Motorbike/Bicycle Anti-Theft Alarm

Key Features:

• Triaxial Accelerometer Sensor
• 7 Levels Sensitivity
• 113 dB Loud Alarm
• SOS Emergency Help Function
• Long Standby Time
• FCC Certified (FCC ID: 2ANPS-KS-WL09C)

Product Description:

The Motorbike/Bicycle Anti-Theft Alarm is designed to protect your vehicle with its advanced features. It boasts a loud 113 dB alarm, a triaxial accelerometer sensor for accurate recognition of movement, and 7 adjustable sensitivity levels. The device also includes a SOS function for emergency situations and a long standby time. Its external cover is made of PC material and is IP55 water & dust proof. Installation is convenient using double-sided tape or cable ties.

External Structure Figure:

The device features a host unit with a cable tie hole and double-sided tape for mounting. The remote control comes in two types (WL03C and WL09C) and has buttons for Arm, Disarm, Ringtone/Switch, and Bell.

Installation Guides:

2.1 Host battery replacement and installation:

The host unit uses 3 AAA alkaline batteries. To replace or install batteries, open the bottom cover by removing the bottom screw and using a flathead screwdriver or similar tool. The host will produce a short 'Bi' sound three times to indicate it's turned on. It is recommended to remove the battery if the device will not be used for an extended period. Avoid installing in locations exposed to high temperatures to prolong battery life.

2.2 Application and Setting:

2.2.1 ARM & DISARM:

Press the Arm key on the remote control to enter ARM mode, indicated by a "Do..Le..Mi" sound followed by a 'Bi' sound. The alarm will trigger upon detecting movement. Press the Disarm key to exit ARM mode. If the alarm is active, pressing the Disarm key will stop the alarm and exit ARM mode.

2.2.2 Touch Sensivity Level, Volume, SOS setting feature:

The sensitivity has 7 levels, and the volume has 3 levels. The SOS function, off by default, can be enabled by holding the Arm key and following calibration steps. The SOS function triggers an alarm if the vehicle is tilted more than 45 degrees. Settings are retained after battery replacement, but SOS may require recalibration.

2.2.3 Bell Ringtone switching function:

Press the Ringtone/Switch key to cycle through 3 available ringtones (cannot be used in ARM mode).

2.2.4 Bell and search function:

Press the Bell key to trigger the selected ringtone to easily locate your motorbike/bicycle.

2.2.5 Remote control Learning Code:

Instructions are provided for learning the code of the first remote control and adding more remote controls. A decoding method is also available to delete all coded addresses. The host can accommodate up to 8 remote controls.

2.2.6 Battery low power indication:

A weak "Du..Du.." sound indicates low battery in the host unit. For the remote control, a dimming flashlight or reduced range indicates a low battery.

3. Operating Guides:

• Host Battery Life: 1-3 months with normal usage, approximately 6 months in standby.
• Remote Control Battery Life: WL03C uses a 27A (12V) battery; WL09C uses a CR2032 (3V) battery. Both offer over 1 year of normal usage (assuming 5 uses per day).
• Operating Environment: Temperature -20~+60 °C, Humidity R/H <80%.
• Storage Temperature: -30 °C to +70 °C.
