ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
ZEAL-C02
User's Manual
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
Introduction
This document has been described how to use the ZEAL-C02. ZEAL-C02 is a Bluetooth
module. This module is connected to the UART. This module is operated with a simple
command.
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
Operating state
ZEAL has several operating state. State transition will use the command.
Command state
ZEAL can execute the command. The input data are all recognized as a command.
Scan state
ZEAL is a state that is waiting for a connection as a Bluetooth slave.
Online state
ZEAL has been connected with the pair device and Bluetooth. ZEAL can perform data
communication with connection device.
Escape state
ZEAL is in connection, and command input is possible.
Scan escape state
ZEAL is in scanning, and command input is possible.
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
Boot mode
ZEAL has four boot modes. These will be switched by the mode pin.
MODE0
MODE0MODE0
MODE0
MODE1
MODE1MODE1
MODE1
Nomal boot mode HIGH HIGH
Pre-settings value boot mode
LOW HIGH
Automatic boot mode HIGH LOW
Firmware rewrite boot mode LOW LOW
Nomal mode
This mode is start in command state with the default settings.
*9600bps, 8bit, non parity, 1stopbit
Pre-setting value boot mode
This mode is start in command state with the pre-settings.
Automatic boot mode
This mode is start in the master or slave with the pre-setting.
Firmware rewrite boot mode
This mode is used when test or firmware rewriting.
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
COMMAND
ZEAL will operate in the original BT COMMAND. Command begins with BT, and
followed by a command character, and termination input the CR. (CR=0x0D)
List of commands
Co
CoCo
Command
mmandmmand
mmand
Description
DescriptionDescription
Description
A Scan start
C Connect
D Disconnect
I Inquiry start
LT Address setting of the link partner
LO Automatic mode setting
LB Baud rate setting
M Show BD address
Y Initialization
Z Show firmware version
Escape command
This is a special command to be ready for input command temporarily.
Escape command is a continuous input three times ‘@’.
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
Result Code
This is the string to notify the results of executing the command. Termination is CR +
LF is output. (LF=0x0A)
List of result codes
Result Code
Result CodeResult Code
Result Code
Description
DescriptionDescription
Description
ACKN Receipt of the command
CONN Connected
DISC Disconnected
TERM Terminate of the command
E000 Unknown Error
E100 Undefined command Error
E101 Parameter Error
E200 State cannot execute this command
E300 Pair could not be found
E301 Failed to authenticate
E400 Incorrect setting value
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
How to use
The connection process
[ZEAL will be used in Bluetooth master]
Exp : BD Address of the connected devices is 00097E00FFFF.
1. To set the BD address of the device to connect to ZEAL
BTLT00097E00FFFF[CR] <- Command
ACKN[CRLF] <- Response
2. The beginning of a connection
BTC [CR] <- Command
ACKN[CRLF] <- Response
CONN[CRLF] <- Response
*Can send and receive data
[ZEAL will be used in Bluetooth slave]
1. The beginning of a scan
BTA[CR] <- Command
ACKN[CRLF] <- Response
3. When it is connected from Bluetooth master device.
CONN[CRLF] <- Response
*Can send and receive data
Disconnection prosess
1. 1.The beginning of a disconnect
@@@BTD[CR] <- Command
ACKN[CRLF] <- Response
DISC[CRLF] <- Response
*No Bluetooth connection
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
Conditions on using ZEAL-C02 regulatory approvals:
I. System integrator must ensure that its product (the “SYSTEM
INTEGRATOR Product”) is electrically identical to ADC Technology
ZEAL-C02. System integrator acknowledges that any modifications to ADC
Technology ZEAL-C02 may invalidate regulatory approvals in relation to the
SYSTEM INTEGRATOR Product, or may necessitate notifications to the
relevant regulatory authorities.
II. System integrator is responsible for ensuring that antennas used with the
product are of the same type, with same or lower gains as approved and
providing antenna reports to ADC technology.
III. System integrator is responsible for regression testing to accommodate
changes to ADC Technology reference designs, new antennas, and portable
RF exposure safety testing/approvals.
IV. Appropriate labels must be affixed to the SYSTEM INTEGRATOR Product
that complies with applicable regulations in all respects.
V. A user’s manual or instruction manual must be included with the System
integrator product that contains the text as required by applicable law.
Without limitation of foregoing, an example (for illustration purposes only) of
possible text to include is set forth below:
USA
USA USA
USA –
––
–
Fede
FedeFede
Federal Communication Commission (FCC)
ral Communication Commission (FCC)ral Communication Commission (FCC)
ral Communication Commission (FCC)
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
INFORMATION TO USER:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy. If not installed and
used in accordance with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by tuning the equipment off and on, the
user is encouraged to try and correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna
- Increase the distance between the equipment and the receiver.
- Connect the equipment to outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Customer must include the FCC ID on the end product.
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
FCC Radio
FCC RadioFCC Radio
FCC Radio-
--
-Frequency Exposure and Approval Conditions:
Frequency Exposure and Approval Conditions:Frequency Exposure and Approval Conditions:
Frequency Exposure and Approval Conditions:
1. Antennas must be installed to provide at least 20cm separation distance from the
transmitting antenna to the body of user during normal operating condition.
2. The antenna(s) used for this transmitter must not be collocated or operating in
conjunction with any other antenna or transmitter within a host device, except in
accordance with FCC multi-transmitter product procedures.
3. Only those antennas with same type and lesser gain filed under this FCC ID
number can be used with this device.
4. The regulatory label on the final system must include the statement: “Contains
FCC ID:ATL001ZEAL-C02 and/or IC:10171A-001ZEALC02” or using electronic
labeling method as documented in KDB784748.
5. The final system integrator must ensure there is no instruction provided in the user
manual or customer documentation indicating how to install or remove the
transmitter module except such device has implemented two-ways authentication
between module and the host system.
6. The final host manual shall include the following regulatory statement:
This equipment has been test and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
tuning the equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures;
- Reorient or relocate the receiving antenna
- Increase the distance between the equipment and the receiver
- Connect the equipment to outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
ZEAL-C02 User’s Manual
Copyrightc All rights reserved by ADC Technology Inc.
Canada – Industry Canada
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation on this device.
L‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes (1)il ne
doit pas produire de brouillage et (2) 1‘ utilisateur du dispositif doit étre prêt à accepter
tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de
compromettre le fonctionnement du dispositif.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (EIRP) is not more
than that required for successful communication.
Caution: Exposure to Radio Frequency Radiation.
To comply with RSS 102 RF exposure compliance requirements, for mobile
configurations, a separation distance of at least 20 cm must be maintained between the
antenna of this device and all persons. This device must not be co-located or operating
in conjunction with any other antenna or transmitter.
System integrators must include the IC ID on the end product.
