Use & Care Manual Clothes Dryer
Manuel d'utilisation et d'entretien Sécheuse á Chargement Frontal
Manual de uso y cuidado Secadora de ropa

EN 2 FR 48 SP 98

electroluxappliances.com\register

IMPORTANT SAFETY INFORMATION

Please read and save this manual
Thank you for choosing Electrolux, our premium brand in home appliances. This Use & Care Manual is part of our commitment to customer satisfaction and product quality throughout the service life of your new appliance.
We view your purchase as the beginning of a relationship. To ensure our ability to continue serving you, please use this page to record important product information.
Keep a record for quick reference

Table of Contents
Important Safety Information........................... 2 Features ..................................................................... 8 Pre-Installation Requirements.......................... 9 Installation ...............................................................17 Controls and Settings ........................................26 Operating Instructions ..................................... 36 Normal Operating Sounds ............................. 38 Care and Cleaning .............................................39 Troubleshooting ................................................... 41

Purchase date

Limited Warranty................................................. 44

Electrolux model number

Electrolux serial number
Electrolux model series*
* The series number can be found within the Model number (example ELFE7637AW = 600 series)

Questions?
For toll free telephone support or online support in the US and Canada contact:
U.S. 1-877-4ELECTROLUX (1-877-435-3287) www.electroluxappliances.com
Canada 1-800-265-8352 www.electroluxappliances.ca

NOTE
Registering your product with Electrolux enhances our ability to serve you. You can register online at www.electroluxappliances.com, by sending your Product Registration Card in the mail, or PHOTOREGISTERSM using a smart phone. See registration card for details.

NOTE
The instructions appearing in this Use & Care Manual are not meant to cover every possible condition and situation that may occur. Common sense and caution must be practiced when installing, operating and maintaining any appliance.

READ ALL INSTRUCTIONS BEFORE OPERATING THIS DRYER. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

IMPORTANT SAFETY INFORMATION

Important safety instructions - gas dryer

WARNING
FIRE or explosion hazard Failure to follow safety warning exactly could result in serious injury, death, or property damage. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. WHAT TO DO IF YOU SMELL GAS: · DO NOT try to light any appliance. · DO NOT touch any electrical switch; DO NOT use
any phone in your building. · Clear the room, building or area of all
occupants. · Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's instructions. · If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency or the gas supplier.

IMPORTANT SAFETY INFORMATION

WARNING
RISK OF FIRE
· Ensure the entire dryer exhaust system is clean and free of lint and debris prior to the installation of your new dryer. The entire exhaust system should be inspected and cleaned a minimum of every 18 months with normal usage. Failure to comply with cleaning your exhaust system will increase the RISK of FIRE.
· DO NOT install a clothes dryer with flexible plastic or flexible foil venting material. Flexible venting materials are known to collapse, be easily crushed and trap lint. These conditions will obstruct clothes dryer airflow and increase the risk of fire.
· DO NOT screen the exhaust ends of the vent system, or use any screws, rivets or other fasteners that extend into the duct to assemble the exhaust system. NO screen or grate of any mesh size is allowed to cover the outdoor exhaust opening.
· Install the clothes dryer according to the manufacturer's instructions and local codes.
· Clothes dryer installation and service must be performed by a qualified installer, service agency or the gas supplier.
· The electrical service to the dryer must conform with local codes and ordinances and the latest edition of the National Electrical Code, ANSI/NFPA 70, or in Canada, the Canadian Electrical Code CSA C22.1 part 1.
· The gas service to the dryer must conform with local codes and ordinances and the latest edition of the National Fuel Gas Code ANSI Z223.1/NFPA 54, or in Canada, the Natural Gas and Propane Installation Code, CSA B149.1. An individual manual shutoff valve must be installed within 6 ft. (1.83 m) of the dryer in accordance with the National Fuel Gas Code, ANSI Z223.1/NFPA 54.
· DO NOT stack a dryer on top of washer already installed on pedestal. DO NOT stack washer on top of dryer. DO NOT stack washer on top of another washer.
· The dryer is designed under ANSI Z21.5.1/CSA 7.1 or UL 2158 - CAN/CSA C22.2 No. 112 (latest editions) for HOME USE only. This dryer is not recommended for commercial applications such as restaurants, beauty salons, etc.
· Destroy the carton and plastic bags after the dryer is unpacked. Children might use them to play. Cartons covered with rugs, bedspreads, or plastic sheets can become airtight chambers causing suffocation. Place all materials in a garbage container or make materials inaccessible to children.
· To reduce the risk of severe injury or death, follow all installation instructions in this manual.
The instructions in this manual and all other literature included with this dryer are not meant to cover every possible condition and situation that may occur. Good safe practice and caution MUST be applied when installing, operating and maintaining any appliance.

WARNING
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or loss of life. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

IMPORTANT SAFETY INFORMATION

Definitions
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

· DO NOT place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire. To reduce the risk of fire due to contaminated loads, the final part of a tumble dryer cycle occurs without heat (cool down period). Avoid stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
· DO NOT dry articles containing rubber, plastic or similar materials such as bras, galoshes, bath mats, rugs, bibs, baby pants, plastic bags and pillows that may melt or burn. Some rubber materials, when heated, can under certain circumstances produce fire by spontaneous combustion.
· DO NOT operate the dryer if the lint screen is blocked, damaged or missing. Fire hazard, overheating and damage to fabrics can occur.
· DO NOT obstruct the flow of ventilating air. DO NOT stack or place laundry or throw rugs against the front or back of the dryer.

IMPORTANT
IMPORTANT indicates installation, operation or maintenance information which is important but not hazard-related.
WARNING
FIRE HAZARD To reduce the risk of fire, electrical shock, or injury to persons when using this dryer, comply with the basic warnings listed below. Failure to comply with the Important Safety Instruction warnings could result in property damage, serious personal injury, or death.
Prevent fire
· DO NOT dry items that have been previously cleaned in, soaked in, or spotted with gasoline, cleaning solvents, kerosene, waxes, or other flammable or explosive substances. DO NOT store these items on or near the dryer. These substances give off vapors that could ignite or explode.

WARNING
FIRE HAZARD Clean the lint screen before or after each load. The interior of the dryer, lint screen housing and exhaust duct should be cleaned approximately every 18 months by qualified service professional. An excessive amount of lint build-up in these areas could result in inefficient drying and possible fire. See Care and Cleaning.
WARNING
FIRE HAZARD A clothes dryer produces combustible lint. The dryer must be connected to an outdoor exhaust. Regularly inspect the outdoor exhaust opening and remove any accumulation of lint around the opening and in the surrounding area.
· DO NOT spray any type of aerosol into, on or near dryer at any time.

IMPORTANT SAFETY INFORMATION

· DO NOT use fabric softeners or products to eliminate static unless recommended by the manufacturer of the fabric softener or product.

Before you throw away your old washer or dryer:
· Remove doors

WARNING
DO NOT continue to use the dryer if you hear squeaking, grinding, rubbing or other unusual noises. This could be a sign of mechanical breakdown and lead to fire or serious injury. Contact a qualified technician immediately.
· Failure to comply with these warnings could result in fire, explosion, serious bodily injury and/or damage to the dryer.
Protect children
· DO NOT allow children to play on or in the dryer. Close supervision of children is necessary when the dryer is used near children. As children grow, teach them the proper, safe use of all appliances.
· Destroy the carton, plastic bag and other packing materials after the dryer is unpacked. Children might use them for play. Cartons covered with rugs, bedspreads or plastic sheets can become airtight chambers.
· Keep laundry products out of children's reach. To prevent personal injury, observe all warnings on product labels.
· Before the dryer is removed from service or discarded, remove the dryer door to prevent accidental entrapment.
· Failure to comply with these warnings could result in serious personal injuries.

· Remove the electric power cord
· Secure all hoses and drain pipes to prevent water from leaking out and creating a slip hazard.
Prevent injury
· To prevent shock hazard and assure stability during operation, the dryer must be installed and electrically grounded by a qualified service person in accordance with local codes. Installation instructions are included in this manual for reference. Refer to the installation sections for detailed grounding procedures. If the dryer is moved to a new location, have it checked and reinstalled by a qualified service professional.
· To prevent personal injury or damage to the dryer, the electrical power cord of a gas dryer must be plugged into a properly grounded and polarized 3-prong outlet. The third grounding prong must never be removed. Never ground the dryer to a gas pipe. DO NOT use an extension cord or an adaptor plug.
· ALWAYS disconnect the dryer from the electrical supply before attempting any service or cleaning. Failure to do so can result in electrical shock or injury.
· DO NOT use any type of spray cleanser when cleaning dryer interior. Hazardous fumes or electrical shock could occur.
· To prevent injury, DO NOT reach into the dryer if the drum is moving. Wait until the dryer has stopped completely before reaching into the drum.

Risk of child entrapment
Child entrapment and suffocation are not problems of the past. Junked or abandoned washers and dryers are still dangerous even if they will sit for "just a few days". If you are getting rid of your old washer or dryer, please follow the instructions below to help prevent accidents.
We strongly encourage responsible appliance recycling/disposal methods. Contact your State/Provence Energy Office, Local Electric and Water Utilities or Conservation Program Office or visit www. energystar.gov/recycle for more information on recycling your old washer or dryer.

Prevent injury and damage to the dryer
· All repairs and servicing must be performed by an authorized service provider unless specifically recommended in this Use & Care Manual. Use only authorized factory parts.
· DO NOT tamper with controls.
· DO NOT sit on, step on or stand on the dryer. DO NOT rest heavy loads on top. The dryer is not meant to support weight.
· DO NOT install or store the dryer where it will be exposed to water and/or to the weather.

IMPORTANT SAFETY INFORMATION
· Thermal limiter switches automatically turn off the motor in the unlikely event of an overheated situation. A service technician must replace the thermal limiter switch(es) after correcting the fault.
· Failure to comply with these warnings could result in serious personal injuries.

WARNING
FIRE/ELECTRICAL SHOCK HAZARD Avoid fire hazard or electrical shock. DO NOT use an adaptor plug or extension cord or remove grounding prong from electrical power cord. Failure to follow this warning can cause serious injury, fire, or death.

10-30R 3-wire
(fused 30 amp)
14-30R 4-wire
(fused 30 amp)

208V/240 v Electric Dryer
UL-approved service cord must be installed on electric dryers (not provided with unit except those manufactured for sale in Canada).

