User Guide for Jeep models including: 2022 Wagoneer
For additional information on any of the topics in this publication, please refer to your Owner’s Manual. WS QSG EN USC BA First Edition Air Bag Electronic Throttle Control (ETC) Vehicle Security Air Suspension Entry/Exit Indicator Electronic Park Brake Low Fuel Service Active Lane Management TOW/HAUL Battery Charge Oil Temperature Engine ...
Open the liftgate fully, then manually pull down or push up to the desired height. 1. Activation Zone. HANDS. -FREE LIFT. GA. TE & FOLD Y.
QUICK START GUIDE Driver Seat Controls HomeLink® Buttons Cruise Control ON/OFF & Buttons Volume Light Controls Instrument Cluster Display Control Buttons Drive Mode Selector VEHICLE OVERVIEW Overhead Console Tune/Browse Passenger Screen Display Passenger Seat Controls Climate Controls Front Comfort & Convenience Display Air Suspension Control GARAGE DOOR OPENER 1 While the car is ON, hold the handheld garage door transmitter 1-3 inches from the HomeLink® button you want to program in the vehicle. 2 Push and hold both the HomeLink® button being programmed and the button on the garage door transmitter. TO ERASE ALL SET CHANNELS: Push and hold the two outside HomeLink® buttons for 20 seconds until the orange indicator flashes. An individual channel cannot be erased. LINK YOUR GARAGE DOOR ? ROLLING OR NON-ROLLING? Check your garage door opener motor in your garage for a "LEARN" or "TRAIN" button by the hanging antenna. If you have one of these, you have a Rolling Code garage door opener. For Non-Rolling Code garage door openers, watch for the indicator light 3 to go constant. For Rolling Code garage door openers, watch for the indicator light to go from a slow blink to blinking rapidly. 4 For Rolling Code garage door openers only, firmly push and release the "LEARN" or "TRAIN" button on your garage door opener motor in your garage, then push the HomeLink® button in your vehicle for two long presses. 5 If the programming was successful, your garage door should open and close with your chosen HomeLink® button. NEED ASSISTANCE? 1-800-355-3515 CONNECTED SERVICES WITH CONNECTED SERVICES YOU CAN... Lock Your Vehicle Unlock Your Vehicle Remote Start Your Vehicle Cancel Remote Start Activate Your Horn HOW TO ACTIVATE YOUR REMOTE SERVICES 1 Press "Apps" on the touchscreen 2 Press "Activate Services" 3 Press "Activate Now" 4 There are two ways to activate: via email or via an agent. On the next page, you can either enter your name and email, or press "Call Care" to directly speak with an agent. NOTE: If you previously were registered at the dealership, enter your email and PIN to activate services. GET PERSONALIZED BY REGISTERING MOPAR® YOUR WAY CREATE YOUR OWNER'S PROFILE TODAY! Get 24/7 Access To Everything You Need Custom vehicle dashboard Access to your vehicle's Owner's Information Schedule dealership service with ease Obtain special offers on Mopar® services ! Registration is simple. Scan the QR code below and provide your email address to get started. View maintenance records** Mobile vehicle commands** ** Requires an active Uconnect Connected Services subscription *Canadian residents are not required to create a profile, as one is created when a Uconnect Connected Services account is activated. HEAD UP DISPLAY (HUD) HOW TO CUSTOMIZE HUD: 1 Select "Settings" in the Instrument Cluster with the Up or Down Arrow button on the steering wheel. 2 Select "HUD" with the Right or Left Arrow button on the steering wheel. Press "OK". 3 Adjust available Settings like Content & Layout, Display Height, and Brightness. Press "OK" to change the setting. NOTE: HUD will appear in your windshield TIP: Select from four available options: Standard, Simple, Advanced, and Custom. Instrument Cluster Display Control Buttons HEAD UP DISPLAY & CRUISE CONTROL CRUISE CONTROL SYSTEMS ACC Distance Increase ACC On/Off Cancel Set Speed or Increase Speed Cruise Control On/Off Resume The Cruise Control system will hold your vehicle's speed when you take your foot off of the accelerator. The Adaptive Cruise Control (ACC) system will adjust the set speed in order to maintain a set distance from the vehicle in front of yours. ACC Distance Decrease Set Speed or Decrease Speed TIP: The ACC distance setting appears in the instrument cluster display PAIR A PHONE 1 Make sure Bluetooth® is enabled on your mobile device. 