• Zynq UltraScale Device Technical Reference Manual (UG1085) [Ref 3]. X-Ref Target - Figure 1-2 Figure 1-2: Converter Tile Structure DAC X0Y0 Data Path 2 Data Path 3 Data Path 1 DAC1 Data Path 0 DAC0 IP State Machine s03 axis s02 axis s01 axis s00 axis 6.4 GSPS RF-DAC Tile ADC X0Y1 Data Path 2 ADC2 Data Path 3 ADC3 Data Path 1 ADC1 Data Path ...
RFSoC Data Converter Evaluation Tool User Guide 5 UG1287 (v2019.1) May 29, 2019 www.xilinx.com Chapter 1 Introduction Overview The objective of this reference design is to he lp you quickly and easily evaluate the new RF
Zynq UltraScale+ RFSoC RF Data Converter Evaluation Tool (ZCU111)
User Guide
UG1287 (v2019.1) May 29, 2019
Revision History
The following table shows the revision history for this document.
Section
General updates.
Programmable Logic Filter Chapter 2, Package Details
Chapter 2, Package Details
DAC Data Flow Streaming MUX GPIO Selection Application Flow DAC Flow for PL DDR Example Commands and Responses
Initial Xilinx release.
Revision Summary
05/29/2019 Version 2019.1
Updated for Vivado Design Suite version 2019.1.
12/05/2018 Version 2018.3
Added this section. Updated the evaluation tool package name for Vivado Design Suite version 2018.3.
11/06/2018 Version 2018.2
Updated design package link.
10/01/2018 Version 2018.2
Added information about feeding data to the RF-DAC. Added channel control selection information. Replaced Table 3-2. Added DDR and BRAM selection information and information to start DMA. Added this section. Added commands to Table A-1.
08/14/2018 Version 2018.2
N/A
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
2
Send Feedback
Table of Contents
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 1: Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Zynq UltraScale+ RFSoC Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Reference Design Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 2: Package Details
Chapter 3: Hardware Design
Hardware Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 DAC Data Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 ADC Data Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Programmable Logic Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Stream Pipes Control and Status Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 GPIO Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Chapter 4: Clocking
Clock Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Resets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Chapter 5: Evaluation Tool System Configuration using the GUI
External Component Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 ADC Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 ADC Clock Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Digital Down Converter Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 DAC Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 DAC Clock Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Digital Up Converter Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 ADC Tone Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 6: Software Architecture
Software Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
3
Send Feedback
Chapter 7: Protocol Specification
Socket Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Command Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Application Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Multi-Tile Sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Chapter 8: Zynq UltraScale+ RFSoC Data Converter Bare-metal/Linux Driver
Chapter 9: System Considerations
Boot Process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 Global Address Map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Memory Mapping for RF-DAC/RF-ADC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Appendix A: Reference Design Protocol Specification
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Example Commands and Responses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Control Path Core Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Appendix B: Additional Resources and Legal Notices
Xilinx Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 Solution Centers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 Documentation Navigator and Design Hubs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 Please Read: Important Legal Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
4
Send Feedback
Chapter 1
Introduction
Overview
The objective of this reference design is to help you quickly and easily evaluate the new RF Data Converter (DC) Evaluation Tool functionality in the Zynq® UltraScale+TM family of RFSoCs. The RFSoC design demonstrates the capabilities and performance of the RF data converter (RFDC--RF-ADC and RF-DAC) available in the RFSoC devices. The evaluation tool serves as a platform for you to evaluate the Zynq UltraScale+ RFSoC features and helps accelerate the product design cycle.
The evaluation tool consists of a ZCU111 evaluation board and a custom-developed graphical user interface (GUI) installed on a Windows host machine. The evaluation tool allows you to configure the operation of the RF-ADCs and RF-DACs and perform some basic tests e.g., FFT analysis of the ADC output for various input test signals. The key differentiator of Zynq UltraScale+ RFSoC devices when compared to many other discrete solutions is that the device contains both RF-ADCs and RF-DACs. However, one significant benefit is the DACs can be used to provide test signals for the ADC (i.e., loopback) which facilitates a very compact and easy to use solution for early demonstration or evaluation.
All communications to the host PC (GUI) use the processing system (PS) Ethernet interface. This is necessary to facilitate the transfer of a large amount of test data as efficiently as possible. The ZCU111 evaluation board supports an external DDR4 memory interface on the programmable logic (PL) in addition to the PS DDR4 memory. Waveforms with a limited number of samples can leverage on-chip memory, but application testing and prototyping require the use of much larger external memories.
The Xilinx® Vivado® IP integrator flow is used to create the hardware design, which is partitioned between the PS, RFDC, and PL. The reference design uses the IP integrator core for the RF Data Converter subsystem. The implementation supports all data rates on PL to the Data Converter interface, all converter sample rates and digital up conversion (DUC)/digital down conversion (DDC) configurations with a single design. The Xilinx PetaLinux flow is used to create and integrate the software components, including the Linux kernel and drivers.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
5
Send Feedback
Chapter 1: Introduction
This user guide describes the architecture of the design and provides a functional description of its components. It is organized as follows:
Chapter 1, Introduction (this chapter) provides a high-level overview of the Zynq UltraScale+ RFSoC architecture, the design architecture, and a summary of key features.
Chapter 2, Package Details gives an overview of the design modules and design components that make up this design.
Chapter 3, Hardware Design describes the hardware platform of the design including key PS and PL peripherals.
Chapter 4, Clocking describes the details on clocking used for the design.
Chapter 5, Evaluation Tool System Configuration using the GUI describes the details of system configuration and features supported using the GUI.
Chapter 6, Software Architecture describes the application processor unit (APU) software platform including the Linux software stack and the Linux rftool application running on the APU.
Chapter 7, Protocol Specification describes the protocol used to communicate between the host and RFSoC.
Chapter 8, Zynq UltraScale+ RFSoC Data Converter Bare-metal/Linux Driver describes where to get more information about the driver.
Chapter 9, System Considerations describes system architecture considerations including boot flow and the system address map.
Appendix A, Reference Design Protocol Specification describes the commands used in the software design.
Appendix B, Additional Resources and Legal Notices lists additional resources and references.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
6
Send Feedback
Chapter 1: Introduction
Zynq UltraScale+ RFSoC Overview
The Zynq UltraScale+ RFSoC family integrates the key subsystems required to implement a complete software-defined radio including direct RF sampling data converters, enabling CPRI and Gigabit Ethernet-to-RF on a single, highly programmable SoC.
Each RFSoC offers multiple RF-sampling analog-to-digital (RF-ADC) and RF-sampling digital-to-analog (RF-DAC) data converters. The RF-ADC supports a maximum sample rate of 4 GSPS with dynamic range and has a signal bandwidth of up to 4 GHz. The RF-DAC can clock at up to 6.554 GSPS with an output signal bandwidth of greater than 4 GHz. The RF data converters also include power efficient digital down converters (DDCs) and digital up converters (DUCs) that include programmable interpolation, decimation rates, a numerically controlled oscillator (NCO), and a complex mixer. The DDCs and DUCs can also support multi-band operation. Figure 1-1 shows the block diagram of the Zynq UltraScale+ RFSoC RF Data Converter.
X-Ref Target - Figure 1-1
Zynq UltraScale+ RFSoC
Data Converter IP Core
Processing System Quad ARM Cortex-A53 Dual ARM Cortex-R5
AXI4-Stream AXI4-Stream
DUC DUC
DAC DAC
8 TX Channels
Programmable Logic
AXI4-Lite AXI4-Stream
GTY Serial Transceivers
AXI4-Stream
Control and Configuration
DDC DDC
ADC ADC
8 RX Channels
Figure 1-1: Zynq UltraScale+ RFSoC RF Data Converter in RFSoC
X21232-092118
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
7
Send Feedback
Chapter 1: Introduction
The RF-ADCs and RF-DACs are organized into tiles, each containing either two or four RF-ADCs or four RF-DACs (see Figure 1-2). Each tile also includes a block with a PLL and all the necessary clock handling logic and distribution routing for the analog and digital logic.
X-Ref Target - Figure 1-2
s03_axis
IP State Machine
s02_axis s01_axis
s00_axis
Data Path 3 Data Path 2
DAC3 DAC2
Data Path 1
DAC1
Data Path 0
DAC0
DAC_X0Y0
6.4 GSPS RF-DAC Tile
m13_axis
IP State Machine
m12_axis m11_axis
m10_axis
Data Path 3 Data Path 2
ADC3 ADC2
Data Path 1
ADC1
Data Path 0
ADC0
ADC_X0Y1
2 GSPS RF-ADC Tile
m03_axis
m02_axis
IP State Machine
m01_axis m00_axis
Figure 1-2: Converter Tile Structure
Data Path 1 (23)
ADC1 (23)
Data Path 0 (01)
ADC0 (01)
ADC_X0Y0
4 GSPS RF-ADC Tile X21300-090918
For device specifications and additional information, see:
· Zynq UltraScale+ RFSoC Data Sheet: Overview (DS889) [Ref 1]
· Zynq UltraScale+ RFSoC Data Sheet: DC and AC Switching Characteristics (DS926) [Ref 2]
· Zynq UltraScale+ Device Technical Reference Manual (UG1085) [Ref 3].
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
8
Send Feedback
Chapter 1: Introduction
Reference Design Overview
The evaluation tool targets the Zynq UltraScale+ RFSoC ZU28DR-FFVG1517 running on the ZCU111 evaluation board and provides a platform to evaluate the RFSoC features. The system level block diagram of the evaluation tool design is shown in Figure 1-3.
X-Ref Target - Figure 1-3
PC User Interface
Gigabit Ethernet
Clock Module
I2C
Power
Mux
Controller
ZCU111 Evaluation Board
Zynq® UltraScale+TM RFSoC
Software Application
I2C
I2C Driver
RFdo Driver
GEM
GEM Driver
$38
Processing System
DMA
AXIS
AXIS Stream Pipes
AXIS
PL DDR
AXI
AXI4-Lite
DMA
AXIS
DMA
AXIS Stream Pipes
AXIS
DAC RFdc IP
ADC
Clocking and Control
Programmable Logic
Daughter Card
(HWRFMCXM500)
Filters
PS DDR
PL DDR
Figure 1-3: RF Data Converter Evaluation Tool System Level Block Diagram
X21291-092118
The evaluation tool uses an integrated RF Data Converter in an 8x8 configuration along with AXI DMA and AXI4-Stream components for high performance data transfers between PL-DDR to RFDC and vice versa. Stream Pipe comprises various AXI4-Stream Infrastructure IPs. The AXI DMA is configured in Scatter Gather (SG) mode for high performance. The evaluation tool also makes use of multiple processing units available inside the PS, such as Gigabit Ethernet, I2C, and SD Interface. The APU inside the PS is configured to run in symmetric multiprocessing (SMP) Linux mode. The main task of the Linux application is to configure and control the RF-ADC and RF-DAC blocks and the flow of data through the streaming pipeline.
A custom-developed Windows-based GUI is provided along with this evaluation tool. It can interact with the RFSoC running on the ZCU111 evaluation board. The GUI connects to the Linux application running on the RFSoC via a TCP Ethernet interface. Based on commands
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
9
Send Feedback
Chapter 1: Introduction
received from the GUI, the Linux application performs various operations that are described in Chapter 6, Software Architecture. Because a TCP socket is used to transfer the data over Ethernet, it is possible to run the GUI on any machine connected to the network (i.e., cloud).
