USERS MANUAL
![](/img.php?id=779486&img=bg1.png)
1.
WHERE ARE YOU?
2. CALL ME AS SOON AS POSSIBLE.
3. HEY, WHAT IS YOUR PLAN?
4. WHAT ARE YOU DOING?
5. LETS PLAY WITH WALKIE TALKIES.
6. HOW ARE YOU?
7. TOYS ARE FUN.
8. CAN YOU PLAY?
9. KIDS, ARE YOU THERE?
10. OVER AND OUT.
*
#
ITEM NO. 10663
GETTING STARTED
1. Pull TAB and slid off belt clip before remove screw and open battery door.
2. According the correct polarities as shown, insert 4 AA batteries (Alkaline batteries recommend) into each unit and
secure battery cover.
3. Press and hold key for 3 seconds to turn each unit on.
4. LCD screen displays all icons for 2 seconds then goes to time 00:00
5. Use Volume Control Knob on side to adjust volume level
6. When transitting, speak clearly in a normal voice, holding the set about 3 inch from your mouth.
7. Best transmission and reception are obtained when the antenna is hold in a vertical position.
8. Item will now function as a walkie talkie. Press "PUSH TO TALK" button and starting to talk after finish hearing
the TX signal. Push to talk, listen to receive.
9. If left idle for 3 minutes the screen will displays the word “IDLE”
10. Push any key to go back to time on screen.
SETTING RING TONE
1. Press key then use and to select “TONE” from menu and press .
2. Use and to select from 4 ring tones and press “ENTER” for the one you choose.
SENDING PRE SET TEXT MESSAGES
1. Press key then use and to select “MESSAGE” and press .
2. Select “TEMP” then press again.
3. Choose your pre set message from the list and punch in the number or sign.
4. Press , select from channels 1 through 4 and press again to send.
WRITING YOUR OWN TEXT MESSAGES
1. Press key then use and to select “MESSAGE” and press .
2. Select “WRITE” and press again.
3. Press the number key of the letter you want once for the first letter, twice for the second letter, or three times
for the third letter on the number.
4. When the cursor appears after the letter you choose, enter the next letter or sign in your message up to 36
characters.
5. Press to delete the unwanted number(s)/or letter(s).
6. Press to move cursor forward and backward.
7. Press , select from channels 1 through 4 and press “ENTER” again to send.
![](/img.php?id=779486&img=bg2.png)
Number/Letter keypad
Power ON/OFF &
Selection Button
Back / Delete
Button
Call Button
Antenna
Volume Control
Hand Strip
LCD Screen
Catching tab
Belt Clip
Speaker / Microphone
"Push To Talk"
Button
OPEN
CLOSE
Each unit uses 4 x AA/UM3
(1.5V) Batteries (Not
Included)
RECEIVING NEW TEXT MESSAGES
1. Unit will beep when new messages are received.
2. After reading your message press to select “REPLY” or “DELETE”.
3. Messages will be automatically saved after 10 seconds if you do not use the key.
READING SAVED TEXT MESSAGES
1. Press key then use and to select “MESSAGE” and press .
2. Use and to Select “READ” and press .
3. Use and to select inbox 1 through 4 and press .
4. Each inbox holds up to 4 messages of 36 characters long/each message.
5. Messages are replaced by the last message received after the inbox is filled
6. When you have read your messages you may store them in the inboxes or press to using and
to select “REPLY” or “DELETE”
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT, SUCH MODIFICATIONS
COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
