User Manual
ii 1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 South Main Street, Gardena, CA 90248, USA
JK Imaging Europe, 71 Clarendon road, Watford, WD17 1DS, UK
Company website: www.kodakpixpro.com
For Customers in the U.S.A.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
For Customers in Europe
"CE" mark indicates that this product complies with the European requirements for safety, health,
environment and customer protection. "CE" marked cameras are intended for sales in Europe.
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of electrical
waste and electronic equipment in the European countries. Please do not throw the equipment
into domestic refuse. Please use the return and collection systems available in your country for
proper, safe disposal of this product.
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
Before You Start
2 32 3
About this Manual
Thank you for purchasing this KODAK PIXPRO digital camera. Please read this manual carefully and
keep it in a safe place for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published manual may be
reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language
or computer language, in any form, by any means, without the prior written permission of JK
Imaging Ltd..
All trademarks mentioned in this manual are used for identification purposes only and are
properties of their respective owners.
This manual will instruct you on how to operate the KODAK PIXPRO digital camera. JK Imaging
Ltd. has tried its utmost to ensure the correctness of the user manual contents, but reserves the
right to modify as necessary. All of these contents are subject to change without prior notice.
Throughout this manual, the following symbols are used to help you locate information quickly
and easily:
Indicates useful information.
In the instructions below, the following symbols may be used throughout this manual on how to
operate the camera. This is to facilitate better understanding：
「Item properties」： The optional properties in the camera interface are indicated by the
symbol「 」.
2 32 3
Safety Notes
Safety notes for this camera
Do not drop the camera or allow it to hit solid objects.
Do not attempt to disassemble or repair the camera.
Do not use or store the camera in dusty places or on a beach to prevent dust or sand from
entering the camera, causing possible damage to it.
Do not use or store the camera in a hot environment or under direct sunlight.
Do not use or store the camera near a powerful magnetic field, for example near a magnet or
transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct sunlight for a long period of time.
To prevent the camera from being damaged by moisture, do not use or store the camera in very humid
environments, such as in rain or near bodies of water.
If water accidentally comes in contact with the camera, turn the camera off, remove the battery
and the memory card, and dry it within 24 hours.
When you take the camera from a cold place to a warmer environment, condensation may occur.
Please wait for a reasonable period of time before you turn it on.
Before you remove the battery and memory card, the camera should be turned off.
When you clean the body of the camera, do not use abrasive, alcohol-based or organic cleaner.
Use a professional lens wiping cloth and dedicated cleaner to wipe and clean the lens.
Download your photos and remove the memory card when you are going to store the camera for
a long period of time.
If this camera is not in use for a long time, please keep it in a dry and clean condition.
Our company will not pay compensation for any failure of playback of pictures or videos caused
by improper operation.
4 5
Safety notes for battery
Please use a battery that is the same type as the one included.
Please use the attached charger to charge the battery.
If battery fluid leaks inside the camera, contact our customer service department. If battery fluid
leaks onto your skin, rinse your skin with clean water and seek immediate medical attention.
Disposal of used batteries should be carried out in accordance with the local (national or
regional) regulations.
To prevent the battery from being damaged, do not drop the battery or allow it to hit solid
objects or to be scratched by the objects.
Do not let the battery come in contact with metal objects (including coins) to avoid short
circuiting, discharging, excessive heat, or possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep the battery contacts dry.
Do not heat the battery or throw it into a fire to avoid a possible explosion.
Do not store the battery in a hot environment or in direct sunlight.
If the battery overheats during charging or use, stop charging or use immediately. Turn off the
product, remove the battery carefully, and wait until it cools down.
When the camera is stored for a long period of time, remove the battery and keep it in a dry
place that is not accessible to infants and children.
In a colder environment, the performance of the battery could be noticeably reduced.
When you install the battery, install it according to the positive and negative markings on the
battery compartment. Never force it into the battery compartment.
4 5
Safety notes for memory card
We suggest buying only well-known, name brand memory cards to ensure peak performance.
Format the memory card using the camera before you use it or insert a new one.
Do not drop the memory card or allow it to hit solid objects to avoid damaging it.
Do not attempt to disassemble or repair the memory card.
Do not expose the memory card to water. Always keep it dry.
Do not remove the memory card when the camera is turned on. Otherwise, the memory card
could be damaged.
Do not directly edit the data on the memory card. Copy the data to your PC before you edit them.
When the camera is stored for a long period of time, be sure to download your photos and
remove the memory card. Store it in a dry environment.
Do not modify the name of the files or folders of the memory card using your PC. Modifying the
file names may cause the files to not be recognized on the camera or a possible error may occur.
A photo taken with the camera will be stored in the folder that is automatically generated on the
memory card. Do not store photos that are not taken using this
camera in these folders as the pictures cannot be recognized during the playback.
When you insert a memory card, make sure the notch of the card matches the markings on the
top of the card slot.
6 76 7
Other Safety Notes
Do not disconnect the power or turn the camera off during the update process. Doing so may
cause incorrect data to be written and the camera may not power on later.
When using your camera on an airplane, observe the relevant rules specified by the airline.
Due to the limitations of manufacturing technology, the LCD may have a few dead or bright
pixels. These pixels do no effect the quality or performance of the camera, photos or video.
Do not expose the LCD to water. In a humid environment, only wipe it with a soft and dry
cleaning cloth.
If the LCD screen is damaged, pay particular attention to the liquid crystal in the screen. If any of
the following situations arise, take the recommended immediate action indicated below:
1. If liquid crystal comes in contact with your skin, please wipe with a dry cloth, wash thoroughly
with soap, and rinse with plenty of clean water.
2. If liquid crystal gets into your eye, flush the eye immediately with plenty of clean water for at
least 15 minutes and then seek for medical assistance.
3. If liquid crystal is swallowed, immediately flush your mouth thoroughly with clean water and
induce vomiting. Seek for medical assistance.
