vSphere Troubleshooting

Update 1

ESXi 6.0

vCenter Server 6.0

This document supports the version of each product listed and

supports all subsequent versions until the document is

replaced by a new edition. To check for more recent editions

of this document, see http://www.vmware.com/support/pubs.

EN-001811-02

vSphere Troubleshooting

2 VMware, Inc.

You can find the most up-to-date technical documentation on the VMware Web site at:

http://www.vmware.com/support/

The VMware Web site also provides the latest product updates.

If you have comments about this documentation, submit your feedback to:

docfeedback@vmware.com

Copyright © 2010–2015 VMware, Inc. All rights reserved. Copyright and trademark information.

VMware, Inc.

3401 Hillview Ave.

Palo Alto, CA 94304

www.vmware.com

Contents

About vSphere Troubleshooting 5

Updated Information 7

1Troubleshooting Overview 9

Guidelines for Troubleshooting 9

Troubleshooting with Logs 11

2Troubleshooting Virtual Machines 13

Troubleshooting Fault Tolerant Virtual Machines 13

Troubleshooting USB Passthrough Devices 18

Recover Orphaned Virtual Machines 19

Virtual Machine Does Not Power On After Cloning or Deploying from Template 20

3Troubleshooting Hosts 23

Troubleshooting vSphere HA Host States 23

Troubleshooting Auto Deploy 27

Authentication Token Manipulation Error 32

Active Directory Rule Set Error Causes Host Profile Compliance Failure 33

Unable to Download VIBs When Using vCenter Server Reverse Proxy 33

4Troubleshooting vCenter Server and the vSphere Web Client 37

Troubleshooting vCenter Server 37

Troubleshooting the vSphere Web Client 38

Troubleshooting vCenter Server and ESXi Host Certificates 40

Troubleshooting vCenter Server Plug-Ins 41

5Troubleshooting Availability 43

Troubleshooting vSphere HA Admission Control 43

Troubleshooting Heartbeat Datastores 45

Troubleshooting vSphere HA Failure Response 46

Troubleshooting vSphere Fault Tolerance in Network Partitions 48

Troubleshooting VM Component Protection 49

6Troubleshooting Resource Management 51

Troubleshooting Storage DRS 51

Troubleshooting Storage I/O Control 56

7Troubleshooting Storage 59

Resolving SAN Storage Display Problems 60

Resolving SAN Performance Problems 61

VMware, Inc. 3

Virtual Machines with RDMs Need to Ignore SCSI INQUIRY Cache 66

Software iSCSI Adapter Is Enabled When Not Needed 66

Failure to Mount NFS Datastores 67

VMkernel Log Files Contain SCSI Sense Codes 67

Troubleshooting Storage Adapters 68

Checking Metadata Consistency with VOMA 68

Troubleshooting Flash Devices 70

Troubleshooting Virtual Volumes 73

Troubleshooting VAIO Filters 75

8Troubleshooting Networking 77

Troubleshooting MAC Address Allocation 78

The Conversion to the Enhanced LACP Support Fails 81

Unable to Remove a Host from a vSphere Distributed Switch 82

Hosts on a vSphere Distributed Switch 5.1 and Later Lose Connectivity to vCenter Server 83

Hosts on vSphere Distributed Switch 5.0 and Earlier Lose Connectivity to vCenter Server 84

Alarm for Loss of Network Redundancy on a Host 85

Virtual Machines Lose Connectivity After Changing the Uplink Failover Order of a Distributed

Port Group 86

Unable to Add a Physical Adapter to a vSphere Distributed Switch That Has Network I/O Control

Enabled 87

Troubleshooting SR-IOV Enabled Workloads 87

A Virtual Machine that Runs a VPN Client Causes Denial of Service for Virtual Machines on the

Host or Across a vSphere HA Cluster 89

Low Throughput for UDP Workloads on Windows Virtual Machines 91

Virtual Machines on the Same Distributed Port Group and on Different Hosts Cannot

Communicate with Each Other 92

Attempt to Power On a Migrated vApp Fails Because the Associated Protocol Profile Is Missing 93

Networking Configuration Operation Is Rolled Back and a Host Is Disconnected from

vCenter Server 94

9Troubleshooting Licensing 97

Troubleshooting Host Licensing 97

Unable to Power On a Virtual Machine 98

Unable to Configure or Use a Feature 98

Index 101

vSphere Troubleshooting

4 VMware, Inc.

About vSphere Troubleshooting

vSphere Troubleshooting describes troubleshooting issues and procedures for vCenter Server implementations

and related components.

Intended Audience

This information is for anyone who wants to troubleshoot virtual machines, ESXi hosts, clusters, and related

storage solutions. The information in this book is for experienced Windows or Linux system administrators

who are familiar with virtual machine technology and data center operations.

VMware, Inc. 5

vSphere Troubleshooting

6 VMware, Inc.

Updated Information

This vSphere Troubleshooting is updated with each release of the product or when necessary.

This table provides the update history of the vSphere Troubleshooting.

Revision Description

EN-001811-02 Added embedded video titled "Troubleshooting Basics". See “Guidelines for Troubleshooting,” on

page 9.

EN-001811-01 Added a new topic about troubleshooting VIB downloads while using a custom vCenter Server reverse

proxy port. See “Unable to Download VIBs When Using vCenter Server Reverse Proxy,” on page 33.

EN-001811-00 Initial release.

VMware, Inc. 7

vSphere Troubleshooting

8 VMware, Inc.

Troubleshooting Overview 1

vSphere Troubleshooting contains common troubleshooting scenarios and provides solutions for each of these

problems. You can also find guidance here for resolving problems that have similar origins. For unique

problems, consider developing and adopting a troubleshooting methodology.

The following approach for effective troubleshooting elaborates on how to gather troubleshooting

information, such as identifying symptoms and defining the problem space. Troubleshooting with log files

is also discussed.

This chapter includes the following topics:

n“Guidelines for Troubleshooting,” on page 9

n“Troubleshooting with Logs,” on page 11

Guidelines for Troubleshooting

To troubleshoot your implementation of vSphere, identify the symptoms of the problem, determine which

of the components are affected, and test possible solutions.

Identifying Symptoms A number of potential causes might lead to the under-performance or

nonperformance of your implementation. The first step in efficient

troubleshooting is to identify exactly what is going wrong.

Defining the Problem

Space

After you have isolated the symptoms of the problem, you must define the

problem space. Identify the software or hardware components that are

affected and might be causing the problem and those components that are

not involved.

Testing Possible

Solutions

When you know what the symptoms of the problem are and which

components are involved, test the solutions systematically until the problem

is resolved.

Troubleshooting Basics (http://link.brightcove.com/services/player/bcpid2296383276001?

bctid=ref:video_vsphere_troubleshooting)

Identifying Symptoms

Before you attempt to resolve a problem in your implementation, you must identify precisely how it is

failing.

The first step in the troubleshooting process is to gather information that defines the specific symptoms of

what is happening. You might ask these questions when gathering this information:

nWhat is the task or expected behavior that is not occurring?

VMware, Inc. 9

nCan the affected task be divided into subtasks that you can evaluate separately?

nIs the task ending in an error? Is an error message associated with it?

nIs the task completing but in an unacceptably long time?

nIs the failure consistent or sporadic?

nWhat has changed recently in the software or hardware that might be related to the failure?

Defining the Problem Space

After you identify the symptoms of the problem, determine which components in your setup are affected,

which components might be causing the problem, and which components are not involved.

To define the problem space in an implementation of vSphere, be aware of the components present. In

addition to VMware software, consider third-party software in use and which hardware is being used with

the VMware virtual hardware.

Recognizing the characteristics of the software and hardware elements and how they can impact the

problem, you can explore general problems that might be causing the symptoms.

nMisconfiguration of software settings

nFailure of physical hardware

nIncompatibility of components

Break down the process and consider each piece and the likelihood of its involvement separately. For

example, a case that is related to a virtual disk on local storage is probably unrelated to third-party router

configuration. However, a local disk controller setting might be contributing to the problem. If a component

is unrelated to the specific symptoms, you can probably eliminate it as a candidate for solution testing.

Think about what changed in the configuration recently before the problems started. Look for what is

common in the problem. If several problems started at the same time, you can probably trace all the

problems to the same cause.

Testing Possible Solutions

After you know the problem's symptoms and which software or hardware components are most likely

involved, you can systematically test solutions until you resolve the problem.

With the information that you have gained about the symptoms and affected components, you can design

tests for pinpointing and resolving the problem. These tips might make this process more effective.

nGenerate ideas for as many potential solutions as you can.

nVerify that each solution determines unequivocally whether the problem is fixed. Test each potential

solution but move on promptly if the fix does not resolve the problem.

nDevelop and pursue a hierarchy of potential solutions based on likelihood. Systematically eliminate

each potential problem from the most likely to the least likely until the symptoms disappear.

nWhen testing potential solutions, change only one thing at a time. If your setup works after many things

are changed at once, you might not be able to discern which of those things made a difference.

nIf the changes that you made for a solution do not help resolve the problem, return the implementation

to its previous status. If you do not return the implementation to its previous status, new errors might

be introduced.

nFind a similar implementation that is working and test it in parallel with the implementation that is not

working properly. Make changes on both systems at the same time until few differences or only one

difference remains between them.

vSphere Troubleshooting

10 VMware, Inc.

Troubleshooting with Logs

You can often obtain valuable troubleshooting information by looking at the logs provided by the various

services and agents that your implementation is using.

Most logs are located in C:\ProgramData\VMware\CIS\logs. Common logs are available in all

implementations. Other logs are unique to certain deployment options (Management Node or Platform

Services Controller).

Common Logs

The following logs are common to all deployments on Windows.

Table 1‑1. Directories for Common Logs

Log Directory Description

CloudVM Logs for allotment and distribution of resources between services

CM VMware Component Manager

FirstBoot Location where first boot logs are stored

rhttpproxy Reverse Web Proxy

SCA VMware Service Control Agent

vmaffd VMware Authentication Framework daemon

vmdird VMware Directory Service daemon

Postthaw, Prefreeze, Restore Utilized by CM and SCA to manipulate services

Management Node Logs

The following logs are available if a management node deployment is chosen.

Table 1‑2. Management Node Logs

Log Description

APIProxy VMware vCenter API Proxy

AutoDeploy VMware vSphere Auto Deploy Waiter

EAM VMware ESX Agent Manager

InvSvc VMware Inventory Service

Mbcs VMware Message Bus Config Service

Netdump VMware vSphere ESXi Dump Collector

Perfcharts VMware Performance Charts

Vapi VMware vAPI Endpoint

Vmcad VMware Certificate Authority daemon

VMdird VMware Directory Service daemon

vmsyslog collector vSphere Syslog Collector

Vmware-sps VMware vSphere Profile-Driven Storage Service

Vmware-vpx VMware VirtualCenter Server

vPostgres vFabric Postgres database service

Vmsm VMware Message Bus Config Service

vSphere-Client VMware vSphere Web Client

Chapter 1 Troubleshooting Overview

VMware, Inc. 11

Table 1‑2. Management Node Logs (Continued)

Log Description

Vws VMware System and Hardware Health Manager

Workflow VMware vCenter workflow manager

Platform Services Controller Logs

You can examine the following logs if a Platform Services Controller node deployment is chosen.

Table 1‑3. Platform Services Controller Node Logs

Log Description

cis-license VMware Licensing Service

SSO VMware Secure Token Service

VMCA VMware Certificate Service

vmdird VMware Directory Service

For Platform Services Controller node deployments, additional runtime logs are located at

C:\ProgramData\VMware\CIS\runtime\VMwareSTSService\logs, including logs for these services:

nVMware Secure Token Service

nVMware Identity Management Service

ESXi Logs

The following logs are available with ESXi hosts. These logs are located in /var/run/log.

Table 1‑4. ESXi Logs

Log Description

hostd.log Logs all hostd service operations

vpxa.log Logs interactions between the host vpxa agent and the vpxd service on vCenter

Server

fdm.log Logs related to vSphere HA clusters

rhttpproxy.log Rhttpproxy logs

syslog.log Default syslog catchall

usb.log USB related logs

hostprofiletrace.log Host profile trace logs

sdrsinjector.log vSphere Storage DRS device injector log

vSphere Troubleshooting

12 VMware, Inc.

Troubleshooting Virtual Machines 2

The virtual machine troubleshooting topics provide solutions to potential problems that you might

encounter when using your virtual machines.

This chapter includes the following topics:

n“Troubleshooting Fault Tolerant Virtual Machines,” on page 13

n“Troubleshooting USB Passthrough Devices,” on page 18

n“Recover Orphaned Virtual Machines,” on page 19

n“Virtual Machine Does Not Power On After Cloning or Deploying from Template,” on page 20

Troubleshooting Fault Tolerant Virtual Machines

To maintain a high level of performance and stability for your fault tolerant virtual machines and also to

minimize failover rates, you should be aware of certain troubleshooting issues.

The troubleshooting topics discussed focus on problems that you might encounter when using the vSphere

Fault Tolerance feature on your virtual machines. The topics also describe how to resolve problems.

You can also see the VMware knowledge base article at http://kb.vmware.com/kb/1033634 to help you

troubleshoot Fault Tolerance. This article contains a list of error messages that you might encounter when

you attempt to use the feature and, where applicable, advice on how to resolve each error.

Hardware Virtualization Not Enabled

You must enable Hardware Virtualization (HV) before you use vSphere Fault Tolerance.

Problem

When you attempt to power on a virtual machine with Fault Tolerance enabled, an error message might

appear if you did not enable HV.

Cause

This error is often the result of HV not being available on the ESXi server on which you are attempting to

power on the virtual machine. HV might not be available either because it is not supported by the ESXi

server hardware or because HV is not enabled in the BIOS.

VMware, Inc. 13

Solution

If the ESXi server hardware supports HV, but HV is not currently enabled, enable HV in the BIOS on that

server. The process for enabling HV varies among BIOSes. See the documentation for your hosts' BIOSes for

details on how to enable HV.

If the ESXi server hardware does not support HV, switch to hardware that uses processors that support

Fault Tolerance.

Compatible Hosts Not Available for Secondary VM

If you power on a virtual machine with Fault Tolerance enabled and no compatible hosts are available for its

Secondary VM, you might receive an error message.

Problem

You might encounter the following error message:

Secondary VM could not be powered on as there are no compatible hosts that can accommodate it.

Cause

This can occur for a variety of reasons including that there are no other hosts in the cluster, there are no

other hosts with HV enabled, Hardware MMU Virtualization is not supported by host CPUs, data stores are

inaccessible, there is no available capacity, or hosts are in maintenance mode.

Solution

If there are insufficient hosts, add more hosts to the cluster. If there are hosts in the cluster, ensure they

support HV and that HV is enabled. The process for enabling HV varies among BIOSes. See the

documentation for your hosts' BIOSes for details on how to enable HV. Check that hosts have sufficient

capacity and that they are not in maintenance mode.

Secondary VM on Overcommitted Host Degrades Performance of Primary VM

If a Primary VM appears to be executing slowly, even though its host is lightly loaded and retains idle CPU

time, check the host where the Secondary VM is running to see if it is heavily loaded.

Problem

When a Secondary VM resides on a host that is heavily loaded, the Secondary VM can affect the

performance of the Primary VM.

Cause

A Secondary VM running on a host that is overcommitted (for example, with its CPU resources) might not

get the same amount of resources as the Primary VM. When this occurs, the Primary VM must slow down to

allow the Secondary VM to keep up, effectively reducing its execution speed to the slower speed of the

Secondary VM.

Solution

If the Secondary VM is on an overcommitted host, you can move the VM to another location without

resource contention problems. Or more specifically, do the following:

nFor FT networking contention, use vMotion technology to move the Secondary VM to a host with fewer

FT VMs contending on the FT network. Verify that the quality of the storage access to the VM is not

asymmetric.

nFor storage contention problems, turn FT off and on again. When you recreate the Secondary VM,

change its datastore to a location with less resource contention and better performance potential.

vSphere Troubleshooting

14 VMware, Inc.

nTo resolve a CPU resources problem, set an explicit CPU reservation for the Primary VM at an MHz

value sufficient to run its workload at the desired performance level. This reservation is applied to both

the Primary and Secondary VMs, ensuring that both VMs can execute at a specified rate. For guidance

in setting this reservation, view the performance graphs of the virtual machine (before Fault Tolerance

was enabled) to see how many CPU resources it used under normal conditions.

Increased Network Latency Observed in FT Virtual Machines

If your FT network is not optimally configured, you might experience latency problems with the FT VMs.

Problem

FT VMs might see a variable increase in packet latency (on the order of milliseconds). Applications that

demand very low network packet latency or jitter (for example, certain real-time applications) might see a

degradation in performance.

Cause

Some increase in network latency is expected overhead for Fault Tolerance, but certain factors can add to

this latency. For example, if the FT network is on a particularly high latency link, this latency is passed on to

the applications. Also, if the FT network has insufficient bandwidth (fewer than 10 Gbps), greater latency

might occur.

Solution

Verify that the FT network has sufficient bandwidth (10 Gbps or more) and uses a low latency link between

the Primary VM and Secondary VM. These precautions do not eliminate network latency, but minimize its

potential impact.

Some Hosts Are Overloaded with FT Virtual Machines

You might encounter performance problems if your cluster's hosts have an imbalanced distribution of FT

VMs.

Problem

Some hosts in the cluster might become overloaded with FT VMs, while other hosts might have unused

resources.

Cause

vSphere DRS does not load balance FT VMs (unless they are using legacy FT). This limitation might result in

a cluster where hosts are unevenly distributed with FT VMs.

Solution

Manually rebalance the FT VMs across the cluster by using vSphere vMotion. Generally, the fewer FT VMs

that are on a host, the better they perform, due to reduced contention for FT network bandwidth and CPU

resources.

Losing Access to FT Metadata Datastore

Access to the Fault Tolerance metadata datastore is essential for the proper functioning of an FT VM. Loss of

this access can cause a variety of problems.

Problem

These problems include the following:

nFT can terminate unexpectedly.

Chapter 2 Troubleshooting Virtual Machines

VMware, Inc. 15

nIf both the Primary VM and Secondary VM cannot access the metadata datastore, the VMs might fail

unexpectedly. Typically, an unrelated failure that terminates FT must also occur when access to the FT

metadata datastore is lost by both VMs. vSphere HA then tries to restart the Primary VM on a host with

access to the metadata datastore.

nThe VM might stop being recognized as an FT VM by vCenter Server. This failed recognition can allow

unsupported operations such as taking snapshots to be performed on the VM and cause problematic

behavior.

Cause

Lack of access to the Fault Tolerance metadata datastore can lead to the undesirable outcomes in the

previous list.

Solution

When planning your FT deployment, place the metadata datastore on highly available storage. While FT is

running, if you see that the access to the metadata datastore is lost on either the Primary VM or the

Secondary VM, promptly address the storage problem before loss of access causes one of the previous

problems. If a VM stops being recognized as an FT VM by vCenter Server, do not perform unsupported

operations on the VM. Restore access to the metadata datastore. After access is restored for the FT VMs and

the refresh period has ended, the VMs are recognizable.

Turning On vSphere FT for Powered-On VM Fails

If you try to turn on vSphere Fault Tolerance for a powered-on VM, this operation can fail.

Problem

When you select Turn On Fault Tolerance for a powered-on VM, the operation fails and you see an Unknown

error message.

Cause

This operation can fail if the host that the VM is running on has insufficient memory resources to provide

fault tolerant protection. vSphere Fault Tolerance automatically tries to allocate a full memory reservation

on the host for the VM. Overhead memory is required for fault tolerant VMs and can sometimes expand to 1

to 2 GB. If the powered-on VM is running on a host that has insufficient memory resources to accommodate

the full reservation plus the overhead memory, trying to turn on Fault Tolerance fails. Subsequently, the

Unknown error message is returned.

Solution

Choose from these solutions:

nFree up memory resources on the host to accommodate the VM's memory reservation and the added

overhead.

nMove the VM to a host with ample free memory resources and try again.

FT Virtual Machines not Placed or Evacuated by vSphere DRS

FT virtual machines in a cluster that is enabled with vSphere DRS do not function correctly if

Enhanced vMotion Compatibility (EVC) is currently disabled.

Problem

Because EVC is a prerequisite for using DRS with FT VMs, DRS does not place or evacuate them if EVC has

been disabled (even if it is later reenabled).

vSphere Troubleshooting

16 VMware, Inc.

Cause

When EVC is disabled on a DRS cluster, a VM override that disables DRS on an FT VM might be added.

Even if EVC is later reenabled, this override is not canceled.

Solution

If DRS does not place or evacuate FT VMs in the cluster, check the VMs for a VM override that is disabling

DRS. If you find one, remove the override that is disabling DRS.

NOTE For more information on how to edit or delete VM overrides, see vSphere Resource Management.

Fault Tolerant Virtual Machine Failovers

A Primary or Secondary VM can fail over even though its ESXi host has not crashed. In such cases, virtual

machine execution is not interrupted, but redundancy is temporarily lost. To avoid this type of failover, be

aware of some of the situations when it can occur and take steps to avoid them.

Partial Hardware Failure Related to Storage

This problem can arise when access to storage is slow or down for one of the hosts. When this occurs there

are many storage errors listed in the VMkernel log. To resolve this problem you must address your storage-

related problems.

Partial Hardware Failure Related to Network

If the logging NIC is not functioning or connections to other hosts through that NIC are down, this can

trigger a fault tolerant virtual machine to be failed over so that redundancy can be reestablished. To avoid

this problem, dedicate a separate NIC each for vMotion and FT logging traffic and perform vMotion

migrations only when the virtual machines are less active.

Insufficient Bandwidth on the Logging NIC Network

This can happen because of too many fault tolerant virtual machines being on a host. To resolve this

problem, more broadly distribute pairs of fault tolerant virtual machines across different hosts.

Use a10-Gbit logging network for FT and verify that the network is low latency.

vMotion Failures Due to Virtual Machine Activity Level

If the vMotion migration of a fault tolerant virtual machine fails, the virtual machine might need to be failed

over. Usually, this occurs when the virtual machine is too active for the migration to be completed with only

minimal disruption to the activity. To avoid this problem, perform vMotion migrations only when the

virtual machines are less active.

Too Much Activity on VMFS Volume Can Lead to Virtual Machine Failovers

When a number of file system locking operations, virtual machine power ons, power offs, or vMotion

migrations occur on a single VMFS volume, this can trigger fault tolerant virtual machines to be failed over.

A symptom that this might be occurring is receiving many warnings about SCSI reservations in the

VMkernel log. To resolve this problem, reduce the number of file system operations or ensure that the fault

tolerant virtual machine is on a VMFS volume that does not have an abundance of other virtual machines

that are regularly being powered on, powered off, or migrated using vMotion.

Lack of File System Space Prevents Secondary VM Startup

Check whether or not your /(root) or /vmfs/datasource file systems have available space. These file systems

can become full for many reasons, and a lack of space might prevent you from being able to start a new

Secondary VM.

