DAIMLER REMOTE CONTROL
USER MANUAL
Model
2738-xxx
Documentstatus: Open
Editor: Thomas Fischer
Document Title: Daimler Remote Control User Manual 28.08.2011
ruwido austria GmbH UserManual.doc 2/4
i. Revision Status
Version
Date
Author
Comment
1.0
20.08.2012
Th. Fischer
Created
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
Document Title: Daimler Remote Control User Manual 28.08.2011
ruwido austria GmbH UserManual.doc 3/4
1 Table of Contents
i. Revision Status ................................................................................................................................ 2
1 Table of contents .............................................................................................................................. 3
2 About this document ......................................................................................................................... 4
3 Startup .............................................................................................................................................. 4
4 Association ....................................................................................................................................... 4
5 Transmitting data .............................................................................................................................. 4
Document Title: Daimler Remote Control User Manual 28.08.2011
ruwido austria GmbH UserManual.doc 4/4
2 About this document
The following document describes the use of the remote control model 2738.
3 Startup
The remote control is battery operated. Please insert two fresh AAA batteries in the battery
compartment on the back side of the remote.
The indication LED above the mode wheel indicates the battery status after each button press. If the
LED blinks red after a button press the batteries should be replaced.
4 Association
To associate the remote with the receiving unit the buttons “ON” and “#” should be pressed
simultaneously while the receiving unit is also in association mode. The indication LED blinks red
during the association process and then blinks green when the association has finished successfully.
If the association is not successful after 30 sec. the association process stops and the red indication
LED stops blinking.
5 Transmitting data
After the association process has finished successfully the remote control send data after each button
press and while turning the navigation wheel. A successful transmission is indicated by the green
indication LED. An unsuccessful transmission is indicated by the orange indication LED.
Turning the mode wheel changes the mode in which the remote works; it does not send any data.
