Motherboard

PRIME H510M-E

E17773 First Edition January 2021 Copyright © 2021 ASUSTeK COMPUTER INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. ("ASUS"). Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. ASUS PROVIDES THIS MANUAL "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners' benefit, without intent to infringe.
ii

Contents
Safety information...................................................................................................... iv About this guide.......................................................................................................... v Package contents....................................................................................................... vi PRIME H510M-E specifications summary................................................................ vi Connectors with shared bandwidth .......................................................................... x

Chapter 1

Product Introduction

1.1 Before you proceed...................................................................................... 1-1

1.2 Motherboard overview ................................................................................. 1-1

1.3 Central Processing Unit (CPU).................................................................... 1-8

1.4 System memory............................................................................................ 1-9

Chapter 2

BIOS Information

2.1 Knowing BIOS............................................................................................... 2-1

2.2 BIOS Setup program .................................................................................... 2-2

2.3 ASUS EZ Flash 3........................................................................................... 2-3

2.4 ASUS CrashFree BIOS 3.............................................................................. 2-4

Appendix Notices ..................................................................................................................... A-1 Warranty................................................................................................................... A-6 ASUS contact information...................................................................................... A-8

iii

Safety information Electrical safety
· To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.
· When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.
· Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.
· Seek professional assistance before using an adapter or extension cord. These devices could interrupt the grounding circuit.
· Ensure that your power supply is set to the correct voltage in your area. If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.
· If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.
Operation safety
· Before installing the motherboard and adding components, carefully read all the manuals that came with the package.
· Before using the product, ensure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.
· To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.
· Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may be exposed to moisture.
· Place the product on a stable surface. · If you encounter technical problems with the product, contact a qualified service
technician or your retailer. · Your motherboard should only be used in environments with ambient temperatures
between 0°C and 40°C.
iv

About this guide
This user guide contains the information you need when installing and configuring the motherboard.
How this guide is organized
This guide contains the following parts: · Chapter 1: Product Introduction
This chapter describes the features of the motherboard and the new technology it supports. It includes descriptions of the switches, jumpers, and connectors on the motherboard. · Chapter 2: BIOS Information This chapter tells how to boot into the BIOS, and upgrade BIOS using the EZ Flash Utility.
Where to find more information
Refer to the following sources for additional information and for product and software updates. 1. ASUS website
The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. 2. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer. These documents are not part of the standard package.
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual.
CAUTION: Information to prevent damage to the components and injuries to yourself when trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
v

Package contents
Check your motherboard package for the following items.

Motherboard Cables Miscellaneous
Application DVD Documentation

1 x PRIME H510M-E motherboard 2 x SATA 6Gb/s cables 1 x I/O Shield 1 x M.2 SSD screw package 1 x Support DVD 1 x User manual

If any of the above items is damaged or missing, contact your retailer.

PRIME H510M-E specifications summary

CPU Chipset Memory
Graphics Expansion Slots

Intel® Socket LGA1200 for 11th Gen Intel® CoreTM Processors & 10th Gen Intel® CoreTM, Pentium® Gold and Celeron® Processors*
Supports Intel® 14 nm CPU
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to www.asus.com for CPU support list. ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Intel® H510 Chipset 2 x DIMM, Max. 64GB, DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz
Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * 10th Gen Intel® CoreTM i7/i9 processors support 2933/2800/2666/2400/2133 natively,
others will run at the maximum transfer rate of DDR4 2666MHz. * 11th Gen Intel® processors support 2933/2800/2666/2400/2133 natively. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and
memory frequency support depends on the CPU types.
1 x DisplayPort 1.4**
1 x D-Sub
1 x HDMITM 2.0***
* Graphics specifications may vary between CPU types. ** Intel® 11th & 10th Gen processors support DisplayPort 1.4 with max. resolution of
4096 x 2304 @60Hz. Please refer to www.intel.com for any updates. ***Only Intel® 11th Gen processors support HDMITM 2.0 with max. resolution of
4K@60Hz, others will only support HDMITM 1.4 with max. resolution of 4K@30Hz. Please refer to www.intel.com for any updates.
Intel® 11th & 10th Gen Processors
1 x PCIe 4.0/3.0 x16 slot
- Intel® 11th Gen processors support PCIe 4.0 x16
- Intel® 10th Gen processors support PCIe 3.0 x16
Intel® H510 Chipset
2 x PCIe 3.0 x1 slots

(continued on the next page) vi

PRIME H510M-E specifications summary

Storage Ethernet USB
Audio
Back Panel I/O Ports
Internal I/O Connectors

Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports Intel® H510 Chipset M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) 4 x SATA 6Gb/s ports * The M.2 slot shares bandwidth with the SATA6G_2 port. When a device in SATA
mode is installed on the M.2 socket, the SATA6G_2 port cannot be used. 1 x Intel® I219-V 1Gb Ethernet Rear USB (Total 4 ports) 2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 6 ports) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Realtek ALC 897/887 7.1 Surround Sound High Definition Audio
CODEC* - Supports: Jack detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Premium Japanese audio capacitors - Dedicated audio PCB layers * A chassis with an HD audio module in the front panel is required to support 7.1
Surround Sound audio output. 2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x D-Sub port 1 x HDMITM port 1 x Intel® I219-V 1Gb Ethernet port 3 x Audio jacks 1 x PS/2 Keyboard (purple) port 1 x PS/2 Mouse (green) port Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin Chassis Fan header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports

(continued on the next page)

vii

PRIME H510M-E specifications summary

Internal I/O Connectors

Miscellaneous 1 x RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header 1 x Speaker header 1 x SPI TPM header (14-1pin) 1 x 10-1 pin System Panel header ASUS 5X PROTECTION III
- DIGI+ VRM - LANGuard - Overvoltage Protection - SafeSlot Core - Stainless-Steel Back I/O

Special Features

ASUS Q-Design - Q-DIMM - Q-Slot
ASUS Thermal Solution - Aluminum heatsink design

Software Features

ASUS Lighting Control - RGB header
ASUS Exclusive Software Armoury Crate AI Suite 3
- Performance And Power Saving Utility TurboV EVO EPU DIGI+ VRM Fan Xpert
- EZ update ASUS CPU-Z AI Charger DAEMON Tools Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY
- ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode

(continued on the next page)

viii

PRIME H510M-E specifications summary

BIOS

128 Mb Flash ROM, UEFI AMI BIOS

Manageability Operating System
Form Factor

WOL by PME, PXE
Windows® 10 64-bit mATX Form Factor 8.9 inch x 8.3 inch (22.6 cm x 21.1 cm)

Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications.

