B660M Phantom Gaming 4

Please follow the instructions in our manual and chassis manual to install your ... Enable/Disable the Intel AVX and AVX2 Instructions. ... January 21, 2022.

B660M Phantom Gaming 4 - ASRock

Disclaimer: Specifications and information contained in this documentation are furnished for informational use only and subject to change without notice, ...

File Info : application/pdf, 96 Pages, 4.25MB

B660M Phantom Gaming 4

Version 1.0 Published December 2021 Copyright©2021 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this documentation may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners' benefit, without intent to infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for informational use only and subject to change without notice, and should not be constructed as a commitment by ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance controlled in Perchlorate Best Management Practices (BMP) regulations passed by the California Legislature. When you discard the Lithium battery in California, USA, please follow the related regulations in advance. "Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/ perchlorate"
ASRock Website: http://www.asrock.com

AUSTRALIA ONLY
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage caused by our goods. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
The terms HDMI® and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING.
LICENSE. Licensee has a license under Intel's copyrights to reproduce Intel's Software only in its unmodified and binary form, (with the accompanying documentation, the "Software") for Licensee's personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions:
(a) Licensee may not disclose, distribute or transfer any part of the Software, and You agree to prevent unauthorized copying of the Software.
(b) Licensee may not reverse engineer, decompile, or disassemble the Software.
(c) Licensee may not sublicense the Software.
(d) The Software may contain the software and other intellectual property of third party suppliers, some of which may be identified in, and licensed in accordance with, an enclosed license.txt file or other text or file.
(e) Intel has no obligation to provide any support, technical assistance or updates for the Software.
OWNERSHIP OF SOFTWARE AND COPYRIGHTS. Title to all copies of the Software remains with Intel or its licensors or suppliers. The Software is copyrighted and protected by the laws of the United States and other countries, and international treaty provisions. Licensee may not remove any copyright notices from the Software. Except as otherwise expressly provided above, Intel grants no express or implied right under Intel patents, copyrights, trademarks, or other intellectual property rights. Transfer of the license terminates Licensee's right to use the Software.
DISCLAIMER OF WARRANTY. The Software is provided "AS IS" without warranty of any kind, EITHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
LIMITATION OF LIABILITY. NEITHER INTEL NOR ITS LICENSORS OR SUPPLIERS WILL BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE, INTERRUPTION OF BUSINESS, OR INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAG

ES OF ANY KIND WHETHER UNDER THIS AGREEMENT OR OTHERWISE, EVEN IF INTEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
LICENSE TO USE COMMENTS AND SUGGESTIONS. This Agreement does NOT obligate Licensee to provide Intel with comments or suggestions regarding the Software. However, if Licensee provides Intel with comments or suggestions for the modification, correction, improvement or enhancement of (a) the Software or (b) Intel products or processes that work with the Software, Licensee grants to Intel a non-exclusive, worldwide, perpetual, irrevocable, transferable, royalty-free license, with the right to sublicense, under Licensee's intellectual property rights, to incorporate or otherwise utilize those comments and suggestions.
TERMINATION OF THIS LICENSE. Intel or the sublicensor may terminate this license at any time if Licensee is in breach of any of its terms or conditions. Upon termination, Licensee will immediately destroy or return to Intel all copies of the Software.
THIRD PARTY BENEFICIARY. Intel is an intended beneficiary of the End User License Agreement and has the right to enforce all of its terms.
U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is a commercial item (as defined in 48 C.F.R. 2.101) consisting of commercial computer software and commercial computer software documentation (as those terms are used in 48 C.F.R. 12.212), consistent with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide the Software to the U.S. Government. Contractor or Manufacturer is Intel Corporation, 2200 Mission College Blvd., Santa Clara, CA 95054.
EXPORT LAWS. Licensee agrees that neither Licensee nor Licensee's subsidiaries will export/re-export the Software, directly or indirectly, to any country for which the U.S. Department of Commerce or any other agency or department of the U.S. Government or the foreign government from where it is shipping requires an export license, or other governmental approval, without first obtaining any such required license or approval. In the event the Software is exported from the U.S.A. or re-exported from a foreign destination by Licensee, Licensee will ensure that the distribution and export/re-export or import of the Software complies with all laws, regulations, orders, or other restrictions of the U.S. Export Administration Regulations and the appropriate foreign government.
APPLICABLE LAWS. This Agreement and any dispute arising out of or relating to it will be governed by the laws of the U.S.A. and Delaware, without regard to conflict of laws principles. The Parties to this Agreement exclude the application of the United Nations Convention on Contracts for the International Sale of Goods (1980). The state and federal courts sitting in Delaware, U.S.A. will have exclusive jurisdiction over any dispute arising out of or relating to this Agreement. The Parties consent to personal jurisdiction and venue in those courts. A Party that obtains a judgment against the other Party in the courts identified in this section may enforce that judgment in any court that has jurisdiction over the Parties.
Licensee's specific rights may vary from country to country.

Contents

Chapter 1 Introduction

1.1 Package Contents

1.2 Specifications

1.3 Motherboard Layout

1.4 I/O Panel

Chapter 2 Installation

2.1 Installing the CPU

2.2 Installing the CPU Fan and Heatsink

2.3 Installing Memory Modules (DIMM)

2.4 Expansion Slots (PCIe Slots)

2.5 Jumpers Setup

2.6 Onboard Headers and Connectors

2.7 Post Status Checker

2.8 CrossFireTM Operation Guide

2.8.1 Installing Two CrossFireTM-Ready Graphics Cards

2.8.2 Driver Installation and Setup

2.9 M.2 WiFi/BT PCIe WiFi Module and Intel® CNVi (Integrated

WiFi/BT) Installation Guide

2.10 M.2_SSD (NGFF) Module Installation Guide (M2_1)

2.11 M.2_SSD (NGFF) Module Installation Guide (M2_2)

Chapter 3 Software and Utilities Operation

3.1 Installing Drivers

3.2 ASRock Motherboard Utility (Phantom Gaming Tuning) 35

3.3 ASRock Live Update & APP Shop

3.3.1 UI Overview

3.3.2 Apps

3.3.3 BIOS & Drivers

3.3.4 Setting

3.4 Nahimic Audio

Chapter 4 UEFI SETUP UTILITY

4.1 Introduction

4.2 EZ Mode

4.3 Advanced Mode

4.3.1 UEFI Menu Bar

4.3.2 Navigation Keys

4.4 Main Screen

4.5 OC Tweaker Screen

4.6 Advanced Screen

4.6.1 CPU Configuration

4.6.2 Chipset Configuration

4.6.3 Storage Configuration

4.6.4 Intel® Thunderbolt

4.6.5 Super IO Configuration

4.6.6 ACPI Configuration

4.6.7 USB Configuration

4.6.8 Trusted Computing

4.7 Tools

4.8 Hardware Health Event Monitoring Screen

4.9 Security Screen

4.10 Boot Screen

4.11 Exit Screen

B660M Phantom Gaming 4
Chapter 1 Introduction
Thank you for purchasing ASRock B660M Phantom Gaming 4 motherboard, a reliable motherboard produced under ASRock's consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock's commitment to quality and endurance. In this documentation, Chapter 1 and 2 contains the introduction of the motherboard and step-by-step installation guides. Chapter 3 contains the operation guide of the software and utilities. Chapter 4 contains the configuration guide of the BIOS setup.
Because the motherboard specifications and the BIOS software might be updated, the content of this documentation will be subject to change without notice. In case any modifications of this documentation occur, the updated version will be available on ASRock's website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock's website as well. ASRock website http://www.asrock.com.
1.1 Package Contents
· ASRock B660M Phantom Gaming 4 Motherboard (Micro ATX Form Factor) · ASRock B660M Phantom Gaming 4 Quick Installation Guide · ASRock B660M Phantom Gaming 4 Support CD · 2 x Serial ATA (SATA) Data Cables (Optional) · 3 x Screws for M.2 Sockets (Optional) · 1 x I/O Panel Shield
1

English

1.2 Specifications

Platform

· Micro ATX Form Factor · Solid Capacitor design

CPU

· Supports 12th Gen Intel® CoreTM Processors (LGA1700) · Digi Power design · 8 Power Phase design · Supports Intel® Hybrid Technology · Supports Intel® Turbo Boost Max 3.0 Technology

Chipset

· Intel® B660

Memory

· Dual Channel DDR4 Memory Technology · 4 x DDR4 DIMM Slots · Supports DDR4 non-ECC, un-buffered memory up to
4800+(OC)*
* Supports DDR4 3200 natively.
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/) · Supports ECC UDIMM memory modules (operate in non-
ECC mode) · Max. capacity of system memory: 128GB · Supports Intel® Extreme Memory Profile (XMP) 2.0

Expansion Slot

· 2 x PCIe x16 Slots (PCIE1/PCIE3: single at Gen4x16 (PCIE1); dual at Gen4x16 (PCIE1) / Gen3x4 (PCIE3))
* Supports NVMe SSD as boot disks · 1 x PCIe Gen3x1 Slot · Supports AMD CrossFireTM · 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe
WiFi module and Intel® CNVi (Integrated WiFi/BT)

