Installation Guide HardieTM Fine Texture Cladding EXTERIORS Australia October 2021 Make sure your information is up to date. When specifying or installing HardieTM products, ensure that you have the current technical information and guides. If in doubt, or you need more information, visit www.jameshardie.com.au or Ask James HardieTM on 13 11 03. Certificate CM40302 CONTENTS 1 INTRODUCTION 2 2 SAFE WORKING PRACTICES 3 Warning 3 Recommended safe working practices 3 Storage and handling 3 3 DESIGN CONSIDERATIONS 3 Framing 4 Fasteners 4 4 HARDIETM FINE TEXTURE CLADDING DESIGN 5 Recommended Accessories 5 Alternative Accessories 5 5 PRODUCTS AND ACCESSORY DETAILS 6 Components 6 Fasteners, Battens and Tapes 7 6 PANEL INSTALLATION - DIRECT FIX 8 7 PANEL INSTALLATION - CAVITY FIX 9 8 CONSTRUCTION DETAILS - DIRECT FIX 10 Junction Details 10 External Corner Details 11 Internal Corner Details 12 Window Details 12 9 CONSTRUCTION DETAILS - CAVITY FIX 13 Junction Details 13 External Corner Details 14 Internal Corner Details 14 Window Details 15 Infills 16 Colunms 16 10 FINISHES AND MAINTENANCE 17 Surface Preparation 17 Painting 17 Maintenance 17 10 PRODUCT INFORMATION 17 Made in Australia SCOPE This guide covers the use of HardieTM Fine Texture Cladding in a residential wall application over a seasoned timber wall frame or a light-gauge steel frame installed in a vertical upright application. CODEMARK CERTIFICATION The CodeMark Certification Scheme is a voluntary third-party building product certification scheme that authorises the use of new and innovative products in specified circumstances in order to facilitate compliance with Volume 1 and 2 of the NCC. HardieTM Fine Texture Cladding has been certified under the CodeMark scheme (Certificate Number CM40302) and availabe at www.jameshardie.com.au. This certificate can be provided to building certifiers and other regulatory authorities to facilitate the assessment of the product compliance or used to verify the suitability of the product for certain applications. HardieTM Fine Texture Cladding. The beauty of clean lines and a modern look. Streamline the building process and deliver the modern looks and clean lines homeowners want. HardieTM Fine Texture Cladding is the first fibre cement cladding panel manufactured in Australia embedded with the texture of fine render. 1 Introduction HardieTM Fine Texture Cladding is a fibre cement panel embedded with a consistent fine render texture. The shiplap joint on the long edges leaves a subtle V-joint. It removes the need for time-consuming set joints and specialty coatings that could be prone to cracking. The panels are pre-sealed, and flush driven brad nails remove the need for patching. Simply apply regular exterior acrylic flat paint on-site (Refer to the Finishing section on page 16 for more information). Renovation. The texture is designed to match popular cement or acrylic render for a consistent match with the rest of the house. New homes and townhouses. Mix it with other cladding products by James Hardie to achieve design diversity. Specifiers. Ensure the information in these specifications is appropriate for the application you're planning. Undertake specific design and detailing for areas which fall outside the scope of these specifications. Installers. Ensure that you follow the design, moisture management and associated details and material selection provided by the designer and the HardieTM Fine Texture Cladding Installation Guide. IMPORTANT NOTES 1. Failure to install, finish or maintain this product in accordance with applicable building codes, regulations, standards and James Hardie's written application instructions may lead to personal injury, affect system performance, violate local building codes, and void James Hardie's product warranty. 2. All warranties, conditions, liabilities (direct, indirect or consequential) and obligations whether arising in contract, tort or otherwise other than those specified in James Hardie's product warranty are excluded to the fullest extent allowed by law. For James Hardie's product warranty information and disclaimers about the information in this guide, visit www.jameshardie.com.au. 3. The builder must ensure the product meets aesthetic requirements before installation. James Hardie will not be responsible for rectifying aesthetic surface variations following installation. 2 Safe Working Practices 3 Design Considerations WARNING - DO NOT BREATHE DUST AND CUT ONLY IN WELL VENTILATED AREA James Hardie's fibre cement products contain sand, a source of respirable crystalline silica. May cause cancer if dust from product is inhaled. Causes damage to lungs and respiratory system through prolonged or repeated inhalation of dust from product. Intact fibre cement products are not expected to result in any adverse toxic effects. The hazard associated with fibre cement arises from the respirable crystalline silica present in dust generated by activities such as cutting, rebating, drilling, routing, sawing, crushing, or otherwise abrading fibre cement, and when cleaning up, disposing of or moving dust. When doing any of these activities in a manner that generates dust, follow James Hardie's instructions and best practices to reduce or limit the release of dust, warn others in the area and consider rotating personnel across the cutting task to further limit respirable silica exposure. If using a dust mask or respirator, use an AS/NZS1716 P1 filter and refer to Australian/New Zealand Standard 1715:2009 Selection, Use and Maintenance of Respiratory Protective Equipment for more extensive guidance and more options for selecting respirators for workplaces. For further information, refer to our installation instructions and Safety Data Sheets available at www.jameshardie.com.au. FAILURE TO ADHERE TO OUR WARNINGS, SAFETY DATA SHEETS, AND INSTALLATION INSTRUCTIONS MAY LEAD TO SERIOUS PERSONAL INJURY OR DEATH. James Hardie Recommended Safe Working Practices CUTTING OUTDOORS 1. Position cutting station so wind will blow dust away from the user or others in working area. 2. Warn others in the area to avoid dust. 3. Consider rotating personnel across cutting tasks to further limit respirable silica exposures. 