Renesas Flash Programmer V3.08 User's Manual

Introduction

This manual provides comprehensive guidance for the Renesas Flash Programmer (RFP) V3.08, a software tool designed for programming flash memory on Renesas Electronics microcontrollers (MCUs). It details the software's features, system requirements, operational procedures, and troubleshooting steps.

Key Features

Controlled programming via host PC.
High-speed writing using emulators (E1, E20, E2, E2 Lite) and debug probes (J-Link).
Simple GUI for development and automatic command-line operation.
Support for programming unique codes and encrypted program files.

System Overview

The Renesas Flash Programmer system connects a host PC to a target system equipped with a Renesas Electronics MCU. Supported connection tools include E1, E20, E2, E2 Lite emulators, and J-Link debug probes, utilizing USB or serial interfaces.

Operating Environment

The software supports Windows and Linux operating systems. Hardware requirements include a processor of 1 GHz or faster, at least 1 GB of RAM, and a display resolution of 1024x768 or higher. It utilizes USB 2.0 or serial interfaces for communication.

Usage Guide

The manual details the process of creating new projects, configuring settings via tabbed pages (Operation, Operation Settings, Block Settings, Flash Option, Connect Settings, Unique Code, User Keys), and executing programming commands. It also covers command-line usage and encryption utilities.

Troubleshooting & Support

Guidance is provided for common issues encountered during startup, operation, and communication. Error messages and their resolutions are listed. For further assistance, users can refer to the FAQ section on the Renesas website.

More information is available at: https://www.renesas.com/rfp
