VOLUME 11, NO. 4
APRIL 1981
Copyright © 1981 Benwill Publishing Corporation, a Morgan-Grampian company
Publication Number: USPS 407-010
22 Magnetic Bubble Memory Systems Software Interfacing to µ,Ps
Commonality must not be overlooked.
25 Single-Chip Video Timer/Controller Eases Video Terminal Design
Video display systems are easily constructed using TM 990 family 16-bit µ,Cs.
.. 28 Expanding Markets For Winchester Disks
Winchester disks are now being produced in increasing quantity.
32 Thin-Film Head Increases Micro-
·
Winchester Capacity
Thin ,film head technology is taking off in 5.25" rigid
disk drives.
38 Consider Applications When Specifying Winchester Disk Drives
Examine reliability, interfacing and capacity.
50 1/4"Streaming Tape Cartridge Backs Up Winchester Drives
The more software overhead in controller firmware, the better.
53 Half-Inch Streaming Drives
Multiple speeds permit half-inch streaming drive use as a start/stop device in addition to backup.
59 Use µ,P-Controlled Stepper Motors To Improve Peripherals
Stepper-µ,Ps are disk head positioning, tape drives, X-Yplotters, optical disks and chart recorders.
64 NCC/81 Paints Industry Portrait
NCC/81 comes to Chicago this year to provide attendees a fresh portrait of the computer industry's present, and a look into the industry's future.
67 1979-1980 Index of Articles
Departments
6 Letters
72 Innovative Design
8 Speakout:
· Architecture Shuffling Distinguishes Image
Computer-Compatible Directory
Processor
10 Technology Trends
· Bubble Memories On Cassette
· RM80 Disk Modularity Improves Reliability and
· Blade Technology Makes Quiet Impact
Servicability · 400% Growth For
74 New Products
Peripherals · Will Teleprinters Break
76 Product Index
'I':
$1,500?
~
· ADA Seminars
· German Computers In
r
World War II
94 Designers' Notebook
· Up/Down Display Counter Counts Over Pos/Neg Range
· ROM Breakpoint Debugging
16 Remote Terminals
Via Logic Analyzer
~ ,
96 Advertisers' Index
Thin film technology and 5.25" hard disk drives provide higher capacity drives .
Photo courtesy of Seagate Technology Cover designed by Josh Randall
Controlled circulation paid at Long Prairie, MN 56347
Postmaster, send Form 3579 to Digital Design, 1050 Commonwealth Ave., Boston, MA 02215
APRIL 1981 Dlgltal Design 3