2 With the vehicle in the ACC or ON/RUN position, press the Phone button in the vehicle's touchscreen menu bar. 3 Press "Device Manager" and then "Add Device". Follow the prompts on your phone and on the touchscreen. CONNECT YOUR APPS Connect your smartphone to the media USB port or pair your smartphone within Device Manager. The Android AutoTM or Apple CarPlay® icon will replace the phone icon on the touchscreen. If the Android AutoTM app was not previously downloaded, it will download the first time you plug in your device. Apple CarPlay® is only compatible with iPhone5® or later and requires Siri being enabled in Settings. PHONE PAIRING, KEY FOB & AMBIENT LIGHTING MULTICOLOR AMBIENT LIGHTS YOU CAN CHANGE THE COLOR OF YOUR AMBIENT LIGHTS! Navigate to the Ambient Color 1 Personalization setting within the Uconnect system. This setting redirects to a new menu. 2 Select one of five colors for the ambient lighting in the cabin. Select a color for Zone 1 by choosing one of the rectangles on the top row of the screen. The second set of rectangles adjust the color for Zone 2. TIP: The selected rectangles will be filled with color, while the others have outlines only. KEY FOB LED Indicator Unlock Remote Start Remote Lowering Lock Power Liftgate Panic Your key fob supports Passive Entry, Keyless Enter 'n GoTM, and more! UCONNECT 5/5 NAV Customize your Home page by adding shortcut widgets Listen to radio stations or play music from your USB or Bluetooth® device Utilize your manual or automatic climate controls through your comfort settings Enter an address or search from multiple points of interest to navigate Pair your Bluetooth®-enabled phone and make hands-free calls Access radio and vehicle settings Swipe down to customize Profile options Press and drag an icon to rearrange Access the available apps installed on your Uconnect system RADIO SET-UP AND PASSENGER SCREEN FRONT PASSENGER SCREEN This screen provides the passenger access to Radio, Rear Seat Entertainment, HDMI, and Navigation functions. It is located on the passenger side of the vehicle, above the glove compartment. Push the Power button under the Front Passenger Screen or under the Controls tab within the Uconnect system. The Passenger Screen Permissions menu within "Settings" will activate/deactivate features within the Passenger Screen. FRONT PASSENGER SCREEN HEADPHONE PAIRING 1 In Device Manager, press "Add Device" or "Pair Bluetooth® Headphones" 2 Press "Search For Headphones" 3 Select the Headphones you wish to pair and follow the on-screen instructions Screen Off Unpair Headphones Brightness Headphone Volume Power Off Mute Button SEAT CONTROLS 20-WAY POWER FRONT SEATS 1 2 3 7 4 65 ADJUST YOUR FRONT SEATS 1 FRONT HEAD RESTRAINT ADJUST Adjust the head restraint up, down, forward or rearward 2 POWER LUMBAR Press the + or -- switch to bring up the Seat menu. Adjust the lumbar support in/out or up/down BACK/THIGH BOLSTER Press the + or -- switch to bring up the Seat menu. Extend or retract the seatback and seat cushion bolsters 3 MEMORY SETTINGS PROFILE Save your seat preferences and more to Memory Profile 1 or 2 4 SEAT CUSHION Adjust the seat cushion up, down, forward, or rearward, or tilt the angle of the cushion up or down 5 CUSHION EXTENDER Extend or retract the seat cushion 6 POWER MASSAGE Turn on and adjust the power massage settings to high, medium, and low, and choose from five massage types 7 UPPER AND LOWER SEATBACK Adjust the angle of the upper or lower seatback SECOND & THIRD ROW SEATS ADJUST, FOLD, AND UNFOLD YOUR REAR SEATS Rear Seat Power Folding Switch A one-touch power folding seat switch is located in the right rear trim panel inside the cargo area. Second Row Left Side Fold Second Row Right Side Fold Third Row Left Side Fold/Unfold Third Row Right Side Fold/Unfold Third Row Power Recline Switch Adjust the third row seatback angle forward/rearward for occupant comfort. This switch is located on the trim panel next to the seat. HANDS-FREE LIFTGATE & FOLD YOUR REAR SEATS HANDS-FREE LIFTGATE OPEN YOUR LIFTGATE WITHOUT PRESSING A BUTTON TO SET AN OPENING HEIGHT: 1 Open the liftgate fully, then manually pull down or push up to the desired height. 