The evaluation tool can be run in three separate modes:
Standalone DAC: In this mode, a pattern is generated using the GUI on the host machine. This pattern is constantly replayed on the selected DAC channel. The output of the DAC can be monitored on any standard external equipment, such as a spectrum analyzer or oscilloscope.
Standalone ADC: In this mode, you generate an analog signal from external equipment, and this signal is fed to ADC inputs. Digital output of the ADC can be analyzed on the host machine using the GUI.
DAC to ADC Loopback: In this mode, the output of the DAC is looped back to the input of ADC. In this way, you can generate a pattern on DAC from the GUI and can analyze the same pattern on ADC output in the GUI. It is recommended to manage RF signal conditioning well. Anti-aliasing filters are supplied in the ZCU111 development kit for the existing RF line up of RFMC-XM500.
Note: For system performance and limitations in various scenarios, see the ZCU111 RFSoC RF Data
Converter Evaluation Tool Getting Started Guide [Ref 4].
Components
· Evaluation platform
° ZCU111 evaluation board ° Daughter card (HW-FMC-XM500) ° Cables and filters (see the Zynq UltraScale+ RFSoC ZCU111 Evaluation Kit Quick
Start Guide (XTP490) [Ref 5]
· Xilinx tools
° Vivado® Design Suite 2019.1 [Ref 6] ° Xilinx® Software Development Kit (XSDK) 2019.1 [Ref 7] ° PetaLinux tools 2019.1 [Ref 8] · Hardware interfaces and IP
° RFDC ° AXI DMA ° DDR controller interface ° AXI SmartConnect ° AXI interconnect
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
10
Send Feedback
Chapter 1: Introduction
° AXI4-Stream IPs · Auxiliary peripherals
° SD ° I2C ° PS-GPIO ° Gigabit Ethernet ° UART ° JTAG
Software Components
· Operating systems
° APU: SMP Linux · Linux frameworks
° Ethernet ° Clock ° Contiguous memory allocator (CMA) · User applications
° APU: Ethernet-based server application · RFDC driver-based features
° Digital down conversion (DDC)/digital up conversion (DUC) ° Nyquist Mix mode ° Digital complex mixers ° Quadrature modulation correction (QMC) ° Internal PLL ° ADC calibration ° DAC high linearity and low noise ° Inverse sinc filter ° DAC Output Current mode (20 or 32 mA) ° External clock driver · AXI-DMA client driver
· Board-specific components
° Voltage controller
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
11
Send Feedback
Chapter 2
Package Details
The evaluation tool ZIP file package rdf0476-zcu111-rf-dc-eval-tool-2019-1.zip contains the following components grouped by application processor unit (APU) or programmable logic (PL). The package is available at the Zynq UltraScale+ RFSoC ZCU111 Evaluation Kit documentation website.
APU
petalinux_bsp: PetaLinux board support package (BSP) is included to build a pre-configured SMP Linux image for the APU. The BSP includes the following components: · First stage boot loader (FSBL) · ARM trusted firmware (ATF) · U-Boot · Linux kernel · Device tree · Root file system (rootfs)
PL
Vivado: Vivado IP integrator design that integrates the RF Data Converter subsystem, AXI DMA, Stream Pipe, AXI Interconnect, and PL DDR controller.
Host System GUI
The user interface connecting to the ZCU111 platform via Ethernet cable.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
12
Send Feedback
Chapter 3
Hardware Design
Hardware Overview
The Vivado IP integrator flow is used to create the hardware design which is partitioned between the processing system (PS), RF Data Converter (RFDC), and programmable logic (PL). Figure 3-1 shows the hardware block diagram.
X-Ref Target - Figure 3-1
Processing System
DDR Controller
GEM
AAPAPAUPUPUU
SD
I2C
S_AXI_HP0_FPD AXI Interconnect
AXI Interconnect S_AXI_HP1_FPD
AXI Interconnect
M_AXI_HPM0_FPD AXI Smartconnect
GPIOs
DMA
DMA
Channel Select Mux
Stream Mux
Stream Pipe
Stream Pipe
Stream Pipe
Stream Pipe
ADC0
ADC7
RFdc
DAC0
DAC7
DDR4 Controller (MIG) Clocking and Control Programmable Logic
Figure 3-1: Hardware Block Diagram
X21233-092118
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
13
Send Feedback
Chapter 3: Hardware Design
The design is configured to operate in 8x8 mode (8-channel RF-DAC and 8-channel RF-ADC). The RFDC datapath consists of AXI DMA and Stream Pipe IPs for high performance data transfers between PS/PL DDR memories and RFDC IP. The RFDC datapath is based on AMBA AXI4-Stream protocol and the control path is based on the AXI4-Lite interface. Both datapath and control paths are implemented in the PL.
The PS is configured with a GEM Ethernet controller (GEM3) and I2C controllers (I2C0 and I2C1). The GEM Ethernet controller enables a Gigabit Ethernet interface between the host machine and the ZCU111 board. The I2C controller provides an interface between the PS and the on-board RF PLLs.
The SD card holds the image and file system, which loads the FPGA part when power is switched on.
The information passed from the host system GUI via Ethernet to the ZCU11 platform is stored in the PL DDR using a DDR controller. The application running on the processor then transfers this data to the programmable logic over the AXI ports.
The following sections provide detailed information for both RF-DAC and RF-ADC datapaths.
DAC Data Flow
Figure 3-2 shows the datapath implementation for the 8-channel RF-DAC (RF-DAC0 and RF-DAC7). There are eight stream pipes implemented. Each of these stream pipes feed data to the RF-DAC. Due to the extreme speed of the RF-DAC, it is not possible to live-feed the data using Ethernet, hence user-selected signals are continuously looped over or replayed to create a continuous and measurable signal at the output of the DAC.
There are two ways input samples are stored and replayed:
· Samples are stored and looped over in PL DDR (high storage but reduced speed). · Samples are stored and looped over in block RAM (low storage but highest speed).
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
14
Send Feedback
X-Ref Target - Figure 3-2
PL DDR + MIG AXI
SG DMA
Chapter 3: Hardware Design
Stream Mux
Memory Loopback 0
Memory Loopback 1
Memory Loopback 2
Memory Loopback 3
Memory Loopback 4
Memory Loopback 5
Memory Loopback 6
Memory Loopback 7
DAC0 DAC1 DAC2 DAC3 DAC4 DAC5 DAC6 DAC7
512 bits x 300 MHz
AXI Streaming Interface
256 bits x 300 MHz
256 bits x DAC CLK
X21293-092118
Figure 3-2: Datapath Implementation for 8-Channel RF-DAC
Figure 3-2 represents the architecture of the 8-channel RF-DAC (RF-DAC0 to RF-DAC7). The Scatter Gather (SG) DMA is used to source the data from the PL DDR memory controller to the DACs. The DMA sends this data to the stream MUX block, which is connected to each of the DAC channel's stream data path. Based on the channel select line input (PS-GPIOs routed through extended multiplexed I/Os (EMIOs)) of the stream pipe, the data gets routed to the corresponding RF-DAC channel. (See GPIO Selection.) In case of continuous replay from DDR, DMA constantly fetches the data and streaming mux switches the channel based on the user selection of enabled channels. For sample storage and replay from BRAM mode, the functionality of the memory loopback system is elaborated upon in Memory Loopback Details.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
15
Send Feedback
Chapter 3: Hardware Design
Streaming MUX
The streaming MUX connects the incoming pattern to the selected channel(s) based on a GUI command. Figure 3-3 shows the stream data interface with AXIS FIFOs.
X-Ref Target - Figure 3-3
Memory Loopback 0
TDATA
Memory Loopback 1
------------
Memory Loopback 7
X21235-090918
Figure 3-3: Stream Data Interface with AXIS FIFOs
The TDATA is broadcast as is without any additional component in the path. This helps to achieve timing closure because there is no multiplexer in the path.
The TVALID signal is ANDed with the Channel Control signal as shown in Figure 3-4. Based on user channel selection, the TVALID signal is enabled. The channel control select is asserted based on mode (BRAM or DDR). For BRAM mode, it is controlled by software using GPIOs. For DDR mode, it is controlled by a hardware logic block channel arbiter. The arbiter block allocates the DMA access among the eight streaming interfaces based on number of channels selected in the GUI. Software programs the Channel Select register based on the GUI command. After the register is programmed, the arbiter block first samples the predefined register to determine the active channels and arbitrates only among those active channels in a round robin fashion (based on the TLAST on the streaming interface), thereby effectively using the DDR bandwidth.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
16
Send Feedback
Chapter 3: Hardware Design
X-Ref Target - Figure 3-4
Memory Loopback
0
Memory Loopback
1
------------
Tvalid 0..7 Channel Select 0..7
Channel Arbiter
Memory Loopback
7
X21236-092118
Figure 3-4: Channel Selection Control Signals Figure 3-5 shows the TREADY signal generation. Only a single TREADY signal is selected based on the Channel Select signal; other TREADY signals are ignored.
X-Ref Target - Figure 3-5
Memory Loopback 0
Memory Loopback 1
------------
TReady Mux
Memory Loopback 7
Channel Arbiter
X21237-092118
Figure 3-5: TREADY Signal Generation
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
17
Send Feedback
Chapter 3: Hardware Design
Memory Loopback Details
Figure 3-6 illustrates the working of memory loopback (BRAM mode) in one DAC path.
X-Ref Target - Figure 3-6
DMA
AXIS FIFO (S00)
AXI Stream Mux
Loopback (S01)
AXIS FIFO
Control Switch
AXIS Broadcaster
DAC Interface
To DAC
DMA Clock Domain
AXIS FIFO
DAC CLK Domain
X21239-092118
Figure 3-6: Implementation of Memory Loopback Component
The data coming from the DMA via the AXI4-Stream decoder (Stream MUX) is fed into an asynchronous AXI4-Stream FIFO. This takes care of the clock domain crossing between the DMA clock and DAC clock domain. The output of the FIFO is fed into an AXI4-Stream multiplexer component. This component switches between regular BRAM (Loopback) mode and DDR (Continuous Playback) mode. The control switch logic block takes input from PS-GPIOs through an EMIO interface, and when it is High (controlled by software), the output of the corresponding control logic goes High and enables the channel. The working of the control switch is further described in the DAC Control Switch section. Based on mode selection, either data is continuously replayed from AXIS FIFO to the AXIS broadcaster, or data is continuously fetched from DMA and subsequently transferred to DAC.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
18
Send Feedback
Chapter 3: Hardware Design
DAC Control Switch
The control switch is the final control logic before the streaming interface is connected to the DAC. This logic provides tight control over the streaming path and helps synchronize all the stream interfaces at any given time. Figure 3-7 shows the control switch.
X-Ref Target - Figure 3-7
Tvalid In Channel Start
Tvalid Out to DAC Control Switch
TReady Out to FIFO
Control Switch
Tready Channel Start
X21238-090918
Figure 3-7: Control Switch
The channel control signal acts as a channel start/stop signal. This signal exists individually for all channels and can be used to control each channel independently. This is done using PS-GPIOs through the EMIO interface that are in turn controlled by software. The control switch controls TVALID input to DAC and TREADY input to FIFO, as shown in Figure 3-7. See GPIO Selection.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
19
Send Feedback
Chapter 3: Hardware Design
ADC Data Flow
Figure 3-8 shows the datapath implementation for 8-channel RF-ADC (RF-ADC0 and RF-ADC7). The default configuration of Real to IQ is enabled in the design so that all possible streaming interfaces from RF-ADC are accessible.
