DIGITAL CAMERA
Reference Manual
•Read this manual thoroughly before using the camera.
•To ensure proper use of the camera, be sure to read “For
Your Safety” (page viii).
•After reading this manual, keep it in a readily accessible
place for future reference.
ii
Quick Topic Search
You can return to this page by tapping or clicking in the lower right of any page.
Main Topics
For Smart Device Users .......................................................................................................iii
Introduction ............................................................................................................................. v
Table of Contents.................................................................................................................xii
Parts of the Camera ...............................................................................................................1
Getting Started........................................................................................................................9
Basic Shooting and Playback Operations....................................................................20
Shooting Features................................................................................................................27
Playback Features.................................................................................................................63
Movies ......................................................................................................................................75
Connecting the Camera to a TV, Printer, or Computer...........................................86
Using the Menu.....................................................................................................................97
Technical Notes.................................................................................................................. 143
Common Topics
For Your Safety What SnapBridge
Can Do for You
Selecting a
Shooting Mode
Using the Zoom
Continuous
Shooting
Editing Images
(Still Images)
Troubleshooting Index
iii
For Smart Device Users
Your images. The world. Connected
Welcome to SnapBridge — Nikon’s new family of services to enrich
your image experience. SnapBridge eliminates the barrier between
your camera and compatible smart device, through a combination
of Bluetooth® low energy (BLE) technology and a dedicated app. The
stories you capture with your Nikon camera and lenses are
automatically transferred to the device as they are taken. They can
even be uploaded effortlessly to cloud storage services, inviting
access across all your devices. You can share your excitement, when
and where you want.
Download the SnapBridge app to get started!
Take advantage of the wide-ranging
convenience by downloading the
SnapBridge app onto your smart device
now. Through a few simple steps, this
app connects your Nikon cameras with a
compatible iPhone®, iPad® and/or iPod
touch® or smart devices running on the
AndroidTM operating system. The app is
available free from the website (http://
snapbridge.nikon.com), Apple App
Store® and Google PlayTM.
For the latest information on SnapBridge, visit the Nikon website for
your area (Avi).
For Smart Device Users
iv
For Smart Device Users
The exciting image experience that SnapBridge offers…
A range of services that enriches your imaging life,
including:
•Camera remote control
•Imprinting up to two pieces of credit
information (e.g. copyright, comments,
text and logos) on pictures
•Automatic update of camera’s date and
time info and location info
•Receive camera’s firmware updates
Automatic picture transfer from camera to smart
device thanks to the constant connection between
the two devices — making online photo sharing
easier than ever
Upload of photos and thumbnail images to the
NIKON IMAGE SPACE cloud service
v
Introduction
Read This First
Introduction
Thank you for purchasing the Nikon COOLPIX B500 digital camera.
Symbols and Conventions Used in This Manual
•Tap or click in the lower right of each page to display “Quick Topic Search”
(Aii).
•Symbols
•SD, SDHC, and SDXC memory cards are referred to as “memory cards” in this
manual.
•The setting at the time of purchase is referred to as the “default setting.”
•The names of menu items displayed on the camera screen, and the names of
buttons or messages displayed on a computer screen appear in bold.
•In this manual, images are sometimes omitted from screen display samples so that
screen indicators can be more clearly shown.
Read This First
Symbol Description
BThis icon marks cautions and information that should be read before
using the camera.
CThis icon marks notes and information that should be read before using
the camera.
AThis icon marks other pages containing relevant information.
vi
Introduction
Read This First
Information and Precautions
Life-Long Learning
As part of Nikon’s “Life-Long Learning” commitment to ongoing product support and
education, continually updated information is available online at the following websites:
•For users in the U.S.A.: http://www.nikonusa.com/
•For users in Europe: http://www.europe-nikon.com/support/
•For users in Asia, Oceania, the Middle East, and Africa: http://www.nikon-asia.com/
Visit these websites to keep up-to-date with the latest product information, tips, answers to
frequently asked questions (FAQs), and general advice on digital imaging and photography.
Additional information may be available from the Nikon representative in your area. Visit the
website below for contact information.
http://imaging.nikon.com/
Use Only Nikon Brand Electronic Accessories
Nikon COOLPIX cameras are designed to the highest standards and include complex
electronic circuitry. Only Nikon brand electronic accessories (including battery chargers,
batteries, and AC adapters) certified by Nikon specifically for use with this Nikon digital
camera are engineered and proven to operate within the operational and safety
requirements of this electronic circuitry.
THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA AND
MAY VOID YOUR NIKON WARRANTY.
For more information about Nikon brand accessories, contact a local authorized Nikon
dealer.
Before Taking Important Pictures
Before taking pictures on important occasions (such as at weddings or before taking the
camera on a trip), take a test shot to ensure that the camera is functioning normally. Nikon
will not be held liable for damages or lost profits that may result from product malfunction.
vii
Introduction
Read This First
About the Manuals
•No part of the manuals included with this product may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form, by
any means, without Nikon’s prior written permission.
•Illustrations and screen content shown in this manual may differ from the actual product.
•Nikon reserves the right to change the specifications of the hardware and software
described in these manuals at any time and without prior notice.
•Nikon will not be held liable for any damages resulting from the use of this product.
•While every effort was made to ensure that the information in these manuals is accurate
and complete, we would appreciate it were you to bring any errors or omissions to the
attention of the Nikon representative in your area (address provided separately).
Comply with Copyright Notices
Under copyright law, photographs or recordings of copyrighted works made with the
camera can not be used without the permission of the copyright holder. Exceptions apply
to personal use, but note that even personal use may be restricted in the case of
photographs or recordings of exhibits or live performances.
Disposing of Data Storage Devices
Please note that deleting images or formatting data storage devices such as memory cards
or built-in camera memory does not completely erase the original image data. Deleted files
can sometimes be recovered from discarded storage devices using commercially available
software, potentially resulting in the malicious use of personal image data. Ensuring the
privacy of such data is the user’s responsibility.
Before discarding a data storage device or transferring ownership to another person, make
sure to reset all of the camera’s settings in Reset all in the setup menu (A98). After
resetting, erase all data in the device using commercial deletion software, or format the
device in Format memory or Format card in the setup menu (A98), then completely
refill it with images containing no private information (for example, images of empty sky).
Care should be taken to avoid injury or damage to property when physically destroying
memory cards.
Conformity Marking
Follow the procedure below to display some of the conformity markings that the
camera complies with.
Press the d button M z menu icon M Conformity marking M kbutton
viii
Introduction
For Your Safety
To prevent damage to property or injury to yourself or to others, read “For Your Safety”
in its entirety before using this product.
Keep these safety instructions where all those who use this product will read them.
For Your Safety
DANGER
Failure to observe the precautions marked
with this icon carries a high risk of death or
severe injury.
WARNING
Failure to observe the precautions marked
with this icon could result in death or
severe injury.
CAUTION
Failure to observe the precautions marked
with this icon could result in injury or
property damage.
WARNING
•Do not use while walking or operating a motor vehicle. Failure to observe this
precaution could result in accidents or other injury.
•Do not disassemble or modify this product. Do not touch internal parts that
become exposed as the result of a fall or other accident. Failure to observe these
precautions could result in electric shock or other injury.
•Should you notice any abnormalities such as the product producing smoke, heat,
or unusual odors, immediately disconnect the batteries or power source.
Continued operation could result in fire, burns or other injury.
•Keep dry. Do not handle with wet hands. Do not handle the plug with wet hands.
Failure to observe these precautions could result in fire or electric shock.
•Do not let your skin remain in prolonged contact with this product while it is on or
plugged in. Failure to observe this precaution could result in low-temperature
burns.
•Do not use this product in the presence of flammable dust or gas such as propane,
gasoline or aerosols. Failure to observe this precaution could result in explosion or
fire.
•Do not aim the flash at the operator of a motor vehicle. Failure to observe this
precaution could result in accidents.
ix
Introduction
For Your Safety
•Keep this product out of reach of children. Failure to observe this precaution could
result in injury or product malfunction. In addition, note that small parts constitute
a choking hazard. Should a child swallow any part of this product, seek immediate
medical attention.
•Do not entangle, wrap or twist the straps around your neck. Failure to observe this
precaution could result in accidents.
•Do not use batteries, chargers, or AC adapters not specifically designated for use
with this product. When using batteries, chargers, and AC adapters designated for
use with this product, do not:
- Damage, modify, forcibly tug or bend the cords or cables, place them under
heavy objects, or expose them to heat or flame.
- Use travel converters or adapters designed to convert from one voltage to
another or with DC-to-AC inverters.
Failure to observe these precautions could result in fire or electric shock.
•Do not handle the plug when using the AC adapter during thunderstorms. Failure
to observe this precaution could result in electric shock.
•Do not handle with bare hands in locations exposed to extremely high or low
temperatures. Failure to observe this precaution could result in burns or frostbite.
CAUTION
•Turn this product off when its use is prohibited. Disable wireless features when the
use of wireless equipment is prohibited. The radio-frequency emissions produced
by this product could interfere with equipment onboard aircraft or in hospitals or
other medical facilities.
•Remove the batteries and disconnect the AC adapter if this product will not be
used for an extended period. Failure to observe this precaution could result in fire
or product malfunction.
•Do not touch moving parts of the lens or other moving parts. Failure to observe
this precaution could result in injury.
•Do not fire the flash in contact with or in close proximity to the skin or objects.
Failure to observe this precaution could result in burns or fire.
•Do not leave the product where it will be exposed to extremely high
temperatures, for an extended period such as in an enclosed automobile or in
direct sunlight. Failure to observe this precaution could result in fire or product
malfunction.
x
Introduction
For Your Safety
DANGER for Batteries
•Do not mishandle batteries. Failure to observe the following precautions could
result in the batteries leaking, overheating, rupturing, or catching fire:
- Do not attempt to recharge non-rechargeable batteries.
- Do not expose batteries to flame or excessive heat.
- Do not disassemble.
- Do not short circuit the terminals by touching them to necklaces, hairpins, or
other metal objects.
- Do not expose batteries or the products in which they are inserted to powerful
physical shocks.
•Recharge all EN-MH2 rechargeable batteries in each pack of four simultaneously.
Failure to observe this precaution could result in the batteries leaking,
overheating, rupturing, or catching fire.
•If battery liquid comes into contact with the eyes, rinse with plenty of clean water
and seek immediate medical attention. Delaying action could result in eye injuries.
WARNING for Batteries
•Do not remove or damage the battery casing. Never use batteries with damaged
casing. Failure to observe this precaution could result in the batteries leaking,
overheating, rupturing, or catching fire.
•Keep batteries out of reach of children. Should a child swallow a battery, seek
immediate medical attention.
•Do not immerse this product in water or expose to rain. Failure to observe this
precaution could result in fire or product malfunction. Immediately dry the
product with a towel or similar object should it become wet.
•Discontinue use immediately should you notice any changes in the batteries, such
as discoloration or deformation. Cease charging EN-MH2 rechargeable batteries if
they do not charge in the specified period of time. Failure to observe this
precaution could result in the batteries leaking, overheating, rupturing, or
catching fire.
•Insert batteries in the correct orientation. Do not mix old and new batteries or
batteries of different types. Failure to observe this precaution could result in the
batteries leaking, overheating, rupturing, or catching fire.
•Prior to disposal, insulate battery terminals with tape. Overheating, rupture, or fire
may result should metal objects come into contact with the terminals. Recycle or
dispose of batteries in accord with local regulations.
xi
Introduction
For Your Safety
•If battery liquid comes into contact with a person’s skin or clothing, immediately
rinse the affected area with plenty of clean water. Failure to observe this
precaution could result in skin irritation.
xii
Table of Contents
Table of Contents
Quick Topic Search ............................................................................................................... ii
Main Topics...................................................................................................................................................................... ii
Common Topics ........................................................................................................................................................... ii
For Smart Device Users ...................................................................................................... iii
Introduction ............................................................................................................................ v
Read This First .......................................................................................................................................... v
Symbols and Conventions Used in This Manual ...................................................................................... v
Information and Precautions ............................................................................................................................... vi
For Your Safety ..................................................................................................................................... viii
Parts of the Camera .............................................................................................................. 1
The Camera Body.................................................................................................................................... 2
The Monitor .............................................................................................................................................. 4
Switching the Information Displayed on the Screen (s Button)........................................... 4
For Shooting.................................................................................................................................................................... 5
For Playback..................................................................................................................................................................... 7
Getting Started....................................................................................................................... 9
How to Attach the Camera Strap and Lens Cap........................................................................ 10
Inserting the Batteries and Memory Card.................................................................................... 11
Applicable Batteries................................................................................................................................................. 11
Removing the Batteries or Memory Card................................................................................................... 12
Memory Cards and Internal Memory............................................................................................................ 12
Changing the Angle of the Monitor............................................................................................... 13
Camera Setup......................................................................................................................................... 14
Setup from a Smartphone or Tablet ............................................................................................................. 14
Setup from the Camera Menus........................................................................................................................ 16
What SnapBridge Can Do for You................................................................................................................... 18
xiii
Table of Contents
Basic Shooting and Playback Operations................................................................... 20
Shooting Images................................................................................................................................... 21
Using the Flash ........................................................................................................................................................... 23
Recording Movies ..................................................................................................................................................... 23
Playing Back Images............................................................................................................................ 24
Deleting Images .................................................................................................................................... 25
The Image Selection Screen for Deletion .................................................................................................. 26
Shooting Features............................................................................................................... 27
Selecting a Shooting Mode............................................................................................................... 28
A (Auto) Mode .................................................................................................................................... 29
Using the Creative Slider ...................................................................................................................................... 29
Scene Mode (Shooting Suited to the Shooting Conditions) ................................................ 31
Tips and Notes About Scene Mode............................................................................................................... 32
Shooting with Easy Panorama.......................................................................................................................... 38
Playback with Easy Panorama........................................................................................................................... 40
Creative Mode (Applying Effects When Shooting)................................................................... 41
Smart Portrait Mode (Enhancing Human Faces When Shooting)....................................... 43
Using Smile Timer..................................................................................................................................................... 44
Using Self-Collage..................................................................................................................................................... 45
Setting Shooting Functions with the Multi Selector ............................................................... 46
Flash Mode.............................................................................................................................................. 47
Self-timer ................................................................................................................................................. 49
Macro Mode (Taking Close-up Pictures) ...................................................................................... 51
Exposure Compensation (Adjusting Brightness) ...................................................................... 52
Using the Zoom..................................................................................................................................... 53
Focusing................................................................................................................................................... 55
The Shutter-release Button................................................................................................................................. 55
Using Target Finding AF ....................................................................................................................................... 55
Using Face Detection ............................................................................................................................................. 56
Using Skin Softening............................................................................................................................................... 57
Subjects Not Suitable for Autofocus............................................................................................................. 57
Focus Lock..................................................................................................................................................................... 58
Default Settings (Flash, Self-timer, and Macro Mode)............................................................. 59
Functions That Cannot Be Used Simultaneously When Shooting...................................... 61
xiv
Table of Contents
Playback Features................................................................................................................ 63
Playback Zoom ...................................................................................................................................... 64
Thumbnail Playback/Calendar Display......................................................................................... 65
List by Date Mode................................................................................................................................. 66
Viewing and Deleting Images in a Sequence............................................................................. 67
Viewing Images in a Sequence......................................................................................................................... 67
Deleting Images in a Sequence ....................................................................................................................... 68
Editing Images (Still Images) ............................................................................................................ 69
Before Editing Images ............................................................................................................................................ 69
Quick Effects: Changing Hue or Mood ........................................................................................................ 69
Quick Retouch: Enhancing Contrast and Saturation .......................................................................... 70
D-Lighting: Enhancing Brightness and Contrast ................................................................................... 70
Red-eye Correction: Correcting Red-eye When Shooting with the Flash ............................. 71
Glamour Retouch: Enhancing Human Faces........................................................................................... 71
Small Picture: Reducing the Size of an Image......................................................................................... 73
Crop: Creating a Cropped Copy....................................................................................................................... 74
Movies ..................................................................................................................................... 75
Basic Operations of Movie Recording and Movie Playback .................................................. 76
Capturing Still Images While Recording Movies ....................................................................... 79
Short Movie Show Mode (Combining Movie Clips to Create Short Movies) .................. 80
Using Special Effects................................................................................................................................................ 82
Operations During Movie Playback ............................................................................................... 83
Editing Movies ....................................................................................................................................... 84
Extracting Only the Desired Portion of a Movie..................................................................................... 84
Saving a Frame from a Movie as a Still Image......................................................................................... 85
Connecting the Camera to a TV, Printer, or Computer.......................................... 86
Utilizing Images..................................................................................................................................... 87
Viewing Images on a TV ..................................................................................................................... 88
Printing Images Without a Computer........................................................................................... 90
Connecting the Camera to a Printer............................................................................................................. 90
Printing Images One at a Time ......................................................................................................................... 91
Printing Multiple Images ...................................................................................................................................... 92
Transferring Images to a Computer (ViewNX-i)......................................................................... 94
Installing ViewNX-i.................................................................................................................................................... 94
Transferring Images to a Computer .............................................................................................................. 94
xv
Table of Contents
Using the Menu.................................................................................................................... 97
Menu Operations.................................................................................................................................. 98
The Image Selection Screen............................................................................................................................ 100
Menu Lists ............................................................................................................................................ 101
The Shooting Menu.............................................................................................................................................. 101
The Movie Menu..................................................................................................................................................... 102
The Playback Menu............................................................................................................................................... 102
The Network Menu ............................................................................................................................................... 103
The Setup Menu ..................................................................................................................................................... 104
The Shooting Menu (The Common Shooting Options)....................................................... 105
Image Mode (Image Size and Quality)...................................................................................................... 105
The Shooting Menu (for A (Auto) Mode)............................................................................... 106
White Balance (Adjusting Hue)...................................................................................................................... 106
Continuous Shooting .......................................................................................................................................... 108
ISO Sensitivity ........................................................................................................................................................... 110
AF Area Mode........................................................................................................................................................... 111
Autofocus Mode ..................................................................................................................................................... 114
The Smart Portrait Menu................................................................................................................. 115
Self-Collage ................................................................................................................................................................ 115
Blink Proof ................................................................................................................................................................... 116
The Movie Menu ................................................................................................................................ 117
Movie Options.......................................................................................................................................................... 117
Autofocus Mode ..................................................................................................................................................... 121
Movie VR ...................................................................................................................................................................... 122
Wind Noise Reduction ........................................................................................................................................ 122
Frame Rate.................................................................................................................................................................. 123
The Playback Menu........................................................................................................................... 124
Mark for Upload....................................................................................................................................................... 124
Slide Show .................................................................................................................................................................. 125
Protect........................................................................................................................................................................... 126
Rotate Image............................................................................................................................................................. 126
Copy (Copy Between the Memory Card and Internal Memory)............................................... 127
Sequence Display Options............................................................................................................................... 128
The Network Menu ........................................................................................................................... 129
Operating the Text Input Keyboard............................................................................................................ 130
xvi
Table of Contents
The Setup Menu................................................................................................................................. 131
Time Zone and Date ............................................................................................................................................ 131
Monitor Settings ..................................................................................................................................................... 133
Date Stamp ................................................................................................................................................................ 134
Photo VR ...................................................................................................................................................................... 135
AF Assist ....................................................................................................................................................................... 135
Digital Zoom ............................................................................................................................................................. 136
Sound Settings......................................................................................................................................................... 136
Auto Off........................................................................................................................................................................ 137
Format Card/Format Memory........................................................................................................................ 138
Language .................................................................................................................................................................... 138
Image Comment .................................................................................................................................................... 139
Copyright Information ........................................................................................................................................ 140
Location Data ........................................................................................................................................................... 141
Reset All........................................................................................................................................................................ 141
Battery Type............................................................................................................................................................... 142
Conformity Marking.............................................................................................................................................. 142
Firmware Version.................................................................................................................................................... 142
Technical Notes................................................................................................................. 143
Notices................................................................................................................................................... 144
Notes About Wireless Communication Functions ................................................................ 146
Caring for the Product ..................................................................................................................... 149
The Camera................................................................................................................................................................ 149
Batteries........................................................................................................................................................................ 150
Memory Cards.......................................................................................................................................................... 151
Cleaning and Storage....................................................................................................................... 152
Cleaning....................................................................................................................................................................... 152
Storage.......................................................................................................................................................................... 152
Error Messages.................................................................................................................................... 153
Troubleshooting ................................................................................................................................ 156
File Names............................................................................................................................................ 162
Optional Accessories........................................................................................................................ 163
Specifications ...................................................................................................................................... 164
Memory Cards That Can Be Used................................................................................................................. 168
Index....................................................................................................................................................... 170
1
Parts of the Camera
Parts of the Camera
The Camera Body ...................................................................................................................2
The Monitor..............................................................................................................................4
2
Parts of the Camera
The Camera Body
The Camera Body
1113
9
7 8
433
1
12
56
10
2
1
Zoom control................................................ 53
f: Wide-angle...................................... 53
g: Telephoto ......................................... 53
h: Thumbnail playback..................65
i: Playback zoom.............................. 64
2Shutter-release button............................ 22
3Eyelet for camera strap ........................... 10
4Power switch/power-on lamp........... 14
5Self-timer lamp ............................................ 49
AF-assist illuminator
6Mode dial ................................................ 21, 28
7Microphone (stereo)
8Flash.............................................................23, 47
9N-Mark (NFC antenna) ............................ 15
10 m (flash pop-up) button..................23, 47
11 Side zoom control ..................................... 53
12 q (snap-back zoom) button.............. 54
13 Lens
3
Parts of the Camera
The Camera Body
1314
6
11
52 43
10
17
16 15
12
9
8
1Monitor........................................................ 4, 13
2Speaker
3s (display) button ................................ 4
4Flash lamp....................................................... 47
5b (e movie-record) button.............76
6c (playback) button ..............................24
7
DC input connector
(for AC adapter available separately
from Nikon)................................................. 163
8HDMI micro connector (Type D) ...... 87
9USB/audio/video output connector
............................................................................... 87
10 Connector cover......................................... 87
11 Multi selector................................................ 98
12 k (apply selection) button................. 98
13 l (delete) button ...................................... 25
14 d (menu) button.................................. 98
15 Battery-chamber/
memory card slot cover......................... 11
16 Tripod socket ..............................................166
4
Parts of the Camera
The Monitor
The information that is displayed on the shooting or playback screen changes
depending on the camera’s settings and state of use.
Switching the Information Displayed on the Screen
(s Button)
To switch the information displayed on the screen
during shooting or playback, press the s (display)
button.
For Shooting
For Playback
The Monitor
3200
3200
25m 0s
25m 0s
3200
3200
25m 0s
25m 0s
Show information Movie frame
Display the range of a
movie in a frame.
Hide information
4/4
4/4
15/11/2016 15:30
15/11/2016 15:30
0004. JPG
0004. JPG
15/11/2016 15:30
15/11/2016 15:30
4/4
4/4
F3
F3
1/250
1/250
0.0
0.0
125
125
Show information Tone level information
(except movies)
Display a histogram,
tone level and shooting
information (A8).
