Wireless FuzzyScan
Reference Manual
International Edition, Rev D6
Revision History
Rev. No.
Released Date
Rev. A
Oct 16, 2009
Rev. A1 Oct 22, 2009
Rev. A2 Nov 27, 2009
Rev. A3 Mar 05, 2010
Rev. A4 Apr 27, 2010
Rev. A5 Rev. A5
Jun 28, 2010 Jun 28, 2010
Rev. A6 Sep 20, 2010
Description
First Release
Modified "Getting Started" - "Clone Function" operation method. Added "Appendix" - "Save Configuration" and "Master Default" System Commands. Modified "Operation Control" - "Bluetooth Device Name". Add "Appendix" - "Indications". Modify "Symbology Reading Control" - "UPC-A & UPC-E Setting" Modified "Serial Interface Control" Renamed "Time Out Control" to "Serial Response Time-out". Modified "Operation Control" "Operation Mode" - Renamed "Presentation Scanning Mode" to
"Presentation Control". Modified "Operation Control" "Rename "Auto Power Off Duration" to "Light Source On Time". Modified "Operation Control" "Good Read Duration" Modified "Operation Control" "Rename "Presentation Scanning Auto-sense" to "Presentation
Auto-sense". Added "Operation Control" "Presentation Sensitivity" Modified "Serial Interface Control" "Baud Rate(BPS)" Modified "Operation Control" " Hands Free Time-out" Added "Symbology Reading Control" - "UPC/EAN Security Level".
Added "Operation Control" " Time Delay to Low Power Trigger" (Renamed to "Time Delay to Low Power Standby Mode" on Rev.C7)
Added "Operation Control" "Good Read Indicator". Modified "Operation Control" " Scan Rate Control" Added "Scan Voting" Modify "Symbology Reading Control" - Renamed "Scan Voting" to "Supplement Scan Voting" Modify "Symbology Reading Control" "EAN Setting" Modify " Keyboard Interface Control" " Keyboard Layout (Language) Setting"
i
Wireless FuzzyScan
Reference Manual
Revision History
Rev. No.
Released Date
Rev. A6 Sep 20, 2010
Rev. A7 Rev. A8 Rev. A9 Rev. B1
Nov 10, 2010 Jan 2, 2011 Mar 4, 2011 Mar 22, 2011
Rev. B2 Jul 22, 2011
Rev. B3 Nov 4, 2011
Rev. B4 Rev. B5
Jan 3, 2012 Mar 5, 2012
Description
Modified "Operation Control" " Scan rate Control" Modified "Operation Control" " Batch Data Quantity Output Format" (Renamed to "Stored Data
Output format" on Rev. C7) Modified "Serial Interface Control" "Baud Rate(BPS)"
Modified "Operation Control" "Buzzer Tone Adjust"
Modified "Serial Interface Control" "Baud Rate(BPS)"
Modify "Symbology Reading Control" "Code 39 Setting" Modified "Serial Interface Control" "Protocol, ACK/NAK Setting"; Added "ACK/NAK Transmission
Indication".(Renamed to "ACK Indication" on Rev. B2) Added " Appendix" - "Numeric Bar Codes ".and "Connecting Apple iOS Devices Quick Sets"
(Removed and modified to "Toggle between Barcode scanning and On-screen keyboard of mobile devices" on Rev.C7) Modify "Symbology Reading Control" "User Defined symbol" Modified "Serial Interface Control" "Protocol, ACK/NAK Setting"; Renamed "ACK/NAK Transmission Indication" to "ACK Indication" Modified "Serial Interface Control" " Serial response time -out" Added "Operation Control" "Laser Aiming Control" Modified "Condensed DataWizard" "Select a Br Code Symbology" Modified "Getting Started" " Paging/ Reset button" Modified "Symbology Reading Control" " Codabar/NW-7 Setting" Modified "Wand/Laser Emulation Control" " Code 39/Code 128 Emulation"
Added "Condensed DataWizard" "1D Barcode Forward-reading Indication", "1D Barcode Backward-reading Indication", and "1D Barcode Direction Indication Transmission"
ii
Wireless FuzzyScan
Reference Manual
Revision History
Rev. No.
Released Date
Rev. B6 Jul 25, 2012
Rev. B7 Aug 20, 2013 Rev. C1 Jan 15, 2014
Rev. C2
Jan 23, 2014 May 8, 2014
Rev. C3 Rev. C4 Rev. C5
May 9, 2014 Feb. 6, 2015 Mar. 9, 2015
Rev. C6 Jun. 3, 2015
Description
Modified "Host Interface Selection" Modified "Symbology Reading Control" " Code 128 Setting" Modified "Wand/Laser Emulation Control" " Code 39/Code 128 Emulation" Added "Operation Control" "LED illumination Control" and "LED Illumination Delay"
Modified "Symbology Reading Control" "Readable Bar Code Setting" section" Modified " Appendix" - "Symbology ID Table"
Supported 2D Functions Modified "Getting Started" " Preparation before Using", " Use FuzzyScan in HID Mode", and "Batch
Scanning" Added "Getting Started" "Sleep Mode" and "Power Off" Modified "Operation Control" "Presentation Sensitivity"
Support 1D Pocket Scanner Added "Host Interface Selection" - "USB EFT Terminal Mode" Added "Appendix" - "USB HID Legacy Mode" Host Interface and "Abort" Option Codes Quick Set
Command
Added "Getting Started" "Clear All Scanned Data" Command.
Added "Symbology Reading Control" " MaxiCode Setting"
Added "Getting Started" "Paging Function" Added "Operation Control" " Radio Connection Beeps", "HID Mode Transmit Delay" and "Link
Quality Control"
Modified "Operation Control" " Good Read Duration" Modified " Appendix" - " Uninstall" Quick Set
Wireless FuzzyScan
Reference Manual
iii
Revision History
Rev. No.
Released Date
Rev. C7 Sep. 9, 2015
Rev. C8 Dec. 23, 2015
Description
Supported 2D Pocket Scanner Added "Getting Started" " Using the Function Keys of Pocket Scanner", " Enter Bluetooth
Discoverable Mode", "How to Delete Last Scanned Data", "Toggle between Barcode Scanning and On-screen Keyboard input", " Check Battery Status" and "Battery Status Indication" Modified "Getting Started" " Power Off" and "How to Transmit Stored Data" Added "Operation Control" "Buzzer Volume", "Timestamp Functions", 2D "Stored Data Output Format", "Radio Link Mode for Discoverable Mode" and "Low Power Stand-by mode Link Indication" Renamed "Operation Control" "Time Delay Low Power Trigger" to "Time Delay to Low Power Standby Mode" Removed "Operation Control" "Link Supervision Time Out" Renamed "Operation Control" "Sleep Time-out Control" to "Radio-off Time-out Control"; Modified "Operation Control" "HID Mode Transmit Delay". "Good Read Duration" and "Time Delay to Low Power Standby Mode" Modified "Operation Control" "Radio-off Time-out Control, Power Off Time-out Control" Renamed "Operation Control" "Batch Data Quantity Output Format" to "Stored Data Output Format" Renamed "Operation Control" "Bluetooth Power Saving Mode" to "Bluetooth Sniff Control"; Enable Bluetooth Sniff Control. Modified "Operation Control" "Link Quality Control" Added "Operation Control" "On-screen Keyboard Control" Modified "Appendix" "Toggle between Barcode Scanning and On-screen Keyboard input" Removed "Appendix" "Sleep" system command
Updated "Revision History" Modified "Getting Started" " Toggle between Barcode Scanning and On-screen Keyboard input" Added "Operation Control" available firmware information for optimized Bluetooth operation
behaviors.
iv
Wireless FuzzyScan
Reference Manual
Revision History
Rev. No.
Released Date
Rev. C9 Mar. 17, 2016
Rev. C10 Rev. C11 Rev. C12 Rev. C13
May. 31, 2016 Aug. 04, 2016 Oct. 7, 2016 Mar. 9, 2017
Rev. C14 Aug. 3, 2017
Rev. C15 Mar. 2, 2018
Rev. C16 Sep. 20, 2018
Description
Added "Getting Started" -A670BT series scanner Modified "Operation Control" available firmware information for optimized Bluetooth operation
behaviors. Modified "Operation Control" "Timestamp Functions"
Added "Symbology Reading Control" "Small DM Code Reading"
Modified "Appendix" " Keyboard Function Code Table"
Modified "Appendix" "Scanner Indication" Modified "Operation Control" " Buzzer Tone Adjust " Moved "Dollar Sign control" from "Operation Control" to "Keyboard Interface Control".
Added "Getting Started" "Validation Scanning" Modified "Getting Started" " Using the Function Keys of Pocket Scanner " Added "Operation Control" "Validation Scanning" Added "Operation Control" "FN2 Function Mode"
Added new released model "A780BT" and "A680BT" Modified "Symbology Reading Control" "Readable Symbology Setting" "Popular 1D" Modified "Getting Familiar with Your FuzzyScan" - A780BT and A680BT series scanner Modified "Preparation before Using" "Charging the Battery"
Added "Operation Control" - "Motion Control" Modified the description of " Symbology Reading Control" " UPC/EAN Security Level" Added information on Code Pages Modified "Radio-off Time-out - Disconnect State" parameter information Modified notes on Unique Barcode Reporting
Wireless FuzzyScan
Reference Manual
v
Revision History
Rev. No.
Released Date
Rev. C17 Nov. 22, 2018 Rev. C18 Mar. 21, 2019
Rev. C19 Jun. 11, 2019 Rev. D1 Oct. 21, 2019
Rev. D2 Nov. 28, 2019
Description
Improved "Symbology Reading Control" "Code 128 Setting ISBT" - ISBT Concatenation settings
Modified "Symbology Reading Control" "QR Code Setting" "Auto detect QR Code Inverse Reading"
Modified "Operation Control" "Motion Control". Redefined "Motion Control" as "Scene Mode". Removed "Operation Control" "Bluetooth Sniff Control" Added "Getting Started" "Preparation before Use Smart Dongle" Added "Getting Started" "Pairing Bluetooth Imager with Dongle"
Added "Getting Started" " Getting Familiar with Your FuzzyScan Scanners" Added "Getting Started" "Preparation before Use" Added "Getting Started" "Using Scanner in PAIR Mode" Added "Getting Started" "Using Scanner in PICO Mode" Added "Getting Started" "Using Scanner in SPP Mode" Added "ECI ID Output" Added new model A660BT Added "SPP Master Simple Mode" Added "SPP Slave Simple Mode" Removed "Bluetooth Authentication"
Added "Serial Port Output" Added "Keyboard Layout Setting" - "Alt-Code Keyboard" input
Wireless FuzzyScan
Reference Manual
vi
Revision History
Rev. No.
Released Date
Rev. D3 Mar. 20, 2020
Rev D4 May 27, 2020
Rev D5 Aug, 14, 2020 Rev D6 April 23, 2021
Description
Added "Using Scanner in SPP Mode" "Auto Reconnection On/Off under SPP Slave Mode" Renamed "Keyboard Layout Setting" - "Alt-Code Keyboard" to "Universal" "Keyboard Interface Control" "Function Key Emulation":
Renamed option "Enable ASCII 00-31 code as keyboard function code output" to "Enable Keyboard Function Code Table 1 Output"
Renamed option "Ctrl-Output" to "Enable Keyboard Function Code Table 2 Output" Added option "Enable Keyboard Function Code Table 3 Output" Modified "Appendix" "Keyboard Function Control Table": Renamed column title "Key Function" to "Key Function 1" Renamed column title "Ctrl-Output" to "Key Function 2" Added column "Key Function 3"
Modified "Symbology Reading Control" "Small DM Code Reading" to "Damaged DM Code Reading".
Modified "Operation Control" "Operation Mode" Added option "Multiple Read Mode"
"Symbology Reading Control" "QR Code Setting" Added function option "QR Code Mirror Images"
Added supported model: PA680BT "Symbology Reading Control" GS1-128 Setting:
Added "GS1-128 Function Control", "GS1-128 FNC1 Setting", "GS1-128 Element String Separator", "GS1-128 Data Separator", "GS1-128 Error Converting"
Added "Operation Control" "Bluetooth Sniff Control" "Keyboard Interface Control" "Keyboard Output": " Added option "Linux Unicode Output" "Aiming Control"- Removed option "Intelligent Aiming" Modified "Operation Control" "Redundancy". Applied to F&L Series only
Wireless FuzzyScan
Reference Manual
vii
© Copyright PC Worth Int'l Co., Ltd Cino makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranty of merchantability and fitness for any particular purpose. Cino shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance, or use of this publication. This publication contains proprietary information that is protected by copyright. All rights are reserved. No part of this publication may be photocopied, reproduced or translated into any language, in any forms, in an electronic retrieval system or otherwise, without prior written permission of Cino. All product information and specifications shown in this document may be changed without prior notice.
Warranty
Cino warrants its products against defects in workmanship and materials from the date of shipment, provided that the product is operated under normal and proper conditions. The warranty provisions and durations are furnished by different warranty programs. The above warranty does not apply to any product which has been (i) misused; (ii) damaged by accident or negligence; (iii) modified or altered by the purchaser or other party; (iv) repaired or tampered by unauthorized representatives; (v) operated or stored beyond the specified operational and environmental parameters; (vi) applied software, accessories or parts are not supplied by Cino; (vii) damaged by circumstances out of Cino's control, such as, but not limited to, lightning or fluctuation in electrical power. Any defective product must follow the warranty program and RMA procedures to return Cino for inspection.
Regulatory
FCC part 15B, FCC part 15C EN61000-6-2, EN61000-6-3, EN60950-1, EN301 489-1, EN301 489-17, EN300 328 EN55022, EN55024 CNS13438, CNS14336
AS/NZS CISPR 22 Class B
Clause 2, Article 58-2 of Radio Waves Act
Class B ITE
LP0002 MIC T401
LED Eye Safety IEC62471 Exempt group Laser Eye Safety IEC60825-1 Class 1
Wireless FuzzyScan
Reference Manual
viii
Table of Contents
GETTING STARTED.....................................................................................................................................1 Getting Familiar with Your FuzzyScan Scanners..................................................................................................................................1 Preparation before Use Pistol Type Scanners...................................................................................................................................5 Preparation before Use Pocket Scanners ......................................................................................................................................... 7 Preparation before Use Smart Dongle .............................................................................................................................................. 8 Decide Your Radio Link Mode .............................................................................................................................................................. 9 Using FuzzyScan in PAIR Mode.........................................................................................................................................................10 Using Scanner in PICO Mode.............................................................................................................................................................14 Using Scanner in HID Mode ...............................................................................................................................................................18 Using Scanner in SPP Mode ..............................................................................................................................................................19 Pairing Bluetooth Imager with Dongle ................................................................................................................................................23 Enter Bluetooth Discoverable Mode ...................................................................................................................................................26 Out-of-range Scanning .......................................................................................................................................................................26 Power Off the Scanner .......................................................................................................................................................................26 Batch Scanning Mode (Inventory Mode) ............................................................................................................................................27 Validation Scanning Mode ..................................................................................................................................................................30 Toggle between Barcode Scanning and On-screen Keyboard Input..................................................................................................33 Presentation Scanning ......................................................................................................................................................................33 Check Battery Status ..........................................................................................................................................................................34 Battery Status Indication.....................................................................................................................................................................34 Paging Function ..................................................................................................................................................................................34 ix
Wireless FuzzyScan
Reference Manual
CONFIGURING YOUR SCANNER ...............................................................................................................35 Configuration Barcode Menu ..............................................................................................................................................................35 Programming Procedures...................................................................................................................................................................36 Host Interface Selection......................................................................................................................................................................40 Symbology Reading Control ...............................................................................................................................................................41 User Defined Symbol ID ............................................................................................................................................................41 Symbology ID Transmission ......................................................................................................................................................43 ECI ID Output.............................................................................................................................................................................44 Readable Bar Code Setting .......................................................................................................................................................45 Code 39/Code 32 Setting...........................................................................................................................................................47 Codabar/NW-7 Setting ...............................................................................................................................................................49 UPC-A & UPC-E Setting ............................................................................................................................................................51 EAN Setting................................................................................................................................................................................53 UCC Coupon Extended Code Setting........................................................................................................................................55 IATA & Interleaved 2 of 5 Setting ...............................................................................................................................................56 Code 25 Family Setting..............................................................................................................................................................57 Code 11 & Code 93 Setting .......................................................................................................................................................58 MSI/Plessey Setting ...................................................................................................................................................................59 Code 128 Setting .......................................................................................................................................................................60 GS1-128 Setting.........................................................................................................................................................................61 UK/Plessey Setting ....................................................................................................................................................................63 Telepen Setting ..........................................................................................................................................................................64 GS1 DataBar Setting..................................................................................................................................................................65
x
Wireless FuzzyScan
Reference Manual
Composite Codes, Codablock F, & PDF417/MicroPDF417 Setting ..........................................................................................66 Code 16K & Code 49 Setting.....................................................................................................................................................67 QR Code Setting ........................................................................................................................................................................68 Data Matrix Setting.....................................................................................................................................................................69 MaxiCode Setting.......................................................................................................................................................................70 Aztec Code Setting ....................................................................................................................................................................71 Australian Post, US Planet, US Postnet, British Post & Japan Post Setting .............................................................................72 Netherlands KIX Code, Intelligent Mail & Korea Post Code Setting ..........................................................................................73 Keyboard Interface Control.................................................................................................................................................................74 Keyboard Layout (Language) Setting ........................................................................................................................................74 Record Suffix, Preamble, Postamble, & FNC1 Symbol Character Transmit .............................................................................75 Caps Lock & Caps Lock Release Control..................................................................................................................................76 Delay Setting..............................................................................................................................................................................77 Function Key & Key Pad Emulation, Upper/Lower Case & Dollar Sign Control ........................................................................78 Code Page: Barcode Encoding Format, Keyboard Output........................................................................................................79 Serial Interface Control .......................................................................................................................................................................82 Record Suffix, Preamble, Postamble Setting.............................................................................................................................82 Delay Setting..............................................................................................................................................................................83 Protocol, ACK/NAK Setting ........................................................................................................................................................84 Time Out Setting, Baud Rate, Data Frame ................................................................................................................................85 Code Page: Barcode Encoding Format, Serial Port Output ......................................................................................................86 Wand/Laser Emulation Control ...........................................................................................................................................................89 Output Polarity, Signal State, Margin/Module Time ...................................................................................................................89
xi
Wireless FuzzyScan
Reference Manual
Code 39/Code 128 Emulation....................................................................................................................................................90 Operation Control ...............................................................................................................................................................................91
Operation Mode .........................................................................................................................................................................91 Batch Reading............................................................................................................................................................................92 Buzzer, Indicator, Vibrator, 1D Code Inverse Reading ..............................................................................................................96 Beeping Control, Radio Connection Beeps ...............................................................................................................................97 Buzzer Volume ...........................................................................................................................................................................98 Timestamp Functions .................................................................................................................................................................99 Radio Link Mode for Discoverable Mode .................................................................................................................................101 Redundancy .............................................................................................................................................................................102 Delay Setting............................................................................................................................................................................103 Light Source & Hand Free Time-out Setting, Good Read Duration .........................................................................................104 Low Power Standby Mode Settings .........................................................................................................................................105 Presentation Scanning Setting.................................................................................................................................................106 Scan Rate Control....................................................................................................................................................................107 Smart Scene ............................................................................................................................................................................108 SmartStand Power Off Timeout, Laser Aiming Control, LED Illumination Control & Delay .....................................................109 Illumination Control, Presentation Background Lighting Control ............................................................................................. 110 Aiming Control, Pre Decode Aiming Timer, Decode Aiming Control........................................................................................ 111 Center Alignment, Unique Barcode Reporting ......................................................................................................................... 112 Out-of-range Scanning............................................................................................................................................................. 113 Radio-off Time-out & Power Off Time-out Control ................................................................................................................... 114 FN2 Function Mode Setting ..................................................................................................................................................... 115
xii
Wireless FuzzyScan
Reference Manual
Batch Scanning Setting............................................................................................................................................................ 116 Batch Scanning Data Transmission Setting............................................................................................................................. 117 Validation Scanning Setting ..................................................................................................................................................... 118 Bluetooth: Device Name & PIN Code Setting .......................................................................................................................... 119 Bluetooth: Other Settings .........................................................................................................................................................120 On-screen Keyboard Control ...................................................................................................................................................121 Condensed DataWizard....................................................................................................................................................................122 Preamble, Postamble, Data Length & Symbol ID Transmission .............................................................................................122 Data Formatter Setting.............................................................................................................................................................123 Data Verifier Setting .................................................................................................................................................................124 Data Replacer Setting ..............................................................................................................................................................125 Data Organizer Setting ............................................................................................................................................................126 Select a Barcode Symbology...................................................................................................................................................127 Application Example.................................................................................................................................................................128 Programming Procedure ..........................................................................................................................................................128 APPENDIX .............................................................................................................................................130 Symbology ID Table ..........................................................................................................................................................................131 Keyboard Function Code Table ........................................................................................................................................................133 Code Page Table of Corresponding Languages............................................................................................................................135 Code Page Unicode Hex Input Setup............................................................................................................................................136 ASCII Input Shortcut .........................................................................................................................................................................140 Link Mode Quick Set Commands .....................................................................................................................................................141 Host Interface Quick Set Commands ...............................................................................................................................................142
xiii
Wireless FuzzyScan
Reference Manual
Option Codes ....................................................................................................................................................................................143 System Commands ..........................................................................................................................................................................144 Indications ......................................................................................................................................................................................... 145
xiv
Wireless FuzzyScan
Reference Manual
Getting Started
GETTING STARTED
Getting Familiar with Your FuzzyScan Scanners
Thank you for choosing Cino FuzzyScan Bluetooth Cordless Image Scanner. Powered by the combination of cutting-edge FuzzyScan Imaging Technology and Bluetooth wireless technology, it not only provides outstanding reading performance, but also delivers the convenience and freedom of mobility. It's ideal for a broad range of applications to unleash your productivity with ease. This document provides a quick reference for installation and operation. The complete documentation is available at www.cino.com.tw.