English

Graphics

· Intel® UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU
integrated. · Intel® Xe Graphics Architecture (Gen 12) · Dual graphics output: support HDMI and DisplayPort 1.4
ports by independent display controllers

B660M Phantom Gaming 4

· Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
· Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz
· Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports

Audio

· 7.1 CH HD Audio (Realtek ALC897 Audio Codec) · Supports Surge Protection · Nahimic Audio

LAN

· Gigabit LAN 10/100/1000 Mb/s · Giga PHY Intel® I219V · Supports Wake-On-LAN · Supports Lightning/ESD Protection · Supports Energy Efficient Ethernet 802.3az · Supports UEFI PXE

Rear Panel I/O

· 3 x Antenna Mounting Points · 1 x PS/2 Mouse/Keyboard Port · 1 x HDMI Port · 1 x DisplayPort 1.4 · 4 x USB 3.2 Gen1 Ports (ASMedia ASM1074 hub) (Supports
ESD Protection) · 2 x USB 2.0 Ports (Supports ESD Protection) · 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED) · HD Audio Jacks: Line in / Front Speaker / Microphone

Storage

· 4 x SATA3 6.0 Gb/s Connectors · 1 x Hyper M.2 Socket (M2_1, Key M), supports type
2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode* · 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode* * Supports Intel® OptaneTM Technology (M2_2 only) * Supports Intel® Volume Management Device (VMD) * Supports NVMe SSD as boot disks * Supports ASRock U.2 Kit

English

RAID

· Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

Connector

· 1 x SPI TPM Header · 1 x Chassis Intrusion and Speaker Header · 1 x CPU Fan Connector (4-pin) * The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power. · 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)
* The CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power. · 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)
* The Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_FAN2/WP, CHA_FAN1~3/WP can auto detect if 3-pin
or 4-pin fan is in use. · 1 x 24 pin ATX Power Connector · 1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor) · 1 x Front Panel Audio Connector · 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock
Thunderbolt 4 AIC Card) · 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection) · 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
(Supports ESD Protection)

BIOS Feature

· AMI UEFI Legal BIOS with multilingual GUI support · ACPI 6.0 Compliant wake up events · SMBIOS 2.7 Support · CPU Core/Cache, CPU GT, DRAM, VDD_IMC, VCCIN
AUX, +1.05V PROC, +0.82V PCH , +1.05V PCH Voltage
Multi-adjustment

English

B660M Phantom Gaming 4

Hardware Monitor
OS Certifications

· Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans
· Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans
· Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/ Water Pump Fans
· CASE OPEN detection · Voltage monitoring: CPU Vcore, +1.05V_PCH, DRAM, VC-
CIN AUX, VCCSA, +1.05V PROC, +0.82V PCH, +12V, +5V, +3.3V
· Microsoft® Windows® 10 64-bit / 11 64-bit
· FCC, CE · ErP/EuP Ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools. Overclocking may affect your system's stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.

English

1.3 Motherboard Layout
6

English

B660M Phantom Gaming 4
No. Description 1 ATX 12V Power Connector (ATX12V1) 2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) 3 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2) 4 CPU Fan Connector (CPU_FAN1) 5 CPU/Water Pump Fan Connector (CPU_FAN2/WP) 6 ATX Power Connector (ATXPWR1) 7 USB 3.2 Gen1 Header (USB3_5_6) 8 SATA3 Connector (SATA3_3)(Lower) 9 SATA3 Connector (SATA3_2)(Upper) 10 System Panel Header (PANEL1) 11 SATA3 Connector (SATA3_0) 12 SATA3 Connector (SATA3_1) 13 SPI TPM Header (SPI_TPM_J1) 14 Post Status Checker (PSC) 15 USB 2.0 Header (USB_5_6) 16 USB 2.0 Header (USB_3_4) 17 Chassis Intrusion and Speaker Header (SPK_CI1) 18 Chassis/Water Pump Fan Connector (CHA_FAN2/WP) 19 Chassis/Water Pump Fan Connector (CHA_FAN3/WP) 20 5-pin Thunderbolt AIC Connector (TB1) 21 Clear CMOS Jumper (CLRMOS1) 22 Front Panel Audio Header (HD_AUDIO1) 23 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
7

English

1.4 I/O Panel
1

No. Description 1 USB 2.0 Ports (USB_12) 2 LAN RJ-45 Port* 3 Line In (Light Blue)** 4 Front Speaker (Lime)** 5 Microphone (Pink)**

No. Description 6 USB 3.2 Gen1 Ports (USB3_3_4) 7 USB 3.2 Gen1 Ports (USB3_1_2) 8 DisplayPort 1.4 9 HDMI Port 10 PS/2 Mouse/Keyboard Port

* There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED
SPEED LED

LAN Port

Activity / Link LED

Status
Off Blinking On

Description
No Link Data Activity Link

Speed LED
Status Off Orange Green

** Function of the Audio Ports in 7.1-channel Configuration:

Description
10Mbps connection 100Mbps connection 1Gbps connection

Port
Light Blue (Rear panel) Lime (Rear panel) Pink (Rear panel) Lime (Front panel)

Function
Rear Speaker Out Front Speaker Out Central /Subwoofer Speaker Out Side Speaker Out

English

B660M Phantom Gaming 4
Chapter 2 Installation
This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.
Pre-installation Precautions
Take note of the following precautions before you install motherboard components or change any motherboard settings. · Make sure to unplug the power cord before installing or removing the motherboard
components. Failure to do so may cause physical injuries and damages to motherboard components. · In order to avoid damage from static electricity to the motherboard's components, NEVER place your motherboard directly on a carpet. Also remember to use a grounded wrist strap or touch a safety grounded object before you handle the components. · Hold components by the edges and do not touch the ICs. · Whenever you uninstall any components, place them on a grounded anti-static pad or in the bag that comes with the components. · When placing screws to secure the motherboard to the chassis, please do not overtighten the screws! Doing so may damage the motherboard.
9

English

2.1 Installing the CPU
1. Before you insert the 1700-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found. Otherwise, the CPU will be seriously damaged.
2. Unplug all power cables before installing the CPU.
1
A B

English

B660M Phantom Gaming 4

English

Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.
12

English

2.2 Installing the CPU Fan and Heatsink

B660M Phantom Gaming 4

CPU_FAN

English

2.3 Installing Memory Modules (DIMM)

This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology.

1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs.
2. It is unable to activate Dual Channel Memory Technology with only one or three memory module installed.
3. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot; otherwise, this motherboard and DIMM may be damaged.

Dual Channel Memory Configuration

Priority
1 2

DDR4_A1 Populated

DDR4_A2
Populated Populated

DDR4_B1 Populated

DDR4_B2
Populated Populated

The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

English

B660M Phantom Gaming 4 1 2
3 15

English

2.4 Expansion Slots (PCIe Slots)
There are 3 PCIe slots on the motherboard.
Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

PCIe slots:
PCIE1 (PCIe 4.0 x16 slot) is used for PCIe x16 lane width graphics cards. PCIE2 (PCIe 3.0 x1 slot) is used for PCIe x1 lane width cards. PCIE3 (PCIe 3.0 x16 slot) is used for PCIe x4 lane width graphics cards.

PCIe Slot Configurations
Single Graphics Card

PCIE1 Gen4x16

PCIE3 N/A

Two Graphics Cards in CrossFireTM Mode

Gen4x16

Gen3x4

For a better thermal environment, please connect a chassis fan to the motherboard's chassis fan connector (CHA_FAN1/WP, CHA_FAN2/WP or CHA_FAN3/WP) when using multiple graphics cards.

English

B660M Phantom Gaming 4
2.5 Jumpers Setup
The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is "Short". If no jumper cap is placed on the pins, the jumper is "Open".

Clear CMOS Jumper (CLRMOS1) (see p.6, No. 21)

2-pin Jumper

CLRMOS1 allows you to clear the data in CMOS. To clear and reset the system parameters to default setup, please turn off the computer and unplug the power cord from the power supply. After waiting for 15 seconds, use a jumper cap to short the pins on CLRMOS1 for 5 seconds. However, please do not clear the CMOS right after you update the BIOS. If you need to clear the CMOS when you just finish updating the BIOS, you must boot up the system first, and then shut it down before you do the clear-CMOS action. Please be noted that the password, date, time, and user default profile will be cleared only if the CMOS battery is removed. Please remember toremove the jumper cap after clearing the CMOS.

If you clear the CMOS, the case open may be detected. Please adjust the BIOS option "Clear Status" to clear the record of previous chassis intrusion status.

English

2.6 Onboard Headers and Connectors
Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard.

System Panel Header (9-pin PANEL1) (see p.6, No. 10)

PLED+ PLEDPWRBTN# GND
1 GND
RESET# GND HDLEDHDLED+

Connect the power switch, reset switch and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables.

