User Guide for Lenovo models including: T14 Gen 2, T15 Gen 2, P14s Gen 2, P15s Gen 2, P14s Gen 2 14 Inch AMD Mobile Workstation, 14 Inch AMD Mobile Workstation, AMD Mobile Workstation, Mobile Workstation, Workstation, ThinkPad P14s Gen 2 14 Inch AMD Mobile Workstation
Second Edition (February 2021) ... instructions might not be applicable to your computer. ... Follow the on-screen instructions to disable TrackPoint.
T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Read this first Before using this documentation and the product it supports, ensure that you read and understand the following: · Safety and Warranty Guide · Setup Guide · Generic Safety and Compliance Notices Second Edition (February 2021) © Copyright Lenovo 2021. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration "GSA" contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS35F-05925. Contents Discover your Lenovo notebook. . . . .iii Chapter 1. Meet your computer . . . . . 1 Front view . . . . . . . . . . . . . . . . . . 1 Side view . . . . . . . . . . . . . . . . . . 4 Bottom view . . . . . . . . . . . . . . . . . 6 Rear view . . . . . . . . . . . . . . . . . . 7 Specifications . . . . . . . . . . . . . . . . 7 USB specifications . . . . . . . . . . . . . 7 Chapter 2. Get started with your computer . . . . . . . . . . . . . . . . . 9 Access networks . . . . . . . . . . . . . . . 9 Connect to Wi-Fi networks. . . . . . . . . . 9 Connect to the wired Ethernet . . . . . . . . 9 Connect to a cellular network (for selected models) . . . . . . . . . . . . . . . . . 9 Turn on the Airplane mode . . . . . . . . . 10 Interact with your computer . . . . . . . . . . 10 Use the keyboard shortcuts . . . . . . . . 10 Use the TrackPoint pointing device . . . . . 12 Use the trackpad . . . . . . . . . . . . 13 Use the touch screen (for selected models) . . 14 Connect to an external display . . . . . . . 16 Chapter 3. Explore your computer . . 19 Lenovo apps . . . . . . . . . . . . . . . . 19 Smart features (for selected models). . . . . . . 19 Color calibration (for selected models) . . . . . . 22 Intelligent cooling . . . . . . . . . . . . . . 22 Manage power . . . . . . . . . . . . . . . 23 Check the battery status . . . . . . . . . 23 Charge the computer . . . . . . . . . . . 23 Change the power settings . . . . . . . . 25 Transfer data . . . . . . . . . . . . . . . . 25 Set up a Bluetooth connection . . . . . . . 25 Set up an NFC connection (for selected models) . . . . . . . . . . . . . . . . 25 Use a microSD card or smart card (for selected models) . . . . . . . . . . . . 26 Use the RFID feature (for selected Intel models) . . . . . . . . . . . . . . . . 27 Accessories . . . . . . . . . . . . . . . . 27 Purchase accessories . . . . . . . . . . 27 Docking station . . . . . . . . . . . . . 27 Chapter 4. Secure your computer and information . . . . . . . . . . . . 31 Lock the computer . . . . . . . . . . . . . 31 Log in with your fingerprint (for selected models) . . 31 Log in with your face ID (for selected models) . . . 31 Protect your privacy (for selected models) . . . . 32 Protect data against power loss (for selected models) . . . . . . . . . . . . . . . . . . 32 UEFI BIOS passwords . . . . . . . . . . . . 32 Password types . . . . . . . . . . . . . 32 Set, change, and remove a password . . . . 34 Associate your fingerprints with passwords (for selected models) . . . . . . . . . . . 35 Chapter 5. Configure advanced settings. . . . . . . . . . . . . . . . . 37 UEFI BIOS . . . . . . . . . . . . . . . . . 37 Enter the UEFI BIOS menu . . . . . . . . . 37 Navigate in the UEFI BIOS interface . . . . . 37 Set the system date and time. . . . . . . . 37 Change the startup sequence . . . . . . . 37 Update UEFI BIOS . . . . . . . . . . . . 37 Install a Windows operating system and drivers . . 38 Chapter 6. CRU replacement . . . . . 41 CRU list . . . . . . . . . . . . . . . . . . 41 Disable Fast Startup and the built-in battery . . . . 42 Replace a CRU . . . . . . . . . . . . . . . 42 Base cover assembly (T14 Gen 2 and P14s Gen 2) . . . . . . . . . . . . . . . . . 42 Base cover assembly (T15 Gen 2 and P15s Gen 2) . . . . . . . . . . . . . . . . . 44 Memory module (for selected models) . . . . 46 M.2 solid-state drive . . . . . . . . . . . 47 Coin-cell battery . . . . . . . . . . . . . 49 Wireless WAN card (for selected models) . . . 49 Speaker assembly . . . . . . . . . . . . 51 Always On USB 3.2 connector Gen 1 board and bracket . . . . . . . . . . . . . . 51 Keyboard . . . . . . . . . . . . . . . 52 Chapter 7. Help and support . . . . . 59 Frequently asked questions . . . . . . . . . . 59 Error messages . . . . . . . . . . . . . . . 60 Beep errors . . . . . . . . . . . . . . . . 61 Self-help resources . . . . . . . . . . . . . 62 Windows label . . . . . . . . . . . . . . . 63 Call Lenovo . . . . . . . . . . . . . . . . 63 Before you contact Lenovo . . . . . . . . 63 Lenovo Customer Support Center . . . . . . 65 © Copyright Lenovo 2021 i Purchase additional services. . . . . . . . . . 65 Appendix A. Compliance information . . . . . . . . . . . . . . . 67 Appendix B. Notices and trademarks . . . . . . . . . . . . . . . 71 ii T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Discover your Lenovo notebook Thank you for choosing a Lenovo® notebook! We are dedicated to delivering the best solution to you. Before starting your tour, please read the following information: · Illustrations in this documentation might look different from your product. · Depending on the model, some optional accessories, features, software programs, and user interface instructions might not be applicable to your computer. · Documentation content is subject to change without notice. To get the latest documentation, go to https:// pcsupport.lenovo.com. © Copyright Lenovo 2021 iii iv T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Chapter 1. Meet your computer ThinkPad T14 Gen 2 and ThinkPad P14s Gen 2 might be shipped with different microprocessors, namely Intel® and Advanced Micro Devices (AMD). ThinkPad T15 Gen 2 and ThinkPad P15s Gen 2 are shipped with Intel microprocessors. Hereby Intel models and AMD models are used to distinguish computer models with different microprocessors. Front view T14 Gen 2 and P14s Gen 2 Microphone* Webcam privacy shutter* Power button © Copyright Lenovo 2021 Infrared (IR) camera* / Camera* Touch screen* TrackPoint® pointing stick 1 RFID label1 Trackpad TrackPoint buttons * for selected models 1 for selected Intel models T15 Gen 2 and P15s Gen 2 Fingerprint reader* Near field communication (NFC) label* Speaker 2 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Microphone* Webcam privacy shutter* Power button Fingerprint reader* NFC label* Speaker IR camera* / Camera* Touch screen* TrackPoint pointing stick Trackpad TrackPoint buttons * for selected models Webcam privacy shutter Slide the webcam privacy shutter to cover or uncover the camera lens. It is designed to protect your privacy. Power button Press to turn on the computer or put the computer to sleep mode. To turn off the computer, open the Start menu, click Power, and then select Shut down. The indicator in the power button shows the system status of your computer. · Blinking for three times: The computer is initially connected to power. · On: The computer is on. · Off: The computer is off or in hibernation mode. · Blinking rapidly (for Intel models): The computer is entering sleep or hibernation mode. · Blinking rapidly (for AMD models): The computer is entering hibernation mode. · Blinking slowly: The computer is in sleep mode. Related topics · "Log in with your face ID (for selected models)" on page 31 · "Smart features (for selected models)" on page 19 · "Use the touch screen (for selected models)" on page 14 · "Use the TrackPoint pointing device" on page 12 · "Use the RFID feature (for selected Intel models)" on page 27 · "Log in with your fingerprint (for selected models)" on page 31 · "Use the trackpad" on page 13 · "Set up an NFC connection (for selected models)" on page 25 Chapter 1. Meet your computer 3 Side view Intel models USB-C® (ThunderboltTM 4) power connector USB 3.2 connector Gen 1 Audio connector Smart-card slot* Ethernet connector * for selected models USB-C (Thunderbolt 4) connector HDMITM connector microSD-card slot Always On USB 3.2 connector Gen 1 Security-lock slot 4 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide AMD models USB-C (3.2 Gen 2) power connector USB-C (3.2 Gen 2) connector USB 3.2 connector Gen 1 Audio connector Smart-card slot* Ethernet connector HDMI connector microSD-card slot Always On USB 3.2 connector Gen 1 Security-lock slot * for selected models Related topics · "USB specifications" on page 7 · "Charge the computer" on page 23 · "Connect to an external display" on page 16 · "Use a microSD card or smart card (for selected models)" on page 26 · "Connect to the wired Ethernet" on page 9 · "Lock the computer" on page 31 Chapter 1. Meet your computer 5 Bottom view T14 Gen 2 and P14s Gen 2 T15 Gen 2 and P15s Gen 2 Emergency-reset hole Keyboard drainage hole Emergency-reset hole If the computer stops responding and you cannot turn it off by pressing the power button, reset your computer: 1. Disconnect your computer from ac power. 2. Insert a straightened paper clip into the hole to cut off power supply temporarily. 3. Connect your computer to ac power and then turn on your computer. 