Owner's Manual for PORTACOOL models including: PAC2K482S, PAC2K363S, PAC2K361S, PAC2K36HPVS, PAC2K24HPVS, PAC163SVT, PAC2K482S Portable Evaporative Cooler, PAC2K482S, Portable Evaporative Cooler
Manuals - Portacool Evaporative Coolers
portacool owner’s manual for pac2k482s, pac2k363s, pac2k361s, pac2k36hpvs, pac2k24hpvs and pac163svt
PORTACOOL OWNER'S MANUAL FOR PAC2K482S, PAC2K363S, PAC2K361S, PAC2K36HPVS, PAC2K24HPVS and PAC163SVT TABLE OF CONTENTS READ AND SAVE THESE INSTRUCTIONS CONTENTS: QUICK SETUP GUIDE......................................................................... page 2 PRODUCT OVERVIEW .................................................................. pages 3-7 SAFETY INFORMATION ..................................................................... page 8 GENERAL OPERATION ............................................................... pages 9-10 MAINTENANCE AND STORAGE ...................................................... page 11 TROUBLESHOOTING ................................................................ pages 12-13 TECHNICAL SUPPORT AND WARRANTY ............................... pages 14-15 EXPLODED VIEWS .................................................................... pages 16-20 WIRING DIAGRAM ............................................................................ page 21 FREQUENTLY ASKED QUESTIONS................................................ page 22 STOP DO NOT RETURN! For questions or comments, please call Portacool Customer Service at 936-598-5651. QUICK SET UP 1 2 3 4 Remove box and palette Position product on level surface Fill sump or attach water hose 5 For setup, pads should appear wet before starting the fan. Check the water gauge to monitor water level in tank.The water flow valve on each unit is set at max flow. However, ensure the knob is turned completely to the left before use. Turn to the left to increase water flow. Less water is required for cooling in more humid environments. Fill the tank, then turn on the pump switch and the fan. Plug into appropriate outlet 16" VERTICAL TANK OVERVIEW PAC163SVT This unit does NOT have a hose fill option. Water Adjustment Valve Control Panel Cord Wrap Electrical Plug Manual Water Fill Gauge Locking 3 Casters Drain Plug 24" HP OVERVIEW Water Adjustment Valve Control Panel Hose Connection Pad Flap Locking Casters Electrical Plug 4 36" OVERVIEW PAC2K36HPVS Water Adjustment Valve Control Panel Cord Wrap Hose Connection Electrical Plug Locking Casters 5 48" OVERVIEW PAC2K482S Water Adjustment Valve Hose Connection Control Panel Cord Wrap Electrical Plug Locking Casters 6 SAFETY INFORMATION OPERATION WARNINGS 1) Not intended for use by children 2) Not intended for use by persons with reduced physical, sensory, or mental capabilities 3) Not intended for use by persons with lack of experience and knowledge, unless they have been given instruction and are supervised during operation 4) Children should be supervised to ensure they do not play with the evaporative cooler SAFE OPERATION To reduce the risk of electric shock, fire, or injury: · Do not operate any product with a damaged cord or plug. Discard product or return to place of purchase for examination and/or repair. · Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Arrange cord away from traffic area so it will not be tripped over. · Read instructions and labels carefully. · Always unplug the electric cord to the Portacool evaporative cooler before performing inspections or repairs. · Plug into three-prong grounded GFCI protected electrical receptacle only. · Do not step on or roll over power cord with heavy or sharp objects. · Do not operate evaporative cooler unless all pads are securely in place. · Remove the plug from the electrical receptacle by pulling on the plug and not the cord. · Test the GFCI receptacle or breaker monthly to ensure it is functioning properly. · Do not operate near open containers of flammable liquids or gases. · Ensure evaporative cooler pumps are running continuously to saturate and wet combustible media when