Volvo Trucks. Driving Progress NEW FH 13 6x2 Pusher Tractor - Standard or Lite - Rear Air Suspension FH 62T P3A Chassis Dimensions [mm] WB Wheelbase A Overall Chassis Length D Center of rear axle to back of cab F Fifth Wheel Position (EC Directive 96/53) T Theoretical Wheelbase Chassis Weights [kg] Front Axle Rear Bogie Kerb Weight Turning Diameter [mm] Turning Circle Diameter Kerb to Kerb Turning Circle Diameter Wall to Wall Plated Weights [kg] Gross Vehicle Weight Gross Combination Weight Front Axle Rear Bogie 3800 8945 2810 675 3279 3900 8945 2910 675 3379 4000 8945 3010 675 3479 4100 8945 3110 675 3579 4690 3005 7695 4695 3010 7705 4695 3015 7710 4695 3025 7720 12100 12400 12700 13000 13400 13700 14000 14300 Plated 22800 44000 7500 19000 Design 26500 44000 7500 19000 3512 ,171 Cab 2495 Important Notes Chassis Dimensions Cab Height: +305 mm for CAB-HSLP, -285 mm for CAB-LSLP, +450 mm for CAB-XHSL. Front Axle to Back of Cab: +141 mm for CAB-LSLP. D-measure includes a front clearance of 50 mm and for rigid trucks also a subframe of 100 mm. Height can vary � 20 mm for leaf and � 10 mm for air suspension. All dimensions are for unladen chassis and any tag axles down. Chassis height used: CHH-HIGH. Height change when chassis height CHH-MED,FRAME266: 0 mm. Weight and dimensions are based upon the following tyres: Front Axle Tyres: 315/80R22.5 Drive Axle Tyres: 315/80R22.5 Trailing/Pusher Axle Tyres: 315/80R22.5 Chassis weight includes oil, water, AdBlue, 0 litres fuel and without driver. Kerb weight can vary � 3%. Turning diameters are theoretically calculated. Tag axle used: PA-FIXED. Legal weights can differ from country to country. For more detailed weight information, including optional equipment weights, ask your Volvo sales contact to enter your specification into the Volvo Weight Information system (WIS). Do NOT use this drawing for bodybuilding. Refer to Volvo Bodybuilder Instructions and chassis assembly drawing FH62TP3A. Ref: FH 62T P3A 01 GBR 2021-06-23 ENG 1 (7) NEW FH 13 6x2 Pusher Tractor - Standard or Lite - Rear Air Suspension FH 62T P3A CORE COMPONENTS CHH-HIGH CHH-LOW CHH-MED CHH-XLOW Chassis Height - High - for loading heights check the unique BEP chassis drawing Chassis Height - Low - for loading heights check the unique BEP chassis drawing Chassis Height - Medium - for loading heights check the unique BEP chassis drawing Chassis Height - Extra-low - for loading heights check the unique BEP chassis drawing PU-EHYS PU-FIXS Pusher axle - Electro-hydraulically steered Pusher axle - Fixed RAPD-G4 RAPD-GR Rear air suspension, 2 axles - 1 lite pusher / 1 driven Rear air suspension, 2 axles - 1 pusher/1 driven FH-HSLP5 FH-LSLP5 FH-SLP5 FH-XHSL5 Globetrotter cab - all steel safety cage design with roof mounted emergency escape hatch. Designed and built to Swedish impact and ECE R29 regulations Cab - Low Sleeper - all-steel safety cage design. Built to Swedish impact and ECE R29 regulations Cab - Sleeper - all-steel safety cage design with roof-mounted emergency escape hatch. Designed and built to Swedish impact and ECE R29 regulations Globetrotter XL cab - all steel safety cage design with roof mounted emergency escape hatch. Designed and built to Swedish impact and ECE R29 regulations EU6HT EU6SCR Emission level - Euro VI step E Emission level - Euro VI step E D13 420S D13 460S D13 460T D13 500S D13 500T D13 540S Engine - D13K420 12.8 litre developing 420hp at 14-1800rpm. Peak torque 2100Nm at 860 -1400rpm. Engine - D13K460 12.8 litre developing 460hp at 14-1800rpm. Peak torque 2300Nm at 900-1400rpm. Engine - D13K460TC 12.8 litre Turbo-compound diesel developing 460hp at 14-1800rpm. Peak torque 2600Nm at 900-1250rpm. Engine - D13K500 12.8 litre developing 500hp at 14-1800rpm. Peak torque 2500Nm at 1000-1400rpm. Engine - D13K500TC 12.8 litre Turbo-compound diesel developing 500hp at 14-1800rpm. Peak torque 2800Nm at 900-1250rpm. Engine - D13K540 12.8 litre developing 540hp at 14-1800rpm. Peak torque 2600Nm at 1000-1450rpm. D13K420 D13K460 D13K500 D13K540 D13K420 - 420hp engine D13K460 - 460hp engine D13K500 - 500hp engine D13K540 - 540hp engine EBR-EPG EBR-EPGC EBR-VEB+ Engine Brake Type - Exhaust brake controlled by steering column switch Engine Brake Type - Exhaust pressure governor for I shift gearbox Engine Brake Type - Volvo engine brake + and exhaust pressure governor, enhanced performance from additional exhaust rocker control. Retardation 375kW AT2612F AT2812F ATO2612F ATO3112F Gearbox - AT2612F 12-speed "I-shift" automated mechanical suitable for gross train weights up to 60tonne only. Refer to sales engineering when used in conjunction with a PTO Gearbox - AT2812E 12-speed "I-shift" automated mechanical suitable for gross train weights up to 60 tonne. Refer to sales engineering when used in conjunction with a PTO Gearbox - ATO2612F 12-speed "I-shift" overdrive automated mechanical, suitable for gross train weights up to 60tonne. Refer to sales engineering when used in conjunction with a PTO Gearbox - ATO3112F 12-speed "I-shift" overdrive automated mechanical, suitable for gross train weights up to 60tonne. Refer to sales engineering when used in conjunction with a PTO SPO2812 Gearbox - SPO2812 - 12-speed I-shift Dual Clutch automated mechanical GCW 60tonne ASO-C ASO-ULC Crawler gear Ratio direct top gearbox 19:1 Ratio Overdrive gearbox 17:1 Ultra low crawler and crawler gear Ratios direct top gearbox 32:1 and 19:1 Ratios Overdrive box 32:1 and 17:1 RSH1370F RSS1344E RSS1352A RSS1370A RSS1370B Drive Axle - RSH1370F 13-tonne hub reduction with differential lock - design GCW 70 tonne Drive Axle - RSS1344E single reduction with differential lock design GCW 44 tonne Drive Axle - RSS1352A single reduction 13 tonne with differential lock - design GCW 52 tonne Drive Axle - RSS1370A single reduction 13 tonne with differential lock - design GCW 70 tonne Drive Axle - RSS1370B single reduction 13 tonne with differential lock - design GCW 70 tonne PACKAGES FUELECO+ Fuel Package - Eco+ with improved economy mode for Volvo FH with I-Save FUELPACK Long Haul Fuel Economy driving package DRIVE5 DRIVE5+ DRIVE5++ Drive Package Drive+ Package Drive++ Package 1LIVIN++ 1LIVING 1LIVING+ 2LIVIN++ 2LIVING 2LIVING+ Sleep & Resting Package - Living one-bed ++ Sleep & Resting Package - Living one-bed Sleep & Resting Package - Living one-bed + Sleep & Resting Package - Living two-bed ++ Sleep & Resting Package - Living two-bed Sleep & Resting Package - Living two-bed + INFOBAS INFODF INFOMED INFONAV INFONDF Basic media package without secondary display Media Information Platform with Dynafleet Support Media Information Platform - Medium level Media Information Platform with Navigation Media Information Platform with Navigation & Dynafleet Support VISI5 VISI5+ VISI5++ VISIC5 VISIC5+ Visibility Package Visibility+ Package Visibility++ Package Visibility Package Visibility+ Package SAFE-VE Active Safety Package SAFE-VE+ Active Safety+ Package CHASSIS FST-AIR FST-PAR Front suspension type - Air Front suspension type - 2 leaf parabolic springs FSLS-BAS FSLS-HI Front suspension levelling - basic stroke Front suspension levelling - high stroke for demount operations - check with bodybuilder FAL7.5 FAL8.0 FAL8.5 FAL9.0 Front axle design capacity - 7.5 tonne Front axle design capacity - 8.0 tonne - check tyre capacity Front axle design capacity - 8.5 tonnes Front axle design capacity - 9.0 tonne - check tyre capacity FSTAB FSTAB2 FSTAB3 Front anti-roll bar - Normal stiffness Front anti-roll bar - Medium stiffness Front anti-roll bar - High stiffness RAL16 RAL19 Rear bogie design capacity - 16 tonne Rear bogie design capacity - 19 tonne RSTAB1 RSTAB3 Rear anti-roll bar - Normal stiffness Rear anti-roll bar - Stiff RALIM115 Rear-axle load limiter -11.5 tonne - speed controlled ASF-DL1 ASF-DL3 Air suspension with 1 driving level Air suspension with 3 driving levels Standard Equipment Optional Equipment For more detailed information about cab and powertrain equipment, please refer to separate specification sheets. For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS). The factory reserves the right to modify design and change equipment without previous notification. The specification can vary from country to country. Ref: FH 62T P3A 01 GBR 2021-06-23 ENG 2 (7) NEW FH 13 6x2 Pusher Tractor - Standard or Lite - Rear Air Suspension FH 62T P3A ACTST-TO ASFE-BAS ASFE-OG ASFE-PO ASFE-PS PSP-FIX PSP-VAR EBS-MED FRAME266 FRAME300 FST6565 FST7070 FST8080 