Shift Modes Manual/auto (1st–D or 2nd–D); Quick-Shift button with 2 selectable modes: kick-down or kick-up/down; and 4 clutch cutoff settings Standard 5-Speed Maximum Travel Speeds (with 20.5 R 25 tires) Forward Reverse Range 1 5.6 km/h (3.5 mph) 5.9 km/h (3.6 mph)
Shift Modes Manual/auto (1st–D or 2nd–D); Quick-Shift button with 2 selectable modes: kick-down or kick-up/down; and 4 clutch cutoff settings Standard 5-Speed Maximum Travel Speeds (with 20.5 R 25 tires) Forward Reverse Range 1 5.6 km/h (3.5 mph) 5.9 km/h (3.6 mph) Range 2 11.0 km/h (6.8 mph) 11.6 km/h (7.2 mph)
L-SERIES WHEEL LOADERS 524L / 544L / 624L VERSATILITY MEETS CAPABILITY ASPIRE TO GO + + MORE EASY-TO-USE NEW SPACIOUS ELECTROHYDRAULIC FRONT-END CAB* CONTROLS FEATURES *Compared to our K-Series models. THE NEW L-SERIES HIGHER. ELEVATE YOUR EXPECTATIONS. Combining new front-end features that dramatically boost productivity with an all-new cab and controls, our 524L, 544L, and 624L Loaders redefine your expectations of what a utility loader can do. Enhancements over previous models include near-parallel lift, a more spacious cab, ergonomic controls, and new bucket and linkage designs. Plus a host of details that improve uptime, including reimagined electrical and hydraulic routing, for performance and reliability that can elevate your operation to a higher level. 4 NEW FRONT-END FEATURES AND MORE MEET THE NEW FRONT-RUNNERS. L-Series Loaders lead the way with new production-boosting features up front, along with a host of other enhancements that help dramatically increase performance. More performance up front Boasting new bucket and linkage designs that improve load leveling, material retention, and visibility, these loaders deliver more productivity and performance than previous models. Enhanced production buckets A wide selection of enhanced production buckets with integrated spill guards, curved side cutters, and greater rollback delivers better bucketfill performance and material retention. Redesigned cab New operator station is more spacious and comfortable, and features extra legroom, an improved HVAC system, additional storage, and a more adjustable seat. Or opt for a premium cab with a larger monitor and a heated and ventilated premium seat. New EH controls Seat-mounted right-hand joystick features two programmable multifunction buttons and new electrohydraulic (EH) controls that are more intuitive to operate compared to our K-Series controls. 8° OF PARALLELISM VS. 21° ON K-SERIES STANDOUT FEATURE GO ABOVE AND BEYOND LOAD MORE. Boasting near-parallel lift along with new High-Lift Plus and Tool Carrier configurations, these versatile loaders put more productivity within reach. Standard Z-Bar with parallel lift Lift path on all Z-Bar linkages has been improved to near parallel for better load-leveling capability. This boosts productivity by minimizing load rollback, reducing material spillage, and requiring fewer manual adjustments. New Tool Carrier configuration Tool Carrier configuration on the 524L and 624L enables a clear view of the coupler and forks, making it easier to quickly move pipes, logs, and pallets. Improved visibility to front tool Cross-tube and boom geometry of the Z-Bar linkage has been streamlined to provide a better view to the front attachment. New High-Lift Plus configuration Need even more reach for dumping into higher feeders, hoppers, trucks, and wagons? New High-Lift Plus configuration provides an additional 24 inches in hinge-pin height over standard lift height and 12 inches over the High-Lift model. All three lift heights feature near-parallel lift. 15° MORE ROLLBACK THAN K-SERIES FOR GREATER MATERIAL RETENTION 6 TAKE PRODUCTIVITY TO NEW HEIGHTS. TONS OF COMFORT TAKE A LOAD OFF. With redesigned cab and controls, more storage and power ports, and a better HVAC system than earlier models, L-Series Loaders make it easy to work harder with less effort. Get in and get comfortable All-new cab boasts three more inches of legroom than previous models. Joystick controls, foot pedals, and sealed-switch module are all ergonomically placed for optimal comfort and convenience. Additional 12-volt and USB power ports and mounting points keep all your devices charged up and within easy reach. Stowaway storage HVAC system has been relocated outside the cab to provide more storage area. There's plenty of space for a powered cooler, along with a handy 12-volt outlet. There's also a Thermos® holder with a Velcro® strap, plus a conveniently placed cupholder. There are even coat hooks. Sit back and relax Updated in stain-resistant cloth, the standard high-back air-ride seat is even more adjustable, for daylong comfort and support. Or choose the optional heated and ventilated premium seat (standard in the premium cab) with heavy-duty air suspension and adjustable seat pan for even more comfort. Keep things cool HVAC system is easier to maintain, with convenient filter and service locations. Brushless motor is more reliable and provides infinite fan speeds, quieter operation, and improved airflow. Blower vent behind the seat further improves airflow and defrosts the rear window. Premium cab features automatic temperature control (ATC). See more, do more Improved visibility to the work tool helps reduce spillage, cycle times, and tool-changeover time. It also helps minimize machine damage when working on crowded jobsites or up against walls. Multi-language color LCD display A large seven-inch in-cab display with easy-on-the-eyes clarity enables intuitive push-button access to key info. Standard rearview camera displays the activity behind the machine on the LCD screen. Add a dedicated seven-inch rearview display to see the action behind and still have access to vital machine data at all times. 8 3" MORE LEGROOM THAN K-SERIES CABS MORE PRODUCTIVITY, HANDS DOWN GET IN TOUCH WITH YOUR PRODUCTIVE SIDE. With redesigned joysticks and expanded, customizable electrohydraulic (EH) controls, maximum productivity is close at hand in an L-Series Loader. Integrated joystick control Operators can easily control up to six functions without removing their hand from the ergonomically designed joystick. A larger F-N-R button provides convenient direction and full-range gear changes. Two industryexclusive multifunction buttons can each be programmed to handle any of 10 functions selected through the monitor. Single-axis controls New low-effort, short-throw control includes two multifunction buttons on the bucket lever that can be programmed to handle any of 10 functions. 10 2 INDUSTRYEXCLUSIVE MULTIFUNCTION JOYSTICK BUTTONS Expanded EH functionality Operators can easily enable the following EH functions using the multifunction buttons and adjust them through the monitor: New SSM functionality Sealed-switch module (SSM) has been repositioned under the monitor so it's in the operator's line of sight. Updated or new functions include: Soft or hard hydraulic stops for both the boom and bucket can be enabled to prolong machine life or temporarily disabled when the application calls for it. Hydraulic-function flow can be used to customize flow for specific attachments without needing special plumbing or valves. Bucket vibrate creates a slight vibration when dumping loose materials into hoppers or feeders, or when sprinkling rock over pipe. Return-to-dig now allows leveling of the bucket from both dump and curl positions, for quick and easy leveling. Constant-flow hydraulics allow the operator to continuously run attachments without having to hold a lever or roller at full stop. Throttle lock maintains a specified rpm so the operator can warm up a machine, run a continuous-flow attachment, or road the machine without having to hold the throttle pedal down. EH Precision mode allows fine metering of the bucket and boom when precise movement is required, for example, laying pipe, moving heavy objects such as road barriers, or placing manholes. Attachment configuration allows settings such as hydraulic flow and responsiveness for up to 10 different attachments to be conveniently stored. TIGHTFISTED EASYGOING ABOUT EVERYTHING BUT THE BOTTOM LINE. Reliable electrical and hydraulic systems Routing for electrical wire harnesses and hydraulic hoses has been improved over the K-Series to reduce rubbing and eliminate leak points, boosting durability and reliability. Same-side ground-level service All daily service points including fuel are conveniently grouped on the left side of the machine for easy access. Innovative Quad-CoolTM system Quad-Cool places the radiator, air-conditioner condenser, intercooler, and hydraulic, transmission, and axle coolers (standard on the 624L, optional on the 524L and 544L) in a unique boxed configuration that's isolated from engine heat, boosting efficiency and durability. Diagnostic messaging Easy-to-navigate LCD monitor displays diagnostic messages if problems occur and even offers possible solutions to help get you back up and running quickly. Efficient cooling Hydraulically driven fan runs only as needed for better cooling and fuel efficiency. Optional programmable fan automatically reverses at predetermined intervals to eject debris from the radiator and cooler cores. Or set individual cleaning cycles through the monitor. 12 Get valuable insight with JOHN DEERE WORKSIGHTTM The John Deere WorkSight suite of construction technology delivers Productivity Solutions to help you get more done, more efficiently. The in-base, five-year JDLinkTM telematics subscription provides machine location, utilization data, and alerts to help you maximize productivity and efficiency. Other productivity solutions including grade-management and payload-weighing options are also available. To maximize uptime and lower costs, JDLink telematics also enables John Deere Connected Support.TM John Deere's centralized Machine Health Monitoring Center analyzes data from thousands of connected machines, identifies trends, and develops recommended actions, called Expert Alerts, to prevent downtime. Dealers use Expert Alerts to proactively address conditions that may otherwise likely lead to downtime. Your dealer can also monitor machine health and leverage remote diagnostics and programming capability to further diagnose problems and even update machine software without a time-consuming trip to the jobsite. S PE C IF IC AT IONS While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Engine 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Manufacturer and Model John Deere PowerTechTM PVS 6068 Gross Peak Torque (ISO 9249) 713 Nm (526 ft.-lb.) at 1,400 rpm Non-Road Emission Standard EPA Final Tier 4/EU Stage V Net Torque Rise 60% Cylinders 6 Fuel System (electronically controlled) High-pressure common rail Valves Per Cylinder 4 Lubrication Full-flow spin-on filter and integral cooler Displacement 6.8 L (414 cu. in.) Aspiration Turbocharged, charge air cooled Net Peak Power (ISO 9249) 113 kW (152 hp) at 1,800 rpm Air Cleaner Under-hood, dual-element dry type, Gross Peak Power (ISO 9249) 120 kW (161 hp) at 1,800 rpm restriction indicator in cab monitor Net Peak Torque (ISO 9249) 683 Nm (504 lb.