USER MANUAL

Paragon NTFS&HFS+

for Linux 9.4

User Manual

Generated 6/2/2016

PARAGON SOFTWARE

Paragon NTFS&HFS+ for Linux 9.4

User Guide

This document covers implementation of NTFS and HFS+ file

systems support in Linux operating systems using Paragon NTFS

and HFS+ file system drivers. Basic installation procedures are

described. Detailed mount options description is given. File

system creation (formatting) and checking utilities are described.

List of supported NTFS/HFS+ features is given with limitations

imposed by Linux. There are also advanced troubleshooting

section.

Abstract

USER MANUAL

graphic, electronic, or mechanical, including photocopying, recording, taping, or information

storage and retrieval systems - without the written permission of the publisher.

Products that are referred to in this document may be either trademarks and/or registered

trademarks of the respective owners. The publisher and the author make no claim to these

trademarks.

While every precaution has been taken in the preparation of this document, the publisher and

the author assume no responsibility for errors or omissions, or for damages resulting from the

use of information contained in this document or from the use of programs and source code

that may accompany it. In no event shall the publisher and the author be liable for any loss of

profit or any other commercial damage caused or alleged to have been caused directly or

indirectly by this document.

Printed: June 2016 in Freiburg, Germany.

Paragon NTFS&HFS+ for Linux 9.4

Special thanks to:

All the people who contributed to this document,

either by writing text, developing solutions to

various issues, performing tests, collecting

information or by requested support from our

team. To our customers who continue to support

us and help us to improve the product by

constantly demanding more.

We welcome your feedback

Please send your feedback to

User Guide

sales@paragon-software.com

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

or use your User account with

Paragon Software.

PARAGON SOFTWARE

Paragon NTFS&HFS+ for Linux 9.4I

Table of Contents

Part I Introduction 2

......................................................................................................................... 21 Historical review

......................................................................................................................... 22 Paragon UFSD technology

......................................................................................................................... 33 How UFSD works on Linux

......................................................................................................................... 34 Key Features

Part II System requirements 6

......................................................................................................................... 61 Hardware requirements

......................................................................................................................... 62 Software requirements

Part III Installation 9

......................................................................................................................... 91 Shipment

......................................................................................................................... 92 Components

......................................................................................................................... 93 Installing the Drivers

......................................................................................................................... 114 Uninstalling the Drivers

Part IV Using The Driver 14

......................................................................................................................... 141 Getting started

......................................................................................................................... 142 Mounting NTFS/HFS+ Partitions

......................................................................................................................... 143 Dirty flag issues

......................................................................................................................... 154 GPT issues

......................................................................................................................... 165 Issues with large HDDs

......................................................................................................................... 166 Unmounting NTFS/HFS+ Partitions

......................................................................................................................... 16

7 Choosing the codepage/charset for NTFS/HFS+

Partitions

Part V Mount options 19

......................................................................................................................... 191 Mount options

Part VI Additional Utilities 23

......................................................................................................................... 231 NTFS utilities

.................................................................................................................23mkntfs

.................................................................................................................24chkntfs

......................................................................................................................... 252 HFS+ utilities

.................................................................................................................25mkhtfs

.................................................................................................................26chkhfs

Part VII Troubleshooting 29

USER MANUAL

Contents

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

......................................................................................................................... 291 Troubleshooting processes

......................................................................................................................... 302 Mount toubleshooting

......................................................................................................................... 303 The install.sh script can’t find kernel sources

......................................................................................................................... 314 Can’t compile the NTFS/HFS+ for Linux driver

......................................................................................................................... 31

5 “Can’t load module” message at the end of

installation

......................................................................................................................... 316 ufsd Module: kernel-module version mismatch

......................................................................................................................... 32

7 ufsd Module: create_module: operation is not

permitted

......................................................................................................................... 328 insmod: a module named as ufsd already exists

......................................................................................................................... 329 insmod: Unknown symbol jnl_op (err 0)

......................................................................................................................... 3210 I can’t mount NTFS/HFS+ volume

......................................................................................................................... 3211 Collecting logs using release build of the driver user

......................................................................................................................... 3412 Sysdump utility

Part VIII UFSD driver compatibility 38

......................................................................................................................... 381 NTFS features

......................................................................................................................... 382 HFS+ features

Part IX Frequently Asked Questions 40

......................................................................................................................... 401 What are 'minor errors' reported by chkntfs utility?

......................................................................................................................... 41

2 Warnings on Windows7/Vista when NTFS HDD is

reconnected from Linux

......................................................................................................................... 43

3 Recently changed file has its modification time a few

hours ahead of or behind the current system time.

Why?

......................................................................................................................... 44

4 Why does mount option A make driver ignore mount

option B?

......................................................................................................................... 445 Why a lot of memory is used for volume mounting?

......................................................................................................................... 446 Why the disk can't be dismounted?

PARAGON SOFTWARE

Part I

Introduction

USER MANUAL

2Introduction

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

1.1 Historical review

Historically, different operating systems supported different file systems. Sharing files among

different platforms was not an easy task. For instance, documents that were created in

Windows and are stored on NTFS partitions may be inaccessible under Linux, because Linux

does not include full support for NTFS. For example, open-source NTFS-3G NTFS driver

does not support random write access to compressed files.

Paragon NTFS&HFS+ driver for Linux solves these problems — now everyone can access

NTFS and HFS+ partitions from Linux in a usual manner with maximum performance and

reliability. The driver allows mounting NTFS and HFS+ partitions, so that programs may work

transparently with these mounted partitions — browse contents, open documents, run

applications, work with existing files (delete/copy/modify) and create new ones.

Paragon combined NTFS&HFS+ driver for Linux is commercial Linux driver for local access to

NTFS and HFS+ volumes. It supports full read/write access. The driver is a Kernel module,

which guarantees rapid and transparent access to supported file systems. Mount volumes

manually or insert into fstab, and NTFS/HFS+ partitions will be available like any other

directory tree.

Paragon NTFS&HFS+ for Linux Professional also includes useful additional utilities that

provide the ability to check integrity and create NTFS/HFS+ volumes.

1.2 Paragon UFSD technology

UFSD (Universal File System Driver) is an unique technology developed by Paragon Software

to provide full access (read/write, format, etc.) to volumes of the popular file systems: NTFS,

FAT, Ext2Fs, Ext3Fs, HFS+ etc. under various platforms, including Windows, Linux, Mac OS

X, etc. in case these file systems are not otherwise supported.

UFSD technology provides access directly to the physical devices that is why it can process

partitions regardless of their support by the current Operating System (OS). With UFSD it is

possible to mount NTFS and HFS+ partitions under Linux, thus getting access to its contents,

just the way it is implemented in the NTFS&HFS+ for Linux driver, and the technology also

allows direct access via physical device addressing, the way it is implemented in the driver

too.

Paragon UFSDs are designed to be readily integrated into any solution using our UFSD

Software Development Kit (UFSD SDK), which includes all of the necessary tools to develop

applications with the following main features:

Access to un-mounted partitions (i.e. drive letter not assigned);

Access to other file systems that normally would not be supported by the operating system;

Platform-independent UFSD API.

Note: NTFS and HFS+ drivers for Linux as well as utilities were written using UFSD SDK.

PARAGON SOFTWARE

3 Paragon NTFS&HFS+ for Linux 9.4

1.3 How UFSD works on Linux

Modern operating systems are based on the concept of Installable File System drivers (IFS).

User simply needs to provide an operating system with the proper file system driver to work

with the file system in usual manner. Paragon NTFS&HFS+ for Linux includes NTFS and

HFS+ drivers for Linux environment. Once appropriate components of Paragon NTFS&HFS+

for Linux are installed, the operating system can mount these file systems and work with

directories/files stored on the file systems.

