Preliminary Specification Number :SP-ZZ1PJ-G < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. W-LAN Bluetooth Module Data Sheet
*Please follow installation manual in Appendix. Europe. EN300 328 v2.1.1, Draft EN 300 328 v2.2.0, EN301 893 v2.1.1 and Final EN300 ...
Preliminary Specification Number :SP-ZZ1PJ-G < Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd. W-LAN Bluetooth Module Data Sheet
Preliminary Specification Number :SP-ZZ1PJ-G
W-LAN + Bluetooth Module Data Sheet
Qualcomm Chipset for 802.11a/b/g/n/ac + Bluetooth 5.0 (Dual) Tentative Part Number: LBEE5ZZ1PJ-TEMP
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 1 / 43
The revision history of the product specification
Revised Date
July 25, 2018
Aug 16, 2018
Revision Code
-
A
Sep 13,
B
2018
Sep 29,
C
2018
Nov 3, 2018
D
Dec 29,
E
2018
Jan 21,
F
2019
Mar 6, 2019
G
Revised Page
-
10 12 16~17 8 12 7
4 7 37~44 3 25~26 38/41 24/25 28 4 17
Revised Item
-
-Revised spec of ta2 -Revised spec of VOL -Added UHS SDIO timing requirement -Revise Operating condition -Revise Digital I/O Requirement -Revised Marking
-Added Radio certification info -Added the module picture -Added Appendix -Updated BT version -Revised DC/RF Characteristics for Bluetooth/BLE -Removed 2.4GHz 11ac description -Amended typo in Appendix -Updated the table for Bluetooth/BLE -Amend Dimension of Reel -Add BT SIG QDID -Amend typo in table of Output timing (SDR104)
Change Reason First release Revised/Added
Revised Revised Added
Revised Revised Add/Revised
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 2 / 43
TABLE OF CONTENTS
1. SCOPE..................................................................................................................................................... 3 2. KEY FEATURE ...................................................................................................................................... 3 3. Manufacturing site ................................................................................................................................. 3 4. Part Number ........................................................................................................................................... 3 5. RoHS Compliance ................................................................................................................................... 3 6. Block Diagram ........................................................................................................................................ 3 7. Certification Information ....................................................................................................................... 4
7.1. Radio Certification ................................................................................................................... 4 8. DIMENSIONS, MARKING AND TERMINAL CONFIGURATIONS ................................................. 4
8.1. Dimensions ............................................................................................................................... 4 8.2. Pin Layout and PIN Descriptions ........................................................................................... 5 8.3. Marking..................................................................................................................................... 7 9. ABSOLUTE MAXIMUM RATINGS*1)................................................................................................... 8 10. OPERATING CONDITION*2) ............................................................................................................ 8 11. External lowpower 32.768 kHz clock............................................................................................... 9 12. POWER SEQUENCE Timing .......................................................................................................... 10 12.1. Case 1: 3.3 V power down after 1.8 V................................................................................ 10 12.2. Case 2: 1.8 V power down after 3.3 V.................................................................................11 12.3. Case 3: All power rails supplied with 3.3 V ...................................................................... 12 13. Digital I/O Requirements ................................................................................................................. 12 14. INTERFACE TIMING ...................................................................................................................... 13 14.1. Bluetooth UART Timing .................................................................................................... 13
14.1.1. UART transmit Timing............................................................................................... 13 14.1.2. UART Receiver Timing ............................................................................................... 13 14.2. I2S Timing ........................................................................................................................... 13 14.2.1. I2S Transmitter Timing............................................................................................... 14 14.2.2. I2S Receiver Timing..................................................................................................... 14 14.3. SDIO Timing ....................................................................................................................... 15 14.3.1. SDIO Default Mode Timing ........................................................................................ 15 14.3.2. SDIO High-Speed Mode Timing ................................................................................. 16 14.3.1. SDIO UHS mode Timing ............................................................................................ 16 15. DC / RF Characteristics.................................................................................................................... 18 15.1. DC/RF Characteristics for IEEE802.11b - 2.4GHz .......................................................... 18 15.2. DC/RF Characteristics for IEEE802.11g - 2.4GHz .......................................................... 19 15.3. DC/RF Characteristics for IEEE802.11n 2.4GHz ......................................................... 20 15.4. DC/RF Characteristics for IEEE802.11a - 5GHz ............................................................. 21 15.5. DC/RF Characteristics for IEEE802.11n - 5GHz ............................................................. 22 15.6. DC/RF Characteristics for IEEE802.11ac - 5GHz............................................................ 23 15.7. DC/RF Characteristics for Bluetooth ................................................................................ 24 15.8. DC/RF Characteristics for Bluetooth (LE)........................................................................ 25 16. LAND PATTERN (TOP VIEW) ........................................................................................................ 26 17. REFERENCE CIRCUIT................................................................................................................... 27 18. TAPE AND REEL PACKING ........................................................................................................... 28 19. NOTICE............................................................................................................................................. 32 19.1. Storage Conditions: ............................................................................................................ 32 19.2. Handling Conditions: ......................................................................................................... 32 19.3. Standard PCB Design (Land Pattern and Dimensions): ................................................. 32 19.4. Notice for Chip Placer: ....................................................................................................... 32 19.5. Soldering Conditions: ......................................................................................................... 33 19.6. Cleaning: ............................................................................................................................. 33 19.7. Operational Environment Conditions: .............................................................................. 33 19.8. Input Power Capacity:........................................................................................................ 34 20. PRECONDITION TO USE OUR PRODUCTS ............................................................................... 35
Please be aware that an important notice concerning availability, standard warranty and use in critical applications of Murata products and disclaimers thereto appears at the end of this specification sheet.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 3 / 43
1. SCOPE
This specification is applied to the IEEE802.11a/b/g/n/ac W-LAN + Bluetooth 5.0 combo module.
2. KEY FEATURE
- Chipset: QCA9377-3 - Size: 7.2 x 7.4 x 1.25 (max) mm - Weight: 0.15g/pc - PCB w/ shielded resin mold module - IEEE802.11a/b/g/n/ac dual band 2.4G/5G - Supports BT5.0 (Except Options) - SDIO 3.0 supporting SDR104 (WLAN), UART/PCM (Bluetooth) - Lead Free Module
3. Manufacturing site
Company name: Shenzhen Murata Technology Co., Ltd.
Address: 15 Cuijing Road, Longtian Street, Shenzhen Grand Industrial Zone, PingShan District, Shenzhen, Guangdong, 518118 China
4. Part Number
Ordering Part Number LBEE5ZZ1PJ-TEMP
Description In case of sample order
5. RoHS Compliance
This module is compliant with the RoHS directive.
6. Block Diagram
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 4 / 43
7. Certification Information
7.1. Radio Certification
USA/Canada
FCC ID
VPYLBEE5ZZ1PJ
IC
772C-LBEE5ZZ1PJ
*Please follow installation manual in Appendix
Europe EN300 328 v2.1.1, Draft EN 300 328 v2.2.0, EN301 893 v2.1.1 and Final draft EN300 440 v2.2.1are prepared.
Japan Certification number: 001-P01296
7.2. BT SIG QDID QDID: 127073 (Controller Subsystem)
Notes: Above QDID can be referred in case that LE packet length is less than TX: 123Bytes / RX: 37Bytes.
8. DIMENSIONS, MARKING AND TERMINAL CONFIGURATIONS 8.1. Dimensions
<TOP VIEW>
<BOTTOM VIEW>
<SIDE VIEW>
Table 1 Dimension (Unit: mm)
Mark
Dimension
L
7.40±0.20
a1
0.30±0.10
a4
0.80±0.10
b2
0.25±0.15
b5
0.20±0.15
b8
1.55±0.15
c3
0.55±0.10
Mark W a2 a5 b3 b6 c1 c4
Dimension 7.20±0.20 0.30±0.10 0.30±0.10 1.45±0.15 1.05±0.15 0.55±0.10 0.80±0.10
Mark T a3 b1 b4 b7 c2 c5
Dimension 1.25 max 0.30±0.10 0.20±0.15 5.15±0.15 1.35±0.15 0.55±0.10 0.30±0.10
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
e1
0.30±0.10
e2
e4
0.30±0.10
e5
Co-planarity: 100um Max.