used in close proximity to open flame or spark producing activities. A distance of at least 35 feet away from open flame or sparks is recommended to ensure safe operation. · Never wash the evaporative cooler cabinet with a garden hose; water may harm the motor and electrical system. · If the product is damaged or malfunctions, do not continue to operate it. Refer to the warranty, troubleshooting or FAQ section, call Portacool, LLC, Technical Support at 1-888-266-5243, or email support@portacool.com. 7 GENERAL OPERATION Electrical Connection PRODUCT MUST BE IN UPRIGHT POSITION WITH COOLING PADS INSTALLED! All models utilize a single power cord and control switches. Before connecting the plug to an outlet, ensure there is no standing water where the cord may lie or where the operator is standing. The use of separate multiple outlet devices is not recommended. When making electrical connections, ensure compliance to local and national codes. Use only with GFCI Protected Receptacles. Please refer to the Barcode Product Label on the side of the product for specific electrical requirements. OPERATING PROCEDURES Specifications Each Portacool evaporative cooler has its own set of operational specifications, sizes, weights, voltage frequency, current requirements, etc. Please ask for the specifications for your model from your distributor, check the serial number plate, or visit www.portacool.com for the specifications for your product. Placement of the Portacool Evaporative Cooler There are three primary considerations when deciding where to place the Portacool evaporative cooler. 1) Make sure there is a clear, unobstructed path to provide maximum airflow. 2) If the evaporative cooler is positioned on a raised platform, ensure the platform constructed for holding the product is stable, well constructed, and will not allow the product to tip over and that it allows for the full weight of the evaporative cooler including water in the tank. The product must be level and in the upright position. 8 3) If placed near a wall or other obstruction, position the product a minimum of 3 feet (0.9 meters) from the wall or obstruction with pads facing the wall. This allows the unrestricted flow of warm air to the cooling pad side of the product. When using multiple products in close proximity, be sure to aim the product so the air flows complement each other to achieve maximum cooling capacity. Starting the Pump and Adjusting the Water Flow Once the water tank is full, moving the pump switch to the "ON" position will turn on the pump. When initially turning on the pump, the level in the water tank will drop suddenly and restart the flow of supply water. This is a normal condition, as the cooling pads require a large amount of water for proper wetting. When the Portacool evaporative cooler is new, the new pads will require an initial `breaking-in' period. This period is required for the pads to begin readily absorbing water. It may require up to a week to achieve maximum efficiency. It is important to ensure that the spray bar is properly adjusted when first starting the water flow in the Portacool evaporative cooler. Increasing the flow using the water flow valve (see Quick Setup on page 2) makes this adjustment. Proper water adjustment should leave the pads saturated with water, but not flooded. Pads should appear wet. However, cascading amounts of water can actually reduce cooling efficiency. Proper adjustment will prevent problems and increase cooling capacity. When properly adjusted, one or two dry streaks will appear across the pads. When turning the evaporative cooler off at the end of the day or week, the pump should be turned off about 15 minutes before the fan to allow the cooling pads to dry. This will increase the life of the pads. Starting the Portacool Evaporative Cooler COOLING PADS MUST BE INSTALLED AND CASTER LOCKS MUST BE ENGAGED Start the fan by turning the fan switch to the `ON' position. Step slowly through the speeds allowing the fan to obtain its full speed at the LOW speed before going to HIGH. 9 MAINTENANCE & STORAGE MAINTENANCE 1) Keep the product clean to ensure peak operating performance. 