Grounding type wall receptacle

120 v Gas Dryer
Do not, under any circumstances, cut, remove, or bypass the grounding prong.

Power cord with 3-prong grounded plug

FEATURES

9 8
1
2

Not all cycles, options, or features listed are available on every model.

1. Door Latch

7. Serial Number and Model Number

2. Front-Mounted Moisture Sensor (on select models)

8. 3 Drum Vanes

3. Drum Light (on select models)

9. Wide-Angle Door Hinge

4. Cycle Selector

10. Reversible Door

5. LED Display

11. Door Striker

6. Control Lock

12. LuxCareTM Lint Shield

Refer to the table below for an overview of features available for each model series.

Anti Static Perfect Steam Wrinkle Release Extended Tumble Drum Light Delay Time Control Lock Sanitize Eco Dry Fast Dry

300 Series 400 Series 500 Series 600 Series

no no yes yes no yes yes no yes 20 min no yes yes yes yes yes yes yes yes 18 min yes yes yes yes yes yes yes yes yes 15 min yes yes yes yes yes yes yes yes yes 15 min

PRE-INSTALLATION REQUIREMENTS

Installation Checklist

Exhaust Venting
Free-flowing, clear of lint buildup 4 inch (102 mm) rigid metal or
semi-rigid metal transition ducting of minimal length and turns NO foil or plastic venting material Approved vent hood exhausted to outdoors
Leveling
Dryer is level, side-to-side and frontto-back
Cabinet is sitting solid on all corners
Gas Supply (Gas Dryer)
Manual shutoff valve present in supply All connections sealed with approved
sealer and wrench tight Conversion kit for LP GAS system
# PCK4200 (not included) and must be purchased separately Gas supply turned on No leaks present at all connections check with soapy water, NEVER check with flame
Water Hookup (Select Models)
Inspect hoses for proper placement of rubber washers
Water supply is turned on

Check for leaks Steam model dryers require use of
ASSEMBLY HOSE Kit #5304495002 (not included) and must be purchased separately.
240v Electric Supply (Electric Dryer)
Approved NEMA 10-30 or 14-30 service cord with all screws tight on terminal block
Approved strain relief installed Terminal access cover installed before
initial operation
Door Reversal
Follow detailed instructions in this manual
Test hinge and latch for function
Electrical Power
House power turned on Dryer plugged in
Final Checks
Installation Instructions and Use & Care Manual read thoroughly
Door latches and drum tumbles when cycle starts
Registration card sent in

10 PRE-INSTALLATION REQUIREMENTS

Tools and materials needed for installation:

Adjustable pliers

Phillips, straight, & square bit screwdrivers

Adjustable wrench

or or

Pipe wrench LP-resistant for gas thread tape supply (for natural gas or LP supply)

Carpenter's External level vent hood

4 inch, rigid metal or

3-wire or 4-wire

semi-rigid metal exhaust duct work 240 volt cord kit

(electric dryer)

4 in. (10.2 cm)
clamp

Gas line shutoff valve (gas dryer)

½" NPT union flare adapters (x2) and flexible

gas supply line

(gas dryer)

Metal foil tape (not duct tape)

ASSEMBLY HOSE KIT - P/N 5304495002, for steam models only, is not included and must be purchased separately.

WARNING
FIRE HAZARD · Failure to follow safety warnings exactly
could result in serious injury, death, or property damage.
· DO NOT install a booster fan in dryer exhaust duct.
· Install all clothes dryers in accordance with the installation instructions in this manual.

Electrical system requirements
NOTE
Because of potentially inconsistent voltage capabilities, the use of this dryer with power created by gas powered generators, solar powered generators, wind powered generators or any other generator other than the local utility company is not recommended.
Electrical requirements for electric dryer:
CIRCUIT - Individual 30 amp. branch circuit fused with 30 amp. time delay fuses or circuit breakers. Use separately fused circuits for washer and dryer. DO NOT operate washer and dryer on same circuit.
POWER SUPPLY - 3-wire or 4-wire, 120/240 volt, single phase, 60 Hz, Alternating Current.
NOTE
A 120/208 volt, single phase, 60 Hz, Alternating Current supply may be used on dryers marked for use on rating plate.
NOTE
The electric dryer has been designed and certified to operate at both 240V and 208V. Drying times on a 208V power supply will, however, be approximately 20% longer than drying times on a 240V power supply. This is normal and expected behavior and applies to all drying cycles.
IMPORTANT
Dryer is internally grounded to neutral unless it was manufactured for sale in Canada.
Only a 4-conductor cord shall be used when the appliance is installed in a location where grounding through the neutral conductor is prohibited. Grounding through the neutral link is prohibited for: (1) new branch circuit installations, (2) mobile homes, (3) recreational vehicles, and (4) areas where local codes DO NOT permit grounding through the neutral.

11 PRE-INSTALLATION REQUIREMENTS

3-wire power supply cord (not supplied)

Electrical requirements for gas dryer:

3-wire receptacle (NEMA type 10-30R)
The dryer MUST employ a 3-conductor power supply cord NEMA 10-30 type SRDT rated at 240 volt AC minimum, 30 amp, with 3 open end spade lug connectors with upturned ends or closed loop connectors and marked for use with clothes dryers. For 3-wire cord connection instructions see "Electrical connection (non-Canada) - 3-wire cord" in Electrical Installation section.

CIRCUIT - Individual, properly polarized and grounded 15 amp. branch circuit fused with 15 amp. time delay fuse or circuit breaker.
POWER SUPPLY - 2-wire, with ground, 120 volt, single phase, 60 Hz, Alternating Current.
POWER SUPPLY CORD - Dryer is equipped with 120 volt 3-wire power cord.
GROUNDING CONNECTION - See "Grounding requirements" in Electrical Installation section.

OUTLET RECEPTACLE - NEMA 10-30R receptacle to be located so the power supply cord is accessible when the dryer is in the installed position.
GROUNDING CONNECTION - See "Grounding requirements" in Electrical Installation section.
4-wire power supply cord (not supplied)
4-wire receptacle (NEMA type 14-30R)
The dryer MUST employ a 4-conductor power supply cord NEMA 14-30 type SRDT or DRT (as required) rated at 240 volt AC minimum, 30 amp, with 4 open end spade lug connectors with upturned ends or closed loop connectors and marked for use with clothes dryers. For 4-wire cord connection instructions see "Electrical connection (non-Canada) - 4-wire cord" in Electrical Installation section.

WARNING
Improper grounding of the dryer may cause serious injury or death. Check with a licensed electrician if you are in doubt as to whether the appliance is properly grounded.
Grounding type wall receptacle
Do not, under any circumstances, cut, remove, or bypass the grounding prong.
Power cord with 3-prong grounded plug

NOTE

Gas supply requirements

Dryers manufactured for sale in Canada have factory-installed, 4-wire power supply cord (NEMA 14-30).
OUTLET RECEPTACLE - NEMA 14-30R receptacle to be located so the power supply cord is accessible when the dryer is in the installed position.
GROUNDING CONNECTION - See "Grounding requirements" in Electrical Installation section.

WARNING
EXPLOSION HAZARD Uncoated copper tubing will corrode when subjected to natural gas, causing gas leaks. Use ONLY black iron, stainless steel, or plastic-coated brass piping for gas supply.
1. The gas service to the dryer must conform with local codes and ordinances and the latest edition of the National Fuel Gas Code ANSI Z223.1/

12 PRE-INSTALLATION REQUIREMENTS

1. NFPA 54, or in Canada, the Natural Gas and Propane Installation Code, CSA B149.1.
2. The gas supply line should be 1/2 inch (1.27 cm) pipe.
3. If codes allow, flexible metal tubing may be used to connect your dryer to the gas supply line. The tubing MUST be constructed of stainless steel or plastic-coated brass.
4. The gas supply line MUST have an individual shutoff valve installed in accordance with the B149.1, Natural Gas and Propane Installation Code.
5. A 1/8 inch (0.32 cm) N.P.T. plugged tapping, accessible for test gauge connection, MUST be installed immediately upstream of the gas supply connection to the dryer.
6. The dryer MUST be disconnected from the gas supply piping system during any pressure testing of the gas supply piping system at test pressures in excess of 1/2 psig (3.45 kPa).
7. The dryer MUST be isolated from the gas supply piping system during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.45 kPa).
8. Connections for the gas supply must comply with the Standard for Connectors for Gas Appliances, ANSI Z21.24/CSA 6.10.
Exhaust system requirements

The following are specific requirements for proper and safe operation of your dryer.
WARNING
FIRE HAZARD · Failure to follow safety warnings exactly
could result in serious injury, death, or property damage. · DO NOT install a booster fan in dryer exhaust duct. · Install all clothes dryers in accordance with the installation instructions in this manual.

Correct

Incorrect

Correct

Incorrect

Use only 4 inch (102 mm) diameter (minimum) rigid or semi rigid metal duct and approved vent hood which has a swing-out damper or dampers that open when the dryer is in operation. When the dryer stops, the damper or dampers automatically close to prevent drafts and the entrance of insects and rodents. To avoid restricting the outlet, maintain a minimum of 12 inches (30.5 cm) clearance between the vent hood and the ground or any other obstruction.

WARNING
FIRE HAZARD Failure to follow these instructions can create excessive drying times and fire hazards.

13 PRE-INSTALLATION REQUIREMENTS

WARNING

FIRE HAZARD
· A clothes dryer must be exhausted outdoors.
· DO NOT exhaust dryer into a chimney, a wall, a ceiling, an attic, a crawl space or any concealed space of a building.
· A clothes dryer produces combustible lint. If the dryer is not exhausted outdoors, some fine lint will be expelled into the laundry area. An accumulation of lint in any area of the home can create a health and fire hazard.
· The dryer must be connected to an exhaust outdoors.
· Regularly inspect the outdoor exhaust opening and remove any accumulation of lint around the outdoor exhaust opening and in the surrounding area.
WARNING
FIRE HAZARD · DO NOT allow combustible materials
(for example: clothing, draperies/ curtains, paper) to come in contact with exhaust system. The dryer MUST NOT be exhausted into a chimney, a wall, a ceiling, or any concealed space of a building which can accumulate lint, resulting in a fire hazard.
· DO NOT screen the exhaust ends of the vent system, or use any screws, rivets or other fasteners that extend into the duct to assemble the exhaust system. No screen, grate, or guard of any mesh size is allowed to cover the exhaust opening. Lint can become caught in the screen, grate, guard, or on the screws or rivets, clogging the duct work and creating a fire hazard as well as increasing drying times. Use an approved vent hood to terminate the duct outdoors, and seal all joints with metal foil tape. All male duct pipe fittings MUST be installed downstream with the flow of air.

