iiyama G-MASTER GB3461WQSU-B1 34-inch UWQHD 144Hz Gaming Monitor
Product Overview and Specifications
Introduction
Experience an expanded field of view with the iiyama G-MASTER GB3461WQSU Red Eagle monitor. Featuring an IPS panel, a rapid 144Hz refresh rate, 1ms MPRT response time, and a sharp 3440x1440 UWQHD resolution, this monitor is engineered for hardcore gamers seeking to maximize their gaming potential and enjoy exceptional image quality. The height-adjustable stand allows for personalized screen positioning, while customizable settings via predefined and custom gaming modes, along with the Black Tuner function, provide precise control over dark scenes for enhanced detail visibility.
Key Features
FreeSync™ Premium Technology
This monitor ensures a smooth gaming experience by guaranteeing low input latency and low framerate compensation (LFC). This technology effectively eliminates screen tearing and stuttering, providing fluid visuals across a wide range of framerates.
ULTRA WIDE - UWQHD
The UWQHD (Ultra Wide Quad High Definition) resolution, combined with a 21:9 aspect ratio, delivers an expansive ultra-wide viewable area, immersing users in their games and content.
Display Characteristics
| Characteristic | Specification |
|---|---|
| Diagonal | 34", 86.7cm |
| Panel | ADS-IPS, matte finish |
| Native resolution | 3440 x 1440 @144Hz (4.9 megapixel UWQHD, DisplayPort) |
| Aspect ratio | 21:9 |
| Brightness | 350 cd/m² typical |
| Static contrast | 1000:1 typical |
| Advanced contrast | 80M:1 |
| Response time (MPRT) | 1ms |
| Viewing zone | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Colour support | 16.7 mln 8bit (sRGB: 100%, NTSC: 74%) |
| Horizontal Sync | 30 - 220kHz |
| Viewable area W x H | 799.8 x 334.8mm, 31.5 x 13.2" |
| Pixel pitch | 0.233mm |
| Colour | matte |
Interfaces / Connectors / Controls
| Interface | Specification |
|---|---|
| Signal input | HDMI x2 (v.2.0, max. 3440 x 1440 @100Hz, max. 2560 x 1440 @120Hz) DisplayPort x2 (v.1.4, max. 3440 x 1440 @144Hz) |
| USB HUB | x2 (v.3.0) |
| HDCP | ✔️ (yes) |
| Headphone connector | ✔️ (yes) |
Features
- Blue light reducer: ✔️ (yes)
- Flicker free: ✔️ (yes)
- FreeSync support: HDMI: 3440 x 1440 @48-120Hz, DP: 3440 x 1440 @48-144Hz
- HDR: ✔️ (HDR ready)
- OSD languages: EN, DE, FR, IT, RU, JP, CZ, NL, PL
- Control buttons: Power, Menu, +/- Volume, -/ ECO, Input/ Exit
- User controls: Picture adjust (brightness, contrast, black tuner, sharpness, OD, ACR, ECO, X-Res Technology, MBR), colour adjust (warm, normal, cool, user control, blue light reducer, gamma), input select, PiP/PbP (PiP/PbP mode, sub win input, PiP size, PiP position, swap), audio (volume, mute, audio input), i-Style (i-Style mode, save user mode 1/2/3), language, OSD settings (OSD H. position, OSD V. position, OSD background, OSD timeout, information), setup menu (video mode adjust, HDMI RGB range, direct drive, FreeSync, HDR, opening logo, LED, memory recall)
- Speakers: 2 x 5W
- Convenience: Kensington-lock™ prepared, DDC2B, Mac OSX
Mechanical
| Adjustment Type | Specification |
|---|---|
| Display position adjustments | height, swivel, tilt |
| Height adjustment | 130mm |
| Swivel stand | 90°; 45° left; 45° right |
| Tilt angle | 22° up; 3° down |
| VESA mounting | 100 x 100mm |
Accessories Included
- Cables: power, USB, HDMI, DP
- Other: quick start guide, safety guide
Power Management
| Parameter | Specification |
|---|---|
| Power supply unit | internal |
| Power supply | AC 100 - 240V, 50/60Hz |
| Power usage | 49W typical, 0.5W stand by, 0.5W off mode |
Sustainability
| Category | Details |
|---|---|
| Regulations | CE, TÜV-Bauart, EAC, PSE, RoHS support, ErP, WEEE, VCCI, REACH |
| Energy efficiency class (Regulation (EU) 2017/1369) | G |
| Other | REACH SVHC above 0.1%: Lead |
Dimensions / Weight
| Item | Specification |
|---|---|
| Product dimensions W x H x D | 817 x 415 (545) x 230mm |
| Box dimensions W x H x D | 900 x 460 x 230mm |
| Weight (without box) | 9.7kg |
| Weight (with box) | 12.8kg |
| EAN code | 4948570117185 |
Technical Drawings
Technical drawings illustrate the monitor's physical dimensions and mounting capabilities. These diagrams provide precise measurements for the product's width, height (including stand adjustment range), and depth. They also detail the standard 100 x 100mm VESA mounting interface, essential for attaching the monitor to compatible stands or wall mounts. The views typically include front, side, and top perspectives to give a comprehensive understanding of the monitor's physical form factor.