Chapter 2 Troubleshooting Virtual Machines

VMware, Inc. 17

Troubleshooting USB Passthrough Devices

Information about feature behavior can help you troubleshoot or avoid potential problems when USB

devices are connected to a virtual machine.

Error Message When You Try to Migrate Virtual Machine with USB Devices

Attached

Migration with vMotion cannot proceed and issues a confusing error message when you connect multiple

USB devices from an ESXi host to a virtual machine and one or more devices are not enabled for vMotion.

Problem

The Migrate Virtual Machine wizard runs a compatibility check before a migration operation begins. If

unsupported USB devices are detected, the compatibility check fails and an error message similar to the

following appears: Currently connected device 'USB 1' uses backing 'path:1/7/1', which is not

accessible.

Cause

To successfully pass vMotion compatibility checks, you must enable all USB devices that are connected to

the virtual machine from a host for vMotion. If one or more devices are not enabled for vMotion, migration

will fail.

Solution

1 Make sure that the devices are not in the process of transferring data before removing them.

2 Re-add and enable vMotion for each affected USB device.

USB Passthrough Device Is Nonresponsive

USB devices can become nonresponsive for several reasons, including unsafely interrupting a data transfer

or if a guest operating system driver sends an unsupported command to the device.

Problem

The USB device is nonresponsive.

Cause

A data transfer was interrupted or nonsupported devices are being used. For example, if a guest driver

sends a SCSI REPORT LUNS command to unsupported USB flash drives, the device stops responding to all

commands.

Solution

uPhysically detach the USB device from the ESXi host and reattach it.

If the host is not physically accessible, you can shut down the host (not reboot) and leave it turned off

for at least 30 seconds to ensure that the host USB bus is completely powered off.

When you turn on the host, the USB device is restored from its nonresponsive state.

vSphere Troubleshooting

18 VMware, Inc.

Cannot Copy Data From an ESXi Host to a USB Device That Is Connected to the

Host

You can connect a USB device to an ESXi host and copy data to the device from the host. For example, you

might want to gather the vm-support bundle from the host after the host loses network connectivity. To

perform this task, you must stop the USB arbitrator.

Problem

If the USB arbitrator is being used for USB passthrough from an ESXi host to a virtual machine the USB

device appears under lsusb but does not mount correctly.

Cause

This problem occurs because the nonbootable USB device is reserved for the virtual machine by default. It

does not appear on the host's file system, even though lsusb can see the device.

Solution

1 Stop the usbarbitrator service:/etc/init.d/usbarbitrator stop

2 Physically disconnect and reconnect the USB device.

By default, the device location is /vmfs/devices/disks/mpx.vmhbaXX:C0:T0:L0.

3 After you reconnect the device, restart the usbarbitrator service:/etc/init.d/usbarbitrator start

4 Restart hostd and any running virtual machines to restore access to the passthrough devices in the

virtual machine.

What to do next

Reconnect the USB devices to the virtual machine.

Recover Orphaned Virtual Machines

Virtual machines appear with (orphaned) appended to their names.

Problem

Virtual machines that reside on an ESXi host that vCenter Server manages might become orphaned in rare

cases. Such virtual machines exist in the vCenter Server database, but the ESXi host no longer recognizes

them.

Cause

Virtual machines can become orphaned if a host failover is unsuccessful, or when the virtual machine is

unregistered directly on the host. If this situation occurs, move the orphaned virtual machine to another host

in the data center on which the virtual machine files are stored.

Solution

1 Determine the datastore where the virtual machine configuration (.vmx) file is located.

a Select the virtual machine in the vSphere Web Client inventory, and click the Related Objects tab.

b Click Datastores.

The datastore or datastores where the virtual machine files are stored are displayed.

c If more than one datastore is displayed, select each datastore and click the file browser icon to

browse for the .vmx file.

d Verify the location of the .vmx file.

Chapter 2 Troubleshooting Virtual Machines

VMware, Inc. 19

2 Return to the virtual machine in the vSphere Web Client, right-click it, and select All Virtual

Infrastructure Actions > Remove from Inventory.

3 Click Yes to confirm the removal of the virtual machine.

4 Reregister the virtual machine with vCenter Server.

a Right-click the datastore where the virtual machine file is located and select Register VM.

b Browse to the .vmx file and click OK.

c Select the location for the virtual machine and click Next.

d Select the host on which to run the virtual machine and click Next.

e Click Finish.

Virtual Machine Does Not Power On After Cloning or Deploying from

Template

Virtual machines do not power on after you complete the clone or deploy from template workflow in the

vSphere Web Client.

Problem

When you clone a virtual machine or deploy a virtual machine from a template, you might not be able to

power on the virtual machine after creation.

Cause

The swap file size is not reserved when the virtual machine disks are created.

Solution

nReduce the size of the swap file that is required for the virtual machine. You can do this by increasing

the virtual machine memory reservation.

a Right-click the virtual machine and select Edit Settings.

b Select Virtual Hardware and click Memory.

c Use the Reservation dropdown menu to increase the amount of memory allocated to the virtual

machine.

d Click OK.

nAlternatively, you can increase the amount of space available for the swap file by moving other virtual

machine disks off of the datastore that is being used for the swap file.

a Browse to the datastore in the vSphere Web Client object navigator.

b Select the Related Objects tab and click the Virtual Machines tab.

c For each virtual machine to move, right-click the virtual machine and select Migrate.

d Select Change storage only.

e Proceed through the Migrate Virtual Machine wizard.

nYou can also increase the amount of space available for the swap file by changing the swap file location

to a datastore with adequate space.

a Browse to the host in the vSphere Web Client object navigator.

b Select the Manage tab and click Settings.

c Under Virtual Machines, select Swap file location.

vSphere Troubleshooting

20 VMware, Inc.

d Click Edit.

NOTE If the host is part of a cluster that specifies that the virtual machine swap files are stored in

the same directory as the virtual machine, you cannot click Edit. You must use the Cluster Settings

dialog box to change the swap file location policy for the cluster.

e Select Use a specific datastore and select a datastore from the list.

f Click OK.

Chapter 2 Troubleshooting Virtual Machines

VMware, Inc. 21

vSphere Troubleshooting

22 VMware, Inc.

Troubleshooting Hosts 3

The host troubleshooting topics provide solutions to potential problems that you might encounter when

using your vCenter Servers and ESXi hosts.

This chapter includes the following topics:

n“Troubleshooting vSphere HA Host States,” on page 23

n“Troubleshooting Auto Deploy,” on page 27

n“Authentication Token Manipulation Error,” on page 32

n“Active Directory Rule Set Error Causes Host Profile Compliance Failure,” on page 33

n“Unable to Download VIBs When Using vCenter Server Reverse Proxy,” on page 33

Troubleshooting vSphere HA Host States

vCenter Server reports vSphere HA host states that indicate an error condition on the host. Such errors can

prevent vSphere HA from fully protecting the virtual machines on the host and can impede vSphere HA's

ability to restart virtual machines after a failure. Errors can occur when vSphere HA is being configured or

unconfigured on a host or, more rarely, during normal operation. When this happens, you should determine

how to resolve the error, so that vSphere HA is fully operational.

vSphere HA Agent Is in the Agent Unreachable State

The vSphere HA agent on a host is in the Agent Unreachable state for a minute or more. User intervention

might be required to resolve this situation.

Problem

vSphere HA reports that an agent is in the Agent Unreachable state when the agent for the host cannot be

contacted by the master host or by vCenter Server. Consequently, vSphere HA is not able to monitor the

virtual machines on the host and might not restart them after a failure.

Cause

A vSphere HA agent can be in the Agent Unreachable state for several reasons. This condition most often

indicates that a networking problem is preventing vCenter Server from contacting the master host and the

agent on the host, or that all hosts in the cluster have failed. This condition can also indicate the unlikely

situation that vSphere HA was disabled and then re-enabled on the cluster while vCenter Server could not

communicate with the vSphere HA agent on the host, or that the ESXi host agent on the host has failed, and

the watchdog process was unable to restart it. In any of these cases, a failover event is not triggered when a

host goes into the Unreachable state.

VMware, Inc. 23

Solution

Determine if vCenter Server is reporting the host as not responding. If so, there is a networking problem, an

ESXi host agent failure, or a total cluster failure. After the condition is resolved, vSphere HA should work

correctly. If not, reconfigure vSphere HA on the host. Similarly, if vCenter Server reports the hosts are

responding but a host's state is Agent Unreachable, reconfigure vSphere HA on that host.

vSphere HA Agent is in the Uninitialized State

The vSphere HA agent on a host is in the Uninitialized state for a minute or more. User intervention might

be required to resolve this situation.

Problem

vSphere HA reports that an agent is in the Uninitialized state when the agent for the host is unable to enter

the run state and become the master host or to connect to the master host. Consequently, vSphere HA is not

able to monitor the virtual machines on the host and might not restart them after a failure.

Cause

A vSphere HA agent can be in the Uninitialized state for one or more reasons. This condition most often

indicates that the host does not have access to any datastores. Less frequently, this condition indicates that

the host does not have access to its local datastore on which vSphere HA caches state information, the agent

on the host is inaccessible, or the vSphere HA agent is unable to open required firewall ports. It is also

possible that the ESXi host agent has stopped.

Solution

Search the list of the host's events for recent occurrences of the event vSphere HA Agent for the host has

an error. This event indicates the reason for the host being in the uninitialized state. If the condition exists

because of a datastore problem, resolve whatever is preventing the host from accessing the affected

datastores. If the ESXi host agent has stopped, you must restart it. After the problem has been resolved, if

the agent does not return to an operational state, reconfigure vSphere HA on the host.

NOTE If the condition exists because of a firewall problem, check if there is another service on the host that

is using port 8182. If so, shut down that service, and reconfigure vSphere HA.

vSphere HA Agent is in the Initialization Error State

The vSphere HA agent on a host is in the Initialization Error state for a minute or more. User intervention is

required to resolve this situation.

Problem

vSphere HA reports that an agent is in the Initialization Error state when the last attempt to configure

vSphere HA for the host failed. vSphere HA does not monitor the virtual machines on such a host and

might not restart them after a failure.

Cause

This condition most often indicates that vCenter Server was unable to connect to the host while the vSphere

HA agent was being installed or configured on the host. This condition might also indicate that the

installation and configuration completed, but the agent did not become a master host or a slave host within

a timeout period. Less frequently, the condition is an indication that there is insufficient disk space on the

host's local datastore to install the agent, or that there are insufficient unreserved memory resources on the

host for the agent resource pool. Finally, for ESXi 5.x hosts, the configuration fails if a previous installation

of another component required a host reboot, but the reboot has not yet occurred.

vSphere Troubleshooting

24 VMware, Inc.

Solution

When a Configure HA task fails, a reason for the failure is reported.

Reason for Failure Action

Host communication

errors

Resolve any communication problems with the host and retry the configuration operation.

Timeout errors Possible causes include that the host crashed during the configuration task, the agent failed to

start after being installed, or the agent was unable to initialize itself after starting up. Verify

that vCenter Server is able to communicate with the host. If so, see “vSphere HA Agent Is in

the Agent Unreachable State,” on page 23 or “vSphere HA Agent is in the Uninitialized State,”

on page 24 for possible solutions.

Lack of resources Free up approximately 75MB of disk space. If the failure is due to insufficient unreserved

memory, free up memory on the host by either relocating virtual machines to another host or

reducing their reservations. In either case, retry the vSphere HA configuration task after

resolving the problem.

Reboot pending If an installation for a 5.0 or later host fails because a reboot is pending, reboot the host and

retry the vSphere HA configuration task.

vSphere HA Agent is in the Uninitialization Error State

The vSphere HA agent on a host is in the Uninitialization Error state. User intervention is required to

resolve this situation.

Problem

vSphere HA reports that an agent is in the Uninitialization Error state when vCenter Server is unable to

unconfigure the agent on the host during the Unconfigure HA task. An agent left in this state can interfere

with the operation of the cluster. For example, the agent on the host might elect itself as master host and

lock a datastore. Locking a datastore prevents the valid cluster master host from managing the virtual

machines with configuration files on that datastore.

Cause

This condition usually indicates that vCenter Server lost the connection to the host while the agent was

being unconfigured.

Solution

Add the host back to vCenter Server (version 5.0 or later). The host can be added as a stand-alone host or

added to any cluster.

vSphere HA Agent is in the Host Failed State

The vSphere HA agent on a host is in the Host Failed state. User intervention is required to resolve the

situation.

Problem

Usually, such reports indicate that a host has actually failed, but failure reports can sometimes be incorrect.

A failed host reduces the available capacity in the cluster and, in the case of an incorrect report, prevents

vSphere HA from protecting the virtual machines running on the host.

Cause

This host state is reported when the vSphere HA master host to which vCenter Server is connected is unable

to communicate with the host and with the heartbeat datastores that are in use for the host. Any storage

failure that makes the datastores inaccessible to hosts can cause this condition if accompanied by a network

failure.

Chapter 3 Troubleshooting Hosts

VMware, Inc. 25

Solution

Check for the noted failure conditions and resolve any that are found.

vSphere HA Agent is in the Network Partitioned State

The vSphere HA agent on a host is in the Network Partitioned state. User intervention might be required to

resolve this situation.

Problem

While the virtual machines running on the host continue to be monitored by the master hosts that are

responsible for them, vSphere HA's ability to restart the virtual machines after a failure is affected. First,

each master host has access to a subset of the hosts, so less failover capacity is available to each host. Second,

vSphere HA might be unable to restart a Secondary VM after a failure (see “Primary VM Remains in the

Need Secondary State,” on page 48).

Cause

A host is reported as partitioned if both of the following conditions are met:

nThe vSphere HA master host to which vCenter Server is connected is unable to communicate with the

host by using the management (or Virtual SAN) network, but is able to communicate with that host by

using the heartbeat datastores that have been selected for it.

nThe host is not isolated.

A network partition can occur for a number of reasons including incorrect VLAN tagging, the failure of a

physical NIC or switch, configuring a cluster with some hosts that use only IPv4 and others that use only

IPv6, or the management networks for some hosts were moved to a different virtual switch without first

putting the host into maintenance mode.

Solution

Resolve the networking problem that prevents the hosts from communicating by using the management

networks.

vSphere HA Agent is in the Network Isolated State

The vSphere HA agent on a host is in the Network Isolated state. User intervention is required to resolve

this situation.

Problem

When a host is in the Network Isolated state, there are two things to consider -- the isolated host and the

vSphere HA agent that holds the master role.

nOn the isolated host, the vSphere HA agent applies the configured isolation response to the running

VMs, determining if they should be shut down or powered off. It does this after checking whether a

master agent is able to take responsibility for each VM (by locking the VM's home datastore.) If not, the

agent defers applying the isolation response for the VM and rechecks the datastore state after a short

delay.

nIf the vSphere HA master agent can access one or more of the datastores, it monitors the VMs that were

running on the host when it became isolated and attempts to restart any that were powered off or shut

down.

Cause

A host is network isolated if both of the following conditions are met:

nIsolation addresses have been configured and the host is unable to ping them.

vSphere Troubleshooting

26 VMware, Inc.

nThe vSphere HA agent on the host is unable to access any of the agents running on the other cluster

hosts.

NOTE If your vSphere HA cluster has Virtual SAN enabled, a host is determined to be isolated if it cannot

communicate with the other vSphere HA agents in the cluster and cannot reach the configured isolation

addresses. Although the vSphere HA agents use the Virtual SAN network for inter-agent communication,

the default isolation address is still the gateway of the host. Hence, in the default configuration, both

networks must fail for a host be declared isolated.

Solution

Resolve the networking problem that is preventing the host from pinging its isolation addresses and

communicating with other hosts.

Configuration of vSphere HA on Hosts Times Out

The configuration of a vSphere HA cluster might time out on some of the hosts added to it.

Problem

When you enable vSphere HA on an existing cluster with a large number of hosts and virtual machines, the

setup of vSphere HA on some of the hosts might fail.

Cause

This failure is the result of a time out occurring before the installation of vSphere HA on the host(s)

completes.

Solution

Set the vCenter Server advanced option config.vpxd.das.electionWaitTimeSec to value=240. Once this

change is made, the time outs do not occur.

Troubleshooting Auto Deploy

The Auto Deploy troubleshooting topics offer solutions for situations when provisioning hosts with Auto

Deploy does not work as expected.

Auto Deploy TFTP Timeout Error at Boot Time

A TFTP Timeout error message appears when a host provisioned by Auto Deploy boots. The text of the

message depends on the BIOS.

Problem

A TFTP Timeout error message appears when a host provisioned by Auto Deploy boots. The text of the

message depends on the BIOS.

Cause

The TFTP server is down or unreachable.

Solution

uEnsure that your TFTP service is running and reachable by the host that you are trying to boot.

Chapter 3 Troubleshooting Hosts

VMware, Inc. 27

Auto Deploy Host Boots with Wrong Configuration

A host is booting with a different ESXi image, host profile, or folder location than the one specified in the

rules.

Problem

A host is booting with a different ESXi image profile or configuration than the image profile or

configuration that the rules specify. For example, you change the rules to assign a different image profile,

but the host still uses the old image profile.

Cause

After the host has been added to a vCenter Server system, the boot configuration is determined by the

vCenter Server system. The vCenter Server system associates an image profile, host profile, or folder

location with the host.

Solution

uUse the Test-DeployRuleSetCompliance and Repair-DeployRuleSetCompliance PowerCLI cmdlets to

reevalute the rules and to associate the correct image profile, host profile, or folder location with the

host.

Host Is Not Redirected to Auto Deploy Server

During boot, a host that you want to provision with Auto Deploy loads iPXE. The host is not redirected to

the Auto Deploy server.

Problem

During boot, a host that you want to provision with Auto Deploy loads iPXE. The host is not redirected to

the AutoDeploy server.

Cause

The tramp file that is included in the TFTP ZIP file has the wrong IP address for the Auto Deploy server.

Solution

uCorrect the IP address of the Auto Deploy server in the tramp file, as explained in the vSphere Installation

and Setup documentation.

Package Warning Message When You Assign an Image Profile to Auto Deploy

Host

When you run a PowerCLI cmdlet that assigns an image profile that is not Auto Deploy ready, a warning

message appears.

Problem

When you write or modify rules to assign an image profile to one or more hosts, the following error results:

Warning: Image Profile <name-here> contains one or more software packages that are not stateless-

ready. You may experience problems when using this profile with Auto Deploy.

vSphere Troubleshooting

28 VMware, Inc.

Cause

Each VIB in an image profile has a stateless-ready flag that indicates that the VIB is meant for use with

Auto Deploy. You get the error if you attempt to write an Auto Deploy rule that uses an image profile in

which one or more VIBs have that flag set to FALSE.

NOTE You can use hosts provisioned with Auto Deploy that include VIBs that are not stateless ready

without problems. However booting with an image profile that includes VIBs that are not stateless ready is

treated like a fresh install. Each time you boot the host, you lose any configuration data that would

otherwise be available across reboots for hosts provisioned with Auto Deploy.

Solution

1 Use Image Builder PowerCLI cmdlets to view the VIBs in the image profile.

2 Remove any VIBs that are not stateless-ready.

3 Rerun the Auto Deploy PowerCLI cmdlet.

Auto Deploy Host with a Built-In USB Flash Drive Does Not Send Coredumps to

Local Disk

If your Auto Deploy host has a built-in USB flash drive, and an error results in a coredump, the coredump is

lost. Set up your system to use ESXi Dump Collector to store coredumps on a networked host.

Problem

If your Auto Deploy host has a built-in USB Flash, and if it encounters an error that results in a coredump,

the coredump is not sent to the local disk.

Solution

1 Install ESXi Dump Collector on a system of your choice.

ESXi Dump Collector is included with the vCenter Server installer.

2 Use ESXCLI to configure the host to use ESXi Dump Collector.

esxcli conn_options system coredump network set IP-addr,port

esxcli system coredump network set -e true

3 Use ESXCLI to disable local coredump partitions.

esxcli conn_options system coredump partition set -e false

Auto Deploy Host Reboots After Five Minutes

An Auto Deploy host boots and displays iPXE information, but reboots after five minutes.

Problem

A host to be provisioned with Auto Deploy boots from iPXE and displays iPXE information on the console.

However, after five minutes, the host displays the following message to the console and reboots.

This host is attempting to network-boot using VMware

AutoDeploy. However, there is no ESXi image associated with this host.

Details: No rules containing an Image Profile match this

host. You can create a rule with the New-DeployRule PowerCLI cmdlet

and add it to the rule set with Add-DeployRule or Set-DeployRuleSet.

The rule should have a pattern that matches one or more of the attributes

listed below.

Chapter 3 Troubleshooting Hosts

VMware, Inc. 29

The host might also display the following details:

Details: This host has been added to VC, but no Image Profile

is associated with it. You can use Apply-ESXImageProfile in the

PowerCLI to associate an Image Profile with this host.

Alternatively, you can reevaluate the rules for this host with the

Test-DeployRuleSetCompliance and Repair-DeployRuleSetCompliance cmdlets.

The console then displays the host's machine attributes including vendor, serial number, IP address, and so

on.

Cause

No image profile is currently associated with this host.

Solution

You can temporarily assign an image profile to the host by running the Apply-EsxImageProfile cmdlet.

You can permanently assign an image profile to the host as follows.

1 Run the New-DeployRule cmdlet to create a rule that includes a pattern that matches the host with an

image profile.

2 Run the Add-DeployRule cmdlet to add the rule to a ruleset.

3 Run the Test-DeployRuleSetCompliance cmdlet and use the output of that cmdlet as the input to the

Repair-DeployRuleSetCompliance cmdlet.

Auto Deploy Host Cannot Contact TFTP Server

The host that you provision with Auto Deploy cannot contact the TFTP server.

Problem

When you attempt to boot a host provisioned with Auto Deploy, the host performs a network boot and is

assigned a DHCP address by the DHCP server, but the host cannot contact the TFTP server.

Cause

The TFTP server might have stopped running, or a firewall might block the TFTP port.

Solution

nIf you installed the WinAgents TFTP server, open the WinAgents TFTP management console and verify

that the service is running. If the service is running, check the Windows firewall's inbound rules to

make sure the TFTP port is not blocked. Turn off the firewall temporarily to see whether the firewall is

the problem.

nFor all other TFTP servers, see the server documentation for debugging procedures.

Auto Deploy Host Cannot Retrieve ESXi Image from Auto Deploy Server

The host that you provision with Auto Deploy stops at the iPXE boot screen.

Problem

When you attempt to boot a host provisioned with Auto Deploy, the boot process stops at the iPXE boot

screen and the status message indicates that the host is attempting to get the ESXi image from the Auto

Deploy server.

Cause

The Auto Deploy service might be stopped or the Auto Deploy server might be unaccessible.

vSphere Troubleshooting

30 VMware, Inc.

Solution

1 Log in to the system on which you installed the Auto Deploy server.

2 Check that the Auto Deploy server is running.

a Click Start > Settings > Control Panel > Administrative Tools.

b Double-click Services to open the Services Management panel.

c In the Services field, look for the VMware vSphere Auto Deploy Waiter service and restart the

service if it is not running.