4. Use one of the following methods based on the required cutting rate: Best n HardieTM knife n Hand guillotine n Fibreshear Better n Position the cutting station in a well-ventilated area. Use a dust reducing circular saw equipped with HardieTM Blade Saw Blade or comparable fibre cement blade and well maintained M-class vacuum or higher with appropriate filter for capturing fine (respirable) dust. Wear a properly-fitted, approved dust mask or respirator (minimum P1). CUTTING INDOORS n Cut only using HardieTM knife, hand guillotine or fibreshears (manual, electric or pneumatic). n Position cutting station in a well-ventilated area. DRILLING/OTHER MACHINING When drilling or machining you should always wear a P1 dust mask and warn others in the immediate area. IMPORTANT NOTES 1. For maximum protection (lowest respirable dust production) James Hardie recommends always using best practice cutting methods where feasible. 2. NEVER use a power saw indoors or in a poorly ventilated area. 3. ALWAYS use a dust reducing circular saw equipped with a sawblade specifically designed to minimise dust creation when cutting fibrecement preferably a sawblade that carries the HardieTM Blade logo or one with at least equivalent performance - connected to a M class or higher vacuum. 4. NEVER dry sweep - Use wet suppression, or an M class vacuum or higher with appropriate filter. 5. NEVER use grinders. 6. ALWAYS follow tool manufacturers' safety recommendations. 7. ALWAYS wear a properly fitted, approved dusk mask, P1 or higher DUST MASKS AND RESPIRATORS As a minimum, an AS/NZS1716 P1 respirator must be used when doing any activity that may create dust. For more extensive guidance and options for selecting respirators for workplaces please refer to Australian/ New Zealand Standard 1715:2009 "Selection, Use and Maintenance of Respiratory Protective Equipment". P1 respirators should be used in conjunction with the above cutting practices to minimise dust exposure. For further information, refer to Safety Data Sheet (SDS) available at www.jameshardie.com.au. If concern still exists about exposure levels or you do not comply with the above practices, you should always consult a qualified industrial hygienist or contact James Hardie for further information. STORAGE AND HANDLING To avoid damage, all James Hardie's fibre cement products should be stored with edges and corners of the product protected from chipping. James Hardie's fibre cement products must be installed in a dry state and protected from weather during transport and storage. The product must be laid flat under cover on a smooth level surface clear of the ground to avoid exposure to water, moisture, etc. All design and construction must comply with the appropriate requirements of the current National Construction Code (NCC) and other applicable regulations and standards. Slab and Footings The slab and footings on which the building is situated must comply with AS 2870 `Residential slabs and footings Construction' and the requirements of the NCC. Ground Clearances Install HardieTM Fine Texture Cladding with a minimum 150mm clearance to the earth on the exterior of the building or in accordance with local building codes if greater than 150mm is required. Maintain a minimum 50mm clearance between the external cladding and roofs, decks, paths, steps and driveways. Adjacent finished grade must slope away from the building in accordance with local building codes, typically a minimum slope of 50mm over the first metre. Do not install external cladding such that it may remain in contact with standing water. NOTE Greater clearance may be required in order to comply with termite protection provisions, see below for more information. Termite Protection The NCC specifies the requirements for termite barriers. Where the exposed slab edge is used as part of the termite barrier system, a minimum of 75mm of the exposed slab edge must be visible to permit ready detection of termite entry. Structural Bracing HardieTM Fine Texture Cladding can be installed to provide wall bracing against lateral forces due to wind. For further information, Ask James Hardie on 13 11 03. Fire Rated Walls HardieTM Fine Texture Cladding can achieve fire ratings of 60/60/60 and 90/90/90 when constructed with additional fire rated linings as specified in James Hardie's Fire and Acoustically Rated Design Manual and Construction of Fire and Acoustically Rated Walls Technical Specification. The length of fasteners must be increased for the additional linings. Moisture Management It is the responsibility of designer or specifier to identify moisture related risks associated with any particular building design. Wall construction design must effectively manage moisture, accounting for both the interior and exterior environments of the building, particularly in buildings that have a higher risk of wind driven rain penetration or that are artificially heated or cooled. In addition, all wall openings, penetrations, junctions, connections, window sills, heads and jambs must incorporate appropriate flashing and waterproofing. Materials, components and their installation that are used to manage moisture in framed wall construction must, at a minimum, comply with the requirements of relevant standards and the NCC. Joint Location Before starting the installation of HardieTM Fine Texture Cladding, plan the location of vertical and horizontal joints to follow the house design. To achieve this, consider aligning the joints with key building features such as windows or other opening, or work from the centerline out to the wall edge to achieve symmetry. HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 3 OF 20 Weather Barrier A suitable water control membrane must be installed under HardieTM cladding in accordance with the AS/NZS 4200.2 `Pliable building membranes and underlays Installation' and NCC requirements. James Hardie has tested and certified the use of HardieTM Wrap weather barrier for Climate Zones 2-8 within Australia. HardieTM Wrap weather barrier is a Class 4 vapour permeable membrane that delivers a tripleshield of protection to help against external weather penetration, internal condensation management and external heat penetration through its safeglare reflective layer. If using an alternate product in lieu of HardieTM Wrap weather barrier or the project is located in a hot, humid area (Climate Zone 1), the