PWRBTN (Power Switch): Connect to the power switch on the chassis front panel. You may configure the way to turn off your system using the power switch.
RESET (Reset Switch): Connect to the reset switch on the chassis front panel. Press the reset switch to restart the computer if the computer freezes and fails to perform a normal restart.
PLED (System Power LED): Connect to the power status indicator on the chassis front panel. The LED is on when the system is operating. The LED keeps blinking when the system is in S1/S3 sleep state. The LED is off when the system is in S4 sleep state or powered off (S5).
HDLED (Hard Drive Activity LED): Connect to the hard drive activity LED on the chassis front panel. The LED is on when the hard drive is reading or writing data.
The front panel design may differ by chassis. A front panel module mainly consists of power switch, reset switch, power LED, hard drive activity LED, speaker and etc. When connecting your chassis front panel module to this header, make sure the wire assignments and the pin assignments are matched correctly.

Chassis Intrusion and Speaker Header (7-pin SPK_CI1) (see p.6, No. 17)

SPEAKER DUMMY DUMMY +5V
1
SIGNAL GND DUMMY

Please connect the chassis intrusion and the chassis speaker to this header.

English

B660M Phantom Gaming 4

Serial ATA3 Connectors Vertical: (SATA3_0: see p.6, No. 11) (SATA3_1: see p.6, No. 12) Right Angle: (SATA3_2: see p.6, No. 9)(Upper) (SATA3_3: see p.6, No. 8)(Lower)

SATA3_2 SATA3_3

SATA3_1 SATA3_0

These four SATA3 connectors support SATA data cables for internal storage devices with up to 6.0 Gb/s data transfer rate.

USB 2.0 Headers (9-pin USB_3_4) (see p.6, No. 16) (9-pin USB_5_6) (see p.6, No. 15)

USB_PWR PP+ GND DUMMY
1 GND
P+ PUSB_PWR

There are two USB 2.0 headers on this motherboard. Each USB 2.0 header can support two ports.

USB 3.2 Gen1 Header (19-pin USB3_5_6) (see p.6, No. 7)

Vbus IntA_PA_SSRXIntA_PA_SSRX+
GND IntA_PA_SSTXIntA_PA_SSTX+
GND IntA_PA_DIntA_PA_D+

Vbus IntA_PB_SSRXIntA_PB_SSRX+ GND IntA_PB_SSTXIntA_PB_SSTX+ GND IntA_PB_DIntA_PB_D+ Dummy 1

There is one USB 3.2 Gen1 header on this motherboard. This USB 3.2 Gen1 header can support two ports.

Front Panel Audio Header (9-pin HD_AUDIO1) (see p.6, No. 22)

GND PRESENCE# MIC_RET OUT_RET
1 OUT2_L
J_SENSE OUT2_R MIC2_R MIC2_L

This header is for connecting audio devices to the front audio panel.

English

1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly. Please follow the instructions in our manual and chassis manual to install your system.
2. If you use an AC'97 audio panel, please install it to the front panel audio header by the steps below: A. Connect Mic_IN (MIC) to MIC2_L. B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L. C. Connect Ground (GND) to Ground (GND). D. MIC_RET and OUT_RET are for the HD audio panel only. You don't need to connect them for the AC'97 audio panel. E. To activate the front mic, go to the "FrontMic" Tab in the Realtek Control panel and adjust "Recording Volume".

Chassis/Water Pump Fan Connectors (4-pin CHA_FAN1/WP) (see p.6, No. 23)
(4-pin CHA_FAN2/WP) (see p.6, No. 18) (4-pin CHA_FAN3/WP) (see p.6, No. 19)

GND

FAN_VOLTAGE

CHA_FAN_SPEED

FAN_SPEED_CONTROL

GND FAN_VOLTAGE CHA_FAN_SPEED FAN_SPEED_CONTROL

This motherboard provides three 4-Pin water cooling chassis fan connectors. If you plan to connect a 3-Pin chassis water cooler fan, please connect it to Pin 1-3.

1 2 3 4

CPU Fan Connector (4-pin CPU_FAN1) (see p.6, No. 4)

4 3 2 1
GND +12V CPU_FAN_SPEED FAN_SPEED_CONTROL

This motherboard provides a 4-Pin CPU fan (Quiet Fan) connector. If you plan to connect a 3-Pin CPU fan, please connect it to Pin 1-3.

CPU/Water Pump Fan Connector (4-pin CPU_FAN2/WP) (see p.6, No. 5)

4 3 21
GND FAN_VOLTAGE CPU_FAN_SPEED FAN_SPEED_CONTROL

This motherboard provides a 4-Pin water cooling CPU fan connector. If you plan to connect a 3-Pin CPU water cooler fan, please connect it to Pin 1-3.

English

B660M Phantom Gaming 4

ATX Power Connector (24-pin ATXPWR1) (see p.6, No. 6)
ATX 12V Power Connector (8-pin ATX12V1) (see p.6, No. 1)
SPI TPM Header (13-pin SPI_TPM_J1) (see p.6, No. 13)
Thunderbolt AIC Connector (5-pin TB1) (see p.6, No. 20)

This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13.

This motherboard provides

a 8-pin ATX 12V power con-

nector. To use a 4-pin ATX

power supply, please plug it

along Pin 1 and Pin 5.

*Warning: Please make sure that the power cable connected is for the CPU and not the graphics card. Do not plug the PCIe power cable to this connector.

SPI_DQ3 SPI_PWR Dummy CLK SPI_MOSI RST# TPM_PIRQ
1
SPI_TPM_CS# GND RSMRST# SPI_MISO SPI_CS0 SPI_DQ2

This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.

Please connect a ThunderboltTM addin card (AIC) to this connector via the GPIO cable. *Please install the ThunderboltTM AIC card to PCIE3 (default slot).

English

2.7 Post Status Checker
Post Status Checker (PSC) diagnoses the computer when users power on the machine. It emits a red light to indicate whether the CPU, memory, VGA or storage is dysfunctional. The lights go off if the four mentioned above are functioning normally.
22

English

B660M Phantom Gaming 4
2.8 CrossFireTM Operation Guide
This motherboard supports CrossFireTM that allows you to install up to two identical PCI Express x16 graphics cards.
1. You should only use identical CrossFireTM-ready graphics cards that are AMD certified.
2. Make sure that your graphics card driver supports AMD CrossFireTM technology. Download the drivers from the AMD's website: www.amd.com
3. Make sure that your power supply unit (PSU) can provide at least the minimum power your system requires. It is recommended to use a AMD certified PSU. Please refer to the AMD's website for details.
4. If you pair a 12-pipe CrossFireTM Edition card with a 16-pipe card, both cards will operate as 12-pipe cards while in CrossFireTM mode.
5. Different CrossFireTM cards may require different methods to enable CrossFireTM. Please refer to AMD graphics card manuals for detailed installation guide.

2.8.1 Installing Two CrossFireTM-Ready Graphics Cards
Step 1 Insert one graphics card into PCIE1 slot and the other graphics card to PCIE3 slot. Make sure that the cards are properly seated on the slots.

CrossFire Bridge

Step 2
Connect two graphics cards by installing a CrossFire Bridge on the CrossFire Bridge Interconnects on the top of the graphics cards. (The CrossFire Bridge is provided with the graphics card you purchase, not bundled with this motherboard. Please refer to your graphics card vendor for details.)

English

Step 3 Connect a VGA/DVI/DP/HDMI cable from the monitor to the corresponding port on the graphics card installed to the PCIE1 slot.
24

English

B660M Phantom Gaming 4

2.8.2 Driver Installation and Setup
Step 1 Power on your computer and boot into OS. Step 2 Remove the AMD drivers if you have any VGA drivers installed in your system.

The Catalyst Uninstaller is an optional download. We recommend using this utility to uninstall any previously installed Catalyst drivers prior to installation. Please check AMD's website for AMD driver updates.

Step 3
Install the required drivers and CATALYST Control Center then restart your computer. Please check AMD's website for details.

AMD Catalyst Control Center

Step 4
Double-click the AMD Catalyst Control Center icon in the Windows® system tray.
Step 5
In the left pane, click Performance and then AMD CrossFireTM. Then select Enable AMD CrossFire and click Apply. Select the GPU number according to your graphics card and click Apply.

English

2.9 M.2 WiFi/BT PCIe WiFi Module and Intel® CNVi (Integrated WiFi/BT) Installation Guide
The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVi (Integrated WiFi/BT). * The M.2 socket does not support SATA M.2 SSDs.
Before you install Intel® Integrated Connectivity (CNVi) module, be sure to turn off the AC power.

Installing the WiFi/BT module or Intel® CNVi (Integrated WiFi/BT)
Step 1
Prepare a type 2230 WiFi/BT PCIe WiFi module or Intel® CNVi (Integrated WiFi/BT) and the screw.

PCB Length: 3cm Module Type: Type2230

Step 2 Find the nut location to be used.

English

20o

B660M Phantom Gaming 4
Step 3 Gently insert the WiFi/BT module or Intel® CNVi (Integrated WiFi/ BT) into the M.2 slot. Please be aware that the module only fits in one orientation.
Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.

English

2.10 M.2_SSD (NGFF) Module Installation Guide (M2_1)
The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_1, Key M) supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode.
Installing the M.2_SSD (NGFF) Module
Step 1 Prepare a M.2_SSD (NGFF) module and the screw.