6 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Keyboard drainage hole Drain out liquid from your computer if you accidentally spill liquid on the keyboard. CAUTION: When the computer is operating, it should be placed on a hard and flat surface with its bottom area not in contact with user's bare skin. Under normal operating conditions, the temperature of the bottom surface will remain within an acceptable range as defined in IEC 62368-1, but such temperatures can still be high enough to cause discomfort or harm to the user if directly touched for over one minute at a time. As such, it is recommended that users avoid prolonged direct contact with the bottom of the computer. Rear view Nano-SIM-card tray* * for selected models Related topic "Connect to a cellular network (for selected models)" on page 9 Specifications For detailed specifications of your computer, go to https://psref.lenovo.com. USB specifications Note: Depending on the model, some USB connectors might not be available on your computer. Chapter 1. Meet your computer 7 Connector name Description Connect USB-compatible devices, such as a USB keyboard, USB mouse, USB storage device, or USB printer. USB 3.2 connector Gen 1 · USB-C (3.2 Gen 2) connector · USB-C (Thunderbolt 4) connector · Charge USB-C compatible devices with the output voltage and current of 5 V and 1.5 A. · Connect to an external display: Intel models: USB-C to VGA: up to 1920 x 1200 pixels, 60 Hz USB-C to DP: up to 5120 x 3200 pixels, 60 Hz AMD models: USB-C to VGA: up to 1920 x 1200 pixels, 60 Hz USB-C to DP: up to 5120 x 2880 pixels, 60 Hz · Connect to USB-C accessories to help expand your computer functionality. To purchase USB-C accessories, go to https:// www.lenovo.com/accessories. Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device. USB device 3.2 Gen 1 / 3.1 Gen 1 3.2 Gen 2 / 3.1 Gen 2 3.2 Gen 2 × 2 Thunderbolt 3 Thunderbolt 4 Data rate (Gbit/s) 5 10 20 40 40 8 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Chapter 2. Get started with your computer Access networks This section helps you connect to a wireless or wired network. Connect to Wi-Fi networks Click the network icon in the Windows® notification area, and then select a network for connection. Provide required information, if needed. Connect to the wired Ethernet Connect your computer to a local network through the Ethernet connector on your computer with an Ethernet cable. Connect to a cellular network (for selected models) If your computer has a wireless wide area network (WAN) card and a nano-SIM card installed, you can connect to a cellular data network and get online everywhere. Note: The cellular service is provided by authorized mobile service carriers in some countries or regions. You must have a cellular plan from a service carrier to connect to the cellular network. To establish a cellular connection: 1. Turn off the computer. © Copyright Lenovo 2021 9 2. Insert a straightened paper clip into the hole in the tray 1 . The tray ejects. Then, slide the tray out of the computer. Install a nano-SIM card into the tray 2 with the metal contacts facing downward. Insert the tray into the nano-SIM-card slot until you hear a click 3 . 3. Turn on the computer. 4. Click the network icon in the Windows notification area, and then select the cellular network icon the list. 5. Provide required information if needed. from Turn on the Airplane mode When the Airplane mode is enabled, all wireless features are disabled. 1. Click the action center icon in the Windows notification area. 2. Click Airplane mode to turn on the Airplane mode. Interact with your computer Your computer provides you various ways to navigate the screen. Use the keyboard shortcuts The special keys on the keyboard help you work more effectively. Invoke the special function printed as an icon on each key or standard function of F1F12 function keys. FnLock indicator on: standard function + FnLock indicator off: special function Enable / disable speakers Decrease volume Increase volume Enable / disable microphones Darken display Brighten display 10 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Manage external displays Enable / disable wireless Open / collapse notification center Answer incoming calls on Microsoft Teams® Decline incoming calls on Microsoft Teams Open the Vantage app. You can customize the function of this key on the Vantage app. Open calculator (for T15 Gen 2 and P15s Gen 2 only) + Enter sleep mode (for T15 Gen 2 and P15s Gen 2 only) + Open Snipping Tool + Toggle keyboard backlight + Break operation + Pause operation + Scroll contents + Send system request + Enter sleep mode + To wake up the computer, press Fn or the power button. If your computer comes with an ePrivacy screen, press Fn+D to enable or disable the privacy protection function. For more information, see "Protect your privacy + (for selected models)" on page 32. Go to beginning + Go to end + Chapter 2. Get started with your computer 11 Use the TrackPoint pointing device The TrackPoint pointing device enables you to perform all the functions of a traditional mouse, such as pointing, clicking, and scrolling. Use the TrackPoint pointing device TrackPoint pointing stick Use your finger to apply pressure to the pointing-stick nonslip cap in any direction parallel to the keyboard. The pointer on the screen moves accordingly. The higher the pressure applied, the faster the pointer moves. TrackPoint buttons The left-click button and right-click button correspond to the left and right buttons on a traditional mouse. Press and hold the dotted middle button while using your finger to applying pressure to the pointing stick in the vertical or horizontal direction. Then, you can scroll through the document, Web site, or apps. Disable the TrackPoint pointing device The TrackPoint pointing device is active by default. To disable the device: 1. Open the Start menu, and then click Settings Devices Mouse. 2. Follow the on-screen instructions to disable TrackPoint. 12 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Replace the pointing-stick nonslip cap Note: Ensure that the new cap has grooves a . Use the trackpad You can use the trackpad to perform all the pointing, clicking, and scrolling functions of a traditional mouse. Use the trackpad Left-click zone Right-click zone Chapter 2. Get started with your computer 13 Use the touch gestures Tap once to select or open an item. Tap twice quickly to display a shortcut menu. Two-finger zoom in or zoom out. Scroll through items. Open the task view to see all open windows. Show the desktop. Notes: · When using two or more fingers, ensure that you position your fingers slightly apart. · Some gestures are not available if the last action was done from the TrackPoint pointing device. · Some gestures are only available when you are using certain apps. · If the trackpad surface is stained with oil, turn off the computer first. Then, gently wipe the trackpad surface with a soft and lint-free cloth moistened with lukewarm water or computer cleaner. For more gestures, see the help information of the pointing device. Disable the trackpad The trackpad is active by default. To disable the device: 1. Open the Start menu, and then click Settings Devices Touchpad. 2. In the Touchpad section, turn off the Touchpad control. Use the touch screen (for selected models) If your computer display supports the multi-touch function, you can navigate the screen with simple touch gestures. Note: Some gestures might not be available when you are using certain apps. 14 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Tap once to single click Tap twice quickly to double-click Tap and hold to right-click Slide to scroll through items Zoom out Zoom in Swipe from the left: view all open windows Swipe from the right: open action center Swipe downwards shortly: show title bar Swipe downwards: close the current app Maintenance tips: · Turn off the computer before cleaning the touch screen. Drag Chapter 2. Get started with your computer 15 · Use a dry, soft, and lint-free cloth or a piece of absorbent cotton to remove fingerprints or dust from the touch screen. Do not apply solvents to the cloth. · The touch screen is a glass panel covered with a plastic film. Do not apply pressure or place any metallic object on the screen, which might damage the touch panel or cause it to malfunction. · Do not use fingernails, gloved fingers, or inanimate objects for input on the screen. · Regularly calibrate the accuracy of the finger input to avoid a discrepancy. Connect to an external display Connect your computer to a projector or a monitor to give presentations or expand your workspace. Connect to a wired display If your computer cannot detect the external display, right-click a blank area on the desktop and select display settings. Then follow the on-screen instructions to detect the external display. The following table lists the supported maximum resolution of the external display. Connect the external display to the USB-C (Thunderbolt 4) connector (for Intel models) the USB-C (3.2 Gen 2) connector (for AMD models) the HDMI connector Supported resolution Up to 5120 x 3200 pixels / 60 Hz Up to 5120 x 2880 pixels / 60 Hz Up to 3840 x 2160 pixels / 60 Hz Notes: The HDMI connector supports the HDMI 2.0 standard by default. If you connect an external display to your computer through the HDMI connector with an HDMI 1.4 cable, the external display might not work. In this case, do one of the following: · Use a qualified HDMI 2.0 cable instead of an HDMI 1.4 cable. · Change the HDMI standard of the HDMI connector from 2.0 to 1.4. To change the HDMI standard, enter the UEFI BIOS menu (see "Enter the UEFI BIOS menu" on page 37), and then configure HDMI Mode Select in the Config menu. Connect to a wireless display To use a wireless display, ensure that both your computer and the external display support the Miracast® feature. Press + and then select a wireless display to connect with. 16 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Set the display mode Press or and then select a display mode of your preference. Change display settings 1. Right-click a blank area on the desktop and select display settings. 