Akko 3084 User Manual
3084 Technical Specifications
| Feature | Specification |
|---|---|
| Dimensions | 315x126x38mm |
| Weight | Approximately 0.85KG |
| Country of Origin | China |
| Type | Mechanical Keyboard |
| Keycap | PBT Material |
| Interface | Type-C To USB |
| Multimedia Keys | YES |
| N-Key Rollover | YES |
| Custom Keys | YES (use Akko Macro V1.0) |
3084 HotKeys
The keyboard features a standard layout with dedicated function keys. The Fn key is located near the right Ctrl key.
Function Key Combinations:
- Fn + F1: File Explorer
- Fn + F2: E-mail
- Fn + F3: Windows Search
- Fn + F4: Browser Homepage
- Fn + F5: Media Player
- Fn + F6: Play/Pause ▶️
- Fn + F7: Previous Song ⏮️
- Fn + F8: Next Song ⏭️
- Fn + M: Mute ?
- Fn + <: Decrease Volume ?
- Fn + >: Increase Volume ?
- Fn + W: Swap WASD keys with Arrow keys (↑↓←→)
Hold Fn + Right Ctrl: Revert Ctrl into Menu (APP) key.
3084 System Commands
These commands control system-level functions of the keyboard.
- Lock Windows Key: Press Fn + Left Win key.
- Restore Factory Settings: Hold down Fn and press the `~` key.
3084S Single-Color Backlight
*Backlight function is only available on the backlight version of 3084s.
The keyboard features adjustable single-color backlighting. The Fn key is located near the right Ctrl key. Keys like Del, -, +, and arrow keys are involved in backlight control.
Backlight Control:
- Fn + Del: Cycles through backlight effects: Steady, Breathe, One-key light up, One-key light off, Wave, Ripple, Raindrop.
- Fn + ↑: Brightness Up / Faster Animation
- Fn + ↓: Brightness Down / Slower Animation
- Fn + ←: Set animation direction to left
- Fn + →: Set animation direction to right
- Fn + -: Slower Animation
- Fn + +: Faster Animation
Note: The adjustments for animation speed and direction may not apply to all lighting effects. For example, effects with constant light only allow brightness adjustment.
3084S Custom Backlight
This section details how to customize the keyboard's lighting effects.
The keyboard offers 4 groups of customizable lighting effects using Fn + F9 through F12. The system also includes 4 groups of pre-loaded default lighting effects.
Triggering Custom Lighting:
- Press Fn + (F9 ~ F12) to trigger custom lighting effects.
Editing Custom Lighting Effects:
- Press Fn + (F9 ~ F12) to enter the custom lighting mode.
- Press Fn + (F9 ~ F12) again to start editing. Select the desired illuminated keys for the specific lighting effect group.
- Continue to press Fn + (F9 ~ F12) to save the changes.
Akko Macro V1.0 Macro Setup Instruction 1
- Akko Macro V1.0 is hardware-based and operates without requiring software drivers.
- The following keys cannot be programmed: "Esc", "Fn", "Left Win".
- To switch to Macro mode, press and hold Fn + Win for 3 seconds. Macro mode is exited upon keyboard re-connection or system restart; you will need to switch to Macro mode again to use programmed keys.
- Akko Macro V1.0 does not support simultaneous trigger. Pressing keys like "AB" at the same time will trigger them in the order of A followed by B.
- Akko Macro V1.0 does not support customized interval time between key presses. The trigger interval between keys A and B will follow the system's default timing.
Akko Macro V1.0 Macro Setup Instruction 2
This section outlines the process for setting up macros using a flowchart.
Workflow:
- Enter Macro Mode: Long Press Fn + Left Win.
- Start Macro Editor: Press Fn + Esc.
- Select Key for Customization: Press Fn + Custom Key.
- Macro Recording: Press the keys to store.
- End Recording for Key: Press Fn + Custom Key.
- Record Next Key: The process loops to record the next key.
- Clear Macro: Long Press Fn + Custom Key.
- Exit Macro Mode (Back to Default Mode): Long Press Fn + Left Win.
- Exit Macro Editor: Press Fn + Esc.
Akko Macro V1.0 Macro Setup Instruction 3
Macro Recording Example: Define "A" as "AKKOGEAR"
- Press and hold Fn + Left Win for 3 seconds to enter the Macro mode.
- Press Fn + ESC to launch the Macro editor.
- Press Fn + A to select key "A" for recording.
- Press the keys A, K, K, O, G, E, A, R in sequence as the definition for "A".
- Press Fn + A again to end the Macro recording for key "A".
At this point, pressing "A" in a text editor (like Notepad) will display "AKKOGEAR".
To create a Macro for key "B", press Fn + B to start the Macro recording.
- Press Fn + Esc to exit the Macro editor.
- Under Macro mode, you can configure your set keys and Macros.
- Press and hold Fn + Left Win for 3 seconds to exit the Macro mode and return to the default key definition.
Akko Warranty and Service Statement
- Akko provides a 1-year warranty for customers in mainland China. For other regions, please contact your seller (Akko distributor) for specific warranty policy.
- If the warranty window expires, customers will need to pay for repairs. Akko can provide instructions for self-repair, but users assume full responsibility for any loss during self-repair.
- Disassembling the keyboard without manufacturer/seller's instruction will immediately void the warranty.
- The return and warranty policy may vary across different platforms and are subject to the specific distributor at the time of purchase.
Precautions:
Man-made damage is not limited to immersion, falling off, and pulling off wires with excessive forces. As an electronic product, please handle the keyboard with care according to electronic product protection methods.
Service Hotline: 0755-27728007
Service QQ: 981572876
Official Service Hours: Monday to Friday, 10:00 AM to 6:00 PM. Public holidays follow national regulations.
Note: Service times may vary due to uncontrollable factors such as repair time, logistics, and parts procurement. Akko will assess the actual damage situation and request user patience.