Preliminary Specification Number : SP-ZZ1PJ-G
5 / 43
0.30±0.10
e3
0.30±0.10
0.30±0.10
(unit : mm)
8.2. Pin Layout and PIN Descriptions Top View
Table 2 Terminal Configurations
Pin
Terminal Name
NO.
Type
VDDIO or pad voltage
1
GND
Ground -
2
VBUCK_GND_PM
3
PWM_PM
4
VDD11_PM
5
GND
6
SDIO_DATA3
7
SDIO_DATA2
8
SDIO_DATA1
9
SDIO_DATA0
10
SDIO_CMD
11
SDIO_CLK
12
VDDIO_SDIO
13
SDIO_INTERRUPT_L
Ground O I Ground I/O I/O I/O I/O I OD(1) Power O
1.1V 1.1V VDDIO_SDIO VDDIO_SDIO VDDIO_SDIO VDDIO_SDIO VDDIO_SDIO VDDIO_SDIO 1.8V or 3.3V VDDIO_SDIO
14
GND
Ground -
15
32KHz_CLK_IN
I
VDDIO_GPIO2
16
VDDIO_GPIO2
Power
1.8V or 3.3V
17
HCI_UART_WAKEHOST OD(1)
VDDIO_GPIO2
18
WLAN_RF_KILL_L
I
VDDIO_GPIO2
19
GND
20
2G_WIFI/BT_RF_OUT
21
GND
22
2G_WIFI/BT_RF_IN
Ground -
A,O
-
Ground -
A, I
-
Connection to IC terminal
-
VBUCK_GND_PM PWM_PM VDD11_PM SDIO_D3 SDIO_D2 SDIO_D1 SDIO_D0 SDIO_CMD SDIO_CLK VDDIO_SDIO SDIO_INTERRUPT_L
LF_CLK_IN VDDIO_GPIO2 HCI_UART_WAKEHOST WLAN_RFKILL_L
-
Description
Ground
Ground for internal 1.1 V regulator SWREG PMU 1.1V output. 1.1 V voltage feedback to SWREG PMU. Ground SDIO data bus D3 SDIO data bus D2 SDIO data bus D1 SDIO data bus D0 SDIO CMD line signal SDIO clock signal Voltage supply for SDIO SDIO interrupt signal
Ground External lowpower 32.768 kHz clock input Voltage supply Bluetooth wakeup host. Active high Turn off WLAN RF analog and frontend. Active low. Ground 2G WIFI and BT output Ground 2G WIFI and BT input
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 6 / 43
23
GND
Ground -
-
Ground
24
ANT
A, I/O
-
-
RF Transmit / Receive Antenna
25
GND
Ground -
-
Ground
26
3D_FRAME_SYNC
I
VDDIO_GPIO1 3D_FRAME_SYNC
Frame sync signal from TV to sync with 3D
glass via Bluetooth.
27
HCI_UART_RXD
I
VDDIO_GPIO1 HCI_UART_RXD
UART RXD signal
28
HCI_UART_TXD
O
VDDIO_GPIO1 HCI_UART_TXD
UART TXD signal
29
HCI_UART_RTS
O
VDDIO_GPIO1 HCI_UART_RTS
UART RTS signal
30
HCI_UART_CTS
I
VDDIO_GPIO1 HCI_UART_CTS
UART CTS signal
31
PCM_CLK
I
VDDIO_GPIO1 BT_I2S_SCK
Bluetooth PCM_CLK signal
32
PCM_SYNC
I/O
VDDIO_GPIO1 BT_I2S_WS
Bluetooth PCM_SYNC signal
33
PCM_IN
OD(1)
VDDIO_GPIO1 BT_I2S_SDI
Bluetooth PCM_IN signal
34
PCM_OUT
O
VDDIO_GPIO1 BT_I2S_SDO
Bluetooth PCM_OUT signal
35
GND
Ground -
-
Ground
36
VDDIO_XTAL
Power
1.8V or 3.3V
VDDIO_XTAL
Voltage supply for XTAL
37
VDDIO_GPIO1
Power
1.8V or 3.3V
VDDIO_GPIO1
Voltage supply
38
GND
Ground -
-
Ground
39
WLAN_EN
I
VDDIO_AO
WL_EN
WLAN enable. Active high
40
BT_EN
I
VDDIO_AO
BT_EN
Bluetooth enable. Active high
41
VDD_3P3
Power
3.3V
VDD33_PM
3.3 V input voltage
42
VDDIO_AO
Power
1.8V or 3.3V
VDDIO_AO_PM
Alwayson I/O supply for power
management and realtime clock. This
supply must be present if any other supply
is present.
43
GND
Ground -
-
Ground
44
LTE_UART_RXD
I
VDDIO_GPIO1 LTE_UART_RXD
LTE coexistence signal.
LTE_UART_RXD or LTE_FS.
45
LTE_UART_TXD
O
VDDIO_GPIO1 LTE_UART_TXD
LTE co existence signal.
LTE_UART_TXD or LTE_PRI.
46
CLK_REQ
O
VDDIO_GPIO1 CLK_REQ
Clock request output
47
DBG_UART_TXD
OD(1)
VDDIO_AO
GPIO[19]
DBG_UART_TXD
48
DBG_UART_RXD
OD(1)
VDDIO_GPIO2 GPIO[18]
DBG_UART_RXD
49
QOW
OD(1)
VDDIO_GPIO2 QOW
This signal can be used to enable for
external Wireless charging UART circuit.
50~ GND
Ground -
-
Ground
62
(1) OD means this PIN is a digital output signal with open drain, an external pull-up or pull-down resistor is needed when this PIN is
used.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
8.3. Marking A B C D
Preliminary Specification Number : SP-ZZ1PJ-G 7 / 43
Marking A B C D
Pin 1 Marking Module P/N Inspection Number Murata Logo
Meaning
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
9. ABSOLUTE MAXIMUM RATINGS*1)
Preliminary Specification Number : SP-ZZ1PJ-G 8 / 43
Parameter
Storage Temperature
VDD_3P3
VDDIO_SDIO
Supply Voltage
VDDIO_GPIO1 VDDIO_GPIO2
VDDIO_XTAL
VDDIO_AO
min.
max.
Unit
-40
85
deg.C
-0.3
3.65
V
-0.3
3.6
V
*1) Stresses in excess of the absolute ratings may cause permanent damage. Functional operation is not implied under these conditions. Exposure to absolute ratings for extended periods of time may adversely affect reliability. No damage assuming only one parameter is set at limit at a time with all other parameters are set within operating condition.
10. OPERATING CONDITION*2)
Parameter
Operating Temperature
Specification Temperature range
VDD_3P3
VDDIO_SDIO
Supply Voltage
VDDIO_GPIO1 VDDIO_GPIO2
VDDIO_XTAL
VDDIO_AO
min. -20 -20 3.135
1.71
typ. 25
3.3
1.8 or 3.3
max. 70 60
3.465
3.46
unit deg.C deg.C
V
V
*2) Functionality is guaranteed but the specifications require the derating at over-temperatures, over-voltage condition.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 9 / 43
11. External lowpower 32.768 kHz clock
The 32 kHz clock is used in low-power modes such as IEEE power-save and sleep. It serves as a timer to determine when to wake up to receive beacons in various power-save schemes and to maintain basic logic operations when in sleep. Type1PJ module does not require an external 32 kHz clock. By default, Type1PJ module utilizes its internal 200 kHz clock shared with the WLAN and BT subsystem. If the end application has a more accurate 32 kHz clock, then it can be supplied externally via the LF_CLK_IN pin. The LF_CLK_IN pin must be grounded when using the default internal clock mode. If an external 32 kHz clock is used, the requirements are:
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
12. POWER SEQUENCE Timing
Preliminary Specification Number : SP-ZZ1PJ-G 10 / 43
12.1. Case 1: 3.3 V power down after 1.8 V
If the battery source can be removed from the end user device (battery removed, AC/DC plugged in), this is the recommended power sequence. It will avoid violating the power off sequence by allowing the 3.3 V rail to shut down after the 1.8 V rail.
Notes: 1. VDDIO_GPIO voltage should match VIO voltage from the host. In some applications,
VDDIO_GPIO may connected to 3.3 V upon Host VIO voltage. 2. In this case, both WLAN_EN and BT_EN on the 1PJ are at 3.3 V due to using the VDD_AO
power rail. If the host VIO voltage is 1.8 V, it must have level shifters to interface with host. 3. All host interface signals must stay floating or low before valid power on sequence (WLAN_EN
and BT-EN goes high).