3 Open a Web browser, enter the following URL, and check whether the Auto Deploy server is accessible.

https://Auto_Deploy_Server_IP_Address:Auto_Deploy_Server_Port/vmw/rdb

NOTE Use this address only to check whether the server is accessible.

4 If the server is not accessible, a firewall problem is likely.

a Try setting up permissive TCP Inbound rules for the Auto Deploy server port.

The port is 6501 unless you specified a different port during installation.

b As a last resort, disable the firewall temporarily and enable it again after you verified whether it

blocked the traffic. Do not disable the firewall on production environments.

To disable the firewall, run netsh firewall set opmode disable. To enable the firewall, run

netsh firewall set opmode enable.

Auto Deploy Host Does Not Get a DHCP Assigned Address

The host you provision with Auto Deploy fails to get a DHCP Address.

Problem

When you attempt to boot a host provisioned with Auto Deploy, the host performs a network boot but is

not assigned a DHCP address. The Auto Deploy server cannot provision the host with the image profile.

Cause

You might have a problem with the DHCP service or with the firewall setup.

Solution

1 Check that the DHCP server service is running on the Windows system on which the DHCP server is

set up to provision hosts.

a Click Start > Settings > Control Panel > Administrative Tools.

b Double-click Services to open the Services Management panel.

c In the Services field, look for the DHCP server service and restart the service if it is not running.

2 If the DHCP server is running, recheck the DHCP scope and the DHCP reservations that you

configured for your target hosts.

If the DHCP scope and reservations are configured correctly, the problem most likely involves the

firewall.

Chapter 3 Troubleshooting Hosts

VMware, Inc. 31

3 As a temporary workaround, turn off the firewall to see whether that resolves the problem.

a Open the command prompt by clicking Start > Program > Accessories > Command prompt.

b Type the following command to temporarily turn off the firewall. Do not turn off the firewall in a

production environment.

netsh firewall set opmode disable

c Attempt to provision the host with Auto Deploy.

d Type the following command to turn the firewall back on.

netsh firewall set opmode enable

4 Set up rules to allow DHCP network traffic to the target hosts.

See the firewall documentation for DHCP and for the Windows system on which the DHCP server is

running for details.

Auto Deploy Host Does Not Network Boot

The host you provision with Auto Deploy comes up but does not network boot.

Problem

When you attempt to boot a host provisioned with Auto Deploy, the host does not start the network boot

process.

Cause

You did not enable your host for network boot.

Solution

1 Reboot the host and follow the on-screen instructions to access the BIOS configuration.

If you have an EFI host, you must switch the EFI system to BIOS compatibility mode.

2 In the BIOS configuration, enable Network Boot in the Boot Device configuration.

Authentication Token Manipulation Error

Creating a password that does not meet the authentication requirements of the host causes an error.

Problem

When you create a password on the host, the following fault message appears: A general system error

occurred: passwd: Authentication token manipulation error.

The following message is included: Failed to set the password. It is possible that your password

does not meet the complexity criteria set by the system.

Cause

The host checks for password compliance using the default authentication plug-in, pam_passwdqc.so. If the

password is not compliant, the error appears.

Solution

When you create a password, include a mix of characters from four character classes: lowercase letters,

uppercase letters, numbers, and special characters such as an underscore or dash.

Your user password must meet the following length requirements.

nPasswords containing characters from one or two character classes must be at least eight characters

long.

vSphere Troubleshooting

32 VMware, Inc.

nPasswords containing characters from three character classes must be at least seven characters long.

nPasswords containing characters from all four character classes must be at least six characters long.

NOTE An uppercase character that begins a password does not count toward the number of character

classes used. A number that ends a password does not count toward the number of character classes used.

You can also use a passphrase, which is a phrase consisting of at least three words, each of which is 8 to 40

characters long.

For more information, see the vSphere Security documentation.

Active Directory Rule Set Error Causes Host Profile Compliance

Failure

Applying a host profile that specifies an Active Directory domain to join causes a compliance failure.

Problem

When you apply a host profile that specifies an Active Directory domain to join, but you do not enable the

activeDirectoryAll rule set in the firewall configuration, a compliance failure occurs. The

vSphere Web Client displays the error message Failures against the host profile: Ruleset

activedirectoryAll does not match the specification. The compliance failure also occurs when you

apply a host profile to leave an Active Directory domain, but you do not disable the activeDirectoryAll rule

set in the host profile.

Cause

Active Directory requires the activeDirectoryAll firewall rule set. You must enable the rule set in the

firewall configuration. If you omit this setting, the system adds the necessary firewall rules when the host

joins the domain, but the host will be noncompliant because of the mismatch in firewall rules. The host will

also be noncompliant if you remove it from the domain without disabling the Active Directory rule set.

Solution

1 Browse to the host profile in the vSphere Web Client.

To find a host profile, click Policies and Profiles > Host Profiles on the vSphere Web Client Home

page.

2 Right-click the host profile and select Edit Settings.

3 Click Next.

4 Select Security and Services > Firewall Configuration > Firewall configuration > Ruleset

Configuration > activeDirectoryAll.

5 In the right panel, select the Flag indicating whether ruleset should be enabled check box.

Deselect the check box if the host is leaving the domain.

6 Click Next, and then click Finish to complete the change to the host profile.

Unable to Download VIBs When Using vCenter Server Reverse Proxy

You are unable to download VIBs if vCenter Server is using a custom port for the reverse proxy.

Problem

If you configure vCenter Server reverse proxy to use a custom port, the VIB downloads fail.

Chapter 3 Troubleshooting Hosts

VMware, Inc. 33

Cause

If vCenter Server is using a custom port for the reverse proxy, the custom port is not automatically enabled

in the ESXi firewall and the VIB downloads fail.

Solution

1 Open an SSH connection to the host and log in as root.

2 (Optional) List the existing firewall rules.

esxcli network firewall ruleset list

3 (Optional) Back up the /etc/vmware/firewall/service.xml file.

cp /etc/vmware/firewall/service.xml /etc/vmware/firewall/service.xml.bak

4 Edit the access permissions of the service.xml file to allow writes by running the chmod command.

nTo allow writes, run chmod 644/etc/vmware/firewall/service.xml.

nTo toggle the sticky bit flag, run chmod +t /etc/vmware/firewall/service.xml.

5 Open the service.xml file in a text editor.

6 Add a new rule to the service.xml file that enables the custom port for the vCenter Server reverse

proxy .

<service id='id_value'>

<id>vcenterrhttpproxy</id>

<rule id='0000'>

<direction>outbound</direction>

<protocol>tcp</protocol>

<port type='dst'>custom_reverse_proxy_port</port>

</rule>

<enabled>true</enabled>

<required>false</required>

</service>

Where id_value must be a unique value, for example, if the last listed service in the service.xml file has

ID 0040, you must enter id number 0041.

7 Revert the access permissions of the service.xml file to the default read-only setting.

chmod 444 /etc/vmware/firewall/service.xml

8 Refresh the firewall rules for the changes to take effect.

esxcli network firewall refresh

9 (Optional) List the updated rule set to confirm the change.

esxcli network firewall ruleset list

vSphere Troubleshooting

34 VMware, Inc.

10 (Optional) If you want the firewall configuration to persist after a reboot of the ESXi host, copy the

service.xml onto persistent storage and modify the local.sh file.

a Copy the modified service.xml file onto persistent storage, for example /store/, or onto a VMFS

volume, for example /vmfs/volumes/volume/.

cp /etc/vmware/firewall/service.xml location_of_xml_file

You can store a VMFS volume in a single location and copy it to multiple hosts.

b Add the service.xml file information to the local.sh file on the host.

cp location_of_xml_file /etc/vmware/firewall

esxcli network firewall refresh

Wherelocation_of_xml_file is the location to which the file was copied.

Chapter 3 Troubleshooting Hosts

VMware, Inc. 35

vSphere Troubleshooting

36 VMware, Inc.

Troubleshooting vCenter Server and

the vSphere Web Client 4

The vCenter Server and vSphere Web Client troubleshooting topics provide solutions to problems you

might encounter when you set up and configure vCenter Server and the vSphere Web Client, including

vCenter Single Sign-On.

This chapter includes the following topics:

n“Troubleshooting vCenter Server,” on page 37

n“Troubleshooting the vSphere Web Client,” on page 38

n“Troubleshooting vCenter Server and ESXi Host Certificates,” on page 40

n“Troubleshooting vCenter Server Plug-Ins,” on page 41

Troubleshooting vCenter Server

These troubleshooting topics provide solutions to problems you might encounter When you use install

vCenter Server on the Windows operating system or deploy the vCenter Server Appliance on a Linux

system.

vCenter Server Upgrade Fails When Unable to Stop Tomcat Service

A vCenter Server upgrade can fail when the installer is unable to stop the Tomcat service.

Problem

If the vCenter Server installer cannot stop the Tomcat service during an upgrade, the upgrade fails with an

error message similar to Unable to delete VC Tomcat service. This problem can occur even if you stop the

Tomcat service manually before the upgrade, if some files that are used by the Tomcat process are locked.

Solution

1 From the Windows Start menu, select Settings > Control Panel > Administrative Tools > Services.

2 Right-click VMware VirtualCenter Server and select Manual.

3 Right-click VMware vCenter Management Webservices and select Manual.

4 Reboot the vCenter Server machine before upgrading.

This releases any locked files that are used by the Tomcat process, and enables the vCenter Server

installer to stop the Tomcat service for the upgrade.

Alternatively, you can restart the vCenter Server machine and restart the upgrade process, but select the

option not to overwrite the vCenter Server data.

VMware, Inc. 37

Microsoft SQL Database Set to Unsupported Compatibility Mode Causes

vCenter Server Installation or Upgrade to Fail

vCenter Server installation with a Microsoft SQL database fails when the database is set to compatibility

mode with an unsupported version.

Problem

The following error message appears: The DB User entered does not have the required permissions

needed to install and configure vCenter Server with the selected DB. Please correct the following

error(s): %s

Cause

The database version must be supported for vCenter Server. For SQL, even if the database is a supported

version, if it is set to run in compatibility mode with an unsupported version, this error occurs. For example,

if SQL 2008 is set to run in SQL 2000 compatibility mode, this error occurs.

Solution

uMake sure the vCenter Server database is a supported version and is not set to compatibility mode with

an unsupported version. See the VMware Product Interoperability Matrixes at

http://partnerweb.vmware.com/comp_guide2/sim/interop_matrix.php?.

Troubleshooting the vSphere Web Client

The vSphere Web Client topics provide solutions to potential problems you might encounter when using the

vSphere Web Client to manage vSphere components, including vCenter Single Sign-On and vCenter Server.

vCenter Server System Does Not Appear in vSphere Web Client Inventory

The vSphere Web Client does not display the vCenter Server systems that you expect to see in the inventory.

Problem

When you log in to the vSphere Web Client, the inventory appears to be empty or the vCenter Server system

you expected to see does not appear.

Cause

In releases of vSphere before vSphere 5.1, you log into individual vCenter Server systems with the vSphere

Client. Unless you work in Linked Mode, only one instance of vCenter Server appears in the inventory.

In vSphere 5.1 and 5.5, you log into the vSphere Web Client to view and manage multiple instances of

vCenter Server. Any vCenter Server system on which you have permissions appears in the inventory, if the

server is registered with the same Component Manager as the vSphere Web Client.

Solution

nLog in to the vSphere Web Client as a user with permissions on the vCenter Server system.

The vCenter Server system will not appear in the inventory if you do not have permissions on it. For

example, if you log in as the vCenter Single Sign On administrator user, you might not have

permissions on any vCenter Server system.

nVerify that the vCenter Server system is registered with the same Component Manager as the

vSphere Web Client.

The vSphere Web Client discovers only vCenter Server systems that are registered with the same

Componenent Manager.

vSphere Troubleshooting

38 VMware, Inc.

Unable to Start the Virtual Machine Console

When you attempt to open a virtual machine console from the vSphere Web Client, the console does not

open.

Problem

When you attempt to open a virtual machine console from the vSphere Web Client, the console does not

open. The following error message appears:

HTTP ERROR 404

Problem accessin /. Reason:

Not Found

Errors similar to the following appear in the virgo-server.log file:

[2012-10-03 18:34:19.170] [ERROR] Thread-40

System.err

2012-10-03

18:34:19.167:WARN:oejuc.AbstractLifeCycle:FAILED org.eclipse.jetty.server.Server@315b0333:

java.net.BindException: Address already in use

[2012-10-03 18:34:19.170] [ERROR] Thread-40 System.err java.net.BindException: Address already

in use

Cause

Another program or process is using port 9443, the default port used by the HTML5 virtual machine

console.

Solution

uEdit the webclient.properties file to add the line html.console.port=port, where port is the new port

number.

The webclient.properties file is located in one of the following locations, depending on the operating

system on the machine on which the vSphere Web Client is installed:

Windows 2008 C:\ProgramData\VMware\vCenterServer\cfg\vsphere-client\

vCenter Server Appliance /var/lib/vmware/vsphere-client/

Unable to View the Alarm Definitions Tab of a Data Center

You might be unable to view the alarm definitions for a data center object in the vSphere Web Client.

Problem

When you click the Alarm Definitions tab on the Manage tab of a data center, the tab appears darkened by

a translucent overlay and no error message appears.

Cause

Inability to view the alarm definitions might be caused by insufficient memory. Problems that occur on the

vCenter Server side should result in an error message, but lack of available memory for Adobe Flash Player

on the client machine prevents the error notification dialog from appearing.

Solution

uVerify that your vCenter Server and vSphere Web Client instances are not constrained by insufficient

system resources.

For hardware requirements, see vSphere Installation and Setup.

Chapter 4 Troubleshooting vCenter Server and the vSphere Web Client

VMware, Inc. 39

Troubleshooting vCenter Server and ESXi Host Certificates

Certificates are automatically generated when you install vCenter Server. These default certificates are not

signed by a commercial certificate authority (CA) and might not provide strong security. You can replace

default vCenter Server certificates with certificates signed by a commercial CA. When you replace vCenter

Server and ESXi certificates, you might encounter errors.

vCenter Server Cannot Connect to the Database

After you replace default vCenter Server certificates, you might be unable to connect to the vCenter Server

database.

Problem

vCenter Server is unable to connect to the vCenter Server database after you replace default vCenter Server

certificates, and management web services do not start.

Cause

The database password must be updated in its encrypted form.

Solution

Update the database password by running the following command: vpxd -P pwd.

vCenter Server Cannot Connect to Managed Hosts

After you replace default vCenter Server certificates and restart the system, vCenter Server might not be

able to connect to managed hosts.

Problem

vCenter Server cannot connect to managed hosts after server certificates are replaced and the system is

restarted.

Solution

Log into the host as the root user and reconnect the host to vCenter Server.

New vCenter Server Certificate Does Not Appear to Load

After you replace default vCenter Server certificates, the new certificates might not appear to load.

Problem

When you install new vCenter Server certificates, you might not see the new certificate.

Cause

Existing open connections to vCenter Server are not forcibly closed and might still use the old certificate.

Solution

To force all connections to use the new certificate, use one of the following methods.

nRestart the network stack or network interfaces on the server.

nRestart the vCenter Server service.

vSphere Troubleshooting

40 VMware, Inc.

Cannot Configure vSphere HA When Using Custom SSL Certificates

After you install custom SSL certificates, attempts to enable vSphere High Availability (HA) fail.

Problem

When you attempt to enable vSphere HA on a host with custom SSL certificates installed, the following

error message appears: vSphere HA cannot be configured on this host because its SSL thumbprint has

not been verified.

Cause

When you add a host to vCenter Server, and vCenter Server already trusts the host's SSL certificate,

VPX_HOST.EXPECTED_SSL_THUMBPRINT is not populated in the vCenter Server database. vSphere HA obtains

the host's SSL thumbprint from this field in the database. Without the thumbprint, you cannot enable

vSphere HA.

Solution

1 In the vSphere Web Client, disconnect the host that has custom SSL certificates installed.

2 Reconnect the host to vCenter Server.

3 Accept the host's SSL certificate.

4 Enable vSphere HA on the host.

Troubleshooting vCenter Server Plug-Ins

In cases where vCenter Server plug-ins are not working, you have several options to correct the problem.

vCenter Server plug-ins that run on the Tomcat server have extension.xml files, which contain the URL

where the corresponding Web application can be accessed. These files are located in C:\Program

Files\VMware\Infrastructure\VirtualCenter Server\extensions. Extension installers populate these XML

files using the DNS name for the machine.

Example from the stats extension.xml file: <url>https://SPULOV-XP-VM12.vmware.com:

8443/statsreport/vicr.do</url>.

vCenter Server, plug-in servers, and the clients that use them must be located on systems under the same

domain. If they are not under the same domain, or if the DNS of the plug-in server is changed, the plug-in

clients will not be able to access the URL, and the plug-in will not work.

You can edit the XML files manually by replacing the DNS name with an IP address. Reregister the plug-in

after you edit its extension.xml file.

Chapter 4 Troubleshooting vCenter Server and the vSphere Web Client

VMware, Inc. 41

vSphere Troubleshooting

42 VMware, Inc.

Troubleshooting Availability 5

The availability troubleshooting topics provide solutions to potential problems that you might encounter

when using your hosts and datastores in vSphere HA clusters.

You might get an error message when you try to use vSphere HA or vSphere FT. For information about

these error messages, see the VMware knowledge base article at http://kb.vmware.com/kb/1033634.

This chapter includes the following topics:

n“Troubleshooting vSphere HA Admission Control,” on page 43

n“Troubleshooting Heartbeat Datastores,” on page 45

n“Troubleshooting vSphere HA Failure Response,” on page 46

n“Troubleshooting vSphere Fault Tolerance in Network Partitions,” on page 48

n“Troubleshooting VM Component Protection,” on page 49

Troubleshooting vSphere HA Admission Control

vCenter Server uses admission control to ensure that sufficient resources in a vSphere HA cluster are

reserved for virtual machine recovery in the event of host failure.

If vSphere HA admission control does not function properly, there is no assurance that all virtual machines

in the cluster can be restarted after a host failure.

Red Cluster Due to Insufficient Failover Resources

When you use the Host Failures Cluster Tolerates admission control policy, vSphere HA clusters might

become invalid (red) due to insufficient failover resources.

Problem

If you select the Host Failures Cluster Tolerates admission control policy and certain problems arise, the

cluster turns red.

Cause

This problem can arise when hosts in the cluster are disconnected, in maintenance mode, not responding, or

have a vSphere HA error. Disconnected and maintenance mode hosts are typically caused by user action.

Unresponsive or error-possessing hosts usually result from a more serious problem, for example, hosts or

agents have failed or a networking problem exists.

VMware, Inc. 43

Another possible cause of this problem is if your cluster contains any virtual machines that have much

larger memory or CPU reservations than the others. The Host Failures Cluster Tolerates admission control

policy is based on the calculation on a slot size consisting of two components, the CPU and memory

reservations of a virtual machine. If the calculation of this slot size is skewed by outlier virtual machines, the

admission control policy can become too restrictive and result in a red cluster. In this case, you can use the

vSphere HA advanced options to reduce the slot size, use a different admission control policy, or modify the

policy to tolerate fewer host failures.

Solution

Check that all hosts in the cluster are healthy, that is, connected, not in maintenance mode and free of

vSphere HA errors. vSphere HA admission control only considers resources from healthy hosts.

Unable to Power On Virtual Machine Due to Insufficient Failover Resources

You might get a not enough failover resources fault when trying to power on a virtual machine in a

vSphere HA cluster.

Problem

If you select the Host Failures Cluster Tolerates admission control policy and certain problems arise, you

might be prevented from powering on a virtual machine due to insufficient resources.

Cause

This problem can have several causes.

nHosts in the cluster are disconnected, in maintenance mode, not responding, or have a vSphere HA

error.

Disconnected and maintenance mode hosts are typically caused by user action. Unresponsive or error-

possessing hosts usually result from a more serious problem, for example, hosts or agents have failed or

a networking problem exists).

nCluster contains virtual machines that have much larger memory or CPU reservations than the others.

The Host Failures Cluster Tolerates admission control policy is based on the calculation on a slot size

comprised of two components, the CPU and memory reservations of a virtual machine. If the

calculation of this slot size is skewed by outlier virtual machines, the admission control policy can

become too restrictive and result in the inability to power on virtual machines.

nNo free slots in the cluster.

Problems occur if there are no free slots in the cluster or if powering on a virtual machine causes the slot

size to increase because it has a larger reservation than existing virtual machines. In either case, you

should use the vSphere HA advanced options to reduce the slot size, use a different admission control

policy, or modify the policy to tolerate fewer host failures.

Solution

View the Advanced Runtime Info pane that appears in the vSphere HA section of the cluster's Monitor tab

in the vSphere Web Client. This information pane shows the slot size and how many available slots there are

in the cluster. If the slot size appears too high, click on the Resource Allocation tab of the cluster and sort

the virtual machines by reservation to determine which have the largest CPU and memory reservations. If

there are outlier virtual machines with much higher reservations than the others, consider using a different

vSphere HA admission control policy (such as the Percentage of Cluster Resources Reserved admission

control policy) or use the vSphere HA advanced options to place an absolute cap on the slot size. Both of

these options, however, increase the risk of resource fragmentation.

vSphere Troubleshooting

44 VMware, Inc.

Fewer Available Slots Shown Than Expected

The Advanced Runtime Info box might display a smaller number of available slots in the cluster than you

expect.

Problem

When you select the Host Failures Cluster Tolerates admission control policy, view the Advanced Runtime

Info pane that appears in the vSphere HA section of the cluster's Monitor tab in the vSphere Web Client.

This pane displays information about the cluster, including the number of slots available to power on

additional virtual machines in the cluster. This number might be smaller than expected under certain

conditions.

Cause

Slot size is calculated using the largest reservations plus the memory overhead of any powered on virtual

machines in the cluster. However, vSphere HA admission control considers only the resources on a host that

are available for virtual machines. This amount is less than the total amount of physical resources on the

host, because there is some overhead.

Solution

Reduce the virtual machine reservations if possible, use vSphere HA advanced options to reduce the slot

size, or use a different admission control policy.

Troubleshooting Heartbeat Datastores

When the master host in a vSphere HA cluster can no longer communicate with a slave host over the

management network, the master host uses datastore heartbeating to determine if the slave host might have

failed or is in a network partition. If the slave host has stopped datastore heartbeating, that host is

considered to have failed and its virtual machines are restarted elsewhere.

vCenter Server automatically selects a preferred set of datastores for heartbeating. This selection is made

with the goal of maximizing the number of hosts that have access to a given datastore and minimizing the

likelihood that the selected datastores are backed by the same storage array or NFS server. In most cases,

this selection should not be changed. To see which datastores vSphere HA has selected for use, in the

vSphere Web Client you can go to the cluster's Monitor tab and select vSphere HA and Heartbeat. Only

datastores mounted by at least two hosts are available here.

NOTE There is no heartbeat datastore available if the only shared storage accessible to all hosts in the cluster

is Virtual SAN.