3 2
1

Step 2
Depending on the PCB type and length of your M.2_SSD (NGFF) module, find the corresponding nut location to be used.

No. Nut Location PCB Length Module Type

1 A 4.2cm Type2242

2 B 6cm Type2260

3 C 8cm Type 2280

English

B660M Phantom Gaming 4
Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location C by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut. Otherwise, release the standoff by hand.
Step 4 Peel off the yellow protective film on the nut to be used. Hand tighten the standoff into the desired nut location on the motherboard.
Step 5 Gently insert the M.2 (NGFF) SSD module into the M.2 slot. Please be aware that the M.2 (NGFF) SSD module only fits in one orientation.

English

20o

NUT2

NUT1

Step 6
Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.
29

M.2_SSD (NGFF) Module Support List

Vendor ADATA ADATA ADATA ADATA ADATA Apacer Corsair Intel Intel Kingston Kingston OCZ PATRIOT Plextor Plextor Plextor Plextor Plextor Plextor Samsung Samsung Samsung Samsung Samsung Samsung Samsung Samsung Samsung SanDisk SanDisk TEAM TEAM WD WD

Interface PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe2 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe PCIe PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe x4 PCIe PCIe PCIe3 x4 PCIe3 x4 PCIe3 x4 PCIe3 x4

P/N ASX7000NP-128GT-C ASX8000NP-256GM-C ASX7000NP-256GT-C ASX8000NP-512GM-C ASX7000NP-512GT-C AP240GZ280 CSSD-F240GBMP500 SSDPEKKF256G7 SSDPEKKF512G7 SKC1000/480G SH2280S3/480G RVD400 -M2280-512G (NVME) PH240GPM280SSDR NVME PX-128M8PeG PX-1TM8PeG PX-256M8PeG PX-512M8PeG PX-G256M6e PX-G512M6e SM961 MZVPW128HEGM (NVM) PM961 MZVLW128HEGR (NVME) 960 EVO (MZ-V6E250) (NVME) 960 EVO (MZ-V6E250BW) (NVME) SM951 (NVME) SM951 (MZHPV256HDGL) SM951 (MZHPV512HDGL) SM951 (NVME) XP941-512G (MZHPU512HCGL) SD6PP4M-128G SD6PP4M-256G TM8FP2240G0C101 TM8FP2480GC110 WDS256G1X0C-00ENX0 (NVME) WDS512G1X0C-00ENX0 (NVME)

For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for details: http://www.asrock.com

English

B660M Phantom Gaming 4
2.11 M.2_SSD (NGFF) Module Installation Guide (M2_2)
The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_2, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode.
Installing the M.2_SSD (NGFF) Module
Step 1 Prepare a M.2_SSD (NGFF) module and the screw.
Step 2 Depending on the PCB type and length of your M.2_SSD (NGFF) module, find the corresponding nut location to be used.

No. Nut Location PCB Length Module Type

1 A 8cm Type2280

English

Step 3
Align and gently insert the M.2 (NGFF) SSD module into the M.2 slot. Please be aware that the M.2 (NGFF) SSD module only fits in one orientation.
A

20o

NUT2

NUT1

Step 4
Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.

English

B660M Phantom Gaming 4

M.2_SSD (NGFF) Module Support List

For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for details: http://www.asrock.com

English

Chapter 3 Software and Utilities Operation
3.1 Installing Drivers
The Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard's features.
Running The Support CD
To begin using the support CD, insert the CD into your CD-ROM drive. The CD automatically displays the Main Menu if "AUTORUN" is enabled in your computer. If the Main Menu does not appear automatically, locate and double click on the file "ASRSETUP.EXE" in the Support CD to display the menu.
Drivers Menu
The drivers compatible to your system will be auto-detected and listed on the support CD driver page. Please click Install All or follow the order from top to bottom to install those required drivers. Therefore, the drivers you install can work properly.
Utilities Menu
The Utilities Menu shows the application software that the motherboard supports. Click on a specific item then follow the installation wizard to install it.
34

English

B660M Phantom Gaming 4

3.2 ASRock Motherboard Utility (Phantom Gaming Tuning)

ASRock Motherboard Utility (Phantom Gaming Tuning) is ASRock's multi purpose software suite with a new interface, more new features and improved utilities.

3.2.1 Installing ASRock Motherboard Utility (Phantom Gaming Tuning)

ASRock Motherboard Utility (Phantom Gaming Tuning) can be downloaded from

ASRock Live Update & APP Shop. After the installation, you will find the icon "AS-

Rock Motherboard Utility (Phantom Gaming Tuning)" on your desktop. Double-

click the "ASRock Motherboard Utility (Phantom Gaming Tuning)"

icon,

ASRock Motherboard Utility (Phantom Gaming Tuning) main menu will pop up.

3.2.2 Using ASRock Motherboard Utility (Phantom Gaming Tuning)
There are five sections in ASRock Motherboard Utility (Phantom Gaming Tuning) main menu: Operation Mode, OC Tweaker, System Info, FAN-Tastic Tuning and Settings.
Operation Mode
Choose an operation mode for your computer.

English

OC Tweaker
Configurations for overclocking the system.
System Info
View information about the system. *The System Browser tab may not appear for certain models.
36

English

B660M Phantom Gaming 4 FAN-Tastic Tuning
Configure up to five different fan speeds using the graph. The fans will automatically shift to the next speed level when the assigned temperature is met.
Settings
Configure ASRock ASRock Motherboard Utility (Phantom Gaming Tuning). Click to select "Auto run at Windows Startup" if you want ASRock Motherboard Utility (Phantom Gaming Tuning) to be launched when you start up the Windows operating system.
37

English

3.3 ASRock Live Update & APP Shop
The ASRock Live Update & APP Shop is an online store for purchasing and downloading software applications for your ASRock computer. You can quickly and easily install various apps and support utilities. With ASRock Live Update & APP Shop, you can optimize your system and keep your motherboard up to date simply with a few clicks.

Double-click utility.

on your desktop to access ASRock Live Update & APP Shop

*You need to be connected to the Internet to download apps from the ASRock Live Update & APP Shop.

3.3.1 UI Overview

Category Panel

Hot News

Information Panel
Category Panel: The category panel contains several category tabs or buttons that when selected the information panel below displays the relative information. Information Panel: The information panel in the center displays data about the currently selected category and allows users to perform job-related tasks. Hot News: The hot news section displays the various latest news. Click on the image to visit the website of the selected news and know more.
38

English

B660M Phantom Gaming 4
3.3.2 Apps
When the "Apps" tab is selected, you will see all the available apps on screen for you to download.
Installing an App
Step 1 Find the app you want to install.
The most recommended app appears on the left side of the screen. The other various apps are shown on the right. Please scroll up and down to see more apps listed. You can check the price of the app and whether you have already intalled it or not.
- The red icon displays the price or "Free" if the app is free of charge. - The green "Installed" icon means the app is installed on your computer. Step 2 Click on the app icon to see more details about the selected app.
39

English

Step 3 If you want to install the app, click on the red icon

to start downloading.

Step 4
When installation completes, you can find the green "Installed" icon appears on the upper right corner.

English

To uninstall it, simply click on the trash can icon . *The trash icon may not appear for certain apps.
40

B660M Phantom Gaming 4
Upgrading an App
You can only upgrade the apps you have already installed. When there is an available new version for your app, you will find the mark of "New Version" appears below the installed app icon.

Step 1 Click on the app icon to see more details.

Step 2

Click on the yellow icon

to start upgrading.

English

3.3.3 BIOS & Drivers
Installing BIOS or Drivers
When the "BIOS & Drivers" tab is selected, you will see a list of recommended or critical updates for the BIOS or drivers. Please update them all soon.

Step 1 Please check the item information before update. Click on Step 2

to see more details.

Click to select one or more items you want to update. Step 3

Click Update to start the update process.

English

B660M Phantom Gaming 4
3.3.4 Setting
In the "Setting" page, you can change the language, select the server location, and determine if you want to automatically run the ASRock Live Update & APP Shop on Windows startup.
43

English

3.4 Nahimic Audio
Nahimic audio software provides an incredible high definition sound technology which boosts the audio and voice performance of your system. Nahimic Audio interface is composed of four tabs: Audio, Microphone, Sound Tracker and Settings.

There are four functions in Nahimic audio :

No. Function

Description

1 Audio

From this tab, you can mute the current audio device, choose between four factory audio profiles, turn all audio effects on/off, restores the current profile to its default settings and access Surround Sound and various features.

2 Microphone

From this tab, you can mute the current mic device, choose between two factory mic profiles, turn/off all microphone effects, restore the current profile to its default settings, and access Static Noise Suppression and various features.

Sound 3
Tracker
4 Settings 44

The Sound Tracker provides a visual indication localizing the sources of the sounds while in a game. These are represented by dynamic segments pointing the direction of the sounds: the more opaque they are, the stronger the sounds are.
From this tab, you can access all settings and information of the software.

