ruwido austria 790B Remote Control with BT 4.0 Low Energy User Manual CONFIDENTIAL
ruwido austria GmbH Remote Control with BT 4.0 Low Energy CONFIDENTIAL
Users Manual
ruwido austria gmbh . Köstendorfer Str. 8 . Austria . t +43 6216 4571-0 . www.ruwido.com Page 1 of 3
product type. 2790-500
Revision Status
Version
Creation Date
Author
Remarks
V0.1
2016-08-29
Ralph Leblhuber
Initial version
remote control user guide
ruwido austria gmbh 2790 RCU guide-2016-08-29.docx Page 2 of 3
1 manual pairing
power on STB
press "play/pause" and "vod" keys for 3 sec to start pairing process (continues red
flashing)
LED will stop flashing red if pairing was successful
to delete pairing from remote control press “rewind” and “fast forward” keys for 3
seconds to delete pairing
LED will flash 4 times red if pairing deletion was successful
2 switching between modes
press and hold for a minimum of 3 seconds
apps + up (for BLE/rstep ) factory default setting
apps + down (for rstep) IR fallback mode
green LED flashes twice
3 factory settings
to set remote control back to factory mode press and hold “apps” + “prev” key for a
minimum of 3 seconds
green LED flashes twice
factory default setting: BLE mode (rstep)
pairing information will remain if batteries are being removed / changed
mode settings will remain if batteries are being removed / changed
ruwido austria gmbh 2790 RCU guide-2016-08-29.docx Page 3 of 3
DECLARATION
User Information FCC 15.2:
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Part 15 Statement. FCC 15.19/RSS Gen Issue 3 Sect. 7.1.3
This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Statement Class B Digital Device FCC 15.105:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
o Reorient or relocate the receiving antenna.
o Increase the separation between the equipment and receiver.
o Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
o Consult the dealer or an experienced radio/ TV technician for help.