A780BT Series
A680BT Series
A770BT Series
A660BT, A670BT, F680BT & L680BT
Wireless FuzzyScan
Reference Manual
1
Wireless FuzzyScan
Reference Manual
F780BT & L780BT HB2112 Smart Cradle HB2100 USB Charging Cradle
Getting Started
Link Indicator Status Indicator Beeper Scan Window
Trigger Battery Cavity End Cap Reset Key
Central Indicator Side Indicators Paging/Reset Button Host Interface Port DC Power Jack Quick Pair Barcode
Central Power Indicator Reserved USB Port DC Power Jack
2
Wireless FuzzyScan
Reference Manual
PA680BT, PF680BT, and PL680BT HB3112 Smart Cradle
Getting Started
Status Indicator Power/Link Indicators Left Key Function Key 1 Function Key 2 Right Key Trigger Battery Cover Reset Key Micro USB Port Scan Window
Central Indicator Side Indicators (HB3112 only) Mounting Holes DC Power Jack Paging/Reset Key Quick Pair Barcode Host Interface Port (HB3112) USB Interface Port (HB3100)
3
Getting Started
Using the Function Keys of Pocket Scanner:
Function Keys
Functions
Left Key
Check battery status Transmit stored batch data
Actions Short press the key Long press the key
Right Key Function Key 1
Power off the scanner On-screen keyboard toggle Enter Bluetooth discovery mode
Long press the key Short press the key Long press the key
Function Key 2
Delete last scanned data (batch scanning) Short press the key
Enter batch scanning (inventory mode)
Long press the key
Register Master Data (Validation Scanning) Short press the key
Enter Validation Scanning (Validation Scanning)
Long Press the key
Short Press: Press the key for less than 1 second. Long Press: Press and hold the key for more than 3 seconds.
The Batch Scanning (Inventory Mode) is set as the default function mode, if you want to use the Function Key to carry out Validation Scanning, you have to change the "FN2 Function Mode" setting.
SD112 Smart Dongle
Status Indicator
Power/Pairing Indicator
Quick Pair Barcode
4
Cap
Wireless FuzzyScan
Reference Manual
Getting Started
Preparation before Use Pistol Type Scanners
Install the Battery
Ensure the battery contacts of the battery pack are facing the charging contacts inside the battery cavity.
Charging the Battery
Slide the battery pack into the battery cavity until hearing a click sound. Press the trigger to power on. The scanner will give 4 beeps when the battery pack is installed properly and if the battery pack still has power. Secure the end cap with the screw provided.
Choose the right plug and slot it into the power supply unit cavity until a "click" is heard. Then plug the power supply unit into the wall outlet. Plug the DC power cord of power supply unit into the DC Jack of the cradle. The smart cradle will emit four beeps and the central indicator blinks blue once and side indicators lights red. If you use the charging cradle, the central indicator lights blue. Place the scanner on the cradle. The status indicator of scanner turns steady red if the battery is not fully charged. When the battery is fully charged, the status indicator will be steady green. Please charge the new battery pack for 8 hours before its first use.
Wireless FuzzyScan
Reference Manual
5
Use USB Bus Power
Getting Started
If USB 3.0 is available in your host device, both battery charging and regular operation can be supported by the USB bus power without using external power supply. If only USB 2.0 is available in your host device, we recommend using external power supply as power source, because the power supplied from USB 2.0 is not enough to support both battery charging and regular operation simultaneously.
Wireless FuzzyScan
Reference Manual
6
Getting Started
Preparation before Use Pocket Scanners
Install the Battery
Take off the battery cover from the scanner by removing two blue tapes. Make sure the battery contacts of the battery pack are facing the charging contacts inside the battery cavity. Then put the battery pack into the battery cavity carefully. Place the battery cover in the right orientation onto the back of the scanner. Screw in and tighten the four shipped M2 screws in sequence by a small screw-driver in the clockwise direction.
Charging the Battery via Power Supply Unit
Choose the right plug and slot it into the power supply unit cavity until a "click" is heard. Then plug the power supply unit into the wall outlet Plug the DC connector of the power supply unit into the DC Jack of the cradle. The cradle emits four beeps. For the smart cradle, the central indicator blinks blue once and side indicators lights red. For the charging cradle, the central indicator lights blue. Place the scanner onto the cradle. The scanner's status indicator will be steady red if the battery is not fully charged. When the battery is fully charged, the status indicator will be steady green.
7
Wireless FuzzyScan
Reference Manual
Getting Started
Charge the Battery via USB 3.0 Port
The scanner can also be charged via the USB 3.0 port without the power supply unit. Connect the cradle to USB 3.0 port of host device by a USB cable.
The scanner can also be charged via its micro USB port by connecting the micro USB cable to USB 3.0 port of host device or the commercial USB power adapter connected to the AC outlet.
Preparation before Use Smart Dongle
Remove the dongle cap Plug the dongle into your host device's USB port. Supply power to the dongle by turning on your host device. The power/pairing indicator will flash blue once and its status indicator will emit alternating red-green flashes ("unpaired state") when powered on.
8
Wireless FuzzyScan
Reference Manual
Getting Started
Decide Your Radio Link Mode
The FuzzyScan Bluetooth image scanner provides several radio link modes to communicate with most host devices. When the Bluetooth-enabled host device is not available, it can work with the smart cradle in PAIR mode (peer-to-peer connection) or PICO mode (multiple connections) to provide a plug-and-play cordless migration of your existing non-Bluetooth-enabled devices. Moreover, you can also use the scanner to work with Bluetooth-enabled host devices via SPP mode or HID mode. When the radio link is disconnected, the scanner is capable of reconnecting automatically when it returns to the communication coverage. If you want to change the radio link mode, please scan the "Uninstall" command to reset the scanner to uninstall state. PAIR Mode If the Bluetooth device is not available in your existing system, PAIR mode is the simplest plug-and-play solution. In this mode, a smart cradle can only work with one scanner. The smart cradle not only provides the Bluetooth radio link with the scanner, but also offers the legacy cabled interfaces to the host device, including USB HID, USB COM and RS232 Serial.
PICO Mode For the requirement of multiple connections, up to 7 scanners can be connected to one smart cradle concurrently. If you want to un-pair all scanners paired with the smart cradle, please press and hold the paging/reset button of the smart cradle for more than 5 seconds. If you just want to un-pair part of the paired scanners, please take those paired scanners to scan the "Uninstall" command one by one.
HID Mode Through the most useful HID service, the scanner can work as a Bluetooth Keyboard. In this mode, the scanner will be discoverable by the radio connection request issued by the remote host device.
SPP Master/Slave Mode Through the standard SPP profile, the scanner can work as a Bluetooth Serial Device. In SPP master mode, the scanner initiates the radio connection request to the remote slave device. In SPP slave mode, the scanner will be discoverable by the radio connection request issued by the remote host device. Once the SPP slave pairing process is completed, the radio link mode will be switched to SPP master automatically. This behavior will enable the auto-reconnection feature when connection is lost
9
Wireless FuzzyScan
Reference Manual
Getting Started
Using FuzzyScan in PAIR Mode
Using a suitable interface cable, connect the smart cradle to your host device. Turn on your host device. Make sure the smart cradle is receiving power, in which case, its LED lights will be on.
USB
RS232
Power on the scanner and keep it well within your smart cradle's Bluetooth range during the entire pairing process.
Please note that if the scanner is shipped together with a smart cradle, they are pre-paired already. You will see the link indicator of scanner gives 1 blue blink per 2.5 seconds and the central indicator of smart cradle turns steady blue. If the scanner and smart cradle just give alternative red and green blinks (in "Uninstall" state), please follow step 4 to establish the connection between scanner and smart cradle.
Uninstall
Scan the smart cradle's Quick Pair Barcode with your scanner. This will launch the pairing process during which the scanner will emit a series of clicking sounds, and its link indicator will flash blue rapidly. Once pairing is completed, the scanner will beep 4 times in ascending tone, and its link indicator will flash blue every 2.5 seconds. The smart cradle's center indicator will be steady blue.
Wireless FuzzyScan
Reference Manual
10
Getting Started
If the pairing process failed, the clicking sounds will stop and the scanner's link indicator will give 3 blue blinks every 2 seconds. Thereafter, the scanner will continue to search for the smart cradle for another 30 seconds before going into "Radio-Off" state. In the interim, you may scan the "Uninstall" command to set the scanner to the "Uninstall" state. If the scanner has entered radio-off state already, you can wake it up by pressing its trigger; this will also cause the scanner to re-attempt pairing. Scan the corresponding host interface quick set command to complete the installation.
The default host interface of smart cradle is preset to USB HID. If you want to set the host interface to USB COM, you have to install the USB virtual COM driver into your host device before using the scanner. Please visit CINO website to download the driver.
11
Wireless FuzzyScan
Reference Manual
Getting Started
Unlocked Pair Mode
When your scanner is paired with Smart Cradle under PAIR mode, they become "locked" by default. The cradle can be paired with any other scanner only if the current pairing is uninstalled. You can also create an "unlocked" PAIR mode by scanning the "Unlocked Pair Mode" barcode before pairing. You do not need to uninstall an unlocked PAIR before pairing another scanner with the cradle. To revert back to default "locked" mode afterwards, scan the Locked Pair Mode barcode before pairing.
Unlocked Pair Mode
Locked Pair Mode
Unpair Scanner from Smart Cradle
To unpair a scanner from its smart cradle: (a) scan the Uninstall barcode with the scanner, or (b) press and hold the smart cradle's reset button for 5 seconds.
Uninstall
If unpairing is successful, both devices will flash red and green lights to reflect their unpaired state.
Wireless FuzzyScan
Reference Manual
12
Getting Started
Override a Pairing under PAIR mode As mentioned, when the scanner and smart cradle are paired under PAIR mode, they become "locked" by default and can no longer be paired with other scanners unless the pair is uninstalled in advance. If you want to override the pairing without uninstalling it first, you can scan "Override the locked scanner" before pairing. This will override the current pairing and pair new scanner with the smart cradle..
Override the locked scanner
Smart Dongle does not reset button, this feature can be very useful when the paired scanner is lost, broken, or unknown (e.g. there are multiple scanners in use, and checking them individually to see which one is paired would be inefficient).
Creating a Barcode for PAIR Mode Under PAIR mode, only one imager can be paired with the smart dongle. The original Quick Pair barcode on the smart dongle is for PAIR mode. To create a back up pairing barcode under this mode, please follow the instructions below.
Pair your dongle with an imager using the Quick Pair barcode. Thereafter, scan the "System Information" command barcode. The dongle's MAC addresses will be displayed on your host device.
SYSTEM INFORMATION
Use your barcode generator to create a pairing barcode for PAIR mode. The barcode's symbology should be Code 128, and its format ought to be as follows: <Fnc 3>Pxxxxxx P is the prefix. xxxxxx represents the last 6 characters of the smart dongle's MAC address For example, if the dongle's MAC address is "00 25 14 11 11 11", the pairing barcode will be: P111111
13
Wireless FuzzyScan
Reference Manual
Getting Started
Using Scanner in PICO Mode
Create a Quick Pair barcode for PICO mode and have it ready. Please refer to next section for instructions on how to prepare such a barcode. Using a suitable interface cable, connect the smart cradle to your host device.
USB
RS232
Turn on your host device. Make sure the smart cradle is receiving power, in which case, its LED lights will be on.
Power on the scanner, and be sure to keep it well within your smart cradle's Bluetooth range during the entire pairing process.
Prior to pairing, the scanner should be in an unpaired state, flashing red and green lights. If not, scan the Uninstall barcode to release it from any current pairing.
Uninstall
Prior to the first scanner pairing under PICO mode, your smart cradle should be in an unpaired state with its side indicators flashing red and green lights. If that's not the case, press and hold the smart cradle's paging/reset button for 5 seconds to release all current pairings. This is not applicable to subsequent pairings of course.
Thereafter, scan the smart cradle's Quick Pair barcode for PICO mode (which you have created in advance) with your scanner. This will launch the pairing process during which the scanner will emit a series of clicking sounds, and its link indicator will flash blue rapidly. Once pairing is completed, the scanner will beep 4 times in ascending tone, and its link indicator will flash blue every 2.5 seconds. The smart cradle's center indicator will be a steady blue.
Wireless FuzzyScan
Reference Manual
14
Getting Started
Once pairing is completed, the scanner will beep 4 times in ascending tone, and its link indicator will flash blue every 2.5 seconds. As for the smart cradle, its center indicator will display a steady blue light and its side indicators will be steady green. As applicable, repeat the above procedures to pair other scanners with the same smart cradle (up to 7 scanners).
The smart cradle's default host interface setting is USB HID, which is plug-and-play and works with host devices running Windows, Linux, or Mac OS. This interface setting may be changed to RS232 or USB COM if needed. See notes below for further details and refer to the Appendix for Host Interface quick set commands.
RS232 interface works with host devices running Windows, Linux, or Mac OS. USB COM interface works with host devices running Windows or Linux. To change the smart cradle's interface setting to USB COM, please first install the USB virtual COM driver on your host device. The driver may be downloaded from www.cino.com.tw.
Unpair Scanner from Smart Cradle To unpair a scanner from its smart cradle: (a) scan the Uninstall barcode with the scanner, or (b) press and hold the smart cradle's reset button for 5 seconds.
Uninstall
To release specific pairings under PICO Mode, scan the Uninstall barcode with the relevant scanners.
15
Wireless FuzzyScan
Reference Manual
Getting Started
Creating a Barcode for PICO Mode Under PICO mode, multiple imagers (up to 7) can be paired with a smart dongle simultaneously. To establish pairings under this mode, you must create a pairing barcode for this purpose with a barcode generator.
Pair your dongle with an imager using the Quick Pair barcode. Thereafter, scan the "System Information" command barcode. The MAC addresses of the dongle will be displayed on your host device.
SYSTEM INFORMATION
Use your barcode generator to create the pairing barcode for PICO mode. The barcode's symbology should be Code 128, and its format ought to be as follows: <Fnc 3>Mxxxxxx M is the prefix. xxxxxx represents the last 6 characters of the smart dongle's MAC address. For example, if the MAC address of the dongle is "00 25 14 11 11 11", the pairing barcode will be "M111111".
16
Wireless FuzzyScan
Reference Manual
Getting Started
Clone Function
For the user's convenience, the clone function will help you to clone the host interface related parameters (please refer to following table for details) from one of the paired scanners to the rest of paired scanners under PICO mode. You can use one of the paired scanners to set the host interface related parameters first and then scan "Save Configuration" command. After that, please take the other paired scanners to scan "Clone" command one by one to clone the host interface related parameters.
Please ensure to keep those paired scanners in connected status when you use the Clone function. Because the host interface related parameters can't be cloned to the paired scanner in disconnected status.
Wireless FuzzyScan
Reference Manual
Save Configuration
The below host interface related parameters will be impacted by clone function:
Data Transmission Parameter Field Delimiter Data Transmission Format
Host Interface Control Host interface Selection
Keyboard Interface Control Keyboard Layout Intermessage Delay Interfunction Delay Intercharacter Delay Caps Lock Control Caps Lock Release Control Function Key Emulation Key Pad Emulation Upper/Lower Case
Serial Interface Control Handshaking Protocol Intermessage Delay Interfunction Delay Intercharacter Delay Baud Rate Data Frame Time Out Control
Wand Emulation Control Output Polarity Initial Signal State Margin Time Module Time Narrow/Wide Ratio Code39 Emulation
17
Clone
Getting Started
Using Scanner in HID Mode
Ensure the battery is fully charged. Power on the scanner within radio coverage and ensure the status indicator of scanner gives alternative red and green blinks (in "Uninstall" state). If your scanner is not in the Uninstall state, please scan the "Uninstall" command first.
Uninstall
If your remote host is equipped with latest Bluetooth drivers, or it's an iOS or Android device, it is recommended to use "HID Mode"..
HID Mode
Once you have scanned the "HID Mode" barcode, the scanner's link indicators will blink blue 3 times every 2 seconds during the search process. You will have to execute a Bluetooth Discovery procedure to find nearby Bluetooth device, then select "PF(L/A)xxxBT-xxxx" (the xxxx are the last 4 digits of its MAC address).
The scanner will emit 4 beeps in ascending tone to indicate the connection is established. The scanner's link indicators will also flash blue every 2.5 seconds to indicate a radio-connected state.
If the scanner is not paired with your host device within 1 minute after scanning the above command, it will enter radio-off state automatically. You can wake the scanner by pressing its trigger; this will also cause the scanner to re-attempt pairing.
The installation procedure may vary depending on different remote host devices, operating systems and the Bluetooth drivers. Please consult your professional IT consultant to obtain necessary support. For more detailed information, please visit CINO website.
18
Wireless FuzzyScan
Reference Manual
Getting Started
Using Scanner in SPP Mode
Establish SPP Master Connection Look for the host device's MAC address under its "Hardware" or "Bluetooth" settings. You will need this MAC address later on. Ensure that a virtual COM port is available on your host device for scanner connection. If not, perform the steps required on your host device to add one. For example, go to "Local Services" under "Bluetooth Advanced Settings" and click on "Add Serial Services" to add a virtual COM port. Power on the scanner within radio coverage, and make sure its status indicator gives alternating red and green blinks (in "Uninstall" state). If not, scan the "Uninstall" barcode to release its current pairing.
Uninstall Scan the "SPP Master Simple Mode" barcode. The scanner's status indicator will turn steady red immediately.
SPP Master Simple Mode Scan the 12 option codes (see Appendix) that correspond to your host device's MAC address, then scan the "FIN" barcode. The scanner will emit a series of clicking sounds and its link indicators will flash blue rapidly. Launch your terminal application to connect it with the scanner. The scanner will emit 4 beeps in ascending tone to indicate radio connection, and its link indicator will flash blue every 2.5 seconds. If the scanner fails to pair with host device within 30 seconds, its link indicator will give 3 blue blinks every 2 seconds. Thereafter, the scanner will continue to search for your host device for another 30 seconds before going into "Radio-Off" state. In the interim, you may scan the "Uninstall" command to set your scanner to the "Uninstall" state. If the scanner has entered radio-off state already, you can wake the scanner by pressing its trigger; this will also cause the scanner to re-attempt pairing.
19
Wireless FuzzyScan
Reference Manual
Getting Started
The above procedures are based on popular Windows operation environment. But the installation procedure may vary depending on different remote host devices, operating systems and the Bluetooth drivers. Please consult your professional IT consultant to obtain necessary support if any problem is arouse during the installation processes. For more detailed information, please visit CINO website. Creating a Barcode for SPP Master Mode You can create an SPP master mode barcode to rapidly pair a scanner with your Bluetooth-enabled host device. Look for the host device's MAC address under its settings. Use the MAC address and a barcode generator to create a Quick Pair barcode for your host device The barcode's symbology should be Code 128, and its format ought to be as follows: <Fnc 3>Sxxxxxxxxxxxx S is the prefix xxxxxxxxxxxx represents the 12 characters of the MAC address For example, if the host device's MAC address is "22 22 22 11 11 11", the barcode will be: S22222211111.
20
Wireless FuzzyScan
Reference Manual
Getting Started
Establish SPP Slave Connection Ensure that a virtual COM port is available on your host device for scanner connection. If not, perform the steps required on your host device to add one. For example, go to "Local Services" under "Bluetooth Advanced Settings" and click on "Add Serial Services" to add a virtual COM port. Power on the scanner within radio coverage, and make sure its status indicator gives off alternating red and green blinks (in "Uninstall" state). If not, scan the "Uninstall" barcode to release its current pairing.
Uninstall Scan the "SPP Slave Simple Mode" barcode. The scanner's status indicator will flash blue 3 times every 2 seconds while it waits for the pairing process to be launched.
SPP Slave Simple Mode Execute the Bluetooth Discovery procedure to find all available Bluetooth device list in your remote host. You will see ,,F(L/A)xxxBT-xxxx (the xxxx are the last 4 digits of its MAC address) is shown in the list if the scanner is successfully discovered. Perform the steps required on your host device to activate the pairing (e.g. tapping or double clicking on the model number, etc.). During the pairing process, the scanner will emit a series of clicking sounds and its link indicators will flash blue rapidly. Launch your terminal application to build the connetion with the scanner. The scanner will emit 4 beeps in ascending tone to indicate the radio is connected, and its link indicator will flash blue every 2.5 seconds. If the scanner is not paired with the host device within 1 minute after scanning the above command, it will enter radio-off state automatically. You can wake up the scanner by pressing its trigger, this will also cause the scanner to re-attempt pairing.
21
Wireless FuzzyScan
Reference Manual
Getting Started
Auto Reconnection On/Off under SPP Slave Mode Cino has implemented a new auto reconnection function for SPP slave mode on all Bluetooth scanners. Scanners switch to SPP master mode automatically after successfully connecting to a device through SPP slave mode. This default function automates the Bluetooth reconnection process following a connection loss.
However, certain devices or applications don't support SPP master mode. User need to manually disable the Auto Reconnection function before connecting Cino Bluetooth scanners to such devices / applications via SPP slave mode.
Scan Auto Reconnection Off before connecting the scanner. To revert back to default auto reconnection function afterwards, scan the Auto Reconnection On barcode before pairing.
SPP Slave Auto Reconnection On
SPP Slave Auto Reconnection Off
Wireless FuzzyScan
Reference Manual
22
Getting Started
Pairing Bluetooth Imager with Dongle
Turn on your FuzzyScan Bluetooth imager. Make sure it is in an unpaired state: its status indicator should emit alternating red-green flashes. Otherwise, scan the "Uninstall" command barcode to release any prior pairing. Initiate the dongle-imager pairing process by scanning the Quick Pair" barcode label of the dongle. Your imager will then produce clicking sounds, and its link indicator will flash blue rapidly. During this process, your dongle will continue to emit red and green lights. Upon successful pairing, the scanner will beep 4 times in ascending tone, and its link indicator will flash blue every 2.5 seconds. The power/pairing indicator of the dongle will be a steady blue.
The Quick Pair barcode on your dongle is designed for "Pair Mode", i.e. the dongle can only pair with one imager at a time. The dongle's default host interface setting is USB HID. To change this setting to USB COM, please first install the USB2COM driver on your host device.
