VMware vCenter Converter Standalone
User's Guide
vCenter Converter Standalone 5.0
This document supports the version of each product listed and
supports all subsequent versions until the document is replaced
by a new edition. To check for more recent editions of this
document, see http://www.vmware.com/support/pubs.
EN-000408-00
VMware vCenter Converter Standalone User's Guide
2 VMware, Inc.
You can find the most up-to-date technical documentation on the VMware Web site at:
http://www.vmware.com/support/
The VMware Web site also provides the latest product updates.
If you have comments about this documentation, submit your feedback to:
docfeedback@vmware.com
Copyright © 2008–2011 VMware, Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. VMware products are covered by one or more patents listed at
http://www.vmware.com/go/patents.
VMware is a registered trademark or trademark of VMware, Inc. in the United States and/or other jurisdictions. All other marks
and names mentioned herein may be trademarks of their respective companies.
VMware, Inc.
3401 Hillview Ave.
Palo Alto, CA 94304
www.vmware.com
Contents
About This Book 5
1Introduction to VMware vCenter Converter Standalone 7
Migration with Converter Standalone 7
Converter Standalone Components 8
Cloning and System Configuration of Physical Machines 8
Types of Data Cloning Operations 13
Using Converter Standalone with Virtual Machine Sources and System Images 16
System Settings Affected by Conversion 16
Changes to Virtual Hardware 17
2System Requirements 19
Supported Operating Systems 19
Installation Space Requirements 20
Screen Resolution Requirements 21
Supported Source Types 21
Supported Destination Types 23
Restoring VCB Images in Converter Standalone 24
Configuring Permissions for vCenter Users 25
Support for IPv6 in Converter Standalone 25
TCP/IP and UDP Port Requirements for Conversion 26
Requirements for Remote Hot Cloning of Windows Operating Systems 27
3Installing and Uninstalling Converter Standalone 31
Perform a Local Installation on Windows 31
Perform a Client-Server Installation in Windows 32
Perform a Command-Line Installation in Windows 34
Command-Line Options for Windows Installation 34
Modify Converter Standalone in Windows 35
Repair Converter Standalone in Windows 36
Uninstall Converter Standalone in Windows 37
Connect to a Remote Converter Standalone Server 37
4Convert a Physical or Virtual Machine 39
Start the Wizard for a Conversion 40
Select a Source Machine to Convert 40
Select a Destination for the New Virtual Machine 46
Configure the Hardware of the Destination Virtual Machine 49
Configure the Software on the Destination Virtual Machine 61
Configure the Conversion Job 66
Review the Summary and Submit the Conversion Job 71
VMware, Inc. 3
5Configure Virtual Machines 73
Save Sysprep Files 73
Start the Configuration Wizard 74
Select a Source Machine to Configure 74
Select the Options to Configure 77
Review and Submit the Configuration Job 81
6Manage Conversion and Configuration Jobs and Tasks 83
Manage Jobs in the Job List 83
Manage Tasks in the Task List 87
Verify Jobs and Tasks Progress and the Log Files 89
Index 91
VMware vCenter Converter Standalone User's Guide
4 VMware, Inc.
About This Book
The VMware vCenter Converter Standalone User's Guide provides information about installing and using
VMware®vCenter Converter Standalone 5.0.
Intended Audience
This book is intended for users who want to perform the following tasks:
nInstall, upgrade, or use Converter Standalone
nNonintrusively copy and transform physical machines into VMware virtual machines that VMware
vCenter manages
The material in this book is written for information systems engineers, software developers, QA engineers,
trainers, salespeople who run demonstrations, and anyone who wants to create virtual machines.
VMware Technical Publications Glossary
VMware Technical Publications provides a glossary of terms that might be unfamiliar to you. For definitions
of terms as they are used in VMware technical documentation, go to http://www.vmware.com/support/pubs.
Document Feedback
VMware welcomes your suggestions for improving our documentation. If you have comments, send your
feedback to docfeedback@vmware.com.
VMware, Inc. 5
Technical Support and Education Resources
The following technical support resources are available to you. To access the current version of this book and
other books, go to http://www.vmware.com/support/pubs.
Online and Telephone
Support
To use online support to submit technical support requests, view your product
and contract information, and register your products, go to
http://www.vmware.com/support.
Customers with appropriate support contracts should use telephone support
for the fastest response on priority 1 issues. Go to
http://www.vmware.com/support/phone_support.html.
Support Offerings To find out how VMware support offerings can help meet your business needs,
go to http://www.vmware.com/support/services.
VMware Professional
Services
VMware Education Services courses offer extensive hands-on labs, case study
examples, and course materials designed to be used as on-the-job reference
tools. Courses are available onsite, in the classroom, and live online. For onsite
pilot programs and implementation best practices, VMware Consulting
Services provides offerings to help you assess, plan, build, and manage your
virtual environment. To access information about education classes,
certification programs, and consulting services, go to
http://www.vmware.com/services.
VMware vCenter Converter Standalone User's Guide
6 VMware, Inc.
Introduction to VMware vCenter
Converter Standalone 1
VMware® vCenter Converter Standalone is a scalable solution to convert virtual and physical machines to
VMware virtual machines. You can also configure existing virtual machines in your vCenter Server
environment.
Converter Standalone eases the exchange of virtual machines among the following products.
nVMware hosted products can be both conversion sources and conversion destinations.
nVMware Workstation
nVMware Fusion™
nVMware Server
nVMware Player
nVirtual machines running on an ESX instance that vCenter Server manages can be both conversion sources
and conversion destinations.
nVirtual machines running on unmanaged ESX hosts can be both conversion sources and conversion
destinations.
You can also use VMware Consolidated Backup (VCB) images to create VMware virtual machines.
This chapter includes the following topics:
n“Migration with Converter Standalone,” on page 7
n“Converter Standalone Components,” on page 8
n“Cloning and System Configuration of Physical Machines,” on page 8
n“Types of Data Cloning Operations,” on page 13
n“Using Converter Standalone with Virtual Machine Sources and System Images,” on page 16
n“System Settings Affected by Conversion,” on page 16
n“Changes to Virtual Hardware,” on page 17
Migration with Converter Standalone
Migration with Converter Standalone involves converting physical machines, virtual machines, and system
images for use in VMware hosted and managed products.
You can convert virtual machines that vCenter Server manages for use in other VMware products. You can
use Converter Standalone to perform a number of conversion tasks.
nImport running remote physical and virtual machines as virtual machines to standalone ESX/ESXi or to
ESX/ESXi hosts that vCenter Server manages.
VMware, Inc. 7
nImport virtual machines hosted by VMware Workstation or Microsoft Hyper-V Server to ESX/ESXi hosts
that vCenter Server manages.
nImport third-party backup or disk images to ESX/ESXi hosts that vCenter Server manages.
nExport virtual machines managed by vCenter Server hosts to other VMware virtual machine formats.
nCreate VMware virtual machines from VCB images.
nConfigure virtual machines managed by vCenter Server so that they are bootable, and install VMware
Tools or customize their guest operating systems.
nCustomize the guest operating systems of virtual machines in the vCenter Server inventory (for example,
change the host name or network settings).
nReduce the time needed to set up new virtual machine environments.
nMigrate legacy servers to new hardware without reinstalling operating systems or application software.
nPerform migrations across heterogeneous hardware.
nReadjust volume sizes and place volumes on separate virtual disks.
Converter Standalone Components
The Converter Standalone application consists of Converter Standalone server, Converter Standalone worker,
Converter Standalone client, and Converter Standalone agent.
Converter Standalone
server
Enables and performs the import and export of virtual machines. The
Converter Standalone server comprises two services, Converter Standalone
server and Converter Standalone worker. The Converter Standalone worker
service is always installed with the Converter Standalone server service.
Converter Standalone
agent
The Converter Standalone server installs the agent on Windows physical
machines to import them as virtual machines. You can choose to remove the
Converter Standalone agent from the physical machine automatically or
manually after the import is complete.
Converter Standalone
client
The Converter Standalone server works with the Converter Standalone client.
The client component consists of the Converter Standalone user interface,
which provides access to the Conversion and the Configuration wizards, and
allows you to manage the conversion and the configuration tasks.
VMware vCenter
Converter Boot CD
The VMware vCenter Converter Boot CD is a separate component that you can
use to perform cold cloning on a physical machine. Converter Standalone 4.3
and later versions do not provide a Boot CD, but you can use previous versions
of the Boot CD to perform cold cloning. See “Prepare for Cold Cloning,” on
page 13.
Cloning and System Configuration of Physical Machines
When you convert a physical machine, Converter Standalone uses cloning and system reconfiguration steps
to create and configure the destination virtual machine so that it works successfully in the vCenter Server
environment. Because the migration process is nondestructive to the source, you can continue to use the
original source machine after the conversion completes.
Cloning is the process of copying the source physical disks or volumes for the destination virtual machine.
Cloning involves copying the data on the source machine’s hard disk and transferring that data to a destination
virtual disk. The destination virtual disk might have a different geometry, size, file layout, and other
characteristics, so the destination virtual disk might not be an exact copy of the source disk.
System reconfiguration adjusts the migrated operating system to enable it to function on virtual hardware.
VMware vCenter Converter Standalone User's Guide
8 VMware, Inc.
If you plan to run an imported virtual machine on the same network as the source physical machine, you must
modify the network name and IP address on one of the machines, so that the physical and virtual machines
can coexist. Besides, you must make sure that the Windows source machine and the destination virtual machine
have different computer names.
NOTE You cannot move original equipment manufacturer (OEM) licenses between physical machines. The
license is attached to the server when you purchase it from the OEM and cannot be reassigned. You can only
reassign retail and volume licenses to new physical servers. If you migrate an OEM Windows image, you must
have a Windows Server Enterprise or Datacenter Edition license to run multiple virtual machines.
Hot and Cold Cloning of Physical Machines
Although Converter Standalone 4.3 and later versions support only hot cloning, you can still perform cold
cloning by using the VMware Converter 4.1.x Boot CD. Depending on your virtual environment, you can
choose to use hot or cold cloning.
Hot cloning, also called live cloning or online cloning, requires converting the source machine while it is
running its operating system. Hot cloning lets you clone machines without shutting them down.
Because processes continue to run on the source machine during conversion, the resulting virtual machine is
not an exact copy of the source machine.
When converting Windows sources, you can set Converter Standalone to synchronize the destination virtual
machine with the source machine after hot cloning. Synchronization is performed by transferring from the
source to the destination the blocks that were changed during the initial cloning period. To avoid loss of data
on the destination virtual machine, Converter Standalone can shut down certain Windows services before the
synchronization. Based on your settings, Converter Standalone shuts down the selected Windows services so
that no critical changes occur on the source machine while destination is being synchronized.
Converter Standalone can shut down the source machine and power on the destination machine when the
conversion process is complete. When combined with synchronization, this action allows seamless migration
of a physical machine source to a virtual machine destination. The destination machine takes over the source
machine operations with the least possible downtime.
NOTE When you hot clone dual-boot systems, you can clone only the default operating system to which the
boot.ini file points. To clone the nondefault operating system, change the boot.ini file to point to the other
operating system and reboot. After the other operating system is booted, you can hot clone it. If your second
operating system is Linux, you can boot it and clone it using the standard procedure for cloning Linux physical
machine sources.
Cold cloning, also called offline cloning, entails cloning the source machine when it is not running its operating
system. When you cold clone a machine, you reboot the source machine using a CD that has its own operating
system and the vCenter Converter application on it. Cold cloning allows you to create the most consistent copy
of the source machine because nothing changes on the source machine during the conversion. Cold cloning
leaves no footprint on the source machine, but requires direct access to the source machine that is being cloned.
When you cold clone a Linux source, the resulting virtual machine is an exact replica of the source machine
and you cannot configure the destination virtual machine. You must configure the destination virtual machine
after the cloning is complete.
Table 1-1 compares the hot and cold cloning modes.
Chapter 1 Introduction to VMware vCenter Converter Standalone
VMware, Inc. 9
Table 1-1. Hot and Cold Cloning Comparison
Comparison Criteria
Hot Cloning with Converter
Standalone 4.3 and 5.x
Cold Cloning with Converter
Enterprise 4.1.x
Licensing No license required with
VMware vCenter Converter
Standalone 4.3 and 5.x.
License file required for Enterprise
features of
VMware Converter Enterprise.
Required installation Full Converter Standalone installation
is required. As part of the cloning
process, Converter Standalone agent is
installed on the source machine
remotely.
No installation is required. All
components required for the conversion
are on the CD.
Supported sources Local and remote powered-on
physical or virtual machines.
Local powered-off physical or virtual
machines.
Advantages nDoes not require direct access to
the source machine.
nClones the source machine while
it is running.
nCreates the most consistent copy of
the source machine.
nLeaves no footprint on the source
machine.
Disadvantages nApplications that constantly
modify files need to be VSS aware
to allow Converter Standalone to
create a consistent snapshot for
cloning.
nDynamic source disks are read but
not preserved during volume-
based conversions. Dynamic disks
are converted into basic volumes
on the target virtual machine.
nRequires that the source machine is
powered off.
nRequires physical access to the
source machine.
nHardware detection and
configuration of the Boot CD.
nConverter Standalone 4.x features
are not supported.
Use nTo clone running source machines
without shutting them down.
nTo clone unique hardware that the
Boot CD does not recognize.
nTo clone a system that Converter
Standalone does not support.
nTo preserve the exact disk layout in
the target.
nTo preserve logical volumes in
dynamic disks (Windows) or LVM
(Linux).
When to not use When you do not want anything to be
installed on the source system.
nWhen you want Linux P2V with
automatic reconfiguration.
nWhen you do not have physical
access to the source machine.
nWhen you cannot afford a long
downtime of the source system.
nTo perform synchronization after
cloning.
Remote Hot Cloning of Physical Machine Sources That Are Running Windows
You can use the Conversion wizard to set up conversion tasks and Converter Standalone components perform
all of the cloning tasks.
The following workflow is an example of remote hot cloning in which the physical machine being cloned
experiences no downtime.
1 Converter Standalone prepares the source machine for the conversion.
Converter Standalone installs the agent on the source machine and the agent takes a snapshot of the source
volumes.
VMware vCenter Converter Standalone User's Guide
10 VMware, Inc.
agent
vCenter Converter Standalone running
on Windows machine
powered-on
physical machine ESX/ESXi
source destination
network
snapshot
source
volumes
2 Converter Standalone prepares the virtual machine on the destination machine.
Converter Standalone creates a virtual machine on the destination machine and the agent copies volumes
from the source machine to the destination machine.
agent
vCenter Converter Standalone running
on Windows machine
powered-on
physical machine ESX/ESXi
copied
volumes
source destination
network
snapshot
VM
source
volumes
3 Converter Standalone completes the conversion process.
The agent installs the required drivers to allow the operating system to boot in a virtual machine and
personalizes the virtual machine (changes the IP information, for example).
agent
vCenter Converter Standalone running
on Windows machine
powered-on
physical machine ESX/ESXi
source destination
network
VM
source
volumes snapshot
reconfiguration
customization (optional)
4 Optionally, Converter Standalone uninstalls the agent from the source machine.
The virtual machine is ready to run on the destination server.
Chapter 1 Introduction to VMware vCenter Converter Standalone
VMware, Inc. 11
Remote Hot Cloning of Physical Machine Sources That Are Running Linux
The conversion process of physical machines that are running Linux operating systems differs from that of
Windows machines.
In Windows conversions, the Converter Standalone agent is installed on the source machine and the source
information is pushed to the destination.
In Linux conversions, no agent is deployed on the source machine. Instead, a helper virtual machine is created
and deployed on the destination ESX/ESXi host. The source data is then copied from the source Linux machine
to the helper virtual machine. After the conversion is complete, the helper virtual machine shuts down to
become the destination virtual machine the next time you power it on.
Converter Standalone supports conversion of Linux sources only to managed destinations.
The following workflow demonstrates the principles of hot cloning physical machine sources that run Linux
to managed destinations.
1 Converter Standalone uses SSH to connect to the source machine and retrieves source information.
Converter Standalone creates an empty helper virtual machine based on your conversion task settings.
The helper virtual machine serves as a container for the new virtual machine during conversion. Converter
Standalone deploys the helper virtual machine on the managed destination, an ESX/ESXi host. The helper
virtual machine boots from a *.iso file that is located on the Converter Standalone server machine.
vCenter Converter Standalone
agent and server
Converter Standalone
agent deploys helper
virtual machine
powered-on Linux
machine ESX/ESXi
source destination
network
Helper
VM
source
volumes
2 The helper virtual machine powers on, boots from the Linux image, connects to the source machine
through SSH, and starts retrieving the selected data from the source. While you set up the conversion task,
you can select which source volumes to be copied to the destination machine.
vCenter Converter Standalone
agent and server
powered-on Linux
machine
data copied to the
helper virtual machine
ESX/ESXi
source destination
network
Helper
VM
source
volumes
3 Optionally, after data is copied, the destination virtual machine is reconfigured to allow the operating
system to boot in a virtual machine.
VMware vCenter Converter Standalone User's Guide
12 VMware, Inc.
4 Converter Standalone shuts down the helper virtual machine. The conversion process is complete.
You can configure Converter Standalone to power on the newly created virtual machine after the
conversion is complete.
Prepare for Cold Cloning
Because Converter Standalone 4.3 and later do not support cold cloning, you must use the Boot CD of an earlier
vCenter Converter edition. The features supported on the Boot CD depend on the product version you choose.
When you cold clone a machine, you reboot the source machine from a CD that has its own operating system
and also includes the vCenter Converter application. You can find a detailed description of the cold cloning
process in the documentation of the Boot CD you decide to use.
VMware vCenter Converter 4.1.x is not a free software product.
Procedure
1 To obtain a Boot CD, go to the VMware Download Web site and download the vCenter Converter 4.1.x
installation package.
2 Extract the Boot CD .iso file from the installation package.
3 Write the Boot CD .iso file on a CD.
What to do next
Follow the onscreen instructions to proceed with cold cloning.
Types of Data Cloning Operations
Converter Standalone supports disk-based cloning, volume-based cloning, and linked-cloning modes.
IMPORTANT Converter Standalone cannot detect any source volumes and file systems that are located on
physical disks larger than 2TB.
Table 1-2. Cloning Modes
Data Copy Types Application Description
Volume based Copy volumes from the source
machine to the destination machine.
Volume-based cloning is relatively
slow. File-level cloning is slower than
block-level cloning. Dynamic disks are
converted into basic volumes on the
target virtual machine.
Disk based Create copies of the source machines,
for all types of basic and dynamic
disks.
You cannot select which data to copy.
Disk-based cloning is faster than
volume-based cloning.
Linked clone Use to quickly check compatibility of
non-VMware images
For certain third-party sources, the
linked clone is corrupted if you power
on the source machine after the
conversion. Linked cloning is the fastest
(but incomplete) cloning mode that
Converter Standalone supports.
Chapter 1 Introduction to VMware vCenter Converter Standalone
VMware, Inc. 13
Volume-Based Cloning
During volume-based cloning, volumes from the source machine are copied to the destination machine.
Converter Standalone supports volume-based cloning for hot and cold cloning, and during the import of
existing virtual machines.
During volume-based cloning, all volumes in the destination virtual machine are converted to basic volumes,
regardless of their type in the corresponding source volume.
Volume-based cloning is performed at the file level or block level, depending on the destination volume size
that you select.
Volume-based cloning at
the file level
Performed when you select a size smaller than the original volume for NTFS
volumes or you choose to resize a FAT volume.
Volume-based cloning at the file level is supported only for FAT, FAT32, NTFS,
ext2, ext3, ext4, and ReiserFS file systems.