6 76 7
Before You Start ......................................................................................................1
Safety Notes ........................................................................................................... 3
Contents .................................................................................................................. 7
Getting Ready ....................................................................................................... 11
Accessories Included ......................................................................................................................................11
Part Names ......................................................................................................................................................12
Installing Battery and Memory Card ..........................................................................................................14
Charging Battery.............................................................................................................................................16
Turning Camera On and Off ......................................................................................................................... 17
How to take pictures ......................................................................................................................................17
Set your Language, Date/Time ...................................................................................................................18
Mode Overview ....................................................................................................21
LCD Screen Display ........................................................................................................................................21
Overview of the Screen Icons in Photo Shooting Mode .................................................................21
Contents
8 9
Overview of the Screen Icons in Movie Mode ................................................................................. 22
Using the Mode Button ................................................................................................................................ 23
Panorama Mode.....................................................................................................................................24
Scene Mode ............................................................................................................................................ 25
Basic Operation ...................................................................................................29
Using the Zoom Function .............................................................................................................................29
Display Setting ...............................................................................................................................................30
Macro Mode .................................................................................................................................................... 31
Self-timer Setting ..........................................................................................................................................32
Flash Mode ..................................................................................................................................................... 33
EV Setting........................................................................................................................................................34
Using Quick Recording ................................................................................................................................. 36
Playback Mode ....................................................................................................37
Overview of the Screen Icons in Playback Mode .................................................................................... 37
Viewing Photos and Videos .........................................................................................................................38
Thumbnail View .............................................................................................................................................39
Using Zoom Playback (for still pictures only) ........................................................................................ 40
8 9
Slideshow .........................................................................................................................................................41
Photos and Video Deletion .........................................................................................................................42
Using the Menus .................................................................................................43
Shooting Menu ...............................................................................................................................................43
Shooting Setting Menu ................................................................................................................................. 49
Movie Menu ................................................................................................................................................... 53
Movie Setting Menu .....................................................................................................................................56
Playback Menu .............................................................................................................................................. 57
Playback Setting Menu.................................................................................................................................60
Setup Menu ....................................................................................................................................................63
Sound Settings .......................................................................................................................................64
Power Saver ............................................................................................................................................64
Language .................................................................................................................................................65
World Time .............................................................................................................................................65
Date & Time ............................................................................................................................................65
LCD Brightness .......................................................................................................................................65
10 1110 11
File Setting ......................................................................................................................................................66
Format ...................................................................................................................................................... 66
Copy to Card ........................................................................................................................................... 67
File Numbering .......................................................................................................................................67
Reset .........................................................................................................................................................68
FW Version .............................................................................................................................................68
Connection Settings ...........................................................................................69
Connecting to a Computer ..........................................................................................................................69
Connecting to a PictBridge Compatible Printer .......................................................................................71
Using the PictBridge Menu .......................................................................................................................... 73
Video System .................................................................................................................................................77
Set Eye-Fi Card Connection Mode ............................................................................................................. 78
Appendices ........................................................................................................... 79
Product Specifications ..................................................................................................................................79
Prompts and Warning Messages ............................................................................................................... 83
Troubleshooting ............................................................................................................................................. 87
10 1110 11
Getting Ready
Your camera box should contain the camera model you purchased along with the following
accessories. If anything is missing or appears to be damaged, please contact your retailer. (Based on
sales in different countries or regions, the shape of the AC adapter will vary. Please subject to the
actual product will prevail.)
Accessories Included
Micro USB cable
Warranty card
AC adapter Wrist strapRechargeable
Li-ion battery
Quick start guide Service card
Quick Start Guide
STOP
12 1312 13
Part Names
1. Micro USB port
2. Zoom lever
3. Shutter button
4. Power button
5. AF assist beam/Self-timer lamp
6. Flash lamp
7. Lens
8. Microphone
2
7
54
8
6
1
3
12 1312 13
9. Indicator lamp
10. Fast video recording button
11. Mode button
12.
AC
Display button/Arrow button (Up)
13.
C
A
Flash button/Arrow button (Right)
14. SET button
15. Playback button
16. Battery cover
17.
CA
Delete button/Arrow button (Down)
18. Menu button
19.
AC
Macro button/Self-timer button/
Arrow button (Left)
20. Tripod socket
21. Speaker
22. LCD
910
12
11
16
13
14
15
18 17
20 19
21
22
14 1514 15
2. Insert the battery into the battery
compartment according to the negative
and positive directions as illustrated in the
picture. Push the battery down until it locks
in place.
1. Open the battery cover.
2
1
Installing Battery and Memory Card
14 1514 15
4. Close the battery cover.
3. Insert the memory card into the memory
card slot as shown in the diagram below:
The memory card (SD/SDHC) is optional
and not included in all camera packaging.
It needs to be purchased separately.
Please use an original memory card
which is Class 4 or higher and has a
capacity of 4GB to 32GB.
To remove your memory card, open the
battery cover, gently press the memory
card to eject it and remove it carefully.
Write
protection
buckle
16 1716 17
Please insert the battery and charge it under
shutdown mode.
1. Connect the camera and the power charger
using the supplied Micro USB cable.
2. Insert the plug of the power charger into the
power outlet to charge the battery.
3. When the camera is turned off, you can also
connect the camera to your PC using a Micro
USB cable to charge the battery.
After the battery is stored for a long period
of time, use the supplied power charger to
charge the battery prior to use.
Charging indicator:
Steady orange: Charging.
The indicator will go out once charging is
finished.
To have maximum battery life, charge the
battery for at least 4 hours the first time.
Please charge the battery indoors
between 0°C and 40°C.
The camera will only charge while
powered off. If the camera is turned on
while connected to power, normal camera
functions will be available for use, but the
camera will not charge until it is turned off.
Charging Battery
Indicator lamp
16 1716 17
Turning Camera On and Off
Press the power button to turn the camera on.
To turn the camera off, press the power button
again.
Power Button
When the power is off, press and hold
the button to power on and enter
playback mode.
How to take pictures
1. Hold the camera with both hands , not
blocking the flash and lens by fingers.
2. Aim the camera at the object and then
frame with the LCD.
3. Use the zoom lever to select Tele or Wide
positions to zoom in or out on your subject.
4. Press the shutter button half way to focus
on the subject. When the focus frame turns
green, press the shutter button completely
down to take the picture.
18 1918 19
Set your Language, Date/Time
1. When you turn the camera on for the
first time, the language selection screen
appears.
2. Press the direction buttons to select your
desired language.
3. After you press the button to confirm
the selection, the Date/Time settings
screen appears.
4. Press the left/right button to select
the Date/Time to be adjusted: Time is
displayed in YYYY.MM.DD HH:MM.
5. Press the up/down button to adjust the
value for the selected Date/Time.
6. Press the button to confirm the time
settings and the snapshot screen appears.
Set your Language, Date/Time after the first power-on
18 1918 19
Resetting your Language
After you set your language for the first time,
follow the instructions below to reset your
language.
1. Press the button, press the up/down
button to select , and press the
button to enter the menu.
2. Press the up/down button to select , and
press the button or right button to enter
the menu.
3. Press the up/down button to
select「Language」and press the
button or right button to enter the menu.
4. Press the direction buttons to select your
desired language and press the button
to confirm.
5. Press the button and the snapshot
screen appears.
20 2120 21
Resetting Date/Time
After you set your Date/Time for the first time,
follow the instructions below to reset date and
time.
1. Press the button, press the up/down
button to select , and press the
button to enter the menu.
2. Press the up/down button to select , and
press the button or right button to enter
the menu.
3. Press the up/down button to select「Date
& Time」and press the button or right
button to enter the menu.
4. Press the left/right button to select
the Date/Time to be adjusted: Time is
displayed in YYYY.MM.DD HH:MM.
5. Press the up/down button to press the
value for your selected block. After you
finish your settings, press the button to
confirm.
6. Press the button and the following
snapshot screen appears.