1.4 Key Features

Paragon NTFS&HFS+ for Linux 9.4 is released in the Express and Professional Editions. All of

the products share the following features:

Transparent read-write access to NTFS and HFS+ volumes — single Kernel module

provides support both NTFS and HFS+ file systems

High performance (in some cases even better than Ext4 FS);

Easy installation and uninstallation (assistant scripts);

Support for the latest Linux Kernels and distributions;

Support for SMP kernels;

Support for iSCSI and SSD storages;

File sharing over network via SAMBA;

Low CPU load during data transfers;

Unlimited file and volume size (within NTFS/HFS+ and Kernel limitations).

What's new in Paragon NTFS&HFS+ for Linux 9.4:

Support for Linux Kernel versions from 2.6.36 up to 4.4.x;

Improved NTFS file systems support (including compatibility with Windows 10 NTFS);

Improved HFS+ support (including compatibility with OS X El Capitan HFS+);

Improved support for very large volumes (16+TB);

Improved TRIM/discard support for SSD storages.

NTFS-specific features:

NTFS versions 1.2, 3.0 and 3.1 (Windows NT 4.0, 2000, XP, 2003, Vista, 7, Windows 8.1,

Windows 10);

Support for compressed files (random access for reading and writing with no limitations);

Sparse files support.

HFS+ specific features:

Both case sensitive and case instensitive types of HFS+ file system are supported;

USER MANUAL

4Introduction

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

During file copy operation (using cp command) on Linux only ‘data’ fork is copied;

Support replay native HFS+ journal.

NTFS compatibility information:

File system version

Comments

NTFS version 1.2

Originates from Microsoft Windows NT 4.0

NTFS version 3.0

Originates from Microsoft Windows 2000

NTFS version 3.1

Originates from Microsoft Windows XP/2003/

Vista/7/8.1 and 10

Additional features of the Professional Edition:

Full support of the native HFS+ journal;

Automatic driver rebuilt for newer supported Kernels (support for the DKMS library);

Automatic NTFS/HFS+ volume mounting;

Additional NTFS utilities:

-mkntfs utility - format any partition as NTFS under Linux;

-chkntfs utility - check NTFS partition integrity and fix errors;

Additional HFS+ utilities:

-mkhtfs utility- format any partition as HFS+ under Linux;

-chkhfs utility - check HFS+ partition for integrity and fix errors;

Debug utility:

-Sysdump utility - debug utility for collecting volume metadata image and debug system

information.

PARAGON SOFTWARE

Part II

System

requirements

USER MANUAL

6System requirements

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

This topic highlights requirements to hardware and software that may be used to run Paragon

NTFS&HFS+ for Linux driver.

2.1 Hardware requirements

Minimum hardware requirements:

Processor: Intel Pentium 300 MHz and higher, or compatible;

both 32- and 64-bit CPUs are supported.

16MB of RAM.

Due to unique technology our NTFS&HFS+ for Linux drivers have low system requirements.

For example, it is enough for our driver to have 650KB of free RAM to work with NTFS

partitions larger than 250 GB. NTFS&HFS+ Kernel modules occupy around 800 Kb of RAM.

Real-life values

200 Kb maximum while executing 5 commands like dd if=/dev/zero of=/mnt/sda1/test

bs=1M count=1000& in background.

516 Kb maximum while executing rsync -r /home /mnt/sda1 command.

17 Mb maximum while compiling bench test on Desktop Linux system in virtual environment

using NTFS file system: a file-tree with a size about 220 Mb was created and patched,

simulating Linux Kernel installation process.

RAM consumption depends first of all on whole amount of memory available in the system. If it

is low then the driver wouldn't keep a lot of descriptors opened to keep the memory usage at

minimum.

2.2 Software requirements

Supported Linux kernels:

Linux with kernel versions 2.6.36 and newer;

Linux with kernel versions up to 4.4.x (NTFS&HFS+ driver was tested with Kernels up to

4.4.9).

Linux distributions the products were tested with:

Ubuntu 16.04;

Debian 8.4;

Fedora 23;

CenOS 7;

OpenSuse 42.1.

Development Environment

PARAGON SOFTWARE

7 Paragon NTFS&HFS+ for Linux 9.4

A development environment is required to compile Linux drivers and utilities. Please verify that

these tools are all functional. The easiest way is to choose the developer toolkit when

installing Linux.

What must be installed:

Kernel source code (recommended) or Kernel header files (doesn’t always work);

#rpm -qa|grep kernel-devel (for RPM based kernel-sources)

GNU C compiler (GCC);

#gcc --version

GNU C++ compiler (g++) — for Professional version only;

#g++ --version

GNU Glibc-static libraries — recommended for Professional version;

GNU Make;

#make --version

GNU ld (binutils);

#ld --version

Modutils (module-init tools);

#insmod -V

DKMS library — for Professional version only.

#dkms --version

Limitations

GNU C compiler (gcc) version 3.3 or higher is required.

The user should login as root to install the drivers and utilities.

Correct operation is not guaranteed for customized Linux kernels. Commercial porting

service to customized Linux kernels is available from Paragon Software Group — for more

information send e-mail to sales@paragon-software.com).

USER MANUAL

Part III

Installation

PARAGON SOFTWARE

9 Paragon NTFS&HFS+ for Linux 9.4

This section describes workflows related to installing and using Paragon NTFS&HFS+ for

Linux driver.

3.1 Shipment

The setup files for each product of the family are provided as the downloadable TGZ archives,

which can be downloaded from the company site.

3.2 Components

The package includes the following components:

Source files for the NTFS&HFS+ for Linux driver;

Assistant script files, which are purposed to simplify the installation and uninstallation

routines;

Source files for additional utilities (for Professional edition only);

Source files for DKMS library support (for Professional edition only);

Source files for automatic mounting integration (for Professional edition only).

Paragon NTFS&HFS+ Linux driver and utilities must be compiled on the end user’s system for

correct configuration. By installing the software you accept the terms of End User License

Agreement listed in License file.

3.3 Installing the Drivers

First, NTFS&HFS+ driver must be built and installed.

Steps to install the NTFS&HFS+ for Linux driver are as follows:

1. Log in as root. This step is obligatory;

2. Build and install the NTFS & HFS+ driver using install.sh script. Alternatively, driver

binary module may be built manually using 'configure' 'make driver' commands.

3. Install the NTFS & HFS+ driver (this step will make the modules available for use);

4. Activating (loading) the driver. After building and installing, the NTFS & HFS+ driver can be

referenced as “universal file system driver” (ufsd) when mounting NTFS and HFS+

partitions.

The steps 1-3 should be made only once while the step 4 is the standard way of using file

system drivers in Linux environment.

NTFS & HFS+ for Linux include a set of assistant script files for the simplification of building,

installing and uninstalling procedures. Note that these assistant scripts may fail to work in

customized Linux configurations or unsupported Linux distributions.

Use install.sh and uninstall.sh script files to install and uninstall (correspondingly)

NTFS & HFS+ driver and utilities. The sections below describe the installation procedure in

details.

USER MANUAL

10Installation

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

Unpacking Setup Files

The setup files of the Linux-based version of the NTFS & HFS+ for Linux are provided in the

form of a gzip archive. The archive should be copied to the hard disk and decompressed.

For example:

For the NTFS & HFS+ for Linux driver and utilities:

create separate folder

# mkdir /usr/tmp/ufsd

change the current directory to the new one

# cd /usr/tmp/ufsd

use tar utility to unpack initial archive

# tar -xf /path/to/the/initial/archive/ufsd_*.tar.gz

Next step is to build and install the NTFS & HFS+ for Linux driver..