Dynamic source disks are read but not preserved during volume-based
conversions. Dynamic disks are converted into basic volumes on the target
virtual machine.
Volume-based cloning at
the block level
Performed when you choose to preserve the size of the source volume or when
you specify a larger volume size for NTFS source volumes.
For certain cloning modes, Converter Standalone might not support some types of source volumes.
Table 1-3 shows the supported and nonsupported source volume types.
Table 1-3. Supported and Nonsupported Source Volumes
Cloning Mode Supported Source Volumes Nonsupported Source Volumes
Virtual machine conversion nBasic volumes
nAll types of dynamic volumes
nMaster boot record (MBR) disks
nRAID
nGUID partition table (GPT) disks
Powered-on machine conversion nAll types of source volumes that
Windows recognizes
nLinux ext2, ext3, and ReiserFS
nRAID
nGUID partition table (GPT) disks
Disk-Based Cloning
Converter Standalone supports disk-based cloning to import existing virtual machines.
Disk-based cloning transfers all sectors from all disks and preserves all volume metadata. The destination
virtual machine receives partitions of the same type, size, and structure, as the partitions of the source virtual
machine. All volumes on the source machine's partitions are copied as they are.
Disk-based cloning supports all types of basic and dynamic disks.
Full and Linked Clones
Clones can be full or linked depending on the amount of data copied from the source to the destination machine.
A full clone is an independent copy of a virtual machine that shares nothing with the parent virtual machine
after the cloning operation. Ongoing operation of a full clone is separate from the parent virtual machine.
Because a full clone does not share virtual disks with the parent virtual machine, full clones generally perform
better than linked clones. Full clones take longer to create than linked clones. Creating a full clone can take
several minutes if the files involved are large.
You can create a full clone by using any disk clone type other than the linked clone type.
VMware vCenter Converter Standalone User's Guide
14 VMware, Inc.
A linked clone is a copy of a virtual machine that shares virtual disks with the parent virtual machine in an
ongoing manner. A linked clone is a fast way to convert and run a new virtual machine. You can create a linked
clone from the current state, or snapshot, of a powered-off virtual machine. This practice conserves disk space
and allows multiple virtual machines to use the same software installation.
All files available on the source machine at the moment of the snapshot continue to remain available to the
linked clone. Ongoing changes to the virtual disk of the parent do not affect the linked clone, and changes to
the disk of the linked clone do not affect the source machine. If you make changes to a source Virtual PC and
Virtual Server machines, or to LiveState images, the linked clone is corrupted and you cannot use it anymore.
A linked clone must have access to the source. Without access to the source, you cannot use a linked clone at
all.
For more information on how to create a linked clone, see “Create a Linked Clone,” on page 58.
Destination Disk Types
Depending on the destination you select, several destination disk types are available.
For detailed information on destination virtual disks types, see Table 1-4.
Table 1-4. Destination Disk Types
Destination Available Disk Types
VMware Infrastructure virtual machine Thick Copies the entire source disk size to the
destination, regardless of its used and
free space.
Thin For managed destinations that support
thin provisioning through GUI, creates
an expanding disk on the destination.
For example, if the source disk size is
10GB, but only 3GB is used, the created
destination disk is 3GB but can expand
to 10GB.
VMware Workstation or other VMware virtual machine Pre-
allocated
Copies the entire source disk size to the
destination, regardless of its used and
free space.
Not pre-
allocated
Creates an expanding disk on the
destination. For example, if the source
disk size is 20GB, but only 5GB is used,
the created destination disk is 5GB but
can expand to 20GB. Take this expansion
into account when you calculate the free
disk space on the destination datastore.
2GB Split
pre-
allocated
Splits the source disk into 2GB sections
on the destination.
2GB Split not
pre-
allocated
Creates 2GB sections on the destination
that include only the real used space on
the source disk. As the destination disk
grows, new 2GB sections are created to
accommodate the new data until the size
reaches that of the original source disk.
To support destination virtual disks on FAT file systems, divide the source data into 2GB files.
Chapter 1 Introduction to VMware vCenter Converter Standalone
VMware, Inc. 15
Using Converter Standalone with Virtual Machine Sources and System
Images
With Converter Standalone, you can convert virtual machines and system images, and configure VMware
virtual machines.
Converting virtual
machines
You can convert VMware virtual machines from and to Workstation,
VMware Player, VMware ACE, VMware Fusion, ESX, ESXi Embedded,
ESXi Installable, and VMware Server. You can also import virtual machines
from Microsoft Virtual Server and Virtual PC.
To be able to run an imported VMware virtual machine and its source virtual
machine on the same network, you must modify the network name and IP
address on one of the virtual machines. Modifying the network name and IP
address allows the original and new virtual machines to coexist on the same
network.
Configuring virtual
machines
If the VMware virtual machines have disks that are populated by using a
backup of a physical host or by cold cloning, Converter Standalone prepares
the image to run on VMware virtual hardware. If you have used a third-party
virtualization software to create a virtual machine on an ESX host, you can use
Converter Standalone to reconfigure it. You can also reconfigure any operating
system installed on a multiboot machine if you have imported the virtual
machine to an ESX host. Before you reconfigure a multiboot machine, you must
change the boot.ini file.
System Settings Affected by Conversion
A VMware virtual machine that Converter Standalone creates contains a copy of the disk state of the source
physical machine, virtual machine, or system image. Some hardware-dependent drivers and sometimes the
mapped drive letters might not be preserved.
The following source computer settings remain unchanged:
nOperating system configuration (computer name, security ID, user accounts, profiles, preferences, and so
on)
nApplications and data files
nVolume serial number for each disk partition
Because the target and the source virtual machines or system images have the same identities (name, SID, and
so on), running them on the same network might result in conflicts. To redeploy the source virtual machine or
system image, make sure that you do not run the source and target images or virtual machines on the same
network at the same time.
For example, if you use Converter Standalone to test whether you can run a Virtual PC virtual machine as a
VMware virtual machine without first decommissioning the original Virtual PC machine, you must first resolve
the duplicate ID problem. You can resolve this problem by customizing the virtual machines in the
Conversion or the Configuration wizard.
VMware vCenter Converter Standalone User's Guide
16 VMware, Inc.
Changes to Virtual Hardware
After conversion, most applications function correctly on the VMware virtual machine because their
configuration and data files have the same location as on the source virtual machine. However, applications
might not work if they depend on specific characteristics of the underlying hardware, such as the serial number
or the device manufacturer.
Table 1-5 contains hardware changes that might occur after virtual machine migration.
Table 1-5. Hardware Changes After Virtual Machine Migration
Hardware Behavior
CPU model and serial numbers Might change after migration if they are activated. They correspond to the physical
computer hosting the VMware virtual machine.
Ethernet adapters Might change (AMD PCNet or VMXnet) and have a different MAC address. The
IP address of each interface must be individually reconfigured.
Graphics cards Might change after migration (VMware SVGA card).
Disks and partitions The number of disks and partitions might change if you rearrange volumes during
the cloning process. Each disk device might have a different model and different
manufacturer strings.
Primary disk controllers Might differ from the source machine.
Applications might not work if they depend on devices that are not available within a virtual machine.
Chapter 1 Introduction to VMware vCenter Converter Standalone
VMware, Inc. 17
VMware vCenter Converter Standalone User's Guide
18 VMware, Inc.
System Requirements 2
You must consider the compatibilities and the interoperabilities among the systems on which and with which
the Converter Standalone components work.
This chapter includes the following topics:
n“Supported Operating Systems,” on page 19
n“Installation Space Requirements,” on page 20
n“Screen Resolution Requirements,” on page 21
n“Supported Source Types,” on page 21
n“Supported Destination Types,” on page 23
n“Restoring VCB Images in Converter Standalone,” on page 24
n“Configuring Permissions for vCenter Users,” on page 25
n“Support for IPv6 in Converter Standalone,” on page 25
n“TCP/IP and UDP Port Requirements for Conversion,” on page 26
n“Requirements for Remote Hot Cloning of Windows Operating Systems,” on page 27
Supported Operating Systems
You can install Converter Standalone components only on Windows operating systems. Converter Standalone
supports Windows and Linux operating systems as sources for powered-on-machine conversions and virtual-
machine conversions. You cannot reconfigure Linux distributions.
For a list of operating systems on which you can install Converter Standalone components, see Table 2-1.
NOTE P2V conversion is not supported for UEFI source machines.
Table 2-1. Supported Operating Systems
Supported Operating
Systems
Converter
Standalone
Server
Support
Converter
Standalone
Client
Support
Converter
Standalone
Agent Support
Source for
Powered-On
Machine
Conversions
Source for
Virtual
Machine
Conversions
Configuration
Source
Windows XP
Professional (32-bit and
64-bit) SP3
Yes Yes Yes Yes Yes Yes
Windows 2003 (32-bit
and 64-bit) SP2,
Revision 2
Yes Yes Yes Yes Yes Yes
VMware, Inc. 19
Table 2-1. Supported Operating Systems (Continued)
Supported Operating
Systems
Converter
Standalone
Server
Support
Converter
Standalone
Client
Support
Converter
Standalone
Agent Support
Source for
Powered-On
Machine
Conversions
Source for
Virtual
Machine
Conversions
Configuration
Source
Windows Vista (32-bit
and 64-bit) SP2
Yes Yes Yes Yes Yes Yes
Windows Server 2008
(32-bit and 64-bit) SP2
Yes Yes Yes Yes Yes Yes
Windows Server 2008 R2
(64-bit)
Yes Yes Yes Yes Yes Yes
Windows 7 (32-bit and
64-bit)
Yes Yes Yes Yes Yes Yes
Red Hat Enterprise
Linux 2.x (32-bit and 64-
bit)
No No No Yes Yes No
Red Hat Enterprise
Linux 3.x (32-bit and 64-
bit)
No No No Yes Yes No
Red Hat Enterprise
Linux 4.x (32-bit and 64-
bit)
No No No Yes Yes No
Red Hat Enterprise
Linux 5.x (32-bit and 64-
bit)
No No No Yes Yes No
SUSE Linux Enterprise
Server 8.x (32-bit and 64-
bit)
No No No Yes Yes No
SUSE Linux Enterprise
Server 9.x (32-bit and 64-
bit)
No No No Yes Yes No
SUSE Linux Enterprise
Server 10.x (32-bit and
64-bit)
No No No Yes Yes No
SUSE Linux Enterprise
Server 11.x (32-bit and
64-bit)
No No No Yes Yes No
Ubuntu 8.x (32-bit and
64-bit)
No No No Yes Yes No
Ubuntu 9.x (32-bit and
64-bit)
No No No Yes Yes No
Ubuntu 10.x (32-bit and
64-bit)
No No No Yes Yes No
Installation Space Requirements
During installation, you can select the Converter Standalone components that you want to install. All
components require different amounts of free disk space to install.
Table 2-2 shows the disk space required to install Converter Standalone and its components.
VMware vCenter Converter Standalone User's Guide
20 VMware, Inc.
Table 2-2. Installation Space Requirements
Installation Component Disk Space Required
Disk Space Requirement for Decompressed
Files
Installation file 100MB 100MB
vCenter Converter client 25MB 25MB
vCenter Converter server 120MB 300MB
vCenter Converter agent 25MB 100MB
Screen Resolution Requirements
To display wizards properly, Converter Standalone requires a screen resolution of at least 1024x768 pixels.
Supported Source Types
With Converter Standalone, you can convert remote powered-on machines, powered-off VMware virtual
machines, Hyper-V virtual machines, and other third-party virtual machines and system images.
Table 2-3 shows the sources that Converter Standalone supports.
Table 2-3. Supported Sources
Source Type Sources
Powered-on machines nRemote Windows physical machines
nRemote Linux physical machines
nLocal Windows physical machines
nWindows virtual machines running on Hyper-V Server
nPowered-on VMware virtual machines
nVMware VCB backup images
VMware vCenter virtual
machines
Powered-off virtual machines managed by the following servers:
nVirtualCenter 2.5
nvCenter Server 4.0, 4.1, and 5.0
nESX Server 2.5.x (if VirtualCenter 2.5 or later manages ESX)
nESX Server 3.0, 3.5, 4.0, and 4.1
nESXi 3.5, 4.0, 4.1, and 5.0
VMware virtual machines Powered-off hosted virtual machines running on the following VMware products:
nVMware Workstation 5.x, 6.x, 7.x, and 8.x
nVMware Fusion 2.x, 3.x, and 4.x
nVMware Player 2.x and 3.x
nVMware Server 2.x
Chapter 2 System Requirements
VMware, Inc. 21
Table 2-3. Supported Sources (Continued)
Source Type Sources
Hyper-V Server virtual
machines
Powered-off virtual machines with the following guest operating systems:
nWindows Server 2003 (x86 and x64), SP1, SP2, and R2
nWindows Server 2008 (x86 and x64) SP2 and R2 SP2
nWindows 7 (except Home editions)
nWindows Vista SP1 and SP2 (except Home editions)
nWindows XP Professional SP2, SP3, and x64 SP2
nSUSE Linux Enterprise Server 10 SP1 and SP2
nSUSE Linux Enterprise Server 11
nRed Hat Enterprise Linux 5.2, 5.3, and 5.4 (x86 and x64)
Third-party virtual machines or
system images
nAcronis True Image Echo 9.1, 9.5, and Acronis True Image Home 10 and 11 (.tib).
nSymantec Backup Exec System Recovery (formerly LiveState Recovery) 6.5, 7.0, 8.0,
and 8.5, LiveState Recovery 3.0 and 6.0 (only .sv2i).
nNorton Ghost version 10.0, 12.0, and 14.0 (.sv2i format only).
nParallels Desktop 2.5, 3.0, and 4.0 (.pvs and .hdd). Compressed disks are not
supported.
nParallels Workstation 2.x (.pvs). Compressed disks are not supported. Parallels
Virtuozzo Containers are not supported.
nStorageCraft ShadowProtect Desktop, ShadowProtect Server, ShadowProtect Small
Business Server (SBS), ShadowProtect IT Edition, versions 2.0, 2.5, 3.0, 3.1, and 3.2
(.spf).
nMicrosoft VHD format for the following sources:
nMicrosoft Virtual PC 2004 and Microsoft Virtual PC 2007 (.vmc)
nMicrosoft Virtual Server 2005 and 2005 R2 (.vmc)
Sources that run Windows 7 and Windows Server 2008 R2 can be converted to ESX 3.5 Update 5, ESX 4.0, or
later destinations. ESX 3.5 Update 4 or earlier versions do not support Windows 7.
Conversion Limitations for Powered-On Machines
When you convert a powered-on machine, some conversion features might not be available for certain source
operating systems.
For a list of limitations dependent on the source operating system, see Table 2-4.
Table 2-4. Limitations for Powered-On Machine Conversion
Source Operating System Limitations
Windows XP and later nSynchronization is supported only for volume-based cloning at the block level.
nScheduling synchronization is supported only for managed destinations that are ESX
4.0 or later.
Linux nOnly volume-based cloning at the file level is supported.
nOnly managed destinations are supported.
nConverting multiboot virtual machines is supported only if GRUB is installed as the
boot loader. LILO is not supported.
Conversion Limitations for VMware Virtual Machines
Certain limitations exist when you convert a VMware virtual machine.
You must power off source virtual machines before you convert them. You can convert running virtual
machines if you follow the procedure for converting powered-on machines.
When you convert a virtual machine with VMware snapshots, the snapshots are not transferred to the
destination virtual machine.
VMware vCenter Converter Standalone User's Guide
22 VMware, Inc.
Certain limitations are applicable when you convert Linux virtual machine sources.
nOnly disk-based cloning is supported for Linux guest operating systems.
nConfiguration or customization is not supported for Linux guest operating systems.
nInstalling VMware Tools is not supported on Linux guest operating systems.
Conversion Limitations for Third-Party Virtual Machines or System Images
Converter Standalone can convert third-party virtual machines, system images, ShadowProtect images, and
BackupExec System Recovery images. These conversions have limitations.
Third-Party Virtual Machines and System Images
Third-party virtual machines and system images have the following limitations.
nVirtual machines created with Macintosh versions of Virtual PC are not supported.
nThe operating system on the source Virtual PC or Virtual Server virtual machine must be a Windows guest
operating system supported by the destination VMware platform (for example, Workstation 5 or 6.0.x).
For a list of supported operating systems, see the Guest Operating System Installation Guide.
Converter Standalone supports Virtual PC and Virtual Server virtual machines with most Windows
operating systems earlier than Windows NT 4.0 and with non-Windows operating systems (for example,
Linux and DOS) only for cloning. Converter Standalone does not support configuring for these systems.
nParallels Virtuozzo containers are not supported.
ShadowProtect and Backup Exec System Recovery
ShadowProtect and Backup Exec System Recovery have the following limitations.
nDynamic disks are not supported.
nAll images for the backup of a machine must be in a single folder. The source folder must not contain
images that are not part of the backup.
nFor volume-based cloning, all volumes in the disk up to the active and system volumes must be backed
up. For example, if a disk has four partitions, 1 through 4, with partition 2 as the active volume and
partition 3 as the system volume, the backup must include partitions 1 through 3.
nFor incremental images, up to 16 incremental backups are supported.
nShadowProtect images of systems with logical drives are not supported if the logical drive is also a system
or active volume.
Supported Destination Types
With Converter Standalone, you can create virtual machines compatible with VMware hosted and managed
products.
Table 2-5 shows the destinations that Converter Standalone supports.
Chapter 2 System Requirements
VMware, Inc. 23
Table 2-5. Supported Destinations
Destination Type Supported Versions
VMware vCenter virtual machines Managed destinations
nESX Server 3.5, 4.0, and 4.1
nESXi 3.5, 4.0, 4.1, and 5.0
nvCenter Server 2.5, 4.0, 4.1, and 5.0
VMware hosted virtual machines Hosted destinations
nVMware Workstation 5.x, 6.x, 7.x, and 8.x
nVMware Fusion 2.x, 3.x, and 4.x
nVMware Player 2.x, and 3.0
nVMware Server 2.x
NOTE For hosted destinations that reside on SMB or NFS shares, you must use volume-based cloning and
create 2GB disks that are not pre-allocated.
Restoring VCB Images in Converter Standalone
You can use VMware Consolidated Backup to back up all of the virtual machines of an entire ESX installation.
The backup is stored by using Workstation disks, a .vmx file, and a catalog file. Converter Standalone can restore
VCB images to ESX hosts and convert them to VMware standalone virtual machines.
Converter Standalone supports restore operations for VCB images of the source operating systems described
in “Supported Operating Systems,” on page 19.
Converter Standalone does not maintain the .nvram file or the VMware log files.
Converter Standalone does not read the original location settings from the catalog file. To restore to the same
location, find information such as datastore, host name, folder name, and resource pool in the catalog file and
specify it in the Conversion wizard. In addition, Converter Standalone does not read the original display name
from the catalog file. If you want to use the same name but do not remember it, you can look it up in the catalog
file. You can read the catalog file as a plain text file.
Information Not Preserved When Using Converter Standalone for Managed
Product Destinations
When you restore VCB images for managed product destinations (ESX hosts, for example), Converter
Standalone does not preserve certain hardware backing information from the original image, but rather
substitutes default settings.
Table 2-6 shows the areas that are affected.
Table 2-6. Changes to Hardware Information Because of Conversion
Affected Area Behavior
CD-ROM Defaults to the client device type.
Floppy Defaults to the client device type.
Network adapters Defaults to the list of network adapters in the GUI. The MAC address is not preserved. The destination
host regenerates the MAC address.
Serial port Defaults to the physical serial port on destination host machine.
Parallel port Defaults to the physical parallel port on destination host machine.
