Korel Air Conditioning Catalog 2020/2021

Discover the latest range of Korel air conditioning solutions.

Split Air Conditioners

NEXO Series

DC Inverter A++

Models: KOR32-09HFN8 (2,6 kW), KOR32-12HFN8 (3,5 kW), KOR32-18HFN8 (5,3 kW), KOR32-24HFN8 (7,0 kW)

Features:

  • Golden Fin: Golden hydrophilic evaporator prevents bacteria spread and enhances heating efficiency by quickly defrosting the outdoor unit, offering resistance to salty air, rain, and corrosive elements.
  • Refrigerant Leakage Detect: The indoor unit alarms if leakage occurs or if there is a surplus of refrigerant.
  • Control Options: IR Remote (standard), Wired remote (optional), WiFi (optional).

OPTIMUS Series

DC Inverter A++

Models: KMA32-09FNX/8 (2,6 kW), KMA32-12FNX/8 (3,5 kW), KMA32-18FNX/8 (5,3 kW), KMA32-24FNX/8 (7,0 kW)

Features:

  • ECO Function: Saves energy by operating in an 8-hour regime, reducing energy consumption by up to 60% compared to normal mode.
  • WiFi Management: Control and regulate the air conditioner unit via a smartphone app.
  • Control Options: IR Remote (standard), WiFi (standard).

URBAN Series

DC Inverter A++

Models: KSAJA-09DCE (2,7 kW), KSAJA-12DCE (3,6 kW), KSAJA-18DCE (5,4 kW), KSAJA-24DCE (7,2 kW)

Features:

  • Unprecedented Elegance: Urban design inspired by pebble shape, with a compact design and simple maintenance.
  • WiFi Operation: Manage and regulate the air conditioner via a smartphone app.
  • Control Options: REMOTE (standard), WiFi (standard).

URBAN ART Series

DC Inverter A++

Model: KSAJP-12DCE (3,6 kW)

Features:

  • Unprecedented Elegance: Urban design with a black matt surface and a luxuriously designed mirror front panel.
  • WiFi Operation: Manage and regulate the air conditioner via a smartphone app.
  • Control Options: REMOTE (standard), WiFi (standard).

AKIRA Series

DC Inverter A++

Model: KAC-12XA61 (3,4 kW)

Features:

  • Smart Air Flow: Directs cold air towards the ceiling for a comfortable feeling ('shower style') in cooling mode, and blows warm air towards the floor ('blanket style') in heating mode.
  • Self-cleaning: After turning off, the indoor unit fan continues to operate for a few minutes to ventilate and dry the heat exchanger.
  • Control Options: REMOTE (standard).

Multi Split Air Conditioners

DC Inverter R32 I A++

Higher efficiency under partial load.

Space savings: 60%

Outdoor Units:

  • K20C-18FN8 (5,3 KW)
  • K30-21FN8 (6,2 KW)
  • K30-27FN8 (7,9 KW)
  • K40-36HFN8 (10,5 KW)
  • K50-24FN8 (12,3 KW)

Features:

  • Up to 5 indoor units
  • 80 m max. pipe length
  • 15 m max. vertical drop
  • Flexible wiring
  • Easy maintenance
  • Check Point button
  • Status and Error Display
  • Low cooling temperature

Maximum Power: 12,3 kW

Oversizing: 50%

Indoor Units:

  • NEXO: KOR32-09HFN8 (2,6 kW) to KOR32-24HFN8 (7,0 kW)
  • OPTIMUS: KMA32-09FNX (2,6 kW) to KMA32-24FNX (7,0 kW)
  • CASSETTE: KCA31-09FNXDO (2,6 kW), KCA3U-12FNX (3,5 kW), KCA3-18FNXDO (5,3 kW)
  • DUCT: KTI-12FNXDO (3,5 kW), KTI-18FNXDO (5,3 kW)

*Functions and characteristics are the same as in MONO unit for NEXO, OPTIMUS, CASSETTE, and DUCT series.