FIRE HAZARD Never exceed more than 4-90° elbows in the exhaust duct system. Exceeding the length of duct pipe or number of elbows allowed in the "MAXIMUM LENGTH" charts can cause an accumulation of lint in the exhaust system. Plugging the system could create a fire hazard, as well as increase drying times.
MAXIMUM LENGTH of 4" (102 mm) Rigid Metal Duct
VENT HOOD TYPE
(Preferred)

Max. Number of 90° turns

4" (10.2 cm) louvered 2.5" (6.35 cm)

0 125 ft. (38 m)

110 ft. (33.5 m)

1 115 ft. (35 m)

100 ft. (30.5 m)

2 105 ft. (32 m)

90 ft. (27.5 m)

3 95 ft. (29 m)

80 ft. (24.5 m)

4 85 ft. (26 m)

70 ft. (21.5 m)

WARNING
FIRE HAZARD · DO NOT install flexible plastic or flexible
foil venting material. · DO NOT exceed 8 ft. (2.4 m) duct length
if installing semi-rigid venting. · DO NOT use screws, rivets or other
fasteners that extend into the duct to assemble the exhaust system.
Exhaust direction
Directional exhausting can be accomplished by installing a quick-turn 90° dryer vent elbow directly to exhaust outlet of dryer. Dryer vent elbows are available through your local parts distributor or hardware store.

See also CLEARANCE REQUIREMENTS.

14 PRE-INSTALLATION REQUIREMENTS

NOTE
Use of 90° quickturn elbow required to meet minimum installation depth.

· Running the exhaust system through an uninsulated area may cause condensation and faster accumulation of lint.
· Compression or crimping of the exhaust system will cause an increase in vent restriction.

WARNING
FIRE HAZARD DO NOT install the dryer where gasoline or other flammables are kept or stored. If the dryer is installed in a garage, it must be a minimum of 18 inches (45.7 cm) above the floor. Failure to do so can result in death, explosion, fire or burns.

· The exhaust system should be inspected and cleaned a minimum of every 18 months with normal usage. The more the dryer is used, the more often you should check the exhaust system and vent hood for proper operation and that it is free of obstructions.
Manufactured or mobile home installation

In installations where the exhaust system is not described in the charts, the following method must be used to determine if the exhaust system is acceptable:
1. Connect an inclined or digital manometer between the dryer and the point the exhaust connects to the dryer.
2. Set the dryer timer and temperature to air fluff (cool down) and start the dryer.
3. Read the measurement on the manometer.
4. The system back pressure MUST NOT be higher than 1.0 inch of water column. If the system back pressure is less than 1.0 inch of water column, the system is acceptable. If the manometer reading is higher than 1.0 inch of water column, the system is too restrictive and the installation is unacceptable.
Install male fittings in correct direction:

1. Installation MUST conform to current Manufactured Home Construction & Safety Standard, Title 24 CFR, Part 3280 (formerly the Federal Standard for Mobile Home Construction and Safety for Mobile Homes, Title 24, HUD Part 280) or Standard CAN/CSAZ240 MH.
2. Dryer MUST be exhausted outside (outdoors, not beneath the mobile home) using metal ducting that will not support combustion. Metal ducting must be 4 inches (10.16 cm) in diameter with no obstructions. Rigid metal duct is preferred.
3. If dryer is exhausted through the floor and area beneath the mobile home is enclosed, the exhaust system MUST terminate outside the enclosure with the termination securely fastened to a non-combustible portion of the mobile home structure.
4. Refer to previous sections in this manual for other important exhaust venting system requirements.

Correct

Incorrect

Although vertical orientation of the exhaust system is acceptable, certain extenuating circumstances could affect the performance of the dryer:

· Only the rigid metal duct work should be used.

5. When installing a gas dryer into a mobile home, a provision must be made for outside make up air. This provision is to be not less than twice the area of the dryer exhaust outlet.
6. Installer MUST anchor this (1) dryer or (2) dryer mounted on pedestal to the floor with approved Mobile Home Installation Kit - P/N 137067200.

· Venting vertically through a roof may expose the exhaust system to down drafts causing an increase in vent restriction.

15 PRE-INSTALLATION REQUIREMENTS

Clearance requirements
IMPORTANT
DO NOT INSTALL YOUR DRYER: 1. In an area exposed to dripping water
or outside weather conditions. 2. In an area where it will come in
contact with curtains, drapes, or anything that will obstruct the flow of combustion and ventilation air. 3. On carpet. Floor MUST be solid with a maximum slope of 1 inch (2.5 cm).

NOTE
To achieve an installation with 0" (0 cm) clearance for the back of the dryer (for other than straight back venting), a quick-turn 90° dryer vent elbow must be installed as described previously in this manual.
For other than straight back venting, a quickturn 90° dryer vent elbow must be installed to achieve 0" (0 cm) installation.

Installation in a recess or closet
1. A dryer installed in a recess or closet, MUST be exhausted outdoors.
2. No other fuel burning appliance shall be installed in the same recess or closet as a gas dryer.
3. Your dryer needs space around it for proper ventilation. See "Clearance Requirements" chart.
4. A minimum of 120 square inches of inlet ventilation opening to the recess or closet is required for proper air flow to the dryer.
5. Inlet air ventilation to the recess or closet can be satisfied by adding 120 square inches of opening, equally divided at the top and bottom of the door and located 3 inches from the bottom and top of the door.
or, adding 120 square inches of ventilation openings to the top, sides or rear wall of the closet wall, if the wall is adjacent to an open room, hallway, or exterior.
or, a louvered door with equivalent air openings equaling 120 sq. inches of ventilation for the full length of the door is acceptable.
It is NOT approved to derive the 120 sq. inches of ventilation from the space between the door edges and the casing or the floor. ** The presence of forced heating and air-conditioning vent openings in the closet does NOT satisfy the 120 square inch ventilation requirement to the closet.

60 sq. Inches
120 sq. Inches Equally Divided Split Vent Door
120 sq. Inches
Solid Door with Wall Ventilation

16 PRE-INSTALLATION REQUIREMENTS
120 sq. Inches min. Louvered Opening

Louvered Door

MIN INSTALLATION CLEARANCES Inches (cm)

Sides Rear Top Front

Alcove/ recess

0" (0 cm)

Open

Closet with door vent

0" (0 cm)

(0 cm) (2.5 cm)

Closet with wall vent

1" (2.5 cm)

Bi-Fold louvered doors with 120 sq. in of ventilation 120 sq. Inches of wall venting
Solid Bi-Fold doors with no ventilation

17 PRE-INSTALLATION REQUIREMENTS
Dryer dimensions

53.1" (136 cm)* to clear open door
32" (81.25 cm)* to front of closed door

freestand dryer on floor floor line
dryer mounted on optional pedestal
floor line

38.0" (96.5 cm)

53.25" (135.5 cm)

1.5" (4 cm)
gas supply pipe on rear of gas unit

17.0" (43 cm)
3.75" (9.5 cm)

27.0" (68.5 cm)

electrical supply on rear of unit1

3.7" (9.5
centerline height of rear vent

13.5" (34.5 cm) to center of rear vent

19.0" (48 cm)

53.1" (136 cm)* to clear open door
32.0" (81.25 cm)* to front of closed door

approved stacking kit (STACKIT7X) required for stacked installation

75.75" (192.5 cm)
water supply connection on rear of unit
gas supply pipe on rear of gas unit

electrical supply on rear of unit1
centerline height for rear vent

floor line

39.0" (99 cm)

drain hose on rear of unit2

power cord on rear of unit3
41.0" (105 cm)

* Connection of water inlet hose on steam dryer adds 3/4 in. (2 cm) to installation depth. 1 Power supply cord length on gas dryer or electric Canadian dryer approximately 60
inches (152.5 cm). 2 Drain hose length on washer approximately 59 inches (150 cm). 3 Power supply cord length on washer approximately 60 inches (152.5 cm).

18 INSTALLATION

Connecting the electrical system

The dryer, when installed, must be electrically grounded in accordance with local codes and the National Electrical code

The following are specific requirements for proper and safe electrical installation of

ANSI/NFPA 70 or the Canadian Electrical Code, Part 1, CSA C22.1.

your dryer. Failure to follow these instructions can create electrical shock and/or a fire

Grounding requirements - electric

hazard.

dryer (USA)

WARNING
ELECTRICAL SHOCK HAZARD
· This appliance MUST be properly grounded. Electrical shock can result if the dryer is not properly grounded. Follow the instructions in this manual for proper grounding.
· DO NOT use an extension cord with this dryer. Some extension cords are not designed to withstand the amounts of electrical current this dryer utilizes and can melt, creating electrical shock and/ or fire hazard. Locate the dryer within reach of the receptacle for the length power cord to be purchased, allowing some slack in the cord. Refer to the Pre-Installation Requirements section of this manual for the proper power cord to be purchased.
WARNING
ELECTRICAL SHOCK HAZARD
· A U.L.-approved strain relief must be installed onto power cord. If the strain relief is not attached, the cord can be pulled out of the dryer and can be cut by any movement of the cord, resulting in electrical shock.
· DO NOT use an aluminum wired receptacle with a copper wired power cord and plug (or vice versa). A chemical reaction occurs between copper and aluminum and can cause electrical shorts. The proper wiring and receptacle is a copper wired power cord with a copper wired receptacle.

WARNING
Improper grounding of the dryer may cause serious injury or death. Check with a licensed electrician if you are in doubt as to whether the appliance is properly grounded.
For a grounded, cord-connected dryer:
1. The dryer MUST be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electrical shock by providing a path of least resistance for electrical current.
2. After you purchase and install a 3-wire or 4-wire power supply cord having an equipment-grounding conductor and a grounding plug that matches your wiring system, the plug MUST be plugged into an appropriate, copper wired receptacle that is properly installed and grounded in accordance with all local codes and ordinances. If in doubt, call a licensed electrician.
3. DO NOT modify the plug you've installed on this appliance. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.
For a permanently connected dryer:
The dryer MUST be connected to a grounded metal, permanent wiring system; or an equipment grounding conductor must be run with the circuit conductors and connected to the equipment-grounding terminal or lead on the appliance.

