User Manual for TELTONIKA models including: BTSX, 2A3HUBTSX, BTSMP1, Bluetooth Temperature and Humidity Sensor, BTSID1
UAB TELTONIKA TELEMATICS BTSX Fleet Management System 2A3HUBTSX 2A3HUBTSX btsx
1 BTSID1 BTSMP1 Bluetooth beacon and sensor Quick Manual v1.0 CONTENT Introduction Know your device Configuration Mounting recommendations Product information Certification Safety information Warranty Warranty disclaimer 2 3 4 6 10 12 15 16 17 18 Quick Manual v1.0 // BTSID1, BTSMP1 3 INTRODUCTION This document provides short instruction how to configure BTSID1 Beacon or BTSMP1 Senor and FM tracker. During the use if you will have any questions or suggestions for improvement please feel free to contact yours Teltonika account manager or write to technical support team over VIP helpdesk. Wireless solutions open up new horizons for your business and help to keep an eye on your assets. Discover our brand-new and certified Bluetooth Low Energy ID beacon and sensor models from Teltonika with robust waterproof casing and a long-lifetime battery. The models designed for a low-cost fast and easy configuration and integration to save precious time, resources, and ensure accountability. About BTSID1: Perfect for traceability use cases, delivery tracking, monitoring of various movable objects in logistics (trailers, containers), agriculture (tractor attachments), and constructions (tools and inventory). Also, it suitable for indoor tracking solutions for items tracking in warehouses, hospitals, transport hubs and other types of industrial areas. EYE beacon supports iBeacon and Eddystone protocols. The device is fully compatible with the Teltonika firmware platform which provides extended functionality. About BTSMP1: Perfect for traceability use cases, delivery tracking, monitoring of various movable objects in logistics (trailers, containers), agriculture (tractor attachments), and constructions (tools and inventory). Sensors data makes it especially suitable for cold chain refrigerator use cases. The built-in accelerometer can detect item movement or fall events. Magnet detection can be used for wireless open/close detection and notifications such as trailer door events, etc. EYE sensor supports iBeacon and Eddystone protocols. The device is fully compatible with the Teltonika firmware platform which provides extended functionality. Quick Manual v1.0 // BTSID1, BTSMP1 KNOW YOUR DEVICE 4 MOUNTING HOLES MEMBRANE ONLY WITH BTSMP1 SENSORS Quick Manual v1.0 // BTSID1, BTSMP1 5 What you get: · Bluetooth BTSID1 Beacon or BTSMP1 Sensor designed for easy & fast configuration and integration. · Quick Manual · Mobile application for Android and iOS* phones. Configure, scan, and update anytime anywhere with a EYE APP - Teltonika. *iOS doesn't show devices with iBeacon protocol Quick Manual v1.0 // BTSID1, BTSMP1 6 CONFIGURATION Devices work constantly and are ready to perform out of the box. Default basic Eye Beacon and Sensor settings are set to: · Transmitting at 2 dBm power. · Data advertising at 3 second intervals. · Eddystone protocol If you would like to change these settings you will need to: 1) Download and install EYE APP - Teltonika application to change sensor settings. *iOS doesn't show devices with iBeacon protocol With the application you will be able to scan for visible Teltonika EYE devices, check their statuses or connect for configuration or firmware update. Quick Manual v1.0 // BTSID1, BTSMP1 Devices in view: 7 1 Short list On/Off 2 Detailed view On/Off 3 Search In this window you will see all visible devices. You have options to see devices in Short list (1) or in default list. When looking at devices in default list you will be able to open Detailed view (2) of devices and check transmitted data statuses. Additionaly if you are looking for specific devices you will be able to use Search (3) function to filter search options. When in this window select a device of your choice to connect and after passing pin code you will go to device overview window. Quick Manual v1.0 // BTSID1, BTSMP1 Overview window 8 1 Device details 2 Firmware version 3 Device configuration In overview window you can see device details (1), check firmware version and update if available (2), go to device configuration settings. If you select to Configure (3) device new window will open with Basic and Advanced settings. Quick Manual v1.0 // BTSID1, BTSMP1 Configure window Configure Basic Settings 2 Configure device broadcasted name 2.1 Configure signal strength 2.2 Configure device advertising interval 2.3 Packet settings 2.4 9 1 Save configuration 3 Select to configure Advanced settings. In this window you can check and change device configuration settings. In main tab Basic Settings (1) you can change main settings. Change Device name (2.1), Power signal strength (2.2), Advertising interval (2.3) and Packet (2.4) transmition type. For more settings go to Advanced settings (3) tab to enable various events. Quick Manual v1.0 // BTSID1, BTSMP1 10 MOUNTING RECOMMENDATIONS 1 Placing: Directly place the monitor on the surface such as table, shelf 2 Using the adhesive sticker: Remove the release liner from one side of the adhesive sticker to stick it on the back of the device, then remove the release liner from the other side to stick it at the desired place on the wall 3 Using