X-Ref Target - Figure 3-8
ADC0 ADC1 ADC2 ADC3 ADC4 ADC5 ADC6 ADC7
Control Switch
Control Switch
Control Switch
Control Switch
Control Switch
Control Switch
Control Switch
Control Switch
I & Q Merge I & Q Merge I & Q Merge I & Q Merge I & Q Merge I & Q Merge I & Q Merge I & Q Merge
AXIS FIFO 64 KS
AXIS FIFO 64 KS
AXIS FIFO 64 KS
AXIS FIFO 64 KS
AXIS FIFO 64 KS
AXIS FIFO 64 KS
AXIS FIFO 64 KS
AXIS FIFO 64 KS
Channel Select Mux
SG DMA
PL DDR + MIG
128 bits x 512 MHz
256 bits x 512 MHz
256 bits x 300 MHz
X21302-092518
Figure 3-8: Datapath Implementation for 8 Channel RF-ADC
All the incoming ADC streams are gated through the control switch logic. After the gates are enabled, the I and Q streams are fed through IQ Merge logic. Based on user selection, either a real or a complex stream is passed on to the AXIS FIFO. The Channel Select MUX connects one of the AXIS FIFO to DMA, based on user selection. This data is further provided to SG DMA to be stored in PL DDR memory. The synchronization among all eight channels is achieved through control switch logic. A common global start signal is used for this purpose.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
20
Send Feedback
Chapter 3: Hardware Design
ADC Control Switch
The control switch is the final control logic before the streaming interface is connected to the ADC. This logic controls the streaming path and also helps to synchronize all the stream interfaces when required through software control. Figure 3-9 shows the control switch.
X-Ref Target - Figure 3-9
Tready Channel Start
Control Switch Tready Out to ADC
Tvalid Out to FIFO
Control Switch
Tvalid Channel Start
X21241-090918
Figure 3-9: Control Switch
The channel select signal acts as a channel start/stop signal. This signal exists individually for all channels and can be used to control each channel independently. This is done using PS-GPIOs through the EMIO interface that are in turn controlled by software.
The control switch controls TVALID input to FIFO and TREADY input to ADC.
I & Q Merge Logic
The IQ datapath for RF-ADC is shown in Figure 3-10. This pipe can capture IQ data while maintaining synchronization and coherency. The data is captured in an interleaved fashion i.e., eight samples of I data and eight samples of Q data. The AXIS combiner IP is used to combine I and Q streams.
Alternatively, you can select a Real channel only (in which case, the width converter IP is used to convert the incoming 128-bit Real data to 256-bit Real data). Finally, the data is stored into an AXIS FIFO.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
21
Send Feedback
X-Ref Target - Figure 3-10
Chapter 3: Hardware Design
I (Real) Stream Q Stream
AXIS Broadcaster
Data Width Converter
AXI4-Stream Mux
DMA
AXIS Combiner IQ Select
Figure 3-10: IQ Datapath
X21242-091318
Channel Select MUX
The Channel MUX implementation is an 8:1 streaming selection logic as shown in Figure 3-11. Among eight incoming streaming inputs, only one streaming data is passed to SG DMA interface based on channel-select input.
X-Ref Target - Figure 3-11
AXIS FIFO 0
AXIS FIFO 1
------------
Channel Select Mux
Stream Out to
DMA
AXIS FIFO 7
Channel Select
Figure 3-11: Channel MUX
X21243-090918
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
22
Send Feedback
Chapter 3: Hardware Design
Programmable Logic Filter
This design element illustrates the ease with which custom high-performance signal processing elements can be added to the signal chain in the Vivado IP integrator. These blocks are generated using the Xilinx System Generator flow. System Generator is a plug-in to the Simulink environment, adding a block set to the Simulink® software library browser. The block set has about 90 blocks. These blocks leverage the Xilinx IP core generators to deliver optimized results for RFSoCs. Using SysGen flow in Vivado Design Suite 2019.1, you can generate vector or multi-sample designs using super sample rate (SSR) filters. These filters help process data at a speed that matches RFDC ADC/DACs.
In the current evaluation design, SSR filters are implemented on tile 0/block0 for both ADC and DAC. The configuration of these filters is fixed to x8, with the user having an option either to bypass or enable x8 interpolation and decimation. If used along with RFDC IPs Interpolation/decimation filters, you can achieve an interpolation/decimation rate of 16x, 32x, and 64x.
Details of the implementation of the SSR filter are shown in Figure 3-12 and Figure 3-13.
X-Ref Target - Figure 3-12
)URP 0HPRU\ /RRSEDFN
Bypass
AXIS Demux
AXIS MUX
AXIS FIFO
SSR IP
Width Converter
AXIS FIFO
X21953-112718
Figure 3-12: DAC SSR IP Block Diagram
The AXIS demux and AXIS multiplexer are is controlled through a common GPIO pin. You have the option to either bypass (disable) SSR IP or enable the SSR IP through the GPIO pin. Additional AXIS FIFO are added to the SSR IP input and output interface to provide a cushion for maintaining rate control.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
23
Send Feedback
Chapter 3: Hardware Design
Similarly, SSR IP for ADC is also enabled. Figure 3-13 shows the implementation of SSR ADC Filter IP.
X-Ref Target - Figure 3-13
)URP $'&
Bypass
7R ,40HUJH
AXIS Demux
AXIS MUX
AXIS FIFO
SSR IP
Width Converter
AXIS FIFO
Figure 3-13: ADC SSR IP Block Diagram
X21954-112718
Stream Pipes Control and Status Registers
The register sets in the design are available under the user_axilite_control block. The block has an AXI4-Lite interface through which the registers can be accessed. In the current implementation, the base address of the user_axilite_control is 0xB005_0000. Table 3-1 lists the registers that are available currently.
Table 3-1: Control and Status Register
Name
DAC_path_0_fifo_data_count
Offset
0x00
DAC_path_1_fifo_data_count
0x04
DAC_path_2_fifo_data_count
0x08
DAC_path_3_fifo_data_count
0x0C
DAC_path_4_fifo_data_count
0x10
DAC_path_5_fifo_data_count
0x14
DAC_path_6_fifo_data_count DAC_path_7_fifo_data_count ADC_path_0_fifo_data_count ADC_path_1_fifo_data_count ADC_path_2_fifo_data_count
0x18 0x1C 0x20 0x24 0x28
ADC_path_3_fifo_data_count
0x2C
ADC_path_4_fifo_data_count
0x30
ADC_path_5_fifo_data_count
0x34
ADC_path_6_fifo_data_count
0x38
ADC_path_7_fifo_data_count
0x3C
Description
Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO Indicates the count inside the FIFO
Default Value
32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0 32'd0
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
24
Send Feedback
Chapter 3: Hardware Design
GPIO Selection
Table 3-2 provides the list of GPIOs for channel control, memory loopback reset, and IQ selection.
Table 3-2: Control Signals
DAC
Function
DAC0 Memory Loopback Reset Reserved DAC0 Channel Control DAC0 Loopback select DAC1 Memory Loopback Reset DAC1 Loopback select DAC1 Channel Control DAC2 Loopback select DAC2 Memory Loopback Reset
GPIO#
0 1 2 3 4 5 6 7 8
ADC
Function
ADC0001 FIFO Reset ADC0001_IQ_Merge_sel ADC0001 Channel Control Reserved ADC0203 FIFO Reset ADC0203_IQ_Merge_sel ADC0203 Channel Control Reserved ADC1011 FIFO Reset
DAC3 Loopback select DAC2 Channel Control DAC4 Loopback select
9 ADC1011_IQ_Merge_sel 10 ADC1011 Channel Control 11 Reserved
DAC3 Memory Loopback Reset 12 ADC1213 FIFO Reset
DAC5 Loopback select
13 ADC1213_IQ_Merge_sel
DAC3 Channel Control
14 ADC1213 Channel Control
DAC6 Loopback select
15 Reserved
DAC4 Memory Loopback Reset 16 ADC2021 FIFO Reset
DAC7 Loopback select
17 ADC2021_IQ_Merge_sel
DAC4 Channel Control
18 ADC2021 Channel Control
Reserved
19 Reserved
DAC5 Memory Loopback Reset 20 ADC2223 FIFO Reset
Reserved
21 ADC2223_IQ_Merge_sel
DAC5 Channel Control
22 ADC2223 Channel Control
Reserved
23 Reserved
DAC6 Memory Loopback Reset 24 ADC3031 FIFO Reset
Reserved
25 ADC3031_IQ_Merge_sel
Common
GPIO#
Function
32 DAC Arbiter Reset
33 ADC Arbiter Reset
34 Reserved
35 Reserved
36 DAC Multi Tile Select
37 Reserved 38 Reserved 39 Reserved 40 ADC Channel Mux
select
41 Reserved
42 ADC Multi Tile Select 43 ADC Fabric Filter
Select
44 DAC Fabric Filter Select
45
46
47
48 49 50 51 52
53
54
55
56
57
GPIO#
64 65 66 67 68 69 70 79:71 82:80
83 84 90
91
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
25
Send Feedback
Chapter 3: Hardware Design
Table 3-2: Control Signals (Cont'd)
DAC
DAC6 Channel Control
ADC
26 ADC3031 Channel Control
58
Reserved
27 Reserved
59
DAC7 Memory Loopback Reset 28 ADC3132 FIFO Reset
60
Reserved
29 ADC3132_IQ_Merge_sel
61
DAC7 Channel Control
30 ADC3132 Channel Control
62
Reserved
31 Reserved
63
Common
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
26
Send Feedback
Chapter 4
Clocking
The evaluation tool design has 256 MHz, 409.625 MHz, 300 MHz, and 512 MHz clock domains. The RF-DAC output is a maximum of 409.625 MHz and RF-ADC 256 MHz. The 256 MHz output from ADC is supplied to the clocking wizard for generating 512 MHz for driving the PL ADC path whereas 409.625 MHz drives the PL DAC path directly. The 300 MHz clock is generated from the PL DDR block (ddr4_0).
Figure 4-1 shows the analog and mixed signal (AMS) clocking structure in the ZCU111 evaluation board.
X-Ref Target - Figure 4-1
LMX2594 PLL 1
To ADC Tile 0 - 1
LMX2594 PLL 2
To ADC Tile 2 - 3
I2C0 PS
I2C1
LMX2594 PLL 3
To DAC Tile 0 - 1
I2C Mux
I2C Expander
I2C SPI
LMK04208
FPGA REF CLK
SysRef FPGA
SysRef In SysRef RFSoC
X21244-092118
Figure 4-1: ZCU111 AMS Clocking Structure
The RF data converter clocking includes a primary external onboard reference PLL (LMK04208) and onboard RF PLLs (LMX2594) to generate RF-ADC and RF-DAC sample clocks. The primary management interface for the PLL devices is the Serial Protocol Interface (SPI). The SPI is enabled on the ZCU111 via an I2C to SPI bridge. The bridge components are enabled using the I2C MUX/Expander component present on ZCU111. This
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
27
Send Feedback
Chapter 4: Clocking
scheme allows the application software to program the PLL chip sets without any external tools.