NOTE
Dryers operating on 208 volt power supply will have longer drying times than dryers operating on 240 volt power supply.

19 INSTALLATION

Grounding requirements electric dryer (Canada)

Grounding requirements gas dryer

WARNING
Improper grounding of the dryer may cause serious injury or death. Check with a licensed electrician if you are in doubt as to whether the appliance is properly grounded.
For a grounded, cord-connected dryer:
1. The dryer MUST be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electrical shock by providing a path of least resistance for electrical current.
2. Since your dryer is equipped with a power supply cord having an equipment-grounding conductor and a grounding plug, the plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. If in doubt, call a licensed electrician.
3. DO NOT modify the plug provided with this appliance. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.

1. The dryer is equipped with a threeprong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle.
2. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. If in doubt, call a licensed electrician.
3. DO NOT modify the plug provided with this appliance. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.
WARNING
Improper grounding of the dryer may cause serious injury or death. Check with a licensed electrician if you are in doubt as to whether the appliance is properly grounded.
Grounding type wall receptacle
Do not, under any circumstances, cut, remove, or bypass the grounding prong.

Power cord with 3-prong grounded plug

20 INSTALLATION

Electrical connection (non-Canada) - 3 wire cord
3-wire receptacle (NEMA type 10-30R)
WARNING

IMPORTANT
If moving dryer from a 4-wire system and installing it in a 3-wire system, move the internal ground from the center terminal back to the GREEN screw next to the terminal block.

ELECTRICAL SHOCK HAZARD Failure to disconnect power source before servicing could result in personal injury or even death.
WARNING

30 AMP NEMA 10-30

Neutral (center wire)

ELECTRICAL HAZARD Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
1. Turn off power supply to outlet.
2. Remove the screw securing the terminal block access cover in the lower corner on the back of the dryer.
3. Install a UL-approved strain relief according to the power cord/strain relief manufacturer's instructions in the power cord entry hole below the access panel. At this time, the strain relief should be loosely in place.
4. Thread an UNPLUGGED, UL-approved, 30 amp. power cord, NEMA 10-30 type SRDT, through the strain relief.
5. Attach the power cord neutral (center wire) conductor to the SILVER colored center terminal on the terminal block. Tighten the screw securely.
6. Attach the remaining two power cord outer conductors to the outer, BRASS colored terminals on the terminal block. Tighten both screws securely.

NOTE
If a terminal screw falls during cord installation, it can be retrieved in the terminal screw recovery slot below the access panel.

DO NOT remove internal ground in a 3-wire system!!

Neutral terminal

WARNING
ELECTRICAL SHOCK HAZARD DO NOT make a sharp bend or crimp wiring/conductor at connections.
7. Follow manufacturer's guidelines for firmly securing the strain relief and power cord.
8. Reinstall the terminal block cover.

21 INSTALLATION

Electrical connection (non-Canada) - 4 wire cord
4-wire receptacle (NEMA type 14-30R)
WARNING
ELECTRICAL SHOCK HAZARD Failure to disconnect power source before servicing could result in personal injury or even death.
WARNING

WARNING
ELECTRICAL SHOCK HAZARD DO NOT make a sharp bend or crimp wiring/conductor at connections.
9. Follow manufacturer's guidelines for firmly securing the strain relief and power cord.
10. Reinstall the terminal block cover.

30 AMP NEMA 14-30

Ground (GREEN
wire)

Neutral (WHITE
wire)

ELECTRICAL HAZARD Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
1. Turn off power supply to outlet.
2. Remove the screw securing the terminal block access cover in the lower corner on the back of the dryer.
3. Install a UL-approved strain relief according to the power cord/strain relief manufacturer's instructions in the power cord entry hole below the access panel. At this time, the strain relief should be loosely in place.
4. Thread an UNPLUGGED, UL-approved, 30 amp. power cord, NEMA 14-30 type DRT or SRDT, through the strain relief.
5. Disconnect the internal (WHITE) dryer harness ground wire from the (GREEN) ground screw next to terminal block.
6. Attach the ground (GREEN) power cord wire to the cabinet with the ground (GREEN) screw. Tighten the screw securely.
7. Move the internal dryer harness ground (WHITE) wire to the terminal block and attach it along with the neutral (WHITE) power cord wire conductor to center, SILVER colored terminal on the terminal block. Tighten the screw securely.
8. Attach the RED and BLACK power cord conductors to the outer, BRASS colored terminals on the terminal block. Tighten both screws securely.

Access Cover Screw Terminal Block Line 2 (BRASS Terminal) Neutral (SILVER Terminal) Line 1 (BRASS Terminal) Internal Ground (GREEN Screw) Install UL-Approved Strain Relief Here Terminal Screw Recovery Slot
NOTE
If a terminal screw falls during cord installation, it can be retrieved in the terminal screw recovery slot below the access panel.

Move internal ground (WHITE)

wire to neutral (SILVER) terminal for 4-wire system.

Neutral terminal

WHITE neutral wire

GREEN ground screw

GREEN ground wire
BLACK or RED power wire

BLACK or RED power wire

22 INSTALLATION

Connecting the gas
1. Remove the shipping cap from gas pipe at the rear of the dryer.
WARNING

WARNING
EXPLOSION HAZARD NEVER test for gas leaks with an open flame.

DO NOT connect the dryer to L.P. gas service without converting the gas valve. An L.P. conversion kit PN# PCK4200 (not included) must be installed by a qualified gas technician.
2. Connect a 1/2 inch (1.27 cm) I.D. semirigid or approved pipe from gas supply line to the 3/8 inch (0.96 cm) pipe located on the back of the dryer. Use a 1/2 inch to 3/8 inch (1.27 cm to 0.96 cm) reducer for the connection. Apply an approved thread sealer that is resistant to the corrosive action of liquefied gases on all pipe connections.

IMPORTANT
Installation to the gas service must follow local codes and ordinances and the latest edition of the National Fuel Gas Code ANSI Z223.1/NFPA 54 or in Canada, CSA B149.1.
Connecting the water
(steam models only)
WARNING

Manual Shutoff Valve

Flare GAS FLOW Flare

Union

Open

Nipple Flexible Inlet Pipe on Connector Back of Dryer
Closed All connections must be wrench-tightened

Periodically inspect all water inlet hoses for water leaks, wear, cuts, corrosion and bulges. Replace all hoses, if any sign of the above is visible. All hoses should be replaced every 5 years to reduce the risk of hose failures.

3. Open the shutoff valve in the gas supply line to allow gas to flow through the pipe. Wait a few minutes for gas to move through the gas line.
IMPORTANT
The supply line must be equipped with an approved manual shutoff valve. This valve should be located in the same room as the dryer and should be in a location that allows ease of opening and closing. DO NOT block access to the gas shutoff valve.

Water supply requirements
Cold water faucet MUST be installed within 42 inches (107 cm) of your dryer's water inlet. The faucet MUST be 3/4 inch (1.9 cm) with threading for laundry hose connection. Water pressure MUST be between 20 and 120 psi. Your water department can advise you of your water pressure.
1. Turn off COLD water supply to washer.

to dryer

from gas supply

2. Remove COLD inlet hose from COLD water supply and inspect for rubber washer. Replace washer if it is torn or worn out.

Shutoff Valve - Open position

4. Check for gas system leaks with a manometer. If a manometer is not available, test all connections by brushing on a soapy water solution.

23 INSTALLATION

Rubber Washer Must be Present and Undamaged
Cold Inlet Hose to Washer
3. Turn on COLD supply and run water to clear any contaminants in the line.

Short Hose "Y" Connector Water Inlet on Dryer
Cold Water Supply Hose to Washer

6. If there is not room to install the "Y" connector directly, thread the short extension hose on to the COLD water supply and snug it by hand; then tighten it another 2/3 turn with pliers.

4. Inspect hose couplings for proper placement of rubber washers. Use hoses from ASSEMBLY HOSE KIT# 5304495002 (not included).

7. Thread the "Y" connector to the short extension hose and snug it by hand; then tighten it another 2/3 turn with pliers.

8. Connect the COLD inlet hose for the washer to the "Y" connector and snug it by hand; then tighten it another 2/3 turn with pliers.

9. Connect the straight end of the long hose

Rubber Washers

from the kit to the other outlet on the "Y"

MUST BE PRESENT

connector and snug it by hand. Connect

the hose's 90° coupling to the brass

water inlet on the back of the dryer and

5. If your installation has room for the COLD

snug it by hand. Tighten each connection

water supply to accept the "Y" connector

of the dryer inlet hose another 2/3 turn

directly, thread the "Y" connector to the

with pliers.

COLD water supply and snug it by hand;

then tighten it another 2/3 turn with pliers. 10. Turn on the water and check for leaks at

all connections.

NOTE

If you were able to install the "Y" connector directly to the COLD water supply, please skip to step 8.

24 INSTALLATION

Completing the installation
1. Connect the exhaust duct to the outside exhaust system. Use of a 4" (102 mm) clamp (item A) is recommended to connect the dryer to the exhaust vent system. Use metal foil tape to seal all other joints.

5. Plug the power cord into a grounded outlet.
WARNING
Improper grounding of the dryer may cause serious injury or death. Check with a licensed electrician if you are in doubt as to whether the appliance is properly grounded.

2. Use a carpenter's level to level your dryer front-to-back and side-to-side.
3. Use adjustable pliers to adjust the leveling legs so the dryer is level frontto-rear and side-to-side, and stable corner-to-corner.

WARNING
Do not store combustible materials, gasoline, and other flammable vapors and liquids near this dryer.

6. Turn on the power at the circuit breaker/fuse box.

7. Read the Use & Care Manual provided with the dryer. It contains valuable and helpful information that will save you time and money.

8. If you have any questions during initial operation, please review the "Avoid Service Checklist" in your Use & Care Manual before calling for service.

9. Place these instructions in a location

4. Press down on alternate corners

near the dryer for future reference.

and sides and feel for the slightest

movement. Adjust the appropriate leg(s) so the dryer sits solidly on

NOTE

the floor on ALL four legs. Keep the leveling leg extension at a minimum for best performance of the dryer.