screws: Place device on the surface and secure it to the surface using two screws Quick Manual v1.0 // BTSID1, BTSMP1 11 4 Ziptie: Lead ziptie thru both device holes and around an object you want device secured to 5 Hanging: Attach lanyard's snap hook to one of the holes Note: Adhesive sticker, screws, lanyard, zipties are not included and sold separately Quick Manual v1.0 // BTSID1, BTSMP1 12 PRODUCT INFORMATION Dimensions and weight Dimensions Weight Technical specifications Model Type Total Capacity Replaceable Battery life (Tx=2 dBm; interval: 3 s) Battery life (Tx=2 dBm; interval: 10 s) Microcontroller Bluetooth Range Available transmission power levels 56,6 x 38 x 13 mm (L x W x H) 18 grams CR2450 Lithium, Manganese Dioxide (Li/MnO2) 600 mAh No 5+ years 10+ years ST Microelectronics BlueNRG-2 Bluetooth 4.2 compliant, Bluetooth 5.2 certified 80m Up to 8 dBm CR2450 Lithium, Manganese Dioxide (Li/MnO2) 600 mAh No 2.5+ years 5+ years ST Microelectronics BlueNRG-2 Bluetooth 4.2 compliant, Bluetooth 5.2 certified 80 m Up to 8 dBm Quick Manual v1.0 // BTSID1, BTSMP1 Technical specifications Sensitivity Material Colors Protection Mounting Customization Operational temperature Certificates Humidity (noncondensing) -88 dBm Plastic Black IP67 Two holes to screw/ leash/strip, tape Custom logo upon request* * Special conditions -20°C / +60°C (-4°F / +140°F) *Possible to have -40°C / + 85°C (-40°F / +185°F) CE RED (EU) FCC (USA) UKCA (UK) RoHS E-mark EAC ANATEL From 0% to 100% 13 -88 dBm Plastic Black IP67 Two holes to screw/ leash/strip, tape Custom logo upon request* * Special conditions -20°C / +60°C (-4°F / +140°F) *Possible to have -40°C / + 85°C (-40°F / +185°F) CE RED (EU) FCC (USA) UKCA (UK) RoHS E-mark EN12830 EAC ANATEL From 0% to 100% Quick Manual v1.0 // BTSID1, BTSMP1 14 Technical specifications ±1.8 (typ.) @30-70% RH ±2 (typ.) @0-30% RH and @70-100% Accuracy ±3.5 (max.) @30-70% RH ±4 (max.) @0-30% RH and @70-100% ±0.2 (typ.) @0-60°C ±0.4 (typ.) @-20-0°C Relative humidity measuring range Temperature measuring range ±0.4 (max.) @0-60°C ±0.7 (max) @-20-0°C ±3.5 (max.) @30-70% RH ±4 (max.) @0-30% RH and @70-100% 0 100 %RH -20 to +60°C *Possible to have -40°C / + 85°C (-40°F / +185°F) ±1.8 (typ.) @30-70% RH ±2 (typ.) @0-30% RH and @70-100% ±3.5 (max.) @30-70% RH ±4 (max.) @0-30% RH and @70100% ±0.2 (typ.) @0-60°C ±0.4 (typ.) @-20-0°C ±0.4 (max.) @0-60°C ±0.7 (max) @-20-0°C 0 100 %RH -20 to +60°C Quick Manual v1.0 // BTSID1, BTSMP1 15 CERTIFICATION 15C This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. (15B)This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. · This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. · The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter and must be installed to provide a separation distance of at least 20cm from all persons. 00647-20-08591 Para maiores informações, consulte o site da ANATEL www.anatel.gov.br Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. For more information, see the ANATEL website www.anatel.gov.br This equipment is not entitled to protection against harmful interference and must not cause interference in duly authorized systems. Quick Manual v1.0 // BTSID1, BTSMP1 16 SAFETY INFORMATION This message contains information on how to operate BTSID1 safely. By following these requirements and recommendations, you will avoid dangerous situations. You must read these instructions carefully and follow them strictly before operating the device! 1. To avoid mechanical damage, it is advised to transport the device in an impact-proof package. 2. In case of malfunction contact yours Teltonika account manager or write to technical support team over VIP helpdesk. Quick Manual v1.0 // BTSID1, BTSMP1 Opening and self fixing devices is strictly forbidden All wireless data transferring devices produce interference that may affect other devices which are placed nearby. The device must be connected only by qualified personnel. The device must be firmly fastened in a predefined location. 17 Installation and/or handling during a lightning storm is prohibited. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. This marking on the product, accessories or literature indicates that product ant its electronic accessories should not be disposed of with other household waste. This Marking on the battery, manual or packaging indicates that batteries in this product should not be disposed with other household waste. Quick Manual v1.0 // BTSID1, BTSMP1 18 WARRANTY TELTONIKA guarantees its products to be free of any manufacturing defects for a period of 24 months. With additional agreement we can agree on a different warranty period, for more detailed information please contact our sales manager. Contact us teltonika-gps.com/about-us/contacts/ WARRANTY DISCLAIMER TELTONIKA PRODUCTS ARE INTENDED TO BE USED BY PERSONS WITH TRAINING AND EXPERIENCE. ANY OTHER USE RENDERS THE LIMITED WARRANTIES EXPRESSED HEREIN AND ALL IMPLIED WARRANTIES NULL AND VOID AND SAME ARE HEREBY EXCLUDED. ALSO EXCLUDED FROM THIS LIMITED WARRANTY ARE ANY AND ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING BUT NOT LIMITED TO, LOSS OF USE OR REVENUE, LOSS OF TIME, INCONVENIENCE OR ANY OTHER ECONOMIC LOSS. More information can be found at teltonika-gps.com/warranty-repair Quick Manual v1.0 // BTSID1, BTSMP1