Connectors with shared bandwidth

KBMS
HDMI

ATX_12V

DIGI+

CPU_FAN

VRM

VGA

ATX_PWR

DDR4 DIMM_A1* (64bit, 288-pin module) DDR4 DIMM_B1* (64bit,288-pin module)

U32G1_34

LGA1200

LAN_USB914
A

CHA_FAN

AUDIO

2280

2260

2242

Ethernet

PCIEX16

Audio CODEC

PCIEX1_1

Super I/O

SPDIF_OUT

PCIEX1_2

AAFP

COM_DEBUG COM RGB_HEADER
CLRTC

BATTERY USB78 USB56

M.2(SOCKET3)

PCIE SATA IRST

3.0 X4 V

SATA6G_1
A

SATA6G_3 SATA6G_2

Intel® H510

128Mb BIOS

TPM

SATA6G_4 SPEAKER

F_PANEL

U32G1_12

Configuration M.2
A SATA6G_2

1 PCIe x4
V

2 SATA
-

· The M.2 slot shares bandwidth with the SATA6G_2 port.
· When a device in SATA mode is installed on the M.2 socket, the SATA6G_2 port cannot be used.

Chapter 1: Product Introduction

Product Introduction

1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change any motherboard settings.

· Unplug the power cord from the wall socket before touching any component.
· Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.
· Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.

1.2

Motherboard overview

21.1cm(8.3in)

KBMS
HDMI

ATX_12V

DIGI+

CPU_FAN

VRM

VGA

DDR4 DIMM_A1* (64bit, 288-pin module) DDR4 DIMM_B1* (64bit,288-pin module)

Place this

side towards

ATX_PWR

the rear of the

chassis

U32G1_34

LGA1200

22.6cm(8.9in)

LAN_USB914

CHA_FAN

4
AUDIO

2280

2260

2242

Ethernet

PCIEX16

3
Audio CODEC

PCIEX1_1

Super I/O

SPDIF_OUT

PCIEX1_2

AAFP

COM_DEBUG COM RGB_HEADER
CLRTC

BATTERY USB78 USB56

14 13 12 10 11

M.2(SOCKET3)

PCIE SATA IRST

3.0 X4 V

SATA6G_1
7

SATA6G_3 SATA6G_2

Intel® H510

128Mb BIOS

TPM

SATA6G_4 SPEAKER

F_PANEL

16 15

U32G1_12

Unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components.

ASUS PRIME H510M-E

1-1

1.2.1 Layout contents
1. CPU socket The motherboard comes with a LGA1200 socket designed for 11th Gen Intel® CoreTM Processors & 10th Gen Intel® CoreTM, Pentium® Gold and Celeron® Processors.
For more details, refer to Central Processing Unit (CPU).

2. DDR4 DIMM slots
The motherboard comes with Dual Inline Memory Modules (DIMM) slots designed for DDR4 (Double Data Rate 4) memory modules.

For more details, refer to System memory.

3. Expansion slots
This motherboard supports one PCIe x16 graphics card and two PCIe 3.0 x1 network cards, SCSI cards and other cards that comply with the PCI Express specification.

4. Fan headers The Fan headers allow you to connect fans to cool the system.

FAN PWM FAN IN
FAN PWR GND

5. Power connectors These Power connectors allow you to connect your motherboard to a power supply. The power supply plugs are designed to fit in only one orientation. Find the proper orientation and push down firmly until the power supply plugs are fully inserted.
Ensure to connect the 8-pin power plug.
· For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12V Specification 2.0 (or later version) and provides a minimum power of 350W.
· We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate.
· If you are uncertain about the minimum power supply requirement for your system, we recommend you to refer to online resources for Power Supply Wattage Calculator.
6. M.2 slot (Key M) The M.2 slot allows you to install an M.2 device such as an M.2 SSD module.
· The M.2 slot supports PCIE 3.0 x4 and SATA modes M Key design and type 2242/2260/2280 storage devices.
· The M.2 slot shares bandwidth with the SATA6G_2 port. When a device in SATA mode is installed on the M.2 socket, the SATA6G_2 port cannot be used.

1-2

Chapter 1: Product Introduction

7. SATA 6Gb/s connectors
The SATA 6Gb/s connectors allow you to connect SATA devices such as optical disc drives and hard disk drives via SATA cables.

8. USB 3.2 Gen 1 header The USB 3.2 Gen 1 header allows you to connect a USB 3.2 Gen 1 module for additional USB 3.2 Gen 1 ports. The USB 3.2 Gen 1 header provides data transfer speeds of up to 5 Gb/s.
The USB 3.2 Gen 1 module is purchased separately.

USB3+5V IntA_P2_SSRXIntA_P2_SSRX+
GND IntA_P2_SSTXIntA_P2_SSTX+
GND IntA_P2_DIntA_P2_D+

PIN 1 USB3+5V IntA_P1_SSRXIntA_P1_SSRX+ GND IntA_P1_SSTXIntA_P1_SSTX+ GND IntA_P1_DIntA_P1_D+ GND

USB+5V USB_P5USB_P5+ GND NC

9. USB 2.0 headers The two USB 2.0 headers allow you to connect USB modules for additional USB 2.0 ports. The USB 2.0 headers provide data transfer speeds of up to 480 Mb/s.
DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard!
PIN 1
The USB 2.0 module is purchased separately.

