User Manual for NOXION models including: Noxion, LED, Bulkhead Pro

LED Bulkhead Pro User Manual 08142020

LED Bulkhead Pro User Manual 08142020 - Noxion

LED Bulkhead Pro User Manual 08142020 Created Date: 9/1/2020 4:53:36 PM ...

LED Bulkhead Pro User Manual 08142020

• Google Docs
• Google Drive
• Download [pdf]
• Download Optimized



File Info : application/pdf, 2 Pages, 2.98MB

Document Document

Content:
1x
3x
Dimension:

1x 3x
Ø300

93

1

2

Noxion LED Bulkhead Pro

EAN

W lm

K

CRI Ta ()

V

Hz

Dim kg

8719157015257 13 1250 2700

80 -20~+35 220-240 50/60

ND

1

13 1400 3000/4000 80 -20~+35 220-240 50/60

ND

1

8719157015264 13 1250 2700

80 -20~+35 220-240 50/60

ND

1

13 1400 3000/4000 80 -20~+35 220-240 50/60

ND

1

Circuit Breaker: Item B16 C16

LF-GIF022YF0350H 18 180
13W 60pcs 104pcs
3

N

L

SL

input cable: 3x1.5mm2 (H05RN, H05RF)

4

5

6

7

8

© 2021 Noxion B.V. - All rights reserved. Data subject to change without notice. Noxion retains the right to modify product specifications without any prior notice or obligation and does not assume any liability for any consequences of using document. Subject to errors and printing errors.
Version: February 2021

Noxion B.V. Schootense Dreef 27,
5708 HZ Helmond, The Netherlands
+31 (0)85 - 303 29 82 www.noxion.com info@noxion.com Page 1 of 1

To adjust the color temperature:

Noxion LED Bulkhead Pro

Sensor Setting:

Detection Range

1

I

100%



50%

Hold Time

2

I

5S



1min

3min

Up

10min

Daylight Sensor

4

I
Down

Disable
30lux

1 234

Default Setting:
Detection area: 100% Hold time: 5s Daylight threshold disable Operating voltage: 220-240VAC, 50/60Hz Microwave power: <0.3mW

Mounting height: 2.5-5m/8.2-16.4ft (ceiling mounted) Detection range: Radius, 3-6m/9.84-19.68ft (ceiling mounted) Operating temperature: -25~+60 Motion detection: 0.5~1.5m/s Microwave frequency: 5.8GHz±75MHz

© 2021 Noxion B.V. - All rights reserved. Data subject to change without notice. Noxion retains the right to modify product specifications without any prior notice or obligation and does not assume any liability for any consequences of using document. Subject to errors and printing errors.
Version: February 2021

Noxion B.V. Schootense Dreef 27,
5708 HZ Helmond, The Netherlands
+31 (0)85 - 303 29 82 www.noxion.com info@noxion.com Page 1 of 1