Symbol
Parameter
Min
ta1 No requirement if VDDIO_AO connected to 3.3 V
0
ta2 90% of 3.3 V to 10% of 1.8 V
0
ta3 90% of VDDIO_GPIO to 0.7 V of both WLAN_EN and BT_EN 10
ta4 WLAN_EN valid to LF_CLK_IN input
0
ta5
WLAN_EN de-assert ("low") to LF_CLK_IN de-assert (tristate or low)
0
ta6 Both WLAN_EN = low and BT_EN = low to 90% of 1.8 V
10
ta7
3.3 V always higher than 1.8 V during operation, with power off by removing battery or unplugging AC/DC
0
ta8
VDDIO_AO and VDDIO_XTAL should be connected to 3.3 V power rail
0
Max Units
-
s
-
s
-
s
-
s
-
s
-
s
-
s
-
s
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 11 / 43
12.2. Case 2: 1.8 V power down after 3.3 V
If the battery source cannot be removed from the end user device, this is the recommended power sequence for this application. This sequence allows the software to control the power on/off sequence.
Notes: 1. VDDIO_GPIO voltage should match VIO voltage from the host. In some applications,
VDDIO_GPIO may connected to 3.3 V upon host VIO voltage. 2. Both WLAN_EN and BT_EN of 1PJ are 1.8 V. If host VIO voltage is 1.8 V, it does
not need level shifter to interface with host. 3. All host interface signals must stay floating or low before WLAN_EN/BT_EN ="high", and
after WLAN_EN/BT_EN = Low.
Symbol
Parameter
Min
tb1 No requirement if VDDIO_AO connected to 1.8 V
0
tb2 90% of 1.8 V to 10% of 3.3 V
0
tb3 90% of 3.3 V to 0.7 V of both WLAN_EN and BT_EN
10
tb4 WLAN_EN valid to LF_CLK_IN input
0
tb5
WLAN_EN de-assert ("low") to LF_CLK_IN de-assert (tristate or low)
0
tb6 Both WLAN_EN = low and BT_EN = low to 90% of 3.3 V
10
tb7 10% of 3.3 V to 90% of 1.8 V
0
tb8
VDDIO_AO and VDDIO_XTAL should be connected to 1.8 V power rail
0
Max Units
-
s
-
s
-
s
-
s
-
s
-
s
-
s
-
s
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 12 / 43
12.3. Case 3: All power rails supplied with 3.3 V
All power pins are connected to 3.3 V only include VDDIO_AO, VDDIO_XTAL, VDDIO_GPIOx.
Notes: All host signals are either GND or floating before WLAN_EN/BT_EN ="high", and after WLAN_EN/BT_EN = Low.
Symbol
Parameter
Min
tc1 90% of 3.3 V to 0.7 V of both WLAN_EN and BT_EN
0
tc4 WLAN_EN valid to LF_CLK_IN input
0
tc5
WLAN_EN de-assert ("low") to LF_CLK_IN de-assert (tristate or low)
0
tc6 Both WLAN_EN = low and BT_EN = low to 90% of 3.3 V
10
Max Units
-
s
-
s
-
s
-
s
13. Digital I/O Requirements
Symbol VIH
Parameter High-level input voltage
VIL
Low-level input voltage
VSHYS
Schmitt hysteresis
IIL
Input low leakage current
RPULL
Input pull resistor
VOH High-level output voltage
VOL Low-level output voltage
IOH High-level output current
IOL
Low-level output current
CIN
Input capacitance
Comments
VIN = 0 V Supply = VIO
max Up or down
Minimum
Type
Maximum Unit
0.7 x VDDIO
-
VDDIO + V
0.3
-0.3
-
0.3 x
V
VDDIO
-
1.8 V IO: 375
-
mV
3.3 V IO: 645
-5
-
5
uA
-
0.9 x VDDIO
0
3 -
1.8 V IO: 120 3.3 V IO: 70
-
-
-
-
VDDIO
0.1 x VDDIO
-11 3
kohm
V
V
mA mA pF
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
14. INTERFACE TIMING 14.1. Bluetooth UART Timing
14.1.1. UART transmit Timing
tofftxd
Preliminary Specification Number : SP-ZZ1PJ-G 13 / 43
Parameter tofftxd
Description Delay from CTS to TXD stop
14.1.2. UART Receiver Timing
Min Typ Max Unit
-
-
8 byte
toffrxd
Parameter toffrxd
Description Delay from RTS to RXD stop
Min Typ Max Unit
-
-
8 byte
14.2. I2S Timing
Transmitter
Lower Limit
Upper Limit
Min
Max
Min
Max
Clock Period T
Ttr
-
-
-
Master Mode: Clock generated by transmitter or receiver
HIGH tHC
0.35Ttr
-
-
-
LOW tLC
0.35Ttr
-
-
-
Slave Mode: Clock accepted by transmitter or receiver
HIGH hTC
-
0.35Ttr
-
-
LOW tLC
-
0.35Ttr
-
-
Rise time tRC Transmitter
-
-
0.15Ttr
-
Delay tdtr
-
-
-
0.8T
Hold time thtr
0
-
-
-
Receiver
Setup time tsr
-
-
-
-
Hold time thr
-
-
-
-
Lower Limit
Min
Max
Ttr
-
Receiver
Upper Limit
Min
Max
-
-
0.35Ttr
-
0.35Ttr
-
-
-
-
-
-
0.35Ttr
-
-
-
0.35Ttr
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
0.2Tr
-
-
-
0
-
-
Notes a
b b
c c d
e d
f f
Notes: a. The system clock period T must be greater than Ttr and Tr because both the transmitter and receiver have to be
able to handle the data transfer rate. b. At all data rates in master mode, the transmitter or receiver generates a clock signal with a fixed mark/space
ratio. For this reason, tHC and tLC are specified with respect to T. c. In slave mode, the transmitter and receiver need a clock signal with minimum HIGH and LOW periods so that
they can detect the signal. So long as the minimum periods are greater than 0.35Tr, any clock that meets the requirements can be used. d. Because the delay(tdtr) and the maximum transmitter speed (defined by Ttr) are related, a fast transmitter driven by a slow clock edge can result in tdtr not exceeding tRC which means thtr becomes zero or negative. Therefore, the transmitter has to guarantee that thtr is greater than or equal to zero, so long as the clock rise-time tRC is not more than tRCmax, where tRCmax is not less than 0.15Ttr.
e. To allow data to be clocked out on a falling edge, the delay is specified with respect to the rising edge of the
clock signal and T, always giving the receiver sufficient setup time.
