Anker Innovations R5113 Roav Smart Car Charger F0 User Manual
Anker Innovations Limited Roav Smart Car Charger F0
User Manual
![](/img.php?id=3875790&img=bg1.png)
Model: R5113
51005000977 V01
Roav Smart Car Charger F0
Owner’s Manual
Safety
Instructions
SAVE THESE INSTRUCTIONS – This manual contains important
safety and operating instructions for the car charger (Model
R5113).
Please read and understand all instructions before using this
product. If damage is caused by failure to follow the instructions,
the warranty does not apply.
• Read all instructions and cautionary markings before using
this product.
• Do not expose to rain, moisture, or snow.
• Use of an attachment is not recommended or sold by the
manufacturer may result in a risk of fire, electric shock, or
injury to persons.
• Do not operate this car charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way; take it to a
qualified service person.
• Do not disassemble this car charger; take it to a qualified
service person when service or repair is required. Incorrect
reassembly may result in a risk of electric shock or fire.
• To reduce risk of electric shock, unplug this car charger before
attempting any maintenance or cleaning. Turning o controls
will not reduce this risk.
• To reduce risk of fire or electric shock, do not interconnect
output terminations.
• Avoid long exposure to direct sunlight, which may cause
damage to the device.
• Exposing this product to open flames may cause it to explode.
• Do not use this product in strong magnetic fields.
• Use a dry, soft lint-free cloth to clean. Do not use any
corrosive cleaner or oil to clean.
• CAUTION - For continued protection against risk of fire,
replace only with the same type and ratings of fuse, fuse
rating is 32V DC / 5A.
• Always obey trac laws and pay attention to the road. Do
not attempt to use this device while driving, as some features
are limited while the vehicle is in motion. Failure to pay full
attention to the operation of your vehicle could result in
death, serious injury or property damage. You assume total
responsibility and risk for using this device.
Consignes de sécurité importantes
CONSERVEZ CES CONSIGNES - Ce manuel contient
d'importantes instructions de sécurité et d'utilisation relatives au
chargeur de voiture modèle R5113.
Veuillez lire et comprendre toutes les instructions avant d'utiliser
ce produit. Si le non-respect des instructions entraîne des
dommages, la garantie ne s'appliquera pas.
• Lisez toutes les instructions et les mises en garde avant
d'utiliser ce produit.
• Ne pas exposer à la pluie, l'humidité ou la neige.
• L'utilisation d'un accessoire non recommandé ou vendu
par le fabricant peut entraîner un risque d'incendie, de choc
électrique ou de blessure.
• Ne pas utiliser ce chargeur de voiture s'il a reçu un coup
violent, s'il est tombé ou s'il a été endommagé de quelque
façon que ce soit ; l’apporter à un technicien qualifié.
• Ne pas démonter ce chargeur de voiture ; l’apporter à un
technicien qualifié lorsqu’une réparation est nécessaire.
Un réassemblage incorrect peut entraîner un risque
d'électrocution ou d'incendie.
• Pour réduire les risques d'électrocution, débrancher le
chargeur de voiture avant d'eectuer toute opération
d'entretien ou de nettoyage. La désactivation des commandes
ne réduit pas ce risque.
• Pour réduire les risques d'incendie ou d'électrocution, ne pas
interconnecter les terminaisons de sortie.
• Éviter toute exposition prolongée à la lumière directe du soleil,
qui pourrait endommager l'appareil.
• L'exposition de ce produit à des flammes nues peut provoquer
son explosion.
• Ne pas utiliser ce produit dans des champs magnétiques
puissants.
• Utiliser un chion sec, doux et non pelucheux pour le
nettoyage. Ne pas utiliser de nettoyant corrosif ni d'huile.
• ATTENTION - Pour une protection continue contre les risques
d'incendie, ne remplacer le fusible que par un fusible de même
type et de même spécification. Le fusible utilisé est de 32V
DC / 5A.
• Keep these instructions.
• Do not drop, puncture or disassemble this product.