2) The rugged, corrosion-resistant construction ensures low maintenance will be required. However, in dusty or dirty environments, optional filters are available from your distributor or at www.portacoolparts.com. Daily Maintenance The pump should be turned off approximately 15 minutes before the fan is turned off. This will allow the cooling pads to dry out and extend their life. This also helps control the growth of mildew, mold, bacteria, and other odor-causing elements. Weekly Maintenance The product should be shut down and the water tank should be drained once a week. Closing the water flow valve and removing the drain plug will accomplish this. Once the water tank is drained and the power disconnected, the pads may be removed to allow cleaning of the water tank. Dust may collect in the water tank over time. Replace pads in correct airflow direction, referring to the label on the pads. Storage 1) Drain all water from the water tank and wipe clean, ensuring the pads and water tank are completely dry. 2) Roll up the electrical power cord and secure it to ensure it will not be rolled over, tripped over, or caught in equipment. 3) Cover the product completely to prevent dust build-up and store in a dry area. This also helps to prevent damage to the pads. Optional dust covers are available from your distributor or at www.portacoolparts.com. 10 TROUBLESHOOTING The Portacool evaporative cooler consists of three systems -- the fan system, the electrical system, and the water system. It is important to determine with which of the systems the problem is associated. Certain problems may be associated with more than one system. A careful check of all systems should be made to fully understand the extent of the problem. CAUTION -- DISCONNECT POWER BEFORE REMOVING COOLING PADS FROM THE PRODUCT! NOTICE -- POWER CORD MAY BE REPLACED ONLY BY THE MANUFACTURER OR QUALIFIED AGENT! Repair and Replacement Procedures Ensure all water is removed from the Portacool evaporative cooler and all power is disconnected. Remove all impediments to access the component you are checking or replacing. REPLACING THE COOLING MEDIA PADS The flap must be removed to allow access to the cooling pads. Start with the center pad, which can be tilted out from the top and lifted out of the drain trough. The two pads to either side of the center pad may then be removed in the same manner. To remove the two outside pads, they must first be pulled sideways toward the center of the Portacool evaporative cooler until they clear the side retainer before removing in the same manner as the other pads. 1) Locate the screw in the rear of the unit on the upper right side of the pad flap. 2) Remove screw and lower pad flap to vertical position. 3) Once the pad flap is moved, grasp the middle pad and tilt out at a 90 degree angle. 4) Pull the pad up to remove from unit. Repeat for other pads. 11 The following troubleshooting guide is intended to address the most common symptoms which may occur. If you are unable to resolve the issue, please call Technical Support. Turn off all power to the evaporative cooler before attempting to troubleshoot any of the following symptoms. SYMPTOM POSSIBLE CAUSES REMEDY Product fails to start or deliver air Product starts but air delivery inadequate Water draining from cooler Musty or unpleasant odor 1. No electrical power to product A. Circuit breaker tripped B. GFCI tripped C. Cord(s) unplugged or damaged 2. Motor overheated and/or frozen 1. Insufficient air exhaust 2. Insufficient water pad not wet A. Cooling pads plugged B. Dry streaks on pads C. Large dry spots on pads D. Pump not working E. Loose water connections 1. Seat in float valve leaking 2. Drain bushing/cap not tight 1. Stale or stagnant water in sump 2. Pads mildewed or clogged 3. Pads not completely wet before cooler is turned on 1. Check power A. Reset breaker* B. Reset GFCI* C. Plug in cord(s) or replace if damaged * If condition