2. Select the display that you want to configure and change display settings of your preference. You can change the settings for both the computer display and the external display. For example, you can define which one is the main display and which one is the secondary display. You also can change the resolution and orientation. Chapter 2. Get started with your computer 17 18 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Chapter 3. Explore your computer Lenovo apps This section provides introduction to the Vantage and Lenovo Quick Clean apps. The Vantage app The preinstalled Vantage app is a customized one-stop solution to help you maintain your computer with automated updates and fixes, configure hardware settings, and get personalized support. To access the Vantage app, type Vantage in the Windows search box. Key features The Vantage app enables you to: · Know the device status easily and customize device settings. · Download and install UEFI BIOS, firmware, and driver updates to keep your computer up-to-date. · Monitor your computer health, and secure your computer against outside threats. · Scan your computer hardware and diagnose hardware problems. · Look up warranty status (online). · Access User Guide and helpful articles. Notes: · The available features vary depending on the computer model. · The Vantage app makes periodic updates of the features to keep improving your experience with your computer. The description of features might be different from that on your actual user interface. Lenovo Quick Clean Depending on the model, your computer might support the Lenovo Quick Clean feature. The preinstalled Lenovo Quick Clean enables you to temporarily disable the keyboard, screen, trackpad, and TrackPoint pointing device for cleaning. To access Lenovo Quick Clean, do one of the following: · Type Lenovo Quick Clean in the Windows search box. · Press Fn and the right Shift key at the same time. To download the latest version of Lenovo Quick Clean, go to https://pcsupport.lenovo.com. Smart features (for selected models) Your computer might be preinstalled with Glance by Mirametrix®. Glance can capture your head movement through camera and makes your computer smarter and more efficient. © Copyright Lenovo 2021 19 Access Glance by Mirametrix Type Glance in the Windows search box and then press Enter. Note: If Glance is uninstalled, you can request it through https://support.lenovo.com/contactus. Explore key features Depending on the model, some features might not be available on your computer. · Protect privacy Presence Detection: Keep your computer awake when in use and automatically lock the computer when your head moves out of the camera range. Privacy Alert: When a shoulder surfer is detected, an alert icon appears on your computer screen. Privacy Guard: When a shoulder surfer is detected, your screen is blurred. Press Alt+F2 to cancel the blur effect. Smart Display: Blur screens you are not looking at. If you are not facing any screen, all screens are blurred. Press Alt+F2 to cancel the blur effect. 20 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Note: If your computer comes with an ePrivacy screen, it can work with Glance to achieve better privacy protection. For details, go to https://support.lenovo.com/us/en/videos/vid500144. · Improve productivity Snap Window: When you select a window on one screen and turn your face to another, the window automatically snaps to the top center of the screen you are facing. Smart Pointer: Relocate the pointer to the screen you are facing. When the pointer moves from one screen to another, it is temporarily drawn large. Note: Snap Window and Smart Pointer only work when your computer is connected to external displays. Ensure that external displays are placed at the same height of your computer. · Promote digital wellness Posture check: Remind you to adjust your posture once you hunch toward the screen. 20/20/20 Alert: Remind you to look away from the screen and relax your eyes for 20 seconds every 20 minutes. Chapter 3. Explore your computer 21 Color calibration (for selected models) The factory color calibration feature is available on computer models preinstalled with the X-Rite Color Assistant program. This feature enables you to render color images or graphics on your display close to the original intent as much as possible. For computer with the factory color calibration feature, the color profiles are preinstalled. You can switch between color profiles as desired: 1. Click the triangular icon in the Windows notification area to show hidden icons. Then, right-click . 2. Follow the on-screen instructions to select a profile as desired. Lenovo provides backup color profiles in Lenovo Cloud. You might need to restore or install color profiles in the following situations: · If any color profile is lost or damaged, a window will be displayed to remind you to restore the color profiles. Click Yes in the window prompted, and the color profiles will be restored from Lenovo Cloud automatically. · If your display has been replaced by a Lenovo-authorized service provider, do the following to install new color profiles: 1. Connect your computer to the network and close the X-Rite Color Assistant program. 2. Go to C:\Program files (x86)\X-Rite Color Assistant and locate the ProfileUpdaterForDisplayReplacement.exe file. 3. Double-click the EXE file. Then, follow the on-screen instructions to input the display serial number and click Submit. Note: When the new color profiles are installed successfully, a window will be displayed. Intelligent cooling The Intelligent Cooling feature helps you adjust fan speed, computer temperature and performance. This feature works in auto mode by default. Press Fn+T to switch between manual mode and auto mode. 22 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Manual mode · Quiet mode: the least fan noise · Balanced mode: balanced performance and fan noise · Performance mode: the highest performance and normal fan noise on ac power on battery power Do the following to select the preferred mode: 1. Click the battery status icon in the Windows notification area. 2. Move the slider to the left or right to select your preferred mode. Auto mode (for Intel models only) · Auto battery mode: Switch between quiet mode and battery mode automatically based on the amount of system activity. · Auto performance mode: Switch among quiet mode, balanced mode and performance mode automatically based on the amount of system activity. Manage power Use the information in this section to achieve the best balance between performance and power efficiency. Check the battery status Click the battery icon in the Windows notification area to check the battery status, view the current power plan, change the power mode, and access battery settings quickly. For more details about your battery, refer to the Vantage app. Charge the computer Use ac power Power source of the ac power adapter: · Power: 45 W or 65 W (depending on the model) · Sine-wave input at 50 Hz to 60 Hz · Input rating of the ac power adapter: 100 V to 240 V ac, 50 Hz to 60 Hz Chapter 3. Explore your computer 23 When the battery power is low, charge your battery by connecting your computer to ac power with the supplied power adapter. The 65 W ac power adapter supports the rapid charge function, the battery is 80% charged in about one hour when the computer is turned off. The actual charging time depends on the battery size, the physical environment, and whether you are using the computer. Notes: To maximize the life of the battery: · Use the battery until the charge is depleted and recharge the battery completely before using it. Once the battery is fully charged, it must discharge to 94% or lower before it will be allowed to recharge again. · The battery may optimize its full charge capacity based on your usage. After prolonged periods of limited use, full battery capacity may not be available until you discharge to as low as 20% and recharge completely. For more information, refer to the power section of the Vantage app. Use P-to-P 2.0 (Peer to Peer 2.0) charging function Both USB-C connectors on the computer feature the Lenovo-unique P-to-P 2.0 charging function. To use the function, ensure that Always On USB and Charge in Battery Mode are enabled in UEFI BIOS of your computers, so that the function works even when the computers are off or in hibernation mode. To enable Always On USB and Charge in Battery Mode: 1. Press F1 to enter the UEFI BIOS menu. 2. Click Config USB, and then to enable Always On USB and Charge in Battery Mode. · When no ac power is available: Note: The remaining battery power of computer A should be at least 30% and be 3% higher than that of computer B. · When ac power is available: 24 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Note: The actual charging speed of your computer depends on many factors, such as the remaining battery power of the computers, the wattage of the ac power adapter, and whether you are using the computers. Change the power settings For ENERGY STAR® compliant computers, the following power plan takes effect when your computer has been idle for a specified duration: · Turn off the display: After 10 minutes · Put the computer to sleep: After 10 minutes To reset the power plan: 1. Right-click the battery status icon and select Power Options. 2. Choose or customize a power plan of your preference. To reset the power button function: 1. Right-click the battery status icon and select Power Options Choose what the power buttons do. 2. Change the settings as you prefer. Transfer data Quickly share your files using the built-in Bluetooth or NFC technology among devices with the same features. You also can insert a microSD card or smart card to transfer data. Set up a Bluetooth connection You can connect all types of Bluetooth-enabled devices to your computer, such as a keyboard, a mouse, a smartphone, or speakers. To ensure successful connection, place the devices at most 10 meters (33 feet) from the computer. 1. Type Bluetooth in the Windows search box and then press Enter. 2. Turn on Bluetooth, if it is off. 3. Select a Bluetooth device, and then follow the on-screen instructions. Set up an NFC connection (for selected models) If your computer supports NFC, you will see an NFC mark or label around the trackpad area. To turn on NFC: 1. Type Airplane mode in the Windows search box and then press Enter. 