Unpairing Bluetooth Imager from Dongle To unpair the imager from a dongle, scan the "Uninstall" barcode with such imager. If unpairing is successful, the imager will beep 4 times in descending tone. Both the dongle and the imager will also emit red-green flashes to reflect their unpaired state.
Uninstall
23
Wireless FuzzyScan
Reference Manual
Getting Started
Creating a Barcode for PAIR Mode Under PAIR mode, only one imager can be paired with the smart dongle. The original Quick Pair barcode on the smart dongle is for PAIR mode. To create a back up pairing barcode under this mode, please follow the instructions below.
Pair your dongle with an imager using the Quick Pair barcode. Thereafter, scan the "System Information" command barcode. The dongle's MAC addresses will be displayed on your host device.
SYSTEM INFORMATION
Use your barcode generator to create a pairing barcode for PAIR mode. The barcode's symbology should be Code 128, and its format ought to be as follows: <Fnc 3>Pxxxxxx P is the prefix. xxxxxx represents the last 6 characters of the smart dongle's MAC address For example, if the dongle's MAC address is "00 25 14 11 11 11", the pairing barcode will be: P111111
Locked Pair Mode When your scanner is paired with Smart dongle under PAIR mode, they become "locked" by default. The dongle can be paired with any other scanner only if the current pairing is uninstalled. You can also create an "unlocked" PAIR mode by scanning the "Unlocked Pair Mode" barcode before pairing. You do not need to uninstall an unlocked PAIR before pairing another scanner with the dongle.
To revert back to default "locked" mode afterwards, scan the Locked Pair Mode barcode before pairing.
Wireless FuzzyScan
Reference Manual
Locked Pair Mode
Unlocked Pair Mode
24
Getting Started
Override the locked scanner As mentioned, when the scanner and smart dongle are paired under PAIR mode, they become "locked" by default and can no longer be paired with other scanners unless the pair is uninstalled in advance. If you want to override the pairing without uninstalling it first, you can scan "Override the locked scanner" before pairing. This will override the current pairing and pair new scanner with the smart dongle..
Override the locked scanner
Creating a Barcode for PICO Mode Under PICO mode, multiple imagers (up to 7) can be paired with a smart dongle simultaneously. To establish pairings under this mode, you must create a pairing barcode for this purpose with a barcode generator.
Pair your dongle with an imager using the Quick Pair barcode. Thereafter, scan the "System Information" command barcode. The dongle's MAC addresses will be displayed on your host device.
SYSTEM INFORMATION
Use your barcode generator to create the pairing barcode for PICO mode. The barcode's symbology should be Code 128, and its format ought to be as follows: <Fnc 3>Mxxxxxx M is the prefix. xxxxxx represents the last 6 characters of the MAC address of the smart dongle. For example, if the MAC address is "00 25 14 11 11 11", the pairing barcode will be "M111111".
To unpair a scanner under PICO mode, please scan the "Uninstall" barcode.
25
Wireless FuzzyScan
Reference Manual
Getting Started
Enter Bluetooth Discoverable Mode (only available for pocket scanners)
If you use pocket scanner, you can have the scanner entered into Bluetooth discoverable mode for pairing with any remote host easily. When you press and hold the FN1 for more than 3 seconds, the scanner will enter into preset Bluetooth discoverable mode. You have to carry out the Bluetooth discovery procedure to find the scanner for pairing. The preset Bluetooth profile for discoverable mode is "HID Mode".
Out-of-range Scanning
When the radio connection is established between scanner and remote host device, the scanner will transmit each scanned data right after scanning the barcode. However, the default of the scanner is unable to scan any barcode data when it loses the radio connection with the remote host device. If you enable the out-of-range scanning function, the scanner is able to continue scanning barcode data while it is out of radio coverage. All scanned data will be temporarily stored into the memory buffer until radio link resumed.
Enable Out-of-range Scanning
Disable Out-of-range Scanning
In case of the scanner is out of radio coverage, you will hear 4 beeps in descending tone to indicate the radio connection lost. The scanner's link indicators will blink blue 3 times per 2 seconds. Once the scanner is back to radio coverage, you will hear 4 beeps in ascending tone to indicate the radio connection rebuilt and the scanner's link indicators blink blue once per 2.5 seconds. At the same time, all the stored scanned data will be transmitted automatically right after the radio link is resumed.
Power Off the Scanner
By default, the scanner goes off if the scanner is not used during the user-defined time-out duration. You also can power off the scanner by scanning the "Power Off" command. If you want to activate the scanner, please press the trigger key.
Power Off
Wireless FuzzyScan
Reference Manual
26
Getting Started
Batch Scanning Mode (Inventory Mode)
Thanks to the specially designed Batch Scanning function, the scanner is capable of storing the barcode data. It is an ideal cost-saving solution for inventory applications.
Once you scan the ""Enter Batch Scanning" command to activate this function, all scanned barcode data will be stored into the memory storage, and the status indicator of scanner will give green blink at regular interval during batch scanning. You can scan and store the barcode data till the memory storage is full. If the storage is full, you will hear 2 long beeps and the status indicator will give 2 red blinks to indicate out of storage.
If you use pocket scanner, you can also press and hold the Function Key 2 for more than 3 seconds to enter Batch Scanning, by which 3 beeps will be heard and the status indicator of the scanner will blink green at regular interval during batch scanning.
To exit the batch scanning, please scan the "Exit Batch Scanning" command. If you use pocket scanner, you can also exit the batch scanning by pressing and holding Function Key 2 for more than 3 seconds.
Enter Batch Scanning
Exit Batching Scanning
Adding a Quantity Value to Barcode Data
The scanner supports quantity feature when it enters batch scanning. When you use quantity feature, the quantity information and scanned barcode data will be stored into the memory storage together. You can enter the quantity information from 1 to 9999 by scanning the following quantity commands right after you scanned the barcode data.
Wireless FuzzyScan
Reference Manual
Quantity 0 Quantity 1 Quantity 2
Quantity 3 Quantity 4
Quantity 5 Quantity 6 Quantity 7 27
Quantity 8 Quantity 9
Getting Started
There are three ways to output the stored barcode data and quantity information. The preset output format is to transmit stored data as many times as the quantity indicated.But you still can set the scanner to output stored barcode data together with quantity information in two fields, and a preset delimter"" will be output in between. To fulfill different application requirements, both the delimiter and output sequency can be changed as well.
As many times as the quantity indicates
<Quantity><Field Delimiter><Scanned Data>
<Scanned Data><Field Delimiter><Quantity>
How to Transmit Stored Data The scanner is preset to transmit all the stored data by scanning the "Transmit Stored Data" command. If you use pocket scanner, you can also transmit the stored data by pressing and holding Left Key for more than 3 seconds. During the transmission, the scanner will emit continuous short clicks and the link indicator will blink blue. Then the scanner will emit two short beeps after data transmission is completed.
Transmit Stored Data
But you are able to transmit the stored data by placing the scanner onto the cradle as well.
Scan Barcode Command
Place Scanner onto the Cradle
Scan command or Place Scanner onto the Cradle
Wireless FuzzyScan
Reference Manual
28
Getting Started
How to Delete Scanned Data The scanner is preset to keep all the stored data until you scan the "Clear All Stored Data" command. But you are still able to change the setting to "Auto Delete Stored Data after Transmission" as well.
Clear All Stored Data
Auto Delete Stored Data after Transmission
Keep Stored Data after Transmission
How to Delete the Last Scanned Data
If you scanned a wrong barcode, the last scanned data can be deleted by scanning the `'Delete Last Scanned Data'' command. If you use pocket scanner, you can also delete the last scanned data by short pressing the FN2.
Delete Last Scanned Data
Wireless FuzzyScan
Reference Manual
29
Getting Started
Validation Scanning Mode
Validation Scanning function is provided to check whether the scanning barcode matches the registered master data or not. The scanner is capable of storing up to 2K bytes master data. You can have your scanner entered or exited the Validation Scanning by scanning the following commands. You will hear 3 short beeps when entering in Validation Scanning. The status indicator of the scanner will blink green once per 2.5 seconds to indicate the scanner is under Validation Scanning. To terminate the validation scanning, please scan the "Exit Validation Scanning" command, the scanner will emit 3 short beeps.
Enter Validation Scanning
Exit Validation Scanning
The Batch Scanning (Inventory Mode) is set as the default Function Mode. Batch Scanning and Validation Scanning can't be used at the same time. If you want to use the Function Key of pocket scanner to carry out Validation Scanning, you have to change the "FN2 Function Mode" default setting. If you use pocket scanner, you can press and hold the FN 2 for more than 3 seconds to enter Validation Scanning. The scanner will emit 3 short beeps and the status indicator of the scanner will blink green once per 2.5 seconds to indicate the scanner is under Validation Scanning. To exit Validation Scanning, press and hold the FN 2 for more than 3 seconds, the scanner will emit 3 short beeps.
30
Wireless FuzzyScan
Reference Manual
Getting Started
Register Master Data Master Data Registration allows you to register your master data for validating the slave data. You can have the scanner entered or exited "Master Data Registration" by scanning following quick set commands.
Register Master Data
Finish Registering Master Data
If you use pocket scanner, you can also have your scanner entered Master Data Registration by short pressing the FN2. The scanner will emit 2 short beeps and the status indicator will become steady green. Once you complete master data registration, you can have the scanner exited "Master Data Registration" by short pressing FN2
After entering Master Data Registration, you can scan and register single or multiple master data by pressing the Trigger Key. If the master data is registered successfully, the scanner will emit 1 good read short beep.
The default Master Data Registration Setting is preset to" Single Master Data", though you can scan multiple master data continuously, only the last master data will be valid, and the master data registered previous to the last master data will be cleared. The scanner is capable of storing up to 2K byes master data.
All scanned master data will be stored into the memory storage. You can scan and store the barcode data till the memory storage is full. If the storage is full, the scanner will emit 2 long beeps and the status indicator will blink red twice to indicate out of storage. Please note that the registered master data will be eliminated once you power off the scanner You can clear the master data by scanning following command.
Clear Master Data
31
Wireless FuzzyScan
Reference Manual
Getting Started
After registering master data, you can check registered master data by scanning following command.
Check Master Data
If the scanner is under "Master Data Registration" and put onto cradle for charging, the status indicator will show battery status indication. Once the scanner leaves the cradle, the scanner will resume to previous status, and the status indicator will present correspondent status indication.
32
Wireless FuzzyScan
Reference Manual
Getting Started
Toggle between Barcode Scanning and On-screen Keyboard Input
You can toggle between use barcode scanning and on-screen keyboard input of the mobile device. To activate the on-screen keyboard input function; you can turn off the radio by scanning "Switch On-screen Keyboard" command. If you use pocket scanner, you can turn off the radio to activate the on-screen keyboard input by short pressing the FN1 Once you finished the keyboard input, pressing the trigger once to turn on the radio, the on-screen keyboard input function will be inactivated.
The scanner is preset to use "General Approach" by controlling the radio to toggle between barcode scanning and on-screen keyboard input of most popular mobile devices. To work with iOS devices, please scan "iOS Ap n-screen keyboard input. If you use pocket scanner, the FN1 can be set to "iOS Approach" to quickly toggle iOS on-screen keyboard input, and you can also toggle the iOS on-screen keyboard input by short pressing the FN1.
General Approach
iOS Approach
Switch On-screen Keyboard
Presentation Scanning (Pistol type scanner only)
The Presentation Scanning is designed for hand-free applications for user's convenience. If the "Presentation Scanning Auto-sense" function is enabled, the scanner is capable of automatically switching to presentation mode as soon as you place it onto the SmartStand or cradle.
Enable Auto-sense
Disable Auto-sense
Wireless FuzzyScan
Reference Manual
33
Getting Started
Check Battery Status
You can check battery status of the scanner by short pressing the Left Key or scanning "Check Battery Status" command. Please refer to the "Battery Status Indication" shown on page 1 for details.
Check Battery Status
Battery Status Indication
The following corresponding flashes of the LED indicators present the current battery status of the scanner.
LED Indication 3 green and blue flashes 3 green flashes 3 orange flashes 3 red flashes
Battery Status More than 75% More than 50% More than 25% Less than 25%
Paging Function
The Paging function is helpful for you to locate the paired smart cradle or scanner. If you would like to page the paired smart cradle, you can scan "Paging" command. If you would like to page the paired scanner, you can press the paging/reset button of the smart cradle no longer than 3 seconds.
Wireless FuzzyScan
Reference Manual
Paging/Reset Button
34
Paging
Configuring Your Scanner
CONFIGURING YOUR SCANNER
Configuration Barcode Menu
The FuzzyScan barcode commands are specially designed Proprietary bar code labels which allow you to set the FuzzyScan internal programming parameters. There are System Command, Family Code and Option Code for programming purpose.
Each programmable family and bar code command label is listed on the same page with major system commands. The detailed explanations and special programming flowchart are printed on facing or following pages. You can read the explanation and set the FuzzyScan concurrently.
A supplemental bar code command menu incorporates the bar code command labels of System Command and Option Code. As you set the FuzzyScan, open the bar code command menu to find the option code page. You may scan the desired family code and option code to set FuzzyScan. If you want to change the programming family for multiple settings, you need only turn over the programming page to find next desired programming family.
System Command
The System Command is the highest level bar code command which directs FuzzyScan to perform immediate operations, such as entering programming mode (PROGRAM), exiting programming mode (EXIT), listing system information (SYSLIST), recovering to factory preset configurations (M_DEFAULT), and so on. Please note that all system commands will take a few seconds to complete the operations. User must wait for the completion beeps before scanning another bar code.
Family Code
The Family Code is scanned to select the user desired programming family. FuzzyScan has already provided more than one hundred programming families to meet any specific requirements.
Option Code
The Option Codes is a set of bar code commands represented by "09", "AF" and finishing selection (FIN). For most setting, you must select at least one option code following the family code selection to set the desired parameter for the selected programming family.
Wireless FuzzyScan
Reference Manual
35
Configuring Your Scanner
Programming Procedures
As you scan the bar code command to select the desired parameters, information about the final selected parameters represented by the bar code commands are stored in the FuzzyScan's internal Flash Memory ASIC or non-volatile memory. If you turn off the unit, the Flash Memory ASIC or non-volatile memory retains all programming options. You need not re-program the FuzzyScan if you want to keep the existing configurations in the next power on.
The programming procedures of FuzzyScan are designed as simple as possible for ease of setting. Most programming families take the Single Scan Selection programming procedure. But several programming families have more complex and flexible programmable options, and you must take Multiple Scans Selection, Cycling Scan Selection or Dual Level Selection to complete their programming procedures. Each kind of programming procedure is listed in the following pages for your reference. Please give careful attention to become familiar with each programming procedure.
If the programming family must take multiple scans selection, cycling scan selection, or dual level selection procedures, the family of the programming menu will be marked with the matched representing symbol of Programming Category (P.C.) in bold font listed in the following table. You can easily find the bold mark in the programming menu, and refer to their flowcharts for details. Before setting the FuzzyScan, please also refer to the "Beeping Indications" listed in Appendix to understand the details of programming beeping indications. It will be very helpful for you to know the existing status while you are programming the FuzzyScan.
Conventions of Programming Menu
Conventions
Descriptions Factory Default Value
P.C.
Programming Category
SS : Single scan selection MS : Multiple scans selection CS : Cycling scan selection DS : Dual level scan selection
( )
Necessary Option Code
[ ]
Selectable Option Code
Wireless FuzzyScan
Reference Manual
36
Program & End
Configuring Your Scanner
System List, Group & Master Default
Scan "PROGRAM"
FuzzyScan will enter programming mode, and inhibit all non-programming functions.
Scan "END"
FuzzyScan will exit programming mode, and store all parameters in Flash Memory ASIC or non-volatile memory,
then issue the completion beeping.
Scan "SYSLIST"
FuzzyScan will list the product information and revision number to host via selected host interface,
then issue the completion beeping.
Scan "M_DEFAULT"
FuzzyScan will recover all programmable parameters into factory preset configurations,
then issue the completion beeping.
Please note that the FuzzyScan will take 3-4 seconds to store parameters in internal Flash Memory ASIC or non-volatile memory after you scan the "END". Please don't turn off the power before the completion beeping. It may destroy all configured parameters.
Wireless FuzzyScan
Reference Manual
37
Configuring Your Scanner
Single scan selection
Scan "PROGRAM"
Enter programming mode.
Scan One of Family Codes
Scan One of Option Codes
Select one of desired programming families.
Select one option code of desired parameter.
Yes Repeat Selection
No Scan "END"
Want to select another programming family?
Exit programming mode.
Multiple scans selection
Scan "PROGRAM"
Enter programming mode.
Scan One of Family Codes
Scan One or Several Option Codes
Yes Repeat Selection
No Scan "END"
Select one of desired programming families.
1. Select one or several option codes to select desired parameters.
2. If it's necessary, scan "FIN" to terminate option code selection.
Want to select another programming family?
Exit programming mode.
Wireless FuzzyScan
Reference Manual
38
Configuring Your Scanner
Cycling scan selection
Dual level selection
Scan "PROGRAM"
Enter program m ing m ode.
Scan One of Fam ily Codes
Scan One of Option Codes
Scan "FIN "
Ye s
Repeat
Selection
No Scan "END"
Select one of desired program m ing fam ilies.
Cycling select one or several option codes of desired param eters as "Single" or "Multiple" scans selection.
Finish cycling selection. (If necessary)
W ant to select another program m ing fam ily?
Exit program m ing m ode.
Scan "P R O G R A M "
Enter program m ing m ode.
Scan One of Fam ily Codes
Select one of desired program m ing fam ilies.
(1st) Scan Several Option Codes
(2nd) Scan One or Several Option Codes
Ye s
Repeat
Selection
No Scan "END"
Select several option codes of desired param eters. 1. Select one or several
option codes of desired param eters. 2. If it's n ecessary, scan "FIN" to term inate option code selection.
W ant to select another program m ing fam ily?
Exit program m ing m ode.
Wireless FuzzyScan
Reference Manual
39
Configuring Your Scanner
Host Interface Selection
PROGRAM Family Code Selection
Host Interface Selection
P.C
Parameter Selection
MS IBM PS/2, 25-30 series keyboard wedge interface MS Standard/TTL RS-232 peer-to-peer serial MS Wand emulation MS USB Com Port Emulation MS PS/2 (DOS/V) direct link (keyboard replacement) MS PS/2 (DOS/V) keyboard wedge turbo mode MS PS/2 (DOS/V) keyboard wedge standard mode MS Laser emulation MS USB HID standard mode MS USB HID turbo mode MS USB HID Legacy MS USB EFT Terminal Mode
A series doesn't support Wand emulation, Laser emulation, and USB HID Legacy Mode.
F_DEFAULT
Option Code
02 06 08 09 10 13 14 17 18 19 20 21
Wireless FuzzyScan
Reference Manual
40
Configuring Your Scanner
PROGRAM Family Code Selection
Symbol ID : 1 character
Symbology Reading Control User Defined Symbol ID
P.C
Parameter Selection
DS Code 128 (default=B) GS1-128 (default=C) UPC-A (default=A) EAN-13 (default=F) Codabar/NW-7 (default=D) Code 39/Code 32 (default=G) Code 93 (default=H) Standard/Industrial 2 of 5 (default=I) Interleaved 2 of 5 (default=J) Matrix 2 of 5 (default=K) China Postal Code (default=L) German Postal Code (default=M) IATA (default=O) Code 11 (default=P) MSI/Plessey (default=R) UK/Plessey (default=S) Telepen (default=T) GS1 DataBar (default=X) UPC-E (default=E) EAN-8 (default=N) Trioptic Code 39 (default=W) UCC Coupon Extended Code (default=Z) PDF417/Micro PDF417 (default=V) Codablock F (default=Y) Code 16K (default=Q) Code 49 (default=U) Korea Post Code (default=a)
QR & Micro QR Code (default=b) Data Matrix (default=c)
Maxi Code (default=d)
Option Code
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
26
28 29 30
F_DEFAULT 2nd Option Code
(1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character)
(1 character)
(1 character) (1 character) (1 character)
Wireless FuzzyScan
Reference Manual
41
Configuring Your Scanner
PROGRAM Family Code Selection
Symbol ID : 1 character
Symbology Reading Control
User Defined Symbol ID (continued)
P.C
Parameter Selection
DS Aztec Code (default=e) Chinese Sensible (default=f) Australian Post (default=g) British Post (default=h) Intelligent Mail (USPS 4CB/One Code) (default=j) Japan Post (default=k) Netherlands KIX Post (default=l) US Planet (default=m) US Postnet (default=o)
Option Code
31 32 33 34 36 37 38 39 41
F_DEFAULT
2nd Option Code
(1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character) (1 character)
Wireless FuzzyScan
Reference Manual
42
Configuring Your Scanner
PROGRAM Family Code Selection
Symbology ID Transmission
Symbology Reading Control Symbology ID Transmission
P.C
Parameter Selection
SS Disable symbology ID transmission SS Enable prefix CINO symbology ID transmission SS Enable suffix CINO symbology ID transmission SS Enable both prefix and suffix CINO symbology ID transmission SS Enable prefix AIM symbology ID transmission SS Enable suffix AIM symbology ID transmission SS Enable both prefix and suffix AIM symbology ID transmission
F_DEFAULT
Option Code
0 1 2 3 4 5 6
Wireless FuzzyScan
Reference Manual
43
Configuring Your Scanner
PROGRAM
Family Code Selection ECI ID Output
Symbology Reading Control ECI ID Output
(A Series, PA Series)
P.C
Parameter Selection
SS Disable ECI ID Output SS Enable ECI ID Output
F_DEFAULT
Option Code
0 1
* The ECI (Extended Channel Interpretation) is embedded information in a bar code that tells the used references for encoding the data in the symbol. By enabling ECI ID output, the associated ECI ID value will be outputted with the data at the same time.