FIL-EEEB FIL-TXEB BBOX-EF BBOX-L BATS-D BATS-S 2BAT210B 2BAT210C BATTAMP BATTIND ADR2 MSWI-A MSWI-C MSWI-R UR-FUEL L480A71S ADTP-BC ADTP-R ADB048 ADB064 ADB065 ADB068 ADB090 ADB100 ADTC-BF FCAP-L FUFF-AS FUFF-ATS ESH-REAR ESH-RIGH ESH-VERT EXST-SSP Active Steering- Volvo Dynamic Steering - VDS - with extra electronic pump and torque overlay Active steering feature - Basic - Volvo Dynamic Steering - VDS - only Active steering feature - Volvo Dynamic Steering - VDS - with stability assist - oversteer Active steering feature - Volvo Dynamic Steering - VDS - with personal settings and stability assist Active steering feature - Volvo Dynamic Steering - VDS - with personal settings Power steering pump - Fixed displacement Power steering pump - Variable displacement Brake package - EBS medium including "hill" hold function Chassis frame section external height - 266 mm Chassis frame section external height - 300 mm Chassis frame thickness - 6.5 mm web and flange Chassis frame thickness - 7 mm web and flange Chassis frame thickness - 8 mm web and flange Chassis frame inner liner - From the end of the engine to the end of the bogie Chassis frame inner liner - From gearbox member to the end of the bogie Battery box position - End of the frame in rear overhang Battery box position - Left hand side Dual energy battery system - 2 living batteries and 2 starter batteries. Single energy battery system (2 batteries) Battery Capacity - 2 x 210 Ah - Gel type Battery Capacity - 2 x 210 Ah - AGM Absorbent Glass-fibre Material type Battery management - Voltage and current gauge Battery management - Charge indicator ADR Adaptation - For transportation of dangerous goods on the road - Note does NOT include safe loading pass package if required this is quoted separately Battery master switch - ADR switch circuit shut down Battery master switch - Chassis mounted toggle by the battery box Battery master switch - Key fob operated remote controlled Without right-hand fuel tank Min volume 150l Max volume 365l Left fuel tank - 480litre aluminium diameter 710mm with catwalk & steps Min volume 160l Max volume 680l Adblue tank position - Behind and under the cab on the righthand side Adblue tank position - Chassis mounted on the right-hand side Plastic AdBlue tank - 48 litre Plastic AdBlue tank - 64 litre Plastic AdBlue tank - 65 litre under/behind the cab Plastic AdBlue tank - 68 litre Plastic AdBlue tank - 90 litre Plastic AdBlue tank - 100 litre AdBlue tank cover with satin alloy look decorative cover Diesel and AdBlue filler cap - Locking Fuel filler - Anti-spill device Fuel filler - Anti-spill & anti-syphon device Exhaust - Horizontal silencer - rear outlet Exhaust - Horizontal silencer - right outlet Exhaust - Horizontal silencer - vertical outlet Stainless steel exhaust stack - NOT polished EXST-ST Steel exhaust stack WHC-FOL2 Two foldable wheel chocks WHCP-F WHCP-T Wheel chock carrier position - In the front part of the vehicle Wheel chock carrier position - Outer luggage locker SUP-BAS EC approved chassis side guards CHAIN-S Snow chains HOOK-SC Snow chain hooks TOWF-NO1 Front towing device - One detachable - stored in cab TOWF-NO2 Front towing device - Two detachable - stored in cab TOWR-ONE Towing hitch attached to rear crossmember TREL15 TREL7 TREL7-7 Trailer electrical connection - Single 15 pin - ADR certified 7 pole - 24N trailer electrical suzie Trailer electrical connection - 2 x 7 pin - 24N and 24S TBC-DUO TBC-EC TBC-GBR Duomatic type air line connectors Trailer brakes with EC palm coupling connectors 'C' and 'CA' type air line connectors TRBR-HCF Full pressure hand controlled trailer brake TRBR-STA Stationary trailer brake control TRB-STRE Stretch Brake - Automatic low speed trailer brake activation to avoid jack-knifing and improve steerability RFEND-B Three piece EC approved rear mud wings and spray flaps RFH-BAS RFH-HIG RFH-LOW Basic rear wing height High rear wing height - higher wing tops Lower rear wing height - shallower wing tops ATANK-AL Air tanks - Aluminium ATANK-ST Air tanks - Steel TL-LED Rear lights - LED BLIGHT-E Emergency brake light WHEELS & TYRES RT-AL RT-ALDP RT-ALDPD RT-ALDU RT-STEEL Wheels - Alcoa brushed aluminium rims - standard holes for long stud fixing