User-Preferred Datastore is Not Chosen

vCenter Server might not choose a datastore that you specify as a preference for vSphere HA storage

heartbeating.

Problem

You can specify the datastores preferred for storage heartbeating, and based on this preference, vCenter

Server determines the final set of datastores to use. However, vCenter Server might not choose the

datastores that you specify.

Cause

This problem can occur in the following cases:

nThe specified number of datastores is more than is required. vCenter Server chooses the optimal

number of required datastores out of the stated user preference and ignores the rest.

Chapter 5 Troubleshooting Availability

VMware, Inc. 45

nA specified datastore is not optimal for host accessibility and storage backing redundancy. More

specifically, the datastore might not be chosen if it is accessible to only a small set of hosts in the cluster.

A datastore also might not be chosen if it is on the same LUN or the same NFS server as datastores that

vCenter Server has already chosen.

nA specified datastore is inaccessible because of storage failures, for example, storage array all paths

down (APD) or permanent device loss (PDL).

nIf the cluster contains a network partition, or if a host is unreachable or isolated, the host continues to

use the existing heartbeat datastores even if the user preferences change.

Solution

Verify that all the hosts in the cluster are reachable and have the vSphere HA agent running. Also, ensure

that the specified datastores are accessible to most, if not all, hosts in the cluster and that the datastores are

on different LUNs or NFS servers.

Unmounting or Removing Datastore Fails

When you try to unmount or remove a datastore, the operation fails.

Problem

The operation to unmount or remove a datastore fails if the datastore has any opened files. For these user

operations, the vSphere HA agent closes all of the files that it has opened, for example, heartbeat files. If the

agent is not reachable by vCenter Server or the agent cannot flush out pending I/Os to close the files, a The

HA agent on host '{hostName}' failed to quiesce file activity on datastore '{dsName} fault is

triggered.

Cause

If the datastore to be unmounted or removed is used for heartbeating, vCenter Server excludes it from

heartbeating and chooses a new one. However, the agent does not receive the updated heartbeat datastores

if it is not reachable, that is, if the host is isolated or in a network partition. In such cases, heartbeat files are

not closed and the user operation fails. The operation can also fail if the datastore is not accessible because of

storage failures such as all paths down.

NOTE When you remove a VMFS datastore, the datastore is removed from all the hosts in inventory. So if

there are any hosts in a vSphere HA cluster that are unreachable or that cannot access the datastore, the

operation fails.

Solution

Ensure that the datastore is accessible and the affected hosts are reachable.

Troubleshooting vSphere HA Failure Response

vSphere HA provides high availability for virtual machines by pooling them and the hosts that they reside

on into a cluster. Hosts in the cluster are monitored and in the event of a failure, the virtual machines on a

failed host are restarted on alternate hosts.

There are various reasons why affected virtual machines might not be restarted and if this happens you

should troubleshoot to determine the cause.

vSphere Troubleshooting

46 VMware, Inc.

Incorrect Virtual Machine Protection State

A virtual machine in a vSphere HA cluster is reported as vSphere HA unprotected although it has been

powered on for several minutes.

Problem

When a virtual machine is powered on for several minutes, yet its vSphere HA protection state remains as

unprotected, if a failure occurs, vSphere HA might not attempt to restart the virtual machine.

Cause

vCenter Server reports a virtual machine as protected after the vSphere HA master host that is responsible

for the virtual machine has saved to disk the information that the virtual machine must be restarted after a

failure. This process can fail for a number of reasons.

nvSphere HA master host has not been elected or vCenter Server is unable to communicate with it.

In this situation, vCenter Server reports the vSphere HA host state for the cluster hosts as Agent

Unreachable or Agent Uninitialized and reports a cluster configuration problem that a master host has

not been found.

nMultiple master hosts exist and the one with which vCenter Server is communicating is not responsible

for the virtual machine.

Problems occur when vCenter Server is in contact with a master host, but due to a management

network partition, there are multiple master hosts, and the agent with which vCenter Server is

communicating is not responsible for the virtual machine. This situation is likely if vCenter Server is

reporting the vSphere HA state of some hosts as network partitioned.

nAgent is unable to access the datastore on which the configuration file of the virtual machine is stored.

vCenter Server might be in contact with the vSphere HA master host that owns the virtual machine, but

the agent is unable to access the datastore on which the configuration file of the virtual machine is

stored. This situation can occur if an all paths down condition affects all hosts in the cluster.

Solution

1 Determine whether vCenter Server is in contact with a vSphere HA master host, and if not, address this

problem.

2 If vCenter Server is in contact with a master host, determine whether there is a network partition, and if

so, address that problem.

3 If the problem persists, determine if other virtual machines that use the same datastore for their

configuration files are also unprotected.

4 If these virtual machines are unprotected, verify that the vSphere HA master host can access the

datastore.

5 If none of the previous steps resolves the problem, restore protection by reconfiguring vSphere HA on

the host on which the virtual machine is running.

Virtual Machine Restart Fails

After a host or virtual machine failure, a virtual machine might not be restarted.

Problem

When a host fails or a virtual machine fails while its host continues running, the virtual machine might not

restart or restarts only after a long delay.

Chapter 5 Troubleshooting Availability

VMware, Inc. 47

Cause

vSphere HA might not restart a virtual machine after a failure or might delay its restart for several reasons.

nVirtual machine is not protected by vSphere HA at the time the failure occurred

nInsufficient spare capacity on hosts with which the virtual machine is compatible

nvSphere HA attempted to restart the virtual machine but encountered a fatal error each time it tried.

nYour cluster's shared storage is Virtual SAN and one of the virtual machine's files has become

inaccessible due to the occurrence of more than the specified number of host failures.

nRestart actually succeeded.

Solution

To avoid virtual machine restart failures, check that virtual machines become protected by vSphere HA after

they are powered on. Also, ensure that your admission control settings match your restart expectations if a

failure occurs. Maximizing the compatibility between virtual machines and hosts in the cluster can also

reduce the likelihood of restart failures.

NOTE For information on the factors vSphere HA considers for virtual machine restarts, see "Determining

Responses to Host Issues" in vSphere Availability.

Troubleshooting vSphere Fault Tolerance in Network Partitions

When a vSphere HA cluster experiences a failure of the network that vSphere uses for inter-agent

communication (the management network), a subset of the cluster's hosts might be unable to communicate

with other cluster hosts. In this case, the set of hosts that can communicate with each other are considered to

be in a network partition.

A cluster partition impedes cluster management functions such as vMotion and can impact vSphere HA’s

ability to monitor and restart virtual machines after a failure. This condition must be corrected as soon as

possible.

Network partitions also degrade the functionality of vSphere Fault Tolerance. For example, in a partitioned

cluster, a Primary VM (or its Secondary VM) could end up in a partition managed by a master host that is

not responsible for the virtual machine. When a Secondary VM must be restarted, vSphere HA does so only

if the Primary VM is in a partition managed by the master host responsible for it. Ultimately, you must

correct the network partition, but until that is possible, you must troubleshoot and correct any problems that

arise with your fault-tolerant virtual machines to ensure that they are properly protected.

Primary VM Remains in the Need Secondary State

A fault tolerant Primary VM can remain in the need secondary state even though sufficient resources are

available to start the Secondary VM.

Problem

vSphere HA might not restart the Secondary VM of a vSphere Fault Tolerance (FT) virtual machine pair

even though there are sufficient resources available.

Cause

To restart a Secondary VM, vSphere HA requires that the Primary VM be running on a host that is in the

same partition as the one containing the vSphere HA master host responsible for the FT pair. In addition,

the vSphere HA agent on the Primary VM’s host must be operating correctly. If these conditions are met, FT

also requires that there be at least one other host in the same partition that is compatible with the FT pair

and that has a functioning vSphere HA agent.

vSphere Troubleshooting

48 VMware, Inc.

Solution

To fix this condition, check the vSphere HA host states reported by vCenter Server. If hosts are identified as

partitioned, isolated, or unreachable, resolve the problem before proceeding. In some situations, you can

resolve a restart problem by reconfiguring vSphere HA on the host that vCenter Server is reporting as the

master host. However, in most situations, this step is insufficient, and you must resolve all host state

problems.

After you have addressed any host state problems, check if there are any hosts in the cluster other than the

Primary VM's that are compatible with the FT virtual machine pair. You can determine compatibility by

trying to migrate the Primary VM to other hosts. Address any incompatibilities that are discovered.

Role Switch Behavior Problems

vCenter Server can report that the Primary VM of a vSphere Fault Tolerance virtual machine pair is

powered off, but the Secondary VM is powered on.

Problem

After a failover occurs, vCenter Server might incorrectly report that the Primary VM is powered off and

registered to its original host, and that the Secondary VM is powered on and registered to its original host.

Cause

This error occurs when vCenter Server is unable to communicate with the hosts on which the Primary VM

and Secondary VM are actually running. vCenter Server reports these hosts as not responding and the

problem persists until vCenter Server is able to communicate with the hosts.

Solution

To fix this problem, resolve the networking problem that is preventing vCenter Server from communicating

with the hosts in the cluster.

Troubleshooting VM Component Protection

If you enable VM Component Protection (VMCP) for your vSphere HA cluster it provides protection against

datastore accessibility failures that can affect a virtual machine running on one of the cluster's hosts.

If the response that you have configured VMCP to make for such a failure is not executed, you should

troubleshoot to determine the cause.

VM with a Swapfile on a Local Datastore is Not Protected

VMCP might not be able to find a compatible host for a virtual machine if its swapfile is on a local datastore.

Problem

If a virtual machine has its swapfile configured to be on a host-local datastore rather than in the default

directory where the VM's configuration file resides, VMCP might not restart the VM on a healthy host if it is

affected by an All Paths Down (APD) datastore accessibility failure.

Cause

VMCP monitors the list of datastores that a virtual machine depends on, including the datastores where the

VM's configuration file, swapfile and disks reside. When an APD failure is detected on a dependent

datastore, VMCP first determines if there is another host which is compatible and has sufficient capacity to

failover the affected VM to. To determine this compatibility, VMCP considers the dependent datastores

along with other factors such as CPU and memory reservations. If a suitable host is found, VMCP

terminates the VM on the host that experienced the APD failure.

Chapter 5 Troubleshooting Availability

VMware, Inc. 49

However, if a VM's swapfile is on a host-local datastore, such a datastore might not be configured on other

hosts in the cluster. This situation prevents VMCP from finding a compatible host to fail over the VM, and

the VM continues running on the host which experienced an APD failure.

Solution

uKeep the VM swap file in the default directory, or ensure that the host-local datastore that the VM's

swapfile resides on is shared among a set of hosts.

Datastore Inaccessibility Is Not Resolved for a VM

When a datastore becomes inaccessible, VMCP might not terminate and restart the affected virtual

machines.

Problem

When an All Paths Down (APD) or Permanent Device Loss (PDL) failure occurs and a datastore becomes

inaccessible, VMCP might not resolve the issue for the affected virtual machines.

Cause

In an APD or PDL failure situation, VMCP might not terminate a virtual machine for the following reasons:

nVM is not protected by vSphere HA at the time of failure.

nVMCP is disabled for this virtual machine.

Furthermore, if the failure is an APD, VMCP might not terminate a VM for several reasons:

nAPD failure is corrected before the VM was terminated.

nInsufficient capacity on hosts with which the virtual machine is compatible

nDuring a network partition or isolation, the host affected by the APD failure is not able to query the

master host for available capacity. In such a case, vSphere HA defers to the user policy and terminates

the VM if the VM Component Protection setting is aggressive.

nvSphere HA terminates APD-affected VMs only after the following timeouts expire:

nAPD timeout (default 140 seconds).

nAPD failover delay (default 180 seconds). For faster recovery, this can be set to 0.

NOTE Based on these default values, vSphere HA terminates the affected virtual machine after 320

seconds (APD timeout + APD failover delay)

Solution

To address this issue, check and adjust any of the following:

nInsufficient capacity to restart the virtual machine

nUser-configured timeouts and delays

nUser settings affecting VM termination

nVM Component Protection policy

nHost monitoring or VM restart priority must be enabled

vSphere Troubleshooting

50 VMware, Inc.

Troubleshooting Resource

Management 6

The resource management troubleshooting topics provide solutions to potential problems that you might

encounter when using your hosts and datastores in vSphere DRS or vSphere Storage DRS cluster.

This chapter includes the following topics:

n“Troubleshooting Storage DRS,” on page 51

n“Troubleshooting Storage I/O Control,” on page 56

Troubleshooting Storage DRS

The Storage DRS troubleshooting topics provide solutions to potential problems that you might encounter

when using Storage DRS-enabled datastores in a datastore cluster.

Storage DRS is Disabled on a Virtual Disk

Even when Storage DRS is enabled for a datastore cluster, it might be disabled on some virtual disks in the

datastore cluster.

Problem

You have enabled Storage DRS for a datastore cluster, but Storage DRS is disabled on one or more virtual

machine disks in the datastore cluster.

Cause

The following scenarios can cause Storage DRS to be disabled on a virtual disk.

nA virtual machine's swap file is host-local (the swap file is stored in a specified datastore that is on the

host). The swap file cannot be relocated and Storage DRS is disabled for the swap file disk.

nA certain location is specified for a virtual machine's .vmx swap file. The swap file cannot be relocated

and Storage DRS is disabled on the .vmx swap file disk.

nThe relocate or Storage vMotion operation is currently disabled for the virtual machine in vCenter

Server (for example, because other vCenter Server operations are in progress on the virtual machine).

Storage DRS is disabled until the relocate or Storage vMotion operation is re-enabled in vCenter Server.

nThe home disk of a virtual machine is protected by vSphere HA and relocating it will cause loss of

vSphere HA protection.

nThe disk is a CD-ROM/ISO file.

nIf the disk is an independent disk, Storage DRS is disabled, except in the case of relocation or clone

placement.

VMware, Inc. 51

nIf the virtual machine has system files on a separate datastore from the home datastore (legacy), Storage

DRS is disabled on the home disk. If you use Storage vMotion to manually migrate the home disk, the

system files on different datastores will be all be located on the target datastore and Storage DRS will be

enabled on the home disk.

nIf the virtual machine has a disk whose base/redo files are spread across separate datastores (legacy),

Storage DRS for the disk is disabled. If you use Storage vMotion to manually migrate the disk, the files

on different datastores will be all be located on the target datastore and Storage DRS will be enabled on

the disk.

nThe virtual machine has hidden disks (such as disks in previous snapshots, not in the current snapshot).

This situation causes Storage DRS to be disabled on the virtual machine.

nThe virtual machine is a template.

nThe virtual machine is vSphere Fault Tolerance-enabled.

nThe virtual machine is sharing files between its disks.

nThe virtual machine is being Storage DRS-placed with manually specified datastores.

Solution

Address the problem that is causing Storage DRS to be disabled on the disk.

Datastore Cannot Enter Maintenance Mode

You place a datastore in maintenance mode when you must take it out of usage to service it. A datastore

enters or leaves maintenance mode only as a result of a user request.

Problem

A datastore in a datastore cluster cannot enter maintenance mode. The Entering Maintenance Mode status

remains at 1%.

Cause

One or more disks on the datastore cannot be migrated with Storage vMotion. This condition can occur in

the following instances.

nStorage DRS is disabled on the disk.

nStorage DRS rules prevent Storage DRS from making migration recommendations for the disk.

Solution

nIf Storage DRS is disabled, enable it or determine why it is disabled. See “Storage DRS is Disabled on a

Virtual Disk,” on page 51 for reasons why Storage DRS might be disabled.

nIf Storage DRS rules are preventing Storage DRS from making migration recommendations, you can

remove or disable particular rules.

a Browse to the datastore cluster in the vSphere Web Client object navigator.

b Click the Manage tab and click Settings.

c Under Configuration, select Rules and click the rule.

d Click Remove.

vSphere Troubleshooting

52 VMware, Inc.

nAlternatively, if Storage DRS rules are preventing Storage DRS from making migration

recommendations, you can set the Storage DRS advanced option IgnoreAffinityRulesForMaintenance to

1.

a Browse to the datastore cluster in the vSphere Web Client object navigator.

b Click the Manage tab and click Settings.

c Select SDRS and click Edit.

d In Advanced Options > Configuration Parameters, click Add.

e In the Option column, enter IgnoreAffinityRulesForMaintenance.

f In the Value column, enter 1 to enable the option.

g Click OK.

Storage DRS Cannot Operate on a Datastore

Storage DRS generates an alarm to indicate that it cannot operate on the datastore.

Problem

Storage DRS generates an event and an alarm and Storage DRS cannot operate.

Cause

The following scenarios can cause vCenter Server to disable Storage DRS for a datastore.

nThe datastore is shared across multiple data centers.

Storage DRS is not supported on datastores that are shared across multiple data centers. This

configuration can occur when a host in one data center mounts a datastore in another data center, or

when a host using the datastore is moved to a different data center. When a datastore is shared across

multiple data centers, Storage DRS I/O load balancing is disabled for the entire datastore cluster.

However, Storage DRS space balancing remains active for all datastores in the datastore cluster that are

not shared across data centers.

nThe datastore is connected to an unsupported host.

Storage DRS is not supported on ESX/ESXi 4.1 and earlier hosts.

nThe datastore is connected to a host that is not running Storage I/O Control.

Solution

nThe datastore must be visible in only one data center. Move the hosts to the same data center or

unmount the datastore from hosts that reside in other data centers.

nEnsure that all hosts associated with the datastore cluster are ESXi 5.0 or later.

nEnsure that all hosts associated with the datastore cluster have Storage I/O Control enabled.

Moving Multiple Virtual Machines into a Datastore Cluster Fails

Migrating more than one datastore into a datastore cluster fails with an error message after the first virtual

machine has successfully moved into the datastore cluster.

Problem

When you attempt to migrate multiple virtual machines into a datastore cluster, some virtual machines

migrate successfully, but migration of subsequent virtual machines fails. vCenter Server displays the error

message, Insufficient Disk Space on Datastore.

Chapter 6 Troubleshooting Resource Management

VMware, Inc. 53

Cause

Until each placement recommendation is applied, the space resources appear to be available to Storage DRS.

Therefore, Storage DRS might reallocate space resources to subsequent requests for space.

Solution

Retry the failed migration operations one at a time and ensure that each recommendation is applied before

requesting the next migration

Storage DRS Generates Fault During Virtual Machine Creation

When you create or clone a virtual machine on a datastore cluster, Storage DRS might generate a fault.

Problem

When you attempt to create or clone a virtual machine on a datastore cluster, you might receive the error

message, Operation Not Allowed in the Current State.

Cause

Storage DRS checks for rule violations when you create a virtual machine on a Storage DRS-enabled

datastore. If Storage DRS cannot create the new virtual machine's disks in compliance with the rules, it

generates a fault. The fault is generated because Storage DRS cannot reference the virtual machine, which is

in the process of being created and does not yet exist.

Solution

Revise or remove the rules and retry the create or clone virtual machine operation.

Storage DRS is Enabled on a Virtual Machine Deployed from an OVF Template

Storage DRS is enabled on a virtual machine that was deployed from an OVF template that has Storage DRS

disabled. This can occur when you deploy an OVF template on a datastore cluster.

Problem

When you deploy an OVF template with Storage DRS disabled on a datastore cluster, the resulting virtual

machine has Storage DRS enabled.

Cause

The vSphere Web Client applies the default automation level of the datastore cluster to virtual machines

deployed from an OVF template.

Solution

1 To manually change the automation level of the virtual machine, browse to the datastore cluster in the

vSphere Web Client object navigator.

2 Click the Manage tab and select Settings.

3 Select VM Overrides and click Add.

4 Select the virtual machine and click OK.

5 From the Keep VMDKs Together dropdown menu, select No and click OK.

vSphere Troubleshooting

54 VMware, Inc.

Storage DRS Rule Violation Fault Is Displayed Multiple Times

When you attempt to put a datastore into maintenance mode, the same affinity or anti-affinity rule violation

fault might appear to be listed more than once in the Faults dialog box.

Problem

The Faults dialog box appears to display multiple instances of identical faults, but in fact, each fault refers to

a different datastore. The Faults dialog box does not list the names of the datastores, which causes the faults

to appear to be redundant.

Solution

The Faults dialog box always displays a separate rule violation fault for each datastore that is considered for

placement. If you want the datastore to enter maintenance mode, remove the rule that prevents the virtual

machine from being migrated.

Storage DRS Rules Not Deleted from Datastore Cluster

Affinity or anti-affinity rules that apply to a virtual machine are not deleted when you remove the virtual

machine from a datastore cluster.

Problem

When you remove a virtual machine from a datastore cluster, and that virtual machine is subject to an

affinity or anti-affinity rule in a datastore cluster, the rule remains. This allows you to store virtual machine

configurations in different datastore clusters. If the virtual machine is moved back into the datastore cluster,

the rule is applied. You cannot delete the rule after you remove the virtual machine from the datastore

cluster.

Cause

vCenter Server retains rules for a virtual machine that is removed from a datastore cluster if the virtual

machine remains in the vCenter Server inventory.

Solution

To remove a rule from a datastore cluster configuration, you must delete the rule before you remove the

virtual machine to which the rule applies from the datastore cluster.

1 In the vSphere Web Client, browse to the datastore cluster.

2 Click the Manage tab and select Settings.

3 Under Configuration, click Rules.

4 Select the rule to delete and click Remove.

5 Click OK.

Alternative Storage DRS Placement Recommendations Are Not Generated

When you create, clone, or relocate a virtual machine, Storage DRS generates only one placement

recommendation.

Problem

Storage DRS generates a single placement recommendation when you create, clone, or relocate a virtual

machine. No alternative recommendations are provided when multiple alternative recommendations are

expected.

Chapter 6 Troubleshooting Resource Management

VMware, Inc. 55

Cause

If the destination host explicitly specifies the virtual machine's swap file location as a datastore in the target

datastore cluster, the disks to be placed in that cluster do not form a single affinity group. Storage DRS

generates alternative placement recommendations only for a single item or a single affinity group.

Solution

Accept the single recommendation. To obtain multiple recommendations, choose a destination host that

does not specify that the virtual machine swap file location is on a datastore that is in the target datastore

cluster.

Applying Storage DRS Recommendations Fails

Storage DRS generates space or I/O load balancing recommendations, but attempts to apply the

recommendations fail.

Problem

When you apply Storage DRS recommendations for space or I/O load balancing, the operation fails.

Cause

The following scenarios can prevent you from applying Storage DRS recommendations.

nA Thin Provisioning Threshold Crossed alarm might have been triggered for the target datastore, which

indicates that the datastore is running out of space and no virtual machines will be migrated to it.

nThe target datastore might be in maintenance mode or is entering maintenance mode.

Solution

nAddress the issue that triggered the Thin Provisioning Threshold Crossed alarm.

nVerify that the target datastore is not in maintenance mode or entering maintenance mode.

Troubleshooting Storage I/O Control

The Storage I/O Control troubleshooting topics provide solutions to potential problems that you might

encounter when using Storage I/O Control with datastores.

Unsupported Host Connected to Datastore

In the vSphere Web Client, an alarm is triggered when vCenter Server detects that a workload from a host

might be affecting performance.