Hide information
5
Parts of the Camera
The Monitor
For Shooting
999
999
29m 0s
29m 0s
F3
F3
1/250
1/250
999
999
9999
9999
+1.0
+1.0
10
10
AF
AF
1
2
3
45
6
8
9
10
11
12
13
14
15
1617
7
1819
20
26
23
24
25
21
22
1Shooting mode ........................................... 28
2Flash mode..................................................... 47
3Macro mode.................................................. 51
4Zoom indicator.................................... 51, 53
5Focus indicator.............................................22
6Movie options (normal speed movies)
............................................................................ 117
7Movie options (HS movies)............... 118
8Image mode............................................... 105
9Easy panorama.............................................38
10 Photo VR icon ............................................ 135
11 Movie VR icon............................................ 122
12 Wind noise reduction ........................... 122
13 Exposure compensation value
................................................................29, 43, 52
14 Remaining movie recording time.... 76
15 Number of exposures remaining
(still images)................................................... 21
16 Internal memory indicator ................... 21
17
Framing border (Moon or Bird-
watching scene mode, or snap-back
zoom)..........................................................37, 54
18 Travel destination icon..........................131
19 ISO sensitivity..............................................110
20 Battery level indicator.............................. 21
21 “Date not set” indicator........................157
22 Date stamp...................................................134
23 Bluetooth communication indicator
.....................................................................19, 129
24 Wi-Fi communication indicator
.....................................................................19, 129
25 Location data..............................................141
26 Airplane mode...................................19, 129
6
Parts of the Camera
The Monitor
HDR
HDR
PRE
PRE
2
2
10
10
H
H
L
L
120
120
6 0
60
5
5
999
999
29m 0s
29m 0s
F3
F3
1/250
1/250
+1.0
+1.0
10
10
27282930
313233
34
37
39
40
41
42
43
44
36
38
35
45
46
48
47
49
50
52
51
27 Focus area (manual or center)
.....................................................................58, 111
28 Focus area (target finding AF)
.....................................................................55, 112
29 Focus area (face detection,
pet detection).....................36, 43, 56, 111
30 Focus area (subject tracking)
..................................................................112, 113
31 F-number......................................................... 55
32 Shutter speed ............................................... 55
33 View/hide framing grid........................ 133
34 Soft ...................................................................... 43
35 Active D-Lighting....................................... 29
36 Foundation makeup................................. 43
37 White balance............................................ 106
38 Hue...................................................................... 29
39 Skin softening............................................... 43
40 Special effects............................................... 82
41 Vividness.......................................................... 29
42 Continuous shooting mode......36, 108
43 Blink proof icon .........................................116
44 Hand-held/tripod................................32, 33
45 Backlighting (HDR) .................................... 33
46 Multiple exp. Lighten............................... 34
47 Still image capture
(during movie recording)...................... 79
48 Self-timer indicator.................................... 49
49 Smile timer ..................................................... 44
50 Self-Collage..........................................45, 115
51 Self-portrait timer....................................... 49
52 Pet portrait auto release......................... 36
7
Parts of the Camera
The Monitor
For Playback
999
/
999
999
/
999
9999
/
9999
9999
/
9999
29
m
0s
29
m
0s
29
m
0s
29
m
0s
15/11/2016 12:00
15/11/2016 12:00
999/999
999/999
12
18
56
12
13
93
10
17 16
4
14
15
19
78
11
23
24
2021
22
1List by date icon .......................................... 66
2Protect icon................................................. 126
3Sequence display (when Individual
pictures is selected)............................. 128
4Glamour retouch icon .............................71
5Quick effects icon....................................... 69
6D-Lighting icon............................................ 70
7Quick retouch icon.................................... 70
8Red-eye correction icon.........................71
9Internal memory indicator
10 Current image number/
total number of images
11 Movie length or elapsed playback
time
12 Volume indicator ........................................ 83
13 Image mode................................................105
14 Movie options ............................................117
15 Easy panorama ............................................ 40
16 Small picture icon ...................................... 73
17 Crop icon..................................................64, 74
18
Easy panorama playback guide
Sequence playback guide
Movie playback guide
19 Quick effects guide
20 Time of recording
21 Date of recording
22 Battery level indicator.............................. 21
23 File number and type............................162
24 Recorded location data indicator ...141
8
Parts of the Camera
The Monitor
Tone Level Information Display
You can check for loss of contrast detail in highlights and shadows from the
histogram that is displayed, or the display for the tone level. These provide guidelines
when adjusting the image brightness with functions such as exposure compensation.
1A histogram is a graph showing the distribution of tones in the image. The horizontal axis
corresponds to pixel brightness, with dark tones to the left and bright tones to the right.
The vertical axis shows the number of pixels.
2The tone level indicates the brightness level.
15/11/2016 15:30
15/11/2016 15:30
4/4
4/4
F3
F3
1/250
1/250
0.0
0.0
125
125
1
2
3
4
5
6
12
13
9
10
78
11
1Current image number/
total number of images
2Histogram1
3Tone level2
4ISO sensitivity............................................. 110
5White balance............................................ 106
6Image mode............................................... 105
7Time of recording.............................14, 131
8Date of recording.............................14, 131
9File number and type............................162
10 Exposure compensation value.......... 52
11 Shooting mode ........................................... 28
12 Shutter speed ............................................... 55
13 F-number ........................................................ 55
9
Getting Started
Getting Started
How to Attach the Camera Strap and Lens Cap........................................................10
Inserting the Batteries and Memory Card ...................................................................11
Changing the Angle of the Monitor ..............................................................................13
Camera Setup ........................................................................................................................14
10
Getting Started
How to Attach the Camera Strap and Lens Cap
Attach the lens cap to the camera strap, and then attach the strap to the camera.
BLens Cap
When the camera is not in use, attach the lens cap to the lens to protect it.
How to Attach the Camera Strap and Lens Cap
Attach the strap at two places.
11
Getting Started
Inserting the Batteries and Memory Card
•Hold the camera upside down to prevent the batteries from falling out, confirm
that the positive (+) and negative (–) terminals of the batteries are oriented
correctly, and insert the batteries.
•Slide the memory card in until it clicks into place (5).
•Be careful not to insert the batteries or memory card upside-down or backward, as
this could cause a malfunction.
•When closing the cover, slide it while securely holding down the area marked 7.
BFormatting a Memory Card
The first time you insert a memory card that has been used in another device into this
camera, make sure to format it with this camera.
•Note that formatting a memory card permanently deletes all images and other
data on the memory card. Be sure to make copies of any images you wish to keep
before formatting the memory card.
•Insert the memory card into the camera, press the d button, and select Format card in
the setup menu (A98).
Applicable Batteries
•Four LR6/L40 (AA-size) alkaline batteries (included batteries*)
•Four FR6/L91 (AA-size) lithium batteries
•Four EN-MH2 Rechargeable Ni-MH (nickel metal hydride) batteries
EN-MH1 Rechargeable Ni-MH batteries cannot be used.
* Although the batteries are described as being “included” in this manual, the batteries may
not be included depending on the country or region in which the camera was purchased.
Inserting the Batteries and Memory Card
12
34
578
6
Memory card slot
12
Getting Started
Inserting the Batteries and Memory Card
BNotes About the Batteries
•Do not combine old and new batteries or batteries of different makes or types.
•Batteries with the following defects cannot be used:
BNotes About EN-MH2 Rechargeable Ni-MH Batteries
When using EN-MH2 batteries with the camera, charge four batteries at a time using MH-73
Battery Charger (A150).
CAlkaline Batteries
Performance of alkaline batteries may vary greatly depending on the brand.
Removing the Batteries or Memory Card
Turn the camera off and make sure that the power-on lamp and screen have turned
off, and then open the battery-chamber/memory card slot cover.
•Gently push the memory card into the camera to partially eject the memory card.
•Be careful when handling the camera, batteries, and memory card immediately
after using the camera, as they may be hot.
Memory Cards and Internal Memory
Camera data, including images and movies, can be saved either on a memory card or
in the camera’s internal memory. To use the camera’s internal memory, remove the
memory card.
Batteries with insulation
that does not cover the
area around the
negative terminal
Batteries with peeling Batteries with a flat
negative terminal
13
Getting Started
Changing the Angle of the Monitor
The angle of the monitor can be lowered down to approx. 85° or raised upward to
approx. 90°.
BNotes About the Monitor
•Do not apply excessive force when changing the angle of the monitor.
•The monitor cannot be moved to the left or right.
•Put the monitor back in the original position when using in normal situations.
Changing the Angle of the Monitor
14
Getting Started
Camera Setup
Setup from a Smartphone or Tablet
•Before proceeding, install the SnapBridge app (Aiii) and enable
Bluetooth and Wi-Fi on your smartphone or tablet (below, “smart
device”).
•The camera and smart device screens shown in this manual may
differ from those of the actual products.
1Turn the camera on.
•Use the multi selector to select and adjust settings.
•A language selection dialog will be displayed. Press
H or I on the multi selector to highlight a
language and press k to select.
•The language can be changed at any time using
the Language option in the setup menu (A98).
2Press k when the dialog at right is
displayed.
•If you do not wish to use a smart device to
configure the camera, press d (A16).
Camera Setup
Multi selector
k button
(apply selection)
RightLeft
Up
Down
Power switch
Cancel
Language
LaterLater Set
Use SnapBridge to send photos to your
smart device and share them online.
To skip this screen and set SnapBridge
later from the Network menu, press
MENU.
15
Getting Started
Camera Setup
3Pair (i.e., establish a Bluetooth link between) the camera and the
smart device.
•Android Devices with NFC Support
After checking that NFC is enabled on the smart
device, touch the camera Y (N-Mark) to the NFC
antenna on the smart device to launch the
SnapBridge app.
- If the SnapBridge download site is displayed,
download and install the app before repeating
the above steps.
•iOS Devices and Android Devices Without
NFC Support
Press the camera k button. The camera will wait
for a connection; launch the SnapBridge app on
the smart device and follow the on-screen
instructions to tap the name of the camera you
want to pair with.
4Check the authentication code.
•After confirming that the camera and smart device
display the same six-digit authentication code,
follow the steps below to complete pairing (note
that the code may not be displayed in some
versions of iOS, but you should follow the steps
below even if the code is not displayed).
-On the camera, press k.
-On the smart device, tap Pairing (the name of
the button varies with the smart device).
CancelCancel
SnapBridge
App
Camera
On your smart device, go to the app
store and search for SnapBridge. After
installing, open the SnapBridge app.
OKOK
Auth. code
000000
CancelCancel
Confirm that the same authentication
code is displayed on the smart device
and press OK.
Camera
16
Getting Started
Camera Setup
5Press k when the dialog at right is
displayed.
•When a constant connection between the camera
and smart device is established, the dialog at right
is displayed.
•If the camera displays Could not connect., press
k to return to Step 3. To cancel pairing settings,
press d.
6Follow the on-screen instructions to complete the setup
process.
•To record location data with photographs, select Yes when prompted and enable
the location data features both in the SnapBridge app and on the smart device itself
(for more information, see the documentation provided with the smart device).
•You can also synchronize the camera clock to the time reported by the smart device
by selecting Yes when prompted and enabling synchronization in the SnapBridge
app. If you select No, set the camera clock from the menus as described in Step 2 on
page 17.
•Setup is complete when the camera returns to the shooting display.
•See page 18 for more information on using SnapBridge.
Setup from the Camera Menus
The camera clock can be set manually.
1Turn the camera on (A14).
•A language selection dialog will be displayed. Press
H or I on the multi selector (A14) to highlight
a language and press k to select.
•The language can be changed at any time using
the Language option in the setup menu (A98).
Next
Your camera and smart device are
connected!
SnapBridge will send your photos to
your smart device as they are taken.
Cancel
Language
17
Getting Started
Camera Setup
2Press d when the dialog
at right is displayed.
•Select Yes when prompted to set
the camera clock.
3Highlight your home time zone and
press k.
•To turn daylight saving time on press H; W will be
displayed at the top of the map. Press I to turn
daylight saving time off.
4Press H or I to choose a date format and press k.
5Enter the current date and time and
press k.
•Press J or K to highlight items and press H or I
to change.
•Press k to set the clock.
6When prompted, press H or I to highlight Yes and press k.
•The camera exits to the shooting display when setup is complete.
CResetting the Clock
The Time zone and date option in the setup menu can be used to choose the time zone
and set the camera clock.
Daylight saving time can be turned on or off in the Time zone menu.
LaterLater Set
Use SnapBridge to send photos to your
smart device and share them online.
To skip this screen and set SnapBridge
later from the Network menu, press
MENU.
Back
London, Casablanca
Edit
Date and time
YMDhm
201601 01 00 00
18
Getting Started
Camera Setup
What SnapBridge Can Do for You
The SnapBridge app can be used for a variety of tasks once the camera
has been paired with your smart device.
Auto Upload
At default settings, pictures will automatically be uploaded to the smart device as they
are taken.
•Place the smart device close to the camera and launch the SnapBridge app.
BNotes About Auto Upload
Movies cannot be uploaded using the Send while shooting or Mark for upload options.
To upload movies to a smart device, use the SnapBridge app.
Option Description
Disabling auto upload
Auto upload can be disabled using the Send while
shooting > Still images option in the camera network
menu (A98).
Upload options
Use the Send while shooting > Upload (photos) item
in the camera network menu to choose the types of
pictures automatically uploaded.
Selecting pictures for upload
You can use this option to automatically upload selected
pictures that were not uploaded during shooting.
•Use the Mark for upload option in the camera
playback menu (A98) to select pictures.
•The constant connection ensures that upload will
continue even when the camera is off.
Resizing pictures for upload
Use the SnapBridge app to choose the size at which
pictures are copied to the smart device. The default size
is 2 megapixels.
Embedding photo info
Use the SnapBridge app to choose the information
imprinted on photographs copied to the smart device.
Comments and copyright information can be entered in
advance from the camera setup menu. You can also
imprint text entered in the SnapBridge app.
19
Getting Started
Camera Setup
Wireless Networks
BWhere the Use of Wireless Devices Is Prohibited
Where the use of wireless devices is prohibited, disable wireless features in the camera
network menu by selecting On for Airplane mode. This will temporarily interrupt the
constant connection with the smart device, but the connection is automatically re-
established when airplane mode is turned off.
Other Options for the SnapBridge App
•See SnapBridge app online help for more information.
Option Description
Pairing
To pair the camera with a smart device (for example, with
a new device or if you did not opt to pair with a smart
device during setup), select Connect to smart device in
the camera network menu and follow the instructions on
page 15, starting with Step 3.
The camera can be paired with up to five smart devices,
but can connect to only one at a time.
Uploading pictures via Wi-Fi
A Wi-Fi connection is recommended for large-volume
uploads.
Follow the on-screen instructions in the SnapBridge app
to switch to a Wi-Fi connection.
•The Wi-Fi > Network settings item in the camera
network menu contains Auth./encryp. and
Password options. The default option for Auth./
encryp. is WPA2-PSK-AES.
Option Description
Remote photography
Use the smart device to release the camera shutter.
Before performing remote photography, turn the camera
on.
Viewing the pictures on the
camera
Use the smart device to view and download the pictures
on the camera. This option is available even when the
camera is off.
20
Basic Shooting and Playback Operations
Basic Shooting and Playback
Operations
Shooting Images...................................................................................................................21
Playing Back Images............................................................................................................24
Deleting Images....................................................................................................................25
21
Basic Shooting and Playback Operations
Shooting Images
A (auto) mode is used here as an example. A (auto) mode enables you to perform
general shooting in a variety of shooting conditions.
1Rotate the mode dial to A.
•Battery level indicator
b: The battery level is high.
B: The battery level is low.
•Number of exposures remaining
C is displayed when no memory card is inserted in
the camera, and images are saved in the internal
memory.
•Press the s (display) button to switch the
information displayed on the screen each time.
2Hold the camera steady.
•Keep fingers and other objects away from the lens, flash, AF-assist illuminator,
microphone, and speaker.
Shooting Images
3200
3200
25m 0s
25m 0s
Battery level indicator
Number of exposures
remaining
22
Basic Shooting and Playback Operations
Shooting Images
3Frame the picture.
•Move the zoom control or the side zoom control to change the zoom lens position.
•If you lose sight of the subject while shooting with the lens in telephoto position,
press the q (snap-back zoom) button to temporarily widen the visible area so that
you can frame the subject more easily.
4Press the shutter-release button
halfway.
•To press the shutter-release button “halfway”
means to press and hold the button at the point
where you feel a slight resistance.
•When the subject is in focus, the focus area or
focus indicator is displayed in green.
•When you are using digital zoom, the camera
focuses in the center of the frame and the focus
area is not displayed.
•If the focus area or focus indicator flashes, the
camera is unable to focus. Modify the composition
and try pressing the shutter-release button halfway
again.
5Without lifting your finger, press the
shutter-release button all the way
down.
BNotes About Saving Images or Movies
The indicator showing the number of exposures remaining or the indicator showing the
remaining recording time flashes while images or movies are being saved. Do not open
the battery-chamber/memory card slot cover or remove the batteries or memory
card while an indicator is flashing. Doing this could result in loss of data, or in damage to the
camera or the memory card.
Zoom out Zoom in
Zoom in
Zoom out
q button
F3
F3
1/250
1/250
Focus area
23
Basic Shooting and Playback Operations
Shooting Images
CThe Auto Off Function
•When no operations are performed for about one minute, the screen turns off, the camera
enters standby mode, and then the power-on lamp flashes. The camera turns off after
remaining in standby mode for about three minutes.
•To turn the screen back on while the camera is in standby mode, perform an operation
such as pressing the power switch or shutter-release button.
CWhen Using a Tripod
•We recommend using a tripod to stabilize the camera in the following situations:
- When the flash is lowered in dark locations or when using a shooting mode in which the
flash does not fire
- When the zoom is at a telephoto position
•When using a tripod to stabilize the camera during shooting, set Photo VR to Off in the
setup menu (A98) to prevent potential errors caused by this function.
Using the Flash
In situations where a flash is needed, such as in dark
locations or when the subject is backlit, press the m (flash
pop-up) button to raise the flash.
•When not using the flash, gently push to lower the flash
until it clicks shut.
Recording Movies
Display the shooting screen and press the b (e
movie-record) button to start recording a movie. Press
the b(e) button again to end recording.
24
Basic Shooting and Playback Operations
Playing Back Images
1Press the c (playback) button to enter
playback mode.
•If you press and hold down the c button while
the camera is turned off, the camera turns on in
playback mode.
2Use the multi selector to select an
image to display.
•Press and hold down HIJK to scroll through
the images quickly.
•Press the s (display) button to switch the
information displayed on the screen each time.
•To play back a recorded movie, press the kbutton.
•To return to shooting mode, press the cbutton
or shutter-release button.
•When e is displayed in full-frame playback
mode, you can press the kbutton to apply an
effect to the image.
•Move the zoom control toward g (i)
in full-frame playback mode to zoom
in on an image.
•In full-frame playback mode, move
the zoom control toward f (h) to
switch to thumbnail playback mode
and display multiple images on the
screen.
Playing Back Images
Display the previous image
Display the next image
4/4
4/4
15/11/2016 15:30
15/11/2016 15:30
0004. JPG
0004. JPG
3.0
3.0
1/20
25
Basic Shooting and Playback Operations
Deleting Images
1Press the l (delete) button to delete
the image currently displayed on the
screen.
2Use the multi selector HI to select the
desired deletion method and press the
kbutton.
•To exit without deleting, press the d button.
3Select Yes and press the kbutton.
•Deleted images cannot be recovered.
BDeleting Images in a Sequence
•Images captured continuously, or with the multiple exp.
lighten, creative mode, or self-collage function, are saved
as a sequence, and only one image in the sequence (the
key picture) is displayed in playback mode (default
setting).
•If you press the l button while a key picture is displayed
for a sequence of images, all images in the sequence are
deleted.
•To delete individual images in a sequence, press the k button to display them one at a
time and press the l button.
CDeleting the Image Captured While in Shooting Mode
When using shooting mode, press the l button to delete the last image that was saved.
Deleting Images
Delete
Current image
Erase selected images
All images
Yes
No
Erase 1 image?
1/51/5
15/11/2016 15:3015/11/2016 15:30
26
Basic Shooting and Playback Operations
Deleting Images
The Image Selection Screen for Deletion
1Use the multi selector JK to select the
image that you want to delete.
•Move the zoom control (A2) toward g (i) to
switch to full-frame playback, or f (h) to switch
to thumbnail playback.
2Use HI to select ON or OFF.
•When ON is selected, an icon is displayed under
the selected image. Repeat steps 1 and 2 to select
additional images.
3Press the kbutton to apply the image selection.
•A confirmation dialog is displayed. Follow the on-screen instructions to operate.
Erase selected images
Back
Erase selected images
Back
27
Shooting Features
Shooting Features
Selecting a Shooting Mode ..............................................................................................28
A (Auto) Mode....................................................................................................................29
Scene Mode (Shooting Suited to the Shooting Conditions) ................................31
Creative Mode (Applying Effects When Shooting) ..................................................41
Smart Portrait Mode (Enhancing Human Faces When Shooting) ......................43
Setting Shooting Functions with the Multi Selector ...............................................46
Flash Mode..............................................................................................................................47
Self-timer.................................................................................................................................49
Macro Mode (Taking Close-up Pictures)......................................................................51
Exposure Compensation (Adjusting Brightness)......................................................52
Using the Zoom ....................................................................................................................53
Focusing ..................................................................................................................................55
Default Settings (Flash, Self-timer, and Macro Mode).............................................59
Functions That Cannot Be Used Simultaneously When Shooting .....................61
28
Shooting Features
Selecting a Shooting Mode
You can rotate the mode dial to align the desired shooting mode with the indicator
mark on the camera body.
•A (Auto) mode
Select this mode to perform general shooting in a variety of shooting conditions.
•y, o, j, e, o, d (Scene) modes
Select any one of scene modes based on the shooting conditions, and you can
take pictures with the appropriate settings for those conditions.
-y: Press the d button and select a scene mode.
-o (scene auto selector): The camera recognizes the shooting conditions when
you frame a picture, and you can take pictures in accordance with the conditions.
-j (night landscape): Use this mode to shoot night landscapes.
-e (night portrait): Use this mode to shoot evening and night portraits that
include background scenery.
-o (backlighting): Use this mode to shoot backlit subjects.
-d (sports): Use this mode to shoot sports photos.
•s (Creative) mode
The camera saves four images with effects and one image without effects
simultaneously in one shot.
•F (Smart portrait) mode
Use glamour retouch to enhance human faces during shooting, and use the smile
timer or self-collage function to take pictures.
•M (Short movie show) mode
The camera creates a short movie that is up to 30 seconds long (e 1080/30p or
S 1080/25p) by recording and automatically combining multiple movie clips
that are several seconds long.
CHelp Display
The descriptions of functions are displayed while changing the shooting mode or while the
setting screen is displayed.
Press the shutter-release button halfway to quickly switch to shooting mode. You can show
or hide the descriptions using Help display in Monitor settings in the setup menu.
Selecting a Shooting Mode
29
Shooting Features
A (Auto) Mode
Select this mode to perform general shooting in a
variety of shooting conditions.
•The focus area for autofocus varies depending on
the setting of AF area mode (A111). The default
setting is Target finding AF (A55).
Functions Available in A (Auto) Mode
•Creative slider (A29)
•Flash mode (A47)
•Self-timer (A49)
•Macro mode (A51)
•Shooting menu (A105, 106)
Using the Creative Slider
You can adjust the brightness (exposure compensation), vividness, hue, and Active
D-Lighting when shooting.
1Press the multi selector K.
2Use JK to select an item.
•F Hue: Adjust the hue (reddish/bluish) of the
entire image.
•G Vividness: Adjust the vividness of the entire
image.
•o Brightness (Exp. +/-): Adjust the brightness of
the entire image.
•J Active D-Lighting: Reduce the loss of details
in highlights and shadows. Select w (High), x (Normal), y (Low) for the
amount of effect.
A (Auto) Mode
Brightness (Exp. +/-)
+2.0
+0.3
-2.0
30
Shooting Features
A (Auto) Mode
3Use HI to adjust the level.
•You can preview the results on the screen.
•To set another item, return to step 2.
•Select y Exit to hide the slider.
•To cancel all settings, select P Reset and press
the k button. Return to step 2 and adjust the
settings again.
4Press the k button when setting is complete.
•The settings are applied and the camera returns to the shooting screen.
CCreative Slider Settings
•This function may not be available to use in combination with other functions (A61).
•The settings for brightness (exposure compensation), vividness, hue, and Active
D-Lighting are saved in the camera’s memory even after the camera is turned off.
•See “Using the Histogram” (A52) for more information.
CActive D-Lighting Versus D-Lighting
•The Active D-Lighting option in the shooting menu captures images while reducing loss
of details in highlights, and adjusts the tone when saving images.
•The D-Lighting (A70) option in the playback menu adjusts the tone of saved images.
Brightness (Exp. +/-)
+2.0
+0.3
-2.0
Slider
Histogram
31
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
Select any one of scene modes based on the shooting conditions, and you can take
pictures with the appropriate settings for those conditions.
1The camera focuses at infinity.
2The camera focuses on the area in the center of the frame.
3Use of a tripod is recommended, because the shutter speed is slow. Set Photo VR
(A135) to Off in the setup menu when using a tripod to stabilize the camera during
shooting.
4When Nightscape + light trails is selected, the camera focuses on the area in the center
of the frame. When Nightscape + star trails or Star trails is selected, the camera
focuses at infinity.
Scene Mode (Shooting Suited to the Shooting Conditions)
j
Night landscape
1, 2 (A32),
e Night portrait (A33),
o Backlighting2 (A33),
d Sports2 (A34)
Rotate the mode dial to j,
e, o, or d and take
pictures.
y
Press the d button to display the scene menu and select one of the following scene
modes using the multi selector.
bPortrait (default setting) kClose-up (A35)
cLandscape1, 2 uFood (A35)
UMultiple exp. Lighten3, 4 (A34) mFireworks show1, 3 (A35)
fParty/indoor2 (A35) VEasy panorama2 (A38)
ZBeach2OPet portrait (A36)
zSnow2LMoon1, 2 (A37)
hSunset2, 3 lBird-watching1, 2 (A37)
iDusk/dawn1, 2, 3
Portrait
Landscape
Multiple exp. Lighten
Party/indoor
Snow
Beach
o (scene auto selector)
(A32)
The camera recognizes the
shooting conditions when you
frame a picture, and you can
take pictures in accordance
with the conditions.
