ST M24SR Series Dynamic NFC Tags Datasheet
File info: application/pdf · 22 pages · 1.60MB
M24SR product presentation
Extracted Text
M24SR series dynamic NFC tags MMY division Smart Things Main M24SR market segments Smart Home Smart Industry Consumer, wearable, healthcare & wellness Home appliance & automation, home gateway Networking, lighting 2 Seamless user interface simplicity � Device control with a mobile phone Servicing & maintenance � Download records history � Update parameters even if device is off Key use cases Wireless pairing "tap & connect" � Ease Bluetooth or WiFi by simple tap Convenient data logging � Data download � Data tracking 3 NFC phones RFID readers Typical NFC type 4 range ISO14443 (106kb/s) Up to 5 cm / 2in. M24SR EEPROM Up to 10cm / 4in. ISO14443 (106kb/s) Modulation more simple (ISO 15693), data rate more limited & consume less so better range M24SR EEPROM 4 M24SR product � The M24SR chip belongs to ST25 NFC / RFID Tags & Readers family. � The M24SR product is Dynamic Tag based on ISO14443 standard with following main features: � ISO14443-A NFC Forum Type 4 RF interface � I�C 1MHz interface � 2.4V to 5.5V � Up to 64-kbit EEPROM memory � 128-bit password for data protection � 200 years data retention & 1Mcycles erase/write � Configurable General Purpose Output signal for MCU wake-up � RF disable feature 5 M24SR02 / 04 / 16 / 64 RF ISO EEPROM I�C Tag 14443-A 2K / 4K / 16K / 64K-bit NFC Type 4 NDEF 2.4/5.5V 106kb/s 128-bit password 1MHz Digital output (GPO) RF disable SO8 TSSOP8 SBN12 Die form, sawn and Bumped inkless 8" wafer, 120�m/ thickness FPN8 M24SR dynamic NFC tag Use cases � Convenient wireless pairing (Bluetooth, Wi-Fi) � Dynamic data exchange with NFC phone � User settings update, information log download,... Key Features � ISO14443-A Type A and NFC Type 4 � High speed operations (106kb/s) � NDEF memory format � Data protection thanks to 128-bit password Key Benefits � Easy of use (limited BOM, 8-pin package) � Flexible interrupt pin (configurable GPO) � 200 years data retention, 1M cycles erase/write 6 Key features Contactless Interface RF range RF speed Single supply voltage Serial Interface Extra features Memory format Memory size Data retention Erase / Write cycles Data protection Temperature range Package M24SR series ISO14443-A NFC Type 4 Short range, up to 10cm 106kbps 2.4V (2.7V) to 5.5V I2C @1MHz MCU wake-up & RF Disable EEPROM preformatted NDEF file 2 / 4 / 16 / 64-kbit 200-year at +55�C 1M cycles at +25�C Password 128-bit -40�C to +85�C -40�C to +105�C for I�C operation for M24SR64 SO8 / TSSOP8 / DFN8 / SBN12 * * SBN12: Die form, sawn and Bumped wafer, 120�m thickness, inkless 8" wafer 7 Memory organization � The memory contains three types of file: � NDEF file, CC file and System file One NDEF file One CC file (1) (Capability Container) One System file (2) Wifi pairing record One text record ... One URL record M24SR memory (1) The CC file gives some information about the M24SR and the NDEF file (access conditions etc.). This file is a read-only file for the RF or I�C host and cannot be modified by issuing a write command. (2) The system file is a ST proprietary file. It can be read by the RF or I�C host and written by the I�C host. 8 � Data protection thanks to a password. Why ? � To lock an NDEF file � Password size: 128 bits � 3.4 1038 possibilities to find the right password � 2 passwords, � One for read access � One for write access � Possible to lock permanently in read or write access � 2 bytes in the CC file are used to define the Read and Write access rights to the NDEF file. Data protection Unlocked Read or Locked Write not autorized Permanent Lock 9 GPO feature � The configurable output signal (GPO) pad is mainly to wake-up or inform a micro-controller about one event. It's an open drain pad so external pull-up resistor to Vcc is required. � 7 possible configurations � Session Open � An RF or I�C session ongoing � MIP (NDEF Message updating In Progress) � RF host writing an NDEF length different from 0x0000. This mode can be used to detect when the RF host changes the NDEF message as defined by NFC Forum � WIP (Writing In Progress) � M24SR is executing a writing operation � INT (interrupt) RF disable 1 8 Vcc � RF or I�C host can force M24SR to send a negative pulse on the pin � State mode AC0 2 AC1 3 7 GPO 6 SCL � RF or I�C host can control the state of the GPO pad during the RF session � I�C ready response Vss 4 5 SDA � An I�C response is ready to be read by the I�C host � RF busy � RF host is communicating with M24SR 10 I�C interface � I�C interface is typically used for connecting M24SR to a microcontroller. It