When you restore images, the Converter Standalone GUI does not preserve certain other virtual machine
properties from the original image, but substitutes default settings. Table 2-7 shows the affected areas.
VMware vCenter Converter Standalone User's Guide
24 VMware, Inc.
Table 2-7. Changes to Properties Because of Conversion
Affected Area Behavior
UUID The virtual machine's BIOS and location, identified by uuid.bios and uuid.location, are not
preserved. The destination host machine regenerates the BIOS and location.
Disk resource allocation Defaults to the values available on the host when the virtual machine is created.
Information Not Preserved for Hosted Product Destinations
When you import a VCB image to a hosted product destination (Workstation, for example), Converter
Standalone cannot guarantee that virtual machine properties can be preserved. This behavior is because
Converter Standalone handles this import as a migration, and not as a restore.
For more information about VCB images, see the Virtual Machine Backup Guide.
Configuring Permissions for vCenter Users
To convert virtual machines to vCenter machines with Converter Standalone, you must have certain vCenter
permissions set at the datacenter level.
nDatastore.Allocate Space
nVirtual machine.Inventory.Create new
nVirtual machine.Configuration.Add new disk
nVirtual Machine.Interaction.Power On (needed only if you choose to power on the destination virtual
machine after conversion)
nVirtual Machine.Provisioning.Allow Disk Access
nResource.Assign Virtual Machine To Resource Pool
nNetwork.Assign network (needed only if you plan to connect the destination virtual machine to a
network)
For more information about setting permissions, see the vSphere Datacenter Administration Guide.
Support for IPv6 in Converter Standalone
Converter Standalone supports both IPv4 and IPv6 Internet protocols with several limitations.
Internet Protocol version 6 (IPv6 or IPng) is the successor to Internet Protocol version 4 (IPv4), which is the
currently used protocol for assigning IP addresses to computers on the Internet. IPv6 was adopted to overcome
the expected exhaustion of IPv4 addresses that might be caused by the constantly increasing number of
computers on the Internet.
While IPv4 uses 32bit addresses, IPv6 uses 128bit. IPv6 addresses can have different formats or notations.
n1040:0:0:0:0:0:0:1
n1040::1
n21DA:00D3:0010:2F3B:02AA:00FF:FE28:9C5A
n[2001:0db8:85a3:08d3:1319:8a2e:0370:7344]:443
Converter Standalone supports all IPv6 notations for all components of the system.
nConverter Standalone installer
nConverter Standalone client
nConverter Standalone agent
Chapter 2 System Requirements
VMware, Inc. 25
nAll destinations supported in Converter Standalone
Along with the higher security level and much larger address space, IPv6 brings about some compatibility
tasks that have not been resolved yet. For example, IPv4-only nodes cannot communicate directly with IPv6
nodes and need additional routing. This makes the end-to-end support of mixed IPv4 and IPv6 environments
precarious.
To reduce this complexity, Converter Standalone supports only pure IPv6 or IPv4 environments, where the
protection source, the protection destination, and the Converter Standalone server and agent must run the
same version of IP.
NOTE You cannot use IPv6 to customize the guest operating systems of virtual machines.
TCP/IP and UDP Port Requirements for Conversion
To enable conversion, the Converter Standalone server and client must be able to send data to each other, to
remote physical machines, and to vCenter Server. Also, the source and destination hosts must receive data
from each other. Designated ports are reserved for this communication.
If any of these ports is blocked, the corresponding conversion task fails.
Ports Used When Converting a Powered-On Physical Machine Running Windows
Table 2-8 contains a list of the ports that must be open during the conversion of physical machine sources
running Windows.
Table 2-8. Ports Required During Windows P2V
Communication Paths
Communication
Ports Notes
Converter Standalone server to
powered-on source machine
TCP - 445, 139,
9089
UDP - 137, 138
If the source computer uses NetBIOS, port 445 is not required. If
NetBIOS is not being used, ports 137, 138, and 139 are not
required. When in doubt, make sure that none of the ports are
blocked.
NOTE Unless you have installed Converter Standalone server or
agent on the source computer, the account used for
authentication to the source computer must have a password,
network file sharing must be enabled on the source computer,
and Simple File Sharing must not be used.
Converter Standalone server to
vCenter Server
TCP - 443 Required only if the conversion destination is a vCenter Server.
Converter Standalone client to
vCenter Server
TCP - 443 Required only if the Converter Standalone server and client
components are on different machines.
Powered-on source machine to
ESX/ESXi
TCP - 443, 902 If the conversion destination is vCenter Server, only port 902 is
required.
Ports Used When Converting a Powered-On Physical Machine Running Linux
Table 2-9 contains a list of the ports that must be open during the conversion of physical machine sources
running Linux.
Table 2-9. Ports Required During Linux P2V
Communication Paths TCP Ports Notes
Converter Standalone server to
powered-on source machine
22 Used to establish an SSH connection between the Converter
Standalone server and the source machine.
Converter Standalone client to Converter
Standalone server
443 Required only if the Converter Standalone server and client
components are on different machines.
VMware vCenter Converter Standalone User's Guide
26 VMware, Inc.
Table 2-9. Ports Required During Linux P2V (Continued)
Communication Paths TCP Ports Notes
Converter Standalone server to
vCenter Server
443 Required only if the conversion destination is a vCenter Server.
Converter Standalone server to
ESX/ESXi
443, 902,
903
If the conversion destination is a vCenter Server, only ports 902
and 903 are required.
Converter Standalone server to helper
virtual machine
443
Helper virtual machine to powered-on
source machine
22 Used to establish an SSH connection between the helper virtual
machine and the source machine. By default, the IP address of the
helper virtual machine is assigned by DHCP. If no DHCP server
is available on the destination network, you must manually assign
the target virtual machine an IP address.
Ports Used When Converting Virtual Machine Sources
Table 2-10 contains a list of the ports that must be open during the conversion of virtual machines.
Table 2-10. Ports Required During V2V
Communication Paths
Communication
Ports Notes
Converter Standalone server to
Fileshare path
TCP - 445, 139
UPD - 137, 138
Required only for standalone virtual machine sources or
destinations. If the computer hosting the source or destination
path uses NetBIOS, port 445 is not required. If NetBIOS is not
being used, ports 137, 138, and 139 are not required. When in
doubt, make sure that none of the ports are blocked.
Converter Standalone client to
Converter Standalone server
TCP - 443 Required only if the Converter Standalone server and client
components are on different machines.
Converter Standalone server to
vCenter Server
TCP - 443 Required only if the conversion destination is a
vCenter Server.
Converter Standalone server to
ESX/ESXi
TCP - 443, 902 If the conversion destination is a vCenter Server, only port 902
is required.
Requirements for Remote Hot Cloning of Windows Operating Systems
To avoid problems related to permissions and network access, ensure that simple file sharing is turned off and
that Windows Firewall does not block file and printer sharing. Also, to access file and printer sharing ports,
you might need to change the scope of the IP addresses that the firewall allows.
To ensure successful remote hot cloning of Windows platforms, verify the following items on the source
machine before you start the application:
nEnsure that simple file sharing is turned off.
nEnsure that file and printer sharing is not blocked by Windows Firewall.
You must allow incoming file share connections in the following cases:
nWhen you use the machine to host standalone images
nWhen you use the machine as a standalone destination
nWhen you remotely hot clone the machine
To enable customization of the guest operating system, install Sysprep files on the machine where Converter
Standalone server runs.
Chapter 2 System Requirements
VMware, Inc. 27
Ensure that Windows Firewall Does Not Block File and Printer Sharing
If Converter Standalone fails to connect to a remote Windows XP machine and issues a bad
username/password error message, ensure that file and printer sharing is not blocked by Windows Firewall.
Procedure
1 Select Start > Settings > Control Panel > Administrative Tools > Local Security Policy.
2 In the Security Settings list on the left, select Local Policies > Security Options.
3 In the policies list on the right, select Network access: Sharing and Security model for local accounts.
4 Verify that Classic – local users authenticate as themselves is selected.
What to do next
For troubleshooting information about file and printer sharing, search the Microsoft TechNet Web site.
For information about setting file and printer sharing on other Windows systems, see the documentation for
your system.
Turn Off Simple File Sharing on Windows XP Professional
To control permissions for individual users, you must turn off simple file sharing on the source machine.
Turning simple file sharing off does not turn off the Shared Documents feature. Use the simple file sharing UI,
located in the folder’s properties, to configure share and file permissions.
For Windows XP Professional operating systems that are part of a workgroup, the simple file sharing UI is
turned on by default. Windows XP Professional operating systems that are part of a domain use only the classic
file sharing and security interface.
Procedure
1 On the source machine, select Start > Settings > Control Panel > Folder Options.
2 Click the View tab and deselect Use Simple File Sharing (Recommended).
Simple file sharing is turned off.
What to do next
For more information about turning simple file sharing on or off, see the Microsoft TechNet Web site.
Prepare Guest Operating System for Customization
To customize the guest operating system of a virtual machine that runs Windows Server 2003 or Windows XP,
you must save the Sysprep files to the specified locations on the machine where Converter Standalone server
runs.
If Sysprep files are missing from the server machine, the Customize Guest OS option is not accessible in the
Converter Standalone wizards.
Prerequisites
You must download the Sysprep files that correspond to the operating system of the source machine.
VMware vCenter Converter Standalone User's Guide
28 VMware, Inc.
Procedure
uSave the Sysprep files that correspond to the source operating system to the specified location on the
machine where Converter Standalone server runs.
Option Description
Windows Server 2003 (32bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\svr2003
Windows Server 2003 (64bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\svr2003-64
Windows XP (32bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\xp
Windows XP (64bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\xp-64
What to do next
You can now customize Windows Server 2003 (32bit and 64bit) and Windows XP (32bit and 64bit) guest
operating systems by using the Conversion or the Configuration wizard.
Limitations Related to Creating Snapshots of Windows Sources
Converter Standalone uses VSS snapshots to save the state of source volumes during hot cloning of physical
and virtual machines that run Windows. VSS snapshots are also used to synchronize the destination virtual
machine with the source machine after the initial conversion. Some of the VSS-related issues are inherited in
Converter Standalone and can prevent the proper completion of your conversion tasks.
Read the limitations listed in Table 2-11 before you initiate a conversion task.
If your conversion task fails with an VSS-related error message, you can check the table for possible reasons
and workarounds.
Table 2-11. VSS Snapshotting Limitations
VSS Limitations Error Messages Workarounds
For all operating systems that
support volume-based cloning,
you need at least one NTFS
volume for VSS to work.
There is no workaround for this
limitation.
VSS under Windows Server 2008
does not support FAT and FAT32.
Deselect all FAT and FAT32
volumes on the View/Edit
Options page of the
vCenter Converter wizards.
VSS under Windows Server 2008
does not support unformatted or
unrecognized volumes.
Failed to create VSS snapshot of source
volume. Error code :2147754764
(0x8004230C)
nFormat all unformatted or
unrecognized volumes and
try the conversion again.
nDeselect all unformatted or
unrecognized volumes while
setting up the conversion task
in the Data to copy pane of the
View/Edit Options page.
Chapter 2 System Requirements
VMware, Inc. 29
Table 2-11. VSS Snapshotting Limitations (Continued)
VSS Limitations Error Messages Workarounds
If the space in the VSS snapshot
storage area is not enough for VSS
to create a snapshot, the
conversion fails.
Failed to create VSS snapshot of source
volume. Error code:
2147754783(0x8004231F)
Clean up the source volumes,
especially the system volume and
all NTFS volumes, and try to
convert the source again.
Importing powered-on Hyper-V
sources fails if the following two
VSS services are not started or are
not operating properly on the
source machine:
nMicrosoft Software Shadow
Copy Provider Service
nVolume Shadow Copy
Service
Failed to create VSS snapshot of source
volume. Error code: 2147754758
(0x80042306)
1 Set the starting mode for
Microsoft Software Shadow
Copy Provider Service and
Volume Shadow Copy
Service to Automatic.
2 Restart the source machine
and try cloning it again.
VMware vCenter Converter Standalone User's Guide
30 VMware, Inc.
Installing and Uninstalling Converter
Standalone 3
You can install Converter Standalone on a physical or a virtual machine. You can also modify or repair a
Converter Standalone installation.
The Local setup installs the Converter Standalone server, Converter Standalone agent, and Converter
Standalone client for local use.
NOTE Local installation of Converter Standalone complies with the following security restrictions:
nAfter the initial setup, the use of an administrator account requires physical access to the product.
nYou can manage Converter Standalone only from the machine where it is installed.
During the client-server installation, you can select the Converter Standalone components that you want to
install on your system.
When you install the Converter Standalone server and Remote access, the local machine becomes a server for
conversions, which you can manage remotely. When you install the Converter Standalone server and the
Converter Standalone client, you can use the local machine to access remote Converter Standalone servers or
create conversion jobs locally.
If you install only Converter Standalone client, you can connect to a remote Converter Standalone server. You
can then use the remote machine to convert hosted virtual machines, managed virtual machines, or remote
physical machines.
This chapter includes the following topics:
n“Perform a Local Installation on Windows,” on page 31
n“Perform a Client-Server Installation in Windows,” on page 32
n“Perform a Command-Line Installation in Windows,” on page 34
n“Command-Line Options for Windows Installation,” on page 34
n“Modify Converter Standalone in Windows,” on page 35
n“Repair Converter Standalone in Windows,” on page 36
n“Uninstall Converter Standalone in Windows,” on page 37
n“Connect to a Remote Converter Standalone Server,” on page 37
Perform a Local Installation on Windows
You can install Converter Standalone on a physical or a virtual machine. The local setup installs the Converter
Standalone server, Converter Standalone agent, and Converter Standalone client for local use.
If you install Converter Standalone in local mode, you can create and manage conversion tasks only from the
machine on which you installed the application.
VMware, Inc. 31
Prerequisites
Make sure your system meets the Converter Standalone system requirements.
Make sure that you have Administrator privileges.
If you have Converter 3.0.x installed and your machine runs Windows Vista, uninstall Converter 3.0.x manually
before you install Converter Standalone 5.0.
If you have an earlier version of Converter Standalone agent on the system, uninstall Converter Standalone
agent.
Procedure
1 Download the latest version of Converter Standalone from the VMware Web site.
2 Navigate to the folder that contains the installer file you downloaded and double-click the VMware-
converter-5.x.x-<xxxxx>.exe file, where <xxxxx> is the number of the build.
3 In the Choose Setup Language dialog box, select the language for the install process and click OK.
4 Follow the prompts till the End-User License Agreement page appears.
5 Select I accept the terms in the License agreement and click Next.
6 On the Destination Folder page, select the location to install Converter Standalone and click Next.
The default location is C:\Program Files\VMware\VMware vCenter Converter Standalone. To install to
another location, you can click Change and browse for the new location.
7 On the Setup Type page, select Local installation and click Next.
8 On the Ready to Install page, click Install.
9 (Optional) On the Installation Completed page, deselect Run Converter Standalone Client now to
complete the installation without starting the application at this time.
10 On the Installation Completed page, click Finish.
A prompt might ask you to restart your system.
Converter Standalone is installed on the local machine and is ready for use.
What to do next
You can use Converter Standalone to convert physical or virtual machine sources to virtual machine
destinations.
Perform a Client-Server Installation in Windows
Perform a client-server installation so that you can create and manage conversion tasks remotely.
During the client-server installation, you can select the Converter Standalone components that you want to
install on your system.
Prerequisites
Make sure your system meets the Converter Standalone system requirements.
Make sure that you have Administrator privileges.
If you have Converter 3.0.x installed and your machine runs Windows Vista, uninstall Converter 3.0.x manually
before you install Converter Standalone 5.0.
If you have an earlier version of Converter Standalone agent on the system, uninstall Converter Standalone
agent.
VMware vCenter Converter Standalone User's Guide
32 VMware, Inc.
Procedure
1 Download the latest version of Converter Standalone from the VMware Web site.
2 Navigate to the folder that contains the installer file you downloaded and double-click the VMware-
converter-5.x.x-<xxxxx>.exe file, where <xxxxx> is the number of the build.
3 In the Choose Setup Language dialog box, select the language for the install process and click OK.
4 On the Setup Type page, select Client-Server installation (advanced) and click Next.
5 On the Custom Setup page, select the components that you want to install and click Next.
Option Description
Converter server Converter Standalone server manages the conversion tasks. It handles the
communication between the Converter Standalone clients and Converter
Standalone agents. You cannot install Converter server alone. You must
install Converter Standalone server together with Remote access or with the
Converter Standalone client, or with both.
Remote access If you install Remote access, local and multiple remote Converter Standalone
clients can connect to the local Converter Standalone server. With remote
access you can create and manage conversion tasks remotely. For remote
access, you must perform a client-server installation.
Converter agent Install Converter Standalone agent to allow the local machine to be a source
machine for conversions.
Converter client If you install only Converter Standalone client, you can connect to remote
Converter Standalone server. You can then use the remote machine to
convert hosted virtual machines, managed virtual machines, or remote
physical machines.
When you install the Converter Standalone server and Remote access, the local machine becomes a server
for conversions, which you can manage remotely. When you install the Converter Standalone server and
the Converter Standalone client, you can use the local machine to access remote Converter Standalone
servers or create conversion jobs locally.
6 (Optional) If you decided to install Remote access or Converter Standalone agent, modify the Web service
ports on the Port Settings page.
nType the HTTPS port service number.
nType the HTTP port service number.
nType the Agent port service number.
7 On the Ready to Install page, click Install.
8 (Optional) If you installed the Converter Standalone client, deselect Run Converter Standalone Client
now to complete the installation without starting the application at this time.
9 On the Installation Completed page, click Finish.
A prompt might ask you to restart your system.
The selected Converter Standalone components are installed on the local machine and are ready for use.
What to do next
You can use Converter Standalone to convert physical or virtual machine sources to virtual machine
destinations.
Chapter 3 Installing and Uninstalling Converter Standalone
VMware, Inc. 33
Perform a Command-Line Installation in Windows
You can install Converter Standalone from the MS-DOS command prompt or by writing a Windows batch file
(.bat) to automate the installation process.
Prerequisites
Make sure your system meets the Converter Standalone system requirements.
Make sure that you have Administrator privileges.
If you have Converter 3.0.x installed and your machine runs Windows Vista, uninstall Converter 3.0.x manually
before you install Converter Standalone 5.0.
If you have an earlier version of Converter Standalone agent on the system, uninstall Converter Standalone
agent.
Procedure
1 Download the latest version of Converter Standalone from the VMware Web site.
2 In the local directory to which you downloaded the installer, see the number of the build, which is a part
of the installer filename.
3 At the command line, install Converter Standalone silently with the log file written to the temp directory.
VMware-converter-<build>.exe /s /v"/qn ADDLOCAL=ALL /l*v %TEMP%\vmconvservermsi.log"
For more command-line options, see “Command-Line Options for Windows Installation,” on page 34.
What to do next
You can use Converter Standalone to convert physical or virtual machine sources to virtual machine
destinations.
Command-Line Options for Windows Installation
You can use the command-line installation options when you install Converter Standalone from the MS-DOS
command prompt in Windows or by writing a Windows batch file (.bat).
For a list of options to perform command-line installation, see Table 3-1.
Table 3-1. Command-Line Options
Option Action
/s Does not display the Windows Installer version check.
/v"
params
"Passes parameters to the msiexec.exe file.
/qn Runs the msi command in silent mode.
/qb Runs the msi command in basic mode.
/qf Runs the msi command in full mode.
/l*v
Logfile
Records login information in the file provided in Logfile.
/x Uninstalls VMware vCenter Converter Standalone.
ADDLOCAL="ALL" Installs full package. The parameter is case-sensitive.
