Shenzhen VanTop E30T Projector: User Guide

Getting Started

This guide provides instructions for setting up and using your Shenzhen VanTop E30T projector.

Power On Option:

• Direct: When the projector is plugged into an electrical outlet, it will power on directly.
• Standby: If you select Standby, you will need to press the power button to turn the projector on. Options for power-off duration include Off, 10min, 20min, 30min, 60min, and 120min.

Scheduled Shutdown: Set the time duration for the projector to shut down automatically.

Projection Distance & Size

The recommended projection distance varies with different projection contents. Please adjust the distance between the wall screen and the projector properly as needed. Ambient darkness will improve the clarity of the projected images.

Distance Chart:

• 4.95ft (1.50m): 40 inches
• 6.56ft (2.00m): 53 inches
• 8.20ft (2.50m): 70 inches
• 9.84ft (3.00m): 80 inches
• 11.48ft (3.50m): 93 inches
• 13.12ft (4.00m): 100 inches

Zoom and Keystone Correction:

• Zoom: Use the Up/Down buttons to enlarge or reduce the image.
• Keystone Correction: Use the Up/Down buttons to correct the image shape if it appears trapezoidal.

Multimedia Connection

Connect various devices to your projector for a multimedia experience.

USB Disk/Memory Card Connection

Step 1: Insert your USB disk or memory card into the corresponding port.

Step 2: Navigate to the Homepage and select the desired category (Music, Movie, Photo, Office Suite) to access your files.

Supported Formats:

• Photo Files: JPEG, BMP, PNG
• Document Files: DOC, DOCX, XLS, XLSX, PPT, PPTX, TXT
• Video Files: AVI, MP4, MKV, FLV, MOV, RMVB, MPG, TS, VOB, SWF, NFO, DAT, TS, WMV
• Audio Files: MP3, WMA, WAV, AAC, FLAC, OGG, APE, M4A, MP2

HD Connection

Step 1: Connect your HD device to the projector using an HD cable.

Step 2: Turn on the projector and connect your HD device to the projector's HD port.

Screen Mirroring

Share your device's screen wirelessly with the projector.

For iOS System

Step 1: Go to Settings, then select WiFi Setting.

Step 2: Turn on the WiFi switch on your iOS device.

Step 3: Activate Screen Mirroring/AirPlay on your iOS device and search for the projector.

Step 4: Select "Leisure XXXX" from the searching list to connect.

Note: Successful WiFi connection is not guaranteed for all devices. Ensure your device supports WiFi mirroring.

For Android System

Step 1: Ensure your Android device supports Multi-screen/Wireless Display. Many devices offer this feature.

Step 2: Turn on the WiFi switch on your Android device.

Step 3: Go to Homepage -> Miracast to enter the interface.

Step 4: Select "Leisure XXXX" from the searching list to connect.

Note: Some mobile devices may not support screen mirroring.

Settings

Access projector settings by navigating to the Homepage and selecting Settings.

• Projection Settings: Adjust various projection parameters.
• WiFi Setting: Configure wireless network settings.
• System Setting: Manage system preferences.
• Other Settings: Access additional customization options.

Troubleshooting Guide

1. Cannot connect to Hulu, Netflix, and similar services: Due to copyright restrictions from Hulu, Netflix, and similar services, you cannot cast these services.
2. Cannot watch content from Hulu, Netflix, etc.: Please prepare a Fire TV Stick, Roku Stick, or Chromecast to watch the content.
3. Blurry Image: Adjust the focus ring and ensure the projection distance is correct.
4. Remote Unresponsive: Make sure remote points are at IR receiver directly. Do not receive IR covers. Try a new pair of AAA batteries.
5. Upside Down Images: Go to Projection Image Setting -> Projection Orientation.
6. Factory Reset: Go to System -> Update -> Restore Factory Settings.

Specifications

Regulatory Information

FCC Warning: This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.

IC Warning (Canada): This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

CE Warning (Europe): This equipment complies with the R&TTE Directive for Class B digital devices. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.

What's Included

• Projector
• Remote Control
• Power Cable
• User Manual