32
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
Tips and Notes About Scene Mode
o Scene auto selector
•The camera automatically recognizes the shooting conditions when you frame a
picture, making it easier to take pictures in accordance with those conditions.
•When the camera automatically recognizes the shooting conditions, the shooting
mode icon displayed on the shooting screen changes accordingly.
* One image is captured at a slow shutter speed.
•Under some shooting conditions, the camera may not select the desired settings. In
this case, select another shooting mode (A28).
•When the digital zoom is in effect, the shooting mode icon changes to d.
j Night landscape
•Press the d button to select YHand-held or ZTripod in Night landscape.
•Y Hand-held (default setting):
-While the j icon on the shooting screen is displayed in green, press the shutter-
release button all the way to capture a series of images which are combined into a
single image and saved.
- Once the shutter-release button is pressed all the way, hold the camera still until a
still image is displayed. After taking a picture, do not turn the camera off before the
screen switches to the shooting screen.
- The angle of view (i.e., the area visible in the frame) seen in the saved image is
narrower than that seen on the shooting screen.
•ZTripod:
- One image is captured at a slow shutter speed when the shutter-release button is
pressed all the way.
- Vibration reduction is disabled even when Photo VR (A135) in the setup menu is
set to On.
ePortrait (for taking close-up portraits of one or two people)
bPortrait (for taking portraits of large numbers of people, or images in which the
background takes up a large portion of the frame)
fLandscape
hNight portrait* (for taking close-up portraits of one or two people)
cNight portrait* (for taking portraits of large numbers of people, or images in which
the background takes up a large portion of the frame)
gNight landscape*
iClose-up
jBacklighting (for taking pictures of subjects other than people)
dBacklighting (for taking portrait pictures)
dOther shooting conditions
33
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
e Night portrait
•Raise the flash before shooting.
•Press the d button to select Y Hand-held or ZTripod in Night portrait.
•Y Hand-held (default setting):
-While the e icon on the shooting screen is displayed in green, press the shutter-
release button all the way to capture a series of images which are combined into a
single image and saved.
- Once the shutter-release button is pressed all the way, hold the camera still until a
still image is displayed. After taking a picture, do not turn the camera off before the
screen switches to the shooting screen.
- If the subject moves while the camera is shooting continuously, the image may be
distorted, overlapped, or blurred.
•Z Tripod:
- One image is captured at a slow shutter speed when the shutter-release button is
pressed all the way.
- Vibration reduction is disabled even when Photo VR (A135) in the setup menu is
set to On.
o Backlighting
•Press the d button to select On or Off to enable or disable the high dynamic range
(HDR) function in HDR based on the shooting conditions.
•Off (default setting): The flash fires to prevent the subject from being hidden in
shadow. Shoot images with the flash raised.
- Press the shutter-release button all the way to capture one image.
•On: Use when taking pictures with very bright and dark areas in the same frame.
- When the shutter-release button is pressed all the way, the camera shoots images
continuously and saves the following two images.
- A non-HDR composite image
- An HDR composite image in which the loss of details in highlights or shadows is
minimized
- If there is only enough memory to save one image, an image processed by D-Lighting
(A70) at the time of shooting, in which dark areas of the image are corrected, is the
only image saved.
- Once the shutter-release button is pressed all the way, hold the camera still until a still
image is displayed. After taking a picture, do not turn the camera off before the screen
switches to the shooting screen.
- The angle of view (i.e., the area visible in the frame) seen in the saved image is
narrower than that seen on the shooting screen.
- Under some shooting conditions, dark shadows may appear around bright subjects
or bright areas may appear around dark subjects.
34
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
dSports
•
While the shutter-release button is held all the way down, images are captured continuously.
•The camera can capture up to about 7 images continuously at a rate of about 7.7 fps
(when Image mode is set to P4608×3456).
•The frame rate for continuous shooting may become slow depending on the current
image mode setting, the memory card used, or shooting conditions.
•Focus, exposure, and hue for the second and subsequent images are fixed at the values
determined with the first image.
y M U Multiple exp. Lighten
•The camera automatically captures moving subjects at regular intervals, compares each
image and composites only their bright areas, and then saves them as one image. Light
trails such as the flow of car lights or motion of stars are captured.
•On the screen displayed when U Multiple exp. Lighten is selected, select
VNightscape + light trails, W Nightscape + star trails, or S Star trails.
•The screen may turn off during the shooting interval. The power-on lamp lights while
the screen is off.
•To end shooting before it automatically ends, press the k button.
•When you have obtained the desired trails, end shooting. If you continue shooting,
details in the composited areas may be lost.
•The images automatically saved during shooting and the image composited when
shooting ends are grouped as a sequence, and the image composited when shooting
ends is used as the key picture (A67).
Option Description
V Nightscape
+ light trails
Use to capture the flow of car lights against a night landscape background.
•Shots are taken at a shutter speed of 4 seconds every 4 seconds.
When 50 shots are taken, the camera automatically stops shooting.
•For every 10 shots taken, one composite image with trails
overlapped from the start of shooting is automatically saved.
W Nightscape
+ star trails
Use to capture the motion of stars with a night landscape in the frame.
•Shots are taken at a shutter speed of 20 seconds every 25 seconds.
When 300 shots are taken, the camera automatically stops shooting.
•For every 30 shots taken, one composite image with trails
overlapped from the start of shooting is automatically saved.
S Star trails
Use to capture the motion of stars.
•Shots are taken at a shutter speed of 25 seconds every 30 seconds.
When 300 shots are taken, the camera automatically stops shooting.
•For every 30 shots taken, one composite image with trails
overlapped from the start of shooting is automatically saved.
35
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
BNotes About Multiple Exp. Lighten
•The camera cannot capture images when a memory card is not inserted.
•Do not rotate the mode dial or insert a new memory card until shooting ends.
•Use batteries with a sufficient amount of charge remaining to prevent the camera from
turning off during shooting.
•Exposure compensation cannot be used (A52).
CTime Remaining
You can check the time remaining until shooting
automatically ends on the screen.
y M f Party/indoor
•To avoid the effects of camera shake, hold the camera steady. Set Photo VR (A135) to
Off in the setup menu when using a tripod to stabilize the camera during shooting.
y M k Close-up
•Macro mode (A51) is enabled and the camera automatically zooms to the closest
position at which it can focus.
•You can move the focus area. Press the k button, use the multi selector HIJK to
move the focus area, and press the k button to apply the setting.
y M u Food
•Macro mode (A51) is enabled and the camera automatically zooms to the closest
position at which it can focus.
•You can adjust hue by using the multi selector HI. The
hue setting is saved in the camera’s memory even after
the camera is turned off.
•You can move the focus area. Press the kbutton, use
the multi selector HIJK to move the focus area, and
press the k button to apply the setting.
y M m Fireworks show
•The shutter speed is fixed at four seconds.
•Exposure compensation cannot be used (A52).
10m 0s10m 0s
End recordingEnd recording
3200
3200
25m 0s
25m 0s
36
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
BPet Portrait Auto Release
•Press the multi selector J (n) to change the Pet portrait auto release setting.
-Y: The camera automatically releases the shutter when it detects a dog or cat face.
-k: The camera does not release the shutter automatically, even if a dog or cat face is
detected. Press the shutter-release button. The camera also detects human faces when
k is selected.
•Pet portrait auto release is set to k after five bursts have been taken.
•Shooting is also possible by pressing the shutter-release button, regardless of the Pet
portrait auto release setting. When V Continuous is selected, you can take pictures
continuously while holding down the shutter-release button all the way.
BFocus Area
•When the camera detects a face, the face is displayed
inside a yellow border. When the camera acquires focus
on a face displayed inside a double border (focus area),
the double border changes to green. If no faces are
detected, the camera focuses on the subject in the
center of the frame.
•Under some shooting conditions, the pet face may not
be detected and other subjects may be displayed inside
a border.
y M O Pet portrait
•When you point the camera at a dog or cat, the camera detects the pet’s face and
focuses on it. By default, the shutter is automatically released when a dog or cat face is
detected (pet portrait auto release).
•On the screen displayed when O Pet portrait is selected, select U Single or
VContinuous.
-U Single: Whenever a dog or cat face is detected, the camera captures one image.
-V Continuous: Whenever a dog or cat face is detected, the camera captures three
images continuously.
32003200
25m 0s25m 0s
37
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
y M L Moon
•At the wide-angle zoom position, the framing border is displayed to indicate the angle
of view equivalent to that of a 900 mm lens (in 35mm [135] format). When you frame the
moon inside the framing border and press the k button, the angle of view becomes
equivalent to that of a 900 mm lens.
•You can adjust hue by using the multi selector HI. The hue setting is saved in the
camera’s memory even after the camera is turned off.
•Adjust the brightness with exposure compensation (A52) according to shooting
conditions such as the waxing and waning of the moon and shooting requirements.
y M l Bird-watching
•On the screen displayed when l Bird-watching is selected, select U Single or
VContinuous.
•U Single: One image is shot each time the shutter-release button is pressed.
•V Continuous (default setting): While the shutter-release button is held all the way
down, images are captured continuously.
The camera can capture up to about 7 images continuously at a rate of about 7.7 fps
(when Image mode is set to P4608×3456).
•At the wide-angle zoom position, the framing border is displayed to indicate the angle
of view equivalent to that of a 440 mm lens (in 35mm [135] format). When you frame a
bird inside the framing border and press the k button, the angle of view becomes
equivalent to that of a 440 mm lens.
38
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
Shooting with Easy Panorama
1Select W Normal or X Wide
as the shooting range and press
the kbutton.
2Frame the first edge of the panorama
scene, and then press the shutter-
release button halfway to focus.
•The zoom position is fixed at wide-angle.
•The camera focuses in the center of the frame.
3Press the shutter-release button all the
way, and then remove your finger from
the shutter-release button.
•KLJI are displayed to indicate the direction of
camera movement.
4Move the camera in one of the four
directions until the guide indicator
reaches the end.
•When the camera detects which direction it is
moving in, shooting begins.
•Shooting ends when the camera captures the
specified shooting range.
•Focus and exposure are locked until shooting
ends.
Rotate the mode dial to y M d button M V (easy panorama) M
kbutton
Easy panorama
Normal
Wide
3200
3200
25m 0s
25m 0s
Guide
39
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
Example of Camera Movement
•Using your body as the axis of rotation, move the camera
slowly in an arc, in the direction of the marking (KLJI).
•Shooting stops if the guide does not reach the edge within
about 15 seconds (when WNormal is selected) or within
about 30 seconds (when X Wide is selected) after
shooting starts.
BNotes About Easy Panorama Shooting
•The range of the image seen in the saved image is narrower than that seen on the screen
at the time of shooting.
•If the camera is moved too quickly or shaken too much, or if the subject is too uniform
(e.g. walls or darkness), an error may occur.
•If shooting is stopped before the camera reaches the half-way point in the panorama
range, a panorama image is not saved.
CImage Size of Easy Panorama
•There are four different image sizes (in pixels), as described below.
When W Normal is set
When X Wide is set
•If more than half of the panorama range is captured but shooting ends before reaching
the edge of the range, the image size becomes smaller.
4800
920
1536
9600
920
1536
40
Shooting Features
Scene Mode (Shooting Suited to the Shooting Conditions)
Playback with Easy Panorama
Switch to playback mode (A24), display an image
captured using easy panorama in full-frame playback
mode, and then press the kbutton to scroll the
image in the direction that was used when shooting.
Playback controls are displayed on the screen during
playback. Use the multi selector JK to select a
control, and then press the k button to perform the
operations described below.
BNotes About Easy Panorama Images
•The images cannot be edited on this camera.
•This camera may not be able to scroll the playback of, or zoom in on, easy panorama
images captured with another make or model of digital camera.
BNotes About Printing Panorama Images
The entire image may not be able to be printed depending on the printer’s settings.
Additionally, printing may not be possible depending on the printer.
Function Icon Description
Rewind AHold down the k button to rewind scroll playback.
Fast-forward BHold down the k button to fast-forward scroll playback.
Pause E
Pause playback. The operations listed below can be performed
while paused.
CHold down the k button to rewind.
DHold down the k button to scroll.
FResume automatic scrolling.
End GReturn to full-frame playback mode.
15/11/2016 15:30
15/11/2016 15:30
4/4
4/4
41
Shooting Features
Creative Mode (Applying Effects When Shooting)
The camera saves four images with effects and one
image without effects simultaneously in one shot.
•The camera focuses in the center of the frame.
1Press the k button.
•The effect selection screen is displayed.
2Use the multi selector HI to select the
desired effect.
•You can select Variety, Selective color (red),
Selective color (green), Selective color (blue),
Light (default setting), Depth, Memory, Classic,
or Noir.
•The image without effects is displayed on the
upper part of the screen. Four types of images with
effects are displayed on the lower part of the screen.
•Only one type of effect can be applied to a movie. Press JK to select the desired
effect.
3Press the shutter-release button or b (e movie-record) button
to shoot.
•The five saved images are treated as a sequence. One image with an applied effect
is used as the key picture (A67).
BNotes About Creative Mode
When Variety is selected as the effect, certain Movie options (A117) are not available.
Creative Mode (Applying Effects When Shooting)
Select eect
Variety
3200
3200
25m 0s
25m 0s
Select eect
Variety
32003200
25m 0s25m 0s
42
Shooting Features
Creative Mode (Applying Effects When Shooting)
Functions Available in Creative Mode
The functions below are available when you press the k button in step 2:
•Flash mode (A47)
•Self-timer (A49)
•Macro mode (A51)
•Exposure compensation (A52)
•Shooting menu (A105)
43
Shooting Features
Smart Portrait Mode (Enhancing Human Faces When Shooting)
You can take a picture with the glamour retouch
function to enhance human faces.
1Press the multi selector K.
2Apply an effect.
•Use JK to select the desired effect.
•Use HI to select the amount of effect.
•You can simultaneously apply multiple effects.
BSkin softening, lFoundation makeup,
QSoft, GVividness, oBrightness (Exp. +/-)
•Select f Exit to hide the slider.
•Press the k button after checking the settings for
all effects.
3Frame the picture and press the shutter-release button.
BNotes About Smart Portrait Mode
•The amount of effect may differ between the image on the shooting screen and the saved
image.
•When Soft is set, some Movie options (A117) are not available.
Functions Available in Smart Portrait Mode
•Smile timer (A44)
•Self-Collage (A45)
•Flash mode (A47)
•Self-timer (A49)
•Smart portrait menu (A115)
Smart Portrait Mode (Enhancing Human Faces
When Shooting)
OFF
1
2
3
4
5
Skin softening
Slider
Effect
44
Shooting Features
Smart Portrait Mode (Enhancing Human Faces When Shooting)
Using Smile Timer
When you press the multi selector J to select a
Smile timer and press the k button, the camera
automatically releases the shutter whenever a smiling
face is detected.
•Set the glamour retouch function before selecting
smile timer (A43).
•When you press the shutter-release button to take a
picture, smile timer is terminated.
BNotes About Smile Timer
Under some shooting conditions, the camera may be unable to detect faces or detect
smiles (A56). The shutter-release button can also be used for shooting.
CWhen the Self-timer Lamp Flashes
When using smile timer, the self-timer lamp flashes when the camera detects a face and
flashes quickly immediately after the shutter is released.
Smile timer
45
Shooting Features
Smart Portrait Mode (Enhancing Human Faces When Shooting)
Using Self-Collage
The camera can capture a series of four or nine images
at intervals and save them as a one-frame image (a
collage image).
1Press the multi selector J to select n
Self-Collage, and press the k button.
•A confirmation dialog is displayed.
•When you press the d button and select Self-
Collage before pressing J, you can configure the
settings for Number of shots, Interval, and
Shutter sound (A115).
•If you want to apply glamour retouch when
shooting, set the effect before selecting self-
collage (A43).
2Take a picture.
•When you press the shutter-release button, a
countdown starts (about five seconds) and the
shutter is automatically released.
•The camera automatically releases the shutter for
the remaining pictures. A countdown starts about
three seconds before shooting.
•The number of shots is indicated by U on the
screen. It is displayed in green during shooting and it changes to white after shooting.
3
On the screen displayed when the camera finishes taking the number of
shots that is set in
Number of shots
, select
Yes
and press the
k
button.
•The collage image is saved.
•Each captured image is saved as an individual image separate from the collage
image. The images are grouped as a sequence, and a one-frame collage image is
used as the key picture (A67).
•When No is selected, the collage image is not saved.
BNotes About Self-Collage
•If you press the shutter-release button before the camera takes the specified number of
shots, shooting is canceled and the collage image is not saved. The pictures that were
taken before shooting was canceled are saved as individual images.
•This function may not be available to use in combination with other functions (A61).
Self-Collage
2
46
Shooting Features
Setting Shooting Functions with the Multi Selector
When the shooting screen is displayed, you can press the multi selector H(m) J(n)
I(p) K(o) to set the functions described below.
•m Flash mode
When the flash is raised, the flash mode can be set according to shooting
conditions.
•n Self-timer
The camera releases the shutter 10 seconds, 5 seconds, or 2 seconds after you press
the shutter-release button.
•p Macro mode
Use macro mode when you take close-up pictures.
•o Exposure compensation
You can adjust overall image brightness.
The functions that can be set vary depending on the shooting mode.
Setting Shooting Functions with the Multi
Selector
47
Shooting Features
Flash Mode
When the flash is raised, the flash mode can be set according to shooting conditions.
1Press the m (flash pop-up) button to raise
the flash.
•When the flash is lowered, flash operation is disabled
and W is displayed.
2Press the multi selector H (X).
3Select the desired flash mode (A48)
and press the k button.
•If the setting is not applied by pressing the
kbutton, the selection will be canceled.
CThe Flash Lamp
•The status of the flash can be confirmed by pressing the
shutter-release button halfway.
- On: The flash fires when you press the shutter-release
button all the way down.
- Flashing: The flash is charging. The camera cannot shoot
images.
- Off: The flash does not fire when a picture is taken.
•If the battery level is low, the screen turns off while the flash is charging.
Flash Mode
Auto
48
Shooting Features
Flash Mode
Available Flash Modes
BNotes About Shooting with the Flash
When using the flash at the wide-angle zoom position, the area around the image may be
dark depending on the distance to the subject.
This may be improved if you move the zoom control slightly toward the telephoto position.
CThe Flash Mode Setting
•The setting may not be available with some shooting modes (A59).
•For A (auto) mode, the applied setting is saved in the camera’s memory even after the
camera is turned off.
CRed-eye Reduction
If the camera detects red-eye while saving an image, the affected area is processed to
reduce red-eye before the image is saved.
Note the following when shooting:
•More time than usual is required to save images.
•Red-eye reduction may not produce the desired results in some situations.
•In rare cases, red-eye reduction may be applied to areas of an image unnecessarily. In
these cases, select another flash mode and take the picture again.
UAuto
The flash fires when necessary, such as in dim lighting.
•The flash mode indicator is only displayed immediately after setting on the
shooting screen.
VAuto with red-eye reduction
Reduce red-eye in portraits caused by the flash.
XFill flash
The flash fires whenever a picture is taken. Use to “fill-in” (illuminate) shadows
and backlit subjects.
YSlow sync
Suited to evening and night portraits that include background scenery. The flash
fires when necessary to illuminate the main subject; slow shutter speeds are
used to capture background at night or under dim lighting.
49
Shooting Features
Self-timer
The camera is equipped with a self-timer that releases the shutter 10 seconds, 5
seconds, or 2 seconds after you press the shutter-release button.
Set Photo VR (A135) to Off in the setup menu when using a tripod to stabilize the
camera during shooting.
1Press the multi selector J (n).
2Select n10s, n2s, or r5s, and press
the kbutton.
•n10s (10 seconds): Use on important occasions,
such as weddings.
•n2s (2 seconds): Use to prevent camera shake.
•r5s (5 seconds) (self-portrait timer): Use for
shooting with a selfie stick. Press the shutter-
release button all the way, and then frame the
picture. After the countdown ends, focus and exposure are set.
•If the setting is not applied by pressing the kbutton, the selection will be
canceled.
•When the shooting mode is Pet portrait scene mode, Y(pet portrait auto release)
is displayed (A36). n10s or n2s cannot be used.
•When the shooting mode is smart portrait mode, you can also use aSmile timer
(A44) and n Self-Collage (A45) in addition to n10s, n2s, or r5s.
3Frame the picture and press the shutter-release button halfway.
•Focus and exposure are set.
Self-timer
Self-timer
50
Shooting Features
Self-timer
4Press the shutter-release button
all the way down.
•Countdown starts. The self-timer lamp
flashes and then glows steadily about
one second before the shutter is
released.
•When the shutter is released, the self-
timer is set to OFF.*
•To stop the countdown, press the
shutter-release button again.
* When the shooting mode is Moon
scene mode, the self-timer is not
automatically set to OFF. To end the
self-timer, select OFF in step 2.
F3
F3
1/250
1/250
9
9
51
Shooting Features
Macro Mode (Taking Close-up Pictures)
Use macro mode when you take close-up pictures.
1Press the multi selector I (p).
2Select ON and press the kbutton.
•If the setting is not applied by pressing the k
button, the selection will be canceled.
3Move the zoom control to set the zoom
ratio to a position where F and the
zoom indicator are displayed in green.
•When the zoom ratio is set to a position where F and the zoom indicator are
displayed in green, the camera can focus on subjects as close as approximately
10 cm (4 in.) from the lens.
•When the zoom position is at the wide-angle and
in the area indicated by 1, the camera can focus
on subjects as close as approximately 1 cm (0.4 in.)
from the lens.
CThe Macro Mode Setting
•The setting may not be available with some shooting modes (A59).
•For A (auto) mode, the applied setting is saved in the camera’s memory even after the
camera is turned off.
Macro Mode (Taking Close-up Pictures)
Macro mode
1
52
Shooting Features
Exposure Compensation (Adjusting Brightness)
You can adjust overall image brightness.
1Press the multi selector K (o).
2Select a compensation value and press
the k button.
•To brighten the image, set a positive (+) value.
•To darken the image, set a negative (–) value.
•The compensation value is applied, even without
pressing the k button.
•When the shooting mode is smart portrait mode,
the glamour retouch screen is displayed instead of
the exposure compensation screen (A43).
•When the shooting mode is A (auto) mode, the
creative slider is displayed instead of the exposure compensation screen (A29).
CExposure Compensation Value
When the shooting mode is Multiple exp. Lighten (A34) or Fireworks show (A35)
scene mode, exposure compensation cannot be used.
CUsing the Histogram
A histogram is a graph showing the distribution of tones in the image. Use as a guide when
using exposure compensation and shooting without the flash.
•The horizontal axis corresponds to pixel brightness, with dark tones to the left and bright
tones to the right. The vertical axis shows the number of pixels.
•Increasing exposure compensation value shifts tone distribution to the right, and
decreasing it shifts tone distribution to the left.
Exposure Compensation (Adjusting Brightness)
Exposure compensation
+2.0
+0.3
-2.0
Histogram
53
Shooting Features
Using the Zoom
When you move the zoom control, the
zoom lens position changes.
•To zoom in: Move toward g
•To zoom out: Move toward f
When you turn the camera on, the
zoom moves to the maximum wide-
angle position.
•Rotating the zoom control all the way in
either direction adjusts the zoom
quickly (except during movie
recording).
•The zoom can also be operated by
moving the side zoom control (A2)
toward g or f.
•A zoom indicator is displayed on the
shooting screen when the zoom
control is moved.
•Digital zoom, which allows you to
further magnify the subject up to
approximately 4× the maximum optical zoom ratio, can be activated by moving
and holding the zoom control or the side zoom control toward g when the
camera is zoomed in to the maximum optical zoom position.
CDigital Zoom
The zoom indicator changes to blue when the digital zoom is activated, and it changes to
yellow when the zoom magnification is increased further.
•Zoom indicator is blue: Image quality is not noticeably reduced by using the Dynamic Fine
Zoom.
•Zoom indicator is yellow: There may be cases in which image quality is noticeably
reduced.
•The indicator remains blue across a wider area when the image size is smaller.
•The zoom indicator may not change to blue when using certain continuous shooting
settings or other settings.
Using the Zoom
Zoom out Zoom in
Zoom out
Zoom in
Optical
zoom
Digital
zoom
54
Shooting Features
Using the Zoom
Using the Snap-back Zoom
If you lose sight of the subject while shooting with the lens in telephoto position,
press the q (snap-back zoom) button to temporarily widen the visible area so that
you can frame the subject more easily.
