Before You Start

User Manual

ii 1ii 1

Declaration of Conformity

Responsible Party: JK Imaging Ltd.

Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA

JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK

Company Website: http://kodakpixpro.com

INDUSTRY CANADA

This device complies with Canadian RSS-210.

This device complies with Industry Canada license-exempt RSS standard (s).Operation is subject

to the following two conditions: (1) this device may not cause interference, and (2) this device must

accept any interference, including interference that may cause undesired operation of the device.

Radiation Exposure Statement:

This product complies with the Canadian portable RF exposure limit set forth for an uncontrolled

environment and is safe for intended operation as described in this manual. Additional RF exposure

reduction can be achieved if the product can be kept as far as possible from the user body or set the

device to lower output power if such function is available.

Before You Start

For Customers in Europe

This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of

electrical waste and electronic equipment in the European countries. Please do not throw

the equipment into domestic refuse. Please use the return and collection systems available

in your country for proper, safe disposal of this product.

Batteries: Please dispose of used batteries at designated collection centers.

Packaging: Please follow local regulations for the recycling of packaging.

“CE” mark indicates that this product complies with the European requirements for safety,

health, environment and customer protection. “CE” marked cameras are intended for sales

in Europe.

Europe – EU Declaration of Conformity

This device complies with the essential requirements of the R&TTE Directive 2014/53/EU.

The following test methods have been applied in order to provepresumption of conformity

with the essential requirements of the R&TTE Directive 2014/53/EU:

- EN 60950-1: 2006+A11:2009 +A1:2010 +A12:2011

Safety of Information Technology Equipment

- EN 50566: 2013

Product standard to demonstrate compliance of radio frequency fields from handheld and

body- mounted wireless communication devices used by the general public (30 MHz — 6

GHz)

- EN 62209-2: 2010

Human exposure to radio frequency fields from handheld and bodymounted wireless

communication devices — Human models, instrumentation, and procedures

Part 2: Procedure to determine the specific absorption rate (SAR) for wireless

communication devices used in close proximity to the human body (frequency range of 30

MHz to 6 GHz)

- EN 300 328 V1.8.1 : 2012

Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband Transmission

systems; Data transmission equipment operating in the 2.4 GHz ISM band and using spread

spectrum modulation techniques; Harmonized EN covering essential requirements under

article 3.2 of the R&TTE Directive.

- EN 301 489-1 V1.9.2: 2011

Electromagnetic compatibility and Radio Spectrum Matters (ERM); Electro Magnetic

Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical

requirements.

- EN 301 489-17 V2.2.1:2012

Electromagnetic compatibility and Radio spectrum Matters (ERM); Electro Magnetic

Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions

for 2.4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment.

Manufacturer: Sintai Optical (Shenzhen) Co., Ltd

Address: Qiwei Ind Sec, 1st, 2nd,& 3RD Bldg, Lisonglang Village, Gongming Town, Bao’an

District, Shenzhen, Guangdong, China

For Customers in the U.S.A.

Federal Communication Commission Interference Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

Radiation Exposure Statement:

This product complies with the FCC portable RF exposure limit set forth for an uncontrolled

environment and is safe for intended operation as described in this manual. Additional RF exposure

reduction can be achieved if the product can be kept as far as possible from the user body or set the

device to lower output power if such function is available.

About this Manual

Thank you for purchasing the KODAK PIXPRO Digital Camera. Please carefully read this manual and

keep it well for future reference.

JK Imaging Ltd. reserves all rights of this document. No part of this published manual may be

reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language

or computer language, in any form, by any means, without the prior written permission of JK

Imaging Ltd..

All trademarks mentioned in this manual are used for identification purposes only and are

properties of their respective owners.

This manual provides you with instructions on how to use your new KODAK PIXPRO Digital

Camera. Every effort has been made to ensure that the contents of this manual are accurate;

however JK Imaging Ltd. reserves the right to make changes without notice.

Throughout this manual, the following symbols are used to help you locate information quickly

and easily:

Indicates useful information.

In the instructions below, the following symbols may be used throughout this manual on how to

operate the camera. This is to facilitate better understanding:

「Item properties」: The optional properties in the camera interface are indicated by the

symbol「」.

6 7

Safety Notes

Do not drop the camera or allow it to hit solid objects.

Do not attempt to disassemble or repair the camera.

Do not use or store the camera in dusty places or on a beach to prevent dust or sand from

entering the camera, causing possible damage to it.

Do not use or store the camera in a hot environment or under direct sunlight.

Do not use or store the camera near a powerful magnetic field, for example near a magnet or

transformer.

Avoid touching the lens of the camera.

Do not expose the camera to direct sunlight for a long period time.

To prevent the camera from being damaged by moisture, do not use or store the camera in very

humid environments, such as in rain or near bodies of water.

If water accidentally comes in contact with the camera. turn the camera off, remove the battery

and the memory card, and dry it within 24 hours

When you take the camera from a cold place to a warmer environment, condensation may occur.

Please wait for a reasonable period of time before you turn it on.

Before you remove the battery and memory card, the camera should be turned off.

When you clean the body of the camera, don not use abrasive, alcohol-based or organic cleaner.

Use a professional lens wiping cloth and dedicated cleaner to wipe and clean the lens.

Download your photos and remove the memory card when you are going to store the camera for

a long period of time.

If this camera is not in use for a long time, please keep it in a dry and clean condition.

Our company will not pay compensation for any failure of playback of pictures or videos caused

by improper operation.

Safety notes for this camera

76 7

Safety notes for battery

Please use a battery that is the same type as the one included.

Please use the attached charger to charge the battery.

If battery fluid leaks inside the camera, contact our customer service department. If the

battery fluid leaks onto your skin, rinse your skin with clean water and seek immediate medical

attention.

Disposal of used batteries shoud be carried out in accordance with local (national or regional)

regulations.

To prevent the battery from being damaged, do not drop the battery or allow it to hit solid

objects or to be scratched by the objects.

Do not let the battery come in contact with metal objects (including coins) to avoid short

circuiting, discharging, excessive heat, or possible leakage.

Do not attempt to disassemble the battery.

Do not expose the battery to water. Always keep the battery contacts dry.

Do not heat the battery or throw it into a fire to avoid a possible explosion.

Do not store the battery in a hot environment or in direct sunlight.

If the battery overheats during charging or use, stop charging or use immediately. Turn off the

product, remove the battery carefully, and wait until it cools down.

When the camera is stored for a long period of time, remove the battery and keep it in a dry

place that is not accessible to infants and children.

In a colder environment, the performance of the battery could be noticeably reduced.

When you install the battery, install it according to the positive and negative markings on the

battery compartment. Never force it into the battery compartment.

Safety notes for memory card

We suggest buying only well-known, name brand memory cards to ensure peak performance.

Format the memory card using the camera before you use it or insert a new one.

Do not drop the memory card or allow it to hit solid objects to avoid damaging it.

Do not attempt to disassemble or repair the memory card.

Do not expose the memory card to water. Always keep it dry.

Do not remove the memory card when the camera is turned on. Otherwise, the memory card

could be damaged.

Do not directly edit the data on the memory card. Copy the data to your PC before you edit them.

When the camera is stored for a long period of time, be sure to download your photos and

remove the memory card. Store it in a dry environment.

Do not modify the name of the files or folders of the memory card using your PC. Modifying the

file names may cause the files to not be recognized on the camera or a possible error may occur.

A photo taken with the camera will be stored in the folder that is automatically generated on the

memory card. Do not store photos that are not taken using this camera in these folders as the

pictures cannot be recognized during the playback.

When you insert a memory card, make sure the notch of the card matches the markings on the

top of the card slot.

Other Safety Notes

Do not disconnect the power or turn the camera off during the update process. Doing so may

cause incorrect data to be written and the camera may not power on later.

Do not hang the neck strap of the camera around the neck of a child.

When using your camera on an airplane, observe the relevant rules specified by the airline.

Due to the limitations of manufacturing technology, the LCD may have a few dead or bright

pixels. These pixels do no effect the quality or performance of the camera, photos or video.

Do not expose the LCD to water. In a humid environment, only wipe it with a soft and dry

cleaning cloth.

If the LCD screen is damaged, pay particular attention to the liquid crystal in the screen. If any of

the following situations arise, take the recommended immediate action indicated below:

1. If liquid crystal comes in contact with your skin, please wipe with a dry cloth, wash thoroughly

with soap, and rinse with plenty of clean water.

2. If liquid crystal gets into your eye, flush the eye immediately with plenty of clean water for at

least 15 minutes and then seek for medical assistance.

3. If liquid crystal is swallowed, immediately flush your mouth thoroughly with clean water and

induce vomiting. Seek for medical assistance.