2. Ensure that the Airplane mode is off and turn on the NFC function. Chapter 3. Explore your computer 25 By using NFC, you can simply tap and connect your computer and another NFC-enabled device over a few centimeters or inches. To pair with an NFC card or smartphone: Note: Ensure that the NFC card is in NFC Data Exchange Format (NDEF), otherwise the card cannot be detected. Use a microSD card or smart card (for selected models) If your computer has a microSD-card or smart-card slot, read the following information. Supported microSD card Note: Your computer does not support the content protection for recordable media (CPRM) feature for the microSD card. · Secure Digital (SD) card · Secure Digital eXtended-Capacity (SDXC) UHS-1 card · Secure Digital High-Capacity (SDHC) UHS-1 card Supported smart card Supported smart card specifications: 85.60 mm (3.37 inches) x 53.98 mm (2.13 inches) Attention: Smart cards with slits are not supported. Do not insert such a smart card into the smart-card reader of your computer. Otherwise the reader might get damaged. Install the card 1. Locate the card slot. 2. Insert the card firmly into the card slot until it is secured in place. Notes: · For the microSD card, ensure that the metal contacts are facing down and pointing toward the card slot. 26 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide · For the smart card, ensure that the metal contacts are facing upward and pointing toward the card slot. Remove the card Attention: Before removing the card: 1. Click the triangular icon in the Windows notification area to show hidden icons. Right-click the icon prompting you to safely remove hardware and eject media. 2. Select the corresponding item to eject the card from the Windows operating system. 3. Press the card and remove it from your computer. Store the card safely for future use. Use the RFID feature (for selected Intel models) Depending on the model, your computer might come with an integrated Radio Frequency Identification (RFID) reader. With the RFID technology, you can log in to an RFID-enabled system using a granted RFID object, such as an ID badge. To log in to the system, place your identification card above the area a . Accessories This section provides instructions on how to use hardware accessories to expand your computer functionalities. Purchase accessories Lenovo has a number of hardware accessories and upgrades to help expand the functionalities of your computer. Options include memory modules, storage devices, network cards, port replicators or docking stations, batteries, power adapters, keyboards, mice, and more. To shop at Lenovo, go to https://www.lenovo.com/accessories. Docking station You can use the following docking stations to extend the capacity of your computer: · ThinkPad Basic Docking Station · ThinkPad Pro Docking Station · ThinkPad Ultra Docking Station Chapter 3. Explore your computer 27 Side connectors of docking stations Figure 1. ThinkPad Basic Docking Station Figure 2. ThinkPad Pro Docking Station Figure 3. ThinkPad Ultra Docking Station 1. Audio connector 3. DisplayPort® connector 5. USB 2.0 connector 7. USB 3.2 connector Gen 1 9. Security-lock slot 11. HDMI connector 13. USB 3.2 connector Gen 2 2. ac power connector 4. VGA connector 6. Always On USB 3.2 connector Gen 1 8. Ethernet connector 10. USB-C connector 12. Always On USB 3.2 connector Gen 2 Attach a docking station Notes: · ThinkPad Basic Docking Station does not ship with a system lock installed. If you do not purchase and install a system lock, skip step 4 and step 7 in the following instruction. · If you do not connect the docking station to ac power, the computer attached runs on battery power. 1. Connect the docking station to ac power. 2. Disconnect the cables and devices from the left side of the computer. 3. Turn the system lock key to the unlocked position ( ). 28 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide 4. Align the top-left corner of the computer with the guide post of the docking station. Attach your computer to the docking station as shown 1 until you hear a click. Slide the latch in the direction as shown 2 . 5. Check the docking status indicator. The docking status indicator turns on when the computer is successfully docked. Note: If the indicator is off, your computer is not attached to the docking station successfully. To solve the problem, detach and reattach the computer. 6. Turn the system lock key to the locked position ( ). Attention: When the computer is attached to a docking station, always hold the whole assembly when you need to move your computer. Otherwise, the docking station might drop down. Detach a docking station Note: ThinkPad Basic Docking Station does not ship with a system lock installed. If you do not purchase and install a system lock, skip step 1 in the following instruction. 1. Turn the system lock key to the unlocked position ( ). Chapter 3. Explore your computer 29 2. Slide the latch in the direction as shown 1 to release the computer, and then grasp both sides of the computer to remove it 2 . Connect multiple external displays You can connect multiple external displays to a supported docking station. To ensure that the multiple displays work correctly, refer to the following table and connect the external displays to the appropriate connectors. Docking station ThinkPad Basic Docking Station ThinkPad Pro Docking Station ThinkPad Ultra Docking Station Connectors supporting external displays DisplayPort VGA DisplayPort (x2) DisplayPort (x2) HDMI VGA 30 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Chapter 4. Secure your computer and information Lock the computer Lock your computer to a desk, table, or other fixtures through a compatible security cable lock. Note: The slot supports cable locks that conform to the Kensington MicroSaver® lock standards (using TbarTM locking technology) or MiniSaver® lock standards (using CleatTM locking technology). You are responsible for evaluating, selecting, and implementing the locking device and security feature. Lenovo is not responsible for the locking device and security feature. You can purchase the cable locks at https:// smartfind.lenovo.com. Log in with your fingerprint (for selected models) Enroll your fingerprints and unlock computer by scanning your fingerprints on the fingerprint reader. 1. Type Sign-in options in the Windows search box and then press Enter. 2. Select the fingerprint setting and then follow the on-screen instruction to enroll your fingerprint. Note: It is recommended that you put your finger at the middle of the fingerprint reader during enrollment and enroll more than one fingerprint in case of any injuries to your fingers. After the enrollment, the fingerprints are associated with the Windows password automatically. 3. Log in with your fingerprint. Associate your fingerprints with UEFI BIOS passwords You can associate your fingerprints with your power-on password and NVMe password. See "Associate your fingerprints with passwords (for selected models)" on page 35. Maintenance tips: · Do not scratch the surface of the reader with anything hard. · Do not use or touch the reader with a wet, dirty, wrinkled, or injured finger. Log in with your face ID (for selected models) For models come with a webcam privacy shutter, slide the webcam privacy shutter to uncover the camera lens before using the Windows Hello face recognition. Create your face ID and unlock your computer by scanning your face: © Copyright Lenovo 2021 31 1. Type Sign-in options in the Windows search box and then press Enter. 2. Select the face ID setting and then follow the on-screen instruction to create your face ID. Protect your privacy (for selected models) Use the ePrivacy screen Your computer might come with an ePrivacy screen. It can reduce screen visibility from side angles to protect screen content against visual hacking. By default, this function is disabled. You can press F12 or Fn +D to enable it. You will be prompted by the on-screen icon or every time the function is enabled or disabled. Your ePrivacy screen can be automatically enabled in case that you are required to input passwords. By default, this automatic function for passwords is disabled. You can enable it on the Vantage app. The ePrivacy screen also can work with the preinstalled Glance app to better protect your privacy. For details, go to https://support.lenovo.com/us/en/videos/vid500144. Set the privacy level The privacy level of this function varies depending on the screen brightness level, the contrast ratio, and the physical environment where you are using this function. · Press to increase the privacy level. · Press to decrease the privacy level. Protect data against power loss (for selected models) NVMe (Non-Volatile Memory express) M.2 solid-state drive features the Lenovo-unique PLP (Power Loss Protection) function to avoid data loss or damage. If your computer is not responding and you might have to shut down your computer by pressing and holding the power button for several seconds. In this case, the PLP function enables your computer data to be saved timely. However, there is no guarantee that all data is saved in any situation. To check the type of your M.2 solid-state drive: 1. Restart the computer. When the logo screen is displayed, press F10 to enter the Lenovo diagnostics window. 2. On the TOOLS tab, select SYSTEM INFORMATION STORAGE using the arrow keys. 3. Locate the Device Type section to check the information UEFI BIOS passwords You can set passwords in UEFI (Unified Extensible Firmware Interface) BIOS (Basic Input/Output System) to strengthen the security of your computer. Password types You can set a power-on password, supervisor password, system management password, or NVMe password in UEFI BIOS to prevent unauthorized access to your computer. However, you are not prompted to enter any UEFI BIOS password when your computer resumes from sleep mode. Power-on password If you set a power-on password, a window is displayed on the screen when you turn on the computer. Enter the correct password to use the computer. 32 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Supervisor password The supervisor password protects the system information stored in UEFI BIOS. When entering the UEFI BIOS menu, enter the correct supervisor password in the window prompted. You also can press Enter to skip the password prompt. However, you cannot change most of the system configuration options in UEFI BIOS. If you have set both the supervisor password and power-on password, you can use the supervisor password to access your computer when you turn it on. The supervisor password overrides the power-on password. System management password The system management password can also protect the system information stored in UEFI BIOS like a supervisor password, but it has lower authority by default. The system management password can be set through the UEFI BIOS menu or through Windows Management Instrumentation (WMI) with the Lenovo client-management interface. You can enable the system management password to have the same authority as the supervisor password to control security-related features. To customize the authority of the system management password through the UEFI BIOS menu: 1. Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. 2. Select Security Password System Management Password Access Control. 3. Follow the on-screen instructions. If you have set both the supervisor password and the system management password, the supervisor password overrides the system management password. If you have set both the system management password and the power-on password, the system management password overrides the power-on password. NVMe passwords The NVMe password prevents unauthorized access to the data on the storage drive. When an NVMe password is set, you are prompted to type a correct password each time you try to access the storage drive. · Single Password When a Single NVMe password is set, the user must enter the user NVMe password to access files and applications on the storage drive. · Dual Password (User + Admin) The admin NVMe password is set and used by a system administrator. It enables the administrator to access any storage drive in a system or any computer connected in the same network. The administrator can also assign a user NVMe password for each computer in the network. The user of the computer can change the user NVMe password as desired, but only the administrator can remove the user NVMe password. When prompted to enter an NVMe password, press F1 to switch between the admin NVMe password and user NVMe password. Notes: The NVMe password is not available in the following situations: · A Trusted Computing Group (TCG) Opal-compliant storage drive and a TCG Opal management software program are installed in the computer, and the TCG Opal management software program is activated. · For Intel models, when an eDrive storage drive is installed in the computer preinstalled with the Windows 10 operating system. Chapter 4. Secure your computer and information 33 Set, change, and remove a password Before you start, print these instructions. 1. Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. 2. Select Security Password by using the arrow keys. 3. Select the password type. Then, follow the on-screen instructions to set, change, or remove a password. You should record all your passwords and store them in a safe place. If you forget any of your passwords, any potential repair actions required are not covered under warranty. What to do if you forget your power-on password If you forget your power-on password, do the following to remove the power-on password: · If you have set a supervisor password and remember it: 1. Restart the computer. When the logo screen is displayed, immediately press F1. 2. Type the supervisor password to enter the UEFI BIOS menu. 3. Select Security Password Power-On Password by using the arrow keys. 4. Type the current supervisor password in the Enter Current Password field. Then, leave the Enter New Password field blank, and press Enter twice. 5. In the Changes have been saved window, press Enter. 6. Press F10 to save changes and exit the UEFI BIOS menu. · If you have not set a supervisor password, contact a Lenovo authorized service provider to have the power-on password removed. What to do if you forget your NVMe password If you forget your NVMe password (Single password) or both user and admin NVMe passwords (Dual password), Lenovo cannot reset your passwords or recover data from the storage drive. You can contact a Lenovo authorized service provider to have the storage drive replaced. A fee will be charged for parts and service. If the storage drive is a CRU (Customer Replaceable Unit), you can also contact Lenovo to purchase a new storage drive to replace the old one by yourself. To check whether the storage drive is a CRU and the relevant replacement procedure, see "CRU list" on page 41. What to do if you forget your supervisor password If you forget your supervisor password, there is no service procedure to remove the password. You have to contact a Lenovo authorized service provider to have the system board replaced. A fee will be charged for parts and service. What to do if you forget your system management password If you forget your system management password, do the following to remove the system management password: · If you have set a supervisor password and remember it: 1. Restart the computer. When the logo screen is displayed, immediately press F1. 2. Type the supervisor password to enter the UEFI BIOS menu. 3. Select Security Password System Management Password by using the arrow keys. 4. Type the current supervisor password in the Enter Current Password field. Then, leave the Enter New Password field blank, and press Enter twice. 5. In the Changes have been saved window, press Enter. 34 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide 6. Press F10 to save changes and exit the UEFI BIOS menu. · If you have not set a supervisor password, contact a Lenovo authorized service provider to have the system management password removed. Associate your fingerprints with passwords (for selected models) Do the following to associate your fingerprints with the power-on password and NVMe password: 1. Turn off and then turn on the computer. 2. When prompted, scan your finger on the fingerprint reader. 3. Enter your power-on password, NVMe password, or both as required. The association is established. When you start the computer again, you can use your fingerprints to log in to the computer without entering your Windows password, power-on password, or NVMe password. To change settings, press F1 to enter the UEFI BIOS menu, and then select Security Fingerprint. Attention: If you always use your fingerprint to log in to the computer, you might forget your passwords. Write down your passwords, and keep them in a safe place. Chapter 4. Secure your computer and information 35 36 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Chapter 5. Configure advanced settings UEFI BIOS UEFI BIOS is the first program that the computer runs. When the computer turns on, UEFI BIOS performs a self test to make sure that various devices in the computer are functioning. Enter the UEFI BIOS menu Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. Navigate in the UEFI BIOS interface You can navigate in the UEFI BIOS interface by pressing the following keys: · F1: General Help · F9: Setup Defaults · F10: Save and Exit · F5: Change to a lower value · F6: Change to a higher value · : Locate an item · Tab: Select a tab · Esc: Back / Close dialog · Enter: Select / Open submenu Set the system date and time 1. Restart the computer. When the logo screen is displayed, press F1. 2. Select Date/Time and set the system date and time as desired. 3. Press F10 to save changes and exit. Change the startup sequence 1. Restart the computer. When the logo screen is displayed, press F1. 2. Select Startup Boot. Then, press Enter. The default device order list is displayed. Note: No bootable device is displayed if the computer cannot start from any devices or the operating system cannot be found. 3. Set the startup sequence as desired. 4. Press F10 to save the changes and exit. To change the startup sequence temporarily: 1. Restart the computer. When the logo screen is displayed, press F12. 2. Select the device that you want the computer to start from and press Enter. Update UEFI BIOS When you install a new program, device driver, or hardware component, you might need to update UEFI BIOS. © Copyright Lenovo 2021 37 Download and install the latest UEFI BIOS update package by one of the following methods: · Open the Vantage app to check the available update packages. If the latest UEFI BIOS update package is available, follow the on-screen instructions to download and install the package. · Go to https://pcsupport.lenovo.com and select the entry for your computer. Then, follow the on-screen instructions to download and install the latest UEFI BIOS update package. To know more about UEFI BIOS, visit Knowledge Base of your computer at https://pcsupport.lenovo.com. Install a Windows operating system and drivers This section provides instructions on installing a Windows operating system and device drivers. Install a Windows operating system Microsoft constantly makes updates to the Windows operating system. Before installing a particular Windows version, check the compatibility list for the Windows version. For details, go to https:// support.lenovo.com/us/en/solutions/windows-support. Attention: · It is recommended that you update your operating system through official channels. Any unofficial update might cause security risks. · The process of installing a new operating system deletes all the data on your internal storage drive, including the data stored in a hidden folder. 1. If you are using the Windows BitLocker® Drive Encryption feature and your computer has a Trusted Platform Module, ensure that you have disabled the feature. 2. Ensure that the security chip is set to Active. a. Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. b. Select Security Security Chip and press Enter. The Security Chip submenu opens. c. Ensure that the security chip for TPM 2.0 is set to Active. d. Press F10 to save the settings and exit. 3. Connect the drive that contains the operating system installation program to the computer. 4. Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. 5. Select Startup Boot to display the Boot Priority Order submenu. 6. Select the drive that contains the operating system installation program, for example, USB HDD. Then, press Esc. Attention: After you change the startup sequence, ensure that you select the correct device during a copy, a save, or a format operation. If you select the wrong device, the data on that device might be erased or overwritten. 