persists, call electrician 2. Replace motor 1. Open windows or doors 2. Check water distribution system A. Clean or replace pads B. Check water level C. Make sure cooler is level, clean spray bar D. Clean or replace pump E. Check for leaks and correct 1. Replace float valve 2. Tighten fitting and/or cap 1. Drain, flush and clean sump 2. Replace pads 3. Turn on pump before starting fan Knocking, shaking, or rattling sounds Water droplets in the discharge air stream 1. Loose parts 2. Fan blade rubbing shroud 1. Too much water delivered to the cooling pads 2. Outdoor humidity level is too high or it is raining 3. Leaking hose 1. Check and tighten where needed 2. Inspect and adjust, or replace 1. Make sure pads are properly positioned in the frames and product is level 2. Use cooler as a fan only (turn pump off) or discontinue use of product until outdoor humidity level drops. 3. Tighten connection or replace hose TECHNICAL SUPPORT TECHNICAL SUPPORT Technical support and service is available directly from your distributor or call Portacool, LLC Technical Support Hot Line at 888-266-5243 for the distributor nearest you. You may also contact the Support Hot Line for consultation on troubleshooting and parts replacement. Please have serial number and model number of product available. WARRANTY AND REPLACEMENT PARTS PORTACOOL® Evaporative Cooler Limited Warranty For one (1) year from date of purchase, Portacool, LLC (hereafter "Portacool") warrants any original component part or parts of its PortacoolTM portable evaporative coolers (the "Equipment") that are found, upon examination by factory-authorized personnel, to be defective in material or workmanship, excepting, however, that the following component motors shall be warranted by Portacool for a period of three (3) years from the date of purchase: MOTOR-013-04, MOTOR-010-07, MOTOR-012-06, MOTOR-012-05 and MOTOR-034-01. All transportation charges for shipment of the Equipment and/or its component parts that are submitted for replacement or repair under this warranty must be borne by the purchaser. If the Equipment and/or its original component parts develop a defect covered by this limited warranty within the applicable time periods described above, the same will be repaired or replaced at Portacool's option. In the case of a breach of any implied or written warranty relating to the Equipment and/or its component parts, Portacool shall not be liable for any incidental or consequential damages, and the limits of liability against Portacool for any such breach shall not exceed the cost of replacement or repair of the Equipment. This warranty is void if the Equipment and/or its component parts are found to have been misused, abused, repaired by or tampered with by unauthorized or unqualified personnel. 13 RETURNS Returned Merchandise Authorization (RMA) Procedures All Portacool evaporative coolers, parts, or materials being returned to Portacool, LLC for warranty replacement or repair require an RMA (Return Merchandise Authorization) number. Warranty parts can be replaced by: 1. The distributor can purchase the part with an RMA number and will only be charged for the cost of the part, not for the shipping. When the defective part is returned freight paid, the distributor's account will be credited for the cost of the part. 2. The defective part need to be returned to Portacool, LLC, labeled with the RMA number within 90 days of receipt of replacement parts. 