USB+5V USB_P6USB_P6+
GND

10. RGB header The RGB header allows you to connect RGB LED strips.
The RGB header supports 5050 RGB multi-color LED strips (12V/G/R/B), with a maximum power rating of 3A (12V), and no longer than 3m.

Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.

· Actual lighting and color will vary with LED strip.
· If your LED strip does not light up, check if the RGB LED extension cable and the RGB LED strip are connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard.
· The LED strip will only light up when the system is powered on. · The LED strip is purchased separately.

11. Clear CMOS header

This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords.

To erase the RTC RAM:

CLRTC

+3V_BAT GND

1. Turn OFF the computer and unplug the power cord.

2. Use a metal object such as a screwdriver to short the two pins.

3. Plug the power cord and turn ON the computer.

PIN 1

4. Hold down the <Del> key during the boot process and enter BIOS setup to reenter data.

ASUS PRIME H510M-E

1-3

If the steps above do not help, remove the onboard battery and short the two pins again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery.

RXD DTR DSR CTS

12. COM Port header

COM

This header is for a serial (COM) port. Connect the serial port module cable to

this header, then install the module to a slot opening at the back of the system

chassis.

PIN 1

DCD TXD GND RTS
RI

13. Front panel audio header
This header is for a chassis-mounted front panel audio I/O module that supports HD audio standard. Connect one end of the front panel audio I/O module cable to this header.

AGND NC SENSE1_RETUR SENSE2_RETUR

· We recommend that you connect a high-definition front panel
audio module to this header to avail of the motherboard's high- AAFP definition audio capability.

PORT1 L PORT1 R PORT2 R SENSE_SEND PORT2 L

· If you want to connect a high-definition front panel audio module to this header, set the Front Panel Type item in the BIOS setup to [HD Audio]. By default, this header is set to [HD
Audio].

HD-audio-compliant pin definition

14. S/PDIF Out header
This header is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect the S/PDIF Out module cable to this header, then install the module to a slot opening at the back of the system chassis.

+5V SPDIFOUT GND

SPDIF_OUT

15. Speaker header
The 4-pin header is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.

SPEAKER

+5V GND GND Speaker Out

F_SPI_HOLD#_R T_SPI_MISO F_SPI_CS0#_R +3V_SPI F2_SPI_CS1#_R S_PLTRST# VCCSPI

PIN 1
16. SPI TPM header This header supports a Trusted Platform Module (TPM) system with a Serial Peripheral Interface (SPI), allowing you to securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance
PIN 1
network security, protects digital identities, and ensures platform integrity. TPM
The SPI TPM module is purchased separately.

T_SPI_MOSI T_SPI_CLK GND
F_BIOS_WP#_R S_SPI_TPM_CS2# S_SPI_TPM_IRQ#

1-4

Chapter 1: Product Introduction

17. 10-1 pin System Panel header
This header supports several chassis-mounted functions.
· System power LED (2-pin +PWR_LED-)
This 2-pin header is for the system power LED. Connect the chassis power LED cable to this header. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
· Hard disk drive activity LED (2-pin +HDD_LED-)
This 2-pin header is for the HDD Activity LED. Connect the HDD Activity LED cable to this header. The HDD LED lights up or flashes when data is read from or written to the HDD.
· Power button/Soft-off button (2-pin PWR_BTN)
This header is for the system power button.
· Reset button (2-pin RESET)

HDD_LED+ HDD_LED-
Ground HWRST#
(NC)

PWR_LED+ PWR_LEDPWR GND

F_PANEL
+PWR_LED- PWR_BTN
PIN 1
+HDD_LED- RESET

This 2-pin header is for the chassis-mounted reset button for system reboot without turning off the system power.

ASUS PRIME H510M-E

1-5

1.2.2 Rear panel connectors

1. PS/2 Mouse port (green). This port is for a PS/2 mouse.
2. Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other VGA-compatible devices.
3. USB 3.2 Gen 1 (up to 5Gbps) ports. These 9-pin Universal Serial Bus (USB) ports connect to USB 3.2 Gen 1 devices.
4. Ethernet port. This port allows Gigabit connection to a Local Area Network (LAN) through a network hub. Refer to the table below for the Ethernet port LED indications.

Ethernet port LED indications

Activity Link LED

Status

Description

OFF

No link

ORANGE

Linked

BLINKING

Data activity

Speed LED

Status Description

OFF

10 Mbps connection

ORANGE 100 Mbps connection

GREEN 1 Gbps connection

ACT/LINK LED

SPEED LED

Ethernet port

5. Line In port (light blue). This port connects the tape, CD, DVD player, or other audio sources.
6. Line Out port (lime). This port connects a headphone or a speaker. In 4-channel, 5.1-channel, and 7.1-channel configurations, the function of this port becomes Front Speaker Out.
7. PS/2 Keyboard port (purple). This port is for a PS/2 keyboard.
8. HDMITM port. This port is for a High-Definition Multimedia Interface (HDMITM) connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected content.
9. DisplayPort. This port is for a DisplayPort-compatible device.
10. USB 2.0 ports. These 4-pin Universal Serial Bus (USB) ports are for USB 2.0 devices.

1-6

Chapter 1: Product Introduction

11. Microphone port (pink). This port connects a microphone. Refer to the audio configuration table for the function of the audio ports in 2, 4, 5.1, or 7.1-channel configuration.
Audio 2, 4, 5.1 or 7.1-channel configuration

Port
Light Blue (Rear panel) Lime (Rear panel) Pink (Rear panel)
Lime (Front panel)
Pink (Front panel)

Headset 2-channel
Line In Line Out
Mic In --
--

4-channel

5.1-channel

7.1-channel

Rear Speaker Out Rear Speaker Out Rear Speaker Out

Front Speaker Out Front Speaker Out Front Speaker Out

Mic In

Bass/Center

Side Speaker Out*/ Headphone

Mic In* / Side Speaker Out

* Multi-streaming is disabled by default, and the Lime (front panel) jack may be used as Side Speaker Out. If multistreaming is enabled, the Lime (front panel) jack will support headphone, and the Pink (front panel) jack will support Side Speaker Out.
To configure a 7.1-channel audio output:
Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output.