Problem

The alarm Pre-4.1 host connected to SIOC-enabled datastore is triggered.

Cause

The datastore is Storage I/O Control-enabled, but it cannot be fully controlled by Storage I/O Control

because of the external workload.

This condition can occur if the Storage I/O Control-enabled datastore is connected to a host that does not

support Storage I/O Control.

Solution

Ensure that all hosts that are connected to the datastore support Storage I/O Control.

vSphere Troubleshooting

56 VMware, Inc.

Unmanaged Workload Detected on Datastore

In the vSphere Web Client, an alarm is triggered when vCenter Server detects that a workload from a host

might be affecting performance.

Problem

The alarm Unmanaged workload is detected on the datastore is triggered.

Cause

The array is shared with non-vSphere workloads, or the array is performing system tasks such as

replication.

Solution

There is no solution. vCenter Server does not reduce the total amount of I/O sent to the array, but continues

to enforce shares.

Unable to View Performance Charts for Datastore

Performance charts for a datastore do not appear on the Performance tab.

Problem

You are unable to view performance charts for a datastore on the Performance tab in the

vSphere Web Client.

Cause

Storage I/O Control is disabled for the datastore.

Solution

1 Browse to the datastore in the vSphere Web Client object navigator.

2 Right-click the datastore and select Configure Storage I/O Control.

3 Select the Enable Storage I/O Control check box.

4 Click OK.

Cannot Enable Storage I/O Control on Datastore

Storage I/O Control is disabled on a datastore and cannot be enabled.

Problem

You cannot enable Storage I/O Control on a datastore.

Cause

The following reasons might prevent you from enabling Storage I/O Control on a datastore.

nAt least one host that is connected to the datastore is not running ESX/ESXi 4.1 or later.

nYou do not have the appropriate license to enable Storage I/O Control.

Solution

nVerify that the hosts connected to the datastore are ESX/ESXi 4.1 or later.

nVerify that you have the appropriate license to enable Storage I/O Control.

Chapter 6 Troubleshooting Resource Management

VMware, Inc. 57

vSphere Troubleshooting

58 VMware, Inc.

Troubleshooting Storage 7

The storage troubleshooting topics provide solutions to potential problems that you might encounter when

using vSphere in different storage environments that include SAN, Virtual SAN, or Virtual Volumes.

This chapter includes the following topics:

n“Resolving SAN Storage Display Problems,” on page 60

n“Resolving SAN Performance Problems,” on page 61

n“Virtual Machines with RDMs Need to Ignore SCSI INQUIRY Cache,” on page 66

n“Software iSCSI Adapter Is Enabled When Not Needed,” on page 66

n“Failure to Mount NFS Datastores,” on page 67

n“VMkernel Log Files Contain SCSI Sense Codes,” on page 67

n“Troubleshooting Storage Adapters,” on page 68

n“Checking Metadata Consistency with VOMA,” on page 68

n“Troubleshooting Flash Devices,” on page 70

n“Troubleshooting Virtual Volumes,” on page 73

n“Troubleshooting VAIO Filters,” on page 75

VMware, Inc. 59

Resolving SAN Storage Display Problems

When you use the vSphere Web Client to display Fibre Channel SAN or iSCSI storage devices, you might

not be able to see all devices available to your host. A number of troubleshooting tasks exist that you can

perform to resolve storage display problems.

Resolving Fibre Channel Storage Display Problems

If Fibre Channel storage devices do not display correctly in the vSphere Web Client, perform

troubleshooting tasks.

Table 7‑1. Troubleshooting Fibre Channel LUN Display

Troubleshooting Task Description

Check cable connectivity. If you do not see a port, the problem could be cable connectivity. Check the cables first.

Ensure that cables are connected to the ports and a link light indicates that the

connection is good. If each end of the cable does not show a good link light, replace the

cable.

Check zoning. Zoning limits access to specific storage devices, increases security, and decreases traffic

over the network. Some storage vendors allow only single-initiator zones. In that case, an

HBA can be in multiple zones to only one target. Other vendors allow multiple-initiator

zones. See your storage vendor’s documentation for zoning requirements. Use the SAN

switch software to configure and manage zoning.

Check access control

configuration.

nThe MASK_PATH plug-in allows you to prevent your host from accessing a specific

storage array or specific LUNs on a storage array. If your host is detecting devices

and paths that you do not want the host to access, path masking could have been set

up incorrectly.

nFor booting from a SAN, ensure that each host sees only required LUNs. Do not

allow any host to see any boot LUN other than its own. Use storage system software

to make sure that the host can see only the LUNs that it is supposed to see.

nEnsure that the Disk.MaxLUN parameter allows you to view the LUN you expect to

see. For information on the parameter, see the vSphere Storage documentation.

Check storage processor

setup.

If a disk array has more than one storage processor (SP), make sure that the SAN switch

has a connection to the SP that owns the LUNs you want to access. On some disk arrays,

only one SP is active and the other SP is passive until there is a failure. If you are

connected to the wrong SP (the one with the passive path), you might see the LUNs but

get errors when trying to access them.

Rescan your HBA. Perform a rescan each time you complete the following tasks:

nCreate new LUNs on a SAN.

nChange the path masking configuration on the host.

nReconnect a cable.

nMake a change to a host in a cluster.

For information, see the vSphere Storage documentation.

vSphere Troubleshooting

60 VMware, Inc.

Resolving iSCSI Storage Display Problems

Perform troubleshooting tasks if iSCSI storage devices do not display correctly in the vSphere Web Client.

Table 7‑2. Troubleshooting iSCSI LUN Display

Troubleshooting Task Description

Check cable connectivity. If you do not see a port, the problem could be cable connectivity or routing. Check the

cables first. Ensure that cables are connected to the ports and a link light indicates that

the connection is good. If each end of the cable does not show a good link light, replace

the cable.

Check routing settings. Controls connectivity between different subnets on your Ethernet configuration. If your

ESXi system and iSCSI storage are not on the same subnet, ensure that appropriate

routing exists between the subnets. Also, ensure that the subnet mask and gateway

address are set correctly on the iSCSI storage and the iSCSI initiator in the ESXi host.

Check access control

configuration.

If the expected LUNs do not appear after rescan, access control might not be configured

correctly on the storage system side:

nIf CHAP is configured, ensure that it is enabled on the ESXi host and matches the

storage system setup.

nIf IP-based filtering is used, ensure that the iSCSI HBA or the VMkernel port group

IP address is allowed.

nIf you are using initiator name-based filtering, ensure that the name is a qualified

iSCSI name and matches the storage system setup.

nFor booting from a SAN, ensure that each host sees only required LUNs. Do not

allow any host to see any boot LUN other than its own. Use storage system software

to make sure that the host can see only the LUNs that it is supposed to see.

nEnsure that theDisk.MaxLUN setting allows you to view the LUN you expect to see.

For information, see the vSphere Storage documentation.

Check storage processor

setup.

If a storage system has more than one storage processor, make sure that the SAN switch

has a connection to the SP that owns the LUNs you want to access. On some storage

systems, only one SP is active and the other SP is passive until a failure occurs. If you are

connected to the wrong SP (the one with the passive path) you might not see the

expected LUNs, or you might see the LUNs but get errors when trying to access them.

For software and dependent

hardware iSCSI, check

network configuration.

The software iSCSI and dependent hardware adapters in ESXi require that VMkernel

network port have access to the iSCSI storage. The adapters use the VMkernel for data

transfer between the ESXi system and the iSCSI storage.

Rescan your iSCSI initiator. Perform a rescan each time you complete the following tasks:

nCreate new LUNs on a SAN.

nChange the LUN masking.

nReconnect a cable.

nMake a change to a host in a cluster.

nChange CHAP settings or add new discovery addresses.

For information, see the vSphere Storage documentation.

Resolving SAN Performance Problems

A number of factors can negatively affect storage performance in the ESXi SAN environment. Among these

factors are excessive SCSI reservations, path thrashing, and inadequate LUN queue depth.

To monitor storage performance in real time, use the resxtop and esxtop command-line utilities. For more

information, see the vSphere Monitoring and Performance documentation.

Chapter 7 Troubleshooting Storage

VMware, Inc. 61

Excessive SCSI Reservations Cause Slow Host Performance

Operations that require getting a file lock or a metadata lock in VMFS result in short-lived SCSI reservations.

SCSI reservations lock an entire LUN. Excessive SCSI reservations by a host can cause performance

degradation on other servers accessing the same VMFS.

Problem

Excessive SCSI reservations cause performance degradation and SCSI reservation conflicts.

Cause

Several operations require VMFS to use SCSI reservations.

nCreating, resignaturing, or expanding a VMFS datastore

nPowering on a virtual machine

nCreating or deleting a file

nCreating a template

nDeploying a virtual machine from a template

nCreating a new virtual machine

nMigrating a virtual machine with VMotion

nGrowing a file, such as a thin provisioned virtual disk

NOTE ESXi hosts use the SCSI reservations mechanism only when storage devices do not support the

hardware acceleration. For storage devices that support the hardware acceleration, the hosts use the atomic

test and set (ATS) algorithm to lock the LUN. For more information on hardware acceleration, see the

vSphere Storage documentation.

Solution

To eliminate potential sources of SCSI reservation conflicts, follow these guidelines:

nSerialize the operations of the shared LUNs, if possible, limit the number of operations on different

hosts that require SCSI reservation at the same time.

nIncrease the number of LUNs and limit the number of hosts accessing the same LUN.

nReduce the number snapshots. Snapshots cause numerous SCSI reservations.

nReduce the number of virtual machines per LUN. Follow recommendations in Configuration Maximums.

nMake sure that you have the latest HBA firmware across all hosts.

nMake sure that the host has the latest BIOS.

nEnsure a correct Host Mode setting on the SAN array.

For information about handling SCSI reservation conflicts on specific storage arrays, see the VMware

knowledge base article at http://kb.vmware.com/kb/1005009.

vSphere Troubleshooting

62 VMware, Inc.

Path Thrashing Causes Slow LUN Access

If your ESXi host is unable to access a LUN, or access is very slow, you might have a problem with path

thrashing, also called LUN thrashing.

Problem

Your host is unable to access a LUN, or access is very slow. The host's log files might indicate frequent path

state changes. For example:

Frequent path state changes are occurring for path vmhba2:C0:T0:L3. This may indicate a storage

problem. Affected device: naa.600600000000000000edd1. Affected datastores: ds1

Cause

The problem might be caused by path thrashing. Path thrashing might occur when two hosts access the

same LUN through different storage processors (SPs) and, as a result, the LUN is never available.

Path thrashing typically occurs on active-passive arrays. Path thrashing can also occur on a directly

connected array with HBA failover on one or more nodes. Active-active arrays or arrays that provide

transparent failover do not cause path thrashing.

Solution

1 Ensure that all hosts that share the same set of LUNs on the active-passive arrays use the same storage

processor.

2 Correct any cabling or masking inconsistencies between different hosts and SAN targets so that all

HBAs see the same targets.

3 Ensure that the claim rules defined on all hosts that share the LUNs are exactly the same.

4 Configure the path to use the Most Recently Used PSP, which is the default.

Increased Latency for I/O Requests Slows Virtual Machine Performance

If the ESXi host generates more commands to a LUN than the LUN queue depth permits, the excess

commands are queued in VMkernel. This increases the latency, or the time taken to complete I/O requests.

Problem

The host takes longer to complete I/O requests and virtual machines display unsatisfactory performance.

Cause

The problem might be caused by an inadequate LUN queue depth. SCSI device drivers have a configurable

parameter called the LUN queue depth that determines how many commands to a given LUN can be active

at one time. If the host generates more commands to a LUN, the excess commands are queued in the

VMkernel.

Solution

1 If the sum of active commands from all virtual machines consistently exceeds the LUN depth, increase

the queue depth.

The procedure that you use to increase the queue depth depends on the type of storage adapter the host

uses.

2 When multiple virtual machines are active on a LUN, change the Disk.SchedNumReqOutstanding

(DSNRO) parameter, so that it matches the queue depth value.

Chapter 7 Troubleshooting Storage

VMware, Inc. 63

Adjust Queue Depth for QLogic, Emulex, and Brocade HBAs

If you are not satisfied with the performance of your hardware bus adapters (HBAs), change the maximum

queue depth on your ESXi host.

The maximum value refers to the queue depths reported for various paths to the LUN. When you lower this

value, it throttles the host's throughput and alleviates SAN contention concerns if multiple hosts are

overutilizing the storage and are filling its command queue.

To adjust the maximum queue depth parameter, use the vCLI commands.

In the procedure, --server=server_name specifies the target server. The specified target server prompts you

for a user name and password. Other connection options, such as a configuration file or session file, are

supported. For a list of connection options, see Getting Started with vSphere Command-Line Interfaces.

Prerequisites

Install vCLI or deploy the vSphere Management Assistant (vMA) virtual machine. See Getting Started with

vSphere Command-Line Interfaces. For troubleshooting, run esxcli commands in the ESXi Shell.

Procedure

1 Verify which HBA module is currently loaded by entering the following command:

esxcli --server=server_name system module list | grep module

Use one the following options for module.

Option Description

qla QLogic

qln QLogic native drivers

lpfc Emulex

bfa Brocade

2 Adjust the queue depth for the appropriate module.

esxcli --server=server_name system module parameters set -p parameter=value -m module

Use the following strings for the parameter and module options.

String Description

-p ql2xmaxqdepth=value

-m qla2xxx

QLogic

-p ql2xmaxqdepth=value

-m qlnativefc

QLogic native drivers

-p lpfc0_lun_queue_depth=value

-m lpfc820

Emulex

-p lpfc0_lun_queue_depth=value

-m lpfc

Emulex native drivers

-p bfa_lun_queue_depth=value

-m bfa

Brocade

3 Reboot your host.

4 Verify your changes by running the following command:

esxcli --server=server_name system module parameters list -m=module.

module is an appropriate driver, such as qlnativefc or bfa.

vSphere Troubleshooting

64 VMware, Inc.

Adjust Maximum Queue Depth for Software iSCSI

If you notice unsatisfactory performance for your software iSCSI LUNs, change their maximum queue

depth by running the esxcli commands.

Prerequisites

nInstall vCLI or deploy the vSphere Management Assistant (vMA) virtual machine. See Getting Started

with vSphere Command-Line Interfaces. For troubleshooting, you can run esxcli commands in the ESXi

Shell.

nIn the procedure, the --server=server_name connection option specifies the target server. Be prepared to

enter a user name and password when the target server prompts you. For a list of other possible

connection options, see Getting Started with vSphere Command-Line Interfaces.

Procedure

1 Run the following command:

esxcli --server=server_name system module parameters set -m iscsi_vmk -p

iscsivmk_LunQDepth=value

The iscsivmk_LunQDepth parameter sets the maximum number of outstanding commands, or queue

depth, for each LUN accessed through the software iSCSI adapter. The default value is 128.

2 Reboot your system.

3 Verify your changes by running the

esxcli --server=server_name system module parameters list -m iscsi_vmk command.

The following output shows the queue depth for software iSCSI.

iscsivmk_LunQDepth int 64 Maximum Outstanding Commands Per LUN

CAUTION Setting the queue depth to a value higher than the default can decrease the total number of LUNs

supported.

Change the Outstanding IO Requests Setting

If you adjusted the LUN queue depth, change the Disk.SchedNumReqOutstanding (DSNRO) parameter, so

that its value matches the queue depth. The parameter controls the maximum number of outstanding IO

requests that all virtual machines can issue to the LUN.

Change this parameter only when you have multiple virtual machines active on a LUN. The parameter does

not apply when only one virtual machine is active. In that case, the bandwidth is controlled by the queue

depth of the storage adapter.

The parameter is set per device.

Procedure

1 Enter the following command to display the current DSNRO setting for the specified device:

esxcli storage core device list -d device_ID

The get the output similar to the following:

No of outstanding IOs with competing worlds: 32

2 Change the DSNRO value by entering the following command:

esxcli storage core device set -O | --sched-num-req-outstanding value -d device_ID

Chapter 7 Troubleshooting Storage

VMware, Inc. 65

3 Verify your changes by entering the following command:

esxcli storage core device list -d device_ID

Virtual Machines with RDMs Need to Ignore SCSI INQUIRY Cache

Storage vendors might require that virtual machines with RDMs ignore SCSI INQUIRY data cached by

ESXi.

Problem

Certain guest operating systems or applications run in virtual machines with RDMs display unpredictable

behavior.

Cause

This behavior might be caused by cached SCSI INQUIRY data that interferes with specific guest operating

systems and applications.

When the ESXi host first connects to a target storage device on a SAN, it issues the SCSI INQUIRY

command to obtain basic identification data from the device. By default, ESXi caches the received SCSI

INQUIRY data (Standard, page 80, and page 83) and the data remains unchanged afterwards.

Solution

uConfigure the virtual machine with RDM to ignore the SCSI INQUIRY cache by adding the following

parameter to the .vmx file.

scsix:y.ignoreDeviceInquiryCache = "true"

where x is the SCSI controller number and y is the SCSI target number of the RDM.

Enable this parameter only when your storage vendor recommends that you do so. This parameter is

required for just a limited number of storage arrays and only for specific guest operating systems.

Software iSCSI Adapter Is Enabled When Not Needed

When your host uses a network adapter with iBFT, the software iSCSI adapter is always enabled by default.

Problem

After your ESXi host's first boot, the software iSCSI adapter is enabled and appears in the

vSphere Web Client on the list of storage adapters.

Cause

The iBFT-enabled network adapter on your host causes the software iSCSI to be always present. This

condition occurs even when you do not use iBFT for the iSCSI boot.

Solution

If you do not use the iBFT-enabled network adapter for the iSCSI boot and do not want the software iSCSI

adapter to be enabled, remove the iBFT configuration from the network adapter. Because this process is

vendor-specific, consult your vendor documentation for details.

vSphere Troubleshooting

66 VMware, Inc.

Failure to Mount NFS Datastores

Attempts to mount NFS datastores with names in international languages result in failures.

Problem

The use of non-ASCII characters for directory and file names on NFS storage might cause unpredictable

behavior. For example, you might fail to mount an NFS datastore or not be able to power on a virtual

machine.

Cause

ESXi supports the use of non-ASCII characters for directory and file names on NFS storage, so you can

create datastores and virtual machines using names in international languages. However, when the

underlying NFS server does not offer internationalization support, unpredictable failures might occur.

Solution

Always make sure that the underlying NFS server offers internationalization support. If the server does not,

use only ASCII characters.

VMkernel Log Files Contain SCSI Sense Codes

Certain VMkernel messages related to storage might contain SCSI Sense codes.

Problem

When you analyze ESXi host's /var/log/vmkernel log files, you encounter events or error messages that

contain SCSI Sense codes.

Solution

Ability to interpret the SCSI Sense codes can help you better understand problems in your storage

environment. Because the SCSI Sense code values are assigned by the T10 committee, you need to consult

the T10 standards documentation to determine the meaning of the codes. This topic explains how to use the

T10 documentation to interpret the SCSI Sense codes.

Example: Interpreting SCSI Sense Codes

The following is an example of a SCSI error message that appears in the ESXi log file:

2011-04-04T21:07:30.257Z cpu2:2050)ScsiDeviceIO: 2315: Cmd(0x4124003edb00) 0x12, CmdSN 0x51 to

dev "naa.600508XXXXXXXXXXXXX" failed H:0x0 D:0x2 P:0x0 Valid sense data: 0x5 0x25 0x0

In this example, SCSI Sense codes are represented by two fields, H:0x0 D:0x2 P:0x0 and 0x5 0x25 0x0.

The first field, H:0x0 D:0x2 P:0x0, is a combination of SCSI Status codes for the three components in your

storage environment, the host, the device, and the plug-in. The SCSI Status code is used to determine the

success or failure of a SCSI command. To interpret each SCSI Status code, see the

http://www.t10.org/lists/2status.htm.

NOTE Hexadecimal numbers in the T10 documentation use the NNNh format, while SCSI Sense codes in

the ESXi log files follow the 0xNNN format. For example, 0x2 = 02h.

You will get the following interpretation for the status field of the above example: H:0x0 D:0x2 P:0x0 =

H(host):GOOD D(device):CHECK CONDITION P(plug-in):GOOD.

The second field in a typical SCSI error message provides more detailed information about the error. It is a

combination of Sense Key (sense), Additional Sense Code (asc), and Additional Sense Code Qualifier (ascq)

parameters.

Chapter 7 Troubleshooting Storage

VMware, Inc. 67

For example, the 0x5 0x25 0x0 field from the above error message can be represented as sense=5 asc=25

ascq=0.

To interpret Sense Keys, see http://www.t10.org/lists/2sensekey.htm.

To determine the meaning of the Additional Sense Code (asc) and Additional Sense Code Qualifier (ascq),

use the two codes together. See http://www.t10.org/lists/2asc.htm for details.

You should get the following interpretation for the 0x5 0x25 0x0 field:

sense=5 (ILLEGAL REQUEST), ASC=25 ASCQ=0 (LOGICAL UNIT NOT SUPPORTED)

Troubleshooting Storage Adapters

If your storage adapters experience performance problems, use the esxcli storage san commands to

identify the problems .

Problem

Storage adapters experience performance and I/O problem.

Solution

Use the esxcli storage san commands to obtain and display events and statistics for the adapters. You can

analyze the commands' output to identify adapter problems and to find appropriate solutions.

Table 7‑3. esxcli storage san commands

Command Description Options

esxcli storage san [FC |

iSCSI | FCoE | SAS] list

List adapter attributes.

NOTE iSCSI applies to software iSCSI only.

-- adapter | -A

Adapter name (vmhbaX),

or none, to list information

for all adapters of the

particular type.

esxcli storage san [FC |

iSCSI | FCoE | SAS] stats

get

Get adapter statistics.

NOTE iSCSI applies to software iSCSI only.

-- adapter | -A

Adapter name (vmhbaX),

or none, to list information

for all adapters of the

particular type.

esxcli storage san [FC |

FCoE | SAS] reset

Reset a particular adapter. -- adapter | -A

Adapter name (vmhbaX).

esxcli storage san fc

events get

Retrieve events for Fibre Channel adapters. -- adapter | -A

Adapter name (vmhbaX),

or none, to list information

for all Fibre Channel

adapters on the system.

Checking Metadata Consistency with VOMA

Use vSphere On-disk Metadata Analyser (VOMA) to identify and fix incidents of metadata corruption that

affect file systems or underlying logical volumes.

Problem

You might need to check metadata consistency of a file system or a logical volume backing the file system

when you experience problems with various functionalities on a VMFS datastore or a virtual flash resource.

For example you might want to perform a metadata check if one of the following occurs:

nYou experience storage outages.

nAfter you rebuild RAID or perform a disk replacement.

vSphere Troubleshooting

68 VMware, Inc.

nYou see metadata errors in the vmkernel.log file.

nYou are unable to access files on a VMFS.

nYou see corruption being reported for a datastore in events tabs of vCenter Server.