3. The customer / distributor can call Tech Support to get an RMA number to send the defective part back to Portacool, LLC. Once the part is received by Portacool, a replacement part will be sent at no charge. Information needed to get an RMA number: 1. The product serial number or manufacturer date code 2. The product model number (ex. PAC2K363S) 3. The part number or description of the part to be replaced Only major component parts need an RMA number, i.e. fans, motors, pumps, and some plumbing parts. For replacement of small parts, the serial and model numbers are still required, but the parts do not need to be returned to Portacool, LLC. For warranty replacement parts call Portacool® Technical Support at 1-888-266-5243. FAX: 936-598-1431. Shipping Address Mailing Address: Portacool, LLC Portacool, LLC 721 FM 2468 P.O. Box 2167 Center, Texas 75935 Center, Texas 75935 To expedite your request, please submit the RMA form found on our website at info.portacool.com/returnshold 14 16" VERTICAL TANK PARTS PAC2K163SHD 21 25 4 2 5 15 29 28 6 12 REVISED 02/12/15 11 17 22 22 20 9 24 24 23 17 22 3 3 22 26 27 3 26 19 16 13 10 18 14 3 8 # PART # 1 BONNET-03 2 BOX-UL-01 3 CLAMP-01 4 CTRL-3SPD-02 5 DRAIN-PLUG-01 6 FAN-ASSM-15 7 FLAP-16-01 8 FLOAT-02 9 HOSE-FM18 10 HOSE-FTG-05 11 MESH-PAC-05 12 MOTOR-012-04E 13 PAC-PLB-01 14 PAD6024/G 15 POWERCORD-01F DESCRIPTION # PART # SPRAY BAR BONNET 16 PRES-REG-01 3 SPD ELECTRICAL BOX 17 PUMP BRACKET 1/2" CLAMP FOR PLASTIC TUBE 18 PUMP-0150-1 3-SPD HARNESS W/SALZER SWITCH 19 PVC-ADP-01 DRAIN PLUG 16 PAC 20 S-004 16" VT FAN BLADE 21 S-006 FRONT FLAP FOR 16" 22 S-009 FLOAT VALVE 23 SPRAY-07 1/2" X 18" F/M HOSE 24 SPRAY-ACC-04 FEM/FEM 3/4" BRASS SWIVEL 25 SWITCHPL-REV3SP FAN SCREEN 26 TUBE-01 16" HD,FC,VT 3 SPD MOTOR 27 VALVE-01 BRASS INLET FITTING 28 VENT16-INJ-01 PAD FOR 16" UNIT (3 per unit) 29 VENTURI-MNT-01 16' POWER CORD W/STRAIN RELIEF DESCRIPTION WATER PRESSURE REGULATOR PLASTIC PUMP COVER/BRACKET PUMP 1/70HP W/NETTING 3/4 X 1/2 ADAPTER 1/4-20 X 1/2" BOLT FOR FLOAT #12 X 1 1/4" TEK SCREW 10-24 x 3/4" TRUSS HEAD SCREW SPRAY BAR FOR 16" PAC CLAMP FASTENER 1029 SWITCH CVR PLATE REVERSE 3SPD 1/2" PLASTIC TUBE (PER FOOT) 1/2" GATE VALVE INJECTION MOLDED VENTURI N/S H/D MOTOR MOUNT FRAME 220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance 16" VERTICAL TANK PARTS PAC163SVT 21 14 25 3 8 16 4 1 24 5 22 2 24 23 6 13 9 27 20 12 18 10 29 15 REVISED 02/17/2015 11 22 24 26 7 28 26 6 19 # PART # DESCRIPTION # PART # DESCRIPTION 1 BASE-JS/VT CASTER BASE ASSEMBLY FOR JS/VT 16 POWERCORD-03F 10FT POWER CORD W/STRAIN RELIEF/ NUT/WASHER 2 BONNET-03 SPRAY BAR BONNET FOR 16" PAC 17 PAD6024/G 16" PAC REPLACEMENT PAD 3 BOX-UL-01 3SPD ELECTRICAL BOX 18 POLY-FTG-06 90DEG FITTING FOR SIGHT TUBE 4 CASTERS-HD-4 4" JS/VT HEAVY DUTY NON-LOCKING CASTER 19 PUMP-0140-1 PUMP ASSEMBLY FOR 16" UNIT 5 CASTERS-HD-4L 4" JS/VT HEAVY DUTY LOCKING CASTER 20 PUMP-ACC-17 JS/VS PUMP BRACKET 6 CLAMP-01 1/2" WIRE SPRING CLAMP 21 S-006 12-14 BLACK TEC SCREW 7 CTRL-VLV-BRKT-1 CONTROL VALVE MOUNTING BRACKET 22 S-009 10-24 X 3/4" TRUSS HEAD SCREW 8 CTRL-3SPD-02 3SPD SWITCH HARNESS 23 SPRAY-07 SPRAY BAR FOR 16" PAC 9 DRAIN-PLUG-34 1/4" NPT PLUG #P-28 FOR 16"UNIT 24 SPRAY-ACC-04 CLAMP FASTENER FOR SPRAY BAR 10 FAN-ASSM-15 16" VT FAN BLADE 25 SWITCHPL-REV3SP 3SPD SWITCH COVER PLATE 11 FLAP-16-01 FRONT FLAP FOR 16" JETSTREAM 26 TUBE-01 SOFT PLASTIC TUBE 12 JS-ACC-01 2" THREADED FILLER CAP RING 27 TUBE-03 SIGHT TUBE 13 JS-ACC-02 2" THREADED FILLER CAP 28 VALVE-01 PUMP TO SPRAYBAR CONTROL VALVE 14 MESH-PAC-05 FAN GUARD SCREEN FOR 16" UNITS 29 VENT16-INJ-01 VENTURI FOR 16" FAN 15 MOTOR-012-04E 16" HD, FC,VT 3SPD MOTOR 220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance 17 16 24" HIGH PERFORMANCE PARTS PAC2K24HPVS 8 35 30 4 12 18 5 9 1 24 6 72 31 20 7 38 29 13 19 11 Revised 02/25/15 32 3 34 15 17 28 22 25 21 16 27 34 33 37 10 14 26 23 36 # PART # DESCRIPTION # 1 BASE-2K24 CADDY 20 2 BLADE-ASSM-02 VOSTERMAN 24" FAN BLADE ASSY. (33deg.) 21 3 BONNET-02 SPRAY BAR BONNET FOR 24" PAC 22 4 BOX-UL-03 VARIABLE SPEED ELECTRICAL BOX 23 5 BRACE-24-01 BONNET STEEL BAR 24 6 CASTERS-HD-4 SWIVEL CASTER 25 7 CASTERS-HD-4L LOCKING SWIVEL CASTER 26 8 CTRL-KNOB-02 D-SHAFT KNOB FOR CONTROL SWITCH 27 9 CRTL-VS-02 SWITCH SET FOR 24" HPVS UNIT 28 10 DRAIN-01 1/2" BOILER DRAIN 29 11 FAN24HP-MNT-01 MOTOR MOUNT ARM FOR 24" HPVS UNIT 30 12 FLAP-24-01 FRONT FLAP FOR 24" PAC 31 13 FLOAT-02 FLOAT VALVE 32 14 HOSE-FF30 1/2" X 30" FEM/FEM HOSE TO PLB TO PUMP 33 15 HOSE-FF37 1/2" X 37" FEM/FEM HOSE TO SPRAYBAR TO PLB 34 16 HOSE-FM22 1/2" X 22" MALE/FEMALE HOSE TO FLOAT 35 17 HOSE-FTG-05 FEM/FEM 3/4" X 