•While pressing the q button, frame the subject inside the framing border of the
shooting screen. To widen the visible area further, move the zoom control toward
f while pressing the q button.
•Release the q button to return to the original zoom position.
•Snap-back zoom is not available during movie recording.
3200
3200
25m 0s
25m 0s
q button Framing border
55
Shooting Features
Focusing
The Shutter-release Button
Using Target Finding AF
When AF area mode (A111) in A (auto) mode is set to Target finding AF, the
camera focuses in the manner described below when you press the shutter-release
button halfway:
•The camera detects the main subject and focuses
on it. When the subject is in focus, the focus area is
displayed in green. If a human face is detected, the
camera automatically sets focus priority on it.
•If no main subject is detected, the camera
automatically selects one or more of the nine focus
areas containing the subject closest to the camera.
When the subject is in focus, the focus areas that are
in focus are displayed in green.
Focusing
Press halfway
To press the shutter-release button “halfway” means to press
and hold the button at the point where you feel a slight
resistance.
•Focus and exposure (shutter speed and f-number) are set
when you press the shutter-release button halfway. Focus
and exposure remain locked while the button is pressed
halfway.
•The focus area varies depending on the shooting mode.
Press all the
way
To press the shutter-release button “all the way” means to
press the button down completely.
•The shutter is released when the shutter-release button is
pressed all the way.
•Do not use force when pressing the shutter-release
button, as this may result in camera shake and blurred
images. Press the button gently.
1/250
1/250
F3
F3
Focus areas
F3
F3
1/250
1/250
Focus areas
56
Shooting Features
Focusing
BNotes About Target Finding AF
•Depending on shooting conditions, the subject that the camera determines to be the
main subject may vary.
•The main subject may not be detected when using certain White balance settings.
•The camera may not detect the main subject appropriately in the following situations:
- When the subject is very dark or bright
- When the main subject lacks clearly defined colors
- When the shot is framed so that the main subject is on the edge of the screen
- When the main subject is composed of a repeating pattern
Using Face Detection
In the following settings, the camera uses face
detection to automatically focus on human faces.
•o(scene auto selector) mode (A32)
•e (night portrait) or Portrait scene mode (A31)
•Smart portrait mode (A43)
•When AF area mode (A111) in A (auto) mode
(A29) is set to Face priority
If the camera detects more than one face, a double border is displayed around the
face that the camera focuses on, and single borders are displayed around the other
faces.
If the shutter-release button is pressed halfway when no faces are detected:
•In o (scene auto selector) mode, the focus area changes depending on the
shooting conditions that the camera recognizes.
•In e (night portrait) and Portrait scene modes or in smart portrait mode, the
camera focuses in the center of the frame.
•In A (auto) mode, the camera selects the focus area containing the subject
closest to the camera.
BNotes About Face Detection
•The camera’s ability to detect faces depends on a variety of factors, including the direction
in which the faces are looking.
•The camera cannot detect faces in the following situations:
- When faces are partially hidden by sunglasses or otherwise obstructed
- When faces take up too much or too little of the frame
3200
3200
25m 0s
25m 0s
57
Shooting Features
Focusing
Using Skin Softening
In the following shooting modes, if human faces are detected, the camera processes
the image to soften facial skin tones before saving the image (up to three faces).
•Smart portrait mode (A43)
- The amount of Skin softening effect can be adjusted.
•o (scene auto selector) mode (A32)
•e (night portrait) or Portrait in scene mode (A31)
Skin softening can also be applied to saved images by using Glamour retouch in
playback mode (A71).
BNotes About Skin Softening
•It may take more time than usual to save images after shooting.
•Under some shooting conditions, the desired skin softening results may not be achieved,
and skin softening may be applied to areas of the image where there are no faces.
Subjects Not Suitable for Autofocus
The camera may not focus as expected in the following situations. In rare cases, the
subject may not be in focus despite the fact that the focus area or the focus indicator
is displayed in green:
•Subject is very dark
•Objects of sharply differing brightness are included in the shooting conditions (e.g.
the sun behind the subject makes that subject appear very dark)
•No contrast between the subject and surroundings (e.g. a portrait subject wearing
a white shirt is standing in front of a white wall)
•Several objects are at different distances from the camera (e.g. the subject is inside
a cage)
•Subjects with repeating patterns (window blinds, buildings with multiple rows of
similarly shaped windows, etc.)
•Subject is moving rapidly
In the situations noted above, try pressing the shutter-release button halfway to
refocus several times, or focus on another subject positioned at the same distance
from the camera as the actual desired subject, and use focus lock (A58).
58
Shooting Features
Focusing
Focus Lock
Focus lock shooting is recommended when the camera does not activate the focus
area that contains the desired subject.
1Set AF area mode to Center in A (auto) mode (A111).
2Position the subject in the
center of the frame and press
the shutter-release button
halfway.
•The camera focuses on the subject and
the focus area is displayed in green.
•Exposure is also locked.
3Without lifting your finger, recompose
the picture.
•Make sure to maintain the same distance between
the camera and the subject.
4Press the shutter-release button all the
way down to take the picture.
F3
F3
1/250
1/250
F3
F3
1/250
1/250
59
Shooting Features
Default Settings (Flash, Self-timer, and Macro Mode)
The default settings for each shooting mode are listed below.
Default Settings (Flash, Self-timer, and Macro
Mode)
Flash1
(A47)
Self-timer
(A49)
Macro mode
(A51)
A (auto) UOff Off
Scene modes
o (scene auto selector) U2Off Off3
j (night landscape) W4Off5Off4
e (night portrait) V6Off Off4
o (backlighting) X/W7Off Off4
d (sports) W4Off4Off4
b (portrait) VOff Off4
c (landscape) W4Off5Off4
U(multiple exp. lighten) W4n 2s Off4
f (party/indoor) V8Off Off4
Z (beach) UOff Off4
z (snow) UOff Off4
h (sunset) W4Off Off4
i (dusk/dawn) W4Off5Off4
k (close-up) WOff On4
u (food) W4Off On4
m (fireworks show) W4Off4Off4
V (easy panorama) W4Off4Off4
O (pet portrait) W4Y9Off
L(moon) W4n 2s Off4
l(bird-watching) W4Off Off
s (creative mode) UOff Off
F (smart portrait) U10 Off11 Off4
M (short movie show) W4Off Off
60
Shooting Features
Default Settings (Flash, Self-timer, and Macro Mode)
1The setting that is used when the flash is raised.
2The camera automatically selects the flash mode appropriate for the shooting conditions
it has selected. W (off) can be selected manually.
3Cannot be changed. The camera enters macro mode when i is selected.
4Cannot be changed.
5r5s cannot be used.
6Cannot be changed. When set to Hand-held, the flash mode setting is fixed at auto and
slow sync with red-eye reduction. When set to Tripod, the flash mode setting is fixed at
fill flash and slow sync with red-eye reduction.
7Flash is fixed at X (fill flash) when HDR is set to Off. The flash does not fire when HDR is
set to On.
8May switch to slow sync with red-eye reduction flash mode.
9Pet portrait auto release can be set to on or off. n10s or n2s cannot be used.
10 Cannot be used when Blink proof is set to On.
11 a Smile timer (A44) and n Self-Collage (A45) can be used in addition to n10s,
n2s, or r5s.
61
Shooting Features
Functions That Cannot Be Used Simultaneously When Shooting
Some functions cannot be used with other menu settings.
Functions That Cannot Be Used Simultaneously
When Shooting
Restricted
function Setting Description
Flash mode
Continuous (A108) When a setting other than Single is selected,
the flash cannot be used.
Blink proof (A116) When Blink proof is set to On, the flash
cannot be used.
Self-timer AF area mode
(A111)
When Subject tracking is selected, the self-
timer cannot be used.
Macro mode AF area mode
(A111)
When Subject tracking is selected, macro
mode cannot be used.
Image mode Continuous (A108)
Image mode is set as follows depending on
the continuous shooting setting:
•Pre-shooting cache: q (image size: 1600
× 1200 pixels)
•Continuous H: 120 fps: O (image size:
640 × 480 pixels)
•Continuous H: 60 fps: M (image size:
1280 × 960 pixels)
White balance
Hue (using the
creative slider)
(A29)
When hue is adjusted using the creative slider,
White balance in the shooting menu cannot
be set. To set White balance, select P in the
creative slider setting screen to reset the
brightness, vividness, hue, and Active
D-Lighting.
Continuous Self-timer (A49)
If the self-timer is used when Pre-shooting
cache is selected, the setting is fixed at
Single.
ISO sensitivity Continuous (A108)
When Pre-shooting cache, Continuous H:
120 fps, or Continuous H: 60 fps is selected,
ISO sensitivity is fixed at Auto.
AF area mode White balance
(A106)
When a setting other than Auto is selected for
White balance in Target finding AF mode,
the camera does not detect the main subject.
Blink proof Self-Collage (A45) When Self-Collage is selected, Blink proof is
disabled.
62
Shooting Features
Functions That Cannot Be Used Simultaneously When Shooting
BNotes About Digital Zoom
•Depending on the shooting mode or the current settings, digital zoom may not be
available (A136).
•When digital zoom is in effect, the camera focuses in the center of the frame.
Date stamp Continuous (A108)
When Pre-shooting cache, Continuous H:
120 fps, or Continuous H: 60 fps is selected,
date and time cannot be stamped on images.
Digital zoom AF area mode
(A111)
When Subject tracking is selected, digital
zoom cannot be used.
Restricted
function Setting Description
63
Playback Features
Playback Features
Playback Zoom......................................................................................................................64
Thumbnail Playback/Calendar Display.........................................................................65
List by Date Mode ................................................................................................................66
Viewing and Deleting Images in a Sequence.............................................................67
Editing Images (Still Images)............................................................................................69
64
Playback Features
Playback Zoom
Moving the zoom control toward g (i playback zoom)
in full-frame playback mode (A24) zooms in on the
image.
•You can change the magnification rate by moving the zoom control toward f
(h) or g (i).
•To view a different area of the image, press the multi selector HIJK.
•When a zoomed image is displayed, press the k button to return to full-frame
playback mode.
CCropping Images
When a zoomed image is displayed, you can press the d button to crop the image to
include only the visible portion and save it as a separate file (A74).
Playback Zoom
g (i)
4/4
4/4
15/11/2016 15:30
15/11/2016 15:30
0004. JPG
0004. JPG
3.0
3.0
g
(i)
f
(h)
Image is zoomed in.Full-frame Playback
Displayed area
guide
65
Playback Features
Thumbnail Playback/Calendar Display
Moving the zoom control toward f (h thumbnail
playback) in full-frame playback mode (A24) displays
images as thumbnails.
•You can change the number of thumbnails displayed by moving the zoom control
toward f(h) or g (i).
•While using thumbnail playback mode, press the multi selector HIJK to select
an image and then press the k button to display that image in full-frame playback
mode.
•While using calendar display mode, press HIJK to select a date and then press
the kbutton to display the images captured on that day.
BNotes About Calendar Display
Images captured when the camera’s date is not set are treated as images captured on
January 1, 2016.
Thumbnail Playback/Calendar Display
f (h)
1/20
1/20
15/11/2016 15:30
15/11/2016 15:30
0001. JPG
0001. JPG
1/20
Sun Mon Tue Wed Thu Fri Sat
2016 11 1
30
3 0
30
29
2 9
29
26
2 6
2625
2 5
2524
2 4
24
23
2 3
23
22
2 2
22
21
2 1
21
20
2 0
20
19
1 9
1918
1 8
1817
1 7
1716
1 6
1615
1 5
1514
1 4
1413
1 3
13
12
1 2
1211
1 1
1110
1 0
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
28
2 8
28
27
2 7
27
Thumbnail Playback
Full-frame Playback Calendar Display
g
(i)
f
(h)
g
(i)
f
(h)
66
Playback Features
List by Date Mode
Use the multi selector HI to select a date and then
press the k button to play back the images captured
on the selected date.
•Functions in the playback menu (A124) can be
used for the images in the selected shooting date
(except Copy).
•The following operations are available while the
shooting date selection screen is displayed.
-d button: The functions listed below are
available.
•Slide show
•Protect*
* The same settings can be applied to all images captured on the selected date.
-l button: Deletes all images captured on the selected date.
BNotes About List by Date Mode
•Up to the most recent 29 dates can be selected. If images exist for more than 29 dates, all
images saved earlier than the most recent 29 dates will be combined under Others.
•The 9,000 most recent images can be displayed.
•Images captured when the camera’s date is not set are treated as images captured on
January 1, 2016.
List by Date Mode
Press the c button (playback mode) M d button M N menu icon M
CList by date M kbutton
List by date
20/11/2016
15/11/2016
3
1
2
10
05/11/2016
04/11/2016
67
Playback Features
Viewing and Deleting Images in a Sequence
Viewing Images in a Sequence
Images captured continuously, or with the multiple exp. lighten, creative mode, or
self-collage function, are saved as a sequence.
One image in a sequence is used as the key picture to
represent the sequence when displayed in full-frame
playback mode or thumbnail playback mode.
To display each image in the sequence individually,
press the k button.
After pressing the k button, the operations listed
below are available.
•To display the previous or next image, press the
multi selector JK.
•To display images that are not included in the
sequence, press H to return to the key picture
display.
•To display images in a sequence as thumbnails, or to
play them back in a slide show, set Sequence
display options to Individual pictures in the playback menu (A128).
BSequence Display Options
Images captured with cameras other than this camera cannot be displayed as a sequence.
CPlayback Menu Options Available When Using Sequence
•When images in a sequence are displayed in full-frame playback mode, press the d
button to select functions in playback menu (A124).
•If you press the d button when a key picture is displayed, the following settings can be
applied to all images in the sequence:
- Mark for upload, Protect, Copy
Viewing and Deleting Images in a Sequence
1/5
1/5
15/11/2016 15:30
15/11/2016 15:30
1/5
1/5
15/11/2016 15:30
15/11/2016 15:30
BackBack
68
Playback Features
Viewing and Deleting Images in a Sequence
Deleting Images in a Sequence
When the l (delete) button is pressed for images in a sequence, the images that are
deleted vary depending on how the sequences are displayed.
•When the key picture is displayed:
-Current image: All images in the displayed sequence are deleted.
-Erase selected images: When a key picture is selected on the erase selected
images screen (A26), all images in that sequence
are deleted.
-All images: All images on the memory card or in the internal
memory are deleted.
•When images in a sequence are displayed in full-frame playback mode:
-Current image: The image currently displayed is deleted.
-Erase selected images: Images that are selected in the sequence are deleted.
-Entire sequence: All images in the displayed sequence are deleted.
69
Playback Features
Editing Images (Still Images)
Before Editing Images
You can easily edit images on this camera. Edited copies are saved as separate files.
Edited copies are saved with the same shooting date and time as the original.
CRestrictions on Image Editing
•An image can be edited up to 10 times. A still image created by editing a movie can be
edited up to 9 times.
•You may not be able to edit images of a certain size or with certain editing functions.
Quick Effects: Changing Hue or Mood
Process images with a variety of effects.
You can select Painting, Photo illustration, Soft portrait, Background
monochrome portrait, Fisheye, Cross screen, or Miniature effect.
1Display the image to which you want to
apply an effect in full-frame playback
mode and press the k button.
2Use the multi selector HIJK to
select the desired effect and press the
k button.
•Move the zoom control (A2) toward g(i) to
switch to full-frame playback or f(h) to switch
to thumbnail playback.
•To exit without saving the edited image, press the
d button.
3Select Yes and press the k button.
•An edited copy is created.
Editing Images (Still Images)
15/11/2016 15:30
15/11/2016 15:30
0004. JPG
0004. JPG
Quick eects
Cancel Check
Painting Soft portraitPhoto
illustration
Portrait
(color + B&W)
Fisheye Cross screen
70
Playback Features
Editing Images (Still Images)
Quick Retouch: Enhancing Contrast and Saturation
Use the multi selector HI to select the
desired effect level and press the kbutton.
•The edited version is displayed on the right.
•To exit without saving the copy, press J.
D-Lighting: Enhancing Brightness and Contrast
Use the multi selector HI to select OK and
press the k button.
•The edited version is displayed on the right.
•To exit without saving the copy, select Cancel and press
the kbutton.
Press the c button (playback mode) M Select an image M d button M
Quick retouch M k button
Press the c button (playback mode) M Select an image M d button M
D-Lighting M k button
Amount
Quick retouch
Normal
D-Lighting
OK
Cancel
71
Playback Features
Editing Images (Still Images)
Red-eye Correction: Correcting Red-eye When
Shooting with the Flash
Preview the result and press the kbutton.
•To exit without saving the copy, press the multi selector J.
BNotes About Red-eye Correction
•Red-eye correction can only be applied to images when red-eye is detected.
•Red-eye correction can be applied to pets (dogs or cats) even if their eyes are not red.
•Red-eye correction may not produce the desired results in some images.
•In rare cases, red-eye correction may be applied unnecessarily to other areas of the image.
Glamour Retouch: Enhancing Human Faces
1Use the multi selector HIJK to
select the face that you want to retouch
and press the k button.
•When only one face is detected, proceed to step 2.
Press the c button (playback mode) M Select an image M d button M
Red-eye correction M k button
Press the c button (playback mode) M Select an image M d button M
Glamour retouch M k button
Save
Back
Red-eye correction
Back
Subject selection
72
Playback Features
Editing Images (Still Images)
2Use JK to select the effect, use HI to
select the effect level, and press the k
button.
•You can simultaneously apply multiple effects.
Adjust or check the settings for all effects before
pressing the k button.
F Small face, B Skin softening,
lFoundation makeup, m Glare reduction,
E Hide eye bags, A Big eyes, G Whiten eyes, n Eye shadow, o
Mascara, H Whiten teeth, p Lipstick, D Redden cheeks
•Press the d button to return to the screen for selecting a person.
3Preview the result and press the k
button.
•To change the settings, press J to return to step 2.
•To exit without saving the edited image, press the
d button.
4Select Yes and press the kbutton.
•An edited copy is created.
BNotes About Glamour Retouch
•One face can be edited at a time. To apply glamour retouch to another face, edit the
edited image again.
•Depending on the direction in which faces are looking, or the brightness of faces, the
camera may be unable to accurately detect faces, or the glamour retouch function may
not perform as expected.
•If no faces are detected, a warning is displayed and the screen returns to the playback
menu.
•The glamour retouch function is available only for images captured at an ISO sensitivity of
1600 or lower, and the image size of 640 × 480 or larger.
Small face
Back
Preview
Save
Yes
No
Save OK?
73
Playback Features
Editing Images (Still Images)
Small Picture: Reducing the Size of an Image
1Use the multi selector HI to select the
desired copy size and press the
kbutton.
•For images captured at an image mode setting of
l 4608×2592, only 640×360 is displayed, and
for those of s3456×3456, only 480×480 is
displayed.
2Select Yes and press the kbutton.
•An edited copy is created (compression ratio of
approximately 1:8).
Press the c button (playback mode) M Select an image M d button M
Small picture M k button
Small picture
640
×
480
320
×
240
160
×
120
Yes
No
Create small picture le?
74
Playback Features
Editing Images (Still Images)
Crop: Creating a Cropped Copy
1Move the zoom control to enlarge the image (A64).
2Adjust the image so that only the
portion that you want to keep is
displayed, and then press the d
(menu) button.
•Move the zoom control toward g (i) or f(h)
to adjust the magnification rate. Set a
magnification rate at which u is displayed.
•Use the multi selector HIJK to scroll to the portion of the image that you want
to display.
3Confirm the area that you want to keep,
and press the k button.
•To set the area again, press J.
4Select Yes and press the kbutton.
•An edited copy is created.
CImage Size
•The aspect ratio (horizontal to vertical) of the cropped copy is the same as the original.
•When the image size of the cropped copy is 320 × 240 or smaller, the image is displayed at
a smaller size during playback.
3.0
3.0
Trim
Save
Yes
No
Save this image as
displayed?
75
Movies
Movies
Basic Operations of Movie Recording and Movie Playback..................................76
Capturing Still Images While Recording Movies.......................................................79
Short Movie Show Mode (Combining Movie Clips to Create Short Movies)...80
Operations During Movie Playback...............................................................................83
Editing Movies.......................................................................................................................84
76
Movies
Basic Operations of Movie Recording and Movie Playback
1Display the shooting screen.
•Check the remaining amount of movie recording
time.
•It is recommended that you display the movie
frame that indicates the area that will be recorded
in a movie (A77).
2Lower the flash (A23).
•Recording movies while the flash is raised may cause the audio to be muffled.
3Press the b (e movie-record) button
to start movie recording.
•The camera focuses on the subject in the center of
the frame.
•Press the multi selector K to pause recording, and
press K again to resume recording (except when
an HS movie option is selected in Movie options).
Recording automatically ends if it remains paused
for about five minutes.
•
You can capture a still image by pressing the shutter-release button while recording a movie (
A
79).
4Press the b (e movie-record) button again to end recording.
5Select a movie in full-frame playback
mode and press the kbutton to play it
back.
•An image with a movie options icon is a movie.
Basic Operations of Movie Recording and Movie Playback
3200
3200
25m 0s
25m 0s
Remaining movie
recording time
Movie frame
12m30s12m30s
15/11/2016 15:30
15/11/2016 15:30
0010. MP4
0010. MP4
10s
10s
Movie options
77
Movies
Basic Operations of Movie Recording and Movie Playback
Movie Frame
•Press the s button to display the movie frame (A4). Check the range of a
movie in the frame before movie recording.
•The area that is recorded in a movie varies depending on the Movie options or
Movie VR settings in the movie menu.
Maximum Movie Recording Time
Individual movie files cannot exceed 4 GB in size or 29 minutes in length, even when
there is sufficient free space on the memory card for longer recording.
•The remaining recording time for a single movie is displayed on the shooting
screen.
•The actual remaining recording time may vary depending on the movie content,
subject movement, or type of memory card.
•Memory cards with an SD Speed Class rating of 6 or faster are recommended when
recording movies (A168). Movie recording may stop unexpectedly when a
memory card with a lower Speed Class rating is used.
BCamera Temperature
•The camera may become hot when recording movies for an extended period of time or
when the camera is used in a hot area.
•If the inside of the camera becomes extremely hot when recording movies, the camera
will automatically stop recording.
The amount of time remaining until the camera stops recording (B10s) is displayed.
After the camera stops recording, it turns itself off.
Leave the camera off until the inside of the camera has cooled.
78
Movies
Basic Operations of Movie Recording and Movie Playback
Notes About Movie Recording
BNotes About Saving Images or Movies
The indicator showing the number of exposures remaining or the indicator showing the
remaining recording time flashes while images or movies are being saved. Do not open
the battery-chamber/memory card slot cover or remove the batteries or memory
card while an indicator is flashing. Doing this could result in loss of data, or in damage to the
camera or the memory card.
BNotes About Recorded Movies
•When using the camera’s internal memory, saving movies may take some time.
•There may be some degradation in image quality when digital zoom is used.
•The sounds of zoom control operation, zoom, autofocus lens drive movement, vibration
reduction, and aperture operation when brightness changes may be recorded.
•The following phenomena may be seen on the screen while recording movies. These
phenomena are saved in the recorded movies.
- Banding may occur in images under fluorescent, mercury-vapor, or sodium-vapor
lighting.
- Subjects that move quickly from one side of the frame to the other, such as a moving
train or car, may appear skewed.
- The entire movie image may be skewed when the camera is panned.
- Lighting or other bright areas may leave residual images when the camera is moved.
•Depending on the distance to the subject or the amount of zoom applied, colored stripes
may appear on subjects with repeating patterns (fabrics, lattice windows, etc.) during movie
recording and playback. This occurs when the pattern in the subject and the layout of the
image sensor interfere with each other; it is not a malfunction.
BNotes About Vibration Reduction During Movie Recording
•When Movie VR (A122) in the movie menu is set to On (hybrid), the angle of view (i.e.,
the area visible in the frame) becomes narrower during movie recording.
•When using a tripod to stabilize the camera during shooting, set Movie VR to Off to
prevent potential errors caused by this function.
BNotes About Autofocus for Movie Recording
Autofocus may not perform as expected (A57). Should this occur, try the following:
1. Set Autofocus mode in the movie menu to Single AF (default setting) before starting
movie recording.
2. Frame another subject (positioned at the same distance from the camera as the intended
subject) in the center of the frame, press the b (e movie-record) button to start
recording, and modify the composition.
79
Movies
Capturing Still Images While Recording Movies
If the shutter-release button is pressed all the way
while recording a movie, one frame is saved as a still
image. Movie recording continues while the still image
is being saved.
•A still image can be captured when y is displayed
on the screen. When z is displayed, a still image
cannot be captured.
