with the headset first BEFORE pairing the
headset with the dongle.
• The default passkey of the dongle is “8888”.
8 9
8 9
Care and Maintenance
Dongle
• Do not drop the dongle as it is fragile.
• Do not force open the protective cover.
• Do not expose the dongle to liquid, moisture or humidity as it
is not waterproof.
• Do not use abrasive cleaning solvents to clean the dongle and
its protective cover.
• Do not expose the dongle to extremely high or low tempera-
tures.
• Do not dispose of the dongle in a fire as it may explode.
• Do not let your dongle come into contact with sharp objects as
this will cause scratches and damage.
• Do not stick anything inside the dongle as this may damage
internal components.
• Do not attempt to disassemble the dongle as it does not
contain serviceable components.
• If you will not use the dongle for a long period, please store it
in a dry place that is free from extreme temperatures and dust.
Built-in Battery
• Do not attempt to replace the dongle’s battery yourself as it is
built-in and is not changeable.
• Charge the battery in accordance with the instructions
supplied with this user guide.
• Only use the charger supplied by the dongle’s original
manufacturer to charge the dongle’s battery.
Charger
• Only use the original manufacturer supplied charger when
charging the dongle. Other chargers may look the same, but
they could be dangerous.
• Do not disassemble the charger as it may expose you to
dangerous voltages or other risks. Incorrect reassembly can
cause electric shock when the dongle is subsequently used.
• Do not use the charger outdoors or in damp areas.
• Charge the dongle’s built-in battery in accordance with the
instructions in this user guide.
• Avoid charging the dongle in extremely high and low
temperatures.
• Unplug the charger from the AC wall outlet when the dongle is
fully charged. Do not leave the fully charged dongle connected
to a charger for a long period as overcharging may shorten its
lifetime.
10 11
10 11
Safety Information
• Check local laws regarding the use of Bluetooth wireless products
whilst driving. You are reminded to pay full attention to the road
conditions if you are using the dongle whilst driving and ensure
you drive in a responsible and safe manner.
• Never allow children to play with the dongle – small parts may be
of choking hazard.
• Observe all signs that require an electrical device or RF radio
product to be switched off in designated areas. These could
include hospitals, blasting areas, and potentially explosive
atmospheres.
• Turn off your dongle prior to boarding an aircraft. Do not use your
dongle inside an aircraft.
• Never mount or leave your dongle above any air bag deployment
area as serious injury may result when an air bag deploys.
• Do not use the dongle in a sauna or steam room.
• Always unplug the charger first before cleaning the dongle.
• Do not attempt to modify the dongle for other purposes.
• Do not attempt to force open or mutilate the built-in battery.
• Dispose of the packaging and the dongle in accordance with local
regulations. Do not dispose of the dongle with household waste.
Troubleshooting
The Dongle
If you are unable to connect your dongle to the headset, please try
the following:
• Check your headset to see if it has the A2DP profile and works
with AVRCP enabled-devices.
• Ensure the dongle is turned on and the battery is fully charged.
• Ensure the dongle is paired with your headset within one metre,
and when pairing there are no other Bluetooth devices nearby.
• Ensure your headset is paired according to the procedure. Please
refer to the headset user guide for detailed instructions.
• Ensure the dongle is within a maximum of 10 metres of your
headset and there are no obstructions, such as walls or other
electronic devices, in between.
If the above suggestions can not help you resolve your problem,
please reset your headset and the dongle. To reset the dongle,
simply recharge the battery of the dongle again for a few minutes.
Then repeat the pairing procedure as described in the section
“Pairing Your Dongle”.
12 13
12 13
The i.Tech BlueCON nano is compliant with and adopts the Bluetooth
Specification V1.2. However, interoperability between the device and
other Bluetooth-enabled products is not guaranteed because it
depends on compatibility. For more information on the compatibil-
ity between the dongle with other Bluetooth-enabled products,
please check with manufacturer or visit:
http://www.itechdynamic.com
Declaration of Conformity (DoC)
We, i.Tech Dynamic Ltd., declare that the following product:
Product Name: i.Tech BlueCON nano
Model No.: C51-A5101-XX
Is in conformity with the following essential requirements of Council
Directive: 1999/5/EC (referred to as R&TTE Directive): Article 3.1a, 3.1.b
and 3.2. and the product is manufactured in accordance with Annex II
of the above directive.
A copy of the Declaration of Conformity can be found at:
http://www.itechdynamic.com
Product Specifications
Bluetooth Specification: Version 1.2 Class 2
Bluetooth Profiles Supported: A2DP and AVRCP
Range of Frequency: 2.4GHz spectrum
Reception Distance: Up to 10 metres
Normal Charging Time: Within 3 hours
Music Play Time*: Up to 10 hours
Dimensions: 113 mm (L) x 43.5 mm (W) x 14 mm (H)
Weight : 36.6 grams
* May vary due to the user’s habit, different modes of operation
and conditions.
* The manufacturer has the right to modify infos, product spec.
and product IDs whithout any advice
14 15
14 15
MENU
MENU
http://www.itechdynamic.com 02/2006
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly
approved by the part responsible for compliance could void the
user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference
that may cause undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. End users must follow the
specific operating instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
Dispose of the packaging and this product in accordance with the
latest provisions.
Printed in China P/N:S3J-51A05101-01
2005 Hutchison Harbour Ring Enterprises Limited
All rights in this publication are reserved and no part may be
quoted or reproduced without the prior written permission of
the company. The contents of this publication are believed to
be correct at the time of going to print, but any information,
specifications, products or services mentioned may be
modified, supplemented or withdrawn without any prior
notice.
The Stylized i.Tech logos are trademarks owned by Hutchison
Harbour Ring Enterprises Limited and/or its affiliates.
Bluetooth® and the Bluetooth logos are trademarks owned by
Bluetooth SIG, Inc, USA and licensed to i.Tech Dynamic Limited.
iPod® is the trademark or registered trademark of Apple
Computer, Inc., in the United States and other countries.
Caution: Changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
i.Tech declares under our sole responsibility that the product is
in conformity with the provisions of the following Council
Directives: 1999/5/EC.
Notes on Environmental Protection
After the implementation of the European Directive
2002/96/EU in the national legal system, the following
applies: Electrical and electronic devices must not be disposed
of with domestic waste. Consumers are obliged by law to
return electrical and electronic devices at the end of their
service lives to the public collection points that are set up for
this purpose or designated points of sale. However, such
details are defined by the national law of the respective
country. This symbol on the product, the instruction manual or
the packaging indicates that the product is subject to these
regulations. By recycling, reusing the materials, or other forms
of utilizing old devices, you are making an important
contribution in protecting our environment.
0 1