Using the INSTALL.SH Assistant Script

The assistant script "install.sh" provides the extremely easy and flexible way to make the

NTFS & HFS+ for Linux and install driver module in the system. Additionally, the script can

reconfigure OS so that driver module is automatically rebuilt for another supported Kernel

version (Professional edition only) and NTFS/HFS+ volumes are automatically mounted with

the UFSD driver (Professional edition only).

Please note that development tools and kernel sources are required to present on the system

and stay in the default locations to build and install the drivers.

Installation

Just run the install.sh script with root privileges:

# ./install.sh or $ sudo ./install.sh

The assistant script will automatically perform the following actions:

1) Detect the Linux Kernel version;

2) Find kernel header files and libraries needed for building the drivers;

3) Add service for rebuilding driver module for supported Kernels via the DKMS library

(Professional edition only).

4) Build driver binary modules (jnl.ko and ufsd.ko);

5) Install the driver;

6) Add automatic mounting settings for NTFS/HFS+ volumes (Professional edition only);

7) Build and install additional utilities (Professional edition only);

PARAGON SOFTWARE

11 Paragon NTFS&HFS+ for Linux 9.4

INSTALL.SH default mode for the NTFS&HFS+ for Linux driver

The assistant script install.sh always names the NTFS&HFS+ for Linux driver module

as ufsd (it is the abbreviation of the project name Universal File System Driver);

Now you can mount any NTFS/HFS+ partition: # mount -t ufsd <device>

<mount_point>.

3.4 Uninstalling the Drivers

To completely remove the drivers and the utilities from the current Kernel, one should

dismount all NTFS/HFS+ partitions mounted with the driver, uninstall the drivers and unload

binary modules from the Kernel.

NTFS&HFS+ for Linux provides tools for the drivers/utilities uninstall automation.

The assistant script uninstall.sh completely removes the drivers/utilities from the system.

Using the UNINSTALL.SH Assistant Script

The assistant script uninstall.sh provides the extremely easy and flexible way to deactivate

and remove the drivers and utilities from the system. The script performs the correct

deactivation, uninstallation and the complete removing of the driver’s and utilities’ files.

Uninstalling

Unmount all currently mounted NTFS and/or HFS+ partitions and then run the 'uninstall.sh'

script:

# ./uninstall.sh

USER MANUAL

12Installation

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

The assistant script will automatically perform the following actions:

1. Deactivate the driver modules. If the drivers is still in use, the further script execution is

aborted;

2. Uninstall the drivers;

3. Remove all binary and source files of the driver

4. Uninstall utilities (for Professional version only).

PARAGON SOFTWARE

Part IV

Using The Driver

USER MANUAL

14Using The Driver

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

After building and installing the NTFS&HFS+ for Linux driver, it can be automatically loaded at

the system startup. The driver allows to mount supported partitions and provides access to

their whole contents.

4.1 Getting started

The goal of this section is to help quickly find out how to use the product. It describes general

approach to mounting partitions using UFSD file system driver and helps to avoid common

issues. We strongly recommend reading this section before starting using our driver.

To mount volume using UFSD driver, standard mount command is used, with File System (FS)

type set to ufsd, e.g.:

/ # mount –t ufsd /dev/sda1 /mnt/sda1

After this command is executed there can be several mount scenarios for a disk (for more

information see Mount toubleshooting subsection):

The disk is “clean” (without any errors), mounted by the driver and ready to use.

Disk can’t be mounted. In this case can be several scenarios:

1. Disk has “dirty” flag set (for more information see Dirty flag issues subsection):

Use chkntfs/chkhfs utilities with –a –f options to check the volume for errors and

inconsistencies and fix them (if any). This is recommended approach (see chkntfs or

chkhfs subsections);

Use ‘force’ mount option (see Dirty flag issues subsection).

2. The disk is a GPT-partitioned disk – check GPT issues subsection for more

information.

3. Follow other steps on the Mount toubleshooting diagram to find the cause of the

issue.

Analyze returned status and check output of (dmesg | tail). In case of failure, follow the

Mount toubleshooting diagram to find possible causes and and try to mount the partition

again using the same or different mount options, if needed (see Mount options subsection).

If there is still a problem mounting the partition fill out Paragon's online request form from your

user account so we could help you with the issue.

4.2 Mounting NTFS/HFS+ Partitions

To gain access to a NTFS/HFS+ partition, use standard mount command with a file system

type set to ufsd. For example:

mount –t ufsd /dev/sdb1 /mnt/ntfs

4.3 Dirty flag issues

‘Dirty’ flag is special feature implemented in most of the modern file systems, including NTFS

and HFS+. This flag is set after volume is mounted in read/write mode and cleared after

volume is correctly unmounted (see notes on 'force' mount option for more information).

PARAGON SOFTWARE

15 Paragon NTFS&HFS+ for Linux 9.4

Without ‘dirty’ flag it is impossible to tell if given volume was correctly unmounted or not.

Detecting incorrectly unmounted volumes helps to detect possible errors as early as possible.

Thus, this flag helps to preserve file system consistency. Please note that even in case ‘dirty’

flag is set on the volume, file system is not necessarily corrupt.

Paragon NTFS&HFS+ for Linux drivers version 8 and newer support ‘dirty’ flag on both NTFS

and HFS+. By default, driver refuses to mount volumes with ‘dirty’ flag set. Recommended

course of action is to check the volume for errors and repair any inconsistencies found using

chkntfs/chkhfs utility with -a -f command line options (see Additional Utilities section). Run

with -a command line option, the utilities check dirty flag state and in case it is set, they

performs all necessary checks. If ‘dirty’ flag is not set, file system checking utilities exits

immediately. If -f command line option is specified, the utilities repair any errors or

inconsistencies that they find and finally clear ‘dirty’ flag. This approach is similar to the way

Windows and MacOS handle ‘dirty’ volumes. See corresponding sections on NTFS and HFS+

utilities and ‘File system checking utilities return codes' section for more information.

To make driver mount dirty volumes without checking for possible errors and correcting them,

‘force’ mount option can be used (while it is not recommended). This way, ‘dirty’ flag is not

cleared and any possibly existing errors or inconsistencies are not fixed. ‘Dirty’ flag will remain

set until volume is checked for errors using Paragon chkntfs/chkhfs with -f command line

option or using Windows chkdsk utility with /f switch or MacOS Disk Utility (for NTFS and

HFS+ volumes, respectively).

4.4 GPT issues

Some Linux Kernels do not behave correctly when there is EFI partition on GPT-partitioned

devices. This is most often the case with HDDs partitioned using MacOS Disk Utility.

This leads to seemingly wrong operation of UFSD driver(s) that refuse to mount partition. In

that case FDISK may report that there is only one EFI partition on the device, ignoring some or

all of the following NTFS and/or HFS+ partition(s). To work around the issue, attention must

be paid to volume type reported by fdisk –l command on GUID-partitioned disks.

Example:

/ # fdisk -l

Disk /dev/sda: 80.0 GB, 80026361856 bytes

255 heads, 63 sectors/track, 9729 cylinders

Units = cylinders of 16065 * 512 = 8225280 bytes

Device Boot Start End Blocks Id System

/dev/sda1 1 9730 78150743+ ee EFI GPT

fdisk reports that /dev/sda only contains single EFI partition that spans via entire disk. EFI

partitions are formatted as FAT32 and therefore cannot be mounted by NTFS/HFS+ driver(s).

Nevertheless, mounting partition /dev/sda2 to /mnt/hda succeedes:

/ # mount –t ufsd /dev/sda2 /mnt/hda

And after that mount command issued without arguments lists, among others, mounted

partition /dev/sda2 that was not listed by fdisk –l (marked with red below).

