Foldable Electric Scooter User Manual

1. The Device & Accessories

This section details the components of the Foldable Electric Scooter.

The main unit is an electric scooter with handlebars, a deck, wheels, and a folding mechanism.

Vehicle Accessories

• Instructions booklet
• Screws (x4)
• Cross Screwdriver
• Charging Adapter

2. Functions

After turning on the Kick scooter, the display shows various information. This device does not support Bluetooth function.

Controls and Display

Key components include: Accelerator, Display, Signal, Brake Lever, Headlight, Charging port, Clamp, Break lights, Disc Brake, Brake compartment, Folding mechanism, Wheel motor, and Kickstand.

Display Indicators

The display features:

• Speed display
• High and low gear indicator
• Total mileage indicator
• Single mileage/total mileage display
• Electric quantity display (shows battery level with four lamps decreasing as power depletes)
• Light display (front and rear lights are always on)
• Brake display (tail light flashes when braking)
• Single mileage mark
• Electric quantity warning indicator lamp (lights up when electric quantity is less than 33V)

Mode Indicators

Powering On/Off: Long press the switch button for 3 seconds. All indicator lights will turn on, then restore default settings.

Switching Functions: Press the adjustable gear button to switch functions (e.g., to the headlight). After booting, the total mileage is displayed, and the single mileage is reset.

Speed Units: The default setting is KM/H. Switch to MPH mode by pressing the gear button three times quickly (KM/H = Kilometers per hour; MPH = Miles per hour).

Auto-Shutdown: The device will automatically shut down 10 minutes after no operation.

3. Assembling the Device

Follow these steps to assemble the scooter:

1. Straighten the steering rod, close the folding lock, and gather the handle upward.
2. Insert the provided screws into the designated holes.
3. Use the screwdriver to tighten the screws securely.
4. Press the power button for 3 seconds to turn on the device.

Power Button Functions

• To turn on the scooter: Press and hold the Power Button for 3 seconds.
• To turn on the headlight: Press the Power Button twice.
• To switch riding mode: Press the Power Button one time.
• To switch the km/h to mph: Press the Power Button three times.

4. Charging Scooter

To charge the scooter:

1. Open the charging port cover.
2. Connect the charging adapter.
3. Close the charging port cover after charging.

5. Driving Instructions

Safety First: Please wear a helmet and other protective equipment, such as knee protection.

1. Turn on the kick scooter and check if there is enough battery for your ride.
2. Stand on the pedal with one leg, then push off the ground with the other leg.
3. Once moving, place both feet on the pedal and press the accelerate button to increase speed.
4. To slow down, release the accelerate button. The energy recovery system will automatically slow the scooter. For urgent braking, press the left disc brake tightly.
5. When turning, lean your body slightly in the direction of the turn and turn the handlebar slowly.

6. Safety Instructions

• ⚠️ It is not recommended to drive in the rain.
• ✅ It is recommended to slightly bend knees to adjust to rough roads.
• Use low speed (5-10 km/h) on rough roads.
• ⚠️ Be careful not to be injured by door frames when riding indoors, such as entering rooms.
• ⚠️ While walking with a scooter, do not place your hand on the accelerate button when the power is on.
• ? Do not place backpacks or any other heavy objects on the handlebar area.
• ? It is forbidden to place one foot on the running board or on the ground.
• ? It is forbidden to ride the kick scooter on the roadway with other motor vehicles.
• ? It is forbidden to make sharp turns when riding in a residential area.
• ? It is forbidden to drive through deep puddles which exceed 2cm.
• ? The kick scooter cannot carry passengers.
• ? Do not tread on the back of the fender.
• ? Do not touch the disc brake.
• ? Do not take your hands off the handlebars while riding scooters.
• ? Do not ride the electric scooter up or down steps or jump over obstacles.

Safety Recommendations

The electric scooter is a device for entertainment and not a vehicle. However, scooters can bring certain risks when riding around. For safety concern, you must read this user manual before riding it.