20 2120 21
LCD Screen Display
Overview of the Screen Icons in Photo Shooting Mode
Mode Overview
5M 3M 2M
-0.3 EV 400 ISO
1234
00:56:00
SD
12 34
5
6
7
8
9
10
11
12
13
141516
17
18
20
21
22
23
19
x3.2
15 sec
1 Shooting Mode 9 Image Size 17 OIS (Optical Image
Stabilization)
2 Macro Mode 10 Video Quality 18 Eye-Fi ON (with signal)
3Zoom Display (By turning
the Zoom Lever) 11 ISO Value 19 Continuous Shot
4Memory Card/Built-in
Memory 12 Remaining
Recording time 20 Expo Metering
5 Battery Status 13 Exposure
Compensation 21 Self-timer
6 White Balance 14 Focus Frame 22 AF Mode
7 Color Effect 15 Shutter Speed 23 Flash Mode
8 Number of remaining shots 16 Histogram
22 2322 23
Overview of the Screen Icons in Movie Mode
-0.3 EV
00:56:00
00:56:00
SD
1 2 43 5 6
91011
12
14
15
13
7
8
x3.
2
1 Movie Mode 6 Battery Status 11 Focus Frame
2 Macro Mode 7 Color Effect 12 Image Stabilization
3 Self-timer 8 Video Quality 13 Eye-Fi ON (with signal)
4Zoom Display (By
turning the Zoom Lever) 9Remaining Recording
time 14 Expo Metering
5Memory Card/Built-in
Memory 10 Exposure Compensation 15 AF Mode
22 2322 23
Using the Mode Button
This camera provides a convenient mode button that allows you to switch easily among different
modes. After pressing the button to enter the mode selection menu, press the left/right button
to choose the selected mode. Press the button to confirm your selection. All the available modes
are listed below:
Mode Name Icon Description
Auto Mode
In this mode, the optimal conditions for taking pictures will be set based
on the subject and environment. It is the most commonly used mode for
taking pictures.
Manual Mode This mode is for manually setting EV, shutter speed and ISO value.
Portrait Mode
The best setting for portrait shooting, enables AE/AF for faces. The
camera is set to automatically adjust exposure for realistic capture of
skin tones.
Movie Mode Record videos.
Panorama
Mode
In this mode, up to 4 frames can be stitched together to create a single
panoramic photo.
Scene Mode Choose from 20 different pre-set scene types and effects for your
photos.
24 25
5. If continuous pictures are less than 4 shots,
press the button, the camera will splice
the pictures automatically. Press playback
button to enter playback mode to see the
effect.
6. If you take 4 pictures, the camera will splice
the pictures automatically. Press playback
button to enter playback mode to see the
effect.
Panorama Mode
Panorama Mode allows you to create
a panoramic picture. The camera will
automatically compose a panoramic picture
using the individual shots that you take.
Follow these easy steps to create a panoramic
picture:
1. Press the button to select panorama
mode ( ).
2. Press the direction buttons to select a
shooting direction. (The right direction
is used as default if you do not make any
choice) 2 seconds later, the camera is ready
to take pictures. You can also press the
button or half press the shutter button to be
ready to take pictures.
3. Compose the first view of the panoramic
picture on the LCD and press the Shutter
button to capture the image.
4. After the first shot is taken, the
semi-transparent image of the first shot
will appear at the edge of the screen. You
can use this image to compose your picture
before you press the Shutter button to
capture and finish manual stitching.
24 25
During shooting, the flash, self-
timer, macro modes and exposure
compensation are not available. Focus
adjustment is also not available at this
time.
In Panorama Mode, up to 4 photos can
be captured when the image size is set
at 2M.
During panorama mode shooting, press
the button to interrupt shooting and
save the current pictures taken. Press the
down button ( ) to cancel shooting and
not to save the previously taken pictures.
Scene Mode
You can select an appropriate mode from
the 20 scene modes according to the type of
environment you are shooting. The camera
then configures the most appropriate settings
automatically.
1. Press the button to select scene mode
( ). The LCD will display a menu like
the example below:
Auto Scene
2. Press the direction buttons to select a
scene, and press the button to confirm.
3. If any need of changing the scene, please
press the button and then the button
and finally the direction buttons to reselect
the scene.
26 27
Scene Description
Auto Scene Identifies the scene automatically; Person, Backlighting, Landscape,
Macro, Night Scene, Night Scene Person, Auto.
Landscape For landscapes and outdoor shots. Vivid reproduction of green and
blue.
Sport For fast-moving subjects. Capture sharp, action shots with minimal
blur. This mode is not recommended for shooting indoors.
Beach For taking pictures in areas with strong sunlight.
Sunset For sunsets. Capture subjects in strong sunlight.
Fireworks For fireworks at night. Slower shutter speed is adjusted for brilliant
images. The use of a tripod is recommended.
Night Landscape For night scenes. The use of tripod is recommended.
Snow For snow scenes. Reproduce natural, clear white scenes.
Children Turns off flash automatically. Avoids disturbing subject, suitable for
taking photos of children.
ID For shooting ID size photos. (It is recommended to print using 6-inch
4R (6X4) photographic paper).
Glass For objects behind transparent glass.
Photo Frame For adding interesting frame effects to the photo.
26 27
Scene Description
Panning Shot Suitable for capturing fast moving objects to have a clear subject with
a blurred background.
Fish Eye For interesting fish eye effect.
Party Suitable for taking indoor party pictures, even under the complicated
lighting conditions.
Indoor For indoor settings. Reduce blur and improve color accuracy.
Leaf For plants. Capture brilliant shots of greenery and blossoms.
Museum For museums or flash-free areas. Retain color and reduce blur.
Night Portrait For portraits against night scenery.
Sketch For taking photos with pencil sketch effect.
28 2928 29
Auto Scene Mode (ASCN)
In “ASCN” scene mode, the camera can detect different environments intelligently and
automatically select the best scene and photo settings for you.
“ASCN” can intelligently detect the following scenes:
Mode Name Description
Landscape Mode For landscapes, will automatically adjust the exposure and
reproduce vivid green and blue colors.
Portrait Mode Most suitable for capturing people with focus on their faces.
Night Portrait When you take portraits at night, or in low light conditions, will
automatically adjust the exposure for people and night scenes.
Backlit Portrait
When the sun or any other light source is behind you, will
automatically adjust the foreground exposure to produce the best
pictures possible.
Night Landscape Mode For night scenes, will automatically increase the ISO value to
compensate for low light.
Macro Mode The Macro setting is ideal for shooting small objects or close-up
photos.
Auto Mode The camera will automatically adjusts the exposure and focus to
ensure the best possible pictures.
28 2928 29
Your camera is equipped with two types of
zoom functions: optical zoom and digital zoom.
Toggle the zoom lever of the camera to zoom in
or out of the subject while taking pictures.
Using the Zoom Function
Basic Operation
Zoom
Indicator
When the optical zoom reaches the threshold
as digital zoom, release and turn the zoom lever
to T to switch between the optical zoom and
digital zoom.