PROPERTY=
property value
Sets the value of a property to property value.
VMCE_HTTP_PORT Sets the HTTP port. The default is 80. Remote machines
connect to the server through this port to download the
Converter Standalone client.
VMware vCenter Converter Standalone User's Guide
34 VMware, Inc.
Table 3-1. Command-Line Options (Continued)
Option Action
VMCE_HTTPS_PORT Set the HTTPS port. The default is 443. Remote Converter
Standalone clients connect to this port on the server and
submit conversion tasks.
VMCE_AGENT_PORT Sets an Agent port. The default is 9089. Remote Converter
Standalone servers connect to this port to convert this
machine.
Modify Converter Standalone in Windows
To change the installed Converter Standalone agent or the communication ports for the Converter Standalone
components, you must modify the Converter Standalone installaton.
Prerequisites
Make sure that you have Administrator privileges.
Close the Converter Standalone application before you start the installer wizard.
Procedure
1 To start the Converter Standalone installer, perform one of the following actions:
nGo to the folder that contains the installer file and double-click the VMware-converter-5.x.x-
<xxxxx>.exe file, where <xxxxx> is the number of the build. Check the number of the build to see if it
matches the build you installed.
nSelect Add or Remove Programs from Control Panel, select Converter Standalone from the list, and
click Change.
2 On the Welcome page of the installer wizard, click Next.
3 On the Program Maintenance page, select Modify and click Next.
4 On the Custom Setup page, select the components that you want to install and click Next.
Option Description
Converter server Converter Standalone server manages the conversion tasks. It handles the
communication between the Converter Standalone clients and Converter
Standalone agents. You cannot install Converter server alone. You must
install Converter Standalone server together with Remote access or with the
Converter Standalone client, or with both.
Remote access If you install Remote access, local and multiple remote Converter Standalone
clients can connect to the local Converter Standalone server. With remote
access you can create and manage conversion tasks remotely. For remote
access, you must perform a client-server installation.
Converter agent Install Converter Standalone agent to allow the local machine to be a source
machine for conversions.
Converter client If you install only Converter Standalone client, you can connect to remote
Converter Standalone server. You can then use the remote machine to
convert hosted virtual machines, managed virtual machines, or remote
physical machines.
When you install the Converter Standalone server and Remote access, the local machine becomes a server
for conversions, which you can manage remotely. When you install the Converter Standalone server and
the Converter Standalone client, you can use the local machine to access remote Converter Standalone
servers or create conversion jobs locally.
Chapter 3 Installing and Uninstalling Converter Standalone
VMware, Inc. 35
5 (Optional) If you decided to install Remote access or Converter Standalone agent, modify the Web service
ports on the Port Settings page.
nType the HTTPS port service number.
nType the HTTP port service number.
nType the Agent port service number.
6 On the Ready to Modify page, click Install.
7 (Optional) If you installed the Converter Standalone client, deselect Run Converter Standalone Client
now to complete the installation without starting the application at this time.
8 On the Installation Completed page, click Finish.
A prompt might ask you to restart your system.
The selected Converter Standalone components are installed on the local machine and are ready for use.
What to do next
You can use Converter Standalone to convert physical or virtual machine sources to virtual machine
destinations.
Repair Converter Standalone in Windows
You can repair the Converter Standalone installation to check for and reinstall the Converter Standalone client
or Converter Standalone agent.
Prerequisites
Make sure that you have Administrator privileges.
Close the Converter Standalone application before you start the installer wizard.
Procedure
1 To start the Converter Standalone installer, perform one of the following actions:
nGo to the folder that contains the installer file and double-click the VMware-converter-5.x.x-
<xxxxx>.exe file, where <xxxxx> is the number of the build. Check the number of the build to see if it
matches the build you installed.
nSelect Add or Remove Programs from Control Panel, select Converter Standalone from the list, and
click Change.
2 On the Welcome page of the installer wizard, click Next.
3 On the Program Maintenance page, select Repair and click Next.
4 On the Ready to Repair page, click Install.
5 On the Installation Completed page, click Finish.
A prompt might ask you to restart your system.
What to do next
You can use Converter Standalone to convert physical or virtual machine sources to virtual machine
destinations.
VMware vCenter Converter Standalone User's Guide
36 VMware, Inc.
Uninstall Converter Standalone in Windows
You can uninstall Converter Standalone by using the Microsoft Windows Add or Remove Programs utility
from the Control Panel or by using the VMware vCenter Converter Standalone installer wizard.
Prerequisites
Make sure that you have Administrator privileges.
Close the Converter Standalone application before you start the installer wizard.
Procedure
1 To start the Converter Standalone installer, perform one of the following actions:
nGo to the folder that contains the installer file and double-click the VMware-converter-5.x.x-
<xxxxx>.exe file, where <xxxxx> is the number of the build. Check the number of the build to see if it
matches the build you installed.
nSelect Add or Remove Programs from Control Panel, select Converter Standalone from the list, and
click Change.
2 On the Welcome page of the installer wizard, click Next.
3 On the Program Maintenance page, select Remove and click Next.
4 On the Ready to Remove page, click Remove.
5 On the Installation Completed page, click Finish.
A prompt might ask you to restart your system.
Connect to a Remote Converter Standalone Server
You can use the Converter Standalone client to connect to a Converter Standalone server installed on a remote
machine.
Prerequisites
Ensure that the Converter Standalone server and agent are installed on the remote machine.
Procedure
1 Start Converter Standalone.
2 Follow the procedure that is applicable for your installation type.
Option Action
Local installation a Select Administration > Connect to another server.
b On the Converter Standalone login page, select Enter the IP address or
host name of the Converter Standalone server.
c Provide the IP address and Administrator credentials, and click Login.
Client-server installation with
remote access
a On the Converter Standalone login page, select Enter the IP address or
host name of the Converter Standalone server.
b Provide the IP address and Administrator credentials, and click Login.
What to do next
You can now use the remote Converter Standalone server to set up and manage conversion tasks.
Chapter 3 Installing and Uninstalling Converter Standalone
VMware, Inc. 37
VMware vCenter Converter Standalone User's Guide
38 VMware, Inc.
Convert a Physical or Virtual Machine 4
You can create a conversion job to convert a physical or virtual machine to a variety of destinations. You can
convert physical machines, VMware virtual machines, third-party backup images and virtual machines, and
Hyper-V Server virtual machines into VMware standalone virtual machines or virtual machines that vCenter
Server manages.
The approach you take for creating the conversion job is determined by the type of source and the type of
destination that you select.
Source type A powered-on physical or virtual machine, a VMware Infrastructure virtual
machine running on an ESX host, or a standalone virtual machine.
Standalone virtual machines include VMware virtual machines, backup
images, and third-party virtual machines, such as VMware Workstation,
VMware Server, VCB, Acronis True Image, Microsoft Virtual PC, Virtual
Server, Symantec Backup Exec Server Recovery (formerly known as
LiveState Recovery), LiveState Recovery, StorageCraft, Parallels Desktop for
Microsoft Windows and Mac OS, Parallels Workstation, and Norton Ghost
(only .sv2i) images.
For a complete list of supported source types and product versions, see
“Supported Source Types,” on page 21.
Destination type ESX host, ESX host that vCenter Server manages, or a VMware standalone
virtual machine.
For a complete list of supported destination types and product versions, see
“Supported Destination Types,” on page 23.
Procedure
1Start the Wizard for a Conversion on page 40
The Conversion wizard guides you through the steps of creating a conversion job.
2Select a Source Machine to Convert on page 40
You can select from several source options for the type of machine to convert.
3Select a Destination for the New Virtual Machine on page 46
When you set up a conversion job, you must select a destination for the new virtual machine.
4Configure the Hardware of the Destination Virtual Machine on page 49
You can configure the virtual hardware resources that the destination virtual machine uses.
5Configure the Software on the Destination Virtual Machine on page 61
You can configure the guest operating system so that it is ready to operate in a virtual environment.
VMware, Inc. 39
6Configure the Conversion Job on page 66
You can configure the conversion process and select the behavior of the source and destination machine
during and after conversion. You can change the status of the source and destination services only when
the source machine is running a Windows operating system.
7Review the Summary and Submit the Conversion Job on page 71
On the Summary page, you can view a summary of the conversion job before you add it to the job list.
Start the Wizard for a Conversion
The Conversion wizard guides you through the steps of creating a conversion job.
Procedure
1 Start the Converter Standalone application.
2 Click Convert Machine in the application menu.
The Conversion wizard opens on the Source System page.
What to do next
You can now select the source machine type to convert.
Select a Source Machine to Convert
You can select from several source options for the type of machine to convert.
Prerequisites
Before you select a source machine to convert, verify that it is listed in the list of supported source types. See
“Supported Source Types,” on page 21.
nSelect a Powered-On Windows Machine to Convert on page 41
You can select a running (powered-on) Windows machine to convert. The source machine can be physical
or virtual.
nSelect a Powered-On Linux Machine to Convert on page 42
You can select a powered-on Linux machine to convert. The source machine can be a physical or virtual
machine.
nSelect an ESX/ESXi or vCenter Server Virtual Machine to Convert on page 42
You can convert a powered-off virtual machine that is located on an ESX/ESXi host, or on an ESX/ESXi
host managed by vCenter Server.
nSelect a VMware Hosted Virtual Machine to Convert on page 44
You can convert a virtual machine created or used in a VMware hosted product, such as VMware
Workstation, VMware Player, VMware Fusion, and VMware Server.
nSelect a Backup Image or a Third-Party Virtual Machine to Convert on page 44
You can select a backup image or a third-party virtual machine as the conversion source.
nSelect a Hyper-V Server Virtual Machine to Convert on page 45
You can convert virtual machines that Hyper-V Server manages.
VMware vCenter Converter Standalone User's Guide
40 VMware, Inc.
Select a Powered-On Windows Machine to Convert
You can select a running (powered-on) Windows machine to convert. The source machine can be physical or
virtual.
Prerequisites
Before you continue, you must prepare the source Windows machine for conversion.
nMake sure that the Windows version installed on the powered-on machine is supported. For a list of
supported operating systems, see “Supported Operating Systems,” on page 19.
nMake sure that the Converter Standalone server machine has network access to the Windows source
machine.
nTurn off firewall applications running on the source machine.
nDisable simple file sharing on the source Windows machine.
nMake sure that no other conversion job is using the source you select.
nRemove any VMware Converter 3.x installations manually from the source machine.
nIf you plan to convert a powered-on machine by using IPv6, ensure that Converter Standalone server is
installed on the Windows Vista, Windows Server 2008, or Windows 7 operating system.
Procedure
1 On the Source System page of the Conversion wizard, select Powered-on machine from the Select source
type drop-down menu.
2 Select an option that corresponds to your source machine location.
Source Location Action
Local Click This local machine.
For local machines, the authorization is set to the current user and cannot be
changed. If remote access is enabled during Converter Standalone
installation, the local machine is treated as a remote physical machine.
Remote a Click A remote machine.
b Provide the IP address or name of the machine and administrator
credentials.
c Select the operating system type from the OS Family drop-down menu.
3 (Optional) Click View source details to see hardware and software information about the source machine.
4 Click Next.
If Converter Standalone agent is not already installed on the source machine, a dialog box prompts you
to confirm the installation and select an uninstallation method for Converter Standalone agent.
5 (Optional) Select the uninstallation procedure for Converter Standalone agent and click Yes.
Converter Standalone agent is installed on the source machine.
Converter Standalone agent prepares the source machine for conversion.
What to do next
On the Destination System page you can select the destination type for the new virtual machine.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 41
Select a Powered-On Linux Machine to Convert
You can select a powered-on Linux machine to convert. The source machine can be a physical or virtual
machine.
You can convert powered-on machines that run Linux only if GRUB is installed as the boot loader on the source.
LILO boot loader is not supported.
Prerequisites
Before you continue, you must prepare the source machine for conversion.
nEnable SSH on the source Linux machine.
nMake sure that you use the root account to convert a Linux powered-on machine.
nMake sure that vCenter Converter server machine has network access to the Linux source machine.
nMake sure that no other conversion job is using the source you select.
nTo be able to convert multiboot virtual machines, make sure to install GRUB as the boot loader. LILO is
not supported.
Procedure
1 On the Source System page of the Conversion wizard, select Powered-on machine from the Select source
type drop-down menu.
2 Provide the IP address or DNS name and root credentials for the Linux machine you want to convert.
3 From the OS Family drop-down menu, select Linux.
4 Click Next.
Converter Standalone connects to the powered-on Linux machine and prepares it for conversion.
What to do next
On the Destination System page you can select the destination type for the new virtual machine.
Select an ESX/ESXi or vCenter Server Virtual Machine to Convert
You can convert a powered-off virtual machine that is located on an ESX/ESXi host, or on an ESX/ESXi host
managed by vCenter Server.
You cannot convert a running or suspended virtual machine by using this procedure. For powered-on virtual
machines, use the procedures for powered-on source machines.
If you connect to a vCenter Server that is part of an environment that contains multiple vCenter Server
instances, Converter Standalone displays only ESX hosts managed directly by the currently connected vCenter
Server.
Prerequisites
If the source machine that you want to convert resides on a VMware DRS cluster that vCenter Server manages,
set VMware DRS Power Management (DPM) to manual so that DPM does not power off the ESX hosts used
by Converter Standalone. When the conversion process completes, restore DPM to its original settings. For
information about how to change DPM settings, see the Resource Management Guide.
Power off the source machine before the conversion.
Procedure
1 On the Source System page of the Conversion wizard, select VMware Infrastructure virtual machine
from the Select source type drop-down menu.
VMware vCenter Converter Standalone User's Guide
42 VMware, Inc.
2 Provide the IP address or host name and credentials for authentication with the ESX host or the vCenter
Server, and click Next.
The Source Machine page appears, displaying the host name or IP address and the inventory of the ESX host
or the vCenter Server.
What to do next
On the Source Machine page of the Conversion wizard, you can browse the virtual infrastructure inventory
and select the virtual machine to convert.
Specify the vCenter Server Virtual Machine to Convert
If you choose to convert a virtual machine managed by a vCenter Server or ESX host, you must browse the
inventory to locate the source virtual machine.
Prerequisites
On the Source System page of the Conversion wizard, select VMware Infrastructure virtual machine as the
conversion source and click Next to proceed to the Source Machine page.
Procedure
1 (Optional) If you are connected to a vCenter Server, select a virtual machine view from the Specify
machine with drop-down menu.
Option Description
Hosts and Clusters The Inventroy tree pane provides a view of hosts, clusters, resource pools,
and vApps. If you select a host managed by a cluster, you see the full list of
virtual machines and templates in the VM list view. If you select a standalone
host or a cluster, you see only the virtual machines that are not deployed in
the resource pools of that host or cluster.
VMs and Templates The Inventory tree pane provides a view of datacenters and VM folders.
2 (Optional) If you are connected to a vCenter Server, select an object from the Inventory tree pane.
Option Description
Hosts and Clusters Select cluster, ESX host, resource pool, or vApp.
VMs and Templates Select datacenter or VM folder.
3 From the virtual machines list, select the virtual machine you want to convert.
You can search for virtual machines in the VM list by typing one or more letters of their names in the
Search for name with text box. You can clear your search by clicking Clear.
NOTE If you connect to a vCenter Server that has a disconnected ESX instance (powered off, connected
to another vCenter Server, or in maintenace mode), you cannot select a virtual machine from that ESX
host.
4 (Optional) To refresh the Inventory, click Refresh.
5 (Optional) To view more details about a machine, select it and click View source details.
6 Click Next to proceed to the Destination System page.
What to do next
On the Destination System page you can select the destination type for the new virtual machine.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 43
Select a VMware Hosted Virtual Machine to Convert
You can convert a virtual machine created or used in a VMware hosted product, such as VMware Workstation,
VMware Player, VMware Fusion, and VMware Server.
Prerequisites
Verify that your source machine is a supported VMware Desktop products virtual machine “Supported Source
Types,” on page 21.
If you plan to use a network path to locate the source, verify that the machine where Converter Standalone
server runs has access to that network path.
Power off the source machine before the conversion.
Procedure
1 On the Source System page of the Conversion wizard, select VMware Workstation or other VMware
virtual machine from the Select source type drop-down menu.
2 Locate the virtual machine source.
nIf you are connected to a remote Converter Standalone server, provide a network path to the source
virtual machine file (.vmx) in the Virtual machine file text box. For
example, \\server\virtual_machines\virtual_machine.vmx.
nIf you are connected to a local Converter Standalone server, provide a network path or a local path
to the .vmx file.
The file type choices are limited to VMware Workstation *.vmx files.
3 If you are connected to a remote Converter Standalone server, enter user credentials for accessing the
source virtual machine.
You do not have to provide user credentials if you are connected to a local Converter Standalone server.
In such cases, Converter Standalone uses the Windows credentials to connect to the source machine.
4 (Optional) To view more information about the selected source, click View source details
5 Click Next to proceed to the Destination System page.
What to do next
On the Destination System page you can select the destination type for the new virtual machine.
Select a Backup Image or a Third-Party Virtual Machine to Convert
You can select a backup image or a third-party virtual machine as the conversion source.
Prerequisites
Verify that your machine is a supported backup image or third-party virtual machine here “Supported Source
Types,” on page 21.
If you plan to use a network path to locate the source, verify that the machine where Converter Standalone
server runs has access to that network path.
Power off the source machine before the conversion.
Procedure
1 On the Source System page, select Backup image or third-party virtual machine from the Select source
type drop-down menu.
VMware vCenter Converter Standalone User's Guide
44 VMware, Inc.
2 Locate the source backup image or virtual machine file.
nIf you are connected to a remote Converter Standalone server, provide a valid network path to the
source backup image or virtual machine file in the Virtual machine file text box. For
example, \\server\backup_images\backup_image.pvs.
nIf you are connected to a local Converter Standalone server, provide a network path or a local path
to the source backup image or virtual machine file.
3 If you are connected to a remote Converter Standalone server, enter user credentials for accessing the
source virtual machine.
You do not have to provide user credentials if you are connected to a local Converter Standalone server.
In such cases, Converter Standalone uses the Windows credentials to connect to the source machine.
4 (Optional) To view more information about the selected source, click View source details
5 Click Next to proceed to the Destination System page.
What to do next
On the Destination System page you can select the destination type for the new virtual machine.
Select a Hyper-V Server Virtual Machine to Convert
You can convert virtual machines that Hyper-V Server manages.
Prerequisites
Power off the source Hyper-V virtual machine.
Procedure
1 On the Source System page, select Hyper-V Server from the Select source type drop-down menu.
2 Provide the IP address or DNS name and administrative credentials to authenticate with the Hyper-V
Server and click Next.
If Converter Standalone agent is not already installed on the Hyper-V Server, a dialog box appears. In it,
you confirm the installation of Converter Standalone agent.
3 (Optional) Select an uninstallation procedure for Converter Standalone agent and click Yes.
Converter Standalone agent is installed on the source Hyper-V Server.
What to do next
On the Source Machine page,browse the Hyper-V Server inventory to locate the source virtual machine to
convert.
Specify the Hyper-V Server Virtual Machine to Convert
If you choose to convert a virtual machine managed by a Hyper-V Server, you must browse the inventory to
locate the source virtual machine.
Prerequisites
On the Source System page, select Hyper-V Server as the source type and navigate to the Source Machine
page.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 45
Procedure
1 On the Source Machine page, select the virtual machine you want to convert.
You can search for virtual machines in the inventory by typing one or more letters of their names in the
Search for name with text box. You can clear your search by clicking Clear.