Solution

To check metadata consistency, run VOMA from the CLI of an ESXi host. VOMA can be used to check and

fix metadata inconsistency issues for a VMFS datastore or a virtual flash resource. To resolve errors reported

by VOMA, consult VMware Support.

Follow these guidelines when you use the VOMA tool:

nMake sure that the VMFS datastore you analyze does not span multiple extents. You can run VOMA

only against a single-extent datastore.

nPower off any virtual machines that are running or migrate them to a different datastore.

The following example demonstrates how to use VOMA to check VMFS metadata consistency.

1 Obtain the name and partition number of the device that backs the VMFS datastore that you need to

check.

#esxcli storage vmfs extent list

The Device Name and Partition columns in the output identify the device. For example:

Volume Name XXXXXXXX Device Name Partition

1TB_VMFS5 XXXXXXXX naa.600508e000000000b367477b3be3d703 3

2 Run VOMA to check for VMFS errors.

Provide the absolute path to the device partition that backs the VMFS datastore, and provide a partition

number with the device name. For example:

# voma -m vmfs -f check -d /vmfs/devices/disks/naa.600508e000000000b367477b3be3d703:3

The output lists possible errors. For example, the following output indicates that the heartbeat address

is invalid.

XXXXXXXXXXXXXXXXXXXXXXX

Phase 2: Checking VMFS heartbeat region

ON-DISK ERROR: Invalid HB address

Phase 3: Checking all file descriptors.

Phase 4: Checking pathname and connectivity.

Phase 5: Checking resource reference counts.

Total Errors Found: 1

Command options that the VOMA tool takes include the following.

Chapter 7 Troubleshooting Storage

VMware, Inc. 69

Table 7‑4. VOMA Command Options

Command Option Description

-m | --module The module to run:

nvmfs. This is a default option. You can check VMFS3

and VMFS 5 datastores. If you specify this module,

minimal checks are performed for LVM as well.

nvmfsl. Check file systems that back virtual flash

volumes.

nlvm. Check logical volumes that back VMFS datastores.

-f | --func Functions to be performed:

nquery. List functions supported by module.

ncheck. Check for errors.

nfix. Check and fix errors.

-d | --device Device or disk to be inspected. Make sure to provide the

absolute path to the device partition backing the VMFS

datastore. For example, /vmfs/devices/disks/naa.

00000000000000000000000000:1.

-s | --logfile Specify the log file to output the results.

-v | --version Display the version of VOMA.

-h | --help Display the help message for the VOMA command.

Troubleshooting Flash Devices

vSphere uses flash drives for such storage features as Virtual SAN, host swap cache, and Flash Read Cache.

The troubleshooting topics can help you avoid potential problems and provide solutions for issues that you

might encounter when configuring flash drives.

Local Flash Devices Are Unavailable for Use with Virtual SAN or Virtual Flash

A local flash device becomes unavailable for virtual flash resource or Virtual SAN configuration when it is

formatted with VMFS or any other file system.

Problem

When you attempt to configure either Virtual SAN or virtual flash resource, a local flash disk does not

appear on the list of disks to be used.

Cause

This problem might occur when a local flash intended for use with either feature has been already formatted

with VMFS. Neither Virtual SAN nor virtual flash can share the flash disk with VMFS or any other file

system.

Also, because virtual flash and Virtual SAN are mutually exclusive consumers of flash disks, both features

cannot share the same flash disk. If the flash disk is already claimed by one feature, for example Virtual

SAN, you are not be able to use it for another, such as virtual flash, unless you release the disk.

Solution

Use only unformatted flash disks for virtual flash resource and Virtual SAN configuration.

nAvoid formatting the flash disks with VMFS during ESXi installation or Auto Deploy.

nIf the flash disk is already formatted with VMFS, remove the VMFS datastore. For information see the

vSphere Storage documentation.

vSphere Troubleshooting

70 VMware, Inc.

nTo use the flash disk as a virtual flash resource, do not claim this disk for Virtual SAN. If the disk is

claimed by Virtual SAN, remove the disk from Virtual SAN. The flash disk is released from Virtual

SAN and becomes available on the list of disks to use with virtual flash. For information about

removing disks from Virtual SAN, see the Administering VMware Virtual SAN documentation.

nIf you intend to use the flash disk with Virtual SAN, do not use the disk for a virtual flash resource. If

the flash disk is used as the virtual flash resource, remove the virtual flash configuration. The disk

becomes available for Virtual SAN. See the vSphere Storage documentation.

Another reason that makes flash disk unavailable is when ESXi cannot detect the disk. See “Local Flash

Disks Are Undetectable,” on page 71.

Keeping Flash Disks VMFS-Free with Auto-Partitioning

When you use auto-partitioning boot option when installing or auto-deploying ESXi, the auto-partitioning

option creates a VMFS datastore on your host's local storage. You have several options to keep your local

storage flash disks unformatted.

Problem

By default, auto-partitioning deploys VMFS file systems on any unused local storage disks on your host,

including flash disks.

However, a flash disk formatted with VMFS becomes unavailable for such features as virtual flash and

Virtual SAN. Both features require an unformatted flash disk and neither can share the disk with any other

file system.

Solution

To ensure that auto-partitioning does not format the flash disk with VMFS, use the following boot options

when you install ESXi or boot the ESXi host for the first time:

nautoPartition=TRUE

nskipPartitioningSsds=TRUE

If you use Auto Deploy, set these parameters on a reference host.

1 In the vSphere Web Client, select the host to use as a reference host and click Manage.

2 Click Settings.

3 Click System to open the system options, and click Advanced System Settings.

4 Scroll to VMkernel.Boot.autoPartition and set the value to true.

5 Scroll to VMkernel.Boot.skipPartitioningSsds and set the value to true.

6 Reboot the host.

If flash disks that you plan to use with Flash Read Cache and Virtual SAN already have VMFS datastores,

remove the datastores.

Local Flash Disks Are Undetectable

If you query for local flash disks during creation of a virtual flash resource or Virtual SAN configuration, the

ESXi host might not return a complete list of the local flash disks.

Problem

ESXi might not be able to automatically detect flash disks, or recognize them as local.

Chapter 7 Troubleshooting Storage

VMware, Inc. 71

Cause

ESXi does not recognize certain devices as flash disks when their vendors do not support automatic flash

disk detection. In other cases, some non-SATA SAS flash disks might not be detected as local. When disks

are not recognized as local flash disks, they are excluded from the list of flash disks available for such

features that require only local flash disks.

Solution

You might need to manually tag disks as flash disks or as local.

nIf ESXi does not automatically recognize its disks as flash disks, tag them as flash disk disks.

nIf ESXi does not detect flash disks as local, manually set them as local.

Mark Storage Devices as Flash

If ESXi does not automatically recognize its devices as flash, mark them as flash devices.

ESXi does not recognize certain devices as flash when their vendors do not support automatic flash disk

detection. The Drive Type column for the devices shows HDD as their type.

CAUTION Marking HDD disks as flash disks could deteriorate the performance of datastores and services

that use them. Mark disks as flash disks only if you are certain that those disks are flash disks.

Prerequisites

Verify that the device is not in use.

Procedure

1 Browse to the host in the vSphere Web Client object navigator.

2 Click the Manage tab, and click Storage.

3 Click Storage Devices.

4 From the list of storage devices, select one or several HDD devices that need to be recognized as flash

devices and click the Mark as Flash Disks icon.

5 Click Yes to save your changes.

The type of the devices changes to flash.

What to do next

If the flash device that you mark is shared among multiple hosts, make sure that you mark the device from

all hosts that share the device.

Mark Storage Devices as Local

ESXi enables you to mark devices as local. This is useful in cases when ESXi is unable to determine whether

certain devices are local.

Prerequisites

nMake sure that the device is not shared.

nPower off virtual machines that reside on the device and unmount an associated datastore.

Procedure

1 Browse to the host in the vSphere Web Client object navigator.

2 Click the Manage tab, and click Storage.

vSphere Troubleshooting

72 VMware, Inc.

3 Click Storage Devices.

4 From the list of storage devices, select one or several remote devices that need to be marked as local and

click the Mark as Local for the Host icon.

5 Click Yes to save your changes.

Troubleshooting Virtual Volumes

Virtual volumes are encapsulations of virtual machine files, virtual disks, and their derivatives. Virtual

volumes are stored natively inside a storage system that is connected through Ethernet or SAN. They are

exported as objects by a compliant storage system and are managed entirely by hardware on the storage

side.

For information about the Virtual Volumes functionality, see the vSphere Storagepublication.

Virtual Volumes and esxcli Commands

You can use the esxcli storage vvol commands to troubleshoot your Virtual Volumes environment.

The following command options are available:

Table 7‑5. esxcli storage vvol commands

Namespace Command Option Description

esxcli storage vvol daemon unbindall Unbind all virtual volumes from

all VASA providers known to the

ESXi host.

esxcli storage vvol

protocolendpoint

List all protocol endpoints that

your host can access.

esxcli storage vvol

storagecontainer

list

restore

List all available storage

containers, or restore the set from

boot.

esxcli storage vvol vasacontext Operations on the Virtual

Volumes VASA context.

esxcli storage vvol vasaprovider list

restore

List all registered storage

providers, or restore the set from

boot.

Virtual Datastore Is Inaccessible

After you create a virtual datastore, it remains inaccessible.

Problem

The vSphere Web Client shows the datastore as inaccessible. You cannot use the datastore for virtual

machine provisioning.

Cause

This problem might occur when you fail to configure protocol endpoints for the SCSI-based storage

container that is mapped to the virtual datastore. Like traditional LUNs, SCSI protocol endpoints need to be

configured so that an ESXi host can detect them.

Solution

Before creating virtual datastores for SCSI-based containers, make sure to configure protocol endpoints on

the storage side.

Chapter 7 Troubleshooting Storage

VMware, Inc. 73

Failures When Migrating VMs or Deploying VM OVFs to Virtual Volumes

Datastores

Your attempts to migrate a virtual machine or to deploy a VM OVF to virtual datastores fail.

Problem

An OVF template or a VM being migrated from a nonvirtual datastore might include additional large files,

such as ISO disk images, DVD images, and image files. If these additional files cause the configuration

virtual volume to exceed its 4-GB limit, migration or deployment to a virtual datastore fails.

Cause

The configuration virtual volume, or config-VVol, contains various VM-related files. On traditional

nonvirtual datastores, these files are stored in the VM home directory. Similar to the VM home directory, the

config-VVol typically includes the VM configuration file, virtual disk and snapshot descriptor files, log files,

lock files, and so on.

On virtual datastores, all other large-sized files, such as virtual disks, memory snapshots, swap, and digest,

are stored as separate virtual volumes.

Config-VVols are created as 4-GB virtual volumes. Generic content of the config-VVol usually consumes

only a fraction of this 4-GB allocation, so config-VVols are typically thin-provisioned to conserve backing

space. Any additional large files, such as ISO disk images, DVD images, and image files, might cause the

config-VVol to exceed its 4-GB limit. If such files are included in an OVF template, deployment of the VM

OVF to vSphere Virtual Volumes storage fails. If these files are part of an existing VM, migration of that VM

from a traditional datastore to vSphere Virtual Volumes storage also fails.

Solution

nFor VM migration. Before migrating a VM from a traditional datastore to a virtual datastore, remove

excess content from the VM home directory to keep the config-VVol under the 4-GB limit.

nFor OVF deployment. Because you cannot deploy an OVF template that contains excess files directly to

a virtual datastore, first deploy the VM to a nonvirtual datastore. Remove any excess content from the

VM home directory, and migrate the resulting VM to vSphere Virtual Volumes storage.

Failed Attempts to Migrate VMs with Memory Snapshots to and from Virtual

Datastores

When you attempt to migrate a VM with hardware version 10 or earlier to and from a vSphere Virtual

Volumes datastore, failures occur if the VM has memory snapshots.

Problem

The following problems occur when you migrate a version 10 or earlier VM with memory snapshots:

nMigration of a version 10 or earlier VM with memory snapshots to a virtual datastore is not supported

and causes a failure.

nMigration of a version 10 or earlier VM with memory snapshots from a virtual datastore to a nonvirtual

datastore, such as VMFS, can succeed. If you later make additional snapshots and attempt to migrate

this VM back to vSphere Virtual Volumes storage, your attempt fails.

Cause

vSphere Virtual Volumes storage does not require that you use a particular hardware version for your

virtual machines. Typically, you can move a virtual machine with any hardware version to vSphere Virtual

Volumes storage. However, if you have a VM with memory snapshots, and plan to migrate this VM

between a virtual datastore and a nonvirtual datastore, use the VM of hardware version 11.

vSphere Troubleshooting

74 VMware, Inc.

Non-VVols virtual machines of hardware version 11 or later use separate files to store their memory

snapshots. This usage is consistent with VMs on vSphere Virtual Volumes storage, where memory

snapshots are created as separate VVols instead of being stored as part of a .vmsn file in the VM home

directory. In contrast, non-VVols VMs with hardware version 10 continue to store their memory snapshots

as part of the .vmsn file in the VM home directory. As a result, you might experience problems or failures

when attempting to migrate these VMs between virtual and nonvirtual datastores.

Solution

To avoid problems when migrating VMs with memory snapshots across virtual and nonvirtual datastores,

use hardware version 11. Follow these guidelines when migrating version 10 or earlier VMs with memory

snapshots:

nMigrating a version 10 or earlier VM with memory snapshots to a virtual datastore is not supported.

The only workaround is to remove all snapshots. Upgrading the hardware version does not solve this

problem.

nMigrating a version 10 or earlier VM with memory snapshots from a virtual datastore to a nonvirtual

datastore, such as VMFS, can succeed. However, the migration might put the VM in an inconsistent

state. The snapshots that were taken on the virtual datastore use the vmem object. Any memory

snapshots taken after migrating to VMFS are stored in the .vmsn file. If you later attempt to migrate this

VM back to vSphere Virtual Volumes storage, your attempt fails. As with the previous case, remove all

snapshots to work around this problem.

Troubleshooting VAIO Filters

vSphere APIs for I/O Filtering (VAIO) provide a framework that allows third parties to create software

components called I/O filters. The filters can be installed on ESXi hosts and can offer additional data services

to virtual machines by processing I/O requests that move between the guest operating system of a virtual

machine and virtual disks.

For information about I/O filters, see the see the vSphere Storagepublication.

Handling I/O Filter Installation Failures

Typically, all ESXi hosts in a cluster have the same set of I/O filters installed. Occasionally, failures might

happen during installation.

If an I/O filter installation fails on a host, the system generates events that report the failure. In addition, an

alarm on the host shows the reason for the failure. Examples of failures include the following:

nThe VIB URL is not accessible from the host.

nThe VIB has an invalid format.

nThe VIB requires the host to be in maintenance mode for an upgrade or uninstallation.

nThe VIB requires the host to reboot after the installation or uninstallation.

nAttempts to put the host in maintenance mode fail because the virtual machine cannot be evacuated

from the host.

nThe VIB requires manual installation or uninstallation.

vCenter Server can resolve some failures. You might have to intervene for other failures. For example, you

might need to edit the VIB URL, manually evacuate or power off virtual machines, or manually install or

uninstall VIBs.

Chapter 7 Troubleshooting Storage

VMware, Inc. 75

Install I/O Filters on a Single ESXi Host

For troubleshooting purposes, you can download an ESXi component of the I/O filter, packaged as a VIB

file, and install it on the ESXi host. Use the esxcli command to install the VIB file.

When you specify a target server by using --server=server_name, the server prompts you for a user name

and password. Other connection options, such as a configuration file or session file, are supported. For a list

of connection options, see Getting Started with vSphere Command-Line Interfaces, or run esxcli --help at the

vCLI command prompt.

Prerequisites

Install vCLI or deploy the vSphere Management Assistant (vMA) virtual machine. See Getting Started with

vSphere Command-Line Interfaces. For troubleshooting, run esxcli commands in the ESXi Shell.

Procedure

1 Install the VIBs by running the following command:

esxcli --server=server_name software vib install --depot path_to_VMware_vib_ZIP_file

Options for the install command allow you to perform a dry run, specify a specific VIB, bypass

acceptance-level verification, and so on. Do not bypass verification on production systems. See the

vSphere Command-Line Interface Reference documentation.

2 Verify that the VIBs are installed on your ESXi host.

esxcli --server=server_name software vib list

vSphere Troubleshooting

76 VMware, Inc.

Troubleshooting Networking 8

The troubleshooting topics about networking in vSphere provide solutions to potential problems that you

might encounter with the connectivity of ESXi hosts, vCenter Server and virtual machines.

This chapter includes the following topics:

n“Troubleshooting MAC Address Allocation,” on page 78

n“The Conversion to the Enhanced LACP Support Fails,” on page 81

n“Unable to Remove a Host from a vSphere Distributed Switch,” on page 82

n“Hosts on a vSphere Distributed Switch 5.1 and Later Lose Connectivity to vCenter Server,” on

page 83

n“Hosts on vSphere Distributed Switch 5.0 and Earlier Lose Connectivity to vCenter Server,” on

page 84

n“Alarm for Loss of Network Redundancy on a Host,” on page 85

n“Virtual Machines Lose Connectivity After Changing the Uplink Failover Order of a Distributed Port

Group,” on page 86

n“Unable to Add a Physical Adapter to a vSphere Distributed Switch That Has Network I/O Control

Enabled,” on page 87

n“Troubleshooting SR-IOV Enabled Workloads,” on page 87

n“A Virtual Machine that Runs a VPN Client Causes Denial of Service for Virtual Machines on the Host

or Across a vSphere HA Cluster,” on page 89

n“Low Throughput for UDP Workloads on Windows Virtual Machines,” on page 91

n“Virtual Machines on the Same Distributed Port Group and on Different Hosts Cannot Communicate

with Each Other,” on page 92

n“Attempt to Power On a Migrated vApp Fails Because the Associated Protocol Profile Is Missing,” on

page 93

n“Networking Configuration Operation Is Rolled Back and a Host Is Disconnected from vCenter

Server,” on page 94

VMware, Inc. 77

Troubleshooting MAC Address Allocation

In vSphere, certain restrictions on the range of MAC addresses that can be assigned to virtual machines

might cause lost of connectivity or inability to power on workloads.

Duplicate MAC Addresses of Virtual Machines on the Same Network

You encounter loss of packets and connectivity because virtual machines have duplicate MAC addresses

generated by vCenter Server.

Problem

The MAC addresses of virtual machines on the same broadcast domain or IP subnet are in conflict, or

vCenter Server generates a duplicate MAC address for a newly created virtual machine.

A virtual machine powers on and functions properly, but shares a MAC address with another virtual

machine. This situation might cause packet loss and other problems.

Cause

Virtual machines might have duplicate MAC addresses due to several reasons.

nTwo vCenter Server instances with identical IDs generate overlapping MAC addresses for virtual

machine network adapters.

Each vCenter Server instance has an ID between 0 and 63 that is randomly generated at installation

time, but can be reconfigured after installation. vCenter Server uses the instance ID to generate MAC

addresses for the network adapters of the machine.

nA virtual machine has been transferred in power-off state from one vCenter Server instance to another

in the same network, for example, by using shared storage, and a new virtual machine network adapter

on the first vCenter Server receives the freed MAC address.

Solution

nChange the MAC address of a virtual machine network adapter manually.

If you have an existing virtual machine with a conflicting MAC address, you must provide a unique

MAC address in the Virtual Hardware settings.

nPower off the virtual machine, configure the adapter to use a manual MAC address, and type the

new address.

nIf you cannot power the virtual machine off for configuration, re-create the network adapter that is

in conflict with enabled manual MAC address assignment and type the new address. In the guest

operating system, set the same static IP address to the re-added adapter as before.

For information about configuring the network adapters of virtual machines, see the vSphere Networking

and vSphere Virtual Machine Administration documentation.

vSphere Troubleshooting

78 VMware, Inc.

nIf the vCenter Server instance generates the MAC addresses of virtual machines according to the default

allocation, VMware OUI, change the vCenter Server instance ID or use another allocation method to

resolve conflicts.

NOTE Changing the vCenter Server instance ID or switching to a different allocation scheme does not

resolve MAC address conflicts in existing virtual machines. Only virtual machines created or network

adapters added after the change receive addresses according to the new scheme.

For information about MAC address allocation schemes and setup, see the vSphere Networking

documentation.

Solution Description

Change the vCenter Server ID You can keep using the VMware OUI allocation scheme if your

deployment contains a small number of vCenter Server instances.

According to this scheme, a MAC address has the following format:

00:50:56:XX:YY:ZZ

where 00:50:56 represents the VMware OUI, XX is calculated as (80 +

vCenter Server ID), and YY:ZZ is a random number.

To change the vCenter Server ID, configure the vCenter Server unique ID

option in the Runtime Settings section from the General settings of the

vCenter Server instance and restart it.

The VMware OUI allocation works with up to 64 vCenter Server instances

and is suitable for small scale deployments.

Switch to prefix-based allocation You can use a custom OUI. For example, for a 02:12:34 locally

administered address range, MAC addresses have the form

02:12:34:XX:YY:ZZ. You can use the fourth octet XX to distribute the

OUI address space between the vCenter Server instances. This structure

results in 255 address clusters, each cluster managed by a vCenter Server

instance, and in about 65000 MAC addresses per vCenter Server. For

example, 02:12:34:01:YY:ZZ for vCenter Server A, 02:12:34:02:YY:ZZ

for vCenter Server B, and so on.

Prefix-based allocation is suitable for deployments of a larger scale.

For globally unique MAC addresses, the OUI must be registered in IEEE.

a Configure MAC address allocation.

b Apply the new MAC address allocation scheme to an existing virtual machine in its Virtual

Hardware settings.

nPower off a virtual machine, configure the adapter to use a manual MAC address, revert to

automatic MAC address allocation, and power on the virtual machine.

nIf the virtual machine is in production and you cannot power it off for configuration, after you

change the vCenter Server ID or the address allocation scheme, re-create the network adapter

in conflict with enabled automatic MAC address assignment. In the guest operating system,

set the same static IP address to the re-added adapter as before.

Chapter 8 Troubleshooting Networking

VMware, Inc. 79

nEnforce MAC address regeneration when transferring a virtual machine between vCenter Server

instances by using the virtual machine files from a datastore.

a Power off a virtual machine, remove it from the inventory, and in its configuration file (.vmx), set

the ethernetX.addressType parameter to generated.

X next to ethernet stands for the sequence number of the virtual NIC in the virtual machine.

b Import the virtual machine from one vCenter Server system to another by registering the virtual

machine from a datastore in the target vCenter Server.

The virtual machine files can reside in a datastore that is shared between the two vCenter Server

instances or can be uploaded to a datastore that is accessible only from the target vCenter Server

system.

For information about registering a virtual machine from a datastore, see vSphere Virtual Machine

Administration.

c Power on the virtual machines for the first time.

While the virtual machine is starting up, an information icon appears on the virtual machine in the

vSphere Web Client.

d Right-click the virtual machine and select Guest OS > Answer Question.

e Select the I Copied It option.