10 11

Contents

Before You Start ......................................................................................................1

Safety Notes ........................................................................................................... 6

Contents ................................................................................................................ 10

Getting Ready .......................................................................................................15

Accessories Included ..................................................................................................................................... 15

Install Lens Cap and Neck Strap .................................................................................................................. 16

Part Names ......................................................................................................................................................17

Installing Battery and Memory Card ..........................................................................................................19

Charging Battery.............................................................................................................................................21

Turning Camera On and Off ........................................................................................................................23

How to take pictures ..................................................................................................................................... 23

Set your Language, Date/Time ..................................................................................................................24

Mode Overview ...................................................................................................27

Display Setting ............................................................................................................................................... 27

LCD Display ....................................................................................................................................................28

1110 11

Overview of the screen icons in photo shooting mode .................................................................28

Overview of the screen icons in movie mode .................................................................................. 29

Overview of the screen icons in playback mode ............................................................................. 30

Using the Mode Dial ............................................................................................ 31

Select an appropriate capture mode .......................................................................................................... 31

Auto Mode .............................................................................................................................................. 32

Program AE ............................................................................................................................................. 34

Shutter priority ....................................................................................................................................... 34

Aperture priority .................................................................................................................................... 34

Manual Mode .........................................................................................................................................34

Face Beautifier ........................................................................................................................................36

Wi-Fi Mode ............................................................................................................................................. 37

Scene Mode ............................................................................................................................................45

Movie Mode............................................................................................................................................50

Custom Settings......................................................................................................................................51

Basic Operation ...................................................................................................53

Using the Zoom Function ............................................................................................................................. 53

Focus Setting .................................................................................................................................................. 54

Macro Mode ................................................................................................................................................... 55

Self-timer Setting .......................................................................................................................................... 56

Flash Mode ..................................................................................................................................................... 57

White Balance Setting .................................................................................................................................. 58

Continuous Shot ............................................................................................................................................ 59

EV Setting........................................................................................................................................................60

Using Quick Recording ................................................................................................................................. 62

i Button Function Menu ................................................................................................................................ 63

Playback Mode ....................................................................................................64

Viewing Photos and Videos .........................................................................................................................64

Thumbnail View ............................................................................................................................................. 65

Using Zoom Playback (for still pictures only) ......................................................................................... 66

Photos and Video Deletion .......................................................................................................................... 67

Slideshow ........................................................................................................................................................ 68

Continuous Capture Group Playback ........................................................................................................69

Animation panorama play ...........................................................................................................................70

Using the Menus ..................................................................................................71

Photo Setup Menu ..........................................................................................................................................71

Photo Shooting Settings Menu ................................................................................................................... 76

Movie Menu ...................................................................................................................................................80

Movie Setting Menu .....................................................................................................................................83

Playback Menu...............................................................................................................................................85

Playback Settings Menu ...............................................................................................................................89

Setup Menu ....................................................................................................................................................93

Sound Settings .......................................................................................................................................94

Power Saver ............................................................................................................................................94

Language .................................................................................................................................................95

Date/Time .............................................................................................................................................. 95

LCD Brightness ....................................................................................................................................... 95

File Setting ......................................................................................................................................................96

Format ......................................................................................................................................................97

14 1514

Copy to Card ...........................................................................................................................................97

File Numbering .......................................................................................................................................98

Reset .........................................................................................................................................................98

FW Version .............................................................................................................................................99

Connection Settings ........................................................................................ 100

Connecting to a Computer .........................................................................................................................101

Connecting to a PictBridge Compatible Printer ....................................................................................103

Using the PictBridge Menu ........................................................................................................................105

Video System ...............................................................................................................................................109

Set Eye-Fi Card Connection Mode ............................................................................................................ 110

Supported HDMI Connections ...................................................................................................................111

Appendices ..........................................................................................................112

Product Specifications .................................................................................................................................112

Prompts and Warning Messages .............................................................................................................. 116

Troubleshooting ........................................................................................................................................... 120

14 15

Getting Ready

Accessories Included

Your camera box should contain the camera model you purchased along with the following

accessories. If anything is missing or appears to be damaged, please contact your retailer. (The

battery charger may be different in shape than what is pictured below. This is due to different power

requirements across countries or regions)

Micro USB cable

Warranty cardNeck strap

Rechargeable

Li-ion battery

AC adapter Lens cap with cord

Quick Start Guide

Quick start guide

STOP

Service card

Install Lens Cap and Neck Strap











Part Names

1 . Micro HDMI port

2. Micro USB port

3. Zoom lever

4. Shutter button

5. Strap eyelet

6. Exposure compensation button

7. Continuous shot button

8. Power button

9. AF assist beam/Self-timer lamp

10. Flash lamp

1 1 . Lens

 















12. Flash button

13. Microphone

14. Indicator lamp

15. Mode dial

16. Fast video recording button

17. Menu button

18.

AF button/Arrow button (Up)

19.

Macro button/Arrow button (Left)

20.

Flash button/Arrow button (Right)

21.

Delete button/Self-timer button/

Arrow button (Down)

22. Display button

23. Playback button

24. SET button

25. i button

26. LCD

27. Speaker

28. Battery cover

29. Tripod socket

  













 

1. Open the battery cover.

2. Insert the battery into the battery

compartment according to the negative

and positive directions as illustrated in the

picture. Push the battery down until it locks

in place.

Installing Battery and Memory Card

Battery lock knob

4. Close the battery cover.

3. Insert the memory card into the memory

card slot as shown in the diagram below:

Write protection

buckle

The memory card (SD/SDHC) is optional and not included in all camera packaging. It needs

to be purchased separately. Please use an original memory card which is Class 4 or higher and

has a capacity of 4GB to 32GB.

To remove your memory card, open the battery cover, gently press the memory card to eject it

and remove it carefully.

Charging Battery

Please insert the battery and charge it under

shutdown mode.

1. Connect the camera and the power charger

using the supplied Micro USB cable.

2. Insert the plug of the power charger into the

power outlet to charge the battery.

After the battery is stored for a long

period of time, use the supplied power

charger to charge the battery prior to

use.

To have maximum battery life, charge the

battery for at least 4 hours the first time.

Charging indicator:

Steady orange: Charging

The indicator will go out once charging is

finished, and the camera will be powered

off automatically.

Indicator lamp

3. When the camera is turned off, you can also connect the camera to your PC using a Micro USB

cable to charge the battery.

Please charge the battery indoors between 0°C and 40°C.

Turning Camera On and Off

Press the Power button to turn the camera on. To

turn the camera off, press the Power button again.

Power Button

Press and hold the button to power on

and enter Playback mode.

How to take pictures

1. Hold the camera with both hands , not

blocking the flash and lens by fingers.

2. Aim the camera at the object and then

frame with the LCD.

3. Use the zoom lever to select Tele or

Wide positions to zoom in or out on your

subject.

4. Press the shutter button half way to focus

on the subject. When the focus frame

turns green, press the shutter button

completely down to take the picture.

Set your Language, Date/Time

Set your Language, Date/Time after the first power-on

1. When you turn the camera on for the first time,

the language selection screen appears.

2. Press the

buttons to select your desired language.

3. After you press the button to confirm the

selection, the Date/Time settings screen

appears.

4. Press the

button to select the

Date/Time to be adjusted: Time is displayed in

YYYY.MM.DD HH:MM.

5. Press the

button to adjust the

value for the selected Date/Time.

6. Press the button to confirm the time settings

and the shooting screen appears.

য檥Иކ

English

Français

এѽИކ

ޙߎ寉

㷼ᄙⱥ

Español

Svenska

Português

Italiano

Deutsch

Рyсский

Language

Date & Time

04 08 00 00

H-M

2015



1. Press the button, press the

button to select , and press the button to

enter the menu.

2. Press the

button to select ,

and press the /

button to enter the menu.

3. Press the

button to select

「Language」and press the /

button to

enter the menu.

4. Press the

buttons to select your desired language and press

the button to confirm.

5. Press the button and the shooting screen

appears.

Sound Settings

Power Saver Auto

Language English

World Time Home

Date & Time 2015.04.08 00:00

য檥Иކ

English

Français

এѽИކ

ޙߎ寉

㷼ᄙⱥ

Español

Svenska

Português

Italiano

Deutsch

Рyсский

Language

Resetting your Language

After you set your language for the first time, follow the instructions below to reset your language.

26 2726

1. Press the button, press the

button to select , and press the button to

enter the menu.

2. Press the

button to select ,

and press the /

button to enter the menu.

3. Press the

button to select

「Date & Time」and press the /

button

to enter the menu.

4. Press the

button to select the

Date/Time to be adjusted: Time is displayed in

YYYY.MM.DD HH:MM.

5. Press the

button to press the

value for your selected block. After you finish

your settings, press the button to confirm.

6. Press the button and the shooting screen

appears.

Resetting Date/Time

After you set your Date/Time for the first time, follow the instructions below to reset date and time.

Sound Settings

Power Saver Auto

Language English

World Time Home

Date & Time 2015.04.08 00:00

Date & Time

04 08 00 00

Back

H-M

2015



26 27

Off: Does not display any additional icons on

screen

Mode Overview

Display Setting

Press the button to display the settings: Classic, Full, Off.

Classic: Displays the camera parameters on

screen

-0.3 EV 400 ISO

1234

00:56:00

F2.8 1/50

Full: Camera parameters with Grid and

Histogram

-0.3 EV 400 ISO

1234

00:56:00

F2.8 1/50

LCD Display

Overview of the screen icons in photo shooting mode

8 White Balance

9 Color Effect

10 Number of remaining shots

11 Image Size

12 Video Quality

13 ISO Value

14 Remaining Recording Time

15 Exposure Compensation

16 Shutter Speed

17 Histogram

18 Aperture Value

19 OIS (Optical Image Stabilization)

20 HDR

21 Eye-Fi ON (with signal)

22 Expo Metering

23 Continuous Shot

24 AF Mode

25 Flash Mode

-0.3 EV 400 ISO

1/50

x3.6x3.6

F3.6F3.6















 



















1234

00:56:00

1 Shooting Mode

2 Macro Mode

3 Self-timer

4 Zoom Display (By turning the Zoom

Lever)

5 Focus Frame

6 Memory Card/Built-in Memory

7 Battery Status

-0.3 EV









    









x3.6

00:56:00

1 Movie Mode

2 Macro Mode

3 Self-timer

4 Zoom Display (By turning the Zoom

Lever)

5 Memory Card/Built-in Memory

6 Battery Status

7 Color Effect

8 Video Quality

9 Remaining Recording Time

10 Exposure Compensation

11 OIS (Optical Image Stabilization)

12 Focus Frame

13 Eye-Fi ON (with signal)

14 Expo Metering

15 AF Mode

For optimal video shooting, it is

recommended that an SDHC memory

card be used.