Commercial Air Conditioners

DC Inverter R32 | A++

Outdoor Units

Features:

  • Anti-corrosion casing: Multi-layer coating provides long-term anti-corrosion properties.
  • Anti-corrosion coating for PCB: Ensures reliability and longevity.
  • GMCC Compressor: Known for power, endurance, and reliability.
  • Reliability & Longevity
  • Specifications: Universal unit, 65 m max. pipe length, 15 m max. vertical drop, flexible wiring, easy maintenance, gilded plates, low cooling temperature.
  • Models: KOU-12FN8-QDO (3,5 kW), KOU-18FN8-QDO (5,3 kW), KOU-24FN8-QDO (7,0 kW), KOU-36FN8-RDO (10,5kW), KOU-55FN8-RDO (15,5 kW)

Maximum Power: 15,5 kW

Cassette Units

COMPACT:

  • Models: KCA3U-12FNX (3,5 KW), KCA3-18FNXDO (5,3 KW)
  • Dimensions: 570x570

SLIM:

  • Models: KCD-24FNX (7,0 kW), KCD-36FNX (10,5 kW), KCD-55FNX (15,5 kW)
  • Dimensions: 840x840
  • Features: Emergency Flap position function, memory, Auto restart, Temperature compensation, Low cooling temperature, Anti-cold function, Refrigerant leakage detect.
  • Air Supply: Fresh air supply.
  • Control Options: IR remote (standard), Wired remote (optional), Panel 360° (standard).
  • Drain Pump: standard.

Duct Units

  • Models: KTI-12FNXDO (3,5 kW), KTI-18FNXDO (5,3 kW), KTI-24FNXDO (7,0 kW), KTI-36FNXDO (10,5 kW), KTI-55FNXDO (15,5 kW)
  • Features: Emergency Flap position function, memory, Auto restart, Temperature compensation, Low cooling temperature, Anti-cold function, Refrigerant leakage detect.
  • Air Supply: Flexible air supply with side and bottom entrances.
  • Control Options: Wired remote (standard).

Ceiling-Floor Units

  • Models: KUE-18FNX (5,3 kW), KUE-24FNX (7,0 kW), KUE-36FNX (10,5 kW), KUE-55FNX (15,5 kW)
  • Features: Turbo function, Timer, Emergency Flap position function, memory, Auto restart, Temperature compensation, Low cooling temperature, Anti-cold function, Refrigerant leakage detect, Night mode.
  • Air Flow: 3D air flow.
  • Control Options: IR remote (standard), Wired remote (optional).

Console Units

  • Models: KFAU-12FNXDO (3,5 kW), KFAU-18FNXDO (4,5 kW)
  • Features: 24h Timer, Turbo function, Emergency Flap position function, memory, Auto restart, Temperature compensation, Low cooling temperature, Anti-cold function, Refrigerant leakage detect, Night mode.
  • Air Intake/Exhaust: 4 intakes, 2 exhausts.
  • Control Options: IR Remote (standard), Wired remote (optional).

TWIN SYSTEM

Available configurations: 18k+18k, 24k+24k.

Functions - Split-type

ENERGY SAVING

  • ECO function: Saves energy by operating in an 8-hour regime, reducing consumption by up to 60%.
  • 1W standby: Intelligent on-off technology reduces standby power consumption from 5W to 1W, saving 80-90% of energy.
  • Night mode: Automatically adjusts temperature by 1°C per hour for the first two hours, then maintains the set temperature before shutting off after 5 hours.

All Korel Air Conditioners use R32 refrigerant

New refrigerant R32 contributes to decreasing the amount of partially halogenated fluorinated hydrocarbons (HFC). Advantages include higher energy efficiency, 30% less refrigerant needed, and similar installation procedures as R410.