NOTE You can select only powered-off virtual machines. To convert a running machine, select a powered-
on machine. To convert a suspended machine, either power it off and use the current procedure, or power
it on and select a powered-on machine as the source.
2 (Optional) To refresh the inventory, click Refresh.
3 (Optional) To view more details about the virtual machine to convert, click View source details.
4 Click Next to proceed to the Destination System page.
The Converter Standalone agent prepares the Hyper-V source machine for conversion.
What to do next
On the Destination System page you can select the destination type for the new virtual machine.
Select a Destination for the New Virtual Machine
When you set up a conversion job, you must select a destination for the new virtual machine.
When you use a VMware DRS cluster as the destination, you must set VMware DRS Power Management
(DPM) to manual. This setting ensures that DPM does not power off the ESX hosts that Converter Standalone
uses. When the conversion process completes, restore DPM to its original settings. For information about how
to change DPM settings, see the Resource Management Guide.
NOTE For conversions of powered-on source machines that run Linux, the only supported destination is a
VMware Infrastructure destination.
Select a Managed Destination
You can convert a virtual machine to use with ESX/ESXi or with an ESX/ESXi host that vCenter Server manages.
Procedure
1 On the Destination System page, select VMware Infrastructure virtual machine from the Select
destination type drop-down menu.
2 Provide the IP address or host name and credentials for authentication with the ESX host or the vCenter
Server.
3 Click Next to proceed to the Destination Virtual Machine page.
What to do next
On the Destination Virtual Machine page, you can specify the name of the destination virtual machine and
select the folder in which it should reside.
Name the Destination Virtual Machine and Select a Folder
For VMware Infrastructure destinations, you can select the destination folder and rename the destination
virtual machine.
If you connect to an ESX host directly, you can view only the list of virtual machines. Therefore, you cannot
select a destination folder.
VMware vCenter Converter Standalone User's Guide
46 VMware, Inc.
Prerequisites
On the Destination System page of the Conversion wizard, select VMware Infrastructure virtual machine as
the destination type.
Procedure
1 On the Destination Virtual Machine page, select the datacenter to accommodate the destination virtual
machine.
If you use folders in your virtual environment to manage groups of virtual machines, you can select a
folder to accommodate the destination virtual machine.
2 In the Name text box, enter a name for the destination virtual machine.
By default, Converter Standalone assigns the source machine name in this text box.
NOTE Search the list of virtual machines in the datacenter or folder you selected to ensure that the name
you assign to the destination virtual machine does not exist. Virtual machines are filtered as you type. You
can clear your search by clicking Clear.
3 (Optional) To refresh the Inventory, click Refresh.
4 Click Next to proceed to the Destination Location page.
What to do next
On the Destination Location page you can modify the destination environment for the new virtual machine.
This includes selecting a host, resource pool, or cluster to accommodate the destination virtual machine,
selecting the Datastore to hold the files of the destination virtual machine, and selecting the virtual hardware
version to install on the destination virtual machine.
Customize the Location of the Destination Virtual Machine
For VMware Infrastructure destinations, you can select an ESX host, a resource pool, or a cluster. You can also
select a datastore and the virtual hardware version to be installed on the destination.
Prerequisites
On the Destination Virtual Machine page, name the destination virtual machine. If the destination is a vCenter
Server, select the destination folder.
Procedure
1 On the Destination Location page of the Conversion wizard, select a datacenter object from the inventory
to accommodate the destination virtual machine.
nSelect an ESX host.
nSelect a resource pool.
nSelect a cluster.
On the selected cluster, if DRS is not running in the automated mode, you can select an ESX host that
belongs to the selected cluster from the Host drop-down menu.
2 (Optional) From the Datastore drop-down menu, select the datastore to hold the destination virtual
machine files.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 47
3 (Optional) From the Virtual machine version drop-down menu, select the virtual hardware version for
the destination virtual machine.
Option Description
Version 4 Select if the destination host is running ESX 3.x.
Version 7 Select if the destination host is running ESX 4.x or later.
Version 8 Select if the destination host is running ESX 5.x or later.
4 Click Next to proceed to the Options page.
What to do next
On the Options page you can set up the parameters of the conversion task. These settings include data layout,
network settings, and guest operating system customization.
Select a Hosted Destination
You can convert a virtual machine for use with VMware Workstation, VMware Fusion, VMware Server, or
VMware Player.
Prerequisites
If you plan to use a network path to locate the destination, verify that you have access to that network path.
nFor powered-on machines or Hyper-V virtual machine sources, verify that the machine where Converter
Standalone agent runs has access to that network path.
nFor all other source types, verify that the machine where Converter Standalone server runs has access to
that network path.
Procedure
1 On the Destination System page, select VMware Workstation or other VMware virtual machine from
the Select destination type drop-down menu.
2 Select the destination VMware hosted product from the Select VMware product drop-down menu.
3 Provide a name for the destination virtual machine in the Name text box.
4 Specify the location to store the destination virtual machine files.
nIf you are connected to a remote Converter Standalone server, provide a network path to the
destination directory. For example, \\server\virtual_machines\.
nIf you are connected to a local Converter Standalone server, provide a network path or a local path
to the destination directory.
5 (Optional) If the destination directory is password-protected, provide valid user credentials.
You do not have to provide user credentials if the destination location is on the local storage of the machine
where Converter Standalone server runs.
6 Click Next to proceed to the Options page.
What to do next
On the Options page you can set up the parameters of the conversion task. These settings include data layout,
network settings, and guest operating system customization.
VMware vCenter Converter Standalone User's Guide
48 VMware, Inc.
Configure the Hardware of the Destination Virtual Machine
You can configure the virtual hardware resources that the destination virtual machine uses.
nOrganize the Data to Copy on the Destination Machine on page 49
Depending on the selected source and destination, you can either created linked clones, or select between
disk-based and volume-based cloning modes. For the conversion job, you can copy all disks to the
destination or select the volumes to be copied or to be excluded. For destinations with multiple datastores,
you can select the data location on specific datastores in your virtual environment.
nEdit the Number of Processor Sockets and Cores on page 58
You can change the number of virtual sockets and the number of processor cores per socket that the
destination virtual machine uses.
nAllocate Memory for the Destination Virtual Machine on page 59
You can change the amount of memory allocated to the destination virtual machine.
nSpecify a Disk Controller for the Destination Virtual Machine on page 59
You can select a disk controller type for the destination virtual disks.
nConfigure the Network Settings of the Destination Virtual Machine on page 60
You can change the number of network adapters and select the network that the destination virtual
machine uses. You can also set network adapters to connect to the network when the destination virtual
machine powers on.
nConfigure the Network for the Helper Virtual Machine on page 61
When you convert a powered-on Linux machine, Converter Standalone creates a Helper virtual machine
on the destination. The Helper virtual machine needs network access to the source machine to clone the
source files. Default conversion settings enforce automatic acquisition of an IPv4 address and a DNS
server for the Helper virtual machine, but you can set up this network connection manually.
Organize the Data to Copy on the Destination Machine
Depending on the selected source and destination, you can either created linked clones, or select between disk-
based and volume-based cloning modes. For the conversion job, you can copy all disks to the destination or
select the volumes to be copied or to be excluded. For destinations with multiple datastores, you can select the
data location on specific datastores in your virtual environment.
IMPORTANT Converter Standalone cannot detect any source volumes and file systems that are located on
physical disks larger than 2TB.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 49
Procedure
uIn the Data to copy pane, select a copy mode from the Data copy type drop-down menu.
Option Description
Copy all disks and maintain layout Results in disk-based cloning. You can preserve the source disk layout in the
destination virtual machine. This option is not available for physical machine
sources.
Select volumes to copy Results in volume-based cloning. Volume-based cloning is performed at file
or block level. You can select the volumes to be copied to the destination
virtual machine. You can also resize and reorganize the volume layout. This
option is available for powered-on source machines that run Windows and
Linux, and for all other supported sources that run Windows.
Linked clone A linked clone allows you to create a VMware virtual machine that shares
the virtual disk of the source machine or system image. This option is
available for hosted sources and hosted destinatons.
Depending on the destination you select, several destination disk types are available. To support
destination virtual disks on FAT file systems, divide the source data into 2GB files. For detailed information
about destination virtual disks types, see “Destination Disk Types,” on page 15.
Resize a Volume
To manage disk space on the destination datastore, you can resize the disk volumes before you begin the
conversion.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 In the Destination size column, select an option to specify the size of a destination volume.
Option Description
Maintain size Maintains the original source volume size.
Min size Copies only the used space of the source volume.
Type size in GB Allows you to type a custom size in GB for the destination volume. The value
cannot be smaller than the used space on the source volume, but can be larger
than the total size of the source volume. The maximum allowed disk size for
the destination is 999GB.
Type size in MB Allows you to type a custom size in MB for the destination volume. The value
cannot be smaller than the used space on the source volume, but can be larger
than the total size of the source volume. The maximum allowed disk size for
the destination is 999GB.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
VMware vCenter Converter Standalone User's Guide
50 VMware, Inc.
Change a Volume Cluster Size
To enhance performance and storage space, you can change the volume cluster size before the conversion.
Modifying the cluster size changes the cloning mode from block level to file level.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Ensure that the source is a Windows machine.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Click Advanced and select the Destination layout tab.
3 Select the volume for which you want to change the cluster size.
4 In the Cluster size column, select an option to specify the cluster size of the destination volume.
Option Description
Default cluster size Applies a default cluster size to the destination volume.
Keep source cluster size Preserves the cluster size of the original source volume.
Select a predefined size Allows you to select a cluster size for the destination volume from a list of
supported values.
In the Copy type column, you can verify that the cloning operation type is set to file level.
5 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Exclude a Source Volume from the Conversion Process
You can choose not to copy a volume from the source machine to the destination virtual machine. During the
conversion process, Converter Standalone ignores the deselected volumes and copies only the volumes that
are selected.
The source virtual machine must have more than one volume to be able to deselect existing volumes.
You cannot delete the system volume from the destination virtual machine. For example, if C: is the volume
that contains the Windows operating system installation, you cannot remove it from the destination virtual
machine.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Deselect the volumes that you do not want to copy to the destination virtual machine.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 51
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
The deselected volumes are ignored during the conversion process and do not appear on the destination virtual
machine.
Move a Volume to a Different Virtual Disk
You can add virtual disks to the destination virtual machine and move source volumes in the new disks.
The number of virtual disks you can create depends on the number of volumes that exist on the source virtual
machine. For example, if you have only one volume on the source virtual machine, you cannot add a virtual
disk to the destination virtual machine.
You cannot move the system volume where the guest operating system is installed. For example, if your
Windows operating system is installed on C:, you cannot move the C: volume.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Click Advanced and select the Destination layout tab.
3 Select a volume from the list and click Add disk.
A new virtual disk appears in the Destination layout column.
4 Select a source volume and use the Move up and Move down buttons to accommodate the volume in the
new virtual disk.
If you leave the new virtual disk empty, Converter Standalone does not create the new virtual disk on the
destination virtual machine.
The selected source volume is copied to a new virtual disk on the destination virutal machine.
Select the Destination Datastore for a Source Volume
You can store a disk volume in a datastore different from the one that accommodates the virtual machine
configuration file (.vmx).
You can select the destination datastore for a volume only for managed destinations with more than one
datastore.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Click Advanced and select the Destination layout tab.
VMware vCenter Converter Standalone User's Guide
52 VMware, Inc.
3 Select a volume from the list and click Add disk.
A new virtual disk appears in the Destination layout column.
4 Select a source volume and use the Move up and Move down buttons to accommodate the volume in the
new virtual disk.
If you leave the new virtual disk empty, Converter Standalone does not create the new virtual disk on the
destination virtual machine.
5 Highlight the new virtual disk and select a different datastore from the Destination datastore drop-down
menu.
6 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
The virtual disk file (.vmdk) that contains the volume is stored in the selected datastore.
Add a Virtual Disk
You can add a virtual disk to the destination virtual machine.
The number of virtual disks depends on the number of volumes that exist on the source virtual machine. For
example, if you have only one volume on the source virtual machine, you cannot add a virtual disk to the
destination virtual machine.
Prerequisites
You must have more than one volumes on the source machine to be able to add an additional virtual disk.
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Click Advanced and select the Destination layout tab.
3 Select a volume from the list and click Add disk.
A virtual disk is added to the destination disk layout.
4 Select a source volume and use the Move up and Move down buttons to accommodate the volume in the
new virtual disk.
If you leave the new virtual disk empty, Converter Standalone does not create the new virtual disk on the
destination virtual machine.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 53
5 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
The new virtual disk is created on the destination datastore.
Set Up a Virtual Disk as a Logical-Volume Group Container
To preserve the LVM structure when converting a Linux source, you can set up a virtual disk as a logical-
volume container. Converter Standalone allows you to preserve and modify the source LVM structure.
You can manage logical volumes and logical-volume groups in the same way as basic volumes and disks.
Logical-volume groups are listed together with virtual disks and are marked with a different icon.
You cannot move active and system volumes in a logical-volume group.
Prerequisites
Ensure that the source is a Linux machine and supports LVM.
Only LVM2 is supported.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Click Advanced and select the Destination layout tab.
3 Select a disk and click To LVG.
Move a Disk to a Different Datastore
You can use disk-based cloning to select a different datastore for a destination virtual disk.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
You can change the destination datastore for a disk only for managed destinations with more than one
datastore.
Procedure
1 From the Data copy type drop-down menu, select Copy all disks and maintain layout.
2 Click the name of the virtual disk to relocate and select a different datastore from the Destination
datastore drop-down menu.
VMware vCenter Converter Standalone User's Guide
54 VMware, Inc.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
The virtual disk file (.vmdk) is stored in the selected datastore.
Create an Expandable Disk on a Managed Destination
To save space on the destination datastore, you can copy only the existing data from a source virtual disk and
create an expandable disk on the destination. Later, as you use the destination virtual machine and write new
data, the destination virtual disk grows.
You can create expandable disks on managed destinations that support thin provisioning through their GUI.
You can create an expandable disk by using volume-based or disk-based cloning.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
nUse disk-based cloning to create an expandable disk.
a From the Data copy type drop-down menu, select Copy all disks and maintain layout.
b Click a virtual disk and select Thin from the Type drop-down menu.
c To apply your settings, select another option from the options list or click Next.
nUse volume-based cloning to create an expandable disk.
a From the Data copy type drop-down menu, select Select volumes to copy and click Advanced.
b Select the Destination layout tab, click a virtual disk, and select Thin from the Type drop-down
menu.
c To apply your settings, select another option from the options list or click Next.
Converter Standalone copies only the existing data to the destination datastore. The empty disk space from
the virtual disk is not copied to the datastore. As you use the destination virtual machine and write new data
to the disk, the size of the destination disk grows.
Create an Expandable Disk on a Hosted Destination
To save space on the destination, you can copy only the existing data from a source virtual disk. Later, as you
use the destination virtual machine and write new data, the destination virtual disk grows.
You can create an expandable disk by using volume-based or disk-based cloning.
Prerequisites
You must select a hosted destination, such as VMware Workstation, to use the Not pre-allocated disk option.
On the Options page of the Conversion wizard, click Data to copy in the options list.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 55
Procedure
nUse disk-based cloning to create an expandable disk.
a From the Data copy type drop-down menu, select Copy all disks and maintain layout.
b From the Type drop-down menu, select Not pre-allocated.
c To apply your settings, select another option from the options list or click Next.
nUse volume-based cloning to create an expandable disk.
a From the Data copy type drop-down menu, select Select volumes to copy and click Advanced.
b Select the Destination layout tab, select a virtual disk, and select Not pre-allocated from the Type
drop-down menu.
c To apply your settings, select another option from the options list or click Next.
Converter Standalone copies only the existing data to the destination datastore. The empty disk space from
the virtual disk is not copied to the datastore. As you use the destination virtual machine and write new data
to the disk, the size of the destination disk grows.
Exclude a Source Disk from the Conversion Process
You can select a disk from the source machine and delete it from the disk layout of the destination virtual
machine.
Prerequisites
The source machine must have more than one hard disk.
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Delete the disk.
Option Description
Preserve the volumes associated
with the disk
a Click Advanced and select the Destination layout tab.
b Move the volumes from the disk that you want to delete to another
virtual disks.
c Highlight the empty disk and click Remove disk.
Delete the volumes associated with
the disk
a Click Advanced and select the Source volumes tab.
b Deselect the volumes associated with the disk that you want to delete.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Converter Standalone creates .vmdk files in the destination datastore only for the virtual disks you decided to
preserve.
VMware vCenter Converter Standalone User's Guide
56 VMware, Inc.
Copy All Disks to the Destination
To preserve the source disks on the destination virtual machine, you can copy all disks to the destination.
Disk-based cloning is not available for powered-on machine sources.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Copy all disks and maintain layout.
2 (Optional) If the destination datastore is low on disk space, click a virtual disk and select a different
datastore from the Destination datastore drop-down menu.
NOTE You must have access to more than one datastore to move a disk to a different datastore.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Converter Standalone copies the disks to the selected datastores and preserves the source disk layout.
Create an Optimized Partition Layout
By default, Converter Standalone optimizes the disk partitions alignment. Optimizing the partition alignment
improves the performance of the destination virtual machine.
Prerequisites
On the Options page of the Conversion wizard, click Data to copy in the options list.
Procedure
1 From the Data copy type drop-down menu, select Select volumes to copy.
2 Select the Create optimized partition layout check box.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Creating an optimized partition layout aligns the partitions on a 1MB boundary for Windows sources and on
a 64KB boundary for Linux sources.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 57
Create a Linked Clone
A linked clone is a VMware virtual machine that shares the virtual disk of the source virtual machine or system
image. Linked clones are useful for checking the compatibility of non-VMware images, such as .sv2i
and .vmc files.
You can create linked clones only when you convert a virtual machine or other image source to a hosted
destination.
You cannot create linked clones from Parallels source images.
You cannot create a linked clone if the source image is password-protected.
CAUTION Linked clones converted from Virtual PC and Virtual Server machines, and from LiveState images
are corrupted if the source is modified or powered on after the conversion.
Prerequisites
Turn off the source virtual machine.
To verify that your source type is a supported third-party source, see “Supported Source Types,” on page 21.
Procedure
1 On the Destination System page, select VMware Workstation or other VMware virtual machine as a
destination and clickNext.
2 On the Options page, click Data to copy in the left pane.
3 In the Data copy type drop-down menu, select Linked clone.
4 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
You have set up a conversion job to create a linked clone.
Edit the Number of Processor Sockets and Cores
You can change the number of virtual sockets and the number of processor cores per socket that the destination
virtual machine uses.
Prerequisites
Make sure the destination host and the guest operating system support the number of processor cores you
assign to the destination virtual machine.
NOTE You can change the number of processors cores per socket only on ESX/vCenter Server 5.0 and later.
On the Options page of the Conversion wizard, click Devices in the options list.
Procedure
1 Click the Other tab.
VMware vCenter Converter Standalone User's Guide
58 VMware, Inc.
2 From the Number of virtual sockets drop-down menu on the CPU Settings panel, select the number of
virtual sockets for the destination virtual machine.
3 From theNumber of cores per socket drop-down menu on the CPU Settings panel, select the number of
cores per socket for the destination virtual machine.
4 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
The destination virtual machine is configured with the number of virtual processor sockets and cores that you
selected. If Converter Standalone shows a message that the destination hardware does not support the number
of cores you selected, you must select a supported number of sockets and cores.
Allocate Memory for the Destination Virtual Machine
You can change the amount of memory allocated to the destination virtual machine.
By default, Converter Standalone recognizes the amount of memory on the source machine and allocates it to
the destination virtual machine.
Prerequisites
On the Options page of the Conversion wizard, click Devices in the options list.
