OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 1
Enable MIDI Control From your RODECaster Pro settings. To do this, go to: Settings> Advanced> Audio> Operations> MIDI Control
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 2
Open OBS and add however many scenes you require with the `+' button in the bottom left of the `Scenes' section
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 3
Navigate to File> Settings> Hotkeys
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 4
Create unique hotkey commands for the `Switch to scene' action for each of your scenes. For example, `Switch to scene' for Scene 1 could be: Ctrl+Alt+Shift+1, `Switch to scene' for Scene 2 could be: Ctrl+Alt+Shift+2 etc
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 5
Download, install and open MIDI Key2Key. Use link to download here: https://midikey2key.de/
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 6
Open MIDI Key2Key, go to File> New and save your new MIDI setup
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 7
Under `MIDI Devices' on the Home screen, select `RODECaster Pro MIDI' as your input device
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 8
Under the `Channel Listeners' section in the bottom right, ensure that boxes 1-8 are checked
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 9
Under the `Start/Stop Listening' section, check the `Log to Window' box and press the `Start' button
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 10
Press the soundpad on your RODECaster Pro that you would like to control the `change to Scene 1' action. You should see an action appear in the `MIDI In-log' window
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 11
In the `MIDI In-log' window, double click on the `Note On' message (the one ending in "Val=127")
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 12
In the new pop-up window, click on the blue box and press the same key-combination that you used for the `Switch to Scene' action for the scene you would like to link. For example, if you used Ctrl+Alt+Shift+1 for Scene 1, you would type this here
OBS MIDICONTROL SETUP GUIDELINES | PC

STEP 13
Repeat steps 11-13 for your remaining scenes with their matching hot-key combinations

PRO TIP: If you would prefer no audio to play when switching scenes, delete the sound on the pads you are using to control your scenes and record a snippet of silence to each. This will enable you to assign them a colour and hit them without firing off audio
