User Guide for Honeywell Home models including: evohome, Smart Multi zone Thermostat
follow the bind instruction for each device in this manual. In this section Powering up your evohome Controller 9 Language selection and WiFi configuration 10 Set-up the evohome controller for your system 11. evohome Installation Guide 9 First, power up the evohome Controller
Refer to boiler or Heat Pump instruction to locate the room thermostat ... evohome Controller will give you on-screen instructions to.
follow the bind instruction for each device in this manual. In this section Powering up your evohome Controller 9 Language selection and WiFi configuration 10 Set-up the evohome controller for your system 11
evohome EN Installation Guide Icon key evohome Controller (ATC928) evohome Controller Wall Bracket (ATF600) evohome Controller Table Stand (ATF800) Radiator Controller (HR92) Radiator Controller (HR91) Radiator Controller (HR80) * Obsolete but compatible Wireless Relay Box (BDR91) Wireless OpenTherm Bridge (R8810) Underfloor Heating Controller (HCE80 or HCC80) Mixing Valve Controller (HM80) * Obsolete but compatible Single Zone Thermostat (T87RF) Room Temperature Sensor (HCW82) * Obsolete but compatible Room Temperature Sensor (HCF82) Digital Room Thermostat (DTS92) Wireless Cylinder Thermostat Transceiver (CS92) Wireless Cylinder Thermostat Strap-on Sensor (CS92) Wireless Cylinder Thermostat Insertion Sensor (CS92) Wireless Relay Box (BDR91) Hot Water Kit (ATF500DHW) evohome Installation Guide 1 Thanks for choosing evohome. evohome means more comfort, and more control of the heating system. It's simple to install and easy to use. Follow these instructions to set up the evohome system. Devices that need to be connected to the mains electricity supply should be installed by a competent person. Before you start Make sure you have all the devices you need for your system. If you used our `Design your evohome system' guide, match each device to the room or zones in your plan. It's a good idea to carry out all the mains electrical and other wiring work first. In this guide Step 1: Wire up the heating system 3 Step 2: Set up your evohome Controller 8 Step 3: Power up and bind devices 12 Step 4: System test 29 Configuration and modification 36 Appendix 39 2 Step 1: Wire up the heating system Step 1: Wire up your heating system Connect all mains powered devices to the heating system You have... a Connected Pack + Un-bound devices You have... an un-bound evohome Controller + Un-bound devices You have... a Connected Pack + No additional devices Step 2: Set up your evohome Controller Power up the evohome Controller, connect to a WiFi network and follow the on-screen instructions for your system Go to Installer Menu Go to Guided Configuration Go to Home screen Step 3: Power up and bind devices Power up all devices, including the battery powered ones, and bind them to the evohome Controller Step 4: Test the system Check that all the devices are working properly evohome Installation Guide 3 Step 1: Wire up the heating system evohome communicates using wireless on a robust 868Mhz signal that is unaffected by common remote controls or WiFi. Some devices need mains power or to be connected to external equipment and it's best to wire up these items first to simplify the binding process later in the setup. The evohome controller will give on screen instructions when these should be powered up. Before you power up your evohome Controller and install the radiator controllers, it's best to install any devices which are mains powered or need specific installation. In this section Wireless Relay Box (BDR91) 4 Wireless Cylinder Thermostat (CS92) 5 Mixing Valve Controller (HM80), Underfloor Heating Controller (HCE80/HCC80), Opentherm Bridge (R8810) 7 4 Step 1: Wire up the heating system Wireless Relay Box (BDR91) ! Turn off at mains and isolate the supply before starting If you're fitting a Wireless Relay Box (BDR91) to your boiler, zone valve or Sundial valve, or as a Heat/cool changeover device. Mount the Wireless Relay Box on a non-metal surface at least 30cm from your boiler, other wireless devices or metallic large metal objects Release the clip on the bottom to open the front cover Follow the wiring diagram to connect the Wireless Relay Box to your boiler's thermostat terminals, zone valve or sundial valve, and to the mains electricity supply Replace the cover Refer to boiler or Heat Pump instruction to locate the room thermostat terminals, determine if the boiler required a permanent live supply. BOILER OR Heat Pump BOILER MINIMUM 30CM REPLACE FRONT COVER evohome Installation Guide 5 Wireless Cylinder Thermostat (CS92) If you're fitting a Wireless Cylinder Thermostat (CS92) You will need to install the CS92 Transceiver and only one of the two sensors (CS92 Strap-on Sensor or CS92 Insertion Sensor). To fit the CS92 Strap-on Sensor Cut away a section of cylinder insulation slightly larger than the sensor unit Clean the exposed cylinder surface Place the sensor on the cylinder surface and secure it using the fixing strap cut the strap to size if it's too long Install the CS92 Transceiver in a suitable location close enough for the cable from the sensor to reach Connect the cable from the sensor to the CS92 Transceiver Position the sensor from one quarter to a third of the way up the cylinder. Wire to CS92 Transceiver 80MM 45MM 1/4 1/3 TOTAL HEIGHT MINIMUM 30CM AxB yC AxB yC 6 Step 1: Wire up the heating system Wireless Cylinder Thermostat (CS92) continued ! If this sensor is used in an unvented hot water storage application, the cylinder manufacturer's instructions must be followed to ensure compliance with all safety regulations. If in doubt, contact the cylinder manufacturer. ! DO NOT remove existing thermostats or high limit cut off devices from thermal stores, but the sensor may be fitted in the same pocket. To fit the CS92 Insertion Sensor Fit in the cylinder immersion well with suitable fittings to provide strain relief and prevent