designer must ensure that the product is fit for purpose and it has the following classification in accordance with AS/NZS 4200.1:2017 `Pliable building membranes and underlays Materials': TABLE 1 Weather Barrier Classification Climate Zone 2-8 1 Water Control Classification Water Barrier Vapour Control Category Vapour Permeable (Class 3 or 4) Vapour Barrier (Class 1 or 2) FRAMING General HardieTM Fine Texture Cladding panels are installed vertically either directly fixed to frame or installed to vertically oriented HardieTM Cavity Trim or timber battens to provide a vented cavity, this can be done over either timber or steel frames. The general framing requirements for installation are given in Table 2. Table 2. Please ensure the frame design considers correct load transfer between the different wall components. Maximum stud, HardieTM Cavity Trim and fastener spacing for HardieTM Fine Texture Cladding panels for wind load classifications of AS 4055 `Wind Loads for Housing' are given in Table 3. FASTENERS General All nails must be driven flush. Brad nails are recommended for best aesthetic finish. For more information and advice, Ask James HardieTM on 13 11 03. Fastener Durability (Including Coastal Areas) Fasteners must have the appropriate level of durability and be fully compatible with all other materials required for the intended project. In areas within 1km of a coastal area, areas subject to salt spray and other corrosive environments, class 4 fasteners must be used. Soft compressible insulation installed between the front of the wall studs and directly behind the external cladding can cause installation issues and is thus not recommended. Flashing All wall openings, penetrations, intersections, connections, window sills, heads and jambs must be flashed prior to cladding installation. Flush nailing Unacceptable under driven Unacceptable over driven TABLE 2 NAIL FASTENER DEPTH General Framing Requirements Type Timber Steel Design Use of timber framing must be in accordance with AS 1684 and the framing manufacturer's specifications Use of steel framing must be in accordance with NASH standard for Residential and LowRise Steel Framing Part 1: Design Criteria and the framing manufacturer's specifications. Durability `Timber used for house construction must have the level of The steel framing must have the appropriate level of durability required to prevent durability appropriate for the relevant climate and expected service corrosion, particularly in coastal areas. life. Reference AS 1684.2 `Residential timber-framed construction'. Tolerances Ensure frame is square and work from a central datum line. A suggested maximum tolerance of between 3mm and 4mm in any 3000mm length of frame will give best results. Thermal Break Not required. Requirement For steel frames, the NCC Sections J1.5 and 3.12.1 Volumes 1 and 2 respectively, state for both residential and commercial buildings a thermal break with an R 0.2m2 K/W must be installed behind external cladding where the cladding and internal lining make direct contact with the same steel frame. Alternatively, off-stud vented cavity installation using HardieTM Cavity Trims or minimum 70x20mm timber battens can be used in these applications. Framing specifications Direct Fix Cavity Fix Cavity Fix BMT NA From 0.55 to 1.6mm. Min. Stud Width 45mm at sheet edges. 35mm at intermediates. 35mm Min. 32mm Min. Stud Depth 70mm 70mm 64mm Max. Nogging spacing Battens 1350mm N/A 1350mm for on stud batten fixing. 800mm for off stud batten fixing. HardieTM Cavity Trims or minimum MGP10 70x20mm timber battens 1350mm when battens are fixed on stud or 800mm when fixed off stud HardieTM Cavity Trims or minimum MGP10 70x20mm timber battens TABLE 3 Maximum Stud, HardieTM Cavity Trim or timber batten & fastener spacing for HardieTM Fine Texture Cladding in AS4055 Wind Classification Stud and Wind Classification cavity trims or timber batten spacing Only required for cavity fix Can be fixed off stud? Batten fastener spacings HardieTM Cavity Trims Timber Battens HardieTM Cavity Trims Timber Battens Sheet Fastener Spacing (Except Brad Nails) Sheet Fastener Spacing (Brad Nails) N1, N2, N3/C1 600 Yes Yes 300 300 200 125 N4/C2 450 No No 200 200 150 125 N5/C3 300 No No 200 150 N6/C4 300 No No 200 125 NOTE - When using brad nails: n Refer to the accessories page for brad nails options. NOTE - Off-stud cavity installation: n When fixing HardieTM Cavity Trims or timber battens offstud, noggings must be spaced based on the maximum batten span as described on Table 4. TABLE 4 Maximum span for HardieTM Cavity Trim or timber batten Batten Dimensions Max. Span (mm) (mm) Timber Frame Steel Frame HardieTM Cavity Trims 70 x 19 800 800* Timber Battens 70 x 20 70 x 35 800 1350* 800* 800* NOTES: *Requires using two nails per fixing point when installing the battens off-stud. Refer to the Product and Accessories Details on page 7 for fastener and fixing requirements. A continous bead of HardieTM Joint Sealant is required between the vertical battens and the back of the cladding in all cases. 4 HardieTM Fine Texture Cladding Design RECOMMENDED ACCESSORIES NEW HardieTM 9mm Aluminium External Slimline Corner A sleek external corner that prioritises design with a sharp, minimal edge. It holds the panels tight with just 3.5mm of coverage. NEW NEW NEW HardieTM 9mm Aluminium Internal Concave Corner A concave internal corner that aids design and productivity. Replace inconsistent sealant application with an aluminium extrusion with 10mm of cover to conceal panel edges. HardieTM 9mm Aluminium Horizontal Express Jointer A new horizontal flashing that creates an attractive 6mm horizontal shadow line. To assist installation, it features an alignment tab for the top panels and a groove to conceal the edge of the bottom panels. HardieTM 9mm Aluminium Base Trim A elegant aluminium trim for the base which can be used to cover the slab edges or as a detail under balconies and cantilevers. An alignment tab helps installation and creates a 6mm horizontal shadow line between the classing and the trim. ALTERNATIVE ACCESSORIES External Corners Internal Corners Horizontal Joiner NEW HardieTM 9mm Aluminium External Square Corner Aluminium extrusion that creates a square edge in external corner. External Corner using AxentTM Trim External