7. Select Restart and ensure that OS Optimized Defaults is enabled. Then, press F10 to save the settings and exit. 8. Follow the on-screen instructions to install the device drivers and necessary programs. 9. After installing the device drivers, apply Windows Update to get the latest updates, for example the security patches. 38 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Install device drivers You should download the latest driver for a component when you notice poor performance from that component or when you added a component. This action might eliminate the driver as the potential cause of a problem. Download and install the latest driver by one of the following methods: · Open the Vantage app to check the available update packages. Select the update packages you want, and then follow the on-screen instructions to download and install the packages. · Go to https://pcsupport.lenovo.com and select the entry for your computer. Then, follow the on-screen instructions to download and install necessary drivers and software. Chapter 5. Configure advanced settings 39 40 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Chapter 6. CRU replacement Customer Replaceable Units (CRUs) are parts that can be upgraded or replaced by the customer. The computers contain the following types of CRUs: · Self-service CRUs: Refer to parts that can be installed or replaced easily by customer themselves or by trained service technicians at an additional cost. · Optional-service CRUs: Refer to parts that can be installed or replaced by customers with a greater skill level. Trained service technicians can also provide service to install or replace the parts under the type of warranty designated for the customer's machine. If you intend on installing a CRU, Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU; and (2) you might be charged for the replacement CRU if Lenovo does not receive the defective CRU within thirty (30) days of your receipt of the replacement CRU. For full details, see the Lenovo Limited Warranty documentation at https://www.lenovo.com/warranty/llw_02. CRU list The following is a list of CRUs of your computer. Self-service CRUs · ac power adapter · Base cover assembly · M.2 solid-state drive · M.2 solid-state drive bracket* · Nano-SIM-card tray* · Power cord Optional-service CRUs · Always On USB 3.2 connector Gen 1 board · Always On USB 3.2 connector Gen 1 board bracket · Coin-cell battery · Keyboard · Memory module* · Speaker assembly · Wireless WAN card* * for selected models Note: Replacement of any parts not listed above, including the built-in rechargeable battery, must be done by a Lenovo-authorized repair facility or technician. Go to https://support.lenovo.com/partnerlocation for more information. © Copyright Lenovo 2021 41 Disable Fast Startup and the built-in battery Before replacing any CRU, ensure that you disable Fast Startup first and then disable the built-in battery. To disable Fast Startup: 1. Go to Control Panel and view by Large icons or Small icons. 2. Click Power Options, and then click Choose what the power buttons do on the left pane. 3. Click Change settings that are currently unavailable at the top. 4. If prompted by User Account Control (UAC), click Yes. 5. Clear the Turn on fast startup check box, and then click Save changes. To disable the built-in battery: 1. Restart your computer. When the logo screen is displayed, immediately press F1 to enter the UEFI BIOS menu. 2. Select Config Power. The Power submenu is displayed. 3. Select Disable Built-in Battery and press Enter. 4. Select Yes in the Setup Confirmation window. The built-in battery is disabled and the computer turns off automatically. Wait three to five minutes to let the computer cool. Replace a CRU Follow the replacement procedure to replace a CRU. Base cover assembly (T14 Gen 2 and P14s Gen 2) Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. Note: Do not remove the base cover assembly when your computer is connected to ac power. Otherwise, there might be a risk of short circuits. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display. 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Turn over the computer. 42 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Removal procedure Installation procedure Chapter 6. CRU replacement 43 Troubleshooting If the computer does not start up after you reinstall the base cover assembly, disconnect the ac power adapter and then reconnect it to the computer. Base cover assembly (T15 Gen 2 and P15s Gen 2) Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. Note: Do not remove the base cover assembly when your computer is connected to ac power. Otherwise, there might be a risk of short circuits. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display. 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Turn over the computer. 44 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Removal procedure Installation procedure Chapter 6. CRU replacement 45 Troubleshooting If the computer does not start up after you reinstall the base cover assembly, disconnect the ac power adapter and then reconnect it to the computer. Memory module (for selected models) Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. Attention: Do not touch the contact edge of the memory module. Otherwise, the memory module might get damaged. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display. 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Remove the base cover assembly. See "Base cover assembly (T14 Gen 2 and P14s Gen 2)" on page 42 or "Base cover assembly (T15 Gen 2 and P15s Gen 2)" on page 44. 46 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Removal procedure Installation procedure M.2 solid-state drive Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. Attention: If you replace a M.2 solid-state drive, you might need to install a new operating system. For details on how to install a new operating system, see "Install a Windows operating system and drivers" on page 38. The M.2 solid-state drive is sensitive. Inappropriate handling might cause damage and permanent loss of data. When handling the M.2 solid-state drive, observe the following guidelines: · Replace the M.2 solid-state drive only for upgrade or repair. The M.2 solid-state drive is not designed for frequent changes or replacement. · Before replacing the M.2 solid-state drive, make a backup copy of all the data that you want to keep. · Do not apply pressure to the M.2 solid-state drive. · Do not touch the contact edge or circuit board of the M.2 solid-state drive. Otherwise the M.2 solid-state drive might get damaged. Chapter 6. CRU replacement 47 · Do not make the M.2 solid-state drive subject to physical shocks or vibration. Put the M.2 solid-state drive on a soft material, such as cloth, to absorb physical shocks. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display. 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Remove the base cover assembly. See "Base cover assembly (T14 Gen 2 and P14s Gen 2)" on page 42 or "Base cover assembly (T15 Gen 2 and P15s Gen 2)" on page 44. Removal procedure of the long M.2 solid-state drive Note: A Mylar film might cover the M.2 solid-state drive. To access the M.2 solid-state drive, open the film first. Removal procedure of the short M.2 solid-state drive Note: A Mylar film might cover the M.2 solid-state drive. To access the M.2 solid-state drive, open the film first. 48 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Coin-cell battery Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Remove the base cover assembly. See "Base cover assembly (T14 Gen 2 and P14s Gen 2)" on page 42 or "Base cover assembly (T15 Gen 2 and P15s Gen 2)" on page 44. Removal procedure Note: After installation, reset the system date and time in the UEFI BIOS menu. See "Set the system date and time" on page 37. Wireless WAN card (for selected models) The following information is only for the computer with user-installable modules. Ensure that you use only a Lenovo-authorized wireless module specifically tested for this computer model. Otherwise, the computer will generate an error-code beep sequence when you turn on the computer. Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. Attention: Do not touch the contact edge of the wireless WAN card. Otherwise the wireless WAN card might get damaged. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display. Chapter 6. CRU replacement 49 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Remove the base cover assembly. See "Base cover assembly (T14 Gen 2 and P14s Gen 2)" on page 42 or "Base cover assembly (T15 Gen 2 and P15s Gen 2)" on page 44. Removal procedure of the wireless WAN card with two antenna cables Note: A Mylar film might cover the wireless WAN card. To access the wireless WAN card, open the film first. Note: After installation, ensure that you connect the orange cable to the connector labeled Orange on the card, and the blue cable to the connector labeled Blue. Removal procedure of the wireless WAN card with four antenna cables (for selected Intel models) Note: A Mylar film might cover the wireless WAN card. To access the wireless WAN card, open the film first. Note: After installation, ensure that you connect the orange cable to the connector labeled Orange on the card, the blue cable to the connector labeled Blue, the white and grey cable to the M1 connector, and the black and grey cable to the M2 connector. 50 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Speaker assembly Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display. 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Remove the base cover assembly. See "Base cover assembly (T14 Gen 2 and P14s Gen 2)" on page 42 or "Base cover assembly (T15 Gen 2 and P15s Gen 2)" on page 44. Removal procedure Always On USB 3.2 connector Gen 1 board and bracket Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. Chapter 6. CRU replacement 51 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Then, close the computer display. 3. Remove the nano-SIM-card tray if your computer comes with one. See "Connect to a cellular network (for selected models)" on page 9. 