accidental removal If the sensor doesn't fit tightly in the immersion well fill the space with heat-conductive compound to ensure maximum heat transfer Install the CS92 Transceiver in a suitable location close enough for the cable from the sensor to reach Connect the cable from the sensor to the CS92 Transceiver. The wires are polarity free, so can be connected in any order. Provide appropriate strain relief to this end of the sensor cable as well. Wire to CS92 Transceiver AxB yC AxB yC evohome Installation Guide 7 Mixing Valve Controller (HM80), Underfloor Heating Controller (HCE80/HCC80), OpenTherm Bridge (R8810) If you're fitting a Mixing Valve Controller (HM80), Underfloor Heating Controller (HCE80/HCC80), OpenTherm Bridge (R8810) Refer to the installation instructions supplied with each device 8 Step 1: Wire up the heating system Step 2: Set up your evohome Controller The evohome Controller has a guided configuration process to help you set up the zones for a single type of system. For mixed systems (i.e. Under Floor Heating zones plus Radiator zones) use Guided Configuration for the larger system then "Add Zones" in the installer menu. To add a stored hot water system use the guided configuration Stored Hot Water option in the installer menu. Some Heat Pumps can cool as well as heat, only select the cooling option if it is available. The following instructions cover the full configuring process for a zone, but if you are using Guided Configuration your evohome Controller will give you on-screen instructions to bind the other components to the evohome Controller just follow the bind instruction for each device in this manual. In this section Powering up your evohome Controller 9 Language selection and WiFi configuration 10 Set-up the evohome controller for your system 11 evohome Installation Guide 9 ! Your evohome Controller comes with *rechargeable batteries which are pre-charged allowing you to set-up the system while off the table stand or wall bracket. Place the evohome Controller on the table stand or wall bracket for normal use. *Only use the AA rechargeable batteries provided. First, power up the evohome Controller Remove the cover, remove the battery tab and replace the cover. Place it on the table stand or wall bracket Once the batteries are fully charged, the evohome Controller can be easily removed from the table stand or wall bracket for ease of programming. After 30 minutes the evohome Controller will emit a beep to indicate that it should be replaced on the stand or wall bracket PULL TAB 10 Step 1: Wire up the heating system Language selection and WiFi configuration ! If you don't have the WiFi network details, or the homeowner doesn't require remote access you can skip the WiFi configuration and proceed with setting up the heating system. WiFi can be configured later in the SETTINGS > WIFI SETTINGS menu. Select a language for the evohome controller and connect to a WiFi network Select a language for the evohome controller user interface Follow the on-screen instructions to connect to a WiFi network. This enables automatic setting of the date and time for your location, as well as enabling remote connectivity via an Apple or Android Smartphone. · To configure WiFi you will need the home WiFi network password Instruct the homowner / user to visit getconnected.honeywellhome.com to create an account, register the evohome Controller and download the app. Select your store Total Connect Comfort Int · To create an account and register the evohome Controller the homeowner will need the MAC ID and CRC which can be found: On a label behind the front cover of the evohome Controller on screen during the WiFi set-up in the SETTINGS > WiFi SETTINGS menu after set-up has been completed evohome Installation Guide 11 Set-up the evohome controller for your system Now choose the correct option for the system you're installing: For a Connected Pack* and NO additional un-bound devices we recommended pressing `Home' then go to "Step 4: System test" on page 29. For an un-bound evohome Controller, PLUS additional un-bound devices we recommended pressing `Guided Configuration' to add the un-bound devices and follow "Step 3: Power up and bind devices" on page 12. For a Connected Pack*, PLUS additional un-bound devices we recommended pressing `Installation Menu' to add the un-bound devices and follow "Step 3: Power up and bind devices" on page 12. * A Connected Pack contains devices which are already bound to the evohome Controller. Choosing "Guided Configuration" will delete the binding from evohome Controller and will require to be bound again. The Wireless Relay Box (BDR91) in a Connected Pack is bound as a boiler controller. If you intend to use it as a Zone Valve or S-Plan/Y-Plan (Sundial) Valve controller the binding must be cleared from the Wireless Relay Box first. 12 Step 3: Power up and bind devices Step 3: Power up and bind devices If you bought a Connected Pack only -- your devices are already bound. Go to Step 4. If you bought an unbound evohome Controller, plus other un-bound devices and are using `Guided Configuration' follow the instructions on your evohome Controller screen and use this section to put the devices into binding mode. If you bought a Connected Pack, plus other un-bound devices, you need to power up all devices and then bind them to the evohome Controller using the `Installation Menu'. It may be easier to power up and bind some devices while they're close to the evohome Controller you can install them in their assigned zones later. Follow the instructions for the device(s) you're going to bind. When you bind a device to the evohome Controller the devices permanently store the connection and there should never be a need to rebind them again even after a power cut. In this section Radiator Controllers (HR91/92) 13 Wireless Cylinder Thermostat (CS92) 16 Wireless Relay Box (BDR91A or T) to control a Boiler or Heat Pump (BDR91T) 18 Wireless Relay Box (BDR91T) to act as a Heat Cool Switch 