corner created with 2 AxentTM Trims 45x19mm. HardieTM 9mm Aluminium Internal Corner Aluminium extrusion that creates an internal box corner. Internal Corner using AxentTM Trim Internal corner created with 1 AxentTM Trims 45x38mm. HardieTM 9mm Aluminium Horizontal T Jointer A ready to paint aluminium flashing which creates a 6mm horizontal express joint while maintaining a subtle look. HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 5 OF 20 5 Products and Accessory Details 5 3 6 7 1 2 4 COMPONENTS 1 HardieTM Fine Texture Cladding (8.5mm thick) Pre-sealed and ready to paint textured sheet with a shiplap V-shaped joint along the two vertical edges. Product Code 405252 405255 405253 405254 Length (mm) 2440 2750 3000 3600 2 HardieTM Joint Sealant 3 HardieTM Wrap Weather Barrier 4 HardieTM 9mm Aluminium Base Trim Width (mm) 1200 1200 1200 1200 Mass (kg) 36 41 44 52 Pack Size 40 40 40 30 Coverage (m2) 2.93 3.30 3.60 4.32 Horizontal Flashing Options 5 HardieTM 9mm Aluminium 5 HardieTM 9mm Aluminium Horizontal T Jointer Horizontal Express Jointer General purpose polyutherane exterior grade joint sealant. Pack Size: 20/Box. Product Code: 305534 300ml Cartridge Product Code: 305672 600ml Sausage Coverage: 2.67m/100ml (5mm dia bead) High water barrier and vapour permeable membrane. Unit size: 2.75 x 30m. Pack Size: 1 Each. Product Code: 305664 Coverage: 85.5m2 per roll NEW Aluminium Base trim that creates a shadow line over slab or balcony edges. Product Code: 306105 Coverage: Length of horizontal joints / 3000mm) Aluminium Sheet joiner that creates a subtle look. Product Code: 306040 T flashing 3000mm (5/pack) Coverage: Length of horizontal joints / 3000mm NEW Aluminium Sheet joiner that creates a 6mm shadow line. Product Code: 306104 Coverage: Length of horizontal joints / 3000mm External Corner Options 6 HardieTM 9mm Aluminium 6 HardieTM 9mm Aluminium External Square Corner External Slimline Corner Internal Corner Options 7 HardieTM 9mm Aluminium 7 HardieTM 9mm Aluminium Internal Concave Corner Internal Corner NEW Aluminium extrusion to be used in external corners. 3000mm long. Pack Size: 5 Product Code: 306100 Coverage: Height of wall x no. of external corners / 3000mm NEW Aluminium extrusion that creates a minimalist edge. Product Code: 306102 Coverage: Length of horizontal joints / 3000mm) Alternative Corner Options 8 HardieTM Corner Flashing 9 AxentTM Trim NEW Aluminium extrusion that replicates the traditional sealant bead look. Product Code: 306103 Coverage: Length of horizontal joints / 3000mm) Aluminium extrusion that creates a box corner. 3000mm long. Pack Size: 5 Product Code: 305520 Coverage: Height of wall x no. of internal corners / 3000mm Manufactured using COLORBOND® Material composite trim used for box steel, used behind cladding at internal corners and for trim around windows and external corners. 75 x 75mm. and doors. Pack Size: 1. 3000mm long. For internal corners: 45 x 38mm. Pack Size: 5. Product Code: 305564 4200mm long. Product Code: 403626 Coverage: Height of clad walls x no. of For external corners: 45 x 19mm. PcAoGrnEer6s O/ 3F02000mHmARDIETM FINE TEXTURE 4C2L0A0DmDmINlGonIgN.SPTroAdLuLcAt TCIoOdNe:G4U04ID6E62 All dimensions and masses are approximate and subject to manufacture tolerances. 5 Products and Accessory Details cont. FASTENERS, BATTENS AND TAPES HardieTM Fine Texture Cladding can be fixed either to timber or steel frames, which can be done directly or over HardieTM Cavity Trims. Depending on the fixing method and substructure, there will be different components required, these are: OPTION 1: DIRECT FIX - TIMBER FRAME 8 HardieTM Foam Back Sealing Tape 9 ND 50mm Stainless Gun Nail* Steel Brad Nail* Fibre Cement Nail* 8 9 Installed under sheet vertical joints to improve water tightness. 50mm wide 25mtr long roll. Pack Size: Each Product Code: 304560 14 gauge x 50mm ND 304 stainless steel nail for fixing HardieTM Fine Texture panels to timber framing. Not supplied by James Hardie. OPTION 2: CAVITY FIX - TIMBER FRAME 12 Battens 13 Nails to fix trim to frame* Only required in high wind areas. 2.8 x 40mm minimum class 3 nail with a minimum 6mm head diameter to be used with gun nails. Not supplied by James Hardie. Only required in high wind areas. 2.8 x 30mm corrosion resistant fibre cement nail for fixing panels onto timber stud frame. Not supplied by James Hardie. 14 Brad Nails* to fix cladding to battens 14 Fibre Cement Nails* to fix cladding to battens 13 12 ScyonTM cavity trim 14 When using HardieTM Cavity Trims Fibre cement trim used to fix external cladding to steel or timber frame. Pack Size: 96 Size: 70 x 19 x 2450mm. Product Code: 403840 2.8 x 65mm long ring shank nail or 75 x 2.8mm D or round head galvanised smooth shank nail. Not supplied by James Hardie. When using Timber Battens Timber batten used to fix external cladding to steel or timber frame. Size: 70 x 20mm min. Not supplied by James Hardie. For 70 x 19mm battens: 2.8 x 65mm long ring shank nail or 75 x 2.8mm D or round head galvanised smooth shank nail. For 70 x 35mm battens: Two 75 x 3.06mm D Head Class 3 nails per fixing 25mm DA or C 16-gauge 304 stainless steel brad nails. Not supplied by James Hardie. Apply continuous HardieTM Joint Sealant between the batten and cladding. 25mm DA or C 16-gauge 304 stainless steel brad nails. Not supplied by James Hardie. Apply continuous HardieTM Joint Sealant between the batten and cladding. Only required in high wind areas. 2.8 x 30mm corrosion resistant fibre cement nail. Not supplied by James Hardie. OPTION 3: CAVITY FIX - STEEL FRAME 12 Battens 15 15 Screws to fix trim to frame* 14 Brad Nails* to fix cladding to battens 12 Timber Battens 14 When using HardieTM Cavity Trims Fibre cement trim used to fix external cladding to steel or timber frame. Pack Size: 96 Size: 70 x 19 x 2450mm. Product Code: 403840 Two HardieTM Drive Screws - Class 3 self-tapping wing-tipped screw for fastening to 0.5mm to 1.6mm BMT light gauge steel frames. 1000 per box. Product Codes: 305984 (loose) 305982 (collated). 25mm DA or C 16-gauge 304 stainless steel brad nails. Not supplied by James Hardie. Apply continuous HardieTM Joint Sealant between the batten and cladding. When using Timber Battens Timber batten used to fix external cladding to steel or timber frame. Size: 70 x 20mm min. Not supplied by James Hardie. For 70 x 19mm battens: Two HardieTM Drive Screws - Class 3 self-tapping wing-tipped screw for fastening to 0.5mm to 1.6mm BMT light gauge steel frames. 