-ft.) at 1,100 rpm for service Cooling Fan Drive Hydraulically driven, proportionally controlled, fan aft of coolers Electrical Electrical System 24 volt with 100-amp alternator (optional 130-amp alternator) Batteries (2 12 volt) 950 CCA (each) Transmission System Type Countershaft-type PowerShiftTM Torque Converter Single stage, single phase Shift Control Electronically modulated, adaptive, load and speed dependent Operator Interface Steering-column or joystick-mounted F-N-R and gear-select lever; Quick-Shift button on hydraulic lever Shift Modes Manual/auto (1stD or 2ndD); Quick-Shift button with 2 selectable modes: kick-down or kick-up/down; and 4 clutch cutoff settings Standard 5-Speed Maximum Travel Speeds (with 20.5 R 25 tires) Forward Reverse Range 1 5.6 km/h (3.5 mph) 5.9 km/h (3.6 mph) Range 2 11.0 km/h (6.8 mph) 11.6 km/h (7.2 mph) Range 3 17.0 km/h (10.6 mph) 27.0 km/h (16.8 mph) Range 4 25.6 km/h (15.9 mph) N/A Range 5 40.0 km/h (24.8 mph) N/A Axles/Brakes Final Drives Heavy-duty inboard-mounted planetary Differentials Hydraulic locking front with conventional rear -- standard; dual locking front and rear -- optional Rear Axle Oscillation, Stop to Stop 24 deg. (12 deg. each direction) (with 20.5 R 25 tires) Brakes (conform to ISO 3450) Service Hydraulically actuated, spring-retracted, self-adjusting inboard sun-shaft mounted, oil cooled, single disc Parking Automatic spring applied, hydraulically released, driveline mounted, sealed wet multi disc Tires/Wheels (see page 18 for complete tire adjustments) Tread Width Width Over Tires Michelin 20.5 R 25, 1 Star L-3 XHA2 1952 mm (76.8 in.) 2546 mm (100.2 in.) Serviceability Refill Capacities Fuel Tank (with lockable cap) 220 L (58 gal.) Axle Oil (each) Cooling System 29.9 L (31.6 qt.) Front 16.6 L (17.5 qt.) Diesel Exhaust Fluid (DEF) 15.6 L (16.5 qt.) Rear 18 L (19 qt.) Engine Oil with Vertical Spin-On Filter 19.5 L (20.6 qt.) Hydraulic Reservoir and Filter 82.1 L (21.7 gal.) Transmission Reservoir with Vertical 21 L (22.2 qt.) Park Brake Oil (wet disc) 0.3 L (10 oz.) Filter Hydraulic System/Steering Pump (loader and steering) Variable-displacement, axial-piston pump; closed-center, pressure-compensating system Maximum Rated Flow at 6895 kPa 178 L/m (47 gpm) (1,000 psi) and 2,200 rpm System Relief Pressure (loader and 24 994 kPa (3,625 psi) steering) Loader Controls 2-function valve, joystick control or fingertip controls, hydraulic-function enable/disable, optional 3rd- and 4th-function valve with auxiliary lever Steering (conforms to ISO 5010) Steering-column-mounted, twist-grip shift lever; Quick-Shift button on hydraulic lever Type Power, fully hydraulic Articulation Angle 80-deg. arc (40 deg. each direction) Turning Radius (measured to centerline 5.0 m (16 ft. 5 in.) of outside tire) Hydraulic Cycle Times Z-Bar / High-Lift / High-Lift Plus Tool Carrier Raise 6.1 sec. 5.8 sec. Dump 2.0 sec. 2.2 sec. Lower (power down) 4.0 sec. 3.5 sec. 14 Total 12.1 sec. 11.5 sec. S PE C IF IC AT IONS While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Dimensions and Specifications with Pin-On Bucket 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER M N I G J H Cab A B L D C K E F 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH PIN-ON BUCKET WITH BOLT-ON EDGE Z-Bar Z-Bar High-Lift High-Lift Plus 2.1-m3 (2.75 cu. yd.) 2.3-m3 (3.0 cu. yd.) 2.1-m3 (2.75 cu. yd.) 2.1-m3 (2.75 cu. yd.) Dimensions with Bucket with Bolt-On Edge general purpose general purpose general purpose general purpose A Height to Top of Cab 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) B Hood Height 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) C Ground Clearance 0.40 m (15.7 in.) 0.40 m (15.7 in.) 0.40 m (15.7 in.) 0.40 m (15.7 in.) D Length from Centerline to Front Axle 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) E Wheelbase 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) F Overall Length, Bucket on Ground 7.37 m (24 ft. 2 in.) 7.45 m (24 ft. 5 in.) 7.80 m (25 ft. 7 in.) 8.10 m (26 ft. 7 in.) G Height to Hinge Pin, Fully Raised 3.81 m (12 ft. 6 in.) 3.81 m (12 ft. 6 in.) 4.17 m (13 ft. 8 in.) 4.42 m (14 ft. 6 in.) H Dump Clearance, 45 deg., Full Height 2.78 m (9 ft. 1 in.) 2.72 m (8 ft. 11 in.) 3.14 m (10 ft. 4 in.) 3.39 m (11 ft. 1 in.) I Reach, 45-deg. Dump, Full Height 0.99 m (3 ft. 3 in.) 1.04 m (3 ft. 5 in.) 1.09 m (3 ft. 7 in.) 1.12 m (3 ft. 8 in.) J Reach, 45-deg. Dump, 2.13-m (7 ft. 0 in.) Clearance 1.44 m (4 ft. 9 in.) 1.47 m (4 ft. 10 in.) 1.81 m (5 ft. 11 in.) 2.03 m (6 ft. 8 in.) K Maximum Digging Depth 102 mm (4.0 in.) 108 mm (4.3 in.) 193 mm (7.6 in.) 198 mm (7.8 in.) L Maximum Rollback at Ground Level 44 deg. 44 deg. 48 deg. 49 deg. M Maximum Rollback, Boom Fully Raised 60 deg. 60 deg. 60 deg. 61 deg. N Maximum Bucket Dump Angle, Fully Raised 50 deg. 50 deg. 46 deg. 45 deg. Loader Clearance Circle, Bucket Carry Position 11.40 m (37 ft. 5 in.) 11.42 m (37 ft. 6 in.) 11.68 m (38 ft. 4 in.) 12.08 m (39 ft. 7 in.) Specifications with Bucket with Bolt-On Edge Capacity, Heaped 2.1 m3 (2.75 cu. yd.) 2.3 m3 (3.0 cu. yd.) 2.1 m3 (2.75 cu. yd.) 2.1 m3 (2.75 cu. yd.) Capacity, Struck 1.7 m3 (2.26 cu. yd.) 1.9 m3 (2.53 cu. yd.) 1.7 m3 (2.26 cu. yd.) 1.7 m3 (2.26 cu. yd.) Bucket Weight with Bolt-On Cutting Edge 1056 kg (2,327 lb.) 1095 kg (2,415 lb.) 1056 kg (2,327 lb.) 1056 kg (2,327 lb.) Bucket Width 2.55 m (8 ft. 4 in.) 2.55 m (8 ft. 4 in.) 2.55 m (8 ft. 4 in.) 2.55 m (8 ft. 4 in.) Breakout Force 11 070 kg (24,406 lb.) 10 285 kg (22,674 lb.) 10 952 kg (24,145 lb.) 11 059 kg (24,381 lb.) Tipping Load, Straight, No Tire Deflection 10 297 kg (22,702 lb.) 10 172 kg (22,426 lb.) 8667 kg (19,107 lb.) 7967 kg (17,564 lb.) Tipping Load, Straight, with Tire Deflection 9753 kg (21,502 lb.) 9630 kg (21,230 lb.) 8253 kg (18,195 lb.) 7614 kg (16,786 lb.) Tipping Load, 40-deg. Full Turn, No Tire Deflection 8955 kg (19,742 lb.) 8840 kg (19,489 lb.) 7496 kg (16,526 lb.) 6860 kg (15,123 lb.) Tipping Load, 40-deg. Full Turn, with Tire 8259 kg (18,208 lb.) 8145 kg (17,957 lb.) 6963 kg (15,351 lb.) 6390 kg (14,088 lb.) Deflection Rated Operating Load, 50% Full-Turn Tipping Load, 4477 kg (9,871 lb.) 4420 kg (9,745 lb.) 3748 kg (8,263 lb.) 3430 kg (7,562 lb.) No Tire Deflection (conforms to ISO 14397-1)* Rated Operating Load, 50% Full-Turn Tipping Load, 4130 kg (9,104 lb.) 4073 kg (8,978 lb.) 3482 kg (7,675 lb.) 3195 kg (7,044 lb.) with Tire Deflection (conforms to ISO 14397-1)* Operating Weight 13 123 kg (28,931 lb.) 13 163 kg (29,018 lb.) 13 341 kg (29,412 lb.) 13 457 kg (29,667 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVS 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affected by changes in tires, ballast, and different attachments. *Rated operating capacity based on Deere attachments only. 524L Dimensions and Specifications with Hi-Vis Coupler and Hook-On Bucket While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER M N I G J H L M Cab N A G I B H J L Cab A B D C K E F K D C E F 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH HI-VIS COUPLER AND HOOK-ON BUCKET WITH BOLT-ON EDGE 524L TOOL-CARRIER LOADER WITH HI-VIS COUPLER AND HOOK-ON BUCKET WITH BOLT-ON EDGE Dimensions with Bucket with Bolt-On Edge A Height to Top of Cab B Hood Height C Ground Clearance D Length from Centerline to Front Axle E Wheelbase F Overall Length, Bucket on Ground G Height to Hinge Pin, Fully Raised H Dump Clearance, 45 deg., Full Height I Reach, 45-deg. Dump, Full Height J Reach, 45-deg. Dump, 2.13-m (7 ft. 0 in.) Clearance K Maximum Digging Depth L Maximum Rollback at Ground Level M Maximum Rollback, Boom Fully Raised N Maximum Bucket Dump Angle, Fully Raised Loader Clearance Circle, Bucket Carry Position Specifications with Bucket with Bolt-On Edge Capacity, Heaped Capacity, Struck Bucket Weight with Bolt-On Cutting Edge Bucket Width Breakout Force Tipping Load, Straight, No Tire Deflection Tipping Load, Straight, with Tire Deflection Z-Bar 2.1-m3 (2.75 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.52 m (24 ft. 8 in.) 3.81 m (12 ft. 6 in.) 2.68 m (8 ft. 10 in.) 1.09 m (3 ft. 7 in.) 1.50 m (4 ft. 11 in.) 108 mm (4.2 in.) 44 deg. 60 deg. 50 deg. 11.44 m (37 ft. 7 in.) 2.1 m3 (2.75 cu. yd.) 1.7 m3 (2.26 cu. yd.) 1454 kg (3,205 lb.) 2.55 m (8 ft. 4 in.) 9604 kg (21,173 lb.) 9483 kg (20,906 lb.) 8967 kg (19,769 lb.) Z-Bar 3.1-m3 (4.0 cu. yd.) light material 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.65 m (25 ft. 1 in.) 3.81 m (12 ft. 6 in.) 2.60 m (8 ft. 6 in.) 1.19 m (3 ft. 11 in.) 1.55 m (5 ft. 1 in.) 111 mm (4.4 in.) 44 deg. 60 deg. 50 deg. 11.80 m (38 ft. 9 in.) 3.1 m3 (4.0 cu. yd.) 2.6 m3 (3.4 cu. yd.) 1683 kg (3,711 lb.) 2.89 m (9 ft. 6 in.) 8569 kg (18,891 lb.) 9168 kg (20,212 lb.) 8637 kg (19,041 lb.) High-Lift 2.1-m3 (2.75 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.95 m (26 ft. 1 in.) 4.17 m (13 ft. 8 in.) 3.04 m (10 ft. 0 in.) 1.19 m (3 ft. 11 in.) 1.87 m (6 ft. 2 in.) 199 mm (7.8 in.) 48 deg. 60 deg. 46 deg. 11.78 m (38 ft. 8 in.) 2.1 m3 (2.75 cu. yd.) 1.7 m3 (2.26 cu. yd.) 1454 kg (3,205 lb.) 2.55 m (8 ft. 4 in.) 9500 kg (20,945 lb.) 7969 kg (17,568 lb.) 7575 kg (16,700 lb.) High-Lift 3.1-m3 (4.0 cu. yd.) light material 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.08 m (26 ft. 6 in.) 4.17 m (13 ft. 8 in.) 2.96 m (9 ft. 9 in.) 1.29 m (4 ft. 3 in.) 1.92 m (6 ft. 4 in.) 202 mm (8.0 in.) 48 deg. 60 deg. 46 deg. 12.22 m (40 ft. 1 in.) 3.1 m3 (4.0 cu. yd.) 2.6 m3 (3.4 cu. yd.) 1683 kg (3,711 lb.) 2.89 m (9 ft. 6 in.) 8475 kg (18,684 lb.) 7672 kg (16,913 lb.) 7260 kg (16,006 lb.) High-Lift Plus 1.9-m3 (2.5 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.15 m (26 ft. 9 in.) 4.42 m (14 ft. 6 in.) 3.35 m (11 ft. 0 in.) 1.17 m (3 ft. 10 in.) 2.06 m (6 ft. 9 in.) 196 mm (7.7 in.) 49 deg. 61 deg. 45 deg. 12.02 m (39 ft. 6 in.) 1.9 m3 (2.5 cu. yd.) 1.5 m3 (1.96 cu. yd.) 1385 kg (3,052 lb.) 2.55 m (8 ft. 4 in.) 10 383 kg (22,891 lb.) 7436 kg (16,394 lb.) 7092 kg (15,635 lb.) High-Lift Plus 3.1-m3 (4.0 cu. yd.) light material 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.37 m (27 ft. 6 in.) 4.42 m (14 ft. 6 in.) 3.21 m (10 ft. 6 in.) 1.33 m (4 ft. 4 in.) 2.16 m (7 ft. 1 in.) 207 mm (8.1 in.) 49 deg. 61 deg. 45 deg. 12.54 m (41 ft. 2 in.) 3.1 m3 (4.0 cu. yd.) 2.6 m3 (3.4 cu. yd.) 1683 kg (3,711 lb.) 2.89 m (9 ft. 6 in.) 8559 kg (18,870 lb.) 7032 kg (15,504 lb.) 6672 kg (14,709 lb.) Tool Carrier 2.1-m3 (2.75 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.77 m (25 ft. 6 in.) 3.89 m (12 ft. 9 in.) 2.79 m (9 ft. 2 in.) 1.34 m (4 ft. 5 in.) 1.81 m (5 ft. 11 in.) 100 mm (3.9 in.) 50 deg. 55 deg. 46 deg. 11.24 m (36 ft. 11 in.) 2.1 m3 (2.75 cu. yd.) 1.7 m3 (2.26 cu. yd.) 1437 kg (3,167 lb.) 2.55 m (8 ft. 4 in.) 10 660 kg (23,501 lb.) 8691 kg (19,160 lb.) 8259 kg (18,208 lb.) Tool Carrier 3.1-m3 (4.0 cu. yd.) light material 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.80 m (25 ft. 7 in.) 3.89 m (12 ft. 9 in.) 2.70 m (8 ft. 10 in.) 1.44 m (4 ft. 9 in.) 1.86 m (6 ft. 1 in.) 102 mm (4.0 in.) 50 deg. 55 deg. 46 deg. 12.04 m (39 ft. 6 in.) 3.1 m3 (4.0 cu. yd.) 2.6 m3 (3.4 cu. yd.) 1656 kg (3,651 lb.) 2.89 m (9 ft. 6 in.) 9109 kg (20,081 lb.) 8385 kg (18,486 lb.) 7938 kg (17,500 lb.) 16 While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 524L Dimensions and Specifications with Hi-Vis Coupler and Hook-On Bucket (continued) 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Z-Bar Z-Bar High-Lift High-Lift High-Lift Plus High-Lift Plus Tool Carrier Tool Carrier 2.1-m3 2.1-m3 1.9-m3 2.1-m3 (2.75 cu. yd.) 3.1-m3 (2.75 cu. yd.) 3.1-m3 (2.5 cu. yd.) 3.1-m3 (2.75 cu. yd.) 3.1-m3 Specifications with Bucket with Bolt-On Edge (continued) general purpose (4.0 cu. yd.) general light material purpose (4.0 cu. yd.) general light material purpose (4.0 cu. yd.) general light material purpose (4.0 cu. yd.) light material Tipping Load, 40-deg. Full Turn, No Tire 8199 kg 7888 kg 6841 kg 6548 kg 6360 kg 5965 kg 7503 kg 7203 kg Deflection (18,075 lb.) (17,391 lb.) (15,082 lb.) (14,436 lb.) (14,021 lb.) (13,150 lb.) (16,541 lb.) (15,880 lb.) Tipping Load, 40-deg. Full Turn, with Tire 7539 kg 7206 kg 6327 kg 6033 kg 5919 kg 5493 kg 6936 kg 6633 kg Deflection (16,621 lb.) (15,886 lb.) (13,949 lb.) (13,300 lb.) (13,049 lb.) (12,110 lb.) (15,291 lb.) (14,623 lb.) Rated Operating Load, 50% Full-Turn 4099 kg 3944 kg 3421 kg 3274 kg 3180 kg 2982 kg 3752 kg 3602 kg Tipping Load, No Tire Deflection (conforms (9,037 lb.) (8,695 lb.) (7,541 lb.) (7,218 lb.) (7,011 lb.) (6,575 lb.) (8,271 lb.) (7,940 lb.) to ISO 14397-1)* Rated Operating Load, 50% Full-Turn Tipping 3770 kg 3603 kg 3164 kg 3017 kg 2960 kg 2747 kg 3468 kg 3317 kg Load, with Tire Deflection (conforms to (8,310 lb.) (7,943 lb.) (6,974 lb.) (6,650 lb.) (6,525 lb.) (6,055 lb.) (7,646 lb.) (7,312 lb.) ISO 14397-1)* Operating Weight 13 541 kg 13 770 kg 13 760 kg 13 989 kg 13 806 kg 14 105 kg 13 390 kg 13 610 kg (29,853 lb.) (30,359 lb.) (30,335 lb.) (30,841 lb.) (30,438 lb.) (31,097 lb.) (29,520 lb.) (30,004 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVS 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/ counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affected by changes in tires, ballast, and different attachments. *Rated operating capacity based on Deere attachments only. Dimensions and Specifications with Hi-Vis Coupler and Hook-On Construction Forks H H G I K O J L Cab O J A G I B L K Cab A B M N D C E F 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH HI-VIS COUPLER AND HOOK-ON CONSTRUCTION FORKS M N D C E F 524L TOOL-CARRIER LOADER WITH HI-VIS COUPLER AND HOOK-ON CONSTRUCTION FORKS Dimensions with Forks A Height to Top of Cab B Hood Height C Ground Clearance D Length from Centerline to Front Axle E Wheelbase F Overall Length, Forks on Ground G Height to Hinge Pin, Fully Raised H Reach, Fully Raised I Fork Height, Fully Raised J Maximum Reach, Fork Level K Fork Height, Maximum Reach L Reach, Ground Level M Depth Below Ground N Tine Length O Load Position, 50% Tine Length Z-Bar 1.22-m (48 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.94 m (26 ft. 1 in.) 3.81 m (12 ft. 6 in.) 0.82 m (32 in.) 3.48 m (11 ft. 5 in.) 1.56 m (5 ft. 1 in.) 1.65 m (5 ft. 5 in.) 0.99 m (3 ft. 3 in.) 99 mm (4 in.) 1.22 m (48 in.) 0.61 m (24 in.) Z-Bar 1.52-m (60 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.24 m (27 ft. 1 in.) 3.81 m (12 ft. 6 in.) 0.82 m (32 in.) 3.48 m (11 ft. 5 in.) 1.56 m (5 ft. 1 in.) 1.65 m (5 ft. 5 in.) 0.99 m (3 ft. 3 in.) 99 mm (4 in.) 1.52 m (60 in.) 0.76 m (30 in.) High-Lift 1.22-m (48 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.37 m (27 ft. 6 in.) 4.17 m (13 ft. 8 in.) 0.92 m (3 ft. 0 in.) 3.84 m (12 ft. 7 in.) 1.89 m (6 ft. 2 in.) 1.66 m (5 ft. 5 in.) 1.40 m (4 ft. 7 in.) 189 mm (7 in.) 1.22 m (48 in.) 0.61 m (24 in.) High-Lift 1.52-m (60 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.68 m (28 ft. 6 in.) 4.17 m (13 ft. 8 in.) 0.92 m (3 ft. 0 in.) 3.84 m (12 ft. 7 in.) 1.89 m (6 ft. 2 in.) 1.66 m (5 ft. 5 in.) 1.40 m (4 ft. 7 in.) 189 mm (7 in.) 1.52 m (60 in.) 0.76 m (30 in.) High-Lift Plus 1.22-m (48 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.67 m (28 ft. 5 in.) 4.42 m (14 ft. 6 in.) 0.96 m (3 ft. 2 in.) 4.09 m (13 ft. 5 in.) 2.10 m (6 ft. 11 in.) 1.66 m (5 ft. 5 in.) 1.65 m (5 ft. 5 in.) 195 mm (8 in.) 1.22 m (48 in.) 0.61 m (24 in.) High-Lift Plus 1.52-m (60 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.97 m (29 ft. 5 in.) 4.42 m (14 ft. 6 in.) 0.96 m (3 ft. 2 in.) 4.09 m (13 ft. 5 in.) 2.10 m (6 ft. 11 in.) 1.66 m (5 ft. 5 in.) 1.65 m (5 ft. 5 in.) 195 mm (8 in.) 1.52 m (60 in.) 0.76 m (30 in.) Tool Carrier 1.22-m (48 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.13 m (26 ft. 8 in.) 3.89 m (12 ft. 9 in.) 1.08 m (3 ft. 7 in.) 3.66 m (12 ft. 0 in.) 1.81 m (5 ft. 11 in.) 1.83 m (6 ft. 0 in.) 1.17 m (3 ft. 10 in.) 154 mm (6 in.) 1.22 m (48 in.) 0.61 m (24 in.) Tool Carrier 1.52-m (60 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.44 m (27 ft. 8 in.) 3.89 m (12 ft. 9 in.) 1.08 m (3 ft. 7 in.) 3.66 m (12 ft. 0 in.) 1.81 m (5 ft. 11 in.) 1.83 m (6 ft. 0 in.) 1.17 m (3 ft. 10 in.) 154 mm (6 in.) 1.52 m (60 in.) 0.76 m (30 in.) 524L While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Dimensions and Specifications with Hi-Vis Coupler and Hook-On Construction Forks (continued) 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Z-Bar Z-Bar High-Lift High-Lift High-Lift Plus High-Lift Plus Tool Carrier Tool Carrier 1.22-m (48 in.) 1.52-m (60 in.) 1.22-m (48 in.) 1.52-m (60 in.) 1.22-m (48 in.) 1.52-m (60 in.) 1.22-m (48 in.) 1.52-m (60 in.) Specifications with Forks tine length tine length tine length tine length tine length tine length tine length tine length Tipping Load, Straight, No Tire Deflection 6990 kg 6574 kg 6101 kg 5760 kg 5701 kg 5393 kg 6504 kg 6135 kg (15,411 lb.) (14,494 lb.) (13,451 lb.) (12,698 lb.) (12,569 lb.) (11,889 lb.) (14,339 lb.) (13,525 lb.) Tipping Load, Straight, with Tire Deflection 6801 kg 6393 kg 5943 kg 5616 kg 5538 kg 5250 kg 6333 kg 5976 kg (14,994 lb.) (14,094 lb.) (13,102 lb.) (12,381 lb.) (12,209 lb.) (11,574 lb.) (13,962 lb.) (13,175 lb.) Tipping Load, 40-deg. Full Turn, No Tire 6050 kg 5681 kg 5246 kg 4943 kg 4877 kg 4604 kg 5619 kg 5289 kg Deflection (13,338 lb.) (12,524 lb.) (11,566 lb.) (10,898 lb.) (10,752 lb.) (10,149 lb.) (12,388 lb.) (11,660 lb.) Tipping Load, 40-deg. Full Turn, with Tire 5796 kg 5442 kg 5013 kg 4728 kg 4674 kg 4401 kg 5385 kg 5085 kg Deflection (12,778 lb.) (11,998 lb.) (11,052 lb.) (10,423 lb.) (10,304 lb.) (9,703 lb.) (11,872 lb.) (11,210 lb.) Rated Operating Load, 50% Full-Turn 2898 kg 2721 kg 2507 kg 2364 kg 2337 kg 2201 kg 2693 kg 2543 kg Tipping Load, with Tire Deflection (6,389 lb.) (5,999 lb.) (5,526 lb.) (5,212 lb.) (5,152 lb.) (4,851 lb.) (5,936 lb.) (5,605 lb.) (conforms to ISO 14397-1 and SAE J1197)* Rated Operating Load, Rough Terrain, 3478 kg 3265 kg 3008 kg 2837 kg 2804 kg 2641 kg 3231 kg 3051 kg 60% Full-Turn Tipping Load, with Tire (7,667 lb.) (7,199 lb.) (6,631 lb.) (6,254 lb.) (6,183 lb.) (5,822 lb.) (7,123 lb.) (6,726 lb.) Deflection (conforms to EN474-3)* Rated Operating Load, Firm and Level 4637 kg 4354 kg 4010 kg 3782 kg 3739 kg 3521 kg 4308 kg 4068 kg Ground, 80% Full-Turn Tipping Load, with (10,222 lb.) (9,598 lb.) (8,841 lb.) (8,339 lb.) (8,244 lb.) (7,762 lb.) (9,498 lb.) (8,968 lb.) Tire Deflection (conforms to EN474-3)* Operating Weight 13 366 kg 13 427 kg 13 585 kg 13 646 kg 13 701 kg 13 762 kg 13 206 kg 13 266 kg (29,468 lb.) (29,601 lb.) (29,950 lb.) (30,084 lb.) (30,206 lb.) (30,339 lb.) (29,114 lb.) (29,246 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVS 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/ counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affected by changes in tires, ballast, and different attachments. *Rated operating capacity based on Deere attachments only. Adjustments to Operating Weights and Tipping Loads with Buckets Adjustments to operating weights, tipping loads, and tires are based on Z-Bar machine with pin-on 2.1-m3 (2.75 cu. yd.) general-purpose bucket with bolt-on cutting edge, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator* Add (+) or deduct () kg (lb.) as indicated Tipping Load, Tipping Load, for loaders with 3-piece rims Operating Weight Straight 40-deg. Full Turn Tread Width Width Over Tires Vertical Height Michelin 20.5 R 25, 1 Star L-3 XHA2 0 kg (0 lb.) 0 kg (0 lb.) 0 kg (0 lb.) 0 mm (0 in.) 0 mm (0 in.) 0 mm (0 in.) Bridgestone 20.5 R 25, 1 Star L-3 VJT +4 kg (+9 lb.) +3 kg (+6 lb.) +3 kg (+6 lb.) 0 mm (0 in.) +2 mm (+0.1 in.) 41 mm (1.6 in.) Titan 20.5 R 25, 1 Star L-3 STL3 +11 kg (+23 lb.) +8 kg (+17 lb.) +7 kg (+15 lb.) 0 mm (0 in.) 7 mm (0.3 in.) 5 mm (0.2 in.) Michelin 20.5 R 25, 1 Star L-2 XTLA 152 kg (335 lb.) 109 kg (241 lb.) 96 kg (212 lb.) 0 mm (0 in.) +4 mm (+0.2 in.) 11 mm (0.4 in.) Bridgestone 20.5 R 25, 1 Star L-2 VUT 65 kg (144 lb.) 47 kg (104 lb.) 41 kg (91 lb.) 0 mm (0 in.) +3 mm (+0.1 in.) 10 mm (0.4 in.) Titan 20.5 R 25, 1 Star L-2 TGD2 85 kg (188 lb.) 61 kg (135 lb.) 54 kg (119 lb.) 0 mm (0 in.) 7 mm (0.3 in.) 10 mm (0.4 in.) Titan 20.5-25, 16 PR L-2 245 kg (541 lb.) 176 kg (389 lb.) 155 kg (343 lb.) 0 mm (0 in.) +8 mm (+0.3 in.) 2 mm (0.1 in.) Firestone 20.5-25, 16 PR L-2 SGG LD 280 kg (617 lb.) 201 kg (443 lb.) 177 kg (391 lb.) 0 mm (0 in.) +5 mm (+0.2 in.) 1 mm (0 in.) Titan 20.5-25, 12 PR L-2 266 kg (587 lb.) 191 kg (422 lb.) 169 kg (372 lb.) 0 mm (0 in.) +8 mm (+0.3 in.) 2 mm (0.1 in.) Firestone 20.5-25, 16 PR L-3 SRG LD 276 kg (608 lb.) 198 kg (437 lb.) 175 kg (385 lb.) 0 mm (0 in.) +8 mm (+0.3 in.) +3 mm (+0.1 in.) Michelin 20.5 R 25, 1 Star L2 SNO-PLUS 96 kg (212 lb.) 69 kg (152 lb.) 61 kg (134 lb.) 0 mm (0 in.) +6 mm (+0.2 in.) 16 mm (0.6 in.) Michelin 620/75R26 MegaXbib£ß 189 kg (417 lb.) 136 kg (300 lb.) 120 kg (264 lb.) +187 mm (+7.4 in.) +247 mm (+9.7 in.) +23 mm (+0.9 in.) CaCl2 in 20.5-25, L-3 Rear Tires, 75% Fill +825 kg +1185 kg +1045 kg N/A N/A N/A (+1,820 lb.) (+2,613 lb.) (+2,304 lb.) *May change based on vehicle configuration, weight, or tire-pressure adjustments. £Equipped with 1-piece rims. ßRequires 8-deg. rear axle stops. 18 While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 524L Bucket Selection Guides 524L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Material Density (kg/m3) 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300 2.54 m3 (3.32 cu. yd.) 2.01 m3 (2.83 cu. yd.) 2.1 m3 (2.75 cu. yd.) Pin-On 2.3 m3 (3.0 cu. yd.) 2.83 m3 (3.71 cu. yd.) 2.24 m3 (2.94 cu. yd.) Z-Bar Linkage 2.1 m3(2.75 cu. yd.) Hi-Vis 2.55 m3 (3.33 cu. yd.) 2.01 m3 (2.64 cu. yd.) Quick-Coupler 3.1 m3(4.0 cu. yd.) Light Material Hi-Vis 3.66 m3 (4.79 cu. yd.) 2.90 m3 (3.79 cu. yd.) 2.1 m3 (2.75 cu. yd.) Pin-On 2.54 m3 (3.32 cu. yd.) 2.01 m3 (2.63 cu. yd.) 2.1 m3(2.75 cu. yd.) Hi-Vis Quick-Coupler High-Lift Linkage 2.55 m3 (3.33 cu. yd.) 2.01 m3 (2.64 cu. yd.) 3.1 m3(4.0 cu. yd.) Light Material Hi-Vis 3.66 m3 (4.79 cu. yd.) 2.90 m3 (3.79 cu. yd.) 2.1 m3 (2.75 cu. yd.) Pin-On 2.54 m3 (3.32 cu. yd.) 2.01 m3 (2.63 cu. yd.) 1.9 m3(2.5 cu. yd.) Hi-Vis Quick-Coupler High-Lift Plus Linkage 2.22 m3 (2.90 cu. yd.) 1.76 m3 (2.30 cu. yd.) 3.1 m3(4.0 cu. yd.) Light Material Hi-Vis 3.66 m3 (4.79 cu. yd.) 2.90 m3 (3.79 cu. yd.) 2.1 m3(2.75 cu. yd.) Hi-Vis Quick-Coupler Tool Carrier Linkage 2.55 m3 (3.33 cu. yd.) 2.01 m3 (2.64 cu. yd.) 3.1 m3(4.0 cu. yd.) Light Material Hi-Vis 3.66 m3 (4.79 cu. yd.) 2.90 m3 (3.79 cu. yd.) 1,011 LOOSE MATERIALS 1,180 1,348 1,517 1,686 1,854 kg/m3 lb./cu. yd. LOOSE MATERIALS 2,023 2,191 2,360 2,528 2,697 Material Density (lb./cu. yd.) kg/m3 lb./cu. yd. 2,865 3,034 3,203 3,371 Bucket Fill Factors 3,540 Chips, pulpwood 288 Cinders (coal, ashes, clinkers) 673 Clay and gravel, dry 1602 Clay, compact, solid 1746 Clay, dry in lump loose 1009 Clay, excavated in water 1282 Coal, anthracite, broken, loose 865 Coal, bituminous, moderately wet 801 Earth, common loam, dry 1218 Earth, mud, packed 1843 Granite, broken 1538 Gypsum 2275 486 1,134 2,700 2,943 1,701 2,160 1,458 1,350 2,052 3,105 2,592 3,834 Limestone, coarse, sized Limestone, mixed sizes Limestone, pulverized or crushed Sand, damp Sand, dry Sand, voids, full of water Sandstone, quarried Shale, broken crushed Slag, furnace granulated Stone or gravel, 37.5 to 87.5-mm (1.5 to 3.5 in.) size Stone or gravel, 18.75-mm (0.75 in.) size 1570 1682 1362 2083 1762 2083 1314 1362 1955 1442 1602 2,646 2,835 2,295 3,510 2,970 3,510 2,214 2,295 3,294 2,430 2,700 130% 120% 110% 105% 100% 95% 3,708 S PE C IF IC AT IONS While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Engine 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS Manufacturer and Model John Deere PowerTechTM PVS 6068 Gross Peak Torque (ISO 9249) 770 Nm (568 ft.-lb.) at 1,600 rpm Non-Road Emission Standard EPA Final Tier 4/EU Stage V Net Torque Rise 47% Cylinders 6 Fuel System (electronically controlled) High-pressure common rail Valves Per Cylinder 4 Lubrication Full-flow spin-on filter and integral cooler Displacement 6.8 L (414 cu. in.) Aspiration Turbocharged, charge air cooled Net Peak Power (ISO 9249) 123 kW (166 hp) at 1,700 rpm Air Cleaner Under-hood, dual-element dry type, Gross Peak Power (ISO 9249) 130 kW (174 hp) at 1,700 rpm restriction indicator in cab monitor Net Peak Torque (ISO 9249) 740 Nm (546 lb.