ASUS PRIME H510M-E

1-7

1.3 Central Processing Unit (CPU)
This motherboard comes with a LGA1200 socket designed for 11th Gen Intel® CoreTM Processors & 10th Gen Intel® CoreTM, Pentium® Gold and Celeron® Processors.
Unplug all power cables before installing the CPU.
· Ensure that you install the correct CPU designed for the LGA1200 socket only. DO NOT install a CPU designed for LGA1150, LGA1151, LGA1155 and LGA1156 sockets on the LGA1200 socket.
· Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components.
· Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1200 socket.
· The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap.
Installing the CPU
1
A
B

2 3

4A D5

4
C
5
B
4

Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary.

1-8

Chapter 1: Product Introduction

1.4 System memory
This motherboard comes with two Double Data Rate 4 (DDR4) Dual Inline Memory Module (DIMM) sockets. The figure illustrates the location of the DDR4 DIMM sockets:

DIMM_A1* DIMM_B1*

Channel Channel A Channel B

Sockets DIMM_A1* DIMM_B1*

· You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation.
· Always install DIMMs with the same CAS latency. For optimal compatibility, we recommend that you install memory modules of the same version or date code (D/C) from the same vendor. Check with the retailer to get the correct memory modules.
· A DDR4 memory module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.
· The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value.
· For system stability, use a more efficient memory cooling system to support a full memory load.
· Refer to www.asus.com for the latest Memory QVL (Qualified Vendors Lists)and memory frequency support depends on the CPU types.
Recommended memory configurations

DIMM_A1*

DIMM_B1*

DIMM_A1* DIMM_B1*

ASUS PRIME H510M-E

1-9

Installing a DIMM 1
To remove a DIMM A
B

2
A

A B

1-10

Chapter 1: Product Introduction

BIOS Information

2.1

Knowing BIOS
The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboardonly BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system. The term "BIOS" in this user manual refers to "UEFI BIOS" unless otherwise specified.

BIOS (Basic Input and Output System) stores system hardware settings such as storage device configuration, overclocking settings, advanced power management, and boot device configuration that are needed for system startup in the motherboard CMOS. In normal circumstances, the default BIOS settings apply to most conditions to ensure optimal performance. DO NOT change the default BIOS settings except in the following circumstances:
· An error message appears on the screen during the system bootup and requests you to run the BIOS Setup.
· You have installed a new system component that requires further BIOS settings or update.
Inappropriate BIOS settings may result to instability or boot failure. We strongly recommend that you change the BIOS settings only with the help of a trained service personnel.
BIOS settings and options may vary due to different BIOS release versions. Please refer to the latest BIOS version for settings and options.

For more information on BIOS configurations, please refer to https://www.asus.com/support, or download the BIOS manual by scanning the QR code.

ASUS PRIME H510M-E

2-1

2.2 BIOS Setup program
Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program.
Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST). If you do not press <Delete> or <F2>, POST continues with its routines.
Entering BIOS Setup after POST To enter BIOS Setup after POST:
· Press <Ctrl>+<Alt>+<Delete> simultaneously.
· Press the reset button on the system chassis.
· Press the power button to turn the system off then back on. Do this option only if you failed to enter BIOS Setup using the first two options.
After doing either of the three options, press <Delete> key to enter BIOS.
· Ensure that a USB mouse is connected to your motherboard if you want to use the mouse to control the BIOS setup program.
· If the system becomes unstable after changing any BIOS setting, load the default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.
· If the system fails to boot after changing any BIOS setting, try to clear the CMOS and reset the motherboard to the default value.
· The BIOS setup program does not support Bluetooth devices.
BIOS menu screen The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode. You can change modes from Setup Mode in Boot menu or by pressing the <F7> hotkey.

2-2

Chapter 2: BIOS Information

2.3 ASUS EZ Flash 3
The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility.
Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.
To update the BIOS:
· This function can support devices such as a USB flash disk with FAT 32/16 format and single partition only.
· DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure!
1. Insert the USB flash disk that contains the latest BIOS file to the USB port. 2. Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select
ASUS EZ Flash 3 Utility and press <Enter>. 3. Press the Left/Right arrow keys to switch to the Drive field. 4. Press the Up/Down arrow keys to find the USB flash disk that contains the latest BIOS,
and then press <Enter>. 5. Press the Left/Right arrow keys to switch to the Folder field. 6. Press the Up/Down arrow keys to find the BIOS file, and then press <Enter> to perform
the BIOS update process. Reboot the system when the update process is done.

ASUS PRIME H510M-E

2-3

2.4 ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file.
Recovering the BIOS
1. Download the latest BIOS version for this motherboard from https://www.asus.com/support/.
2. Rename the BIOS file as ASUS.CAP or PH510ME.CAP and copy the renamed BIOS file to a USB flash drive.
3. Turn on the system.
4. Insert the USB flash drive containing the BIOS file to a USB port.
5. The utility automatically checks the devices for the BIOS file. When found, the utility reads the BIOS file and enters ASUS EZ Flash 3 automatically.
6. The system requires you to enter BIOS Setup to recover the BIOS setting. To ensure system compatibility and stability, we recommend that you press <F5> to load default BIOS values.
DO NOT shut down or reset the system while updating the BIOS! Doing so can cause system boot failure!

