Installation Guide for AQUALISA models including: RS.A2.01.18, Concealed Digital Shower Mixer Rise
The Quartz Smart Valve™ must be installed in an ... to allow removal for service and maintenance ... pump (works on both positive and negative head.
TMRISETM INSTALLATION GUIDE IMPORTANT INFORMATION Safety information This appliance can be used by children aged from 3 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. This product must be installed by a competent person in accordance with all relevant current local and national Water Supply Regulations. ALL PRODUCTS REQUIRING AN ELECTRICAL CONNECTION MUST BE INSTALLED BY A QUALIFIED PERSON FOLLOWING THE LATEST REVISION OF THE ELECTRICAL WIRING REGULATIONS, BOTH NATIONAL AND LOCAL AND CERTIFIED TO CURRENT BUILDING REGULATIONS. This system should be installed so that other taps or appliances operated elsewhere within the premises do not significantly affect the flow. The Quartz Smart ValveTM must not be used with a hot water supply temperature of over 65ºC. If the maximum hot water temperature is likely to rise above 65ºC then a Thermostatic Blending Valve must be used. The Quartz Smart ValveTM is supplied factory pre-set at maximum temperature of 45ºC. The maximum temperature is fully adjustable to suit site conditions. If adjusted, we recommend the outlet temperature is set to a MAXIMUM of 46ºC. The Quartz Smart ValveTM must be installed in an accessible location for servicing and maintenance. The Quartz Smart ValveTM must not be installed in situations where either the ambient temperature is likely to exceed 40ºC or where freezing may occur. The controller must not be installed in situations where the ambient temperature is likely to fall below 5ºC or rise above 40ºC. We do not recommend the use of a controller in steam therapy facilities. This appliance must be earthed. Cables must be protected by a suitably sized conduit or trunking to avoid risk of damage and to allow removal for service and maintenance purposes. Failure to install this way may invalidate the warranty. Ensure that the conduit is run to avoid the controller fixing holes. Surface mounted cables must also be protected by a suitable approved conduit, even in a loft, where there may be a risk of damage from vermin. The power lead must only be replaced by the manufacturer or his accredited agent. The controller is supplied from a safety low voltage source. This product is suitable for domestic use only. Aqualisa products are supplied complete with a 1 year guarantee that can be upgraded by registering the product with Aqualisa. See www.aqualisa.co.uk/guarantee for details. Installation of the pumped Quartz Smart ValveTM (for gravity stored systems) The pumped Quartz Smart ValveTM shower system is designed to operate up to a maximum static pressure of 100kPa ((1 bar)(10 metres head)(14.5psi)). Under no circumstances must the pumped Quartz Smart ValveTM be connected directly to the water main or in line with another booster pump. The minimum actual capacity of the cold water storage cistern should be not less than 225 litres (50 gallons). The capacity of the hot water cylinder must be capable of meeting anticipated demand. RiseTM Installation Guide 02 Installation of the standard (unpumped) Quartz Smart ValveTM (for balanced high pressure and unvented systems, combination boiler systems and separately pumped gravity systems) Pressures: The standard (unpumped) Quartz Smart ValveTM is designed to operate up to a maximum static pressure of 700kPa ((7 bar) (100psi)). Where pressures are likely to exceed 700kPa ((7 bar)(100psi)), a pressure reducing valve must be fitted to the incoming mains supply. A setting of 400kPa ((4 bar)(60psi)) is recommended. It should be noted that daytime pressures approaching 600kPa ((6 bar)(80psi)) can rise above the stated maximum overnight. Special notes for combination boiler systems The appliance must have a minimum domestic hot water rating of 24kW and be of the type fitted with a fully modulating gas valve. If in any doubt, please contact the appliance manufacturer before installation commences. PLEASE NOTE: DUE TO PERFORMANCE CHARACTERISTICS OF COMBINATION BOILERS, SEASONAL INLET TEMPERATURE CHANGE WILL AFFECT THE QUARTZ SMART VALVETM OUTLET FLOW RATE RESULTING IN VARYING SHOWER FLOW RATE AND FLOW CONTROL RANGE. INLET TEMPERATURE CHANGE MAY ALSO CAUSE THE TEMPERATURE DISPLAY TO FLASH; THIS IS NOT NECESSARILY CHANGING THE OUTLET TEMPERATURE. Special notes for separately pumped gravity systems and universal/negative head pumps (for divert systems) We recommend a MINIMUM pump rating of 1.5 bar. For optimum performance a 2.5 bar pump should be used for all separately pumped installations. A twin ended pump is required for use with single outlet products. A universal/negative head type twin ended pump (works on both positive