Wheels - Alcoa Dura-Bright aluminium rims - standard holes for long stud fixing Wheels - Alcoa Dura-Bright EVO aluminium rims - countersunk holes for short stud fixing Wheels - Alcoa brushed aluminium rims - countersunk holes for short stud fixing Wheels - Steel rims WCAP Aerodynamic hub caps JACK-12T JACK-15T JACK-20T 12 tonne bottle jack 15 tonne bottle jack 20 tonne bottle jack TOOL-BAS Basic Toolkit TOOLKIT Complete tool kit INFLAHOS Tyre inflation hose GAUGE-TP Tyre pressure gauge DRIVELINE EQUIPMENT TRAP-HD Reinforced gearbox application DRM-BE DRM-E Balanced & Economy Drive Mode Economy Drive Mode PVT-MAP I-See Predictive Cruise Control - using map based topography information CRUIS-E CRUIS-E4 CRUIS-E5 CRUISEC Eco cruise control (with eco-roll and I-cruise, controls in steering wheel) Eco fleet software - with cruise speed 85, I-See and push button I-shift. Cruise control, standard Standard Equipment Optional Equipment For more detailed information about cab and powertrain equipment, please refer to separate specification sheets. For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS). The factory reserves the right to modify design and change equipment without previous notification. The specification can vary from country to country. Ref: FH 62T P3A 01 GBR 2021-06-23 ENG 3 (7) NEW FH 13 6x2 Pusher Tractor - Standard or Lite - Rear Air Suspension FH 62T P3A AMSO-AUT AVO-ENH APF-ENH RET-TH TC-MAOH2 TC-MWO 2COM1100 2COMP900 CLU-AIRC AIRIN-FR AIRIN-HI AIRIN-LO ACL1ST-S 24AL110B 24AL120B 24AL150B CCV-C CCV-OX PRIM-EL PRIM-MAN AF-R FUEFE2LW EST-AID 220EBH15 PTER-100 PTER-DIN PTER1400 HPE-F101 HPE-F41 HPE-F51 HPE-F61 HPE-F81 HPE-T53 HPE-T70 HPE-V45 HPE-V75 PTR-D PTR-DH PTR-DM PTR-F PTR-FH PTR-FL PTRD-D PTRD-D1 Enhanced I-shift software with manual shift available in auto mode and kickdown facility on accelerator pedal I-Shift application software - for construction and off road applications I-shift enhanced PTO functions Gearbox mounted retarder Extra high performance transmission oil cooler - air to oil with front mounted radiator Basic transmission oil cooler - water to oil Air compressor - Two-cylinder 1100 litres per minute Air compressor - Two-cylinder 900 litres per minute Clutchable air compressor Front air intake fitted to the underside of cab engine tunnel Air intake - Roof-mounted behind cab on the left-hand side Low level air intake behind cab on left hand side Air filter - two-stage element Alternator capacity - 110 amp Alternator capacity - 120 amp alternator Alternator capacity - 150 amp Closed crankcase engine ventilation Closed crankcase ventilation for cold markets Electrical priming pump Manual priming pump Hot fuel recirculation heated fuel filter Large engine mounted dual fuel filter with water separator Engine starting aid -Preheating element in the air inlet manifold 220V/1.5Kw electric engine block heater Engine power-take-off - Rear-mounted with DIN100/ISO7646 flange Engine power-take-off - Rear-mounted with DIN5462 (female) splined shaft for a close-coupled pump Models with 3 steering axles will use this to drive the steering pump (AUXPSP) Engine power-take-off - Rear-mounted with SAE 1410 flange Parker F1-101,engine mounted, fixed displacement, single flow, engine mounted hydraulic pump Parker F1-41, engine mounted, fixed displacement, single flow, engine mounted hydraulic pump Parker F1-51, engine mounted, fixed displacement, single flow, engine mounted hydraulic pump Parker F1-61, engine mounted, fixed displacement, single flow, engine mounted hydraulic pump Parker F1-81, engine mounted, fixed displacement, single flow, engine mounted hydraulic pump Parker F2-53/53, engine mounted, Fixed displacement, Twin flow engine mounted hydraulic pump Parker F2-70/35, engine mounted, Fixed displacement, Twin flow engine mounted hydraulic pump Parker VP1-45, variable displacement, single flow, engine mounted hydraulic pump Parker VP1-75, variable displacement, single flow, engine mounted hydraulic pump Gearbox PTO for plug-in pump, 0.71xeng speed Gearbox driven high speed PTO for one plug-in hydraulic pump Gearbox driven medium speed PTO for one plug-in hydraulic pump Gearbox driven PTO with rear flange connection Gearbox driven high speed PTO