20 OpenTherm Bridge (R8810) 21 Wireless Relay Box (BDR91A or T) to control a Zone Valve 22 Underfloor Heating Controller (HCE80 or HCC80) 24 Mixing Valve Controller (HM80) 27 evohome Installation Guide 13 Radiator Controllers (HR91/92) evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display first: 1. Press and hold `Settings' for 3 seconds 2. Press the green tick 3. Press ADD ZONE 4. Type a name for the new zone and press the green tick 5. Press RADIATOR VALVE 6. If you want to control the zone temperature with the evohome Controller (which needs to be located in that zone) press YES, otherwise press NO. You must repeat these steps for each radiator controller. Power up and bind Radiator Controllers (HR91) Bind the Radiator Controllers (HR91) Remove the top cover Open the battery clip and insert the AA batteries supplied Close the clip and replace the cover Press the Binding button for 5 secs. The LED will flash amber for up to 2 mins whilst binding. Successful binding is confirmed by LED showing continuous green for 5 seconds. You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) Either press the green tick to add another radiator to the zone. Or press the red cross if you don't need to add another radiator to the zone 5 SEC 2 MIN 5 SEC 14 Step 3: Power up and bind devices Radiator Controllers (HR91/HR92) evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display first: 1. Press and hold `Settings' for 3 seconds 2. Press the green tick 3. Press ADD ZONE 4. Type a name for the new zone and press the green tick 5. Press RADIATOR VALVE 6. If you want to control the zone temperature with the evohome Controller (which needs to be located in that zone) press YES, otherwise press NO. You must repeat these steps for each radiator controller. Power up and bind Radiator Controllers (HR92) Your evohome Zone Kit Bind the Radiator Controllers (HR92) Remove the circular top cover Open the battery clip and insert the AA batteries supplied Close the clip and replace the cover Press the button once - it should say UNBOUND Press and hold the button for a further 5 seconds until it says BIND Press the button once it should say BINDING You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) The name of the allocated zone should appear on the HR92 display when you press the button 9 Either press the green tick to add another radiator to the zone. Or press the red cross if you don't need to add another radiator to the zone PRESS ONCE PRESS AND HOLD 5 SEC PRESS ONCE evohome Installation Guide 15 Install the Radiator Controllers Locate the room (zone) for the radiator controller Slide the locking mechanism to the unlock position Remove the adaptor from the bottom of the controller Unscrew the black wheel fully anti-clockwise Remove any existing control on the radiator valve Screw the white end of the adaptor on to the radiator valve Push the controller fully on to the adaptor with the screen facing towards you Slide the locking mechanism to the locked position REMOVE ROTATE 16 Step 3: Power up and bind devices Wireless Cylinder Thermostat (CS92) evohome Controller If you are NOT following GUIDED CONF IGUR AT ION follow these steps on your evohome Controller display first: 1. Press and hold "Settings" for 3 seconds 2. Press the green tick 3. Select GUIDED CONFIGURATION 4. Press STORED HOT WATER CONFIGURATION 5. Press the green tick To control a stored hot water system you first need to bind the CS92 Transceiver and then bind the Wireless Relay Box (BDR91) that is controlling the hot water valve. Power up and bind the CS92 Transceiver On the CS92 Transceiver Remove the CS92 Transceiver cover, pull out the battery tab and replace the cover On the CS92 Transceiver press and hold the button for 5 seconds. The green light should come on and the red light should flash Press the button again You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) Choose the correct hot water valve type for the system you're installing and follow the on screen instructions PULL TAB PRESS AND HOLD 5 SEC PRESS ONCE evohome Installation Guide 17 ! You may need to refer to the wiring diagrams in the Appendix ! The Wireless Relay Box in a Connected Pack is bound as a boiler controller. If you intend to use it as a S-Plan/Y-Plan Valve controller the binding must be cleared from the Wireless Relay Box first as described in step 1. To bind the Wireless Relay Box (BDR91A or T) controlling the hot water valve On the Wireless Relay Box, press and hold the button for 15 seconds (until the red LED blinks rapidly) to clear any previous binding data Press and hold the button again for 5 seconds (until the red LED blinks slowly) On the evohome Controller press the green bind button You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) PRESS AND HOLD 15 SEC PRESS AND HOLD 5 SEC 18 Step 3: Power up and bind devices Wireless Relay Box (BDR91) evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display first: 1. Press and hold `Settings' for 3 seconds 2. Press the green tick 3. Press SYSTEM DEVICES 4. Press APPLIANCE CONTROL 5. Press WIRELESS RELAY Power up and bind a Wireless Relay Box (BDR91A or T) to control a boiler or buffer tank secondary pump. Make sure the Wireless Relay Box (BDR91A or T) is wired to the boiler and powered up. To bind the Relay Box Press and hold the button for 15 seconds (until the red LED blinks rapidly) to clear any previous binding data Press and hold the button again for 5 seconds (until the red LED blinks slowly) On the evohome Controller press the green bind button You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) PRESS AND HOLD 15 SEC PRESS AND HOLD 5 SEC evohome Installation Guide 19 evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display first: 1. Press and hold `Settings' for 3 seconds 2. Press the green tick 3. Press SYSTEM DEVICES 4. Press APPLIANCE CONTROL 5. Press Heat Pump RELAY ! The Wireless Relay Box in a Connected Pack is bound as a boiler controller. If you intend to use it to directly