1000 per box. Product Codes: 305984 (loose) 305982 (collated). For 70 x 35mm battens: Two 10-24 x 65mm Class 3 selfdrilling CSK-Head screws per fixing. 25mm DA or C 16-gauge 304 stainless steel brad nails. Not supplied by James Hardie. Apply continuous HardieTM Joint Sealant between the batten and cladding. 14 Fibre Cement Nails* to fix cladding to battens Only required in high wind areas. 2.8 x 30mm corrosion resistant fibre cement nail. Not supplied by James Hardie. Accessories Exterior Water Based Gap Filling Agent Tools Sponge or course Utility Pad HardieTM Blade Saw Blade Dust-Reducing Saw with M class Drop Saw* 185mm Diameter or higher vacuum Extraction Recommended sealers include Selleys® No More Gaps - Exterior/ Weatherboard or Polyfilla® - Large Cracks. Used with recommended external based filling agent to match the panel texture finish. Poly-diamond blade for HardieTM fibre cement. Product Code: 300660 Pack Size: 1 each. Dust reducing saw with a HardieTM Blade saw blade. Makita® 5057KB / Hitachi® C7YA. Drop saw with an aluminium blade. *Not to be used for cutting the HardieTM Fine Texture Cladding. * In coastal areas and other corosive enviroments class 4 fasteners must be used. All other areas require minimum class 3. HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 7 OF 20 6 Panel Installation Process* - Direct Fix STEP 1 Plan the location of sheet joints to align with the house design. STEP 2 Ensure your frame is square, maximum tolerance of 4mm in 3000mm length STEP 3 Fix at 300mm centres Consider working from the centerline out to the wall edge to achieve symmetry, or Align the joints with key features of the house such as windows STEP 4 Install HardieTM Wrap weather barrier Overlap HardieTM Wrap weather barrier 150mm on horizontal joints Extend min. 150mm around corners STEP 5 Refer to Table 3 for maximum stud spacing Install the required corrosion resistant flashing over windows and other openings. Behind every vertical sheet join, fix a continuous strip of 50mm EPDM foam back sealing tape to the HardieTM Wrap weather barrier along the stud STEP 6 Fix at max. 300mm centres (10mm min. clearance from the edge) Corrosion resistant flashing with min. 75mm upstand Refer to the HardieTM Wrap Weather Barrier Technical data Sheet for further information Galvanised staple fastener every 450mm per stud Install the corner accessories extending them by 60mm below the bottom plate. The bottom edge of the corner accessories must be at least 90mm from the ground. STEP 7 When using the Slimline corners, the base flashing must be cut at 45 degrees. Slimline Corner 45º Base Flashing Install base flashing, sliding it into the corner accessories STEP 8 Fix the first sheet along the perimeter and to each intermediate stud 50mm min. clearance at corners Refer to Table 3 for fastener spacings STEP 9 Centre of stud 3 mm 18 mm Centre of stud 3 mm 18 mm Apply a continuous 4mm diameter bead of HardieTM joint sealant to the edge of the shiplap and fix the subsequent boards along the perimeter and to intermediate studs. Repeat the process to the following boards. Wipe any excess sealant from joint. STEP 10 Slide the HardieTM Fine Texture Cladding panels into the corner accessory and apply a continuous bead of sealant along the vertical joint. 45º When using the Slimline Corner, HardieTM Fine Texture Cladding Panels must be cut at 45 degrees STEP 11 300mm STEP 12 Paint the wall with an exterior acrylic paint within 3 months of being fixed or within 7 days if located within 1km of a coastal area or corrosive environment Apply a continuous 4mm diameter bead of HardieTM joint sealant to the edge of the panel and install the horizontal jointer Slimline Corner 45º When using the Slimline corners, the horizontal jointer flashing must be cut at 45 degrees. Horizontal jointer If patching is required use a gap filling agent and a sponge to mimic the texture of the surface and do not sand the wall. Ensure to refer to Finishing section on page 17 for full information. *This is an overview of the installation process only. It is not a substitute for reviewing this document in its entirety prior to installation. PAGE 8 OF 20 HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE 7 Panel Installation Process* - Cavity Fix STEP 1 Plan the location of sheet joints to align with the house design. STEP 2 Ensure your frame is square, maximum tolerance of 4mm in 3000mm length STEP 3 Fix at 300mm centres Consider working from the centerline out to the wall edge to achieve symmetry, or Align the joints with key features of the house such as windows STEP 4 Install HardieTM Wrap weather barrier Overlap HardieTM Wrap weather barrier 150mm on horizontal joints Extend min. 150mm around corners STEP 5 Refer to the HardieTM Wrap Weather Barrier Technical data Sheet for further information Galvanised staple fastener every 450mm per stud Damp proof course Max. 800mm centres when fixing cavity trims off-stud Refer to Table 3 for maximum stud spacing Install the HardieTM PVC cavity vent Strip Fix at 600mm centres maximum, with 10mm edge clearance. 15m0inm.m HardieTM PVC cavity vent mitred at corners and kept clear of debris. Do 10 mm not insert HardieTM cavity trim into the vent strip Install the required corrosion resistant flashing over windows and other openings. Corrosion resistant flashing with min. 75mm upstand STEP 6 Install the cavity trims (must be fixed off-stud in steel frames) 45º cut 50 HardieTM Joint Sealant 50 HardieTM cavity trim or timber batten 20 mm min. Refer to Table 3 for fastener spacing STEP 7 Install corner accessories as required. For alternative corners refer to Detailing section Fix at max. 300mm centres (10mm min. clearance from the edge) STEP 8 When using the Slimline corners, the base flashing must be cut at 45 degrees. Slimline Corner 45º Base Flashing 60mm below the bottom plate Install the corner accessories extending them 60mm below the bottom plate. The bottom edge of the corner accessories must be at least 90mm from the ground. Install base flashing, sliding it into the corner accessories STEP 9 Apply HardieTM Joint Sealant over the cavity