A wiring diagram and technical data sheet are located under the dryer top panel.

IMPORTANT
Be sure the power is off at a circuit breaker/fuse box before plugging the power cord into an outlet.

CAUTION
When discarding or storing your old dryer, remove the door.

25 INSTALLATION

Reversing the door
NOTE
Door reversibility is available on all dryer models.

IMPORTANT

Tools needed for reversal:

BEFORE YOU REVERSE YOUR DRYER DOOR:
1. Be sure you have adequate swing area before reversing door.
2. Gather your tools - including a screw driver with a #2 square bit and plastic knife (or small, flat prying tool that won't damage paint).
3. Be sure dryer is unplugged from power source!

Screwdriver with #2 square bit
Plastic knife

WARNING
ELECTRICAL SHOCK HAZARD Failure to disconnect power source before servicing could result in personal injury or even death.

Removing latch and hole plugs
1. Open the door.
2. Remove plastic hole plugs and save to reinstall later. You may have to use a non-scratching plastic knife if you are unable to dislodge the plugs manually.

3. Remove both screws from door latch. Save latch and screws for reinstallation later.

26 INSTALLATION

Removing door assembly
1. Completely open the door to expose all four hinge screws.
2. Remove all four hinge screws with #2 square bit driver. Save for reinstalling later.

Reinstalling latch and hole plugs
1. Install door latch with screws removed earlier.

3. Grasp the door with both hands and lift slightly as you pull door and hinge away from the front panel.
Reinstalling door assembly
1. Rotate the door and hang the upper hook on the back of the hinge in the upper hole of the front panel.

2. Insert plastic hole plugs removed earlier.

Verify reversed door operation
1. Test door for free, smooth swinging operation and secure latching when closed.
2. Plug in dryer and close the door. Start a test cycle: drum should tumble until door is pulled open or cycle is paused or canceled.
2. Reinstall and tighten all four screws removed earlier - two front screws first, then two side screws.

27 ACCESSORIES AND REPLACEMENT PARTS

Accessories
MATCHING STORAGE PEDESTAL* White Pedestal - P/N EPWD257UIW Titanium Pedestal - P/N EPWD257UTT A storage pedestal accessory, specifically designed for this dryer may be used to elevate the dryer for ease of use. This pedestal will add about 15" (38 cm) to the height of your unit.
*Other colors may be available. Contact the source where you purchased your dryer.
DRYER STACKING KIT P/N STACKIT7X Depending on the model you purchased, a kit for stacking a matching dryer on top of this washer may have been included in the initial purchase of your dryer. If your model did not include a stacking kit or you desire another stacking kit, you may order one.

WARNING
Failure to use accessories manufactured by (or approved by) the manufacturer could result in personal injury, property damage or damage to the dryer.
27" (68.5 cm)
15" (38 cm)
(6276c.5m")
Storage Pedestal

LP CONVERSION KIT P/N PCK4200 Gas dryers intended for use in a location supplied with LP must use a conversion kit prior to installation.

MOBILE HOME INSTALLATION KIT P/N 137067200 Installations in mobile homes require use of MOBILE HOME INSTALLATION KIT.
UNIVERSAL APPLIANCE WRENCH P/N 137019200 A UNIVERSAL APPLIANCE WRENCH is available to aid in dryer/washer/pedestal feet adjustment.
TOUCH UP PAINT PENS White - P/N 5304468812 Titanium - P/N 5304475700
*Other colors may be available. Contact the source where you purchased your dryer.
ASSEMBLY HOSE KIT P/N 5304495002 For use in dryer models that include a steam feature.

Universal Appliance Wrench
Replacement parts in U.S. and Canada
If replacements parts are needed for your dryer, you can contact the source where you purchased your dryer, call 1-877-4ELECTROLUX (1-877-435-3287) in the U.S. or 1-800-265-8352 in Canada, or visit our website, www.electroluxappliances.com in the U.S. or www.electroluxappliances.ca in Canada for the Electrolux Authorized Parts Distributor nearest you.

28 CONTROLS AND SETTINGS
Model series

300 SERIES

POWER

CLEAN LINT

BULKY HEAVY DUTY NORMAL 20MIN FAST DRY DELICATES TOWELS TIME DRY
CYCLES

HIGH NORMAL LOW ECO DRY TEMP

HIGH
NORMAL
LOW
DAMP DRY LEVEL

AUTO
60 MIN
45 MIN
30 MIN DRY TIME

EXTENDED TUMBLE WRINKLE RELEASE
DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

4 5 6 7 8 9 10 11

400 SERIES

POWER

CLEAN LINT

BULKY

SANITIZE

HEAVY DUTY

HIGH

NORMAL 18MIN FAST DRY DELICATES

NORMAL LOW

TIME DRY INSTANT REFRESH

ECO DRY TEMP

CYCLES

MAX HIGH NORMAL LOW DAMP DRY LEVEL

AUTO 75 MIN 60 MIN 45 MIN 30 MIN DRY TIME

PERFECT STEAM WRINKLE RELEASE EXTENDED TUMBLE
DRUM LIGHT DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

4 5 6 7 8 9 10 11

500 SERIES

PREDICTIVE DRY LUXCARE DRY

POWER

CALL SERVICE MIN
CLEAN LINT

ALLERGEN HEAVY DUTY NORMAL ACTIVEWEAR MIXED LOAD TOWELS 15MIN FAST DRY DELICATES TIME DRY
INSTANT REFRESH

SANITIZE HIGH NORMAL LOW ECO DRY TEMP

MAX HIGH NORMAL LOW DAMP DRY LEVEL

AUTO 75 MIN 60 MIN 45 MIN 30 MIN DRY TIME

ANTI-STATIC PERFECT STEAM WRINKLE RELEASE EXTENDED TUMBLE
DRUM LIGHT DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

4 5 6 7 8 9 10 11

600 SERIES GAS/ELECTRIC

BALANCED DRY LUXCARE DRY

POWER

CALL SERVICE MIN
CLEAN LINT

ALLERGEN HEAVY DUTY NORMAL ACTIVEWEAR MIXED LOAD TOWELS 15MIN FAST DRY DELICATES AIR DRY
TIME DRY INSTANT REFRESH

SANITIZE HIGH NORMAL LOW ECO DRY TEMP

MAX HIGH NORMAL LOW DAMP DRY LEVEL

AUTO 75 MIN 60 MIN 45 MIN 30 MIN DRY TIME

ANTI-STATIC PERFECT STEAM WRINKLE RELEASE EXTENDED TUMBLE
DRUM LIGHT DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

4 5 6 7 8 9 10 11

1 POWER 4 Temp Selector 7 Options 10 START/PAUSE

2 Cycle Selector 5 DRY LEVEL 8 SELECT/DE-SELECT 11 DRY BOOST

3 Cycle LED Display 6 DRY TIME 9 CANCEL

This manual covers many models and not all cycles, options, or features listed are available on every model. Consoles shown above for reference only. Your model may differ.

29 CONTROLS AND SETTINGS
Setting chart - 300 series dryer

POWER

CLEAN LINT

BULKY HEAVY DUTY NORMAL 20MIN FAST DRY DELICATES TOWELS TIME DRY
CYCLES

HIGH NORMAL LOW ECO DRY TEMP

HIGH
NORMAL
LOW
DAMP DRY LEVEL

AUTO
60 MIN
45 MIN
30 MIN DRY TIME

EXTENDED TUMBLE WRINKLE RELEASE
DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

These temperature, dryness levels and options are available with the following cycles: CYCLE SELECTIONS

BULKY HEAVY DUTY NORMAL 20 MIN FAST DRY DELICATES TOWELS TIME DRY

CYCLE SETTINGS

TEMPERATURE (temp)

High

Normal

Low

Eco Dry

DRYNESS

High

Normal

Low

Damp

Dry Time

Auto Dry

60 Min

45 Min

30 Min

OPTIONS

Extended Tumble

Wrinkle Release

Delay Time

Control Lock

Dry Boost

= Available selections. = Factory presets. = Non-modifiable presets.

CYCLE OPTIONS

30 CONTROLS AND SETTINGS
Setting chart - 400 series dryer

POWER

CLEAN LINT

BULKY

SANITIZE

HEAVY DUTY

HIGH

NORMAL 18MIN FAST DRY DELICATES

NORMAL LOW

TIME DRY

ECO DRY

INSTANT REFRESH TEMP

CYCLES

MAX HIGH NORMAL LOW DAMP DRY LEVEL

AUTO 75 MIN 60 MIN 45 MIN 30 MIN DRY TIME

PERFECT STEAM WRINKLE RELEASE EXTENDED TUMBLE
DRUM LIGHT DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

These temperature, dryness levels and options are available with the following cycles: CYCLE SELECTIONS

BULKY HEAVY DUTY NORMAL 18 MIN FAST DRY DELICATES TIME DRY INSTANT REFRESH

CYCLE SETTINGS

TEMPERATURE (temp)

Sanitize High

Normal

Low Eco Dry

DRYNESS Max

High

Normal Low

Damp

DRY TIME Auto Dry 75 Min

60 Min

45 Min

30 Min

OPTIONS Perfect Steam

Wrinkle Release

Extended Tumble Drum Light

Delay Time Control Lock

Dry Boost

= Available selections. = Factory presets. = Non-modifiable presets.

CYCLE OPTIONS

31 CONTROLS AND SETTINGS

Setting chart - 500 series dryer

PREDICTIVE DRY LUXCARE DRY

POWER

CALL SERVICE MIN
CLEAN LINT

ALLERGEN HEAVY DUTY NORMAL ACTIVEWEAR MIXED LOAD TOWELS 15MIN FAST DRY DELICATES TIME DRY
INSTANT REFRESH

SANITIZE HIGH NORMAL LOW ECO DRY TEMP

MAX HIGH NORMAL LOW DAMP DRY LEVEL

AUTO 75 MIN 60 MIN 45 MIN 30 MIN DRY TIME

ANTI-STATIC PERFECT STEAM WRINKLE RELEASE EXTENDED TUMBLE
DRUM LIGHT DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

These temperature, dryness levels and options are available with the following cycles: CYCLE SELECTIONS

ALLERGEN HEAVY DUTY NORMAL ACTIVE WEAR MIXED LOADS (COLORS) TOWELS 15 MIN FAST DRY DELICATES TIME DRY INSTANT REFRESH

CYCLE SETTINGS

TEMPERATURE (temp)

Sanitize High Normal Low Eco Dry (No Heat/Air)

DRYNESS Max High

Normal Low

Damp

DRY TIME Auto Dry

75 Min

60 Min

45 Min

30 Min

OPTIONS

Anti-Static Perfect Steam

Wrinkle Release Extended Tumble

Drum Light

Delay Time Control Lock

Dry Boost

= Available selections. = Factory presets. = Non-modifiable presets.