Wireless FuzzyScan
Reference Manual
44
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
Symbology Reading Control
PROGRAM
Readable Bar Code Setting
Family Code Selection P.C
Parameter Selection
Readable Symbology Setting
SS Auto CS Popular 1D
CS Code 128 *
CS GS1-128 *
CS UPC-A *
CS UPC-E *
CS EAN-13 *
CS EAN-8 *
CS Codabar/NW-7 *
CS Code 39 *
CS Trioptic Code 39
CS Standard/Industrial 2 of 5
CS Matrix 2 of 5
CS Interleaved 2 of 5 *
Remember to scan "FIN" to terminate
CS
China Postal Code
this selection. But if you select the
CS Germany Postal Code
"Auto", FuzzyScan will terminate this
CS CS
Code 93 * Code 11
selection automatically.
CS MSI/Plessey
CS UK/Plessey
CS Telepen
CS GS1 DataBar (RSS-14) *
CS IATA
CS PDF417 * /Micro PDF417
CS Codablock F
CS Code 16K
CS Code 49
CS Korea Post Code
CS QR Code */ Micro QR Code *
CS Data Matrix *
CS MaxiCode
CS Aztec Code *
CS Chinese Sensible (Han Xin) Code
45
F_DEFAULT
Option Code
00 C0 01 31 02 03 04 05 06 07 47 08 38 48 58 68 09 10 11 12 13 14 15 17 18 19 20 21 A0 A1 A2 A3 A4
Configuring Your Scanner
Symbology Reading Control
PROGRAM
Readable Bar Code Setting (continued)
F_DEFAULT
Family Code Selection P.C
Parameter Selection
Option Code
Readable Symbology Setting
CS Australian Post CS British Post
B0 B1
CS Intelligent Mail barcode
B3
CS Japanese Post
B4
CS KIX Post
B5
CS Planet Code
B6
CS Postnet
B8
If your application is known, you may select those known symbologies only to increase the reading speed and decrease the possibility of reading error. Furthermore, to add
the "Symbology ID" into the transmitted data is also helpful to identify the specific symbology.
Above symbologies marketed with * are enabled as default. When you select "Auto", the scanner only reads those symbologies marked with *.
"Popular 1D" includes "Code 128", "GSA-128", "UPC-A", "UPC-E", "EAN-13", "EAN-8", "Codabar/NW-7", "Code 39", " Interleaved 2 of 5", "Code 93", "GS1 DataBar
(RSS-14)". When you set the minimum and maximum length of each symbology, please note the data length of scanned bar code doesn't include start/stop characters.
Wireless FuzzyScan
Reference Manual
46
Configuring Your Scanner
PROGRAM Family Code Selection
Code 39 Family Setting
Trioptic Code 39 Setting
Symbology Reading Control Code 39/Code 32 Setting
P.C
Parameter Selection
SS Disable Code 39 SS Enable Code 39 SS Select Standard Code 39 as primary format
SS Select Full ASCII Code 39 as primary format
SS Select Code 32 (PARAF, Italian Pharmaceutical) as primary format SS Disable start/stop symbol transmission
SS Enable start/stop symbol transmission SS Disable Code 32 leading A transmission
SS Enable Code 32 leading A transmission SS Disable MOD 43 check digit verification
SS Enable MOD 43 check digit verification SS Disable check digit transmission
SS Enable check digit transmission SS Disable Code 39 buffering
SS Enable Code 39 buffering
SS Disable Trioptic Code 39 SS Enable Trioptic Code 39
F_DEFAULT
Option Code
0 1 2 3 4 5 6 7 8 9 A B C D E
0 1
Wireless FuzzyScan
Reference Manual
Code 39 Min. Length
SS Default (01) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
Code 39 Max. Length
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
Trioptic Code 39 and Code 39 Full ASCII cannot be enabled simultaneously.
47
FIN (2 digits)
FIN (2 digits)
Configuring Your Scanner
PROGRAM Family Code Selection
Code 39 Security Level
Symbology Reading Control Code 39/Code 32 Setting (continued)
P.C
SS Level 0 SS Level 1 SS Level 2 SS Level 3
Parameter Selection
F_DEFAULT
Option Code
0 1 2 3
Code 39 Security Level The scanner offers four levels of decode security for Code39 bar codes:
Level 0: If you are experiencing misread of poorly-printed or serious out-of-spec. bar codes in level 1, please select level 0.
Level 1: If you are experiencing misread of poorly-printed or out-of-spec. bar codes in level 2, please select level 1. Level 2: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding "in-spec" Code39 bar codes. Level 3: If you failed to read poorly-printed or out-of-spec. bar codes in level 2, please select level 3. This is the most aggressive setting and may increase the misread.
Wireless FuzzyScan
Reference Manual
48
Configuring Your Scanner
PROGRAM Family Code Selection
Codabar Setting
Codabar Check Digit Settings Codabar Min. Length
Symbology Reading Control Codabar/NW-7 Setting
P.C
Parameter Selection
SS Disable Codabar SS Enable Codabar SS Select Codabar standard format
SS Select Codabar ABC format SS Select Codabar CLSI format SS Select Codabar CX format SS Disable start/stop symbol transmission SS Enable ABCD/ABCD start/stop symbol transmission SS Enable abcd/abcd start/stop symbol transmission
SS Enable ABCD/TN*E start/stop symbol transmission SS Enable abcd/tn*e start/stop symbol transmission SS Disable check digit verification
SS Enable check digit verification SS Disable check digit transmission SS Enable check digit transmission
SS Modulus 16 SS Modulus 10/weight 3 SS Modulus 11 SS Modulus 10/weight 2 SS 7 check DR SS Weight Modulus 11 SS Runes (Modulus 10/weight 2)
SS Default (04) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
F_DEFAULT
Option Code
0 1 2 3 4 5 6 7 8 9 A B C D E
0 1 2 3 4 5 6
FIN (2 digits)
Wireless FuzzyScan
Reference Manual
49
Configuring Your Scanner
PROGRAM Family Code Selection
Codabar Max. Length
Symbology Reading Control
Codabar/NW-7 Setting (continued)
P.C
Parameter Selection
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
F_DEFAULT
Option Code
FIN (2 digits)
Wireless FuzzyScan
Reference Manual
50
Configuring Your Scanner
Symbology Reading Control
PROGRAM
UPC-A & UPC-E Setting
F_DEFAULT
Family Code Selection P.C
Parameter Selection
Option Code
UPC Family Setting
SS Disable UPC-A
0
SS Enable UPC-A
1
SS Disable UPC-E
2
SS Enable UPC-E
3
SS Disable UPC-E expansion
4
SS Enable UPC-E expansion
5
SS Disable UPC standardization
6
SS Enable UPC standardization
7
SS Disable UPC numeric system
8
SS Enable UPC numeric system
9
SS Disable UPC-A check digit transmission
A
SS Enable UPC-A check digit transmission
B
SS Disable UPC-E check digit transmission
C
SS Enable UPC-E check digit transmission
D
SS Disable UPC "leading 1" portion
E
SS Enable UPC "leading 1" portion
F
When enable UPC-E expansion, the UPC-E decoded data will be converted to UPC-A format and affected by related setting, such as UPC standardization, UPC numeric
system, UPC-A check digit transmission.
UPC-E & EAN-8 Expansion
: Expand the 8-digit UPC-E and 8-digit ENA-8 to 12-digit UPC-A and 13-digit EAN-13.
UPC-A/E Standardization
: Expand the 12-digit UPC-A to 13-digit EAN-13 with 1 zero insertion.
UPC Lead 1 Numeric System
: Enable to read UPC leading with the 1 numeric system, you must enable this option.
WPC Selection (UPC/EAN/CAN)
UPC-A UPC-E EAN-13 EAN-8
Basic Length
12 8 13 8
Disable Check Digit
- 1 - 1 - 1 - 1
Disable Numeric System
- 1 - 1 NC NC
With 2-digit Addendum
+ 2 + 2 + 2 + 2
With 5-digit Addendum
+ 5 + 5 + 5 + 5
Enable Standardization
+ 1 + 1 NC NC
Enable Expansion
0 + 4 0 + 5
Wireless FuzzyScan
Reference Manual
51
Configuring Your Scanner
PROGRAM Family Code Selection
UPC Supplement Setting
UPC/EAN Security Level
Symbology Reading Control
UPC-A & UPC-E Setting (continued)
P.C
Parameter Selection
SS Select UPC without supplement digits SS Select UPC with only 2 supplement digits SS Select UPC with only 5 supplement digits SS Select UPC with 2/5 supplement digits SS Disable force supplement digits output SS Enable force supplement digits output SS UPC Family Addenda Separator Off SS UPC Family Addenda Separator On
SS Level 0 SS Level 1 SS Level 2
Only available for UPC-A & EAN-13
F_DEFAULT
Option Code
0 1 2 3 4 5 6 7
0 1
2
Supplement Scan Voting
SS None SS Level 1 SS Level 2 SS Level 3 SS Level 4 SS Level 5 SS Level 6
Level 7 Level 8 Level 9 Level 10 Level 11 Level 12 Level 13
0
7
1
8
2
9
3
A
4
B
5
C
6
D
UPC/EAN Security Level The scanner offers three levels of decode security for UPC/EAN bar codes:
Level 0: If you are experiencing misread of poorly-printed or out-of-spec. bar codes, especially in characters 1, 2, 7, and 8 in level 1, please select level 0. Selection of this security level may significantly impair the decoding ability of the scanner.
Level 1: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding "in-spec" UPC/EAN bar codes. Level 2: If you failed to read poorly-printed or out-of-spec. bar codes in level 1, please select level 2. This is the most aggressive setting and may increase the misread. The Supplement Scan Voting is the number of times the same UPC/EAN with 2/5 supplement digits has to be decoded before it is transmitted. It is helpful when decoding a mix of UPC/EAN symbols with and without supplement digits. This function is effective when you select UPC/EAN with only 2 supplement digits, UPC/EAN with only 5 supplement digits or UPC/EAN with 2/5 supplement digits. The default value is Level 3. When you select higher level, it may impact the reading speed on poorly-printed, low contrast or damage barcode labels.
Wireless FuzzyScan
Reference Manual
52
Configuring Your Scanner
Symbology Reading Control
PROGRAM
EAN Setting
F_DEFAULT
Family Code Selection P.C
Parameter Selection
Option Code
EAN Setting
SS Disable EAN-13
0
SS Enable EAN-13
1
SS Disable EAN-8
2
SS Enable EAN-8
3
SS Disable EAN-8 expansion
4
SS Enable EAN-8 expansion
5
SS Disable EAN-13 check digit transmission
6
SS Enable EAN-13 check digit transmission
7
SS Disable EAN-8 check digit transmission
8
SS Enable EAN-8 check digit transmission
9
SS Disable ISBN/ISSN Conversion reading check
A
SS Enable ISBN/ISSN Conversion reading check
B
EAN Supplement Setting
SS Select EAN without supplement digits
0
SS Select EAN with only 2 supplement digits
1
SS Select EAN with only 5 supplement digits
2
SS Select EAN with 2/5 supplement digits
3
SS Disable force supplement digits output
4
SS Enable force supplement digits output
5
SS EAN Addenda Separator Off
6
SS EAN Addenda Separator On
7
Supplement Scan Voting
SS None SS Level 1 SS Level 2 SS Level 3 SS Level 4 SS Level 5 SS Level 6
Level 7 Level 8 Level 9 Level 10 Level 11 Level 12 Level 13
0
7
1
8
2
9
3
A
4
B
5
C
6
D
The Supplement Scan Voting is the number of times the same UPC/EAN with 2/5 supplement digits has to be decoded before it is transmitted. It is helpful when decoding a mix of UPC/EAN symbols with and without supplement digits. This function is effective when you select UPC/EAN with only 2 supplement digits, UPC/EAN with only 5 supplement digits or UPC/EAN with 2/5 supplement digits. The default value is Level 3. When you select higher level, it may impact the reading speed on poorly-printed, low contrast or damage barcode labels.
53
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
Symbology Reading Control
PROGRAM Family Code Selection
UPC/EAN Security Level
EAN Setting (continued)
P.C
Parameter Selection
SS Level 0 SS Level 1 SS Level 2
Only available for UPC-A & EAN-13
F_DEFAULT
Option Code
0 1 2
EAN Supplement Control
SS Disable all specific prefix supplement digital output
0
SS Enable all specific prefix supplement digital output
1
SS Enable 491 Supplement Digit Output
2
SS Enable 978/979 Supplement Digit Output
3
SS Enable 977 Supplement Digit Output
4
SS Enable 378/379 Supplement Digit Output
5
SS Enable 414/419 Supplement Digit Output
6
SS Enable 434/439 Supplement Digit Output
7
UPC/EAN Security Level The scanner offers three levels of decode security for UPC/EAN bar codes:
Level 0: If you are experiencing misread of poorly-printed or out-of-spec. bar codes, especially in characters 1, 2, 7, and 8 in level 1, please select level 0. Selection of this security level may significantly impair the decoding ability of the scanner.
Level 1: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding "in-spec" UPC/EAN bar codes. Level 2: If you failed to read poorly-printed or out-of-spec. bar codes in level 1, please select level 2. This is the most aggressive setting and may increase the misread. EAN Supplement Control
If you select EAN with only 2, or 5 or 2/5 supplement digits and enable 491 prefix supplement digit output, the scanner will transmit EAN with 2, or 5 or 2/5 supplement
digits bar codes starting with 491 prefix. The EAN without supplement digit will not be transmitted.
If you select EAN with only 2, or 5 or 2/5 supplement digits and enable the other except 491 prefix supplement digit output, the scanner will transmit EAN with 2, or 5, or 2/5
supplement digits bar codes starting with specific prefix. The EAN without supplement digit will be transmitted.
Wireless FuzzyScan
Reference Manual
54
Configuring Your Scanner
PROGRAM Family Code Selection UCC Coupon Extended Code
Symbology Reading Control UCC Coupon Extended Code Setting
P.C
Parameter Selection
SS Disable UCC Coupon Extended Code SS Enable UCC Coupon Extended Code
F_DEFAULT
Option Code
0 1
UCC Coupon Extended Code When UCC coupon extended code function is enabled, scanner decodes UPC-A barcodes starting with digit "5", EAN-13 barcodes starting with digit "99" and GS1-128 Coupon Codes. UPC-A, EAN-13 and EAN-128 must be enabled to scan all types of Coupon Codes.
Wireless FuzzyScan
Reference Manual
55
Configuring Your Scanner
PROGRAM Family Code Selection
IATA Setting
Interleaved 2 of 5 Setting
Symbology Reading Control IATA & Interleaved 2 of 5 Setting
P.C
Parameter Selection
SS Disable IATA SS Enable IATA SS Select 15-digit fixed length IATA checking SS Select variable length IATA SS Disable check digit verification SS Enable check digit automatic verification SS Enable S/N checking digit verification only SS Enable CPN checking digit verification only SS Enable CPN, Airline and S/N check digit verification SS Disable check digit transmission SS Enable check digit transmission SS Disable start/stop symbol transmission SS Enable start/stop symbol transmission
SS Disable Interleaved 2 of 5 SS Enable Interleaved 2 of 5 SS Select Interleaved 2 of 5 as primary format
SS Select German Postal Code as primary format SS No check character
SS Validate USS check digit
SS Validate OPCC check digit SS Disable check digit transmission
SS Enable check digit transmission
F_DEFAULT
Option Code
0 1 2 3 4 5 6 7 8 9 A B C
0 1 2 3 4 5 6 7 8
Wireless FuzzyScan
Reference Manual
56
Configuring Your Scanner
Symbology Reading Control
PROGRAM
Code 25 Family Setting
F_DEFAULT
Family Code Selection Code 25 Setting
P.C
Parameter Selection
SS Disable Standard/Industrial 2 of 5
SS Enable Standard/Industrial 2 of 5 SS Disable Matrix 2 of 5
SS Enable Matrix 2 of 5 SS Disable China Postal Code
SS Enable China Postal Code SS Disable check digit verification
SS Enable check digit verification SS Disable check digit transmission
SS Enable check digit transmission
Option Code
0 1 2 3 4 5 6 7 8 9
Code 25 Family Min. Length
SS Default (04) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
FIN (2 digits)
Code 25 Family Max. Length
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
FIN (2 digits)
For Code25 setting, we recommend you to select only one type of Code 25 or set the maximum/minimum bar code length. To decode all types of Code 25 or to variable length of Code 25 will increase the possibility of reading error.
Wireless FuzzyScan
Reference Manual
57
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM Family Code Selection
Code 11 Setting
Code 11 Min. Length Code 11 Max. Length
Code 93 Setting Code 93 Min. Length Code 93 Max. Length
Symbology Reading Control Code 11 & Code 93 Setting
P.C
Parameter Selection
SS Disable Code 11 SS Enable Code 11 SS Disable check digit verification SS Select 1-check digit verification SS Select 2-check digit verification SS Disable check digit transmission SS Enable check digit transmission
SS Default (04) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Disable Code 93 SS Enable Code 93 SS Disable check digit transmission
SS Enable check digit transmission
SS Default (01) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
58
F_DEFAULT Option Code
0 1 2 3 4 5 6 FIN (2 digits)
FIN (2 digits)
0 1 2 3
FIN (2 digits)
FIN (2 digits)
Configuring Your Scanner
PROGRAM Family Code Selection
MSI/Plessey Setting
MSI/Plessey Min. Length
MSI/Plessey Max. Length
Symbology Reading Control MSI/Plessey Setting
P.C
Parameter Selection
SS Disable MSI/Plessy SS Enable MSI/Plessy SS Select MOD 10 check digit SS Select MOD 10-10 check digit SS Select MOD 11-10 check digit SS Disable check digit transmission SS Enable check digit transmission
SS Default (04) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
F_DEFAULT Option Code
0 1 2 3 4 5 6
FIN (2 digits)
FIN (2 digits)
Wireless FuzzyScan
Reference Manual
59
Configuring Your Scanner
PROGRAM Family Code Selection
Code 128 Setting
Code 128 Min. Length
Code 128 Max. Length
Code 128 Security Level
Symbology Reading Control Code 128 Setting
P.C
Parameter Selection
SS Disable Code 128 SS Enable Code 128 SS ISBT Concatenation Off
SS ISBT Concatenation On
SS ISBT Concatenation On Check ISBT table SS ISBT Concatenation Auto
SS Default (01) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Level 0 SS Level 1
F_DEFAULT Option Code
0 1 2 3 4 5 FIN (2 digits)
FIN (2 digits)
0 1
Code 128 Setting ISBT Concatenation Off: The scanner will not output ISBT concatenated barcodes. ISBT Concatenation On: The scanner will only decode and output ISBT concatenated barcodes. The scanner will not decode or output single ISBT barcodes. ISBT Concatenation On Check ISBT table: The scanner will only output ISBT concatenated barcodes that conform to ICCBBA standards. The scanner will not output single ISBT barcodes or ISBT concatenated barcodes that do not conform to ICCBBA standards. ISBT Concatenation Auto: The Scanner will decode and output both ISBT concatenated barcodes and single ISBT barcodes.
Code 128 Security Level The scanner offers two levels of decode security for Code128 bar codes: Level 0: If you are experiencing misread of poor-printed or out-of-spec. bar code in level1, please select level 0. Level 1: This is the default setting which allows the scanner to operate fastest, while providing sufficient security in decoding "in-spec." Code128 bar codes.
Wireless FuzzyScan
Reference Manual
60
Configuring Your Scanner
PROGRAM Family Code Selection
GS1-128 Setting
Symbology Reading Control GS1-128 Setting
P.C
SS Disable GS1-128 SS Enable GS1-128
Parameter Selection
F_DEFAULT
Option Code
0 1
GS1-128 Min. Length
SS Default (01) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
FIN (2 digits)
GS1-128 Max. Length
SS Default (98) MS 98-Minimum
FIN (2 digits)
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
GS1-128 Function Control
SS Disable GS1-128 special function
0
SS Enable GS1-128 special function
1
SS Disable First FNC1 transmission
2
SS Enable First FNC1 convert to "]C1" and transmission
3
SS Disable Application Identifier output
4
SS Enable Application Identifier output
5
SS Enable Application Identifier output with additional "()"
6
SS Disable "DD=00" transmission when AI data field contains the date
7
SS Enable "DD=00" transmission when AI data field contains the date
8
SS Disable decimal point insert
9
SS Enable decimal point insert
A
For First FNC1 transmission, chart of the FNC1 is provided in Appendix-Keyboard Function Code Table. When the scanner is set to Keyboard Interface, the scanned
code is converted to corresponding key function value before it is transmitted.
