Amazon Fire TV Cube (2nd Generation) Quick Start Guide

What's in the box:

• Amazon Fire TV Cube (2nd generation)
• Alexa Voice Remote (3rd generation)
• Power adaptor
• Ethernet adaptor
• IR extender cable (for controlling components inside a closed cabinet)
• 2 AAA batteries

1. Position your Fire TV Cube

Place Fire TV Cube 30-60 cm away from any speakers, including your TV speakers, with the logo facing where you usually sit.

This device acts like a remote control. It needs to hear you and should be unobstructed, not in a closed cabinet.

(Optional) To control entertainment components that are inside a closed cabinet, use the included IR extender cable.

2. Connect your Fire TV Cube

1. Connect one end of the HDMI cable (not included) into the HDMI port on Fire TV Cube. Connect the other end into the HDMI port on your TV. Remember which HDMI port on your TV, or AVR, was used for the device. You'll need that information later during setup.
2. (Optional) To use an Ethernet cable (not included), connect the Amazon Ethernet Adaptor as shown.
3. Plug the included power cable into Fire TV Cube and then into an electrical socket.
4. Turn on your TV, then select the appropriate input.
5. Set your TV volume to your typical listening level.
6. (Optional) To use the IR extender cable, plug it into the IR port on the back of your Fire TV Cube as shown.

Diagram Description: Shows connections for HDMI, Ethernet adaptor (optional), and IR extender cable (optional) to the Fire TV Cube.

3. Power up your Alexa Voice Remote

1. Open the back of the remote and insert the included batteries.
2. After pairing your Alexa Voice Remote, follow the on-screen instructions to control the power and volume of your TV.

If your remote is not discovered, press and hold the Home button until the LED starts to rapidly flash amber.

Diagram Description: Illustrates inserting batteries into the Alexa Voice Remote and shows the remote's buttons including Power, Alexa Voice, Navigation, Select, Home, Back, Menu, Rewind, Fast Forward, Mute, Play/Pause, Guide, Volume, and App buttons.

Get to know Fire TV Cube

Diagram Description: A diagram of the Fire TV Cube highlighting the following ports and features:

• Microphone
• Off/On button
• Light bar
• Volume down button
• Action button
• Volume up button
• Microphones
• Power port
• HDMI port
• IR port (not for audio)
• Micro-USB port (not for power)

Key Features:

• Light bar: The colour indicates what Fire TV Cube is doing.
• Volume buttons: Control the internal speaker of Fire TV Cube.
• Action button: Multi-function button used to wake Alexa.
• IR port: Supports included IR extender. This is not an audio jack.
• Micro-USB port: Used for external storage or for the Amazon Ethernet adaptor.

Get the most out of your Fire TV Cube

Download the Amazon Alexa app

Download the Alexa app from an app store to manage your lists, news, skills and more.

Talking to Alexa

To learn what phrases you can use with Fire TV Cube, say "Alexa, what can I say?" or go to Things to Try in the Alexa app.

Control your TV and sound devices

Follow the on-screen instructions, or go to Settings on your Fire TV Cube to set up new entertainment devices.

• Alexa, volume up.
• Alexa, turn on the TV.
• Alexa, switch to satellite TV.
• Alexa, change to ITV Hub+.

TV programmes, films, podcasts, music and radio

• Alexa, play 'Jack Ryan'.
• Alexa, play Tuneln.

News, weather and more

Customise these features in the Alexa app.

• Alexa, what's my Flash Briefing?
• Alexa, what's the weather?

Tips and troubleshooting

Wi-Fi network

Using the included remote control, go to the Settings menu in Fire TV Cube, and select your network from the list displayed.

If your network is hidden, enter your network name.

If you see a lock icon ?, your Wi-Fi network requires a password, so make sure you have it available. This password is not your Amazon account password.

For best performance, use the 5 GHz band on your wireless router if available. Do not place your router in a closed cabinet as it may impact Wi-Fi signal strength.

Wired network

If you're having trouble with your Ethernet connection, verify that the Ethernet cable and adaptor are properly connected, then restart your Fire TV Cube. To understand how to set up Ethernet, go to the Connect Your Fire TV Cube section.

For more troubleshooting and information, go to www.amazon.com/devicesupport.