3/4" BRASS SWIVEL 36 18 MESH-PAC-03 FAN SCREEN FOR 24" PAC 37 19 MOTOR-012-06 1/3 HP DIRECT DRIVE VOSTERMAN MOTOR 38 PART # LOCKNUT-FNG-516 PAC-PLB-01 PAC-PLB-02 PAD6036/G POWERCORD-01F PRES-REG-01 PUMP-016-4Z PUMP-ACC-15 PVC-ADP-01 S-004 S-006 S-007 S-009 SPRAY-04 SPRAY-ACC-04 SWITCHPL-VSPD-T TROUGH-02 VALVE-01 VENTURI-24-02 DESCRIPTION 5/16-18 FLANGE NYLON INSERT LOCK NUT BRASS INLET FITTING BLACK PLUMBING ASSEMBLY PAD FOR 24" PAC (4 per unit) 16' POWER CORD ASSEMBLY WATER PRESSURE REGULATER SUBMERSIBLE 1/6 HP PUMP PUMP BRACKET- 1/6 HP PUMP 24" PAC 3/4" X 1/2" REDUCING ADAPTER 1/4-20 X 1/2" BOLT FOR FLOAT #12 X 1 1/4" TEK SCREW 5/16" TRUSS HEAD SCREW FOR CASTER 10-24 X 3/4" TRUSS HEAD SCREW SPRAY BAR FOR 24" PAC CLAMP FASTENER 1029 SWITCH PLATE FOR HP UNIT PAD TROUGH FOR 24" PAC 1/2" GATE VALVE PLASTIC VENTURI FOR 24"HPVS UNIT 220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance 36" SINGLE-SPEED PARTS PAC2K361S 13 32 19 4 37 36 16 10 5 25 1 22 33 89 40 3 30 18 26 31 12 17 23 29 14 2 7 27 21 20 # Revised 02/25/15 1 34 2 6 3 35 4 36 5 39 6 11 7 15 8 9 28 10 24 11 12 13 14 15 16 17 18 38 19 20 PART # DESCRIPTION # BASE-2K36 CADDY 21 BEARING-FAN-01 BEARING FOR 24" & 36" PAC 22 BELT2K-38-01 A-38 FAN BELT 23 BONNET-01 SPRAY BAR BONNET 24 BOX-UL-02 1 SPD ELECTRICAL BOX 25 BRACE-36-02 BONNET BRACE 26 BRACE-36-03 36" PULTRUSION ASSEMBLY 27 CASTERS-HD-4 HEAVY DUTY CASTER 28 CASTERS-HD-4L HEAVY DUTY LOCKING CASTER 29 CTRL-1SPD-01 1 SPEED SWITCH SET 30 DRAIN-01 1/2" BOILER DRAIN VALVE 31 FAN-ASSM-01 PLASTIC BLADE & HUB ASSEMBLY FOR 36" PAC 32 FLAP-36-01 FRONT FLAP FOR 36" 33 FLOAT-02 FLOAT VALVE 34 HOSE-FF24 1/2" X 24" FEM/FEM HOSE PUMP TO PLB 35 HOSE-FF50 1/2" X 50" FEM/FEM HOSE PLB TO SPRAYBAR 36 HOSE-FM30 1/2" X 30"FEM/MALE HOSE INLET TO FLOAT 37 HOSE-FTG-05 FEM/FEM 3/4" BRASS SWIVEL 38 MESH-PAC-02 FAN SCREEN 39 MOTOR-012-01STA 1SPD STUD MOUNT MOTOR (PRODUCED W/9K922B) 40 PART # MOTOR-MNT-01 N-516-NYLOK PAC-PLB-01 PAD6048/G POWERCORD-01F PRES-REG-01 PULLEY-3.75 PUMP-016-4Z PUMP-ACC-13 PVC-ADP-01 S-004 S-006 S-007 S-009 SPRAY-06 SPRAY-ACC-04 SWITCHPL-1SPD TROUGH-01 VALVE-01 VENTURI-36-01 DESCRIPTION MOUNT FOR 36" MOTOR 5/16" NYLOCK NUT FOR CASTERS BRASS INLET FITTING PAD FOR 36" PAC (5 per unit) POWER CORD ASSEMBLY WATER PRESSURE REGULATOR 3.75 O.D. PULLEY L/G 1/6HP SUBMERSIBLE PUMP SUBMERSIBLE PUMP BRACE 3/4" X 1/2" REDUCING ADAPTER 1/4-20 X 1/2" BOLT FOR FLOAT #12 X 1 1/4" TEK SCREW 5/16-18 TRUSS HEAD SCREW 10-24 X 3/4" TRUSS HEAD SCREW SPRAY BAR FOR 36" PAC CLAMP FASTENER 1029 SWITCH COVER PLATE PAD TROUGH FOR 36" PAC 1/2" GATE VALVE 36" RTM FAN VENTURI 220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance 18 36" THREE-SPEED PARTS PAC2K363S 38 33 20 10 5 26 15 1 23 35 89 8 41 3 28 13 4 37 17 27 24 19 18 31 30 32 14 9 2 12 7 22 21 Revised 02/25/15 # 1 PART # BASE-2K36 DESCRIPTION CADDY # PART # 22 MOTOR-MNT-01 DESCRIPTION MOUNT FOR 36" MOTOR 34 2 BEARING-FAN-01 BEARING FOR 24"/36" FAN BLADE ASSEMBLY 23 N-516-NYLOK 5/16" NYLOCK NUT FOR CASTERS 3 BELT2K-38-01 A-38 FAN BELT 24 PAC-PLB-01 BRASS INLET FITTING 6 36 37 40 11 16 4 BONNET-01 5 BOX-UL-04 6 BRACE-36-02 7 BRACE-36-03 8 CASTERS-HD-4 9 CASTERS-HD-4L SPRAY BAR BONNET 3 SPD ELECTRICAL BOX BONNET BRACE 36" PULTRUSION ASSEMBLY HEAVY DUTY SWIVEL CASTER HEAVY DUTY LOCKING SWIVEL CASTER 25 PAD6048/G PAD FOR 36" PAC (5 per unit) 26 POWERCORD-01F 16' ELECTRICAL CORD 27 PRES-REG-01 WATER PRESSURE REGULATOR 28 PULLEY-3.75 3.75 O.D. PULLEY 29 PUMP-016-4Z 1/6 HP SUBMERSIBLE PUMP FOR 36" PAC 30 PUMP-ACC-13 PUMP BRACE 29 25 10 CTRL-3SPD-02 11 DRAIN-01 12 FAN-ASSM-01 3 SPEED SALZER SWITCH SET 1/2" BOILER DRAIN VALVE PLASTIC BLADE & HUB ASSEMBLY 31 PVC-ADP-01 32 S-004 33 S-006 3/4"X1/2" REDUCING ADAPTER 1/4-20 X 1/2" BOLT FOR FLOAT #12 X 1 1/4" TEK SCREW 13 FLAP-36-01 FRONT FLAP FOR 36" 34 S-007 5/16-18 TRUSS HEAD SCREW 14 FLOAT-02 FLOAT VALVE 35 S-009 10-24 X 3/4" TRUSS HEAD SCREW 15 FLOATSWITCH-01 WATER PUMP SHUT OFF SWITCH 36 SPRAY-06 SPRAY BAR FOR 36" PAC 16 HOSE-FF24 1/2" X 24" FEM/FEM HOSE PLB TO PUMP 37 SPRAY-ACC-04 CLAMP FASTENER 