Flexible fiber, simple network solution
Your network needs to be easily upscaled and ready for future expansion. CommScope's G2 portfolio of panels, modules and cassettes is designed to help you get there. Pushing what's possible in your network.
In a reality where the only way to stay ahead of the ever-increasing network demand is with agility and relentless innovation, CommScope offers a simple solution with the G2 Family Portfolio. A design born from CommScope's 30 year experience, the G2 Family of products not only seamlessly integrate with one another, to maximize the potential in your network with a minimal amount of part numbers. The G2 portfolio of products also offers the quality and reliability only an industry leader can offer.
CommScope's G2 panels, modules, and cassettes' broad range of solutions meet the needs of any in-building network, no matter the size. In the telecom room, the panels, modules, and cassettes allow for easy configurations and quick installations.
Image: A professional presenting to colleagues in a modern office setting, with screens displaying network data.
G2 Fiber Panels
The G2 family of panels and modules is a versatile solution that is available in configurations for any application. No matter what polarity, fiber count or performance needed; the G2 family has a solution.
- A modular solution which easily allows for adds and changes to optimize your network with minimal components.
- G2 family modules fit into any AGL, HD or UD panels offering density up to 144f duplex LC per RU or 48f MPO per RU adding flexibility to any configuration.
Images depicting various G2 fiber panel configurations: AGL-1U-FX, AGL-1U-DRW, AGL-1U-ENC-FX, HD-1U, HD-2U, HD-4U, UD-2U, UD-4U.
AGL, HD and UD Panels
The AGL, HD and UD fiber panels support the G2 style module and adapter panels. Available in multiple sizes, you can select the panel which meets your needs and easily plan for the needs of tomorrow.
- The AGL panel is a low-cost solution for usable density in a 1U format.
- The HD (High Density) panel is available in 1U, 2U and 4U sizes, and supports high density applications.
- The UD (Ultra Density) panel is designed for even higher density applications and is available in 2U and 4U sizes.
- HD and UD panels support intelligence through imVision, the Automated Infrastructure Management (AIM) solution. More details on imVision are shown on page 9.
The following high-level overview provides details of the AGL, HD and UD panels and associated modules and components.
| Series | Density | Concept | Material ID | Description |
|---|---|---|---|---|
| AGL - AGILE Simple & Cost Effective | 96 LC/RU 32 MPO/RU |
Open Rear Fixed | 760241517 | AGL-1U-FX |
| Open Rear Sliding | 760241518 | AGL-1U-ANG-FX | ||
| Basic 2-Piece Drawer | 760242453 | AGL-1U-SL | ||
| Basic Enclosed Fixed | 760242454 | AGL-1U-ANG-SL | ||
| Basic Enclosed Sliding | 760242455 | AGL-1U-DRW-SL | ||
| 760242475 | AGL-1U-ENC-FX | |||
| 760242476 | AGL-1U-ENC-SL | |||
| HD - High Density Premium Features | 96 LC/RU 32 MPO/RU |
Standard Fixed | 760210732 | HD-1U-FX |
| 760210740 | HD-2U-FX | |||
| 760210757 | HD-4U-FX | |||
| Standard Sliding | 760209940 | HD-1U | ||
| 760209957 | HD-2U | |||
| 760209965 | HD-4U | |||
| Standard w/Splicing | 760231506 | HD-1U-SP | ||
| 760231514 | HD-2U-SP | |||
| 760231522 | HD-4U-SP | |||
| UD - Ultra Density Premium Features | 144 LC/RU 48 MPO/RU |
Premium Sliding | 760227306 | UD-2U |
| 760227314 | UD-4U |
G2 Modules
CommScope's Ultra Low Loss (ULL) solution, the G2 module, supports higher speeds over longer distances allowing you to meet the loss budgets of today's ULL links and offer the reliability of the CommScope Application Assurance Guarantee.
- Factory tested to 0.35 dB IL multimode and 0.60 dB singlemode
- The G2 modules are backwards compatible with previous hardware such as the InstaPATCH® 360 and SYSTIMAX 360™ G2 fiber panels.
Image: A G2 module, model 360CM12-2x3-LS, showing its compact form factor and connectors.
G2 MODULES - ULTRA LOW LOSS SOLUTIONS METHOD B ENHANCED
| MPO 8 - 24 Fiber | MPO 12 - 12 Fiber | MPO 12 - 24 Fiber | MPO 24 - 24 Fiber | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Material ID | Description | Material ID | Description | Material ID | Description | Material ID | Description | ||
| 760236108 | DM08-24LC-LS-ULL | 760238838 | DM12-12LC-LS-ULL | 760236110 | DM12-24LC-LS-ULL | 760236112 | DM24-24LC-LS-ULL | ||
| LC Multimode (OM3-OM4) | 760236109 | DM08-24LC-WB-ULL | 760238839 | DM12-12LC-WB-ULL | 760236111 | DM12-24LC-WB-ULL | 760236113 | DM24-24LC-WB-ULL | |
| LC Multimode (OM5) | 760238082 | DM08-24LC-SM-ULL | 760238837 | DM12-12LC-SM-ULL | 760238083 | DM12-24LC-SM-ULL | X | X | |
| LC Singlemode UPC | |||||||||
G2 Splice Cassettes With and Without Pigtails
Adds and changes to an existing network can be challenging. The G2 splice cassette simplifies adds and changes while increasing the flexibility of the entire G2 portfolio by enabling in-panel splicing without the need for a separate splice panels or trays.