/dev/root on / type squashfs (ro)

none on /dev type devfs (rw)

USER MANUAL

16Using The Driver

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

none on /proc type proc (rw,nodiratime)

devpts on /dev/pts type devpts (rw)

none on /sys type sysfs (rw)

none on /tmp type ramfs (rw)

/dev/mtdblock/2 on /usr/local/etc type yaffs (rw,noatime)

/dev/rd/0 on /mnt/rd type vfat

(rw,nodiratime,fmask=0022,dmask=0022,codepage=cp437,iocharset=iso8859-1)

/dev/sda2 on /mnt/hda type ufsd

(rw,nodiratime,nls=iso8859-1,uid=0,gid=0,fmask=22,dmask=22,nocase)

/dev/scsi/host2/bus0/target0/lun0/part1 on /tmp/usbmounts/sdb1 type ufsd

(ro,nodiratime,nls=utf8,uid=0,gid=0,fmask=0,dmask=0)

Older Linux kernels do not support GPT at all. To work around this issue, Paragon

NTFS&HFS+ driver for Linux can read and parse GUID partitioning table and use it to mount

the first HFS+ partition on that disk. To mount the first HFS+ volume on GPT disk the

following command may be used:

/ # mount –t ufsd /dev/sda /mnt/hda

Please note that entire disk device is specified instead of specific partition. This approach may

only be used to mount the first HFS+ volume on GPT disks.

4.5 Issues with large HDDs

Though our driver supports partitions larger than 2 Tb (tested on 20 Tb partitions on real

hardware and on 25 Tb partitions in virtual environment), not all versions of Linux Kernels

support block devices larger than 2 Tb on all possible interfaces. E.g. Ubuntu 10.04 does not

support 2.5 Tb SATA HDD attached via USB->SATA converter, while the same HDD with the

same converter is mounted OK on Windows 7 and the same HDD connected to Ubuntu 10.04

via SATA interface can be mounted and used successfully.

If there is similar issue, please perform the test cases described above to make sure where the

root cause of the issue is (in Paragon's driver or in Linux Kernel).

4.6 Unmounting NTFS/HFS+ Partitions

To unmount a NTFS/HFS+ partition, use the standard command umount. For example:

umount /dev/sdb1

4.7 Choosing the codepage/charset for NTFS/HFS+ Partitions

The format of filenames on NTFS/HFS+ partitions differs from text standard presentation used

in Linux. To accommodate NTFS/HFS+ standards to Linux ones, character translation is

required. The character translation uses charset or codepage information for correct

translation non-English characters between NTFS/HFS+ and Linux.

Unfortunately Linux is unable to automatically detect NTFS/HFS+ codepage/charset/nls

settings. For this reason, the user must assign character set for filenames translation

manually.

The standard Linux command mount allows choosing the character set that is used for the

PARAGON SOFTWARE

17 Paragon NTFS&HFS+ for Linux 9.4

filenames translation, the codepage/charset/nls parameter is used for this purpose.

Examples:

1. Mounting a partition:

mkdir /mnt/test

mount -t ufsd /dev/sda6 /mnt/test

2. Dismounting a partition:

umount /mnt/test

3. Mounting partition in read-only mode:

mount -t ufsd -o ro /dev/sda6 /mnt/test

4. Choosing character set to be used with NTFS/HFS+ when mounting partitions manually:

mount -t ufsd -o nls=utf8 /dev/sdb1 /mnt/test

For more information on mount options please refer to the Mount options sub-section.

USER MANUAL

Part V

Mount options

PARAGON SOFTWARE

19 Paragon NTFS&HFS+ for Linux 9.4

This section describes mount options for mounting supported file system partitions.

5.1 Mount options

SYNOPSYS

mount –t ufsd [-o options] device mount_point

Option

S+

Expected behavior and examples

iocharset

nls

-o iocharset={NAME1}[,iocharset={NAME2}]

-o nls={NAME1}[,nls={NAME2}]

The NTFS/HFS+ file systems store all file/directory names in

Unicode format (UTF-16), which can represent any character from

any language. In case none of these options is set, the default

codepage will be used (CONFIG_NLS_DEFAULT). If none of the

specified codepages exist on the system, the default codepage will

be used again. This option informs the driver how to interpret path

strings and translate them to Unicode and back. Up to 8 different

code pages can be specified. The driver tries to use the codepages

from specified list in order until it manages to translate all the

characters in the string. If none of the specified codepages allows to

translate all the characters, Kernel’s default codepages is used.

Note:

Paragon driver uses extended UTF-8 for Unicode number

U+10000 characters support when ‘=utf8’ is specified.

Codepage, nls and iocharset mount option must be used in the

form: nls=cp... iocharset=cp...

Example:

nls=utf8

nocase

-o nocase

All file and directory operations (open, find, rename) are case

insensitive. Casing is preserved in the names of existing files and

directories.

showmeta

-o showmeta

Use this parameter to show all meta-files (System Files) on a

mounted NTFS/HFS+ partition. By default, all meta-files are hidden.

noatime

-o noatime

All files and directories will not update their last access time attribute

if a NTFS/HFS+ partition is mounted with this parameter. This option

can speed up file system operation.

uid

-o uid={USERID}

By default all files on a mounted NTFS/HFS+ volume are owned by

USER MANUAL

20Mount options

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

Option

S+

Expected behavior and examples

root. By specifying the uid parameter you can set an owner of files.

The userid can be any name from /etc/passwd, or any number

representing a user id.

gid

-o gid={GROUPID}

By default all files on a mounted NTFS/HFS+ volume are owned by

group root. By specifying the gid parameter you can set a owner

group of the files. The groupid can be any name from /etc/group, or

any number representing a group id.

umask

-o umask={VALUE}

The default permissions given to a mounted NTFS/HFS+ volume are

rwx------ (for security reasons). The umask option controls these

permissions for files/directories created after the volume is mounted.

mount –t ufsd /dev/hda1 /mnt/ntfs_0 –o umask=0222

fmask

dmask

-o fmask={VALUE}

-o dmask={VALUE}

umask option changes the permissions for new created files and

directories; fmask is applied to files; dmask to directories that already

exist on a mounted volume. The effect of these options can be

combined. To mount Samba, FTP or NFS shares the combination of

umask=000,fmask=000,dmask=000 is usually specified.

To mount an NTFS/HFS+ volume in read-only mode.

bestcompr

Instructs the driver to use highest compression level when writing

compressed files. High CPU-load.

nobuf

Disables buffered read/write operations for metadata and directories.

Useful option for embedded device with little memory (<64MB).

Note: this option is not supported on driver versions 8.2 and higher

sparse

Create new files as “sparse”. This feature allows creating holes

inside new created files (avoids filling unwritten space with zeroes).

This option is not recommended in case NTFS partition is used for

BitTorrent downloads.

force

Not recommended for use.

Forces the driver to mount partitions even if ‘dirty’ flag (volume dirty)

is set. It is recommended to use Paragon or OS-specific file system

checking utility before mounting ‘dirty’ partitions to reset the ’dirty’

flag.

Note that if ‘dirty’ volume was mounted with ‘force’ mount option, dirty

flag will not be cleared when volume is unmounted using umount

command.

nohidden

Files with the Windows-specific HIDDEN attribute will not be shown

under Linux.

PARAGON SOFTWARE

21 Paragon NTFS&HFS+ for Linux 9.4

Option

S+

Expected behavior and examples

sys_immutabl

Files with the Windows-specific SYSTEM attribute will be marked as

system immutable files.

acl

acl={1|0}

Support POSIX ACLs (Access Control Lists). Effective if supported by

Kernel. Not to be confused with NTFS ACLs

The option specified as acl or acl=1 enables support for POSIX

ACLs; acl=0 disables it.

user_xattr

user_xattr=

{1|0}

Support user.* extended attributes. Effective if supported by Kernel.