CYCLE OPTIONS

32 CONTROLS AND SETTINGS

Setting chart - 600 series dryer

BALANCED DRY LUXCARE DRY

POWER

CALL SERVICE MIN
CLEAN LINT

ALLERGEN HEAVY DUTY NORMAL ACTIVEWEAR MIXED LOAD TOWELS 15MIN FAST DRY DELICATES AIR DRY
TIME DRY INSTANT REFRESH

SANITIZE HIGH NORMAL LOW ECO DRY TEMP

MAX HIGH NORMAL LOW DAMP DRY LEVEL

AUTO 75 MIN 60 MIN 45 MIN 30 MIN DRY TIME

ANTI-STATIC PERFECT STEAM WRINKLE RELEASE EXTENDED TUMBLE
DRUM LIGHT DELAY TIME CONTROL LOCK

START PAUSE CANCEL
DRY BOOST

OPTIONS

SELECT DE-SELECT

HOLD `SELECT' 3s TO MUTE/UNMUTE

These temperature, dryness levels and options are available with the following cycles: CYCLE SELECTIONS

ALLERGEN HEAVY DUTY NORMAL ACTIVE WEAR MIXED LOADS (COLORS) TOWELS 15 MIN FAST DRY DELICATES AIR DRY TIME DRY INSTANT REFRESH

CYCLE SETTINGS

TEMPERATURE (temp)

Sanitize

High

Normal

Low

Eco Dry (No Heat/Air)

DRYNESS

Max

High

Normal

Low

Damp

Dry Time

Auto Dry

75 Min

60 Min

45 Min

30 Min

OPTIONS

Anti-Static

Perfect Steam

Wrinkle Release

Extended Tumble

Drum Light

Delay Time

Control Lock

Dry Boost

= Available selections. = Factory presets. = Non-modifiable presets.

CYCLE OPTIONS

33 CONTROLS AND SETTINGS

Cycle selection
Selecting the right cycle to save energy
This dryer has been specifically designed with options to help you save energy and at the same time utilize the optimal drying setting for your clothing.
The normal cycle was used to rate the dryer for energy efficiency. The normal cycle resets to normal temperature setting, normal dryness level.
Some cycles save more energy than others. Cycles that use the least amount of heat save the most energy and display the leaf icon on the console. Use the lowest heat setting (auto and timed dry cycles) and less dry setting (auto dry cycles) to save on energy and prevent over drying your clothing.

Press the power button to turn on the unit.

sensors may not detect enough moisture to

Turn the cycle selector in either direction

continue the cycle and the cycle may end

or repeatedly press the cycles button

after a few minutes. If this occurs, then select

(depending on your model) to scroll to the

the time dry cycle to dry such loads.

desired cycle. The indicator light for the cycle selected will be illuminated and the estimated drying time for Auto Dry cycles or the actual drying time for Time Dry cycles will be

Room temperature and humidity, type of installation and electrical voltage or gas pressure can also affect drying time.

displayed on the LED display screen.
Default settings and options will automatically

NOTE

be indicated for the cycle selected. In most cases cycle settings and options can be changed. See Cycle Settings, Cycle Options, and Setting Charts for more details.

Models equipped with the Predictive Dry feature use the first 90 seconds of Auto Dry cycles to sense the load in the dryer. During this 90 second period the LED display will

To change the cycle once it has begun,

show 2 circling lines. When the sensing

press the cancel button before selecting a

is complete, the LED display will show

new cycle. Turning the cycle selector ring

the remaining cycle time in minutes and

or pressing the cycles button WILL NOT

accurately count down to the end of the

change the cycle.

cycle.

Auto dry cycles
Auto dry cycles take the guesswork out of selecting the correct drying time for each load. Moisture sensors sense the moisture level of the load as it tumbles through the heated air. With auto dry cycles, the load will automatically be dried at the selected temperature to the desired dryness level.

Timed dry cycles
The timed drying cycles allow the selection of exact drying times. The time dry cycle allows the option to select drying time settings ranging from 30 to 75 minutes (depending on the model). Various drying times and temperature settings can be selected when using this cycle.

Auto dry cycles save time and energy and protect fabrics. When the load has reached the selected dryness level, it will continue to tumble, unheated, during a cool down period. This helps reduce wrinkling and makes items easier to handle during unloading.
NOTE
Initial cycle times for auto dry cycles are only estimates, the actual drying time may differ slightly from the time displayed.
Drying times vary depending on size and dampness of the load and fabric type. If the load is too small or almost dry, the moisture

The fast dry cycles (on select models) have preset times of 15, 18 or 20 minutes (dependent on model) with a preset temperature of high only.
Dryness levels will not be an available option when using either of the timed drying cycles.
WARNING
FIRE HAZARD To avoid fire hazard, DO NOT use heat to dry items containing feathers or down, foam rubber, plastics similarly textured, rubber-like materials. Use the time dry cycle and the eco dry (no heat) setting.

34 CONTROLS AND SETTINGS

Cycles
LOAD ALLERGEN (select models)
BULKY (select models) HEAVY DUTY (select models) NORMAL
ACTIVEWEAR (select models)
MIXED LOAD (select models)
TOWELS (select models) FAST DRY (varies by model) 15/18/20 min. DELICATES
TIME DRY
AIR DRY INSTANT REFRESH (select models)

LOAD TYPE

CYCLE PRESET

Allergen removal (not for items prone to heat damage) Large loads and durable fabrics (such as towels, jeans and overalls) Large loads and durable fabrics (such as jeans and overalls) Everyday loads (cottons, linens and sheets) Lightweight synthetic athletic apparel (synthetic athletic fabrics and stretch fabrics) Mixed load of fabrics
Large loads and durable fabrics (such as towels, jeans and overalls) Small loads of 3 to 5 garments

· high temperature* · maximum dryness* · auto dry* · high temperature · maximum dryness · auto dry*
· normal temperature · normal dryness · auto dry* · low temperature · normal dryness · auto dry* · normal temperature · normal dryness · auto dry* · high temperature* · maximum dryness* · auto dry* · high temperature* · preset time*
(15,18 or 20 minutes)

Knit fabrics and delicates
Manually set drying time, heat and dry level for any type of load Small loads of 3 to 5 garments Refresh fabrics, remove odors and reduce static by injecting steam into clothing.

· low temperature* · normal dryness · auto dry*
· normal temperature · 30-75 minutes time
· no heat
· high temperature* · perfect steamTM*

* setting can not be changed from preset.

NOTE
It is not recommended to use fabric softener sheets with steam cycles or steam options as it may cause staining on clothes.

NOTE
To change a cycle setting once the cycle has begun, press the start/pause button, make the new selection and press start/ pause again.

Cycle settings
To set or change the drying temperature, dryness level, or drying time press the temp, dryness or time dry buttons to scroll to the desired settings. The indicator light for each setting will be illuminated when selected.

To protect your fabrics, not all temperatures or dryness levels are available with every cycle. If a temperature or dryness level is not appropriate for the cycle, it cannot be selected and will not be lit when scrolling through the settings.

35 CONTROLS AND SETTINGS

With exception of the sanitize and perfect steamtm, adjustments made to cycle settings and options will be remembered and recalled each time that cycle is selected in the future.

the future, select high or max (on select models). To decrease drying time for similar loads, select less (on select models).
Select damp for items you wish to partially dry before hanging or ironing.

To return to factory settings, press the dryness and options buttons at the same time and hold until the signal sounds.
Drying temperature (temp)
To change the temperature, press the temp button to scroll to the desired setting.

Drying time (time dry)
Manually select or change the drying time for a time dry cycle (on select models) by pressing the time dry button to scroll though the available options. Time dry options include 30, 45, 60 and 75 minutes (dependent on model).
The auto selection is a default for all auto dry cycles and fast dry cycles and cannot be selected or changed. All actual or predicted dry times will count down on the LED display.

For best results
Follow the fabric care label instructions on items to be dried.
sanitize (on select models) Recommended for durable fabrics and towels. Use this selection to remove harmful bacteria from your clothing or other items where sanitization is desired. This option will kill 99.9% of bacteria using a higher temperature required to kill bacteria. Please check fabric care labels to prevent damage.
high Recommended for most cotton fabrics.
normal Recommended for wrinkle free, easy care, lightweight fabrics and bulky loads.
low (on select models) Recommended for delicate fabrics.
eco dry (no heat) This setting should only be used with a time dry cycle to dry items containing feathers, down, foam rubber, plastics or rubber-like materials; to refresh clothing, stuffed animal, pillows or blankets; and to dust draperies.
Dryness level (dryness)
To set or change the dryness level, press the dryness button to scroll to the desired setting.
The dryness levels include max (on select models), high, normal, low (on select models), and damp. Most Auto Dry cycles default to the normal dryness level.
Occasionally a load may seem too damp or over-dried at the end of the cycle. To increase drying time for similar loads in

Cycle options
To select an option, press options and scroll though the options until the indicator light for the desired option flashes, then press select (set). The indicator will illuminate when the option has been selected. Follow the same steps to deselect an option. The indicator light will turn off when the option is deselected.
options select de-select
NOTE
To change a cycle option once the cycle has begun, press the start/pause button, make the new selection and press start/ pause again.
To protect your fabrics, not all options are available with every cycle. If an option is not available for a cycle, the indicator will not light.
Occasionally, two options or settings in the same cycle will conflict with each other, like the perfect steam option and sanitize temperature (on select models). When this happens, the option selected first will cause the conflicting option to not be selectable.
perfect steamTM (on select models)The perfect steamTM option injects steam into the clothing prior to cool down to reduce wrinkling, ironing and static cling.

