Olight Warrior Mini 2 User Manual

In the Box

• Warrior Mini 2 (with Battery)
• USB Magnetic Charging Cable
• Lanyard
• Carabiner-Style Ring

Specifications

*All specifications are test results based on ANSI/NEMA FL1-2009 Standard, performed using the included battery.

Battery Installation

Before first use, unscrew the body and remove the insulating film. If the battery needs replacement, ensure the positive end of the new battery faces the flashlight head.

Available Batteries

• 1 x customized 3500mAh 18650 rechargeable lithium battery

Battery Level Indicator

• >60%: Green Indicator
• 10~60%: Orange Indicator
• 5~10%: Red Indicator
• <5%: Indicator Blinks Red

Note: If using moonlight mode, the battery indicator will only display when the battery level is below 5%.

Charging

USB Magnetic Charging Cable -- MCC3

Before first use, please fully charge the product. Connect the USB end of the magnetic charging cable to an external USB power source, then attach the other end to the charging port. The red indicator means charging, while the green indicator means charging completed. Only charge with standard MCC3; not compatible with other MCCs.

How to Operate

Side Switch

• ON/OFF: Single click the side switch. The light returns to the previously memorized mode.
• Change Brightness Level: When the flashlight is on, press and hold the side switch. It will cycle through Low, Medium, and High modes. Release the switch to select the desired mode. (Moonlight and Turbo modes are not in this automatic cycle).
• Moonlight Mode: When the flashlight is off, press and hold the side switch for over one second to access Moonlight mode. If the memorized mode was Moonlight, a simple click will activate it.
• Turbo and Return: Fast double-click the side switch to enter Turbo mode. Double-click again to return to the previous mode. If the previous mode was High or Medium, it returns to Medium. If it was Low or Moonlight, it returns to that mode.
• Strobe: Quickly triple-click the side switch to enter Strobe mode. To quit, single-click or press and hold the side switch.
• Lockout/Unlock: When the flashlight is off, press and hold the side switch (approx. 2 seconds) to access lockout mode. The flashlight will briefly enter Moonlight mode then switch off to signal lockout. In lockout mode, pressing the side switch for less than one second will illuminate a red indicator for two seconds. To unlock, hold the side switch for over one second until Moonlight mode is active again.

Tail Switch

The flashlight offers different output settings based on how the tail switch is pressed (lightly or hard). There are two program configurations:

Configuration 1 (Factory Default Setting)

• Half press for Medium mode.
• Hard press for Turbo mode.
• Single press (press and release quickly) to turn the flashlight on or off.
• Press and hold for momentary illumination; release to turn off.

Configuration 2

• Half press for Turbo mode.
• Hard press for Strobe mode.
• Release the switch to turn the flashlight off.

Switch Between Different Program Configurations

To switch between Configuration 1 and 2, press and hold the tail switch firmly, and simultaneously single-click the side switch. Releasing the tail switch selects the configuration.

Proximity Protection Function

When the front lens proximity sensor detects an obstruction nearby, the brightness will automatically reduce. In this state, the side switch can only turn the light off. The light will turn off directly if the blockage continues for more than 60 seconds.

Attention

1. Please keep the surface of the lens clean. Stains or water mist can affect the performance of the built-in sensor, potentially causing high and above modes to fail. Clean promptly.
2. Protect the lens from scratches. Scratches reduce luminous flux and can affect internal sensor performance, leading to failure of high and above modes.

Danger

• DO NOT shine the light directly into human eyes, as this may cause temporary blindness or permanent eye damage.
• The Carabiner-Style Ring has a maximum load of 5kg; DO NOT use it for climbing.

Notice

• When the flashlight is turned off, Moonlight, Low, Medium, or High mode will be memorized and become the default mode upon next activation. (High mode is only memorized for 10 minutes; after that, it reverts to Medium).
• Turbo mode will slowly step down to High mode in 4 minutes at normal temperature.
• DO NOT short-circuit the tail switch cap with the surrounding ring. This can cause weak electric discharge and potentially complete battery drain if left for too long.
• The magnetic tail attracts iron debris; keep the tail switch cap and surrounding ring clean.
• The lanyard clip can only be installed in the rear clip slot.

Warning

• DO NOT repeatedly activate Turbo mode in high temperatures to prevent overheating and user injury.
• The tail switch may not function when immersed in seawater or other conductive media; keep it clean and dry.
• DO NOT use non-protected rechargeable batteries.
• DO NOT use the battery if the wrapper is broken or compromised.
• DO NOT take the battery out of the flashlight for charging.
• Handle batteries with care. If replacing a battery, keep the removed battery in a safe place and do not mix it with conductive metals.
• If the product is left unused or transported, lock the button to prevent accidental activation.

Exclusion Clause

Olight is not liable for damages or injuries sustained from product usage inconsistent with the warnings in this manual, including but not limited to using the product without engaging the recommended lockout mode.

Warranty

• Within 30 days of purchase: Contact the original seller for repair or replacement.
• Within 5 years of purchase: Contact Olight for repair or replacement.
• Battery warranty: Olight offers a one-year warranty for all rechargeable batteries.
• MCC magnetic USB charging cable: One-year warranty.
• Fragile or low-value fittings (lanyard, clip): Contact customer support within 30 days of purchase for quality issues or damage under normal use. Conditional assurance applies for issues arising after 30 days or due to abnormal use.

Customer Support

USA Customer Support: cs@olightstore.com

Global Customer Support: Customer-service@olightworld.com

Visit www.olightworld.com to see our complete product line.

EU Declaration of Conformity

Can be found here: https://olightworld.com/ec-declaration

Manufacturer Information

Dongguan Olight E-Commerce Technology Co., Ltd

4th Floor, Building 4, Kegu Industrial Park, No 6 Zhongnan Road, Changan Town, Dongguan City, Guangdong, China.

Made in China

Document Version: B. 28, 5, 2021, Model: 3.0334.6010.9002