CLEAN AIR

  • High density filter: Offers 50% higher dust removal and 80% higher pollen removal compared to ordinary dust filters.
  • Carbon filter: Eliminates odors and nicotine smoke, captures small dust particles, and prevents allergies.
  • Bio filter: Contains particles, bacteria & microorganisms, and biological enzymes that eliminate up to 95% of bacteria and capture 99% of dust for effective sterilization.
  • Self-cleaning: After shutdown, the indoor unit fan runs for 10 minutes to ventilate and dry the heat exchanger.
  • Golden Fin: Hydrophilic evaporator prevents bacteria spread and enhances heating efficiency by quickly defrosting the outdoor unit, providing resistance to corrosive elements.

Specifications - Split-type

NEXO Series

SpecificationKOR32-09HFN8KOR32-12HFN8KOR32-18HFN8KOR32-24HFN8
Energy rate (c/h)A++/A+A++/A+A++/A+A++/A+
Cooling power (kW)2,63,55,37
Heating capacity (kW)2,93,85,67,3
RefrigerantR32R32R32R32
Power input cooling (W)710 (100-1240)1237 (130-1580)1921 (140-2360)2345 (160-2960)
Power input - heating (W)739 (120-1200)964 (100-1580)1546 (200-2410)2035 (260-3140)
SEER (W)6,26,17,16,1
SCOP(W)4444
Voltage (ph-V-Hz)1-220-501-220-501-220-501-220-50
Sound pressure level - indoor unit (dB(A))40/30/26/2140/34/26/2244/37/30/2544.5/42/34.5/28
Sound power level - indoor unit (dB(A))53535559
Sound pressure level outdoor unit (dB(A))55,5565659,5
Sound power level - outdoor unit (dB(A))61656167
Dimensions - indoor unit - WxHxD (mm)805x285x194805x285x194957x302x2131040x327x220
Dimensions outdoor unit - WxHxD (mm)700x550x275700x550x275800x554x333845x702x363
Weight - indoor unit (kg)7,57,51012,3
Weight outdoor unit (kg)22,722,73451,5
Piping size liquid (inch(mm))1/4" (fi 6,35)1/4" (fi 6,35)1/4" (fi 6,35)3/8" (fi 9,52)
Piping size - gas (inch(mm))3/8" (fi 9,53)3/8" (fi 9,53)3/8" (fi 9,53)1/2" (fi 12,7)
Max pipe length (m)25253050
Max difference in level (m)10102025
Air flow - indoor unit (m3/h)520/460/360600/500/360840/680/540980/817/662
Ambient temperature cooling (°C) min-max-15-50-15-50-15~50-15-50
Ambient temperature - heating (°C) min-max-15-30-15-30-15~30-15~30
Brackets distance (mm)454551,454
Warranty2 years2 years2 years2 years

OPTIMUS Series

SpecificationKMA32-09FNXKMA32-12FNXKMA32-18FNXKMA32-24FNX
Energy rate (c/h)A++/A+A++/A+A++/A+A++/A+
Cooling power (kW)2,63,55,37,3
Heating capacity (kW)2,93,85,67,6
RefrigerantR32R32R32R32
Power input - cooling (W)749 (70-1230)1089 (50-1600)1538 (120~2390)2402 (230-3350)
Power input - heating (W)715 (140-1310)1050 (130-1710)1461 (190-2490)2177 (230-3370)
SEER (W)7,176,46,4
SCOP(W)44,144
Voltage (ph-V-Hz)1-220-501-220-501-220-501-220-50
Sound pressure level - indoor unit (dB(A))37/33/22/2038/32/22/2142/33/27/2146/40/30/26
Sound power level - indoor unit (dB(A))54565862
Sound pressure level - outdoor unit (dB(A))55555759
Sound power level - outdoor unit (dB(A))59606466
Dimensions - indoor unit - WxHxD (mm)722x290x187802x297x189965x319x2151080x335x226
Dimensions outdoor unit - WxHxD (mm)770x555x300770x555x300800x554x333845x700x320
Weight - indoor unit (kg)7,48,2912
Weight outdoor unit (kg)26,526,43748,7
Piping size - liquid (inch(mm))1/4" (fi 6,35)1/4" (fi 6,35)1/4" (fi 6,35)1/4" (fi 6,35)
Piping size - gas (inch(mm))3/8" (fi 9,53)3/8" (fi 9,53)3/8" (fi 9,52)1/2" (fi 12,7)
Max pipe length (m)30202020
Max difference in level (m)10102525
Air flow - indoor unit (m3/h)521/429/259539/478/294750/505/4201050/750/560
Ambient temperature cooling (°C) min-max-15-50-15-50-15-50-15-50
Ambient temperature - heating (°C) min-max-15-30-15-30-15-30-15-30
Brackets distance (mm)48,748,751,454
Warranty2 years2 years2 years2 years