control a Heat Pump or as a heat/cool changeover the binding must be cleared from the Wireless Relay Box first as described in step 1. Power up and bind a Wireless Relay Box (BDR91T) to directly control a Heat Pump Make sure the wireless relay box (BDR91T) is wired to the appliance and powered up. To bind the Relay Box Press and hold the button for 15 seconds (until the red LED blinks rapidly) to clear any previous binding data Press and hold the button again for 5 seconds (until the red LED blinks slowly) On the evohome Controller press the green bind button You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) ! You may need to refer to the hydronic diagrams in the Appendix. ! If you are controlling a Heat Pump directly or heat/cool changeover use a BDR91T PRESS AND HOLD 15 SEC PRESS AND HOLD 5 SEC 20 Step 3: Power up and bind devices Wireless Relay Box (BDR91) continued evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display first: 1. Press and hold `Settings' for 3 seconds 2. Press the green tick 3. Press GUIDED CONFIG 4. Select HEAT/COOL CONFIG 5. Select SYSTEM TYPE as HEAT/COOL ! The Wireless Relay Box in a Connected Pack is bound as a boiler controller. If you intend to use it to directly control a Heat Pump or as a heat/cool changeover the binding must be cleared from the Wireless Relay Box first as described in step 1. ! If you are controlling a Heat Pump directly or heat/cool changeover use a BDR91T Power up and bind a Wireless Relay Box (BDR91T) to work as a heat cool change over device. Make sure the wireless relay box (BDR91T) is wired to the appliance and powered up. To bind the Relay Box Press and hold the button for 15 seconds (until the red LED blinks rapidly) to clear any previous binding data Press and hold the button again for 5 seconds (until the red LED blinks slowly) On the evohome Controller press the green bind button You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) PRESS AND HOLD 15 SEC PRESS AND HOLD 5 SEC evohome Installation Guide 21 OpenTherm Bridge (R8810) evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display first: 1. Press and hold "Settings" for 3 seconds 2. Press the green tick 3. Press SYSTEM DEVICES 4. Press APPLIANCE CONTROL 5. Press OPENTHERM BRIDGE Power up and bind an OpenTherm Bridge (R8810) to control an OpenTherm boiler Make sure the OpenTherm (R8810) is wired to the Zone Valve and powered up. To bind the OpenTherm Bridge Press and hold the power button for 15 seconds(until the red LED blinks rapidly) to clear any previous binding data Press and hold the button again for 5 seconds (until the red LED blinks slowly) On the evohome controller press the green bind button You should receive a SUCCESS message on the evohome controller (if not go back and re-bind) PRESS AND HOLD 15 SEC PRESS AND HOLD 5 SEC 22 Step 3: Power up and bind devices Wireless Relay Box (BDR91) to control a Zone Valve evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display first: 1. Press and hold "Settings" for 3 seconds 2. Press the green tick 3. Press ADD ZONE 4. Type a name for the new zone and press the green tAick 5. Press ZONE VALVES ! All of the remote room sensors will automatically exit from their binding menu after a short period. Power up and bind a Wireless Relay Box (BDR91A or T) to control a Zone Valve Make sure the Wireless Relay Box (BDR91) is wired to the Zone Valve and powered up. If you want to control the zone temperature with the evohome Controller (the evohome Controller needs to be located in that zone) press YES, otherwise press NO and bind a sensor either Digital Room Thermostat (DTS92), Single Zone Thermostat (T87RF), or Room Temperature Sensor (HCW82/HCF82). To bind the Digital Room Thermostat (DTS92) Press and hold the power button for 2 seconds to put the unit into standby Press the up and down arrows together for 3 seconds it should say INst Press the down arrow it should say COnt Press the up arrow three times it should say CLr Press the power button once to clear any previous binding data Press the up arrow it should say COnt Press the power button once to send the binding signal to the evohome Controller You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) To bind the Single Zone Thermostat (T87RF) Press and hold on the left touch zone (just below and to the left of the display) for approximately 10 seconds until a flashing 'Bo' is displayed Turn the dial clockwise until a flashing 'Co' is displayed Press the left touch zone once to send the binding signal to the evohome Controller You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) evohome Installation Guide 23 To bind the Room Temperature Sensor (HCW82 or HCF82) Press the bind button on the bottom right hand corner of the unit once. The red LED light will flash You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) ! The Wireless Relay Box in a Connected Pack is bound as a boiler controller. If you intend to use it as a Zone Valve controller the binding must be cleared from the Wireless Relay Box first. Then, on the Wireless Relay Box (BDR91) Press and hold the button for 15 seconds (until the red LED blinks rapidly) to clear any previous binding data Press and hold the button again for 5 seconds (until the red LED blinks slowly) On the evohome Controller press the green bind button You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) PRESS AND HOLD 15 SEC PRESS AND HOLD 5 SEC 24 Step 3: Power up and bind devices Underfloor Heating Controller (HCE80 or HCC80) evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display once the underfloor heating controller and sensors have been fitted: 1. On the evohome Controller press and hold "Settings" for 3 seconds 2. Press the green tick 3. Press ADD ZONE 4. Type a name for the new zone and press the green tick 5. Press UNDERFLOOR HEATING 6. You need to install a sensor (HCW82, HCF82, DTS92) in each zone controlled by the underfloor heating controller and bind it to the evohome Controller. You need to repeat this