The LMK component shown in Figure 4-1 provides a low jitter and low noise clock to RFDC IP and to RF PLLs which act as a source for further clock generation and clock synchronization. LMK modules generate six clock outputs that are connected to these various blocks and components:
· PL: Sys Ref
· DAC: Sys Ref
· PL: FPGA Ref Clk
· LMX: Ref Clock
· LMX: Sync Clock
· SMA: 12.8 MHz Clock
Refer to Appendix A, Reference Design Protocol Specification for more details about clock commands and arguments.
In each Zynq UltraScale+ RFSoC, each RF-ADC or RF-DAC tile has its own clock input. Additionally, there is a dedicated input PL SYSREF pin pair per package. The PL SYSREF clock is used for multi-tile and multi-chip synchronization. For multi-tile designs, the PL SYSREF connects into a master tile and the signal is distributed within the master tile and all the other tiles in the design. The generation from PL SysRef is done using the output of the LMK module. The RFDC IP requires PL SysRef synchronously captured in the PL. For this purpose, PL SysRef provided to the IP must be synchronous to the clock domain of the group, i.e., PL clock. This is achieved using the logic diagram shown in Figure 4-2.
X-Ref Target - Figure 4-2
PL SYSREF (LMK)
Sync 1st Stage
Sync 2nd Stage
user_sysref to RFdc
PL REF CLK (LMK)
MMCM
Fabric Clock
Fabric Logic
Figure 4-2: SysRef Synchronization
X21245-092118
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
28
Send Feedback
Chapter 4: Clocking
First, the PL SysRef is synchronized to the incoming PL clock for both DAC and ADC as shown in Figure 4-2. This output of the second stage synchronizer is connected to user_sysref ports of RFDC IP. Refer to Zynq UltraScale+ RFSoC RF Data Converter LogiCORE IP Product Guide (PG269) for more details on multi-tile synchronization [Ref 9].
Clock Switching
The design supports multi-tile synchronization (MTS) mode and non-MTS mode. The requirements for both modes are different. In MTS mode, all the DAC and ADC streams should be triggered and captured at the same time. Hence all the DAC fabric paths associated with different tiles are sourced by a common PL clock. This is the same case with all the ADC paths. In non-MTS mode, the streaming interface clocks can be sourced by their respective DAC and ADC tile clocks. The switching of the clock is controlled via a clock MUX primitive BUFGMUX (see Figure 4-3 and Figure 4-4). Clock selection depends on whether MTS mode is selected or not.
X-Ref Target - Figure 4-3
Tile Clock
BUFGMUX
PL Fabric Clock
Multi-Tile Mode
X21246-091318
Figure 4-3: Clock MUX Selection
The other requirement of MTS mode is that all the incoming and outgoing streams of RFDC IP should be triggered at the same instant. This is achieved using a combination of control switch and channel control logic (Figure 4-5 and Figure 4-6). Figure 4-6 shows the channel control scheme implemented in the design. The individual channel control signal is generated using PS-GPIO pins. Later on, these signals are synchronized with respect to the selected clock from BUFGMUX. This signal acts as an individual channel start/stop signal which is fed to the control switch block of the ADC/DAC datapath. However, in MTS mode,
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
29
Send Feedback
Chapter 4: Clocking
this signal is overridden with a global start/stop signal which is generated using Channel Select of the Master DAC block, i.e., tile 0 block 0. This signal selection is controlled using multi-tile mode select.
X-Ref Target - Figure 4-4
Example: Fs = 3.2 GHz Decimation = x1 SYREF = 8 MHz PL SYSREF = 8 MHz PL REF CLK = 200 MHz PL CLK = 400 MHz
333 MHz
PL DDR + MIG
DMA
Stream Mux
PL SYSREF (PCB) PL REF CLK (PCB)
PS
GP IO
User_sysref_adc
MMCM
PL CLK (Fabric Clock)
AXIS FIFO 64 KS
AXIS FIFO 64 KS
I & Q Merge
I & Q Merge
Multi-Tile Control
Tile0_clk
PL CLK Tile0 _ADC_Clock out
PLL
ADC 0 Tile 0 ADC 1
To Tile0 channels
To Tile1 channels
Sync logic
PL
CLK
To Tile2 channels
To Tile3 channels
AXIS FIFO 64 KS
I & Q Merge
Multi-Tile Control
Tile3_clk
PL CLK
Tile3 _ADC_Clock out PLL
AXIS FIFO 64 KS
I & Q Merge
ADC 2 Tile 1 ADC 3
ADC 4 Tile 2
ADC 5
ADC 6 Tile 3 ADC 7
ADC 0 Analog Clock (PCB)
ADC 1 Analog Clock (PCB) SYSREF (PCB) User_sysref_dac (Fabric Clock) ADC 2 Analog Clock (PCB)
ADC 3 Analog Clock (PCB)
Figure 4-4: RF-ADC Multi-Tile Sync Clocking Structure
X21247-092118
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
30
Send Feedback
X-Ref Target - Figure 4-5
Channel 0 Control Channel 1 Control
PS GPIO
Channel 2 Control Channel 3 Control PS Clock Multi-Tile Control Channel 4 Control Channel 5 Control
Channel 6 Control Channel 7 Control
N-stage Sync logic
N-stage Sync logic
ADC 0 Control ADC 1 Control
PL CLK ADC 2 Control ADC 3 Control
N-stage Sync logic
N-stage Sync logic
ADC 4 Control ADC 5 Control
ADC 6 Control ADC 7 Control
Chapter 4: Clocking
Multi-Tile Control
Tile0_clk
PL CLK
Tile0 _ADC_Clock out
PLL
Multi-Tile Control
Tile1_clk
PL CLK Tile1 _ADC_Clock out
PLL
Multi-Tile Control
Tile2_clk
PL CLK Tile2 _ADC_Clock out
PLL
Multi-Tile Control
Tile3_clk
PL CLK Tile3 _ADC_Clock out
PLL
ADC 0 Tile 0 ADC 1
ADC 2 Tile 1 ADC 3
ADC 4 Tile 2 ADC 5
ADC 6 Tile 3 ADC 7
ADC 0 Analog Clock (PCB)
ADC 1 Analog Clock (PCB) SYSREF (PCB) User_sysref_dac (Fabric Clock) ADC 2 Analog Clock (PCB)
ADC 3 Analog Clock (PCB)
X-Ref Target - Figure 4-6
Figure 4-5: RF-ADC Control Signals for Multi-Tile Sync (Sync Block)
PS Clock
Tile0 _clk
PS Clock
Tile2 _clk
Channel 0 Control
Synchronizer
Channel 1 Control
Synchronizer
PS Clock
Tile1 _clk
ADC 0 CONTROL Multi-Tile Control ADC 1 CONTROL Multi-Tile Control
Channel 4 Control
Synchronizer
Channel 5 Control
Synchronizer
PS Clock
Tile3 _clk
Channel 2 Control
Synchronizer
Channel 3 Control
Synchronizer
Channel 0 Control
Synchronizer
PS Clock
PLL CLK
ADC 2 CONTROL Multi-Tile Control ADC 3 CONTROL Multi-Tile Control
Channel 6 Control Channel 7 Control
Synchronizer Synchronizer
Figure 4-6: N-Stage Sync Logic for RF-ADC
X21248-092118
ADC 4 CONTROL Multi-Tile Control ADC 5 CONTROL Multi-Tile Control ADC 6 CONTROL Multi-Tile Control ADC 7 CONTROL Multi-Tile Control
X21249-091318
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
31
Send Feedback
Chapter 4: Clocking
Table 4-1 lists the clocks used for the RF-ADC control path and datapath.
Table 4-1: Clock Domains in RF-ADC Control and Datapath
Logic Block
ADC (usp_rf_data_converter) Channel select multiplexer FIFO (axis_data_fifo_0) (ADC 0-ADC7) Asynchronous FIFO DMA (axi_dma) AXI interconnect (AXI smart connect) PL DDR controller interface ADC_0 I & Q Merge ADC_1 I & Q Merge ADC_2 I & Q Merge ADC_3 I & Q Merge ADC_4 I & Q Merge ADC_5 I & Q Merge ADC_6 I & Q Merge ADC_7 I & Q Merge
ADC Stream Clock Domain
(512 MHz)
X (WRITE Clock)
X X X X X X X X
Clock Domain (300 MHz)
X X (READ Clock)
X X X
ADC Clock Domain (256 MHz)
X
The RF-DAC has 300 MHz and DAC_CLK_OUT (409.625 MHz) clock domains. The DAC_CLK_OUT is an output of RF data converter block (usp_rf_data_converter_0) and is currently being configured to 409.625 MHz. Figure 4-7 and Figure 4-8 show the RF-DAC clock domains.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
32
Send Feedback
Chapter 4: Clocking
X-Ref Target - Figure 4-7
Example: Fs = 6.4 GHz Interpolation = x1 SYREF = 8 MHz PL SYSREF = 8 MHz PL REF CLK = 200 MHz PL CLK = 400 MHz
333 MHz
PL DDR + MIG
DMA
Stream Mux
PL SYSREF (PCB) PL REF CLK (PCB)
PS
GP IO
User_sysref_dac
MMCM
PL CLK (Fabric Clock)
Clock Converter
Loopback Component
AXIS FIFO 64 KS
DAC 0
Clock Converter
Loopback Component
PL CLK
To Tile0 channels
Sync logic
To Tile1 channels
AXIS FIFO 64 KS
PL CLK
Tile0 _DAC_ Clock out
Multi-Tile Control
DAC 1 Tile 0 DAC 2
DAC 3
DAC 4
Clock Converter
Loopback Component
Multi-Tile Control PL CLK
AXIS FIFO 64 KS
Tile1 _DAC_ Clock out
DAC 5 Tile 1 DAC 6
Clock Converter
Loopback Component
AXIS FIFO 64 KS
DAC 7
DAC 0 Analog Clock (PCB)
SYSREF (PCB) User_sysref_dac (Fabric Clock)
DAC 1 Analog Clock (PCB)
X-Ref Target - Figure 4-8if
Figure 4-7: RF-DAC Multi-Tile Sync Clocking Structure
X21250-092118
DAC 0 to DAC 3
Channel 0-4 Control
PS GPIO
PS Clock Multi-Tile Control
Channel 5-6 Control
N-stage Sync logic
N-stage Sync logic
DAC 4 to DAC 7
PL CLK
Tile0 _clk
PL CLK
BUFG MUX Tile0 _DAC_Clock out
Multi-Tile Control
DAC 0
DAC 1 Tile 0 DAC 2
DAC 3
Tile1 _clk
PL CLK
BUFG MUX Tile0 _DAC_Clock out
Multi-Tile Control
DAC 4
DAC 5 Tile 1 DAC 6 DAC 7
DAC 0 Analog Clock (PCB)
SYSREF (PCB) User_sysref_dac (Fabric Clock)
DAC 1 Analog Clock (PCB)
Figure 4-8: RF-DAC Control Signals for Multi-Tile Sync (Sync Block)
X21251-092118
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
33
Send Feedback
Chapter 4: Clocking
X-Ref Target - Figure 4-9
PS Clock
Tile0 _clk
PS Clock
Tile1 _clk
Channel 0 Control
Synchronizer
Channel 1 Control
Synchronizer
Channel 2 Control
Synchronizer
Channel 3 Control
Synchronizer
Channel 0 Control
Synchronizer
DAC 0 CONTROL Channel 4 Control Multi-Tile Control
Synchronizer
DAC 1 CONTROL Channel 5 Control Multi-Tile Control
Synchronizer
DAC 2 CONTROL Channel 6 Control
Synchronizer
Multi-Tile Control DAC 3 CONTROL Channel 7 Control
Synchronizer
Multi-Tile Control
DAC 4 CONTROL Multi-Tile Control DAC 5 CONTROL Multi-Tile Control DAC 6 CONTROL Multi-Tile Control DAC 7 CONTROL Multi-Tile Control
PS Clock
PL CLK
Figure 4-9: N-Stage Sync Logic for RF-DAC Table 4-2 lists the clocks used for RF-DAC control path and datapath.