•The size of the captured still image is determined by
the movie image size (A117).
BNotes About Capturing Still Images During Movie Recording
•Still images cannot be saved during movie recording in the following situations:
- When the remaining movie recording time is less than five seconds
- When Movie options (A117) is set to Z 1080/60i, U 1080/50i, g 480/
30p, W480/25p, or HS movie
•The sounds of operating the shutter-release button when saving a still image may be
heard in the recorded movie.
•If the camera moves when the shutter-release button is pressed, the image may be
blurred.
Capturing Still Images While Recording Movies
12m30s
12m30s
80
Movies
Short Movie Show Mode (Combining Movie Clips to Create Short Movies)
The camera creates a short movie that is up to 30
seconds long (e 1080/30p or S 1080/25p) by
recording and automatically combining multiple
movie clips that are several seconds long.
1Press the d (menu) button and
configure the settings for recording
movies.
•
Number of shots
: Set the number of movie clips that
the camera records and the recording time for each
movie clip. By default, the camera records 15 movie
clips that are 2 seconds each to create a 30-second
short movie.
•Special effects (A82): Apply various effects to movies when shooting. Effects can
be changed for each movie clip.
•Background music: Select the background music. You can preview it by moving
the zoom control (A2) toward g (i).
•After the settings are complete, press the d button or shutter-release button to
exit the menu.
2Press the b (e movie-record) button
to record a movie clip.
•The camera automatically stops recording the
movie clip when the time specified in step 1
elapses.
•
Movie clip recording can be paused temporarily.
See “Pausing Movie Recording” (A81).
3Check the recorded movie clip, or
delete it.
•To check it, press the k button.
•To delete it, press the l button. The last recorded
movie clip or all movie clips can be deleted.
•To continue recording movie clips, repeat the
operation in step 2.
•To change the effects, return to step 1.
Short Movie Show Mode (Combining Movie
Clips to Create Short Movies)
Number of shots
Special eects
Background music
End recording
3200
3200
25m 0s
25m 0s
0
15
3200
3200
24m36s
24m36s
12
15
PreviewPreview
Number of movie clips recorded
81
Movies
Short Movie Show Mode (Combining Movie Clips to Create Short Movies)
4Save the short movie show.
•The short movie show is saved when the camera finishes recording the specified
number of movie clips.
•To save a short movie show before the camera finishes recording the specified
number of movie clips, press the d button when the shooting standby screen is
displayed, and then select End recording.
•Movie clips are deleted when a short movie show is saved.
Operations During Movie Clip Playback
To adjust the volume, move the zoom control while a
movie clip is playing (A2).
Playback controls are displayed on the screen.
The operations described below can be performed by
using the multi selector JK to select a control and
then pressing the kbutton.
BNotes About Recording a Short Movie Show
•The camera cannot record movies if a memory card is not inserted.
•Do not exchange the memory card until a short movie show is saved.
CPausing Movie Recording
•A still image (l 4608×2592) can be captured if you press the shutter-release button
when the shooting standby screen is displayed.
•You can pause movie recording and play back images or enter other shooting modes to
take pictures. Movie recording resumes when you enter short movie show mode again.
Function Icon Description
Rewind AHold down the k button to rewind the movie.
Fast-forward BHold down the k button to fast-forward the movie.
Pause E
Pause playback. The operations listed below can be performed
while paused.
CRewind the movie one frame. Hold down the kbutton
for continuous rewinding.
DAdvance the movie one frame. Hold down the
kbutton for continuous advancing.
FResume playback.
End playback GReturn to the shooting screen.
End recording pSave the short movie show using the recorded movie clips.
10s
10s
Playback controls
82
Movies
Short Movie Show Mode (Combining Movie Clips to Create Short Movies)
Functions Available in Short Movie Show Mode
•Self-timer (A49)
•Macro mode (A51)
•Exposure compensation (A52)
•Short movie show menu (A80)
•Movie options menu (A117)
Using Special Effects
Apply effects to images during shooting.
•When Selective color or Cross process is selected,
use the multi selector HI to select the desired
color, and press the k button to apply the color. To
change the color selection, press the k button
again.
Rotate the mode dial to n M d button M n menu icon M Special effects M
k button
Type Description
O Soft Softens the image by adding a slight blur to the entire image.
P Nostalgic sepia Adds a sepia tone and reduces the contrast to simulate the
qualities of an old photograph.
F High-contrast
monochrome Creates a black-and-white photograph with a strong contrast.
I Selective color
Keeps only a selected color and makes other colors black-and-white.
l Pop Increases the color saturation of the entire image to create a
bright look.
o Cross process
Gives the image a mysterious appearance based on a specific color.
m Toy camera effect 1 Gives the entire image a yellowish hue and darkens the image
periphery.
n Toy camera effect 2 Decreases the color saturation of the entire image and darkens
the image periphery.
b Mirror Creates a bilaterally symmetric image whose right half is an
inverted mirror image of the left half.
k Off
(default setting) No effect is applied to the image.
SaveSave
Selective colorSelective color
83
Movies
Operations During Movie Playback
To adjust the volume, move the zoom control while a
movie is playing (A2).
Playback controls are displayed on the screen.
The operations described below can be performed by
using the multi selector JK to select a control and
then pressing the kbutton.
Operations During Movie Playback
Function Icon Description
Rewind AHold down the k button to rewind the movie.
Fast-forward BHold down the k button to fast-forward the movie.
Pause E
Pause playback. The operations listed below can be performed
while paused.
CRewind the movie one frame. Hold down the kbutton
for continuous rewinding.
DAdvance the movie one frame. Hold down the kbutton
for continuous advancing.
IExtract the desired portion of a movie and save it as a
separate file.
HExtract a single frame of a movie and save it as a still
image.
FResume playback.
End GReturn to full-frame playback mode.
Volume indicator
When paused
84
Movies
Editing Movies
Extracting Only the Desired Portion of a Movie
The desired portion of a recorded movie can be saved as a separate file.
1Play back a desired movie and pause at the start point of the
portion that you want to extract (A83).
2Use the multi selector JK to select
the I control, and then press the
kbutton.
3Use HI to select M (choose start
point).
•Use JK to move the start point.
•To cancel editing, select O (back), and press the
kbutton.
4Use HI to select N (choose end
point).
•Use JK to move the end point.
•To preview the specified portion, select G and
then press the k button. Press the kbutton
again to stop previewing.
5Use HI to select m (save) and press
the kbutton.
•Follow the instructions on the screen to save the
movie.
Editing Movies
1m30s1m30s
Choose start point
1m 0s1m 0s
Choose end point
30s
30s
Save
30s
30s
85
Movies
Editing Movies
BNotes About Movie Editing
•Use batteries with a sufficient amount of charge remaining to prevent the camera from
turning off during editing. When the battery level indicator is B, movie editing is not
possible.
•A movie that was created by editing cannot be edited again.
•The actual trimmed portion of a movie may differ slightly from the portion selected using
the start and end points.
•Movies cannot be trimmed so that they are less than two seconds long.
Saving a Frame from a Movie as a Still Image
The desired frame of a recorded movie can be extracted and saved as a still image.
•Pause a movie and display the frame to be extracted
(A83).
•Use the multi selector JK to select the H control
and press the kbutton.
•Select Yes when a confirmation dialog is displayed,
and press the k button to save the image.
•The image quality of the still images to be saved is
normal (compression ratio of approximately 1:8).
The image size is determined by the original movie
image size (A117).
BNotes About Saving Still Images
Still images cannot be saved from movies recorded at Z 1080/60i, U 1080/50i,
g480/30p, W 480/25p, or HS movie (A117).
1m30s
1m30s
Yes
No
Copy this frame as a still image?
86
Connecting the Camera to a TV, Printer, or Computer
Connecting the Camera to a TV,
Printer, or Computer
Utilizing Images ....................................................................................................................87
Viewing Images on a TV.....................................................................................................88
Printing Images Without a Computer...........................................................................90
Transferring Images to a Computer (ViewNX-i) ........................................................94
87
Connecting the Camera to a TV, Printer, or Computer
Utilizing Images
In addition to using the SnapBridge app (Aiii) to enjoy the captured images, you can
also utilize the images in various ways by connecting the camera to the devices
described below.
BNotes About Connecting Cables to the Camera
•Make sure to turn the camera off before connecting or disconnecting cables. Check the
shape and direction of the plugs and do not insert or remove the plugs at an angle.
•Make sure that the remaining battery level is sufficient. If the EH-67/EH-67s AC Adapter
(available separately) is used, this camera can be powered from an electrical outlet. Do
not, under any circumstances, use an AC adapter other than the EH-67/EH-67s. Failure to
observe this precaution could result in overheating or damage to the camera.
•For information about the connection methods and subsequent operations, refer to the
documentation included with the device in addition to this document.
Utilizing Images
Viewing Images on a TV
Images and movies captured with the camera can be viewed on a TV.
Connection method: Connect the video and audio plugs of the optional
audio video cable to the TV’s input jacks. Alternatively, connect a
commercially available HDMI cable to the TV’s HDMI input jack.
Printing Images Without a Computer
If you connect the camera to a PictBridge-compatible printer, you can
print images without using a computer.
Connection method: Connect the camera directly to the printer’s USB
port with the included USB cable.
Transferring Images to a Computer (ViewNX-i)
You can transfer images and movies to a computer for viewing and
editing.
Connection method: Connect the camera to the computer’s USB port
with the USB cable.
•Before connecting to a computer, install ViewNX-i on the computer.
Open the connector
cover.
Insert the plug.
HDMI micro connector (Type D)
USB/audio/video output
connector
88
Connecting the Camera to a TV, Printer, or Computer
Viewing Images on a TV
1Turn off the camera and connect it to the TV.
•Check the shape and direction of the plugs and do not insert or remove the plugs at
an angle.
When using the audio/video cable
When using a commercially available HDMI cable
2Set the TV’s input to external input.
•See the documentation provided with your TV for details.
Viewing Images on a TV
WhiteYellow Red
HDMI micro connector (Type D)
to HDMI jack
89
Connecting the Camera to a TV, Printer, or Computer
Viewing Images on a TV
3Press and hold down the c (playback)
button to turn on the camera.
•Images are displayed on the TV.
•The camera screen does not turn on.
90
Connecting the Camera to a TV, Printer, or Computer
Printing Images Without a Computer
Users of PictBridge-compatible printers can connect the camera directly to the printer
and print images without using a computer.
Connecting the Camera to a Printer
1Turn on the printer.
2Turn off the camera and connect it to the printer using the USB
cable.
•Check the shape and direction of the plugs and do not insert or remove the plugs at
an angle.
3Turn on the camera.
•The PictBridge startup screen (1) is displayed on the camera screen, followed by
the Print selection screen (2).
Printing Images Without a Computer
Print selection
15/11/2016 No. 32 32
12
91
Connecting the Camera to a TV, Printer, or Computer
Printing Images Without a Computer
Printing Images One at a Time
1Use the multi selector JK to select the
desired image and press the k button.
•Move the zoom control toward f (h) to switch
to thumbnail playback or g (i) to switch to full-
frame playback.
2Use HI to select Copies and press the
kbutton.
•Use HI to set the desired number of copies (up
to nine) and press the k button.
3Select Paper size and press the
kbutton.
•Select the desired paper size and press the k
button.
•To print with the paper size setting configured on
the printer, select Default.
•The paper size options available on the camera
vary depending on the printer that you use.
4Select Start print and press the
kbutton.
•Printing starts.
Print selection
15/11/2016 No. 32 32
1
prints
Paper size
Copies
Start print
PictBridge
4
prints
Paper size
Copies
Start print
PictBridge
4
prints
Paper size
Copies
Start print
PictBridge
92
Connecting the Camera to a TV, Printer, or Computer
Printing Images Without a Computer
Printing Multiple Images
1When the Print selection screen is
displayed, press the d (menu)
button.
2Use the multi selector HI to select
Paper size and press the kbutton.
•Select the desired paper size and press the k
button.
•To print with the paper size setting configured on
the printer, select Default.
•The paper size options available on the camera
vary depending on the printer that you use.
•To exit the print menu, press the d button.
3Select Print selection or Print all
images and press the k button.
Print selection
15/11/2016 No. 32 32
Print menu
Paper size
Print all images
Print selection
Print menu
Paper size
Print all images
Print selection
93
Connecting the Camera to a TV, Printer, or Computer
Printing Images Without a Computer
Print selection
Select images (up to 99) and the number of
copies (up to 9) of each.
•Use the multi selector JK to select
images, and use HI to specify the
number of copies to be printed.
•Images selected for printing are
indicated by a and the number of
copies to be printed. To cancel the print
selection, set the number of copies to 0.
•Move the zoom control toward g (i) to switch to full-frame playback or
f (h) to switch to thumbnail playback.
•Press the k button when setting is complete. When the screen for
confirming the number of print copies is displayed, select Start print and
press the k button to start printing.
Print all images
One copy each of all images saved in the internal memory, or on the
memory card, is printed.
•When the screen for confirming the number of print copies is displayed,
select Start print and press the k button to start printing.
11
3
5
Print selection
Back
94
Connecting the Camera to a TV, Printer, or Computer
Transferring Images to a Computer (ViewNX-i)
Installing ViewNX-i
ViewNX-i is free software that enables you to transfer images and movies to your
computer for viewing and editing.
To install ViewNX-i, download the latest version of the ViewNX-i installer from the
following website and follow the on-screen instructions to complete installation.
ViewNX-i: http://downloadcenter.nikonimglib.com
For system requirements and other information, see the Nikon website for your
region.
Transferring Images to a Computer
1Prepare a memory card that contains images.
You can use any of the methods below to transfer images from the memory card to a
computer.
•SD memory card slot/card reader: Insert the memory card into the card slot of
your computer or the card reader (commercially available) that is connected to the
computer.
•
Direct USB connection
: Turn the camera off and ensure that the memory card is
inserted in the camera. Connect the camera to the computer using the USB cable. Turn
the camera on.
To transfer images that are saved in the camera’s internal memory, remove the
memory card from the camera before connecting it to the computer.
Transferring Images to a Computer (ViewNX-i)
95
Connecting the Camera to a TV, Printer, or Computer
Transferring Images to a Computer (ViewNX-i)
If a message is displayed prompting you to choose a program, select Nikon Transfer 2.
•When using Windows 7
If the dialog shown on the right is
displayed, follow the steps below to
select Nikon Transfer 2.
1Under Import pictures and
videos, click Change program. A
program selection dialog will be
displayed; select Nikon Transfer 2
and click OK.
2 Double-click the Nikon Transfer 2 icon.
•When using Windows 10 or Windows 8.1
If the dialog shown on the right is displayed, click
the dialog and then click Import File/Nikon
Transfer 2.
•When using Mac OS X
If Nikon Transfer 2 does not automatically start, launch the Image Capture
application that comes bundled with Mac while the camera and your computer are
connected, and select Nikon Transfer 2 as the default application to open when the
camera is connected to your computer.
If the memory card contains a large number of images, it may take a while for Nikon
Transfer 2 to start. Wait until Nikon Transfer 2 starts.
BNotes About Connecting the USB Cable
Operation is not guaranteed if the camera is connected to the computer via a USB hub.
CUsing ViewNX-i
Consult online help for more information.
96
Connecting the Camera to a TV, Printer, or Computer
Transferring Images to a Computer (ViewNX-i)
2After Nikon Transfer 2 starts, click Start Transfer.
•Image transfer begins. When image transfer is complete, ViewNX-i starts and the
transferred images are displayed.
3Terminate the connection.
•If you are using a card reader or card slot, choose the appropriate option in the
computer operating system to eject the removable disk corresponding to the
memory card and then remove the memory card from the card reader or card slot.
•If the camera is connected to the computer, turn the camera off and disconnect the
USB cable.
Start Transfer
97
Using the Menu
Using the Menu
Menu Operations..................................................................................................................98
Menu Lists ............................................................................................................................101
The Shooting Menu (The Common Shooting Options) ......................................105
The Shooting Menu (for A (Auto) Mode)...............................................................106
The Smart Portrait Menu ................................................................................................115
The Movie Menu................................................................................................................117
The Playback Menu...........................................................................................................124
The Network Menu ...........................................................................................................129
The Setup Menu.................................................................................................................131
98
Using the Menu
Menu Operations
You can set the menus listed below by pressing the d (menu) button.
•A Shooting menu1, 2
•D Movie menu1
•G Playback menu3
•J Network menu
•z Setup menu
1Press the d button when the shooting screen is displayed.
2Menu icons and available setting options vary depending on the shooting mode.
3Press the d button when the playback screen is displayed. Menu icons and available
setting options vary depending on the playback mode.
1Press the d (menu) button.
•The menu is displayed.
2Press the multi selector J.
•The current menu icon is displayed in
yellow.
3Select a menu icon and press
the k button.
•The menu options become
selectable.
Menu Operations
Shooting menu
Image mode
White balance
Continuous
ISO sensitivity
AF area mode
Autofocus mode
Menu icons
Set up
Time zone and date
Monitor settings
Date stamp
Photo VR
AF assist
Digital zoom
99
Using the Menu
Menu Operations
4Select a menu option and
press the k button.
•Certain menu options cannot be set
depending on the current shooting
mode or the state of the camera.
5Select a setting and press the
k button.
•The setting you selected is applied.
•When you are finished using the
menu, press the d button.
•When a menu is displayed, you can
switch to shooting mode by pressing
the shutter-release button or b (e)
button.
Time zone and date
Monitor settings
Date stamp
Photo VR
Digital zoom
AF assist
O
Date stamp
Date and time
Date
100
Using the Menu
Menu Operations
The Image Selection Screen
When an image selection screen such as the one
shown on the right is displayed while operating the
camera menu, follow the procedures described below
to select the images.
1Use the multi selector JK to select the
desired image.
•Move the zoom control (A2) toward g (i) to
switch to full-frame playback or f (h) to switch
to thumbnail playback.
•Only one image can be selected for Rotate
image. Proceed to step 3.
2Use HI to select ON or OFF.
•When ON is selected, an icon is displayed with the
image. Repeat steps 1 and 2 to select additional
images.
3Press the k button to apply the image selection.
•When a confirmation dialog is displayed, follow the on-screen instructions to
operate.
Erase selected images
Back
Erase selected images
Back
Erase selected images
Back
101
Using the Menu
Menu Lists
The Shooting Menu
Common Options
For A (Auto) Mode
For Smart Portrait Mode
Menu Lists
Enter shooting mode M d button
Option Default setting A
Image mode P 4608×3456 105
Option Default setting A
White balance Auto 106
Continuous Single 108
ISO sensitivity Auto 110
AF area mode Target finding AF 111
Autofocus mode Pre-focus 114
Option Default setting A
Self-Collage – 115
Blink proof Off 116
102
Using the Menu
Menu Lists
The Movie Menu
The Playback Menu
1Select an image on the image selection screen. See "The Image Selection Screen"
(A100) for more information.
2Edited images are saved as separate files. Some images may not be edited.
Enter shooting mode M d button M D menu icon M k button
Option Default setting A
Movie options e 1080/30p or S 1080/25p 117
Autofocus mode Single AF 121
Movie VR On (hybrid) 122
Wind noise reduction Off 122
Frame rate – 123
Press the c button (playback mode) M d button
Option A
Mark for upload1124
Quick retouch270
D-Lighting270
Red-eye correction271
Glamour retouch271
Slide show 125
Protect1126
Rotate image1126
Small picture273
Copy1127
Sequence display options 128
103
Using the Menu
Menu Lists
The Network Menu
Press the d button M J menu icon M k button
Option A
Airplane mode 129
Connect to smart device 129
Send while shooting 129
Wi-Fi 129
Bluetooth 129
Restore default settings 129
104
Using the Menu
Menu Lists
The Setup Menu
Press the d button M z menu icon M k button
Option A
Time zone and date 131
Monitor settings 133
Date stamp 134
Photo VR 135
AF assist 135
Digital zoom 136
Sound settings 136
Auto off 137
Format card/Format memory 138
Language 138
Image comment 139
Copyright information 140
Location data 141
Reset all 141
Battery type 142
Conformity marking 142
Firmware version 142
105
Using the Menu
The Shooting Menu (The Common Shooting Options)
Image Mode (Image Size and Quality)
* Image mode can be set in any shooting mode other than short movie show mode. The
setting is also applied to other shooting modes (except Easy panorama scene mode).
Select the combination of image size and compression ratio to be used when saving images.
The higher the image mode setting, the larger the size at which it can be printed, and
the lower the compression ratio, the higher the quality of the images, but the number
of images that can be saved is reduced.
* The numerical values indicate the number of pixels that are captured.
Example: P 4608×3456 = approx. 16 megapixels, 4608 × 3456 pixels
BNotes About Printing Images at 1:1 Aspect Ratio
Change the printer setting to “Border” when printing images at a 1:1 aspect ratio. Some
printers may not be able to print images at a 1:1 aspect ratio.
BNotes About Image Mode
This function may not be available to use in combination with other functions (A61).
CNumber of Images That Can Be Saved
•The approximate number of images that can be saved can be checked on the screen
when shooting (A21).
•Note that due to JPEG compression, the number of images that can be saved may vary
greatly depending on the image content, even when using memory cards with the same
capacity and the same image mode setting. In addition, the number of images that can be
saved may vary depending on the make of the memory card.
•If the number of exposures remaining is 10,000 or more, the number of exposures
remaining display shows “9999.”
The Shooting Menu (The Common Shooting Options)
Enter shooting mode* M d button M Image mode M k button
Option* Compression ratio Aspect ratio
(horizontal to vertical)
Q 4608×3456PApprox. 1:4 4:3
P 4608×3456 (default setting) Approx. 1:8 4:3
R 3264×2448 Approx. 1:8 4:3
r 2272×1704 Approx. 1:8 4:3
q 1600×1200 Approx. 1:8 4:3
O 640×480 Approx. 1:8 4:3
g 4608×2592 Approx. 1:8 16:9
s 3456×3456 Approx. 1:8 1:1
106
Using the Menu
The Shooting Menu (for A (Auto) Mode)
White Balance (Adjusting Hue)
Adjust white balance to suit the light source or weather conditions in order to make
the colors in images match what you see with your eyes.
BNotes About White Balance
•Lower the flash when white balance is set to any setting other than Auto or Flash (A23).
•This function may not be available to use in combination with other functions (A61).
The Shooting Menu (for A (Auto) Mode)
Rotate the mode dial to A M d button M A menu icon M White balance
M k button
Option Description
aAuto (default setting) White balance is automatically adjusted.
bPreset manual Use when the desired result is not achieved with Auto,
Incandescent, etc. (A107).
cDaylight Use under direct sunlight.
dIncandescent Use under incandescent lighting.
eFluorescent Use under fluorescent lighting.
fCloudy Use under overcast skies.
gFlash Use with the flash.
107
Using the Menu
The Shooting Menu (for A (Auto) Mode)
Using Preset Manual
Follow the procedures described below to measure the white balance value under
the lighting used during shooting.
1Place a white or gray reference object under the lighting that
will be used during shooting.
2Use the multi selector HI to select
Preset manual in the White balance
menu, and press the k button.
•The lens extends to the zoom position for
measurement.
3Select Measure.
•To apply the last measured value, select Cancel
and press the k button.
4Frame the white or gray reference
object in the measuring window, and
press the k button to measure the
value.
•The shutter is released and measurement is
complete (no image is saved).
BNotes About Preset Manual
A white balance value for flash lighting cannot be measured with Preset manual. When
shooting using the flash, set White balance to Auto or Flash.
Daylight
Daylight
Incandescent
Incandescent
Fluorescent
Fluorescent
Cloudy
Cloudy
Auto
Auto
Preset manual
White balance
Measure
Cancel
Preset manual
Measure
Cancel
Preset manual
Measuring window
108
Using the Menu
The Shooting Menu (for A (Auto) Mode)
Continuous Shooting
Rotate the mode dial to A M d button M A menu icon M Continuous M
k button
Option Description
USingle
(default setting)
One image is captured each time the shutter-release button is
pressed.
k Continuous H
While the shutter-release button is held all the way down, images
are captured continuously.
•The camera can capture up to about 7 images continuously at a
rate of about 7.7 fps (when image mode is set to
P4608×3456).
m Continuous L
While the shutter-release button is held all the way down, images
are captured continuously.
•The camera can capture up to about 7 images continuously at a
rate of about 2 fps (when image mode is set to
P4608×3456). When you continue to hold the shutter-
release button all the way down, the speed decreases.
q Pre-shooting
cache
Pre-shooting cache shooting begins when the shutter-release
button is pressed halfway. When the shutter-release button is
pressed the rest of the way down, the camera saves the current
image as well as the images captured immediately before the
button is pressed (A109). Pre-shooting cache makes it easy to
capture perfect moments.