Procedure
1 Click the Memory tab.
2 In the Memory panel, use the slider or the spin-box to specify the amount of memory for the destination
virtual machine.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Converter Standalone validates the amount of memory. A warning appears if you set the memory amount to
more than the maximum supported or to less than the required minimum.
Specify a Disk Controller for the Destination Virtual Machine
You can select a disk controller type for the destination virtual disks.
Prerequisites
On the Options page of the Conversion wizard, click Devices in the options list.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 59
Procedure
1 Click the Other tab.
2 From the Disk controller drop-down menu, select a disk controller for the destination virtual disk.
Option Description
SCSI Bus Logic Use SCSI virtual disks in the destination virtual machine.
IDE Use IDE virtual disks in the destination virtual machine.
LSI Logic Use LSI Logic SCSI virtual disks in the destination virtual machine.
LSI Logic SAS Use LSI Logic SCSI (SAS) virtual disks in the destination virtual machine.
Auto select Use the same types of disk controllers as those installed on the source
machine. If they are not supported on the destination virtual machine,
replace them with supported ones.
NOTE When converting Linux virtual machines on ESX and vCenter Server
earlier than 4.1, the system might not retrieve the full list of supported
controllers.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Configure the Network Settings of the Destination Virtual Machine
You can change the number of network adapters and select the network that the destination virtual machine
uses. You can also set network adapters to connect to the network when the destination virtual machine powers
on.
NOTE You cannot use IPv6 to customize the guest operating systems of virtual machines.
Prerequisites
On the Options page of the Conversion wizard, select Networks from the options list.
Procedure
1 From the Network adapters to connect drop-down menu, select the number of network adapters to be
used by the destination virtual machine.
2 Use the Network drop-down menu to select the network that the adapter connects to.
3 To connect an adapter when you power on the destination virtual machine, select the Connect at power-
on check box.
VMware vCenter Converter Standalone User's Guide
60 VMware, Inc.
4 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Configure the Network for the Helper Virtual Machine
When you convert a powered-on Linux machine, Converter Standalone creates a Helper virtual machine on
the destination. The Helper virtual machine needs network access to the source machine to clone the source
files. Default conversion settings enforce automatic acquisition of an IPv4 address and a DNS server for the
Helper virtual machine, but you can set up this network connection manually.
Procedure
1 On the Options page of the Conversion wizard, click Helper VM network.
2 (Optional) To assign a static IPv4 address to the Helper virtual machine, select Use the following IP
address and specify the IPv4 address, subnet mask, and default gateway.
Be sure that the IP address you specify for the Helper virtual machine is not already in use on the network.
3 (Optional) Select Use the following DNS server address and type the preferred DNS server address to
configure the DNS server address manually.
Optionally, you can type an alternative DNS server address as well.
4 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Converter Standalone uses the IP address and DNS server you specify to copy data from the source Linux
machine to the Helper virtual machine during conversion.
Configure the Software on the Destination Virtual Machine
You can configure the guest operating system so that it is ready to operate in a virtual environment.
Software configuration includes a number of settings.
nCustomize the Windows Guest Operating System on page 62
You can customize guest operating systems running Windows XP or later so that the virtual machine is
prepared to work immediately in the destination environment.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 61
nInstall VMware Tools on the Destination Virtual Machine on page 65
When converting Windows source machines, you can install VMware Tools to improve graphics
performance of the guest operating system. Other enhancements include automatic grab and release of
the mouse pointer, copy and paste operations between guest and host, and improved mouse
performance.
nRemove System Restore Checkpoints on page 66
When you convert source machines running Windows XP or later, you can remove System Restore
checkpoints so that the conversion process is faster.
Customize the Windows Guest Operating System
You can customize guest operating systems running Windows XP or later so that the virtual machine is
prepared to work immediately in the destination environment.
Prerequisites
Save the Sysprep files to %ALLUSERSPROFILE%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep on the machine that runs vCenter Converter server. For more details on the Sysprep files
location for different operating systems, see Save Sysprep Files.
On the Options page of the Conversion wizard, click Advanced options, click the Post-conversion tab, and
select Customize guest preferences for the virtual machine. Click Next to view and adjust the available
customization options.
nCustomize the Identity of the Destination Virtual Machine on page 62
To configure the identity of the destination virtual machine for the destination network, personalize it
by editing its name, owner, and organization name, and by generating a new security ID.
nEnter the Windows License Information on page 63
Ensure that you enter licensing information for all destination virtual machines running guest operating
systems as necessary.
nSet the Time Zone for the Destination Virtual Machine on page 64
You can set the time zone if you are converting a virtual machine to use in a different time zone.
nConfigure the Network Adapters on page 64
You can configure the network settings of the virtual machine to work with the network configuration
of the destination environment.
nAssign a Workgroup or Domain Details on page 65
You can set up the workgroup and the domain in which the destination virtual machine belongs.
Customize the Identity of the Destination Virtual Machine
To configure the identity of the destination virtual machine for the destination network, personalize it by
editing its name, owner, and organization name, and by generating a new security ID.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options, click the Post-conversion tab, and
select Customize guest preferences for the virtual machine. Click Next to view and adjust the available
customization options.
Procedure
1 On the Customizations page, select Computer information from the options list.
VMware vCenter Converter Standalone User's Guide
62 VMware, Inc.
2 Customize the guest operating system identity.
a In the Computer Name text box, specify a computer name to identify the virtual machine on the
network.
Valid characters include A-Z, a-z, 0-9, and the hyphen (-). The underscore (_) is nonstandard, but
Converter Standalone permits it. The recommended length for most languages is 15 characters or less.
Computer names cannot consist only of numerals.
b In the Owner Name text box, write the name of the owner of the virtual machine.
Valid characters include A-Z, a-z, 0-9, and the hyphen (-). The underscore (_) is nonstandard, but
Converter Standalone permits it. The owner name cannot have more than 63 characters or consist
only of numerals.
c In the Organization field, enter an organization name.
Valid characters include all printable characters. The limit is 63 characters.
3 (Optional) To create a new security identifier, select Generate New Security ID (SID).
By default, the security ID is selected for source systems that run Windows Vista or later and cannot be
deselected.
The identifiers of the destination virtual machine are assigned according to your settings.
What to do next
You can select another option to set or click Next to view a summary of the conversion job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
Enter the Windows License Information
Ensure that you enter licensing information for all destination virtual machines running guest operating
systems as necessary.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options, click the Post-conversion tab, and
select Customize guest preferences for the virtual machine. Click Next to view and adjust the available
customization options.
Procedure
1 On the Customizations page, select Windows license from the options list.
2 Type Product ID information for the destination virtual machine.
3 (Optional) Select Include server license information if the guest operating system is Windows Server
2003 or Windows Server 2008.
4 Select a Server license mode option.
Option Description
Per seat For individual user licenses.
Per server For a concurrent user license. Specify the Maximum connections value when
you select this option.
The Windows license information is saved to the destination virtual machine after the conversion.
What to do next
You can select another option to set or click Next to view a summary of the conversion job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 63
Set the Time Zone for the Destination Virtual Machine
You can set the time zone if you are converting a virtual machine to use in a different time zone.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options, click the Post-conversion tab, and
select Customize guest preferences for the virtual machine. Click Next to view and adjust the available
customization options.
Procedure
1 On the Customizations page, select Time zone from the options list.
2 Select the target time zone from the Time zone drop-down menu.
The time zone is set on the destination virtual machine after the conversion.
What to do next
You can select another option to set or click Next to view a summary of the conversion job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
Configure the Network Adapters
You can configure the network settings of the virtual machine to work with the network configuration of the
destination environment.
The option for configuring network adapters is available for all supported destinations.
NOTE You cannot use IPv6 to customize the guest operating systems of virtual machines.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options, click the Post-conversion tab, and
select Customize guest preferences for the virtual machine. Click Next to view and adjust the available
customization options.
Procedure
1 On the Customizations page, select Network interface settings from the options list.
2 Select a network adapter and click Customize to configure its properties.
a On the General tab, type the IPv4 address and DNS server address.
b On theDNS tab, specify the DNS connections by entering DNS suffixes.
c Enter a DNS suffix and click Add.
You can add more than one DNS suffix.
d If you are specifying multiple DNS suffixes, use Move up and Move down to specify the order in
which the guest operating system uses the connections.
e On the WINS tab, type the primary and secondary WINS IP address in the text box.
When powered on, the destination virtual machine uses the network settings that you configured.
What to do next
You can select another option to set or click Next to view a summary of the conversion job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
VMware vCenter Converter Standalone User's Guide
64 VMware, Inc.
Assign a Workgroup or Domain Details
You can set up the workgroup and the domain in which the destination virtual machine belongs.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options, click the Post-conversion tab, and
select Customize guest preferences for the virtual machine. Click Next to view and adjust the available
customization options.
Procedure
1 On the Customizations page, select Workgroup/Domain from the options list.
2 Select how the virtual machine participates in the destination network.
Option Description
Workgroup Valid characters include A-Z, a-z, 0-9, space, and the hyphen (-). Maximum
length is 15 characters.
Windows server domain The text box must have a value. Valid characters include A-Z, a-z, 0-9, space,
period, and hyphen (-). The entire text string can be up to 64 characters. User
credentials are required.
The destination virtual machine connects to the specified workgroup and domain server.
What to do next
You can select another option to set or click Next to view a summary of the conversion job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
Install VMware Tools on the Destination Virtual Machine
When converting Windows source machines, you can install VMware Tools to improve graphics performance
of the guest operating system. Other enhancements include automatic grab and release of the mouse pointer,
copy and paste operations between guest and host, and improved mouse performance.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options in the options list.
Procedure
1 Click the Post-conversion tab.
2 In the Post-conversion processing section, select the Install VMware Tools on the destination virtual
machine check box.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Converter Standalone installs VMware Tools on the destination machine when the destination machine is
powered on for the first time after the conversion job.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 65
Remove System Restore Checkpoints
When you convert source machines running Windows XP or later, you can remove System Restore checkpoints
so that the conversion process is faster.
System Restore is enabled on Windows Vista and Windows XP systems by default. For Windows Vista, if you
are performing volume-based file-level cloning, System Restore checkpoints are removed automatically from
the destination virtual machine, regardless of whether the Remove System Restore checkpoints on
destination check box is selected or deselected. If you are performing disk-based cloning or volume-based
block-level cloning, deselecting the check box instructs Converter Standalone to keep the System Restore
checkpoints in the destination virtual machine.
Removing System Restore checkpoints prevents the target machine from reverting to a preconversion state.
In the target virtual machine, restoring a checkpoint that was created before you cloned the source machine
can damage the system and prevent the destination virtual machine from starting up.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options in the options list.
Procedure
1 Click the Post-conversion tab.
2 In the Post-conversion processing section, select the Remove System Restore checkpoints on
destination check box.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Configure the Conversion Job
You can configure the conversion process and select the behavior of the source and destination machine during
and after conversion. You can change the status of the source and destination services only when the source
machine is running a Windows operating system.
nSet the Startup Mode for Destination Services on page 67
To minimize downtime for a Windows service, you can select the service and have it start automatically
on the destination virtual machine. You can also prevent Windows services from automatically starting
on the destination machine.
nStop Services Running on the Source Machine on page 68
You can make sure that you do not lose data from services running on the source machine. You can select
the services that you want to stop before Converter Standalone synchronizes the data between the source
and destination machine. As a result, the services do not generate data while source and destination
machines are synchronized.
VMware vCenter Converter Standalone User's Guide
66 VMware, Inc.
nSynchronize the Destination Machine with Changes Made to the Source Machine on page 68
When you convert a powered-on Windows machine, Converter Standalone copies data from the source
machine to the destination machine while the source machine is still running and generating changes.
This process is the first transfer of data. You can transfer data for the second time by copying only the
changes made during the first transfer of data. This process is called synchronization.
nPower Off the Source Machine After Conversion on page 69
If your source machine is running services that you want to start on the destination virtual machine after
conversion, you can power off the source machine to avoid interference between source and destination
services.
nPower On the Destination Virtual Machine After Conversion on page 70
You can minimize the downtime of important services by powering on the destination virtual machine
immediately after the conversion is complete.
nLimit the Amount of Resources Used by the Conversion Job on page 70
A conversion job competes for computing resources with other processes. To limit the impact of the
conversion job on other workloads, you can throttle the job. If you do not throttle conversion jobs, they
are carried out with normal priority and depending on the available computing resources during
conversion.
nUninstall Converter Standalone Agent from the Source Machine on page 71
When setting up a conversion job for a powered-on Windows source or a Hyper-V Server virtual
machine, you can choose how you want to remove the Converter Standalone agent from the source after
the conversion. If the Converter Standalone agent is installed by the Converter Standalone server, it is
uninstalled automatically. Otherwise, you must uninstall it manually.
Set the Startup Mode for Destination Services
To minimize downtime for a Windows service, you can select the service and have it start automatically on
the destination virtual machine. You can also prevent Windows services from automatically starting on the
destination machine.
You can change the settings for the destination services only when you convert source machines that run
Windows.
Prerequisites
On the Options page of the Conversion wizard, click Services in the options list.
Procedure
1 If you are converting a powered-on source machine, click the Destination services tab.
If the source machine is poweredoff, the Services pane displays no tabs. You can modify only the starting
mode of destination services.
2 On the services list, select the startup mode for each service.
Option Description
Automatic The service starts automatically after the destination machine is powered on.
Manual The service does not start after the destination machine is powered on, but
you can start it manually.
Disabled The service is disabled and does not start after the destination machine is
powered on.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 67
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Stop Services Running on the Source Machine
You can make sure that you do not lose data from services running on the source machine. You can select the
services that you want to stop before Converter Standalone synchronizes the data between the source and
destination machine. As a result, the services do not generate data while source and destination machines are
synchronized.
You can stop services on the source only when you convert a powered-on Windows machine.
Prerequisites
On the Options page of the Conversion wizard, click Services in the options list.
Procedure
1 Click the Source services tab.
2 To stop a service on the source machine before synchronization, highlight a service and select the Stop
check box to the right.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Converter Standalone stops the selected source services before it synchronizes the destination machine with
the source machine.
Synchronize the Destination Machine with Changes Made to the Source Machine
When you convert a powered-on Windows machine, Converter Standalone copies data from the source
machine to the destination machine while the source machine is still running and generating changes. This
process is the first transfer of data. You can transfer data for the second time by copying only the changes made
during the first transfer of data. This process is called synchronization.
Synchronization is available only for Windows XP or later source operating systems.
If you resize FAT volumes or shrink NTFS volumes, or change the cluster size on the destination volume, you
cannot use the synchronization option.
You cannot add or remove volumes on the source machine between two cloning tasks of a synchronizable job
because it might cause conversion to fail.
VMware vCenter Converter Standalone User's Guide
68 VMware, Inc.
Prerequisites
Stop various source services to make sure they do not generate additional changes during the synchronization,
as that might lead to data loss.
On the Options page of the Conversion wizard, click Advanced options in the options list.
Procedure
1 Click the Synchronize tab.
2 Select Synchronize changes.
3 Specify when you want to perform the synchronization.
Option Description
Select the Run immediately after
cloning check box
Synchronization is performed immediately after the cloning is complete.
Select the Schedule check box Synchronization is perfomed at the scheduled time and date. Use the Run
at text box to specify the start date and time for the synchronization.
4 Select Perform final synchronization if you do not plan to make further synchronizations between the
source and the destination.
5 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Power Off the Source Machine After Conversion
If your source machine is running services that you want to start on the destination virtual machine after
conversion, you can power off the source machine to avoid interference between source and destination
services.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options in the options list.
Procedure
1 Click the Post-conversion tab.
2 In the Post-conversion power state panel, select Power off source machine.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 69
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Converter Standalone powers off the source machine after the conversion is complete.
Power On the Destination Virtual Machine After Conversion
You can minimize the downtime of important services by powering on the destination virtual machine
immediately after the conversion is complete.
Prerequisites
On the Options page of the Conversion wizard, click Advanced options in the options list.
Procedure
1 Click the Post-conversion tab.
2 In the Post-conversion power state panel, select Power on destination machine.
3 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
After the conversion, Converter Standalone powers on the destination machine.
Limit the Amount of Resources Used by the Conversion Job
A conversion job competes for computing resources with other processes. To limit the impact of the conversion
job on other workloads, you can throttle the job. If you do not throttle conversion jobs, they are carried out
with normal priority and depending on the available computing resources during conversion.
A powered-on source machine runs its own conversion job. You can limit the impact of the conversion job on
other workloads running on the powered-on machine.
For source machines that are not powered on, you can limit the resources used on the machine where Converter
Standalone server is installed.
Throttling controls the CPU and network resources that the conversion process uses. You cannot throttle disk
I/O from the Converter Standalone interface, but can throttle it indirectly by throttling the network bandwidth.
NOTE You cannot throttle conversion jobs for powered-on source machines that run Linux.
VMware vCenter Converter Standalone User's Guide
70 VMware, Inc.
Procedure
1 On the Options page, select Throttling from the options list.
2 From the CPU throttling drop-down menu, select the priority of the conversion task.
Option Description
None The priority of the current conversion task is set to normal.
Light The priority of the current conversion task is reduced slightly below normal.
Medium The priority of the current conversion task is set to lowest.
NOTE Converter Standalone reduces the thread priorities of conversion tasks to control the CPU resources
they consume.
3 (Optional) Select Network bandwidth throttling and specify the maximum network bandwidth at which
Converter Standalone performs the conversion jobs.
4 Save your settings.
Option Description
Select another option from the
options list
Saves your settings and displays the pane for the selected option.
Click Next Saves your settings and displays the next page of the Conversion wizard.
nThe Customizations page is displayed if you select Customize guest
preferences for the virtual machine in the Advanced options pane.
nThe Summary page is displayed if you do not select Customize guest
preferences for the virtual machine in the Advanced options pane.
Uninstall Converter Standalone Agent from the Source Machine
When setting up a conversion job for a powered-on Windows source or a Hyper-V Server virtual machine,
you can choose how you want to remove the Converter Standalone agent from the source after the conversion.
If the Converter Standalone agent is installed by the Converter Standalone server, it is uninstalled
automatically. Otherwise, you must uninstall it manually.
Use Add or Remove Programs on the source machine to uninstall the Converter Standalone agent.
Procedure
1 In Windows, run Add or Remove Programs.
2 In the list of installed programs, locate and click VMware vCenter Converter Standalone Agent.
3 Click Remove.
4 In the confirmation dialog box, click Yes.
Windows installer uninstalls the Converter Standalone agent from the source machine.
Review the Summary and Submit the Conversion Job
On the Summary page, you can view a summary of the conversion job before you add it to the job list.
The summary includes information about the source machine, the destination virtual machine, and destination
customization settings (if any). Converter Standalone performs job validation at this stage.
Prerequisites
You must complete all steps in the Conversion wizard to access the Summary page.
Chapter 4 Convert a Physical or Virtual Machine
VMware, Inc. 71
Procedure
1 Review the summary of the job.
2 Click Finish to submit the job.
Converter Standalone validates the job parameters. This might take several minutes. If the validation succeeds,
the conversion job appears in the Job View list in the main application window. You can find information about
the tasks of the job in the Task View. If the validation fails, you must click Back and correct the invalid
parameters as prompted.
VMware vCenter Converter Standalone User's Guide
72 VMware, Inc.
Configure Virtual Machines 5
You might need to configure a virtual machine after you convert it so that it is ready to start in the destination
virtual environment. You might also need to configure virtual machines if their virtual environment changes
or if you need to improve their performance.
NOTE You can configure only virtual machines that run Windows XP or later. You cannot configure virtual
machines that run operating systems other than Windows.