Optical Zoom and Digital Zoom can be

adjusted (208X in total). Digital Zoom

can be adjusted to 4X.

Overview of the screen icons in movie mode

30 3130

1 DPOF File

2 File Protection

3 Memory Space (indicating the current

number of photos and total number of

photos)

4 Memory Card/Built-in Memory

5 Battery Status

6 Zoom Magnification Area

7 Image Zoom Ratios

8 Image Zone

9 Shooting Date

10 Continuous Capture Group Playback

11 Eye-Fi ON (with signal)

12 Touch-up

13 HDR

14 Date Folder

Overview of the screen icons in playback mode

30 31

This camera provides a convenient mode dial that allows you to manually switch among different

modes with ease.

Select an appropriate capture mode

1. Press the Power button to turn the camera on. Aim the camera at the object and then frame with

the LCD.

2. Rotate the mode dial to select an appropriate shooting mode.

Auto Mode Manual Mode Movie Mode

Program AE Face Beautifier Custom Settings

Shutter priority Wi-Fi Mode

Aperture priority Scene Mode

3. Rotate the zoom lever to zoom in or out of the subjects and compose a photo within the framing

scope.

4. Press the Shutter button half way down to focus on the subject. When the focus frame turns

green, press the Shutter button completely down to take the picture.

Using the Mode Dial

Auto Mode

The camera will automatically detect the most suitable scene to capture the best pictures.

1234

00:56:00

Auto Mode

The camera will automatically adjust the exposure and focus to ensure the best possible pictures.

Landscape Mode

For landscapes, will automatically adjust the exposure and reproduce vivid green and blue colors.

Portrait Mode

Most suitable for capturing people with focus on their faces.

Night Portrait

When you take portraits at night, or in low light conditions, will automatically adjust the exposure

for people and night scenes.

Backlit Portrait

When the sun or any other light source is behind you, will automatically adjust the foreground

exposure to produce the best pictures possible.

Night Mode

For night scenes, will automatically increase the ISO value to compensate for low light.

Macro Mode

To produce more detailed close-ups, will automatically engage the camera’s Macro Mode and

automatically focus the lens.

Program AE

The user can switch the ISO and EV value according to personal preference, the camera can

automatically set the shutter speed and aperture value.

Shutter priority

The user can adjust the shutter speed, EV and ISO values. It is mostly used to shoot the moving

object.

Aperture priority

The user can adjust the aperture size, EV and ISO values. It is generally used to shoot inanimate

object and control the view depth.

Manual Mode

The user can adjust the aperture size, shutter speed and ISO values manually. It is generally used to

shoot static photos.

Mode:

Follow the steps below to adjust the parameters:

1. Rotate the mode dial to select a mode you want, press the button to configure settings.

1/50

400 ISO

1/50

400 ISO

0.3 EV

F2.8F2.8

2. Press the

button to select an adjustment item.

3. Press the

button to adjust the parameters.

4. Press the button to confirm the settings and enter the shooting screen.

Items that can be adjusted under mode: ( ○: Optional ×: Not optional, auto display)

Items

Mode Aperture value Shutter speed EV value ISO value

× × ○ ○

×○ ○ ○

○×○ ○

○ ○ ×○

Face Beautifier

The camera is set to automatically adjust camera exposure for realistic portrayal of skin tones.

1. Rotate the mode dial to select .

2. Press the button and press the

button to select .

3. Press the

button to select an option and press the button to confirm and

return to photo shooting mode.

-0.3 EV 400 ISO

x3.6

1234

00:56:00

• Effect 1: Skin Soften

• Effect 2: Skin Soften+Eye Brightening

• Effect 3: Skin Soften+Eye Brightening+Eye Enlargement

Wi-Fi Mode

Make image transmission and remote control by connecting smart device with Wi-Fi.

Matters needing attention before use

Your smart device operating system version needs to be iOS 7 or higher, or Android 4.2 or higher.

If not, please upgrade your smart device before using the APP.

Please do not use in places having high intensity magnetic field, electrostatic and electric wave

interference (for example near a microwave oven), which may cause failure in receiving signals.

To maintain a connection, please keep the camera within 10 meters (32.8 feet) without signal

shielding interference.

Please do not use Wi-Fi connection functionality on a plane.

The camera and the smart device can only be connected one to one.

Android system:

For Android devices, search and download

the App “PIXPRO Remote Viewer” in

Google play, and install it following the

instructions on the interface.

iOS system:

For Apple devices, search and download

the App “PIXPRO Remote Viewer”

in App store, and install it following the

instructions on the interface.

Route of downloading the APP package:

Please download APP installation package (APP name: PIXPRO Remote Viewer) to your

smart device from the path below and install this application procedure.

https://play.google.com/store/apps/

details?id=com.jkimaging.pixproremoteviewer

https://itunes.apple.com/us/app/

pixpro-remote-viewer/id833154167?mt=8

Refer to the "PIXPRO Remote Viewer User Manual" located on the web:

http://kodakpixpro.com/

Americas/support/downloads.php

http://www.kodakpixpro.com/

Europe/support/multi-lang-downloads.php

Americas Europe

1. Rotate the mode dial to select and then enter the Wi-Fi selection interface.

Settings Station AP mode

Wi-Fi Mode

In AP mode, the camera will act

as an access point enabling another

Wi-Fi device to connect to it.

2. Press the

button to select and set options.

• 「Settings」: Customize the Wi-Fi settings for the camera system.

• 「Station」: Use the Station Mode to connect to a "Personal Hotspot" created by

your mobile device.

• 「AP mode」: In AP mode, the camera will act as an access point enabling another

Wi-Fi device to connect to it.

Rotate the mode dial to disconnect.

AP mode

This camera may connect with your smart

device through Wi-Fi.

Settings of Camera:

1. Select and press the button to enter

the setting interface.

AP mode

Back

Setting pre-connected device for the

following serial number:

SSID: PIXPRO AZ527_XXXX

WPA2 PSK: XXXXXXXX

Refresh

Press the

button to select:

• Refresh: Create a new WPA2 PSK

password

• Back: Back to previous page

Settings of Smart Device:

2. Enable the Wi-Fi of smart device and then

search surrounding wireless devices.

3. Select the name of camera SSID to be

connected and then input the eight-digit

number password after WPA2 PSK on the

camera.

4. Click the icon of the APP to enable the

APP.

Set up completion:

5. Once the APP is connected to the camera,

functional operations can be enabled on the

smart device.

Station

Enable image transmission and remote control

by connecting the camera with a Wi-Fi access

point created by your smart device.

1. Enable the Wi-Fi access point of smart

device.

2. Select on camera and then press the

button to confirm connection with smart

device.

Station

Wi-Fi Mode

Device1-SSID

Device2-SSID

Device3-SSID

Searching for devices.

*SSID

zi

Press the

button to select:

• Scan: Search again surrounding wireless

devices.

• : Select the name of device to be

connected.

• Back: Back to Wi-Fi mode select screen.

3. Press the

button to select

the name of smart device to be connected

and then press the button to confirm.

Then, the camera enters the password input

interface.

Type the network security key

Enter Password

#!?

ABCDEFGH IJ

KLMNOPQ RST

WXYZ

A/a

4567 90

123

CancelSave

Meanings of interface icons:

Icon Description

Delete the last letter

$D

Switch the display of letters in

capital and lowercase

Move the Cursor

#!? Switch the symbol input

Input Space

Display of Wi-Fi Connection Status

The Wi-Fi has successfully connected but APP

is not enabled:

Wi-Fi Mode

Connected with device

3')'JJXKYY ^^ ^^ ^^

AP mode

Disconnect

The Wi-Fi has successfully connected and APP

is enabled:

Wi-Fi Mode

Connected with APP

XXXXX

Disconnect

4. Press the

buttons to select and then press the

button to confirm your selection. Enter the

completion of WPA2 PSK after password

storage.

5. Connect immediately after saving.

• If connected, the LCD will display as

shown below:

Station

Wi-Fi Mode

Connected with device

SSID: XXXXXXXX

Disconnect

• If connect failed, please check Wi-Fi

device and try again.

6. After connection, click the icon of the APP

on the smart device, you may use it to

carry out relative operation.

The Wi-Fi of smart device interrupts:

Wi-Fi Mode

Disconnected, please check

Wi-Fi device and try again.

AP mode

Back

• Back: Back to Wi-Fi mode SSID screen.

For interrupting the connection:

Wi-Fi Mode

Disconnect from device?

Yes

• No: Keep Wi-Fi connected and back to

previous page.

• Yes: Disconnect and back to Wi-Fi

mode for interface connection.

DSC Device

The default name of DSC Device is「PIXPRO

AZ527」. Change the name of DSC device

through key stroking.

Name between 1-18 Letters

PIXPRO AZ527

Cancel

DSC Device

Save

#!?