X21252-090918
Table 4-2: Clock Domains in RF-DAC Control and Datapath
Logic Block
Clock Domain (300 MHz)
PL DDR MIG SG DMA
Streaming MUX Memory Loopback 0 Memory Loopback 1
X X X x (Write) x (Write)
Memory Loopback 2
x (Write)
Memory Loopback 3
x (Write)
Memory Loopback 4
x (Write)
Memory Loopback 5
x (Write)
Memory Loopback 6
x (Write)
Memory Loopback 7
x (Write)
DAC_CLK_OUT (409.625 MHz)
x (Read) x (Read) x (Read) x (Read) x (Read) x (Read) x (Read) x (Read)
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
34
Send Feedback
Chapter 4: Clocking
Resets
The following reset sources are in the design:
· pl_resetn0 (from PS to PL)
This active-Low reset is asserted by the PS during initialization.
· ddr4_sync_rst (or c0_ddr4_ui_clk_sync_rst from the PL DDR memory interface group (MIG))
This active-High reset is asserted by the PL DDR MIG. It is synchronized to the UI clock coming out the PL DDR MIG.
· User-controlled reset block
This reset block is used to control the reset of FIFOs in both the RF-ADC datapaths (adc_0, adc_1) and RF-DAC datapath (dac_0). It has an AXI4-Lite interface through which the reset register can be accessed. Each bit of the register can be used to drive reset to the block appropriately.
Table 4-3: Reset Distribution in the Evaluation Tool Design
Logic Block
PL DDR MIG DAC DMA ADC DMA RF data converter AXIS slave and master interfaces (so, s1, and m0) ADC_0 block AXIS data FIFO ADC_1 block AXIS data FIFO ADC_2 block AXIS data FIFO ADC_3 block AXIS data FIFO ADC_4 block AXIS data FIFO ADC_5 block AXIS data FIFO ADC_6 block AXIS data FIFO ADC_7 block AXIS data FIFO DAC 0 block- output AXIS data FIFOs DAC 1 block- output AXIS data FIFOs DAC 2 block- output AXIS data FIFOs DAC 3 block- output AXIS data FIFOs
pl_resetn0
X X X
ddr4_sync_rst
X
User-controlled Reset Block
x (reset_0_n) x (reset_1_n) x (reset_2_n) x (reset_3_n) x (reset_4_n) x (reset_5_n) x (reset_6_n) x (reset_7_n) x (dac reset_0_n) x (dac reset_1_n) x (dac reset_2_n) x (dac reset_3_n)
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
35
Send Feedback
Chapter 4: Clocking
Table 4-3: Reset Distribution in the Evaluation Tool Design (Cont'd)
Logic Block
pl_resetn0
ddr4_sync_rst
DAC 4 block- output AXIS data FIFOs DAC 5 block- output AXIS data FIFOs DAC 6 block- output AXIS data FIFOs DAC 7 block- output AXIS data FIFOs
User-controlled Reset Block
x (dac reset_4_n) x (dac reset_5_n) x (dac reset_6_n) x (dac reset_7_n)
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
36
Send Feedback
Chapter 5
Evaluation Tool System Configuration using the GUI
The evaluation tool GUI is PC-based software that allows you to configure the operating modes of the ADCs and DACs. The GUI also generates test patterns which can be downloaded for DAC testing and manages the upload of data from the ADCs for analysis in the GUI. The GUI shipped with the Xilinx evaluation board supports most of the API functions and configuration options for the ADC and DACs. The GUI also supports the testing of all ADCs and DACs, both individually and simultaneously. Details of the supported configuration are outlined in the following sections.
The GUI is further documented in the RF Data Converter Interface User Guide (UG1309) [Ref 10].
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
37
Send Feedback
Chapter 5: Evaluation Tool System Configuration using the GUI
External Component Configuration
In the overview tab, when clicking on Clock Settings, the external PLL can be configured with a set of predefined frequencies as shown in Figure 5-1.
X-Ref Target - Figure 5-1
X21283-090918
Figure 5-1: Overview of External PLLs
When clicking on Power Settings, the DAC power mode can be changed between 20 mA and 32 mA.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
38
Send Feedback
Chapter 5: Evaluation Tool System Configuration using the GUI
When selecting a tile, the tile status is displayed on the left side as shown in Figure 5-2, including the power up state machine's current state. Controls for reset and shutdown/startup are provided. A reset reconfigures the tile to its original bitstream state.
X-Ref Target - Figure 5-2
X21284-090918
Figure 5-2: Overview of Tile Status Each individual tile configuration can be accessed by double-clicking the desired tile.
ADC Configuration
The ADC tiles contain the ADCs and supporting signal processing blocks or digital down converters (DDCs). There are also clock generators or PLLs in each ADC tile. The GUI supports the configuration of all these blocks. The ADC settings need to be optimized for certain modes of operation. The modes relate to where the signal being sampled by the ADC (Fin) lies in relation to the sampling frequency (Fs) of the ADCs. As shown in Figure 5-3, the ADC configuration is similar to the RF Data
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
39
Send Feedback
Chapter 5: Evaluation Tool System Configuration using the GUI
Converter IP GUI. A notable difference is the multi-band and complex/real settings available in the crossbar setting shown in Figure 5-4.
X-Ref Target - Figure 5-3
Figure 5-3: ADC Configuration
X21280-090918
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
40
Send Feedback
X-Ref Target - Figure 5-4
Chapter 5: Evaluation Tool System Configuration using the GUI
Figure 5-4: ADC Crossbars
X21281-092118
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
41
Send Feedback
Chapter 5: Evaluation Tool System Configuration using the GUI
ADC Clock Configuration
The GUI supports: · Selection of external or internal (PLL) sample clock options · On-chip PLL configuration for internal sample clock generation (see Figure 5-5). · The configuration of the RF PLLs on the evaluation board for external clocking Note: RFPLL (LMK) is also used to set up the reference clock for the on-chip PLLs. The nominal
settings are 245.76 MHz or 491.52 MHz, for example.
X-Ref Target - Figure 5-5
Figure 5-5: ADC Internal PLL
X21282-092118
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
42
Send Feedback
Chapter 5: Evaluation Tool System Configuration using the GUI
Digital Down Converter Configurations
The GUI supports: · Setting up complex mixer functionality and NCO frequency · Setting the decimation rate on the decimation filters · Selecting and configuring the decimation filter in the PL, if desired · Configuring the quadrature modulator correction block · Enabling and configuring dual band support
DAC Configuration
Like the ADC tiles, the DAC tiles contain four DACs. Unlike the ADC tiles, there is only one configuration. The DAC tile contains the same clock generation (PLL) functionality as the ADC tiles and a digital up converter (DUC) signal processing block. The following features are supported in the GUI: · DAC output current range (20 mA or 32 mA) · DAC low noise mode · DAC enhanced linearity mode · DAC mix mode operation for second Nyquist zone operation
DAC Clock Configurations
The GUI supports: · Selection of external or internal (PLL) sample clock options · On-chip PLL configuration for internal sample clock generation · Full access to configuring the on-chip PLLs using the software API
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
43
Send Feedback
Chapter 5: Evaluation Tool System Configuration using the GUI
Digital Up Converter Configurations
The GUI supports:
· Setting the complex mixer functionality and NCO frequency · Setting the interpolation rate on the filters · Selecting and configuring the interpolation filters in the PL, if desired · Configuring the quadrature modulator correction block · Enabling and configuring dual band support
ADC Tone Testing
The GUI supports uploading ADC output data for all ADC channels one by one, but the capture can happen simultaneously. The GUI supports the simultaneous capture and generation of samples in Real and Complex mode (in-phase and quadrature I/Q data).
For FFT analysis, the setup supports coherent sampling. The two basic requirements for coherent sampling are:
· The sample clocks for the DAC (or external signal generator) and ADC are frequency-locked. This is achieved if the ADC and DAC clocks are derived from the same reference clock in the case of the on-chip PLLs or external PLLs that use the same clock reference.
· The test signal (e.g., test tone) should generate an integer number of complete cycles when sampled by the ADC at the specified rate because the FFT expects a periodic signal. This is usually managed by carefully choosing the frequency of the input test tone(s) to the ADC or output tone(s) from the DAC for a fixed sample clock setting. For loopback testing, it means careful generation of the DAC output tone(s) frequency (i.e., SRAM vectors), which is sent to the DAC. This is automatically handled by the GUI for DAC for CW generation. For the ADC, the recommended coherent tones are listed to allow you to set external test equipment.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
44
Send Feedback
Chapter 6
Software Architecture
This chapter describes the software platform running on the application processor unit (APU), which is logically further subdivided into user and kernel space components (see Figure 6-1). The Linux application rftool in the user space receives the command over Ethernet and performs the appropriate action. This application is the main interface to the GUI and uses a string-based communication protocol described in Chapter 7, Protocol Specification. Device drivers expose a systematic interface to control hardware. These interfaces are used by the user space application to control hardware.
All configurations of the ADCs and DACs are done by the rftool Linux application running on the PS. The application supports all the configuration options supported by the GUI. The GUI sends configuration details, via the Ethernet interface, to the Linux application, which is implemented by their respective SW API.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
45
Send Feedback
Chapter 6: Software Architecture
Software Architecture
Figure 6-1 shows the APU Linux software platform which has two logical software flows, namely control path and datapath. Datapath and control path are implemented using two different TCP sockets. The components involved in the software flows are implemented in the user space and kernel space.
X-Ref Target - Figure 6-1
Remote Machine
LabVIEW UI
User space
Rftool (Application)
/dev/pl_mem
/sys/..../power1_input /sys....frequency* /sys/..../voltage
RFDC user space driver
/sys/../xxx.usp_rf_data_converter
Kernel space
DMA client driver
ina2xx driver
lmx2594 / lmk04208 driver
irps5401 driver
UIO
TCP/IP stack
DMA Engine
IIC driver
GEM driver
AXI DMA driver
Hardware GEM
PL
I2C
Clock Generator
Power generator
GPIO Controller
Stream Pipes RFDC IP
AXI DMAs
Figure 6-1: APU Linux Software Platform
X21292-092118
User Space Components
· Application is the Linux application that receives commands over Ethernet from the PC GUI and performs appropriate actions.
· RFDC User Space Drivers provide APIs for communication with the RFDC hardware.
· DMA client driver interface /dev/pl_mem is used to allocate buffer from PL DDR. It is also used to trigger a DMA transaction from the user space.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
46
Send Feedback
Chapter 6: Software Architecture
Kernel Space Components
· GEM driver provides the interface to send and receive packets over the GEM Ethernet controller.
· TCP/IP stack provides the interface to create a transmission control protocol (TCP) socket. It also provides the interface to send and receive data over the TCP socket. The stack uses the GEM driver to send and receive packets from a network interface card (NIC).
· DMA client driver provides the interface for a user application to trigger DMA transactions.