The options specified as user_xattr or user_xattr=1 enables

support for user.* extended attrubutes; user_xattr=0 disables it.

discard

Discard is the mount option in the UFSD driver, which is

recommended for use with the solid-state drives (SSD) to enable

support of the TRIM command for improved performance on delete

operations..

USER MANUAL

Part VI

Additional Utilities

PARAGON SOFTWARE

23 Paragon NTFS&HFS+ for Linux 9.4

Additional utilities for Paragon NTFS&HFS+ for Linux provide the ability to check integrity and

create NTFS/HFS+ volumes on block devices from your Linux OS. Additional utilities for

Paragon NTFS&HFS+ for Linux were developed with Paragon UFSD SDK.

6.1 NTFS utilities

There are 2 basic utilities for NTFS file system:

mkntfs — format any partition as NTFS under Linux;

chkntfs — check NTFS partition for integrity and (optionally) fix errors;

6.1.1 mkntfs

MKNTFS utility creates NTFS volumes (1.2, 3.0, 3.1 (Windows NT 4.0/2000/XP/2003/

Vista/7/8.1/10) file system) on user specified (block) device (disk partition) under Linux OS.

Synopsis

mkntfs [options] device

E.g.: mkntfs -f /dev/sdb1

Options

-v:label

Specify volume label.

-c

Files created on the new volume will be compressed by

default.

-a:size

Override the default allocation unit size. Default settings are

strongly recommended for general use. NTFS supports 512,

1024, 2048, 4096, 8192, 16K, 32K, 64K. File compression is

not supported for allocation unit size above 4096.

-b:size

Override the default block (sector) size. Default settings are

strongly recommended for general use. One can use 512,

1024, 2048, 4096.

-m:size

Override default MFT record size. Default settings are

strongly recommended for general use. One can use 512,

1024, 2048, 4096.

-j:size

Set journal size for Paragon journal on NTFS volume.

Supported sizes: from 1MB to 512MB. By default Paragon

journal for NTFS is disabled.

-f

Force the format without confirmation.

-s:start

Specify “hidden” sectors in the boot area.

-g:tracks:sectors

Specify disk geometry that should be written in the boot

area.

tracks

specifies number of tracks per disk side.

USER MANUAL

24Additional Utilities

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

sectors

specifies number of sectors per track.

The most popular geometries are:

NORMAL: 63 sectors per track and 15(16) tracks per

cylinder.

LBA: 63 sectors per track and 255 tracks per cylinder.

Generally Windows uses the LBA geometry (-g:255:63). If

–g is not specified, the utility obtains geometry from OS.

-winxp

Create NTFS compatible with Windows XP (default)

-winvista

Create NTFS compatible with Windows Vista

-win7

Create NTFS compatible with Windows 7

--help

Display this help.

--trace

Turn on UFSD trace.

--verbose

Explain what is being done.

--nopercents

Do not print percents during format process.

--version

Show the version and exit.

Description

mkntfs is a standalone utility that allows to format NTFS partitions under Linux. It is used to

create a NTFS 1.2, 3.0, 3.1 (Windows NT 4.0/2000/XP/2003/Vista/7/8.1/10) file system on a

device (usually a disk partition).

Note: mkntfs doesn’t change the MBR (Master Boot Record) when formatting a partition.

Therefore, most of Linux commands (like fdisk -l) will be unable to determine that partition’s

files system was changed to NTFS.

6.1.2 chkntfs

CHKNTFS utility performs consistency checking of NTFS volumes and (optionally) fixes

errors.

Synopsis

chkntfs [options] device

E.g.: chkntfs -f /dev/sdb1

Options

-fs:ntfs

Treat target volume as NTFS (parameter set by default if

chkntfs utility used)

-fs:hfs

Treat target volume as HFS+ (parameter set by default if

chkhfs utility used)

-f

Fix errors on the disk.

-a

Perform checks only if ‘dirty’ flag is set.

PARAGON SOFTWARE

25 Paragon NTFS&HFS+ for Linux 9.4

-b:size

Override default block (sector) size). Usage of default

settings are strongly recommended. The '-b' parameter can

use following values: 512, 1024, 2048, 4096.

-m:size

Set a limit for memory usage during file system check. Usage

of this parameter may lower file system check performance.

-h

Display this help.

-m:size

Memory limit used by the utility

--short

Minimum file system check

--safe

Errors are not fixed, dirty flag is cleared if no errors found

--showminors

Show minor errors.

--no-orphans

Do not restore real orphan files

--trace

Turn on UFSD trace.

--verbose

Explain what is being done.

--nopercents

Do not print percents during checking process.

--version

Show version and exit.

Description

chkntfs creates and displays a status report about a NTFS file system. Chkntfs also lists

and corrects errors on the disk, if any (-f flag must be specified).

Note:

1) when --no-orphans option is used, real orphan files will be deleted. Without this option chkntfs

restores real orphan files to found.XXX folders.

2) Starting from NTFS&HFS+ for Linux 9.4 separate chkntfs utility is the symlink to the combined

chkufsd utility, which can perform checking and/or fixing of both NTFS and HFS+ volumes.

6.2 HFS+ utilities

There are 2 additional utilities for HFS+ file system:

mkhtfs — format any partition as HFS+ under Linux;

chkhfs — check HFS+ partition for integrity and (optionally) fix errors.

6.2.1 mkhtfs

MKHFS Utility - Create an HFS+ volume on a partition.

Name

mkhfs — create an HFS+ volume on specified (block) device under Linux OS.

Synopsis

USER MANUAL

26Additional Utilities

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

mkhfs [options] device

E.g.: mkhfs -j /dev/hdb1

Options

-v:label

Specify the volume label.

-a:size

Override the default allocation unit size. Default settings are strongly

recommended for general use.

HFS+ supports 512, 1024, 2048, 4096, 8192, 16K, 32K and 64K.

-ne:size

Specify extents b-tree node size: 512-32K.

-nc:size

Specify catalog b-tree node size: 4K-32K.

-na:size

Specify attributes b-tree node size: 4K-32K

-f

Force the format without confirmation.

-j

Make volume journalized with default journal size

-j:size

Make volume journalized, manually setting size of the journal

-c

Make volume case-sensitive.

-h

Display this help

--help

Display this help.

--trace

Turn on UFSD trace.

--verbose

Explain what is being done.

--nopercents

Do not print percents during format process.

--version

Show the version and exit.

Description

mkhfs is a standalone utility that allows to format HFS+ partitions under Linux. It is used to

create an HFS+ file system on a device (usually a disk partition).

6.2.2 chkhfs

CHKHFS Utility - Perform consistency checks on an HFS+ volume.

Name

chkhfs — provide consistency checking of a HFS+ volume and fix errors.

Synopsis

chkhfs [options] device

E.g.: chkhfs -f /dev/sdb1

PARAGON SOFTWARE

27 Paragon NTFS&HFS+ for Linux 9.4

Options

-fs:ntfs

Treat target volume as NTFS (parameter set by default if

chkntfs utility used)

-fs:hfs

Treat target volume as HFS+ (parameter set by default if

chkhfs utility used)

-f

Fix errors on the disk.

-a

Perform checks only if ‘dirty’ flag is set.

-b:size

Override default block (sector) size). Usage of default

settings are strongly recommended. The '-b\ parameter can

use following values: 512, 1024, 2048, 4096.

-m:size

Set a limit for memory usage during file system check. Usage

of this parameter may lower file system check performance.

-h

Display this help.

-m:size

Memory limit used by the utility

--short

Minimum file system check

--safe

Errors are not fixed, dirty flag is cleared if no errors found

--showminors

Show minor errors.