f. The data setup and hold time must not be less than the specified receiver setup and hold time.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
14.2.1. I2S Transmitter Timing
Preliminary Specification Number : SP-ZZ1PJ-G 14 / 43
14.2.2. I2S Receiver Timing
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 15 / 43
14.3. SDIO Timing
14.3.1. SDIO Default Mode Timing
fPP
tWL
tWH
CLK
tTHL
tTLH
tISU
tIH
Input
Output
tODLY (max)
tODLY (min)
SDIO Bus Timing parameters (default Mode)
Parameter
Symbol Min
SDIO CLK (All values are referred to minimum VIH and maximum VIL
Frequency-Data Transfer Mode Frequency-Identification Mode Clock Low Time Clock High Time Clock Rise Time Clock low Time Inputs: CMD, DAT (referenced to CLK)
fPP
0
fOD
0a /100
tWL
10
tWH
10
tTLH
-
tTHL
-
Input Setup Time Input Hold Time Outputs: CMD, DAT (referenced to CLK)
tISU
5
tIH
5
Output Delay time-Data Transfer Mode Output Delay time-Identification Mode
tODLY
0
tODLY
0
Typ
-
-
-
Max
25 400 10 10
-
14 50
Unit
MHz kHz ns ns ns ns
ns ns
ns ns
a. 0 Hz means to stop the clock. The given minimum frequency range is for cases where continuous clock is required.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 16 / 43
14.3.2. SDIO High-Speed Mode Timing
50% VDD
fPP
tWL
tWH
CLK
tTHL
tTLH
tISU
tIH
Input
Output
tODLY
tOH
SDIO Bus Timing parameters (High-Speed Mode)
Parameter
Symbol Min Typ
SDIO CLK (All values are referred to minimum VIH and maximum VIL
Frequency-Data Transfer Mode Clock Low Time Clock High Time Clock Rise Time Clock low Time Inputs: CMD, DAT (referenced to CLK)
fPP
0
-
tWL
7
-
tWH
7
-
tTLH
-
-
tTHL
-
-
Input Setup Time Input Hold Time Outputs: CMD, DAT (referenced to CLK)
tISU
6
-
tIH
2
-
Output Delay time-Data Transfer Mode Output Hold time Total System Capacitance (each line)
tODLY
-
-
tOH
2.5
-
CL
-
-
Max
50 3 3
-
14 40
Unit
MHz ns ns ns ns
ns ns
ns ns pF
14.3.1. SDIO UHS mode Timing In UHS mode the supported features are: 1. Embedded SDIO
The chip is only designed for embedded system; that is, it should be mounted on the PCB with host system and not support plug & play. 2. Fixed voltage supply (VDDIO_SDIO 1.8 V) There is no on-chip LDO to do voltage switch when it receives CMD11 (voltage switch command). In other words, the VDDIO_SDIO power supply is provided from host and should keep constant. Note, though, it does not support voltage switch, it does follow the timing flow of CMD11, with the exception of no voltage change, so there is no effect to SW code. 3. Support for 8-bit mode The 8-bit mode dedicated to embedded system is supported with the maximum frequency of 50 MHz
a). Clock signal timing
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Symbol
Min
Max
Unit
tCLK
4.8
-
ns
tCR, tCF
-
0.2*tCLK
ns
Clock duty
30
70
%
b). Input timing
Preliminary Specification Number : SP-ZZ1PJ-G 17 / 43
Remark 208MHz (max.) between rising edge, VCT=0.975V
tCR, tCF<0.96ns (max.) at 208MHz, C=10 pF
Symbol
Min
Max
Unit
tIS
1.4
-
ns
tIH
0.8
-
ns
Symbol
Min
Max
Unit
tIS
3
-
ns
tIH
0.8
-
ns
c). Output timing (SDR12/SDR25/SDR50)
SDR104 mode C =10 pF, VCT=0.975V C=10 pF, VCT=0.975V SDR12, SDR25 and SDR50 modes C =10 pF, VCT=0.975V C=10 pF, VCT=0.975V
Symbol
Min
Max
Unit
tODLY
-
7.5
ns
tTODLY
-
14
ns
tOH
1.5
-
ns
d). Output timing (SDR104)
Remark TCLK=10ns, CL=30 pF, driver B for SDR50 TCLK=20ns, CL=40 pF, driver B for SDR25,12
Hold time at the tODLY , CL=15 pF
Symbol
Min
Max
Unit
tOP
0
2
UI
Delta tOP
-350 1550
ps
tODW
0.6
-
UI
Remark Output phase Delay variation due to temperature change after tuning tODW=2.88ns at 208 MHz.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 18 / 43
15. DC / RF Characteristics
15.1. DC/RF Characteristics for IEEE802.11b - 2.4GHz
Specification Mode Frequency Data rate
IEEE802.11b DSSS / CCK 2412 to 2472 MHz 1, 2, 5.5, 11Mbps
Conditions : 25deg.C,
VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V
Output power setting=19 dBm, 11Mbps mode unless otherwise specified.
Items
Contents
- DC Characteristics -
min.
typ.
max.
unit
1. DC current
1) Tx mode (1024byte, 20usec interval) *4) *5)
-
330
-
mA
2) Rx mode
-
60
-
mA
- Tx Characteristics -
min.
typ.
max.
Unit
2. Output Power
-
19
-
dBm
3. Spectrum Mask margin
1) 1st side lobes(-30dBr)
0
-
-
dB
2) 2nd side lobes(-50dBr)
0
-
-
dB
4. Power-on and Power-down ramp
-
2.0
sec
5. RF Carrier Suppression
15
-
-
dB
6. Modulation Accuracy (EVM)
-
-
35
%
7.Frequency tolerance
-20
-
20
Ppm
8. Out band Spurious Emissions
1) 30-1000MHz
-
-
-36
dBm
2) 1000-12750MHz
-
-
-30
dBm
3) 1800-1900MHz
-47
dBm
4) 5150-5300MHz
-
-
-47
dBm
- Rx Characteristics -
min.
typ.
max.
Unit
9. Minimum Input Level Sensitivity
-
-89
-76
dBm
10. Maximum Input Level (PER < 8%)
-10
-
-
dBm
11. Adjacent Channel Rejection (FER < 8%)
35
-
-
dB
*4): Defined when output power setting is 19 dBm at Murata module antenna pad
*5): Data rate is 1Mbps
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 19 / 43
15.2. DC/RF Characteristics for IEEE802.11g - 2.4GHz
Specification Mode Frequency Data rate
IEEE802.11g OFDM
2412 to 2472 MHz 6, 9, 12, 18, 24, 36, 48, 54Mbps
Conditions : 25deg.C,
VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V
Output power setting=17 dBm, 54Mbps mode unless otherwise specified.
Items
Contents
- DC Characteristics -
min.
typ.
max.
1. DC current
1) Tx mode (1024byte, 20usec interval) *6) *7)
-
310
-
2) Rx mode
-
60
-
- Tx Characteristics -
min.
typ.
max.
2. Output Power
-
17
-
3. Spectrum Mask margin
1) 9MHz to 11MHz (0~ -20dBr)
0
-
-
2) 11MHz to 20MHz (-20~ -28dBr)
0
-
-
3) 20MHz to 30MHz (-28~ -40dBr)
0
-
-
4) 30MHz to 33MHz (-40dBr)
0
-
-
4. Constellation Error (EVM)
-
-
-25
5.Frequency tolerance
-20
-
20
6. Out band Spurious Emissions
1) 30-1000MHz
-
-
-36
2) 1000-12750MHz
-
-
-30
3) 1800-1900MHz
-47
4) 5150-5300MHz
-
-
-47
- Rx Characteristics -
min.
typ.
max.
7. Minimum Input Level Sensitivity
-
-74
-65
8. Maximum Input Level (PER < 10%)
-20
-
-
9. Adjacent Channel Rejection (PER < 10%)
-1
-
-
*6): Defined when output power setting is 18dBm at Murata module antenna pad
*7): Data rate is 6Mbps
Unit
mA
mA Unit dBm
dB dB dB dB dB Ppm
dBm dBm dBm dBm Unit dBm dBm
dB
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 20 / 43
15.3. DC/RF Characteristics for IEEE802.11n 2.4GHz
Specification Mode Frequency Data rate
IEEE802.11n OFDM
2412 to 2472 MHz MCS0-MCS7
Conditions : 25deg.C,
VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V
Output power setting=16 dBm, BW=20MHz, MCS7 unless otherwise specified.
- DC Characteristics -
min.
typ.
max.
1. DC current
1) Tx mode (1024byte, 20usec interval) *8)*9)
-
310
-
2) Rx mode
-
60
-
- Tx Characteristics -
min.
typ.
max.
2. Output Power
-
16
-
3. Spectrum Mask
1) 9MHz to 11MHz (0 ~ -20dBr)
0
-
-
2) 11MHz to 20MHz (-20 ~ -28dBr)
0
-
-
3) 20MHz to 30MHz (-28 ~ -45dBr)
0
-
-
4) 30MHz to 33MHz (-45dBr)
0
-
-
4. Constellation Error (EVM)
-
-
-27
5.Frequency tolerance
-20
-
20
6. Out band Spurious Emissions
1) 30-1000MHz
-
-
-36
2) 1000-12750MHz
-
-
-30
3) 1800-1900MHz
-47
4) 5150-5300MHz
-
-
-47
- Rx Characteristics -
min.
typ.
max.
7. Minimum Input Level Sensitivity
-
-71
-64
8. Adjacent Channel Rejection (PER < 10%)
-2
-
-
*8): Defined when output power setting is 18 dBm at Murata module antenna pad
*9): Data rate is MCS0
Unit
mA
mA Unit dBm
dB dB dB dB dB Ppm
dBm dBm dBm dBm Unit dBm
dB
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 21 / 43
15.4. DC/RF Characteristics for IEEE802.11a - 5GHz
Specification Mode Frequency Data rate
IEEE802.11a OFDM
5180 to 5825MHz 6, 9, 12, 18, 24, 36, 48, 54Mbps
Conditions : 25deg.C,
VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V
Output power setting= 11 dBm, 54Mbps unless otherwise specified.