URBAN / URBAN ART Series

SpecificationKSAJA-09DCEKSAJA/P-12DCEKSAJA-18DCEKSAJA-24DCE
Energy rate (c/h)A++/A+A++/A+A++/A+A++/A+
Cooling power (kW)2,73,65,47,2
Heating capacity (kW)3,03,75,87,2
RefrigerantR32R32R32R32
Power input - cooling (W)800109016501490
Power input - heating (W)75097022001960
SEER (W)6,166,126,576,89
SCOP(W)4,174,144,024,11
Voltage (ph-V-Hz)1-220-501-220-501-220-501-220-50
Sound pressure level - indoor unit (dB(A))44444748
Sound power level - indoor unit (dB(A))56545858
Sound pressure level - outdoor unit (dB(A))53535657
Sound power level - outdoor unit (dB(A))61606465
Dimensions - indoor unit - WxHxD (mm)792x292x201792x292x201940x316x2241132x330x232
Dimensions outdoor unit - WxHxD (mm)730×545×285730×545×285800×545×315900×700×350
Weight - indoor unit (kg)88,51215
Weight outdoor unit (kg)25253545
Piping size - liquid (inch(mm))1/4" (fi 6,35)1/4" (fi 6,35)1/4" (fi 6,35)3/8" (fi 9,52)
Piping size - gas (inch(mm))3/8" (fi 9,53)3/8" (fi 9,53)1/2" (fi 12,7)5/8" (fi 15,9)
Max pipe length (m)20202020
Max difference in level (m)10101015
Air flow - indoor unit (m3/h)6006009001150
Ambient temperature cooling (°C) min-max-15-32-15-32-15-32-15-32
Ambient temperature - heating (°C) min-max-15-32-15-32-15-32-15-32
Brackets distance (mm)545454,563
Warranty2 godine2 godine2 godine2 godine

AKIRA Series

SpecificationKAC-12XA61KAC-12XA61
Energy rate (c/h)A++/A+A++/A+
Cooling power (kW)3,43,4
Heating capacity (kW)3,43,4
RefrigerantR32R32
Power input - cooling (W)1130(290-1500)1130(290-1500)
Power input - heating (W)922(290-1720)922(290-1720)
SEER (W)6,16,1
SCOP(W)4,04,0
Voltage (ph-V-Hz)1-220-501-220-50
Sound pressure level - indoor unit (dB(A))40/37/33/25/2240/37/33/25/22
Sound power level - indoor unit (dB(A))50/47/43/35/3250/47/43/35/32
Sound pressure level - outdoor unit (dB(A))5050
Sound power level - outdoor unit (dB(A))6060
Dimensions - indoor unit - WxHxD (mm)777×250×201777×250×201
Dimensions outdoor unit - WxHxD (mm)777×498×290777×498×290
Weight - indoor unit (kg)88
Weight outdoor unit (kg)2424
Piping size - liquid (inch(mm))1/4" (fi 6,35)1/4" (fi 6,35)
Piping size - gas (inch(mm))3/8" (fi 9,53)3/8" (fi 9,53)
Max pipe length (m)2525
Max difference in level (m)1010
Air flow - indoor unit (m3/h)550550
Ambient temperature cooling (°C) min-max17-3217-32
Ambient temperature - heating (°C) min-max-15-53-15-53
Brackets distance (mm)--
Warranty2 godine2 godine