Unlike the conversion process, which is nondestructive to the source machine, the configuration process affects
the source. When you create a configuration job, your settings are applied to the configuration source machine
and cannot be reverted.
Procedure
1Save Sysprep Files on page 73
To customize the guest operating system of a virtual machine that runs Windows Server 2003 or Windows
XP, you must save the Sysprep files to the specified locations on the machine where Converter Standalone
server runs.
2Start the Configuration Wizard on page 74
You can configure VMware desktop virtual machines or virtual machines managed by ESX hosts or
vCenter Server.
3Select a Source Machine to Configure on page 74
You can select a powered-off VMware virtual machine as the source for a configuration task.
4Select the Options to Configure on page 77
When you create a configuration job, you can select the steps of the configuration process that you want
to run.
5Review and Submit the Configuration Job on page 81
After you review your settings on the Summary page of the Configuration wizard, you can go back and
change a setting or submit the job.
Save Sysprep Files
To customize the guest operating system of a virtual machine that runs Windows Server 2003 or Windows XP,
you must save the Sysprep files to the specified locations on the machine where Converter Standalone server
runs.
Prerequisites
You must download the Sysprep files that correspond to the operating system of the source machine.
VMware, Inc. 73
Procedure
uSave the Sysprep files that correspond to the source operating system to the specified location on the
machine where Converter Standalone server runs.
Option Description
Windows Server 2003 (32bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\svr2003
Windows Server 2003 (64bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\svr2003-64
Windows XP (32bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\xp
Windows XP (64bit) The Sysprep files Location for Windows: %ALLUSERSPROFILE
%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep\xp-64
You can now customize Windows Server 2003 (32bit and 64bit) and Windows XP (32bit and 64bit) guest
operating systems by using the Conversion or the Configuration wizard.
What to do next
You can now use the Configuration wizard to customize Windows guest operating systems.
Start the Configuration Wizard
You can configure VMware desktop virtual machines or virtual machines managed by ESX hosts or vCenter
Server.
A physical machine cannot be a configuration source.
You can configure only powered-off virtual machines.
Procedure
1 Start the VMware vCenter Converter Standalone application.
2 Click Configure Machine in the application menu.
The Configuration wizard opens.
What to do next
Select the source machine to configure.
Select a Source Machine to Configure
You can select a powered-off VMware virtual machine as the source for a configuration task.
Prerequisites
On the Source System page of the Configuration wizard, select a source type from the drop-down menu.
What to do next
On the Options page of the Configuration wizard, you can select the required configuration options.
VMware vCenter Converter Standalone User's Guide
74 VMware, Inc.
Select a VMware Infrastructure Virtual Machine to Configure
If the system you want to configure is a virtual machine that runs on an ESX host or on an ESX host managed
by vCenter Server, you must select a VMware Infrastructure virtual machine as the source type.
Prerequisites
Power off the source machine before the configuration.
In the main application window of Converter Standalone, click Configure Machine to open the
Configuration wizard.
Procedure
1 On the Source System page of the Configuration wizard, select VMware Infrastructure virtual machine
from the Select source type drop-down menu.
2 Provide the IP address or host name and credentials for authentication with the ESX host or the vCenter
Server, and click Next.
The Source Machine page appears, displaying the host name or IP address and the inventory of the ESX host
or the vCenter Server.
What to do next
On the Source Machine page of the Configuration wizard you can browse the virtual infrastructure inventory
and select the virtual machine to configure.
Specify the vCenter Server Virtual Machine to Configure
If you choose to configure a virtual machine managed by a vCenter Server or ESX host, you must browse the
inventory to locate the source virtual machine.
Prerequisites
On the Source System page of the Configuration wizard, select VMware Infrastructure virtual machine as the
configuration source and click Next to proceed to the Source Machine page.
Procedure
1 (Optional) If you are connected to a vCenter Server, select a virtual machine view from the Specify
machine with drop-down menu.
Option Description
Hosts and Clusters The Inventroy tree pane provides a view of hosts, clusters, resource pools,
and vApps. If you select a host managed by a cluster, you see the full list of
virtual machines and templates in the VM list view. If you select a standalone
host or a cluster, you see only the virtual machines that are not deployed in
the resource pools of that host or cluster.
VMs and Templates The Inventory tree pane provides a view of datacenters and VM folders.
2 (Optional) If you are connected to a vCenter Server, select an object from the Inventory tree pane.
Option Description
Hosts and Clusters Select cluster, ESX host, resource pool, or vApp.
VMs and Templates Select datacenter or VM folder.
Chapter 5 Configure Virtual Machines
VMware, Inc. 75
3 From the virtual machines list, select the virtual machine you want to configure.
You can search for virtual machines in the VM list by typing one or more letters of their names in the
Search for name with text box. You can clear your search by clicking Clear.
NOTE If you connect to a vCenter Server that has a disconnected ESX instance (powered off, connected
to another vCenter Server, or in maintenace mode), you cannot select a virtual machine from that ESX
host.
4 (Optional) To refresh the Inventory, click Refresh.
5 (Optional) To view more details about a machine, select it and click View source details.
6 Click Next to proceed to the Options page.
What to do next
On the Options page of the Configuration wizard, you can select the required configuration options.
Select a VMware Desktop Virtual Machine to Configure
If the system you want to configure is a standalone VMware virtual machine created with VMware
Workstation, VMware Fusion, VMware Player, VMware Server, or VMware ACE, you must select VMware
Workstation or other VMware virtual machine as the configuration source type.
Prerequisites
If you plan to use a network path to locate the source, verify that the machine where Converter Standalone
server runs has access to that network path.
In the main application window of Converter Standalone, click Configure Machine to open the
Configuration wizard.
Procedure
1 On the Source System page of the Configuration wizard, select VMware Workstation or other VMware
virtual machine.
2 Locate the virtual machine source.
nIf you are connected to a remote Converter Standalone server, provide a network path to the source
virtual machine file (.vmx) in the Virtual machine file text box. For
example, \\server\virtual_machines\virtual_machine.vmx.
nIf you are connected to a local Converter Standalone server, provide a network path or a local path
to the .vmx file.
The file type choices are limited to VMware Workstation *.vmx files.
3 If you are connected to a remote Converter Standalone server, enter user credentials for accessing the
source virtual machine.
You do not have to provide user credentials if you are connected to a local Converter Standalone server.
In such cases, Converter Standalone uses the Windows credentials to connect to the source machine.
4 (Optional) To view more information about the selected source, click View source details
5 Click Next to proceed to the Options page.
What to do next
On the Options page of the Configuration wizard, you can select the required configuration options.
VMware vCenter Converter Standalone User's Guide
76 VMware, Inc.
Select the Options to Configure
When you create a configuration job, you can select the steps of the configuration process that you want to
run.
Procedure
uOn the Options page, select one or more configuration steps to perform and click Next.
Option Description
Install VMware Tools on the
destination virtual machine
Installs VMware Tools to enhance the performance of the destination virtual
machine.
Customize guest preferences for the
virtual machine
Allows you to customize Windows XP or later guest operating systems so
that the virtual machine is prepared to work in the destination environment.
Remove System Restore
checkpoints on destination
Removes System Restore checkpoints from the destination virtual machine.
Reconfigure destination virtual
machine
Updates the drivers on the virtual machine so that it is bootable in a virtual
environment.
What to do next
On the basis of the configuration options you selected, you can either customize the guest operating system of
the source virtual machine or view the Summary page of the Configuration wizard.
Install VMware Tools on a Virtual Machine
Install VMware Tools to improve graphics performance for the guest operating system of a configured virtual
machine. Other enhancements include automatic grab and release of the mouse pointer, copying and pasting
between guest and host, improved mouse performance, and so on.
Install VMware Tools on the virtual machine you are configuring.
Procedure
uOn the Options page of the Configuration wizard, select Install VMware Tools on the destination virtual
machine and click Next.
vCenter Converter Standalone installs VMware Tools on the configured virtual machine.
What to do next
Depending on the configuration options you selected, you can either customize the guest operating system or
view the Summary page of the Configuration wizard.
Customize the Windows Guest Operating System
As a part of the configuration job, you can customize virtual machines running Windows XP or later.
Prerequisites
Save the Sysprep files to %ALLUSERSPROFILE%\Application Data\VMware\VMware vCenter Converter
Standalone\sysprep on the machine that runs vCenter Converter server. For more details on the Sysprep files
location for different operating systems, see Save Sysprep Files.
On the Options page of the Configuration wizard, select Customize guest preferences for the virtual
machine and click Next to view and adjust the available customization options.
Chapter 5 Configure Virtual Machines
VMware, Inc. 77
nCustomize the Identity of a Virtual Machine on page 78
To configure the identity of a virtual machine on a virtual network, personalize the virtual machine by
editing its name, owner, and organization name, and by generating a new security ID.
nSpecify the Windows License Information on page 79
Ensure that you enter licensing information for all destination virtual machines running guest operating
systems as necessary.
nSet the Time Zone on page 79
You can configure the time zone for a virtual machine.
nConfigure the Network Adapters on page 79
You can change the network settings of a virtual machine to work with the network configuration of the
virtual environment.
nAssign a Workgroup or Domain Details on page 80
You can configure the workgroup and the domain for a virtual machine.
Customize the Identity of a Virtual Machine
To configure the identity of a virtual machine on a virtual network, personalize the virtual machine by editing
its name, owner, and organization name, and by generating a new security ID.
Prerequisites
On the Options page of the Configuration wizard, select Customize guest preferences for the virtual
machine and click Next to view and adjust the available customization options.
Procedure
1 On the Customizations page, select Computer information from the options list.
2 Customize the guest operating system identity.
a In the Computer Name text box, specify a computer name to identify the virtual machine on the
network.
Valid characters include A-Z, a-z, 0-9, and the hyphen (-). The underscore (_) is nonstandard, but
Converter Standalone permits it. The recommended length for most languages is 15 characters or less.
Computer names cannot consist only of numerals.
b In the Owner Name text box, write the name of the owner of the virtual machine.
Valid characters include A-Z, a-z, 0-9, and the hyphen (-). The underscore (_) is nonstandard, but
Converter Standalone permits it. The owner name cannot have more than 63 characters or consist
only of numerals.
c In the Organization field, enter an organization name.
Valid characters include all printable characters. The limit is 63 characters.
3 (Optional) To create a new security identifier, select Generate New Security ID (SID).
By default, the security ID is selected for source systems that run Windows Vista or later and cannot be
deselected.
The identifiers of the configured virtual machine are assigned according to your settings.
What to do next
You can select another option to set or click Next to view a summary of the configuration job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
VMware vCenter Converter Standalone User's Guide
78 VMware, Inc.
Specify the Windows License Information
Ensure that you enter licensing information for all destination virtual machines running guest operating
systems as necessary.
Prerequisites
On the Options page of the Configuration wizard, select Customize guest preferences for the virtual
machine and click Next to view and adjust the available customization options.
Procedure
1 On the Customizations page, select Windows license from the options list.
2 Type Product ID information for the destination virtual machine.
3 (Optional) Select Include server license information if the guest operating system is Windows Server
2003 or Windows Server 2008.
4 Select a Server license mode option.
Option Description
Per seat For individual user licenses.
Per server For a concurrent user license. Specify the Maximum connections value when
you select this option.
The Windows license information is saved to the configuration source machine when the configuration task
is completed.
What to do next
You can select another option to set or click Next to view a summary of the configuration job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
Set the Time Zone
You can configure the time zone for a virtual machine.
Prerequisites
On the Options page of the Configuration wizard, select Customize guest preferences for the virtual
machine and click Next to view and adjust the available customization options.
Procedure
1 On the Customizations page, select Time zone from the options list.
2 Select the target time zone from the Time zone drop-down menu.
The time zone is set on the destination machine when the configuration job completes.
What to do next
You can select another option to set or click Next to view a summary of the configuration job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
Configure the Network Adapters
You can change the network settings of a virtual machine to work with the network configuration of the virtual
environment.
The options for configuring network adapters are available for all supported customization sources.
Chapter 5 Configure Virtual Machines
VMware, Inc. 79
Prerequisites
On the Options page of the Configuration wizard, select Customize guest preferences for the virtual
machine and click Next to view and adjust the available customization options.
Procedure
1 On the Customizations page, select Network interface settings from the options list.
2 Select a network adapter and click Customize to configure its properties.
a On the General tab, type the IPv4 address and DNS server address.
b On theDNS tab, specify the DNS connections by entering DNS suffixes.
c Enter a DNS suffix and click Add.
You can add more than one DNS suffix.
d If you are specifying multiple DNS suffixes, use Move up and Move down to specify the order in
which the guest operating system uses the connections.
e On the WINS tab, type the primary and secondary WINS IP address in the text box.
When powered on, the configured virtual machine uses the network settings that you specified.
What to do next
You can select another option to set or click Next to view a summary of the configuration job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
Assign a Workgroup or Domain Details
You can configure the workgroup and the domain for a virtual machine.
Prerequisites
On the Options page of the Configuration wizard, select Customize guest preferences for the virtual
machine and click Next to view and adjust the available customization options.
Procedure
1 On the Customizations page, select Workgroup/Domain from the options list.
2 Select how the virtual machine participates in the destination network.
Option Description
Workgroup Valid characters include A-Z, a-z, 0-9, space, and the hyphen (-). Maximum
length is 15 characters.
Windows server domain The text box must have a value. Valid characters include A-Z, a-z, 0-9, space,
period, and hyphen (-). The entire text string can be up to 64 characters. User
credentials are required.
The configured virtual machine connects to the specified workgroup and domain server.
What to do next
You can select another option to set or click Next to view a summary of the configuration job. If the Next button
is inactive, check the Current settings list for other settings that need your attention on this page.
VMware vCenter Converter Standalone User's Guide
80 VMware, Inc.
Remove System Restore Checkpoints
Remove the System Restore checkpoints of newly imported source machines to prevent them from reverting
to a preconversion state. For other configuration source machines, removing System Restore checkpoints helps
you save disk space by deleting unnecesary data.
Procedure
uOn the Options page of the Configuration wizard, select Remove System Restore checkpoints on the
destination and click Next.
The System Restore checkpoints are deleted from the configuration source machine.
What to do next
Depending on the configuration options you selected, you can either customize the guest operating system or
view the Summary page of the Configuration wizard.
Update the Device Drivers of a Virtual Machine
If a newly converted virtual machine does not start properly in the destination virtual environment, try
configuring it to update its device drivers.
Procedure
uOn the Options page of the Configuration wizard, select Reconfigure destination virtual machine and
click Next.
Converter Standalone updates the device drivers on the source machine so it can work in the virtual
environment.
What to do next
Depending on the configuration options you selected, you can either customize the guest operating system or
view the Summary page of the Configuration wizard.
Review and Submit the Configuration Job
After you review your settings on the Summary page of the Configuration wizard, you can go back and change
a setting or submit the job.
Procedure
1 Review the summary of the settings for the source virtual machine.
2 Click Finish to submit the configuration job.
The job appears in the jobs list in the Job View list of the main application window. You can view the progress
of the current task on the Task progress tab in Task View.
What to do next
To view details about the configuration task, click the Summary tab.
Chapter 5 Configure Virtual Machines
VMware, Inc. 81
VMware vCenter Converter Standalone User's Guide
82 VMware, Inc.
Manage Conversion and
Configuration Jobs and Tasks 6
Converter Standalone provides a manager for managing conversion and configuration jobs and tasks.
After you create a conversion or configuration job by using the Converter Standalone wizards, you can use the
Task View and the Job View of the Converter Standalone manager to monitor and manage the existing jobs
and their tasks.
Scheduled synchronized conversion jobs can contain multiple tasks.
This chapter includes the following topics:
n“Manage Jobs in the Job List,” on page 83
n“Manage Tasks in the Task List,” on page 87
n“Verify Jobs and Tasks Progress and the Log Files,” on page 89
Manage Jobs in the Job List
The Job View of the Converter Standalone manager provides a list of all jobs that are submitted. You can use
the main application menus to control the way jobs appear in the job list and to edit them.
Prerequisites
You must submit a conversion or configuration job to view it in the job list.
You must be in the Job View of the Converter Standalone manager to access the application menus for job
managing.
nAdd a Job to the Job List on page 84
Converter Standalone allows you to create and run conversion and configuration jobs.
nView the Running Task of a Job on page 84
You can switch from Job View to Task View to view and edit the currently running task of a job.
nDeactivate a Job on page 84
You can deactivate an active job without applying any changes to the destination machine.
nDelete a Job on page 85
You can delete a job and all its tasks.
nCreate a Job by Copying an Existing Job on page 85
You can create a new job by creating a copy of an exisiting job and modifying its settings in the Conversion
or the Configuration wizard. The settings for the original job appear at each step of the wizard so that
you can reuse or change them.
VMware, Inc. 83
nFilter the Jobs in the Jobs List on page 85
You can select the jobs that you want the job list to display by filtering them.
nAdd a Synchronization Task to a Conversion Job on page 86
You can add a synchronization task to an active conversion job and modify the synchronization settings
in the Conversion wizard.
Add a Job to the Job List
Converter Standalone allows you to create and run conversion and configuration jobs.
Procedure
uOn the Summary page of the Conversion or the Configuration wizard, make sure no settings need
adjustment, and click Finish to add a conversion or configuration job.
The job appears at the beginning of the job list in the Job View and its tasks appear in the Task View.
What to do next
In the job list, you can view the job status, which task of the job is currently running, and other details. You
can also delete a job, and perform other job operations.
View the Running Task of a Job
You can switch from Job View to Task View to view and edit the currently running task of a job.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 From the job list, select a job.
3 On the main menu, select Job > Go to running task.
The Converter Standalone manager switches to Task View and preselects the currently running task of the job
you selected in Job View. If none of the job's tasks is running, no selection is made.
Deactivate a Job
You can deactivate an active job without applying any changes to the destination machine.
Prerequisites
NOTE You can deactivate a job only if none of its tasks is currently running.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 From the job list, select the job you want to deactivate.
3 From the main menu, select Job > Deactivate.
The job state changes to inactive and no changes are applied to the destination.
NOTE An inactive job cannot be reactivated.
VMware vCenter Converter Standalone User's Guide
84 VMware, Inc.
Delete a Job
You can delete a job and all its tasks.
Prerequisites
You can delete only deactivated jobs.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 From the job list, select the job you want to delete.
3 From the main menu, select Job > Delete.
The job is removed from the job list, and all the tasks of the job are removed from the task list.
Create a Job by Copying an Existing Job
You can create a new job by creating a copy of an exisiting job and modifying its settings in the Conversion or
the Configuration wizard. The settings for the original job appear at each step of the wizard so that you can
reuse or change them.
NOTE You can copy only jobs that were created with the Converter Standalone client.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 From the job list, select the job you want to copy.
3 Select Job > Copy As New.
4 Follow the prompts to modify the job settings.
5 Click Finish to add the new job the job list.
Filter the Jobs in the Jobs List
You can select the jobs that you want the job list to display by filtering them.
You can filter jobs by history, status, or multiple criteria.
nFilter Jobs by History on page 85
You can filter the list so that it displays only the last submitted jobs. By default, the job list displays the
last twenty jobs.
nFilter Jobs by Status on page 86
You can filter the job list to display jobs based on their status: Active, Inactive, and All. By default, the
job list displays only active jobs. Active jobs include all running, scheduled, and not scheduled jobs.
nFilter Jobs by Multiple Criteria on page 86
You can combine filtering criteria to filter jobs in the job list.
Filter Jobs by History
You can filter the list so that it displays only the last submitted jobs. By default, the job list displays the last
twenty jobs.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
Chapter 6 Manage Conversion and Configuration Jobs and Tasks
VMware, Inc. 85
2 On the main menu, click View > History Filter and select a level of filtering.
Only jobs that correspond to selected filtering level remain in the job list.