ABCDEFGH IJ

KLMNOPQ RST

WXYZ

A/a

4567 90

123

For the method of input, please refer to the

introduction on password input on Page 41.

MAC Address

Check the wireless MAC Address of this

camera.

Settings

The name of this camera can be changed

through key stroking.

1. Select and then press the button to

enter the setting interface.

2. Press the

button to select

the option to be adjusted and then press the

button to enter the menu.

DSC Device

MAC Address :

PIXPRO AZ527

38:67:93:XX:XX:XX

3. Press the button to confirm settings and

then skip the menu.

Scene Mode

The user can select an appropriate mode from the 13 scene modes according to the type of

environment you are shooting. The camera then configures the most appropriate settings

automatically.

1. Rotate the mode dial to select .

2. Press the

buttons to select a scene, and press the button

to confirm.

Multi Exposure

3. If any need of changing the scene, please press the button and then the button and finally

the

buttons to reselect the scene.

Handheld Night

Reduce blur when shooting low light/ illuminated scenes.

Quickly take 4 photos below 8M (including 8M) and then overlap as a clear night image.

Pet Mode

Rapidly identify pet (dog/cat), capture the dynamic moment of pet.

When a cat /dog face is detected, a white focus frame appears. The camera will take a picture

and save it regardless of whether the focus is successful (if successful, there appears a green

focus frame; if not, there is an orange frame).

At most, 10 dog/cat faces can be detected at one time.

Sunset

For sunsets. Capture subjects in strong sunlight.

Fireworks

For fireworks at night. Suggest using tripod.

Multi Exposure

Suitable for shooting moving objects (as many as 7) in the same background.

Keep camera steady before shooting. Press and hold the Shutter button to take 7 photos

continuously when it will stop automatically. To stop shooting, release the Shutter button in

the midway.

Objects shall be moved only from left to the right in order to be recorded. Objects moving

from other directions would not be recorded.

Shooting effect will be influenced if object is moving too fast or too close.

Sport

For fast-moving subjects. Capture sharp action shots without blur.

Night Portrait

For portraits against night time scenery (Suggest using tripod).

Landscape

Speed adjusted for brilliant images.

Portrait

For shooting portraits

Snow

For subjects in the snow. Reduce underexposure.

Children

For kids and pets. Flash is disabled for eye protection.

Party

For subjects at night without using a tripod. Capture sharp shots without blur.

Panorama Mode

This feature allows you to capture a panoramic view that will have significantly more content than a

single photograph. Follow the instruction arrow with a smooth and steady movement of the camera

to seamlessly shoot an ultra-wide scene of up to 360 degrees.

Follow the steps below:

1. Select Panorama Mode ( ), and then press the button to confirm.

2. Press the

buttons to select a shooting direction. (The right

direction is used as default if you do not make any choice) 2 seconds later, the camera is ready

to take pictures. You can also press the button or half press the Shutter button to be ready to

take pictures.

3. Compose your shot on the LCD and half press the Shutter button to focus on the subject. After

focusing, fully press the Shutter button down to take picture. At this time, the process dialog of

panorama mode stitching appears on the screen.

4. Rotate the camera according to the set direction. When the range of rotation does not exceed

the range that the camera can detect, the progress dialog along the indication arrow partially

turns red. When it completely turns red, panorama mode shooting is finished.

Panoramic image can be played back by the method of flash playing. Please see the animation

panoramic playback on page 70.

During shooting, the flash, self-timer, macro modes and exposure compensation are not

available. Focus adjustment is also not available at this time.

During panorama mode shooting, press the button to interrupt shooting and save the

current pictures taken. Press the

button to cancel shooting and not to save the

previously taken pictures.

During panorama mode shooting, when the moving direction of the camera is wrong or the

angle deviates from the internal settings, the LCD shows a warning message「Improper

alignment. Please try again.」and the current pictures taken are saved.

Movie Mode

Switch to this mode to record videos.

Follow the steps below:

1. Rotate the mode dial to select , and it will enter the movie screen.

2. Press the button or the Shutter button to start recording.

00:00:06

x3.6

3. Press the button or the Shutter button again to stop recording, save it automatically and then

the camera will return to the movie screen.

In the recording process, you can rotate the zoom lever to zoom in or out of the subject.

Settings under mode (unset state or state

after reset):

1. Rotate the mode dial to select , and then

the camera enters the setting interface as

shown below:

Select one capture mode to define CS .

Auto Mode

Save

Exit

2. As shown in the picture, press the

button to select a capture mode that

you want to define as , and press the

button to enter the shooting screen.

3. As shown in the picture, press the

button to confirm setting or to exit without

setting by turning the mode dial.

Rotate the mode dial to skip .

Go to setting CS mode.

Yes

For setting under other modes (use this

method to select a different custom setting):

1. Select any mode or scene mode to be

stored.

2. Set your desired parameters in the current

mode.

3. Press the button and then the

button to select , and press the

button to enter the menu.

4. Press the

button to select

, and press the /

button to

enter the menu.

Custom Settings

The user can store frequently used shooting modes or scene modes with parameters and switch to

this mode for quick adjustment.

52 5352

7. Rotate the mode dial to switch to .

8. The photo settings you stored the last time

are invoked.

When the mode is used for the first

time, there is no preset parameter stored

in the mode.

If you want to remove the parameter

setting of「Custom Settings」, please

utilize the reset function as described on

page 98.

5. Press the

button to select

「Custom Settings」and then press the /

button to enter the menu

Custom Settings

6. Select「Ye s 」to save or「No」to cancel.

Custom Settings

Reset camera settings to

custom settings mode.

Yes

52 53

Basic Operation

Using the Zoom Function

Your camera is equipped with two types of zoom functions: optical zoom and digital zoom. Toggle

the zoom lever of the camera to zoom in or out of the subject while taking pictures.

When the optical zoom reaches the threshold as digital zoom, release and turn the zoom lever to T

to switch between the optical zoom and digital zoom.

Zoom Indicator

Zoom In

Zoom Out

Zoom Lever

Focus Setting

This function can be adjusted in mode, please follow the steps below to configure the

settings:

1. Press the

button to enter the Focus menu.

Single-AF

2. Press the

button to select the following 3 modes:

• Single-AF

The focus frame appears on the center of the LCD to focus on the subject.

• Multi-AF

The camera automatically focuses the subject in a wide area to find the focus point.

• Object Tracking

Smart tracking of the object in motion under the focusing shooting.

3. Press the button to confirm the settings and enter the shooting screen.

Once enabled, Object Tracking will only work when lens is focused on the object.

Macro Mode

The Macro Setting is ideal for shooting small objects or close-up photos. This mode allows you to

focus on subjects very close to the camera.

It can be adjusted in mode, please follow the steps below to configure the settings:

1. Press the

button to enter the Marco menu.

Macro Off

2. Press the

button to select the following 2 modes:

• Macro Off

Select this option to disable Macro.

• Macro On

Select this option to make focusing on the object closer to the lens (At the W side, the

shooting distance should be more than 1 cm).

3. Press the button to confirm the settings and enter the shooting screen.

Self-timer Setting

Using this function can take photos at regular time. The camera can be set to shoot after 2 seconds,

10 seconds since pressing the Shutter button or shoot after smile.

It can be adjusted in mode, please follow the steps below to configure the

settings:

1. Press the

button to enter the

Self-timer menu.

Self-timer Off

2. Press the

button to select the

following 4 modes:

• Self-timer Off

Disables the Self-timer.

• Self-timer 2 sec

A single picture is shot 2 seconds

after the shutter button is pressed.

• Self-timer 10 sec

A single picture is shot 10 seconds

after the shutter button is pressed.

• Self-timer Smile

Press the shutter button

and a picture will be taken

immediately after a smile is

detected.

3. Press the button to confirm the

settings and enter the shooting screen.

When enabling the self-timer, pressing

the shutter button or the

button can disable the self-timer and

return to the shooting screen while

keeping the self-timer setting.

When enabling the smile detection,

pressing the shutter button or the

button can disable the self-timer and

return to the shooting screen without

keeping the self-timer Smile setting.

Flash Mode

The flash provides supplemental light for the scene. The flash is usually used when shooting against

the light to highlight the object; it is also suitable for metering and shooting in darker scenes to

improve the exposure.

It can be adjusted in mode, please follow the steps below to configure the settings:

1. Press the Flash Button to pop up the

flash.

2. Press the

button to enter the Flash

menu.

଎ܠ昘旅

ਘ⥺斿Ұ

Force Off

3. Press the

button to select

the following 6 modes:

• Force Off

Flash is turned off.

• Flash Auto

Camera flash goes off automatically

based on existing light conditions.

• Fill Flash

The flash will engage with each shot

even if there is enough available

light to take the photo without flash.

• Slow Sync.

This allows you to take pictures of

people at night that clearly show

both your subjects and the night

time backdrop. The use of a tripod

is recommended when shooting

with this setting.

• Slow Sync. + Red-Eye

Use this mode for slow synchro

shots with red-eye reduction.

• Red-Eye Reduction

The camera emits a brief pre-flash

before the picture is taken to reduce

red-eye effects.

4. Press the button to confirm the settings

and enter the shooting screen.

White Balance Setting

The white balance function allows adjustment of the color temperature for different light sources.

It can be adjusted in mode, please follow the steps below to configure the settings:

1. Press button to enter the White Balance

menu.