The target vCenter Server re-generates the MAC address of the virtual machine. The new MAC address

starts with the VMware OUI 00:0c:29 and is based on the BIOS UUID of the virtual machine. The BIOS

UUID of the virtual machine is calculated from the BIOS UUID of the host.

nIf the vCenter Server and hosts are version 6.0 and later and the vCenter Server instances are connected

in Enhanced Linked Mode, migrate virtual machines by using vMotion across vCenter Server systems.

When a virtual machine is migrated across vCenter Server systems, the source vCenter Server adds the

MAC address of the virtual machine to a blacklist and does not assign them to other virtual machines.

Attempt to Power On a Virtual Machine Fails Due to a MAC Address Conflict

After you set a certain static MAC address to a virtual machine adapter you cannot power on the virtual

machine.

Problem

In the vSphere Web Client, after you assign a MAC address within the range 00:50:56:40:YY:ZZ –

00:50:56:7F:YY:ZZ to a virtual machine, attempts to power the virtual machine on fail with a status message

that the MAC address is in conflict.

00:50:56:XX:YY:ZZ is not a valid static Ethernet address. It

conflicts with VMware reserved MACs for other usage.

Cause

You attempt to assign a MAC address which starts with the VMware OUI 00:50:56 and is within the

address range allocated for host VMkernel adapters on the vCenter Server system.

Solution

If you want to preserve the VMware OUI prefix, set a static MAC address within the range

00:50:56:00:00:00 – 00:50:56:3F:FF:FF. Otherwise, set an arbitrary MAC address whose prefix is different

from the VMware OUI one. For information about the ranges available for static MAC addresses that have

the VMware OUI prefix, see the vSphere Networking documentation.

vSphere Troubleshooting

80 VMware, Inc.

The Conversion to the Enhanced LACP Support Fails

Under certain conditions, the conversion from an existing LACP configuration to the enhanced LACP

support on a vSphere Distributed Switch 5.5 and later might fail.

Problem

After you upgrade a vSphere distributed switch to version 5.5 and later, when you initiate the conversion to

the enhanced LACP support from an existing LACP configuration, the conversion fails at a certain stage of

the process.

Cause

The conversion from an existing LACP configuration to the enhanced LACP support includes several tasks

for reconfiguring the distributed switch. The conversion might fail because another user might have

reconfigured the distributed switch during the conversion. For example, physical NICs from the hosts might

have been reassigned to different uplinks or the teaming and failover configuration of the distributed port

groups might have been changed.

Another reason for the failure might be that some of the hosts have disconnected during the conversion.

Solution

When the conversion to the enhanced LACP support fails on a certain stage, it is completed only partially.

You must check the configuration of the distributed switch and the participating hosts to identify the objects

with incomplete LACP configuration.

Check the target configuration that must result from each conversion stage in the order that is listed in the

table. When you locate the stage where the conversion has failed, complete its target configuration manually

and continue with the stages that follow.

Table 8‑1. Steps to Complete the Conversion to the Enhanced LACP Manually

Conversion Stage Target Configuration State Solution

1. Create a new LAG. A newly created LAG must be

present on the distributed

switch.

Check the LACP configuration of the distributed switch

and create a new LAG if there is none.

2. Create a an intermediate

LACP teaming and failover

configuration on the

distributed port groups.

The newly created LAG must

be standby that lets you

migrate physical NICs to the

LAG without losing

connectivity.

Check the teaming and failover configuration of the

distributed port group. Set the new LAG as standby if it

is not.

If you do not want to use a LAG to handle the traffic for

all distributed port groups, revert the teaming and

failover configuration to a state where standalone

uplinks are active and the LAG is unused .

3. Reassign physical NICs

from standalone uplinks to

LAG ports.

All physical NICs from the

LAG ports must be reassigned

from standalone uplinks to

the LAG ports

Check whether physical NICs are assigned to the LAG

ports. Assign a physical NIC to every LAG port.

NOTE The LAG must remain standby in the teaming and

failover order of the distributed port groups while you

reassign physical NICs to the LAG ports.

4. Create the final LACP

teaming and failover

configuration on the

distributed port groups.

The final LACP teaming and

failover configuration is the

following.

nActive: only the new LAG

nStandby: empty

nUnused: all standalone

uplinks

Check the teaming and failover configuration of the

distributed port group. Create a valid LACP teaming and

failover configuration for all distributed port groups for

which you want to apply LACP.

Chapter 8 Troubleshooting Networking

VMware, Inc. 81

For example, suppose you verify that a new LAG has been created on the distributed switch and that an

intermediate teaming and failover configuration has been created for the distributed port groups. You

continue with checking whether there are physical NICs assigned to the LAG ports. You find out that not all

hosts have physical NICs assigned to the LAG ports, and you assign the NICs manually. You complete the

conversion by creating the final LACP teaming and failover configuration for the distributed port groups.

Unable to Remove a Host from a vSphere Distributed Switch

Under certain conditions, you might be unable to remove a host from the vSphere distributed switch.

Problem

nAttempts to remove a host from a vSphere distributed switch fail, and you receive a notification that

resources are still in use. The notification that you receive might look like the following:

The resource '16' is in use.

vDS DSwitch port 16 is still on host 10.23.112.2 connected to MyVM nic=4000 type=vmVnic

nAttempts to remove a host proxy switch that still exists on the host from a previous networking

configuration fail. For example, you moved the host to a different data center or vCenter Server system,

or upgraded the ESXi and vCenter Server software, and created new networking configuration. When

trying to remove the host proxy switch, the operation fails because resources on the proxy switch are

still in use.

Cause

You cannot remove the host from the distributed switch or delete the host proxy switch because of the

following reasons.

nThere are VMkernel adapters on the switch that are in use.

nThere are virtual machine network adapters connected to the switch.

Solution

Problem Solution

Cannot remove a

host from a

distributed switch

1 In the vSphere Web Client, navigate to the distributed switch.

2 Select Manage > Ports.

3 Locate all ports that are still in use and check which VMkernel or virtual machine network

adapters on the host are still attached to the ports .

4 Migrate or delete the VMkernel and virtual machine network adapters that are still connected

to the switch.

5 Use the Add and Manage Hosts wizard in the vSphere Web Client to remove the host from

the switch.

After the host is removed, the host proxy switch is deleted automatically.

Cannot remove a

host proxy switch

1 In the vSphere Web Client, navigate to the host.

2 Delete or migrate any VMkernel or virtual machine network adapters that are still connected

to the host proxy switch.

3 Delete the host proxy switch from the Networking view on the host.

vSphere Troubleshooting

82 VMware, Inc.

Hosts on a vSphere Distributed Switch 5.1 and Later Lose

Connectivity to vCenter Server

Hosts on a vSphere Distributed Switch 5.1 and later cannot connect to vCenter Server after a port group

configuration.

Problem

After you change the networking configuration of a port group on a vSphere Distributed Switch 5.1 and

later that contains the VMkernel adapters for the management network, the hosts on the switch lose

connectivity to vCenter Server. In the vSphere Web Client the status of the hosts is nonresponsive.

Cause

On a vSphere Distributed Switch 5.1 and later in vCenter Server that has networking rollback disabled, the

port group containing the VMkernel adapters for the management network is misconfigured in

vCenter Server and the invalid configuration is propagated to the hosts on the switch.

Solution

1 From the Direct Console User Interface (DCUI) to an affected host, use the Restore vDS option from the

Network Restore Options menu to configure the uplinks and the ID of the VLAN for the management

network.

The DCUI creates a local ephemeral port and applies the VLAN and uplink configuration to the port.

The DCUI changes the VMkernel adapter for the management network to use the new host local port to

restore connectivity to vCenter Server.

After the host re-connects to vCenter Server, the vSphere Web Client displays a warning that some

hosts on the switch have different networking configuration from the configuration stored in vSphere

distributed switch.

2 In the vSphere Web Client, configure the distributed port group for the management network with

correct settings.

Situation Solution

You have altered the port group

configuration only once

You can roll the configuration of the port group back one step. Right-click

the port group, click Restore Configuration, and select Restore to

previous configuration.

You have backed up a valid

configuration of the port group

You can restore the configuration of the port group by using the backup

file. Right-click the port group, click Restore Configuration, and select

Restore configuration from a file.

You can also restore the configuration for the entire switch, including the

port group, from a backup file for the switch.

You have performed more than one

configuration step and you do not

have a backup file

You must provide valid settings for the port group manually.

For information about networking rollback, recovery, and restore, see the vSphere Networking

documentation.

3 Migrate the VMkernel adapter for the management network from the host local ephemeral port to a

distributed port on the switch by using the Add and Manage Hosts wizard.

Unlike distributed ports, the ephemeral local port of the VMKernel has a non-numeric ID.

For information about handling VMkernel adapters through the Add and Manage Hosts wizard, see

the vSphere Networking documentation.

Chapter 8 Troubleshooting Networking

VMware, Inc. 83

4 Apply the configuration of the distributed port group and VMkernel adapter from vCenter Server to

the host.

nPush the correct configuration of the distributed port group and VMkernel adapter from

vCenter Server to the host.

a In the vSphere Web Client, navigate to the host.

b Under the Manage tab, click Networking

c From the Virtual switches list, select the distributed switch and click Rectify.

nWait until vCenter Server applies the settings within the next 24 hours.

Hosts on vSphere Distributed Switch 5.0 and Earlier Lose

Connectivity to vCenter Server

Hosts on a vSphere Distributed Switch 5.0 and earlier cannot connect to vCenter Server after a port group

configuration.

Problem

After you change the networking configuration of a port group on a vSphere Distributed Switch 5.0 or

earlier that contains the VMkernel adapters for the management network, the hosts on the switch lose

connectivity to vCenter Server. In the vSphere Web Client the status of the hosts is nonresponsive.

Cause

On a vSphere Distributed Switch 5.0 and earlier in vCenter Server, the port group containing the VMkernel

adapters for the management network is misconfigured in vCenter Server and the invalid configuration is

propagated to the hosts on the switch.

Solution

1 Connect to an affected host by using the vSphere Client.

2 Under Configuration, select Networking.

3 In the vSphere Standard Switch view, create a new standard switch if the host does not have a standard

switch suitable for the management network.

a Click Add Networking.

b In the Add Network wizard, under Connection Types select Virtual Machine, and click Next.

c Select Create a vSphere standard switch.

d Under the Create a vSphere standard switch section, select one or more unoccupied physical

adapters on the host to carry the management traffic and click Next.

If all physical adapters are already busy with traffic from other switches, create the switch without

a physical network adapter connected. Later, remove the physical adapter for the management

network from the proxy switch of the distributed switch and add it to this standard switch.

e In the Port Group Properties section, type a network label that identifies the port group that you

are creating and optionally a VLAN ID.

f Click Finish.

vSphere Troubleshooting

84 VMware, Inc.

4 In the vSphere Distributed Switch view, migrate the VMkernel adapter for the network to a standard

switch.

a Select the vSphere Distributed Switch view, and for the distributed switch, click Manage Virtual

Adapters.

b In the Manage Virtual Adapters wizard, select the VMkernel adapter from the list and click

Migrate.

c Select the newly created or another standard switch to migrate the adapter to, and click Next.

d Enter a network label that is unique in the scope of the host and optionally a VLAN ID for the

management network, and click Next.

e Review the settings on the target standard switch and click Finish.

5 In the vSphere Web Client, configure the distributed port group for the management network with

correct settings.

6 Migrate the VMkernel adapter for the management network from the standard switch to a port on the

distributed switch by using the Add and Manage Hosts wizard.

For information about the Add and Manage Hosts wizard, see the vSphere Networking documentation.

7 If you have moved the physical adapter from the proxy switch to the standard switch, you can reattach

it to the distributed switch again by using the Add and Manage Hosts wizard.

Alarm for Loss of Network Redundancy on a Host

An alarm reports a loss of uplink redundancy on a vSphere standard or a distributed switch for a host.

Problem

No redundant physical NICs for a host are connected to a particular standard or a distributed switch, and

the following alarm appears:

Host name or IP Network uplink redundancy lost

Cause

Only one physical NIC on the host is connected to a certain standard or a distributed switch. The redundant

physical NICs are either down or are not assigned to the switch.

For example, assume that a host in your environment has physical NICs vmnic0 and vmnic1 connected to

vSwitch0, and the physical NIC vmnic1 goes offline, leaving only vmnic0 connected to vSwitch0. As a result,

the uplink redundancy for vSwitch0 is lost on the host.

Solution

Check which switch has lost uplink redundancy on the host. Connect at least one more physical NIC on the

host to this switch and reset the alarm to green. You can use the vSphere Web Client or the ESXi Shell.

If a physical NIC is down, try to bring it back up by using the ESXi Shell on the host.

For information about using the networking commands in the ESXi Shell, see vSphere Command-Line Interface

Reference. For information about configuring networking on a host in the vSphere Web Client, see vSphere

Networking.

Chapter 8 Troubleshooting Networking

VMware, Inc. 85

Virtual Machines Lose Connectivity After Changing the Uplink

Failover Order of a Distributed Port Group

Changes in the failover NIC order on a distributed port group cause the virtual machines associated with

the group to disconnect from the external network.

Problem

After you rearrange the uplinks in the failover groups for a distributed port group in vCenter Server, for

example, by using the vSphere Web Client, some virtual machines in the port group can no longer access the

external network.

Cause

After changing the failover order, many reasons might cause virtual machines to lose connectivity to the

external network.

nThe host that runs the virtual machines does not have physical NICs associated with the uplinks that

are set to active or standby. All uplinks that are associated with physical NICs from the host for the port

group are moved to unused.

nA Link Aggregation Group (LAG) that has no physical NICs from the host is set as the only active

uplink according to the requirements for using LACP in vSphere.

nIf the virtual machine traffic is separated in VLANs, the host physical adapters for the active uplinks

might be connected to trunk ports on the physical switch that do not handle traffic from these VLANs.

nIf the port group is configured with IP hash load balancing policy, an active uplink adapter is connected

to a physical switch port that might not be in an EtherChannel.

You can examine the connectivity of the virtual machines in the port group to associated host uplinks and

uplink adapters from the central topology diagram of the distributed switch or from the proxy switch

diagram for the host.

Solution

nRestore the failover order with the uplink that is associated with a single physical NIC on the host back

to active.

nCreate a port group with identical settings, make it use the valid uplink number for the host, and

migrate the virtual machine networking to the port group.

nMove the NIC to an uplink that participates in the active failover group.

You can use the vSphere Web Client to move the host physical NIC to another uplink.

nUse the Add and Manage Hosts wizard on the distributed switch.

a Navigate to the distributed switch in the vSphere Web Client.

b From the Actions menu select Add and Manage Hosts.

c Select the Manage host networking option and select the host.

d To assign the NIC of the host to an active uplink, select the Manage physical adapters option

and associate the NIC to the switch uplink in the Manage physical adapters page.

nMove the NIC at the level of the host.

a Navigate to the host in the vSphere Web Client, and under Manage, click Networking.

b Select Virtual Switches and select the distributed proxy switch.

c Click Manage the physical adapters, and move the NIC to the active uplink

vSphere Troubleshooting

86 VMware, Inc.

Unable to Add a Physical Adapter to a vSphere Distributed Switch

That Has Network I/O Control Enabled

You might be unable to add a physical adapter with low speed, for example, 1 Gbps, to a vSphere

Distributed Switch that has vSphere Network I/O Control version 3 configured.

Problem

You try to add a physical adapter with low speed, for example, 1 Gbps, to a vSphere Distributed Switch that

is connected to physical adapters with high speed, for example, 10 Gbps. Network I/O Control version 3 is

enabled on the switch and bandwidth reservations exist for one or more system traffic types, such as

vSphere management traffic, vSphere vMotion traffic, vSphere NFS traffic, and so on. The task for adding

the physical adapter fails with a status message that a parameter is incorrect.

A specified parameter was not correct: spec.host[].backing.pnicSpec[]

Cause

Network I/O Control aligns the bandwidth that is available for reservation to the 10-Gbps speed of the

individual physical adapters that are already connected to the distributed switch. After you reserve a part of

this bandwidth, adding a physical adapter whose speed is less than 10 Gbps might not meet the potential

needs of a system traffic type.

For information about Network I/O Control version 3, see the vSphere Networking documentation.

Solution

1 In the vSphere Web Client, navigate to the host.

2 On the Manage tab, click Settings.

3 Expand the System group of settings and click Advanced System Settings.

4 List the physical adapters that you want to use outside the scope of Network I/O Control as a comma-

separated list to the Net.IOControlPnicOptOut parameter.

For example: vmnic2,vmnic3

5 Click OK to apply the changes.

6 In the vSphere Web Client, add the physical adapter to the distributed switch.

Troubleshooting SR-IOV Enabled Workloads

Under certain conditions, you might experience connectivity or power-on problems with virtual machines

that use SR-IOV to send data to physical network adapters.

Virtual Machine That Uses an SR-IOV Virtual Function Fails to Power On

Because the Host Is Out of Interrupt Vectors

On an ESXi host, one or more virtual machines that use SR-IOV virtual functions (VFs) for networking are

powered off.

Problem

On an ESXi host, one or more virtual machines that use SR-IOV virtual functions (VFs) for networking fail to

power on if the total number of assigned virtual functions is close to the maximum number of VFs specified

in the vSphere Configuration Maximums guide.

Chapter 8 Troubleshooting Networking

VMware, Inc. 87

The virtual machine log file vmware.log contains the following message about the VF:

PCIPassthruChangeIntrSettings: vf_name failed to register interrupt (error code 195887110)

The VMkernel log file vmkernel.log contains the following messages about the VF assigned to the virtual

machine:

VMKPCIPassthru: 2565: BDF = vf_name intrType = 4 numVectors: 3

WARNING: IntrVector: 233: Out of interrupt vectors

Cause

The number of allocatable interrupt vectors scales up with the number of physical CPUs on an ESXi host.

An ESXi host that has 32 CPUs can provide a total of 4096 interrupt vectors. When the host boots, devices on

the host such as storage controllers, physical network adapters, and USB controllers consume a subset of the

4096 vectors. If these devices require more than 1024 vectors, the maximum number of potentially

supported VFs is reduced.

When a virtual machine powers on and the guest operating system VF driver starts, interrupt vectors are

consumed. If the required number of interrupt vectors is not available, the guest operating system shuts

down unexpectedly without any error messages.

No rule presently exists to determine the number of interrupt vectors consumed or available on a host. This

number depends on the hardware configuration of the host.

Solution

uTo be able to power on the virtual machines, reduce the total number of VFs assigned to virtual

machines on the host.

For example, change the SR-IOV network adapter of a virtual machine to an adapter that is connected

to a vSphere Standard Switch or vSphere Distributed Switch.

SR-IOV Enabled Workload Cannot Communicate After You Change Its MAC

Address

After you change the MAC address in the guest operating system of an SR-IOV enabled virtual machine, the

virtual machine loses connectivity.

Problem

When you connect the network adapter of a virtual machine to an SR-IOV virtual function (VF), you create a

passthrough network adapter for the virtual machine. After the (VF) driver in the guest operating system

modifies the MAC address for the passthrough network adapter, the guest operating system shows that the

change is successful but the VM network adapter loses connectivity. Although the guest operating system

shows that the new MAC address is enabled, a log message in the /var/log/vmkernel.log file indicates that

the operation has failed.

Requested mac address change to new MAC address on port VM NIC port number, disallowed by

vswitch policy.

where

nnew MAC address is the MAC address in the guest operation system.

nVM NIC port number is the port number of the VM network adapter in hexadecimal format.

Cause

The default security policy on the port group to which the passthrough network adapter is connected does

not allow changes in the MAC address in the guest operating system. As a result, the networking interface

in the guest operating system cannot acquire an IP address and loses connectivity.

vSphere Troubleshooting

88 VMware, Inc.

Solution

uIn the guest operating system, reset the interface to cause the passthrough network adapter to regain its

valid MAC address. If the interface is configured to use DHCP for address assignment, the interface

acquires an IP address automatically.

For example, on a Linux virtual machine run the ifconfig console command.

ifconfig ethX down

ifconfig ethX up

where X in ethX represents the sequence number of the virtual machine network adapter in the guest

operating system.

A Virtual Machine that Runs a VPN Client Causes Denial of Service for

Virtual Machines on the Host or Across a vSphere HA Cluster

A virtual machine sending Bridge Protocol Data Unit (BPDU) frames, for example, a VPN client, causes

some virtual machines connected to the same port group to lose connectivity. The transmission of BPDU

frames might also break the connection of the host or of the parent vSphere HA cluster.

Problem

A virtual machine that is expected to send BPDU frames causes the traffic to the external network of the

virtual machines in the same port group to be blocked.

If the virtual machine runs on a host that is a part of a vSphere HA cluster, and the host becomes network-

isolated under certain conditions, you observe Denial of Service (DoS) on the hosts in the cluster.

Cause

As a best practice, a physical switch port that is connected to an ESXi host has the Port Fast and BPDU guard

enabled to enforce the boundary of the Spanning Tree Protocol (STP). A standard or distributed switch does

not support STP, and it does not send any BPDU frames to the switch port. However, if any BPDU frame

from a compromised virtual machine arrives at a physical switch port facing an ESXi host , the BPDU guard

feature disables the port to stop the frames from affecting the Spanning Tree Topology of the network.

In certain cases a virtual machine is expected to send BPDU frames, for example, when deploying VPN that

is connected through a Windows bridge device or through a bridge function. If the physical switch port

paired with the physical adapter that handles the traffic from this virtual machine has the BPDU guard on,

the port is error-disabled, and the virtual machines and VMkernel adapters using the host physical adapter

cannot communicate with the external network anymore.

If the teaming and failover policy of the port group contains more active uplinks, the BPDU traffic is moved

to the adapter for the next active uplink. The new physical switch port becomes disabled, and more

workloads become unable to exchange packets with the network. Eventually, almost all entities on the ESXi

host might become unreachable.

If the virtual machine runs on a host that is a part of a vSphere HA cluster, and the host becomes network-

isolated because most of the physical switch ports connected to it are disabled, the active master host in the

cluster moves the BPDU sender virtual machine to another host. The virtual machine starts disabling the

physical switch ports connected to the new host. The migration across the vSphere HA cluster eventually

leads to accumulated DoS across the entire cluster.

Chapter 8 Troubleshooting Networking

VMware, Inc. 89

Solution

nIf the VPN software must continue its work on the virtual machine, allow the traffic out of the virtual

machine and configure the physical switch port individually to pass the BPDU frames.

Network Device Configuration

Distributed or

standard switch

Set the Forged Transmit security property on the port group to Accept to allow BPDU frames to

leave the host and reach the physical switch port.

You can isolate the settings and the physical adapter for the VPN traffic by placing the virtual

machine in a separate port group and assigning the physical adapter to the group.

CAUTION Setting the Forged Transmit security property to Accept to enable a host to send BPDU

frames carries a security risk because a compromised virtual machine can perform spoofing

attacks.

Physical switch nKeep the Port Fast enabled.

nEnable the BPDU filter on the individual port. When a BPDU frame arrives at the port, it is

filtered out.