· The AXI DMA driver and DMA Engine are used to provide a driver interface to AXI DMA. The DMA client driver uses APIs for this DMA engine. The DMA Engine uses the AXI DMA driver to control hardware.
· ina2xx_driver is a Linux driver for ina2xx chips. It also provides a sysfs interface for the application to control hardware. This chip is connected over an inter IC (I2C) bus, hence the ina2xx driver uses the I2C subsystem to configure the ina2xx chip set. It is a power monitor chip from Texas Instruments (TI) on the ZCU111 evaluation board to monitor key RFSoC power rails.
· irps5401_driver is a Linux driver for power management ICs (PMICs). It also provides a sysfs interface for the application to control hardware. This chip is connected over an I2C bus, hence this driver uses the I2C subsystem to configure PMICs.
· UIO is a Linux framework used to export a hardware space to a user space. It is used by RFDC user space driver libmetal to configure RFDC hardware.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
47
Send Feedback
Figure 6-2 shows the application execution flow.
X-Ref Target - Figure 6-2
GUI
Chapter 6: Software Architecture
TCP Socket (Command/Data)
Protocol Layer
Command Handler
DMA Client Driver
I2C/Clock Driver
RFdc User Space Driver
Figure 6-2: Application Execution Flow
X21254-091318
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
48
Send Feedback
Chapter 7
Protocol Specification
The communication between the GUI and Linux application uses a string-based, space-separated command and response protocol. The Linux application maintains a table that maps command, arguments, and the corresponding method for that command (see Figure 7-1).
X-Ref Target - Figure 7-1
Figure 7-1: Command Table
X21255-090918
In the command table, the first member is a command string, the second string is the help string for the command, the third argument describes the type and number of arguments, and the last argument is the function pointer which needs to be called for the command.
For the SetMixerSettings command, the type of required arguments is "uiudduuuu". The type definitions are as follows:
· u: unsigned integer · i: integer · d: double
For example: GetMixerSetting takes three arguments: Type, Tile, Block and type "uiu".
GetMixerSetting 0 1 1
The above example means that it takes a type as an unsigned integer, tile ID as integer, and block ID as unsigned integer. So the command GetMixerSetting is for ADC, tile 1, and block 1.
The arguments should be in the same order as described by the third member string, e.g., uiddduuuu.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
49
Send Feedback
Chapter 7: Protocol Specification
Socket Interface
The TCP/IP socket protocol is used for the datapath and control path. The LabVIEW GUI running on the host machine has TCP clients, and the TCP servers are running under the Linux application on the RFSoC PS. The control path works on TCP port 8081 and datapath works on TCP port 8082. The TCP socket uses a Linux TCP/IP stack, which uses the GEM Ethernet controller and driver for sending packets. Because the TCP socket is used, it is possible to run the GUI on any networked machines.
Control Path
The control interface is a generic command-response interface that can be used to call any software API or function. Its main purpose is to provide a robust communication method between a host and client application that allows RFDC hardware control commands to be issued and responses to be retrieved. All control commands are sent over TCP port 8081. At a high-level, it is string-based--meaning when supporting a new hardware interface, all that is required is the ability to send and receive terminated strings over that interface, and the core code remains unchanged.
Control Path State Machine
The control path is used to control and configure the RF-ADCs, RF-DACs, or board peripherals. It uses the I2C client driver or RFDC driver to configure peripherals. Figure 7-2 shows the Control/Command state machine.
X-Ref Target - Figure 7-2
Get Command
Parse Command
Error
Return
Execute
X21256-090918
Figure 7-2: Control/Command State Machine
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
50
Send Feedback
Chapter 7: Protocol Specification
Datapath
The datapath interface is used to get the data and commands. The interface accepts the command and data on TCP port 8082. It accepts two commands: readdatafrommemory and writedatatomemory. Based on the received command, it triggers the DMA. It uses the DMA client driver to perform DMA operations. Like the control path, the datapath also accepts string-based commands.
On receiving a writedatatomemory command, the application receives the number of data bytes from the socket. After receiving data samples from the socket, the application triggers DMA. After DMA is successfully triggered, the writedatatomemory command returns status to the GUI.
On receiving a readdatafrommemory command, the application triggers DMA to receive the number of bytes specified in the command. After the DMA is done, data is sent to the GUI.
Datapath State Machine
The datapath is used to get data and commands related to data. Figure 7-3 shows the datapath state machine.
X-Ref Target - Figure 7-3
Get Command
Parse Command
Error
Return
Trigger DMA (Read/Write
Data)
Figure 7-3: Datapath State Machine
X21257-090918
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
51
Send Feedback
Chapter 7: Protocol Specification
Command Types
The commands for the evaluation tool fall into the following categories:
· Basic commands · RFDC API commands--Arguments are 1:1 with the RFDC API definition, with the order
specified by the order they appear in the API and C structures (Struct). · ZCU111 onboard clock commands · Memory read/write and data movement-related commands
Refer to Appendix A, Reference Design Protocol Specification for more details about commands and arguments.
Application Flow
Control/datapath description:
· Upon receiving a command, the parser parses it. · If the command is incorrect, it returns an error. · If the command is correct, it executes. · If the execution fails, it returns an error with an explicit message. · If the execution succeeds, it returns the command and optional return values.
Input command format:
· CMD PARAM1 PARAM2 PARAM3 (with any number of parameters) · Commands and parameters are separated by an ASCII space. · Commands and parameters are human readable, i.e., sent in ASCII format. · Receive end of line is \n. · Control path command syntax is the same as the RFSoC driver with "XRFdc_" removed.
Parameters are the same as in the RFSoC drivers.
° Parameters for C structures are provided in the order they appear in the structure. ° The command format is provided in the code. ° Datapath command syntax is as below:
writedatatomemory <tile_id> <block_id> <Number_of_bytes> <il_pair> <DDR/BRAM>
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
52
Send Feedback
Chapter 7: Protocol Specification
1. Depending on the memory type, select BRAM/DDR and set GPIOs. (If it is BRAM, the hardware loops back the data; if it is DDR, DMA loops back the data.)
2. Map the memory, copy content, and trigger DMA. 3. Book-keep the memory type and addresses used for every pipeline for future use.
readdatafrommemory <tile_id> <block_id> <Number_of_bytes> <il_pair> <BRAM/DDR>
Check on the data length request based on mem_type. If it is BRAM, the size limit is 128K. If it is DDR, the limit is 128 MB.
For example, to send 1024-byte samples to firmware, the following command is used:
writedatatomemory 0 1 1024 0
Output return format:
· If an input command is not recognized, the parser errors out and sends ERROR: CMD: Invalid Command\n.
· If an input command is recognized, the parser checks the number of arguments, and sends ERROR: CMD: Invalid Number of Arguments\n
· If the argument count is correct, it passes the command and parameters to the execute state.
· If execution succeeds, the result is returned CMD param1 param2 ... paramX value1 value2 ... valueY\n
· Commands that are not expected to return values return their name if execution succeeds: [CMD]
· CMD and values are separated by a space. · Values are the same as returned by the RFSoC driver. · End of a line is \n · If execution fails (e.g., in case of XRFdc driver failure), an error is returned
ERROR: CMD: Execution\n · Any log or messages from metal-log can be returned via the getlog command.
° \r\n characters are replaced from any log messages with "|" and a single \n appended at the end.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
53
Send Feedback
Chapter 7: Protocol Specification
Figure 7-4 shows the control path and datapath flow.
X-Ref Target - Figure 7-4
Remote Machine
User Space
TCP Socket
Control Path (TCP port 8081)
*8,
TCP Socket
Datapath (TCP port 8082)
TCP Socket
TCP Socket
Firmware/Application
PL Memory Device
sysfs
RFdc User Space Driver
Libmetal
Kernel
IIC Client Drivers
DMA Client Driver
(Clock, Power, and Power
UIO
Measurement)
DMA Engine
AXI DMA Driver
IIC Driver
Hardware
AXI DMA Datapath
Power Generator Clock Generator
Power Measurement
Control Path
Figure 7-4: Control and Datapath
RFdc
X21258-091318
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
54
Send Feedback
Chapter 7: Protocol Specification
At a high-level, all datapaths do the same function, i.e., writing and reading data to and from memories. At a low-level, data is read and written to and from PS/PL DDR and DMA is triggered to copy data to RFDC. Datapath supports two commands: writedatatomemory and readdatafrommemory.
Using the writedatatomemory command, you can send data from a remote PC to the RFSoC board via Ethernet. On receiving this command, the socket application reads data over Ethernet and copies data to the PL-DDR. After data is copied to PL-DDR, DMA is triggered to transfer data from PL-DDR to DAC.
Using the readdatafrommemory command, you can receive data from the RFSoC board over Ethernet. On receiving this command, the socket application triggers DMA to transfer data from ADC to PL-DDR. After data is available in the PL-DDR, the socket application sends this data over Ethernet to a remote PC.
To support PL DDR mode, firmware checks the selected channels. Based on this information, the firmware creates a bitmask for the selected channels and updates the hardware register, so that the hardware knows the enabled channels.
Depending on the numbers of channels, invoke dmaengine_prep_dma_cyclic (dma_addr, length) and dmaengine_submit() multiple times. These functions prepare the BD list in the DMA driver. For each iteration, increment dma_addr by 128k for each channel, depending on the size. For example, if the number of channels is 4 and the size of the channel is 128 MB, invoke the above two functions 4096 times. Invoke dma_async_issue_pending () to start DMA.
Multi-Tile Sync
For details about the multi-tile sync feature, see the "Multi-Converter Synchronization" section of the Zynq UltraScale+ RFSoC RF Data Converter LogiCORE IP Product Guide (PG269) [Ref 9].
DAC Flow for Non-MTS
1. This sequence needs to be followed for each writedatatomemory () command per DAC channel: a. Get Tile Id, Block ID, and size of data. b. Get DAC memory pointer for the corresponding DAC channel. c. Read data from the GUI. d. Disable Channel X Control GPIO (X = 0...7) for corresponding DAC. e. Select requested DAC channel by configuring streaming MUX GPIO. f. Assert external FIFO RESET for corresponding DAC channel.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
55
Send Feedback
Chapter 7: Protocol Specification
g. Deassert external FIFO RESET for corresponding DAC channel. h. Enable RFDC FIFO for corresponding DAC channel. i. Trigger SG DMA. j. On DMA completion, enable Channel X Control GPIO (X = 0...7) as per selected DAC.
DAC Flow for MTS
1. MTS_Setup (enable, DAC) command a. Disables RFDC FIFOs for all eight channels (DAC0 to DAC7). b. Asserts the external Memory Loopback Reset signal for all eight DAC pipelines (DAC0 to DAC7). c. Configures the Multi-Tile Control select signal to enable PL CLK out of BUFGMUX and to enable Channel 0 Control (common channel control signal). d. Deasserts external FIFO RESET signal for all eight DAC pipelines (DAC0 to DAC7). e. Enables RFDC FIFOs for all eight channels.
2. MultiConverter_Init (DAC) command a. Triggers XRFdc_MultiConverter_Init() command and returns status. This is an RFDC driver internal function.
3. MultiConverter_Sync (DAC, latency) command a. Triggers XRFdc_MultiConverter_Sync () command and returns the status.
4. This sequence needs to be followed for each writedatatomemory() command per DAC channel: a. Get tile Id, block ID, and size of data. b. Get DAC memory pointer for the corresponding DAC channel. c. Read data from the GUI. d. Select the requested DAC channel by configuring streaming MUX GPIO. e. Trigger SG DMA (non-cyclic). f. Wait for DMA completion. (Wait for DMA completion means that TLAST is asserted at the input of the DAC path.) g. LocalMemTrigger (DAC) command h. Enable Channel 0 Control GPIO.