- DC Characteristics -
min.
typ.
max.
1. DC current
1) Tx mode (1024byte, 20usec interval) *8)*9)
-
420
-
2) Rx mode
-
80
-
- Tx Characteristics -
min.
typ.
max.
2. Output Power
-
11
-
3. Spectrum Mask
1) 9MHz to 11MHz (0 ~ -20dBr)
0
-
-
2) 11MHz to 20MHz (-20 ~ -28dBr)
0
-
-
3) 20MHz to 30MHz (-28 ~ -45dBr)
0
-
-
4) 30MHz to 33MHz (-45dBr)
0
-
-
4. Constellation Error (EVM)
-
-
-25
5.Frequency tolerance
-20
-
20
6. Out band Spurious Emissions
1) 30-1000MHz
-
-
-36
2) 1000-12750MHz
-
-
-30
3) 1800-1900MHz
-47
4) 5150-5300MHz
-
-
-47
- Rx Characteristics -
min.
typ.
max.
7. Minimum Input Level Sensitivity
-
-71
-65
8. Adjacent Channel Rejection (PER < 10%)
-1
-
-
*8): Defined when output power setting is 14 dBm at Murata module antenna pad
*9): Data rate is 6Mbps
Unit
mA
mA Unit dBm
dB dB dB dB dB Ppm
dBm dBm dBm dBm Unit dBm
dB
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 22 / 43
15.5. DC/RF Characteristics for IEEE802.11n - 5GHz
Specification Mode Frequency Data rate
IEEE802.11n OFDM
5180 to 5825MHz MCS0-MCS7
Conditions : 25deg.C, VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V Output power setting= 10 dBm, BW=20MHz ,MCS7 unless otherwise specified.
- DC Characteristics -
min.
typ.
max.
1. DC current
1) Tx mode (1024byte, 20usec interval) *8)*9)
-
420
-
2) Rx mode
-
80
-
- Tx Characteristics -
min.
typ.
max.
2. Output Power
-
10
-
3. Spectrum Mask
1) 9MHz to 11MHz (0 ~ -20dBr)
0
-
-
2) 11MHz to 20MHz (-20 ~ -28dBr) 3) 20MHz to 30MHz (-28 ~ -45dBr)
0
-
-
0
-
-
4) 30MHz to 33MHz (-45dBr)
0
-
-
4. Constellation Error (EVM)
-
-
-27
5.Frequency tolerance
-20
-
20
6. Out band Spurious Emissions
1) 30-1000MHz
-
-
-36
2) 1000-12750MHz
-
-
-30
3) 1800-1900MHz
-47
4) 5150-5300MHz
-
-
-47
- Rx Characteristics -
min.
typ.
max.
7. Minimum Input Level Sensitivity
-
-69
-64
8. Adjacent Channel Rejection (PER < 10%)
-2
-
-
*8): Defined when output power setting is 14 dBm at Murata module antenna pad *9): Data rate is MCS0
Unit
mA
mA Unit dBm
dB dB dB dB dB Ppm
dBm dBm dBm dBm Unit dBm
dB
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 23 / 43
15.6. DC/RF Characteristics for IEEE802.11ac - 5GHz
Specification Mode Frequency Data rate
IEEE802.11ac OFDM
5210 to 5775MHz MCS0-MCS9
Conditions : 25deg.C,
VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V
Output power setting= 8 dBm, BW=80MHz ,MCS9 unless otherwise specified.
- DC Characteristics -
min.
typ.
max.
1. DC current
1) Tx mode (1024byte, 20usec interval) *8)*9)
-
370
-
2) Rx mode
-
90
-
- Tx Characteristics -
min.
typ.
max.
2. Output Power *10)
-
8
-
3. Spectrum Mask
1) 9MHz to 11MHz (0 ~ -20dBr)
0
-
-
2) 11MHz to 20MHz (-20 ~ -28dBr)
0
-
-
3) 20MHz to 30MHz (-28 ~ -45dBr)
0
-
-
4) 30MHz to 33MHz (-45dBr)
0
-
-
4. Constellation Error (EVM)
-
-
-32
5.Frequency tolerance
-20
-
20
6. Out band Spurious Emissions
1) 30-1000MHz
-
-
-36
2) 1000-12750MHz
-
-
-30
3) 1800-1900MHz
-47
4) 5150-5300MHz
-
-
-47
- Rx Characteristics -
min.
typ.
max.
7. Minimum Input Level Sensitivity
-
-59
-51
8. Adjacent Channel Rejection (PER < 10%)
-9
-
-
*8): Defined when output power setting is 12dBm at Murata module antenna pad
*9): Data rate is MCS0
*10):Target output power for MCS9 VHT=40 at 5190, 5230, 5270 and 5310MHz is 7dBm.
Unit
mA
mA Unit dBm
dB dB dB dB dB Ppm
dBm dBm dBm dBm Unit dBm
dB
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 24 / 43
15.7. DC/RF Characteristics for Bluetooth
Conditions : 25deg.C,
VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V
Items
Contents
Bluetooth specification (power class)
Version 5.0 (Class 1)
Channel frequency (spacing)
2402 to 2480 MHz (1MHz)
Current Consumption
Min.
Typ.
Max.
(a) Tx=DH5
-
55
-
(b) Tx=2DH5
-
50
-
(c) Tx=3DH5
-
50
-
(d) Rx=DH5
-
22
-
(e) Rx=2DH5
-
22
-
(f) Rx=3DH5
-
22
-
Transmitter
Min.
Typ.
Max.
Output Power@DH5
8
Frequency range
2402
-
2480
20dB bandwidth Adjacent Channel Power *1
-
950
1000
(a) [M-N] =2
-
-
-20
(b) [M-N] 3
-
-
-40
Modulation characteristics
(a) Modulation f1avg
140
-
175
(b) Modulation f2max
115
-
(c) Modulation f2avg / f1avg
0.8
-
-
Carrier Frequency Drift
(a) 1slot
-25
-
+25
(b) 3slot / 5slot
-40
-
+40
(c) Maximum drift rate
-
20
EDR Relative Power
-4
-
+1
EDR Carrier Frequency Stability and
Modulation Accuracy
(a) i
-75
-
+75
(b) i+o
-75
-
+75
(c) o
-10
-
+10
(d) RMS DEVM (DQPSK)
-
-
20
(e) Peak DEVM (DQPSK)
-
-
35
(f) 99% DEVM (DQPSK)
-
-
30
(g) RMS DEVM (8DPSK)
-
-
13
(h) Peak DEVM (8DPSK)
-
-
25
(i) 99% DEVM (8DPSK)
-
-
20
Spurious Emissions
(a) 10MHzf<2387MHz
-
-
-36
(b) 2387MHzf<2400MHz
-
-
-30
(c) 2483.5MHz<f2496.5MHz
-47
(d) 2496.5MHz<f8GHz
-
-
-47
Receiver
Min.
Typ.
Max.
BDR Sensitivity (BER<0.1%)
-
-92
-80
EDR Sensitivity (BER<0.007%)@8DPSK
-
C/I Performance (BER<0.1%) *2
-87
-77
(a) co-channel
-
-
11
(b) 1MHz
-
-
0
(c) 2MHz
-
-
-30
(d) 3MHz
-
-
-40
Maximum Input Level (BER<0.1%)
-20
-
-
*1: Up to three spurious responses within Bluetooth limits are allowed.
*2: Up to five spurious responses within Bluetooth limits are allowed.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
unit mA mA mA mA mA mA Unit dBm MHz MHz
dBm dBm
kHz kHz
kHz kHz
kHz/50us
dB
kHz kHz kHz % % % % % %
dBm dBm dBm dBm unit dBm dBm
dB dB dB dB dBm
Preliminary Specification Number : SP-ZZ1PJ-G 25 / 43
15.8. DC/RF Characteristics for Bluetooth (LE)
Conditions : 25deg.C,
VDD_3P3,VDDIO_SDIO,VDDIO_GPIO1,VDDIO_GPIO2,VDDIO_XTAL,VDDIO_AO=3.3V
Items
Contents
Bluetooth specification (power class)
Version 5.0 (LE)
Channel frequency (spacing)
2402 to 2480 MHz (2MHz)
Number of RF Channel
40
Item / Condition
Min.
Typ.
Max.