and negative head conditions) MUST be used with divert products. The minimum actual capacity of the cold water storage cistern should be not less than 225 litres (80 gallons). The capacity of the hot water cylinder must be capable of meeting the anticipated demand. THIS PRODUCT IS NOT SUITABLE FOR USE WITH A SINGLE ENDED PUMP. Shower Heads The range of shower heads has been designed for use with RiseTM systems. Installation of any shower heads other than these may result in poor shower performance. If at any stage during installation you have any questions then please contact the Aqualisa Customer Service Department on 01959 560010 for advice. Connections This product incorporates 15mm `push-fit' type connections. Tube should be cut using a rotary type cutter and lubricated using a silicone grease, petroleum jelly, or similar, prior to insertion into the fitting. 15mm pipework must be used to connect the product. If plastic pipe is used, the tube insert must not increase the tube diameter or extend the cut-off length by more than 2mm. THESE FITTINGS ARE NOT SUITABLE FOR STAINLESS STEEL TUBE. COMPRESSION FITTINGS MUST NOT BE USED. Pipe sizing PLEASE NOTE: Check pipe size requirements for connections to outlets and accessories. Long pipe runs, on both inlet and outlet, will reduce the flow rate at the shower head, 22mm pipe work should be used on inlets and reduce down to 15mm as close to the valve as possible to reduce pressure losses and help maintain flow rate. If using 15mm pipe, copper pipe is preferred, to optimise performance minimise the number of elbows used. If long pipe runs are unavoidable on the outlet, use copper pipe rather than plastic, particularly if a diverter is used, and minimise the number of elbows as the pipe inserts are very restrictive. RiseTM Installation Guide 03 Flushing Some modern fluxes can be very corrosive and, if left in contact, will attack the working parts of this unit. All soldering must be completed and the pipe work thoroughly flushed out in accordance with current local and national Water Supply Regulations prior to connection of the product. Declaration of conformity Aqualisa Products Limited declares that the Quartz Smart ValveTM and controller, in conjunction with the diverter and remote control, complies with the essential requirements and other relevant provisions of the Low Voltage Directive (2014/35/EU) and the EMC Directive (2014/30/EU). After installation Familiarise the end user with the operation of this product and hand them this guide. Complete and post the guarantee card or register online at www.aqualisa.co.uk RiseTM Installation Guide 04 COMPONENTS Concealed components (HP/Combi) Mains fed and separately pumped water systems only Concealed components (Gravity Pumped) Gravity stored water systems only Exposed components (HP/Combi) Mains fed and separately pumped water systems only Exposed components (Gravity Pumped) Gravity stored water systems only RiseTM Installation Guide 05 WALL MOUNTED COMPONENTS CEILING MOUNTED COMPONENTS RiseTM Installation Guide 06 Ceiling mounted fixed head Wall mounted fixed head RiseTM concealed with adjustable height head RiseTM exposed with adjustable height head RiseTM Installation Guide 07 SYSTEM LAYOUT DIAGRAMS Typical gravity system installation (compatible with pumped Quartz Smart ValveTM) Supply NB: THE BASE OF THE QUARTZ SMART VALVETM MUST BE SITED NO HIGHER THAN THE BASE LEVEL OF THE CISTERN Cold feed to cylinder Connect `A' or `B' B A 10m max Shower controller Hot water cylinder Typical UHW system installation (compatible with standard Quartz Smart ValveTM) Supply Shower controller 10m max Hot water cylinder Typical thermal storage unit system installation (compatible with standard Quartz Smart ValveTM) Central heating boiler Shower controller 10m max Supply RiseTM Installation Guide 08 Typical combination boiler installation (compatible with standard Quartz Smart ValveTM) Shower controller 10m max Pressure reducing valve if required Supply Typical pumped system installation (compatible with standard Quartz Smart ValveTM) Supply Underside of cistern Cold feed to cylinder B Connect A `A' or `B' Shower controller 10m max Hot water cylinder NB: 1.5 bar MINIMUM universal pump rating RiseTM Installation Guide 09 INSTALLATION ! This product must be installed by a competent person in accordance with the relevant Water Supply Regulations. Prior to installation, ensure all additional guides supplied with this product are read and understood. In addition to the guide below, it is essential that the important information (above) is read and understood and that you have all the necessary components before commencing installation. The RiseTM shower system is supplied with universal fixings intended to secure it to a suitable wall. DIGITAL TV INTERFERENCE Although the Quartz Smart