Greenworks Pro 60V Cordless Tools
Operator Manuals and Parts Information
Greenworks Pro 60V Chainsaw
Model Numbers: CS60L03, CS60L4R3
Product Description: A Greenworks Pro 60V UltraPower cordless chainsaw with an 18-inch bar and chain. It features a brushless motor and a visible chain brake mechanism.
Operator Manual
Exploded View and Parts List
Diagram Description: The exploded view shows the chainsaw disassembled into 11 numbered parts, illustrating how components like the bar, chain, sprocket, oil cap, chain brake, tensioner, wrench, sprocket cover, and handles are arranged.
| No. | Part No. | Qty | Description |
|---|---|---|---|
| 1 | R0201872-00 | 1 | Bar |
| 2 | RB322041075 | 1 | Chain |
| 3 | R0200302-00 | 1 | Sprocket Kit |
| 4 | R0200303-00 | 1 | Oil Cap Assembly |
| 5 | R0201868-00 | 1 | Chain Brake Kit |
| 6 | R0200009-00 | 1 | Chain Brake Handle |
| 7 | R0200896-00 | 1 | Tensioner Kit |
| 8 | RB333001890 | 1 | Wrench |
| 9 | R0200304-00 | 1 | Sprocket Cover Assembly |
| 10 | R0200306-00 | 1 | Auxiliary Handle Kit |
| 11 | RB341182031B | 1 | Scabbard |
Greenworks Pro 60V Blower
Model Numbers: BL60L01, BL60L251
Product Description: A Greenworks Pro 60V UltraPower cordless blower. It has a long nozzle and a handle with a trigger.
Operator Manual
Exploded View and Parts List
Diagram Description: The exploded view shows the blower disassembled into 3 numbered parts: the main blower tube, a concentrator nozzle for directing airflow, and a shoulder strap for carrying.
| No. | Part No. | Qty | Description |
|---|---|---|---|
| 1 | R0201910-00 | 1 | Blower tube |
| 2 | R0201909-00 | 1 | Concentrator nozzle |
| 3 | RB37902144 | 1 | Shoulder strap |
Greenworks Pro 60V String Trimmer
Model Numbers: ST60L03, ST60L413
Product Description: A Greenworks Pro 60V UltraPower cordless string trimmer with a long shaft and a cutting head at the bottom. It has an adjustable auxiliary handle.
Operator Manual
Exploded View and Parts List
Diagram Description: The exploded view shows the string trimmer disassembled into several components, including the auxiliary handle assembly (with its parts: bolt, handle, clamp, knob), coupler knob, Allen key, shoulder strap, guard assembly, and the trimmer head assembly.
| No. | Part No. | Qty | Description |
|---|---|---|---|
| 1 | R0201836-00 | 1 | Auxiliary handle assembly |
| 1.1 | R0201826-00 | 1 | Bolt |
| 1.2 | R0201827-00 | 1 | Auxiliary handle |
| 1.3 | R0201828-00 | 1 | Lower clamp |
| 1.4 | R0201833-00 | 1 | Knob |
| 2 | R0201784-00 | 1 | Coupler knob |
| 3 | R0201770-00 | 1 | Allen key |
| 4 | RB37902144 | 1 | Shoulder strap |
| 5 | R0201835-00 | 1 | Guard assembly |
| 6 | R0201834-00 | 1 | Trimmer head assembly |
Greenworks Pro 60V Hedge Trimmer
Model Numbers: HT60L211, HT60L01
Product Description: A Greenworks Pro 60V UltraPower cordless hedge trimmer with long, dual-action cutting blades. It features an ergonomic handle design.
Operator Manual
Exploded View and Parts List
Diagram Description: The exploded view shows the hedge trimmer disassembled into 3 numbered parts: the auxiliary handle assembly, the guard that protects the user, and the blade cover for storage and transport.
| No. | Part No. | Qty | Description |
|---|---|---|---|
| 1 | R0201807-00 | 1 | Auxiliary handle assembly |
| 2 | R0201808-00 | 1 | Guard |
| 3 | R0201931-00 | 1 | Blade cover |
Models: CS60L03, 18-Inch 60-Volt Electric Cordless Chainsaw
Full PDF Document
If the inline viewer fails, it will open the original document in compatibility mode automatically. You can also open the file directly.