English

B660M Phantom Gaming 4
Chapter 4 UEFI SETUP UTILITY
4.1 Introduction
This section explains how to use the UEFI SETUP UTILITY to configure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines. If you wish to enter the UEFI SETUP UTILITY after POST, restart the system by pressing <Ctl> + <Alt> + <Delete>, or by pressing the reset button on the system chassis. You may also restart by turning the system off and then back on.
Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
45

English

4.2 EZ Mode

The EZ Mode screen appears when you enter the BIOS setup program by default. EZ mode is a dashboard which contains multiple readings of the system's current status. You can check the most crucial information of your system, such as CPU speed, DRAM frequency, SATA information, fan speed, etc.

Press <F6> or click the "Advanced Mode" button at the upper right corner of the screen to switch to "Advanced Mode" for more options.

1234

No. Function 1 Help 2 Load UEFI Defaults 3 Save Changes and Exit 4 Discard Changes 5 Change Language 6 Switch to Advanced Mode
46

English

B660M Phantom Gaming 4

4.3 Advanced Mode
The Advanced Mode provides more options to configure the BIOS settings. Refer to the following sections for the detailed configurations.
To access the EZ Mode, press <F6> or click the "EZ Mode" button at the upper right corner of the screen.

4.3.1 UEFI Menu Bar
The top of the screen has a menu bar with the following selections:

Main

For setting system time/date information

OC Tweaker

For overclocking configurations

Advanced

For advanced system configurations

Tool

Useful tools

H/W Monitor

Displays current hardware status

Security

For security settings

Boot

For configuring boot settings and boot priority

Exit

Exit the current screen or the UEFI Setup Utility

English

4.3.2 Navigation Keys
Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter> to get into the sub screen. You can also use the mouse to click your required item.
Please check the following table for the descriptions of each navigation key.

Navigation Key(s) Description

+ / -

To change option for the selected items

<Tab>

Switch to next function

<PGUP>

Go to the previous page

<PGDN>

Go to the next page

<HOME>

Go to the top of the screen

<END>

Go to the bottom of the screen

<F1>

To display the General Help Screen

<F5>

Add / Remove Favorite

<F7>

Discard changes and exit the SETUP UTILITY

<F9>

Load optimal default values for all the settings

<F10>

Save changes and exit the SETUP UTILITY

<F12>

Print screen

<ESC>

Jump to the Exit Screen or exit the current screen

English

B660M Phantom Gaming 4
4.4 Main Screen
When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview.
The availability and location of BIOS settings can be different for different models and BIOS versions.
My Favorite
Display your collection of BIOS items. Press F5 to add/remove your favorite items.
49

English

4.5 OC Tweaker Screen
In the OC Tweaker screen, you can set up overclocking features.
Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
CPU Configuration CPU Turbo Ratio Information
This item allows users to browse the CPU Turbo Ratio information.
CPU Configuration CPU P-Core Ratio
The CPU speed is determined by the CPU P-Core Ratio multiplied with the BCLK. Increasing the CPU P-Core Ratio will increase the internal CPU clock speed without affecting the clock speed of other components.
AVX2 Ratio Offset
AVX2 Ratio Offset specifies a negative offset from the CPU Ratio for AVX workloads. AVX is a more stressful workload that lower the AVX ratio to ensure maximum possible ratio for SSE workloads. 50

English

B660M Phantom Gaming 4
CPU E-Core Ratio
The E-Core speed is determined by the E-Core Ratio multiplied with the BCLK. Increasing the E-Core Ratio will increase the internal E-Core clock speed without affecting the clock speed of other components.
CPU Cache Ratio
The CPU Internal Bus Speed Ratio. The maximum should be the same as the CPU Ratio.
GT Frequency
Configure the frequency of the integrated GPU.
BCLK Aware Adaptive Voltage
BCLK Aware Adaptive Voltage enable/disable. When enabled, pcode will be aware of the BCLK frequency when calculating the CPU V/F curves. This is ideal for BCLK OC to avoid high voltage overrides.
Boot Performance Mode
Select the performance state that the BIOS will set before OS handoff.
Ring to Core Ratio Offset
Disable Ring to Core Ratio Offset so the ring and core can run at the same frequency.
SA PLL Frequency Override
Configure SA PLL Frequency.
BCLK TSC HW Fixup
BCLK TSC HW Fixup disable during TSC copy from PMA to APIC.
FLL Overclocking Mode
Nominal is good for normal core ratio overclocking. Elevated and Extremely Elevated are good for high BCLK OC.
Intel SpeedStep Technology
Intel SpeedStep technology allows processors to switch between multiple frequencies and voltage points for better power saving and heat dissipation.
Intel Turbo Boost Technology
Intel Turbo Boost Technology enables the processor to run above its base operating frequency when the operating system requests the highest performance state.
51

English

Intel Speed Shift Technology
Enable/Disable Intel Speed Shift Technology support. Enabling will expose the CPPC v2 interface to allow for hardware controlled P-sates.
Intel Turbo Boost Max Technology 3.0
Intel Turbo Boost Technology enables the processor to run above its base operating frequency when the operating system requests the highest performance state.
Intel Thermal Velocity Boost Voltage Optimizations
This service controls thermal based voltage optimizations for processors that implment the Intel Thermal Velocity Boost (TVB) feature.
Dual Tau Boost
Enable Dual Tau Boost feature. This is only applicable for CMLS 35W/65W/125W skus. This item is only supported with processors with Config TDP support.
Long Duration Power Limit
Configure Package Power Limit 1 in watts. When the limit is exceeded, the CPU ratio will be lowered after a period of time. A lower limit can protect the CPU and save power, while a higher limit may improve performance.
Long Duration Maintained
Configure the period of time until the CPU ratio is lowered when the Long Duration Power Limit is exceeded.
Short Duration Power Limit
Configure Package Power Limit 2 in watts. When the limit is exceeded, the CPU ratio will be lowered immediately. A lower limit can protect the CPU and save power, while a higher limit may improve performance.
CPU Core Unlimited Current Limit
To unlock voltage regulator current limit completely, you can set this option to Enabled.
CPU Core Current Limit
Configure the current limit of the CPU core. A lower limit can protect the CPU and save power, while a higher limit may improve performance.
GT Unlimited Current Limit
To unlock voltage regulator current limit completely, you can set this option to Enabled.
52

English

B660M Phantom Gaming 4
GT Current Limit
Configure the current limit of the GT slice. A lower limit can protect the CPU and save power, while a higher limit may improve performance.
DRAM Configuration Memory Information
Allows users to browse the serial presence detect (SPD) and Intel extreme memory profile (XMP) for DDR4 modules.
DRAM Timing Configuration DRAM Reference Clock
Select Auto for optimized settings.
DRAM Frequency
If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency automatically.
DRAM Gear Mode
High gear is good for high frequency.
Primary Timing CAS# Latency (tCL)
The time between sending a column address to the memory and the beginning of the data in response.
RAS# to CAS# Delay (tRCD)
The number of clock cycles required between the opening of a row of memory and accessing columns within it.
Row Precharge (tRP)
The number of clock cycles required between the issuing of the precharge command and opening the next row.
RAS# Active Time (tRAS)
The number of clock cycles required between a bank active command and issuing the precharge command.
Command Rate (CR)
53

English

The delay between when a memory chip is selected and when the first active command can be issued.
Secondary Timing Write Recovery Time (tWR)
The amount of delay that must elapse after the completion of a valid write operation, before an active bank can be precharged.
Refresh Cycle Time (tRFC)
The number of clocks from a Refresh command until the first Activate command to the same rank.
RAS to RAS Delay (tRRD_L)
The number of clocks between two rows activated in different banks of the same rank.
RAS to RAS Delay (tRRD_S)
The number of clocks between two rows activated in different banks of the same rank.
Write to Read Delay (tWTR_L)
The number of clocks between the last valid write operation and the next read command to the same internal bank.
Write to Read Delay (tWTR_S)
The number of clocks between the last valid write operation and the next read command to the same internal bank.
Read to Precharge (tRTP)
The number of clocks that are inserted between a read command to a row precharge command to the same rank.
Four Activate Window (tFAW)
The time window in which four activates are allowed the same rank.
CAS Write Latency (tCWL)
Configure CAS Write Latency.
Third Timing tREFI
54

English

B660M Phantom Gaming 4
Configure refresh cycles at an average periodic interval.
tCKE
Configure the period of time the DDR4 initiates a minimum of one refresh command internally once it enters Self-Refresh mode.
Turn Around Timing Turn Around Timing Optimization
Auto is enabled in general case.
TAT Training Value tRDRD_sg
Configure between module read to read delay.
tRDRD_dg
Configure between module read to read delay.
tRDRD_dr
Configure between module read to read delay.
tRDRD_dd
Configure between module read to read delay.
tRDWR_sg
Configure between module read to write delay.
tRDWR_dg
Configure between module read to write delay.
tRDWR_dr
Configure between module read to write delay.
tRDWR_dd
Configure between module read to write delay.
tWRRD_sg
Configure between module write to read delay.
tWRRD_dg
Configure between module write to read delay. 55

English

tWRRD_dr
Configure between module write to read delay.
tWRRD_dd
Configure between module write to read delay.
tWRWR_sg
Configure between module write to write delay.
tWRWR_dg
Configure between module write to write delay.
tWRWR_dr
Configure between module write to write delay.
tWRWR_dd
Configure between module write to write delay.
TAT Runtime Value tRDRD_sg
Configure between module write to read delay.
tRDRD_dg
Configure between module write to read delay.
tRDRD_dr
Configure between module write to read delay.
tRDRD_dd
Configure between module write to read delay.
tRDWR_sg
Configure between module write to read delay.
tRDWR_dg
Configure between module write to read delay.
tRDWR_dr
Configure between module write to read delay.
56

English

tRDWR_dd
Configure between module write to read delay.
tWRRD_sg
Configure between module write to read delay.
tWRRD_dg
Configure between module write to read delay.
tWRRD_dr
Configure between module write to read delay.
tWRRD_dd
Configure between module write to read delay.
tWRWR_sg
Configure between module write to write delay.
tWRWR_dg
Configure between module write to write delay.
tWRWR_dr
Configure between module write to write delay.
tWRWR_dd
Configure between module write to write delay.
Round Trip Timing Round Trip Timing Optimization
Auto is enabled in general case.
Round Trip Level
Configure round trip level.
Initial RTL IO Delay Offset
Configure round trip latency IO delay initial offset.
Initial RTL FIF0 Delay Offset
Configure round trip latency FIF0 delay initial offset.