ValveTM complies with all relevant EMC standards, if incorrectly sited, it may interfere with digital TV reception. Please follow the recommendations below to minimise this effect. If TV interference is an issue a service kit is available (part no: 652102). See recommended layouts below. Images of Quartz Smart ValveTM for illustration only, refer to instruction 1 for orientation. Valve colour may vary the Original QuartzTM valve being black, and the Quartz Smart ValveTM being orange. DATA CABLE LARGEST POSSIBLE DISTANCE AERIAL CABLE TO TV POWER CABLE LOWEST PROBABILITY OF INTERFERENCE DATA CABLE AERIAL SHORT DISTANCE HIGH PROBABILITY OF INTERFERENCE, BOTH RADIATED AND CONDUCTED POWER CABLE CABLE TO TV LAYOUT WHICH COULD CAUSE PROBLEMS · Route cables separately, and as far apart from each other as possible. · Aerial to point away from the Quartz Smart ValveTM. · Ensure the distance between the Quartz Smart ValveTM and the aerial is as large as possible. Installation videos are available on our website www.aqualisa.co.uk/installation-videos or alternatively, scan the QR codes on the reverse of this guide. RiseTM Installation Guide 10 1 To ensure safe operation and installation of this product, the Quartz Smart ValveTM MUST be installed in one of the orientations shown. 450 mm 221700mmmm 70 mm 300 mm 210 mm 70 mm 300 mm 210 mm 450 mm 2 Isolation valves are supplied with the Quartz Smart ValveTM and must be fitted on both inlets and the blended water outlet. All pipe work should be run in 15mm pipe. All pipe work should be supported. For gravity fed installations, 22mm pipe work should be run as close to the Quartz Smart ValveTM as possible before reducing down to 15mm. 210 mm ! To ensure optimum performance we recommend using copper pipe with a minimum number of elbows. ! The inlet supply centres are 48mm. Please note arrow on isolation valve to indicate direction of flow. DO NOT use compression fittings on the inlet and outlet spigots this will affect the warranty if fitted. 3 Choose the position for your Quartz Smart ValveTM as close to the controller as possible. The Quartz Smart ValveTM may be sited in the roof space above the proposed shower site, in the airing cupboard or behind a screwed bath panel if more convenient. For information regarding protecting the Quartz Smart ValveTM from cold/frost, contact Aqualisa Customer Services or refer to the Aqualisa website. Insulation material must not be placed under or on top of the Quartz Smart ValveTM, the location should be where freezing cannot occur. Please refer to the system layout diagrams. Exposed installation example shown The Quartz Smart ValveTM MUST be sited in a position that is safely accessible for servicing and commissioning purposes. When fitted in a loft space, the route to and the area around the Quartz Smart ValveTM must be boarded to ensure a safe working environment. The optimum position for the Quartz Smart ValveTM is in the roof space above the controller site to take full advantage of the ease and speed of installation. The distance between the Quartz Smart ValveTM and the controller must be within the range of the 10m data cable supplied. RiseTM Installation Guide 11 4 Place the Quartz Smart ValveTM on a solid mounting surface, and place the fixing feet into suitable positions. Mark, then drill and prepare suitable fixings before securing the Quartz Smart ValveTM to the mounting surface using the screws provided, (if suitable). 5 01 1/7/15 10:12 Page 2 Flush through both hot and cold supply pipes. ! Refer to safety information section The maximum hot water inlet temperature must be no more than 65°C. 6 Attach the supply pipes to the Quartz Smart ValveTM, ensuring that the cold and hot feeds are fitted into the appropriately marked inlets. ! Do not solder near to plastic components. If you have a concealed system continue with instructions 7-12. If you have an exposed system proceed to instruction 13. 7 Run a pipe from the mixed water outlet of the Quartz Smart ValveTM to the proposed siting for the shower hose outlet, fixed head or diverter depending on the system purchased. ! To ensure optimum performance we recommend using copper pipe with a minimum number of elbows. 8 Place the paper template on the wall in the desired location for the controller and mark all fixing points and the data cable entry point. Remove the template and drill a Ø16mm hole at the appropriate position for the data cable. ! Ensure the data cable is the correct way round as both ends differ in type of connection used (transparent connector to the Quartz Smart ValveTM or diverter). Data cables must be protected by suitable sheathing or conduit in the event of servicing and maintenance. Failure to install this way may invalidate the warranty. Care should be taken to ensure the mounting holes do not pierce the data cable conduit. RiseTM Installation Guide 12 If installing this RiseTM product as a replacement product, it may be necessary to purchase a concealed retro-fit wall plate to cover the existing hole in the tiling. The cavity in the wall should be plugged using a suitable material for the wall plate to be secured to. Contact our Customer Service Department to purchase product code: QZD.B3.RWP.14 Concealed retro-fit wall plate. 