Specifications - Multi Outdoor Units

MULTI OUTDOOR UNITK20C-18HFN8K30-21FN8K30-27HFN8K40-36HFN8K50-42FN8
Energy rate (c/h)A++/A+A++/A+A++/A+A++/A+A++/A
Cooling power (kW)5,36,27,910,5512,31
Heating capacity (kW)5,66,68,210,812,31
RefrigerantR32R32R32R32R32
Power input cooling (W)1630 (650-2000)1950 (180-2240)2450 (235-3220)3270 (1140-4090)4260 (1490-4580)
Power input - heating (W)1390 (600-1670)1780 (325-1920)2100 (310-2890)2760 (970-3450)3100 (1090-4000)
SEER (W)6,16,56,16,56,6
SCOP(W)4,04,04,04,03,8
Voltage (ph-V-Hz)1-220-501-220-501-220-501-220-501-220-50
Sound pressure level (dB(A))5657,5546364
Sound power level (dB(A))6565676769
Dimensions - outdoor unit - WxHxD (mm)800x554x333845x702x363845x702x363946x810x410946x810x410
Weight outdoor unit (kg)35,546,851,168,873,3
Piping size - liquid (inch(mm))2 x 1/4" (fi 6.35)3 x 1/4" (fi 6.35)3 x 1/4" (fi 6.35)4 x 1/4" (fi 6.35)5 x 1/4" (fi 6.35)
Piping size - gas (inch(mm))2 x 3/8" (fi 9.52)3 x 3/8" (fi 9.52)3 x 3/8" (fi 9.52)3 x 3/8" (fi 9.52) + 1 x1/2" (fi 12,7)4 x 3/8" (fi 9.52) + 1 x1/2" (fi 12,7)
Max pipe length (m)4060608080
Max pipe length one unit (m)2530303535
Max difference in level between OU and IU (m)1515151515
Max difference in level between IU (m)1010101010
Air flow (m3/h)22003000270040003850
Ambient temperature cooling (°C) min-max-15-50-15-50-15-50-15-50-15-50
Ambient temperature - heating (°C) min-max-15-24-15-24-15-24-15-24-15-24
Brackets distance (mm)51,4545467,367,3
Warranty2 years2 years2 years2 years2 years

COMMERCIAL OUTDOOR UNITS

OUTDOOR UNITKOU-12FN8-QDOKOU-18FN8-QDOKOU-24FN8-QDOKOU-36FN8-RDOKOU-55FN8-RDO
RefrigerantR32R32R32R32R32
Power input - Max. (W)23502950295056007500
Voltage (ph-V-Hz)1-220-501-220-501-220-503-380-503-380-50
Sound pressure level (dB(A))55,555626666
Sound power level (dB(A))6363656874
Dimensions - outdoor unit - WxHxD(mm)800x554x333800x554x333845x702x363946x810x410952x1333x415
Weight outdoor unit (kg)34,733,766,881,5111,3
Piping size - liquid (inch(mm))1/4" (fi 6,35)1/4" (fi 6,35)3/8" (fi 9,53)3/8" (fi 9,53)3/8" (fi 9,53)
Piping size - gas (inch(mm))3/8" (fi 9,53)1/2" (fi 12,7)5/8" (fi 15,9)5/8" (fi 15,9)5/8" (fi 15,9)
Max pipe length (m)2530506565
Max difference in level between OU and IU (m)1020253030
Ambient temperature cooling (°C) min-max-15-50-15-50-15-50-15-50-15-50
Ambient temperature - heating (°C) min-max-15-24-15-24-15-24-15-24-15-24
Brackets distance (mm)51,451,4546763,4
Warranty2 years2 years2 years2 years2 years