•The camera can capture up to about 25 images continuously at
a rate of about 15 fps (including a maximum of 4 images
captured in the pre-shooting cache).
•Image mode is fixed at q (image size: 1600 × 1200 pixels).
n Continuous H:
120 fps
Each time the shutter-release button is pressed all the way down,
images are captured continuously at a high speed rate.
•The camera can capture up to about 50 images continuously at
a rate of about 120 fps.
•Image mode is fixed at O (image size: 640 × 480 pixels).
j Continuous H:
60 fps
Each time the shutter-release button is pressed all the way down,
images are captured continuously at a high speed rate.
•The camera can capture up to about 25 images continuously at
a rate of about 60 fps.
•Image mode is fixed at M (image size: 1280 × 960 pixels).
109
Using the Menu
The Shooting Menu (for A (Auto) Mode)
BNotes About Continuous Shooting
•Focus, exposure and white balance are fixed at the values determined with the first shot in
each series.
•It may take some time to save the images after shooting.
•When ISO sensitivity increases, noise may appear in captured images.
•The frame rate may become slower depending on the current image mode setting,
memory card type or shooting conditions.
•When using Pre-shooting cache, Continuous H: 120 fps, or Continuous H: 60 fps,
banding or variance in brightness or hue may occur in images that were captured under
lighting that flashes quickly at high speeds, such as fluorescent, mercury-vapor, or
sodium-vapor lighting.
•This function may not be available to use in combination with other functions (A61).
CPre-shooting Cache
When the shutter-release button is pressed halfway or all the way down, images are saved
as described below.
•The pre-shooting cache icon (Q) on the shooting screen changes to green while the
shutter-release button is pressed halfway.
Images saved before pressing all the way Images saved by pressing all
the way
Press down halfway Press down all the way
110
Using the Menu
The Shooting Menu (for A (Auto) Mode)
ISO Sensitivity
A higher ISO sensitivity allows darker subjects to be captured. Additionally, even with
subjects of similar brightness, pictures can be taken at faster shutter speeds, and
blurring caused by camera shake and subject movement can be reduced.
•When a higher ISO sensitivity is set, images may contain noise.
BNotes About ISO Sensitivity
This function may not be available to use in combination with other functions (A61).
CISO Sensitivity Display on the Shooting Screen
•When Auto is selected, E is displayed when the ISO sensitivity increases.
•
When
Fixed range auto
is selected, the maximum value for ISO sensitivity is displayed.
Rotate the mode dial to A M d button M A menu icon M ISO sensitivity M
k button
Option Description
a Auto
(default setting)
Sensitivity is automatically selected from the range of
ISO 125 to 1600.
I Fixed range auto
Select the range in which the camera automatically
adjusts ISO sensitivity, from ISO 125-400 or ISO 125-
800.
125, 200, 400, 800, 1600, 3200,
6400 Sensitivity is locked at the specified value.
111
Using the Menu
The Shooting Menu (for A (Auto) Mode)
AF Area Mode
Set how the camera selects the focus area for autofocus.
Rotate the mode dial to A M d button M A menu icon M AF area mode M
k button
Option Description
a Face priority
When the camera detects a
human face, it focuses on that
face. See “Using Face Detection”
(A56) for more information.
When framing a composition
with no human subjects or
detected faces, the camera
automatically selects one or
more of the nine focus areas
containing the subject closest
to the camera when the shutter-
release button is pressed
halfway.
x Manual
Use the multi selector HIJK
to move the focus area to where
you want to focus.
•To use the multi selector to
configure the flash mode or
other settings, press the k
button. To return to moving
the focus area, press the k
button again.
32003200
25m 0s25m 0s
Focus area
F3
F3
1/250
1/250
Focus areas
Focus area
Scope of movable
focus area
112
Using the Menu
The Shooting Menu (for A (Auto) Mode)
BNotes About AF Area Mode
•When digital zoom is in effect, the camera focuses on the area in the center of the frame
regardless of the AF area mode setting.
•This function may not be available to use in combination with other functions (A61).
y Center
The camera focuses on the
subject in the center of the
frame.
s Subject tracking
Use this function to take
pictures of moving subjects.
Register the subject on which
the camera focuses. The focus
area automatically moves to
track the subject.
See “Using Subject Tracking”
(A113) for more information.
M Target finding
AF (default setting)
When the camera detects the
main subject, it focuses on that
subject.
See “Using Target Finding AF”
(A55).
Option Description
3200
3200
25m 0s
25m 0s
Focus area
Start
3200
3200
25m 0s
25m 0s
1/250
1/250
F3
F3
Focus areas
113
Using the Menu
The Shooting Menu (for A (Auto) Mode)
Using Subject Tracking
1Register a subject.
•Align the subject that you want to track with the
border in the center of the frame and press the
kbutton.
•When the subject is registered, a yellow border
(focus area) is displayed around it and the camera
begins tracking the subject.
•If the subject cannot be registered, the border is
displayed in red.
Change the composition and try registering the
subject again.
•To cancel subject registration, press the k button.
•If the camera can no longer track the registered subject, the focus area disappears.
Register the subject again.
2Press the shutter-release button all the
way to take the picture.
•If the shutter-release button is pressed while the
focus area is not displayed, the camera focuses on
the subject in the center of the frame.
BNotes About Subject Tracking
•If you perform operations such as zooming while the camera is tracking the subject, the
registration is canceled.
•Subject tracking may not be possible in certain shooting conditions.
Rotate the mode dial to A M d button M A menu icon M AF area mode M
k button M s Subject tracking M k button M d button
25m 0s
25m 0s
3200
3200
Start
F3
F3
1/250
1/250
114
Using the Menu
The Shooting Menu (for A (Auto) Mode)
Autofocus Mode
Set how the camera focuses when shooting still images.
CAutofocus Mode for Movie Recording
Autofocus mode for movie recording can be set with Autofocus mode (A121) in the
movie menu.
Rotate the mode dial to A M d button M A menu icon M Autofocus mode
M k button
Option Description
ASingle AF The camera focuses only when the shutter-release button is
pressed halfway.
BFull-time AF
The camera always focuses even if the shutter-release button
is not pressed halfway. The sound of lens drive movement is
heard while the camera focuses.
a Pre-focus
(default setting)
Even if the shutter-release button is not pressed halfway, the
camera focuses when subject movement is detected or
when the composition of the framed image is significantly
changed.
115
Using the Menu
The Smart Portrait Menu
•See “Image Mode (Image Size and Quality)” (A105) for information about Image
mode.
Self-Collage
The Smart Portrait Menu
Rotate the mode dial to F M d button M F menu icon M Self-Collage M
k button
Option Description
Number of shots
Set the number of shots that the camera automatically captures
(number of captured images for an aggregated image).
•4 (default setting) or 9 can be selected.
Interval Set the interval time between each shot.
•Short, Medium (default setting), or Long can be selected.
Shutter sound
Set whether to activate the shutter sound when shooting with the
self-collage function.
•Standard, SLR, Magic (default setting), or Off can be selected.
•The same setting that is specified for Shutter sound in Sound
settings in the setup menu is not applied to this setting.
116
Using the Menu
The Smart Portrait Menu
Blink Proof
BNotes About Blink Proof
This function may not be available to use in combination with other functions (A61).
Rotate the mode dial to F M d button M F menu icon M Blink proof M
kbutton
Option Description
y On
The camera automatically releases the
shutter twice with every shot and
saves one image in which the
subject’s eyes are open.
•If the camera saved an image in
which the subject’s eyes may have
been closed, the dialog shown on
the right is displayed for a few
seconds.
•The flash cannot be used.
Off
(default setting) Turns the blink proof off.
A blink was detected in the
picture just taken.
117
Using the Menu
The Movie Menu
Movie Options
Select the desired movie option to record. Select normal speed movie options to
record at normal speed, or HS movie options (A118) to record in slow or fast motion.
The movie options that can be selected vary depending on the Frame rate setting
(A123).
•Memory cards with an SD Speed Class rating of 6 or faster are recommended for
recording movies (A168).
Normal Speed Movie Options
1Interlaced format uses Fields per second.
2The setting is not available when using certain effects in creative mode or glamour
retouch.
The Movie Menu
Enter shooting mode M d button M D menu icon M Movie options M
kbutton
Option
(Image size/Frame rate1,
File format)
Image size Aspect ratio
(horizontal to vertical)
e
S
1080/30p
1080/25p
(default setting)
1920 × 1080 16:9
Z
U
1080/60i2
1080/50i21920 × 1080 16:9
f
V
720/30p
720/25p 1280 × 720 16:9
g
W
480/30p
480/25p 640 × 480 4:3
118
Using the Menu
The Movie Menu
HS Movie Options
Recorded movies are played back in fast or slow motion.
See “Recording Movies in Slow Motion and Fast Motion (HS Movie)” (A120).
1The setting is not available when using certain effects in creative mode or glamour
retouch.
2While recording movies, the camera can be switched between normal speed movie
recording and slow motion or fast motion movie recording.
The maximum recording time shown here refers only to the portion of the movie that is
recorded in slow motion or fast motion.
BNotes About HS Movie
•Sound is not recorded.
•Zoom position, focus, exposure, and white balance are locked when movie recording
starts.
Option
Image size
Aspect ratio
(horizontal to vertical)
Description
h
aHS 480/4×1640 × 480
4:3
1/4-speed slow motion movies
•Max. recording time2: 15 seconds
(playback time: 1 minute)
j
YHS 1080/0.5×11920 × 1080
16:9
2× speed fast motion movies
•Max. recording time2: 2 minutes
(playback time: 1 minute)
119
Using the Menu
The Movie Menu
CPlaying Back in Slow Motion and Fast Motion
When recording at normal speed:
When recording at h/a HS 480/4×:
Movies are recorded at 4× normal speed.
They are played back in slow motion at 4× slower speed.
When recording at j/Y HS 1080/0.5×:
Movies are recorded at 1/2 normal speed.
They are played back in fast motion at 2× faster speed.
Recording
time
Playback
time
10 s
10 s
Recording
time
Playback
time
Slow motion playback
10 s
40 s
Recording
time
Playback
time
Fast motion playback
10 s
5 s
120
Using the Menu
The Movie Menu
Recording Movies in Slow Motion and Fast Motion (HS Movie)
Movies recorded using HS movie can be played back in slow motion at 1/4 of the
normal playback speed, or in fast motion at twice the normal playback speed.
1Use the multi selector HI to select an
HS movie option (A118) and press the
k button.
•After applying the option, press the d button to
return to the shooting screen.
2Press the b (e movie-record) button
to start recording.
•The camera starts recording an HS movie.
•The camera switches between normal speed
movie recording and HS movie recording each
time the k button is pressed.
•The movie options icon changes when switching
between HS movie recording and normal speed
movie recording.
•When the maximum recording time for HS movies (A118) is reached, the camera
automatically switches to normal speed movie recording.
3Press the b (e movie-record) button to end recording.
Enter shooting mode M d button M D menu icon M Movie options M
kbutton
Movie options
1080/30p
1080/60i
720/30p
480/30p
HS 480/4×
HS 1080/0.5×
5 s
5s
121
Using the Menu
The Movie Menu
Autofocus Mode
Set how the camera focuses when recording movies.
CNotes About Autofocus Mode
When an HS movie option is selected in Movie options, the setting is fixed at Single AF.
Enter shooting mode M d button M D menu icon M Autofocus mode M
kbutton
Option Description
A Single AF
(default setting)
Focus is locked when movie recording starts.
Select this option when the distance between the camera and the
subject will remain fairly consistent.
B Full-time AF
The camera focuses continuously.
Select this option when the distance between the camera and
subject will change significantly during recording. The sound of the
camera focusing may be heard in the recorded movie. Use of Single
AF is recommended to prevent the sound of the camera focusing
from interfering with recording.
122
Using the Menu
The Movie Menu
Movie VR
Select the vibration reduction setting used when recording movies.
Set to Off when using a tripod to stabilize the camera during shooting.
BNotes About Movie VR
•When an HS movie option is selected in Movie options, the setting is fixed at Off.
•Vibration reduction may be unable to completely eliminate the effects of camera shake in
some situations.
Wind Noise Reduction
Enter shooting mode M d button M D menu icon M Movie VR M kbutton
Option Description
V On (hybrid)
(default setting)
Performs optical compensation for camera shake using lens shift
VR and simultaneously performs electronic VR using image
processing. The angle of view (i.e., the area seen in the frame)
becomes narrower.
g On Performs compensation for camera shake using lens shift VR.
Off Vibration reduction is disabled.
Enter shooting mode M d button M D menu icon M Wind noise reduction
M k button
Option Description
Y On
Reduces the sound that is produced when wind passes over the
microphone during movie recording. Other sounds may become
difficult to hear during playback.
Off (default setting) Wind noise reduction is disabled.
123
Using the Menu
The Movie Menu
Frame Rate
Select the frame rate (fields per second for the interlaced format) used when
recording movies. When the frame rate setting is switched, options that can be set in
Movie options (A117) change.
Enter shooting mode M d button M D menu icon M Frame rate M
kbutton
Option Description
30 fps (30p/60i) Suited for playback on a TV using the NTSC standard.
25 fps (25p/50i) Suited for playback on a TV using the PAL standard.
124
Using the Menu
The Playback Menu
•See “Editing Images (Still Images)” (A69) for information about image editing
functions.
Mark for Upload
Select images in the camera that you want to transfer to a smart device in advance
before transferring them.
On the image selection screen (A100), select or deselect images for the Mark for
upload function.
•Movies cannot be selected. To upload movies to a smart device, use the
SnapBridge app.
•Note that when you select Reset all (A141) in the setup menu or Restore
default settings (A129) in the network menu, the Mark for upload settings that
you made are canceled.
The Playback Menu
Press the c button (playback mode) M d button M Mark for upload M
kbutton
125
Using the Menu
The Playback Menu
Slide Show
Play back images one by one in an automated “slide show.” When movie files are
played back in the slide show, only the first frame of each movie is displayed.
1Use the multi selector HI to select
Start and press the kbutton.
•The slide show begins.
•To change the interval between images, select
Frame intvl, press the k button, and specify the
desired interval time before selecting Start.
•To repeat the slide show automatically, select
Loop and press the k button before selecting
Start.
•The maximum playback time is up to about 30 minutes even if Loop is enabled.
2End or restart the slide show.
•The screen shown on the right is displayed after
the slide show ends or is paused. To exit the show,
select G and then press the k button. To
resume the slide show, select F and then press
the k button.
Operations During Playback
•Use the multi selector JK to display the previous/next image. Press and hold
down JK to rewind/fast-forward images quickly.
•Press the k button to pause or end the slide show.
Press the c button (playback mode) M d button M Slide show M kbutton
Slide show
Start
Loop
Pause
Frame intvl
126
Using the Menu
The Playback Menu
Protect
The camera protects selected images from accidental deletion.
Select images to protect or cancel protection from the image selection screen
(A100).
Note that formatting the memory card or the camera’s internal memory permanently
deletes all data including protected files (A138).
Rotate Image
Specify the orientation in which saved images are displayed during playback.
Still images can be rotated 90 degrees clockwise or 90 degrees counterclockwise.
Select an image from the image selection screen (A100). When the Rotate image
screen is displayed, press the multi selector JK to rotate the image 90 degrees.
Press the k button to finalize display orientation, and save orientation information
with the image.
Press the c button (playback mode) M d button M Protect M kbutton
Press the c button (playback mode) M d button M Rotate image M
kbutton
Rotate image
Rotate
Back
Rotate image
Rotate
Back
Rotate image
Rotate
Back
Rotate 90 degrees
counterclockwise
Rotate 90 degrees
clockwise
127
Using the Menu
The Playback Menu
Copy (Copy Between the Memory Card and Internal Memory)
Images can be copied between a memory card and the internal memory.
•When a memory card that contains no images is inserted and the camera is
switched to playback mode, Memory contains no images. is displayed. In that
case, press the d button to select Copy.
1Use the multi selector HI to select a
destination option to which images are
copied and press the k button.
2Select a copy option and press the
kbutton.
•When you choose Selected images, use the image
selection screen to specify images (A100).
BNotes About Copying Images
•Only files in formats that this camera can record can be copied.
•Operation is not guaranteed with images captured with another make of camera or that
have been modified on a computer.
CCopying Images in a Sequence
•If you select a key picture of a sequence in Selected images, all images in the sequence
are copied.
•If you press the d button while images in a sequence are displayed, only the Card to
camera copy option is available. All images in the sequence are copied if you select
Current sequence.
Press the c button (playback mode) M d button M Copy M kbutton
Copy
Camera to card
Card to camera
Camera to card
Selected images
All images
128
Using the Menu
The Playback Menu
Sequence Display Options
Select the method used to display images in the sequence (A67).
Settings are applied to all sequences, and the setting is saved in the camera’s memory
even after the camera is turned off.
Press the c button (playback mode) M d button M Sequence display
options M kbutton
Option Description
Q Individual pictures Displays each image in a sequence individually.
F is displayed on the playback screen.
V Key picture only
(default setting) Displays only the key picture for images in a sequence.
129
Using the Menu
The Network Menu
Configure the wireless network settings to connect the camera and a smart device.
* See “Operating the Text Input Keyboard” (A130) for information on how to enter
alphanumeric characters.
The Network Menu
Press the d button M J menu icon M k button
Option Description
Airplane mode Select On to turn off all wireless connections.
Connect to smart device
Select when pairing a smart device with the camera. This
setting cannot be selected while a wireless connection is
established.
See step 3 in “Setup from a Smartphone or Tablet” (A15)
for more information.
Send while shooting Set the conditions for automatically sending images to a
smart device.
Wi-Fi
Network
settings
SSID*: Change the SSID. Set a 1- to 32-character
alphanumeric SSID.
Auth./encryp.: Select whether or not to encrypt the
communications between the camera and the connected
smart device.
Communications are not encrypted when Open is
selected.
Password*: Set the password. Set an 8- to 36-character
alphanumeric password.
Channel: Select the channel used for wireless connections.
Current
settings Display the current settings.
Bluetooth
Connection Select Disable to turn off Bluetooth communication.
Paired
devices
Change the smart device to connect with, or delete the
pairing with the smart device.
Send while
off
Set whether or not to allow the camera to communicate
with the smart device when the camera is off or in standby
mode (A23).
Restore default settings
Restore all network menu settings to their default values.
This setting cannot be selected while a wireless connection
is established.
130
Using the Menu
The Network Menu
Operating the Text Input Keyboard
•Use the multi selector HIJK to select
alphanumeric characters. Press the k button to
enter the selected character in the text field and
move the cursor to the next space.
•To move the cursor in the text field, select N or O
on the keyboard, and press the kbutton.
•To delete one character, press the l button.
•To apply the setting, select P on the keyboard and
press the k button.
Delete
Back
SSID
Text field
Keyboard
131
Using the Menu
The Setup Menu
Time Zone and Date
Set the camera clock.
The Setup Menu
Press the d button M z menu icon M Time zone and date M kbutton
Option Description
Sync with
smart device
Set whether or not to synchronize the date and time setting with a
smart device.
Date and time
Set the date and time if Sync with smart device is set to Off.
•Select a field: Press the multi
selector JK.
•Edit the date and time: Press HI.
•Apply the setting: Select the minute
field setting and press the kbutton.
Date format Select Year/Month/Day, Month/Day/Year, or Day/Month/Year.
Time zone
Set time zone and daylight saving time.
•When Travel destination (x) is set after having set the home time
zone (w), the time difference between the travel destination and the
home time zone is automatically calculated, and the date and time
are saved for the selected region.
Edit
Date and time
YMDhm
01 01 2016 00 00
132
Using the Menu
The Setup Menu
Setting the Time Zone
1Use the multi selector HI to select
Time zone and press the kbutton.
2Select w Home time zone or x Travel
destination and press the k button.
•The date and time displayed on the screen
changes depending on whether the home time
zone or travel destination is selected.
3Press K.
4Use JK to select the time zone.
•Press H to enable daylight saving time function,
and W is displayed. Press I to disable the daylight
saving time function.
•Press the k button to apply the time zone.
•If the correct time is not displayed for the home or
travel destination time zone setting, set the
appropriate time in Date and time.
15/11/2016 15:30
London, Casablanca
Time zone and date
Time zone
Date format
Date and time
Sync with smart device
15/11/2016 15:30
London, Casablanca
Home time zone
Travel destination
Time zone
15/11/2016 15:30
London, Casablanca
Home time zone
Travel destination
Time zone
10:30 –05:00
New York, Toronto, Lima
Back
133
Using the Menu
The Setup Menu
Monitor Settings
Press the d button M z menu icon M Monitor settings M k button
Option Description
Help display
The descriptions of functions are displayed while changing the
shooting mode or while the setting screen is displayed.
•Default setting: On
Image review
Set whether or not to display the captured image immediately after
shooting.
•Default setting: On
Brightness Adjust the brightness.
•Default setting: 3
View/hide
framing grid
Set whether or not to display a boxed guide for framing on the
shooting screen.
•Default setting: Off
134
Using the Menu
The Setup Menu
Date Stamp
The shooting date and time can be stamped on
images when shooting.
BNotes About Date Stamp
•Stamped date and time form a permanent part of image data and cannot be deleted. The
date and time cannot be stamped on images after they have been captured.
•The date and time cannot be stamped in the following situations:
- When the scene mode is set to Night landscape (when set to Y Hand-held), Night
portrait (when set to Y Hand-held), Backlighting (when HDR is set to On), or Easy
panorama
- When the continuous shooting setting (A108) is set to Pre-shooting cache,
Continuous H: 120 fps, or Continuous H: 60 fps
- When recording movies
- When saving still images during movie recording
- When creating still images by editing movies
•The stamped date and time may be difficult to read when using a small image size.
Press the d button M z menu icon M Date stamp M k button
Option Description
fDate Date is stamped on images.
SDate and time Date and time are stamped on images.
Off (default setting) Date and time are not stamped on images.
15.11.2016
15.11.2016
135
Using the Menu
The Setup Menu
Photo VR
Select the vibration reduction setting used when shooting still images.
Set to Off when using a tripod to stabilize the camera during shooting.
BNotes About Photo VR
•After turning on the camera or after switching from playback mode to shooting mode,
wait until the shooting screen is ready before taking pictures.
•Images on the screen may be displayed blurry immediately after shooting.
•Vibration reduction may be unable to completely eliminate the effects of camera shake in
some situations.
AF Assist
Press the d button M z menu icon M Photo VR M k button
Option Description
g On (default setting) Compensation for camera shake is performed using lens shift VR.
Off Compensation is not performed.
Press the d button M z menu icon M AF assist M k button
Option Description
a Auto
(default setting)
The AF-assist illuminator automatically lights up when you press the
shutter-release button under dim lighting. The illuminator has a
range of about 2.0 m (6 ft 6 in.) at the maximum wide-angle position
and about 1.6 m (5 ft 2 in.) at the maximum telephoto position.
•The AF-assist illuminator may not light depending on the position
of the focus area or the shooting mode.
Off The AF-assist illuminator does not light.
136
Using the Menu
The Setup Menu
Digital Zoom
BNotes About Digital Zoom
•Digital zoom cannot be used in the following shooting modes:
-Night landscape, Night portrait, Backlighting (when HDR is set), Portrait, Easy
panorama, or Pet portrait scene mode
-Creative mode
-Smart portrait mode
•Digital zoom cannot be used in other shooting modes when using certain settings
(A62).
Sound Settings
Press the d button M z menu icon M Digital zoom M k button
Option Description
On (default setting) Digital zoom is enabled.
Off Digital zoom is disabled.
Press the d button M z menu icon M Sound settings M k button
Option Description
Button sound
When On (default setting) is selected, the camera produces one
beep when operations are performed, two beeps when focus is
acquired on the subject, and three beeps when an error occurs. The
welcome screen sound is also produced.
•Sounds are disabled when using Pet portrait or Bird-watching
scene mode.
Shutter sound
When On (default setting) is selected, the shutter sound is produced
when the shutter is released.
•The shutter sound is not produced when recording movies or
when using Pet portrait or Bird-watching scene mode.
137
Using the Menu
The Setup Menu
Auto Off
Set the amount of time that elapses before the camera enters standby mode (A23).
You can select 30 s, 1 min (default setting), 5 min, or 30 min.
CSetting the Auto Off Function
The time that passes before the camera enters standby mode is fixed in the following
situations:
•When a menu is displayed: 3 minutes (when auto off is set to 30 s or 1 min)
•When shooting using Pet portrait auto release: 5 minutes (when auto off is set to 30 s
or 1 min)
•When shooting using Smile timer: 5 minutes (when auto off is set to 30 s or
1 min)
•When the audio/video cable is connected: 30 minutes
•When an HDMI cable is connected: 30 minutes
•When the EH-67/EH-67s AC Adapter is connected: 30 minutes
Press the d button M z menu icon M Auto off M k button
138
Using the Menu
The Setup Menu
Format Card/Format Memory
Use this option to format a memory card or the internal memory.
