Precautions
Before using this product, carefully read this manual and any manuals for compatible hardware. Retain instructions for future reference.
Safety
- Only use the AC adaptor ? and AC power cord ? included with the product. Other types may cause fire, electrical shock or malfunction.
- Do not connect the AC power cord ? to a voltage transformer or inverter. Connecting the AC power cord to a voltage transformer for overseas travel or an inverter for use in an automobile may cause heat to build up in the AC adaptor and may cause burns or a malfunction.
- Unplug the AC power cord ? from the electrical outlet ⚡ before cleaning or when you do not intend to use the product for an extended period of time.
- Keep the product out of the reach of small children. Small children may swallow small parts or may wrap the cables around themselves, which may inflict injury or cause an accident or a malfunction.
Use and Handling
- Do not swing the charging station, AC adaptor ? or the AC power cord ? around by their cables.
- Do not allow liquid or small particles to get into the product. If this happens, stop use and disconnect it from the electrical outlet ⚡ immediately.
- Do not touch the product with wet hands.
- Do not throw or drop the product or subject it to strong physical shock.
- Do not stand on or put objects on the product.
- Do not touch the ports or insert any foreign objects into the product.
- Do not let any other metal items come into contact with the connectors.
- Never disassemble or modify the product.
- Do not place this product on an unstable surface or leave on the floor.
- The product and its parts are made from metal and plastic materials. When disposing of the product, follow local regulations for the proper disposal of such materials.
Cleaning
Follow the instructions below to help prevent the product exterior from deteriorating or becoming discoloured.
- Wipe with a soft, dry cloth.
- Do not apply insecticides or other volatile substances.
- Do not place any rubber or vinyl materials on the product exterior for an extended period of time.
- Do not use solvents or other chemicals. Do not wipe with a chemically-treated cleaning cloth.
- If you see dust or foreign objects on the connectors, wipe them with a dry cloth before connecting.
Storage Conditions
- Do not expose the product to high temperatures, high humidity or direct sunlight during operation, transportation and storage.
- Do not leave the product in a car with the windows closed, particularly in hot weather.
- Do not expose the product to dust, smoke or steam.
Charging
- Connect the supplied AC power cord ? to the supplied AC adaptor ?. Then, connect the AC adaptor to the DC IN connector ? on the charging station. Make all connections before plugging in the AC power cord into an electrical outlet ⚡.
Diagram Description: Shows the AC power cord connecting to the AC adaptor, and the AC adaptor connecting to the DC IN connector on the charging station.
- Attach the wireless controller to the charging station. Align the charging terminals on the controller with the charging connector on the charging station. Press down on the controller until it clicks ✅. The light bar ? on the controller slowly blinks orange ? while the controller charges. When the controller finishes charging, the light bar turns off ⚫.
Diagram Description: Shows a wireless controller being placed onto the charging station, aligning the charging terminals with the charging connector.
To remove the controller: ⬆️ Lift the controller out of the charging station to remove it.
Charging time: It takes approximately 3 hours to charge the controller when the battery has no remaining charge.
Specifications ⚙️
| Charging Station | AC adaptor | |
|---|---|---|
| Ratings | Input 5.1 V ⎓ | Input 100-240 V~0.4 A 50/60 Hz Output 5.1 V ⎓ 2.8 A |
| External dimensions | Approx. 52 x 62 x 159 mm (w x h x d) | |
| Mass | Approx. 180 g | |
| Operating temperature | 5 °C to 35 °C | |
ℹ️ Design and specifications are subject to change without notice.
Limited Substances Information
The following table indicates the presence of hazardous substances in the product.
| Equipment Name: CHARGING STATION | Model: CFI-ZDS1 | ||||||
|---|---|---|---|---|---|---|---|
| Restricted Substance Name and Chemical Symbol | Lead (Pb) | Mercury (Hg) | Cadmium (Cd) | Hexavalent Chromium (Cr+6) | Polybrominated Biphenyls (PBB) | Polybrominated Diphenyl Ethers (PBDE) | |
| Printed circuit boards | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | |
| Housing | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | |
| Accessories (AC adaptor ?, etc.) | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | |
| Stand | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | |
| Power socket (DC Jack) | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ | ✔️ |
Notes:
- "Exceeds 0.1 wt %" and "Exceeds 0.01 wt %" indicate that the percentage content of the restricted substance exceeds the reference percentage value.
- "✔️" indicates that the percentage content of the restricted substance does not exceed the reference percentage value.
- "-" indicates that the restricted substance is an exclusion item.
Legal Information
"PlayStation" and "DualSense" are registered trademarks or trademarks of Sony Interactive Entertainment Inc.
"SONY" and "®" are registered trademarks or trademarks of Sony Corporation.
©2020 Sony Interactive Entertainment Inc.
Printed in China