1029 17 HOSE-FF50 1/2" X 50" FEM/FEM HOSE SPRAY BAR TO PLB 38 SWITCHPL-3SPD SWITCH COVER PLATE - 3SPD 18 HOSE-FM30 1/2" X 30" MALE/FEM HOSE INLET TO FLOAT 39 TROUGH-01 PAD TROUGH FOR 36" PAC 19 HOSE-FTG-07 FEM/FEM 3/4" BRASS SWIVEL 40 VALVE-01 39 20 MESH-PAC-02 FAN SCREEN 41 VENTURI-36-01 1/2" GATE VALVE 36" FAN VENTURI 21 MOTOR-012-02STA 3 SPD MOTOR 220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance 36" VARIABLE SPEED PARTS PAC2K36HPVS 13 37 32 20 5 8 3 4 9 15 26 1 6 34 22 2 40 36 24 29 27 23 19 31 7 18 30 14 11 21 12 38 Revised 02/25/15 33 36 35 17 39 10 16 28 25 ITEM # PART # 1 BASE-2K36 2 BLADE-ASSM-01 3 BONNET-01 4 BOX-UL-06 5 BRACE-36-02 6 CASTERS-HD-4 7 CASTERS-HD-4L 8 CTRL-KNOB-01 9 CTRL-VS-01 10 DRAIN-01 11 FANHP-BOOTS 12 FAN36HP-MNT-01 13 FLAP-36-01 14 FLOAT-02 15 FLOATSWITCH-01 16 HOSE-FF24 17 HOSE-FF50 18 HOSE-FM30 19 HOSE-FTG-07 20 MESH-PAC-02 DESCRIPTION CADDY VOSTERMAN 36" FAN BLADE ASSEMBLY SPRAY BAR BONNET FOR 36" PAC VARIABLE SPEED ELECTRICAL BOX BONNET BRACE HEAVY DUTYSWIVEL CASTER HEAVY DUTY LOCKING SWIVEL CASTER LONG EXT. KNOB FOR CONTROL SWITCH VAR. SPD. SWITCH SET FOR 36" HPVS 1/2" BOILER DRAIN BOOTS FOR 36" MTR CONNECTS TO ARMS PI-CO 3VP1006 MOTOR SUPPORT ARM- 36" PAC FRONT FLAP FOR 36" PAC FLOAT VALVE WATER PUMP SHUT OFF SWITCH FEM/FEM HOSE 24" LONG FEM/FEM HOSE 50" LONG FEM/MALE HOSE 30" LONG FEM/FEM 3/4" BRASS SWIVEL FAN SCREEN FOR 36" PAC ITEM # 21 22 23 24 25 26 27 28 29 30 31 PART # MOTOR-012-05 N-516-NYLOK PAC-PLB-01 PAD6048/G POWERCORD-01F PRES-REG-01 PUMP-016-4Z PUMP-ACC-13 PVC-ADP-01 S-004 S-006 32 S-007 33 S-009 34 SPRAY-06 35 SPRAY-ACC-04 36 SWITCHPL-VSPD-T 37 TROUGH-01 38 VALVE-01 39 VENTURI-36-01 DESCRIPTION 1/2 HP DIRECT DRIVE VOSTERMAN MOTOR 5/16-18 NYLOK NUT BRASS INLET FITTING PAD FOR 36" PAC (5 per unit) ELECTRICAL CORD FOR PAC WATER PRESSURE REGULATER SUBMERSIBLE 1/6 HP PUMP PUMP BRACKET- 1/6 HP PUMP 3/4" X 1/2" REDUCING ADAPTER 1/4-20 X 1/2" BOLT FOR FLOAT #12 X 1 1/4" TEK SCREW 5/16-18 TRUSS HEAD SCREW 10-24 X 3/4" TRUSS HEAD SCREW SPRAY BAR FOR 36" PAC CLAMP FASTENER 1029 SWITCH COVER PLATE VAR. SPD. PAD TROUGH FOR 36" PAC 1/2" GATE VALVE 36" FAN VENTURI 220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance 20 48" TWO-SPEED PARTS PAC2K482S 33 18 36 8 4 25 13 6 32 7 40 2 27 20 21 21 1 11 35 15 16 23 26 22 14 17 REVISION 02/17/15 31 5 3 34 35 39 9 28 24 30 29 12 38 10 37 19 # PART # DESCRIPTION 1 BASE-2K48 CADDY 2 BELT2K-45-01 A-45 FAN BELT 3 BONNET-04 SPRAY BAR BONNET 4 BOX-UL-02 2 SPD ELECTRICAL BOX 5 BRACE-48-03 BRACE FOR BONNET 6 CASTERS-8 8" CASTERS 7 CASTERS-8L 8" LOCKING CASTERS 8 CTRL-2SPD-01 2 SPEED SWITCH SET 9 DRAIN-01 1/2" BOILER DRAIN VALVE 10 FAN-ASSM-05 FAN BLADE ASSEMBLY FOR 48" UNIT 11 FLAP-48-01 FRONT FLAP FOR 48" PAC 12 FLOAT-02 FLOAT VALVE 13 FLOATSWITCH-01 WATER PUMP SHUT OFF SWITCH 14 HOSE-FF37 1/2" X 37" FEM/FEM HOSE PLB TO PUMP 15 HOSE-FF68 1/2" X 68" FEM/FEM HOSE SPRAY BAR TO PLB 16 HOSE-FM25 1/2" X 25" MALE/FEM HOSE INLET TO FLOAT 17 HOSE-FTG-05 FEM/FEM 3/4" X 3/4" SWIVEL 18 MESH-PAC-06 FAN SCREEN 19 MOTOR-010-01 1HP/2SPD MOTOR FOR 48" UNIT 20 MOTOR-MNT-48 MOTOR MOUNT FOR 48" UNIT # PART # 21 N-516-NYLOK 22 PAC-PLB-01 23 PAC-PLB-02 24 PAD6060/G 25 POWERCORD-01F 26 PRES-REG-01 27 PULLEY-3.25 28 PUMP-016-4Z 29 PVC-ADP-01 30 S-004 31 S-006 32 S-007 33 S-009 34 SPRAY-08 35 SPRAY-ACC-04 36 SWITCHPL-2SPD 37 TROUGH-03 38 UPRIGHTS-48 39 VALVE-01 40 VENTURI-48-02 DESCRIPTION 5/16-18 NYLOK NUT FOR CASTERS BRASS INLET FITTING BLACK PLUMBING ASSEMBLY PAD FOR 48" PAC (6 per unit) ELECTRICAL POWER CORD WATER PRESSURE REGULATOR 3.25 MOTOR PULLEY L/G 1/6HP SUBMERSIBLE PUMP 3/4" X 1/2" ADAPTER 1/4-20 X 1/2" BOLT FOR FLOAT #12 X 1 1/4" TEK SCREW 5/16-18 TRUSS HEAD SCREW FOR CASTERS 10-24 X 3/4" TRUSS HEAD SCREW SPRAY BAR FOR 48" PAC CLAMP FASTENER 1029 2SPD SWITCH COVER PLATE PAD TROUGH FOR 48" PAC UPRIGHT FOR 48" UNIT 1/2" GATE VALVE VENTURI FOR 48" PAC FAN ASSEMBLY 220/50 and 220/60 models require additional parts. Please contact Customer Service for assistance VARIABLE SPD WIRING DIAGRAM 22 ONE-SPEED WIRING