9 Drill and prepare the four wall fixings for the controller using the fixings provided, (if suitable). 10 Feed the controller connection end of the data cable through the centre hole in the mounting plate. Run a bead of silicone sealant in the mastic groove on the back of the mounting plate and press into position on the finished wall surface. Ensure the data cable is held securely by the narrow middle slot of the mounting plate and fix to the wall using the brass screws provided. 11 Lining up the key way, push the data cable plug into the back of the controller, ensuring both rubber skirts are recessed into the connection (see diagram below), using a blunt flat bladed screwdriver or similar tool if required. To make a water tight fitting, ensure the rubber seal is no longer visible. Slide the controller onto the mounting plate. 12 Secure the controller onto the mounting plate with the fixing screw located at the base of the controller using a small Pozidriv screwdriver. ! To ensure a watertight seal, we recommend running a thin bead of silicone around the concealed controller once it has been secured to the mounting plate. If you have an exposed system continue with instructions 13-24. If you have a concealed system proceed to instruction 25. 13 Locate a suitable entry point into the ceiling for the riser rail, avoiding joists and services. ! The centre of the riser rail stands 45mm from the wall. If this is not suitable, the spacers provided with the fixing brackets will increase the depth to 70mm from the wall. RiseTM Installation Guide 13 14 Drill a hole through the ceiling, a minimum of Ø30mm, maximum Ø40mm. 15 Feed the riser rail assembly containing the supply pipe and data cable through the hole in the ceiling, ensuring the controller is at the desired height, the rail is vertical, and that there is adequate working clearance above the top of the rail in the roof space. ! DO NOT use a compression fitting to connect the outlet pipe to the top of the RiseTM exposed product. This will affect the warranty. The black push fit elbow provided MUST be used. This connection MUST be sited in a position that is safely accessible for commissioning, servicing and maintenance purposes. If the ceiling height is over 2.4m (8ft), a riser rail extension kit will be required. Contact our Customer Service Department to purchase a riser rail extension kit (part no: 223217). 16 Temporarily slide the gel hook up the rail ensuring it is positioned above the lower fixing bracket assembly. 17 Place the lower bracket support pillar into position ensuring the locking lug is correctly fitted into the location hole in the rail. 18 Carefully slide the fixing bracket over the rail onto the support pillar. RiseTM Installation Guide 14 19 Ensuring the rail assembly has been passed through the hole in the ceiling and is at the desired height, mark the screw holes and remove the fixing bracket. 20 Prepare suitable fixings and slide the fixing bracket back over the rail onto the support pillar. Secure to the wall using the screws provided. 21 Place the upper rail bracket support pillar into the desired location ensuring that both the hose restraint and the Aqualisa Pinch GripTM holder are below the rail wall bracket. 22 Slide the fixing bracket over the rail onto the support pillar and repeat fixing procedures 18-20. 23 Carefully slide the rail end covers onto the fixing brackets flush with the finished wall surface and click the sides firmly into position. RiseTM Installation Guide 15 24 Slide the ceiling plate up to the ceiling to cover the entry hole. ! The ceiling plate cannot be sited against an uneven surface. If there is coving or an alternative obstruction, please ensure the entry hole is neat and unobtrusive; otherwise the inner tube could be visible within the showering area. For both concealed and exposed systems continue with instructions 25-27. 25 Connect the outlet pipe to the mixed water outlet on the Quartz Smart ValveTM. Using pipe clips as appropriate, ensure that all pipe work is perpendicular to the Quartz Smart ValveTM, i.e. not putting any strain on the fittings. ! Before any electrical adjustment is attempted, the electricity supply must be turned off at the mains switch. Electrical installation may only be carried out by a qualified person. All copper pipe work must be cross-bonded and connected to a reliable earthing point. 