଎ܠ昘旅

AWB

2. Press the

button to select the

following 8 modes:

• AWB

• Daylight

• Cloudy

• Fluorescent

• Fluorescent CWF

• Incandescent

• Manual WB

(Fully press the Shutter button to

detect the white balance value)

• Color Temp. (1900K~10000K)

Press the

button to "Adjust the K value";

Press the

button to exit the

K value.

3. Press the button to confirm the settings

and enter the shooting screen.

Continuous Shot

This function can be adjusted in mode, please follow the steps below to configure the

settings:

1. Press the button to enter the Continuous

Shot menu.

Single

2. Press the

button to select the

following 5 modes:

• Single

Capture a single shot only.

• Continuous Shot

Take several pictures at a time.

• Cont.Shot-High Speed (VGA)

For continuous shot with VGA

pixel.

• Cont.Shot-Fast (2M)

For continuous shot with 2M

pixels.

• Time-Lapse

Take pictures based on the preset

interval (30sec/ 1min/ 5min/

10min).

3. Press the button to confirm the settings

and enter the shooting screen.

4. Press the Shutter button to start continuous

shooting.

In Continuous Shot mode, the flash is

automatically set to Force Off in order to

achieve quick succession of shots.

Exposure Compensation

Set up to adjust the picture brightness. In

the case of a very high contrast between the

photographed object and the background, the

brightness of the picture can be appropriately

adjusted. (Adjustable in Mode)

1/50

400 ISO

1/50

400 ISO

0.3 EV

F2.8F2.8

The adjustable range of exposure value is from

EV -3.0 to EV+3.0.

EV Setting

The EV function menu of the camera includes

functions, such as EV adjustment, ISO

adjustment, Shutter adjustment, Aperture

adjustment, etc. Using the appropriate function

settings can improve your pictures.

Please follow the steps below to configure the

settings:

1. Press the button to display the settings

screen.

2. Press the

button to select

the setting options.

3. Press the

button to adjust

the option values.

4. Press the button to confirm the settings

and enter the shooting screen.

ISO

ISO allows you to set the sensitivity of the

camera sensor. Please use a higher ISO value

in darker places and a lower value in brighter

conditions. (Adjustable in Mode).

1/50

0.3 EV 400 ISO0.3 EV 400 ISO

F2.8F2.8

The camera’s ISO settings include: Auto, 100,

200, 400, 800, 1600 and 3200.

Shutter Adjustment

For shutter speed, the camera may

automatically set the aperture value

corresponding to the manually set shutter

speed so as to obtain a most suitable exposure

value. The movement of object may be shown

by adjusting the shutter speed. High shutter

value will allow you to clearly capture the

movement of fast moving objects while a low

shutter value will allow you to take a picture

of a fast moving object while showing a strong

sense of movement. (Adjustable in Mode).

-1.0 EV

1/50

400 ISO

1/50

400 ISO

0.3 EV0.3 EV

F2.8F2.8

Aperture Adjustment

You can adjust the aperture size value.

Selecting a large aperture opening will

emphasize the point of focus and show a blurry

background and foreground. A small aperture

opening will keep both the background and

main object in clear focus. (Adjustable in

Mode)

400 ISO0.3 EV0.3 EV 400 ISO

1/50

F2.8F2.8

Using Quick Recording

In shooting mode, press the button to begin

recording video.

After recording, press the button or the

shutter button to stop recording. The camera

will store the video and return to the shooting

screen.

i Button Function Menu

The Image Color Setting allows you to select different color effects.

It can be adjusted in mode, please

follow the steps below to configure the settings:

1. Press the button to select the Image

Color Setting Menu.

2. Press the

button to select

the Image Color Setting options.

( ) represents optional in Movie mode.

There are 20 Image Color options in photo shooting mode :

Normal ( ) Sepia ( ) Vignetting

Vivid ( ) Partial Color-Red ( ) ) Salon

Japan Style Partial Color-Blue ( ) Fish Eye (20M Not

optional)

Italian Style Partial Color-Yellow ( ) Reflection

French Style Partial Color-Green ( ) 4 Grids - Stylish

(2M)

Punk Negative Sketch

Black and White ( ) Dreamy

Normal

64 65

Viewing Photos and Videos

To view photos and videos on the LCD:

1. After pressing the button, the last photo or video clip taken will be displayed on the LCD.

2. Use the

button to scroll through the photos or video clips stored in the internal

memory or on the memory card.

3. To play a selected video clip, press the button to enter the movie playback mode.

During video playback, the operating instructions will appear on the screen. Press the appropriate

buttons to enable the corresponding functions.

Mute

Under Playback Paused

00:00:47 00:01:23

1Increase volume 6Back to the beginning of the video

2Pause 7 Play

3Fast forward 8 Play video forward

4Decrease volume 9 Cancel playback

5Rewind 10 Play video backward

Playback Mode

6564 65

Thumbnail View

When in playback mode, rotate the zoom lever counter to the position to display thumbnail

images of the photos and videos on the screen.

1. Slide the zoom lever to switch between 3x3 and 4x4 thumbnails.

2. Press the

buttons to select a picture or video clip to view and

press the button to restore it to the original size.

When the icon appears, it means this is a video file.

When playing back photos, you can also use the Zoom Lever

to zoom in on the photos 2 to 8 times.

1. Press the button to switch to playback mode.

2. Press the

button to select a picture to be

zoomed in.

3. Rotate the zoom lever clockwise to to zoom in.

4. The screen will display the number of times and

area of the photo zooming operation.

5. Press the

buttons to

navigate and select a part of the image to be zoomed in.

6. Press the button to return the image to its original

scale.

Movie images cannot be magnified.

Using Zoom Playback (for still pictures only)

T Zoom In

Photos and Video Deletion

In playback mode, press the

button to delete your photos and videos.

To delete photos or videos:

1. Press the button to switch to playback mode.

2. Press the

button to select the photos and videos to be deleted.

3. Press the

button and the deletion screen is displayed.

Delete One

Exit

4. Press the

button to select 「Delete One」or「Exit」and press the button

to confirm.

Erased photos/video clips cannot be recovered.

Please refer to page 91 for instructions on deleting more than one image at a time.

Slideshow

This setting allows you to view all the stored images as a slideshow.

1. Press the button to enter playback screen.

2. Press the button to enter slide option.

3. Press the

button to select slideshow playing or「Cancel」to return to the

playback screen.

Cancel

4. Press the button to confirm the setting.

The continuous capture group playback may be displayed by slideshow.

Pictures rotate automatically during a slide show.

Slide playing function supports movie playing.

Continuous Capture Group Playback

Cont.Shot-High Speed (VGA) and Cont.Shot-Fast (2M) can make continuous capture for group

image playback.

1. Press button to enter playback screen.

2. Press the

button to select cont. group.

3. Press to start playback.

1/45

00:0000:00

20152015 04-08

04-08

70 7170

Animation panorama play

Panoramic animation playing is to play full size image in accordance with the shooting direction.

After playing, it will automatically return to the static screen of panoramic image.

1. Press the button to enter playback screen.

2. Press the

button to select animated panoramic photos.

3. Press the button to play in selected shooting direction.

In the process of panoramic animation playback, press the

button ( ) to stop

playing and return to the playback screen.

70 71

Photo Setup Menu

Using the Menus

Functions that can be enabled are different

under each mode.

Mode:

1. In photo shooting mode, press the

button to enter the shooting menu.

2. Press the

button to

select the item to be set.

3. Press the

button to

select an option and press the

button to confirm.

Refer to the following pages for more

details about each setting.

Expo Metering

Use this setting to select the “target” size of the

camera’s field of view to be metered.

• AiAE (Artificial Intelligence AE):

Automatically selects the central

and peripheral metering, to calculate

the reasonable value of metering by

weighting.

• Spot: For metering targets a small area in

the center of the camera’s field of view.

• Center: For metering targets a slightly

larger area in the center of the cameras

field of view.

It can be adjusted in all modes except for

Panorama Mode.

Image Size

The size setting refers to the image resolution

in pixels. A higher image resolution allows

you to print that image in larger sizes without

degrading the image quality.

• Size: High quality printing

• Size: Full size printing

• Size: 16:9 display

• Size: Poster printing

• Size: A3 printing

• Size: A4 printing

• Size: 4”x 6” printing

• Size: E-Mail

The larger the number of recorded pixels,

the larger the file size and the fewer files

that can be saved on your memory card.

OIS (Optical Image Stabilization)

This mode can help reduce photo blur caused

by unintentional hand shake, low light.

• OIS: Off

• OIS: On

Use this image stabilization mode in dark

environments.

Shooting in a windy or unstable

environment (such as a moving vehicle)

may cause blurred images.

Cont. AF

Enable the continuous AF to be able to

continuously focus automatically when taking

pictures.

• Cont.AF: Off

• Cont.AF: On

Beautifier

Set the effect of the face beautifier mode.

• Effect 1: Skin Soften

• Effect 2: Skin Soften+Eye

Brightening

• Effect 3: Skin Soften+Eye

Brightening +Eye

Enlargement

HDR

Use this setting to control wide dynamic image

range when taking static pictures. Photos with

extreme contrast of bright and dark areas will

still maintain distinguishable detail and depth.

(Suggest using tripod)

• HDR: Off

• HDR: On

In the scenario with high light contrast

(too dark or too light), this function can

be used to shoot satisfactory photos.

Scene

Select the scene mode under the SCN

mode.