process for every zone that uses underfloor heating. ! Make sure the zone you're adding on the evohome Controller corresponds to the correct underfloor heating zone. Power up and bind an Underfloor Heating Controller (HCE80 or HCC80) If you want to control the zone temperature with your evohome Controller (the evohome Controller needs to be located in that zone) press YES, otherwise press NO and bind a sensor either Digital Room Thermostat (DTS92), Single Zone Thermostat (T87RF), or Room Temperature Sensor (HCW82/HCF82) To bind the Digital Room Thermostat (DTS92) Press and hold the power button for 2 seconds to put the unit into standby Press the up and down arrows together for three seconds it should say INst Press the down arrow it should say COnt Press the up arrow three times it should say CLr Press the once to clear any previous binding data Press the up arrow it should say COnt Press the once to send the binding signal to the evohome Controller You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) To bind the Single Zone Thermostat (T87RF) Press and hold on the left touch zone (just below and to the left of the display) for approximately 10 seconds until a flashing 'Bo' is displayed Turn the dial clockwise until a flashing 'Co' is displayed Press the left touch zone once to send the binding signal to the evohome Controller You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) evohome Installation Guide 25 ! All of the remote room sensors will automatically exit from their binding menu after a short period. To bind the Room Temperature Sensor (HCW82 or HCF82) Press the bind button on the bottom right hand corner of the unit once. The red LED light will flash You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) ! If you have a Heat Pump that can cool as well as heat, enable the cooling mode in the HCE80 and bind a cooling setpoint. ! Enable the Evotouch cooling function before binding the HCE80. Enabling cooling in the Underfloor Heating Controller (HCE80 or HCC80) If you enable cooling, it will allow a seperate cooling setpoint to be bound to each zone. You should first select heat/cool or cooling in the Evotouch GUIDED CONFIG in COOLING CONFIGURATION Press and hold the HCE80 MODE button for 4 sec. The LED will show green for cooling enabled, red for heating only. You can switch between the two by pressing the button. When finished press the MODE button. 26 Step 3: Power up and bind devices Underfloor Heating Controller (HCE80 or HCC80) continued ! There are two versions of HCE80/HCC80, newer versions have a simplified single stage bind process while older versions have a two stage bind process. Note the colour of the flashing zone light (GREEN or RED) and follow the instructions for that version. Put a tick next to the version for future reference. Binding to the underfloor controller Press and hold the bind button until the bind light turns solid YELLOW and the zone number light flashes (either GREEN or RED). Follow the instructions below depending on which colour the zone number light is flashing: If the zone light is flashing GREEN (single stage bind): On the evohome Controller, press the green bind button When the zone light turns solid YELLOW the binding is successful for the zone If you want to bind a cooling setpoint press the button twice so the zone flashes yellow. Press the back button on the evohome screen then press the button The light will turn solid yellow when successful Press forward on the evohome Controller to complete the binding for this zone If you are binding more zones repeat the process from the sensor binding step on the previous page, then press the bind button twice on the Underfloor Heating Controller - The GREEN light will flash on the next zone. If the zone light is flashing RED (two stage bind): On the evohome Controller, press the green bind button When the message is received the zone light will turn solid RED Press the back arrow on the evohome Controller Press the bind button on the Underfloor Heating Controller the zone light should flash GREEN On the evohome Controller, press the green bind button When the zone light turns solid GREEN the binding is successful for the zone Press forward on the evohome Controller to complete the binding for this zone If you are binding more zones repeat the process from the sensor binding step on the previous page, then press the bind button once on the Underfloor Heating Controller - The RED light will flash on the next zone. evohome Installation Guide 27 Mixing Valve Controller (HM80) evohome Controller If you are NOT following GUIDED CONFIGURATION follow these steps on your evohome Controller display once the Mixing Valve Controller and sensor have been installed: 1. On the evohome Controller press and hold "Settings" for 3 seconds 2. Press the green tick 3. Press ADD ZONE 4. Type a name for the new zone and press the green tick 5. Press MIXING VALVE 6. If you want to control the zone temperature with your evohome Controller (the evohome Controller needs to be located in that zone) YES, otherwise press NO and bind the sensor. ! All of the remote room sensors will automatically exit from their binding menu after a short period. Power up and bind a Mixing Valve Controller (HM80) A Mixing Valve Controller should only be fitted by a qualified fitter. Unless you're using the evohome Controller as a sensor, you need to install a sensor (DTS92, T87RF, HCW82 or HCF82) before binding the controller to the evohome Controller. To bind the Digital Room Thermostat (DTS92) Press and hold the power button for 2 seconds to put the unit into standby Press the up and down arrows together for three seconds it should say INst Press the down arrow it should say COnt Press the up arrow three times it should say CLr Press the power button once to clear any previous binding data Press the up arrow it should say COnt Press the power button once to send the binding signal to the evohome Controller You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) To