4. Remove the base cover assembly. See "Base cover assembly (T14 Gen 2 and P14s Gen 2)" on page 42 or "Base cover assembly (T15 Gen 2 and P15s Gen 2)" on page 44. Removal procedure Keyboard Prerequisite Before you start, read Generic Safety and Compliance Notices and print the following instructions. For access, do the following: 1. Disable the built-in battery. See "Disable Fast Startup and the built-in battery" on page 42. 2. Turn off the computer and disconnect the computer from ac power and all connected cables. Notes: 52 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide · You might be instructed to slide the keyboard frame forward or backward in some of the following steps. In this case, ensure that you do not press or hold the keys while sliding the keyboard frame. Otherwise, the keyboard frame cannot be moved. · Your keyboard might look different from the illustrations in this topic. Removal procedure 1. For T15 Gen 2 and P15s Gen 2, loosen the screw that secures the keyboard. 2. Take the tool out of the new keyboard packaging. Insert the tabs a and b into the slot between the TrackPoint buttons and the trackpad 1 . Slightly pivot the tool downward 2 to release the left and right TrackPoint buttons. Then, remove the two Trackpoint buttons 3 . Chapter 6. CRU replacement 53 3. Loosen the screws that secure the keyboard. 4. Insert the tabs c and d into the two dents near the two screw heads as shown. 5. Pivot the tool in the direction as shown to release the keyboard 1 . Push the keyboard in the direction as shown by arrows 2 to release the latches from the keyboard bezel. 54 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide 6. Pivot the keyboard slightly upward as shown by arrow 1 . Then, turn over the keyboard as shown by arrow 2 . 7. Put the keyboard on the palm rest as shown and detach the connectors. Then, remove the keyboard. Chapter 6. CRU replacement 55 Installation procedure 1. Attach the connectors and turn over the keyboard as shown. 2. Insert the keyboard into the keyboard bezel as shown. Ensure that the top edge of the keyboard (the edge that is close to the display) is under the keyboard bezel. 56 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide 3. Slide the keyboard in the direction as shown by the arrows. Ensure that the latches are secured under the keyboard frame. 4. Tighten the screws to secure the keyboard. Chapter 6. CRU replacement 57 5. Take the new TrackPoint buttons out of the new keyboard packaging. Install the TrackPoint buttons as shown. 6. For T15 Gen 2 and P15s Gen 2, tighten the screw that secures the keyboard. 7. Connect the ac power adapter and all disconnected cables to the computer. 58 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Chapter 7. Help and support Frequently asked questions How do I access Control Panel? Type Control Panel in the Windows search box and then press Enter. How do I turn off my computer? How do I partition my storage drive? Open the Start menu and click Power. Then, click Shut down. https://support.lenovo.com/solutions/ht503851 What do I do if my computer stops responding. 1. Press and hold the power button until the computer turns off. Then, restart the computer. 2. If step 1 does not work: · For models with an emergency reset hole: Insert a straightened paper clip into the emergency reset hole to cut off power supply temporarily. Then, restart the computer with ac power connected. · For models without an emergency reset hole: For models with the removable battery, remove the removable battery and disconnect all power sources. Then, reconnect to ac power and restart the computer. For models with the built-in battery, disconnect all power sources. Press and hold the power button for about seven seconds. Then, reconnect to ac power and restart the computer. 1. Carefully unplug the ac power adapter and turn off the computer immediately. The more quickly you stop the current from passing through the computer the more likely you will reduce damage from short circuits. What do I do if I spill liquid on the computer? Attention: Although you might lose some data or work by turning off the computer immediately, leaving the computer on might make your computer unusable. 2. Do not try to drain out the liquid by turning over the computer. If your computer has keyboard drainage holes on the bottom, the liquid will be drained out through the holes. 3. Wait until you are certain that all the liquid is dry before turning on your computer. How do I enter the UEFI BIOS menu? Restart the computer. When the logo screen is displayed, press F1 to enter the UEFI BIOS menu. Where can I get the latest device drivers and UEFI BIOS? · From the Vantage app. See "Install a Windows operating system and drivers" on page 38, and . "Update UEFI BIOS" on page 37 · Download from Lenovo Support Web site at https://pcsupport.lenovo.com. © Copyright Lenovo 2021 59 Error messages If you see a message that is not included in the following table, record the error message first, then shut down the computer and call Lenovo for help. See "Lenovo Customer Support Center" on page 65. Message 0190: Critical low-battery error 0191: System Security - Invalid remote change requested 0199: System Security - Security password retry count exceeded. 0271: Check Date and Time settings. 210x/211x: Detection/Read error on HDDx/SSDx Solution The computer turned off because the battery power is low. Connect the ac power adapter to the computer and charge the batteries. The system configuration change has failed. Confirm the operation and try again. This message is displayed when you enter a wrong supervisor password more than three times. Confirm the supervisor password and try again. The date or the time is not set in the computer. Enter the UEFI BIOS menu and set the date and time. The storage drive is not working. Reinstall the storage drive. If the problem still exists, replace the storage drive. Note: This error indicates that the operating system or programs cannot create, modify, or delete data in the non-volatile system UEFI variable storage due to insufficient storage space after POST. Error: The non-volatile system UEFI variable storage is nearly full. The non-volatile system UEFI variable storage is used by the UEFI BIOS and by the operating system or programs. This error occurs when the operating system or programs store large amounts of data in the variable storage. All data needed for POST, such as UEFI BIOS setup settings, chipset, or platform configuration data, are stored in a separate UEFI variable storage. Press F1 after the error message is displayed to enter the UEFI BIOS menu. A dialog asks for confirmation to clean up the storage. If you select "Yes", all data that were created by the operating system or programs will be deleted except global variables defined by the Unified Extensible Firmware Interface Specification. If you select "No", all data will be kept, but the operating system or programs will not be able to create, modify, or delete data in the storage. Fan error. Press ESC to startup with limited performance. If this error happens at a service center, Lenovo authorized service personnel will clean up the non-volatile system UEFI variable storage using the preceding solution. The thermal fan might not work correctly. After the error message is displayed, press ESC within five seconds to start up the computer with limited performance. Otherwise, the computer will shut down immediately. If the problem still exists when you starts up next time, have your computer serviced. 60 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Beep errors Lenovo SmartBeep technology enables you to decode beep errors with your smartphone when a black screen occurs with beeps from your computer. To decode the beep error with Lenovo SmartBeep technology: 1. Go to https://support.lenovo.com/smartbeep or scan the following QR Code. 2. Download the proper diagnostic app and install it on your smartphone. 3. Run the diagnostic app and place the smartphone near the computer. 4. Press Fn on your computer to emit the beep again. The diagnostic app decodes the beep error and shows possible solutions on the smartphone. Note: Do not attempt to service a product yourself unless instructed to do so by the Customer Support Center or product documentation. Only use a Lenovo-authorized service provider to repair your product. Chapter 7. Help and support 61 Self-help resources Use the following self-help resources to learn more about the computer and troubleshoot problems. Resources How to access? Troubleshooting and FAQ Accessibility information · https://www.lenovo.com/tips · https://forums.lenovo.com https://www.lenovo.com/accessibility Reset or restore Windows Use the Vantage app to: · Configure device settings. · Download and install UEFI BIOS, drivers, and firmware updates. · Secure your computer from outside threats. · Diagnose hardware problems. · Check the computer warranty status. · Access User Guide and helpful articles. · Use Lenovo recovery options. 1. Go to https://support.lenovo.com/ HowToCreateLenovoRecovery. 2. Follow the on-screen instructions. · Use Windows recovery options. 1. Go to https://pcsupport.lenovo.com. 2. Detect your computer or manually select your computer model. 