B660M Phantom Gaming 4 57

English

Initial RTL (MC0 C0 A1/A2)
Configure round trip latency initial value.
Initial RTL (MC0 C1 A1/A2)
Configure round trip latency initial value.
Initial RTL (MC1 C0 B1/B2)
Configure round trip latency initial value.
Initial RTL (MC1 C1 B1/B2)
Configure round trip latency initial value.
RTL (MC0 C0 A1/A2)
Configure round trip latency.
RTL (MC0 C1 A1/A2)
Configure round trip latency.
RTL (MC1 C0 B1/B2)
Configure round trip latency.
RTL (MC1 C1 B1/B2)
Configure round trip latency.
ODT Setting Dimm ODT Training
ODT values will be optimized by Dimm On-Die Termination Training.
ODT WR (A1)
Configure the memory on die termination resistors' WR for channel A1.
ODT WR (A2)
Configure the memory on die termination resistors' WR for channel A2.
ODT WR (B1)
Configure the memory on die termination resistors' WR for channel B1.
ODT WR (B2)
Configure the memory on die termination resistors' WR for channel B2.
58

English

B660M Phantom Gaming 4
ODT NOM (A1)
Use this to change ODT (CH A1) Auto/Manual settings. The default is [Auto].
ODT NOM (A2)
Use this to change ODT (CH A2) Auto/Manual settings. The default is [Auto].
ODT NOM (B1)
Use this to change ODT (CH B1) Auto/Manual settings. The default is [Auto].
ODT NOM (B2)
Use this to change ODT (CH B2) Auto/Manual settings. The default is [Auto].
ODT PARK (A1)
Configure the memory on die termination resistors' PARK for channel A1.
ODT PARK (A2)
Configure the memory on die termination resistors' PARK for channel A2.
ODT PARK (B1)
Configure the memory on die termination resistors' PARK for channel B1.
ODT PARK (B2)
Configure the memory on die termination resistors' PARK for channel B2.
Advanced Setting ASRock Timing Optimization
Configure the fast path through the MRC.
ASRock Second Timing Optimization
Configure the second fast path through the MRC.
MRC Training Respond Time
Configure the MRC Training Respond Time.
Realtime Memory Timing
Configure the realtime memory timings. [Enabled] The system will allow performing realtime memory timing changes after MRC_DONE.
59

English

Reset for MRC Failed
Reset system after MRC training is failed.
MRC Training on Warm Boot
When enabled, memory training will be executed when warm boot.
MRC Fast Boot
Enable Memory Fast Boot to skip DRAM memory training for booting faster.
Voltage Configuration Voltage Mode
[OC]: Larger range voltage for overclocking. [STABLE]: Smaller range voltage for stable system.
CPU Core/Cache Voltage
Input voltage for the processor by the external voltage regulator.
CPU Core/Cache Load-Line Calibration
CPU Core/Cache Load-Line Calibration helps prevent CPU Core/Cache voltage droop when the system is under heavy loading.
CPU GT Voltage
Configure the voltage for the integrated GPU.
CPU GT Load-Line Calibration
GT Load-Line Calibration helps prevent integrated GPU voltage droop when the system is under heavy load.
DRAM Voltage
Use this to configure DRAM Voltage. The default value is [Auto].
VDD_IMC Voltage
VDD_IMC Voltage for memory controller.
VCCIN AUX Voltage
Configure the voltage for the VCCIN AUX.
+1.05V PROC Voltage
Configure the voltage for the +1.05V PROC.
60

English

B660M Phantom Gaming 4
+0.82V PCH Voltage
Configure the voltage for the +0.82V PCH.
+1.05 PCH Voltage
Configure the voltage for the +1.05 PCH.
AVX Configuration AVX2 Voltage Guardband Scale Factor
AVX2 Voltage Guardband Scale Factor controls the voltage guardband applied to AVX2 workloads. A value > 1.00 will increase the voltage guardband, and < 1.00 will decrease the voltage guardband.
FIVR Configuration P-Core Voltage Mode
Selects between Adaptive and Override Voltage modes. In Override Mode, the voltage selected will be applied over all operating frequencies. In Adaptive mode, the voltage is interpolated only in turbo mode.
Extra Turbo Voltage
Specifies the extra turbo voltage applied while the IA Core is operating in turbo mode.
VF Offset Mode
Selects between Legacy and Selection modes. Need Reset System after enabling OverClocking Feature to initialize the default value. In Legacy Mode, setting a global offset for the entire VF curve. In Selection modes, setting a selected VF point.
VF Configuration Scope
Allows all cores VF curve or per-core VF curve configuration.
Core Voltage Offset
Specifies the offset voltage applied to the IA Core domain. This voltage is specified in millivolts.
Offset Prefix
Sets the offset value as positive or negative.
E-Core L2 Voltage Mode
Selects between adaptive and Override Voltage modes. In Override Mode the voltage selected will be applied over all operating frequencies. In Adaptive Mode
61

English

the voltage is interpolated only in turbo mode. Uses Mailbox 0SR 0x150, cmd 0x10, 0x11.
Extra Turbo Voltage
Specifies the extra turbo voltage applied while Atom L2 is operating in turbo mode. Uses Mailbox MSR 0x150, cmd 0x10, 0x11. Range 0-2000 mV.
E-Core L2 Voltage Offset
Specifies the Offset Voltage applied to the Atom L2 domain. This voltage is specified in millivolts. Uses Mailbox MSR 0x150, cmd 0x11. Range -500 to 500 mV.
Offset Prefix
Sets the offset value as positive or negative.
Ring Voltage Mode
Selects between adaptive and Override Voltage modes. In Override Mode the voltage selected will be applied over all operating frequencies. In Adaptive Mode the voltage is interpolated only in turbo mode. Uses Mailbox 0SR 0x150, cmd 0x10, 0x11.
Extra Turbo Voltage
Specifies the extra turbo voltage applied while ring is operating in turbo mode. Uses Mailbox MSR 0x150, cmd 0x10, 0x11. Range 0-2000 mV.
VF Offset Mode
Selects between Legacy and Selection modes. Need Reset System after enabling OverClocking Feature to initialize the default value. In Legacy Mode, setting a global offset for the entire VF curve. In Selection modes, setting a selected VF point.
Ring Voltage Offset
Specifies the Offset Voltage applied to the Ring domain. This voltage is specified in millivolts. Uses Mailbox MSR 0x150, cmd 0x11. Range -500 to 500 mV.
Offset Prefix
Sets the offset value as positive or negative.
GT Voltage Mode
Selects between adaptive and Override Voltage modes. In Override Mode the voltage selected will be applied over all operating frequencies. In Adaptive Mode the voltage is interpolated only in turbo mode. Uses Mailbox 0SR 0x150, cmd 0x10, 0x11.
62

English

B660M Phantom Gaming 4
Extra Turbo Voltage
Specifies the extra turbo voltage applied while GT is operating in turbo mode. Uses Mailbox MSR 0x150, cmd 0x10, 0x11. Range 0-2000 mV.
GT Voltage Offset
Specifies the Offset Voltage applied to the GT domain. This voltage is specified in millivolts. Uses Mailbox MSR 0x150, cmd 0x11. Range -500 to 500 mV.
Offset Prefix
Sets the offset value as positive or negative.
System Agent Voltage Mode
Selects between adaptive and Override Voltage modes. In Override Mode the voltage selected will be applied over all operating frequencies. In Adaptive Mode the voltage is interpolated only in turbo mode.
Extra Turbo Voltage
Specifies the extra turbo voltage applied while SA Uncore is operating in turbo mode. Uses Mailbox MSR 0x150, cmd 0x10, 0x11. Range 0-2000 mV.
System Agent Voltage Offset
Specifies the Offset Voltage applied to the Uncore domain. This voltage is specified in millivolts.
Offset Prefix
Sets the offset value as positive or negative.
Save User Default
Type a profile name and press enter to save your settings as user default.
Load User Default
Load previously saved user defaults.
Save User UEFI Setup Profile to Disk
It helps you to save current UEFI settings as an user profile to disk.
Load User UEFI Setup Profile from Disk
You can load previous saved profile from the disk.
63