--no-orphans

Do not restore real orphan files

--trace

Turn on UFSD trace.

--verbose

Explain what is being done.

--nopercents

Do not print percents during checking process.

--version

Show version and exit.

Description

chkhfs creates and displays a status report about a HFS+ file system. Chkhfs also lists and

corrects errors on the disk, if any (-f flag must be specified).

Note: Starting from NTFS&HFS+ for Linux 9.4 separate chkhfs utility is the symlink to the combined

chkufsd utility, which can perform checking and/or fixing of both NTFS and HFS+ volumes.

USER MANUAL

Part VII

Troubleshooting

PARAGON SOFTWARE

29 Paragon NTFS&HFS+ for Linux 9.4

This section highlights troubleshooting processes.

7.1 Troubleshooting processes

Step 1. Consult Documentation

Please consult documentation to make sure that encountered behavior is not by design, with

special attention given to the part related to installation, testing and troubleshooting as well as

to section on System requirements . Please also review Mount toubleshooting and Using

The Driver subsection.

Step 2. Make sure the issue is not related to Linux itself

Now, make sure that root cause of the issue is not related to Linux itself. For example, if an

issue is discovered while performing certain file system-related operation on a volume

mounted with Paragon NTFS&HFS+ driver, make sure the same issue is not observed when

the same operation is performed on ‘native’ file system like Ext2fs, Ext3fs or FAT (except, of

course, for operations specific to NTFS or HFS+ file systems or to Paragon's driver itself, e.g.

IOCTLs, additional utilities and so on).

Step 3. Prepare to report the issue

After performing previous steps and making sure that the issue is related to Paragon

NTFS&HFS+ driver, prepare to report the issue to Paragon.

Collect all information on the issue

The most important point in issue resolution process is quickly obtaining all the information

related to the issue. Quick collection of required information is the key to resolving an issue

faster.

Step 4. Assist Paragon engineers to resolve the issue quickly

Please provide any firmware updates required to reproduce the issue together with information

on how to upgrade firmware in your hardware samples. Try to provide as detailed information

on the issue, as possible.

6 30

USER MANUAL

30Troubleshooting

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

7.2 Mount toubleshooting

Use our mount troubleshooting diagram for faster mount issue resolution.

7.3 The install.sh script can’t find kernel sources

1. Read system requirements section, make sure all tools are functional. For more information,

please read kernel documentation.

2. Linux kernel must be configured correctly.

3. Make sure that you have kernel sources, for example, in the /usr/src/linux-x.x.xx

directory, where x.x.xx is your kernel version (for example, 4.4.9). Type uname-r in the

command line to know your current kernel version.

4. Create a symbolic link from the /usr/src/linux-x.x.xx directory to /usr/src/linux.

To create the link type ln –s /usr/src/linux-$(uname-r) /usr/src/linux .

PARAGON SOFTWARE

31 Paragon NTFS&HFS+ for Linux 9.4

5. Make sure that you have the config-x.x.xx file, for the booted Linux kernel, in the /boot

directory. If you haven’t the config-x.x.xx file then type ln –s /usr/src/

linux-$(uname-r)/.config /boot/config-$(uname –r) to create a symbolic link to

the config file.

Note: There are cases when the kernel sources may be located in other directories. In these

cases you should create a symbolic link to /usr/src/linux, for example, ln –s /lib/

modules/$(uname-r)/build /usr/src/linux .

If you still have the same problem i.e. the install.sh script can’t find the kernel sources it is

better to rebuild your kernel or download and build a stable kernel from the www.kernel.org

site.

7.4 Can’t compile the NTFS/HFS+ for Linux driver

1. Read System requirements section, make sure all tools are functional. For more information,

please read kernel documents.

2. Linux kernel must be configured correctly.

3. The /boot directory must contain the config-(kernel version) file. If the file is missing you

should execute the following command: ln –s /usr/src/linux-$(uname-r)/.config /

boot/config-$(uname –r).

7.5 “Can’t load module” message at the end of installation

1. Make sure that you use the same version of GCC compiler that was used for kernel

compilation.

2. Make sure that the Makefile of the kernel (you can find the Makefile in the directory

where the kernel sources are located) have the correct kernel version at the beginning of

the file. For example: if your loaded kernel version is 4.4.9-300.fc23.x86_64 then the

following lines must be found at the beginning of the Makefile:

VERSION = 4

PATCHLEVEL = 4

SUBLEVEL = 9

EXTRAVERSION = -300.fc23.x86_64

7.6 ufsd Module: kernel-module version mismatch

That means kernel version mismatch.

1. Check kernel source version in /usr/include/linux/version.h

2. Check the currently running kernel version: uname -r

3. Both version must match.

4. If they don’t match, please restore Kernel configuration or recompile kernel (advanced).

USER MANUAL

32Troubleshooting

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

7.7 ufsd Module: create_module: operation is not permitted

That means you must have root privilege to load driver.

7.8 insmod: a module named as ufsd already exists

That means driver have been loaded. There is no need to load it again.

Driver status can be found by using the following command: lsmod | grep ufsd

7.9 insmod: Unknown symbol jnl_op (err 0)

That means one is trying to load ufsd.ko module into the Linux Kernel before jnl.ko module

has been loaded:

# insmod ufsd.ko

insmod: ERROR: could not insert module ufsd.ko: Unknown symbol in module

# dmesg | tail

[84199.673358] ufsd: Unknown symbol jnl_op (err 0)

Load jnl.ko module first and ufsd.ko afterwards:

# insmod jnl.ko

# insmod ufsd.ko

# lsmod | grep ufsd

ufsd 614400 0

jnl 36864 1 ufsd

7.10 I can’t mount NTFS/HFS+ volume

1.Make sure that the driver is activated (loaded into the Kernel): lsmod | grep ufsd

2.Make sure that the driver supports file system mounted partition is formatted with:

cat /proc/fs/ufsd/version

3.The volume is dirty. Use chkntfs/chkhfs utility with –a –f command line options to reset ‘

dirty’ flag. Alternatively, use ‘force’ mount options to make the driver ignore ‘dirty’ flag.

7.11 Collecting logs using release build of the driver user

Additional logs in the NTFS&HFS+ for Linux driver are used to collect information on driver’s

internal operations. This information is very important for faster issue resolution. In some

cases, with log files available reproduction of the issue at Paragon's lab is not needed at all,

that will save a lot of time. Please collect logs and send them to Paragon together with issue

report.

PARAGON SOFTWARE

33 Paragon NTFS&HFS+ for Linux 9.4

For easier logs collection on customer's side, we have added trace functionality to the release

ufsd.ko driver module.

Driver settings related to logging

Logs collection can be set up when driver is loaded into the platform (with the insmod

command), during volume mount (similar to the debug driver usage) or manually via the /proc

files usage:

# insmod ufsd.ko trace=all log=/tmp/ufsd.log

# mount -t ufsd -o trace=all,log=/tmp/ufsd_trace.log

# echo "/tmp/ufsd_trace.log" > /proc/fs/ufsd/log

# echo "all" > /proc/fs/ufsd/trace

where trace - level of tracing messages (possible values are: all, vfs, or hex value can be

used, e.g.: 0xffffffff)

log - path to log file

Trace and log parameters can be verified and changed on the fly, while NTFS&HFS+ for

Linux driver is in use, via /proc interface:

Trace option

To verify current settings for the trace option use the /proc/fs/ufsd/trace metafile:

# cat /proc/fs/ufsd/trace

all

To change trace settings use the echo command to provide new value:

# echo "vfs" > /proc/fs/ufsd/trace

# cat /proc/fs/ufsd/trace

vfs

Log option is altered the same way

To verify current settings for the log option use the /proc/fs/ufsd/log metafile:

# cat /proc/fs/ufsd/log

/tmp/ufsd_trace.log

To change log settings use the echo command to provide new value:

# echo "/root/ufsd_trace.log" > /proc/fs/ufsd/log

# cat /proc/fs/ufsd/log

/root/ufsd_trace.log

Collecting driver logs

Please note that log file must not be stored on any volume that is mounted using Paragon

driver because that will cause infinite recursion and then stack overflow.