bind the Single Zone Thermostat (T87RF) Press and hold on the left touch zone (just below and to the left of the display) for approximately 10 seconds until a flashing 'Bo' is displayed Turn the dial clockwise until a flashing 'Co' is displayed Press the left touch zone once to send the binding signal to the evohome Controller You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) 28 Step 3: Power up and bind devices Mixing Valve Controller (HM80) continued To bind the Room Temperature Sensor (HCW82 or HCF82) Press the bind button on the bottom right hand corner of the unit once. The red LED light will flash You should receive a SUCCESS message on the evohome Controller (if not go back and re-bind) Then on the Mixing Valve Controller Press and hold both buttons on the Mixing Valve Controller for 4 seconds until the red light flashes On the evohome Controller press the green bind button Press the next arrow on the evohome Controller PRESS AND HOLD 4 SEC evohome Installation Guide 29 Step 4: System test Now that all the devices are bound to your evohome Controller and installed in their final locations, check that the system works properly and that all the devices are responding to commands from the evohome Controller. You can perform a simple functional check of the heating system by overriding the temperature of each zone to their minimum and maximum while listening for a response from the radiator (or zone) controllers and boiler. To save power the battery devices only communicate with the evohome Controller every four minutes therefore the system may not respond immediately to a manual temperature change. In this section Advanced RF communication check 30 Mains Powered Wireless Devices 30 Battery Powered Wireless Devices 31 30 Step 4: System test Advanced RF communication check ! To save power the battery devices only communicate with the evohome Controller every four minutes therefore the system may not respond immediately to a manual change. To check the RF signal strength between the wireless devices and the evohome Controller go to RF COMMS CHECK in the evohome Controller Installer Menu and test each wireless device. On the evohome Controller press and hold `Settings' for 3 seconds Press the green tick Press RF COMMS CHECK Choose the devices you want to test Mains Powered Wireless Devices Mains powered devices do not need to be put into test mode and will automatically respond to the test message sent from the evohome Controller: Wireless Relay Box (BDR91) · The Relay Box will flash the red LED from 1 flash (poor) to 5 flashes (excellent) no flashing means the Relay Box has not received a test signal from the evohome Controller Underfloor Heating Controller (HCE80/HCC80) · The Underfloor Heating Controller will flash the green LED for the zone you are testing from 1 flash (poor) to 5 flashes (excellent) no flashing means the Underfloor Heating Controller has not received a test signal from the evohome Controller evohome Installation Guide 31 Battery Powered Wireless Devices Battery powered devices need to be put into test mode to send and receive a test signal: Radiator Controller (HR92) Press the button, the zone name is displayed Press and hold the button again for 5 seconds, the display should say BIND Turn the dial to display RF CHECK Press the button, the display should flash CHECKING Press the button again, the display should flash SIGNAL and will display a signal strength bar and a rating from 1 (poor) to 5 (excellent) 0 means the Radiator Controller has not received a test signal from the evohome Controller. To exit test mode turn the dial to exit and press the button. It will also exit automatically after 10 minutes. PRESS AND HOLD 4 SEC "RF CHECK" 32 Step 4: System test Advanced RF communication check continued Radiator Controller (HR91) Press and hold the and button for 5 seconds, both LED should flash amber. Press the tick on the Evo screen to start the test, Signal strength will be shown from poor to excellent. Press the button to exit. It will also exit automatically after 10 minutes. 5 SEC 10 MIN evohome Installation Guide 33 Digital Room Thermostat (DTS92) Put the Room Thermostat into standby mode Press up and down together for 3 seconds Press down once, the display should say CONT Press down for 3 seconds, the display should say TEST Press down for 3 seconds, the display should say SS The evohome Controller will display the signal strength (poor to excellent) and the Room Thermostat will display a signal strength rating from 1 (poor) to 5 (excellent) 0 means the Room Thermostat has not received a test signal from the evohome Controller. To exit test mode, press off on Room Thermostat for 5 seconds. It will exit automatically after 10 minutes. PRESS AND HOLD 2 SEC PRESS AND HOLD 3 SEC 34 Step 4: System test Advanced RF communication check continued Room Temperature Sensor (HCF82 or HCW82) Remove the cover from the sensor Press and hold the bind button for approximately 30 seconds until the red LED goes off The red LED will flash each time it sends a test message The evohome Controller will display the signal strength (poor to excellent) no flashing means the Temperature Sensor has not received a test signal from the evohome Controller. To exit test mode, press the bind button on the Temperature Sensor. It will exit automatically after 5 minutes. PRESS AND HOLD 30 SEC evohome Installation Guide 35 Wireless Cylinder Thermostat (CS92A) Press the button on the Cylinder Thermostat transceiver for 5 seconds The green light should come on. If it doesn't, reinsert the batteries and try again The evohome Controller will display the signal strength (poor to excellent) and the transceiver should flash the red LED from 1 flash (poor) to 5 flashes (excellent) no flashing means the transceiver has not received a test signal from the evohome Controller. To exit test mode press the button on the transceiver. PRESS AND HOLD 5 SEC 36 Configuration and modification Configuration and