Wireless FuzzyScan
Reference Manual
61
Configuring Your Scanner
PROGRAM Family Code Selection
GS1-128 FNC1 Setting
Symbology Reading Control GS1-128 Setting (continued)
P.C
Parameter Selection
SS None
SS GS (1DH)
MS User defined character (1~2 characters)
GS1-128 Element String Separator
SS None MS User defined character (1~2 characters)
F_DEFAULT Option Code
0 1 2, [GS1-128 ASCII Table] [FIN]
FIN [GS1-128 ASCII Table], [FIN]
GS1-128 Data Separator
SS None MS User defined character (1~2 characters)
GS1-128 Error Converting
SS When the conversion from code 128 to GS1 128 is failed, the code 128 SS is not output
When the conversion from code 128 to GS1 128 is failed, the code 128
is output directly without conversion
FIN [GS1-128 ASCII Table], [FIN]
0 1
Wireless FuzzyScan
Reference Manual
62
Configuring Your Scanner
PROGRAM Family Code Selection
UK/Plessey Setting
UK/Plessey Min. Length UK/Plessey Max. Length
Symbology Reading Control UK/Plessey Setting
P.C
Parameter Selection
SS Disable UK/Plessey
SS Enable UK/Plessey SS Select UK/Plessey Standard Format
SS Select UK/Plessey CLSI Format SS Disable Convert X to A-F
SS Enable Convert X to A-F SS Disable check digit transmission
SS Enable check digit transmission
SS Default (04) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
F_DEFAULT Option Code
0 1 2 3 4 5 6 7
FIN (2 digits)
FIN (2 digits)
Wireless FuzzyScan
Reference Manual
63
Configuring Your Scanner
PROGRAM Family Code Selection
Telepen Setting
Telepen Min. Length
Telepen Max. Length
Symbology Reading Control Telepen Setting
P.C
Parameter Selection
SS Disable Telepen
SS Enable Telepen SS Select Telepen Numeric mode SS Select Telepen Full ASCII mode SS Disable check digit transmission SS Enable check digit transmission
SS Default (04) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (98) MS 98-Minimum
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
F_DEFAULT Option Code
0 1 2 3 4 5 FIN (2 digits)
FIN (2 digits)
Wireless FuzzyScan
Reference Manual
64
Configuring Your Scanner
PROGRAM Family Code Selection
GS1 DataBar Setting
GS1 DataBar Min. Length
GS1 DataBar Max. Length
Symbology Reading Control GS1 DataBar Setting
P.C
Parameter Selection
SS Disable GS1 DataBar (RSS-14) SS Enable GS1 DataBar (RSS-14)
SS Disable GS1 DataBar Limited SS Enable GS1 DataBar Limited
SS Disable GS1 DataBar Expanded SS Enable GS1 DataBar Expanded
SS Default (04) MS 01- Maximum
Only available for Expanded GS1 Databar. Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (74) MS 74-Minimum
Only available for Expanded GS1 Databar.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
F_DEFAULT Option Code
0 1 2 3 4 5 FIN (2 digits)
FIN (2 digits)
Wireless FuzzyScan
Reference Manual
65
Configuring Your Scanner
PROGRAM
Symbology Reading Control
Composite Codes, Codablock F, & PDF417/MicroPDF417 Setting
Family Code Selection Composite Codes Setting
Codablock F Setting
P.C
Parameter Selection
SS Disable composite codes
SS Enable composite codes
SS UPC Composite Mode: UPC never linked
SS UPC Composite Mode: UPC always linked
If UPC Composite Mode: UPC never linked is selected, UPC barcodes are transmitted whether MicroPDF417 symbol is detected or not.
If UPC Composite Mode: UPC always linked is selected, UPC barcodes are only transmitted when the MicroPDF417 is detected.
SS Disable SS Enable
F_DEFAULT
Option Code
0 1 2 3
0 1
PDF417/Micro PDF417 Setting SS Disable PDF417
0
SS Enable PDF417
1
SS Disable MicroPDF417
2
SS Enable MicroPDF417
3
Wireless FuzzyScan
Reference Manual
66
Configuring Your Scanner
PROGRAM Family Code Selection
Code 16K Setting
Symbology Reading Control Code 16K & Code 49 Setting
P.C
SS Disable Code 16K SS Enable Code 16K
Parameter Selection
F_DEFAULT
Option Code
0 1
Code 16K Min. Length Code 16K Max. Length
Code 49 Setting
SS Default (01) MS 01-Maximum
Scan 3 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
SS Default (160) MS 160-Minimum
Scan 3 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
SS Disable Code 49 SS Enable Code 49
FIN (3 digits)
FIN (3 digits)
0 1
Code 49 Min. Length Code 49 Max. Length
SS Default (01) MS 01-Maximum
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
SS Default (81) MS 81-Minimum
Scan 2 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
FIN (2 digits)
FIN (2 digits)
Wireless FuzzyScan
Reference Manual
67
Configuring Your Scanner
PROGRAM
Symbology Reading Control ( A Series & PA Series ) QR Code Setting
F_DEFAULT
Family Code Selection P.C
Parameter Selection
Option Code
QR Code Setting QR Code Min. Length
SS Disable QR Code SS Enable QR Code
Disable MicroQR Code Enable MicroQR Code Disable QR Code Append Enable QR Code Append Disable QR Code Inverse Reading Enable QR Code Inverse Reading Auto detect QR Code Inverse Reading Disable QR Code Mirror Images Enable QR Code Mirror Images Auto detect QR Code Mirror Images SS Default (01) MS 01-Maximum
0 1 2 3 4 5 6 7 8 9 A B FIN (4 digits)
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
QR Code Max. Length
SS Default (7089)
FIN
MS 7089-Minimum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
(4 digits)
QR Code Inverse Reading: When Enabled, the scanner only read inversed (white on black) QR codes. If Auto detect is selected the scanner can read both normal and
inversed QR codes. However, Auto detect might increase decoding time under certain circumstances. QR Code Mirror Images: When Enabled, the scanner only read mirrored QR and Micro QR codes. If Auto detect is selected the scanner can read both normal and
mirrored QR/Micro QR codes. However, Auto detect might increase decoding time under certain circumstances.
Wireless FuzzyScan
Reference Manual
68
Configuring Your Scanner
PROGRAM 11Family Code Selection
Data Matrix Setting
Data Matrix Min. Length Data Matrix Max. Length Damaged DM Code Reading
Symbology Reading Control ( A Series & PA Series )
Data Matrix Setting
P.C
Parameter Selection
SS Disable Data Matrix SS Enable Data Matrix
SS Disable Data Matrix Inverse Reading
SS Enable Data Matrix Inverse Reading SS Auto Detect Data Matrix Inverse Reading
SS Disable Data Matrix Mirror Images
SS Enable Data Matrix Mirror Images SS Auto Detect Data Matrix Mirror Images
SS Default (01) MS 01-Maximum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
SS Default (3116) MS 3116-Minimum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
SS Disable SS Enable
F_DEFAULT
Option Code
0 1 4 5 6 7 8 9 FIN (4 digits)
FIN (4 digits)
0 1
Data Matrix Inverse Reading: When Enabled, the scanner only read inversed (white on black) Data Matrix. If Auto detect is selected the scanner can read both normal
and inversed Data Matrix. However, Auto detect might increase decoding time under certain circumstances. Data Matrix Mirror Images: When Enabled, the scanner only read mirrored Data Matrix. If Auto detect is selected the scanner can read both normal and mirrored Data
Matrix. However, Auto detect might increase decoding time under certain circumstances. Damaged DM Code Reading: When using 2D scanner to read small or damaged DataMatrix, you can enable this function to improve the scanner's reading ability. Be
aware that the scanner's snappiness decreases when the function is enabled.
Wireless FuzzyScan
Reference Manual
69
Configuring Your Scanner
PROGRAM
Family Code Selection MaxiCode Setting
Symbology Reading Control ( A Series & PA Series )
MaxiCode Setting
P.C
SS Disable MaxiCode SS Enable MaxiCode
Parameter Selection
F_DEFAULT
Option Code
0 1
MaxiCode Min. Length MaxiCode Max. Length
SS Default (01) MS 01-Maximum
Scan 3 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
SS Default (150) MS 150-Minimum
Scan 3 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
FIN (3 digits)
FIN (3 digits)
Wireless FuzzyScan
Reference Manual
70
Configuring Your Scanner
PROGRAM
Family Code Selection Aztec Code Setting
Symbology Reading Control ( A Series & PA Series )
Aztec Code Setting
P.C
SS Disable Aztec Code SS Enable Aztec Code
Parameter Selection
F_DEFAULT
Option Code
0 1
Aztec Code Min. Length Aztec Code Max. Length
SS Default (01) MS 01-Maximum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
SS Default (3832) MS 3832-Minimum
Scan 4 digits from the option code chart in Appendix; then FuzzyScan will terminate this selection automatically.
FIN (4 digits)
FIN (4 digits)
Wireless FuzzyScan
Reference Manual
71
Configuring Your Scanner
PROGRAM Family Code Selection
Australian Post Setting
US Planet Setting US Postnet Setting British Post Setting Japan Post Setting
Symbology Reading Control
( A Series & PA Series )
Australian Post, US Planet, US Postnet, British Post & Japan Post Setting
P.C
Parameter Selection
SS Disable Australian Post
SS Enable Australian Post
SS Raw format Output
SS Numeric Encoding Output (N Encoding Table)
SS Alphanumeric Encoding Output (C Encoding Table)
SS Auto-discriminate Output (Combination C & N Encoding Table)
SS Disable US Planet SS Enable US Planet SS Disable Check Digit Transmission SS Enable Check Digit Transmission
SS Disable US Postnet SS Enable US Postnet SS Disable Check Digit Transmission SS Enable Check Digit Transmission
SS Disable British Post SS Enable British Post SS Disable Check Digit Transmission SS Enable Check Digit Transmission
SS Disable Japan Post SS Enable Japan Post
F_DEFAULT
Option Code
0 1 2 3 4 5
0 1 2 3
0 1 2 3
0 1 2 3
0 1
Australian Post Setting: Auto-discriminate output option increase the risk of misread because the encoded data format does not specify the Encoding Table used for encoding.
Wireless FuzzyScan
Reference Manual
72
Configuring Your Scanner
PROGRAM
Family Code Selection Netherlands KIX Code Setting
Symbology Reading Control
( A Series & PA Series )
Netherlands KIX Code, Intelligent Mail & Korea Post Code Setting
P.C
Parameter Selection
SS Disable Netherlands KIX Code
SS Enable Netherlands KIX Code
F_DEFAULT
Option Code
0 1
Intelligent Mail Setting
SS Disable Intelligent Mail
0
(USPS 4CB/One Code)
SS Enable Intelligent Mail
1
Korea Post Code Setting
SS Disable
0
SS Enable
1
Length fixed in 6 characters.
Wireless FuzzyScan
Reference Manual
73
Configuring Your Scanner
PROGRAM Family Code Selection
Keyboard Layout
Keyboard Interface Control
Keyboard Layout (Language) Setting
P.C
Parameter Selection
SS USA (QWERTY)
SS France (AZERTY)
SS Germany (QWERTZ)
SS United Kingdom - UK (QWERTY)
SS Canadian French (QWERTY)
SS Spain (Spanish, QWERTY)
SS Sweden/Finland (QWERTY)
SS Portugal (QWERTY)
SS Norway (QWERTY)
SS Spain (Latin America, QWERTY)
SS Italy (QWERTY)
SS Netherlands (QWERTY)
SS Denmark (QWERTY)
SS Belgium (AZERTY)
SS Switzerland-Germany (QWERTZ)
SS Iceland (QWERTY)
SS Japan (DOS/V)
SS Czech (QWERTY)
SS Universal
F_DEFAULT
Option Code
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 99
Please refer to the ASCII/HEX Table listed in the Appendix to determine HEX codes for characters, symbols, and functions to be used as preamble or postamble. To set preamble or postamble as function key output, you must enable the "Function Key Emulation" feature as listed in page 77 first When Universal is selected, ASCII and Extended ASCII characters are sent as sequence of alt key plus numeric keypad value. This is only valid for Windows OS. Keyboard Interface Message String :
Preamble
Data Length
Prefix Symbol ID
Scanned Data
Suffix Symbol ID
Postamble
Record Suffix
1-15 characters
2-4 digits
1 or 3 characters
Variable length
1 or 3 characters
1-15 characters
1 character
Wireless FuzzyScan
Reference Manual
74
Configuring Your Scanner
PROGRAM
Keyboard Interface Control
Record Suffix, Preamble, Postamble, & FNC1 Symbol Character Transmit
Family Code Selection Record Suffix
Preamble
P.C
Parameter Selection
SS None SS RETURN SS TAB SS SPACE SS ENTER (Numeric Key Pad) SS User defined character (1 character)
SS None MS 1-15 characters
Maximum 15-character input; scan "FIN" to terminate this selection.
Postamble
SS None MS 1-15 characters
Maximum 15-character input; scan "FIN" to terminate this selection.
FNC1 Symbol Char. Transmit
SS Disable SS Enable
F_DEFAULT
Option Code
0 1 2 3 4 5, (00-7F) FIN [00-7F], [FIN]
FIN [00-7F], [FIN]
0 1
FNC1 Symbol Char. Transmit: When this function is enabled and the FNC1 is contained in scanned data, the scanner transmits the FNC1 to the host. Chart of theFNC1 is provided in Appendix- Keyboard Function Code Table. When the scanner interface is set to keyboard, the scan code is converted to corresponding key function before it is transmitted.
Wireless FuzzyScan
Reference Manual
75
Configuring Your Scanner
PROGRAM
Family Code Selection Caps Lock Control
Keyboard Interface Control Caps Lock & Caps Lock Release Control
P.C
Parameter Selection
SS "Caps Lock Off" State SS "Caps Lock On" State SS Auto Detect (PC/AT, PS/2, Keyboard Replacement and DOS/V Machines only)
Caps Lock Release Control
SS "Caps Lock On, Caps Off" SS "Caps Lock On, Shift Off"
F_DEFAULT
Option Code
0 1 2
0 1
The function of "Caps Lock Control" is only available for IBM PC/AT, PS/VP, PS/2 series personal computers and compatible machines. While selecting the other host interfaces, these selections don't perform the above functions for you.
Please check the actual Caps Lock state in use while software application is running. If the Caps Lock state is off, select "Caps Lock Off" state, then FuzzyScan will perform normal data transmission. If the Caps Lock state is on, select "Caps Lock On" state. Select "Auto Detect", FuzzyScan will perform special transmission handshaking without changing the status of Caps Lock switch.
Wireless FuzzyScan
Reference Manual
76
Configuring Your Scanner
Keyboard Interface Control
PROGRAM
Delay Setting
F_DEFAULT
Family Code Selection Intermessage Delay
P.C
Parameter Selection
SS None MS 1-99 (x10) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
Option Code
FIN (2 digits)
Intercharacter Delay
SS None MS 1-99 (x5) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
FIN (2 digits)
Interfunction Delay
SS None MS 1-99 (x5) msec.
FIN (2 digits)
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
Intermessage Delay is a time delay between messages output by FuzzyScan. Increasing this delay will help host applications process the incoming data on time. Intercharacter Delay is a time delay between data characters output by FuzzyScan. This parameter is used to synchronize data communication when : 1) the data
transmission speed is too fast, characters may be skipped; 2) multitasking operation system or host computers in a network may slow down the keyboard handling; 3) various notebook or desktop PC systems require different timing parameter settings. Please always add one extra unit as safety margin when adjusting this parameter Interfunction Delay is a time delay between the transmissions of each segment of the message string.
Intermessage Delay, Intercharacter Delay, and Interfunction Delay are unconfigurable under SPP and HID modes.
Wireless FuzzyScan
Reference Manual
77
Configuring Your Scanner
PROGRAM Family Code Selection
Function Key Emulation
Key Pad Emulation
Keyboard Interface Control
Function Key & Key Pad Emulation, Upper/Lower Case & Dollar Sign Control
P.C
Parameter Selection
SS Enable Keyboard Function Code Table 1 Output SS Enable Keyboard Function Code Table 2 Output (Ctrl-Output) SS Enable Keyboard Function Code Table 3 Output
Refer to Appendix Keyboard Function Code Table for details.
SS Disable key pad emulation SS Enable numeric output as key pad (Num Lock On) output
F_DEFAULT
Option Code
0 1 2
0 1
Upper/Lower Case
SS Normal case (neglect the upper/lower case control)
0
SS Inverse case (change all characters output to inverse case)
1
SS Upper case (force all characters output as upper case)
2
SS Lower case (force all characters output as lower case)
3
Dollar Sign Control
SS Dollar sign output as " $ " SS Dollar sign output as ""
0 1
SS Dollar sign output as " "
2
SS Dollar sign output as " £ "
3
SS Dollar sign output as " ¢ "
4
The function of "Key Pad Emulation" is only available for IBM PC/AT, PS/VP, PS/2 series personal computers and compatible machines. While selecting the other host
interfaces, these selections don't perform the above functions for you.
Wireless FuzzyScan
Reference Manual
78
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM Family Code Selection Barcode Encoding Format
Keyboard Interface Control
Code Page: Barcode Encoding Format, Keyboard Output
P.C
Parameter Selection
MS UTF8
Code page 950
Code page 949
Code page 936
Code page 932
Code page 874
WIN1250
WIN1251
WIN1252
WIN1253
WIN1254
WIN1255
WIN1256
WIN1257
WIN1258
ISO 8859-1 Latin 1, Western European
ISO 8859-2 Latin 2, Central European
ISO 8859-3 Latin 3, Southern European
ISO 8859-4 Latin 4, Northern European
ISO 8859-5 Cyrillic
ISO 8859-6 Arabic
ISO 8859-7 Greek
ISO 8859-8 Hebrew
ISO 8859-9 Latin 5, Turkish
ISO 8859-10 Latin 6, Nordic
ISO 8859-11 Thai
ISO 8859-13 Latin 7, Baltic
79
F_DEFAULT
Option Code
00 10 11 12 13 14 15 16 17 18 19 1a 1b 1c 1d 1e 1f 20 21 22 23 24 25 26 27 28 29
Configuring Your Scanner
ISO 8859-14 Latin 8, Celtic
2a
ISO 8859-15 Latin 9
2b
ISO 8859-16 Latin 10, South-Eastern European
2c
Keyboard Output
MS Linux Unicode Output
00
MAC Unicode Output
01
WIN Notepad Unicode Output
02
WIN Wordpad Unicode Output
03
Code page 950 Output
10
Code page 949 Output
11
Code page 936 Output
12
Code page 932 Output
13
Code page 874 Output
14
WIN1250 Output
15
WIN1251 Output
16
WIN1252 Output
17
WIN1253 Output
18
WIN1254 Output
19
Code page 852 Output
30
Code page 855 Output
31
Code page 866 Output
32
Code page 850 Output
33
Code page 437 Output
34
Code page 737 Output
35
Code page 857 Output
36
Code page 862 Output
37
Code page 720 Output
38
Code page 775 Output
39
WIN1255 Output
1a
WIN1256 Output
1b
WIN1257 Output
1c
WIN1258 Output
1d
Wireless FuzzyScan
Reference Manual
80
Configuring Your Scanner Corresponding Languages: Please see Appendix below, "Code Page - Table of Corresponding Languages". Barcode Encoding Format: 2D barcodes can be encoded using different code pages. To properly decode the data of a 2D barcode, the scanner must first be set to the
corresponding code page of such data. Select UTF8 if the 2D barcode was encoded in Unicode (UTF-8). Keyboard Output: Different languages use different code pages. For your scanner to properly display the content of a 2D barcode, select the code page that corresponds
to the content's language. Please check your system locale setting in Windows and make sure that it also matches this language. 1) Mac Device Output: If your host is a Mac device, select "MAC Unicode Output" as the scanner's output setting (the data will be in Unicode). You must also first ensure
that your Mac device has the required Unicode Hex Input Setup and is configured for the 16-bit input method. Please see Appendix below, "Code Page - Unicode Hex Input Setup". 2) WIN Notepad Unicode Output: If your host is a Windows device, you can output the data in Unicode format to Notepad. You must first ensure that your Windows device has the required Unicode Hex Input Setup, and is set to the US English input method. Please see Appendix below, "Code Page - Unicode Hex Input Setup". 3) WIN WordPad Unicode Output: If your host is a Windows device, you can output the data in Unicode format to WordPad. You must first ensure that your Windows device is set to the US English input method.
81
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM Family Code Selection
STX/ETX Control
Record Suffix
Preamble
Serial Interface Control
Record Suffix, Preamble, Postamble Setting
P.C
Parameter Selection
SS Disable STX/ETX transmission SS Enable STX/ETX transmission
STX/ETX are two characters used to indicate the starting and ending of the total data frame transmitted via serial interface.
SS None SS CR (0DH) SS LF (0AH) SS CRLF (0D0AH) SS TAB (09H) SS SPACE (20H) MS User defined character (1 character)
SS None MS 1-15 characters
Maximum 15-character input; scan "FIN" to terminate this selection.
F_DEFAULT Option Code
0 1
0 1 2 3 4 5 6, (00-7F) FIN [00-7F], [FIN]
Postamble
SS None MS 1-15 characters
Maximum 15-character input; scan "FIN" to terminate this selection.
FIN [00-7F], [FIN]
FNC1 Symbol Char. Transmit
SS Disable SS Enable
When this function is enabled and the FNC1 is contained in scanned data, the scanner transmits the FNC1 to the host. Chart of the FNC1 is provided in Appendix Keyboard Function Code Table. When the scanner interface is set to keyboard, the scan code is converted to corresponding key function before it is transmitted
Serial Interface Message String (RS232, USB COM) :
STX
Preamble
Data Length Prefix Symbol ID Scanned Data Suffix Symbol ID Postamble
ETX
1 character 1-15 characters
2-4 digits 1 or 3 characters Variable length 1 or 3 characters 1-15 characters 1 character
0 1
Record Suffix 1 character
82
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
Serial Interface Control
PROGRAM Family Code Selection
Intermessage Delay
Delay Setting
P.C
Parameter Selection
SS None MS 1-99 (x10) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
F_DEFAULT
Option Code
FIN (2 digits)
Intercharacter Delay
SS None MS 1-99 (x5) msec.
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
FIN (2 digits)
Interfunction Delay
SS None MS 1-99 (x5) msec.
FIN (2 digits)
Scan 2 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
Intermessage Delay is a time delay between messages output by FuzzyScan. Increasing this delay will help host applications process the incoming data on time. Intercharacter Delay is a time delay between data characters output by FuzzyScan. These two parameters are used to synchronize data communication when : 1) the data
transmission speed is too fast, characters may be skipped; 2) multitasking operation system or host computers in a network may slow down the keyboard handling; 3) various notebook or desktop PC systems require different timing parameter settings. Please always add one extra unit as safety margin when adjusting these two parameters. Interfunction Delay is a time delay between the transmissions of each segment of the message string. Intermessage Delay, Intercharacter Delay and Interfunction Delay are unconfigurable under SPP and HID modes.
Wireless FuzzyScan
Reference Manual
83
Configuring Your Scanner
PROGRAM Family Code Selection
Handshaking Protocol
NAK Retry Count
Serial Interface Control Protocol, ACK/NAK Setting
P.C
Parameter Selection
SS None (free running mode) SS RTS/CTS (hardware handshaking) SS ACK/NAK (software handshaking) SS Xon/Xoff (software handshaking)
SS 3 times SS 0~255 times
F_DEFAULT
Option Code
0 1 2 3
FIN (3 digits)
Wireless FuzzyScan
Reference Manual
ACK Indication
SS Disable ACK Time-out Indication
0
SS Enable ACK Time-out Indication
1
SS Disable ACK Indication
2
SS Enable ACK Indication
3
USB COM doesn't support RTS/CTS handshaking protocol. When the ACK/NAK Software Handshaking option is selected, the FuzzyScan waits for an ACK (acknowledge) or NAK (not acknowledge) from the host computer after
each data transmission. If the NAK is received, FuzzyScan will re-send the data until receiving ACK.