with SAE drive flange Gearbox driven low speed PTO with SAE drive flange Gearbox driven HIGH SPEED PTO for two plug-in hydraulic pumps PTRD-D1 Gearbox driven HIGH SPEED PTO (1 SAE flange & 1 plug-in hydraulic pump) PTRD-D2 PTRD-F Gearbox driven HIGH SPEED PTO (2 SAE flanges & 1 plug-in hyd pump) PTO with 1 DIN + 1 flange connection rear, manual gearbox HPG-F101 HPG-F41 HPG-F51 HPG-F61 HPG-F81 Parker F1-101 gearbox mounted, fixed displacement, single flow, hydraulic pump Parker F1-41 gearbox mounted, fixed displacement, single flow, hydraulic pump Parker F1-51 gearbox mounted, fixed displacement, single flow, hydraulic pump Parker F1-61 gearbox mounted, fixed displacement, single flow, hydraulic pump Parker F1-81 gearbox mounted, fixed displacement, single flow, hydraulic pump STWPOS-R Steering wheel position - RIGHT-HAND DRIVE STWM-LE Leather steering wheel STGW-AD2 Adjustable steering wheel with neck tilt STGW-ADJ Adjustable steering wheel AIRBAG SRS Driver's air bag INST-BAS Basic level instruments DRC-AMII DPF Regeneration control switch - for manual and switching off regeneration 1DAYDIG2 Tachograph - Continental VDO 4.0 ARSL Additional road speed limit - switch in dashboard ESP-BAS1 Electronic Stability Control ESPC-RO ESP (Electronic Stability Program) functionality control Reduced / Off HWSS-ACB HWSS-FCB Adaptive cruise control ACC with forward collision warning and AEBS advanced emergency brake system Forward collision warning with AEBS advanced emergency brake system LSS-DW Lane departure-warning system LCS Lane change support DAS-W Driver Alert Support system RSENS-W Rain sensing windscreen wipers CU-ECC CU-ECC2 CU-MCC Cab Climate Unit - Electrically controlled air conditioning with sun sensor Cab Climate Unit - Electrically controlled air conditioning with a carbon filter, sun, mist, and air quality sensor Cab Climate Unit - Manual air conditioning IMMOBIL Thatcham H2 approved immobiliser ALARM-E Enhanced vehicle alarm - Thatcham H1 approved - Cab plus external sensor for body/trailer ALCOLOCK Alcolock AMPL400 Radio amplifier, 8 channel, 400 W with subwoofer Located in right hand external storage box BUPMON Back up monitor - Digital reverse camera, parameter & lead supplied loose in cab. PHONE-PK Telephone preparation kit (antenna, antenna attachm. cable incl.) ISUNS-BS Side sun visor - Driver & passenger side ISUNS-DS Side sun visor - Driver-side ISUNF-RE Electrically operated textile interior sun blind ISUNF-RM Manually operated textile interior sun blind CSPL-BX Lower center dash open storage box CSPL-BXD Lower centre dash drawer CSPU-SDR CSPU-SS One open storage and one drawer - behind push open lid - in upper part of the centre dash panel Two open storages - behind push open lid in upper part of the centre dash panel Standard Equipment Optional Equipment For more detailed information about cab and powertrain equipment, please refer to separate specification sheets. For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS). The factory reserves the right to modify design and change equipment without previous notification. The specification can vary from country to country. Ref: FH 62T P3A 01 GBR 2021-06-23 ENG 4 (7) NEW FH 13 6x2 Pusher Tractor - Standard or Lite - Rear Air Suspension FH 62T P3A ADFS Two extra DIN slots in front shelf - can be fitted with card or drawer available as an accessory BUPALARM Reverse alarm RTOLL-PK Road toll PREPARATION kit for trucks operating with "Toll Collect" in Germany LOADIND Load indicator with central dashboard display REMC-MF Multi-functio wireless remote control FIREXT3S Fire extinguisher - 3kg mounted on the seat base WARNVEST High visibility warning vest - no sleeves AIDKIT AIDKIT1B First aid kit - Legal demand for EU markets including delivery to EU bodybuilder First aid kit - Legal demand for trucks transiting Germany WARNLAMP Portable warning lamp LAMP-IN Inspection lamp BULBKIT Bulb and fuse kit WRITEPAD Writing pad DST-CF4 DST-CF5 DST-CF6 DST-LUX1 DST-LUX2 Driver seat - Suspended, adjustable shock absorber, travel, backrest & lumbar controls - seatbelt mounted to the seat Driver seat - Suspended with adjustable shock absorber, travel, backrest, lumbar & heat controls - seatbelt mounted to the seat Driver