Zoom
Lever
Zoom Out Zoom In
30 31
Classic: Displays the camera parameters on
screen
-0.3
EV
400
ISO
1234
SD
16M
00:56:00
Full: Camera parameters with Grid and
Histogram
-0.3
EV
400
ISO
1234
SD
16M
00:56:00
Off: Does not display any additional icons on
screen
Display Setting
Press the button to display the settings: Classic, Full, Off.
30 31
Macro Mode
The Macro setting is ideal for shooting small
objects or close-up photos. This mode allows
you to focus on subjects very close to the
camera.
1. Press the left button ( ) to enter the
marco menu.
2. Press the left/right button to select the
following 2 modes:
• Macro Off
Select this option to disable
macro.
• Macro On
Select this option to make focusing
on the object closer to the lens (At
the W side, the shooting distance
should be more than 3 cm).
3. Press the button to confirm the settings
and enter the shooting screen.
32 33
Self-timer Setting
Use this function to take pictures at pre-set
intervals. First choose 2 seconds, 10 seconds,or
by smile detection. and then take the pictures.
1. Press the left button ( ) , and then
press the down button ( ) to enter the
self-timer menu.
2. Press the left/right button to select the
following 4 modes:
• Self-timer Off
Disables the Self-timer.
• Self-timer 2 sec
A single picture is shot 2 seconds
after the shutter button is pressed.
• Self-timer 10 sec
A single picture is shot 10 seconds
after the shutter button is pressed.
• Self-timer Smile
Press the shutter button and a
picture will be taken immediately
after a smile is detected.
3. Press the button to confirm the settings
and enter the shooting screen.
When enabling the self-timer, pressing
the shutter or the ( ) button can
disable the self-timer and return to the
shooting screen while keeping the
self-timer setting.
When enabling the smile detection,
pressing the shutter or the button
can disable the self-timer and return to
the shooting screen without keeping the
Self-timer Smile setting.
32 33
Flash Mode
The flash provides supplemental light for the
scene. The flash is usually used when shooting
against the light to highlight the object; it is
also suitable for metering and shooting in
darker scenes to improve the exposure.
1. Pop up the flash manually as shown below
(as shown in the figure).
2. Press the right button ( ) to enter the
flash settings menu.
3. Press the left/right button to select the
following 6 modes:
• Force Off
Flash is turned off.
• Flash Auto
Camera flash goes off
automatically based on existing
light conditions.
• Fill Flash
The flash will engage with each
shot even if there is enough
available light to take the photo
without flash.
• Slow Sync.
This allows you to take pictures of
people at night that clearly show
both your subjects and the night
time backdrop. The use of a tripod
is recommended when shooting
with this setting.
• Slow Sync. + Red-Eye
Use this mode for slow synchrony
shots with red-eye reduction.
• Red-Eye Reduction
The camera emits a brief pre-flash
before the picture is taken to
reduce red-eye effects.
4. Press the button to confirm the settings
and enter the shooting screen.
34 3534 35
EV Setting
The EV function menu of the camera includes
functions, such as EV, shutter adjustment, ISO.
Using the appropriate function settings can
improve your pictures.
To select the best setting for optimum photos,
follow these steps:
1. Press the button to display the settings
screen.
2. Press the left/right button to select the
setting options.
3. Press the up/down button to adjust the
option values.
4. Press the button to confirm the settings
and enter the shooting screen.
Exposure Compensation
Set up to adjust the picture brightness. In
the case of a very high contrast between the
photographed object and the background, the
brightness of the picture can be appropriately
adjusted. (Adjustable in Mode)
The adjustable range of exposure value is from
EV -2.0 to EV+2.0.
34 3534 35
ISO
The ISO function allows you to set the
sensitivity of the camera's light sensor based
on the brightness of the scene. To improve
the camera's sensor performance in darker
environments, a higher ISO value is required.
A lower ISO value is needed when shooting in
brighter conditions.
Pictures taken at higher ISO settings will
generally have more noise than those taken at
lower ISO settings. (Adjustable in Mode)
The camera's ISO settings include: Auto, 80,
100, 200, 400, 800, 1600.
Shutter Adjustment
For shutter speed, the camera may
automatically set the aperture value
corresponding to the manually set shutter
speed so as to obtain a most suitable exposure
value. The movement of object may be shown
by adjusting the shutter speed. High shutter
value can make you clearly capture the
movement of fast moving object while low
shutter value can allow you to take a picture
for fact moving object with a strong sense of
movement. (Adjustable in Mode)
36 3736 37
Using Quick Recording
In shooting mode, press the button to begin recording video.
After recording, press the button or the shutter button to stop recording. The camera will store
the video and return to the shooting screen.
36 3736 37
Playback Mode
Overview of the Screen Icons in Playback Mode
1/45
x2
SD
9
321
4
5
11
10
12
6
8
7
2015 06-25 00:002015 06-25 00:00
1 DPOF File 7 Image Zoom Ratios
2 File Protection 8 Image Zone
3Memory space (indicating the current number
of photos and total number of photos) 9 Shooting Date
4 Memory Card/Built-in Memory 10 Eye-Fi ON (with signal)
5 Battery Status 11 Red-Eye Reduction
6 Zoom Magnification Area 12 HDR
38 39
Viewing Photos and Videos
To view the captured photos and video clips on the LCD:
1. After pressing the button, the last photo or video clip taken will be displayed on the LCD.
2. Use the left/right navigation buttons to scroll through the photos or video clips stored in the
internal memory or on the memory card.
3. To play a selected video clip, press the button to enter the movie playback mode.
An operation guide appears on the screen when playing back a video. Press the appropriate buttons
to enable the corresponding functions.
00:00:47 00:01:23

00:00:47 00:01:23
1 Increase volume
2 Pause
3 Fast forward
4 Decrease volume
5 Rewind
6 Back to the beginning of the video
7 Play
8 Play video forward
9 Cancel playback
10 Play video backward
Mute
Under Playback Paused
38 39
Thumbnail View
When in playback mode, rotate the zoom
lever counter to the position to display
thumbnail images of the photos and videos on
the screen.
1. Slide the zoom lever to switch between 3x3
and 4x4 thumbnails.
2. Press the direction buttons to select a
picture or video clip to view and press the
button to restore it to the original size.
When the icon appears, it means this
is a video file.
W
40 41
Using Zoom Playback (for still pictures only)
When playing back photos, you can also use the
zoom lever to zoom in on the photos 2 to 8 times.
1. Press the button to switch to playback mode.
2. Press the left/right button to select a picture to
be zoomed in.
3. Rotate the zoom lever to to zoom in.
4. The screen will display the number of times and
area of the photo zooming operation.
5. Press the direction buttons to navigate and select
a part of the image to be zoomed in.
6. Press the button to return the image to its
original scale.
Movie images cannot be magnified.
x2
x2
x2
T Zoom In
40 41
This setting allows you to view all the stored images as a slideshow.
1. Press the button to enter playback screen.
2. Press the button to enter slide option.
3. Press the left/right button to select slideshow playing or 「Cancel」 to return to the playback
screen.
