Product Overview
The iFi ZEN Stream is a sophisticated Wi-Fi audio transport designed to elevate your audio system. It acts as a perfect streaming partner for devices like the iFi ZEN DAC, offering a future-proof, open-source architecture that supports multiple platforms.
Built with custom-designed hardware and software from the ground up, the ZEN Stream prioritizes exceptional sonic performance. It delivers state-of-the-art hi-res audio support over Wi-Fi and integrates seamlessly with popular streaming services such as Spotify and Tidal.
Key Features:
- Powerful 64-bit quad-core ARM Cortex microprocessor.
- Supports 32-bit/384kHz PCM and DSD256 over Wi-Fi or Ethernet.
- Direct streaming from Spotify and Tidal apps via Spotify Connect and Tidal Connect.
- Integrated Airplay and Chromecast for easy streaming from Apple and Android devices.
- Compatible with Roon, NAA, and DLNA.
- 'Exclusive mode' selection allows dedicated streaming modes (e.g., Tidal, Roon, NAA, DLNA) for optimized performance.
- USB and SPDIF interfaces are regulated by a femto-precision GMT clock to eliminate jitter.
- Incorporates Active Noise Cancellation and iPurifier technologies to reduce audio signal distortion.
- Dual-band Wi-Fi reception (2.4GHz and 5GHz) with 802.11a/b/g/n/ac support.
- Future firmware updates are planned for additional features (e.g., Airplay and Chromecast support mentioned as potentially via future update).
Product Image Description
The iFi ZEN Stream is a compact, silver-finished audio component with a sleek, minimalist design. The top surface features the "STREAM" logo. A rear view of the device reveals connectivity ports, including power input, an Ethernet port, two USB 3.0 Type-A sockets, and an SPDIF (Coaxial) output. A Wi-Fi antenna is visible extending from the rear. The front panel includes a circular power button with a green LED indicator.
Specifications
| Specification | Details |
|---|---|
| Input Voltage | DC 9V/1.8A-15V/0.8A, AC 100-240V, 50/60Hz |
| Input | WiFi / Ethernet / USB DISK HDD etc. |
| Supported Formats | PCM384 / DSD256 |
| Output | USB 3.0 / Type-A Socket x2 and SPDIF (Coaxial) |
| Power Consumption | No Signal: ~6W Max Signal: ~10W |
| Dimensions | 158 x 100 x 35 mm (6.2" x 3.9" x 1.4") |
| Net Weight | 578g (1.14 lbs) |
| Warranty Period | 12 months |
Specifications are subject to change without notice.
Contents
- 1 x ZEN Stream unit
- 1 x Ethernet Cable
- 1 x Plastic screwdriver
- 1 x Instruction card
- 1 x Power Adapter
- 1 x Antenna
- 1 x User Manual
Additional Information
Technology licensed from AMR-Audio, UK.
Assembled in China.
Version: Ver1.0
Model/Serial Number: S/N:
Website: ifi-audio.com