Center Frequency
2402
-
2480
Channel Spacing
-
2
-
Number of RF channel
-
40
-
Output power
8
Modulation Characteristics
1) f1avg
225
-
275
2) f2max (at 99.9%)
185
-
-
3) f2avg / f1avg
0.8
-
-
Carrier frequency offset and drift
1) Frequency offset
-
-
150
2) Frequency drift
-
-
50
3) Drift rate
-
-
20
Receiver sensitivity (PER < 30.8%)
-
-96
-70
Maximum input signal level (PER < 30.8%)
-10
-
-
PER Report Integrity (-30dBm input)
50
-
65.4
Unit MHz MHz
dBm
kHz kHz
-
kHz kHz kHz dBm dBm %
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
16. LAND PATTERN (TOP VIEW)
Preliminary Specification Number : SP-ZZ1PJ-G 26 / 43
<Top View>
***Stencil design: For 0.3×0.55mm electrodes, stencil pad is 0.24mm*0.44mm and should put in the center of the each conductor. For 0.8×0.8mm electrodes, stencil pad is 0.66mm*0.66mm and should put in the center of the each conductor. ***This is based on Murata's condition using the thickness of the stencil 100 um. So this is just the recommendation and needs to modify based on your condition.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 27 / 43
17. REFERENCE CIRCUIT
Notes for the power supply voltage:
1. VDD_3V3 is powered by 3.3V typically. 2. VDDIO_AO, VDDIO_GPIO1, VDDIO_GPIO2, VDDIO_XTAL,
VDDIO_SDIO can be powered by 1.8V or 3.3V. It should match the VIO voltage from host. For the each I/O voltage group of 1PJ module, please refer to 1PJ module datasheet.
VDDIO_GPIO2 VDDIO_AO
R5 R6
R4
10K 10K
10K
L1 1.5uH
OQW
VDD_3V3 VDDIO_AO VDDIO_GPIO1
C4 10uF
C5
C6
2.2uF
1uF
VDDIO_GPIO2 VDDIO_XTAL
VDDIO_SDIO
TOLERANCE = 20%
C7
C3
47uF
1uF
3 4 PWM_PM 2 VDD11_PM
VBUCK_GND_PM 1
GND
VDD_3V3
C8
C9
C10 C11
1uF
1uF
10uF 0.1uF
VDDIO_GPIO1
41 VDD_3P3
VDDIO_AO
42 VDDIO_AO
VDDIO_SDIO
VDDIO_GPIO2
37 16 VDDIO_GPIO1
VDDIO_GPIO2
VDDIO_XTAL
36 VDDIO_XTAL
R10 R11 R12 R13 R14 R15 VDDIO_SDIO
12 VDDIO_SDIO
10K NU NU NU 10K NU
SDIO_DATA3 SDIO_DATA2 SDIO_DATA1 SDIO_DATA0 SDIO_CMD SDIO_CLK WL_DEV_WAKEUP_HOST
32KHz Clock in
6 7 SDIO_DATA3 8 SDIO_DATA2 9 SDIO_DATA1 10 SDIO_DATA0 11 SDIO_CMD 13 SDIO_CLK
SDIO_INTERRUPT_L 15
32KHZ_CLK_IN
LLBBEEEE55ZZZZ11PPJ-J1-63477
5 GND
14 GND
58 57 GND 56 GND 55 GND 54 GND 53 GND 52 GND 51 GND 59 GND 60 GND 61 GND 62 GND 50 GND
GND 43
GND 38
GND 35
GND
49 QOW
48 DBG_UART_RXD 47 DBG_UART_TXD
46 CLK_REQ
45 LTE_UART_TXD 44 LTE_UART_RXD
40 BT_EN 39 WLAN_EN
18 WLAN_RF_KILL_L
17 HCI_UART_WAKEHOST
DBG_UART_RXD DBG_UART_TXD
CLK_REQ LTE_UART_TXD LTE_UART_RXD WLAN_RF_KILL_L
BT Reset
VDDIO_AO
SW1 SKQY A
1
2
VDDIO_GPIO2
R2 27 BT_EN
R1 10K
C1 0.1uF
J1 1 2
CON2
R3 10K
BT_DEV_WAKEUP_HOST BT_EN WLAN_EN
VDDIO_GPIO1
WLAN Reset
R8 WLAN_EN
34 PCM_OUT 33
PCM_IN 32 PCM_SY NC 31
PCM_CLK
R9 10K
BT_PCM_OUT BT_PCM_IN BT_PCM_SY NC BT_PCM_CLK
VDDIO_AO
R7
27
10K
C2 0.1uF
SW2 SKQY A
1
2
J2 1 2
CON2
26 3D_FRAME_SY NC
27 HCI_UART_RXD 28 HCI_UART_TXD 29 HCI_UART_RTS 30 HCI_UART_CTS
BT_HOST_WAKEUP_DEV/3D_FRAME_SY NC
BT_UART_RXD BT_UART_TXD BT_UART_RTS BT_UART_CTS
25 GND 24 ANT 23 GND 22 2G_WIFI/BT_RF_IN 21 GND 20 2G_WIFI/BT_RF_OUT 19 GND
R17 0R
R16 0R
C12
C13
NU
NU
J3 2
1
3
5
4
RF-SOCKET_0 SMA connector
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
18. TAPE AND REEL PACKING
(1) Dimensions of Tape (Plastic tape)
Preliminary Specification Number : SP-ZZ1PJ-G 28 / 43
Feeding direction
W
16+/-0.2
P2
F
7.5+/-0.1
A0
T
0.3+/-0.05
B0
E
1.75+/-0.1
K0
P
12+/-0.1
D0
P0
4+/-0.1
D1
(2) Dimensions of Reel
2+/-0.1 7.8+/-0.1 7.6+/-0.1 1.25+/-0.1 1.5+0.1/-0 1.5+/-0.1
Unit: mm
W1
17.5 +/-1.0
W2
21.5 +/-1.0
Unit: mm
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
(3) Taping Diagrams
Preliminary Specification Number : SP-ZZ1PJ-G 29 / 43
[1] Feeding Hole : As specified in (1) [2] Hole for chip : As specified in (1) [3] Cover tape : 62 um in thickness [4] Base tape : As specified in (1)
[3] [1]
[2]
[3]
[4] Feeding Hole Feeding Direction
Chip
(4) Leader and Tail tape
Tail tape (No components) Components
No components
Leader tape (Cover tape alone)
160 to 190 mm
150mm min. Feeding direction
250 mm min.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 30 / 43
-The tape for chips are wound clockwise, the feeding holes to the right side as the tape is pulled toward the user.
-The cover tape and base tape are not adhered at no components area for 250 mm min.
-Tear off strength against pulling of cover tape: 5 N min.
-Packaging unit: 1000 pcs/ reel
- Material: Base tape: Plastic Reel : Plastic Cover tape, cavity tape and reel are made the anti-static processing.
- Peeling of force: 1.1 N max. in the direction of peeling as shown below.
1.1 N max.
165 to 180 °
Cover tape
Base tape
- PACKAGE (Humidity proof packing)
Humidity Indicator
Desiccant
Caution Certification
label
label
Label
Anti-humidity Plastic Bag
Tape and reel must be sealed with the anti-humidity plastic bag. The bag contains the desiccant and the humidity indicator.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 31 / 43
- Box Box for plastic bag: 90 x 350 x 350 mm Carton box: 390 x 380 x 380 mm 5 boxes for plastic bag are stored to a carton box as below.
- Label
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 32 / 43
19. NOTICE 19.1. Storage Conditions:
Please use this product within 6month after receipt. - The product shall be stored without opening the packing under the ambient temperature from 5 to 35deg.C and humidity from 20 to 70%RH. (Packing materials, in particular, may be deformed at the temperature over 40deg.C.) - The product left more than 6months after reception, it needs to be confirmed the solderbility before used. - The product shall be stored in non corrosive gas (Cl2, NH3, SO2, Nox, etc.). - Any excess mechanical shock including, but not limited to, sticking the packing materials by sharp object and dropping the product, shall not be applied in order not to damage the packing materials.
This product is applicable to MSL3 (Based on JEDEC Standard J-STD-020) - After the packing opened, the product shall be stored at <30deg.C / <60%RH and the product shall be used within 168hours. - When the color of the indicator in the packing changed, the product shall be baked before soldering.
Baking condition: 125+5/-0deg.C, 24hours, 1time The products shall be baked on the heat-resistant tray because the material (Base Tape, Reel Tape and Cover Tape) are not heat-resistant.