4. Press the button to confirm the setting.
Slide playing function supports movie playing.
Images don’t rotate in the slideshow playback.
Slideshow
42 4342 43
Photos and Video Deletion
In playback mode, press the down button ( )
to delete your photos and videos.
To delete photos or videos:
1. Press the button to switch to playback
mode.
2. Press the left/right button to select the
photos and videos to be deleted.
3. Press the down button ( ) and the
deletion screen is displayed.
4. Press the up/down button to
select「Delete One」or「Exit」and press
the button to confirm.
Erased photos/video clips cannot be
recovered.
Please refer to page 61 for instructions on
deleting more than one image at a time.
42 4342 43
Shooting Menu
Using the Menus
Functions that can be enabled are different
under each mode.
Mode:
1. In photo shooting mode, press the
button to enter the shooting menu.
2. Press the up/down button to select the
shooting menu to be set.
3. Press the left/right button to select the
shooting menu to be set and press the
button to confirm.
Refer to the following pages for more details
about each setting.
Expo Metering
Use this setting to select the "target" size of
the camera's field of view to be metered.
• AIAE (Artificial Intelligence AE)
Automatically selects the central
and peripheral metering, to calculate
the reasonable value of metering by
weighting.
• Spot
For metering targets a small area in
the center of the camera's field of
view.
• Center
For metering targets a slightly larger
area in the center of the cameras
field of view.
44 45
Image Size
The size setting refers to the image resolution
in pixels. A higher image resolution allows
you to print that image in larger sizes without
degrading the image quality.
The larger the number of recorded pixels,
the larger the file size and the fewer files
that can be saved on your memory card.
OIS (Optical Image Stabilization)
This mode can help reduce photo blur caused
by unintentional hand shake, low light.
• OIS: Off
• OIS: On
Use this image stabilization mode in dark
environments.
Shooting in a windy or unstable
environment (such as a moving vehicle)
may cause blurred images.
44 45
Cont. AF
Enable the continuous AF to be able to
continuously focus automatically when taking
pictures.
• Cont. AF: Off
• Cont. AF: On
White Balance Setting
The white balance setting allows you to adjust
the color temperature for different lighting
sources to ensure the most accurate color
reproduction.
• AWB
• Daylight
• Cloudy
• Fluorescent
• Fluorescent CWF
• Incandescent
• Manual WB (Fully press the
shutter button to detect the white
balance value)
46 47
Focus Setting
In different photo shooting modes, you can
select different focus methods.
• Single-AF
The focus frame appears on the
center of the LCD to focus on the
subject.
• Multi-AF
The camera automatically focuses
the subject in a wide area to find
the focus point.
Continuous Shot
Use this setting to perform continuous
shooting. After entering this mode, you can
shoot multiple images by continuously holding
the shutter button down.
• Single
• Continuous Shot
• 3 Shots
• Time-Lapse 30sec
• Time-Lapse 1min
• Time-Lapse 5min
• Time-Lapse 10min
46 47
Color Effect
The image color setting allows you to select
different effects.
1. In photo shooting mode, press the
button to enter the shooting menu.
2. Press the up/down button to select the
image color setting menu, press the
button to enter the menu.
3. Press the left/right button to select the
image color setting options.
• Normal
• Vivid
• Sepia
• Black and White
The flash is disabled in the continuous
shooting in order to achieve quick
succession of shots.
48 4948 49
• Options in the shooting mode (○: Disponible ×: Indisponible)
Options
Shooting Modes
○○○○
○○○○
○ ○ × ×
○○○ ×
○○○ ×
○ ○ × ×
×○× ×
×○× ×
×××○
48 4948 49
Mode:
1. Press the button in photo shooting mode
and press the up/down button to select .
2. Press the button to enter the menu.
3. Press the up/down button to select , and
press the button or right button to enter
the menu.
4. Press the up/down button to select the item
to be set and press the button or right
button to enter the menu.
5. Press the up/down buttons to select an
option and press the button to confirm.
Shooting Setting Menu
Quality
The quality setting can be used to adjust the
image compression ratio.
• Best (16M Average File Size: 4.0MB)
• Fine (16M Average File Size: 2.5MB)
• Normal (16M Average File Size: 2.0MB)
50 51
AF Assist Beam
In a darker environment, AF assist beam can be
turned on for better focus.
• Off
• On
Digital Zoom
This setting is for adjusting digital zoom. If this
function is disabled, only optical zoom can be
used.
• Off
• On
50 51
Quick Review
This option allows quick review of the photos
immediately after they are taken. Each photo
is displayed on the LCD based on the selected
time.
• Off
• 1 sec
• 2 sec
• 3 sec
Date Imprint
Include a Date/Time stamp on the photo
image.
• Off
• Date
• Date / Time
52 5352 53
Face Detection
For detecting and focusing on faces to make all
faces as clear as possible in photo mode.
1. Hold the camera steadily and then focus on
the object to detect its face. A focus frame
will appear at the face on the screen when a
face is detected.
1/50F2.9
2. Press the shutter button half-way down
to focus. The LCD will show a green focus
frame when the subject is in focus.
1/50F2.9
3. Press the shutter button all the way down to
take pictures.
The closed eyes detection is usually on. If
the camera detects in the course of quick
review there is a face with eyes closed, a
prompt of closed eyes will appear .
52 5352 53
Movie Menu
Mode:
1. Press the button, select the mode
and press the button to enter the movie
menu.
2. Press the up/down button to select the
movie menu to be set.
3. Press the left/right button to select the
movie menu to be set and press the
button to confirm.
Expo Metering
Use this setting to select the "target" size of
the camera's field of view to be metered.
• AIAE (Artificial Intelligence AE)
Automatically selects the central
and peripheral metering, to
calculate the reasonable value of
metering by weighting.
• Spot
For metering targets a small area
in the center of the camera's field
of view.
• Center
For metering targets a slightly larger
area in the center of the cameras
field of view.
54 55
Video Quality
Set the image resolution used during video
recording.
The speed requirements for reading and
writing high image pixel images to memory
card are as follows:
No. Image Pixel Frame Recommendation Recording time
(4GB) About
11280x720 *30 Class 4 19 minutes
21280x720 15 Class 4 37 minutes
3640x480 30 Class 4 33 minutes
* The longest recording time is 29
minutes at one time.
When recording in higher pixel
resolutions for extended periods of time,
this can cause the camera to generate
heat. This is not a camera malfunction.
54 55
Color Effect
The image color setting allows you to select
different effects.
1. Press the button to select the Image
color setting menu.
2. Press the left/right button to select the
image color setting options.
• Normal
• Vivid
• Sepia
• Black and White
OIS (Optical Image Stabilization)
This mode can help reduce images blur caused
by unintentional hand shake, low light.
• OIS: Off
• OIS: On
Use this image stabilization mode in dark
environments.
Shooting in a windy or unstable
environment (such as a moving vehicle)
may cause blurred images.
56 57
Movie Setting Menu
Mode:
1. Press the button, and select to enter
the video recording screen.