Note: For information on how buffers are set up, see Memory Mapping for RF-DAC/RF-ADC.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
56
Send Feedback
Chapter 7: Protocol Specification
MTS Disable Flow for DAC
1. Send MTS_Setup (disable, DAC) command with disable argument. a. Configure Multi-Tile Control select signal to enable Tile0_DAC_Clock and Tile1_DAC_Clock out of BUFGMUX and to disable Channel 0 Control (common channel control signal). b. Disable channel control GPIOs (Channel 'X' Control) for all DACs (X = 0...7). c. Disable RFDC FIFO for all DAC pipelines (DAC0 to DAC7).
DAC Flow for PL DDR
1. Select DDR mode. 2. Generate equal sizes of patterns while loading more than one (firmware tracks the
tile/block IDs and increments the channel count). 3. Write to the scratch pad register to route the BDs to the corresponding FIFOs of the DAC
channel. 4. The firmware prepares the BD chain and triggers the DMA transfer. 5. Send the Stop command to reset the currently running DMA transfers (before selecting
any other mode or sending new data or selection of new channels in DDR mode).
ADC Flow for MTS
1. MTS_Setup (enable, ADC) command a. Disable RFDC FIFOs for all eight channels (ADC0 to ADC7). b. Assert external FIFO RESET signal for all eight DAC pipelines (ADC0 to ADC7). c. Configure Multi-Tile Control select signal to enable PL CLK out of BUFGMUX and to enable Channel 0 Control (common channel control signal). d. Deassert external FIFO RESET signal for all eight DAC pipelines (ADC0 to ADC7). e. Enable RFDC FIFOs for all eight channels.
2. MTS_init (ADC) command a. Trigger XRFdc_MultiConverter_Init() command and return the status.
3. MTS_Sync (ADC, latency) command a. Trigger XRFdc_MultiConverter_Sync() command and return the status.
4. LocalMemTrigger (ADC) command a. Enable Channel 0 Control GPIO.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
57
Send Feedback
Chapter 7: Protocol Specification
5. This sequence needs to be followed for each readdatafrommemory () command per ADC channel. a. Get Tile Id, Block ID, and size of data. b. Select requested ADC channel by configuring streaming MUX GPIO. c. Enable IQ GPIO, if IQ mode is selected. d. Trigger DMA. e. Send requested ADC data to GUI.
ADC Flow for Non-MTS
This sequence needs to be followed for each readdatafrommemory() command per ADC channel:
1. Get Tile Id, Block ID, and size of data. 2. Get ADC memory pointer for the corresponding channel. 3. Select requested ADC channel by configuring streaming MUX GPIO. 4. Enable IQ GPIO, if IQ mode is selected. 5. Assert external FIFO RESET for corresponding ADC channel. 6. Deassert external FIFO RESET for corresponding ADC channel. 7. Enable RFDC FIFO of corresponding ADC channel. 8. Enable Channel X Control GPIO (X = 0...7) as per selected ADC. 9. Trigger SG DMA. 10. Disable RFDC FIFO of the corresponding ADC channel. 11. Send requested ADC data to the GUI.
MTS Disable Flow for ADC
1. Send MTS_Setup (disable, ADC) command with the disable argument. a. Configure Multi-Tile Control select signal to enable Tile0_ADC_Clock, Tile1_ADC_Clock, Tile2_ADC_Clock, and Tile3_ADC_Clock, out of BUFGMUX and to disable Channel 0 Control (common channel control signal). b. Disable channel control GPIOs (Channel 'X' Control) for all ADCs. c. Disable RFDC FIFO for all ADC pipelines (ADC0 to ADC7).
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
58
Send Feedback
Chapter 8
Zynq UltraScale+ RFSoC Data Converter Bare-metal/Linux Driver
The Linux APIs for the Zynq® UltraScale+TM RFSoC Data Converter is described in the Zynq UltraScale+ RFSoC Data Converter Bare-metal/Linux Driver appendix of Zynq UltraScale+ RFSoC RF Data Converter LogiCORE IP Product Guide (PG269) [Ref 9].
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
59
Send Feedback
Chapter 9
System Considerations
This chapter describes the boot process and address mapping.
Boot Process
The design uses a non-secure boot flow and SD boot mode. The sequence diagram in Figure 9-1 shows the steps and order in which the individual boot components are loaded and executed.
X-Ref Target - Figure 9-1
PMU
Release CSU
CSU
Load PMU FW
Load FSBL
APU
FSBL
Power Management
Tamper Monitoring
ATF U-boot
Linux Kernel
Rootfs
rftrd (Linux App)
PL
PL Bitstream
Time
X21303-090918
Figure 9-1: Boot Flow Sequence
The platform management unit (PMU) is responsible for handling primary pre-boot tasks and is the first unit to wake up after power-on reset (POR). After the initial boot process, the PMU continues to run and is responsible for handling various clocks and resets of the system as well as system power management. In the pre-configuration stage, the PMU executes the PMU ROM and releases the reset of the configuration security unit (CSU). It then enters the PMU server mode where it provides platform management functions.
The CSU handles the configuration stages and executes the boot ROM as soon as it comes out of reset. The boot ROM determines the boot mode by reading the boot mode register, it initializes the on-chip memory (OCM), and reads the boot header. The CSU loads the PMU firmware into the PMU RAM and signals to the PMU to execute the firmware, which
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
60
Send Feedback
Chapter 9: System Considerations
provides advanced management features instead of the PMU ROM. It then loads the first stage boot loader (FSBL) into OCM and, if enabled, switches into tamper monitoring mode.
In this design, the FSBL is executed on APU-0. It initializes the PS and configures the PL and APU based on the boot image header information. The following steps are performed:
1. The PL is configured with a bitstream and the PL reset is deasserted. 2. The ARM trusted firmware (ATF) is loaded into OCM and executed on APU-0. 3. The second stage boot loader U-Boot is loaded into DDR to be executed by APU-0.
For more information on the boot process, see chapters Programming View of Zynq UltraScale+ MPSoC Devices and System Boot and Configuration in the Zynq UltraScale+ MPSoC Software Developer Guide (UG1137) [Ref 11], and chapter Boot and Configuration in the Zynq UltraScale+ Device Technical Reference Manual (UG1085) [Ref 3].
Global Address Map
For more information on system addresses, see the System Addresses chapter in the Zynq UltraScale+ Device Technical Reference Manual (UG1085) [Ref 3].
Memory
The DMA instances in the PL use a 36-bit address space so they can access the DDR Low and DDR High address. Table 9-1 lists the APU software components used in this design and where they are stored or executed from in memory.
Table 9-1: Software Executables and Their Memory Regions
Component
Processing Unit
FSBL
APU-0
ARM trusted firmware (ATF) U-Boot Linux kernel/device tree/rootfs rftool application (Linux)
APU-0 APU-0 APU (SMP) APU (SMP)
Memory
OCM OCM DDR DDR DDR
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
61
Send Feedback
Chapter 9: System Considerations
Memory Mapping for RF-DAC/RF-ADC
PL DDR is divided into four partitions (reserved memory), and each partition is 512 MB. It can run either RF-DAC/RF-ADC from these partitions. It can run either RF-DAC/RF-ADC from this partition. Table 9-2 lists partitions, their starting address, and their size.
Table 9-2: Memory Mapping for RF-DAC/RF-ADC
Partition
1 2 3 4
DDR
PL PL PL PL
Start Address
0x410000000 0x418000000 0x420000000 0x428000000
5
PL
0x430000000
6
PL
0x438000000
7
PL
0x440000000
8
PL
0x448000000
9
PL
0x450000000
10
PL
0x458000000
11
PL
0x460000000
12
PL
0x468000000
13
PL
0x470000000
14
PL
0x478000000
15
PL
0x480000000
16
PL
0x488000000
Size
128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB 128MB
Component
RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC RF-DAC/RF-ADC
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
62
Send Feedback
Appendix A
Reference Design Protocol Specification
Commands
Table A-1 lists the commands used in the evaluation tool design.
Table A-1: Command List
Command
Arguments
Basic Commands
RFdcVersion
None
Version
None
TermMode
mode
Return
Version Number(s) Version Number(s) None
GetLog
None
Logged Strings
iic_write
iic_read
RFdc API Commands
SetMixerSettings
iic instance, slave address, register offset, size, data iic instance, slave address, size
Success/Fail Success/Fail
Type, Tile, Block, MixerSettings
None
GetMixerSettings
Type, Tile, Block
Type, Tile, Block, MixerSettings
Purpose/Comments
RFdc API version, for example, "v3_1" Protocol version, for example, "v1_0" Switch between UI mode (mode=0) and Interactive mode (mode=1). Interactive mode prints more status information to the terminal, and should not be used with the Evaluation Tool GUI. Uses metal_log to return any error, warning, or informational messages returned from the API or command interface. Write number of bytes to I2C slave.
Read number of bytes from I2C slave.
Where MixerSettings is 1:1 with the API: Freq, PhaseOffset, EventSource, FineMixerMode, CoarseMixerFreq, FineMixerScale Get mixer settings for the requested type, tile, and block.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
63
Send Feedback
Appendix A: Reference Design Protocol Specification
Table A-1: Command List (Cont'd)
Command
GetQMCSettings
Arguments
Type, Tile, Block
ShutDown
Type, Tile
StartUp
Type, Tile
GetTileStatus
Type, Tile
GetBlockStatus
Type, Tile, Block
GetPLLConfig
Type, Tile
DynamicPLLConfig GetLinkCoupling
Type,Tile, Source, Refclkfreq, sampling rate Tile, Block
SetCoarseDelaySettings Type, Tile, Block
GetCoarseDelaySettings Type, Tile, Block
SetInterpolationFactor Tile, Block
GetInterpolationFactor Tile, Block
SetDecimationFactor
Tile, Block
GetDecimationFactor Tile, Block
MultiConverter_Init
Type
MultiConverter_Sync
Type, Latency, Tile
MTS_Setup
Type, Enable
Return
Type, Tile, Block, QMCSettings None None TileStatus
BlockStatus
RefClkFreq, SampleRate, RefClkDivider, FeedbackDivider, OutputDivider RefClkDivider, FeedbackDivider, OutputDivider Tile, Block, Mode Success/Fail Type, Tile, Block, CoarseDelay, EventSource Success/Fail Tile, Block, Interpolationfactor Success/Fail Tile, Block, Decimationfactor Success/Fail Latency, Offsets, Marker delay, Sysrefenable Success/Fail
Purpose/Comments
Get QMC settings for the requested type, tile, and block. Shuts down a tile (the tile must be enabled in the bitstream). Starts up a tile (the tile must be enabled in the bitstream). Returns the TileStatus returned from an XRFdc_IPStatus function call. SamplingFreq, AnalogDataPathStatus, DigitalDataPathStatus, DataPathClocksStatus, IsFIFOFlagsEnabled, IsFIFOFlagsAsserted Get PLL configuration for the requested type and tile.
Configure the PLL sampling rate depending on the source.
Get link coupling mode for the requested tile and block. Set Coarse delay settings for the requested type, tile, and block. Get coarse delay settings for the requested type, tile, and block.