When riding in a public area, you must comply with all recommendations for safety. Be aware of the possibility of collision. Violating traffic rules for pedestrians or vehicles and improper operation of the device will increase the risk of injury. The higher the speed of the electric scooter, the greater the braking distance. Emergency braking may cause higher risks, especially on a slippery road. Therefore, it is necessary to be alert all the time. Please use an appropriate speed and keep a safe distance from pedestrians and other vehicles when riding your scooter.

Be cautious of pedestrians and children when riding your scooter. Reduce your speed rate and leave enough space when passing by them.

Please strictly follow state and federal road rules while riding. Violation of the above rules may result in financial expenses, personal injury, traffic accidents, legal disputes, conflict, and other unpleasant situations. The company does not assume responsibility for any direct or joint and several liability.

All others should read this user manual before you allow them to ride your electric scooter.

Please inspect your scooter carefully each time before your use. If you find shattered parts, bad battery life, broken tires, wired sounds when turning, or other abnormal symptoms, please stop use the scooter immediately and contact customer support.

7. Fold and Transportation

Folding the Scooter

To fold the scooter:

1. Ensure the scooter is turned off.
2. Hold the front pole, release the lock lever, and lower the steering rack.
3. Position the steering rack horizontally and secure it by inserting a hook through a special ring located on the rear wheel mudguard.

Transportation

You can transfer the folded scooter with one hand.

8. Daily Maintenance and Storage

Cleaning and Storage

You can use a soft cloth with soap water to clean your scooter.

Warning: Do not use alcohol to wash your electric scooter or apply water under strong pressure. Make sure the scooter is turned off. After charging, ensure the charging port plug is reinserted to prevent electric shock or serious water damage.

When you do not use the scooter, store it in a dry, cool place. Leaving the device under the sun can cause rapid damage to the materials, battery, and wheels.

Maintenance of Electric Scooter Battery

1. Always use certified batteries.
2. Do not open the battery yourself before asking for professional advice.
3. It is recommended to use the certified AC adapter that comes in the original package.
4. Improper disposal of used batteries and accumulators is a cause of severe environmental pollution. Please dispose of batteries in accordance with local laws. Do not dispose of batteries together with food waste.
5. After each use of the device, charge the battery to prolong its service life.
6. Do not store the scooter battery in rooms with temperatures exceeding 50°C or below -20°C (e.g., do not leave the battery in cars in summertime on a hot sun), and do not leave the battery near fire. These actions can deteriorate the battery, cause overheating, and even inflammation.
7. If the scooter is not used for 30 days, keep the device in a cool, dry place and charge the battery. You need to charge the battery every 60 days to protect its life.
8. Avoid a full discharge of the device, as it will reduce battery life. When using the device at room temperature, the battery will provide a longer range and better performance. When you use the scooter at temperatures below 0°C, vehicle performance will be decreased.

Note: A fully charged scooter runs about 120-180 days of standby time. The battery has a smart chip that stores information about its charging-discharging. If you do not charge the battery for a long time, it can cause serious damage, making it impossible to charge the device again. This type of damage is not included in free warranty service. (Caution: Do not disassemble the device by unauthorized people, as there is a risk of electric shock or serious injury as a result of a short circuit.)

9. Product Parameters

Operating Parameters

Battery and Adaptor Parameters

10. Presence of Toxic and Harmful Substances

Date provided in accordance with provisions of SJ/T 11364.

O: Toxic and harmful substances in all components of the device are contained in an amount below the limit value, according to standard GB/T 26572-2011.

X: Presence of toxic and hazardous substances at least one of components of the device in an amount that exceeds the threshold, according to GB/T 26572-2011.

11. Warranty

• Carefully read all instructions before using the electric kick scooter.
• This product is warranted according to the local laws.
• The warranty shall not apply to any products that have been subjected to misuse, negligence, accidental or abnormal conditions of operation and does not cover natural capacity fadeout.
• Please refer to qualified and authorized people for the repair of the electric kick scooter.
• A non-professional repair may cause malfunction and risks and void your warranty rights.