3. Click Diagnostics Operating System Diagnostics and then follow the on-screen instructions. Type Vantage in the Windows search box and then press Enter. Note: The available features vary depending on the computer model. Product documentation: · Safety and Warranty Guide · Generic Safety and Compliance Notices · Setup Guide · This User Guide · Regulatory Notice Go to https://pcsupport.lenovo.com. Then, follow the onscreen instructions to filter out the documentation you want. 62 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Resources Lenovo Support Web site with the latest support information of the following: · Drivers and software · Diagnostic solutions · Product and service warranty · Product and parts details · Knowledge base and frequently asked questions Windows help information How to access? https://pcsupport.lenovo.com · Open the Start menu and click Get Help or Tips. · Use Windows Search or the Cortana® personal assistant. · Microsoft support Web site: https:// support.microsoft.com Windows label Your computer might have a Windows Genuine Microsoft label affixed to its cover depending on the following factors: · Your geographic location · Edition of Windows that is preinstalled Go to https://www.microsoft.com/en-us/howtotell/Hardware.aspx for illustrations of the various types of Genuine Microsoft labels. · In the People's Republic of China, the Genuine Microsoft label is required on all computer models preinstalled with any edition of the Windows operating system. · In other countries and regions, the Genuine Microsoft label is required only on computer models licensed for Windows Pro editions. The absence of a Genuine Microsoft label does not indicate that the preinstalled Windows version is not genuine. For details on how to tell whether your preinstalled Windows product is genuine, refer to the information provided by Microsoft at https://www.microsoft.com/en-us/howtotell/default.aspx. There are no external, visual indicators of the Product ID or Windows version for which the computer is licensed. Instead, the Product ID is recorded in the computer firmware. Whenever a Windows product is installed, the installation program checks the computer firmware for a valid, matching Product ID to complete the activation. In some cases, an earlier Windows version might be preinstalled under the terms of the Windows Pro edition license downgrade rights. Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Prepare the following before you contact Lenovo: 1. Record the problem symptoms and details: Chapter 7. Help and support 63 · What is the problem? Is it continuous or intermittent? · Any error message or error code? · What operating system are you using? Which version? · Which software applications were running at the time of the problem? · Can the problem be reproduced? If so, how? 2. Record the system information: · Product name · Machine type and serial number The following illustration shows where to find the machine type and serial number of your computer. T14 Gen 2 and P14s Gen 2 T15 Gen 2 and P15s Gen 2 64 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Lenovo Customer Support Center During the warranty period, you can call Lenovo Customer Support Center for help. Telephone numbers For a list of the Lenovo Support phone numbers for your country or region, go to https:// pcsupport.lenovo.com/supportphonelist for the latest phone numbers. Note: Phone numbers are subject to change without notice. If the number for your country or region is not provided, contact your Lenovo reseller or Lenovo marketing representative. Services available during the warranty period · Problem determination - Trained personnel are available to assist you with determining if you have a hardware problem and deciding what action is necessary to fix the problem. · Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service. · Engineering change management - Occasionally, there might be changes that are required after a product has been sold. Lenovo or your reseller, if authorized by Lenovo, will make selected Engineering Changes (ECs) that apply to your hardware available. Services not covered · Replacement or use of parts not manufactured for or by Lenovo or nonwarranted parts · Identification of software problem sources · Configuration of UEFI BIOS as part of an installation or upgrade · Changes, modifications, or upgrades to device drivers · Installation and maintenance of network operating systems (NOS) · Installation and maintenance of programs For the terms and conditions of the Lenovo Limited Warranty that apply to your Lenovo hardware product, go to: · https://www.lenovo.com/warranty/llw_02 · https://pcsupport.lenovo.com/warrantylookup Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https:// pcsupport.lenovo.com/warrantyupgrade. Service availability and service name might vary by country or region. Chapter 7. Help and support 65 66 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Appendix A. Compliance information For compliance information, refer to Regulatory Notice at https://pcsupport.lenovo.com and Generic Safety and Compliance Notices at https://pcsupport.lenovo.com/docs/generic_notices. Certification-related information Product name Compliance ID · ThinkPad T14 Gen 2 · ThinkPad T14 Gen 2 LTE12 · ThinkPad T14 Gen 2 LTE22 · ThinkPad T14 Gen 2 AMD2 · ThinkPad T14 Gen 2 LTE AMD2 · ThinkPad P14s Gen 2 · ThinkPad P14s Gen 2 LTE22 · ThinkPad P14s Gen 2 AMD2 · ThinkPad T15 Gen 2 · ThinkPad T15 Gen 2 LTE12 · ThinkPad P15s Gen 2 · Intel models: TP00103J TP00103J03 TP00103J13 TP00103J23 TP00103J33 TP00103J43 TP00103J53 TP00103J63 · AMD models: TP00103K TP00103K03 TP00103K13 TP00103K23 TP00103L TP00103L03 TP00103L13 TP00103L23 · TP00104E · TP00104E03 · TP00104E13 · TP00104E23 · TP00104E33 · TP00104E43 2 for mainland China only 3 for India only Machine types · Intel models: ThinkPad T14 Gen 2: 20W0 and 20W1 ThinkPad P14s Gen 2: 20VX and 20VY · AMD models: ThinkPad T14 Gen 2: 20XK and 20XL ThinkPad P14s Gen 2: 21A0 and 21A1 · ThinkPad T15 Gen 2: 20W4 and 20W5 · ThinkPad P15s Gen 2: 20W6 and 20W7 Locate the UltraConnect wireless antennas Your computer has an UltraConnectTM wireless antenna system. You can enable wireless communication wherever you are. © Copyright Lenovo 2021 67 The following illustration shows the antenna locations on your computer: 1. Wireless-LAN antenna (main) 2. Wireless-WAN antenna (main, for selected models) 3. Wireless-WAN antenna (auxiliary, for selected models) 4. Wireless-LAN antenna (auxiliary) 5. 4x4 MIMO Wireless-WAN antenna (auxiliary, for selected Intel models) 6. 4x4 MIMO Wireless-WAN antenna (main, for selected Intel models) Operating environment Maximum altitude (without pressurization) 3048 m (10 000 ft) Temperature · Operating: 5°C to 35°C (41°F to 95°F) · Storage and transportation in original shipping packaging: -20°C to 60°C (-4°F to 140°F) · Storage without packaging: 5°C to 43°C (41°F to 109°F) Note: When you charge the battery, its temperature must be no lower than 10°C (50°F). 68 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Relative humidity · Operating: 8% to 95% at wet-bulb temperature 23°C (73°F) · Storage and transportation: 5% to 95% at wet-bulb temperature 27°C (81°F) Appendix A. Compliance information 69 70 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User Guide Appendix B. Notices and trademarks Notices Lenovo may not offer the products, services, or features discussed in this document in all countries. Consult your local Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. However, it is the user's responsibility to evaluate and verify the operation of any other product, program, or service. Lenovo may have patents or pending patent programs covering subject matter described in this document. The furnishing of this document does not give you any license to these patents. You can send license inquiries, in writing, to: Lenovo (United States), Inc. 8001 Development Drive Morrisville, NC 27560 U.S.A. Attention: Lenovo Director of Licensing LENOVO PROVIDES THIS PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you. Changes are made periodically to the information herein; these changes will be incorporated in new editions of the publication. To provide better service, Lenovo reserves the right to improve and/or modify the products and software programs described in the manuals included with your computer, and the content of the manual, at any time without additional notice. The software interface and function and hardware configuration described in the manuals included with your computer might not match exactly the actual configuration of the computer that you purchase. For the configuration of the product, refer to the related contract (if any) or product packing list, or consult the distributor for the product sales. Lenovo may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. The products described in this document are not intended for use in implantation or other life support applications where malfunction may result in injury or death to persons. The information contained in this document does not affect or change Lenovo product specifications or warranties. Nothing in this document shall operate as an express or implied license or indemnity under the intellectual property rights of Lenovo or third parties. All information contained in this document was obtained in specific environments and is presented as an illustration. The result obtained in other operating environments may vary. Lenovo may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. Any references in this publication to non-Lenovo Web sites are provided for convenience only and do not in any manner serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk. © Copyright Lenovo 2021 71 Any performance data contained herein was determined in a controlled environment. Therefore, the result obtained in other operating environments may vary significantly. Some measurements may have been made on development-level systems and there is no guarantee that these measurements will be the same on generally available systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux® agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice. For the latest information or any questions or comments, contact or visit the Lenovo Web site: https://pcsupport.lenovo.com Trademarks LENOVO, LENOVO logo, THINKPAD, THINKPAD logo, TRACKPOINT, and ULTRACONNECT are trademarks of Lenovo. Intel and Thunderbolt are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Linux is the registered trademark of Linus Torvalds in the U.S. and other countries. Microsoft, Microsoft Teams, Windows, BitLocker, and Cortana are trademarks of the Microsoft group of companies. DisplayPort is a trademark of the Video Electronics Standards Association. NVIDIA is a registered trademark of NVIDIA Corporation. The terms HDMI and HDMI High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. USB-C is a registered trademark of USB Implementers Forum. Wi-Fi and Miracast are registered trademarks of Wi-Fi Alliance. All other trademarks are the property of their respective owners. 72 T14 Gen 2, T15 Gen 2, P14s Gen 2, and P15s Gen 2 User GuidePTC Arbortext Publishing Engine iLovePDF
