Dell Thunderbolt Dock - WD19TB / WD19TBS - with Apple certification
The Dell Thunderbolt Dock WD19TB / WD19TBS was certified by Apple through an independent third-party laboratory to work with Apple USB-C hosts. Here is a guide to what you can expect to work with the Dell Thunderbolt Dock – WD19TB / WD19TBS.
Dell Thunderbolt Dock - WD19TB / WD19TBS - with Apple certification
dell-thunderbolt-dock-wd19tb-apple-certification Dell Thunderbolt Dock
NOW WITH APPLE CERTIFICATION
The Dell Thunderbolt Dock WD19TB / WD19TBS helps you stay productive whether you are working at home or in the office. Delivering up to 130W of power, the WD19TB / WD19TBS dock keeps your devices charged while supporting up to dual 4K displays or one 5K display. The WD19TB / WD19TBS dock is now certified by Apple® to work with Mac devices.
CLUTTER-FREE DESK SPACE
· Mount your WD19TB / WD19TBS dock on to a VESA compatible monitor, under a desk or on a wall to free up precious desk space.
· Install easily by attaching the optional Docking Station Mounting Kit to your Dell Thunderbolt Dock WD19TB / WD19TBS.
FLEXIBLE SETUP
· Set up your desk however you want with a longer 0.8m (approx. 31 inches) dock cable.
· Get a variety of connectivity options, from HDMI port, DisplayPort to a dedicated speaker-out port for desktop speakers.
PEACE OF MIND
· Enjoy 3 years Advanced Exchange Service1 with the option to upgrade to a 4 or 5-year warranty2.
· Secure your dock via either the T-bar or wedge shaped lock slot.
Dell Thunderbolt Dock
NOW WITH APPLE CERTIFICATION
The Dell Thunderbolt Dock WD19TB / WD19TBS with v1.0.14.1 update (which includes NVM43 firmware) was certified by Apple through an independent third-party laboratory to work with Apple USB-C hosts. Here is a guide to what you can expect to work with the Dell Thunderbolt Dock WD19TB / WD19TBS.
Apple USB-C Host
MacBook Pro, MacBook Air w/ ThunderboltTM 3 (USB-C®) ports MacBook w/ USB-C port
iPad Pro w/ USB-C port
External Displays
Up to Dual 4k @ 60Hz3 Up to Single 5k @ 60Hz Up to Single 4k @ 60Hz4
Up to Single 5k @ 60Hz4
Port Functionality Thunderbolt, USB and Ethernet USB and Ethernet USB and Ethernet5
Summary of Dell Thunderbolt Dock features available when paired with Dell PCs and Mac devices
Functionality Multi-Stream Transport (MST) support for monitors "Extended Desktops" mode Dock power button emulates system power button Dock cable LED
Power Delivery
MAC address pass-through
Wake on Dock
Wake on LAN Firmware update via system native OS (Firmware Update Utility)
Dell Commercial Laptops Yes Yes Yes Up to 130 Watts Yes Yes Yes Yes
Apple USB-C Host No (workaround required3)
No Yes Up to 90 Watts No No No No (Must be connected to a Dell Windows OS system)
Dell Docks work best with Dell laptops. The Dell Thunderbolt Dock is also compatible with notebooks from other manufacturers such as Apple, HP and Lenovo which support industry standards for Thunderbolt docking6.
For functional limitations with notebooks from other manufactures in comparison to Dell Commercial notebooks, please see this support article. For a seamless docking experience, choose a Dell Latitude, XPS or Precision.
Create a clutter-free desk with the Dell Docking Station Mounting kit
Simply attach the mounting bracket to your Dell Docking station and mount it anywhere you want -- behind a monitor, to a wall, under the desk or to any flat surface -- to maximize your desk space. Set up is easy and you get the convenience of attaching and removing the docking station whenever you want.
Jump-start your productivity.
Product availability varies by country. Contact your Dell representative or visit Dell.com to learn more. To troubleshoot Dell docks when used with Mac devices, please contact Apple. For more information, please refer to article SLN320770 on Dell.com/support.
1 Advanced Exchange Service replacement dock ships, if needed, after phone/online diagnosis. Fee charged for failure to return defective unit. See dell.com/servicecontracts. 2 For a copy of the Limited Hardware Warranty, write to Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see dell.com/warranty. 3 Refer to the Dual Monitor Setup section on Dell.com for more information on dual monitor connections through WD19TB/ WD19TBS. Dual external monitor support is not available on
MacBooks with M1 chip due to a limitation of the M1 chip. 4 Connection to the monitor should happen through DP/HDMI/USB-C port on the dock, not through the Thunderbolt port. 5 Refer to Apple support pages for the list of USB connections/devices supported by iPad Pro. 6 Dell USB-C and ThunderboltTM Docks support notebooks that have implemented USB-CTM or ThunderboltTM industry specifications. For USB-CTM functionality, non-Dell notebooks
must support USB Power Delivery 2.0 (or greater) for power delivery of up to 90W, USB 3.2 (or better) for up to 10Gbps of data transfer and DisplayPortTM Alt mode for video output. For ThunderboltTM functionality, non-Dell notebooks must support USB Power Delivery 2.0 (or greater) for power delivery of up to 90W and ThunderboltTM 3 (or better) for up to 40Gbps of video and data transfer. Power button to turn on system, MAC Address Pass-Through, Wake-on Dock and Wake-on LAN features only function on Dell Commercial notebooks. Firmware Update Utility functions with Windows OS systems. Multi-Stream Transport support for monitors (Extended Desktops) not supported on Apple PCs, Dell USB-C Docks will only display in cloned mode. Visit the support page of your non-Dell notebook to determine compatibility. © 2021 Dell Inc. or its subsidiaries. All Rights Reserved. Dell Technologies, Dell, EMC, Dell EMC and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners. ID#G21000009