ACK/NAK handshaking protocol is workable under following conditions:
1) Pair mode by using RS232 or USB COM interface.
2) SPP master or slave mode. NAK Retry Count
After transmitting data, the scanner expects a NAK response from the host up to the preset "Serial Response Time-out". If the scanner doesn't get a response, the scanner will issue an error indication and discard the data. When a NAK is received, the scanner transmits the same data again and waits for either an ACK or NAK. The scanner issues an error indication and discards the data under following two conditions: 1) After preset NAK retry counts is received within the preset serial response time-out. 2) If the preset time-out is up but the preset NAK retry counts haven't come to the end. The default retry counts are three times. If you program "0 time", the scanner won't resend the data to the host when the scanner receives a NAK. The scanner will discard the data. If you program "255 times", the scanner can receive unlimited NAKs from the host within the pre-set serial response time-out.
This function is not available for batch mode. When you enable this function in on-line mode, the out-of-range function will be disable automatically. ACK Indication:
Disable: There's neither LED nor beeping indication for this setting. Enable: There's a specific LED and beeping indication for this setting.
84
Configuring Your Scanner
Serial Interface Control
PROGRAM Family Code Selection Serial Response Time-out
Time Out Setting, Baud Rate, Data Frame
P.C
MS None SS 200 msec SS 500 msec SS 800 msec SS 1 second SS 2 seconds
Parameter Selection
3 seconds 4 seconds 5 seconds 8 seconds 10 seconds 15 seconds
F_DEFAULT
Option Code
0
6
1
7
2
8
3
9
4
A
5
B
Baud Rate (BPS)
SS 38.4K BPS SS 19.2K BPS SS 9600 BPS SS 4800 BPS
2400 BPS 1200 BPS 57.6K BPS 115.2K BPS
0
4
1
5
2
8
3
9
Data Frame
SS 8, None, 1 SS 8, Odd, 1 SS 8, Even, 1 SS 8, Space, 1 SS 8, Mark, 1 SS 8, None, 2 SS 7, Odd, 1 SS 7, Even, 1
7, Space, 1 7, Mark, 1 7, None, 2 7, Odd, 2 7, Even, 2 7, Space, 2 7, Mark, 2
0
8
1
9
2
A
3
B
4
C
5
D
6
E
7
When the RTS/CTS Hardware Handshaking option is selected, the RTS (request to send) and CTS (clear to send) signals will be issued before normal data communication. This option is very helpful to ensure the reliability of data communication.
The Serial Response Time-out is a pre-defined delay time for FuzzyScan to wait for handshaking, acknowledgment or non-acknowledgment from the host computer.
Wireless FuzzyScan
Reference Manual
85
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM
Family Code Selection Barcode Encoding Format
Serial Interface Control ( A Series & PA Series )
Code Page: Barcode Encoding Format, Serial Port Output
P.C
Parameter Selection
UTF8
Code page 950
Code page 949
Code page 936
Code page 932
Code page 874
WIN1250
WIN1251 WIN1252
WIN1253
WIN1254
MS WIN1255
WIN1256
WIN1257
WIN1258
ISO 8859-1 Latin 1, Western European
ISO 8859-2 Latin 2, Central European
ISO 8859-3 Latin 3, Southern European
ISO 8859-4 Latin 4, Northern European
ISO 8859-5 Cyrillic
ISO 8859-6 Arabic
ISO 8859-7 Greek
ISO 8859-8 Hebrew
86
F_DEFAULT
Option Code
00 10 11 12 13 14 15 16 17 18 19 1a 1b 1c 1d 1e 1f 20 21 22 23 24 25
Configuring Your Scanner
ISO 8859-9 Latin 5, Turkish
26
ISO 8859-10 Latin 6, Nordic
27
ISO 8859-11 Thai
28
ISO 8859-13 Latin 7, Baltic
29
ISO 8859-14 Latin 8, Celtic
2a
ISO 8859-15 Latin 9
2b
ISO 8859-16 Latin 10, South-Eastern European
2c
Serial Port Output
Raw Data
00
Unicode (Big Endian)
01
Unicode (Little Endian)
02
UTF8
03
CP950 Output (Big Endian)
10
CP949 Output (Big Endian)
11
CP936 Output (Big Endian)
12
CP932 Output (Big Endian)
13
CP874 Output
14
WIN1250 Output
15
WIN1251 Output
16
MS WIN1252 Output
17
WIN1253 Output
18
WIN1254 Output
19
WIN1255 Output
1A
WIN1256 Output
1B
WIN1257 Output
1C
WIN1258 Output
1D
CP852
30
CP855
31
CP866
32
CP850
33
CP437
34
Wireless FuzzyScan
Reference Manual
87
Configuring Your Scanner
CP737
35
CP857
36
CP862
37
CP720
38
CP775
39
CP950 Output (Little Endian)
90
CP949 Output (Little Endian)
91
CP936 Output (Little Endian)
92
CP932 Output (Little Endian)
93
To get multilingual output with the serial interface, please choose correct barcode encoding format and its corresponding serial port output format.
Wireless FuzzyScan
Reference Manual
88
Configuring Your Scanner
PROGRAM Family Code Selection
Output Polarity Initial Signal State
Margin Time
Module Time Narrow/Wide Ratio
Wand/Laser Emulation Control
(F, L, PF & PL)
Output Polarity, Signal State, Margin/Module Time
P.C
Parameter Selection
SS High level (5Vdc) on Bar (low level on Space)
SS Low level (0Vdc) on Bar (high level on Space)
Determine the output voltage level for both bar and space. SS High Level (5Vdc) SS Low Level (0Vdc)
Determine the initial state of output voltage level.
SS 10 msec. SS 15 msec. SS 20 msec. SS 25 msec. SS 30 msec.
SS Extremely short SS Short SS Medium SS Long
SS 1:2 SS 1:2.5 SS 1:3
F_DEFAULT
Option Code
0 1
0 1
0 1 2 3 4 0 1 2 3 0 1 2
Wireless FuzzyScan
Reference Manual
89
Configuring Your Scanner
PROGRAM
Wand/Laser Emulation Control (F, L, PF, PL & PA Series)
Code 39/Code 128 Emulation
F_DEFAULT
Family Code Selection P.C
Parameter Selection
Option Code
Code 39/Code 128 Emulation
SS Disable standard Code 39 emulation
0
SS Enable standard Code 39 skip emulation
1
SS Enable standard Code 39 replace emulation
2
SS Enable Full ASCII Code 39 emulation
3
SS Enable Code 128 emulation
4
Code 39 Skip: When this option is selected, all scanned data will be translated as Standard Code 39 wand/laser emulation output. If any lower case characters are read, they will be translated to upper case characters. Any other characters that are not available in Code 39 symbology set will be skipped.
Code 39 Replace: Any character not normally available in the standard Code 39 symbology set, will be translated as Space.
Wireless FuzzyScan
Reference Manual
90
Configuring Your Scanner
PROGRAM Family Code Selection
Operation Mode
Operation Control
Operation Mode
P.C
SS Trigger mode SS Presentation mode SS Multiple Read mode
Parameter Selection
F_DEFAULT
Option Code
1 2 8
PF / PL / PA series do not support Presentation Mode
Trigger Mode (Low Power Triggering) The scanner goes into standby state after scanning the barcode. You must press the trigger to turn on the light source of the scanner before scanning the bar code.
Presentation Mode (Auto Detection) Presentation mode uses ambient light to detect the barcodes. The light source is off until the scanner detects an image which is similar to a barcode. Then the light source turns on automatically to read the barcode. If the light level in the room is not high enough, Presentation Mode may not work properly. You can choose different level of "Presentation Sensitivity" to meet your application (Please refer to the setting of "Presentation Sensitivity").
Multiple Read Mode The scanner is allowed to decode multiple barcodes with a single pull of the trigger. When you press and hold the trigger to aim at a series of barcodes, the scanner will decode each barcode and beep for each good read. For more precise barcode decoding, you are recommended to enable Center Alignment function while multiple read mode is selected. You can enable Unique Barcode Reporting function to avoid reading the same code multiple times in a same scanning session.
Wireless FuzzyScan
Reference Manual
91
Configuring Your Scanner
Operation Control
PROGRAM
(A Series & PA Series) Batch Reading
Family Code Selection P.C
Parameter Selection
Batch Reading
SS None Batch Reading rule input ( 01-16 rules)
F_DEFAULT
Option Code
[FIN] [Rules] [FIN]
Wireless FuzzyScan
Reference Manual
Batch Reading: When this function is enabled, you can scan multiple barcodes one by one continuously upon one trigger event. The scanner reports a good read beep and indication only if all bar codes set by the "Batch Reading Rule" are read. Otherwise, the scanner reports an error beep and indication. The scanned data will be transmitted according to the preset sequence which is defined in "Batch Reading Rule" regardless the scanned order of those barcodes. Batch Reading function is only available Trigger Mode. Batch Reading is not available when Multiple Read Mode or Center Alignment is turned on.
Batch Reading Rule:
- To set the Batch Reading rule 1.Scan the PROGRAM symbol. 2.Scan the Batch Reading symbol (Family Code). 3.Use the Option Code to define the preset Batch Reading rule. 4.Scan the FIN symbol. 5.Scan the END symbol to save your Batch Reading rule. Note: Scan the ABORT and END symbol to exit without saving any Batch Reading rule setting.
- When you scan "None", the preset Batch Reading Rule will be cancelled. - Batch Reading Rule Syntax:
[n] [Element 1] FF [Element 2] FF [Element 3] FF ...[Element n] FF Where n is the number of elements in the overall rule. The number of elements is up to 16.FF indicates the end of one element.
- Element structure: [Cino ID Hex value] [Code length] [Character match(es)] Where: · [Cino ID Hex value] Length: 2 byte Please find Cino ID hex value from Symbology ID Table in appendix. Locate the Hex value for the symbology and scan the 2 digit hex values from the Option Code. Note: 99 is the universal number, indicating all symbologies.
92
Configuring Your Scanner
· [Code length] Length: 4 byte Specify what length of data output will be acceptable for this symbology. When you calculate the length, you must consider the whole data string which includes the programmed Preamble, Postamble, Scanned Data Length, Prefix/Suffix Symbol ID or AIM ID. Scan the four digit data length from the Option Code. Note: 40 characters is entered as 0040; 9999 is a universal number, indicating all lengths.
· [Character match] Length: 2-8 byte You can refer to HEX/ASCII Reference Table to find the Hex value that represents the character(s) you want to match. Use the Option Code to scan the alphanumeric combination that represents the ASCII characters. You can match up to 4 characters which are counted from the start character of the whole Data String. Note: When setting the matched character(s), you must match the content of the whole Data String, including the programmed Preamble, Postamble, Scanned Data Length, Prefix/Suffi Symbol ID OR AIM ID if you had defined. FF is the universal character, indicating all characters.
- Batch Reading rule example In this example, you are scanning Code 39, Code 128, and Code 93 bar codes, but you would like to output the data in following sequence: Code 128 - Code 39 - Code 93
B-CODE39
A-CODE128
C-CODE93
93
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
You would set up the Batch Reading rule with the following command line:
[PROGRAM] [Batch Reading] [0301999941FF07999942FF09999943FF] [FIN] [END]
The breakdown of the command line is shown below:
03
The number of elements in the overall rule
01
Code identifier of Code 128
9999
Code length that must match for Code 128, 9999 = all lengths
41
Start character match for Code 128, 41h = "A"
FF
End of first code
07
Code identifier of Code 39
9999
Code length that must match for Code 39, 9999 = all lengths
42
Start character that must match for Code 39, 42h = "B"
FF
End of second code
09
Code identifier of Code 93
9999
Code length that must match for Code 93, 9999 = all lengths
43
Start character match for Code 93, 43h = "C"
FF
End of third code
To program the previous example using specific lengths, you would have to count the programmed Preamble, Postamble, Scanned Data Length, Prefix/Suffix Symbol ID OR AIM ID if you had defined as part of the length. If you enable the Suffix Symbol ID of symbology, you would add one character to the previous example's length.
You would set up the Batch Reading rule with the following command line:
[PROGRAM] [Batch Reading] [0301001041FF070009FF09000943FF] [FIN] [END]
Wireless FuzzyScan
Reference Manual
94
Configuring Your Scanner
The breakdown of the command line is shown below:
03
The number of elements in the overall rule
01
Code identifier of Code 128
0010
Code length that must match for Code 128
A-CODE128 sample length (9) plus Suffix Symbol ID (1) = 10
41
Start character match for Code 128, 41h = "A"
FF
End of first code
07
Code identifier of Code 39
0009
Code length that must match for Code 39
B-CODE39 sample length (8) plus Suffix Symbol ID (1) = 9
Universal matched character, indicating all character FF
Also indicate end of second code
09
Code identifier of Code 93
0009
Code length that must match for Code 93
C-CODE93 sample length (8) plus Suffix Symbol ID (1) = 9
43
Start character match for Code 93, 43h = "C"
FF
End of third code
Note: If the [Character match(es)] is set to "FF", the following "FF" which indicated the end of the code was not need to set.
- Structure of Data String
STX (RS232/USB COM
interface)
Preamble
Scanned Data Length
1 character
1-15 characters
2-4 digits
Prefix Symbol ID Or
Prefix AIM Symbol ID
1 or 3 characters
Scanned Data modified by DataWizard
Variable length
Suffix Symbol ID Or
Suffix AIM Symbol ID
1 or 3 characters
Postamble
ETX (RS232/USB COM
interface)
1-15 characters
1 character
Wireless FuzzyScan
Reference Manual
95
Configuring Your Scanner
PROGRAM Family Code Selection
Buzzer Tone Adjust
Power On Indicator
Operation Control
(All Series)
Buzzer, Indicator, Vibrator, 1D Code Inverse Reading
P.C
Parameter Selection
SS Buzzer tone mute SS Buzzer tone low (Frequency 1.20 kHz) SS Buzzer tone medium (Frequency 2.70 kHz) SS Buzzer tone high (Frequency 2.81 kHz) SS Buzzer tone - extremely high (Frequency 2.93 kHz) SS Power-on / power-off beep
SS No power-on / power-off beep
SS Disable (LED off) SS LED steady on
SS LED flash
F_DEFAULT
Option Code
0 1 2 3 4 5 6
0 1 2
Good Read Indicator
SS Disable
0
SS Enable
1
Vibrator Control
SS Disable
0
SS Enable
1
Optional function, only available for vibrator model.
1D Barcode Inverse Reading
SS Disable
0
SS Enable
1
Wireless FuzzyScan
Reference Manual
96
Configuring Your Scanner
PROGRAM Family Code Selection
Beeping Control
Radio Connection Beeps
Operation Control (All Series)
Beeping Control, Radio Connection Beeps
P.C
Parameter Selection
SS Radio Connected/ Disconnected Beep On SS Radio Connected/ Disconnected Beep Off SS Battery Power Low Beep On SS Battery Power Low Beep Off
SS Four ascending tone / Four descending tone SS Low-high two beeps / High-low two beeps
F_DEFAULT
Option Code
0 1 2 3
0 1
Wireless FuzzyScan
Reference Manual
97
Configuring Your Scanner
PROGRAM
Family Code Selection Buzzer Volume
P.C
SS Low SS Medium SS High
Operation Control ( A Series & PA Series )
Buzzer Volume
Parameter Selection
Available firmware: A770BT: A670BT: Other A and PA Series scanners:
1.00.13 and above; 2.00.03 and above 1.00.01 and above All firmware versions
F_DEFAULT
Option Code
0 1 2
Wireless FuzzyScan
Reference Manual
98
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM
Family Code Selection Set Date
Operation Control ( A Series & PA Series ) Timestamp Functions
P.C
Parameter Selection
SS Scan Date (MMDDYY)
Set Time
For example, 2014-12-24, set 122414 SS Set Time (HHMM)
Timestamp Format Setting
For example, for 24-hour clock Time Conversion, 14:56 set 1456
SS HH:MM DD/MM/YYYY SS HH:MM MM/DD/YYYY SS HH:MM YYYY/MM/DD SS HH:MM:SS DD/MM/YYYY SS HH:MM:SS MM/DD/YYYY SS HH:MM:SS YYYY/MM/DD SS DD/MM/YYYY HH:MM SS MM/DD/YYYY HH:MM SS YYYY/MM/DD HH:MM SS DD/MM/YYYY HH:MM:SS SS MM/DD/YYYY HH:MM:SS SS YYYY/MM/DD HH:MM:SS SS DD/MM/YYYY SS MM/DD/YYYY SS YYYY/MM/DD SS HH:MM SS HH:MM:SS
99
F_DEFAULT
Option Code
6 digits + END
4 digits + END
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM Family Code Selection Date & Time Format Setting Timestamp Output Control Stored Data Output Format
Online Mode Output Format
Operation Control ( A Series & PA Series ) Timestamp Functions (continued)
P.C
Parameter Selection
SS 12 hour SS 24 hour
SS Short Year (YY) SS Full Year (YYYY)
SS None SS Batch mode SS Online mode SS Online mode & Batch mode
SS Data/Record SS Quantity + Data/Record SS Data/Record + Quantity SS Timestamp + Data/Record SS Data/Record + Timestamp SS Timestamp + Quantity + Data/Record SS Timestamp + Data/Record + Quantity SS Quantity + Timestamp + Data/Record SS Quantity + Data/Record + Timestamp SS Data/Record + Timestamp + Quantity SS Data/Record + Quantity + Timestamp
SS Data/Record SS Timestamp + Data/Record SS Data/Record + Timestamp
Timestamp Function is available for both Online Mode and Batch Mode.
100
F_DEFAULT
Option Code
0 1 2 3
0 1 2 3
0 1 2 3 4 5 6 7 8 9 10 0 1 2
Configuring Your Scanner
PROGRAM
Family Code Selection Radio Link Mode for Discoverable Mode
Operation Control
( PF, PL &PA Series )
Radio Link Mode for Discoverable Mode
P.C
Parameter Selection
SS HID Mode SS HID Mode with Passkey SS HID Legacy Mode SS SPP Slave Mode
You may also press FN1 of pocket scanner for more than 3 seconds to enter discoverable mode.
F_DEFAULT
Option Code
0 1 2 3
Wireless FuzzyScan
Reference Manual
101
Configuring Your Scanner
Operation Control
PROGRAM
(F&L Series) Redundancy
Family Code Selection P.C
Parameter Selection
Redundancy
SS None SS Level 1 SS Level 2 SS Level 3 SS Level 4 SS Level 5
To prevent potential miss reading.
The Redundancy is the number of additional times the same bar code label has to be decoded before it is transmitted.
F_DEFAULT
Option Code
0 1 2 3 4 5
Wireless FuzzyScan
Reference Manual
102
Configuring Your Scanner
PROGRAM Family Code Selection
Reread Delay (Double Scan Verification)
Good Read Delay
HID Mode Transmit Delay
Operation Control (All Series)
Delay Setting
P.C
SS Disable SS Immediate time out SS Short time out SS Medium time out SS Long time out SS Force verification
SS None SS 200 msec. SS 500 msec. SS 1 sec. SS 1.5 sec. SS 2 sec. SS 3 sec.
SS None
MS 1-250 msec.
Parameter Selection
F_DEFAULT
Option Code
0 1 2 3 4 5
0 1 2 3 4 5 6
FIN (3 digits)
Scan 3 digits from the option code chart in Appendix, then FuzzyScan will terminate this selection automatically.
The Reread Delay (Double Scan Verification) is designed to inhibit FuzzyScan from reading the same bar code label twice in pre-defined short duration. Force Verification will not allow reading of the same bar code twice.
This Good Read Delay is the minimum amount of time before the scanner can read another bar code. This HID Mode Transmit Delay will affect HID mode; When the scanner pairs with the Android, set this to 70ms to avoid data loss.
Wireless FuzzyScan
Reference Manual
103
Configuring Your Scanner
PROGRAM
Operation Control (All Series)
Light Source & Hand Free Time-out Setting, Good Read Duration
F_DEFAULT
Family Code Selection P.C
Parameter Selection
Option Code
Light Source On Time
SS Short
0
SS Medium
1
SS Long
2
SS Extremely long
3
Hands Free Time-out
SS Short
0
SS Medium
1
SS Long
2
SS Extremely long
3
SS Disable
4
Good Read Duration
SS Short SS Medium
0 1
SS Long
2
SS Extremely long
3
SS Extremely short
4
The Light Source On Time is a pre-defined light source time out counter for Alternative Mode, Presentation Mode and Level Mode. The scanner keeps the light source on
till the pre-defined light source on time is up. You can adjust this parameter to meet your own application requirement.
The Presentation Mode is referred to as "hands free" mode. The hands free mode will be automatically changed to manual trigger mode when you press the trigger. You
can remain the scanner in manual trigger mode by setting the Hands Free Time-Out. Once the time-out duration is up (if there's no any trigger operation), the imager will
revert to the original hands free mode.
Use Good Read Duration (Good Read Beep and Vibration Duration) to define beeps and vibration according to operator preference and work environment.
Wireless FuzzyScan
Reference Manual
104
Configuring Your Scanner
PROGRAM Family Code Selection
Time Delay to Low Power Standby Mode
Low Power Standby Mode Link Indication
Operation Control
(All Series)
Low Power Standby Mode Settings
P.C
SS 1 sec SS 3 secs SS 5 secs SS 7 secs SS 9 secs SS Immediate
SS Turn off immediately SS Last for 1 minute SS Keep on till power-off
Parameter Selection
F_DEFAULT
Option Code
0 1 2 3 4 5 0 1 2
The Time Delay to Low Power Standby Mode sets the time for scanner to enter low power trigger mode after any scanning activity.