2. Press the button, press the up/down
button to select , and press the
button to enter the menu.
3. Press the up/down button to select ,
and press the button or right button to
enter the menu.
4. Select the items to be set and press the
button or the right button to enter the
menu.
5. Press the up/down buttons to select an
option and press the button to confirm.
Digital Zoom
This setting is for adjusting digital zoom. If this
function is disabled, only optical zoom can be
used.
• Off
• On
56 57
Playback Menu
Mode:
1. Press the button to display the playback
screen and press the button to enter the
menu.
2. Press the up/down button to select the
playback to be set and press the button
to enter.
3. Press the left/right buttons to select an
option and press the button to confirm.
Refer to the following pages for more details
about each setting.
HDR
With the HDR function, pictures that are
overexposed may be corrected to optimize
the highlights and lowlights captured to more
accurately represent the actual scene.
: HDR
: Cancel
After using the HDR function, the image
will be saved as a new file and the
original file is still stored in the memory.
58 59
Red-Eye Reduction
You can use this setting to reduce the Red-Eye of
the picture.
: Red-Eye Reduction
: Cancel
Rotate
You can use this setting to change the
orientation of the picture.
: Turn Right
: Turn Left
: Cancel
Videos and panoramic pictures cannot
be rotated.
The rotated picture file will replace the
original photo.
58 59
Resize
This setting allows you to resize a picture to
a particular resolution and saves it as a new
picture.
: Resize to 1024x768
: Resize to 640x480
： Cancel
Only for adjusting pictures with high
resolution to those with low resolution.
Color Effect
This setting allows you to change the picture
color effect. The file is saved as a new photo
and stored in memory together with the
original photo.
: Cancel
: Vivid
: Sepia
: Black and White
60 6160 61
Mode:
1. Press the button to show the playback
screen, press the button, and press the
up/down button to select .
2. Press the button to enter the menu.
3. Press the up/down button to select ,
and press the button or right button to
enter the menu.
4. Press the up/down button to select the
item to be set and press the button or
right button to enter the menu.
5. Press the up/down buttons to select an
option and press the button to confirm.
Refer to the following pages for more details
about each setting.
Playback Setting Menu
60 6160 61
Protect
To prevent any pictures or videos from being
accidentally erased, use this setting to lock one
or all of the files.
• One: Lock the selected photo or video if
they are unprotected; unlock the
selected photo or video if they are
protected.
• All: Lock all photos or videos.
• Reset: Cancel all locked photos or videos.
Delete
You can delete one or all photo/video files.
• One: Delete one photo or video.
• All: Delete all photos or videos.
The “ ” indicator means a file is
protected. File protection must be
removed first before a file can be
deleted.
Deleting files will cause DPOF settings
to be reset.
62 6362 63
Trim
The Trim Setting allows you to crop photos and
save them as new pictures.
1. Select「Yes」to confirm trim. Select a part to
be trimmed using the zoom lever and direction
buttons to trim a photo.
2. Press the button and the「Save Change?」
prompt appears. Select「 」to change
and save the picture. Select「 」to cancel
changes and return to the trim prompt screen.
The image cannot be clipped/trimmed again
once it has been clipped to 640X480.
DPOF (Digital Print Order Format)
The DPOF feature allows you to compile and
select a group of pictures that you would like
to print and will save your selection on the
memory card so that you can use the memory
card to print without having to individually
specify the photos you want to print.
The printer that supports DPOF is
needed for printing.
62 6362 63
Setup Menu
Mode :
1. Press the button in any mode and press
the up/down button to select .
2. Press the button to enter the menu.
3. Press the up/down button to select ,
and press the button or right button to
enter the menu.
4. Press the up/down button to select the
item to be set and press the button or
right button to enter the menu.
5. Press the up/down buttons to select an
option and press the button to confirm.
Refer to the following pages for more details
about each setting.
64 65
Power Saver
This setting allows you to save power and get
the maximum possible running time for your
camera’s batteries. Turn the LCD and camera
off automatically after a consecutive period of
inactivity.
• Auto
• Normal
• Best
Sound Settings
With this setting you may adjust the sound
volume.
Press the left/right button to adjust the volume
and Press the button to confirm.
Power Saver LCD power
off time Turn off time
Auto 3 min 5 min
Normal 1 min 3 min
Best 30 s 1 min
64 65
Language
Refer to the “Reset your language” section on
page 19.
World Time
The world time setting is a useful function for
your overseas trips. This feature enables you
to display the local time on the LCD while you
are abroad.
1. Press the up/down to select the departure
place ( ) and destination ( ) fields.
2. Press the left/right button to select a city
located in the same time zone as that of
the field. Press the button to confirm
settings.
Date & Time
Refer to the “Reset Date/Time” section on
page 20.
LCD Brightness
Use this setting to adjust the brightness of your
LCD.
LCD Brightness Normal




Normal
66 6766 67
Mode :
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press the up/down button to select and
press the button or right button to enter
the menu.
Format
Copy to Card
Reset
FW Version
File Numbering
<>>>
4. Press the up/down button to select the
item to be set and press the button or
right button to enter the menu.
5. Press the up/down buttons to select an
option and press the button to confirm.
File Setting
Format
Please note: formatting enables you to delete
all contents in the memory card and built-in
memory, including protected photo and movie
files.
If you select「Yes」the camera formats its
memory.
If there is no memory card in the camera,
the built-in memory will be formatted;
if there is a memory card, it will be
formatted only.
66 6766 67
File Numbering
After you take a picture or video clip, the
camera will save it with a sequential number.
You can use this to reset the file numbering to
0001.
Copy to Card
Use this setting to copy the files stored in the
built-in memory to a memory card.
If there is no card available in the camera,
this function will not be displayed.
68 6968 69
FW Version
Use this setting to view the current camera
firmware version.
FW Version
Current Ver: X.XX
Back
When there is a new firmware version in the
memory card, select「Ye s 」to update.
FW Version
Current Ver: X.XX
New Ver: X.XX
Cancel
Yes
Update Firmware?
Reset
Use this setting to restore the camera to its
original default settings.
68 6968 69
4. Press the up/down buttons to select「PC」
and press the button to confirm.
Connecting to a Computer
You can use a Micro USB cable to connect
the camera and copy (transmit) photos to a
computer, printer or other device.
Setting the USB Mode
The camera’s USB port can be set to connect
with either a computer or a printer. The
following steps will allow you to ensure that
the camera is correctly configured to connect
with a PC.
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press the up/down button to select and
press the button or right button to enter
the menu.
3. Press the up/down button to select「USB」
and press the button or right button to
enter the menu.
Connection Settings
70 7170 71
Transferring files to your computer
The computer will automatically detect the
camera as a removable drive. Double-click the
my computer icon on the desktop to locate the
removable drive and to copy folders and files
in the drive to a directory on your PC as you
would copy any typical folder or file.
Follow the steps below to connect the camera
to a computer.
1. Make sure the computer is turned on.
2. Connect one end of the supplied Micro USB
cable to the USB port on your camera.