seat - Suspended with adjustable shock absorber, travel, backrest, lumbar, heat and ventilation controls - seatbelt mounted to the seat Driver seat - Deluxe 1: electrical adjustment with memory function, lumbar support, heating & ventilation - seatbelt mounted to the seat Driver seat - Deluxe 2: electrical adjustment with memory function, lumbar support & heating - seatbelt mounted to the seat SBD-RED Seat belt colour - Red SBPRE-DS Driver seat belt pretensioner PST-BAS1 PST-CF4 PST-CF5 PST-RX1 PST-STD2 PST-STD4 Passenger seat - Fixed non suspended fold up with seatbelt mounted in cab Passenger seat - Suspended, adjustable shock absorber, travel, backrest & lumbar controls - seatbelt mounted to the seat Passenger seat - Suspended with adjustable shock absorber, travel, backrest, lumbar & heat controls - seatbelt mounted to the seat Passenger seat - Fixed non suspended, features: 90-degree rotation and tilt function with seatbelt mounted in cab Passenger seat - Fixed with backrest adjustment, non suspended with seatbelt mounted in cab Passenger seat - Standard suspended with seatbelt mounted in cab SBPRE-PS Passenger seat belt pretensioner ARMRE-BB Armrests - Two on both driver & passenger seats ARMRE-DB Armrests - Two on the driver seat ARMRE-PB Armrests - Two on the passenger seat ARU-BAS ARU-LEA Armrest upholstery - Vinyl Armrest upholstery - Leather GRABHI-B Steel instep cab grab handle GRABHI-L Leather covered instep cab grab handle FMAT-RUB FMAT-TX2 Footwell floor mats - Rubber Footwell floor mats - Two sets, Rubber and textile with an embossed pile supplied in the cab LBK80F LBK80FRE LBK80FRM Lower fixed bunk with wide middle section 815 in the centre x 2000 mm Lower electrically operated recline bunk with wide middle section 815 in the centre x 2000 mm Lower manually operated recline bunk with wide middle section 815 in the centre x 2000 mm MATL-FI MATL-FI4 MATL-SF Firm lower bunk pocket sprung mattress Lower mattress - firm, memory foam, 2000x700x130 mm Lower flexizone mattress - semi-firm, pocket springs up to 100kg - 16 stone OLMAT-BA 35mm mattress overlay protector OLMAT-PR 50mm premium mattress overlay protector TBK60AD TBK60F TBK70AD TBK70F Height adjustable foldable top bunk 600 x 1900mm Fixed foldable top bunk 600 x 1900mm Height adjustable foldable top bunk 700 x 1900mm Fixed foldable top bunk 700 x 1900mm PH-CAB2 1.8kW Air to air night heater PH-ENGCA Engine and cab night heater CPC-ADV I-ParkCool - Advanced cab parking cooler with 120V DC electrical compressor SLCP-BAS SLCP-LUX Sleeper control panel - Basic with switches for interior light, night heater, roof hatch and door lock Sleeper control panel - Luxury with switches for interior light, night heater, roof hatch, door lock, alarm clock, window and radio SAFE Safe box for driver's personal items RUS-BAS RUS-HIG Rear cab upper storage - 300 mm high Rear cab upper storage - 440 mm high - volume 245 litres TABLE Folding and height adjustable table - on lower bunk REFR-RUS Fridge - 28 litre rear upper wall mounted with dividers REFRIG Fridge - 33 litre under-bunk mounted with freezer dividers MICRO-PK Wiring preparation kit for microwave oven BOTH-D BOTH-DL BOTH-L One bottle holder under dashboard centre section Two bottle holders, one under dashboard centre section and one mounted to the under bunk drawer One bottle holder mounted to the under bunk drawer COFMA-PK Coffee maker, preparation kit. INLI-BAS INLI-NL INLI-NLD Interior white LED lights - basic Interior white and red night LED light with no dimmer Interior white and red night LED light with dimmer ARL-FLEX Two flexible reading lamps (snake lamps) RH-EE RH-ER RH-ETR RH-MTR Fixed tinted glass sky window with emergency exit Steel roof hatch - Electrically operated, rear opening with emergency exit Tinted glass roof hatch - Electrically operated, rear opening with emergency exit Tinted glass roof hatch - Manually operated, rear opening with emergency exit GLAS-TIN Tinted windows. SWIND-BS Extra side window on both sides behind "B" pillar VANMIR Vanity mirror in front shelf AS-FUS Extra shelf in front upper storage compartments INFOT-PK Preparation kit for the mounting of a flat screen TV in cab above the driver's door, includes bracket, electrical