Formatting the memory cards or internal memory permanently deletes all
data. Data that has been deleted cannot be recovered. Make sure to save
important images to a computer before formatting.
Formatting a Memory Card
•Insert a memory card into the camera.
•Select Format card in the setup menu and then press the k button.
Formatting the Internal Memory
•Remove the memory card from the camera.
•Select Format memory in the setup menu and then press the k button.
To start formatting, select Format on the screen that is displayed and press the
kbutton.
•Do not turn the camera off or open the battery-chamber/memory card slot cover
during formatting.
•This setting cannot be selected while a wireless connection is established.
Language
Select a language for display of camera menus and messages.
Press the d button M z menu icon M Format card/Format memory M
kbutton
Press the d button M z menu icon M Language M k button
139
Using the Menu
The Setup Menu
Image Comment
Attach a comment that was previously registered to images that will be captured.
You can imprint the attached comment to images that will be sent to a smart device
using an application (A18).
You can also check with ViewNX-i metadata.
CImage Comments Display
Image comments are not displayed even if images are played back on the camera.
Press the d button M z menu icon M Image comment M k button
Option Description
Attach comment
A comment registered with Input
comment is attached to images.
•Select Attach comment, press K,
and set the check box to on (w).
When you press the k button, the
setting is enabled, and the
comment will be attached to the
images captured afterwards.
Input comment
You can register a comment of up to 36 alphanumeric characters.
•Select Input comment, press K, and the input screen is displayed.
See “Operating the Text Input Keyboard” (A130) for information
about the input method.
Set Conrm
Image comment
Input comment
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
Attach comment
140
Using the Menu
The Setup Menu
Copyright Information
Attach the copyright information that was previously registered to images that will be
captured.
You can imprint the attached copyright information to images that will be sent to a
smart device using an application (A18).
You can also check with ViewNX-i metadata.
BNotes About Copyright Information
•To prevent illegal use of artist names and copyright owner names when lending or
transferring ownership of the camera, make sure to disable the Attach copyright info
setting. Also, make sure that the artist name and copyright owner name are blank.
•Nikon is not responsible for any kind of trouble or damage resulting from the use of
Copyright information.
CCopyright Information Display
Copyright information is not displayed even if images are played back on the camera.
Press the d button M z menu icon M Copyright information M k button
Option Description
Attach copyright
info
Copyright information registered
with Artist and Copyright is
attached to images.
•Select Attach copyright info,
press K, and set the check box to
on (w). When you press the
kbutton, the setting is enabled,
and the copyright information
will be attached to the images
captured afterwards.
Artist
You can register an artist name of up to 36 alphanumeric characters.
•Select Artist, press K, and the input screen is displayed. See
“Operating the Text Input Keyboard” (A130) for information
about the input method.
Copyright
You can register a copyright owner name of up to 54 alphanumeric
characters.
•Select Copyright, press K, and the input screen is displayed. See
“Operating the Text Input Keyboard” (A130) for information
about the input method.
Set Conrm
Copyright information
Artist
Copyright
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
Attach copyright info
141
Using the Menu
The Setup Menu
Location Data
Set whether or not to add shooting location information to the images that you take.
Reset All
When Reset is selected, the camera’s settings are restored to their default values.
•The network menu settings are also restored to their default values.
•Some settings, such as Time zone and date or Language, are not reset.
•This setting cannot be selected while a wireless connection is established.
CResetting File Numbering
To reset file numbering to “0001”, delete all images saved on the memory card or in the
internal memory (A25) before selecting Reset all.
Press the d button M z menu icon M Location data M k button
Option Description
Download from device
Select Yes to add location information from a smart device
to the images that you take. Enable the location information
function of the SnapBridge app.
Position
Display the obtained location information.
•The information is not updated while it is being displayed.
To update it, perform Position again.
Press the d button M z menu icon M Reset all M k button
142
Using the Menu
The Setup Menu
Battery Type
To ensure that the camera shows the correct battery level (A21), select the type that
matches the batteries currently in use.
Conformity Marking
View some of the conformity markings that the camera complies with.
Firmware Version
View the current camera firmware version.
•This setting cannot be selected while a wireless connection is established.
Press the d button M z menu icon M Battery type M k button
Option Description
k Alkaline (default setting) LR6/L40 (AA-size) alkaline batteries
l COOLPIX (Ni-MH) Nikon EN-MH2 Rechargeable Ni-MH (nickel metal
hydride) batteries
m Lithium FR6/L91 (AA-size) lithium batteries
Press the d button M z menu icon M Conformity marking M kbutton
Press the d button M z menu icon M Firmware version M k button
143
Technical Notes
Technical Notes
Notices...................................................................................................................................144
Notes About Wireless Communication Functions ................................................146
Caring for the Product.....................................................................................................149
The Camera.................................................................................................................149
Batteries .......................................................................................................................150
Memory Cards............................................................................................................151
Cleaning and Storage ......................................................................................................152
Cleaning .......................................................................................................................152
Storage .........................................................................................................................152
Error Messages ................................................................................................................... 153
Troubleshooting................................................................................................................156
File Names............................................................................................................................ 162
Optional Accessories........................................................................................................163
Specifications......................................................................................................................164
Memory Cards That Can Be Used........................................................................168
Index ......................................................................................................................................170
144
Technical Notes
Notices
Notices for Customers in the U.S.A.
Federal Communications Commission (FCC) Radio Frequency Interference
Statement
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/television technician for help.
CAUTIONS
Modifications
The FCC requires the user to be notified that any changes or modifications made to
this device that are not expressly approved by Nikon Corporation may void the user’s
authority to operate the equipment.
Interface Cables
Use the interface cables sold or provided by Nikon for your equipment. Using other
interface cables may exceed the limits of Class B Part 15 of the FCC rules.
Notices
145
Technical Notes
Notices
Notice for Customers in the State of California
WARNING
Handling the cord on this product will expose you to lead, a chemical known to the
State of California to cause birth defects or other reproductive harm.
Wash hands after handling.
Nikon Inc.,
1300 Walt Whitman Road, Melville, New York 11747-3064, U.S.A.
Tel: 631-547-4200
Notice for Customers in Canada
CAN ICES-3 B / NMB-3 B
Notices for Customers in Europe
This symbol indicates that electrical and electronic equipment is to be
collected separately.
The following apply only to users in European countries:
•This product is designated for separate collection at an appropriate
collection point. Do not dispose of as household waste.
•Separate collection and recycling helps conserve natural resources and
prevent negative consequences for human health and the environment that might
result from incorrect disposal.
•For more information, contact the retailer or the local authorities in charge of waste
management.
This symbol on the batteries indicates that the batteries are to be collected
separately.
The following apply only to users in European countries:
•All batteries, whether marked with this symbol or not, are designated
for separate collection at an appropriate collection point. Do not
dispose of as household waste.
•For more information, contact the retailer or the local authorities in charge of waste
management.
146
Technical Notes
Notes About Wireless Communication Functions
Restrictions on Wireless Devices
The wireless transceiver included in this product conforms to wireless regulations in
the country of sale and is not for use in other countries (products purchased in the EU
or EFTA can be used anywhere within the EU and EFTA). Nikon does not accept
liability for use in other countries. Users who are unsure as to the original country of
sale should consult with their local Nikon service center or Nikon-authorized service
representative. This restriction applies to wireless operation only and not to any other
use of the product.
Security
Although one of the benefits of this product is that it allows others to freely connect
for the wireless exchange of data anywhere within its range, the following may occur
if security is not enabled:
•Data theft: Malicious third-parties may intercept wireless transmissions to steal user
IDs, passwords, and other personal information.
•Unauthorized access: Unauthorized users may gain access to the network and alter
data or perform other malicious actions. Note that due to the design of wireless
networks, specialized attacks may allow unauthorized access even when security is
enabled. Nikon is not responsible for data or information leaks that may occur
during data transfer.
•Do not access networks that you are not permitted to use, even if they are
displayed on your smartphone or tablet. Doing so may be regarded as
unauthorized access. Only access networks that you are permitted to use.
Personal Information Management and Disclaimer
•User information registered and configured on the product, including wireless LAN
connection settings and other personal information, is susceptible to alteration
and loss resulting from operational error, static electricity, accident, malfunction,
repair or other handling. Always keep separate copies of important information.
Nikon is not responsible for any direct or indirect damages or lost profits resulting
from alteration or loss of content that is not attributable to Nikon.
•Before discarding this product or transferring it to another owner, perform Reset
all in the setup menu (A98) to delete all user information registered and
configured with the product, including wireless LAN connection settings and other
personal information.
•Nikon is not responsible for any damages resulting from unauthorized use of this
product by third parties in the event that the product is stolen or lost.
Notes About Wireless Communication
Functions
147
Technical Notes
Notes About Wireless Communication Functions
Precautions when Exporting or Carrying This Product Abroad
This product is controlled by the United States Export Administration Regulations
(EAR). The permission of the United States government is not required for export to
countries other than the following, which as of this writing are subject to embargo or
special controls: Cuba, Iran, North Korea, Sudan, and Syria (list subject to change).
Notice for Customers in the U.S.A. and Canada
Federal Communications Commission (FCC) and Industry of Canada (IC)
Declaration of Conformity
This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of this device.
FCC/IC RF Exposure Statement
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
The available scientific evidence does not show that any health problems are
associated with using low power wireless devices. There is no proof, however, that
these low power wireless devices are absolutely safe. Low power wireless devices
emit low levels of radio frequency energy (RF) in the microwave range while being
used. Whereas high levels of RF can produce health effects (by heating tissue),
exposure of low-level RF that does not produce heating effects causes no known
adverse health effects. Many studies of low-level RF exposures have not found any
biological effects. Some studies have suggested that some biological effects might
occur, but such findings have not been confirmed by additional research.
COOLPIX B500, which is equipped with a LBEE5ZZ1GV-893 (FCC ID:2AAD3JA0M0P0 /
IC ID:4634A-6152EC) Wireless LAN Module, has been tested and found to comply with
FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-
102 of the IC radio frequency (RF) Exposure rules. Please refer to the SAR test report
that was uploaded to FCC website.
Notice for Customers in Europe
Declaration of Conformity (Europe)
Hereby, Nikon Corporation, declares that COOLPIX B500 is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC. The
declaration of conformity may be consulted at
http://imaging.nikon.com/support/pdf/DoC_B500.pdf.
148
Technical Notes
Notes About Wireless Communication Functions
Notice for Customers in Singapore
This device complies with radio-frequency regulations.
Notice for Customers in Jamaica
This product contains a Type Approved Module by Jamaica: “SMA – LBEE5ZZ1GV-893”
Complies with
IDA Standards
DA103423
149
Technical Notes
Caring for the Product
Observe the precautions described below in addition to the warnings in “For Your
Safety” (Aviii–xi) when using or storing the device.
The Camera
Do Not Apply Strong Impact to the Camera
The product may malfunction if subjected to strong shock or vibration. In addition, do not
touch or apply force to the lens.
Keep Dry
The device will be damaged if immersed in water or subjected to high humidity.
Avoid Sudden Changes in Temperature
Sudden changes in temperature, such as when entering or leaving a heated building on a
cold day, can cause condensation to form inside the device. To prevent condensation, place
the device in a carrying case or a plastic bag before exposing it to sudden changes in
temperature.
Keep Away from Strong Magnetic Fields
Do not use or store this device in the vicinity of equipment that generates strong
electromagnetic radiation or magnetic fields. Doing so could result in loss of data or camera
malfunction.
Do Not Point the Lens at Strong Light Sources for Extended Periods
Avoid pointing the lens at the sun or other strong light sources for extended periods when
using or storing the camera. Intense light may cause the image sensor to deteriorate or
produce a white blur effect in photographs.
Turn the Product Off Before Removing or Disconnecting the Power Source or
Memory Card
Do not remove the batteries while the product is on, or while images are being saved or
deleted. Forcibly cutting power in these circumstances could result in loss of data or in
damage to the memory card or internal circuitry.
Notes About the Monitor
•Monitors (including electronic viewfinders) are constructed with extremely high precision;
at least 99.99% of pixels are effective, with no more than 0.01% being missing or defective.
Hence while these displays may contain pixels that are always lit (white, red, blue, or
green) or always off (black), this is not a malfunction and has no effect on images recorded
with the device.
•Images in the monitor may be difficult to see under bright lighting.
•Do not apply pressure to the monitor, as this could cause damage or malfunction. Should
the monitor break, care should be taken to avoid injury caused by broken glass and to
prevent the liquid crystal from the display touching the skin or entering the eyes or
mouth.
Caring for the Product
150
Technical Notes
Caring for the Product
Batteries
Precautions for Use
•Note that the batteries may become hot after use.
•Do not use batteries beyond their recommended expiration date.
•Do not turn the camera on and off repeatedly if discharged batteries are inserted in the
camera.
Carrying Spare Batteries
We recommend carrying spare batteries depending on where you are shooting. It may be
difficult to purchase batteries in certain areas.
Charging Batteries
If using optional rechargeable batteries, charge the batteries before taking pictures. Batteries
are not fully charged at the time of purchase.
Be sure to read and follow the warnings noted in the operating instructions included with
the battery charger.
Charging Rechargeable Batteries
•Do not mix batteries with different amounts of charge remaining, or batteries of a
different make or model.
•When using EN-MH2 batteries with this camera, charge four batteries at a time using MH-73
Battery Charger. Use only MH-73 Battery Charger to charge EN-MH2 batteries.
•When using MH-73 Battery Charger, only charge EN-MH2 batteries.
•EN-MH1 Rechargeable Ni-MH batteries cannot be used.
Notes About Rechargeable Ni-MH Batteries
•If you repeatedly charge rechargeable Ni-MH batteries while they still have some charge
remaining, the message Battery exhausted. may be displayed prematurely when using
the batteries. This is due to the “memory effect,” in which the amount of charge the
batteries can hold decreases temporarily. Use the batteries until there is no charge
remaining and they will return to their normal behavior.
•Rechargeable Ni-MH batteries discharge even when not being used. We recommend
charging the batteries just before using them.
Using the Batteries When Cold
On cold days, the capacity of batteries tends to decrease. If exhausted batteries are used at a
low temperature, the camera may not turn on. Keep spare batteries in a warm place and
exchange as necessary. Once warmed, cold batteries may recover some of their charge.
Battery Terminals
Dirt on the battery terminals may prevent the camera from functioning. Should the battery
terminals become dirty, wipe them off with a clean, dry cloth before use.
Remaining Battery Charge
If you insert discharged batteries into the camera, the camera may indicate that the batteries
have adequate charge remaining. This is a characteristic of batteries.
151
Technical Notes
Caring for the Product
Recycling Used Batteries
Replace the batteries when they no longer hold a charge. Used batteries are a valuable
resource. Please recycle used batteries in accordance with local regulations.
Memory Cards
Precautions for Use
•Use only Secure Digital memory cards (A168).
•Be sure to follow the precautions described in the documentation included with the
memory card.
•Do not put labels or stickers on memory cards.
Formatting
•Do not format the memory card using a computer.
•The first time you insert a memory card that has been used in another device into this
camera, be sure to format it with this camera. We recommend formatting new memory
cards with this camera before using them with this camera.
•Note that formatting a memory card permanently deletes all images and other
data on the memory card. Be sure to make copies of any images you wish to keep
before formatting the memory card.
•If the message Card is not formatted. Format card? is displayed when the camera is
turned on, the memory card must be formatted. If there is data that you do not want to
delete, select No. Copy the necessary data to a computer, etc. If you want to format the
memory card, select Yes. The confirmation dialog will be displayed. To start formatting,
press the k button.
•Do not perform the following during formatting, while data is being written to or deleted
from the memory card, or during data transfer to a computer. Failure to observe this
precaution could result in the loss of data or in damage to the camera or memory card:
- Open the battery-chamber/memory card slot cover to remove/insert the batteries or
memory card.
-Turn off the camera.
- Disconnect the AC adapter.
152
Technical Notes
Cleaning and Storage
Cleaning
Do not use alcohol, thinner, or other volatile chemicals.
Storage
Remove the batteries if the camera will not be used for an extended period. To
prevent mold or mildew, take the camera out of storage at least once a month.
Turn the camera on and release the shutter a few times before putting the camera
away again. Do not store the camera in any of the following locations:
•Places that are poorly ventilated or subject to humidity of over 60%
•Exposed to temperatures above 50°C (122°F) or below –10°C (14°F)
•Next to equipment that produces strong electromagnetic fields, such as televisions
or radios
Cleaning and Storage
Lens
Avoid touching glass parts with your fingers. Remove dust or lint with a
blower (typically a small device with a rubber bulb attached to one end that
is pumped to produce a stream of air out the other end). To remove
fingerprints or other stains that cannot be removed with a blower, wipe the
lens with a soft cloth, using a spiral motion that starts at the center of the
lens and working toward the edges. If this fails, clean the lens using a cloth
lightly dampened with commercial lens cleaner.
Monitor Remove dust or lint with a blower. To remove fingerprints and other stains,
clean the monitor with a soft, dry cloth, being careful not to apply pressure.
Body
Use a blower to remove dust, dirt, or sand, then wipe gently with a soft, dry
cloth. After using the camera at the beach or other sandy or dusty
environment, wipe off any sand, dust, or salt with a dry cloth lightly
dampened with fresh water and dry thoroughly. Note that foreign matter
inside the camera could cause damage not covered by the warranty.
153
Technical Notes
Error Messages
Refer to the table below if an error message is displayed.
Error Messages
Display Cause/Solution A
Battery temperature is
elevated. The camera
will turn off. The camera turns off automatically. Wait until the
camera or battery temperature has cooled before
resuming use.
–
The camera will turn off
to prevent overheating.
Memory card is write
protected.
The write-protect switch is in the “lock” position.
Slide the write-protect switch to the “write” position. –
This card cannot be
used. An error occurred while accessing the memory card.
•Use an approved memory card.
•Check that the terminals are clean.
•Confirm that the memory card is correctly inserted.
11, 168
This card cannot be
read.
Card is not formatted.
Format card?
The memory card has not been formatted for use in
the camera.
Formatting deletes all data saved on the memory
card. If you need to keep copies of any images, make
sure to select No and save the copies to a computer
or other medium before formatting the memory
card. Select Yes and press the kbutton to format
the memory card.
151
Out of memory. Delete images or insert a new memory card. 11, 25
Image cannot be saved.
An error occurred while saving the image.
Insert a new memory card or format the memory
card or internal memory.
138
The camera has run out of file numbers.
Insert a new memory card or format the memory
card or internal memory.
138
There is insufficient space to save the copy.
Delete images from the destination. 25
Image cannot be
modified. Check that the images can be edited. 69, 160
154
Technical Notes
Error Messages
Cannot record movie.
A time-out error occurred while saving the movie on
the memory card.
Select a memory card with a faster write speed.
77, 168
Memory contains no
images.
There are no images in the internal memory or on
the memory card.
•Remove the memory card to play back images in
the internal memory.
•To copy the images saved in the camera’s internal
memory to the memory card, press the d
button to select Copy in the playback menu.
12
127
File contains no image
data.
The file was not created or edited with this camera.
The file cannot be viewed on this camera.
View the file using a computer or the device used to
create or edit this file.
–
All images are hidden. There are no images available for a slide show, etc. 125
This image cannot be
deleted.
The image is protected.
Disable protection. 126
Raise the flash.
The flash is lowered.
Raise the flash when shooting in Night portrait or
Backlighting (when HDR is set to Off) scene mode.
33, 47
Turn the camera off and
then on again.
Remove the lens cap.
If the error persists, contact your retailer or Nikon-
authorized service representative.
10, 156
Communications error
An error occurred while communicating with the
printer.
Turn the camera off and reconnect the USB cable.
90
System error
An error occurred in the camera’s internal circuitry.
Turn the camera off, remove and reinsert the
batteries, and turn the camera on. If the error persists,
contact your retailer or Nikon-authorized service
representative.
156
Printer error: check
printer status.
After solving the problem, select Resume and press
the kbutton to resume printing.* –
Printer error: check
paper.
Load the specified size of paper, select Resume, and
press the k button to resume printing.* –
Printer error: paper jam. Remove the jammed paper, select Resume, and
press the kbutton to resume printing.* –
Printer error: out of
paper.
Load the specified size of paper, select Resume, and
press the k button to resume printing.* –
Display Cause/Solution A
155
Technical Notes
Error Messages
* See the documentation provided with your printer for further guidance and information.
Printer error: check ink.
There is a problem with the printer’s ink.
Check the ink, select Resume, and press the k
button to resume printing.*
–
Printer error: out of ink. Replace the ink cartridge, select Resume, and press
the kbutton to resume printing.* –
Printer error: file corrupt.
There is a problem with the image file to be printed.
Select Cancel and press the k button to cancel
printing.
–
Display Cause/Solution A
156
Technical Notes
Troubleshooting
If the camera fails to function as expected, check the list of common problems below
before consulting your retailer or Nikon-authorized service representative.
Power, Display, Settings Issues
Troubleshooting
Problem Cause/Solution A
The camera is on
but does not
respond.
•Wait for recording to end.
•If the problem persists, turn the camera off.
If the camera does not turn off, remove and reinsert the
battery or batteries or, if you are using an AC adapter,
disconnect and reconnect the AC adapter.
Note that although any data currently being recorded
will be lost, data that have already been recorded will
not be affected by removing or disconnecting the
power source.
–
The camera cannot
be turned on.
The batteries are exhausted. 11, 150
The camera turns
off without
warning.
•The camera automatically turns off to save power (auto
off function).
•The camera and batteries may not work properly at low
temperatures.
•The inside of the camera has become hot. Leave the
camera off until the inside of the camera has cooled, and
then try turning it on again.
23
150
–
The monitor is
blank.
•The camera is off.
•The camera automatically turns off to save power (auto
off function).
•The flash lamp flashes while the flash is charging. Wait
until charging is complete.
•The camera is connected to a TV or computer.
•The camera is shooting in Multiple exp. Lighten scene
mode.
14
23
–
–
–
The camera
becomes hot.
The camera may become hot when used for an extended
period of time such as to shoot movies, or when used in a
hot environment; this is not a malfunction.
–
The monitor is
hard to see.
•The surroundings are too bright.
- Move to a darker place.
•Adjust the screen brightness.
–
133
157
Technical Notes
Troubleshooting
Shooting Issues
O flashes on the
screen.
•If the camera clock has not been set, O flashes on the
shooting screen, and images and movies saved before
the clock is set are dated “00/00/0000 00:00” and “01/01/
2016 00:00” respectively. Set the correct time and date
for Time zone and date in the setup menu.
•The camera clock is not as accurate as ordinary watches
or clocks. Periodically compare the time of the camera
clock with that of a more accurate timepiece and reset
as required.
4, 131
Date and time of
recording are not
correct.
No information
displayed on the
screen.
Shooting and photo information may be hidden. Press the
s button until information is displayed. 4
Date stamp not
available. Time zone and date has not been set in the setup menu. 131
Date not stamped
on images even
when Date
stamp is enabled.
•The current shooting mode does not support Date
stamp.
•The date cannot be stamped on movies.
134
Screen for setting
time zone and
date is displayed
when the camera
is turned on.
The clock battery is exhausted; all settings were restored to
their default values. Configure the camera settings again.
•The internal clock battery is used to power the camera
clock and to retain certain settings. Charging time of the
clock battery takes about 10 hours when you insert the
batteries into the camera or connect the AC adapter
(available separately) to the camera, and the clock
battery operates for several days even after the camera
batteries are removed.
–
The camera
settings reset.
The camera
makes sound.
When Autofocus mode is set to Full-time AF or while in
some shooting modes, the camera may produce an
audible focusing sound.
28, 121
Problem Cause/Solution A
Cannot switch to
shooting mode. Disconnect the HDMI cable or USB cable. 87
Cannot take
pictures or record
movies.
•
When the camera is in playback mode, press the
c
button,
shutter-release button, or
b
(
e
) button.
•When menus are displayed, press the d button.
•
The flash is charging while the flash lamp is flashing.
•The batteries are exhausted.
2, 24
98
47
11, 150
Problem Cause/Solution A
158
Technical Notes
Troubleshooting
The camera
cannot focus.
•The subject is too close. Try shooting using scene auto
selector mode, Close-up scene mode, or macro mode.
•The subject is hard to focus on.
•Set AF assist in the setup menu to Auto.
•Turn the camera off and then on again.