3. Connect the other end of the Micro USB
cable to an available USB port on your
computer.
4. After the transmission is complete,
disconnect the Micro USB cable according
to the instructions specifying how to safely
remove USB devices.
70 7170 71
Connecting to a PictBridge Compatible Printer
PictBridge technology allows printing of the
photos saved in the memory card by the
printer.
To find out if a printer is PictBridge compatible,
simply look for the PictBridge logo on the
packaging or check the owner's manual for
specifications. With the PictBridge function on
your camera, you can print the captured photos
directly to a PictBridge compatible printer
using the supplied Micro USB cable, without
the need for a PC.
Setting the USB Mode
The camera’s USB port can be set to connect
with either a PC or a Printer, the following
steps will ensure that the camera is correctly
configured to connect with a Printer.
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press up/down button to select and
press the button or right button to enter
the menu.
3. Press the up/down button to select「USB」
and press the button or right button to
enter the menu.
4. Press the up/down button to select
「Printer」and press the button to
confirm.
After the camera is reset, it will switch to
PC mode automatically from USB mode.
See “Using the PictBridge Menu“ section
on page 73.
72 7372 73
Connecting to your Printer
1. Make sure the printer is turned on.
2. Connect one end of the supplied Micro USB
cable to the USB port on your camera.
3. Connect the other end of the Micro USB
cable to the USB port on the printer.
If the camera is not connected to a PictBridge
compatible printer, the following error message
will appear on the LCD.
The error message above will also appear
if the USB mode is set incorrectly, in
which case you should disconnect the
Micro USB cable, check the USB mode
settings, ensure that the Printer is turned
on, and then try connecting the Micro
USB cable again.
72 7372 73
Using the PictBridge Menu
After setting the USB mode to Printer, the
PictBridge menu will appear.
Press the up/down button to select a menu
item and press the button or right button to
enter the item.
Refer to the following sections for more
detailed information on each setting.
Print (with Date)
If you have set the date and time on your
camera, the date and time will be recorded and
saved with each photo you take.
1. In the PictBridge menu, select「Print (with
Date)」and the screen as shown below
appears.
2. Press the left/right button to select a photo
to be printed.
74 75
3. Press the up/down button to select
the number of copies for the currently
displayed photo.
4. Press the button and the following
screen will appear.
5. Select「Yes」and press the button
to confirm printing; select「Cancel」and
press the button to cancel printing.
Print (without Date)
Use this setting to print the photos without
dates on them.
1. In the PictBridge menu, select「Print
(without Date)」and the screen as shown
below appears.
2. Press the left/right button to select a photo
to be printed.
3. Press the up/down button to select
the number of copies for the currently
displayed photo.
4. Press the button and the following
screen will appear.
74 75
5. Select「Yes」and press the button
to confirm printing; select「Cancel」and
press the button to cancel printing.
Print Index
You can print all photos in the camera via this
function.
1. In the PictBridge menu, select「Print
Index」and the screen as shown below
appears.
2. Select「Ye s 」and press the button
to confirm printing; select「Cancel」and
press the button to cancel printing.
76 7776 77
Print DPOF Images
To use DPOF printing, you must select your
photos for printing using the DPOF settings
beforehand. See “DPOF” section on page 62.
1. In the PictBridge menu, select「Print DPOF
Images」and the screen as shown below
appears.
2. Select「Yes」and press the button
to confirm printing; select「Cancel」and
press the button to cancel printing.
Exit
Select「Exit」to exit the PictBridge menu. At
this time, the message「Remove USB Cable!」
appears on the screen.
Disconnect the Micro USB cable from the
camera and printer.
76 7776 77
Video System
You can use the AV cable (which should be
purchased separately) to connect the camera
and the television for realizing the video output.
Connect one end of the AV cable to AV port of
the camera, connect the other end to AV-OUT
port of the television. Adjust the format of
the video output system according to your
requirements, and the steps are as follows:
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press the up/down button to select and
press the button or right button to enter
the menu.
3. Press the up/down button to select「TV-
System」and press the button or right
button to enter the menu.
4. Press the up/down button to
select「NTSC」or「PAL」and press the
button to confirm.
NTSC: English, Chinese (Traditional),
Japanese, French, Korean, Russian,
Vietnamese, Greek, Hungarian
PAL: German, Spanish, Italian, Chinese
(Simplified), Portuguese, Swedish,
Danish, Finnish, Indonesia,
Norwegian, Dutch, Turkish, Polish,
Thai, Croatian, Czech, Arabic, Hindi
The video output system would change
accordingly based upon the changes of
the selected language.
78 7978 79
This camera supports wireless connection for Eye-Fi memory cards. Enable the Eye-Fi connection by
following the steps below.
1. Press the button, press the up/down button to select and press the button to enter the
menu.
2. Press the up/down button to select and press the button or right button to enter the
menu.
3. Press the up/down button to select「Eye-Fi」and press the button or right button to enter
the menu.
4. Press the up/down buttons to select「On」or「Off」and press the button to confirm.
If the Eye-Fi card is not available in the camera, this feature is not displayed.
Set Eye-Fi Card Connection Mode
78 7978 79
Product Specifications
Appendices
Design and specifications are subject to change without notice.