Wireless FuzzyScan
Reference Manual
105
Configuring Your Scanner
PROGRAM
Family Code Selection Presentation Auto-sense
Operation Control
(All Series)
Presentation Scanning Setting
P.C
SS Disable SS Enable
Parameter Selection
F_DEFAULT
Option Code
0 1
Presentation Sensitivity
SS Level 1 SS Level 2 SS Level 3 SS Level 4 SS Level 5
Level 6 Level 7
0
5
1
6
2
3
4
When enable the Presentation Auto-sense, the scanner can be switched between hands free scanning and hand-held scanning automatically when working with the SmartStand or cradle.
The Presentation Sensitivity is used to configure the sensitivity level when the scanner is set as presentation mode. The higher lever means higher sensitivity for detecting the barcode.
Wireless FuzzyScan
Reference Manual
106
Configuring Your Scanner
PROGRAM
Family Code Selection Scan Rate Control
P.C
SS Dynamic SS Fixed
Operation Control (F, L, PF, & PL Series) Scan Rate Control
Parameter Selection
F_DEFAULT
Option Code
0 1
Scan Rate Control: The scanner will have better motion tolerance when you select "Fixed" scan rate. It's suitable for application which needs higher motion tolerance on the move. But this may impact to the reading distance.
Wireless FuzzyScan
Reference Manual
107
Configuring Your Scanner
PROGRAM
Operation Control (A, PA Series) Smart Scene
F_DEFAULT
Family Code Selection P.C
Parameter Selection
Option Code
Smart Scene
SS Scene 1
0
SS Scene 2
1
SS Scene 3
2
SS Scene 4
3
SS Scene 5
4
SS Scene 6
5
SS Scene 7
6
Smart Scene optimizes scanners' motion tolerance, scanning speed and scanning sensitivity in different scanning environment. Scene 1: This is the default setting. It optimizes scanners' motion tolerance, scanning speed and scanning sensitively in most working environment. Scene 2: The scanner is optimized for scanning high-density barcode. Scene 3: This setting is for general retail application. Scene 4: Another setting also optimized for general retail application, as well as the performance when scanning barcodes displayed on the screens of devices, especially those with large screen LCD or with low brightness. Scene 5: An application-specific mode optimizes the scanner for scanning low PCS (print contrast) barcodes on circuit board. Scene 6: An application-specific mode optimizes the scanner for scanning barcodes on circuit board with the sufficient ambient light. Scene 7: An application-specific mode optimizes the scanner for scanning barcodes from the mobile device screens.
Wireless FuzzyScan
Reference Manual
108
Configuring Your Scanner
PROGRAM
Family Code Selection SmartStand Power Off Timeout
Operation Control
(L & PL Series)
SmartStand Power Off Timeout, Laser Aiming Control, LED Illumination Control & Delay
P.C
SS 3 mins SS 5 mins SS 10 mins
Parameter Selection
Laser Aiming Control
Only available for FuzzyScan L series scanners.
SS Disable SS Enable
LED Illumination Control
SS Always on SS Intelligent Mode
F_DEFAULT
Option Code
0 1 2
0 1
0 1
LED Illumination Delay
SS 100 ms
0
SS 150 ms
1
SS 200 ms
2
SS 250 ms
3
SS 300 ms
4
The SmartStand Power Off Timeout is a pre-defined duration for scanner's light source on time when the scanner is placed on SmartStand. While the scanner is placed on SmartStand, the scanner will be switched from hand-held scanning to presentation scanning and the light source will be forced on automatically. The light source will be off when the pre-defined duration is up.
Laser Aiming Control: You can disable or enable laser aiming line when you scan PDF barcode. LED Illumination Control: When you enable "always on", the LED illumination will be always on when you press the trigger. When you enable "intelligent mode", the
scanner will emit the laser aiming line first, the LED illumination will be turned on after the preset LED illumination delay. Intelligent mode is recommended to be used in regular ambient light environment.
109
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM
Family Code Selection Illumination Control
Operation Control (A Series & PA Series)
Illumination Control, Presentation Background Lighting Control
P.C
SS Disable SS Enable
Parameter Selection
F_DEFAULT
Option Code
0 1
Presentation Background Lighting SS LEDs Off
0
SS LEDs On
1
The Illumination Control is only available for hand-held mode.
Presentation Background Lighting Control: You can enable or disable presentation background lighting of the scanner according to the ambient light condition in
presentation mode. When the ambient light is dim or dark, you can enable this function to turn on the scanner's LED illumination at a dim level. This is helpful for scanner to detect the motion of scene.
Wireless FuzzyScan
Reference Manual
110
Configuring Your Scanner
PROGRAM
Family Code Selection Aiming Control
Operation Control (A Series & PA Series)
Aiming Control, Pre Decode Aiming Timer, Decode Aiming Control
P.C
Parameter Selection
SS Regular Aiming
SS Pre-decode Aiming Control
F_DEFAULT
Option Code
0 2
Pre Decode Aiming Timer
SS 200 ms SS 400 ms SS 800 ms SS 1 sec
1.5 secs. 2 secs. 3 secs. 4 secs.
0
4
1
5
2
6
3
7
Decode Aiming Control
SS Disable in Hand-Held mode
0
SS Enable in Hand-Held mode
1
SS Disable in Hand-Free mode
2
SS Enable in Hand-Free mode
3
The Aiming Control is available for Trigger mode and Multiple Read Mode. Under Regular Aiming, the aiming light is turned on only when the trigger button is pressed. Pre-decode Aiming provides a time duration for the user to aim the target barcode before the scanner starts to decode. When the user presses and holds the trigger button, the aiming light will be on but the main light source won't until the timer runs out. When the timer runs out, the scanner will turn on its main light source and start to find a barcode to decode. The time duration between the pressed trigger and the start of the scan session can be adjusted by setting Pre-Decode Aiming Timer. The Pre-decode Aiming can help the user to avoid a misreading if the user needs to read a specific barcode when there are other barcodes within close range.
The Pre-decode Aiming is only effective under Trigger Mode and Multiple Read Mode. Use Decode Aiming Control to turn on or turn off the aiming light during the scan session:
Under Handheld mode, enable/disable Decode Aiming Control to turn on/off the aiming light when the trigger is pressed. Under Hands-free mode, enable/disable Decode Aiming Control to turn on/off the aiming light when the scanner detects an object and starts a scan session.
Wireless FuzzyScan
Reference Manual
111
Configuring Your Scanner
PROGRAM Family Code Selection
Center Alignment
Unique Barcode Reporting
Operation Control (A Series & PA Series) Center Alignment, Unique Barcode Reporting
P.C
Parameter Selection
SS Disable in Hand-Held Mode
SS Enable in Hand-Held Mode
SS Disable in Hand-Free Mode SS Enable in Hand-free Mode
SS Disable SS Enable
F_DEFAULT
Option Code
0 1 2 3
0 1
Center Alignment: When this function is enabled, the scanner only decodes barcode(s) around aiming line. Unique Barcode Reporting: When this function is enabled, the scanner will only output data from each barcode once during a scanning cycle (trigger key pressed and
held without release). This prevents the output of repeat data in case a barcode is accidentally read multiple times during the same scanning cycle. For Multiple Read
mode only.
Wireless FuzzyScan
Reference Manual
112
Configuring Your Scanner
PROGRAM
Family Code Selection Out-of-range Scanning
P.C
SS Disable SS Enable
Operation Control (All Series)
Out-of-range Scanning
Parameter Selection
F_DEFAULT
Option Code
0 1
Out-of-range Scanning - When radio link is built between the scanner and remote host device, the scanner will transmit each scanned data right after scanning the barcode data. However, the scanner is preset for unable to scan any barcode data when it loses the radio connection. You can enable the Out-of-range Scanning function to continue scanning barcode data into memory buffer until radio link resumed.
.
Wireless FuzzyScan
Reference Manual
113
Configuring Your Scanner
PROGRAM
Family Code Selection Radio-off Time-out - Connect State
Operation Control (All Series)
Radio-off Time-out & Power Off Time-out Control
P.C
SS 12 (x5) minutes MS 0-99 (x5) minutes
Parameter Selection
Radio-off Time-out - Disconnect State
If you don't want the scanner to enter power-off, please set time-out to "0"
SS 1 (x1) minute MS 0-99 (x1) minutes
Power Off Time-out
If you don't want the scanner to enter power-off, please set time-out to "0"
SS 1 (x5) minutes MS 0-99 (x5) minutes
F_DEFAULT Option Code
FIN (2 digits)
FIN (2 digits)
FIN (2 digits)
If you want the scanner to enter power off mode immediately, please set time-out to "0"
The Radio-off Time-out Control can be set under radio connection or disconnection state. If the scanner is not used within the preset time-out duration, it will automatically enter "Power Off" for power saving purpose. You are able to disable this function by setting the time-out duration to "0".
The Power Off Time-out: When the scanner is under radio-off, it is preset to enter Power Off automatically if the radio is not on after the time-out duration. If you would like to power on the scanner, please press the trigger button. You can have the scanner enter this function immediately by setting the time-out duration to "0"
Wireless FuzzyScan
Reference Manual
114
Configuring Your Scanner
PROGRAM
Family Code Selection FN2 Function Mode
Operation Control (PF, PL, & PA Series) FN2 Function Mode Setting
P.C
SS Batch Scanning SS Validation Scanning
Parameter Selection
F_DEFAULT
Option Code
0 1
The FN2 Function Mode: The Batch Scanning (Inventory Mode) is set as the default FN2 function mode. Batch Scanning and Validation Scanning can't be used at the same time. If you want to use Function Key of pocket scanner to carry out Validation Scanning, you have to change the default setting.
Wireless FuzzyScan
Reference Manual
115
Configuring Your Scanner
PROGRAM
Family Code Selection Batch Scanning Link Control
Operation Control (All Series)
Batch Scanning Setting
P.C
SS Radio disable SS Radio enable
Parameter Selection
F_DEFAULT
Option Code
0 1
Stored Data Transmission
SS All
0
SS On cradle
1
SS Scan barcode
2
Delete Stored Data after
SS Disable
0
Transmission
SS Enable
1
The Batch Scanning Link Control is a pre-defined radio option to control the radio-on or radio-off status under batch scanning operation. Please note that if the radio disable is activated, the radio link will be disconnected once you enter batching scanning. The radio link will be resumed when you transmit the stored data or exit batch scanning.
The Stored Data Transmission is a pre-defined approach when you want to transmit the scanned data under batch scanning operation. You can transmit the scanned data by placing the scanner onto the cradle or scanning "Transmit Stored Data" command, or by either one of both methods.
In batching scanning, the default setting of Delete Stored Data after Transmission is disable. The scanner will keep all stored data after transmission until you scan the "Clear All Stored Data" command. You are also able to delete all stored data after transmission automatically by enabling this function.
Wireless FuzzyScan
Reference Manual
116
Configuring Your Scanner
PROGRAM Family Code Selection
Field Delimiter
Stored Data Output Format
Operation Control (All Series)
Batch Scanning Data Transmission Setting
P.C
Parameter Selection
SS None SS
SS SPACE SS SS
SS User define
SS As many times as the quantity indicates SS <Quantity><Field Delimiter><Scanned Data> SS <Scanned Data><Field Delimiter><Quantity>
F_DEFAULT
Option Code
0 1 2 3 4 5, [00-7F]
0 1 2
Data Transmission Format
SS Disable (scanned data only)
0
SS Leading with MAC address (MAC address and scanned data)
1
SS Leading with ID No. (scanner ID and scanned data)
2
Only available for RS232, USB HID and USB COM interface in PAIR & PICO modes
The Field Delimiter is used to separate the specific information and scanned data into two fields. You can choose desired delimiter format. The Stored Data Output Format If you want to input the quantity information of barcode data, you can enter the quantity from 1 to 9999 by scanning the quantity barcodes
right after you scanned the barcode data. The quantity information will be stored into the memory storage together with the barcode data. There are three ways to output the stored barcode data and quantity information. In PICO mode, up to 7 scanners can be connected with one smart cradle. The Data Transmission Format can help user to identify the source of the transmitted data. You can choose to transmit the scanned data leading with MAC address or pre-assigned ID. Example format: <MAC address><Field Delimiter><Data> or <ID><Field Delimiter><Data>.
Wireless FuzzyScan
Reference Manual
117
Configuring Your Scanner
PROGRAM
Family Code Selection Validation Mode Link Control
Operation Control (All Series)
Validation Scanning Setting
P.C
SS Radio Disabled SS Radio Enabled
Parameter Selection
F_DEFAULT
Option Code
0 1
Master Data Setting
SS Single master data
0
SS Multiple master data
1
Validation Output
SS Disable data transmission
0
SS Transmit valid data
1
SS Transmit invalid data
2 3
SS Transmit valid data or "NG"
4
SS Transmit invalid data or "OK"
5
SS Transmit "OK" or "NG"
6
The Validation Mode Link Control is a pre-defined radio option to control the radio-on or radio-off status under Validation Scanning operation. Please note that if the radio
disable is activated, the radio link will be disconnected once you enter Validation Scanning. The radio link will be resumed when you enable data transmission or exit
Validation Scanning.
The Master Data Setting: The default Master Data Setting is preset to "Single Master Data". If Single Master Data is selected, though you can scan multiple master data
continuously, only the last master data will be valid, and the master data registered previous to the last master data will be cleared. If the multiple master data is required,
you have to change the default setting. The scanner is capable of storing up to 2K byes master data.
The Validation Output (Validation Result Output) is preset to"Disable data transmission". There are six ways to output the validation result.
Wireless FuzzyScan
Reference Manual
118
Configuring Your Scanner
PROGRAM Family Code Selection
Bluetooth Device Name
Bluetooth PIN Code
Operation Control (All Series)
Bluetooth: Device Name & PIN Code Setting
P.C
Parameter Selection
SS Default device name MS User define;
F/L series: 1-16 characters A series: 1-32 characters
SS Default Bluetooth PIN Code MS User define, 1-8 numbers
F_DEFAULT
Option Code
FIN [00-7F], FIN
FIN [30-39], FIN
The default Bluetooth Device Name for F/L series is "F(L)xxxBT-xxxx", and for PF/PL series is PF(L)xxxBT-xxxx, you will be able to change the device name by scanning HEX values (1-16 characters).
The default Bluetooth Device Name for A series is "AxxxBT-xxxx", you will be able to change the device name by scanning HEX values (1-32 characters). The default Bluetooth PIN Code is "00000000", you will be able to change the PIN Code by scanning HEX values (1-8 numbers).
Wireless FuzzyScan
Reference Manual
119
Configuring Your Scanner
PROGRAM
Family Code Selection Bluetooth Sniff Control
Operation Control (All Series)
Bluetooth: Other Settings
P.C
SS Disable SS Enable
Parameter Selection
F_DEFAULT
Option Code
0 1
Link Quality Control
SS Disable
0
SS Level 1
1
SS Level 2
2
SS Level 3
3
SS Level 4
4
Bluetooth Sniff Control: the Bluetooth module will enter low power consumption mode when this function is enabled. Link Quality Control: This function is only available for SPP and HID mode. When you use the scanner in the boundary of radio signal, you can enable this function to
increase the reliability of data transmission. Be aware this function will affect the communication distance: the higher the level is, the shorter the communication distance is.
Wireless FuzzyScan
Reference Manual
120
Configuring Your Scanner
PROGRAM
Operation Control (All Series)
On-screen Keyboard Control
Family Code Selection On-screen Keyboard Control
P.C
SS Disable SS Enable
Parameter Selection
F_DEFAULT
Option Code
0 1
When On-screen Keyboard Control is enabled, the scanner is preset to switch between barcode scanning and on-screen keyboard of most popular devices; you also can
have the scanner entered this setting by scanning "General Approach " quick set command. Then you can turn off the radio to activate the on-screen keyboard by scanning "Switch On-screen Keyboard" quick set command. If you use pocket scanner, you can activate the on-screen keyboard toggle by short pressing the FN1. To work with iOS device, please change On-screen Keyboard Control to disable, or scan the "iOS Approach" quick set command to activate this function. Then you can scan ""Switch On-screen Keyboard" quick set command to toggle the iOS on-screen keyboard. If you use pocket scanner, you can also activate the iOS on-screen keyboard toggle by short pressing the FN1.
When you finished the keyboard input, please press the trigger once to turn on the radio, and the on-screen keyboard will be inactivated.
Wireless FuzzyScan
Reference Manual
121
Configuring Your Scanner
PROGRAM Family Code Selection
Preamble
Condensed DataWizard
Preamble, Postamble, Data Length & Symbol ID Transmission
P.C
SS None MS 1-15 characters
Parameter Selection
F_DEFAULT
Option Code
FIN [00-7F], [FIN]
Postamble
Maximum 15-character input; scan "FIN" to terminate this selection.
SS None MS 1-15 characters
FIN [00-7F], [FIN]
Maximum 15-character input; scan "FIN" to terminate this selection.
Data Length Transmission
SS Disable
0
SS Enable 2 digits data length transmission
1
If data length exceeds 99, 3-digit data length will be transmitted.
Symbology ID Transmission
SS Disable symbology ID transmission
0
SS Enable prefix symbology ID transmission
1
SS Enable suffix symbology ID transmission
2
SS Enable both prefix and suffix symbology ID transmission
3
SS Enable prefix AIM symbology ID transmission
4
SS Enable suffix AIM symbology ID transmission
5
SS Enable both prefix and suffix AIM symbology ID transmission
6
DataWizard is the most powerful, Artificial-Intelligence based data editing expert system provided specially for the FuzzyScan family bar code readers. Through
DataWizard, you can process the scanned data prior the transmissions in many ways as Insert, Delete, Match, Verify, Replace, Reorganize, and Repeat Transmission.
It will help you to arrange the transmission of scanned data to any specific format without software modification. Due to the resources concern, Full-feature DataWizard is only supported by PowerTool. Through the PowerTool, all settings and configurations can be done on-screen on
Windows-based operating system. A Condensed Version DataWizard is provided by each FuzzyScan scanner. Through this menu, the condensed DataWizard can be utilized easily via barcode menu
readings. Please note that all "Character" input should be referred to the ASCII/HEX Table listed in Appendix to find matched HEX value. If you have any problem to use DataWizard, please refer to following pages for details, as well as consult your local FuzzyScan vendor or our web site for further assistance.
Wireless FuzzyScan
Reference Manual
122
Configuring Your Scanner
PROGRAM Family Code Selection
Formatter Control
Condensed DataWizard Data Formatter Setting
P.C
Parameter Selection
SS Disable MS Select one bar code symbology MS Select all bar code symbologies
Option Code
FIN (2 digits)
00
F_DEFAULT 2nd Option Code
automatic termination automatic termination
1st Insertion
SS Disable DS Enable
FIN (2 digits)
[1-3 characters], [FIN]
2nd Insertion
2-digits identified position; max. 3 insertion characters
SS Disable DS Enable
position
FIN (2 digits)
[1-3 characters], [FIN]
3rd Insertion
2-digits identified position; max. 3 insertion characters
SS Disable DS Enable
position
FIN (2 digits)
[1-3 characters], [FIN]
4th Insertion
2-digits identified position; max. 3 insertion characters
SS Disable DS Enable
position
FIN (2 digits)
[1-3 characters], [FIN]
2-digits identified position; max. 3 insertion characters
position
The Data Formatter is used to edit the scanned raw data prior to transmitting the data to the host computers or terminals. It allows you to select desired bar code symbologies for formatter control, and provides Multiple Position Insertion and Multiple Character Insertion (max three characters) in the identified position.
While the Data Formatter is enabled, it arranges only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbolology ID or Record Suffix. All of the above programmable parameters perform the same function depending on your setting.
Regarding the "Bar Code Selection" and "Position Calculation" of data formatter, please refer to page 60 for details. Please note that all "Character" input should be referred to the ASCII/HEX Table listed in Appendix to find matched HEX value.
123
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
PROGRAM Family Code Selection
Verifier Control
Condensed DataWizard Data Verifier Setting
P.C
Parameter Selection
SS Disable MS Select one bar code symbology MS Select all bar code symbologies
Option Code
FIN (2 digits)
00
F_DEFAULT 2nd Option Code
automatic termination automatic termination
Identified Data Length
SS Disable MS Enable
FIN (2 digits)
1st Identified Character
Determine the identified data length for verification.
SS Disable DS Enable
FIN (2 digits)
[00-7F]
2nd Identified Character
2-digits checking position; 1 identified character
SS Disable DS Enable
position
FIN (2 digits)
[00-7F]
3rd Identified Character
2-digits checking position; 1 identified character
SS Disable DS Enable
position
FIN (2 digits)
[00-7F]
2-digits checking position; 1 identified character
position
The Data Verifier is used to provide advanced verification for error-free scanning and to work as an Embedded Data Transmitting Filter. All data must conform to the Identified Bar Code Symbologies, Identified Data Length, and one to three Identified Characters in the checking position. Otherwise, the
FuzzyScan will not transmit the data to the host computers or terminals, but will instead issue 3 long beeps for verification error and skip the scanned data. The Data Verifier checks only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbology ID or Record Suffix. Regarding the "Bar Code Selection" and "Position Calculation" of Data Verifier, please refer to page 60 for details. Please note that all "Character" input should be referred to the ASCII/HEX Table listed in Appendix to find matched HEX value.
Wireless FuzzyScan
Reference Manual
124
Configuring Your Scanner
PROGRAM Family Code Selection
Replacer Control
Condensed DataWizard Data Replacer Setting
P.C
Parameter Selection
SS Disable MS Select one bar code symbology MS Select all bar code symbologies
Option Code
FIN (2 digits)
00
F_DEFAULT 2nd Option Code
automatic termination automatic termination
1st Replacement
SS Disable DS Enable
FIN (2 digits)
[00-7F]
2nd Replacement
2-digits identified position; 1 replacement character
SS Disable DS Enable
position
FIN (2 digits)
[00-7F]
3rd Replacement
2-digits identified position; 1 replacement character
SS Disable DS Enable
position
FIN (2 digits)
[00-7F]
2-digits identified position; 1 replacement character
position
The Data Replacer is used to edit the scanned raw data prior to transmitting the data to the host computers or terminals. It allows you to select desired bar code symbologies for replacer control, and provides Multiple Position Replacement in the identified position.
All data must conform to the Identified Bar Code Symbologies, and one to three Identified Characters in the identified position while the Data Replacer is enabled, it arranges only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbology ID or Record Suffix.