trims or timber battens and fix the first sheet along the perimeter and to each intermediate stud 50mm min. clearance at corners Refer to Table 3 for fastener spacings 18 mm STEP 10 18 mm Apply a continuous 4mm diameter bead of HardieTM joint sealant to the edge of the shiplap and fix the subsequent boards along the perimeter and to intermediate studs. Repeat the process to the following boards. Wipe any excess sealant from joint. STEP 11 300mm Slimline Corner Apply a continuous 4mm diameter bead of HardieTM joint sealant to the edge of the panel and install the horizontal jointer 45º When using the Slimline corners, the horizontal jointer flashing must be cut at 45 degrees. Horizontal Jointer STEP 12 Paint the wall with an exterior acrylic paint within 3 months of being fixed or within 7 days if located within 1km of a coastal area or corrosive environment If patching is required use a gap filling agent and a sponge to mimic the texture of the surface and do not sand the wall. Ensure to refer to Finishing section on page 17 for full information. *This is an overview of the installation process only. It is not a substitute for reviewing this document in its entirety prior to installation. HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 9 OF 20 8 Construction Details - Direct Fix 75mm 75mm JUNCTION DETAILS HardieTM Flex Eaves Lining HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier HardieTM 9mm Aluminium Base Trim 57mm Min.90mm FIGURE 1 SLAB/EAVE JUNCTION DETAIL Alternative Detail: HardieTM Wrap Weather Barrier HardieTM 9mm Aluminium Horizontal Express Jointer NOTE: Do not fix the upper HardieTM Fine Texture Cladding panel to the bottom plate. Apply continuous 4mm diameter beads of HardieTM Joint Sealant Timber frame Flooring Apply continuous bead of HardieTM Joint Sealant vertically between joint flashing Fasten at centre of joist HardieTM Fine Texture Cladding FIGURE 2 UPPER FLOOR JUNCTION OPTION 1 HardieTM Wrap Weather Barrier HardieTM 9mm Aluminium Horizontal T Jointer NOTE: Do not fix the upper panel to the bottom plate. min. 6mm Apply continuous 5mm diameter beads of HardieTM Joint Sealant Fasten at centre of joist HardieTM Fine Texture Cladding Timber frame Flooring Apply continuous bead of HardieTM Joint Sealant vertically between T flashing 2mm gap left between Horizontal T flashing behind jointer HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding SecuraTM Interior Flooring The panels must not continue over a floor junction or where excessive movement or creep will occur, see Figures 25 and 26. FIGURE 3 UPPER FLOOR JUNCTION OPTION 2 FIGURE 4 LOWER FLOOR JUNCTION HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding 3mm Continuous 3mm diameter bead of HardieTM Joint Sealant iPnsoisditeivfeacfaellotfopwaarradpset Capping overlap 50 min. Pressed metal capping by others with sealed joints corresponding with joint in the facade HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier FIGURE 5 VERTICAL BUTT JOINT HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding 10mm HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding Damp proof course where required Footing HardieTM Fine Texture Cladding Corrosion resistant flashing HardieTM 9mm Aluminium Base Trim Min.90mm FIGURE 6 HORIZONTAL JUNCTION 2 PAGE 10 OF 20 HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE FIGURE 7 BLADE WALL Notch out around cladding 6mm bead of HardieTM Joint Sealant Note: 75mm slab edge exposure is an NCC requirement for termite detection Ensure the flashing is aligned with the cladding to prevent sharp edges. 75mm min. 10 75 Step angle 75mm min. Slide HardieTM 9mm Aluminium Base Trim Flashing over step angle FIGURE 8 SLAB STEP OPTION EXTERNAL CORNER DETAILS HardieTM Fine Texture Cladding HardieTM 9mm Aluminium Slimline External Corner HardieTM Wrap Weather Barrier HardieTM Joint Sealant applied at joint FIGURE 10 SLIMLINE CORNER OPTION 45-60 degree cut HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier Soffit framing 0.75 corrosion resistant shadow trim fixed horizontally along bottom chord Soffit lining 4mm bead of HardieTM Joint Sealant FIGURE 9 FACADE/SOFFIT JUNCTION HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier HardieTM 9mm Aluminium External Square Corner HardieTM Joint Sealant applied at joint FIGURE 11 ALUMINIUM SQUARE CORNER OPTION HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding NOTE: Joint is filled up with HardieTM Joint Sealant 5mm thick by 5mm high HardieTM Wrap Weather Barrier HardieTM 75x75mm Corner Flashing HardieTM Fine Texture Cladding Apply a continuous bead of HardieTM Joint Sealant along trim and panel HardieTM 75x75mm Corner Flashing FIGURE 12 SEALANT FILL OPTION Continuous bead of HardieTM Joint Sealant HardieTM Fine Texture Cladding Joint is filled with HardieTM Joint Sealant Cut the panel edge based on the corner angle 75x75mm corrosion resistant flashing Apply a continuous bead of HardieTM Joint Sealant along trim and panel FIGURE 13 TRIM CORNER OPTION AxentTM Trim 75x75mm corrosion resistant flashing HardieTM Wrap Weather Barrier Continuous bead of HardieTM Joint Sealant HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier Continuous bead of HardieTM Joint Sealant Joint is filled with HardieTM Joint Sealant FIGURE 14 SEALANT FILL OPTION - MORE THAN 90º EXTERNAL CNR FIGURE 15 SEALANT FILL OPTION - LESS THAN 90º EXTERNAL CNR HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 11 OF 20 INTERNAL CORNER DETAILS Framing HardieTM Wrap Weather Barrier HardieTM 9mm Internal Concave Corner HardieTM Joint Sealant HardieTM Fine Texture Cladding FIGURE 16 ALUMINIUM CORNER DETAIL Continuous bead of HardieTM Joint Sealant Continuous bead of HardieTM Joint Sealant AxentTM Trim HardieTM Fine Texture Cladding HardieTM 75x75mm Corner Flashing HardieTM Wrap Weather Barrier FIGURE 17 TRIM CORNER OPTION HardieTM Wrap Weather Barrier Continuous bead of HardieTM Joint Sealant HardieTM Fine Texture Cladding HardieTM 75x75mm Corner Flashing HardieTM Wrap Weather Barrier FIGURE 18 SEALANT FILL OPTION WINDOW DETAILS HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier Optional AxentTM Trim fastened to frame Clearence in accordance with window manufacturer Open joint to allow moisture to escape min. 6mm Suitable corrosion resistant flashing with min. 