Night Portrait

Press SET To Select Scene

Shooting menu in the Photo shooting mode

( ○: Optional ×: Not optional)

Options

Photo Shooting Modes

○○○○○○

×○○○○○

×○○○○ ×

×××××○

Mode:

1. Press the button in Photo Shooting mode and press the

button to select

2. Press the button to enter the menu.

3. Press the

button to select , and press the /

button to enter the

menu.

4. Press the

button to select the item to be set and press the /

button

to enter the menu.

5. Press the

button to select an option and press the button to confirm.

Photo Shooting Settings Menu

Quality

The Quality Setting can be used to adjust the

image compression ratio.

QualityBest

Fine

Normal

• Best

• Fine

• Normal

AF Assist Beam

In a darker environment, AF Assist Beam can

be turned on for better focus.

AF Assist Beam

Off

Digital Zoom

This setting is for adjusting digital zoom. If this

function is disabled, only optical zoom can be

used.

Digital Zoom

Off

Quick Review

This option allows quick review of the photos

immediately after they are taken. Each photo

is displayed on the LCD based on the selected

time.

Quick Review

Off

1 sec

2 sec

3 sec

• Off

• 1 sec

• 2 sec

• 3 sec

Date Imprint

Include a Date/Time stamp on the photo

image.

Date Imprint

Off

Date

Date/Time

• Off

• Date

• Date/Time

Custom Settings

Custom Settings stores the current photo

shooting mode or scene mode and its

parameters. The stored mode and parameters

are directly invoked in mode.

Custom Settings

Reset camera settings to

custom settings mode.

Yes

There are 2 options:

• No

• Yes

In mode, select「Custom Settings」

the camera will enter the setting

interface as shown below:

Select one capture mode to define CS .

Auto Mode

Save

Exit

Movie Menu

Mode:

1. Rotate the mode dial to select and press

the button to enter the movie menu.

2. Press the

button to select

the movie menu to be set.

3. Press the

button to select an

option and press the button to confirm.

Expo Metering

Use this setting to select the “target” size of

the camera’s field of view to be metered.

Expo Metering: AiAE

• AiAE (Artificial Intelligence AE)

Automatically selects the central

and peripheral metering, to

calculate the reasonable value of

metering by weighting.

• Spot

For metering targets a small area

in the center of the camera’s field

of view.

• Center

For metering targets a slightly

larger area in the center of the

cameras field of view.

Movie Size

Set the image resolution used during video recording.

Size: 1080p 30fps

The speed requirements for reading and writing high image pixel images to memory card are as

follows:

No. Image Pixel Frame Recommendation Recording time (4GB) About

1 1920x1080 * 30 Class 4 30 minutes

2 1280x720 * 60 Class 4 32 minutes

3 1280x720 * 30 Class 4 59 minutes

4 640x480 30 Class 4 106 minutes

5 640x360 120 Class 4 54 minutes

* The longest recording time is 29 minutes at one time.

• Size: 1080p 30fps

• Size: 720p 60fps

• Size: 720p 30fps

• Size: 640x480 30fps

• Size: 640x360 120fps

(High Speed Movie)

When recording in higher pixel

resolutions for extended periods of time,

this can cause the camera to generate

heat. This is not a camera malfunction.

When the video format is set as

640x360 (120fps), shooting time is 30

seconds, playback time is 2 minutes.

Sound recording is disabled when

640x360 120fps is chosen.

OIS (Optical Image Stabilization)

This mode can help reduce images blur caused

by unintentional hand shake, low light.

5/9 5LL

• OIS: Off

• OIS: On

Use this image stabilization mode in dark

environments.

Shooting in a windy or unstable

environment (such as a moving vehicle)

may cause blurred images.

Movie Setting Menu

Mode:

1. Rotate the Mode Dial and select to enter the video recording screen.

2. Press the button, press the

button to select , and press the button

to enter the menu.

Press SET To Enter

3. Press the

button to select , and press the /

button to enter the

menu.

4. Select the item to be set and press the /

button to enter the menu.

5. Press the

button to select an option and press the button to confirm.

Custom Settings

Custom Settings stores the current movie

mode and its parameters. The stored mode

and parameters can be invoked directly in

mode.

Custom Settings

Reset camera settings to

custom settings mode.

Yes

Digital Zoom

This setting is for adjusting digital zoom. If this

function is disabled, only optical zoom can be

used.

Digital Zoom Off

Playback Menu

Mode:

1. Press the button to display the

playback screen and press the button

to enter the menu.

2. Press the

button to

select the item to be set and press the

button to enter.

3. Press the

button to select

an option and press the button to

confirm.

Normal Mode

Press SET To Confirm

Refer to the following pages for more details

about each setting.

Playback Mode

Select , and press the button to enter the

settings screen:

Normal Mode: Display all images.

• Normal Mode:

Display all images.

• Date Mode:

Arranged by date.

• Cont. Photo Mode:

Arranged by Cont. Photo Group.

The Date Folder is displayed in date order

based on camera's Date/Time Settings.

If there is no continuous shot image file in

memory, continuous shot playback mode

cannot be enabled.

HDR

With the HDR function, pictures that are

overexposed may be corrected to optimize

the highlights and lowlights captured to more

accurately represent the actual scene.

Select , and press the button to enter

the settings screen:

HDR

Cancel

After using the HDR function, the image

will be saved as a new file and the

original file is still stored in the memory.

Touch-up

The playback beauty feature allows for

beautification using three individual effects.

Select , and press the button to enter

the settings screen:

Red-Eye Reduction

Skin Soften

Eye Brightening

Eye Enlargement

Cancel

Using the face beautifier mode allows

you to select from single, two, or all three

effects combined.

Rotate

You can use this setting to change the

orientation of the picture.

Select , and press the button to enter

the settings screen:

Turn Right

Turn Left

Cancel

Videos and panoramic pictures cannot

be rotated.

The rotated picture file will replace the

original photo.

Resize

This setting allows you to resize a picture to

a particular resolution and saves it as a new

picture.

Select , and press the button to enter

the settings screen:

Resize to 1024x768

Resize to 640x480

Cancel

Only for adjusting pictures with high

resolution to those with low resolution.

Sizes of photos taken in panorama mode

or rotated cannot be adjusted.

Color Effect

This setting allows you to change the picture color effect. The file is saved as a new photo and

stored in memory together with the original photo.

Press the button to enter the settings screen:

Cancel

There are 19 options available:

Cancel Sepia Vignetting

Vivid Partial Color-Red Salon

Japan Style (8M) Partial Color-Blue Fish Eye (20M Not

optional)

Italian Style (8M) Partial Color-Yellow Reflection

French Style (8M) Partial Color-Green 4 Grids - Stylish(2M)

Punk (4M) Negative (8M)

Black and White Dreamy

Playback Settings Menu

Mode:

1. Press the button to show the playback screen, press the button, press the

button to select , and press the button to enter the menu.

2. Press the

button to select , and press the /

button to enter the

menu.

Protect

DPOF

Delete

Trim

3. Press the

button to select the item to be set and press the /

button

to enter the menu.

4. Press the

button to select an option and press the button to confirm.

Refer to the following pages for more details about each setting.

Protect

To prevent any pictures or videos from being accidentally erased, use this setting to lock one or all

of the files.

Protect One

Cont. Group

Reset

All

Reset

Date Folder

There are 5 options available:

• One: Lock the selected photo or video if they are unprotected; unlock the selected

photo or video if they are protected.

• Date Folder: Protect all photos in the date folder.

• Cont. Group: Protect all photos in the cont. photo folder.

• All: Lock all photos or videos.

• Reset: Cancel all locked photos or videos.

Delete

You can delete one or all photo/video files.

Delete

One

Cont. Group

Date Folder

All

There are 4 options available:

• One: Delete one photo or video.

• Date Folder: Delete all photos in the date folder.

• Cont. Group: Delete all photos in the cont. photo folder.

• All: Delete all photos or videos.

The “ ” indicator means a file is protected. File protection must be removed first before a

file can be deleted.

Deleting files will cause DPOF settings to be reset.

When one photo in the cont. photo and date folders is protected, it will be kept but any other

photos will be deleted.

Trim

The Trim Setting allows you to crop photos

and save them as new pictures.

1. Select「Yes」to confirm trim. Rotate the

zoom lever to select the aspect ratio and

press the

buttons to adjust the part you want

to trim.

2. Press the button and the「Save

Change?」prompt appears. Select

「」to change and save the picture.

Select「」to cancel changes and

return to the trim prompt screen.

The image cannot be clipped/trimmed

again once it has been clipped to

640X480.

DPOF (Digital Print Order Format)

The DPOF feature allows you to compile and

select a group of pictures that you would like

to print and will save your selection on the

memory card so that you can use the memory

card to print without having to individually

specify the photos you want to print.

DPOF

One

All

Reset

The printer that supports DPOF is

needed for printing.

Setup Menu

Mode:

1. Press the button in any mode, press the

button to select , and press the

button to enter the menu.

2. Press the

button to select , and press the /

button to enter the

menu.

Sound Settings

Power Saver Auto

Language English

World Time Home

Date & Time 2015.04.08 00:00

3. Press the

button to select the item to be set and press the /

button

to enter the menu.

4. Press the

button to select an option and press the button to confirm.

Refer to the following pages for more details about each setting.

Power Saver

This setting allows you to save power and get

the maximum possible running time for your

camera’s batteries. Turn the LCD and camera

off automatically after a consecutive period of

inactivity.