19.2. Handling Conditions:
Be careful in handling or transporting products because excessive stress or mechanical shock may break products.
Handle with care if products may have cracks or damages on their terminals, the characteristics of products may change. Do not touch products with bear hands that may result in poor solder ability and destroy by static electrical charge.
19.3. Standard PCB Design (Land Pattern and Dimensions):
All the ground terminals should be connected to the ground patterns. Furthermore, the ground pattern should be provided between IN and OUT terminals. Please refer to the specifications for the standard land dimensions.
The recommended land pattern and dimensions is as Murata's standard. The characteristics of products may vary depending on the pattern drawing method, grounding method, land dimensions, land forming method of the NC terminals and the PCB material and thickness. Therefore, be sure to verify the characteristics in the actual set. When using non-standard lands, contact Murata beforehand.
19.4. Notice for Chip Placer:
When placing products on the PCB, products may be stressed and broken by uneven forces from a worn-out chucking locating claw or a suction nozzle. To prevent products from damages, be sure to follow the specifications for the maintenance of the chip placer being used. For the positioning of products on the PCB, be aware that mechanical chucking may damage products.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 33 / 43
19.5. Soldering Conditions:
The recommendation conditions of soldering are as in the following figure. When products are immersed in solvent after mounting, pay special attention to maintain the temperature difference within 100 °C. Soldering must be carried out by the above mentioned conditions to prevent products from damage. Set up the highest temperature of reflow within 260 °C. Contact Murata before use if concerning other soldering conditions.
235 to 245 deg.C 220 deg.C 180 deg.C
Reflow soldering standard conditions(Example)
Within 3s
Cooling down Slowly
150 deg.C
Pre-heating
Within 120s
Within 60s
time(s)
Please use the reflow within 2 times. Use rosin type flux or weakly active flux with a chlorine content of 0.2 wt % or less.
19.6. Cleaning:
Since this Product is Moisture Sensitive, any cleaning is not permitted.
19.7. Operational Environment Conditions:
Products are designed to work for electronic products under normal environmental conditions (ambient temperature, humidity and pressure). Therefore, products have no problems to be used under the similar conditions to the above-mentioned. However, if products are used under the following circumstances, it may damage products and leakage of electricity and abnormal temperature may occur.
- In an atmosphere containing corrosive gas ( Cl2, NH3, SOx, NOx etc.). - In an atmosphere containing combustible and volatile gases. - Dusty place. - Direct sunlight place. - Water splashing place. - Humid place where water condenses. - Freezing place.
If there are possibilities for products to be used under the preceding clause, consult with Murata before actual use.
As it might be a cause of degradation or destruction to apply static electricity to products, do not apply static electricity or excessive voltage while assembling and measuring.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 34 / 43
19.8. Input Power Capacity: Products shall be used in the input power capacity as specified in this specifications. Inform Murata beforehand, in case that the components are used beyond such input power capacity range.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 35 / 43
20. PRECONDITION TO USE OUR PRODUCTS
PLEASE READ THIS NOTICE BEFORE USING OUR PRODUCTS.
Please make sure that your product has been evaluated and confirmed from the aspect of the fitness for the
specifications of our product when our product is mounted to your product.
All the items and parameters in this product specification/datasheet/catalog have been prescribed on the premise that
our product is used for the purpose, under the condition and in the environment specified in this specification. You are
requested not to use our product deviating from the condition and the environment specified in this specification.
Please note that the only warranty that we provide regarding the products is its conformance to the specifications
provided herein. Accordingly, we shall not be responsible for any defects in products or equipment incorporating such
products, which are caused under the conditions other than those specified in this specification.
WE HEREBY DISCLAIMS ALL OTHER WARRANTIES REGARDING THE PRODUCTS, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION ANY WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, THAT THEY
ARE DEFECT-FREE, OR AGAINST INFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS.
The product shall not be used in any application listed below which requires especially high reliability for the prevention
of such defect as may directly cause damage to the third party's life, body or property. You acknowledge and agree that,
if you use our products in such applications, we will not be responsible for any failure to meet such requirements.
Furthermore, YOU AGREE TO INDEMNIFY AND DEFEND US AND OUR AFFILIATES AGAINST ALL CLAIMS,
DAMAGES, COSTS, AND EXPENSES THAT MAY BE INCURRED, INCLUDING WITHOUT LIMITATION, ATTORNEY
FEES AND COSTS, DUE TO THE USE OF OUR PRODUCTS IN SUCH APPLICATIONS.
- Aircraft equipment.
- Aerospace equipment
- Undersea equipment.
- Power plant control equipment - Medical equipment.
- Transportation equipment (vehicles, trains, ships, elevator, etc.).
- Traffic signal equipment.
- Disaster prevention / crime prevention equipment.
-Burning / explosion control equipment
- Application of similar complexity and/ or reliability requirements to the applications listed in the above.
We expressly prohibit you from analyzing, breaking, reverse-engineering, remodeling altering, and reproducing our
product. Our product cannot be used for the product which is prohibited from being manufactured, used, and sold by
the regulations and laws in the world.
We do not warrant or represent that any license, either express or implied, is granted under any our patent right,
copyright, mask work right, or our other intellectual property right relating to any combination, machine, or process in
which our products or services are used. Information provided by us regarding third-party products or services does not
constitute a license from us to use such products or services or a warranty or endorsement thereof. Use of such
information may require a license from a third party under the patents or other intellectual property of the third party, or a
license from us under our patents or other intellectual property.
Please do not use our products, our technical information and other data provided by us for the purpose of developing of
mass-destruction weapons and the purpose of military use.
Moreover, you must comply with "foreign exchange and foreign trade law", the "U.S. export administration regulations",
etc.
Please note that we may discontinue the manufacture of our products, due to reasons such as end of supply of materials
and/or components from our suppliers.
By signing on specification sheet or approval sheet, you acknowledge that you are the legal representative for your
company and that you understand and accept the validity of the contents herein. When you are not able to return the
signed version of specification sheet or approval sheet within 30 days from receiving date of specification sheet or
approval sheet, it shall be deemed to be your consent on the content of specification sheet or approval sheet. Customer
acknowledges that engineering samples may deviate from specifications and may contain defects due to their
development status. We reject any liability or product warranty for engineering samples. In particular we disclaim liability
for damages caused by
- the use of the engineering sample other than for evaluation purposes, particularly the installation or integration in the
product to be sold by you,
-deviation or lapse in function of engineering sample,
-improper use of engineering samples.
We disclaim any liability for consequential and incidental damages.
If you can't agree the above contents, you should inquire our sales.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 36 / 43
Appendix
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 37 / 43
LBEE5ZZ1PJ Installation Manual (FCC)
FCC ID of this module is as follows;
FCC ID:
VPYLBEE5ZZ1PJ
For OEM integration only device cannot be sold to general public. Therefore we will ask OEM to include the following statement required by FCC on the product and in the installation manual Notice.
Contents 1. Theory of operation 2. Antenna 3. Notice
1. Theory of operation
Frequency of operation
2.4GHz 802.11b/g/n-HT20
2412MHz 2462MHz (ch1 ch11)
802.11n-HT40
2422MHz 2452MHz (ch3 ch9)
W52
802.11a/n-HT20/ac-VHT-20 5180MHz 5240MHz (ch36 ch48)
802.11n-HT40/ac-VHT-40 5190MHz 5239MHz (ch38 ch46)
802.11ac-VHT80
5210MHz (ch42)
W53
802.11a/n-HT20/ac-VHT-20 5260MHz 5320MHz (ch52 ch64)
802.11n-HT40/ac-VHT-40 5270MHz 5310MHz (ch54 ch62)
802.11ac-VHT80
5290MHz (ch58)
W56
802.11a/n-HT20/ac-VHT-20 5500MHz 5720MHz (ch100 ch144)
802.11n-HT40/ac-VHT-40 5510MHz 5710MHz (ch102 ch142)
802.11ac-VHT80
5530MHz 5690MHz (ch106 ch138)
W58
802.11a/n-HT20/ac-VHT-20 5745MHz 5825MHz (ch149 ch165)
802.11n-HT40/ac-VHT-40 5755MHz 5795MHz (ch151 ch159)
802.11ac-VHT80
5775MH (ch155)
The device cannot operate in 5600MHz~5650MHz band in Canada
Scan
Active Active Active Active Active Passive Passive Passive Passive Passive Passive Active Active Active
Ad-hoc mode Yes Yes Yes Yes Yes No No No No No No Yes Yes Yes
Compliance with FCC requirement 15.407(c) Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure.