NOTE Do not enable the BPDU filter globally. If the BPDU filter is enabled globally, the Port Fast

mode becomes disabled and all physical switch ports perform the full set of STP functions.

nTo deploy a bridge device between two virtual machine NICs connected to the same Layer 2 network,

allow the BPDU traffic out of the virtual machines and deactivate Port Fast and BPDU loop prevention

features.

Network Device Configuration

Distributed or

standard switch

Set the Forged Transmit property of the security policy on the port groups to Accept to allow

BPDU frames to leave the host and reach the physical switch port.

You can isolate the settings and one or more physical adapters for the bridge traffic by placing

the virtual machine in a separate port group and assigning the physical adapters to the group.

CAUTION Setting the Forged Transmit security property to Accept to enable bridge deployment

carries a security risk because a compromised virtual machine can perform spoofing attacks.

Physical switch nDisable Port Fast on the ports to the virtual bridge device to run STP on them.

nDisable BPDU guard and filter on the ports facing the bridge device.

nProtect the environment from DoS attacks in any case by activating the BPDU filter on the ESXi host or

on the physical switch.

nOn a host running ESXi 4.1 Update 3, ESXi 5.0 Patch 04 and later 5.0 releases, and ESXi 5.1 Patch 01

and later, enable the Guest BPDU filter in one of the following ways and reboot the host:

nIn the Advanced System Settings table on the Manage tab for the host in the

vSphere Web Client, set the Net.BlockGuestBPDU property to 1.

nIn an ESXi Shell to the host, type the following vCLI command:

esxcli system settings advanced set -o /Net/BlockGuestBPDU -i 1

nOn a host that does not have the Guest BPDU filter implemented enable the BPDU filter on the

physical switch port to the virtual bridge device.

Network Device Configuration

Distributed or

standard switch

Set the Forged Transmit property of the security policy on the port group to Reject.

Physical switch nKeep the Port Fast configuration.

nEnable the BPDU filter on the individual physical switch port. When a BPDU frame

arrives at the physical port, it is filtered out.

NOTE Do not enable the BPDU filter globally. If the BPDU filter is enabled globally, the

Port Fast mode becomes disabled and all physical switch ports perform the full set of

STP functions.

vSphere Troubleshooting

90 VMware, Inc.

Low Throughput for UDP Workloads on Windows Virtual Machines

When a Windows virtual machine in vSphere 5.1 and later transmits large UDP packets, the throughput is

lower than expected or is oscillating even when other traffic is negligible.

Problem

When a Windows virtual machine transmits UDP packets larger than 1024 bytes, you experience lower than

expected or oscillating throughput even when other traffic is negligible. In case of a video streaming server,

video playback pauses.

Cause

For every UDP packet larger than 1024 bytes, the Windows network stack waits for a transmit completion

interrupt before sending the next packet. Unlike for earlier releases, vSphere 5.1 and later releases do not

provide a transparent workaround of the situation.

Solution

nIncrease the threshold in bytes at which Windows changes its behavior for UDP packets by modifying

the registry of the Windows guest OS.

a Locate the HKLM\System\CurrentControlSet\Services\Afd\Parameters registry key.

b Add a value with the name FastSendDatagramThreshold of type DWORD equal to 1500.

For information about fixing this issue in the Windows registry, see

http://support.microsoft.com/kb/235257.

nModify the coalescing settings of the virtual machine NIC.

If the Windows virtual machine has a VMXNET3 vNIC adapter, configure one of the following

parameters in the .vmx file of the virtual machine. Use the vSphere Web Client, or directly modify

the .vmx file.

Action Parameter Value

Increase the interrupt rate of the virtual machine to a higher rate than

expected packet rate. For example, if the expected packet rate is 15000

interrupts per second, set the interrupt rate to 16000 interrupts per

second. Set the ethernetX.coalescingScheme parameter to rbc and

the ethernetX.coalescingParams parameter to 16000. The default

interrupt rate is 4000 interrupts per second.

ethernetX.coalescingScheme

ethernetX.coalescingParams

rbc

16000

Disable coalescing for low throughput or latency-sensitive workloads.

For information about configuring low-latency workloads, see Best

Practices for Performance Tuning of Latency-Sensitive Workloads in

vSphere VMs.

ethernetX.coalescingScheme disabled

Revert to the coalescing algorithm from earlier ESXi releases.

NOTE The ability to revert to the earlier algorithm will not be

available in later vSphere releases.

ethernetX.coalescingScheme calibrate

X next to ethernet stands for the sequence number of the vNIC in the virtual machine.

For more information about configuring parameters in the .vmx file, see the vSphere Virtual Machine

Administrationdocumentation.

nModify ESXi host coalescing settings.

This approach affects all virtual machines and all virtual machine NICs on the host.

You can edit the advanced system settings list for the host in the vSphere Web Client, or by using a

vCLI console command on the host from the ESXi Shell.

Chapter 8 Troubleshooting Networking

VMware, Inc. 91

Action

Parameter in the

vSphere Web Client

Parameter for the esxcli

system settings sdvanced

set Command Value

Set a default interrupt rate higher

than the expected packet rate. For

example, set the interrupt rate to

16000 if 15000 interrupts are expected

per second.

Net.CoalesceScheme

Net.CoalesceParams

/Net/CoalesceScheme

/Net/CoalesceParams

rbc

16000

Disable coalescing for low

throughput or latency-sensitive

workloads. For information about

configuring low-latency workloads,

see Best Practices for Performance

Tuning of Latency-Sensitive

Workloads in vSphere VMs.

Net.CoalesceDefaultOn /Net/CoalesceDefaultOn 0

Revert to the coalescing scheme from

earlier ESXi releases.

NOTE The ability to revert to the

earlier algorithm will not be available

in later vSphere releases.

Net.CoalesceScheme /Net/CoalesceScheme calibrate

For information about configuring a host from the vSphere Web Client, see the vCenter Server and Host

Management documentation. For information about setting host properties by using a vCLI command,

refer to the vSphere Command-Line Interface Reference documentation.

Virtual Machines on the Same Distributed Port Group and on Different

Hosts Cannot Communicate with Each Other

Under certain conditions, the virtual machines that are on the same distributed port group but on different

hosts cannot communicate with each other.

Problem

Virtual machines that reside on different hosts and on the same port group are unable to communicate.

Pings from one virtual machine to another have no effect. You cannot migrate the virtual machines between

the hosts by using vMotion.

Cause

nThere are no physical NICs on some of the hosts assigned to active or standby uplinks in the teaming

and failover order of the distributed port group.

nThe physical NICs on the hosts that are assigned to the active or standby uplinks reside in different

VLANs on the physical switch. The physical NICs in different VLANs cannot see each other and thus

cannot communicate with each other.

Solution

nIn the topology of the distributed switch, check which host does not have physical NICs assigned to an

active or standby uplink on the distributed port group. Assign at least one physical NIC on that host to

an active uplink on the port group.

nIn the topology of the distributed switch, check the VLAN IDs of the physical NICs that are assigned to

the active uplinks on the distributed port group. On all hosts, assign physical NICs that are from the

same VLAN to an active uplink on the distributed port group.

vSphere Troubleshooting

92 VMware, Inc.

Attempt to Power On a Migrated vApp Fails Because the Associated

Protocol Profile Is Missing

You cannot power on a vApp or virtual machine that you transferred to a data center or a vCenter Server

system because a network protocol profile is missing.

Problem

After you cold migrate a vApp or a virtual machine to another data center or vCenter Server system, an

attempt to power it on fails. An error message states that a property cannot be initialized or allocated

because the network of the vApp or virtual machine does not have an associated network protocol profile.

Cannot initialize property 'property'. Network 'port group' has no associated network protocol

profile.

Cannot allocate IP address for property 'property'. Network 'port group' has no associated

network protocol profile.

Cause

By using the OVF environment, the vApp or virtual machine retrieves network settings from a network

protocol profile that is associated with the port group of the vApp or virtual machine.

vCenter Server creates such a network protocol profile for you when you install the OVF of a vApp and

associates the profile with the port group that you specify during the installation.

The mapping between the protocol profile and port group is valid only in the scope of a data center. When

you move the vApp, the protocol profile is not transferred to the target data center because of the following

reasons:

nThe network settings of the protocol profile might not be valid in the network environment of the target

data center.

nA port group that has the same name and is associated with another protocol profile might already exist

in the target data center, and vApps and virtual machines might be connected to this group. Replacing

the protocol profiles for the port group might affect the connectivity of these vApp and virtual

machines.

Solution

nCreate a network protocol profile on the target data center or vCenter Server system with the required

network settings and associate the protocol profile with the port group to which the vApp or virtual

machine is connected. For example, this approach is suitable if the vApp or virtual machine is a

vCenter Server extension that uses the vCenter Extension vService.

For information about providing network settings to a vApp or virtual machine from a network

protocol profile, see the vSphere Networking documentation.

nUse the vSphere Web Client to export the OVF file of the vApp or virtual machine from the source data

center or vCenter Server system and deploy it on the target data center or vCenter Server system.

When you use the vSphere Web Client to deploy the OVF file, the target vCenter Server system creates

the network protocol profile for the vApp.

For information about managing OVF files in the vSphere Web Client, see the vSphere Virtual Machine

Administration documentation.

Chapter 8 Troubleshooting Networking

VMware, Inc. 93

Networking Configuration Operation Is Rolled Back and a Host Is

Disconnected from vCenter Server

When you attempt to add or configure networking on a vSphere Distributed Switch on a host, the operation

is rolled back and the host is disconnected from vCenter Server.

Problem

In vSphere 5.1 or later, an attempt to perform a networking configuration operation on a vSphere

Distributed Switch on a host, such as creating a virtual machine adapter or a port group, causes the host to

disconnect from vCenter Server and results in the error message Transaction has rolled back on the

host.

Cause

Under stressful conditions on a host, that is, if many concurrent networking operations compete for limited

resources, the time to perform some of the operations might exceed the default timeout for rollback of

network configuration operations on the distributed switch. As a result, these operations are rolled back.

For example, such a condition might come up when you create a VMkernel adapter on a host that has a very

high number of switch ports or virtual adapters, all of which consume system resources on the host.

The default timeout to roll an operation back is 30 seconds.

Solution

nUse the vSphere Web Client to increase the timeout for rollback on vCenter Server.

If you encounter the same problem again, increase the rollback timeout with 60 seconds incrementally

until the operation has enough time to succeed.

a On the Manage tab of a vCenter Server instance, click Settings.

b Select Advanced Settings and click Edit.

c If the property is not present, add the config.vpxd.network.rollbackTimeout parameter to the

settings.

d Type a new value, in seconds, for the config.vpxd.network.rollbackTimeout parameter

e Click OK.

f Restart the vCenter Server system to apply the changes.

nIncrease the timeout for rollback by editing the vpxd.cfg configuration file.

If you encounter the same problem again, increase the rollback timeout with 60 seconds incrementally

until the operation has enough time to succeed.

a On a vCenter Server instance, navigate to the directory that contains the vpxd.cfg configuration

file.

nOn a Windows Server operating system, navigate to vCenter Server home

directory\Application Data\VMware\VMware VirtualCenter.

nOn the vCenter Server Appliance, navigate to /etc/vmware-vpx.

b Open the vpxd.cfg file for editing.

vSphere Troubleshooting

94 VMware, Inc.

c Under the <network> section, increase the timeout, in the <rollbackTimeout> element.

<config>

<vpxd>

<network>

<rollbackTimeout>60</rollbackTimeout>

</network>

</vpxd>

</config>

d Save and close the file.

e Restart the vCenter Server system to apply the changes.

Chapter 8 Troubleshooting Networking

VMware, Inc. 95

vSphere Troubleshooting

96 VMware, Inc.

Troubleshooting Licensing 9

The troubleshooting licensing topics provide solutions to problems that you might encounter as a result of

an incorrect or incompatible license setup in vSphere.

This chapter includes the following topics:

n“Troubleshooting Host Licensing,” on page 97

n“Unable to Power On a Virtual Machine,” on page 98

n“Unable to Configure or Use a Feature,” on page 98

Troubleshooting Host Licensing

You might encounter different problems that result from an incompatible or incorrect license configuration

of ESXi hosts.

Unable to Assign a License to an ESXi Host

Under certain conditions, you might be unable to assign a license to an ESXi host.

Problem

You try to assign a license to an ESXi host, but you cannot perform the operation and you receive an error

message.

Cause

You might be unable to assign a license to an ESXi host because of the following reasons:

nThe calculated license usage for the host exceeds the license capacity. For example, you have a vSphere

license key with capacity for two CPUs. You try to assign the key to a host that has four CPUs. You

cannot assign the license, because the required license usage for the host is greater than the license

capacity.

nThe features on the host do not match the license edition. For example, you might configure hosts with

vSphere Distributed Switch and vSphere DRS while in evaluation mode. Later, you try to assign

vSphere Standard license o the hosts. This operation fails because the vSphere Standard edition does

not include vSphere Distributed Switch and vSphere DRS.

nThe host is connected to a vCenter Server system that is assigned a license that restricts the edition of

the license that you want to assign.

Solution

nAssign a license with larger capacity.

VMware, Inc. 97

nUpgrade the license edition to match the resources and features on the host, or disable the features and

resources that do not match the license edition.

nAssign a vSphere license whose edition is compatible with the license edition of vCenter Server.

ESXi Host Disconnects from vCenter Server

An ESXi host might disconnect from vCenter Server or all ESXi hosts might disconnect from vCenter Server

at the same time.

Problem

nAn ESXi host disconnects fromvCenter Server or all ESXi hosts disconnect from vCenter Server and you

receive a licensing-related error message.

nYou cannot add hosts to the vCenter Server inventory. The hosts and the virtual machines on the hosts

continue to run.

Cause

nThe 60-day evaluation period of the host has expired or the host license has expired.

nThe 60-day evaluation period of vCenter Server is expired or the vCenter Server license is expired.

Solution

nAssign a vSphere license to the ESXi host and try to reconnect it to vCenter Server.

nAssign a vCenter Server license to thevCenter Serversystem.

Unable to Power On a Virtual Machine

You try to power on a virtual machine, but the operation is unsuccessful and you receive an error message.

Problem

You cannot power on a virtual machine on an ESXi host.

Cause

You might be unable to power on a virtual machine because of the following reasons.

nThe 60-day evaluation period of the host is expired.

nThe license of the host is expired.

Solution

Table 9‑1. Power on a Virtual Machine

Cause Solution

The evaluation period of the host is expired. Assign a vSphere license to the ESXi host.

The license of the host is expired.

Unable to Configure or Use a Feature

You cannot use a feature or change its configuration.

Problem

You cannot use or configure a feature and a licensing-related error message appears.

vSphere Troubleshooting

98 VMware, Inc.

Cause

The host or the vCenter Server system is assigned a license that does not support the features that you want

to configure.

Solution

Check the licensed features on the host and on the vCenter Server system. Upgrade the edition of the license

assigned to the host or vCenter Server if they do not include the features that you try to configure or use.

Chapter 9 Troubleshooting Licensing

VMware, Inc. 99

vSphere Troubleshooting

100 VMware, Inc.

Index

A

access to the FT metadata datastore, losing 15

Active Directory 33

address already in use, Jetty server 39

advanced settings,

Disk.SchedNumReqOutstanding 65

Advanced Runtime Info 45

alarm definitions 39

All Paths Down (APD) 50

authentication 61

Auto Deploy

coredump 29

DHCP address 31

failing to complete boot 29

failure to boot 30

image profile warning 28

network boot problem 32

redirection problem 28

TFTP server 30

timout error 27

troubleshooting 27

wrong image 28

auto-partitioning, prevent flash disk

formatting 71

C

cannot apply Storage DRS recommendations,

troubleshooting 56

cannot enable Storage I/O Control 57

certificates

hosts 40

vCenter Server 40

CHAP authentication 61

common logs 11

compliance failure, host profiles 33

config.vpxd.das.electionWaitTimeSec 27

converting to the enhanced LACP fails 81

custom reverse proxy 33

D

datastore clusters, maintenance mode 52

datastore heartbeating 45

datastores

maintenance mode 52

performance charts troubleshooting 57

Denial of Service

virtual machine, VPN 89

See also DoS

Disk.SchedNumReqOutstanding 65

distributed switch

cannot remove host 82

physical network adapter 87

distributed port group, virtual machines cannot

communicate 92

downloading VIBs, using custom vCenter Server

reverse proxy 33

DRS does not place FT VM 16

E

Enhanced vMotion Compatibility 16

ESXi logs 11

EVC 16

extensions, troubleshooting 41

F

failed conversion to the enhanced LACP 81

failover, lost virtual machine connectivity 86

failure of vSphere Fault Tolerance for powered-

on VM 16

Fault Tolerance

logging 17

troubleshooting 13, 14

Feature 98

flash devices, marking 72

flash drives 70

flash disk formatting, prevent during auto-

partitioning 71

flash player, insufficient memory 39

H

Hardware Virtualization (HV) 13, 14

HBAs, queue depth 64

host profiles, compliance failure 33

host certificates 40

Host Failures Cluster Tolerates admission

control policy 43–45

host isolation response 26

hosts, no connection with vCenter Server 83, 84

hosts overloaded with FT VMs 15

VMware, Inc. 101

I

I/O filters

installation failures 75

installing 76

troubleshooting 75

iBFT 66

identifying symptoms, troubleshooting 9

imbalanced placement of FT VMs 15

IPv4 26

IPv6 26

J

Jetty server, address already in use 39

L

license capacity 98

License capacity 97

License edition 97, 98

license key 98

local flash disks, undetectable 71

local flash disks are unavailable 70

logging 11

losing access to the FT metadata datastore 15

loss of uplink redundancy 85

lost virtual machine connectivity, failover 86

low throughput, Windows virtual machine 91

LUN not visible, SP visibility 60, 61

LUN queue depth 63

LUN thrashing 63

M

maintenance mode, datastores 52

management node logs 11

marking, flash devices 72

maximum HBA queue depth 64

metadata consistency, checking with VOMA 68

monitoring, Storage I/O Control 56, 57

N

Network I/O Control, physical network adapter,

failing to add 87

network latency for FT VMs 15

network partition 45, 46, 48

network protocol profiles, powering on a vApp or

virtual machine fails 93

networking

host disconnected 94

transaction rolled backed 94

NFS datastores 67

no uplink redundancy 85

non-ASCII characters 67

O

orphaned virtual machines, recovering 19

outstanding disk requests 65

overcommitted host 14

P

password requirements 32

path thrashing 63

Percentage of Cluster Resources Reserved

admission control policy 44

performance, problems 61

performance charts for datastores,

troubleshooting viewing performance

charts 57

Permanent Device Loss (PDL) 50

Platform Services Controller logs 11

plug-ins, troubleshooting 41

prevent flash disk formatting during auto-

partitioning 71

Primary VM 48, 49

problem space, troubleshooting 10

problems

performance 61

visibility 60, 61

Q

queue depth 64, 65

R

recommendations for Storage DRS,

troubleshooting 56

Red Cluster 43

remove datastore 46

reverse proxy, custom 33

S

SCSI INQUIRY 66

SCSI reservations, reducing 62

SCSI Sense codes 67

Secondary VM 48, 49

Single Root I/O Virtualization, See SR-IOV

slot size 43–45

software iSCSI adapters, queue depth 65

SP visibility, LUN not visible 60, 61

SQL compatibility mode 38

SR-IOV

MAC address, lost connectivity 88

out of interrupt vectors 87

virtual machines, troubleshooting 87

virtual machine, lost connectivity 88

SR-IOV, virtual machine is powered off 87

SSDs 70

SSL certificates, troubleshooting in vSphere

HA 41

storage adapters, troubleshooting 68

storage devices, display problems 60

vSphere Troubleshooting

102 VMware, Inc.

storage devices, marking as local 72

Storage DRS

affinity rules 55

cannot apply recommendations 56

deleting affinity rules 55

disabled 51

disabling 54

faults 55

OVF templates 54

placement 55

recommendations 55

rule violation 55

troubleshooting 51

Storage I/O Control

monitoring 56, 57

troubleshooting 56, 57

swapfile 49

T

testing solutions 10

TFTP server, Auto Deploy 30

timeout error, Auto Deploy 27

Tomcat service, vCenter Server upgrade

failure 37

troubleshooting

certificates 40

extensions 41

plug-ins 41

USB devices 18

vCenter Server 37

vSphere Web Client 37, 38

VVols datastore 73

troubleshooting guidelines 9

troubleshooting licensing 97

troubleshooting overview 9

troubleshooting problem space 10

troubleshooting Fault Tolerance 13

Troubleshooting host licensing 97

Troubleshooting Hosts 23

troubleshooting storage 59

troubleshooting Virtual Volumes

OVF deployment failures 74

VM migration failures 74

Troubleshooting Virtual Machines 13

U

unmount datastore 46

updated information 7

uplink redundancy lost 85

USB devices, error messages 18

USB passthrough

restarting the USB arbitrator 19

troubleshooting 18

troubleshooting device connections 19

V

VAIO filters, troubleshooting 75

vCenter Server

custom reverse proxy 33

no connection with hosts 83, 84

troubleshooting 37

troubleshooting certificates 40

vCenter Server certificates 40

vCenter Server license 98

vCenter Server system does not appear 38

vCenter Server upgrade fails, Tomcat service 37

VDS, cannot remove host 82

VIB download failure 33

Virtual Volumes

troubleshooting 73

VM migration failures 74

virtual datastore, troubleshooting 73

virtual datastores

OVF deployment failures 74

VM migration failures 74

virtual flash, local flash disks unavailable 70

virtual machine

BPDU 89

bridge 89

Denial of Service 89

duplicate MAC addresses 78

low throughput 91

MAC address 78

MAC address conflict 78

MAC address, out of range 80

SR-IOV, lost connectivity 88

UDP 91

VPN 89

Windows 91

virtual machine console does not launch,

vSphere Web Client 39

virtual machine is powered off, SR-IOV 87

Virtual Machine Protection State 47

virtual machines, SR-IOV, troubleshooting 87

virtual machines, orphaned 19

Virtual SAN 26, 45, 47

visibility problems 60, 61

VM Component Protection 49, 50

VM-Host affinity rules 47

VMCP 49

VMFS, checking metadata consistency 68

VMware On-disk Metadata Analyser, See VOMA

VOMA 68

Index

VMware, Inc. 103

vSphere distributed switch

hosts not responding 83, 84

lost virtual machine connectivity 86

vSphere license 98

vSphere DRS 47

vSphere Fault Tolerance 48, 49

vSphere HA

Denial of Service 89

troubleshooting SSL certificates 41

vSphere HA admission control 43

vSphere HA Admission Control 43

vSphere HA agent 23–26

vSphere HA cluster 48

vSphere HA failovers 46

vSphere HA host state

Agent Uninitialized 24

Agent Unreachable 23

Host Failed 25

Initialization Error 24

Network Isolated 26

Network Partitioned 26

Uninitialization Error 25

vSphere HA restart failures 47

vSphere Web Client

troubleshooting 37, 38

virtual machine console does not launch 39

VVols 74

VVols datastores 74

VVols functionality, and esxcli commands 73

W

webclient.properties file 39

vSphere Troubleshooting

104 VMware, Inc.