2 Push and hold the liftgate close button, located on the left side trim panel inside the cargo area, for three seconds. An audible chime will sound. ? LIFTGATE NOT OPENING? Use a straight in and out kicking motion within the activation zone. A sweeping motion under the activation zone can also be used for hands-free activation. Activation Zone NOTE: The Hands-Free Liftgate feature can be turned on and off within the Uconnect system. REAR SEAT ENTERTAINMENT GET STARTED: You will be prompted to pair the remote, connect to a network, and sign into an Amazon account. You can also enable parental controls. With Uconnect Rear Seat Entertainment, you can stream movies and music and much more! 1 Push the Power button on the remote or swipe on either of the Rear Touchscreens to turn on the screen 2 Select from one of the available apps or source inputs, like HDMI or USB, through the Amazon Fire TV interface KNOW & GO Download the Know & Go* app to your smartphone to discover more about the exciting features on your new Wagoneer/Grand Wagoneer using augmented reality, a features library, and push notifications. AUX Port HDMI Port USB C Charging Port REAR SEAT ENTERTAINTMENT GET TO KNOW YOUR REMOTE Power Button Home Button Alexa Button Five Way Navigation Control Playback Control Buttons REAR SEAT ENTERTAINMENT HEADPHONE PAIRING 1 Select "Settings" from the top menu on the Home screen 2 Select "Controllers & Bluetooth® Devices" 3 Select "Other Bluetooth® Devices" 4 Follow the on-screen prompts to pair your headphones Settings Button Alexa Button DID YOU KNOW? You can download games from the Apps menu to play on your rear touchscreens. WARNING & INDICATOR LIGHTS Air Bag Electronic Throttle Control (ETC) Night Vision Pedestrian Detect Transmission Temperature Air Suspension Aerodynamic Height Auto HOLD! Fault WFaorrnwinargd(FCCoWllis)ioOnff PeNdeisgthritaVn iDsioetnect Service Forward Collision Warning (FCW) Active Lane Management Front Fog Stop/Start Active Hill Descent Control (HDC) Battery Charge Engine Temperature Oil Pressure Vehicle Security Air Suspension Entry/Exit Indicator Electronic Park Brake Low Fuel Oil Level Sensor Fault Service Stop/Start System Adaptive Cruise Control (ACC) Set With Target Night Vision Active Turn Signal Rear Seat Unoccupied Brake Hood Open Oil Temperature 4WD Low Air Suspension Off-Road 1 Electronic Stability Control (ESC) Active Low Washer Fluid Service 4WD Tire Pressure Monitoring System Adaptive Cruise Control (ACC) Set Without Target Parking /Headlights On Active Lane Management Selec-Speed Control Door Open Liftgate Open Rear Seat Belt Reminder Active Lane Management Air Suspension Off-Road 2 Electronic Stability Control (ESC) OFF NEUTRAL Service Active Lane Management TOW/HAUL Auto HOLD! Rear Seat Belt Fastened Adaptive Cruise Control (ACC) Ready High Beam Your vehicle may be equipped with different features than shown in this guide. For additional information on any of the topics in this publication, please refer to your Owner's Manual. ©2021 FCA US LLC. All Rights Reserved. Tous droits réservés. Wagoneer is a registered trademark of FCA US LLC. Wagoneer est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google. Electric Power Steering (EPS) Fault ANniigmhatlVDiseitoenct Seat Belt Reminder Air Suspension Active Anti-Lock Brake System Engine Check/ Malfunction Indicator ANniigmhatlVDiseitoenct Service Adaptive Cruise Control (ACC) Towing Hook Breakdown Cruise Control SET Sport Mode Cruise Control Ready Night Vision Suppressed WS_QSG_EN_USC_BA First EditionAdobe PDF Library 15.0