-ft.) at 1,100 rpm for service Cooling Fan Drive Hydraulically driven, proportionally controlled, fan aft of coolers Electrical Electrical System 24 volt with 100-amp alternator (optional 130-amp alternator) Batteries (2 12 volt) 950 CCA (each) Transmission System Type Countershaft-type PowerShiftTM Torque Converter Single stage, single phase Shift Control Electronically modulated, adaptive, load and speed dependent Operator Interface Steering-column or joystick-mounted F-N-R and gear-select lever; kick-down button on hydraulic lever Shift Modes Manual/auto (1stD or 2ndD); Quick-Shift button with 2 selectable modes: kick-down or kick-up/down; and 4 clutch cutoff settings Standard 5-Speed with Lockup Torque Converter Optional 5-Speed without Lockup Torque Converter Maximum Travel Speeds (with 20.5 R 25 tires) Forward Reverse Forward Reverse Range 1 6.1 km/h (3.7 mph) 5.9 km/h (3.6 mph) 5.6 km/h (3.5 mph) 6.0 km/h (3.7 mph) Range 2 12.0 km/h (7.4 mph) 12.7 km/h (7.8 mph) 11.2 km/h (7.0 mph) 11.9 km/h (7.3 mph) Range 3 18.6 km/h (11.5 mph) 29.4 km/h (18.3 mph) 17.4 km/h (10.8 mph) 27.6 km/h (17.1 mph) Range 4 27.9 km/h (17.3 mph) N/A 26.2 km/h (16.2 mph) N/A Range 5 40.0 km/h (24.8 mph) N/A 40.0 km/h (24.8 mph) N/A Axles/Brakes Final Drives Heavy-duty inboard-mounted planetary Differentials Hydraulic locking front with conventional rear -- standard; dual locking front and rear -- optional Rear Axle Oscillation, Stop to Stop 24 deg. (12 deg. each direction) (with 20.5 R 25 tires) Brakes (conform to ISO 3450) Service Hydraulically actuated, spring-retracted, self-adjusting inboard sun-shaft mounted, oil cooled, single disc Parking Automatic spring applied, hydraulically released, driveline mounted, sealed wet multi disc Tires/Wheels (see page 24 for complete tire adjustments) Tread Width Width Over Tires Michelin 20.5 R 25, 1 Star L-3 XHA2 1950 mm (76.8 in.) 2546 mm (100.2 in.) Serviceability Refill Capacities Fuel Tank (with lockable cap) 298 L (79 gal.) Axle Oil (each) Cooling System 29.9 L (31.6 qt.) Front 16.6 L (17.5 qt.) Diesel Exhaust Fluid (DEF) 15.6 L (16.5 qt.) Rear 18 L (19 qt.) Engine Oil with Vertical Spin-On Filter 19.5 L (20.6 qt.) Hydraulic Reservoir and Filter 82.1 L (21.7 gal.) Transmission Reservoir with Vertical 21 L (22.2 qt.) Park Brake Oil (wet disc) 0.3 L (10 oz.) Filter Hydraulic System/Steering Pump (loader and steering) Variable-displacement, axial-piston pump; closed-center, pressure-compensating system Maximum Rated Flow at 6895 kPa 220 L/m (58 gpm) (1,000 psi) and 2,200 rpm System Relief Pressure (loader and 25 166 kPa (3,650 psi) steering) Loader Controls 2-function valve, joystick control or fingertip controls, hydraulic-function enable/disable, optional 3rd- and 4th-function valve with auxiliary lever Steering (conforms to ISO 5010) Steering-column-mounted, twist-grip shift lever; Quick-Shift button on hydraulic lever Type Power, fully hydraulic Articulation Angle 80-deg. arc (40 deg. each direction) Turning Radius (measured to centerline 5.0 m (16 ft. 5 in.) of outside tire) Hydraulic Cycle Times Z-Bar / High-Lift / High-Lift Plus Raise 5.5 sec. Dump 2.2 sec. Lower (power down) 3.5 sec. 20 Total 11.2 sec. S PE C IF IC AT IONS While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Dimensions and Specifications with Pin-On Bucket 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS M N I G J H Cab A B L D C K E F 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH PIN-ON BUCKET WITH BOLT-ON EDGE Z-Bar Z-Bar High-Lift High-Lift High-Lift Plus High-Lift Plus 2.3-m3 (3.0 cu. yd.) 2.5-m3 (3.25 cu. yd.) 2.1-m3 (2.75 cu. yd.) 2.3-m3 (3.0 cu. yd.) 2.1-m3 (2.75 cu. yd.) 2.3-m3 (3.0 cu. yd.) Dimensions with Bucket with Bolt-On Edge general purpose general purpose general purpose general purpose general purpose general purpose A Height to Top of Cab 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) 3.33 m (10 ft. 11 in.) B Hood Height 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) 2.375 m (7 ft. 9 in.) C Ground Clearance 0.40 m (15.7 in.) 0.40 m (15.7 in.) 0.40 m (15.7 in.) 0.40 m (15.7 in.) 0.40 m (15.7 in.) 0.40 m (15.7 in.) D Length from Centerline to Front Axle 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) 1.45 m (4 ft. 9 in.) E Wheelbase 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) 2.93 m (9 ft. 7 in.) F Overall Length, Bucket on Ground 7.49 m (24 ft. 7 in.) 7.49 m (24 ft. 7 in.) 7.80 m (25 ft. 7 in.) 7.88 m (25 ft. 10 in.) 8.17 m (26 ft. 10 in.) 8.25 m (27 ft. 1 in.) G Height to Hinge Pin, Fully Raised 3.89 m (12 ft. 9 in.) 3.89 m (12 ft. 9 in.) 4.17 m (13 ft. 8 in.) 4.17 m (13 ft. 8 in.) 4.49 m (14 ft. 9 in.) 4.49 m (14 ft. 9 in.) H Dump Clearance, 45 deg., Full Height 2.80 m (9 ft. 2 in.) 2.80 m (9 ft. 2 in.) 3.14 m (10 ft. 4 in.) 3.09 m (10 ft. 2 in.) 3.47 m (11 ft. 4 in.) 3.41 m (11 ft. 2 in.) I Reach, 45-deg. Dump, Full Height 1.01 m (3 ft. 4 in.) 1.01 m (3 ft. 4 in.) 1.09 m (3 ft. 7 in.) 1.14 m (3 ft. 9 in.) 1.13 m (3 ft. 8 in.) 1.19 m (3 ft. 11 in.) J Reach, 45-deg. Dump, 2.13-m (7 ft. 1.51 m (4 ft. 11 in.) 1.51 m (4 ft. 11 in.) 1.81 m (5 ft. 11 in.) 1.84 m (6 ft. 0 in.) 2.10 m (6 ft. 11 in.) 2.14 m (7 ft. 0 in.) 0 in.) Clearance K Maximum Digging Depth 0.1 m (4 in.) 0.1 m (4 in.) 0.19 m (8 in.) 0.2 m (8 in.) 0.2 m (8 in.) 0.2 m (8 in.) L Maximum Rollback at Ground Level 44 deg. 44 deg. 48 deg. 48 deg. 49 deg. 49 deg. M Maximum Rollback, Boom Fully Raised 60 deg. 60 deg. 60 deg. 60 deg. 61 deg. 61 deg. N Maximum Bucket Dump Angle, Fully Raised 48 deg. 48 deg. 46 deg. 46 deg. 45 deg. 45 deg. Loader Clearance Circle, Bucket Carry Position 11.46 m (37 ft. 7 in.) 11.58 m (38 ft. 0 in.) 11.68 m (38 ft. 4 in.) 11.7 m (38 ft. 5 in.) 12.16 m (39 ft. 11 in.) 12.20 m (40 ft. 0 in.) Specifications with Bucket with Bolt-On Edge Capacity, Heaped 2.3 m3 (3.0 cu. yd.) 2.5 m3 (3.25 cu. yd.) 2.1 m3 (2.75 cu. yd.) 2.3 m3 (3.0 cu. yd.) 2.1 m3 (2.75 cu. yd.) 2.3 m3 (3.0 cu. yd.) Capacity, Struck 1.9 m3 (2.5 cu. yd.) 2.1 m3 (2.7 cu. yd.) 1.7 m3 (2.3 cu. yd.) 1.9 m3 (2.5 cu. yd.) 1.7 m3 (2.3 cu. yd.) 1.9 m3 (2.5 cu. yd.) Bucket Weight with Bolt-On Cutting Edge 1095 kg (2,415 lb.) 1131 kg (2,493 lb.) 1056 kg (2,327 lb.) 1095 kg (2,415 lb.) 1056 kg (2,327 lb.) 1095 kg (2,415 lb.) Bucket Width 2.54 m (8 ft. 4 in.) 2.68 m (8 ft. 10 in.) 2.55 m (8 ft. 4 in.) 2.54 m (8 ft. 4 in.) 2.55 m (8 ft. 4 in.) 2.54 m (8 ft. 4 in.) Breakout Force 13 166 kg (29,026 lb.) 13 145 kg (28,979 lb.) 13 983 kg (30,827 lb.) 13 005 kg (28,672 lb.) 14 138 kg (31,168 lb.) 13 149 kg (28,988 lb.) Tipping Load, Straight, No Tire Deflection 11 139 kg (24,557 lb.) 11 097 kg (24,464 lb.) 9699 kg (21,384 lb.) 9591 kg (21,145 lb.) 8630 kg (19,026 lb.) 8537 kg (18,820 lb.) Tipping Load, Straight, with Tire Deflection 10 533 kg (23,221 lb.) 10 491 kg (23,129 lb.) 9231 kg (20,351 lb.) 9120 kg (20,106 lb.) 8244 kg (18,175 lb.) 8145 kg (17,957 lb.) Tipping Load, 40-deg. Full Turn, No Tire 9653 kg (21,281 lb.) 9612 kg (21,190 lb.) 8374 kg (18,460 lb.) 8274 kg (18,241 lb.) 7410 kg (16,336 lb.) 7323 kg (16,145 lb.) Deflection Tipping Load, 40-deg. Full Turn, with Tire 8865 kg (19,544 lb.) 8823 kg (19,451 lb.) 7755 kg (17,097 lb.) 7650 kg (16,865 lb.) 6891 kg (15,192 lb.) 6807 kg (15,007 lb.) Deflection Rated Operating Load, 50% Full-Turn Tipping 4827 kg (10,641 lb.) 4806 kg (10,595 lb.) 4187 kg (9,230 lb.) 4137 kg (9,120 lb.) 3705 kg (8,168 lb.) 3662 kg (8,073 lb.) Load, No Tire Deflection (conforms to ISO 14397-1)* Rated Operating Load, 50% Full-Turn Tipping 4433 kg (9,772 lb.) 4412 kg (9,726 lb.) 3878 kg (8,548 lb.) 3825 kg (8,433 lb.) 3446 kg (7,596 lb.) 3404 kg (7,503 lb.) Load, with Tire Deflection (conforms to ISO 14397-1)* Operating Weight 13 844 kg (30,520 lb.) 13 879 kg (30,598 lb.) 13 992 kg (30,847 lb.) 14 032 kg (30,935 lb.) 14 178 kg (31,257 lb.) 14 218 kg (31,345 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVS 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/ counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affect by changes in tires, ballast, and different attachments. *Rated operating capacity based on Deere attachments only. 544L Dimensions and Specifications with Hi-Vis Coupler and Hook-On Bucket While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS M N I G J H L Cab A B D C K E F 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH HI-VIS COUPLER AND HOOK-ON BUCKET WITH BOLT-ON EDGE Dimensions with Bucket with Bolt-On Edge A Height to Top of Cab B Hood Height C Ground Clearance D Length from Centerline to Front Axle E Wheelbase F Overall Length, Bucket on Ground G Height to Hinge Pin, Fully Raised H Dump Clearance, 45 deg., Full Height I Reach, 45-deg. Dump, Full Height J Reach, 45-deg. Dump, 2.13-m (7 ft. 0 in.) Clearance K Maximum Digging Depth L Maximum Rollback at Ground Level M Maximum Rollback, Boom Fully Raised N Maximum Bucket Dump Angle, Fully Raised Loader Clearance Circle, Bucket Carry Position Specifications with Bucket with Bolt-On Edge Capacity, Heaped Capacity, Struck Bucket Weight with Bolt-On Cutting Edge Bucket Width Breakout Force Tipping Load, Straight, No Tire Deflection Tipping Load, Straight, with Tire Deflection Z-Bar 2.3-m3 (3.0 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.56 m (24 ft. 10 in.) 3.89 m (12 ft. 9 in.) 2.76 m (9 ft. 1 in.) 1.06 m (3 ft. 6 in.) 1.54 m (5 ft. 1 in.) 0.1 m (4 in.) 44 deg. 60 deg. 48 deg. 11.60 m (38 ft. 1 in.) 2.3 m3 (3.0 cu. yd.) 1.9 m3 (2.4 cu. yd.) 1489 kg (3,283 lb.) 2.68 m (8 ft. 10 in.) 12 307 kg (27,131 lb.) 10 362 kg (22,844 lb.) 9789 kg (21,581 lb.) Z-Bar 2.5-m3 (3.25 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.64 m (25 ft. 1 in.) 3.89 m (12 ft. 9 in.) 2.70 m (8 ft. 10 in.) 1.12 m (3 ft. 8 in.) 1.56 m (5 ft. 1 in.) 0.11 m (4 in.) 44 deg. 60 deg. 48 deg. 11.60 m (38 ft. 0 in.) 2.5 m3 (3.25 cu. yd.) 2.1 m3 (2.7 cu. yd.) 1537 kg (3,388 lb.) 2.68 m (8 ft. 10 in.) 11 539 kg (25,439 lb.) 10 250 kg (22,597 lb.) 9675 kg (21,330 lb.) Z-Bar 3.4-m3 (4.5 cu. yd.) light material 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.83 m (25 ft. 8 in.) 3.89 m (12 ft. 9 in.) 2.58 m (8 ft. 6 in.) 1.25 m (4 ft. 1 in.) 1.62 m (5 ft. 4 in.) 0.11 m (5 in.) 44 deg. 60 deg. 48 deg. 11.88 m (39 ft. 0 in.) 3.4 m3 (4.5 cu. yd.) 2.9 m3 (3.8 cu. yd.) 1747 kg (3,850 lb.) 2.89 m (9 ft. 6 in.) 10 013 kg (22,074 lb.) 9912 kg (21,853 lb.) 9321 kg (20,549 lb.) High-Lift 2.1-m3 (2.75 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.95 m (26 ft. 1 in.) 4.17 m (13 ft. 8 in.) 3.04 m (10 ft. 0 in.) 1.19 m (3 ft. 11 in.) 1.87 m (6 ft. 2 in.) 0.2 m (8 in.) 48 deg. 60 deg. 46 deg. 11.78 m (38 ft. 8 in.) 2.1 m3 (2.75 cu. yd.) 1.9 m3 (2.4 cu. yd.) 1454 kg (3,205 lb.) 2.55 m (8 ft. 4 in.) 12 179 kg (26,849 lb.) 8963 kg (19,759 lb.) 8508 kg (18,757 lb.) High-Lift 2.3-m3 (3.0 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 7.95 m (26 ft. 1 in.) 4.17 m (13 ft. 8 in.) 3.04 m (10 ft. 0 in.) 1.19 m (3 ft. 11 in.) 1.87 m (6 ft. 2 in.) 0.2 m (8 in.) 48 deg. 60 deg. 46 deg. 11.86 m (38 ft. 11 in.) 2.3 m3 (3.0 cu. yd.) 1.9 m3 (2.4 cu. yd.) 1489 kg (3,283 lb.) 2.68 m (8 ft. 10 in.) 12 155 kg (26,797 lb.) 8910 kg (19,642 lb.) 8460 kg (18,651 lb.) High-Lift 3.1-m3 (4.0 cu. yd.) light material 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.08 m (26 ft. 6 in.) 4.17 m (13 ft. 8 in.) 2.96 m (9 ft. 9 in.) 1.29 m (4 ft. 3 in.) 1.92 m (6 ft. 4 in.) 0.2 m (8 in.) 48 deg. 60 deg. 46 deg. 12.22 m (40 ft. 1 in.) 3.1 m3 (4.0 cu. yd.) 2.5 m3 (3.3 cu. yd.) 1683 kg (3,711 lb.) 2.89 m (9 ft. 6 in.) 10 907 kg (24,045 lb.) 8663 kg (19,099 lb.) 8199 kg (18,076 lb.) High-Lift Plus 1.9-m3 (2.5 cu. yd.) general purpose 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.23 m (27 ft. 0 in.) 4.49 m (14 ft. 9 in.) 3.43 m (11 ft. 3 in.) 1.17 m (3 ft. 10 in.) 2.13 m (7 ft. 0 in.) 0.2 m (8 in.) 49 deg. 61 deg. 45 deg. 12.12 m (39 ft. 9 in.) 1.9 m3 (2.5 cu. yd.) 1.6 m3 (2.1 cu. yd.) 1385 kg (3,052 lb.) 2.55 m (8 ft. 4 in.) 13 305 kg (29,333 lb.) 8085 kg (17,825 lb.) 7713 kg (17,004 lb.) High-Lift Plus 3.1-m3 (4.0 cu. yd.) light material 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.45 m (27 ft. 9 in.) 4.49 m (14 ft. 9 in.) 3.28 m (10 ft. 9 in.) 1.33 m (4 ft. 5 in.) 2.23 m (7 ft. 4 in.) 0.21 m (8 in.) 49 deg. 61 deg. 45 deg. 12.62 m (41 ft. 5 in.) 3.1 m3 (4.0 cu. yd.) 2.5 m3 (3.3 cu. yd.) 1683 kg (3,711 lb.) 2.89 m (9 ft. 6 in.) 11 028 kg (24,313 lb.) 7679 kg (16,614 lb.) 7290 kg (15,774 lb.) 22 While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 544L Dimensions and Specifications with Hi-Vis Coupler and Hook-On Bucket (continued) 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS Z-Bar Z-Bar Z-Bar High-Lift High-Lift High-Lift High-Lift Plus High-Lift Plus 2.3-m3 2.5-m3 2.1-m3 2.3-m3 1.9-m3 (3.0 cu. yd.) (3.25 cu. yd.) 3.4-m3 (2.75 cu. yd.) (3.0 cu. yd.) 3.1-m3 (2.5 cu. yd.) 3.1-m3 Specifications with Bucket with Bolt-On Edge (continued) general purpose general purpose (4.5 cu. yd.) general light material