Power Saver

Auto

Normal

Best

• Auto

• Normal

• Best

Power

Saver

LCD power off

time Turn off time

Auto 3 min 5 min

Normal 1 min 3 min

Best 30 s 1 min

Sound Settings

With this setting you may adjust the sound

volume.

Press the

button to adjust the

volume and press the button to confirm our

setting.

Sound Settings

Volume

Back

Language

Refer to the “Reset your language” section on

page 25.

World Time

The world time setting is a useful function for

your overseas trips. This feature enables you

to display the local time on the LCD while you

are abroad.

1. Press the

button to select

the departure place ( ) and destination

( ) fields.

2. Press the

button to select a

city located in the same time zone as that

of the field. Press the button to confirm

settings.

Date/Time

Refer to the “Reset Date/Time” section on

page 26.

LCD Brightness

Use this setting to adjust the brightness of your

LCD.

Press the

button to adjust

the brightness of screen, and press the

button to confirm our setting.

LCD Brightness Normal

-2

-1

Normal

File Setting

Mode:

1. Press the button, press the

button to select and press the button to

enter the menu.

2. Press the

button to select and press the /

button to enter the

menu.

3. Press the

button to select the item to be set and press the /

button

to enter the menu.

Format

File Numbering

Copy to Card

Reset

FW Version X.XX

4. Press the

button to select an option and press the button to confirm.

Refer to the following pages for more details about each setting.

Format

Please note: formatting enables you to delete

all contents in the memory card and built-in

memory, including protected photo and movie

files.

Format

Doing so will clear all data.

Yes

If you select「Ye s 」the camera formats

its memory.

If there is no memory card in the camera,

the built-in memory will be formatted;

if there is a memory card, it will be

formatted only.

Copy to Card

Use this setting to copy the files stored in the

built-in memory to a memory card.

Copy to Card

Copy files from built-in memory to

the memory card.

Yes

If there is no card available in the camera,

this function will not be displayed.

Reset

Use this setting to restore the camera to its

original default settings.

Reset

Reset camera settings to

factory defaults.

Yes

File Numbering

After you take a picture or video clip, the

camera will save it with a sequential number.

You can use this to reset the file numbering to

0001.

File Numbering

Create a new directory and

reset the file number.

Yes

FW Version

Use this setting to view the current camera

firmware version.

FW Version

Current Ver:1.XX

Back

When there is a new firmware version in the

memory card, select「Yes」to update.

FW Version

Current Ver:1.XX

New Ver.:2.XX

Cancel

Yes

Update Firmware?

100 101

Connection Settings

Mode:

1. Press the button, press the

button to select and press the button to

enter the menu.

2. Press the

button to select and press the /

button to enter the

menu.

3. Press the

button to select the item to be set and press the /

button

to enter the menu.

USB PC

TV-System NTSC

Eye-Fi Off

4. Press the

button to select an option and press the button to confirm.

Refer to the following pages for more details about each setting.

101100 101

Connecting to a Computer

You can use the Micro USB cable to connect the camera and copy (transmit) photos to a computer,

printer or other device.

Setting the USB Mode

The camera’s USB port can be set to connect with either a computer or a printer. The following steps

will allow you to ensure that the camera is correctly configured to connect with a PC.

1. Press the

button to select「USB」and press the /

button to enter

the menu.

2. Press the

button to select「PC」and press the button to confirm.

USB PC

Printer

102

Transferring files to your computer

The computer will automatically detect the camera as a removable drive. Double-click the My

Computer icon on the desktop to locate the removable drive and to copy folders and files in the

drive to a directory on your PC as you would copy any typical folder or file.

Follow the steps below to connect the camera to a computer.

1. Make sure the computer is turned on.

2. Connect one end of the supplied Micro USB cable to the USB port on your camera.

3. Connect the other end of the Micro USB cable to an available USB port on your computer.

4. After the transmission is complete, disconnect the Micro USB cable according to the instructions

specifying how to safely remove USB devices.

103

To find out if a printer is PictBridge compatible,

simply look for the PictBridge logo on the

packaging or check the owner’s manual for

specifications. With the PictBridge function on

your camera, you can print the captured photos

directly to a PictBridge compatible printer using

the supplied Micro USB cable, without the need

for a PC.

Setting the USB Mode

The camera’s USB port can be set to connect

with either a PC or a Printer; the following

steps will ensure that the camera is correctly

configured to connect with a Printer.

1. Press the

button to

select「USB」and press the /

button to enter the menu.

2. Press the

button to

select「Printer」and press the button

to confirm.

USB PC

Printer

After the camera is reset, it will switch to

PC mode automatically from USB mode.

See “Using the PictBridge Menu“ section

on page 105.

Connecting to a PictBridge Compatible Printer

PictBridge technology allows printing of the photos saved in the memory card by the printer.

104

If the camera is not connected to a PictBridge

compatible printer, the following error message

will appear on the LCD.

Connection Failed!

The error message above will also appear

if the USB mode is set incorrectly, in

which case you should disconnect the

Micro USB cable, check the USB mode

settings, ensure that the printer is turned

on, and then try connecting the Micro

USB cable again.

1. Make sure the printer is turned on.

2. Connect one end of the supplied Micro USB

cable to the USB port on your camera.

3. Connect the other end of the Micro USB

cable to the USB port on the printer.

Connecting to your Printer

105

After setting the USB mode to Printer, the

PictBridge menu will appear.

PictBridge

Print (with Date)

Exit

Print (without Date)

Print Index

Print DPOF Images

Press the

button to select a

menu item and press the /

button to

enter the item.

Refer to the following sections for more

detailed information on each setting.

Using the PictBridge Menu

Print (with Date)

If you have set the date and time on your

camera, the date and time will be recorded and

saved with each photo you take.

1. In the PictBridge menu, select「Print (with

Date)」and the screen as shown below

appears.

Back

2. Press the

button to select a

photo to be printed.

106

3. Press the

button to select

the number of copies for the currently

displayed photo.

4. Press the button and the following

screen will appear.

Print (with Date)

Cancel

Yes

5. Select「Yes」and press the button

to confirm printing; select「Cancel」and

press the button to cancel printing.

Print (without Date)

Use this setting to print the photos without

dates on them.

1. In the PictBridge menu, select「Print

(without Date)」and the screen as shown

below appears.

Back

2. Press the

button to select a

photo to be printed.

3. Press the

button to select

the number of copies for the currently

displayed photo.

107

4. Press the button and the following

screen will appear.

Print (Without Date)

Cancel

Yes

5. Select「Yes」and press the button

to confirm printing; select「Cancel」and

press the button to cancel printing.

Print Index

You can print all photos in the camera via this

function.

1. In the PictBridge menu, select「Print

Index」and the screen as shown below

appears.

Yes

Print Index

Cancel

Yes

2. Select「Yes」and press the button

to confirm printing; select「Cancel」and

press the button to cancel printing.

108

Print DPOF Images

To use DPOF printing, you must select your

photos for printing using the DPOF settings

beforehand. See “DPOF” section on page 92.

1. In the PictBridge menu, select「Print DPOF

Images」and the screen as shown below

appears.

Print DPOF Images

Cancel

Yes

2. Select「Yes」and press the button

to confirm printing; select「Cancel」and

press the button to cancel printing.

Exit

Select「Exit」to exit the PictBridge menu. At

this time, the message「Remove USB Cable!」

appears on the screen.

Disconnect the Micro USB cable from the

camera and printer.

109

Video System

You can use the AV cable (which should be purchased separately) to connect the camera and the

television for realizing the video output. Connect one end of the AV cable to USB/AV port of the

camera; connect the other end to AV-OUT port of the television. Adjust the format of the video

output system according to your requirements, and the steps are as follows:

1. Press the

button to select「TV-System」and press the /

button to

enter the menu.

2. Press the

button to select「NTSC」, and press the button to confirm.

TV-System

PAL

NTSC

The video output system would change accordingly based upon the changes of the selected

language.

NTSC: English, Chinese (Traditional), Japanese, French, Korean, Russian, Vietnamese,

Greek, Hungarian

PAL: German, Spanish, Italian, Chinese (Simplified), Portuguese, Swedish, Danish, Finnish,

Indonesia, Norwegian, Dutch, Turkish, Polish, Thai, Croatian, Czech, Arabic, Hindi

110

Set Eye-Fi Card Connection Mode

This camera supports the wireless connection for Eye-Fi memory card, Enable Eye-Fi connection by

following below steps.

1. Press the

button to select「Eye-Fi」and press the /

button to enter

the menu.

2. Press the

button to select「On」or「Off」and press the button to

confirm.

Eye-Fi

Off

If the Eye-Fi card is not available in the camera, this feature is not displayed.

111

Supported HDMI Connections

HDMI (High Definition Multimedia Interface) is a fully digital audio/video transmission interface,

through which uncompressed audio and video signals are transmitted. Direct transmission of digital

video signals to your TV reduces conversion loss and improves image quality.

Connecting HDMI-Ready TV

1. Use the cable with high resolution output

terminal (which should be purchased

separately) to connect the camera to the

television which meets HDMI standard.

2. The camera will be automatically detected

by the TV.

3. After connecting via HDMI, the camera

enters Playback Mode.

Make sure the camera and the TV are

both turned on before connecting.

Refer to your TV instruction manual for

information on what resolution sizes it

will support. The resolution and output

formats that are not supported will be

grayed out on the camera’s LCD.

HDMI

(Type D)

112 113

Product Specifications

Design and specifications are subject to change without notice.