Regarding the "Bar Code Selection" and "Position Calculation" of Data Replacer, please refer to page 60 for details. Please note that all "Character" input should be referred to the ASCII/HEX Table listed in Appendix to find matched HEX value.
Wireless FuzzyScan
Reference Manual
125
Configuring Your Scanner
PROGRAM Family Code Selection
Organizer Control
Condensed DataWizard Data Organizer Setting
P.C
Parameter Selection
SS Disable MS Select one bar code symbology MS Select all bar code symbologies
Option Code
FIN (2 digits)
00
F_DEFAULT 2nd Option Code
automatic termination automatic termination
1st Organization 2nd Organization Include/Exclude Control
SS Disable DS Enable
2-digits identified position; Forward/backward data transmission setting
SS Disable DS Enable
2-digits identified position; Forward/backward data transmission setting
SS Transmitted data excluded the data of identified position DS Transmitted data included the data of identified position
FIN (2 digits) position direction
FIN (2 digits) position direction
0 1
0 (Forward) 1 (Backward)
0 (Forward) 1 (Backward)
The Data Organizer is used to edit the scanned raw data prior to transmitting the data to the host computers or terminals. It allows you to select desired bar code symbologies for organizer control, and provides maximum two identified positions to send the data forward or backward. It also allows you to control the transmitted data including or excluding the data of identification position. Please refer to the application example listed in page 60 for details.
While the Data Organizer is enabled, it arranges only scanned data without Preamble, Postamble, STX, ETX, Data Length, Prefix/Suffix Symbology ID or Record Suffix.
Regarding the "Bar Code Selection" and "Position Calculation" of Data Organizer, please refer to page 60 for details. Please note that all "Character" input should be referred to the ASCII/HEX Table.
Wireless FuzzyScan
Reference Manual
126
Configuring Your Scanner
Select a Barcode Symbology
You can select one or all types of barcode symbologies to use Condensed DataWizard for advanced transmission arrangement. If you scan "00" to select all types, the FuzzyScan will arrange all incoming data to meet your pre-defined format. If you want to select only one type bar code, please select one of the option code listed below.
1D Bar Code Symbology
Code 128
01 Matrix 2 of 5
38
GS1-128
31 Interleaved 2 of 5
48
UPC-A
02 China Postal Code
58
UPC-A with 2 supplement
32 German Postal Code
68
UPC-A with 5 supplement
42 Standard/Industrial 2 of 5
08
UPC-E
03 Code 93
09
UPC-E with 2 supplement
33 Code 11
10
UPC-E with 5 supplement
43 MSI/Plessey
11
EAN-13
04 UK/Plessey
12
EAN-13 with 2 supplement
34 Telepen
13
EAN-13 with 5 supplement
44 GS1 DataBar
14
EAN-8
05 IATA
15
EAN-8 with 2 supplement
35 Coupon Code
16
EAN-8 with 5 supplement
45 PDF417
17
Codabar/NW-7
06 Codablock F
18
Code 39
07 Code 16K
19
Code 32
37 Code 49
20
Trioptic Code 39
47 GS1 DataBar Limited
22
GS1 DataBar Expanded
23
Composite Codes
24
Micro PDF417
25
2D Bar Code Symbology
QR Code
A0 MaxiCode
A2
MicroQR Code
A0 Aztec Code
A3
DataMatrix GS1 DataMatrix
A1 Chinese Sensible Code
A4
A5
Postal Code
Korea Post Code
21 Japanese Post
B4
Australian Post
B0 KIX Post
B5
British Post
B1 Planet Code
B6
Intelligent Mail barcode
B3 Postnet
B8
Position Calculation [Data Formatter]
If there is a 5-character input data string, refer to the following to calculate the actual position for insertion:
X
X
X
X
X
00
01
02
03
04
05
[Data Verifier, Data Replacer, Data Organizer] If there is a 11-character data string, please refer to the following to calculate the actual position for identification.
X X X X X X X X X X X 00 01 02 03 04 05 06 07 08 09 10
Wireless FuzzyScan
Reference Manual
127
Configuring Your Scanner
Application Example
If your bar code label is a 16-digit Interleaved 2 of 5 which includes the information of 6-digit date code, 6-digit serial number and 4-digit unit price, you want the FuzzyScan do the following for you without software modification: Apply only Interleaved 2 of 5 to the condensed
DataWizard. Check bar code is actually with 16-digit length. Allow bar code output whose date code is leading with "9". Three outputs with "TAB" suffix. The date code output should skip "9" and replaced it by
"A". The serial number output should be led with "SN". The unit price output should be skipped the first 2 digits. Test Bar Code : 9 8 1 0 2 5 1 2 3 4 5 6 9 8 7 6
Actual Output : A81025[TAB]SN123456[TAB]76[TAB]
Programming Procedure
[Data Verifier]
Scan "Program" to enter the programming mode. Scan "Verifier Control" and set bar code symbology to
"48" (Interleaved 2 of 5). Scan "Identified Data Length" and set the length to
"16". Scan "1st Identified Character" and set the identified
position to "00", then set the identified character to "39" (Hex Code of 9).
[Data Formatter]
Scan "Formatter Control" and set bar code symbology to "48".
Scan 1st Insertion" and set the identified position to "06", then inserted characters to "09" (Hex Code of TAB), "53" (Hex Code of S), "4E" (Hex Code of N).
Scan "2nd Insertion" and set the identified position to "12", then inserted character to "09". In the final, you must scan "FIN" (Finish) code to terminate this selection.
Scan "3rd Insertion" and set the identified position to "16", then inserted character to "09". In the final, you must scan "FIN" (Finish) code to terminate this selection.
128
Wireless FuzzyScan
Reference Manual
Configuring Your Scanner
[Data Replacer] Scan "Replacer Control" and set bar code symbology to
"48". Scan "1st Replacement" and set the identified position to
"00", then replaced character to "41" (Hex Code of A).
[Data Organizer] Scan "Organizer Control" and set bar code symbology to
"48". Scan "1st Organization" and set the identified position to
"16", then set the data transmission to "0" (forward). Scan "2nd Organization" and set the identified position to
"17", then set the data transmission to "1" (backward). Scan "END" (Exit) to terminate the programming.
[Important Notice] Please note that Condensed DataWizard will follow the preset working flow as below:
Verifier Formatter Replacer Organizer
So when you set the identified position in Data Organizer, you must consider the inserted data which you already set via Data Formatter.
129
Wireless FuzzyScan
Reference Manual
Wireless FuzzyScan
Reference Manual
Appendix
APPENDIX
130
Appendix
Symbology ID Table
Each AIM Code Identifier contains the three-character string ]cm where: ] = Flag Character, c = Code Character, m = Modifier Character
1D Symbology ID Table
Cino ID
AIM ID
Code Family
Primary Format
Hex
Code
Char.
value
Char.
Modified Char.
UPC
Code 128 Codabar
Code 25
UPC-A
2
0
UPC-A with 2 supple.
32
A
1
UPC-A with 5 supple.
42
UPC-E
3
2 E
0
UPC-E with 2 supple.
33
E
1
UPC-E with 5 supple.
43
2
Example: A UPC-A bar code 012345678950 with 2 supplement 12 is transmitted as ]E0012345678950]E112
Code 128 GS1-128
01
B
m
C
31
C
1
Codabar/NW-7
06
D
F
m
Standard/Industrial 2 of 5 08
I
S
0
Matrix 2 of 5
38
K
X
0
Interleaved 2 of 5
48
J
I
m
China Postal Code
58
L
X
0
German Postal Code
68
M
I
m
IATA
IATA
15
O
R
m
UCC Coupon Code
Z
UCC Coupon
Example : A UPC-A 512345678900 + GS1-128 81010123451297 bar code is transmitted as]E0512345678900]C181010123451297
Example: A EAN-13 9923456789019 + GS1-128 81010123451297 bar code is transmitted as ]E09923456789019]C181010123451297
Cino ID
AIM ID
Code Family
Primary Format
Hex value
Char.
Code Char.
Modified Char.
EAN/JAN
Code 93 Code 11 MSI/Plessey UK/Plessey Telepen GS1 DataBar Composite Code 39 PDF417 Codablock Korea Post
EAN/JAN-8
05
4
EAN/JAN-8 with 2 supple.
35
N
E
1
EAN/JAN-8 with 5 supple.
45
2
EAN/JAN-13
04
0
EAN/JAN-13 with 2 supple.
34
F
E
1
EAN/JAN-13 with 5 supple.
44
2
Example: A EAN/JAN-8 bar code 49123562 with 5 supplement 12345 is transmitted as ]E449123562]E212345
Code 93
09
H
G
m
Code 11
10
P
H
m
MSI/Plessey
11
R
M
m
UK/Plessey
12
S
P
0
Telepen
13
T
B
m
GS1 Databar
14
GS1 DataBar Limited
22
X
e
m
GS1 DataBar Expanded
23
Composite Code
24
Code 39
07
G
A
m
Code 39 Trioptic
47
W
X
0
Code 32
37
G
A
0
PDF417 Micro PDF417
17
V
L
m
25
Codablock F
18
Y
O
m
Korea Post Code
21
a
X
0
Remark: Above examples are given for the transmission of AIM ID.
Wireless FuzzyScan
Reference Manual
131
Code Family
Primary Format
QR Code Micro QR Code
Data Matrix
MaxiCode Aztec Code Chinese Sensible Australian Post
QR Code Micro QR Code Data Matrix GS1 Data Matrix MaxiCode Aztec Code Chinese Sensible
Australian Post
Appendix
Cino ID Hex
Char. Value
A0
b
A1 c
A5
A2
d
A3
e
A4
f
B0
g
2D Symbology ID Table
AIM ID
Code Char.
Modified Char.
Q
m
d
m
U
m
z
m
Code Family
Primary Format
British Post Intelligent Mail barcode
Japanese Post
KIX Post Planet Code
British Post Intelligent Mail barcode
Japanese Post KIX Post Planet Code
0
Postnet
Postnet
X
0
Cino ID
Hex Value
B1
Char. h
B3
j
AIM ID
Code Char.
Modified Char. 0
0
B4
k
0
X
B5
l
0
B6
m
0
B8
o
0
Wireless FuzzyScan
Reference Manual
132
Keyboard Function Code Table
No.
ANSI
00
NUL
01
SOH
02
STX
03
ETX
04
EOT
05
ENQ
06
ACK
07
BEL
08
BS
09
HT
10
LF
11
VT
12
FF
13
CR
14
SO
15
SI
16
DLE
17
DC1
18
DC2
19
DC3
ASCII 00H 01H 02H 03H 04H 05H 06H 07H 08H 09H 0AH 0BH 0CH 0DH 0EH 0FH 10H 11H 12H 13H
Appendix
Key Function 1 RESERVED CTRL (Left) ALT (Left) SHIFT CAPS LOCK NUM LOCK ESC F1 BACK SPACE TAB F2 F3 F4 ENTER (CR) F5 F6 F7 F8 F9 F10
Key Function 2 Ctrl + @ Ctrl + A Ctrl + B Ctrl + C Ctrl + D Ctrl + E Ctrl + F Ctrl + G Ctrl + H Ctrl + I Ctrl + J Ctrl + K Ctrl + L Ctrl + M Ctrl + N Ctrl + O Ctrl + P Ctrl + Q Ctrl + R Ctrl + S
Key Function 3 CTRL MAKE (Left) CTRL BREAK (Left) ALT MAKE (Left) ALT BREAK (Left)
CAPS LOCK NUM LOCK
ESC F1 BACK SPACE TAB F2 F3 F4 ENTER (CR) F5 F6 F7 F8 F9 F10
Wireless FuzzyScan
Reference Manual
133
Appendix
No.
ANSI
20
DC4
21
NAK
22
SYN
23
ETB
24
CAN
25
EM
26
SUB
27
ESC
28
FS
29
GS
30
RS
31
US
ASCII 14H 15H 16H 17H 18H 19H 1AH 1BH 1CH 1DH 1EH 1FH
Key Function 1 F11 F12
INS (Insert) (Edit) DEL (Delete) (Edit)
HOME (Edit) END (Edit) PAGE UP (Edit) PAGE DOWN (Edit) UP (Edit) DOWN (Edit) LEFT (Edit) RIGHT (Edit)
Key Function 2 Ctrl + T Ctrl + U Ctrl + V Ctrl + W Ctrl + X Ctrl + Y Ctrl + Z Ctrl + [ Ctrl + \ Ctrl + ] Ctrl + 6
*see below note
Key Function 3 WIN MAKE (Left) WIN BREAK (Left) SHIFT MAKE (Left)
SHIFT BREAK (Left) HOME (Edit) END (Edit)
PAGE UP (Edit) PAGE DOWN (Edit)
UP (Edit) DOWN (Edit) LEFT (Edit) RIGHT (Edit)
To emulate the keyboard function key input for user definable parameters, user must configure actual content using the Reserved ASCII 0 31 characters, and also Enable the "Function Key Emulation". Otherwise, the Ctrl output will be done by the scanner. Please refer to the above Keyboard Function Code Table which is for IBM PC/XT/AT, PS/2, PS/VP, COMPAQ PC, HP Vectra PC, Notebook PC, APPLE and PowerMac, and WYSE PC Enhanced or fully compatible machines.
The last character in the Ctrl Output column is varied for different countries.
Country (refer to Keyboard Layout) & Character
United State -
Switzerland -
Belgium
-
UK
-
Sweden
-
Denmark
-
Spain
-
Italy
-
France
=
Germany
-
Norway
-
Wireless FuzzyScan
Reference Manual
134
Wireless FuzzyScan
Reference Manual
Appendix
Code Page Table of Corresponding Languages
Description
Albanian Arabic Arabic Baltic Bulgarian Catalan Croatian Cyrillic Czech Danish Dutch Estonian English - United Kingdom English - Australia English - Canada English - New Zealand English - United States English - South Africa English - Philippines Finnish French German Greece Greece Hebrew - write Hebrew Israel
Code Page
850 1256 720 1257 866 850 852 1251 852 850 850 775 850 850 850 850 437 437 437 850 850 850 737 1253 1255 862
Description
Hungarian Icelandic Italian Japanese Korean Latin 1 Latin 2 Latin 5 Latin American Latvian Lithuanian Norwegian Polish Portuguese Romanian Russian Serbian Slovakian Slovenian Spanish Swedish Chinese (Tradition) Chinese (Simple) Thai Turkish Vietnamese
135
Code Page
852 850 850 932 949 1252 1250 1254 850 775 775 850 852 850 852 866 855 852 852 850 850 950 936 874 857 1258
Appendix
Code Page Unicode Hex Input Setup
1. Windows - Setting up the Windows Registry Step 1: Open the Registry Editor. You can do so by typing "regedit" in the "Search Windows" function or in Command Prompt. Step 2: Go to HKEY_CURRENT_USER\Control Panel\Input Method
Step 3: Right-click on mouse or press shift + F10 (on keyboard) to add a new String Value (of type "REG_SZ").
136
Wireless FuzzyScan
Reference Manual
Appendix
Step 4: Name the new String value as "EnableHexNumpad" and set its Value data to "1".
Step 5: Reboot the computer. 2. MAC - Adding Unicode Hex Input in menu bar
Step 1: Go to the Apple Menu -> System Preferences -> Keyboard
137
Wireless FuzzyScan
Reference Manual
Appendix
Step 2: On the Keyboard tab, click on "Input Sources" and check the "Show Input menu in menu bar" box.
Step 3: Click the "+" button to add an input source.
138
Wireless FuzzyScan
Reference Manual
Appendix
Step 4: Scroll to and select "Others". Click on "Unicode Hex Input" (you can also use the Search function to find it). When done, click on the "Add" button.
Step 5: Close the Keyboard Preferences menu. Step 6: Change the input selection to Unicode Hex Input in menu bar.
139
Wireless FuzzyScan
Reference Manual
Appendix
ASCII Input Shortcut
To configure the user definable parameters of FuzzyScan via programming menu, FuzzyScan will ask you to scan your desired ASCII value in HEX form. You have to refer to the "HEX/ASCII Table" for details.
Example: If you want the scanned data output leading with a Dollar Sign, you have to set the "Preamble" to "$". The configuration procedure is listed below for reference.
Scan the system command PROGRAM listed on page 3-24 to enter programming mode.
Scan family code PREAMBLE to select this family. Refer to the Hex/ASCII Table, you will find the HEX value
of "$" is 24. Scan the option code 2 listed on the fold out back cover. Scan the option code 4 listed on the fold out back cover. Scan the system command FIN (Finish) to terminate
Preamble setting.
Scan the system command End to exit the programming mode for normal operation.
HEX/ASCII Reference Table
H
0
1
2
3
4
5
6
7
L
0
NUL DLE SPACE 0
@
P
`
p
1
SOH DC1 !
1
A
Q
a
q
2
STX DC2 "
2
B
R
b
r
3
ETX DC3 #
3
C
S
c
s
4
EOT DC4 $
4
D
T
d
t
5
ENQ NAK %
5
E
U
e
u
6
ACK SYN &
6
F
V
f
v
7
BEL ETB '
7
G
W
g
w
8
BS CAN (
8
H
X
h
x
9
HT EM
)
9
I
Y
i
y
A
LF SUB *
:
J
Z
j
z
B
VT ESC +
;
K
[
k
{
C
FF FS
,
<
L
\
l
|
D
CR GS
-
=
M
]
m
}
E
SO RS
.
>
N
^
n
~
F
SI US
/
?
O
_
o DEL
Example: ASCII "A" HEX "41"; ASCII "a" "61"
: High Byte of HEX Value
: Low Byte of HEX Value
Wireless FuzzyScan
Reference Manual
140
Link Mode Quick Set Commands
Appendix
PAIR Mode SPP Master Simple Mode
HID Legacy Mode
Uninstall HID Mode
PICO Mode SPP Slave Simple Mode HID Mode with Passkey
Wireless FuzzyScan
Reference Manual
141
Host Interface Quick Set Commands
(With Smart Cradle only)
Appendix
USB HID Standard Mode USB HID Turbo Mode USB HID Legacy Mode
RS232 Serial USB Com Port Emulation
PS/2 (DOS/V) KBW Standard Mode PS/2 (DOS/V) KBW Turbo Mode
PS/2 (DOS/V) Keyboard Replacement
Wireless FuzzyScan
Reference Manual
142
Option Codes
0 1 2 3
FIN (Finish)
Appendix
8 4
9 5
A 6
B 7
Abort
C D E F END (Exit)
Wireless FuzzyScan
Reference Manual
143
System Commands
Appendix
PROGRAM (Enter Programming Mode)
Paging
Save Configuration
FIN (Finish)
Clone
PowerTool Host Link
END (Exit Programming Mode)
Power Off
Factory Default
System Information List (SYSLIST)
Master Default
Factory Default: After scanning" Factory Default" command, all parameters will be returned to factory default value (The radio link will be disconnected and the scanner will revert to uninstall state).
Master Default: After scanning "Master Default" command, the scanner will remain the pre-set parameters of Host Interface Selection, Keyboard Interface Control (except Record Suffix; Preamble; Postamble), Serial Interface Control (except Record Suffix; Preamble; Postamble), Wand/Laser Emulation Control, Bluetooth Device Name, Bluetooth PIN Code, and Out-of-range Scanning, the rest of parameters will be returned to default value (The radio link is still keep on).
Wireless FuzzyScan
Reference Manual
Save User Default
User Default
User Default: After scanning" Save User Default" command, all current parameters will be stored to the flash memory. Once you change the parameter and would like to return to previous setting, please scan "User Default".
144
Indications
Scanner Indication
Items Radio connection Radio disconnection During connection Radio connection built Radio connection lost Data Transmission
Items Under charging (on cradle) Fully charged (on cradle) Under batch scanning Pair failure Out of memory Battery power low Battery power extremely low Good read Under Configuration Uninstall state Upgrade state Time out warning Paged by smart cradle Battery no power Power Off
Appendix
Link Indicator 1 blue blink per 2.5 sec. 3 blue blinks per 2 sec. Quick blue blinks 1 blue blink per 2.5 sec. 3 blue blinks per 2 sec. Quick blue blink
Status Indicator Steady red Steady green 1 green blink per 2.5 sec. 3 blue blinks per 2 sec. 2 red blinks 1 red blink at regular interval 1 red blink 1 green blink Steady red Alternative red and green blinks Steady red Off Off Off Off
Beeping Off Off Short clicks 4 beeps in ascending tone 4 beeps in descending tone Short clicks
Beeping Off Off Off Off 2 long beeps 1 beep at regular interval 8 beeps 1 good read beep Off Off Short click 3 long beeps 6 page beeps Off Off
Wireless FuzzyScan
Reference Manual
145
Appendix
Central Indicator Side Indicators
Central Indicator Side Indicators
HB2112 / HB3112 Smart Cradle Indications
Items
Central
Power on
Blink blue once
Smart Cradle Upgrade State
Off
Uninstall state
Off
PICO Mode
Radio Connected Steady blue Radio Disconnected Off
PAIR Mode
Radio Connected Steady blue Radio Disconnected Off
Smart cradle paged by scanner
PICO Mode PAIR Mode
Steady blue Steady blue
Indicators Side
Beeping
Off
Power on beeps
Steady red
Short clicks
Alternative red-green blinks Off
Steady green
Off
Steady red
Off
Off
Off
Steady red
Off
Steady green
6 page beeps
Off
6 page beeps
HB2100 Charging Cradle Indication
Power on
Items
Central Indicator Steady blue
Beeping Off
Wireless FuzzyScan
Reference Manual
146
Appendix
SD112 Smart Dongle Indications
Power on
Event
Power/Pairing Indicator
blue blink once
Off
Status Indicator
Dongle Upgrading
Off
Steady red
Unpaired
Off
Alternative red-green blinks
PICO Mode
Radio Connected Steady blue Radio Disconnected Off
Steady Green Steady red
PAIR Mode
Radio Connected Steady blue Radio Disconnected Off
Off Steady red
Wireless FuzzyScan
Reference Manual
147
Wireless FuzzyScan
Reference Manual
Appendix 148
Microsoft Word for Microsoft 365