Filter Jobs by Status
You can filter the job list to display jobs based on their status: Active, Inactive, and All. By default, the job list
displays only active jobs. Active jobs include all running, scheduled, and not scheduled jobs.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 On the main menu, select View > Filter by.
3 Select a level of display from the drop-down menu.
If you are connected to a remote Converter Standalone server, you can select My own to view only jobs
that you have created.
Filter Jobs by Multiple Criteria
You can combine filtering criteria to filter jobs in the job list.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 Use the drop-down menus in the toolbar to select the status and the history criteria.
The two filtering conditions combine to show only jobs that comply with both conditions.
Add a Synchronization Task to a Conversion Job
You can add a synchronization task to an active conversion job and modify the synchronization settings in the
Conversion wizard.
NOTE You can add synchronization tasks only to jobs that were created with the Converter Standalone client.
Prerequisites
The conversion job must be active and allow synchronization.
No synchronization task that belongs to this job must be running.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 From the job list, select the conversion job to which you want to add a synchronization task.
3 From the main menu, select Job > Synchronize.
4 Follow the prompts to modify the synchronization settings.
5 Click Finish to save changes.
VMware vCenter Converter Standalone User's Guide
86 VMware, Inc.
Manage Tasks in the Task List
The Task View of the Converter Standalone manager provides a list of all tasks that are submitted. You can
use the main application menus to control the way tasks appear in the task list and to edit them.
Prerequisites
You must submit a conversion or configuration job to view its tasks in the task list.
You must be in the Tasks View of the Converter Standalone manager to access the application menus for
managing task.
nControl the Number of Tasks Running Concurrently on page 87
You can set the number of tasks that can run concurrently to improve the conversion speed. Limiting the
number of concurrent tasks helps you reduce the network resources required for the conversion tasks.
Limiting the number of concurrent tasks also helps to limit the CPU load on the machine where the
Converter Standalone server runs.
nView the Job to Which a Task Belongs on page 88
You can switch from Task View to Job View to view and edit the job to which a selected task belongs.
nCancel a Task on page 88
You can cancel a task that is in the queue or in progress.
nFilter the Tasks in the Task List on page 88
The number of archived tasks can grow to be very large. To minimize clutter in the task list, you can
lower the number of tasks that appear. You can select the tasks that you want the task list to display by
filtering them.
Control the Number of Tasks Running Concurrently
You can set the number of tasks that can run concurrently to improve the conversion speed. Limiting the
number of concurrent tasks helps you reduce the network resources required for the conversion tasks. Limiting
the number of concurrent tasks also helps to limit the CPU load on the machine where the Converter Standalone
server runs.
You can set the number of concurrent tasks to any number from 1 to 12. The default number of concurrent
tasks is set to Maximum.
Procedure
1 On the main menu, select Administration > Maximum Concurrent Tasks.
2 In the Custom spin-box, specify a number.
3 Click OK.
The setting takes effect immediately for all newly added tasks. See “Example: Limiting the Number of
Concurrent Tasks,” on page 87.
Example: Limiting the Number of Concurrent Tasks
Assume that Converter Standalone is running 12 tasks. If you change the number of concurrent tasks to 6, these
12 tasks continue running, but all newly added tasks remain pending in the task list.
When the number of running tasks drops to 5, a new task from the wait list starts.
Chapter 6 Manage Conversion and Configuration Jobs and Tasks
VMware, Inc. 87
View the Job to Which a Task Belongs
You can switch from Task View to Job View to view and edit the job to which a selected task belongs.
Procedure
1 From the View by drop-down menu on the toolbar, select Tasks.
2 From the task list, select a task.
3 On the main menu, select Task > Go to job.
The Converter Standalone manager switches to Job View. The job that contains the task you selected in Task
View is preselected in the list and complies with the current filter of the Job View.
Cancel a Task
You can cancel a task that is in the queue or in progress.
When you cancel a conversion task, the task is removed from the queue. Canceling a configuration task removes
it from the queue and reverts the source machine to its original state. Canceling a task that is not a
synchronization task deactivates the job to which the task belongs.
Canceling a task in progress does not stop it. You cannot restart a canceled task.
Procedure
1 From the View by drop-down menu on the toolbar, select Tasks.
2 From the task list, select the task you want to cancel.
3 Click Cancel.
The task is now out of the queue and the time of cancellation appears in the End Time column.
Filter the Tasks in the Task List
The number of archived tasks can grow to be very large. To minimize clutter in the task list, you can lower the
number of tasks that appear. You can select the tasks that you want the task list to display by filtering them.
You can filter tasks by history, status, or multiple criteria.
nFilter Tasks by History on page 88
You can use the date on which a task is created to filter the task list.
nFilter Tasks by Status on page 89
You can change which tasks appear in the task list based on their running status.
nFilter Tasks by Multiple Criteria on page 89
You can combine filtering criteria to filter tasks in the task list. Tasks that are currently running are
displayed regardless of the filtering criteria you apply.
Filter Tasks by History
You can use the date on which a task is created to filter the task list.
This option does not affect tasks in progress. Tasks in progress always appear in the task list.
Procedure
1 From the View by drop-down menu on the toolbar, select Tasks.
VMware vCenter Converter Standalone User's Guide
88 VMware, Inc.
2 On the main menu, click View > History Filter and select a level of filtering.
Only tasks that correspond to the selected filtering level remain in the task list.
Filter Tasks by Status
You can change which tasks appear in the task list based on their running status.
Procedure
1 From the View by drop-down menu on the toolbar, select Tasks.
2 On the main menu, select View > Filter by.
3 Select a level of display from the drop-down menu.
If you are connected to a remote Converter Standalone server, you can select My own to view only tasks
of jobs that you create.
Filter Tasks by Multiple Criteria
You can combine filtering criteria to filter tasks in the task list. Tasks that are currently running are displayed
regardless of the filtering criteria you apply.
Procedure
1 From the View by drop-down menu on the toolbar, select Tasks.
2 Use the drop-down menus to select the status and history criteria.
The two filtering conditions combine to show only tasks that comply with both conditions.
Verify Jobs and Tasks Progress and the Log Files
The Task View and Job View of the Converter Standalone manager allows you to observe the progress and the
state of the listed jobs and tasks.
If certain problems cause a job or task to fail, you can also review information in the log files.
nView Task Progress on page 89
The Task view and the Details view show the progress of tasks. You can view the estimated time left to
the completion of a conversion task in the End Time column.
nExport the Log Files for Jobs on page 90
You can review the log files for information about the jobs, or send a copy of log files to VMware technical
support. You can export the log files for all jobs in the job list.
nExport the Log Files for a Task on page 90
If any problems cause a task to fail, you can review information about the task in the log files or send a
copy of the log files to VMware technical support. You can export the log files for a specific task in the
task list.
nBack-End and Client Log Files Locations on page 90
Converter Standalone saves log files as it operates.
View Task Progress
The Task view and the Details view show the progress of tasks. You can view the estimated time left to the
completion of a conversion task in the End Time column.
You can obtain a general indication of a task's progress by looking at its row in the task list of the Task view.
You can view the Task progress tab in the Details view for more information.
Chapter 6 Manage Conversion and Configuration Jobs and Tasks
VMware, Inc. 89
Procedure
1 From the View by drop-down menu on the toolbar, select Tasks.
2 Select the row in the task list for the task to view.
The information for that task appears in the Details pane below the tasks list.
3 Click the Task progress tab to view the task status and log highlights.
Export the Log Files for Jobs
You can review the log files for information about the jobs, or send a copy of log files to VMware technical
support. You can export the log files for all jobs in the job list.
Procedure
1 From the View by drop-down menu on the toolbar, select Jobs.
2 Select a job in the job list.
3 On the main menu, select Job > Export Logs.
4 Select a location to which you want to save the files and click Save.
The log files for all jobs in the job list are saved to the selected location.
Export the Log Files for a Task
If any problems cause a task to fail, you can review information about the task in the log files or send a copy
of the log files to VMware technical support. You can export the log files for a specific task in the task list.
Procedure
1 From the View by drop-down menu on the toolbar, select Tasks.
2 Select the task in the task list.
3 In the Details pane, click the Task Progress tab.
4 Click Export Logs.
5 Select a location to which you want to save the files and click Save.
The log files for this task are saved to the selected location.
Back-End and Client Log Files Locations
Converter Standalone saves log files as it operates.
Table 6-1 lists the default locations where log files are saved. You can view the log files or send them to VMware
support, if necessary.
These file locations are also the file locations on the remote machine if you are running a remote hot clone. To
send these log files from a remote machine to VMware support, you must manually compress and send them.
Table 6-1. Log Files Locations
Log Files File Path
Converter Standalone server and agent log files %ALLUSERSPROFILE%\Application
Data\VMware\VMware vCenter Converter
Standalone\logs*
Converter Standalone client log files %USERPROFILE%\Local Settings\Application
Data\VMware\VMware vCenter Converter
Standalone\Logs*
VMware vCenter Converter Standalone User's Guide
90 VMware, Inc.
Index
A
Acronis True Image, source 21
add a disk 52
adding jobs 84
advanced customization
guest operating system 62
installing VMware Tools 65
removing system restore checkpoints 66
synchronizing source and destination 68
agent 8
allocate memory 59
audience 5
C
changing the number of tasks displayed 88, 89
client 8
cloning
cold, defined 9
disk based 13
disk-based cloning 14
full clones 14
hot, defined 9
linked clones 14
volume based 13
volume-based cloning 14
cloning modes 13
cold cloning
boot CD 13
defined 9
command-line commands 34
components 8
configuration options 77
configuration, submitting job 81
configure the conversion job 66
configure the hardware
allocate memory 59
configure the Helper VM network 61
configure the network settings 60
edit the number of processors 58
edit the number of processors cores 58
edit the number of processors sockets 58
specify a disk controller 59
configure the hardware of the destination
machine 49
configure the network settings 60
configure the software 61
configuring
domain details 80
guest operating system 77
install VMware tools 77
removing system restore checkpoints 81
selecting a source 74
selecting VMware Fusion source 74
selecting VMware Player source 74
selecting VMware Server source 74
selecting Workstation source 74
sysprep files locations 28
Sysprep files locations 73
time zone 79
updating drivers 81
workgroup 80
configuring permissions for vCenter users 25
connect to a remote Converter Standalone
server 37
controlling the number of concurrent tasks 87
conversion 86
conversion jobs
submitting 71
viewing summary 71
conversion limitations
configuration limitations 22
Linux guest limitations 22
powered-on machine limitations 22
third-party images limitations 22
third-party virtual machines or system
images 23
virtual machines 22
VSS snapshots 29
windows guest limitations 22
conversion tasks
managing 83
maximum running 87
starting 40
conversion throttling 70
conversion wizard, starting 40
conversion, viewing job summary 71
Converter Standalone
installing client in Windows 31
installing in Windows 31
installing server and agent in Windows 31
VMware, Inc. 91
modifying installation in Windows 35
repairing in Windows 36
converting
existing system images 16
existing virtual machines 16
converting machines 39
converting, powered-on machines 68
copy all disks 57
copy disks or volumes
copy all disks 57
create an expandable disk on a hosted
destination 55
create an expandable disk on a managed
destination 55
delete a disk 56
move a disk to a different datastore 54
move a volume to a different datastore 52
move a volume to a different virtual disk 52
resize a volume 50
skip a volume 51
create an expandable disk on a hosted
destination 55
create an expandable disk on a managed
destination 55
customization 28
customize the location 47
customizing
computing resources 70
tasks throttling 70
customizing the guest operating system 62
D
data to copy 49, 57
delete a disk 56
delete job 85
destination
ESX host 23
vCenter Server 23
VirtualCenter 23
VMware Fusion 23
VMware Player 23
VMware Server 23
Workstation 23
destination machine
folder 46
naming 46
power on 70
destination services, startup mode 67
destination setup
computer information 62
DNS 64
domain details 65
guest operating system 62
network adapters 64
SID 62
time zone 64
Windows license 63
WINS 64
workgroup 65
disk
2GB split 15
not pre-allocated 15, 55
thick 15
thin-provisioned 15, 55
disk cloning modes
disk-based cloning, defined 14
full clones, defined 14
linked clones, defined 14
volume-based cloning, defined 14
disk controller 59
disk-based cloning 13, 14, 54, 55, 57
disks, adding 53
dual boot systems 9
duplicate ID 16
E
edit the number of processors 58
errors, viewing in the log files 90
ESX host
destination 23
source 21
support 21
ESX VM, source 42
exporting
to hosted formats 46, 48
to managed formats 46
exporting a single task log file 90
exporting jobs logs 90
F
feedback 5
filtering jobs 85
filtering jobs by history 85
full clones, defined 14
G
glossary 5
go to job 88
go to running task 84
guest operating system configuration
computer information 78
DNS 79
domain 80
network adapters 79
SID 78
VMware vCenter Converter Standalone User's Guide
92 VMware, Inc.
time zone 79
Windows license 79
WINS 79
workgroup 80
guest operating system customization
computer information 62
DNS 64
network adapters 64
SID 62
time zone 64
Windows license 63
WINS 64
workgroup and domain page 65
guest operating system, configuration 77
guest operating system, customization 62
guest operating system, customizing 62
GUID Partition Table (GPT) disks 14
H
Helper VM 61
hosted destinations
converting to 48
Fusion 48
VMware Server 48
Workstation 48
hosted VM, source 44
hot cloning
defined 9
Linux sources 12
Windows sources 10
hot cloning, synchronization 68
Hyper-V Server VM, source 45
Hyper-V, source 21
I
importing machines
configure the hardware 49
customize the location 47
select a source machine 40
install VMware Tools 65, 77
installation space requirements 20
installing 31
installing Converter Standalone, in Windows 31
installing VMware vCenter Converter Standalone,
Windows command-line installation 34
introduction 7
IPng support 25
IPv6 support 25
J
job 85
job copy 85
job create 85
job manager, checking tasks progress 89
jobs 85, 86
jobs list 84
jobs, adding 84
L
linked clones 13
linked clones, defined 14
live cloning, See hot cloning
log files, exporting and viewing 90
logical volume 54
logical volume group 54
logs, location 90
LVM 54
M
managing jobs, job view 83
managing tasks
canceling 88
changing the number of tasks displayed 88,
89
checking task progress 89
filtering tasks by history 88
filtering tasks by status 89
multiple-criteria filtering 89
task view 83
Master Boot Record (MBR) disks 14
maximum number of tasks 87
Microsoft Virtual PC, source 21
Microsoft Virtual Server, source 21
modes of cloning 13
modifying 35
move a disk to a different datastore 54
move a volume to a different datastore 52
move a volume to a different virtual disk 52
N
network settings 60, 61
not pre-allocated disks 55
O
offline cloning, See cold cloning
online cloning, See hot cloning
operating systems, support 19
optimized partition alignment 57
P
Parallels Desktop, source 21
permissions, configuring for vCenter users 25
port requirements 26
power off source machine 69
power on destination machine 70
Index
VMware, Inc. 93
powered-on machine conversion limitations 22
powered-on machine, source 41, 42
progress viewing 89
R
reconfiguring, starting the Wizard 74
remote Converter Standalone server 37
repairing 35
S
screen resolution requirements 21
selecting configuration sources
VMware Desktop VMs 76
VMware Infrastructure VMs 75
selecting sources
ESX virtual machine 42
hosted virtual machine 44
Hyper-V Server VM 45
Linux powered-on machine 42
powered-on machine 41
third-party VM 44
vCenter Server VM 42
Windows powered-on machine 41
server 8
services
on destination 67
on source 68
setting up destination
computer information 62
DNS 64
domain details 65
guest operating system 62
network adapters 64
SID 62
time zone 64
Windows license 63
WINS 64
workgroup 65
setting up SID 78
Simple File Sharing, turning off 28
skip a volume 51
snapshots, limitations 29
source machine
power off 69
uninstall Converter Standalone agent 71
source services, stop 68
specify a disk controller 59
starting
conversion 40
conversion wizard 40
starting the reconfiguration wizard 74
stop source services 68
StorageCraft ShadowProtect, source 21
support 5
supported destination types
ESX host 23
vCenter Server 23
virtual appliances 23
VirtualCenter 23
VMware Fusion 23
VMware Player 23
VMware Server 23
Workstation 23
supported operating systems 19
supported source types
Acronis True Image 21
ESX support 21
Hyper-V 21
Microsoft Virtual PC support 21
Microsoft Virtual Server support 21
Parallels Desktop 21
powered-on machines 21
StorageCraft ShadowProtect 21
Symantec LiveState Recovery 21
vCenter Server 21
Virtual Iron 21
VirtualCenter support 21
VMware Fusion support 21
VMware Server support 21
VMware virtual machines 21
Workstation support 21
Xen 21
switch to jobs view 84, 88
Symantec LiveState Recovery, source 21
synchronize conversion 86
synchronizing source with destination 68
sysprep 28
system images, converting existing 16
system reconfiguration 8
system requirements
installation space requirements 20
supported operating systems 19
TCP/IP and UDP port requirements 26
Windows operating systems 27
T
task manager
canceling tasks 88
combined filtering 89
filtering by multiple criteria 89
filtering tasks by history 88
filtering tasks by status 89
number of concurrent tasks 87
viewing task progress 89
tasks, filtering 88
VMware vCenter Converter Standalone User's Guide
94 VMware, Inc.
tasks, managing 87
tasks, submitting configuration 81
TCP/IP and UDP port requirements 26
thin-provisioned destination disks 7
thin-provisioned disk 55
third-party VM, source 44
throttling conversion tasks 70
time zone configuration 79
U
uninstall Converter Standalone agent 71
uninstalling 31
uninstalling VMware vCenter Converter
Standalone, in Windows 37
V
VCB, See VMware Consolidated Backup
vCenter Converter
migration with 7
tasks 7
vCenter permissions 25
vCenter Server, destination 23
vCenter Server support 21
vCenter Server virtual machines 43
vCenter Server VM, source 42
version support 21
viewing a task's progress 89
viewing conversion job summary 71
viewing the log files 90
virtual disk 52
virtual disk, adding 53
virtual hardware
CPU issues 17
disk device issues 17
Ethernet adapter issues 17
graphics card issues 17
Virtual Iron, source 21
virtual machines
conversion limitations 22
converting existing 16
destination on same network as source 16
VirtualCenter
destination 23
source 21
support 21
VMware Consolidated Backup 24
VMware Fusion
destination 23
source 21
support 21
VMware hosted products, information not
preserved when using Converter
Standalone 25
VMware hosted products support 21
VMware managed products, information not
preserved when using Converter
Standalone 24
VMware managed products support 21
VMware Player
destination 23
source 21
support 21
VMware Server
destination 23
source 21
support 21
VMware Tools 65
VMware vCenter Converter Boot CD 8
VMware vCenter Converter Standalone
command-line installation in Windows 34
installing remote access in Windows 32
uninstalling in Windows 37
volume cluster size 51
volume-based cloning 13, 50–52, 55, 56
volume-based cloning, defined 14
volume, supported types 13, 14
volumes, excluding 51
volumes, moving 53
volumes, resizing 50
VSS snapshots limitations 29
W
Windows, Simple File Sharing 28
Windows virtual machines, configuring 73
Windows XP, turning off Simple File Sharing 28
Windows XP, checking Windows Firewall
blocks 28
worker 8
Workstation
destination 23
source 21
support 21
X
Xen, source 21
Index
VMware, Inc. 95
VMware vCenter Converter Standalone User's Guide
96 VMware, Inc.

Navigation menu