2-4

Chapter 2: BIOS Information

Appendix
Notices
FCC Compliance Information
Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA
Phone / Fax No: (510)739-3777 / (510)608-4555
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected. - Consult the dealer or an experienced radio/TV technician for help.
HDMI Compliance Statement
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

ASUS PRIME H510M-E

A-1

Compliance Statement of Innovation, Science and Economic Development Canada (ISED)
This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. CAN ICES-003(B)/NMB-003(B)
Déclaration de conformité de Innovation, Sciences et Développement économique Canada (ISED)
Le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. CAN ICES-003(B)/NMB-003(B)
VCCI: Japan Compliance Statement Class B ITE
Japan JATE
LAN
KC: Korea Warning Statement

A-2

Appendices

GoogleTM License Terms
Copyright© 2021 Google Inc. All Rights Reserved. Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at: http://www.apache.org/licenses/LICENSE-2.0 Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.
Declaration of compliance for product environmental regulation
ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements. Please refer to http://csr.asus.com/Compliance.htm for information disclosure based on regulation requirements ASUS is complied with:
EU REACH and Article 33 Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.
EU RoHS This product complies with the EU RoHS Directive. For more details, see http://csr.asus.com/english/article.aspx?id=35
India RoHS This product complies with the "India E-Waste (Management) Rules, 2016" and prohibits use of lead, mercury, hexavalent chromium, polybrominated biphenyls (PBBs) and polybrominated diphenyl ethers (PBDEs) in concentrations exceeding 0.1% by weight in homogenous materials and 0.01% by weight in homogenous materials for cadmium, except for the exemptions listed in Schedule II of the Rule.
Vietnam RoHS ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. Các sn phm ASUS bán ti Vit Nam, vào ngày 23 tháng 9 nm2011 tr v sau, u phi áp ng các yêu cu ca Thông t 30/2011/TT-BCT ca Vit Nam.
Turkey RoHS AEEE Yönetmeliine Uygundur

ASUS PRIME H510M-E

A-3

ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in different regions.
DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.
Regional notice for California
WARNING
Cancer and Reproductive Harm www.P65Warnings.ca.gov

A-4

Appendices

English ASUSTeK Computer Inc. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of related Directives. Full text of EU declaration of conformity is available at: www.asus.com/support
Français AsusTek Computer Inc. déclare par la présente que cet appareil est conforme aux critères essentiels et autres clauses pertinentes des directives concernées. La déclaration de conformité de l'UE peut être téléchargée à partir du site Internet suivant : www.asus.com/support
Deutsch ASUSTeK Computer Inc. erklärt hiermit, dass dieses Gerät mit den wesentlichen Anforderungen und anderen relevanten Bestimmungen der zugehörigen Richtlinien übereinstimmt. Der gesamte Text der EUKonformitätserklärung ist verfügbar unter: www.asus.com/support
Italiano ASUSTeK Computer Inc. con la presente dichiara che questo dispositivo è conforme ai requisiti essenziali e alle altre disposizioni pertinenti con le direttive correlate. Il testo completo della dichiarazione di conformità UE è disponibile all'indirizzo: www.asus.com/support
ASUS , . , , www.asus.com/support
ASUSTeK Computer Inc. , . : www.asus.com/support
Hrvatski ASUSTeK Computer Inc. ovim izjavljuje da je ovaj ureaj sukladan s bitnim zahtjevima i ostalim odgovarajuim odredbama vezanih direktiva. Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support
Cestina Spolecnost ASUSTeK Computer Inc. tímto prohlasuje, ze toto zaízení spluje základní pozadavky a dalsí píslusná ustanovení souvisejících smrnic. Plné znní prohlásení o shod EU je k dispozici na adrese: www.asus.com/support
Dansk ASUSTeK Computer Inc. erklærer hermed, at denne enhed er i overensstemmelse med hovedkravene og andre relevante bestemmelser i de relaterede direktiver. Hele EU-overensstemmelseserklæringen kan findes på: www.asus.com/support
Nederlands ASUSTeK Computer Inc. verklaart hierbij dat dit apparaat voldoet aan de essentiële vereisten en andere relevante bepalingen van de verwante richtlijnen. De volledige tekst van de EU-verklaring van conformiteit is beschikbaar op: www.asus.com/support
Eesti Käesolevaga kinnitab ASUSTeK Computer Inc, et see seade vastab asjakohaste direktiivide oluliste nõuetele ja teistele asjassepuutuvatele sätetele. EL vastavusdeklaratsiooni täielik tekst on saadaval järgmisel aadressil: www.asus.com/support
Suomi ASUSTeK Computer Inc. ilmoittaa täten, että tämä laite on asiaankuuluvien direktiivien olennaisten vaatimusten ja muiden tätä koskevien säädösten mukainen. EU-yhdenmukaisuusilmoituksen koko teksti on luettavissa osoitteessa: www.asus.com/support
, AsusTek Computer Inc. . : www.asus.com/support
Magyar Az ASUSTeK Computer Inc. ezennel kijelenti, hogy ez az eszköz megfelel a kapcsolódó Irányelvek lényeges követelményeinek és egyéb vonatkozó rendelkezéseinek. Az EU megfelelségi nyilatkozat teljes szövege innen letölthet: www.asus.com/support
Latviski ASUSTeK Computer Inc. ar so pazio, ka s ierce atbilst saistto Direktvu btiskajm prasbm un citiem citiem saistosajiem nosacjumiem. Pilns ES atbilstbas paziojuma teksts pieejams seit: www.asus.com/support
Lietuvi ,,ASUSTeK Computer Inc." siuo tvirtina, kad sis renginys atitinka pagrindinius reikalavimus ir kitas svarbias susijusi direktyv nuostatas. Vis ES atitikties deklaracijos tekst galima rasti: www.asus.com/support
Norsk ASUSTeK Computer Inc. erklærer herved at denne enheten er i samsvar med hovedsaklige krav og andre relevante forskrifter i relaterte direktiver. Fullstendig tekst for EU-samsvarserklæringen finnes på: www.asus.com/support
Polski Firma ASUSTeK Computer Inc. niniejszym owiadcza, e urzdzenie to jest zgodne z zasadniczymi wymogami i innymi wlaciwymi postanowieniami powizanych dyrektyw. Pelny tekst deklaracji zgodnoci UE jest dostpny pod adresem: www.asus.com/support
Português A ASUSTeK Computer Inc. declara que este dispositivo está em conformidade com os requisitos essenciais e outras disposições relevantes das Diretivas relacionadas. Texto integral da declaração da UE disponível em: www.asus.com/support