26 Connect the Quartz Smart ValveTM power lead to a double pole 3 amp fuse switched spur incorporated in the fixed wiring circuit, in accordance with current wiring rules (refer to safety information section). Ensure that this is located in an accessible, dry location and not in the bathroom. ! THIS APPLIANCE MUST BE EARTHED We recommend protecting surface mounted cables in suitable approved conduit to avoid the risk of damage from vermin. The power lead should also be clipped in place with `P' clips or similar to avoid accidents. RiseTM Installation Guide 16 27 Loosen the single fixing screw on the top of the Quartz Smart ValveTM and then carefully tilt the lid up and off the location lugs, and set the lid aside. Plug in the transparent connector of the low voltage, 10m data cable into the socket adjacent to the temperature adjuster as indicated on the label. Feed the cable out of the Quartz Smart ValveTM ensuring it is correctly routed within the data cable channel. ! A further data cable socket has been provided for use with a remote control or diverter. This can be accessed by carefully snapping and removing the entry pillar and connecting the cable as described above. Please refer to the Wired Remote Installation Guide or Diverter Installation Guide for the relevant wiring diagrams. For concealed products, fit the shower head system following the installation instructions overleaf, then proceed to point 31. For exposed products continue with instructions 28-33. 28 Ensuring the hose washers are fitted at either end of the shower hose, attach the hose to the male thread located underneath the controller. Connect the power to the Quartz Smart ValveTM and press the `Start/Stop' button on the controller to turn the shower on. Run the shower for 15 seconds to clear any debris and flush the system through. Turn the shower off and isolate from the electrical supply. 29 Thread the shower hose through the hose restraint. 30 To attach the handset to the hose, disengage the pivot clip from the bottom of the handset by pressing the tab and pulling the pivot hose connector clear. Ensure the hose washer is in the correct position and screw the pivot hose connector into the hose. Re-insert the pivot hose connector into the handset and push the tab to lock into position, then place the handset into the Aqualisa Pinch GripTM holder. For both concealed and exposed systems please follow the remaining instructions. RiseTM Installation Guide 17 31 The Quartz Smart ValveTM is supplied factory set to either `NORMAL HP' mode or `NORMAL GRAVITY' mode depending on which product has been ordered. BALANCED HP SYSTEMS AND SEPARATELY PUMPED GRAVITY SYSTEMS: The standard Quartz Smart ValveTM fits to balanced high pressure systems or separately pumped gravity systems. It may be set to `NORMAL HP', or for water economy, `ECO HP' mode. STANDARD COMBINATION BOILER SYSTEMS: When installed on combi boiler systems, the standard Quartz Smart ValveTM should be set to `COMBI' mode for optimum performance. GRAVITY PUMPED QUARTZ SMART VALVETM: The gravity pumped Quartz Smart ValveTM installed on gravity systems ONLY may be set to `NORMAL GRAVITY', or for water economy, `ECO GRAVITY' mode. ! The `ECO' flow rate mode should NOT be selected for shower or bath systems fitted to combination boilers. ! When making any adjustment to the Quartz Smart ValveTM settings the power MUST be isolated. 32 Reinstate the electrical supply to the Quartz Smart ValveTM. Press the `Start/Stop' button on the controller to turn the shower on. 33 Run the shower at maximum temperature (factory pre set to 45ºC). If required, maximum temperature adjustment can be made with a flat bladed screwdriver using the `MAX TEMP ADJUSTMENT' control as indicated. When the temperature has been set to the desired position, carefully replace the Quartz Smart ValveTM lid and secure the fixing screw, hand tight only. ! Site conditions can affect temperature settings, installer to adjust as required. The RiseTM product has a number of additional functions available. Please note these features are disabled as a factory default. To activate and programme these features please refer to the separate user guide for commissioning and user instructions on how to operate the shower. RiseTM Installation Guide 18 INSTALLATION ADJUSTABLE HEIGHT HEADS 1 Ensure the finished wall surface is even, prepare pipework from the Quartz Smart ValveTM or diverter to the required position for the hose outlet using a Ø15mm copper pipe. Slide the wall spacer down the projecting pipe flush with the finished wall surface. 2 Slide the 15mm gripper ring down the projecting pipe flush with the wall spacer fitting. 3 Trim the projecting pipe to a length of 15-22mm, measured from the face of the gripper ring, using a rotary type cutter. If a hacksaw is used, the pipe end must be carefully de-burred and chamfered. RiseTM Installation Guide 19 4 Clean and lubricate the pipe using a suitable (silicone based) lubricant. 