English

4.6 Advanced Screen
In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, Intel(R) Thunderbolt, Super IO Configuration, ACPI Configuration, USB Configuration and Trusted Computing.
Setting wrong values in this section may cause the system to malfunction.
UEFI Configuration UEFI Setup Style
Select the default mode when entering the UEFI setup utility.
Active Page on Entry
Select the default page when entering the UEFI setup utility.
Full HD UEFI
When [Auto] is selected, the resolution will be set to 1920 x 1080 if the monitor supports Full HD resolution. If the monitor does not support Full HD resolution, then the resolution will be set to 1024 x 768. When [Disable] is selected, the resolution will be set to 1024 x 768 directly. 64

English

4.6.1 CPU Configuration

B660M Phantom Gaming 4

Processor E-Core Information
This item displays the E-Core Information.
Processor P-Core Information
This item displays the P-Core Information.
Intel Hyper Threading Technology
Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved.
Active Processor P-Cores
Select the number of cores to enable in each processor package.
Active Processor E-Cores
Select the number of E-Cores to enable in each processor package.
CPU C States Support
Enable CPU C States Support for power saving. It is recommended to keep C6 and C7 enabled for better power saving.
Enhanced Halt State (C1E)
Enable Enhanced Halt State (C1E) for lower power consumption.
65

English

CPU C6 State Support
Enable C6 deep sleep state for lower power consumption.
CPU C7 State Support
Enable C7 deep sleep state for lower power consumption.
Package C State Support
Enable CPU, PCIe, Memory, Graphics C State Support for power saving.
CFG Lock
This item allows you to disable or enable the CFG Lock.
C6DRAM
Enable/Disable moving of DRAM contents to PRM memory when CPU is in C6 state.
CPU Thermal Throttling
Enable CPU internal thermal control mechanisms to keep the CPU from overheating.
Intel AVX/AVX2
Enable/Disable the Intel AVX and AVX2 Instructions. This is applicable for Big Core only.
Intel Virtualization Technology
Intel Virtualization Technology allows a platform to run multiple operating systems and applications in independent partitions, so that one computer system can function as multiple virtual systems.
Hardware Prefetcher
Automatically prefetch data and code for the processor. Enable for better performance.
Adjacent Cache Line Prefetch
Automatically prefetch the subsequent cache line while retrieving the currently requested cache line. Enable for better performance.
Legacy Game Compatibility Mode
When enabled, pressing the scroll lock key will toggle the Efficient cores between being parked when Scroll Lock LED is on and un-parked when LED is off.
66

English

4.6.2 Chipset Configuration

B660M Phantom Gaming 4

Primary Graphics Adapter
Select a primary VGA.
Above 4G Decoding
Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding).
C.A.M (Clever Access Memory)
If system has Resizable BAR capable PCIe Devices, use this option to enable or disable Resizable BAR support (only of the system supports 64-bit PCI decoding).
VT-d
Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance.
SR-IOV Support
If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.
DMI Link Speed
Configure DMI Slot Link Speed. Auto mode is optimizing for overclocking.
67

English

PCIE1 Link Speed
Select the link speed for PCIE1.
PCIE2 Link Speed
Select the link speed for PCIE2.
PCIE3 Link Speed
Select the link speed for PCIE3.
PCI Express Native Control
Select Enable for enhanced PCI Express power saving in OS.
PCIE ASPM Support
This option enables/disables the ASPM support for all CPU downstream devices.
PCH PCIE ASPM Support
This option enables/disables the ASPM support for all PCH PCIE devices.
DMI ASPM Support
This option enables/disables the control of ASPM on CPU side of the DMI Link.
PCH DMI ASPM Support
This option enables/disables the ASPM support for all PCH DMI devices.
Share Memory
Configure the size of memory that is allocated to the integrated graphics processor when the system boots up.
IGPU Multi-Monitor
Select disable to disable the integrated graphics when an external graphics card is installed. Select enable to keep the integrated graphics enabled at all times.
Inte(R) Ethernet Connection I219-V
Enable or disable the onboard network interface controller.
Onboard HD Audio
Enable/disable onboard HD audio. Set to Auto to enable onboard HD audio and automatically disable it when a sound card is installed.
68

English

B660M Phantom Gaming 4 Front Panel
Enable/disable front panel HD audio.
Onboard HDMI HD Audio
Enable audio for the onboard digital outputs.
Onboard WAN Device
Use this item to enable or disable the onboard WAN device.
Deep Sleep
Configure deep sleep mode for power saving when the computer is shut down.
Restore on AC/Power Loss
Select the power state after a power failure. If [Power Off] is selected, the power will remain off when the power recovers. If [Power On] is selected, the system will start to boot up when the power recovers.
69

English

4.6.3 Storage Configuration
SATA Controller(s)
Enable/disable the SATA controllers.
SATA Mode Selection
AHCI: Supports new features that improve performance.
Hybrid Storage Detection and Configuration Mode
This item allows you to select Hybrid Storage Detection and Configuration Mode.
SATA Aggressive Link Power Management
SATA Aggressive Link Power Management allows SATA devices to enter a low power state during periods of inactivity to save power. It is only supported by AHCI mode.
Hard Disk S.M.A.R.T.
S.M.A.R.T stands for Self-Monitoring, Analysis, and Reporting Technology. It is a monitoring system for computer hard disk drives to detect and report on various indicators of reliability.
VMD Configuration
This item allows you to enable or disable the Intel VMD support function.
70

English

4.6.4 Intel® Thunderbolt

B660M Phantom Gaming 4

Discrete Thunderbolt(TM) Support
Enable or disable the Discrete Thunderbolt(TM) Support.
Thunderbolt Boot Support
Enabled to allow booting from Bootable devices which are present behind Thunderbolt.
Thunderbolt Usb Support
Enabled to allow booting from Usb devices which are present behind Thunderbolt.
Windows 10 Thunderbolt support
Specify Windows 10 Thunderbolt support level. Disabled: No OS native support. Enabled: OS Native support only. no RTD3.
71

English

4.6.5 Super IO Configuration
PS2 Y-Cable
Enable the PS2 Y-Cable or set this option to Auto.
72

English

4.6.6 ACPI Configuration

B660M Phantom Gaming 4

Suspend to RAM
Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving.
PS/2 Keyboard S4/S5 Wakeup Support
Allow the system to be waked up by a PS/2 Keyboard in S4/S5.
PCIE Devices Power On
Allow the system to be waked up by a PCIE device and enable wake on LAN.
I219 LAN Power On
Allow the system to be waked up by the Onboard Intel LAN.
RTC Alarm Power On
Allow the system to be waked up by the real time clock alarm. Set it to By OS to let it be handled by your operating system.
USB Keyboard/Remote Power On
Allow the system to be waked up by an USB keyboard or remote controller.
USB Mouse Power On
Allow the system to be waked up by an USB mouse.
73

English

4.6.7 USB Configuration
Legacy USB Support
Enable or disable Legacy OS Support for USB 2.0 devices. If you encounter USB compatibility issues it is recommended to disable legacy USB support. Select UEFI Setup Only to support USB devices under the UEFI setup and Windows/Linux operating systems only.
XHCI Hand-off
This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.
74

English

4.6.8 Trusted Computing

B660M Phantom Gaming 4

NOTE: Options vary depending on the version of your connected TPM module.
Security Device Support
Use this item to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
Active PCR banks
This item displays active PCR Banks.
Available PCR Banks
This item displays available PCR Banks.
SHA256 PCR Bank
Use this item to enable or disable SHA256 PCR Bank.
SHA384 PCR Bank
Use this item to enable or disable SHA384 PCR Bank.
SM3_256 PCR Bank
Use this item to enable or disable SM3_256 PCR Bank.
Pending Operation
Schedule an Operation for the Security Device.
75

English

NOTE: Your computer will reboot during restart in order to change State of the Device.
Platform Hierarchy
Use this item to enable or disable Platform Hierarchy.
Storage Hierarchy
Use this item to enable or disable Storage Hierarchy.
Endorsement Hierarchy
Use this item to enable or disable Endorsement Hierarchy.
Physical Presence Spec version
Select this item to tell OS to support PPI spec version 1.2 or 1.3. Please note that some HCK tests might not support version 1.3.
TPM 2.0 InterfaceType
Select the Communication Interface to TPM 2.0 Device
Device Select
Use this item to select the TPM device to be supported. TPM 1.2 will restrict support to TPM 1.2 devices. TPM 2.0 will restrict support to TPM 2.0 devices. Auto will support both with the default set to TPM 2.0 devices. If TPM 2.0 devices are not found, TPM 1.2 devices will be enumerated.
76