and speaker connections CAB EXTERIOR EXTL-BAS EXTL-EN2 EXTL-ENH Basic exterior finish - Satin Volvo badges, grey grille, instep, bumper, bumper spoiler, grille, door handles mirror housing and sunvisor if specified. Enhanced complete painted finish - Satin Volvo badges. Main grille, instep, door handles, mirror housing, and bumper in cab colour. Aluminium step inserts. Sunvisor and bumper spoiler in cab colour if specified. Enhanced exterior finish - Painted grille in cab colour with grey instep, bumper, bumper spoiler, grille, door handles mirror housing and sunvisor if specified, and aluminium step inserts DGLAS-H DGLAS-L Tempered door glass Laminated door glass Standard Equipment Optional Equipment For more detailed information about cab and powertrain equipment, please refer to separate specification sheets. For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS). The factory reserves the right to modify design and change equipment without previous notification. The specification can vary from country to country. Ref: FH 62T P3A 01 GBR 2021-06-23 ENG 5 (7) NEW FH 13 6x2 Pusher Tractor - Standard or Lite - Rear Air Suspension FH 62T P3A LOCK-REM Door locks - Remote central locking BUMP-B BUMP-B2 BUMP-HD Plastic front bumper Steel front bumper Heavy duty front bumper BUMP-SP Front bumper spoiler GUARD-EH Engine guard to protect sump and engine hoses BUGNET Insect screen in front of radiator CTILTP-E CTILTP-M Electrically operated hydraulic cab tilt Manually operated hydraulic cab tilt FCABS-A FCABS-M Front cab suspension - Air Front cab suspension - Mechanical spring RCABS-A Rear cab suspension - Air RCABS-M Rear cab suspension - Mechanical spring HCC-INEX Exterior and interior hood catch control MIRCFCPS MIRCOMF MIRSTD Mirrors - Electrically heated and operated main and wide-angle with manually adjusted kerb view mirror on the passenger side and position camera in nearside mirror arm. Electrically heated and operated main and wide angle mirrors and manually adjusted kerb view mirror on passenger side Electrically heated main and wide angle mirrors and manually adjusted kerb view mirror on passenger side AMIR-F20 Auxiliary front view mirror with a 200mm radius SUNV-H External smoke grey sunvisor AD-ROOF Roof air deflector AD-SIDEL Side air deflector extension panels AD-CHASX Chassis side skirts ADCF-F Additional black edging on chassis side skirt HL-BASIC Halogen H7 head lamps HL-CLEAN Head lamp cleaner - washer jets HLP-ST Headlamp protection HL-ADJ Headlight adjustment - Switch in cab DRIVL2 UDRIVL Two spot lamps Without auxiliary driving lights FOGL-WC Front fog lights CL-STAT Static corner lights ASL-RF2 Two Hella H11 70W spotlamps in sign box - only available with the basic headlight and no lower driving lights. BEACOA2F BEACOA2R BEACON-P BEACONA4 Roof beacons - Two front roof mounted amber LED Roof beacons - Two rear roof mounted amber LED Roof beacons - wiring preparation only Roof beacons - Four amber LED - two front/ two rear CABPT-R1 Single outlet for roof mounted accessories CABPT-R2 Twin outlets for roof mounted accessories. SPOTP-F SPOTP-R SPOTP-RF Spotlamp preparation in front, max 280W Spotlamp preparation on roof, max 280W Spotlamp preparation on cab roof and in cab front, max 2x280W ROS-IL2 Preparation kit for illuminated roof sign with switch loose in cab, fit after registration CSGN-GTR "Globetrotter" headboard logo HORN-F1S Horn - Air single tone - chassis mounted HORN-R2S Horn - Air - Two roof-mounted ANT-CBR Roof mounted antenna for CB radio, single aerial ACCBR-AP Front, middle & rear roof mounted accessory brackets ACCBR-F Front roof mounted accessory bracket ACCBR-FM Front & middle roof mounted accessory brackets ACCBR-FR ACCBR-M ACCBR-R ACCBR-RM Front & rear roof mounted accessory brackets Middle roof mounted accessory bracket Rear roof mounted accessory bracket Rear & middle roof mounted accessory brackets STUC-B STUC-L STUC-R Left and right storage compartments under cab Left storage compartment under cab Right storage compartment under cab RFCAR-BC Rear mudwing carrier, back of cab LADDER Ladder back of cab REFS-TW REFS-TY White cab conspicuity markings by packed in cab Yellow cab conspicuity markings by packed in cab