36 CONTROLS AND SETTINGS

NOTE
It is not recommended to use fabric softener sheets with steam cycles or steam options as it may cause staining on clothes.
anti-static (on select models) The anti-static option injects steam into the clothing just before cycle completion to reduce static.
dry boost This option increases the drying effectiveness for difficult loads. In conjunction with Automatic moisture sensors and the dry boost option may slightly decrease cycle times.

(models 300/400) or the cycle selector (models 500/600) to scroll to the desired delay time and press start. The delay time icon will illuminate on the LED display to indicate the delay time option is activated, The delay time will begin counting down on the LED display once activated.
NOTE
While counting down during delay time, you will notice your dryer periodically tumbling for a few minutes without heat to redistribute the load, maximizing load freshness.

leaf icon
This icon will appear on the console when the dryer is using energy efficient settings. These settings use less heat and longer cycle times to dry. The dryer will always default to the energy efficient Normal cycle with the leaf icon displayed.
wrinkle release
The wrinkle release option helps prevent wrinkles and tangling by tumbling the dry load without heat for 5 minutes out of every 10 minutes. The 5 minutes on and 5 minutes off is repeated for a total 45 minutes. A chime will sound after each tumble as a reminder to remove the dried load.
NOTE
When extended tumble and wrinkle release options are both selected the amount of time the load will tumble without heat will increase to a period of up to 75 minutes.

control lock To lock the controls between cycles, scroll to the control lock option and press select. The control lock icon will show on the LED display. To unlock the controls scroll to the control lock option again and press select. Use this feature to reduce the likelihood of accidental operation by children. Dryer cycles will not run when Control Lock is activated.
chime A signal will sound at the end of the cycle (and periodically during extended tumble or wrinkle release). To mute or unmute the chime, press and hold the select button for 3 seconds.
options select de-select
hold `select' 3 s to mute/unmute

extended tumble (on select models)
Select the extended tumble option if the dried load might not be removed promptly at the end of the cycle. The dried load will tumble continuously without heat for 30 minutes. A chime will sound periodically to remind you to remove the dried load.
delay time (on select models)
Use delay time to delay the start of the drying cycle to a time convenient to your schedule or during off-peak energy hours. The start of any cycle can be delayed for 30 minutes to 12 hours. After selecting the delay time option, use the cycle button

Other features
LED display
CALL SERVICE
MIN CLEAN LINT
Icons may vary according to model.

37 CONTROLS AND SETTINGS

The estimated cycle time for auto dry, the actual time for time dry, or the delay time countdown will be displayed when the cycle is selected. Once the cycle has started, the estimated remaining time will be displayed for the remainder of the cycle.
As the dryer progresses through the cycle phases, the row of cycle phase indicators lights up under the cycle time.
Delay time, leaf, control lock, mute icons (select models) and CLEAN LINT will also appear on this LED display when activated.

LuxCareTM Lint Shield filter
The dryer is equipped with a clamshell style LuxCareTM Lint Shield filter.

Drum light (on select models)
The drum light will come on whenever the door is opened to illuminate the drum during loading and unloading. Closing the door turns off the light. The drum light will automatically turn off if the door is left open more than 3 minutes. Select the drum light option to enable or disable the drum light.
Reversible door
The dryer is equipped with a reversible door. The door can be hinged on the right or left side.
NOTE
For step-by-step instructions on door reversal, refer to the installation sections of this manual.

WARNING
Clean the filter after every load. A CLEAN LINT message will appear on the LED display at the end of the cycle to remind you to remove the lint from the filter.
NOTE
For step-by-step instructions cleaning the lint filter, refer to Cleaning the Filter in the Care and Cleaning section of this Use & Care Manual.

38 OPERATING INSTRUCTIONS

Operating the dryer
WARNING
To reduce the risk of fire, electric shock or injury to persons, read the Important Safety Information in this Use & Care Manual before operating your dryer.

WARNING
DO NOT operate dryer without lint filter in place.

WARNING
Clean the lint filter after every load.

STEPS

TIPS

IMPORTANT

1. Prepare load · Dry items of similar fabric, weight and

for drying.

construction in the same load.

· Separate dark items from light-colored items. Separate items that shed lint from those that attract lint.

· Check for stains which may not have been removed in washing. Repeat stain removal process and wash again before drying. Dryer heat may permanently set some stains.

· Place delicate, rubber coated, or small items in a mesh bag (not included).

· Be sure buckles, buttons and trim are heatproof and won't damage the drum finish. Close zippers; fasten hooks and loop fasteners. Tie strings and sashes to prevent snagging and tangling.

DO NOT machine wash items containing fiberglass. Small particles of fiberglass left in drum may transfer to fabrics in other loads and cause skin irritation and/or damage to fabrics.
DO NOT wash water resistant and water repellent type clothing or other materials.

2. Check that the lint filter is clean and in place.

DO NOT operate dryer without lint filter in place.

3. Load the dryer and close the door.

· Load items loosely. The average wet load will DO NOT overload

fill the drum 1/3 to 1/2 full. Items need room to the dryer. To save

tumble freely for even drying and less wrinkling. energy, time and

If desired, place a dryer fabric softener sheet on top of the load at the beginning of the cycle.

avoid uneven drying and wrinkling avoid overloading the dryer.

· When drying large items, dry only two or three items at a time. Fill out the load with smaller items.

DO NOT over-dry. Over-drying can cause wrinkles, shrinkage, lint,

· For delicate or very small loads, add two

and a build up of static

or three similar items to improve tumbling action. electricity.

39 OPERATING INSTRUCTIONS

STEPS
1. Select the appropriate cycle and settings for each load.

TIPS

IMPORTANT

· See Cycle Selection and Cycle Settings for

Over-drying can

detailed descriptions of cycle controls.

cause wrinkles,

· See Cycle Setting Charts to determine which settings are available for each cycle.

shrinkage, lint, harshness, and a build up of static

· To provide the best care, not every setting or

electricity.

option is available with every cycle. If a setting or option is not available for the cycle selected, the indicator will not light. See Setting Chart for information of available options for each cycle by model.

To prevent unintentional and accidental exposure of delicate material

· Adjustments made to most cycle settings will be to excess heat

remembered each time the cycle is selected in the or unexpected

future. When the dryer is powered on, the default steam, the sanitize

cycle will be the normal cycle. Select your desired temperature

cycle and previous settings will remain. To return to setting and the

factory settings, press the dryness button and the perfect steamTM

options button at the same time and hold until the option will not be

signal sounds.

remembered and

must be reselected

each time.

2. Close the dryer door and start the drying cycle.

· To start the drying cycle, close the door and press the start/pause button.
· To add an item to the dryer drum, press start/ pause. Add the item, close the door and press start/pause to resume the cycle.
· To change settings or options after the cycle has begun, press start/pause, change the settings, and then press start/pause. If the cycle is not paused first, the unit will emit several beeps when the buttons are pressed but no changes to the cycle will be applied.
· To change the cycle once the cycle has begun, press cancel to cancel the cycle, select the new cycle, and press start/pause to begin the new cycle. Changing a cycle selection without cancelling the current WILL NOT change the cycle.

The dryer will not operate with the door open.
When drying a single large or bulky item, such as a comforter, pause the cycle part way through to turn the item "inside out" and maximize drying effectiveness.

· To cancel a cycle, press cancel.

3. Remove items when done.

· A signal will sound at the end of the cycle if the chime option is not set to mute.
· Immediately remove items when the cycle is completed and hang or fold.

See product manufacturer's instructions.

4. Clean the lint · See Care and Cleaning section of this instruction.

filter.

· CLEAN LINT will be displayed at the end of the

cycle as a reminder to remove lint from filter.

ALWAYS REMOVE LINT at the end of the cycle (see warning on previous page).

40 NORMAL OPERATING SOUNDS

Normal operating sounds

You may or may not hear the following sounds from your new dryer:

1. WATER VALVE (Steam models only.)

The flow of water is controlled by

electric solenoids. During operation

there may be a clicking sound as the

valve opens and closes to control the

water flow.

2. SUSPENSION ROLLERS The dryer

drum is supported by a set of

suspension rollers. At times there may

be a thumping or rolling sound when

the dryer starts. This may happen if

the dryer has not been in use for a

period of time, or after a heavy load

has remained in the dryer drum for an

extended period, creating a temporary

flat spot on the edge of the roller. The

noise should dissipate as the dryer

operates and the flat spots smooth out.

3. AIR FLOW SYSTEM Your dryer is equipped with a high volume air

Before operating your dryer

handling system. In some installations Read the important instructions in this

there may be some sounds associated section of the Use & Care Manual before

with air movement throughout the

operating your dryer.

dryer, including the air duct, blower,

and exhaust system. This is normal and can vary with load size and type.

WARNING

4. GAS VALVE (Gas models only.) The flow of gas is controlled by electric solenoids. During operation there may be a clicking sound as the valve opens and closes to control the gas flow.

To reduce the risk of fire, electric shock or injury to persons, read the Important Safety Information in this Use & Care Manual before operating your dryer.

5. GAS BURNER (Gas models only.) When the burner is operating, there may be sounds generated as the air flow mixes with the gas flame. This noise is normal and will only occur when the gas is ignited in the combustion tube.

41 CARE AND CLEANING

WARNING

4. Snap the filter closed and place back into the dryer.

To reduce risk of fire or serious injury to persons or property, comply with the basic warnings listed in the Important Safety Information and those listed below.
Cleaning the filter

IMPORTANT
· DO NOT open the clamshell filter beyond the hinge limit.
· ALWAYS handle the clamshell filter by the frame, not by the mesh material.

WARNING
Clean the lint filter after every load. CLEAN LINT will be displayed at the end of the cycle to remind you to remove lint from the filter. Clean the lint filter after every load. Lint build-up on the filter restricts air flow, which causes longer drying times. The filter is located at the bottom of the door opening.
Cleaning the LuxCareTM Lint Shield filter
1. Remove the filter by pulling it straight up from the dryer.
2. Press down the button on the top of the filter to open the clamshell.
3. Gently clean the lint from the filter.