Român ASUSTeK Computer Inc. declar c acest dispozitiv se conformeaz cerinelor eseniale i altor prevederi relevante ale directivelor conexe. Textul complet al declaraiei de conformitate a Uniunii Europene se gsete la: www.asus.com/support
Srpski ASUSTeK Computer Inc. ovim izjavljuje da je ovaj ureaj u saglasnosti sa osnovnim zahtevima i drugim relevantnim odredbama povezanih Direktiva. Pun tekst EU deklaracije o usaglasenosti je dostupan da adresi: www.asus.com/support
Slovensky Spolocnos ASUSTeK Computer Inc. týmto vyhlasuje, ze toto zariadenie vyhovuje základným poziadavkám a ostatým príslusným ustanoveniam príslusných smerníc. Celý text vyhlásenia o zhode pre státy EÚ je dostupný na adrese: www.asus.com/support
Slovenscina ASUSTeK Computer Inc. izjavlja, da je ta naprava skladna z bistvenimi zahtevami in drugimi ustreznimi dolocbami povezanih direktiv. Celotno besedilo EU-izjave o skladnosti je na voljo na spletnem mestu: www.asus.com/support
Español Por la presente, ASUSTeK Computer Inc. declara que este dispositivo cumple los requisitos básicos y otras disposiciones pertinentes de las directivas relacionadas. El texto completo de la declaración de la UE de conformidad está disponible en: www.asus.com/support
Svenska ASUSTeK Computer Inc. förklarar härmed att denna enhet överensstämmer med de grundläggande kraven och andra relevanta föreskrifter i relaterade direktiv. Fulltext av EU-försäkran om överensstämmelse finns på: www.asus.com/support
ASUSTeK Computer Inc. , . : www.asus.com/support
Türkçe AsusTek Computer Inc., bu aygitin temel gereksinimlerle ve ilikili Yönergelerin dier ilgili koullariyla uyumlu olduunu beyan eder. AB uygunluk bildiriminin tam metni u adreste bulunabilir: www.asus.com/support
Bosanski ASUSTeK Computer Inc. ovim izjavljuje da je ovaj ureaj usklaen sa bitnim zahtjevima i ostalim odgovarajuim odredbama vezanih direktiva. Cijeli tekst EU izjave o usklaenosti dostupan je na: www.asus.com/support

ASUS PRIME H510M-E

A-5

Warranty

EN: ASUS Guarantee Information
· ASUS offers a voluntary manufacturer's Commercial Guarantee.
· ASUS reserves the right to interpret the provisions of the ASUS Commercial Guarantee.
· This ASUS Commercial Guarantee is provided independently and in addition to the statutory Legal Guarantee and in no way affects or limits the rights under the Legal Guarantee.
For all the guarantee information, please visit https://www.asus.com/support.

Garantie ASUS

· ASUS fournit une garantie commerciale en tant que garantie volontaire du fabricant.

· ASUS se réserve le droit d'interpréter et de clarifier les informations relatives à la garantie commerciale ASUS.

· Cette garantie commerciale ASUS est fournie indépendamment
et parallèlement à la garantie légale, elle n'affecte ou ne limite d'aucune façon les droits acquis par la garantie légale. Pour plus d'informations sur la garantie, consultez le site https://www.asus.com/fr/support/.

ASUS Garantieinformationen

· ASUS bietet eine freiwillige Warengarantie des Herstellers an.
· ASUS behält sich das Recht zur Auslegung der Bestimmungen in der ASUS Warengarantie vor.
· Diese ASUS Warengarantie wird unabhängig und zusätzlich zur rechtmäßigen gesetzlichen Garantie gewährt und beeinträchtigt oder beschränkt in keiner Weise die Rechte aus der gesetzlichen Garantie.

Die vollständigen Garantieinformationen finden Sie unter https://www.asus.com/de/support/.

Informativa sulla Garanzia ASUS

· ASUS offre una Garanzia Commerciale volontaria del produttore.

· ASUS si riserva il diritto di interpretare le disposizioni della Garanzia Commerciale ASUS.

· La presente Garanzia Commerciale ASUS viene fornita in modo indipendente e in aggiunta alla Garanzia Legale prevista per

legge e non pregiudica o limita in alcun modo i diritti previsti dalla Garanzia Legale.

Per tutte le informazioni sulla garanzia, visitare

https://www.asus.com/it/support.

ASUS

· ASUS .

· ASUS ASUS.

· ASUS , .

https://www.asus.com/ru/support/.

DA: ASUS garantioplysninger
· ASUS tilbyder en valgfri handelsmæssig garanti.
· ASUS forbeholder sig retten til at fortolke bestemmelserne i ASUS' handelsmæssige garanti.
· Denne handelsmæssige garanti fra ASUS tilbydes uafhængigt, som en tilføjelse til den lovbestemte juridiske garanti og den påvirker eller begrænser på ingen måde rettighederne i den juridiske garanti.
Alle garantioplysningerne kan findes på https://www.asus.com/dk/support/.
BG: ASUS
· ASUS .
· ASUS ASUS.
· ASUS . .
, , https://www.asus.com/support.

CZ: Informace o záruce spolecnosti ASUS
· Spolecnost ASUS nabízí dobrovolnou komercní záruku výrobce. · Spolecnost ASUS si vyhrazuje právo vykládat ustanovení
komercní záruky spolecnosti ASUS. · Tato komercní záruka spolecnosti ASUS je poskytována nezávisle
a jako doplnk zákonné záruky a zádným zpsobem neovlivuje ani neomezuje práva vyplývající ze zákonné záruky. Vsechny informace o záruce najdete na adrese https://www.asus.com/cz/support/.