- Available in 12 and 24 fiber (LC and SC).
- Supports both stranded and rollable ribbon. Available for multiple fiber types too!
- Bezels are available in multiple colors to help you easily identify fiber type for each cassette.
- Internal shutter reduces dust contamination, automatically actuates with connector insertion or removal and the shutter door illuminates with VFL when checking continuity.
Images depicting G2 splice cassettes: G2-SP-24LCG-PT and G2-SP-24LCV-PT.
G2 SPLICE CASSETTES
| Stranded | Ribbon | |||
|---|---|---|---|---|
| Material ID | Description | Material ID | Description | |
| LC Multimode (OM4) | 760244927 | G2-SP-24LCX-PT | 760244928 | G2-SP-24LCX-RPT |
| 760245399 | G2-SP-12LCX-PT | 760245400 | G2-SP-12LCX-RPT | |
| 760245398 | G2-SP-24LCV-PT | N/A | N/A | |
| LC Multimode (OM5) | 760245403 | G2-SP-12LCV-PT | N/A | N/A |
| LC UPC Singlemode | 760244929 | G2-SP-24LCG-PT | 760244930 | G2-SP-24LCG-RPT |
| 760245401 | G2-SP-12LCG-PT | 760245402 | G2-SP-12LCG-RPT | |
| LC APC Singlemode | 760245961 | G2-SP-24LAG-PT | N/A | N/A |
| 760245960 | G2-SP-12LAG-PT | N/A | N/A | |
| Empty Cassette No Fiber | 760245494 | G2-SP-24LC | N/A | N/A |
| 760245495 | G2-SP-12LC | N/A | N/A | |
| 760245497 | G2-SP-0000 | N/A | N/A | |
G2 PIGTAIL CASSETTES
| No Pigtails | Pigtails Included | |||
|---|---|---|---|---|
| Material ID | Description | Material ID | Description | |
| LC Multimode (OM3-OM4) | 760109256 | 360G2 Cartridge 12-LC-LS-AQ | 760109470 | 360G2 Cartridge 12-LC-LS-AQ-Pigtails |
| LC Singlemode UPC | 760109272 | 360G2 Cartridge 12-LC-SM-BL | 760109496 | 360G2 Cartridge 12-LC-SM-BL-Pigtails |
| LC Singlemode APC | 760109280 | 360G2 Cartridge 12-LCA-SM-GR | 760109504 | 360G2 Cartridge 12-LCA-SM-GR-Pigtails |
| SC Multimode (OM3-OM4) | 760109298 | 360G2 Cartridge 6-SC-LS-AQ | 760109512 | 360G2 Cartridge 6-SC-LS-AQ-Pigtails A |
| X | X | 760109520 | 360G2 Cartridge 6-SC-LS-AQ-Pigtails B | |
| SC Singlemode UPC | 760109314 | 360G2 Cartridge 6-SC-SM-BL | 760109553 | 360G2 Cartridge 6-SC-SM-BL-Pigtails A |
| X | X | 760109561 | 360G2 Cartridge 6-SC-SM-BL-Pigtails B | |
| SC Singlemode APC | 760109322 | 360G2 Cartridge 6-SCA-SM-GR | 760109579 | 360G2 Cartridge 6-SCA-SM-GR-Pigtails A |
| X | X | 760109587 | 360G2 Cartridge 6-SCA-SM-GR-Pigtails B | |
G2 Adapter packs
Images depicting various G2 adapter packs: 360DPis-24LC-LS, 360DP-2MPO, 360DP-4MPO, 360DP-6MPO-BK, 360DP-8MPO.