features: � Two-wires I�C serial interface supports 1MHz protocol Single supply voltage � 2.4V to 5.5V for grade G (M24SR04) � 2.7V to 5.5V for grade Y (M24SR02/04/16/64) � I�C uses only two bidirectional open-drain lines � Serial Clock (SCL) � Input signal used to strobe all data in and out of the device � Pull-up resistor must be connected from SCL to Vcc � Serial Data (SDA) � Bidirectional signal is used to transfer data in or out of the device � Pull-up resistor must be connected from SDA to Vcc RF disable 1 AC0 2 AC1 3 Vss 4 8 Vcc 7 GPO 6 SCL 5 SDA 11 RF tuning capacitance � The internal RF tuning capacitance is 25pF which is allowing antenna design from Class 1 to Class 6 form factor. Standard Main carrier frequency Data sub-carrier frequency Optimal frequency tuning Internal capacitor (measured at 0.5V) Recommended internal capacitor value for antenna design M24SR ISO14443 13.56MHz + 848kHz 14MHz � 14.4MHz 25pF 27pF 12 M24SR packages � SO8N Package � 4.9 x 3.9 mm RF disable AC0 AC1 Vss 1 8 2 3 SO8 7 6 4 5 Vcc GPO SCL SDA � TSSOP8 Package - 3.0 x 4.4 mm RF disable AC0 AC1 Vss 1 8 2 3 TSSOP8 7 6 4 5 Vcc GPO SCL SDA � UFDFPN8 Package - 2 x 3 mm Vout 1 8 Vcc 1 8 AC0 AC1 2 3 UFDFPN8 7 6 RF WIP / BUSY SCL 2 3 7 6 Vss 4 5 SDA 4 5 Top view Bottom view � Sawn & Bumped for wafer SBN12 * * : sawn and bumped inkless 8" wafer, 120�m thickness (for M24LR04E and 64E) Bump Signal name 1 RF disable 2 AC0 3 AC1 4 Vss 5 SDA 6 SCL 7 GPO 8 Vcc 13 M24SR rich eco-system � Discovery kits based on STM32 MCU � STM32 Nucleo boards ecosystem � STM32Cube software ecosystem � Antenna e-design tool � Schematic and BOM � Gerber files � Android ST25 NFC tap app � PC software tool � MCU drivers firmware � Documentation � e2e community � Webinar / MOOC � Training 14 M24SR part numbers M24SR Dynamic NFC Type 4 Tag ISO14443-A I2C IF + GPO + RF disable + Extended Temperature Package SO8 TSSOP8 UFDFPN8 SBN12 SO8 TSSOP8 2k-bit M24SR02-YMN6T/2 M24SR02-YDW6T/2 M24SR02-YMC6T/2 M24SR02-YSG12l/2 4k-bit M24SR04-YMN6T/2 M24SR04-YDW6T/2 M24SR04-YMC6T/2 M24SR04-GSG12l/2 16k-bit M24SR16-YMN6T/2 M24SR16-YDW6T/2 M24SR16-YMC6T/2 64k-bit M24SR64-YMN6T/2 M24SR64-YDW6T/2 M24SR64-YMC6T/2 M24SR64-YSG12l/2 M24SR64-YMN8T/2 M24SR64-YDW8T/2 15 Evaluation boards M24SR evaluation boards M24SR-DISCO-PREM M24SR discovery kit � M24SR64 Dynamic NFC Tag IC � 30x30mm 5 turns double layer antenna � STM32F1 MCU � LCD Color display + Joystick + LEDs � USB & JTAG connectors � BT / Audio module with audio headset X-NUCLEO-NFC01A1 M24SR Nucleo Shield � M24SR64 Dynamic NFC Tag IC � 31x30mm 5 turns double layer antenna � Compatible with STM32 Nucleo boards � I2C interface to MCU through ArduinoTM connector � Open drain output for MCU wake-up ANT7-T-M24SR64 M24SR Tiny antenna � M24SR64 Dynamic NFC Tag IC � 14x14mm dual layer antenna � I2C test points to connect to MCU � GPO open drain user configurable output to indicate an ongoing RF operation 17 � M24SR evaluation and demonstration board � M24SR64 dynamic NFC tag IC � 30x30mm 5 turns double layer antenna � STM32F1 micro-controller � LCD color display + Joystick + LEDs � USB & JTAG connectors � BT / audio module with audio headset � Reference: M24SR-DISCO-PREM M24SR discovery kit http://www.st.com/web/en/catalog/tools/PF259659 18 � M24SR Nucleo board for fast prototyping � M24SR64 dynamic NFC tag IC � 31x30mm 5 turns double layer antenna � Compatible with STM32 Nucleo boards � I2C interface to MCU through Arduino connector � Open drain output for MCU wake-up � Powered through the Arduino UNO R3 connector � 3 general purpose color LEDs � Reference: X-NUCLEO-NFC01A1 M24SR Nucleo shield http://www.st.com/web/en/catalog/tools/PF260759 19 ANT7-T-M24SR antenna board � ANT7-T-M24SR antenna reference board is a ready-to-use PCB that features a M24SR64-Y dynamic NFC tag. � M24SR64-Y dynamic NFC tag � 14 mm x 14 mm, 13.56 MHz dual layer etched antenna � I2C test points to connect to MCU � Open drain user configurable output to indicate an ongoing RF operation (GPO) � Digital RF disable input (DIS) � Reference: ANT7-T-M24SR http://www.st.com/content/st_com/en/products/evaluation-tools/product-evaluation-tools/st25-nfc-rfid-eval-boards/st25-nfc-rfid-eval-boards/ant7-t-m24sr64.html Link does not work 20 Solutions for NFC / RFID Tags & Readers ST25 SIMPLY MORE CONNECTED Thank you � STMicroelectronics - All rights reserved. ST logo is a trademark or a registered trademark of STMicroelectronics International NV or its affiliates in the EU and/or other countries. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other product or service names are the property of their respective owners.