CR: Informacije o ASUS jamstvu · ASUS dragovoljno nudi komercijalno proizvoacko jamstvo. · ASUS zadrzava prava na tumacenje odredbi ASUS komercijalnog
jamstva.
· Ovo ASUS komercijalno jamstvo daje se neovisno i kao dodatak zakonskom jamstvu i ni na koji nacin ne ogranicuje prava iz okvira zakonskog jamstva.
Sve informacije o jamstvu potrazite na https://www.asus.com/support.

DU: ASUS-garantie-informatie
· SUS biedt een vrijwillige commerciële garantie van de fabrikant. · ASUS behoudt zich het recht voor om de bepalingen van de
commerciële garantie van ASUS uit te leggen. · Deze commerciële garantie van ASUS wordt onafhankelijk en
als aanvulling op de statutaire Wettelijke garantie geboden en beïnvloedt of beperkt in geen geval de rechten onder de wettelijke garantie.
Voor alle informatie over de garantie, gaat u naar https://www.asus.com/nl/support/.

EE: Teave ASUS-e garantii kohta
· ASUS pakub vabatahtlikku tasulist tootjagarantiid.
· ASUS jätab endale õiguse tõlgendada ASUS-e tasulise garantii tingimusi.
· See ASUS-e tasuline garantii on sõltumatu lisagarantii seadusega kehtestatud garantiile ega mõjuta mingil määral seadusega kehtestatud garantiid ning seadusega kehtestatud garantii piiranguid.
Vaadake garantiiga seotud teavet veebisaidilt https://www.asus.com/ee/.

GK: ASUS
· ASUS .
· ASUS ASUS.
· ASUS .
, https://www.asus.com/gr-el/.

HUG: ASUS garanciális információk
· Az ASUS önkéntes gyártói kereskedelmi garanciát kínál. · Az ASUS fenntartja magának a jogot, hogy értelmezze az ASUS
kereskedelmi garanciára vonatkozó rendelkezéseket. · Ezt a kereskedelmi garanciát az ASUS függetlenül és a törvényes
garancia mellett nyújtja és semmilyen módon nem befolyásolja, vagy korlátozza a jogi garancia nyújtotta jogokat. A garanciára vonatkozó teljes kör információkért látogasson el a https://www.asus.com/hu/support/ oldalra.

LV: ASUS garantijas informcija
· ASUS piedv brvprtgu razotja komercilo garantiju. · ASUS patur tiesbas interprett ASUS komercils garantijas
noteikumus.
· S ASUS komercil garantija tiek piedvta neatkargi un papildus likum noteiktajai juridiskajai garantijai, un t nekdi neietekm vai neierobezo juridiskaj garantij noteikts tiesbas.
Lai iegtu informciju par garantiju, apmekljiet vietni https://www.asus.com/lv/.

LT:

Informacija apie ASUS garantij

· ASUS silo savanorisk komercin gamintojo garantij. · ASUS pasilieka teis savo nuozira aiskinti sios komercins ASUS
garantijos nuostatas.
· Si komercin ASUS garantija suteikiama nepriklausoma, be statymins teisins garantijos, ir jokiu bdu nepaveikia ar neapriboja teisins garantijos suteikiam teisi.
Nordami gauti vis informacij apie garantij, apsilankykite https://www.asus.com/lt/.

PL: Informacje o gwarancji firmy ASUS
· Firma ASUS oferuje dobrowoln gwarancj handlow producenta. · Firma ASUS zastrzega sobie prawo do interpretacji warunków
gwarancji handlowej firmy ASUS.
· Niniejsza gwarancja handlowa firmy ASUS jest udzielana niezalenie, jako dodatek do wymaganej ustawowo gwarancji prawnej i w aden sposób nie wplywa na prawa przyslugujce na mocy gwarancji prawnej ani ich nie ogranicza.
Wszelkie informacje na temat gwarancji mona znale na stronie https://www.asus.com/pl/support.