G2 ADAPTER PACKS
| 12 Fiber | 24 Fiber | |||
|---|---|---|---|---|
| Material ID | Description | Material ID | Description | |
| LC Multimode (OM3-OM4) | 760230938 | 360DPis-12LC-LS | 760216754 | 360DPis-24LC-LS |
| LC Multimode (OM5) | 760236043 | 360DPis-12LC-WB | 760236041 | 360DPis-24LC-WB |
| LC Singlemode | 760230946 | 360DPis-12LC-SM | 760216762 | 360DPis-24LC-SM |
| LC Singlemode APC | 760230961 | 360DPis-12LCA-SM | 760216770 | 360DPis-24LCA-SM |
| SC Multimode (OM3-OM4) | 760134551 | 360DP-12SC-LS | X | X |
| SC Singlemode | 760135087 | 360DP-12SC-SM | X | X |
| SC Singlemode APC | 760135095 | 360DP-12SCA-SM | X | X |
G2 MPO ADAPTER PACKS
| Material ID | Description | |
|---|---|---|
| 2 MPO | 760107490 | 360DP-2MPO |
| 4 MPO | 760107508 | 360DP-4MPO |
| 6 MPO | 760107516 | 360DP-6MPO-BK |
| 8 MPO | 760107524 | 360DP-8MPO |
G2 Wall Boxes & G2 Accessories
Wall Mount Building enclosures provide fiber distribution management when rack space is at a premium. A simple and reliable way to maximize the potential of your network while minimizing your footprint.
- Compatible with all G2 modules, splice cassettes and adapter packs, the WBE-MOD adds a flexible solution with a reduced footprint.
Images depicting G2 wall boxes and accessories: WBE-EMT-BK-4P-MOD, AGL-SPLICE-48, AGL-1U-TROUGH, 360 LP-STACK-SPT.
G2 WALLBOXES
| Density | Material ID | Description |
|---|---|---|
| 24 LC | 760245881 | WBE-EMT-BK-1P-MOD |
| 48 LC | 760164616 | WBE-EMT-BK-2P-MOD |
| 96 LC | 760060426 | WBE-EMT-BK-4P-MOD |
| 192 LC | 760164624 | WBE-EMT-BK-8P-MOD |
Note: the G2 splice cassettes are not compatible with WBE-EMT-BK-1P-MOD
G2 ACCESSORIES
| Material ID | Product Code | Description |
|---|---|---|
| AGILE Panel Accessories | ||
| 760241378 | AGL-SPLICE-48 | AGILE Splice Tray Kit |
| 760193938 | AGL-1U-TROUGH | AGILE panel 1U Jumper Management Trough |
| Panel Accessories | ||
| 760039867 | RS-2AF-16SF | RoloSplice Kit with 2 fusion splice trays for 1U and 2U rack mount, 2 and 4 port wall mount |
| 760031856 | RS-4AF-16SF | RoloSplice Kit with 4 fusion splice trays for 1U and 2U rack mount, 2 and 4 port wall mount |
| 760031054 | SW-6AF-16SF | Fusion Splice Wallet Kit with 6 splice trays for 4U rack mount and 8 port wall mount. See page 2 for reference. |
| 760148502 | 360-LP-STACK-SPT | Fusion Splice Tray Kit, stackable, large format for 1U and 2U rack mount |
| Miscellaneous | ||
| 760207944 | HD-1U-REAR-EXT | 1U Rear cable extension |
| 760239082 | SD-HD-UD-UDS2U-DOOR-LOCK-KT | Door lock kit for SD, HD, UD and UDS2U panels, including one (1) lock and one (1) key |
| 760209619 | CABLE-MOUNT-KIT-12 | Cable attachment molding x 12 |
| 760058677 | RMB-6-1/2 | InstaPATCH Plus attachment bracket, rack mounted, six 1/2" fittings |
| 760058685 | RMB-6-3/8 | InstaPATCH Plus attachment bracket, rack mounted, six 3/8" fittings |
| 760109462 | 360G2-MOD-BLANK-4PK | Mod Panel Blank Adapter Pack, 4 Panels |
| 760039875 | G2-SRF | Small Diameter Cable Entrance Kit |
| 760039883 | G2-23BRKT | Mounting Bracket |
| 760185595 | KIT, FIBER DRUM | Fiber Drum Kit (2 per kit) |
| 760238380 | BK-FP-SML | Ribbon splice cassette blocking kit for HD-1U, HD-2U and UD-2U |
| 760238381 | BK-FP-LRG | Ribbon splice cassette blocking kit for HD-4U and UD-4U |
imVision® Automated Infrastructure Management
imVision is the automated infrastructure management system that provides a holistic view of enterprise network connectivity fiber and copper, all in real time. When used in conjunction with the HD and UD panels in the G2 family, imVision shows you exactly where your assets are connected, what they're doing, and how you can get more out of them.
- Document the end-to-end paths to all IP devices, such as fiber switches, IP security cameras, high-definition audio and video equipment.
- Map fiber links between buildings.
- Can be deployed as part of the CommScope G2 HD and UD fiber panel product family, as well as with SYSTIMAX copper panels.
- Intelligent functionality can be factory-ordered for initial deployment, as shown in Figure A, or added via overlays on day 2 as depicted in Figure B.
For detailed configuration and ordering information on imVision, please download the imVision Solutions Guide.
Diagrams: Figure A and Figure B illustrating imVision deployment options. Screenshot: A visual representation of the imVision interface showing network connection details.