Sensor

Type 1/2.3”BSI CMOS

Effective Pixels 20.68 Megapixels

Total Pixels 21.14 Megapixels

Lens

Focal Length 4.3mm (Wide) — 223.6mm (Tele)

35mm film equivalent 24mm (Wide) — 1248mm (Tele)

F number F2.8 (Wide) ~ F5.6 (Tele)

Lens Construction 13 groups 15 elements

Optical Zoom 52x

Optical Zoom Normal: (Wide) 60cm ~ ∞, (Tele) 300cm ~ ∞;

Macro: 1cm ~ ∞ (Wide Only)

Autofocus System TTL Autofocus

Anti-Handshake Optical Image Stabilization

Digital Zoom 4x Digital Zoom (Combined Zoom: 208x)

Appendices

113112 113

Number of

Recording

Pixels

Still Image

(4:3)

20MP: 5184 X 3888

10MP: 3648 X 2736

5MP: 2592 X 1944

3MP: 2048 X 1536

0.3MP: 640 X 480

(3:2)

18MP: 5184 X 3456

(16:9)

15MP: 5120 X 2880

2MP: 1920 X 1080

Movie 1920 X 1080 (30fps), 1280 X 720 (60fps/30fps), 640 X 480 (30fps),

High-Speed Movie: 640 X 360 (120fps)

Image Compression Best, Fine, Normal

DCF, DPOF (Ver1.1)

Support Ye s

File Format Still Image Exif 2.3 (JPEG)

Movie MOV [Image: H.264; Audio: Linear PCM (Stereo)]

Shooting Modes

Auto Mode, Program AE, Shutter priority, Aperture priority, Manual

Mode, Face Beautifier, Wi-Fi Mode, Scene Mode, Movie Mode,

Custom Settings

Scene Mode

Handheld Night, Pet Mode, Sunset, Fireworks, Multi Exposure, Sport,

Night Portrait, Landscape, Portrait, Snow, Children, Party, Panorama

Mode

Detection Features Face, Smile, Blink, Cat, Dog

Photo Touch-up Red-Eye Reduction, Skin Soften, Eye Brightening, Eye Enlargement

HDR Ye s

114

Scan Panorama Up to 360°

LCD 3.0 inch (460k Pixels)

Image Auto Rotation Ye s

ISO Sensitivity Auto, ISO100/200/400/800/1600/3200

AF Method Single AF, Multi-AF (TTL 25-point), Object Tracking,

Face-Detection

Exposure Metering

Method

Artificial Intelligence AE (AiAE), Center-Weighted Average, Spot

(Fixed to Center of Frame), Face AE

Exposure Control Method Program AE (AE-Lock Available), Shutter Prior AE, Aperture Prior AE

Exposure Compensation ±3 EV in 1/3 Step Increments

Shutter Speed 1/2000 ~ 30 Seconds

Continuous Shot Ye s

Playback Modes Single, Index (9/16 Thumbnails), Slide Show, Date,

Continuous Shooting, Zoom (Approx. x2 ~ x8)

White Balance Control AWB, Daylight, Cloudy, Fluorescent, Fluorescent CWF, Incandescent,

Manual WB, Color Temp. (1900K ~ 10000K)

Flash

Flash Method Pop-up (Manual)

Flash Modes Force Off, Flash Auto, Fill Flash, Slow Sync., Slow Sync.+Red-Eye,

Red-Eye Reduction

115

Recording Media Internal Memory: Approx. 8MB

SD/SDHC Card (Up to 32GB Support) [MMC Card Not Supported]

Multi-Language Support 27 Languages

Jacks AV-OUT/USB 2.0 (Micro 5 pin USB), HDMI (Type D)

Eye-Fi Support Ye s

Wi-Fi Yes (802.11b/g/n)

Remote Viewfinder Yes (via ios/Android device)

Power Rechargeable Li-ion Battery LB-060, 3.7V 1100mAh,

In-Camera Charging

Shooting Capability

(Battery Performance) Approx. 240 Shots (Based on CIPA Standards)

Operation Environment Temperature: 0 ~ 40°C, Humidity: 0 ~ 90%

Dimensions (W X H X D) Approx. 121.3 X 85.8 X 97.5mm (Based on CIPA Standards)

Weight Approx. 508g (Body only)

116

Prompts and Warning Messages

Message Description Action

Warning! Battery

exhausted.

Warning before power off when the

camera battery is exhausted. Charge the battery.

Lens obstruction,

Re-start Camera.

The lens is jammed or some foreign

object is preventing the lens from

functioning properly.

Turn off the camera and

restart it to reset the lens.

Suggest using tripod.

The message will appear when

shooting in low light/illuminated

scenes.

Use of a tripod or other

support is suggested.

Built-in memory error! An error occurs in built-in memory. Format the internal memory.

Improper alignment.

Please try again.

The offset is too big for panorama

shooting.

Remove the message after

2 seconds and return to

shooting.

Warning! Do not turn

off your camera during

update!

The message appears during the

firmware update process.

The message disappears

after the camera update and

restart.

117

Message Description Action

Remove USB Cable! Indicates that you can disconnect the

Micro USB cable.

The message disappears after

you disconnect the Micro

USB cable.

Connection Failed! Failure to connect to your PC, printer,

TV (with HDMI).

Remove the cable and retry

connection.

Write Protect ! The memory card is locked. Unlock the write-protect

switch of the memory card.

Card Full ! Indicates that the memory card is full. Insert a new memory card or

delete unwanted images.

Memory Full ! Indicates that the internal memory is

full.

Insert a new memory card or

delete unwanted images.

118

Message Description Action

Card Error ! The memory card can’t be identified

after being formatted.

Insert a new memory card

or format the card with this

camera.

Card is not formatted.

The inserted memory card is

unformatted or has been formatted on

a computer or other device and is not

compatible with this camera.

Disappear after 2 seconds

and enter the formatting

process.

Slow access

When a memory card lower than Class 4

is used to record a HD movie, the writing

speed will be slower and recording will

not continue.

Use an memory card with

Class 4 or higher.

No Red-Eye Detected! Red eyes have not been detected in the

image.

The message will disappear

after 2 seconds.

This image cannot be

edited.

The file format does not support editing

or the edited file cannot be edited again.

The message will disappear

after 2 seconds.

119

Message Description Action

Exceeded

maximum folder

number.

Prompt message when the archives or file

folders in the memory card have reached the

maximum (9999 for archives, 999 for file

folder).

Copy the images to

your PC and format the

memory card with this

camera.

Too many pictures

for fast processing.

During the playback by date, the images

exceed specifications so that it is not possible

to play by date.

This may be solved by

deleting unnecessary

images.

Unable to

recognize files.

The format of the file to be viewed is not

supported or the file is corrupted so it cannot

be properly read.

You may be able to play

it back on another brand

of camera or on your

computer.

No Picture! When you press the play button, no image

files exist in the camera or memory card.

The message disappears

2 seconds later to return

to the photo shooting

screen.

No continuous

group file.

When you switch from the playback mode

to continuous photo mode, there is no

continuous group file.

The message disappears

after 2 seconds and the

camera returns to the

normal playback mode.

Protected!

Undeletable!

The file is protected. The message appears

when you delete it.

Unprotect the file before

deleting.

120

Troubleshooting

Problem Possible Causes Solution

Camera does not

turn on

The battery has been depleted.

The battery is not inserted

correctly.

Recharge the battery.

Correctly reinstall the battery.

Camera turns off

suddenly during

operation

The batteries have been

depleted. Recharge the battery.

The picture is blurred Camera shakes while taking a

picture.

Turn on OIS feature.

Please use tripod for high

magnification (above 15X) optical

zoom.

Images and video files

cannot be saved

The memory card is full.

The memory card is locked.

Use another memory card or

delete unnecessary files.

Unlock the memory card.

Images will not print

from the connected

printer

The camera is not connected to

the printer correctly.

The printer is not PictBridge

compatible.

The printer is out of paper or ink.

The printer paper is jammed.

Check the connection between the

camera and printer.

Use a PictBridge compatible

printer.

Load paper into the printer or

replace the ink cartridge in the

printer.

Remove the jammed paper.

121

Problem Possible Causes Solution

Saving data to memory

card is slow

Using a memory card below Class

4 may result in slower recording

times.

Use an memory card with

write Class higher than 4 to

improve performance.

Cannot write to the

memory card The memory card has been locked.

Release the write lock of the

memory card or replace with

another card.

Too many movies to

process

The number of pictures or folders

in the memory card exceed the

specifications, so the playback of

data folder cannot be displayed.

Delete unwanted files.

The flash icon

appears on the LCD

Current shooting environment

requires flash. Turn on flash.

When shooting with stacked filters attached, the corners of the photo may turn dark

(Vignetting effect) because the filter holder blocks light from reaching the camera image

sensor; especially, at wide angle zoom control settings. Please take test shots and review the

results when using stacked filters.

122

Please enter the new password on smart device after changing Wi-Fi password. Some models

of smart device will remember the Wi-Fi password previously entered, so please clear the old

password on smart device manually before connection (For different models, this operation

may be varied, please subject to your user manual.)

iOS system Android system

Ver. 2

The Kodak trademark and trade dress are used under license from Kodak.

JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA

JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK

http://kodakpixpro.com

Licensed

Product

Kodak Pix Pro AZ 527 Operating Guide Az527 En

Navigation menu

Versions of this User Manual:

Views

Navigation