A-6

Appendices

PG: Informações de Garantia ASUS · A ASUS oferece uma Garantia Comercial voluntária do fabricante. · A ASUS reserva o direito de interpretar as disposições da
Garantia Comercial da ASUS.
· Esta Garantia Comercial da ASUS é fornecida de forma independente além da Garantia Legal estatutária e não afeta nem limita de qualquer forma os direitos estabelecidos na Garantia Legal.
Para consultar todas as informações sobre a garantia, visite https://www.asus.com/pt/support/.
RO: Informaii despre garania ASUS · ASUS ofer o garanie comercial voluntar a productorului. · ASUS îi rezerv dreptul de a interpreta prevederile garaniei
comerciale ASUS. · Aceast garanie comercial ASUS este oferit independent i în plus
fa de garania obligatorie legal i nu afecteaz sau limiteaz în niciun fel drepturile acordate conform garaniei legale. Pentru toate informaiile legate de garanie, vizitai https://www.asus.com/ro/support.
SL: Informacije o garanciji ASUS · ASUS ponuja prostovoljno trzno garancijo proizvajalca. · ASUS si pridrzuje pravico do razlage dolocb trzne garancije
druzbe ASUS. · Ta trzna garancija druzbe ASUS je na voljo neodvisno in kot
dodatek zakonsko predpisani pravni garanciji ter na noben nacin ne vpliva na pravice, ki jih zagotavlja pravna garancija, oziroma jih omejuje.
Vse informacije o garanciji najdete na spletnem mestu https://www.asus.com/support.
SK: Informácie o záruke ASUS · ASUS ponúka dobrovonú obchodnú záruku výrobcu. · ASUS si vyhradzuje právo interpretova ustanovenia obchodnej
záruky ASUS. · Táto obchodná záruka ASUS je poskytnutá nezávisle a navyse
k zákonnej záruke a v ziadnom prípade neovplyvuje ani neobmedzuje tieto práva poda tejto zákonnej záruky. Vsetky alsie informácie o záruke nájdete na https://www.asus.com/sk/support.
ES: Información de garantía de ASUS · ASUS ofrece una garantía comercial voluntaria del fabricante. · ASUS se reserva el derecho de interpretar las disposiciones de
esta garantía comercial de ASUS. · Esta garantía comercial de ASUS se proporciona de forma
independiente y adicional a la garantía estatutaria y de ninguna manera afecta a los derechos bajo la garantía legal ni los limita. Para obtener toda la información sobre la garantía, visite https://www.asus.com/ES/support/.
TR: ASUS Garanti Bilgileri · ASUS, gönüllü olarak üretici Ticari Garantisi sunar. · ASUS, ASUS Ticari Garantisinin hükümlerini yorumlama hakkini
sakli tutar. · Bu ASUS Ticari Garantisi, baimsiz olarak ve hukuki Yasal
Garanti'ye ek olarak salanir ve hiçbir ekilde Yasal Garanti kapsamindaki haklari etkilemez veya sinirlandirmaz. Tüm garanti bilgileri için lütfen https://www.asus.com/tr/support adresini ziyaret edin.
FI: ASUS-takuutiedot
· ASUS tarjoaa vapaaehtoisen valmistajan kaupallisen takuun.
· ASUS pidättää oikeuden tulkita ASUS-kaupallisen takuun ehdot.
· Tämä ASUS-kaupallinen takuu tarjotaan itsenäisesti lakisääteisen oikeudellisen takuun lisäksi eikä se vaikuta millään tavoin laillisen takuun oikeuksiin tai rajoita niitä.
Saadaksesi kaikki takuutiedot, siirry osoitteeseen https://www.asus.com/fi/support.
NW: Informasjon om ASUS-garanti
· ASUS tilbyr som produsent en frivillig kommersiell garanti.
· ASUS forbeholder seg retten til å tolke bestemmelsene i ASUS sin kommersielle garanti.
· ASUS sin kommersielle garanti gis uavhengig og i tillegg til den lovbestemte juridiske garantien, og verken påvirker eller begrenser rettighetene under den juridiske garantien på noen måte.
Du finner fullstendig informasjon om garanti på https://www.asus.com/no/support/.

SB: Informacije o ASUS garanciji · ASUS nudi dobrovoljnu proizvoacku komercijalnu garanciju. · ASUS zadrzava pravo da tumaci odredbe svoje ASUS
komercijalne garancije. · Ova ASUS komercijalna garancija daje se nezavisno, kao dodatak
zakonskoj pravnoj garanciji, i ni ka koji nacin ne utice na i ne ogranicava prava data pravnom garancijom.
Za sve informacije o garanciji, posetite https://www.asus.com/support/.
SW: ASUS garantiinformation
· ASUS erbjuder en frivillig kommersiell tillverkningsgaranti.
· ASUS förbehåller sig rätten att tolka bestämmelserna i ASUS kommersiella garanti.
· Denna kommersiella garanti från ASUS tillhandahålles separat och som tillägg till den lagstadgade garantin, och påverkar eller begränsar på intet sätts rättigheterna under den lagstadgade garantin.
För all garantiinformation, besök https://www.asus.com/se/support/.
UA: ASUS · ASUS . · ASUS
ASUS ·
' ; . : https://www.asus.com/ua/support.
MX: Garantía y Soporte Esta Garantía aplica en el país de compra. Usted acepta que en esta garantía:
· Los procedimientos de servicio pueden variar en función del país. · Algunos servicios y/o piezas de reemplazo pudieran no estar
disponibles en todos los países. · Algunos países pueden tener tarifas y restricciones que se
apliquen en el momento de realizar el servicio, visite el sitio de soporte de ASUS en https://www.asus.com/mx/support/ para ver más detalles. · Si tiene alguna queja o necesidad de un centro de reparación local o el periodo de garantía del producto ASUS, por favor visite el sitio de Soporte de ASUS en https://www.asus.com/mx/support/ para mayores detalles.
Información de contacto ASUS Esta garantía está respaldada por: ASUSTeK Computer Inc. Centro de Atención ASUS +52 (55) 1946-3663
BP: Informações de garantia ASUS Esta garantia aplica-se ao período definido pela garantia legal (90 dias) mais o período de garantia comercial oferecido pela ASUS. Por exemplo: 12M significa 12 meses de garantia no total (3 meses de garantia legal mais 9 meses de garantia contratual), 24 meses significa 24 meses de garantia no total (3 meses de garantia legal mais 21 meses de garantia contratual) e 36 meses significa 36 meses de garantia no total (3 meses de garantia legal e 33 de garantia contratual) a contar da data da garantia declarada (Data de Início da Garantia).
Para todas as informações de garantia, visite https://www.asus.com/br/support/.

ASUS PRIME H510M-E

A-7

ASUS contact information

ASUSTeK COMPUTER INC.

Address

1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan

Telephone

+886-2-2894-3447

Fax

+886-2-2890-7798

Web site

https://www.asus.com

Technical Support
Telephone Online support

+86-21-38429911 https://qr.asus.com/techserv

ASUS COMPUTER INTERNATIONAL (America)

Address

48720 Kato Rd., Fremont, CA 94538, USA

Telephone

+1-510-739-3777

Fax

+1-510-608-4555

Web site

https://www.asus.com/us/

Technical Support
Support fax Telephone Online support

+1-812-284-0883
+1-812-282-2787 https://qr.asus.com/techserv

ASUS COMPUTER GmbH (Germany and Austria)

Address

Harkortstrasse 21-23, 40880 Ratingen, Germany

Web site

https://www.asus.com/de

Online contact

https://www.asus.com/support/Product/ContactUs/ Services/questionform/?lang=de-de

Technical Support
Telephone (DE) Telephone (AT) Online support

+49-2102-5789557 +43-1360-2775461 https://www.asus.com/de/support

A-8

Appendices

References

Adobe PDF Library 15.0 Adobe InDesign 15.0 (Windows)