5 Remove the locking screw, rotate the chrome outlet assembly and remove the outlet from the wall mounting plate. 6 Ensuring the locking screw hole is positioned at the bottom, place the wall outlet mounting plate onto the pipe assembly and mark and prepare the fixing points, using the fixings provided, (if suitable). 7 Secure the wall mounting plate to the wall using the screws provided, (if suitable). 8 Place the `O' ring on the recess of the spigot section on the mounting plate, offer the wall outlet onto the mounting plate in the 5 o'clock position and rotate clockwise until a stop is reached. 9 Refit the locking screw taking care not to overtighten. RiseTM Installation Guide 20 10 Drill and prepare 2 holes between 550mm (minimum) and 805mm (maximum) apart using the fixings provided, (if suitable). ! The top rail bracket can be adjusted to suit existing screw holes in the finished wall by sliding the bracket up or down the rail to suit the required position. 11 Pass the rail through the Aqualisa Pinch GripTM holder while keeping the slider levers depressed. 12 Carefully slide the gel hook onto the rail under the Aqualisa Pinch GripTM holder. ! Current Water Supply Regulations state that the handset should not be allowed to pass a point 25mm above the spill over level of the bath or shower tray. If this cannot be achieved, the hose must be passed through the gel hook which has been designed to be utilised as a hose restraint. 13 Fix the top rail bracket into position using the screws provided, if suitable. 14 Slide the rail assembly up through the top rail fixing bracket and temporarily support whilst fixing the bottom bracket. RiseTM Installation Guide 21 15 Fix the bottom bracket to the wall using the screws provided, if suitable. 16 Ensuring the rail cut out aligns with the guide on the rail bracket, slide the rail assembly into position and lock into place. ! If the rail needs to be removed at any stage, insert the special tool provided into the rear of the bottom rail bracket to disengage the rail locking tab. Carefully ease the rail up and away from the fixing bracket. 17 Ensuring the hose washers are in the correct position, attach the hose to the wall outlet. Run the shower for a few seconds to clear any debris that may be present. 18 Pass the hose through the gel hook. 19 To attach the handset to the hose, remove the anti-swivel connector from the handset by pressing the tab in on the retaining clip and pulling the anti-swivel connector clear from the head. RiseTM Installation Guide 22 20 Ensure the hose washer is in the correct position and screw the anti-swivel hose connector into the hose (hand tight). 21 Reattach the hose to the head by inserting the anti-swivel connector back into the bottom of the handset, and then ensuring the tab is pressed to lock the retaining clip back into place. 22 Push the silver accent ring and Aqualisa badge into the centre of the shower head to cover the screw, and remove the protective film. WALL MOUNTED HEAD RiseTM Installation Guide 23 1 Run a 15mm outlet pipe from the Quartz Smart ValveTM/diverter to the preferred position for the fixed head. 2 Cut the outlet pipe to the finished length (55mm 150mm measured from the finished wall surface) using a rotary type cutter. If a hacksaw is used, the pipe end must be carefully de-burred and chamfered. Slide the wall spacer down the projecting pipe flush with the finished wall surface. 3 Slide the 15mm gripper ring down the projecting pipe flush with the wall spacer fitting. 4 Ensure the pipe is clean and free of dust and slide the fixing bush onto the pipe flush with the finished wall surface. 5 Slide the fixed head arm over the fixing bush flush with the wall surface and mark the four fixing points. 6 Carefully remove the fixed head arm and drill and prepare using the fixings provided, if suitable, taking care to avoid pipework hidden in the wall. 7 Ensure the fixing bush is clean and free of dust, fit the 15mm `O' ring against the end of the fixing bush. Lubricate the `O' ring using a suitable silicone based lubricant. ! The `O' ring must be positioned on the 15mm pipe flush to the fixing bush, not onto the fixing bush shaft. RiseTM Installation Guide 24 8 Refit the shower arm and secure it to the wall using the screws provided. 9 Run the shower for a few seconds to clear any debris that may be present. 10 Slide the cover plate into position flush with the finished wall surface. 11 Ensuring the rubber washer is in the correct position, attach the shower head to the fixed arm and carefully secure using a suitable spanner, or a tool with smooth jaws, sufficiently to lock the head into position. RiseTM Installation Guide 25 CEILING MOUNTED HEAD ! The ceiling mounted fixed head is supplied with screws for fixing the product to a noggin. A NOGGIN MUST BE USED AS PART OF THIS INSTALLATION. 