purpose general purpose (4.0 cu. yd.) general light material purpose (4.0 cu. yd.) light material Tipping Load, 40-deg. Full Turn, No Tire 8931 kg 8827 kg 8499 kg 7686 kg 7635 kg 7390 kg 6899 kg 6501 kg Deflection (19,690 lb.) (19,459 lb.) (18,736 lb.) (16,945 lb.) (16,833 lb.) (16,293 lb.) (15,209 lb.) (14,040 lb.) Tipping Load, 40-deg. Full Turn, with Tire 8181 kg 8073 kg 7731 kg 7083 kg 7035 kg 6771 kg 6393 kg 5988 kg Deflection (18,036 lb.) (17,798 lb.) (17,044 lb.) (15,615 lb.) (15,510 lb.) (14,927 lb.) (14,094 lb.) (12,884 lb.) Rated Operating Load, 50% Full-Turn 4466 kg 4413 kg 4249 kg 3843 kg 3818 kg 3695 kg 3449 kg 3251 kg Tipping Load, No Tire Deflection (conforms (9,845 lb.) (9,730 lb.) (9,368 lb.) (8,473 lb.) (8,417 lb.) (8,146 lb.) (7,604 lb.) (7,020 lb.) to ISO 14397-1)* Rated Operating Load, 50% Full-Turn Tipping 4091 kg 4037 kg 3866 kg 3542 kg 3518 kg 3386 kg 3197 kg 2994 kg Load, with Tire Deflection (conforms to (9,018 lb.) (8,899 lb.) (8,522 lb.) (7,808 lb.) (7,755 lb.) (7,464 lb.) (7,047 lb.) (6,442 lb.) ISO 14397-1)* Operating Weight 14 258 kg 14 305 kg 14 515 kg 14 411 kg 14 446 kg 14 641 kg 14 528 kg 14 827 kg (31,433 lb.) (31,538 lb.) (32,000 lb.) (31,771 lb.) (31,849 lb.) (32,277 lb.) (32,029 lb.) (32,827 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVS 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/ counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affected by changes in tires, ballast, and different attachments. *Rated operating capacity based on Deere attachments only. Dimensions and Specifications with Hi-Vis Coupler and Hook-On Construction Forks H O J G I L K Cab A B M N D C E F 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH HI-VIS COUPLER AND HOOK-ON CONSTRUCTION FORKS Dimensions with Forks A Height to Top of Cab B Hood Height C Ground Clearance D Length from Centerline to Front Axle E Wheelbase F Overall Length, Forks on Ground G Height to Hinge Pin, Fully Raised H Reach, Fully Raised I Fork Height, Fully Raised J Maximum Reach, Fork Level K Fork Height, Maximum Reach L Reach, Ground Level M Depth Below Ground N Tine Length O Load Position, 50% Tine Length Z-Bar 1.52-m (60 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.29 m (27 ft. 2 in.) 3.89 m (12 ft. 9 in.) 0.80 m (31 in.) 3.56 m (11 ft. 8 in.) 1.59 m (5 ft. 3 in.) 1.66 m (5 ft. 5 in.) 1.03 m (3 ft. 5 in.) 91 mm (4 in.) 1.52 m (60 in.) 0.76 m (30 in.) Z-Bar 1.83-m (72 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.59 m (28 ft. 2 in.) 3.89 m (12 ft. 9 in.) 0.80 m (31 in.) 3.56 m (11 ft. 8 in.) 1.59 m (5 ft. 3 in.) 1.66 m (5 ft. 5 in.) 1.03 m (3 ft. 5 in.) 91 mm (4 in.) 1.83 m (72 in.) 0.91 m (3 ft. 0 in.) High-Lift 1.52-m (60 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.68 m (28 ft. 6 in.) 4.17 m (13 ft. 8 in.) 0.92 m (3 ft. 0 in.) 3.84 m (12 ft. 7 in.) 1.89 m (6 ft. 2 in.) 1.66 m (5 ft. 5 in.) 1.40 m (4 ft. 7 in.) 190 mm (7 in.) 1.52 m (60 in.) 0.76 m (30 in.) High-Lift 1.83-m (72 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 8.98 m (29 ft. 6 in.) 4.17 m (13 ft. 8 in.) 0.92 m (3 ft. 0 in.) 3.84 m (12 ft. 7 in.) 1.89 m (6 ft. 2 in.) 1.66 m (5 ft. 5 in.) 1.40 m (4 ft. 7 in.) 190 mm (7 in.) 1.83 m (72 in.) 0.91 m (3 ft. 0 in.) High-Lift Plus 1.52-m (60 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 9.04 m (29 ft. 8 in.) 4.49 m (14 ft. 9 in.) 0.97 m (3 ft. 2 in.) 4.16 m (13 ft. 8 in.) 2.16 m (7 ft. 1 in.) 1.66 m (5 ft. 5 in.) 1.72 m (5 ft. 8 in.) 195 mm (8 in.) 1.52 m (60 in.) 0.76 m (30 in.) High-Lift Plus 1.83-m (72 in.) tine length 3.33 m (10 ft. 11 in.) 2.375 m (7 ft. 9 in.) 0.40 m (15.7 in.) 1.45 m (4 ft. 9 in.) 2.93 m (9 ft. 7 in.) 9.35 m (30 ft. 8 in.) 4.49 m (14 ft. 9 in.) 0.97 m (3 ft. 2 in.) 4.16 m (13 ft. 8 in.) 2.16 m (7 ft. 1 in.) 1.66 m (5 ft. 5 in.) 1.72 m (5 ft. 8 in.) 195 mm (8 in.) 1.83 m (72 in.) 0.91 m (3 ft. 0 in.) 544L While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Dimensions and Specifications with Hi-Vis Coupler and Hook-On Construction Forks (continued) 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS Z-Bar Z-Bar High-Lift High-Lift High-Lift Plus High-Lift Plus 1.52-m (60 in.) 1.83-m (72 in.) 1.52-m (60 in.) 1.83-m (72 in.) 1.52-m (60 in.) 1.83-m (72 in.) Specifications with Forks Tipping Load, Straight, No Tire tine length tine length tine length tine length tine length tine length 7263 kg (16,013 lb.) 6852 kg (15,107 lb.) 6480 kg (14,287 lb.) 6132 kg (13,520 lb.) 5909 kg (13,027 lb.) 5604 kg (12,355 lb.) Deflection Tipping Load, Straight, with Tire 7068 kg (15,582 lb.) 6669 kg (14,703 lb.) 6309 kg (13,909 lb.) 5973 kg (13,168 lb.) 5751 kg (12,679 lb.) 5451 kg (12,017 lb.) Deflection Tipping Load, 40-deg. Full Turn, 6261 kg (13,804 lb.) 5897 kg (13,001 lb.) 5556 kg (12,249 lb.) 5248 kg (11,569 lb.) 5033 kg (11,096 lb.) 4763 kg (10,501 lb.) No Tire Deflection Tipping Load, 40-deg. Full Turn, 5991 kg (13,208 lb.) 5649 kg (12,454 lb.) 5319 kg (11,726 lb.) 5031 kg (11,091 lb.) 4830 kg (10,648 lb.) 4566 kg (10,066 lb.) with Tire Deflection Rated Operating Load, 50% Full-Turn 2996 kg (6,604 lb.) 2825 kg (6,227 lb.) 2660 kg (5,863 lb.) 2516 kg (5,546 lb.) 2415 kg (5,324 lb.) 2283 kg (5,033 lb.) Tipping Load, with Tire Deflection (conforms to ISO 14397-1 and SAE J1197)* Rated Operating Load, Rough Terrain, 3595 kg (7,925 lb.) 3389 kg (7,472 lb.) 3191 kg (7,036 lb.) 3019 kg (6,655 lb.) 2898 kg (6,389 lb.) 2740 kg (6,040 lb.) 60% Full-Turn Tipping Load, with Tire Deflection (conforms to EN474-3)* Rated Operating Load, Firm and 4793 kg (10,566 lb.) 4519 kg (9,963 lb.) 4255 kg (9,381 lb.) 4025 kg (8,873 lb.) 3864 kg (8,519 lb.) 3653 kg (8,053 lb.) Level Ground, 80% Full-Turn Tipping Load, with Tire Deflection (conforms to EN474-3)* Operating Weight 14 108 kg (31,103 lb.) 14 168 kg (31,236 lb.) 14 297 kg (31,520 lb.) 14 357 kg (31,652 lb.) 14 483 kg (31,930 lb.) 14 544 kg (32,063 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVS 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affected by changes in tires, ballast, and different attachments. *Rated operating capacity based on Deere attachments only. Adjustments to Operating Weights and Tipping Loads with Buckets Adjustments to operating weights, tipping loads, and tires are based on Z-Bar machine with pin-on 2.3-m3 (3.0 cu. yd.) general-purpose bucket with bolt-on cutting edge, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator* Add (+) or deduct () kg (lb.) as indicated Tipping Load, Tipping Load, for loaders with 3-piece rims Michelin 20.5 R 25, 1 Star L-3 XHA2 Operating Weight Straight 0 kg (0 lb.) 0 kg (0 lb.) 40-deg. Full Turn Tread Width 0 kg (0 lb.) 0 mm (0 in.) Width Over Tires Vertical Height 0 mm (0 in.) 0 mm (0 in.) Bridgestone 20.5 R 25, 1 Star L-3 VJT +4 kg (+9 lb.) +3 kg (+6 lb.) +2 kg (+5 lb.) 0 mm (0 in.) +2 mm (+0.1 in.) 41 mm (1.6 in.) Titan 20.5 R 25, 1 Star L-3 STL3 +11 kg (+23 lb.) +7 kg (+16 lb.) +7 kg (+14 lb.) 0 mm (0 in.) 7 mm (0.3 in.) 5 mm (0.2 in.) Michelin 20.5 R 25, 1 Star L-2 XTLA 152 kg (335 lb.) 107 kg (235 lb.) 94 kg (207 lb.) 0 mm (0 in.) +4 mm (+0.2 in.) 11 mm (0.4 in.) Bridgestone 20.5 R 25, 1 Star L-2 VUT 65 kg (144 lb.) 46 kg (101 lb.) 40 kg (89 lb.) 0 mm (0 in.) +3 mm (0.1 in.) 10 mm (0.4 in.) Titan 20.5 R 25, 1 Star L-2 TGD2 85 kg (188 lb.) 60 kg (132 lb.) 53 kg (116 lb.) 0 mm (0 in.) 7 mm (0.3 in.) 10 mm (0.4 in.) Titan 20.5-25, 16 PR L-2 245 kg (541 lb.) 172 kg (379 lb.) 152 kg (335 lb.) 0 mm (0 in.) +8 mm (+0.3 in.) 2 mm (0.1 in.) Firestone 20.5-25, 16 PR L-2 SGG LD 280 kg (617 lb.) 196 kg (433 lb.) 173 kg (382 lb.) 0 mm (0 in.) +5 mm (+0.2 in.) 1 mm (0 in.) Titan 20.5-25, 12 PR L-2 266 kg (587 lb.) 187 kg (412 lb.) 165 kg (363 lb.) 0 mm (0 in.) +8 mm (+0.3 in.) 2 mm (0.1 in.) Firestone 20.5-25, 16 PR L-3 SRG LD 276 kg (608 lb.) 194 kg (427 lb.) 171 kg (376 lb.) 0 mm (0 in.) +8 mm (+0.3 in.) +3 mm (+0.1 in.) Michelin 20.5 R 25, 1 Star L2 SNO-PLUS 96 kg (212 lb.) Michelin 620/75R26 MegaXbib£ß 189 kg (417 lb.) Michelin 750/65R26 MegaXbib£ß +55 kg (+121 lb.) 67 kg (148 lb.) 133 kg (293 lb.) +38 kg (+85 lb.) 59 kg (131 lb.) 117 kg (258 lb.) +34 kg (+75 lb.) 0 mm (0 in.) +6 mm (+0.2 in.) 16 mm (0.6 in.) +187 mm (+7.4 in.) +247 mm (+9.7 in.) +23 mm (+0.9 in.) +322 mm (+12.7 in.) +521 mm (+20.5 in.) +36 mm (+1.4 in.) CaCl2 in 20.5-25, L-3 Rear Tires, 75% Fill +825 kg +1157 kg +1020 kg N/A N/A N/A (+1,820 lb.) (+2,551 lb.) (+2,250 lb.) *May change based on vehicle configuration, weight, or tire-pressure adjustments. £Equipped with 1-piece rims. ßRequires 8-deg. rear axle stops. 24 While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 544L Bucket Selection Guides 600 700 544L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS Material Density (kg/m3) 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300 2.84 m3 (3.71 cu. yd.) 2.25 m3 (2.94 cu. yd.) 2.3 m3 (3.0 cu. yd.) Pin-On 2.5 m3 (3.25 cu. yd.) 3.00 m3 (3.93 cu. yd.) 2.38 m3 (3.11 cu. yd.) 2.3 m3(3.0 cu. yd.) Hi-Vis Z-Bar Linkage 2.71 m3 (3.55 cu. yd.) 2.15 m3 (2.81 cu. yd.) 3.00 m3 (3.93 cu. yd.) 2.38 m3 (3.11 cu. yd.) 2.5 m3(3.25 cu. yd.) Hi-Vis Quick-Coupler 3.4 m3(4.5 cu. yd.) Light Material Hi-Vis 2.1 m3 (2.75 cu. yd.) Pin-On 2.3 m3 (3.0 cu. yd.) 4.24 m3 (5.54 cu. yd.) 3.36 m3 (4.39 cu. yd.) 2.54 m3 (3.32 cu. yd.) 2.84 m3 (3.71 cu. yd.) 2.55 m3 (3.33 cu. yd.) 2.71 m3 (3.55 cu. yd.) 2.01 m3 (2.63 cu. yd.) 2.25 m3 (2.94 cu. yd.) 2.01 m3 (2.63 cu. yd.) 2.15 m3 (2.81 cu. yd.) 2.1 m3(2.75 cu. yd.) Hi-Vis High-Lift Linkage 2.3 m3(3.0 cu. yd.) Hi-Vis Quick-Coupler 3.1 m32.1 m3 (4.0 cu. yd.) (2.75 cu. yd.) Light Material Hi-Vis 3.66 m3 (4.79 cu. yd.) 2.90 m3 (3.79 cu. yd.) 2.54 m3 (3.32 cu. yd.) 2.01 m3 (2.63 cu. yd.) Pin-On 2.3 m3 (3.0 cu. yd.) High-Lift Plus Linkage 2.84 m3 (3.71 cu. yd.) 2.25 m3 (2.94 cu. yd.) 1.9 m3(2.5 cu. yd.) Hi-Vis Quick-Coupler 2.22 m3 (2.90 cu. yd.) 1.76 m3 (2.30 cu. yd.) 3.1 m3(4.0 cu. yd.) Light Material Hi-Vis 3.66 m3 (4.79 cu. yd.) 2.90 m3 (3.79 cu. yd.) 1,011 LOOSE MATERIALS 1,180 1,348 1,517 1,686 1,854 kg/m3 lb./cu. yd. LOOSE MATERIALS 2,023 2,191 2,360 2,528 2,697 Material Density (lb./cu. yd.) kg/m3 lb./cu. yd. 2,865 3,034 3,203 3,371 Bucket Fill Factors 3,540 Chips, pulpwood 288 Cinders (coal, ashes, clinkers) 673 Clay and gravel, dry 1602 Clay, compact, solid 1746 Clay, dry in lump loose 1009 Clay, excavated in water 1282 Coal, anthracite, broken, loose 865 Coal, bituminous, moderately wet 801 Earth, common loam, dry 1218 Earth, mud, packed 1843 Granite, broken 1538 Gypsum 2275 486 1,134 2,700 2,943 1,701 2,160 1,458 1,350 2,052 3,105 2,592 3,834 Limestone, coarse, sized Limestone, mixed sizes Limestone, pulverized or crushed Sand, damp Sand, dry Sand, voids, full of water Sandstone, quarried Shale, broken crushed Slag, furnace granulated Stone or gravel, 37.5 to 87.5-mm (1.5 to 3.5 in.) size Stone or gravel, 18.75-mm (0.75 in.) size 1570 1682 1362 2083 1762 2083 1314 1362 1955 1442 1602 2,646 2,835 2,295 3,510 2,970 3,510 2,214 2,295 3,294 2,430 2,700 130% 120% 110% 105% 100% 95% 3,708 3,876 S PE C IF IC AT IONS While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Engine 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Manufacturer and Model John Deere PowerTechTM PVX 6068 Gross Peak Torque (ISO 9249) 923 Nm (681 ft.-lb.) at 1,500 rpm Non-Road Emission Standard Cylinders Valves Per Cylinder EPA Final Tier 4/EU Stage V 6 4 Net Torque Rise Fuel System (electronically controlled) Lubrication 58% standard High-pressure common rail Full-flow spin-on filter and integral cooler Displacement 6.8 L (414 cu. in.) Aspiration Turbocharged, charge air cooled Net Peak Power (ISO 9249) 143 kW (192 hp) at 1,600 rpm Air Cleaner Under-hood, dual-element dry type, Gross Peak Power (ISO 9249) 152 kW (203 hp) at 1,600 rpm restriction indicator in cab monitor Net Peak Torque (ISO 9249) 874 Nm (644 lb.