15% slope NOTE Joint is filled up with HardieTM Joint Sealant 5mm thick by 5mm high. NOTE: Before installing the window, please verify the overall frame thickness compared to the window reveal sizing to prevent gaps Lintel Waterproof Air Seal e.g. Suitable Expanded Foam Timber Architrave by installer Timber Reveal HardieTM Fine Texture Cladding Joint is filled with HardieTM Joint Sealant Cut the panel edge based on the corner angle 75x75mm corrosion resistant flashing FIGURE 19 SEALANT FILL OPTION - LESS THAN 90º INTERNAL CNR Internal lining Timber or FC Packer by installer Timber Reveal HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding Optional AxentTM Trim fastened to frame Suitable corrosion resistant flashing FIGURE 21 WINDOW JAMB - TRIM Continuous bead of HardieTM Joint Sealant Sill Weather Flap Flashing over sarking Sill Plate Optional AxentTM Trim fastened to frame HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier Timber Reveal Timber or FC Packer by installer Waterproof Air Seal e.g. Suitable Expanded Foam Timber Architrave by installer Internal Lining FIGURE 20 WINDOW HEAD AND SILL - TRIM PAGE 12 OF 20 HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE 9 Construction Details - Cavity Fix JUNCTION DETAILS HardieTM Wrap Weather Barrier 65 x 2.8mm ring shank gun nail HardieTM Fine Texture Cladding HardieTM Cavity Trim HardieTM 9mm Aluminium Base Trim Min. 10 mm Alternative Detail: HardieTM Cavity Trim DPC where required Min. 90 Rebated mm concrete slab DPC where required Rebated concrete slab FIGURE 22 ALTERNATIVE SLAB EDGE DETAILS HardieTM Fine Texture Cladding HardieTM Cavity Trim HardieTM Cavity Trim fixed to bottom plate. Do not fix to joist HardieTM 9mm Aluminium Horizontal Express Jointer Continuous horizontal bead of HardieTM Joint Sealant 5mm nom. dia. HardieTM Wrap Weather Barrier HardieTM Cavity Trim fixed to to plate. Do not fix to joist FIGURE 23 FLOOR LEVEL JUNCTION HORIZONTAL EXPRESS JOINTER HardieTM Cavity Trim HardieTM Cavity Trim fixed to bottom plate. Do not fix to joist HardieTM 9mm Aluminium Horizontal T Jointer 6mm Continuous horizontal beads of HardieTM Joint Sealant 5mm nom. dia. HardieTM Wrap Weather Barrier HardieTM Cavity Trim fixed to to plate. Do not fix to joist Pressed metal capping by others with sealed joints corresponding with joint in the facade Metal hold down clips screw through clearance hole Capping overlap 50 min. 30 HardieTM Fine Texture Cladding HardieTM Cavity Trim HardieTM Wrap Weather Barrier iPnosisditeivfeacfaellotof pwaarradpset Hardwood support screw fixed to structural framing 1º 2º to assure hugging fit Parapet lining FIGURE 24 FLOOR LEVEL JUNCTION HORIZONTAL T-JOINTER OPTION FIGURE 25 PARAPET CAPPING DETAIL HardieTM Fine Texture Cladding Min. 6mm gap between flashing and HardieTM Cavity Trim HardieTM Wrap Weather Barrier HardieTM Cavity Trim Flashing behind HardieTM Cavity Trim 150mm min. upstand Bond breaker tape over the top HardieTM Wrap weather barrier HardieTM Cavity Trim HardieTM Fine Texture Cladding 3mm Continuous 3mm diameter bead of HardieTM Joint Sealant FIGURE 26 FACADE/SOFFIT JUNCTION FIGURE 27 VERTICAL BUTT JOINT HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 13 OF 20 EXTERNAL CORNER DETAILS HardieTM Weather Barrier HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier HardieTM 75x75mm Corner Flashing HardieTM 9mm Aluminium External Square Corner HardieTM Fine Texture Cladding HardieTM Joint Sealant applied at joint FIGURE 28 ALUMINIUM SQUARE CORNER OPTION - CAVITY TRIM HardieTM 9mm Aluminium Slimline External Corner HardieTM Joint Sealant applied at joint FIGURE 29 SLIM CORNER OPTION - CAVITY TRIM HardieTM Wrap Weather Barrier HardieTM 75x75mm Corner Flashing HardieTM Fine Texture Cladding Apply a continuous bead of HardieTM Joint Sealant along trim and panel. 45-60 degree cut 30mm Apply a continuous bead of HardieTM Joint Sealant along trim and panel. 30mm AxentTM Trim FIGURE 30 TRIM CORNER OPTION - CAVITY TRIM INTERNAL CORNER DETAILS HardieTM Wrap Weather Barrier HardieTM 9mm Internal Concave Corner HardieTM Fine Texture Cladding FIGURE 31 ALUMINIUM CORNER DETAIL - CAVITY TRIM HardieTM 75x75mm Corner Flashing HardieTM Wrap Weather Barrier 5mm gap Note: Joint is filled up with HardieTM Joint Sealant 5mm thick by 5mm high. Bond breaker tape HardieTM Fine Texture Cladding FIGURE 32 SEALANT FILL OPTION - CAVITY TRIM PAGE 14 OF 20 HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE WINDOW DETAILS HardieTM Wrap Weather Barrier HardieTM Cavity Trim HardieTM Fine Texture cladding Corrosion resistant flashing with min. 75mm upstand NOTE: Before installing the window, please verify the overall frame thickness compared to the window reveal sizing to prevent gaps Continuous bead of HardieTM Joint Sealant HardieTM Cavity Trim HardieTM Fine Texture Cladding HardieTM Wrap Weather Barrier FIGURE 33 WINDOW HEAD AND SILL - CAVITY TRIM HardieTM Wrap Weather Barrier HardieTM Cavity Trim HardieTM Fine Texture Cladding Continuous bead of HardieTM Joint Sealant FIGURE 34 WINDOW JAMB - CAVITY TRIM HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 15 OF 20 INFILLS Where HardieTM Fine Texture Cladding is to be used as an infill piece, such as above garage or porticos, refer to the figures below: Refer to Figure 37 Refer to Figure 36 Refer to Figure 38 Rendered masonry wall HardieTM Fine Texture Cladding fixed in a horizontal orientation (Maximum heighth 1200mm) FIGURE 35 GARAGE DOOR DIAGRAM EPDM foam tape or HardieTM Cavity Trim or timber batten when installing on a drainage cavity HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding installed in a horizontal orientation (maximum height 1200mm) 3mm Continuous 3mm diameter bead of HardieTM Joint Sealant FIGURE 36 VERTICAL BUTT JOINT DIRECT FIX COLUMN 75x75mm minimum corrosion resistant flashing or HardieTM Cavity Trim or timber batten when installing on a drainage cavity Bond breaker tape HardieTM Joint Sealant over bond breaker tape HardieTM Wrap Weather Barrier HardieTM Fine Texture Cladding FIGURE 37 MASONRY (E.G. BRICK) ABUTMENT DETAIL) HardieTM 9mm aluminium Slimline External Corner HardieTM Fine Texture Cladding STEP1 Prepare panel edge with a 45-60 degree cut if using Slimline Extenal Corner. Position and fix the cladding to two faces of the column. Ensure the