Frequency Tolerance: ± 20ppm
End users cannot modify the software because F/W & driver are installed in device.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 38 / 43
2. Antenna
Please refer to KDB 996369 Please perform the antenna design that followed the specifications of the antenna. About the signal line between an antenna and a module It is a 50-ohm line design. Fine tuning of return loss etc. can be performed using a matching network. However, it is required to check "Class1 change" and "Class2 change" which the authorities define then.
The concrete contents of a check are the following three points. 1) It is the same type as the antenna type of antenna specifications. 2) An antenna gain is lower than a gain given in antenna specifications. 3) The emission level is not getting worse.
50-ohm feed line(microstrip line length) Antenna type 50-ohm feed line length
Antenna 2.4GHz Monopole Antenna 5GHz Monopole Antenna We test it at 26.4mm as a representative
3. Notice
For OEM integration only device cannot be sold to general public. Therefore we will ask OEM to include the following statements required by FCC/IC on the product and in the Installation manual Notice. Please describe the following warning on the final product which contains this module.
Contains Transmitter Module FCC ID: VPYLBEE5ZZ1PJ or
Contains FCC ID: VPYLBEE5ZZ1PJ
Please describe the following warning to the manual.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
When the product is small, as for these words mentioned above, the posting to a manual is possible.
When installing it in a mobile equipment. Please describe the following warning to the manual. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person's body.
RF Exposure requirements are met when installed in mobile equipment. This module cannot be installed in portable equipment without further testing and a change to FCC's grant of authorization. Contact Murata regarding portable applications.
Note) Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm. Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 39 / 43
This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. 3) The use of an antenna with gain less than 2.0 dBi(2.4GHz), 2.0 dBi(5.15~5.35GHz), 1.2 dBi (5.47~5.725GHz) and 1.0 dBi (5.725~5.85GHz). As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: "Contains FCC ID: VPYLBEE5ZZ1PJ". The grantee's FCC ID can be used only when all FCC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user's manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 40 / 43
LBEE5ZZ1PJ Installation Manual (IC)
IC No. of this device is as follows;
IC:
772C-LBEE5ZZ1PJ
For OEM integration only device cannot be sold to general public. Therefore, we will ask OEM to include the following statements required by IC on the product and in the installation manual Notice.
Contents 1. Theory of operation 2. Antenna 3. Notice
1. Theory of operation
Frequency of operation
2.4GHz 802.11b/g/n-HT20
2412MHz 2462MHz (ch1 ch11)
802.11n-HT40
2422MHz 2452MHz (ch3 ch9)
W52
802.11a/n-HT20/ac-VHT-20 5180MHz 5240MHz (ch36 ch48)
802.11n-HT40/ac-VHT-40 5190MHz 5239MHz (ch38 ch46)
802.11ac-VHT80
5210MHz (ch42)
W53
802.11a/n-HT20/ac-VHT-20 5260MHz 5320MHz (ch52 ch64)
802.11n-HT40/ac-VHT-40 5270MHz 5310MHz (ch54 ch62)
802.11ac-VHT80
5290MHz (ch58)
W56
802.11a/n-HT20/ac-VHT-20 5500MHz 5720MHz (ch100 ch144)
802.11n-HT40/ac-VHT-40 5510MHz 5710MHz (ch102 ch142)
802.11ac-VHT80
5530MHz 5690MHz (ch106 ch138)
W58
802.11a/n-HT20/ac-VHT-20 5745MHz 5825MHz (ch149 ch165)
802.11n-HT40/ac-VHT-40 5755MHz 5795MHz (ch151 ch159)
802.11ac-VHT80
5775MH (ch155)
The device cannot operate in 5600MHz~5650MHz band in Canada
Scan
Active Active Active Active Active Passive Passive Passive Passive Passive Passive Active Active Active
Ad-hoc mode Yes Yes Yes Yes Yes No No No No No No Yes Yes Yes
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure.
La transmission des données est toujours initiée par le logiciel, puis les données sont transmises par 'intermédiaire du MAC, par la bande de base numérique et analogique et, enfin, à la puce RF. Plusieurs paquets spéciaux sont initiés par le MAC. Ce sont les seuls moyens pour qu'une partie de la bande de base numérique active l'émetteur RF, puis désactive celui-ci à la fin du paquet. En conséquence, l'émetteur reste uniquement activé lors de la transmission d'un des paquets susmentionnés. En d'autres termes, ce dispositif interrompt automatiquement toute transmission en cas d'absence d'information à transmettre ou de défaillance.
End users cannot modify the software because F/W & driver are installed in device.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 41 / 43
2. Antenna
Please refer to KDB 996369 Please perform the antenna design that followed the specifications of the antenna. About the signal line between an antenna and a module It is a 50-ohm line design. Fine tuning of return loss etc. can be performed using a matching network. However, it is required to check "Class1 change" and "Class2 change" which the authorities define then.
The concrete contents of a check are the following three points. 1) It is the same type as the antenna type of antenna specifications. 2) An antenna gain is lower than a gain given in antenna specifications. 3) The emission level is not getting worse.
50-ohm feed line(microstrip line length) Antenna type 50-ohm feed line length
Antenna 2.4GHz Monopole Antenna 5GHz Monopole Antenna We test it at 26.4mm as a representative
3. Notice
For OEM integration only device cannot be sold to general public. Therefore we will ask OEM to include the following statements required by FCC/IC on the product and in the Installation manual Notice. Please describe the following warning on the final product which contains this module.
Contains IC: 772C-LBEE5ZZ1PJ
This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : 1) l'appareil ne doit pas produire de brouillage; 2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
*When the product is small, as for these words mentioned above, the posting to a manual is possible.
5150-5250 MHz band is restricted to indoor operation only.
La bande 5150-5250 MHz est restreinte à une utilisation à l'intérieur seulement.
High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
Les radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz, et ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 42 / 43
When installing it in a mobile equipment. Please describe the following warning to the manual. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person's body.
Cet équipement est conforme aux limites d'exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles d'exposition aux fréquences radioélectriques (RF) CNR-102 de l'IC. Cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre le radiateur et le corps humain.
RF Exposure requirements are met when installed in mobile equipment. This module cannot be installed in portable equipment without further testing and a change to FCC's grant of authorization. Contact Murata regarding portable applications.
Note) Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm. Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
This device is intended only for OEM integrators under the following conditions: (For module device use) 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. 3) The use of an antenna with gain less than 2.0 dBi (2.4GHz), 2.0dBi (5.15~5.35GHz), 1.2dBi (5.47~5.725GHz) and 1.0dBi (5.725~5.85GHz).
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes: (Pour utilisation de dispositif module) 1)L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée entre l'antenne et les utilisateurs, et 2)Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
Tant que les 3 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité supplémentaires requis pour ce module installé.
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure. La transmission des données est toujours initiée par le logiciel, puis les données sont transmises par 'intermédiaire du MAC, par la bande de base numérique et analogique et, enfin, à la puce RF. Plusieurs paquets spéciaux sont initiés par le MAC. Ce sont les seuls moyens pour qu'une partie de la bande de base numérique active l'émetteur RF, puis désactive celui-ci à la fin du paquet. En conséquence, l'émetteur reste uniquement activé lors de la transmission d'un des paquets susmentionnés. En d'autres termes, ce dispositif interrompt automatiquement toute transmission en cas d'absence d'information à transmettre ou de défaillance.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Preliminary Specification Number : SP-ZZ1PJ-G 43 / 43
IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the Canada authorization is no longer considered valid and the IC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate Canada authorization. NOTE IMPORTANTE: Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations d'ordinateur portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC ne peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera chargé de réévaluer le produit final (y compris l'émetteur) et 'obtention d'une autorisation distincte au Canada.
End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled
in a visible area with the following: "Contains IC: 772C-LBEE5ZZ1PJ ".
Plaque signalétique du produit final Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante:
"Contient des IC: 772C-LBEE5ZZ1PJ ".
Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user's manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Manuel d'information à l'utilisateur final L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module. Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme indiqué dans ce manuel.
< Specification may be changed by Murata without notice > Murata(China) Investment Co., Ltd.
Microsoft Office Word 2007