Sensor
Type 1/2.3"CCD
Effective Pixels 16.15 Megapixels
Total Pixels 16.44 Megapixels
Lens
Focal Length 4.3mm (Wide) — 64.5mm (Tele)
35mm film equivalent 24mm (Wide) — 360mm (Tele)]
F number F3.3 (Wide) — F5.9 (Tele)
Lens Construction 9 groups 10 elements
Optical Zoom 15x
Focusing Range
Normal: (Wide) 60cm ~ ∞
(Tele) 250cm ~ ∞
Macro: 3cm ~ ∞ (Wide Only)
Autofocus System TTL Autofocus
Anti-Handshake Optical Image Stabilization
Digital Zoom 6x Digital Zoom (Combined Zoom: 90x)
80 81
Number of
Recording
Pixels
Still Image
(4:3)
16MP: 4608×3456
10MP: 3648×2736
5MP: 2592×1944
3MP: 2048×1536
0.3MP: 640×480
(3:2)
14MP: 4608×3072
(16:9)
12MP: 4608×2592
2MP: 1920×1080
Movie 1280×720 (15/30fps), 640×480 (30fps)
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1) Support Yes
File Format
Still Image Exif 2.3 (JPEG)
Movie MOV [Image: Motion JPEG; Audio: G.711 (Monaural)]
Shooting Modes Auto Mode, Manual Mode, Portrait Mode, Movie Mode, Panorama
Mode, Scene Mode
Scene Mode
Auto Scene, Landscape, Sport, Beach, Sunset, Fireworks, Night
Landscape, Snow, Children, ID, Glass, Photo Frame, Panning Shot,
Fish Eye, Party, Indoor, Leaf, Museum, Night Portrait, Sketch
Detection Features Face, Smile, Blink
Red-Eye Removal Yes
HDR Yes (Post-Processing)
80 81
Panorama Up to 180° (Horizontal）
LCD Display 3.0inch (230k Pixels)
Image Auto Rotation Yes
ISO Sensitivity Auto, ISO80/100/200/400/800/1600
AF Method Single AF, Multi-AF (TTL 9-point), Face-Detection
Exposure Metering Method Artificial Intelligence AE (AiAE), Center-Weighted Average,
Spot (Fixed to Center of Frame), Face AE
Exposure Control Method Program AE (AE-Lock Available)
Exposure Compensation ±2EV in 1/3 Step Increments
Shutter Speed 1/2000 ~ 4 Seconds (Manual: 30 Seconds)
Continuous Shooting Yes
Playback Modes
Single Photo, Index (9/16 Thumbnails), Slide Show
Zoom (Approx. x2~x8)
White Balance Control AWB, Daylight, Cloudy, Fluorescent, Fluorescent CWF,
Incandescent, Manual WB
82 8382 83
Flash
Flash Method Pop-up (Manual)
Flash Modes Force Off, Flash Auto, Fill Flash, Slow Sync., Slow Sync. +
Red-Eye, Red-Eye Reduction
Recording Media
Internal Memory: Approx. 8MB
SD/SDHC Card (Up to 32GB Support) (MMC Card Not
support )
Multi-Language Support 27 Languages
Jacks AV-OUT/USB 2.0 (Micro 5 pin USB)
Eye-Fi Support Yes
Power Rechargeable Li-ion Battery LB-052, 3.7V 880mAh,
In-Camera Charging
Shooting Capability (Battery
Performance) Approx. 210 Shots (Based on CIPA Standards)
Operation Environment Temperature: 0 ~ 40oC, Humidity: 0 ~ 90%
Dimensions (W×H×D) Approx. 108.4×69.9×32.8mm (Based on CIPA Standards)
Weight Approx. 185g (Body Only)
82 8382 83
Prompts and Warning Messages
Message Description Action
Warning! Battery
exhausted.
The camera battery is used up. It is a warning
indicating that the camera is going to shut
down.
Charge the battery.
Lens obstruction,
Re-start Camera.
The lens is jammed or some foreign object is
preventing the lens from functioning properly.
Turn off the camera and
restart it to reset the lens.
Suggest using
tripod.
The message will appear when shooting in
low light/illuminated scenes.
Use of a tripod or other
support is suggested.
Battery temperature
is too high. The battery temperature reaches 58°C.
Let the battery cool
before attempting to use
the camera again. The
message will disappear
after 2 seconds.
Built-in memory
error! An error occurs in internal memory. Format the internal
memory.
Slow shutter is on:
may easily cause
overexposure.
When the B shutter is on, the prompt appears
on the screen after you go back to the photo
shooting screen.
The message will
disappear after 2
seconds.
84 85
Message Description Action
Improper
alignment.
Please try again.
The offset is too big for panorama shooting. The message will
disappear after 2 seconds.
Connection Failed! In the case of failing to connect to a PC or a
printer.
Remove transmission line
to stop connection, and the
message is removed.
Warning! Do
not turn off your
camera during
update!
The message appears during the firmware
update process.
The message disappears
after the camera update
and restart.
Remove USB
Cable！
Indicates that you can disconnect the Micro
USB cable.
The message disappears
after you disconnect the
Micro USB cable.
Write Protect ! The memory card is locked.
Unlock the write-protect
switch of the memory
card.
Card Full ! Indicates that the memory card is full.
Insert a new memory
card or delete unwanted
images.
84 85
Message Description Action
Memory Full ! Indicates that the internal memory
is full.
Insert a new memory card or delete
unwanted images.
Card Error ! The memory card cannot be
recognized after being formatted.
Insert a new memory card or format
the card with this camera.
Card is not
formatted.
The inserted memory card is
unformatted or has been formatted
on a computer or other device and
is not compatible with this camera.
Disappear after 2 seconds and enter
the formatting process.
Slow access
When a memory card lower than
Class 4 is used to record a HD
movie, the writing speed will be
slower and recording will not
continue.
Use an memory card with Class 4 or
higher.
No Red-Eye
Detected!
Red eyes have not been detected in
the image.
The message will disappear after 2
seconds.
86 8786 87
Message Description Action
This image cannot be
edited.
The file format does not support
editing or the edited file cannot be
edited again.
The message will disappear
after 2 seconds.
Exceeded maximum
folder number.
Prompt message when the archives
or file folders in the memory card
have reached the maximum (9999 for
archives, 999 for file folder).
Copy the images to your PC
and format the memory card
with this camera.
Too many pictures for
quick processing.
During the playback by date, the
images exceed specifications so that it
is not possible to play by date.
This may be solved by deleting
unnecessary images.
Unable to recognize
files.
The format of the file to be viewed is
not supported or the file is corrupted
so it cannot be properly read.
You may be able to play it back
on another brand of camera or
on your computer.
No Picture!
When you press the playbutton, no
image files exist in the camera or
memory card.
The message disappears 2
seconds later to return to the
photo shooting screen.
Protected!
Undeletable!
The file is protected. The message
appears when you delete it.
Unprotect the file before
deleting.
86 8786 87
Troubleshooting
Problem Possible causes Solution
Camera does not turn on
The battery has been
depleted.
The battery is not inserted
correctly.
Recharge the battery.
Correctly reinstall the battery.
Camera turns off suddenly
during operation
The batteries have been
depleted.
Recharge the battery.
The picture is blurred Camera shakes while taking a
picture.
Turn on OIS feature.
Images and video files
cannot be saved
The memory card is full.
The memory card is locked.
Use another memory card or
delete unnecessary files.
Unlock the memory card.
Images will not print from
the connected printer
The camera is not connected
to the printer correctly.
The printer is not PictBridge
compatible.
The printer is out of paper or
ink.
The printer paper is jammed.
Check the connection between
the camera and printer.
Use a PictBridge compatible
printer.
Load paper into the printer or
replace the ink cartridge in the
printer.
Remove the jammed paper.
88 89
Problem Possible Causes Solution
Saving data to memory card is
slow
Using a memory card below
Class 4 may result in slower
recording times.
Use a memory
card with write
Class 4 or higher
than 4 to improve
performance.
Cannot write to the memory card The memory card has been
locked.
Release the write
lock of the memory
card or replace with
another card.
Too many movies to process The number of pictures or
folders in the memory card
exceed the specifications, so
the playback of data folder can
not be displayed.
Delete unwanted files.
The flash flashes on the LCD
screen.
Current shooting environment
requires flash.
Turn on flash.
The Kodak trademark and trade dress are used under license from Kodak.
© 2015 by JK Imaging Ltd. All Rights Reserved.
JK Imaging Ltd., 17239 South Main Street, Gardena, CA 90248, USA
JK Imaging Europe, 71 Clarendon road, Watford, WD17 1DS, UK
www.kodakpixpro.com
Ver. 2

Navigation menu