If NTFS&HFS+ for Linux driver module (ufsd.ko) is loaded into the platform manually, logs

collection can be enabled, when driver module is loaded into the Kernel:

# insmod ufsd.ko trace=all log=/tmp/ufsd.log

If NTFS&HFS+ for Linux driver is already loaded into the system, logs collection can be

enabled:

USER MANUAL

34Troubleshooting

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

using the /proc file interface:

# echo "/tmp/ufsd_trace.log" > /proc/fs/ufsd/log

# echo "all" > /proc/fs/ufsd/trace

using mount command options:

mount the test volume adding the following options to the list of mount options used on your

system:

–o trace=all,log=/path-to-log-file/on-non-ufsd-mounted-volume

After NTFS&HFS+ for Linux driver logs are enabled, perform reproduction steps for the issue,

so driver operations are written into the log file.

After the issue is reproduced, unmount the volume, unload ufsd.ko and jnl.ko driver

modules (to flush and close log file), compress driver’s log file and send it to Paragon along

with the issue report and log of reproduction steps.

Use case examples:

When issue reproduction takes a lot of time, but platform is halted after it happens (e.g. in

case of the Kernel panic issues) additional 'cycle=<log file size>' mount option are

recommended for usage, so UFSD logs are added to the file of the fixed size. New logs

would be written instead of older ones, when logs file size is reached, e.g.:

# mount -t ufsd -o trace=all,cycle=100M,log=/tmp/ufsd_trace.log

In this case file limit for the UFSD logs file is 100 MB.

If there are several operation need to be made, before reproducing the issue, additional

logging could be turned on/off on the fly via /proc/fs/ufsd/trace parameters.

For example when logging is already activated and is needed to be temporary turned off:

# cat /proc/fs/ufsd/trace

all

# echo "0" > /proc/fs/ufsd/trace

# cat /proc/fs/ufsd/trace

# echo "all" > /proc/fs/ufsd/trace

# cat /proc/fs/ufsd/trace

all

In the UFSD driver log file you will see trace level information:

trace mask set to 5fffbf7f (when trace level is set to 'all')

trace mask set to 00000000 (when trace logs are turned off)

trace mask set to 5fffbf7f (when trace level is returned to 'all')

7.12 Sysdump utility

Collecting images of volumes with file system inconsistencies

In case Paragon chk*fs utilities cannot fix metadata inconsistencies on NTFS/HFS+ volumes,

or report that volume is OK while it is obviously not so (e.g. content of NTFS volume cannot be

read under MS Windows or HFS+ volume cannot be read under MacOS), sysdump utility can

PARAGON SOFTWARE

35 Paragon NTFS&HFS+ for Linux 9.4

be used to capture very compact images of volumes with file system inconsistencies along

additional system information, which would be automatically compacted into single archive.

This archive then may be forwarded to Paragon via support service for analysis. This helps us

to improve our products.

Using the sysdump utility to collect both platform system information and

metadata image of the affected volume

Note that sysdump utility requires root privileges as they are needed for working with

storage devices on Linux platform.

1. Copy sysdump utility to a folder with read/write access.

2. In terminal change to the folder with the sysdump utility. Use the following command to

capture the metadata image and to collect platform system information:

./sysdump /path/to/partition

3. This will create an archive named, based on platform parameters <Architecture>.<Kernel

version>.<date>.tar with storage device metadata image, its md5 sum and sample system

information:

$ sudo ./sysdump /dev/sdf1

Collecting dump of file system...

Scanning NTFS...

Added 3 files/dirs from $Extend

Recognized as NTFS.

Dumping "/dev/sdf1" (931.48 Gb) ...

Dump finished. File size 598602752 bytes (including tail)

System information was saved to /home/user/UFSD_driver/

ufsd_driver_Retail_Professional_UFSD_HEAD_r278264_b804/linutil/objfre/

bin/x86_64.4.4.9.20160601.tar

Changing the name of output archive

Name of the output archive can be changed by using the additional ’-o’ parameter and adding

new file name.

For example: ./sysdump /dev/sdc1 -o test.tar

Scanning NTFS...

Added 13 files/dirs from $Extend .

Recognized as NTFS.

Dumping "/dev/sdc1" (465.76 Gb) ...

Dump finished. File size 1248334848 bytes (including tail)

Collecting system information...

System information was saved to /home/UFSD_utilites/test.tar

Output file description

The Sysdump utility creates a single tar archive in the working folder with its’ work results for

easier data transfer to Paragon team. This archive can be easily uncompressed with the tar

utility, e.g.:

# tar -xf ./x86_64.3.11.9.20131211.tar

There are several files inside archive:

USER MANUAL

36Troubleshooting

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

dmesg - contents of the ’dmesg’ command output;

dumpbin.gz - compressed metadata image of the test volume;

dumpbin.md5 -md5 checksum for the collected image itself, not the archive file;

modules - list of all Kernel modules (*.ko files) found on the platform;

sysinfo - file with platform system information: list of storage devices, Linux Kernel version,

version of the loaded UFSD driver, CPU, memory information, etc.

Delivering collected data to Paragon

Please send the tar file, generated by the ’Sysdump’ utility to your support contact at Paragon

Software via ’My account’ page at Paragon Software Support Portal.

Paragon’s Sysdump utility doesn’t collect any personal or user-sensitive information. Platform

data is obtained via usage of the native Linux utilities and standard system files (e.g. fdisk,

parted, /proc/cpuinfo, /proc/meminfo and others). The resulted volume metadata image

includes only file system metadata and risk of leaking sensitive data when using the sysdump

utility is minimized. Nevertheless, collected information is also covered by the mutual Non-

disclosure agreement and couldn’t be forwarded to any third party.

PARAGON SOFTWARE

PartVIII

UFSD driver

compatibility

USER MANUAL

38UFSD driver compatibility

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

This section describes file system features supported by Paragon NTFS&HFS+ driver,

respectively.

8.1 NTFS features

Compressed files

Reading and writing compressed files is fully supported in both sequential and random orders.

Encrypted files

Encrypted files are read encrypted. During copy operation, file data streams will be copied

encrypted with loss of decryption capability.

Alternate data streams

When copying from NTFS to Linux FS: all additional streams will not be copied, along with

compression flag and security attributes.

Hardlinks and symlinks

Any link will be copied as a full file with its body, losing link information.

Maximum filename length

NTFS stores filenames in UTF-16 encoding. This may cause trouble when very long filenames

containing non-latin characters are used and UTF-8 is selected as default Kernel codepage.

8.2 HFS+ features

This section describes features of HFS+ file system supported by the driver.

Case sensitivity

Both case sensitive and case instensitive types of HFS+ file system are supported.

Alternate data streams (forks)

During file copy operation (using cp command) on Linux only ‘data’ fork is copied.

PARAGON SOFTWARE

Part IX

Frequently Asked

Questions

USER MANUAL

40Frequently Asked Questions

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

9.1 What are 'minor errors' reported by chkntfs utility?

Most of information about files (times, sizes, attributes) in NTFS is duplicated and triplicated.

Minor error means that copies does not match original. E.g. "latime" means last access time.