Specifications - Indoor Units

INDOOR CASSETTE UNITS

INDOOR UNITKCA31-09FNXDOKCA3U-12FNXKCA3-18FNXDOKCD-24FNXKCD-36FNXKCD-55FNX
Energy rate (c/h)A++/A++A++/A++A++/A+A++/A+A++/A+A++/A+
Cooling power (kW)2,63,55,37,010,515,5
Heating capacity (kW)2,94,45,47,611,118,2
RefrigerantR32R32R32R32R32R32
Power input cooling (W)850 (350-1600)1100 (310-1800)1633 (720-1860)2050 (500-2880)3950 (890-4500)5951 (1147-6682)
Power input - heating (W)40401460 (700-1930)3040(730-4550)2993 (720-4450)6036 (1022-6448)
SEER (W)7,86,16,16,16,16,1
SCOP(W)4,64,04,04,04,04,0
Voltage (ph-V-Hz)1-220-501-220-501-220-501-220-501-220-501-220-50
Sound pressure level - indoor unit (dB(A))38/33/2941/36/3342.5/39/35.551/49/4653/50.5/4847/43/40
Sound power level - indoor unit (dB(A))535156596265
Dimensions - indoor unit - WxHxD (mm)570x260x570570x260x570570x260x570840x205x840840x205x840840x205x840
Dimesions of panel - WxHxD (mm)647x50x647647x50x647647x50x647950x55x950950x55x950950x55x950
Weight - indoor unit / panel (kg)14,7/2,516,2/2,516,2/2,523/527,5/529,7/5
Piping size - liquid (inch(mm))1/4" (fi 6,35)1/4" (fi 6,35)1/4" (fi 6,35)3/8" (fi 9,53)3/8" (fi 9,53)3/8" (fi 9,53)
Piping size gas (inch(mm))3/8" (fi 9,53)3/8" (fi 9,53)1/2" (fi 12,7)5/8" (fi 15,9)5/8" (fi 15,9)5/8" (fi 15,9)
Air flow - indoor unit (m3/h)580/500/450617/504/416720/625/5401378/1200/10321775/1620/14381970/1737/1537
Ambient temperature cooling (°C) min-max17-3217-3017-3017-3017-3017-30
Ambient temperature - heating (°C) min-max0-300-300-300-300-300-30
Warranty2 years2 years2 years2 years2 years2 years
CombinationsONLY MULTIMULTI AND COMMERCIALMULTI AND COMMERCIALONLY COMMERCIALONLY COMMERCIALONLY COMMERCIAL

INDOOR CONSOLE UNITS

INDOOR UNITKFAU-12FNXDOKFAU-18FNXDO
Energy rate (c/h)A++/A+A++/A+
Cooling power (kW)3,54,8
Heating capacity (kW)3,85,0
RefrigerantR32R32
Power input cooling (W)1168 (174-1844)1511 (651-1714)
Power input - heating (W)1100 (149-1465)1400 (606-2022)
SEER (W)7,06,1
SCOP(W)4,04,0
Voltage (ph-V-Hz)1-220-501-220-50
Sound pressure level - indoor unit (dB(A))43/41.5/3542.5/39/35/25
Sound power level - indoor unit (dB(A))5860
Dimensions - indoor unit - WxHxD (mm)700x210x600700x210x600
Weight - indoor unit (kg)14,814,8
Piping size - liquid (inch(mm))1/4" (fi 6,35)1/4" (fi 6,35)
Piping size - gas (inch(mm))3/8" (fi 9,53)3/8" (fi 9,53)
Air flow - indoor unit (m3/h)512/480/370560/480/400
Ambient temperature cooling (°C) min-max17-3017-30
Ambient temperature - heating (°C) min-max0-300-30
Warranty2 years2 years
CombinationsONLY COMMERCIALONLY COMMERCIAL

Frigo-kor d.o.o.

Majstorska 11

10000 Zagreb

Croatia

Email: info@frigo-kor.hr

www.korel.hr

*We are not responsible for eventual typos and we reserve the right to change design and specification without notice.

Models: KOR32-09HFN8, KOR32-12HFN8, KOR32-18HFN8, KOR32-24HFN8, Split Air Conditioner

Full PDF Document

Loading PDF...
Download PDF

If the inline viewer fails, it will open the original document in compatibility mode automatically. You can also open the file directly.

References