English

4.7 Tools

B660M Phantom Gaming 4

UEFI Tech Service
Contact ASRock Tech Service if you are having trouble with your PC. Please setup network configuration before using UEFI Tech Service.
Easy RAID Installer
Easy RAID Installer helps you to copy the RAID driver from the support CD to your USB storage device. After copying the drivers please change the SATA mode to RAID, then you can start installing the operating system in RAID mode.
SSD Secure Erase Tool
All the SSD's listed that supports Secure Erase function.
NVME Sanitization Tool
After you Sanitize SSD, all user data will be permanently destroyed on the SSD and cannot be recovered.
Instant Flash
Save UEFI files in your USB storage device and run Instant Flash to update your UEFI.
Internet Flash - DHCP (Auto IP), Auto
77

English

ASRock Internet Flash downloads and updates the latest UEFI firmware version from our servers for you. Please setup network configuration before using Internet Flash. *For BIOS backup and recovery purpose, it is recommended to plug in your USB pen drive before using this function.
Network Configuration
Use this to configure internet connection settings for Internet Flash.
Internet Setting
Enable or disable sound effects in the setup utility.
UEFI Download Server
Select a server to download the UEFI firmware.
78

English

B660M Phantom Gaming 4
4.8 Hardware Health Event Monitoring Screen
This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage.
Fan Tuning
Measure Fan Min Duty Cycle.
Fan-Tastic Tuning
Select a fan mode for CPU Fan, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.
CPU Fan 1 Setting
Select a fan mode for CPU Fan 1, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.
CPU Fan 1 Step Up
Set the value of CPU Fan 1 Step Up.
CPU Fan 1 Step Down
Set the value of CPU Fan 1 Step Down.
CPU_FAN2 / W_PUMP Switch
Switch CPU_FAN2 / W_PUMP header function. 79

English

CPU Fan 2 Control Mode
Select DC/PWM mode for CPU Fan 2.
CPU Fan 2 Setting
Select a fan mode for CPU Fan 2, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.
CPU Fan 2 Temp Source
Select a fan temperature source for CPU Fan 2.
CPU Fan 2 Step Up
Set the value of CPU Fan 2 Step Up.
CPU Fan 2 Step Down
Set the value of CPU Fan 2 Step Down.
CHA_FAN1 / W_PUMP Switch
Select Chassis Fan 1 or Water Pump mode.
Chassis Fan 1 Control Mode
Select PWM mode or DC mode for Chassis Fan 1.
Chassis Fan 1 Setting
Select a fan mode for Chassis Fan 1, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.
Chassis Fan 1 Temp Source
Select a fan temperature source for Chassis Fan 1.
Chassis Fan 1 Step Up
Set the value of Chassis Fan 1 Step Up.
Chassis Fan 1 Step Down
Set the value of Chassis Fan 1 Step Down.
CHA_FAN2 / W_PUMP Switch
Select Chassis Fan 2 or Water Pump mode.
Chassis Fan 2 Control Mode
Select PWM mode or DC mode for Chassis Fan 2.
80

English

B660M Phantom Gaming 4
Chassis Fan 2 Setting
Select a fan mode for Chassis Fan 2, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.
Chassis Fan 2 Temp Source
Select a fan temperature source for Chassis Fan 2.
Chassis Fan 2 Step Up
Set the value of Chassis Fan 2 Step Up.
Chassis Fan 2 Step Down
Set the value of Chassis Fan 2 Step Down.
CHA_FAN3 / W_PUMP Switch
Select Chassis Fan 3 or Water Pump mode.
Chassis Fan 3 Control Mode
Select PWM mode or DC mode for Chassis Fan 3.
Chassis Fan 3 Setting
Select a fan mode for Chassis Fan 3, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.
Chassis Fan 3 Temp Source
Select a fan temperature source for Chassis Fan 3.
Chassis Fan 3 Step Up
Set the value of Chassis Fan 3 Step Up.
Chassis Fan 3 Step Down
Set the value of Chassis Fan 3 Step Down.
Case Open Feature
Enable or disable the feature of Case Open.
81

English

4.9 Security Screen
In this section you may set or change the supervisor/user password for the system. You may also clear the user password.
Supervisor Password
Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.
User Password
Set or change the password for the user account. Users are unable to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.
Secure Boot
Use this item to enable or disable support for Secure Boot.
Intel(R) Platform Trust Technology
Enable/disable Intel PTT in ME. Disable this option to use discrete TPM Module.
82

English

B660M Phantom Gaming 4
4.10 Boot Screen
This section displays the available devices on your system for you to configure the boot settings and the boot priority.
Fast Boot
Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device. The VBIOS must support UEFI GOP if you are using an external graphics card. Please notice that Ultra Fast mode will boot so fast that the only way to enter this UEFI Setup Utility is to Clear CMOS or run the Restart to UEFI utility in Windows.
Boot From Onboard LAN
Allow the system to be waked up by the onboard LAN.
Setup Prompt Timeout
Configure the number of seconds to wait for the setup hot key.
Bootup Num-Lock
Select whether Num Lock should be turned on or off when the system boots up.
Boot Beep
Select whether the Boot Beep should be turned on or off when the system boots up. Please note that a buzzer is needed.
83

English

Full Screen Logo
Enable to display the boot logo or disable to show normal POST messages.
AddOn ROM Display
Enable AddOn ROM Display to see the AddOn ROM messages or configure the AddOn ROM if you've enabled Full Screen Logo. Disable for faster boot speed.
Boot Failure Guard Message
If the computer fails to boot for a number of times the system automatically restores the default settings.
CSM (Compatibility Support Module)
CSM
Enable to launch the Compatibility Support Module. Please do not disable unless you're running a WHCK test.
Launch PXE OpROM Policy
Select UEFI only to run those that support UEFI option ROM only. Select Legacy only to run those that support legacy option ROM only. Select Do not launch to not execute both legacy and UEFI option ROM.
84

English

B660M Phantom Gaming 4 Launch Storage OpROM Policy
Select UEFI only to run those that support UEFI option ROM only. Select Legacy only to run those that support legacy option ROM only. Select Do not launch to not execute both legacy and UEFI option ROM.
Other PCI Device ROM Priority
For PCI devices other than Network. Mass storage or Video defines which OpROM to launch.
85

English

4.11 Exit Screen
Save Changes and Exit
When you select this option the following message, "Save configuration changes and exit setup?" will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY.
Discard Changes and Exit
When you select this option the following message, "Discard changes and exit setup?" will pop out. Select [OK] to exit the UEFI SETUP UTILITY without saving any changes.
Discard Changes
When you select this option the following message, "Discard changes?" will pop out. Select [OK] to discard all changes.
Load UEFI Defaults
Load UEFI default values for all options. The F9 key can be used for this operation.
Launch EFI Shell from filesystem device
Copy shellx64.efi to the root directory to launch EFI Shell.
86

English

Contact Information
If you need to contact ASRock or want to know more about ASRock, you're welcome to visit ASRock's website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at http://www.asrock.com/support/tsd.asp ASRock Incorporation 2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) ASRock EUROPE B.V. Bijsterhuizen 11-11 6546 AR Nijmegen The Netherlands Phone: +31-24-345-44-33 Fax: +31-24-345-44-38 ASRock America, Inc. 13848 Magnolia Ave, Chino, CA91710 U.S.A. Phone: +1-909-590-8308 Fax: +1-909-590-1026

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2.1077(a)
Responsible Party Name: ASRock Incorporation Address: 13848 Magnolia Ave, Chino, CA91710
Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product
Product Name : Motherboard Model Number : B660M Phantom Gaming 4 Conforms to the following specifications:
FCC Part15, SubpartB,Unintentional Radiators Supplementary Information:
is device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) is device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Representative Person's Name: James
Signature : Date : May 12, 2017

EU Declaration of Conformity

For the following equipment: Motherboard (Product Name)
B660M Phantom Gaming4 / ASRock (Model Designation / Trade Name)
ASRock Incorporation (Manufacturer Name)
2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) (Manufacturer Address)

EMC Directive - 2014/30/EU
¾EN 55032:2015/A11:2020 ¾EN 61000-3-2:2014 ¾EN 61000-3-3:2013

¾EN 55024:2010/A1:2015 ½EN 55035:2017/A11:2020 ¾EN 61000-4-2:2009 ¾EN 61000-4-3:2006/A1:2008/A2:2010 ¾EN 61000-4-4:2012 ¾EN 61000-4-5:2014/A1:2017 ¾EN 61000-4-6:2014/AC:2015 ¾EN 61000-4-8:2010 ¾EN 61000-4-11:2004/A1:2017

Low Voltage Directive - 2014/35/EU
½EN 62368-1:2014 ½EN 62368-1:2014/A11:2017

RoHS Directive - 2011/65/EU
¾(EU) 2015/863½EN 50581:2012

CE marking

(EU conformity marking)

ASRock EUROPE B.V. (Company Name)
Bijsterhuizen 1111 6546 AR Nijmegen The Netherlands (Company Address)
Person responsible for making this declaration:

(Name, Surname) A.V.P (Position / Title) January 21, 2022 (Date)
P/N: 15G062346000AK V1.0

Adobe PDF Library 9.0 Adobe InDesign CS4 (6.0)