The native chkdsk from Microsoft does not show these mismatches and fixes it silently (if /f is

specified) — see http://technet.microsoft.com/en-us/library/cc959914.aspx. Paragon chkntfs

utility can also find the following minor errors:

mdtime — modification time

chtime — last change time

asize — data allocated size

dsize — data size

attrib — attributes

To see more verbose output on minor errors, use --showminors command line option when

running chkntfs. For an example output, please see the log below:

# chkntfs --showminors /dev/sda2

WARNING! f parameter not specified.

Running chkntfs in read-only mode.

Checking Volume /dev/sda2...

Verifying 1680 records ...

$UpCase file is formatted for use in Windows NT/2K/XP Verifying 161

folders ...

minor error " latime" in index 0x5 "." => "admin"

minor error " latime" in index 0xb "$Extend" => "$Reparse"

minor error " latime" in index 0x1f "public" => "EZ TALK.doc"

minor error " latime" in index 0x1f "public" => "Fedora-13-i686-Live-

KDE"

minor error " latime" in index 0x1f "public" => "Fedora-13-x86_64-Live"

minor error " latime" in index 0x1f "public" => "FEDORA~1"

minor error " latime" in index 0x1f "public" => "FEDORA~2"

minor error " latime" in index 0x1f "public" => "FTP_login _information.

doc"

minor error " latime" in index 0x1f "public" => "Reports"

minor error " latime" in index 0x1f "public" => "... 2 K.M..b."

minor error " latime" in index 0x1f "public" => "...~1"

minor error " mdtime chtime latime" in index 0x5bd

"_restore{FB5EFA8E-F7E1-4999-B498-21EEC0CF7124}" => "RP83"

minor error " latime" in index 0x676 "mungchacha_com .+LC Kung Fu Dunk"

=> "DISC2.DAT.bc!"

minor error " latime" in index 0x676 "mungchacha_com .+LC Kung Fu Dunk"

=> "DISC2D~1.BC!"

Verifying files security...

4.83 Gb in 1492 files

464 Kb in 163 directories

0 Kb in bad blocks in 0 fragments

90424 Kb in use by the system

PARAGON SOFTWARE

41 Paragon NTFS&HFS+ for Linux 9.4

65536 Kb occupied by the log file

4096 bytes in each allocation unit

182879943 total allocation units on volume

181590430 allocation units available on volume

The volume /dev/sda2 contains minor error(s).

9.2 Warnings on Windows7/Vista when NTFS HDD is reconnected

from Linux

After NTFS volume previously operated by Paragon NTFS&HFS+ driver is attached to

Windows Vista/Windows 7 machine, warnings are displayed on the screen. Why?

This is the case when volume was not unmounted correctly before it was detached from Linux

system.

This section illustrates ‘dirty’ volumes handling as implemented in Windows 7. For more

information on dirty flag and its support in Paragon file system drivers products see ‘Dirty flag

issues’ subsection of Using The Driver section.

An USB HDD enclosure with 320 Gb SATA HDD with one NTFS partition was detached from

system while file copy operation was in progress. After the enclosure was attached to

Windows 7 PC again, the following dialog was displayed:

After user clicks ‘Scan and fix (recommended)’, scan process begins:

USER MANUAL

42Frequently Asked Questions

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

After checking is completed, the following summary window is displayed:

After user clicks ‘Details’, the window is expanded and more detailed information is displayed

to the user:

PARAGON SOFTWARE

43 Paragon NTFS&HFS+ for Linux 9.4

In case there are no errors, the following information is displayed:

9.3 Recently changed file has its modification time a few hours

ahead of or behind the current system time. Why?

This offset occurs due to the fact that NTFS stores file times as UTC time (in contrast to FAT

that stores local time) and the system might not have time zone setting that can be read by C

library and then used to convert file times reported by Kernel to local time.

Consequently, if a file is written to an NTFS volume on Windows with time zone set to, say,

UTC+8, and then the volume is connected to the Linux system, C library reports values

provided by Kernel ‘as is’ without converting them to local time. However, if a file is modified

on the Linux system, its modification time is written to the file system as system’s current time

USER MANUAL

44Frequently Asked Questions

PARAGON Technologie GmbH, Systemprogrammierung

Heinrich-von-Stephan-Str. 5c • 79100 Freiburg, Germany

Tel. +49 (0) 761 59018201 • Fax +49 (0) 761 59018130

www.paragon-software.com • sales@paragon-software.com

and then it is reported correctly. In the latter case, after the file modified on the Linux system is

brought back to the Windows machine (with its local time zone set to UTC+8), the file's

modification time will be reported 8 hours ahead of current time (assuming that current time is

the same on the Linux system and Windows PC).

There is 'bias' mount option (see Mount Options subsection) that allows to work around the

issue on systems that do not have time zone setting readable by C standard library (first

introduced in version 8.1.023). However, we recommend that time zone setting that can be

used by C standard library to convert time values, is added to the Linux system.

9.4 Why does mount option A make driver ignore mount option B?

When you mount disk with several mount options driver may ignore some of them. Why?

This issue can happen when mount command is used with several options coded like:

mount -t ufsd -o option A,option B -o option C device mount point

In this case driver may ignore options A and B when mounting disk with option C.

To prevent this possibility it is recommended to write your commands with several options

like:

mount -t ufsd -o option A,option B,option C device mount point

9.5 Why a lot of memory is used for volume mounting?

Let me describe what’s going on when UFSD driver mounts volumes.

First of all, the driver must read file system boot record, and after verifying it, it must also read

some metadata from the mounted volume, namely, parts of $Mft and the entire $Bitmap

metafile. For example, if the volume has $Bitmap of 74 MB, the driver has to read not less

than 74MB to mount it. When our driver reads data from disk, Kernel keeps the data cached in

memory. The amount of memory that Kernel allocates for I/O buffers is printed in line #3 of /

proc/meminfo file (Buffers: XXXX kB). It’s up to Kernel to decide how much memory to

allocate for I/O buffers (this can be tuned via Kernel metafiles – please see the link below for

more information). The memory (allocated for ‘Buffers’) is normally reclaimed by kernel when

Kernel or an application needs to allocate some memory for ‘private’ use.

The real-time report on memory allocated by our driver for operations on specific partition that

is currently mounted, is available in line #2 of file /proc/fs/ufsd/<block_device_name>/

volinfo. Peak amount of memory allocated by UFSD driver when mounting NTFS volume is

around 250 KB. The amount then reduced to ~40 KB after mount operation is completed.

9.6 Why the disk can't be dismounted?

When you try to dismount the disk with the 'umount' command the volume is reported 'busy'

and can't be unmounted. Why?

This issue can happen when there are working processes, that are still using the volume.

Therefore, there are several options to remove the conditions that prevent the storage medium

from being unmounted:

PARAGON SOFTWARE

45 Paragon NTFS&HFS+ for Linux 9.4

1. Check if it is possible to safely unmount the storage using the system’s web interface.

2. Check if support for external storage can be disabled from the system's web interface.

Disable the services and retry unmounting the storage medium.

3. Check if the various file/media sharing services (like multimedia, SAMBA (SMB), AFP, etc)

can be disabled from the system's web interface. Disable the services and retry unmounting

the storage medium.

Notes:

Windows system keeps SAMBA connection to the storage for several minutes. Disable the

connection and retry to unmount the storage medium. For example in Windows XP it can be

done from 'Disconnect network drive' menu (e.g. 'My computer' -> 'Tools' -> '

Disconnect Network Drive' menu).

If the volume couldn't be unmount with these steps, use 'sync' command to flush buffers to the

storage medium before detaching it manually from the device.

Paragon NTFS&HFS+ For Linux 9.4 NTFS Operating Instructions Hfs 9 4 En

Navigation menu

Versions of this User Manual:

Views

Navigation