modification Once you've completed these steps you're ready to start using your evohome system. You can also make parameter adjustments in the evohome Controller to match the exact requirements of the heating system. The operation and functions of the each zone can also be adjusted. These can be found in the Installer Menu. Components can be added or replaced by editing the zones or system in the Installer menu. In this section Parameters and control features 37 Configuring a zone with multiple rooms 37 Adding or replacing components in an existing system 38 evohome Installation Guide 37 Parameters and control features Once you've completed these steps you're ready to start using evo. The user guide gives you instructions for personalising the settings on the evohome Controller. You can also make parameter adjustments on your evohome Controller to match the exact requirements of the heating system. These can be found in the Installer Menu. On the evohome Controller press and hold `Settings' for 3 seconds Press the green tick Press SYETEM PARAMETERS and choose the parameter you want to adjust: Internal Sensor Offset Cycle Rate Minimum On Time Fail Safe Hot Water Parameters For more details on parameters visit www.getconnected.honeywellhome.com Configuring a zone with multiple rooms ! A multiple room zone does not support separate remote temperature sensors (such as DTS92). Room temperature sensing is done by the radiator controllers. evohome allows you to create a zone with multiple rooms (i.e. Bedroom's) that are controlled together as one group. It does this by letting all the radiator controllers bound to that zone to independently measure room temperature and control a radiator. This means you can locate the radiator controllers in separate rooms without them all being controlled by one temperature sensor like a single room zone does. To create a multiple room zone either: · Add a new zone and bind the radiator controllers for all the rooms. Go to the parameters menu and select multiple room zone. or · Go to Zone Configuration and edit an existing zone's parameters. Any bound radiator controllers already bound to that zone will now work independently 38 Configuration and modification Adding or replacing components in an existing system ! If the device you are replacing is no longer required in the system remove the power as it may still try to communicate with the system. To add or replace a zone device such as a Radiator Controller or Temperature Sensor On the evohome Controller press and hold "Settings" for 3 seconds Press the green tick Press ZONE CONFIGURATION Select the required zone Press RF DEVICE BINDING then follow the instructions to bind the device. To replace a system device such as a Wireless Relay Box, System Valve, or Hot Water component On the evohome Controller press and hold "Settings" for 3 seconds Press the green tick Press SYSTEM DEVICES Select the type of device and follow the instructions to bind. evohome Installation Guide 39 Appendix Heating system schematics, Wiring diagrams In this section Sample evohome systems 40 Safety information 48 evohome Controller technical data 49 40 Appendix Sample evohome systems Connecting an OpenTherm Bridge (R8810) Wiring an OpenTherm Bridge to an OpenTherm boiler. Opentherm bridge Opentherm equipped boiler Opentherm input on the boiler ONLY. Do not connect to the room thermostat terminals evohome Installation Guide 41 Single zone or thermostat operation The evohome Controller is the sensor for the whole home which is controlled to the same time and temperature schedule. This system also includes wireless connectivity, which is available for any configuration. BOILER 230vac Basic Boiler Wiring for a basic boiler (not requiring a pump overrun). The relay powers the boiler live input. Boiler that requires a permanent live For use with boilers that require permanent live (this is a typical combi boiler wiring) but please check manufacturers instructions. This can be used for boilers with low voltage or 230vac room thermostat inputs Place link here BDR91 A-B:5(3)A A-C:5(3)A 230V 50-60Hz N LL ABC L <5A N NL BDR91 A-B:5(3)A A-C:5(3)A 230V 50-60Hz N LL ABC <5A L N Appliance thermostat terminals (see instructions). NL Remove link at boiler if fitted. If the boiler has an inbuilt timer leave this on constant. 42 Appendix Sample evohome systems S plan 2 two-port valves There are two zone valves - one for stored hot water one for central heating. The evohome Controller is the sensor for the whole home which is controlled to the same time and temperature schedule. The valves open when needed and the boiler is operated via a wired junction box. ! If a system has been set up and the Wireless Relay Boxes are moved to a new function, the relay binding must be cleared or it will continue to carry out its original function. Connecting a two port zone valve G/Y: Green/Yellow Earth wire BL: Blue Motor Neutral BR: Brown Motor Live GR: Grey end Switch (if used) Permanent Live O: Orange End Switch (if used) In wired system this typically feeds the boiler When a wireless boiler relay is fitted, the end switch is not required ! If connecting a two port zone valve with an unvented cylinder connection for a high limit thermostat, the 'L' permanent live feed must be broken when high limit cutout activates on the insertion thermostat. evohome Installation Guide 43 Sundial or system valves S Plan:2 two-port valves with a wired boiler ! Two port valves with a wired boiler. If a wireless boiler relay is used the Grey, Orange wire and feed to pump and boiler are not required. Optional See note on boiler Relay 44 Appendix Sample evohome systems Y plan 1 three-port mid-position valve The operation is identical to the S plan but it uses a single three-port or mid position valve. ! If a system has been set up and the Wireless Relay Boxes are moved to a new function, the relay binding must be cleared or it will continue to carry out its original function. evohome Installation Guide 