• This product shall not be exposed to dripping or splashing.
• Avoid long exposure to direct sunlight, which may cause
damage.
• Exposing this product to open flames may cause explosion.
• Do not use the product in strong magnetic field.
• Use clean, soft cloth to clean. Do not use any corrosive
cleaner/oil to clean.
• Keep your attention on the road. Do not operate the controls
of this product while driving.
1 2 3 4 5
Introduction
Features
• Hands-free call
• Streaming music to a car stereo via FM transmission or the
AUX-Out socket
• Charging via Two USB charging ports
• Anker PowerIQ technology for faster device charging
What’s Included
Owner’s Manual
Roav Smart Car Charger F0
Manual
Roav Smart Car
Charger F0
At a Glance
USB charging port Microphone
LED display
LED indicators Status
/ FM frequency flashes
alternately
No Bluetooth connection detected
FM frequency is displayed Bluetooth connected
FM frequency flashes
Enter FM mode
Incoming call
In a call in hands-free mode
In a call through smartphone
/
Multifunction button
AUX-Out socket
/ Car charger adapter
Press and hold for 3 seconds to power on/o.
6
![](/img.php?id=3875790&img=bg2.png)
Roav F0_XXXX
Turn on the FM radio on your car audio deck and tune to
an unoccupied frequency (you should hear white noise).
Press and hold the multifunction button on car charger until
the FM frequency flashes. Press or hold / until the
transmitting frequency matches the frequency your car
stereo is tuned to.
FM
Play Music
When the car charger is successfully connected with your
smartphone, you can play music from your phone. Music
can then be streamed to your car's audio system via FM
transmitter or Aux-Out socket.
Roav F0_XXXX
FM
AUX OUT AUX IN
Play / Pause Press
Previous / Next track Press /
To further reduce echo and cabin noise on your
calls and
music , you can connect a 3.5 mm AUX cable (not provided) to
the AUX-Out socket of the Roav smart car charger and the AUX-
In socket of your car's audio system.
FM AUX IN
Make Hands-
Free Calls
When the car charger is successfully connected with your smartphone,
you can enjoy convenient hands-free call.
Answer / End a call Press
Reject a call Press and hold for 1 second
Charge Your
Devices
The car charger is equipped with two USB charging
ports. You can charge two devices simultaneously
with a maximum output of 5V/4.8A.
T
2.4A 2.4A
Specifications
Specifications are subject to change without notice.
DC input: 12V - 24V
Power output: 5V 4.8A max
Bluetooth: V4.2
Bluetooth transmission distance: 10 m / 393.7 in
FM frequency range: 87.5-108 MHz
FM transmission range: 2 m / 78.7 in
Operating temperature range: -20°C to 40°C / -4°F to 104°F
Storage temperature range: -40°C to 85°C / -40°F to 185°F
Notice
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Warning:
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
Note:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates uses and can radiate radio
frequency
energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radi
o communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures: (1) Reorient or
relocate the receiving antenna. (2) Increase the separation
8 9 10 117
Get Started
Plug Roav smart car charger F0 into your vehicle’s cigarette
lighter socket.
Start your vehicle’s engine and the LED display will light up.
/ FM frequency will flash alternatively. Once you have
completed step , you should hear a “waiting to pair”
voice prompt.
Enable Bluetooth on your smartphone and search for available
Bluetooth devices. Select “Roav F0_XXXX” and connect.
Once successfully connected, FM frequency will be displayed.
Once you have completed step
, you should hear a
“successfully paired” voice prompt.
12 13 14
between the equipment and receiver. (3) Connect the equipment
into an outlet on a circuit different from that to which the receiver
is connected. (4) Consult the dealer or an experienced radio/TV
technician for help.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure
requirements. The device can be used in fixed/mobile exposure
condition. The min separation distance is 20cm.
Customer
Service
12-month limited warranty
Lifetime technical support
support@goroav.com
+1(800) 988 7973 (US) Mon-Fri 9:00-17:00 (PT)
@GoRoav @GoRoav