SUPERSTRUCTURE PREPARATIONS 5WM-ASL 5WM-ASM 5WM-ISOL 5WM-ISOM 5WM-LPRO 5WM-MASM Mount - Air operated slider with 4mm L profiles Mount - Air operated slider with 50mm L profiles Mount - Flush L profiles with 12mm ISO plate - 16mm high above chassis frame Mount - 50mm L profiles with 10mm ISO plate - 60mm high above chassis frame Mount - Direct to frame with inverted 'L'-profiles Mount - Manual slider with 50mm L profiles 5WH150 5WH160 5WH175 5WH185 5WH195 5WH200 5WH205 5WH210 5WH220 5WH230 Leg-height - 150 mm Leg-height - 160 mm Leg-height - 175mm Leg-height - 185 mm Leg-height - 195mm Leg-height - 200 mm Leg-height - 205 mm Leg-height - 210 mm Leg-height - 220mm Leg-height - 230 mm 5WT-FO14 5WT-FO15 5WT-JO10 5WT-JO8 5WT-JO9 5WT-SH Fifth wheel - Fontaine 150SP2 pressed steel Fifth wheel - Fontaine 3000 lightweight cast air operated slider - for moderate duty off-road. Fifth wheel - Jost JSK 36 pressed Fifth wheel - Jost JSK 37 cast Fifth wheel - Jost JSK 42 cast Fifth wheel - SAF-Holland/+GF+ SK-S 36.20 cast 5WLM-B 5WLM-L Maintenance - Basic fifth wheel - standard top plate Maintenance - Low maintenance with nylon top plate 5WL-S1 5WL-S2 Fifthwheel lubrication - locking mechanism and top plate Fifthwheel lubrication - locking mechanism TCIND Trailer connection indicator - Sensors for height, kingpin and coupling lock RDECK RDECK-M Catwalk - Single plate and step Catwalk - Extended with two plates and step SRWL-PK SWL-2RW SWL-PK Chassis-mounted working lamps - Side work and reverse lamp preparation and 3 position switch - Max load 280W Chassis-mounted working lamps - Two white rear-mounted LED lamps Chassis-mounted working lamps - Side work lamp preparation and 2 position switch - Max load 280W WL-TA1W Coupling light - White WLC-H2W WLC-PKH WLC-PKL WLC-PKLH Two H3/70W white working lamps high mounted on the back of cab Preparation kit, cables and switch for high mounted working lamps back of cab Preparation kit, cables and switch for low mounted working lamps back of cab Preparation kit - cables and switch for low and high mounted working lamps back of cab. ECBB-HIG Body builder electrical centre with body builder module BBCHAS1 One 7-pole connector for Body builder interface BBCHAS3 Three 7-pole connectors for Body builder interface BEPR-T2 Body builder electrical software preparation for tipper with remote control Standard Equipment Optional Equipment For more detailed information about cab and powertrain equipment, please refer to separate specification sheets. For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS). The factory reserves the right to modify design and change equipment without previous notification. The specification can vary from country to country. Ref: FH 62T P3A 01 GBR 2021-06-23 ENG 6 (7) NEW FH 13 6x2 Pusher Tractor - Standard or Lite - Rear Air Suspension FH 62T P3A EXSTER External steering control - Volvo dynamic steering and bodybuilder module prepared for external control system, installed and computer by bodybuilder TD-LED Trailer detection with LED sensing AUXL-SPK Electrical preparation kit - wiring and switch for snow plough lights TAILPRE2 Tail lift preparation kit, wireless remote operation TAILPREP Taillift preparation kit - cab switch and warning in driver display AESW2 AESW2PK Two Body builder bistable electrical switches (marked AUX1 / AUX2) 2 Body builder bistable el.switches (marked AUX1/AUX2) and prep. for 4 more switches AUXSW-4 Wiring for 4 extra switches (from Body builder electrical centre to switch positions) DELIVERY SERVICES TGW-4GWL Telematics gateway - GSM/GPRS/4G modem, LTE & WLAN FMS-PK Fleet Management System gateway DRUT2 Driver utility app - "My Truck" - two-year subscription For mobile phone, tablet, with android and IOS systems. Only available with Volvo Connect subscription Standard Equipment Optional Equipment For more detailed information about cab and powertrain equipment, please refer to separate specification sheets. For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS). Volvo Truck Corporation The factory reserves the right to modify design and change equipment withvooultvpotreruvciokus.sconmotification. The specification can vary from country to country. Ref: FH 62T P3A 01 GBR 2021-06-23 ENG 7 (7)