-ft.) at 1,300 rpm for service Cooling Fan Drive Hydraulically driven, proportionally controlled, fan aft of coolers Electrical Electrical System 24 volt with 130-amp alternator Batteries (2 12 volt) 950 CCA (each) Transmission System Type Countershaft-type PowerShiftTM Torque Converter Single stage, single phase Shift Control Electronically modulated, adaptive, load and speed dependent Operator Interface Steering-column or joystick-mounted F-N-R and gear-select lever; kick-down button on hydraulic lever Shift Modes Manual/auto (1stD or 2ndD); Quick-Shift button with 2 selectable modes: kick-down or kick-up/down; and 4 clutch cutoff settings Standard 5-Speed with Lockup Torque Converter Optional 5-Speed without Lockup Torque Converter Maximum Travel Speeds (with 20.5 R 25 tires) Range 1 Range 2 Range 3 Range 4 Range 5 Forward 7.0 km/h (4.3 mph) 12.1 km/h (7.5 mph) 18.7 km/h (11.6 mph) 29.1 km/h (18.1 mph) 40.0 km/h (24.8 mph) Reverse 6.6 km/h (4.1 mph) 12.8 km/h (7.9 mph) 30.7 km/h (19.0 mph) N/A N/A Forward 6.3 km/h (3.9 mph) 11.4 km/h (7.0 mph) 17.5 km/h (10.8 mph) 27.2 km/h (16.9 mph) 40.0 km/h (24.8 mph) Reverse 6.7 km/h (4.1 mph) 12.0 km/h (7.4 mph) 28.7 km/h (17.8 mph) N/A N/A Axles/Brakes Final Drives Heavy-duty inboard-mounted planetary Differentials Hydraulic locking front with conventional rear -- standard; dual locking front and rear -- optional Rear Axle Oscillation, Stop to Stop 24 deg. (12 deg. each direction) (with 20.5 R 25 tires) Brakes (conform to ISO 3450) Service Hydraulically actuated, spring-retracted, self-adjusting inboard sun-shaft mounted, oil cooled, single disc Parking Automatic spring applied, hydraulically released, driveline mounted, oil-cooled, multi disc Tires/Wheels (see page 32 for complete tire adjustments) Tread Width Width Over Tires Michelin 20.5 R 25, 1 Star L-3 XHA2 2053 mm (80.8 in.) 2657 mm (104.6 in.) Serviceability Refill Capacities Fuel Tank (with lockable cap) 299 L (79 gal.) Axle Oil (each) Cooling System 36.5 L (38.6 qt.) Diesel Exhaust Fluid (DEF) 15.6 L (16.5 qt.) Engine Oil with Vertical Spin-On Filter 19.5 L (20.6 qt.) Transmission Reservoir with Vertical 27 L (28.5 qt.) Front Rear Hydraulic Reservoir and Filter Park Brake Oil (wet disc) 22 L (23 qt.) 17 L (18 qt.) 102.8 L (27.2 gal.) 0.3 L (10 oz.) Filter Hydraulic System/Steering Pump (loader and steering) Variable-displacement, axial-piston pump; closed-center, pressure-compensating system Maximum Rated Flow at 6895 kPa 261 L/m (69 gpm) (1,000 psi) and 2,200 rpm System Relief Pressure (loader and 24 821 kPa (3,675 psi) steering) Loader Controls 2-function valve, joystick control or fingertip controls, hydraulic-function enable/disable, optional 3rd- and 4th-function valve with auxiliary lever Steering (conforms to ISO 5010) Steering-column-mounted, twist-grip shift lever; Quick-Shift button on hydraulic lever Type Power, fully hydraulic Articulation Angle 80-deg. arc (40 deg. each direction) Turning Radius (measured to centerline 5.27 m (17 ft. 4 in.) of outside tire) Hydraulic Cycle Times Z-Bar / High-Lift / High-Lift Plus Tool Carrier Raise 5.5 sec. 5.8 sec. Dump Lower (power down) 2.0 sec. 4.0 sec. 2.5 sec. 4.0 sec. 26 Total 11.5 sec. 12.3 sec. S PE C IF IC AT IONS While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Dimensions and Specifications with Pin-On Bucket 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER M N G I H J Cab A B L K D C E F 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH PIN-ON BUCKET WITH BOLT-ON EDGE Z-Bar Z-Bar High-Lift High-Lift High-Lift Plus High-Lift Plus 2.7-m3 (3.5 cu. yd.) 2.9-m3 (3.75 cu. yd.) 2.7-m3 (3.5 cu. yd.) 2.9-m3 (3.75 cu. yd.) 2.7-m3 (3.5 cu. yd.) 2.9-m3 (3.75 cu. yd.) Dimensions with Bucket with Bolt-On Edge general purpose general purpose general purpose general purpose general purpose general purpose A Height to Top of Cab 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) B Hood Height 2.46 m (8 ft. 1 in.) 2.46 m (8 ft. 1 in.) 2.46 m (8 ft. 1 in.) 2.46 m (8 ft. 1 in.) 2.46 m (8 ft. 1 in.) 2.46 m (8 ft. 1 in.) C Ground Clearance 384 mm (15.1 in.) 384 mm (15.1 in.) 384 mm (15.1 in.) 384 mm (15.1 in.) 384 mm (15.1 in.) 384 mm (15.1 in.) D Length from Centerline to Front Axle 1.52 m (5 ft. 0 in.) 1.52 m (5 ft. 0 in.) 1.52 m (5 ft. 0 in.) 1.52 m (5 ft. 0 in.) 1.52 m (5 ft. 0 in.) 1.52 m (5 ft. 0 in.) E Wheelbase 3.09 m (10 ft. 1 in.) 3.09 m (10 ft. 1 in.) 3.09 m (10 ft. 1 in.) 3.09 m (10 ft. 1 in.) 3.09 m (10 ft. 1 in.) 3.09 m (10 ft. 1 in.) F Overall Length, Bucket on Ground 7.76 m (25 ft. 6 in.) 7.83 m (25 ft. 8 in.) 8.22 m (27 ft. 0 in.) 8.22 m (27 ft. 0 in.) 8.52 m (27 ft. 11 in.) 8.58 m (28 ft. 2 in.) G Height to Hinge Pin, Fully Raised 3.96 m (13 ft. 0 in.) 3.96 m (13 ft. 0 in.) 4.32 m (14 ft. 2 in.) 4.32 m (14 ft. 2 in.) 4.57 m (15 ft. 0 in.) 4.57 m (15 ft. 0 in.) H Dump Clearance, 45 deg., Full Height 2.84 m (9 ft. 4 in.) 2.80 m (9 ft. 2 in.) 3.20 m (10 ft. 6 in.) 3.16 m (10 ft. 4 in.) 3.46 m (11 ft. 4 in.) 3.41 m (11 ft. 2 in.) I Reach, 45-deg. Dump, Full Height 1.07 m (3 ft. 6 in.) 1.12 m (3 ft. 8 in.) 1.21 m (4 ft. 0 in.) 1.25 m (4 ft. 1 in.) 1.22 m (4 ft. 0 in.) 1.27 m (4 ft. 2 in.) J Reach, 45-deg. Dump, 2.13-m (7 ft. 1.59 m (5 ft. 2 in.) 1.61 m (5 ft. 3 in.) 1.98 m (6 ft. 6 in.) 2.00 m (6 ft. 7 in.) 2.20 m (7 ft. 2 in.) 2.22 m (7 ft. 3 in.) 0 in.) Clearance K Maximum Digging Depth L Maximum Rollback at Ground Level M Maximum Rollback, Boom Fully Raised N Maximum Bucket Dump Angle, Fully Raised 0.10 m (4 in.) 44 deg. 60 deg. 48 deg. 0.11 m (4 in.) 44 deg. 60 deg. 48 deg. 0.20 m (8 in.) 48 deg. 60 deg. 46 deg. 0.21 m (8 in.) 48 deg. 60 deg. 46 deg. 0.20 m (8 in.) 49 deg. 60 deg. 45 deg. 0.20 m (8 in.) 49 deg. 60 deg. 45 deg. Loader Clearance Circle, Bucket Carry Position 12.02 m (39 ft. 5 in.) 12.04 m (39 ft. 6 in.) 12.32 m (40 ft. 5 in.) 12.5 m (41 ft. 0 in.) 12.66 m (41 ft. 6 in.) 12.78 m (41 ft. 11 in.) Specifications with Bucket with Bolt-On Edge Capacity, Heaped Capacity, Struck Bucket Weight with Bolt-On Cutting Edge 2.7 m3 (3.5 cu. yd.) 2.2 m3 (2.9 cu. yd.) 1196 kg (2,637 lb.) 2.9 m3 (3.75 cu. yd.) 2.4 m3 (3.1 cu. yd.) 1239 kg (2,732 lb.) 2.7 m3 (3.5 cu. yd.) 2.2 m3 (2.9 cu. yd.) 1196 kg (2,637 lb.) 2.9 m3 (3.75 cu. yd.) 2.4 m3 (3.1 cu. yd.) 1239 kg (2,732 lb.) 2.7 m3 (3.5 cu. yd.) 2.2 m3 (2.9 cu. yd.) 1196 kg (2,637 lb.) 2.9 m3 (3.75 cu. yd.) 2.4 m3 (3.1 cu. yd.) 1239 kg (2,732 lb.) Bucket Width Breakout Force Tipping Load, Straight, No Tire Deflection Tipping Load, Straight, with Tire Deflection Tipping Load, 40-deg. Full Turn, No Tire 2.69 m (8 ft. 10 in.) 13 605 kg (29,994 lb.) 13 205 kg (29,113 lb.) 12 435 kg (27,414 lb.) 11 439 kg (25,218 lb.) 2.69 m (8 ft. 10 in.) 12 929 kg (28,503 lb.) 13 116 kg (28,915 lb.) 12 345 kg (27,216 lb.) 11 359 kg (25,042 lb.) 2.69 m (8 ft. 10 in.) 13 443 kg (29,638 lb.) 11 132 kg (24,541 lb.) 10 563 kg (23,287 lb.) 9595 kg (21,153 lb.) 2.69 m (8 ft. 10 in.) 12 774 kg (28,163 lb.) 11 060 kg (24,383 lb.) 10 488 kg (23,122 lb.) 9530 kg (21,010 lb.) 2.69 m (8 ft. 10 in.) 13 510 kg (29,785 lb.) 10 297 kg (22,701 lb.) 9792 kg (21,588 lb.) 8837 kg (19,483 lb.) 2.69 m (8 ft. 10 in.) 12 839 kg (28,304 lb.) 10 231 kg (22,555 lb.) 9723 kg (21,436 lb.) 8778 kg (19,351 lb.) Deflection Tipping Load, 40-deg. Full Turn, with Tire 10 425 kg (22,983 lb.) 10 338 kg (22,791 lb.) 8820 kg (19,445 lb.) 8754 kg (19,299 lb.) 8145 kg (17,957 lb.) 8091 kg (17,838 lb.) Deflection Rated Operating Load, 50% Full-Turn Tipping 5719 kg (12,609 lb.) 5680 kg (12,521 lb.) 4797 kg (10,576 lb.) 4765 kg (10,505 lb.) 4419 kg (9,741 lb.) 4389 kg (9,676 lb.) Load, No Tire Deflection (conforms to ISO 14397-1)* Rated Operating Load, 50% Full-Turn Tipping 5213 kg (11,492 lb.) 5169 kg (11,396 lb.) 4410 kg (9,722 lb.) 4377 kg (9,650 lb.) 4073 kg (8,978 lb.) 4046 kg (8,919 lb.) Load, with Tire Deflection (conforms to ISO 14397-1)* Operating Weight 15 747 kg (34,715 lb.) 15 790 kg (34,810 lb.) 15 953 kg (35,171 lb.) 15 996 kg (35,266 lb.) 16 195 kg (35,703 lb.) 16 238 kg (35,798 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVX 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/ counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affect by changes in tires, ballast, and different attachments, and assumes no tire deflection per the standard ISO 14397-1 section 5. *Rated operating capacity based on Deere attachments only. 624L Dimensions and Specifications with Hi-Vis Coupler and Hook-On Bucket While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER M M N G I H J L Cab N A G I B H J L Cab A B K D C E F 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH HI-VIS COUPLER AND HOOK-ON BUCKET WITH BOLT-ON EDGE D C K E F 624L TOOL-CARRIER LOADER WITH HI-VIS COUPLER AND HOOK-ON BUCKET WITH BOLT-ON EDGE Dimensions with Bucket with Bolt-On Edge A Height to Top of Cab B Hood Height C Ground Clearance D Length from Centerline to Front Axle E Wheelbase F Overall Length, Bucket on Ground G Height to Hinge Pin, Fully Raised H Dump Clearance, 45 deg., Full Height I Reach, 45-deg. Dump, Full Height J Reach, 45-deg. Dump, 2.13-m (7 ft. 0 in.) Clearance K Maximum Digging Depth L Maximum Rollback at Ground Level M Maximum Rollback, Boom Fully Raised N Maximum Bucket Dump Angle, Fully Raised Loader Clearance Circle, Bucket Carry Position Z-Bar 2.7-m3 (3.5 cu. yd.) general purpose 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 7.89 m (25 ft. 11 in.) 3.96 m (13 ft. 0 in.) 2.76 m (9 ft. 1 in.) 1.17 m (3 ft. 10 in.) 1.64 m (5 ft. 5 in.) 0.10 m (4 in.) 44 deg. 60 deg. 48 deg. 12.06 m (39 ft. 7 in.) Z-Bar 4.0-m3 (5.25 cu. yd.) light material 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.04 m (26 ft. 5 in.) 3.96 m (13 ft. 0 in.) 2.66 m (8 ft. 9 in.) 1.28 m (4 ft. 2 in.) 1.69 m (5 ft. 7 in.) 0.11 m (4 in.) 44 deg. 60 deg. 48 deg. High-Lift 2.5-m3 (3.25 cu. yd.) general purpose 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.31 m (27 ft. 3 in.) 4.32 m (14 ft. 2 in.) 3.15 m (10 ft. 4 in.) 1.28 m (4 ft. 2 in.) 2.03 m (6 ft. 8 in.) 0.20 m (8 in.) 48 deg. 60 deg. 46 deg. High-Lift 3.4-m3 (4.5 cu. yd.) light material 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.50 m (27 ft. 11 in.) 4.32 m (14 ft. 2 in.) 3.02 m (9 ft. 11 in.) 1.42 m (4 ft. 8 in.) 2.10 m (6 ft. 11 in.) 0.21 m (8 in.) 48 deg. 60 deg. 45 deg. High-Lift Plus 2.3-m3 (3.0 cu. yd.) general purpose 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.53 m (28 ft. 0 in.) 4.57 m (15 ft. 0 in.) 3.45 m (11 ft. 4 in.) 1.24 m (4 ft. 1 in.) 2.21 m (7 ft. 3 in.) 0.19 m (7 in.) 49 deg. 60 deg. 45 deg. High-Lift Plus 3.1-m3 (4.0 cu. yd.) light material 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.66 m (28 ft. 5 in.) 4.57 m (15 ft. 0 in.) 3.37 m (11 ft. 1 in.) 1.34 m (4 ft. 5 in.) 2.27 m (7 ft. 6 in.) 0.19 m (7 in.) 49 deg. 60 deg. 45 deg. Tool Carrier 2.7-m3 (3.5 cu. yd.) general purpose 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 7.99 m (26 ft. 2 in.) 4.00 m (13 ft. 1 in.) 2.74 m (9 ft. 0 in.) 1.39 m (4 ft. 7 in.) 1.83 m (6 ft. 0 in.) 0.13 m (5 in.) 52 deg. 57 deg. 50 deg. 12.44 m 12.34 m 12.80 m 12.76 m 13.00 m 12.24 m (40 ft. 10 in.) (40 ft. 6 in.) (42 ft. 0 in.) (41 ft. 11 in.) (42 ft. 8 in.) (40 ft. 2 in.) Tool Carrier 3.4-m3 (4.5 cu. yd.) light material 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.13 m (26 ft. 8 in.) 4.00 m (13 ft. 1 in.) 2.64 m (8 ft. 8 in.) 1.51 m (4 ft. 11 in.) 1.89 m (6 ft. 2 in.) 0.13 m (5 in.) 52 deg. 57 deg. 50 deg. 12.5 m (41 ft. 0 in.) 28 While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 624L Dimensions and Specifications with Hi-Vis Coupler and Hook-On Bucket (continued) 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Z-Bar Z-Bar High-Lift High-Lift High-Lift Plus High-Lift Plus Tool Carrier Tool Carrier 2.7-m3 2.5-m3 2.3-m3 2.7-m3 (3.5 cu. yd.) 4.0-m3 (3.25 cu. yd.) 3.4-m3 (3.0 cu. yd.) 3.1-m3 (3.5 cu. yd.) 3.4-m3 Specifications with Bucket with general (5.25 cu. yd.) general (4.5 cu. yd.) general (4.0 cu. yd.) general (4.5 cu. yd.) Bolt-On Edge Capacity, Heaped purpose 2.7 m3 light material purpose 4.0 m3 2.5 m3 light material purpose 3.4 m3 2.3 m3 light material purpose 3.1 m3 2.7 m3 light material 3.4 m3 Capacity, Struck (3.5 cu. yd.) (5.25 cu. yd.) (3.25 cu. yd.) (4.5 cu. yd.) (3.0 cu. yd.) (4.0 cu. yd.) (3.5 cu. yd.) (4.5 cu. yd.) 2.17 m3 3.46 m3 2.1 m3 2.9 m3 1.9 m3 2.6 m3 1.9 m3 2.9 m3 Bucket Weight with Bolt-On Cutting Edge (2.8 cu. yd.) 1655 kg (3,649 lb.) (4.53 