1 Run a 15mm outlet pipe from the Quartz Smart ValveTM/diverter to the preferred position for the fixed head. 2 Locate the position for the fixed head in the bathroom and firstly drill a pilot hole to mark the position before checking that there is suitable space behind the ceiling for the fixing assembly. ! The minimum height required behind the ceiling is 50mm and the space must allow for an 80mm wide, 50mm deep noggin to be used to support the assembly. RiseTM Installation Guide 26 3 Drill a hole (minimum ø28mm, maximum ø40mm) through the ceiling and the noggin. 4 Remove the fixing bracket carefully from the fixed head arm. 5 Set the fixing bracket into position and mark the fixing points. Remove the bracket and drill and prepare suitable fixings. Refit the fixing bracket and secure it through the ceiling and into the noggin using the screws provided, (if suitable). 6 Feed the arm through the fixing bracket to the correct depth. Tighten the nut using a 32mm spanner if necessary to facilitate. 7 Cut off the excess pipe allowing for a suitable working length to allow for the required 22mm connection. If a push fit connector is to be used then the pipe must be abraded to remove all chrome plating. 8 Connect the pipe work from the Quartz Smart ValveTM/diverter to the end of the fixed head pipe using a suitable coupling. Fully tighten the nut on the ceiling mounting bracket using a 32mm spanner if necessary to facilitate. ! Run the shower for a few seconds to clear any debris and to check for any leaks. 9 Lubricate the `O' ring if necessary and carefully slide the cover plate back over the fixed head arm and into position against the ceiling. RiseTM Installation Guide 27 10 Secure the cover plate to the arm using the grub screw and 2.5mm hexagonal key provided. 11 Ensuring the rubber washer is in the correct position, attach the shower head to the fixed arm and carefully secure using a suitable spanner, or a tool with smooth jaws, sufficiently to lock the head into position. RiseTM Installation Guide 28 ADJUSTABLE HEAD USER GUIDE ! To avoid residual water dripping from the shower head after use, we advise to tilt the head to allow residual water to drain out. The above recommendation applies to both adjustable and fixed shower heads. RiseTM Installation Guide 29 1. To select one of three spray patterns, rotate the shower spray cassette clockwise or anti-clockwise. 2. To select the preferred height for the shower head, depress the levers fully to enable the Aqualisa Pinch GripTM holder to be moved up or down the rail. 3. Angular adjustment is made by carefully but firmly pulling forwards or pushing back the shower head against the knuckle ratchet in the holder. Fixed head user guide The angle of the fixed shower head can be adjusted. The shower head is mounted on a multi directional ball joint to allow for angular adjustment in any direction by carefully holding the shower head and moving the head to the desired angle. Cleaning and maintenance Your RiseTM shower system should be cleaned using only a soft cloth and washing up liquid. DO NOT USE ABRASIVE CLEANERS To reduce the need for chemical descaling in hard water areas, your shower head incorporates a `clear flow' system, whereby any scale build up can be broken down by gently rubbing the flexible tips of the jets during use. This procedure should be completed regularly, as often as once a week in some hard water areas, as scale build up can affect the spray pattern and cause the shower to perform poorly. Failure to descale the shower head can affect the internal seals and may affect the warranty. Cleaning and maintenance should not be undertaken by children without supervision by a person responsible for their safety. Should chemical descaling of the head become necessary, remove the shower head fully and immerse in a mild proprietary descalent. ! It is imperative that descaling is carried out in accordance with the manufacturer's instructions, substances that are not suitable for plastics and electroplated surfaces must not be used. RiseTM Installation Guide 30 Aqualisa Products Limited The Flyers Way Westerham Kent TN16 1DE Customer Helpline: 01959 560010 Brochure Hotline: 0800 652 3669 Website: www.aqualisa.co.uk Email: enquiries@aqualisa.co.uk Republic of Ireland Sales enquiries: 01-864-3363 Service enquiries: 01-844-3212 Please note that calls may be recorded for training and quality purposes. The company reserves the right to alter, change or modify the product specifications without prior warning. TM Trademark of Aqualisa Products Limited. Part No: 704026 Issue 04 Mar 19Adobe InDesign CC 14.0 (Macintosh) 3-Heights(TM) PDF Optimization Shell 5.9.1.5 (http://www -tools.com)