DIAGRAM 23 TWO-SPEED WIRING DIAGRAM 24 THREE-SPEED WIRING DIAGRAM 25 FREQUENTLY ASKED QUESTIONS Q. WHAT ASSEMBLY IS REQUIRED? A. None. Portacool evaporative coolers are ready to use right out of the box. Q. HOW DO I PREPARE MY PORTACOOL PRODUCT FOR STORAGE? A. Drain the product, dry out the pads, cover the product, and store in a dry place. Q. I JUST RAN THE EVAPORATIVE COOLER FOR THE FIRST TIME AND THERE'S AN UNPLEASANT ODOR! A. The pads, located in the back of your Portacool product, have never been wet before. The resin in the pads will emit an odor the first time you wet them that lasts approximately one to three weeks. Keep the product in an open area until the odor goes away or put a capful of laundry softener directly in the tank in the bottom of your product. After approximately two weeks of operation, the odor should disappear. Q. MY PORTACOOL PRODUCT ISN'T PUTTING OUT ANY COOL AIR. A. First, make sure the water source and electricity source are connected and working. Second, check to see if the pads are damp. If not, adjust the water flow with the water adjustment valve. Third, make sure there is water in the tank. It should be allowed to fill before you turn the pump on. Q. WHAT IS THE BEST ENVIRONMENT TO PRODUCE THE MOST COOL AIR? A. For optimum performance, the temperature should be 85° F or higher and the relative humidity should be below 75%. However, Portacool products will reduce the temperature in almost any environment, making it more pleasant. Q. HOW OFTEN DO PADS HAVE TO BE REPLACED? A. Depending on the quality of maintenance and frequency of use, pads typically last up to five years. Q. WHAT IS THE DIFFERENCE BETWEEN EVAPORATIVE COOLING AND MISTING SYSTEMS? A. Misting units spray a shower of water into the air that will collect on people, objects, equipment, floors, etc. Portacool products use the process of evaporation to produce cooler air, but do not discharge a mist. Q. WHERE CAN I BUY REPLACEMENT PARTS? A. Replacement parts may be purchased from any Portacool product distributor or directly from Portacool Parts/Technical Support department. You may also visit www. portacoolparts.com to order online. Q. WHAT IS THE AMOUNT OF MOISTURE PRODUCED? A. An increase in humidity of approximately two to five percent is produced, depending on the temperature and humidity of the environment. This increase is not noticeable in a ventilated area where the air produced by the unit is exhausted. Q. HOW LONG WILL THE WATER SUPPLY LAST IN THE TANK? A. With no direct water source available, the water will evaporate in a filled water tank within two to 10 hours of operation, depending on the water capacity of the product, ambient conditions, temperature, and humidity. A water source for refilling the tank is recommended by the manufacturer. Q. WHERE ARE THE MODEL AND SERIAL NUMBERS FOUND? A. The model number can be found on a metal plate on the outside of the product. Model numbers begin with the letters "PAC." Serial numbers are all-digits. Q. WHAT IF MY QUESTIONS AREN'T ANSWERED HERE? A. Our Tech Support staff is available 8 a.m. to 5 p.m. Central Time, Monday though Friday at 1-888-COOL-AID or you can e-mail them at support@portacool.com. CUSTOMER SERVICE CONTACT 1-936-598-5651 · 1-800-695-2942 ORDERS@PORTACOOL.COM TECHNICAL/PARTS CONTACT 1-936-598-5651 · 1-888-COOLAID SUPPORT@PORTACOOL.COM The manual is available in other languages. To download a digital copy, please visit www.portacool.com. El manual está disponible en otros idiomas. Para descargar una copia digital, por favor visite www.portacool.com. Le manuel est disponible en d'autres langues. Pour télécharger une copie numérique, se il vous plaît visitez www.portacool.com. . www.portacool.com VISIT PORTACOOL.COM OR CALL 1-936-598-5651 FOR MORE INFORMATION MANR0003 Portacool, LLC · Manufacturer of PortacoolTM portable evaporative coolers and KÜÜL® Pads evaporative media 709 Southview Circle · Center, Texas 75935 · 936-598-5651 · www.portacool.com · www.kuulpads.comGPL Ghostscript 9.50 Adobe InDesign CC 2014 (Macintosh)