fasteners do not interfere with the HardieTM 9mm Aluminium Slimline Corner HardieTM Cavity Trims affixed to timber or steel column using appropiate fasteners. Contact fastener manufacturers for specific details. STEP2 Prepare cladding for the final remaining face with panel edges cut to 45 degrees and Slimline External Corner accessories fitted to each edge. Insert the whole assemby into position against the column as shown and fix in place. Timber or steel column FIGURE 38 FIXING TO TIMBER OR STEEL COLUMN PAGE 16 OF 20 HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE 10 Finishes and Maintenance 11 Product Information SURFACE PREPARATION Ensure the surface is dry, clean and any overdriven nails are patched in accordance with this specification. Any slightly overdriven brad nails (1mm max.) may be repaired using a suitable external grade filling agent and blended with the surrounding texture using a sponge or utility pad if required. Sealants James Hardie recommends the use of HardieTM joint sealant, which is a paintable polyurethane sealant. Use of alternative sealants must comply with manufacturer's instructions. Sealants, if coated, must be compatible with the paint system. PAINTING Panels must be finished within 3 months of being fixed with the recommended coating set out in Table 4 and the project specification. In areas within 1km of a coastal area or corrosive environment, panels must be coated immediately after fixing sheets to minimise contamination build up on the heads of the fasteners. TABLE 4 HardieTM Fine Texture Cladding Finishing Requirements Flat Acrylic Paints Exterior acrylic flat paint. A nap roller of 12mm or 3 greater is recommended for optimal finish. For best results,use low-sheen or matt finish exterior paints in natural colours. Roll-On Texture Paints (1-2mm) 8 Panels are pre-textured, they are not compatible with textured paints. Stains & Clear Sealers Semi-transparent stains can vary in uniformity of appearance depending on method of application and conditions and will require a high level of skill and craftsmanship to achieve a 8 uniform appearance. Clear coats have not proven durable in exterior exposure and James Hardie considers them a maintenance item that may require application of a refurbishing sealer at regular intervals. James Hardie does not warrant the appearance or durability of semi-transparent stains and clear coats. MAINTENANCE The extent and nature of maintenance will depend on the geographical location and exposure of the building. As a guide, it is recommended that basic normal maintenance tasks shall include but not be limited to: n Washing down exterior surfaces every 6-12 months* n Periodic inspections should be made to ensure fasteners are adequately securing the sheets to framing. n Re-applying of exterior protective finishes* n Maintaining the exterior envelope and connections including joints, penetrations, flashings and sealants that may provide a means of moisture entry beyond the exterior cladding. n Cleaning out gutters, blocked pipes and overflows as required. n Pruning back vegetation that is close to or touching the building. PRODUCT INFORMATION Material The basic composition of James Hardie's fibre cement products is Portland cement, ground sand, cellulose fibre, water and proprietary additives. James Hardie's fibre cement products are manufactured to AS/NZS 2908.2 `Cellulose-Cement Products-Flat Sheet'. These are also compliant with equivalent standard ISO 8336 `Fibre-cement flat sheets - Product specification and test methods'. For product classification refer to the relevant Physical Properties Data Sheet. Durability Resistance to Moisture/Rotting HardieTM Fine Texture Cladding have demonstrated resistance to permanent moisture induced deterioration (rotting) by passing the following tests in accordance with AS/NZS 2908.2: n Water permeability (Clause 8.2.2) n Warm water (Clause 8.2.4) n Heat rain (Clause 6.5) n Soak dry (Clause 8.2.5) Resistance to fire HardieTM Fine Texture Cladding is suitable where non-combustible materials are required in accordance with C1.9 of the National Construction Code (NCC). James Hardie's fibre cement building products have been tested by CSIRO in accordance with AS/NZS 3837 and are classified as conforming to Group 1 material (highest and best result possible), with an average specific extinction area far lower than the permissible 250m2/kg, as referenced in Specification C1.10a of the National Construction Code (NCC). Resistance to Termite Attack Based on testing completed by CSIRO Division of Forest Products and Ensis Australia, James Hardie's fibre cement building products have demonstrated resistance to termite attack. Alpine Regions In regions subject to freeze/thaw conditions, all fibre cement external cladding must be installed and painted in the warmer months of the year where the temperature does not create freeze and thaw conditions or paint issues. The cladding must be painted immediately after installation. In addition, fibre cement cladding must not be in direct contact with snow and/or ice build up for extended periods, e.g. external walls in alpine regions subject to snow drifts over winter. Furthermore, a reputable paint manufacturer must be consulted in regards to a suitable product, specifications and warranty. The paint application must not be carried out if the air temperature or the substrate temperature is outside the paint manufacturer's recommendation including the specified drying temperature range James Hardie's fibre cement products external cladding products are tested for resistance to frost in accordance with AS/NZS 2908.2 Clause 8.2.3. *Refer to your paint manufacturer for washing down and recoating requirements related to paint performance. HARDIETM FINE TEXTURE CLADDING INSTALLATION GUIDE PAGE 17 OF 20 For information and advice call 13 11 03 | jameshardie.com.au Australia October 2021 © 2021 James Hardie Australia Pty Ltd ABN 12 084 635 558 TM and ® denote a trademark or registered mark owned by James Hardie Technology Limited. Colorbond®, Selleys®, Polyfilla®, Hitachi, Makita®, Taubmans®, Wattyl® and Hilti are trademarks or registered trademarks of their respective owners and are not owned by James Hardie Technology Limited.Adobe PDF Library 15.0 Adobe InDesign 15.1 (Macintosh)