cu. yd.) (2.7 cu. yd.) 1925 kg 1633 kg (4,245 lb.) (3,601 lb.) (3.8 cu. yd.) 1843 kg (4,063 lb.) (2.4 cu. yd.) 1586 kg (3,496 lb.) (3.4 cu. yd.) 1780 kg (3,924 lb.) (2.4 cu. yd.) 1437 kg (3,167 lb.) (3.8 cu. yd.) 1626 kg (3,584 lb.) Bucket Width 2.68 m 3.05 m 2.69 m 2.89 m 2.69 m 2.89 m 2.68 m 2.89 m Breakout Force Tipping Load, Straight, No Tire Deflection Tipping Load, Straight, with Tire Deflection Tipping Load, 40-deg. Full Turn, (8 ft. 10 in.) 12 161 kg (26,810 lb.) 12 357 kg (27,242 lb.) 11 613 kg (25,602 lb.) 10 652 kg (10 ft. 0 in.) 10 789 kg (23,785 lb.) 11 990 kg (26,434 lb.) 11 220 kg (24,736 lb.) 10 292 kg (8 ft. 10 in.) 13 052 kg (28,776 lb.) 10 624 kg (23,422 lb.) 10 074 kg (22,209 lb.) 9130 kg (9 ft. 6 in.) 10 709 kg (23,610 lb.) 10 177 kg (22,437 lb.) 9600 kg (21,164 lb.) 8690 kg (8 ft. 10 in.) 13 266 kg (29,246 lb.) 9779 kg (21,559 lb.) 9294 kg (20,490 lb.) 8348 kg (9 ft. 6 in.) 11 874 kg (23,731 lb.) 9547 kg (20,701 lb.) 9042 kg (19,577 lb.) 8120 kg (8 ft. 10 in.) 11 477 kg (25,302 lb.) 11 577 kg (25,523 lb.) 10 920 kg (24,074 lb.) 9993 kg (9 ft. 6 in.) 10 290 kg (22,686 lb.) 11 544 kg (25,450 lb.) 10 854 kg (23,929 lb.) 9939 kg No Tire Deflection Tipping Load, 40-deg. Full Turn, (23,483 lb.) (22,690 lb.) (20,127 lb.) 9663 kg 9273 kg 8385 kg (19,158 lb.) 7911 kg (18,405 lb.) 7686 kg (17,581 lb.) 7437 kg (22,031 lb.) 9108 kg (21,912 lb.) 9006 kg with Tire Deflection (21,303 lb.) Rated Operating Load, 50% Full-Turn 5326 kg Tipping Load, No Tire Deflection (11,742 lb.) (20,443 lb.) 5146 kg (11,345 lb.) (18,486 lb.) 4565 kg (10,064 lb.) (17,441 lb.) 4345 kg (9,579 lb.) (16,945 lb.) 4174 kg (9,203 lb.) (16,032 lb.) 4060 kg (8,790 lb.) (20,080 lb.) 4997 kg (11,015 lb.) (19,855 lb.) 4970 kg (10,956 lb.) (conforms to ISO 14397-1)* Rated Operating Load, 50% Full-Turn 4832 kg Tipping Load, with Tire Deflection (10,652 lb.) 4637 kg (10,222 lb.) 4193 kg (9,243 lb.) 3956 kg (8,720 lb.) 3843 kg (8,472 lb.) 3719 kg (8,016 lb.) 4554 kg 4503 kg (10,040 lb.) (9,927 lb.) (conforms to ISO 14397-1)* Operating Weight 16 225 kg (35,769 lb.) 16 495 kg (36,365 lb.) 16 410 kg (36,178 lb.) 16 620 kg (36,641 lb.) 16 605 kg 16 799 kg (36,607 lb.) (37,174 lb.) 15 939 kg (35,140 lb.) 16 128 kg (35,556 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVX 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affected by changes in tires, ballast, and different attachments, and assumes no tire deflection per the standard ISO 14397-1 section 5. *Rated operating capacity based on Deere attachments only. 624L While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Dimensions and Specifications with Hi-Vis Coupler and Hook-On Construction Forks 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER H H O J G I L K Cab O J G A I B L K Cab A B N M D C E F 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS LOADERS WITH HI-VIS COUPLER AND HOOK-ON CONSTRUCTION FORKS N M D C E F 624L TOOL-CARRIER LOADER WITH HI-VIS COUPLER AND HOOK-ON CONSTRUCTION FORKS Dimensions with Forks A Height to Top of Cab B Hood Height C Ground Clearance D Length from Centerline to Front Axle E Wheelbase F Overall Length, Forks on Ground G Height to Hinge Pin, Fully Raised H Reach, Fully Raised I Fork Height, Fully Raised J Maximum Reach, Fork Level K Fork Height, Maximum Reach L Reach, Ground Level M Depth Below Ground N Tine Length O Load Position, 50% Tine Length Z-Bar 1.52-m (60 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.50 m (27 ft. 11 in.) 3.96 m (13 ft. 0 in.) 0.81 m (32 in.) 3.64 m (11 ft. 11 in.) 1.62 m (5 ft. 4 in.) 1.69 m (5 ft. 7 in.) 1.06 m (3 ft. 6 in.) 77 mm (3 in.) 1.52 m (60 in.) 0.76 m (30 in.) Z-Bar 1.83-m (72 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.80 m (28 ft. 11 in.) 3.96 m (13 ft. 0 in.) 0.81 m (32 in.) 3.64 m (11 ft. 11 in.) 1.62 m (5 ft. 4 in.) 1.69 m (5 ft. 7 in.) 1.06 m (3 ft. 6 in.) 77 mm (3 in.) 1.83 m (72 in.) 0.91 m (3 ft. 0 in.) High-Lift 1.52-m (60 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.96 m (29 ft. 5 in.) 4.32 m (14 ft. 2 in.) 0.95 m (3 ft. 1 in.) 4.00 m (13 ft. 2 in.) 1.98 m (6 ft. 6 in.) 1.69 m (5 ft. 7 in.) 1.49 m (4 ft. 11 in.) 181 mm (7 in.) 1.52 m (60 in.) 0.76 m (30 in.) High-Lift 1.83-m (72 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 9.26 m (30 ft. 5 in.) 4.32 m (14 ft. 2 in.) 0.95 m (3 ft. 1 in.) 4.00 m (13 ft. 2 in.) 1.98 m (6 ft. 6 in.) 1.69 m (5 ft. 7 in.) 1.49 m (4 ft. 11 in.) 181 mm (7 in.) 1.83 m (72 in.) 0.91 m (3 ft. 0 in.) High-Lift Plus 1.52-m (60 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 9.25 m (30 ft. 4 in.) 4.57 m (15 ft. 0 in.) 0.96 m (3 ft. 2 in.) 4.25 m (13 ft. 11 in.) 2.18 m (7 ft. 2 in.) 1.69 m (5 ft. 7 in.) 1.73 m (5 ft. 8 in.) 173 mm (7 in.) 1.52 m (60 in.) 0.76 m (30 in.) High-Lift Plus 1.83-m (72 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 9.56 m (31 ft. 4 in.) 4.57 m (15 ft. 0 in.) 0.96 m (3 ft. 2 in.) 4.25 m (13 ft. 11 in.) 2.18 m (7 ft. 2 in.) 1.69 m (5 ft. 7 in.) 1.73 m (5 ft. 8 in.) 173 mm (7 in.) 1.83 m (72 in.) 0.91 m (3 ft. 0 in.) Tool Carrier 1.52-m (60 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.63 m (28 ft. 4 in.) 4.00 m (13 ft. 1 in.) 1.05 m (3 ft. 5 in.) 3.72 m (12 ft. 2 in.) 1.80 m (5 ft. 11 in.) 1.80 m (5 ft. 11 in.) 1.21 m (4 ft. 0 in.) 173 mm (7 in.) 1.52 m (60 in.) 0.76 m (30 in.) Tool Carrier 1.83-m (72 in.) tine length 3.40 m (11 ft. 2 in.) 2.46 m (8 ft. 1 in.) 384 mm (15.1 in.) 1.52 m (5 ft. 0 in.) 3.09 m (10 ft. 1 in.) 8.94 m (29 ft. 4 in.) 4.00 m (13 ft. 1 in.) 1.05 m (3 ft. 5 in.) 3.72 m (12 ft. 2 in.) 1.80 m (5 ft. 11 in.) 1.80 m (5 ft. 11 in.) 1.21 m (4 ft. 0 in.) 173 mm (7 in.) 1.83 m (72 in.) 0.91 m (3 ft. 0 in.) 30 While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 624L Dimensions and Specifications with Hi-Vis Coupler and Hook-On Construction Forks (continued) 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Z-Bar Z-Bar High-Lift High-Lift High-Lift Plus High-Lift Plus Tool Carrier Tool Carrier 1.52-m 1.83-m 1.52-m 1.83-m 1.52-m 1.83-m 1.52-m 1.83-m (60 in.) (72 in.) (60 in.) (72 in.) (60 in.) (72 in.) (60 in.) (72 in.) Specifications with Forks Tipping Load, Straight, No Tire Deflection Tipping Load, Straight, with Tire Deflection Tipping Load, 40-deg. Full Turn, tine length 8808 kg (19,418 lb.) 8553 kg (18,856 lb.) 7602 kg tine length 8328 kg (18,360 lb.) 8091 kg (17,838 lb.) 7178 kg tine length 7736 kg (17,054 lb.) 7515 kg (16,568 lb.) 6639 kg tine length 7342 kg (16,186 lb.) 7134 kg (15,728 lb.) 6291 kg tine length 7296 kg (16,085 lb.) 7104 kg (15,662 lb.) 6232 kg tine length 6937 kg (15,293 lb.) 6759 kg (14,901 lb.) 5915 kg tine length 8505 kg (18,750 lb.) 8283 kg (18,261 lb.) 7350 kg tine length 8061 kg (17,771 lb.) 7851 kg (17,308 lb.) 6957 kg No Tire Deflection Tipping Load, 40-deg. Full Turn, (16,760 lb.) 7251 kg (15,825 lb.) 6858 kg (14,636 lb.) 6330 kg (13,869 lb.) 6006 kg (13,739 lb.) 5946 kg (13,041 lb.) 5643 kg (16,204 lb.) 7023 kg (15,338 lb.) 6648 kg with Tire Deflection (15,986 lb.) Rated Operating Load, 50% Full-Turn 3626 kg Tipping Load, with Tire Deflection (7,993 lb.) (15,119 lb.) 3429 kg (7,560 lb.) (13,955 lb.) 3165 kg (6,978 lb.) (13,241 lb.) 3003 kg (6,620 lb.) (13,109 lb.) 2973 kg (6,554 lb.) (12,441 lb.) 2822 kg (6,220 lb.) (15,483 lb.) 3512 kg (7,742 lb.) (14,656 lb.) 3324 kg (7,328 lb.) (conforms to ISO 14397-1 and SAE J1197)* Rated Operating Load, Rough Terrain, 60% Full-Turn Tipping Load, 4351 kg (9,591 lb.) 4115 kg (9,072 lb.) 3798 kg (8,373 lb.) 3604 kg (7,945 lb.) 3568 kg (7,865 lb.) 3386 kg (7,464 lb.) 4214 kg (9,290 lb.) 3989 kg (8,794 lb.) with Tire Deflection (conforms to EN474-3)* Rated Operating Load, Firm and Level Ground, 80% Full-Turn Tipping 5801 kg (12,789 lb.) 5486 kg (12,095 lb.) 5064 kg (11,164 lb.) 4805 kg (10,593 lb.) 4757 kg (10,487 lb.) 4514 kg (9,953 lb.) 5618 kg (12,386 lb.) 5318 kg (11,725 lb.) Load, with Tire Deflection (conforms to EN474-3)* Operating Weight 16 005 kg (35,286 lb.) 16 066 kg (35,420 lb.) 16 213 kg (35,744 lb.) 16 272 kg (35,875 lb.) 16 454 kg (36,274 lb.) 16 516 kg (36,412 lb.) 15 721 kg 15 807 kg (34,659 lb.) (34,849 lb.) Loader operating information is based on machine with identified linkage and standard equipment, PowerTech PVX 6068 (EPA Final Tier 4/EU Stage V) engine, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. This information is affected by changes in tires, ballast, and different attachments. *Rated operating capacity based on Deere attachments only. 624L While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Adjustments to Operating Weights and Tipping Loads with Buckets 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Adjustments to operating weights, tipping loads, and tires are based on Z-Bar machine with pin-on 2.7-m3 (3.5 cu. yd.) general-purpose bucket with bolt-on cutting edge, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator* Add (+) or deduct () kg (lb.) as indicated Tipping Load, Tipping Load, for loaders with 3-piece rims Michelin 20.5 R 25, 1 Star L-3 XHA2 Operating Weight Straight 0 kg (0 lb.) 0 kg (0 lb.) 40-deg. Full Turn Tread Width 0 kg (0 lb.) 0 mm (0 in.) Width Over Tires Vertical Height 0 mm (0 in.) 0 mm (0 in.) Bridgestone 20.5 R 25, 1 Star L-3 VJT +4 kg (+9 lb.) +3 kg (+6 lb.) +3 kg (+6 lb.) 0 mm (0 in.) +3 mm (+0.1 in.) 41 mm (1.6 in.) Titan 20.5 R 25, 1 Star L-3 STL3 +8 kg (+19 lb.) +6 kg (+13 lb.) +5 kg (+13 lb.) 0 mm (0 in.) 6 mm (0.2 in.) 7 mm (0.3 in.) Michelin 20.5 R 25, 1 Star L-2 XTLA 152 kg (335 lb.) 110 kg (242 lb.) 97 kg (214 lb.) 0 mm (0 in.) +5 mm (+0.2 in.) 10 mm (0.4 in.) Bridgestone 20.5 R 25, 1 Star L-2 VUT 68 kg (149 lb.) 49 kg (108 lb.) 43 kg (95 lb.) 0 mm (0 in.) +4 mm (+0.2 in.) 10 mm (0.4 in.) Titan 20.5 R 25, 1 Star L-2 TGD2 116 kg (255 lb.) 84 kg (184 lb.) 74 kg (162 lb.) 0 mm (0 in.) 6 mm (0.2 in.) 10 mm (0.4 in.) Firestone 20.5-25, 16 PR L-3 SRG Bias 276 kg (608 lb.) 200 kg (440 lb.) 176 kg (388 lb.) 0 mm (0 in.) +9 mm (+0.4 in.) +6 mm (+0.2 in.) Titan 20.5-25, 16 PR L-2 Bias 232 kg (511 lb.) +168 kg (+370 lb.) 148 kg (326 lb.) 0 mm (0 in.) +9 mm (+0.4 in.) 1 mm (0 in.) Firestone 20.5-25, 16 PR L-2 SGG Bias 280 kg (617 lb.) 203 kg (446 lb.) 178 kg (393 lb.) 0 mm (0 in.) +6 mm (+0.2 in.) +2 mm (+0.1 in.) Michelin 600/65 R 25, 1 Star L-3T XLD§ +16 kg (+36 lb.) +12 kg (+26 lb.) +10 kg (+23 lb.) 0 mm (0 in.) +95 mm (+3.7 in.) 31 mm (1.2 in.) Michelin 20.5 R 25, L2T XSNO-PLUS 96 kg (212 lb.) 69 kg (153 lb.) 61 kg (135 lb.) 0 mm (0 in.) +7 mm (+0.3 in.) 33 mm (1.3 in.) Michelin 620/75R26 MegaXbib£ß 207 kg (457 lb.) 150 kg (331 lb.) 132 kg (291 lb.) +86 mm (+3.4 in.) +147 mm (+5.8 in.) +23 mm (+0.9 in.) Michelin 750/65R26 MegaXbib£ß +37 kg (+81 lb.) +27 kg (+58 lb.) +23 kg (+51 lb.) +222 mm (+8.7 in.) +422 mm (+16.6 in.) +36 mm (+1.4 in.) CaCl2 in 20.5-25, L-3 Rear Tires, 75% Fill +825 kg +1193 kg +1051 kg N/A N/A N/A (+1,820 lb.) (+2,631 lb.) (+2,318 lb.) *May change based on vehicle configuration, weight, or tire-pressure adjustments. §CaCl2 not recommended. £Equipped with 1-piece rims. ßRequires 8-deg. rear axle stops. 32 While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. 