45 Y Plan: Three-port Mid position valve with a wired boiler If a wireless boiler relay is used the Orange wire and feed to pump and boiler are not required. Optional See note on boiler Relay C Connecting a mid position 3 port valve G/Y: Green/Yellow Earth wire B: Blue Motor Neutral W: White Heating Relay GR: Grey Hot water Relay O: Orange End switch (if used). In wired system, this typically feeds the boiler. When a wireless boiler relay is fitted the end switch is not required. When a wireless boiler relay is fitted, the end switch is not required 46 Appendix Sample evohome systems Stored hot water and zoned heating Stored hot water and zoned heating system. This system needs HR92s or other zoning solutions for the radiators. ! If a system has been set up and the Wireless Relay Boxes are moved to a new function, the relay binding must be cleared or it will continue to carry out its original function. Connecting a two port zone valve G/Y: Green/Yellow Earth wire BL: Blue Motor Neutral BR: Brown Motor Live GR: Grey end Switch (if used) Permanent Live O: Orange End Switch (if used) In wired system this typically feeds the boiler When a wireless boiler relay is fitted, the end switch is not required ! If connecting a two port zone valve with an unvented cylinder connection for a high limit thermostat, the 'L' permanent live feed must be broken when high limit cutout activates on the insertion thermostat. evohome Installation Guide 47 Heat Pump Diagrams The BDR91T can now be used to control boilers or heat pumps. The diagram shows when it should be bound as a heat pump to increase the range of setting parameters. Heat Pump with buffer tank - separate control Heat Pump Control Heat Pump Controller Bind as a Heat Pump Relay (BDR91T) optional Heat Pump control Evohome Control Bind as an Appliance Relay (BDR91A or T) DHW Cylinder Heat Pump Buffer Tank Secondary Pump Evohome Central Controller Buffer Control Zones Heat Pump with low loss header only - Integrated control Heat Pump Control Evohome Control Heat Pump Controller Heat Pump Bind as Heat Pump (BDR91T) Low Loss header Secondary Pump DHW Cylinder Evohome Central Controller Zones Heat Pump Direct control, no hydronic separation (*use with caution) Heat Pump Control Evohome Control Heat Pump Controller Heat Pump Bind as Heat Pump (BDR91T) Bypass DHW Cylinder Evohome Central Controller Zones *Always refer to appliance manufacturers advice for configuration and integration settings 48 Safety information Appendix EMC compliance considerations Caution: Isolate power supply and make safe before wiring the unit to prevent electric shock and equipment damage. Installation should be carried out by a competent person. Location of device evohome Controller should be installed in an open space for best performance as it is a radio frequency device. Leave at least 30cm distance from any metal objects including wall boxes and at least 1 metre from any other electrical equipment eg. radio, TV, PC etc. Do not mount onto metal wall boxes. For the best temperature control performance the evohome Controller should not be placed near heat or cool sources (e.g. cooker, lamp, radiator, doorways, windows). Disclaimer This product and its associated documentation and packaging are protected by various intellectual property rights belonging to Resideo Inc and its subsidiaries and existing under the laws of the UK and other countries. These intellectual and property rights may include patent applications, registered designs, unregistered designs, registered trademarks, unregistered trademarks and copyrights. Resideo reserves the right to modify this document, product and functionality without notice. This document replaces any previously issued instructions and is only applicable to the product(s) described. This product has been designed for applications as described within this document. For use outside of the scope as described herein, refer to Resideo for guidance. Pittway Sarl cannot be held responsible for misapplication of the product(s) described within this document. PLEASE RESPECT YOUR ENVIRONMENT! Take care to dispose of this product and any packaging or literature in an appropriate way. WEEE directive 2012/19/EU Waste Electrical and Electronic Equipment directive · At the end of the product life dispose of the packaging and product in a corresponding recycling centre. · Do not dispose of the unit with the usual domestic refuse. · Do not burn the product. · Remove the batteries. · Dispose of the batteries according to the local statutory requirements and not with the usual domestic refuse. evohome Installation Guide 49 evohome Controller technical data Electrical Table Stand Power supply Wall Bracket Power supply Room unit power supply input Low voltage cable length (max) Battery type (rechargeable) Input voltage: 100-240V 50/60Hz 0.2A Output voltage: +5V 1A Input voltage: 230VAC ±10% Output voltage: 4VDC ±0.2V, max 2.6W 5V ±0.2V, max. 2.6W 10m, 1.0mm2; 5m, 0.5mm2 Type AA 1.2V NiMH 2000-2400mAh RF Communication RF operation band ISM (868.0--870.0) MHz, Receiver Category 2 RF communication range 30m in a residential building environment Wireless LAN IEEE 802.11b,g,n (2.400-2.485 GHz) Environmental and Standards Operating temperature 0 to 40ºC Storage temperature -20 to +50°C Humidity 10 to 90% relative humidity non condensing IP Protection Class lP30 Mechanical Dimensions 136 x 93 x 20mm (WxHxD) evohome evohome is designed to convert a system with single zone pipework into a multi zone system, resulting in optimal control and comfort combined with maximum energy saving. For more information on Smart Heat Zoning for your home, visit: www.getconnected.honeywellhome.com Pittway Sarl, Z.A. La Pièce 4, 1180 Rolle, Switzerland Country of origin : UK © 2020 Resideo Technologies, Inc. All rights reserved. The Honeywell Home trademark is used under license from Honeywell International Inc. This product is manufactured by Resideo Technologies, Inc. and its affiliates. 32303494-001 C