Inside
· Occasionally a waxy build-up may form on the lint filter and/or moisture sensing bars from using dryer-added fabric softener sheets. To remove this build-up, wash them with warm, soapy water. Dry the filter thoroughly and replace. DO NOT operate the dryer without the lint filter in place.
· If the dryer drum becomes stained from non colorfast fabrics, clean the drum with a damp cloth and a mild liquid household cleanser. Remove cleanser residue before drying the next load.
· Before cleaning the dryer drum interior, unplug the electrical power cord to avoid electrical shock hazards.
· DO NOT use any type spray cleanser when cleaning the dryer interior. Hazardous fumes or electrical shock could occur.
· Every 18 months a qualified service professional should clean the dryer cabinet interior, lint screen housing and exhaust duct. These areas can collect lint and dust over time. An excessive amount of lint build-up could result in inefficient drying and possible fire hazard.
Outside
· Clean the dryer cabinet with mild soap and water. Never use harsh, gritty or abrasive cleansers.
· If the cabinet becomes stained, clean with diluted chlorine bleach (1 part bleach to 8 parts water). Rinse several times with clear water.
· Remove glue residue from tape or labels with a mixture of warm water and mild detergent. Or, touch residue with the sticky side of the tape or label.

42 CARE AND CLEANING

· When cleaning chrome parts, it is best to use only a damp cloth.
· Before moving the dryer, place a strip of cardboard or thin fiberboard under the front leveling legs to prevent damage to the floor.

thread the fittings. DO NOT allow the hose to rub against sharp objects. Always ensure the hose fitting rubber gasket is installed and free from water leaks when water pressure is applied.

WARNING
FIRE HAZARD
A clothes dryer produces combustible lint. The dryer must be connected to an outdoor exhaust. Regularly inspect the outdoor exhaust opening and remove any accumulation of lint around the opening and in the surrounding area.

Rubber Washers Must Be Present

USE ONLY NEW HOSES

Limited use, vacation, and away from home

IMPORTANT
DO NOT store or place laundry products on top of dryer at any time. They can damage the finish or controls. It is recommended to keep laundry products in the storage drawer between cycles if installed on a pedestal.

CAUTION
Your dryer should be operated ONLY when you are home. If you are away from home or not using your dryer for extended periods of time, follow these steps:
1. Turn off the water supply to dryer (steam models only) to avoid water leaks due to water pressure surges and unforeseen occurrences in the water supply.
2. Disconnect or unplug the electrical power to the dryer.

Reconnecting water supply and electrical

Water inlet hose
inspection (steam models only)
Periodically inspect all water inlet hoses for water leaks, wear, cuts, corrosion and bulges. Replace all hoses, if any sign of the above is visible. All hoses should be replaced every 5 years to reduce the risk of hose failures. When replacing hoses, refer to the installation instructions for proper installation. DO NOT overtighten or cross

IMPORTANT
When reinstalling the dryer after disconnecting the water supply lines (steam models only) and electrical power, please follow the steps below:
1. Review the installation instructions provided with the dryer to ensure the appliance is level and the water and electrical power supply is properly connected.
2. Ensure the water lines are flushed of debris, prior to connecting the water lines to the dryer inlet.
3. Check for water leaks and replace supply hoses if needed.

43 TROUBLESHOOTING

Common drying inquiries

Many drying problems involve poor cleaning results, poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory drying results, follow these suggestions provided by The Soap and Detergent Association.

PROBLEM POSSIBLE CAUSES

SOLUTIONS

PREVENTIVE MEASURES

Greasy, oily stains

· Fabric softener sheet

· Rub fabric softener · Add a few bath towels to small

stains with bar

loads for proper tumbling.

soap. Rinse and rewash.

· Some "silk-like" fabrics should be air dried.

· Use proper drying temperature.

· Place fabric softener sheet on top of load before starting the dryer.

Lint

· Overloading · Reduce load

· DO NOT overload dryer.

· Overdrying causes static electricity
· Lint screen not clean when cycle began
· Lint is attached to "pills"

size and rewash using liquid fabric softener in the final rinse.
· Or, add a fabric softener sheet and tumble without heat.
· Use lint brush or

· Use fabric softener in washer or dryer to reduce static electricity.
· Remove items when they are slightly damp to avoid overdrying.
· Check that lint filter is clean and in place.

roller to remove lint.

Pilling (fibers · Overdrying break off, ball up and cling to fabric)

· Use a lint brush or shaver to remove pills.

· Use fabric softener to lubricate fibers.
· When ironing, use spray starch or fabric finish on collars and cuffs.
· Turn items inside out to reduce abrasion.

Shrinking

· Temperature too high
· Overdrying

· Irreversible condition.

· Follow fabric care label directions.
· If shrinking is a concern, check load often.
· Remove items while slightly damp and hang or lay flat to complete drying.
· Block knits into shape.

Wrinkling

· Overloading
· Leaving items in dryer after cycle ends

· Reduce load size and tumble at medium or low heat for 5-10 minutes.
· Remove items immediately. Hang or fold.

· DO NOT overload dryer.
· Remove items as soon as cycle ends.

Isolated wet · Low water

· Check water line

spots on

pressure in

pressure.

fabrics after home is not

completed sufficient

Steam cycle to atomize

incoming water

during steam

cycle

· Ensure water line pressure is minimum of 20 psi. DO NOT exceed 120 psi.

44 TROUBLESHOOTING

Before calling
Before calling for service, review this list. It may save both time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this dryer.

PROBLEM Dryer does not start.
LED displays " ". Dryer runs but won't heat.

POSSIBLE CAUSES
· Electrical power cord is not securely plugged in or plug may be loose.
· House fuse blown or circuit breaker tripped.
· Action of pressing start button on "touch screen" style console not recognized
· Thermal limiter tripped.
· Delay time inadvertently activated.
· Door may be open. Unit will not operate with door open.
· Difficult load to dry.
· Dryer has been programmed to temporarily perform a repeating demo cycle.
· There are 2 house fuses in the dryer circuit. If 1 of the 2 fuses is blown, the drum may turn but the heater will not operate (electric models).
· Gas supply valve is not open (gas models).
· Dryer does not have enough air supply to support the burner flame (gas models).
· LP gas supply tank is empty or there has been a utility interruption of natural gas (gas models).

SOLUTIONS · Make sure the plug fits tightly in wall
outlet.
· Reset circuit breaker or replace fuse. · Make sure electrical line is not
overloaded and the dryer is on a separate circuit. · Press start button with bare fingertip.
· Call authorized service person for replacement.
· Ensure delay time not activated.
· Ensure door is closed.
· Select Dry Boost option · Reset the unit back to factory default
settings as described earlier.
· Replace fuse.
· Check to make sure supply valve is open. Refer to the installation instructions provided with the dryer.
· See the Installation sections of this manual.
· Refill or replace tank. Dryer should heat when utility service is restored.

45 TROUBLESHOOTING

PROBLEM POSSIBLE CAUSES

SOLUTIONS

Drying cycle takes too long, outside of the dryer feels too hot or smells hot.

· Lint filter is clogged with lint.
· Exhaust duct requirements have not been met.
· Electric dryer is connected to a 208 volt circuit.
· Drying procedures have not been followed.
· Outside exhaust hood or exhaust duct may be clogged or restricted.
· High humidity.

· Make sure all lint has been removed from the dryer lint filter before starting each cycle.
· Exhaust duct must be at least 4 inches in diameter and made of rigid or semirigid metal.
· When in place, the duct must not exceed length listed in the installation instructions.
· Drying time will be 20% longer than drying on a 240 volt circuit.
· See Operating Instructions.
· Clean out any obstruction. · Use a dehumidifier near the dryer.

Excess moisture in drum between cycles.

· Exhaust damper stuck open or not present.

· Fix or clean the damper, or install new one.

Excessive wrinkling.

· Dryer is overloaded.
· Items left in dryer too long. · Insufficient sorting of items. · Drying temperature too high. · Drying load is very small.

· DO NOT overload. See Operating Instructions.
· Remove items as soon as cycle ends. · See Operating Instructions. · Follow fabric care label instructions. · Add two or three larger items.

Scratching or chipping of the drum finish.

· Foreign objects such as coins, pins, clips or buttons are inside the dryer.*
· Permanently attached items such as belt buckles, zippers and fasteners may be hitting the inside of the drum.*

· Always remove foreign objects from pockets before laundering. Remove objects from drum and restart dryer.
· It may be necessary to sew a scrap of material securely around ornaments before drying to prevent scratching and damage to the dryer.

* Drum damage caused by foreign objects or permanently attached items is not covered by the warranty.

46 LIMITED WARRANTY
For the applicable warranty period as set forth below, as measured from your original date of purchase, Electrolux will repair or replace any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
Warranty Periods: · All parts -- One year including labor. In addition, your appliance is covered by a one year, parts only,
limited warranty. During the 2nd year from your original date of purchase, Electrolux will pay for parts needed for this appliance that have proven to be defective in materials or workmanship when your appliance is installed, used, and maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following: 1. Products with original serial numbers that have been removed, altered or cannot be readily determined. 2. Product that has been transferred from its original owner to another party or removed outside the USA or Canada. 3. Rust on the interior or exterior of the unit. 4. Products purchased "as-is" are not covered by this warranty. 5. Products used in a commercial setting. 6. Service calls which DO NOT involve malfunction or defects in materials or workmanship, or for appliances not in
ordinary household use or used other than in accordance with the provided instructions. 7. Service calls to correct the installation of your appliance or to instruct you how to use your appliance. 8. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which
are not a part of the appliance when it is shipped from the factory. 9. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs, handles,
or other cosmetic parts. 10. Pickup and delivery costs; your appliance is designed to be repaired in the home. 11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or
mileage expense for service calls to remote areas, including the state of Alaska. 12. Damages to the finish of appliance or home incurred during transportation or installation, including but not limited
to floors, cabinets, walls, etc. 13. Damages caused by: services performed by unauthorized service companies; use of parts other than genuine
Electrolux parts or parts obtained from persons other than authorized service companies; or external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. Service under this warranty must be obtained by contacting Electrolux at the addresses or phone numbers below. This warranty only applies in the USA, Puerto Rico and Canada. In the USA and Puerto Rico, your appliance is warranted by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice.

USA 1-877-435-3287 Electrolux Home Products, Inc., North America 10200 David Taylor Drive Charlotte, NC 28262

Canada 1-800-265-8352 Electrolux Canada Corp. 5855 Terry Fox Way Mississauga, Ontario, Canada
L5V 3E4

A20448901 (March 2021)

electroluxappliances.com

References

Home Appliances: Kitchen Appliances, Washers & Dryers | Electrolux

Adobe PDF Library 15.0 Adobe InDesign 16.1 (Windows)