624L Bucket Selection Guides 600 700 624L Z-BAR / HIGH-LIFT / HIGH-LIFT PLUS / TOOL CARRIER Material Density (kg/m3) 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300 3.18 m3 (4.16 cu. yd.) 2.52 m3 (3.30 cu. yd.) 2.7 m3 (3.5 cu. yd.) Pin-On 2.9 m3 (3.75 cu. yd.) 3.45 m3 (4.51 cu. yd.) 2.73 m3 (3.57 cu. yd.) Z-Bar Linkage 2.7.0 m3 (3.5 cu. yd.) Hi-Vis 3.18 m3 (4.16 cu. yd.) 2.52 m3 (3.30 cu. yd.) Quick-Coupler 4.0 m3(5.25 cu. yd.) Light Material Hi-Vis 4.92 m3 (6.43 cu. yd.) 3.89 m3 (5.09 cu. yd.) 2.7 m3 (3.5 cu. yd.) 3.18 m3 (4.16 cu. yd.) 2.52 m3 (3.30 cu. yd.) Pin-On 2.9 m3 (3.75 cu. yd.) High-Lift Linkage 3.45 m3 (4.51 cu. yd.) 2.73 m3 (3.57 cu. yd.) 2.5.0 m3 (3.25 cu. yd.) Hi-Vis 3.00 m3 (3.93 cu. yd.) 2.38 m3 (3.11 cu. yd.) Quick-Coupler 3.4 m3(4.5 cu. yd.) Light Material Hi-Vis 4.24 m3 (5.54 cu. yd.) 3.36 m3 (4.39 cu. yd.) 2.7 m3 (3.5 cu. yd.) 3.18 m3 (4.16 cu. yd.) 2.52 m3 (3.30 cu. yd.) Pin-On 2.9 m3 (3.75 cu. yd.) High-Lift Plus Linkage 3.45 m3 (4.51 cu. yd.) 2.73 m3 (3.57 cu. yd.) 2.3 m3(3.0 cu. yd.) Hi-Vis 2.71 m3 (3.55 cu. yd.) 2.15 m3 (2.81 cu. yd.) Quick-Coupler 3.1 m3(4.0 cu. yd.) Light Material Hi-Vis 3.66 m3 (4.79 cu. yd.) 2.90 m3 (3.79 cu. yd.) 2.7 m3(3.5 cu. yd.) Hi-Vis Quick-Coupler Tool Carrier Linkage 3.18 m3 (4.16 cu. yd.) 2.52 m3 (3.30 cu. yd.) 3.4 m3(4.5 cu. yd.) Light Material Hi-Vis 4.24 m3 (5.54 cu. yd.) 3.36 m3 (4.39 cu. yd.) 1,011 LOOSE MATERIALS 1,180 1,348 1,517 1,686 1,854 kg/m3 lb./cu. yd. LOOSE MATERIALS 2,023 2,191 2,360 2,528 2,697 Material Density (lb./cu. yd.) kg/m3 lb./cu. yd. 2,865 3,034 3,203 3,371 Bucket Fill Factors 3,540 Chips, pulpwood 288 Cinders (coal, ashes, clinkers) 673 Clay and gravel, dry 1602 Clay, compact, solid 1746 Clay, dry in lump loose 1009 Clay, excavated in water 1282 Coal, anthracite, broken, loose 865 Coal, bituminous, moderately wet 801 Earth, common loam, dry 1218 Earth, mud, packed 1843 Granite, broken 1538 Gypsum 2275 486 1,134 2,700 2,943 1,701 2,160 1,458 1,350 2,052 3,105 2,592 3,834 Limestone, coarse, sized Limestone, mixed sizes Limestone, pulverized or crushed Sand, damp Sand, dry Sand, voids, full of water Sandstone, quarried Shale, broken crushed Slag, furnace granulated Stone or gravel, 37.5 to 87.5-mm (1.5 to 3.5 in.) size Stone or gravel, 18.75-mm (0.75 in.) size 1570 1682 1362 2083 1762 2083 1314 1362 1955 1442 1602 2,646 2,835 2,295 3,510 2,970 3,510 2,214 2,295 3,294 2,430 2,700 130% 120% 110% 105% 100% 95% 3,708 3,876 Additional equipment Key: l Standard s Optional or special See your John Deere dealer for further information. 524 544 624 Engine l l l Wet-sleeve cylinder liners l l l Automatic glow plugs for cold start l l l Programmable auto-idle and auto shutdown l l l Selected idle adjustment from 9001,250 rpm l l l Starter protection l l l Automatic engine cool-down timer l l l Automatic derating for exceeded system temperatures l l l Serpentine drive belt for automatic tensioner l l l Electrical fuel-priming pump l l l Dual-stage fuel filter and water separator l l l 500-hour vertical spin-on oil filter s s s Engine-compartment light s s s Chrome exhaust stack s s s Engine-block heater (recommended for cold starts below 23 deg. C [10 deg. F]) s s s Centrifugal engine air pre-cleaner s s s Throttle lock Powertrain l l l Clutch cutoff with 4 operator settings: Automatic, level ground, small slope, or steep slope l l l Programmable maximum high gear l l l Clutch calibration engaged from monitor l l l 2,000-hour vertical spin-on transmission filter l l l Transmission fill tube and sight gauge l l l Transmission diagnostic ports l l 5-speed transmission with lockup torque converter l s s 5-speed transmission with non-lockup torque converter l l l Front locking differential s s s Rear locking differential l l l Brake retractors and adjusters s s s Automatic differential lock l l l Axle oil temperature sensing s s s Wheel-spin control Quad-CoolTM Cooling System l l l Heavy-duty, trash-resistant radiator and high-ambient cooling package l l l 2-side access to all coolers l l l Isolated from engine compartment l l l Engine radiator l l l Integral engine oil cooler l l l Hydraulic oil cooler (oil to air) l l l Transmission oil cooler (oil to air) l l l Charge air cooler (air to air) l l l Fuel cooler l l l Coolant recovery tank l l l Antifreeze, 37 deg. C (34 deg. F) l l l Cool-on-demand, hydraulically driven, swing-out fan l l l Enclosed fan safety guard s s s Automatic reversing fan drive s s l Axle and service-brake coolers 524 544 624 Hydraulics l l l Electrohydraulic (EH) controls with soft stops and adjustable settings l l l In-cab adjustable automatic return-to-dig bucket positioner l l l In-cab adjustable automatic boom-height kickout/return to carry l l l Reservoir with sight gauge and fill strainer l l l Hydraulic diagnostic ports l l l 4,000-hour in-tank filter l l l 2 function -- joystick with F-N-R s s s 2 function -- 2-lever fingertip controls and steering column F-N-R s s s 3 function -- joystick with F-N-R and integrated 3rd-function roller s s s 3 function -- 3-lever fingertip controls and steering column F-N-R s s s 4 function -- joystick with F-N-R and integrated 3rd/4th function rollers l l l 2 programmable multifunction buttons l l l Adjustable and continuous hydraulic-flow settings l l l Programmable attachment settings s s s Ride control, automatic with monitor-adjustable speed settings s s s Hydraulic control system for quick-coupler locking pins s s s HydrauTM XR cold-temperature hydraulic fluid recommended below 25 deg. C. (13 deg. F) Steering Systems l l l Conventional steering wheel with spinner knob s s s Secondary steering Electrical l l l Solid-state electrical power-distribution system l l l Lockable master electrical-disconnect switch l l l Battery-terminal safety covers l l l By-pass start safety cover at starter l l l Remote jump-start access in battery box l l l Pre-wired for beacon/strobe light l l l Lights: Halogen driving lights with guards (2) / Front (4), rear cab (2), and rear grille (2) work lights / LED front turn signals and flashers / LED stop and taillights s s s Premium LED light package (all exterior lights are heavy-duty LED) l l l Programmable courtesy lights l l l Horn, electric l l l Reverse warning alarm l l l Multifunction/multi-language 178-mm (7 in.) LCD color monitor includes: Digital instruments -- Analog display (hydraulic oil temperature, engine coolant temperature, transmission oil temperature, and engine oil pressure) / Digital display (engine rpm, transmission gear/direction indicator, hour meter, fuel level, diesel exhaust fluid (DEF) level, speedometer, odometer, and average fuel consumption) s s s Multifunction/multi-language 127-mm (5 in.) LCD color monitor includes: Digital instruments -- Analog display (hydraulic oil temperature, engine coolant temperature, transmission oil temperature, and engine oil pressure) / Digital display (engine rpm, transmission gear/direction indicator, hour meter, fuel level, DEF level, speedometer, odometer, and average fuel consumption) s s s Integrated cycle counter with 5 categories l l l Indicator lights: Standard and selected options / Amber caution and red stop While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Net engine power is with standard equipment including air cleaner, exhaust system, alternator, and cooling fan at test conditions per ISO 9249. No derating is required up to 3050-m (10,000 ft.) altitude. Specifications and design subject to change without notice. Specifications with the exception of bucket capacity are in accordance with all applicable ISO standards. Except where otherwise noted, these specifications are based on units with applicable linkage and standard equipment, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. 34 Additional equipment (cont.) Key: l Standard s Optional or special See your John Deere dealer for further information. 524 544 624 Electrical (continued) l l l Operator-warning messages l l l Built-in diagnostics: Diagnostic-code details / Sensor values / Calibrations / Individual circuit tester s s s Electrical corrosion-prevention package l l l Standard AM/FM/Weather-Band (WB) radio with remote auxiliary port s s s Premium AM/FM/WB radio with Bluetooth®, remote auxiliary port, and remote USB port (premium cab only) l l l 24- to 12-volt, 8-amp converter and cab power ports (3) s s s 24- to 12-volt, 15- or 30-amp converter and cab power ports (3) Operator's Station l l l Standard cab with air conditioning/heater (ROPS/FOPS Level 1, isolation mounted) s s s Premium cab with air conditioning/heater (ROPS/FOPS Level 1, isolation mounted) s s s Automatic temperature control (premium cab only) l l l Rear window defrost vent l l l Keyless start with multiple security modes l l l Sealed-switch module with function indicators l l l Seat with backrest extension, deep foam, fabric cover, and adjustable air suspension s s s Premium seat with high-wide back and headrest extension, heated and ventilated, leather/fabric cover, and adjustable heavy-duty air suspension l l l Hydraulic controls integrated to seat l l l High-visibility, bright-orange seat belt, 76 mm (3 in.), with retractor s s s Seat-belt minder monitoring with JDLinkTM and seat-belt indicator beacon l l l Cup holder and cup/thermos holder with retaining strap l l l Lunch-box/cooler holder with tie-down brackets l l l Coat hook l l l LED dome and reading light l l l Rubber floor mat l l l Dual-tilt steering column l l l Operator's manual storage compartment l l l Outside (2) and inside (1) rearview mirrors s s s Heated outside mirrors with convex lens s s s In-cab adjustable heated outside mirrors with convex lens (premium cab only) l l l Left-side operator-station access l l l Slip-resistant steps and ergonomic handholds l l l Pull-down front sun visor l l l Front and rear intermittent windshield wipers and washers s s s Powered cab air pre-cleaner s s s Beacon bracket only s s s Beacon bracket with strobe beacon l l l Rearview camera s s s Rearview camera with radar object-detection system s s s Dedicated 178-mm (7 in.) rear camera display l l l Payload scale ready s s s Fire extinguisher 524 544 624 Loader Linkage l l l Z-Bar loader linkage (parallel lift) s s s High-Lift Z-Bar loader linkage (parallel lift) s s s High-Lift Plus Z-Bar loader linkage (parallel lift) s s Tool Carrier linkage for visibility (parallel lift) Buckets and Attachments s s s Full line of Deere pin-on buckets s s s John Deere hydraulic coupler that accepts JRB-pattern attachments s s s Hi-Vis hydraulic coupler which accepts Euro-pattern attachments (ISO) s s s Full line of Deere hook-on buckets and forks Overall Vehicle l l l JDLink wireless communication system (available in specific countries; see your dealer for details) l l l NeverGreaseTM rear-axle oscillation l l l Front and rear tie-downs l l l Rear cast bumper/counterweight with rear hitch and locking pin l l l Articulation locking bar l l l Loader boom service locking bar l l l 40-deg. steering articulation to each side with rubber-cushion stops on frame l l l Vandal protection with lockable engine enclosures, right counterweight storage, and filler access for radiator/fuel/DEF/hydraulic transmission l l l Left-side service steps and handholds s s s Right-side service steps and handrails s s s Left-side close-mounted steps l l l Storage compartment l l l Fuel-tank fill strainer l l l Heavy-duty fuel-tank guard l l l DEF and ground-level fueling l l l Same-side ground-level daily servicing l l l 20.5R25 tires on 3-piece rims s s s Ag material-handling package s Waste handler (Z-Bar and High-Lift) s s s Environmental drains and sample ports for engine, transmission, hydraulic oils, and engine coolant l l l Fenders, front narrow s s s Fenders, front full width s s s Fenders, front and rear full width s s s Fenders, front and rear full width with mudflaps s s s Less wheels and tires with 8-deg. axle stops s s s Rims less tires s s s Transmission side-frame and bottom guards s s s Lift eyes s s s License-plate bracket and light s Special guarding for waste applications While general information, pictures, and descriptions are provided, some illustrations and text may include product options and accessories NOT AVAILABLE in all regions, and in some countries products and accessories may require modifications or additions to ensure compliance with the local regulations of those countries. Net engine power is with standard equipment including air cleaner, exhaust system, alternator, and cooling fan at test conditions per ISO 9249. No derating is required up to 3050-m (10,000 ft.) altitude. Specifications and design subject to change without notice. Specifications with the exception of bucket capacity are in accordance with all applicable ISO standards. Except where otherwise noted, these specifications are based on units with applicable linkage and standard equipment, ROPS cab, rear cast bumper/counterweight, transmission side-frame guards, bottom guards, standard tires, full fuel tank, and 79-kg (175 lb.) operator. 06-22-20 JohnDeere.comDALiM Software Applications