Set the interpolation factor for the requested tile and block. Get interpolation factor for the requested tile and block. Set decimation factor for the requested tile and block. Get decimation factor for the requested tile and block. Initializes multi-tile synchronization feature. Synchronize between tiles.
Setup resources for multi-tile synchronization feature.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
64
Send Feedback
Appendix A: Reference Design Protocol Specification
Table A-1: Command List (Cont'd)
Command
SetMemtype
Arguments
Mem_type
GetMemtype
None
ZCU111 Board Commands
SetExtParentclk
board id, frequency
SetExtPllClkRate SetDACPowerMode GetDACPower
board id, pll source, frequency board id, Tile, Block, output current Board, Tile
Memory Access Commands
WriteDataToMemory
Tile, Block, number_of_bytes, interleaved_pair
Return
Success/Fail Mem_type
Success/Fail Success/Fail Success/Fail Board, Tile, DAC_AVTT, DAC_AVCC_AUX, DAC_AVCC, ADC_AVCC_AUX, ADC_AVCC
Actual bytes written
ReadDataFromMemory
Tile, Block, number_of_bytes, interleaved_pair
Actual bytes read
Purpose/Comments
Set memory type to DDR or BRAM. Get selected memory type.
Configure PLL clock with requested frequency. Configure PLL with requested frequency. Configure DAC power. Get DAC power mode for the requested board and tile.
In this case, the buffer address is allocated by Linux (CMA pool) from PS DDR and firmware writes the data to the buffer by reading data from a socket. In this case, the buffer address is allocated by Linux (CMA pool) from PL DDR and firmware reads the data from the buffer and sends it to a socket. In this command, the number of bytes should be aligned to 32.
Example Commands and Responses
A list of example commands and responses follows: #invalid command name SetMixerSett 0 1 2 ... Error: SetMixerSett: Invalid command
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
65
Send Feedback
Appendix A: Reference Design Protocol Specification
#invalid number of arguments SetMixerSettings 0 Error: SetMixerSettings: Invalid Number of Arguments
# valid command and response (no data returned - args: Type, Tile, Block, Freq, PhaseOffset, EventSource, FineMixerMode, CoarseMixerFreq, FineMixerScale) SetMixerSettings 0 1 2 3.4 0.0 .. SetMixerSettings:
#valid command and response (data returned - Freq, PhaseOffset, EventSource, FineMixerMode, CoarseMixerFreq, FineMixerScale) GetMixerSettings 0 1 2 GetMixerSettings: 3.14 ...
Control Path Core Implementation
Structure
The control path core code is implemented in C code and runs on the APU. The main functions are separated into files so the protocol-core is independent from the interface input or output and the commands themselves. This allows easier re-use and extension. Files: · io_interface (.c/.h)
° This file contains the communication specific code that implements getString/sendString
° The sub-functions here are used to separate the core (cmd_interface) from the physical communications channel.
° To port to another communications medium, this is the only file that should be edited.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
66
Send Feedback
Appendix A: Reference Design Protocol Specification
· cmd_interface (.c/.h) ° This is the core of the command protocol. It contains a menu/table of commands and their expected arguments. ° This menu is implemented as an array of command-structures. - The command-structures contain the command name, the expected arguments, the argument number format (long, unsigned, double), and a function-pointer to call if the command matches. - Extending to add a new command involves adding a new entry in the table, adding the associated function-pointer, and adding the function itself.
When a command is received, it is checked for a match in the table, and the number of arguments received is checked against the expected number of arguments from the table. Arguments are parsed from the command string and converted based on the expected data type. The arguments are put into an array of unions to allow the same data type to be passed to functions that expect different argument data types.
The associated wrapper function is called by the function-pointer, and a return value/message string generated.
· rfdc_commands (.c/.h) ° This file contains the ADC/DAC wrapper functions that are called from the menu (via the function pointer). ° Each wrapper function calls the corresponding API function.
Porting
Porting the control path to support a new communications interface involves only editing the io_interface functions. The key functions that must be addressed are:
· GetString ° This function must return a full command string, which is terminated by \n. ° If a string is partially received (i.e., still being received), this function should not block (see the Non-blocking function), and return 0. ° When a string is fully received, it returns a non-zero number to reflect there is a new command to be parsed.
· SendHW ° This function is called from SendString which pre-parses a string to remove embedded \r and \n characters and append a single \r\n at the end. ° SendHW is essentially a print function that actually transmits the information at the end.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
67
Send Feedback
Appendix A: Reference Design Protocol Specification
° This function should be pointed to the method used to actually transmit strings or characters over the desired communication interface.
· Non-blocking ° Implementation of command and datapath is non-blocking.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
68
Send Feedback
Appendix B
Additional Resources and Legal Notices
Xilinx Resources
For support resources such as Answers, Documentation, Downloads, and Forums, see Xilinx Support.
Solution Centers
See the Xilinx Solution Centers for support on devices, software tools, and intellectual property at all stages of the design cycle. Topics include design assistance, advisories, and troubleshooting tips.
Documentation Navigator and Design Hubs
Xilinx® Documentation Navigator provides access to Xilinx documents, videos, and support resources, which you can filter and search to find information. To open the Xilinx Documentation Navigator (DocNav): · From the Vivado® IDE, select Help > Documentation and Tutorials. · On Windows, select Start > All Programs > Xilinx Design Tools > DocNav. · At the Linux command prompt, enter docnav. Xilinx Design Hubs provide links to documentation organized by design tasks and other topics, which you can use to learn key concepts and address frequently asked questions. To access the Design Hubs: · In the Xilinx Documentation Navigator, click the Design Hubs View tab. · On the Xilinx website, see the Design Hubs page. Note: For more information on Documentation Navigator, see the Documentation Navigator page
on the Xilinx website.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
69
Send Feedback
Appendix B: Additional Resources and Legal Notices
References
The most up to date information related to the ZCU111 board and its documentation is available on the following websites.
Zynq UltraScale+ RFSoC ZCU111 Evaluation Kit
ZCU111 Evaluation Kit Master Answer Record 70958
ZCU111 RF Data Converter Evaluation Tool Master Answer Record 71424
These Xilinx documents provide supplemental material useful with this guide:
1. Zynq UltraScale+ RFSoC Data Sheet: Overview (DS889) 2. Zynq UltraScale+ RFSoC Data Sheet: DC and AC Switching Characteristics (DS926) 3. Zynq UltraScale+ Device Technical Reference Manual (UG1085) 4. ZCU111 RFSoC RF Data Converter Evaluation Tool Getting Started Guide wiki 5. ZCU111 UltraScale+ RFSoC ZCU111 Evaluation Kit Quick Start Guide (XTP490) 6. Vivado Design Suite 7. Xilinx Software Development Kit (XSDK) 8. PetaLinux Tools 9. Zynq UltraScale+ RFSoC RF Data Converter LogiCORE IP Product Guide (PG269) 10. RF Data Converter Interface User Guide (UG1309) 11. Zynq UltraScale+ MPSoC Software Developer Guide (UG1137) 12. Coherent Sampling vs. Window Sampling application note from Maxim Integrated
(Tutorial 1040) 13. PCB Design Guidelines for Zynq UltraScale+ RFSoCs User Guide (UG582) (Registration
Required) 14. Vivado Design Suite User Guide: Designing IP Subsystems using IP Integrator (UG994) 15. Vivado Design Suite User Guide: Designing with IP (UG896) 16. Vivado Design Suite User Guide: Getting Started (UG910) 17. Vivado Design Suite User Guide: Logic Simulation (UG900) 18. Vivado Design Suite User Guide: Programming and Debugging (UG908) 19. Zynq UltraScale+ Device Packaging and Pinouts User Guide (UG1075) 20. Zynq UltraScale+ MPSoC: Embedded Design Tutorial (UG1209) 21. ZCU111 Evaluation Board User Guide (UG1271)
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
70
Send Feedback
Appendix B: Additional Resources and Legal Notices
22. AXI4-Stream Infrastructure IP Suite, LogiCORE IP Product Guide (PG085)
Please Read: Important Legal Notices
The information disclosed to you hereunder (the "Materials") is provided solely for the selection and use of Xilinx products. To the maximum extent permitted by applicable law: (1) Materials are made available "AS IS" and with all faults, Xilinx hereby DISCLAIMS ALL WARRANTIES AND CONDITIONS, EXPRESS, IMPLIED, OR STATUTORY, INCLUDING BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT, OR FITNESS FOR ANY PARTICULAR PURPOSE; and (2) Xilinx shall not be liable (whether in contract or tort, including negligence, or under any other theory of liability) for any loss or damage of any kind or nature related to, arising under, or in connection with, the Materials (including your use of the Materials), including for any direct, indirect, special, incidental, or consequential loss or damage (including loss of data, profits, goodwill, or any type of loss or damage suffered as a result of any action brought by a third party) even if such damage or loss was reasonably foreseeable or Xilinx had been advised of the possibility of the same. Xilinx assumes no obligation to correct any errors contained in the Materials or to notify you of updates to the Materials or to product specifications. You may not reproduce, modify, distribute, or publicly display the Materials without prior written consent. Certain products are subject to the terms and conditions of Xilinx's limited warranty, please refer to Xilinx's Terms of Sale which can be viewed at https://www.xilinx.com/legal.htm#tos; IP cores may be subject to warranty and support terms contained in a license issued to you by Xilinx. Xilinx products are not designed or intended to be fail-safe or for use in any application requiring fail-safe performance; you assume sole risk and liability for use of Xilinx products in such critical applications, please refer to Xilinx's Terms of Sale which can be viewed at https://www.xilinx.com/legal.htm#tos. AUTOMOTIVE APPLICATIONS DISCLAIMER AUTOMOTIVE PRODUCTS (IDENTIFIED AS "XA" IN THE PART NUMBER) ARE NOT WARRANTED FOR USE IN THE DEPLOYMENT OF AIRBAGS OR FOR USE IN APPLICATIONS THAT AFFECT CONTROL OF A VEHICLE ("SAFETY APPLICATION") UNLESS THERE IS A SAFETY CONCEPT OR REDUNDANCY FEATURE CONSISTENT WITH THE ISO 26262 AUTOMOTIVE SAFETY STANDARD ("SAFETY DESIGN"). CUSTOMER SHALL, PRIOR TO USING OR DISTRIBUTING ANY SYSTEMS THAT INCORPORATE PRODUCTS, THOROUGHLY TEST SUCH SYSTEMS FOR SAFETY PURPOSES. USE OF PRODUCTS IN A SAFETY APPLICATION WITHOUT A SAFETY DESIGN IS FULLY AT THE RISK OF CUSTOMER, SUBJECT ONLY TO APPLICABLE LAWS AND REGULATIONS GOVERNING LIMITATIONS ON PRODUCT LIABILITY. © Copyright 20182019 Xilinx, Inc. Xilinx, the Xilinx logo, Artix, ISE, Kintex, Spartan, Virtex, Vivado, Zynq, and other designated brands included herein are trademarks of Xilinx in the United States and other countries. Arm is a registered trademark of Arm Limited in the EU and other countries. Simulink is a registered trademark of The MathWorks, Inc. All other trademarks are the property of their respective owners.
RFSoC Data Converter Evaluation Tool User Guide
UG1287 (v2019.1) May 29, 2019
www.xilinx.com
71
Send Feedback
Acrobat Distiller 15.0 (Windows)