28, 32,
35, 46,
51
57
135
–
Images are
blurred.
•Use the flash.
•Increase the ISO sensitivity value.
•Enable Photo VR when shooting still images. Enable
Movie VR when recording movies.
•Use a tripod to stabilize the camera (using the self-timer
at the same time is more effective).
47
110
122,
135
49
Bright specks
appear in images
captured with
flash.
The flash is reflecting off particles in the air. Lower the flash. 23, 47
Flash does not
fire.
•The flash is lowered.
•A scene mode that restricts the flash is selected.
•A function that restricts the flash is enabled.
23, 47
59
61
Digital zoom
cannot be used.
•Digital zoom is set to Off in the setup menu.
•Digital zoom cannot be used with certain shooting
modes or when using certain settings in other functions.
136
62, 136
Image mode not
available. A function that restricts Image mode is enabled. 61
No sound when
the shutter is
released.
•Off is selected for Shutter sound in Sound settings in
the setup menu. No sound is produced with some
shooting modes, even when On is selected.
•Do not block the speaker.
136
3
AF-assist
illuminator does
not light.
Off is selected for the AF assist option in the setup menu.
AF-assist illuminator may not light depending on the
position of the focus area or the shooting mode, even
when Auto is selected.
135
Problem Cause/Solution A
159
Technical Notes
Troubleshooting
Images appear
smeared. The lens is dirty. Clean the lens. 152
Colors are
unnatural. White balance or hue is not adjusted properly. 35, 106
Randomly spaced
bright pixels
(“noise”) appear in
image.
The subject is dark and the shutter speed is too slow, or ISO
sensitivity is too high. Noise can be reduced by:
•Using the flash
•Specifying a lower ISO sensitivity setting
47
110
Images are too
dark
(underexposed).
•The flash is lowered or a shooting mode that restricts the
flash is selected.
•The flash window is blocked.
•The subject is beyond the range of the flash.
•Adjust exposure compensation.
•Increase ISO sensitivity.
•The subject is backlit. Select Backlighting scene mode
or raise the flash and set the flash mode setting to X (fill
flash).
23, 47,
59
21
165
52
110
33, 47
Images are too
bright
(overexposed).
Adjust exposure compensation. 52
Unexpected results
when flash set to
V
(auto with
red-eye reduction).
Use any shooting mode other than Night portrait, and
change the flash mode to any setting other than V (auto
with red-eye reduction) and try taking the picture again.
47, 59
Skin tones are not
softened.
•Under some shooting conditions, facial skin tones may
not be softened.
•For images containing four or more faces, try using Skin
softening in Glamour retouch in the playback menu.
57
71
Saving images
takes time.
It may take more time to save images in the following
situations:
•When the noise reduction function is in operation, such as
when shooting in a dark environment
•When the flash mode is set to V (auto with red-eye
reduction)
•When shooting in Night landscape, Night portrait, or
Backlighting (when HDR is set to On) scene mode
•When the skin softening function is applied while
shooting
•When using continuous shooting mode
–
48
32, 33
43, 57
108
Problem Cause/Solution A
160
Technical Notes
Troubleshooting
Playback Issues
Problem Cause/Solution A
File cannot be
played back.
•This camera may not be able to play back images saved
with another make or model of digital camera.
•This camera cannot play back movies recorded with
another make or model of digital camera.
•This camera may not be able to play back data edited on
a computer.
–
Cannot zoom in
on image.
•Playback zoom cannot be used with movies.
•When zooming in on a small-sized image, the
magnification rate shown on the screen may differ from
the actual magnification rate of the image.
•This camera may not be able to zoom in on images
captured with another make or model of digital camera.
–
Cannot edit
images.
•Some images cannot be edited. Images that have
already been edited may not be edited again.
•There is not enough free space on the memory card or
in the internal memory.
•This camera is unable to edit images captured with
other cameras.
•Editing functions used for images are not available for
movies.
40, 69
–
–
–
Cannot rotate
image.
This camera cannot rotate images captured with another
make or model of digital camera. –
Images are not
displayed on TV.
•A computer or printer is connected to the camera.
•The memory card contains no images.
•Remove the memory card to play back images in the
internal memory.
–
–
12
Nikon Transfer 2
does not start
when the camera
is connected to a
computer.
•The camera is off.
•The batteries are exhausted.
•The USB cable is not correctly connected.
•The camera is not recognized by the computer.
•The computer is not set to start Nikon Transfer 2
automatically. For more information about Nikon
Transfer 2, refer to help information contained in
ViewNX-i.
–
87
87, 94
–
–
161
Technical Notes
Troubleshooting
Images to be
printed are not
displayed.
•The memory card contains no images.
•Remove the memory card to print images in the internal
memory.
–
12
Cannot select
paper size with
the camera.
The camera cannot be used to select the paper size in the
following situations, even when printing from a PictBridge-
compatible printer. Use the printer to select the paper size.
•The printer does not support the paper sizes specified by
the camera.
•The printer automatically selects the paper size.
–
Problem Cause/Solution A
162
Technical Notes
File Names
Images or movies are assigned file names as follows.
File name: DSCN
0001
.JPG
(1) (2) (3)
File Names
(1) Identifier
Not shown on the screen of the camera.
•DSCN: Original still images, movies, still images created by the
movie editing function
•SSCN: Small picture copies
•RSCN: Cropped copies
•FSCN: Images created by an image editing function other than
crop and small picture, movies created by the movie editing
function
(2) File number Assigned in ascending order, starting with “0001” and ending with
“9999.”
(3) Extension
Indicates file format.
•.JPG: Still images
•.MP4: Movies
163
Technical Notes
Optional Accessories
* When using EN-MH2 Rechargeable Ni-MH batteries with the camera, charge the batteries
four at a time using MH-73 Battery Charger. Also, do not charge batteries at the same time
if they have different amounts of charge remaining (A150). EN-MH1 Rechargeable Ni-
MH batteries cannot be used.
Availability may vary with country or region.
See our website or brochures for the latest information.
Optional Accessories
Battery charger,
rechargeable batteries*
•MH-73 Battery Charger (includes four EN-MH2
Rechargeable Ni-MH batteries)
•Replacement rechargeable batteries: EN-MH2-B4
Rechargeable Ni-MH batteries (set of four EN-MH2 batteries)
AC adapter EH-67/EH-67s AC Adapter
Audio/video cable EG-CP16 Audio Video Cable
Hand strap AH-CP1 Hand Strap
164
Technical Notes
Specifications
Nikon COOLPIX B500 Digital Camera
Specifications
Type Compact digital camera
Number of effective pixels 16.0 million (Image processing may reduce the number of
effective pixels.)
Image sensor
1
/
2.3
-in. type CMOS; approx. 16.76 million total pixels
Lens NIKKOR lens with 40× optical zoom
Focal length 4.0–160 mm (angle of view equivalent to that of
22.5–900 mm lens in 35mm [135] format)
f/-number f/3–6.5
Construction 12 elements in 9 groups (3 ED lens elements)
Digital zoom magnification Up to 4× (angle of view equivalent to that of approx.
3600 mm lens in 35mm [135] format)
Vibration reduction Lens shift (still images)
Lens shift and electronic VR (movies)
Autofocus (AF) Contrast-detect AF
Focus range
•[W]: Approx. 30 cm (1 ft)–∞,
[T]: Approx. 3.5 m (11 ft)–∞
•Macro mode: Approx. 1 cm (0.4 in.)–∞ (wide-angle
position)
(All distances measured from center of front surface of lens)
Focus-area selection Face priority, manual with 99 focus areas, center, subject
tracking, target finding AF
Monitor
7.5 cm (3-in.), approx. 921k-dot, wide viewing angle TFT LCD
with anti-reflection coating and 5-level brightness
adjustment, tiltable approx. 85° downward, approx. 90°
upward
Frame coverage
(shooting mode)
Approx. 99% horizontal and vertical (compared to actual
picture)
Frame coverage
(playback mode)
Approx. 99% horizontal and vertical (compared to actual
picture)
Storage
Media Internal memory (approx. 20 MB), SD/SDHC/SDXC memory
card
File system DCF and Exif 2.3 compliant
File formats
Still images: JPEG
Movies: MP4 (Video: H.264/MPEG-4 AVC, Audio: AAC
stereo)
165
Technical Notes
Specifications
Image size
(pixels)
•16M (High) [4608 × 3456P]
•16M [4608 × 3456]
•8M [3264 × 2448]
•4M [2272 × 1704]
•2M [1600 × 1200]
•VGA [640 × 480]
•16:9 [4608 × 2592]
•1:1 [3456 × 3456]
ISO sensitivity
(Standard output
sensitivity)
•ISO 125–1600
•ISO 3200, 6400 (available when using Auto mode)
Exposure
Metering mode Matrix, center-weighted (digital zoom less than 2×), spot
(digital zoom 2× or more)
Exposure control Programmed auto exposure and exposure compensation
(–2.0 – +2.0 EV in steps of 1/3 EV)
Shutter Mechanical and CMOS electronic shutter
Speed
•1/1500–1 s
•1/4000 s (maximum speed during high-speed
continuous shooting)
•25 s (Star trails in Multiple exp. Lighten scene mode)
Aperture Electronically-controlled ND filter (–2 AV) selection
Range 2 steps (f/3 and f/6 [W])
Self-timer •10 s, 2 s
•5 s (self-portrait timer)
Flash
Range (approx.)
(ISO sensitivity: Auto)
[W]: 0.5–6.9 m (1 ft 8 in.–22 ft)
[T]: 3.5 m (11 ft)
Flash control TTL auto flash with monitor preflashes
Interface
USB connector
Hi-Speed USB
•Supports Direct Print (PictBridge)
•Audio/video output connector (NTSC or PAL can be
selected)
HDMI output connector HDMI micro connector (Type D)
DC input connector For EH-67/EH-67s AC Adapter (available separately)
166
Technical Notes
Specifications
•All measurements are performed in conformity with Camera and Imaging Products
Association (CIPA) standards or guidelines.
Wi-Fi (Wireless LAN)
Standards IEEE 802.11b/g (standard wireless LAN protocol)
Operating frequency 2412–2462 MHz (1-11 channels)
Authentication Open system, WPA2-PSK
Bluetooth
Communication
protocols Bluetooth Specification Version 4.1
Supported languages
Arabic, Bengali, Bulgarian, Chinese (Simplified and
Traditional), Czech, Danish, Dutch, English, Finnish, French,
German, Greek, Hindi, Hungarian, Indonesian, Italian,
Japanese, Korean, Marathi, Norwegian, Persian, Polish,
Portuguese (European and Brazilian), Romanian, Russian,
Serbian, Spanish, Swedish, Tamil, Telugu, Thai, Turkish,
Ukrainian, Vietnamese
Power sources
•Four LR6/L40 (AA-size) alkaline batteries
•Four FR6/L91 (AA-size) lithium batteries
•Four EN-MH2 Rechargeable Ni-MH batteries (available
separately)
•EH-67/EH-67s AC Adapter (available separately)
Battery life1
Still images
•Approx. 600 shots when using alkaline batteries
•Approx. 1240 shots when using lithium batteries
•Approx. 750 shots when using EN-MH2 batteries
Movie recording
(actual battery life for
recording)2
•Approx. 1 h 30 min when using alkaline batteries
•Approx. 4 h 30 min when using lithium batteries
•Approx. 2 h 35 min when using EN-MH2 batteries
Tripod socket 1/4 (ISO 1222)
Dimensions (W × H × D) Approx. 113.5 × 78.3 × 94.9 mm (4.5 × 3.1 × 3.8 in.)
(excluding projections)
Weight Approx. 542 g (1 lb 3.2 oz) (including LR6/L40 (AA-size)
alkaline batteries and memory card)
Operating environment
Temperature 0°C–40°C (32°F–104°F)
Humidity 85% or less (no condensation)
167
Technical Notes
Specifications
1Battery life does not reflect the use of SnapBridge and may vary with the conditions of
use, including temperature, the interval between shots, and the length of time that
menus and images are displayed. The supplied batteries are for trial use only. The figures
listed for lithium batteries were obtained using commercially-available FR6/L91 (AA-size)
Energizer® Ultimate Lithium batteries.
2Individual movie files cannot exceed 4 GB in size or 29 minutes in length. Recording may
end before this limit is reached if camera temperature becomes elevated.
•Nikon will not be held liable for any errors this manual may contain.
•The appearance of this product and its specifications are subject to change without
notice.
168
Technical Notes
Specifications
Memory Cards That Can Be Used
The camera supports SD, SDHC, and SDXC memory cards.
•Memory cards with an SD Speed Class rating of 6 or faster are recommended for
recording movies. When using a memory card with a lower Speed Class rating,
movie recording may stop unexpectedly.
•If you use a card reader, make sure that it is compatible with your memory card.
•Contact the manufacturer for information on features, operation, and limitations
on use.
Trademark Information
•Windows is either a registered trademark or trademark of Microsoft Corporation in
the United States and/or other countries.
•The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Nikon Corporation is under
license.
•Apple®, App Store®, the Apple logos, Mac, OS X, iPhone®, iPad®, iPod touch® and
iBooks are trademarks or registered trademarks of Apple Inc., in the U.S. and other
countries.
•Android and Google Play are trademarks or registered trademarks of Google Inc.
The Android robot is reproduced or modified from work created and shared by
Google and used according to terms described in the Creative Commons 3.0
Attribution License.
•iOS is a trademark or registered trademark of Cisco Systems, Inc., in the United
States and/or other countries and is used under license.
•Adobe, the Adobe logo, and Reader are either trademarks or registered trademarks
of Adobe Systems Incorporated in the United States and/or other countries.
•SDXC, SDHC, and SD Logos are trademarks of SD-3C, LLC.
•PictBridge is a trademark.
•HDMI, HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing, LLC.
•Wi-Fi and the Wi-Fi logo are trademarks or registered trademarks of the Wi-Fi
Alliance.
•The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United
States and in other countries.
•All other trade names mentioned in this manual or the other documentation
provided with your Nikon product are the trademarks or registered trademarks of
their respective holders.
169
Technical Notes
Specifications
AVC Patent Portfolio License
This product is licensed under the AVC Patent Portfolio License for the personal and
non-commercial use of a consumer to (i) encode video in compliance with the AVC
standard (“AVC video”) and/or (ii) decode AVC video that was encoded by a consumer
engaged in a personal and non-commercial activity and/or was obtained from a video
provider licensed to provide AVC video. No license is granted or shall be implied for
any other use.
Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com.
FreeType License (FreeType2)
Portions of this software are copyright © 2012 The FreeType Project
(http://www.freetype.org). All rights reserved.
MIT License (HarfBuzz)
Portions of this software are copyright © 2016 The HarfBuzz Project
(http://www.freedesktop.org/wiki/Software/HarfBuzz). All rights reserved.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic
accessory has been designed to connect specifically to iPod, iPhone, or iPad,
respectively, and has been certified by the developer to meet Apple performance
standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that the use of this
accessory with iPod, iPhone, or iPad may affect wireless performance.
170
Technical Notes
Index
Symbols
A Auto mode.................................... 28, 29
o Scene auto selector mode
............................................................... 28, 31, 32
o Backlighting mode............. 28, 31, 33
s Creative mode........................... 28, 41
y Scene mode........................ 28, 31
n Short movie show mode ....... 28, 80
d Sports mode........................... 28, 31, 34
F Smart portrait mode ................ 28, 43
e Night portrait mode.......... 28, 31, 33
j Night landscape mode ... 28, 31, 32
c Playback mode.................................... 24
C List by date mode............................... 66
i Playback zoom .............................. 24, 64
f (Wide-angle)........................................... 53
h Thumbnail playback................ 24, 65
g (Telephoto) ................................................ 53
q Snap-back zoom button ........... 2, 54
k Apply selection button .............. 3, 98
c Playback button............................. 3, 24
l Delete button.................................... 3, 25
b (e Movie-record) button........ 3, 23
s Display button.............................. 3, 4
m Flash pop-up button............. 2, 23, 47
d Menu button................................ 3, 98
n Self-timer......................................... 46, 49
m Flash mode ...................................... 46, 47
p Macro mode................................... 46, 51
o Exposure compensation
..................................................... 29, 43, 46, 52
Y N-Mark ................................................... 2, 15
A
AC adapter........................................... 87, 163
Active D-Lighting ........................................ 29
AF area mode ................................... 101, 111
AF assist .............................................. 104, 135
AF-assist illuminator...................................... 2
Airplane mode ............................... 103, 129
Alkaline batteries .......................................... 11
Audio/video cable ................. 87, 88, 163
Audio/video-in jack.......................... 87, 88
Auto flash ........................................................ 48
Auto mode ............................................. 28, 29
Auto off...................................... 23, 104, 137
Autofocus.............................................. 57, 121
Autofocus mode...... 101, 102, 114, 121
B
Background music..................................... 80
Backlighting mode .................... 28, 31, 33
Battery ................................................................. 11
Battery charger........................................... 163
Battery level..................................................... 21
Battery type...................................... 104, 142
Battery-chamber/memory card slot
cover....................................................................... 3
Beach Z........................................................... 31
Bird-watching l........................................ 37
Blink proof.......................................... 101, 116
Bluetooth................................... 15, 103, 129
Brightness...................................................... 133
Button sound .............................................. 136
C
Calendar display.......................................... 65
Capturing still images while recording
movies............................................................... 79
Close-up k............................................. 31, 35
Compression ratio.................................... 105
Computer............................................... 87, 94
Conformity marking ................... 104, 142
Connect to smart device ......... 103, 129
Connector cover .................................... 3, 87
Index
171
Technical Notes
Index
Continuous shooting.................. 101, 108
Copy ...................................................... 102, 127
Copyright information .............. 104, 140
Creative mode...................................... 28, 41
Creative slider................................................ 29
Crop........................................................... 64, 74
Current settings......................................... 129
D
Date and time..................................... 14, 131
Date format........................................... 17, 131
Date stamp....................................... 104, 134
Daylight saving time ...................... 17, 132
DC input connector...................................... 3
Delete........................................................ 25, 68
Digital zoom............................ 53, 104, 136
Direct print ............................................. 87, 90
D-Lighting............................................ 70, 102
Dusk/dawn i.............................................. 31
E
Easy panorama playback....................... 40
Easy panorama V.............................. 31, 38
Editing images ............................................. 69
Editing movies .................................... 84, 85
End recording................................................ 81
EN-MH2 ............................................... 150, 163
Exposure compensation
..................................................... 29, 43, 46, 52
Extracting still images...................... 83, 85
Eyelet for camera strap............................... 2
F
Face detection .............................................. 56
Face priority.................................................. 111
File names..................................................... 162
Fill flash ............................................................. 48
Fireworks show m............................. 31, 35
Firmware version.......................... 104, 142
Fixed range auto........................................ 110
Flash...................................................... 2, 23, 47
Flash lamp.................................................. 3, 47
Flash mode............................................ 46, 47
F-number.......................................................... 55
Focus................................................................... 55
Focus area....................................................... 22
Focus indicator ................................................ 5
Focus lock ....................................................... 58
Food u....................................................... 31, 35
Format internal memory.......... 104, 138
Format memory cards....... 11, 104, 138
Formatting............................................ 11, 138
Foundation makeup................................. 43
Frame rate......................................... 102, 123
Full-frame playback................................... 24
Full-time AF.................................................. 121
G
Glamour retouch ..................... 43, 71, 102
H
HDMI cable............................................ 87, 88
HDMI micro connector...................... 3, 87
HDR ...................................................................... 33
Help display ................................................. 133
High-speed continuous ....................... 108
Histogram................................................... 8, 52
HS movie............................................. 118, 120
Hue...................................................................... 29
I
Image comment ........................... 104, 139
Image mode..................................... 101, 105
Image review............................................... 133
Internal memory .......................................... 12
Interval ............................................................. 115
ISO sensitivity................................... 101, 110
L
Landscape c................................................ 31
Language........................................... 104, 138
Lens............................................................. 2, 164
List by date mode ...................................... 66
172
Technical Notes
Index
Lithium batteries .......................................... 11
Location data.................................. 104, 141
M
Macro mode.......................................... 46, 51
Mark for upload............................. 102, 124
Memory card............................. 11, 151, 168
Memory card slot ......................................... 11
Microphone (stereo)..................................... 2
Mode dial ........................................... 2, 21, 28
Monitor........................................ 3, 4, 13, 152
Monitor settings............................ 104, 133
Moon L........................................................... 37
Movie menu ........................................ 98, 117
Movie options ................................. 102, 117
Movie recording.................................. 23, 76
Movie VR............................................. 102, 122
Multi selector ........................................... 3, 98
Multiple exp. Lighten U............... 31, 34
N
Network menu.................................. 98, 129
Night landscape mode........... 28, 31, 32
Night portrait mode ................. 28, 31, 33
Number of exposures remaining
..................................................................... 21, 105
Number of shots............................... 80, 115
O
Optical zoom ................................................. 53
Optional accessories .............................. 163
P
Paper size ................................................ 91, 92
Party/indoor f.................................... 31, 35
Pet portrait auto release ......................... 36
Pet portrait O....................................... 31, 36
Photo VR ............................................ 104, 135
PictBridge................................................ 87, 90
Playback .......................................... 24, 67, 83
Playback menu ................................. 98, 124
Playback mode ............................................ 24
Playback zoom.................................... 24, 64
Portrait b......................................................... 31
Power switch/power-on lamp...... 2, 14
Preset manual............................................. 107
Pre-shooting cache..................... 108, 109
Pressing halfway .......................................... 55
Print.................................................... 87, 91, 92
Printer ....................................................... 87, 90
Protect................................................. 102, 126
Q
Quick effects.................................................. 69
Quick retouch.................................... 70, 102
R
Rechargeable battery............................. 163
Rechargeable nickel-metal hydride
batteries.............................................................. 11
Recording movies .............................. 23, 76
Recording slow motion movies
.................................................................. 118, 120
Red-eye correction .......................... 71, 102
Red-eye reduction ..................................... 48
Remaining movie recording time
....................................................................... 76, 77
Reset all............................................... 104, 141
Restore default settings............ 103, 129
Rotate image................................... 102, 126
S
Scene auto selector mode.... 28, 31, 32
Scene mode........................................... 28, 31
SD memory card.................... 11, 151, 168
Self-Collage ............................... 45, 101, 115
Self-portrait timer....................................... 49
Self-timer ................................................ 46, 49
Self-timer lamp ....................................... 2, 50
Send while shooting .................. 103, 129
Sequence display options
........................................................ 67, 102, 128
Setup menu ......................................... 98, 131
173
Technical Notes
Index
Shooting .................................................. 21, 28
Shooting information.................................. 4
Shooting menu .................... 98, 105, 106
Shooting mode ............................................ 28
Short movie show menu....................... 80
Short movie show mode............... 28, 80
Shutter sound.................................. 115, 136
Shutter speed................................................ 55
Shutter-release button ...................... 2, 22
Side zoom control ........................ 2, 22, 53
Single AF......................................................... 121
Single-frame shooting .......................... 108
Skin softening............................................... 43
Slide show.......................................... 102, 125
Slow sync......................................................... 48
Small picture ...................................... 73, 102
Smart portrait menu....................... 98, 115
Smart portrait mode......................... 28, 43
Smile timer ..................................................... 44
Snow z............................................................ 31
Soft ...................................................................... 43
Sound settings............................... 104, 136
Speaker................................................................. 3
Special effects....................................... 80, 82
Sports mode.................................. 28, 31, 34
Strap .................................................................... 10
Subject tracking .............................. 112, 113
Sunset h......................................................... 31
Sync with smart device ......................... 131
T
Target finding AF.............................. 55, 112
Telephoto......................................................... 53
Thumbnail playback......................... 24, 65
Time difference.......................................... 132
Time zone .............................................. 17, 131
Time zone and date............ 14, 104, 131
Tone level............................................................ 8
Tone level information.......................... 4, 8
Tripod socket ........................................ 3, 166
TV................................................................. 87, 88
U
USB cable....................................... 87, 90, 94
USB/audio/video output connector
............................................... 3, 87, 88, 90, 94
V
View/hide framing grid................... 6, 133
ViewNX-i........................................................... 94
Vividness ................................................. 29, 43
Volume.............................................................. 83
W
White balance.................................. 101, 106
Wide-angle ...................................................... 53
Wi-Fi...................................................... 103, 129
Wind noise reduction ................ 102, 122
Z
Zoom................................................................... 53
Zoom control.................................. 2, 22, 53
Zoom in............................................................. 53
Zoom out ......................................................... 53
CT6D03(11)
6MN66411-03
No reproduction in any form of this manual, in whole or in part
(except for brief quotation in critical articles or reviews), may be
made without written authorization from NIKON CORPORATION.

Navigation menu
